Hamilton Beach 31605N User Guide

READ BEFORE USE LIRE AVANT UTILISATION LEA ANTES DE USAR

Visit www.hamiltonbeach.com for our complete line of products and Use and Care Guides – as well as delicious recipes, tips, and to register your product online.

Rendez-vous sur www.hamiltonbeach.ca pour notre liste complète de produits et de nos manuels utilisateur – ainsi que nos délicieuses recettes et nos conseils.

Visite www.hamiltonbeach.com ( o

www.hamiltonbeach.com.mx (México) para ver otros productos de Hamilton Beach o para contactarnos.

Questions Please call us – our friendly associates are ready to help. USA: 1.800.851.8900

Questions N’hésitez pas à nous appeler – nos associés s’empresseront de vous aider. CAN : 1.800.267.2826

Preguntas Por favor llámenos – nuestros amables representantes están listos para ayudar. EE. UU.: 1.800.851.8900 MEX: 01 800 71 16 100

Le invitamos a leer cuidadosamente este instructivo antes de usar su aparato.

EE. UU.)

Indoor/Outdoor Grill

Gril-santé pour

l’intérieur/extérieur

Parrilla Interior/Exterior

English ...................... 2

Français ..................... 9

Español ................... 16

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed to reduce the risk of ﬁre, electric shock, and/or injury to persons, including the following:

1. Read all instructions.

2. This appliance is not intended for use by persons (including

children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they are closely supervised and instructed concerning use of the appliance by a person responsible for their safety.

3. Close supervision is necessary when any appliance is used

by or near children. Children should be supervised to ensure that they do not play with the appliance.

4. Do not touch hot surfaces. Use handles or knobs.

5. To protect against electrical shock, do not immerse cord

assembly or plug in water or other liquid.

6. Unplug from outlet when not in use and before cleaning.

Allow to cool before putting on or taking off parts and before cleaning the appliance and before moving the appliance.

7. Always attach plug to appliance first, then plug cord into

the wall outlet. To disconnect, turn control to MIN and remove plug from wall outlet.

8. Do not leave the appliance unattended when in use.

9. Do not operate any appliance with a damaged supply

cord or plug, or after the appliance malfunctions or has been dropped or damaged in any manner. Supply cord replacement and repairs must be conducted by the

manufacturer, its service agent, or similarly qualiﬁed persons in order to avoid a hazard. number for information on examination, repair, or adjustment.

10. Do not let cord hang over edge of table or counter, or touch

hot surfaces, including the stove.

11. Do not place on or near a hot gas or electric burner, or in a

heated oven.

12. Always use the appliance on a dry level surface.

13. Do not use appliance for other than intended use.

14. Use extreme caution when moving an appliance containing

hot oil or other hot liquids.

15. Always unplug grill and then remove cord before attempting

to move the grill.

16. The use of accessory attachments not recommended by the

appliance manufacturer may cause injuries.

17. Do not use without base in place. Clean after each use.

18. Fuel, such as charcoal briquettes, is not to be used with

appliance.

19. Use only on properly grounded outlet.

20. When in operation, a fire may occur if the grill is touching or

near flammable material, including curtains, draperies, walls, backsplashes, cabinets, and the like.

Call the provided customer service

SAVE THESE INSTRUCTIONS

Other Consumer Safety Information

This appliance is intended for household use only.

w WARNING

Electrical Shock Hazard: This appliance is provided

with a grounded (3-prong) plug to reduce the risk of electric shock. The plug fits only one way into a grounded outlet. Do not defeat the safety purpose of the plug by modifying the plug in any way or by using an adapter. If the plug does not fit into the outlet, have an electrician replace the outlet.

The length of the cord used on this appliance was selected to reduce the hazards of becoming tangled in or tripping over a longer cord. If a longer cord is necessary, an approved extension cord may be used. The electrical rating of the extension cord must be equal to or greater than the rating of the appliance. The extension cord must be a grounding-type, 3-wire cord. Care must be taken to arrange the extension cord so that it will not drape over the countertop or tabletop where it can be pulled on by children or accidentally tripped over.

To avoid an electrical circuit overload, do not use another highwattage appliance on the same circuit with this appliance.

Do not leave this appliance unattended while in use.

w WARNING

Fire Hazard: To reduce risk of fire, do not allow

flammable materials such as curtains, draperies, walls, cabinets, backsplashes, and the like to touch any part of the grill or grilling surface when the grill is in operation. Place grill at least 6 inches (15.2 cm) away from walls, appliances, or any object which could be damaged by heat.

WHEN USING OUTDOORS:

w CAUTION

Electrical Shock Hazard: To ensure continued

protection against risk of electric shock, connect to properly grounded outlets only.

WHEN USING AN EXTENSION CORD OUTDOORS:

w CAUTION

Electrical Shock Hazard: To reduce the risk of

electric shock, keep extension cord connection dry and off the ground.

Outdoor extension cords should be used with outdoor use products and are surface marked with suffix letters “W-A” and with a tag stating “Suitable for Use with Outdoor Appliances.”

Store unit indoors, out of reach of children. Do not clean this product with a water spray or the like.

Parts and Features

To order parts: US: 1.800.851.8900 www.hamiltonbeach.com Canada: 1.800.267.2826 Mexico:

01 800 71 16 100

Base

Grill Plate

BEFORE FIRST USE: Wash the grill plate and base in hot, soapy water. Rinse and dry thoroughly. Do not immerse power cord in water or other liquid.

Cord Receptacle

Variable-Heat Power Cord

Variable-Heat Power Cord Always make sure the power cord

is turned to MIN and unplugged from wall outlet before inserting or removing the power cord.

How to Grill

NOTE: Adding water to the base of the grill helps to reduce smoke and a mess when grilling foods higher in fat, such as burgers, steak, or chicken with skin. Drippings fall into the water and do not get baked on for easy cleanup.

1. Set base on countertop. Add

1 cup (237 ml) water to center of

base. Place grill plate on base.

5. When finished grilling, turn

control to MIN. Remove plug

from outlet and then from cord

receptacle.

2. Plug power cord into the cord

receptacle, and then plug into outlet. The indicator light on the power cord will glow.

GRILLING TIPS:

• Please remember that your grill plate is coated with a nonstick surface and that plastic utensils should always be used.

• If grilling vegetables, fish, or lean meat, spray the grilling surface with a cooking spray. If grilling meat with any amount of fat, or if the food has been marinated, there is no need to treat the grill plate.

• For best results, preheat the grill for 5 to 10 minutes before grilling.

3. Set temperature control dial to

desired heat setting. See chart on page 6. Preheat 5 to 10 minutes before grilling or until indicator light turns off.

4. Use only utensils which are

high heat-resistant (~450°F/ 232°C) and safe for nonstick surfaces. This will help prolong the life of the nonstick coating.

• Skewers are available in most large supermarkets. If using the disposable, wooden-type skewers, soak the skewers in water at least 10 minutes before threading on food. This prevents the skewer from scorching and makes a more attractive presentation.

• If using a marinade with oil, keep water in the base during grilling to reduce mess and smoke for easy cleanup.

NOTE: The variable-heat power cord offers heat settings from “MIN” and

Cooking Chart

Visit www.foodsafety.gov for more information on safe internal cooking temperatures.

FOOD APPROXIMATE TIME DONENESS

Bacon 8 to 10 minutes Until crisp Steaks, Beef, 1/2-in. (1.3-cm) thick 6 to 14 minutes Meat thermometer registers 125°F/52°C (rare);

135°–140°F/57°–60°C (medium); 155°–160°F/ 68°–71°C (well done)

Pork Chops, 1/2-in. (1.3-cm) thick 7 to 9 minutes Meat thermometer registers 145°F/63°C Chicken Breasts (4 oz.), boneless 12 to 15 minutes Meat thermometer registers 165°F/74°C or

juices run clear Hamburgers, 1/2-in. (1.3-cm) thick 8 to 10 minutes Meat thermometer registers 145°F/63°C Sausage Links or Patties 12 to 14 minutes Meat thermometer registers 160°F/71°C or

juices run clear Hot Dogs 7 to 9 minutes Meat thermometer registers 165°F/74°C Fish Fillets 10 minutes per Opaque and flakes with fork

1-in. (2.5-cm) thickness

1 (low) to 5 (high). Setting 5 is for quick cooking of steaks, boneless chicken, hamburgers, and hot dogs. Settings 3 and 4 are for thick cuts of meat or large pieces of bone-in chicken. Start cooking at the higher setting, then reduce heat if needed. Settings 1 and 2 should be used to keep food warm after it has been cooked.

For delicious grilling recipes and more, visit www.hamiltonbeach.com/recipes.

Care and Cleaning

Grilling Guidelines

w WARNING

cleaning. Do not immerse cord or plug in water or any liquid.

1. Unplug grill from outlet and allow to cool. Carefully dispose of

any grease and any remaining water.

2. Wash the grill plate and base in hot, soapy water. Use a nylon

or plastic scouring pad and a nonabrasive liquid cleanser. Do not use metal scouring pads. Rinse and let dry.

3. DO NOT use the “SANI” setting when washing in the

dishwasher. “SANI” cycle temperatures could damage your product.

Electrical Shock Hazard. Disconnect power before

• Grilling Times: Recipe cooking times are estimates. Cooking

time will vary based on the temperature of the grill plate, the surrounding air, and the food itself. Watch food carefully while grilling and adjust the cooking time as necessary.

• Marinating Tips: Never marinate foods in metal containers for

extended lengths of time (2 or more hours). The acids in foods can react with metal, causing an unpleasant taste. Instead, use glass, ceramic, or plastic bag containers for marinating.

• Meat Safety Tip: To reduce the risk of spoiling, store meat in the

refrigerator until you’re ready to cook. Never thaw or marinate meat at room temperature, especially in warm climates.

• Food Safety Tip: Never use leftover marinade as a finishing sauce

on cooked foods. The leftover marinade must first be boiled for one to two minutes to kill any bacteria from the raw food that was marinated.

• Nonstick Grilling Tip: Without the use of oil, certain foods will

stick slightly to nonstick surfaces. This is easily prevented. Before turning on your grill, brush or spray the grill plates lightly with oil or nonstick cooking spray. (Never add oil or spray to a heated grill plate—this is dangerous.)

• Always read all safety information.

Limited Warranty

This warranty applies to products purchased and used in the U.S. and Canada. This is the only express warranty for this product and is in lieu of any other warranty or condition.

This product is warranted to be free from defects in material and workmanship for a period of ﬁve (5) years from the date of original purchase in Canada and one (1) year from the date of original purchase in the U.S. During this period, your exclusive remedy is repair or replacement of this product or any component found to be defective, at our option; however, you are responsible for all costs associated with returning the product to us and our returning a product or component under this warranty to you. If the product or component is no longer available, we will replace with a similar one of equal or greater value.

This warranty does not cover glass, ﬁlters, wear from normal use, use not in conformity with the printed directions, or damage to the product resulting from accident, alteration, abuse, or misuse. This warranty extends only to the original consumer purchaser or gift recipient. Keep the original sales receipt, as proof of purchase is required to make a warranty claim. This warranty is void if the product is used for other than single-family household use or subjected to any voltage and waveform other than as speciﬁed on the rating label (e.g., 120 V ~ 60 Hz).

We exclude all claims for special, incidental, and consequential damages caused by breach of express or implied warranty. All liability is limited to the amount of the purchase price. Every implied warranty, including any statutory warranty or condition

of merchantability or ﬁtness for a particular purpose, is disclaimed except to the extent prohibited by law, in which case such warranty or condition is limited to the duration of this written warranty. This warranty gives you speciﬁc legal rights. You may have

other legal rights that vary depending on where you live. Some states or provinces do not allow limitations on implied warranties or special, incidental, or consequential damages, so the foregoing limitations may not apply to you.

To make a warranty claim, do not return this appliance to the store. Please call 1.800.851.8900 in the U.S. or 1.800.267.2826 in Canada or visit hamiltonbeach.com in the U.S. or hamiltonbeach.ca in Canada. For faster service, locate the model, type, and series numbers on your appliance.
