READ BEFORE USE
LIRE AVANT UTILISATION
LEA ANTES DE USAR
Visit www.hamiltonbeach.com for our
complete line of products and Use and
Care Guides – as well as delicious recipes,
tips, and to register your product online!
Rendez-vous sur www.hamiltonbeach.ca
pour notre liste complète de produits et de
nos manuels utilisateur – ainsi que nos
délicieuses recettes et nos conseils !
¡Visite www.hamiltonbeach.com (
o
www.hamiltonbeach.com.mx (México)
para ver otros productos de Hamilton Beach
o para contactarnos!
EE. UU.)
Toaster Oven
Four grille-pain
Questions?
Please call us – our friendly
associates are ready to help.
USA: 1.800.851.8900
Questions ?
N’hésitez pas à nous appeler –
nos associés s’empresseront
de vous aider.
CAN : 1.800.267.2826
¿Preguntas?
Por favor llámenos – nuestros
amables representantes están
listos para ayudar.
EE. UU.: 1.800.851.8900
MEX: 01 800 71 16 100
Le invitamos a leer cuidadosamente este
instructivo antes de usar su aparato.
Horno de la
Tostadora
English ...................... 2
Français ................... 12
Español ................... 22
wWARNING
Fire Hazard.
• If contents ignite, do not open oven door. Unplug oven and allow contents to stop burning and cool before
opening door.
• Do not operate unattended while in Toast or Broil modes.
• Do not use with oven cooking bags.
• Always allow at least 1 inch (2.5 cm) between food and heating element.
• Always unplug toaster oven when not in use.
• Regular cleaning reduces risk of fire hazard.
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to
persons, including the following:
1. Read all instructions.
2. This appliance is not intended for use by persons (including
children) with reduced physical, sensory, or mental capabilities,
or lack of experience and knowledge, unless they are closely
supervised and instructed concerning use of the appliance by a
person responsible for their safety.
3. Close supervision is necessary when any appliance is used by or
near children. Children should be supervised to ensure that they
do not play with the appliance.
4. Do not touch hot surfaces. Use handles or knobs.
5. To protect against electrical shock, do not immerse cord, plug,
or toaster oven in water or other liquid.
6. Unplug from outlet when not in use and before cleaning. Allow to
cool before cleaning appliance and putting on or taking off parts.
7. Do not operate any appliance with a damaged supply cord or
plug, or after the appliance malfunctions or has been dropped
or damaged in any manner. Supply cord replacement and
repairs must be conducted by the manufacturer, its service
agent, or similarly qualified persons in order to avoid a hazard.
Call the provided customer service number for information on
examination, repair, or adjustment.
2
8. The use of accessory attachments not recommended by the
appliance manufacturer may cause injuries.
9. Do not use outdoors.
10. Do not let cord hang over edge of table or counter or touch
hot surfaces.
11. Do not place on or near a hot gas or electric burner, or in a
heated oven.
12. Extreme caution must be used when moving an appliance
containing hot oil or other hot liquids.
13. To disconnect, turn all controls to OFF (
from wall outlet.
14. Use extreme caution when removing pan or disposing of hot
grease.
15. Do not clean with metal scouring pads. Pieces can break off the
pad and touch electrical parts, creating a risk of electrical shock.
16. Oversize foods or metal utensils must not be inserted in a
toaster oven as they may create a fire or risk of electric shock.
17. A fire may occur if the toaster oven is covered, touching, or near
flammable material, including curtains, draperies, walls, and the
like, when in operation. Do not store any item on top of the
appliance when in operation or before the appliance cools down.
); then remove plug
18. Extreme caution should be exercised when using containers
constructed of materials other than metal or glass.
19. Do not store any materials, other than manufacturer- recommended
accessories, in this oven when not in use.
20. Do not place any of the following materials in the oven: paper,
cardboard, plastic, and the like.
21. Do not cover crumb tray or any part of the oven with metal foil.
This will cause overheating of the oven.
SAVE THESE INSTRUCTIONS
Other Consumer Safety Information
This appliance is intended for household use only.
w WARNING
with a polarized plug (one wide blade) to reduce the risk of electric
shock. The plug fits only one way into a polarized outlet. Do not
defeat the safety purpose of the plug by modifying the plug in any
way or by using an adapter. If the plug does not fit fully into the
outlet, reverse the plug. If it still does not fit fully into the outlet, have
an electrician replace the outlet.
The length of the cord used on this appliance was selected to reduce
the hazards of becoming tangled in or tripping over a longer cord.
If a longer cord is necessary, an approved extension cord may be
used. The electrical rating of the extension cord must be equal to
or greater than the rating of the appliance. Care must be taken
to arrange the extension cord so that it will not drape over the
countertop or tabletop where it can be pulled on by children or
accidentally tripped over.
Electrical Shock Hazard: This appliance is provided
22. To turn oven off, turn Timer to OFF (
“How To” sections for specifics.
23. Do not place eyes or face in close proximity with tempered
safety glass door, in the event that the safety glass breaks.
24. Always use appliance with crumb tray securely in place.
25. Do not use appliance for other than intended use.
26. Clean oven interior carefully. Do not scratch or damage heating
element tube.
This appliance is equipped with a fully tempered safety glass door.
The tempered glass is four times stronger than ordinary glass and
more resistant to breakage. Tempered glass can break; however, it
breaks into pieces with no sharp edges. Care must be taken to avoid
scratching door surface or nicking edges. If the door has a scratch or
nick, call our toll-free customer service number.
Always unplug your toaster oven from the outlet when not in use.
) position. See any of the
Before First Use
Most heating appliances produce an odor and/or smoke when used
the first time. Plug the toaster oven into an outlet. Turn Temperature
Dial to 450°F (230°C). Heat at this temperature for 10 minutes. The
odor should not be present after this initial preheating. Wash baking
pan and oven rack before using.
3
Parts and Features
*To order parts:
US: 1.800.851.8900
www.hamiltonbeach.com
Canada: 1.800.267.2826
Mexico:
01 800 71 16 100
Oven Rack*/
Toasting Area
CAUTION: HOT SURFACE. The
temperature of accessible surfaces may
be high when the appliance is operating.
Broiling/Baking pan
slides under oven rack.
Temperature
Dial
Function Dial
Timer
ON Indicator
Light
HIGH RACK POSITION:
baking, broiling, and toasting
LOW RACK POSITION:
baking
Slide-Out
Crumb Tray*
Broiling/
Baking Pan*
4
How to Toast
w WARNING
• If contents ignite, do not open oven door.
Unplug oven and allow contents to stop
burning and cool before opening door.
Fire Hazard.
• Do not leave appliance unattended when
in operation.
• Always unplug toaster oven when not in
use.
1
Plug into outlet. Place oven rack
in LOW RACK POSITION (shown) for
toast, English muffins, bagels, and
waffles.
5
2
Turn Temperature Dial to BROIL/
TOAST.
• When toasting only two
slices of bread, place bread
in center of toasting area
on low rack position to get
even toasting on top and
bottom.
• To toast bagels, English
muffins, and waffles,
place oven rack in low rack
position and place food cut/split side facing up.
This will toast the cut/split side more than the
outside food. Set Timer to desired setting.
• To toast regular toaster pastries or frozen
pastries, place oven rack in the low rack
position.
3
Place food in oven. Turn Function
Dial to TOAST.
4
Rotate Timer past 10 and then back to
desired toast color. A bell will sound
when the toast cycle is complete.
• Select a color lighter than Medium and toast
directly on the oven rack. If pastry has a glaze or
frosting, use baking pan.
• When toasting, condensation may form on the
oven door. The moisture will slowly escape from
the enclosed oven.
• The number of slices of bread and the bread
freshness will affect toast color. For example,
toasting 4 slices of bread will require a darker
toast color setting than 2 slices of bread.
Adjust the Timer based on desired color and
number of slices.
• If you are not satisfied with the color balance
between the two sides of your food in the
recommended rack position, select a different
rack position.
5
How to Bake
w WARNING
• If contents ignite, do not open oven door.
Unplug oven and allow contents to stop
burning and cool before opening door.
Fire Hazard.
• Do not use oven cooking bags.
• Always allow at least 1 inch (2.5 cm)
between food and heating element.
• Always unplug toaster oven when not in use.
1
Plug into outlet. Place oven rack
on HIGH RACK POSITION or LOW
RACK POSITION (depending on food
to be cooked). LOW RACK POSITION
shown.
5
6
2
Turn Temperature Dial to desired
temperature.
• Do not totally enclose foods in aluminum foil.
Foil can insulate foods and slow down heating.
• To reheat rolls or biscuits, place on baking pan
and heat at 300ºF (149ºC) for 10 minutes.
• Reheat leftover roasts or casseroles at 350ºF
(177ºC) for 20 to 30 minutes or until heated
through.
3
Turn Function Dial to BAKE.
toast” to preheat oven for 5 minutes before beginning to bake. After
oven is preheated, set Timer to desired time by rotating Timer past 10
and then to desired baking time or rotate Timer to STAY ON.
4
Rotate Timer past 10 and then back to “dark
• Bake foods, such as pizza, on the LOW RACK
POSITION. Place food directly on oven rack or in
baking pan.
• Bake foods, such as a whole chicken, on the LOW
RACK POSITION. Place food in baking pan.
• Turn foods halfway through cooking time.
Visit foodsafety.gov for more safe cooking
temperature information.
How to Broil
w WARNING
• If contents ignite, do not open oven door.
Unplug oven and allow contents to stop
burning and cool before opening door.
• Follow food manufacturer’s instructions.
Fire Hazard.
• Do not leave oven unattended during
operation.
• Keep 1 inch (2.5 cm) between food and
heating element.
• Do not use oven cooking bags.
• Do not heat foods in plastic containers.
1
Plug into outlet. Place oven rack in oven. HIGH RACK POSITION is for
faster broiling times. LOW RACK POSITION is for foods needing longer
broiling times, like chicken breasts. Slide the broiling/baking pan
under the oven rack. DO NOT PREHEAT OVEN. Turn Temperature
Dial to BROIL/TOAST.
5
2
NOTE: Turn foods halfway
through cooking time.
Visit foodsafety.gov for more
safe cooking temperature
information.
3
Turn Function Dial to B
ROIL.
4
Rotate Timer past 10 and then
to the desired broiling time or
rotate Timer to STAY ON. Turn
foods when browned or halfway
through cooking time.
7
w WARNING
Cleaning
Your toaster oven should be cleaned regularly for best performance and long life. Regular cleaning will also reduce the risk of fire hazard.
Do not clean with metal scouring pads. Pieces can break off pad and touch electrical parts.
Electrical Shock Hazard.
1
5
Wipe outside of oven with a
damp cloth. Do not use abrasive
cleansers or metal scouring pads.
8
2
To clean inside of oven, wipe oven
walls, bottom of oven, and glass
door with a damp, soapy cloth.
Repeat with a damp, clean cloth.
For stubborn stains, use a plastic
scouring pad.
3
4
Troubleshooting
PROBLEM PROBABLE CAUSE/SOLUTION
Oven will not heat.
Moisture forms on
inside of oven door
when toasting.
An odor and smoke
come from oven.
Oven will not toast.
Some foods burn and
some are not done.
• Check to make sure electrical outlet is working and the oven is plugged in. Turn Temperature Dial to
350°F (177°C). Turn Function Dial to BAKE; then turn Timer to STAY ON.
• This is normal when toasting in a toaster oven. Moisture is slower to escape from a toaster oven than
from a toaster. The amount of moisture will differ between fresh bread, bagels, and frozen pastries.
• Smoke and odor are normal during first use of most heating appliances. These will not be present after
initial heating period.
• Check to make sure outlet is working and oven is plugged in. Turn Temperature Dial to T
Turn Function Dial to T
• Adjust oven rack position to center food in oven.
• Adjust oven temperature or cooking time for best results with your recipes.
OAST; then rotate Timer past 10 and then back to desired toast color.
OAST/BROIL.
9
Notes
10
Loading...
