SAFETY INSTRUCTIONS

BEFORE SWITCHING THE APPLIANCE ON FOR THE FIRST TIME

BEF

RE

E

DO ...
... Make sure that the transport bolt are removed.
... Use a separate earthed socket for the power supply.
... Make sure that the plug is accessible.
... Hold the plug and not the electric cable when

unplugging the power supply.

... Make sure that the fuses in the power circuit are rated

for 15A.

... Keep away from heat sources and direct sun light to

prevent plastic and rubber components from aging.

... Make sure that the power cord is not caught under or

in the appliance and avoid damage to the power cable.

... Check that hose joints and connections are firm and no
water can leak. If joints are loose or there is leakage, turn off the
water supply and refix. Do not use the washing machine until the
hoses are properly fixed.

DO NOT ...

... Touch or use the appliance when barefoot or with wet or

damp hands or feet.

... Use flammable detergent or dry cleaning agent.
... Use any flammable sprays in close vicinity to the

appliance.

... Remove or insert the plug in the presence of flammable

gas.

... Allow children or infirm persons to play with the appliance

or packing materials.

... Install the appliance outdoors in a damp place, or in an
area which may be prone to water leaks such as under or near a
sink unit. In the event of a water leak allow the machine to dry
naturally.

... Place the washing machine directly on a carpet, or close
to a wall or furniture.

DURING DAILY USE OF THE APPLIANCE

DO ...

... Pull up zips and fix loose threads to prevent the items
from being entangled. If necessary, put small items into a net bag
or pillow.

... Turn off the machine after each wash program and
switch it off at the mains to save electricity and for safety. Wipe
clean the lower part of the porthole.

... Keep the door slightly open when the washing machine
is not in use to prevent formation of odours.

... Let the power cord be replaced by the manufacturer, his
service agent or other accordingly qualified persons, in case it is
damaged.

... Ensure that the appliance is not used by persons
with reduced physical, sensory or mental capabilities, lack of
experience and knowledge without supervision or instruction by a
person responsible for their safety.

DO NOT ...

... Touch the washer door during the washing process - it

gets hot!

...Place heavy objects or sources of heat or damp on top

of the appliance.

... Hot wash foam rubber or sponge-like materials.
... Open the detergent distribution drawer during the wash

cycle.

... Force the washer door open. The door is fitted with a
self-lock device and will open shortly after the washing procedure
is ended.

... Open the washer door if the water level is visibly over

the porthole.

... Cover the washing machine with plastic cover so that
inside dampness cannot be kept in.

... Supervise children to ensure that they do not play with

the appliance.

BEF

O

SE

RE U

INSTALLATION

DISMANTLE THE TRANSPORTATION BOLTS

The transportation bolts are designed for clamping anti-vibration components
inside of the washing machine during the transportation process.

Remove the back cover.1.
Remove the four bolts on the rear side and take out the synthetic 2.

stabilisers from within the machine.

Replace the back cover.3.
Fill the holes left by the bolts with blanking plugs.4.

Note:

1.When you replace the back cover,the convexity must face
to outside, and you have to insert the back cover from the
two gaps as shown in fig.5.

2.Keep the transportation bolts and synthetic stabilisers
in a safe place for later use.

5.

ADJUSTING THE WASHING MACHINE

There are adjustable feet under the bottom of the washing machine. Before use, they should be
adjusted so that the machine is level. This will minimise vibrations and thus noise during use. It will also
reduce wear and tear. We recommend using a spirit level to level the appliance.The floor should be as
stable and flat as possible.

O

US

INLET HOSE

1. Connect the nut on the inlet hose to the connector on the water
valve.

2. Apply inlet hose to a water tap with cold, fresh water.

BEF

RE

E

7

Note: Use the hose-set supplied with the appliance. Old
hose-sets should not be reused.

DRAIN HOSE

1. Use the drain hose bracket to keep the end of the drain hose retained
and prevent the outflow of water. Don't extend the length of the drain
hose; if an extended hose is required, please consult a serviceman.

2. The height of the drainage outlet must be 80-100 cm. Fix the drain
hose to the clip at the back of the washing machine to prevent it from
dropping off.

Note: The drain hose should not be submerged in water
and should be securely fixed and leak-free. If the drain hose is placed on the ground or if the pipe is at a
height of less than 80cm, the washing machine will continuously drain while being filled (self-siphoning).

1.

1.

2.

8 0 - 1 0 0cm

2.

CONNECTING TO THE POWER SUPPLY

Before connecting to the power supply, check:

¬ The socket is adequate for the maximum power of the washing machine

(For safety, fuses in the power circuit should be rated for no less than 15A).

¬ The voltage should meet the requirement.

¬ The power outlet should be capable of accepting the washing machine plug.

¬ Connect the machine to an earthed socket outlet.

Intense

Speed Up

Delay Extra Rinse Prewash Rinse Hold

IJK L M

Spin

Temp.

Start/Pause

ABEDCFGH

hsaWyliaDnottoC

HW90-1482

'52tropScitehtnyS

Power

'51sserpxExiM

snaeJetacileD

R

eraCybaBlooW

niarD/nipShsaWdnaH

9Kg

Capacity Energy

Spin speed

°C- -,20,30,40,50,60,70,80,90

11

2

3

1

2

3

1

4.5kg

4.5kg

TEMPERATURE

ENERGY
CONSUMPTION

WATER
CONSUMPTION

SPIN DRYING
PERFORMANCE

*）

*）

*）

4.5kg

4.5kg

9kg

60

60

2:32 46L

2:52

2:52

0.757kwh

1.277kwh

1.272kwh

4.5kg

4.5kg

2kg

4.5kg

4.5kg

*）Energy Label Program Settings: 1. “Cotton+40°C+Intense+Max speed” ; 2. “Cotton+60°C+Intense+Max speed”

46L

62L

53%

HW90-1482

9

1400

850 650 595

74

0.48

0.48

USINE THE APPLIANCE

WASHING METHODS

PLEASE NOTE

This washing machine is for domestic use only. If the machine is use for commercial purpose the guarantee
will not be valid anymore.Do not use it for purposes other than that for which it was designed. Follow the
instructions given on the label of each garment and wash only machine-washable garments.

POWER SUPPLY

Connect the washing machine to the power supply (220V to 240V~/50Hz).

WATER CONNECTION

Turn on the tap. The water must be clean and clear.

Note: Before use, check for leakage in the joints between the tap and the inlet hose
by turning on the tap.

PREPARING THE LAUNDRY

¬ Sort out clothes according to fabric (cotton, synthetics, wool or silk) and to how dirty they are.

¬ Separate white clothes from coloured ones. Wash them first by hand to check if they fade or run.

¬ Empty pockets(clips,coins,keys,etc.)and remove the harder decorative objects(e.g. brooches) to avoid
them entrying the drain pump and blocking.

Attention: Small parts (like buttons, etc) may lead to repair work which user has to
pay by themselves and can cause damage in the machine.

¬ Garments without hems, underwear, finely woven textile such as fine curtains are to be put into wash
bag (it is better not to wash them in a washing machine).

¬ Close zippers and hooks, make sure the buttons are sewn on tightly and place small items such as
socks, belts, bras, etc. in the wash bag.

Unfold large pieces of fabric such as bed sheets, bedspreads, etc.

¬

¬ Turn shirts inside out.

Intense

Speed Up

Delay Extra RinsePrewash Rinse Hold

hsaWyliaDnottoC

HW90-1482

'52tropScitehtnyS

Spin

Power

'51sserpxExiM

Temp.

snaeJetacileD

eraCybaBlooW

R

niarD/nipShsaWdnaH

Start/Pause

9Kg

Spin speed

Capacity

Energy

Intense

Speed Up

Delay Extra Rinse Prewash Rinse Hold

2

3

1

hsaWyliaDnottoC

HW90-1482

Spin

Temp .

R

Start/Pause

'52tropScitehtnyS

'51sserpxExiM

snaeJetacileD

eraCybaBlooW

niarD/nipShsaWdnaH

Power

9Kg

Capacit

y Énergie

Spin speed

Intense

Speed Up

Delay Extra Rinse Prewash Rinse Hold

Intense

Speed Up

Delay Extra Rinse Prewash Rinse Hold

Intense

Speed Up

Delay Extra Rinse Prewash Rinse Hold

hsaWyliaDnottoC

HW90-1482

Delay Extra Rinse Prewash Rinse Hold

'52tropScitehtnyS

Power

'51sserpxExiM

snaeJetacileD

eraCybaBlooW

niarD/nipShsaWdnaH

9Kg

Capacit

Energy

y

Spin speed

hsaWyliaDnottoC

HW80-1482-F

'52tropScitehtnyS

Power

'51sserpxExiM

snaeJetacileD

eraCybaBlooW

niarD/nipShsaWdnaH

9Kg

Capacit

Energy

y

Spin speed

hsaWyliaDnottoC

HW80-1482-F

'52tropScitehtnyS

Power

'51sserpxExiM

snaeJetacileD

eraCybaBlooW

niarD/nipShsaWdnaH

9Kg

Capacit

Energy

y

Spin speed

hsaWyliaDnottoC

HW90-1482

'52tropScitehtnyS

Spin

Power

'51sserpxExiM

Temp.

snaeJetacileD

eraCybaBlooW

R

niarD/nipShsaWdnaH

Start/Pause

9Kg

Energy

Capacit

y

Spin speed

Spin

Temp.

R

Start/Pause

Spin

Temp.

R

Start/Pause

Spin

Temp.

R

Start/Pause

Intense

SpeedUp

If it is not suitable to open the door,using the pole can open it,but it is not a normal way.

G

CARE CHART

IN

THE APPLIANCE

LOAD REFERENCE

Resistant material

Delicate fabric

Washable at 95 °C

Washable at 60 °C

Washable at 40 °C

Washable at 30 °C

Hand wash

Dry clean only

Wool Seal

Bleachable in cold water

Do not bleach

Iron at 200 °C

Iron at 150 °C

Iron at 100 °C

Don't iron

Dry cleaning with any solvent

Dry cleaning with pericloride

Dry cleaning with aviation fuel

Don't dry clean

Dry flat

Hung to dry

Dry on clothes hanger

Tumble dry, normal heat

Tumble dry, reduced heat

Don't tumble dry

Socks Blended fabrics Approximately 50g

Underwear Blended fabrics Approximately 70g

g008yletamixorppAnottoC)elgnis(teehsdeB

g0003yletamixorppAlooWteknalB

g008yletamixorppA/sehtolccirbafdednelB

g008yletamixorppAnottoCstekcaJ

g008yletamixorppA/snaeJ

g059yletamixorppAnottoCsllarevO

g002yletamixorppA/samajyPseidaL

g003yletamixorppA/strihS

g003yletamixorppAnottoCstrihS-T

1

6

CLEANING & CARE

AFTER WASHING

Turn off the water supply and pull out electricity plug after each wash.
Open the washer door to prevent formation of moisture and odours. If
the washing machine is left idle for a long period, drain the water in
the machine and replace the drain hose.

CLEANING THE DETERGENT DRAWER

Clean the detergent distribution drawer regularly.

Swing out the drawer, flush it clean with water and then replace it.

CLEANING THE MACHINE

1.

2.

2.

.

1

Unplug the machine during cleaning and maintenance. Use a soft cloth
dampened with soap liquid to clean the machine case and rubber components. Do not use organic chemicals or corrosive solvents.

CLEANING THE FILTER

Clean the filter once a month:

1. Open the bottom cover.

2.Remove the filter by turning counterclockwise.

3.Flush the filter clean with running water.

4.Replace the filter by turning clockwise and
remount the cover.

Caution:

1.The filter must be in place, or it may lead to leakage.

1.

2.

2.Place a container under the drain pump filter, to collect
any excess water that may come out of the drain pump
when the filter is removed.

3.

4.

Intense

SpeedUp

Delay Extra Rinse Prewash Rinse Hold

hsaWyliaDnottoC

HW90-1482

'52tropScitehtnyS

Spin

Power

'51sserpxExiM

Temp.

snaeJetacileD

eraCybaBlooW

R

niarD/nipShsaWdnaH

Start/Pause

9Kg

Energy

Capacity

Spin speed

The driving computer and the computer
board of display cann’t communiacte.

MAINTENAN

C

E

TROUBLESHOOTING

TROUBLESHOOTING

The following circumstances do not constitute problems. Do not contact the Service Center until the problem has been confirmed.

SNOITULOSSESUACMELBORP

9

Washing machine fails to
operate.

Washing machine cannot be
filled with water.

Machine is draining while
being filled.

Drainage failure. ¬ Drain hose is blocked.

¬ Poor connection to the power supply.
¬ Power failure.
¬ The washer door is not properly closed.
¬ Machine has not been switched on.

¬ The "Start/Pause" button is not pressed.
¬ Water tap is not turned on.
¬ Water pressure is less than 0,03 Mpa.
¬ The inlet hose is kinked.
¬ Water supply failure.
¬ The program knob is not properly set.
¬ The washer door is not properly closed.
¬ The inlet hose filter is blocked.

¬ The height of the drain hose is below 80 cm.
¬ The drain hose is in water.

¬ Drain hose end is higher than 100 cm above
the floor level.
¬ The filter is blocked.

_ Check connection to the power supply.
_ Check the power supply.
_ Close the washer door properly.
_ Make sure the machine is switched on.

_ press the "Start/Pause" button.
_ Turn on the water tap.
_ Check water pressure.
_ Check the inlet hose.
_ Ensure the water supply.
_ Set the program knob properly.
_ Close the washer door properly.
_ Unblock the inlet hose filter.

_ Install drain hose within 80-100 cm of height.
_ Make sure the drain hose is not in water.

_ Unblock the drain hose.
_ Make sure the drain hose end is lower than

100 cm above floor level.

_ Unblock the filter.

Strong vibration while
spinning.

Operation stops before
completing wash cycle.

Operation stops for a period
of time.

Excessive foam in the
drum, which is spilled to the
distribution drawer.

Automatic adjustment of the
washing time.

Spinning fails ¬ Unbalance of the laundry _ Add clothes or run a spinning program again.

¬ Not all transportation bolts have been removed.
¬ Washing machine is located on an uneven
surface or is not level.
¬ Machine load is over Max load.

¬ Water or electricity failure. _ Check the power supply.

¬ Washing machine gives an error message.
¬ Washing machine is in soaking cycle?

¬ The detergent is not a low-foaming type or for
manual wash.
¬ Excessive use of detergent.

¬ The washing program duration will be adjusted _ This is normal and doesn't affect the

_ Remove all transportation bolts.
_ Make sure the washing machine is on

an even surface and levelled.

_ Reduce amount of laundry in the drum.

_ Check display codes.
_ Press the rinse hood button or the Start/pause
button again to cancel it.

_ Check if your detergent is appropriate.
_ Reduce amount of detergent in the distribution

drawer.

functionality.

0

MAINTENANCE
