Haier HVTS08, HVTS04, HVTS06 User Manual

Countertop Wine Cellars

Compoir Cave á Vin Systéme

Encimera Enfriado de Vinos

Model #HVTS08 shown only for illustration purposes only. Size of unit and features vary by model purchased.

User Manual

Model # HVTS04, HVTS06, HVTS08

Guide de l’Utilisateur

Modéle # HVTS04, HVTS06, HVTS08

Manual del Usuario

Para Modelo de # HVTS04, HVTS06, HVTS08

Quality Innovation Style

English

IMPORTANT SAFEGUARDS

When using this appliance, always exercise basic safety precautions, including the following:

1) Read all of the instructions before using this appliance.

2) This wine cellar must be properly installed in accordance with the installation instructions before it is used. See grounding instructions in the installation section.

3) Never unplug your wine cellar by pulling on the power cord. Always grasp the plug firmly and pull straight out from the outlet.

4) Repair or replace immediately, all electric service cords that have become frayed or otherwise damaged. Do not use a cord that shows cracks or abrasion damage along its length, the plug or the connector end.

5) Unplug your wine cellar before cleaning or before making any repairs. Note: If for any reason this product requires service, we strongly recommend that a certified technician performs the service.

6) If your wine cellar is not being used, we recommend that you remove the door and leave the shelves in place. This will reduce the possibility of danger to children.

7) This wine cellar should not be recessed or built-in in an enclosed cabinet. It is designed for freestanding installation only.

8) Do not operate your wine cellar in the presence of explosive fumes.

9) Do not store foods in wine cellar as interior temperature may not be cool enough to prevent spoilage.

SAVE THESE INSTRUCTIONS

DANGER

Risk of child entrapment. Before you throw away your old

appliance, take off the doors. Leave the shelves in place so

that children may not easily climb inside.

English

table of contents

PAGE

IMPORTANT SAFEGUARDS 1 PARTS AND FEATURES 3 INSTALLING YOUR WINE CELLAR 4-5

Unpacking your Wine Cellar 4 Leveling your Wine Cellar 4 Proper Air Circulation 4 Electrical Requirements 5 Use of Extension Cords 5 Installation Limitations 5

WINE CELLAR FEATURES AND USE 6 Temperature Adjustment 6

PROPER WINE CELLAR CARE AND CLEANING 7 Cleaning and Maintenance 7 Power interruptions 7 Vacation & Moving Care 7

TROUBLESHOOTING 8 WARRANTY 9

Thank you for purchasing our Haier product. This easy-to-use manual will guide you in getting the best

Model number

use of your wine cellar. Remember to record the model and

Serial number

serial number. They are on a label inside of the wine cellar.

Staple your receipt to your manual.

You will need it to obtain warranty service.

Date of purchase

English

parts and features

Model #HVTS06 shown only for illustration purposes only. Size of unit and features vary by model purchased.

1. Removable Chrome Shelves

2. Leveling Legs (quantity and location vary by model)

3. Glass Door

4. Temperature Control Panel

5. Drip Tray (not shown, located in back of unit)

English

installing your wine cellar

Unpacking your Wine Cellar

1. Remove all packaging material. This includes the base and all adhesive tape holding the wine cellar accessories inside and outside.

2. Inspect and remove any remains of packing, tape or printed materials before powering on the wine cellar.

Leveling your Wine Cellar

• Your wine cellar may have 4 leveling legs. After properly placing your wine

cellar in its final position, you can level your wine cellar.

• Leveling legs can be adjusted by turning them counterclockwise to raise your

wine cellar or by turning them clockwise to lower your wine cellar.

• Install the legs by screwing in the legs into the preset screw holes.

Proper Air Circulation

• To ensure that your wine cellar works at the maximum efficiency it was

designed for, you should install it in a location where there is proper air circulation and electrical connections.

• The following are recommended clearances around the wine cellar:

Sides…………… 2“ (50mm)

Top................... 4” (100mm)

Back..................2” (50mm)

• Do not over fill your wine cellar for proper internal air circulation.

NOTE: Allow enough space in the front of the unit to open the

door to 120˚.

English

Electrical Requirement

• Make sure there is a suitable power Outlet (110 volts, 15 amps outlet) with

proper grounding to power the wine cellar.

• Avoid the use of three plug adapters or cutting off the third grounding in

order to accommodate a two plug outlet. This is a dangerous practice since it provides no effective grounding for the wine cellar and may result in shock hazard.

Use of Extension Cords

• Avoid the use of an extension cord because of potential safety hazards under

certain conditions. If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade grounding plug and a 3-slot outlet that will accept the plug. The marked rating of the extension cord must be equal to or greater than the electrical rating of the appliance.

Installation Limitations

• Do not install your wine cellar in any location not properly insulated or heated

e.g. garage etc.

• Select a suitable location for the wine cellar on a hard, even surface away

from direct sunlight or heat source e.g. radiators, baseboard heaters, cooking appliances etc. Any surface unevenness should be corrected with the leveling legs located on the front and rear bottom corners of the wine cellar. Avoid placing unit where there may be electrical interference.

• Your wine cellar is designed for freestanding installation only. It is not designed

for built-in application.

NOTE: To minimize the risk of rusting, leakage and insulation

damage, avoid placing the unit in a place where heavy moisture is present. Under no circumstances spill or directly apply water onto or into the unit.

English

ºC/ºF

wine cellar feature and use

General Features

Temperature Adjustments:

• Your wine cellar has an electronic temperature control on the front of the unit.

You can set the temperature of your wine cellar at any setting you desire.

The temperature will range from 46˚F to 64˚F. When initially turned on, the temperature display will show the ambient (room) temperature and will then display the internal temperature.

NOTE: White wine temperature is cooler than red wine

temperature.

By pressing the touchpad on the display you can increase the temperature and pressing the touchpad will lower the temperature. After you set your required temperature, the set temperature will flash for approximately 5 seconds and then the display will revert to the ambient temperature.

Your wine cellar also has a light for you viewing pleasure. A light switch on the

control panel will activate the light manually. Under normal operation it is best for the light to remain off.

Please note that the actual internal temperature in a thermal electric unit corresponds with the room temperature and may fluctuate.

By pressing the (C/F) touchpad you can have the temperature readout either in celsius or fahrenheit (not on all models).

When the ambient temperature is below the pre-set temperature, the cellar will not operate until the ambient temperature increases to higher than the pre-set temperature.

English

proper wine cellar care & cleaning

Cleaning and Maintenance

Warning: To avoid electric shock always unplug your wine cellar

before cleaning. Ignoring this warning may result in death or injury.

Caution: Before using cleaning products, always read and follow

manufacturer’s instructions and warnings to avoid personal injury or product damage.

General:

• If water has collected in the drip tray from the back of the

unit, discard the water and reinsert the drip tray into the holder.

• Prepare a cleaning solution of 3-4 tablespoons of baking

soda mixed with warm water. Use sponge or soft cloth, dampened with the cleaning solution, to wipe down your wine cellar.

• Rinse with clean warm water and dry with a soft cloth.

• Do not use harsh chemicals, abrasives, ammonia, chlorine

bleach,concentrated detergents, solvents or metal scouring pads. Some of these chemicals may dissolve, damage and/ or discolor your wine cellar.

Power Interruptions

• Occasionally there may be power interruptions due to thunderstorms or other

causes. Remove the power cord from AC outlet when a power outage occurs. When power has been restored, replug power cord to AC outlet.

Vacation and Moving Care

• For long vacations or absences, unplug the unit, empty contents from wine

cellar, and clean the wine cellar and door gaskets according to “General cleaning” section. Prop doors open, so air can circulate inside.

troubleshooting

Wine Cellar does not operate

• Check if wine cellar is plugged in.

• Check if there is power at the ac outlet, by checking the circuit breaker.

Wine appears too warm

• Frequent door openings.

• Allow time for recently added wine to reach desired temperature.

• Check gaskets for proper seal.

• Adjust temperature control to colder setting.

Wine temperature is too cold

• If temperature control setting is too cold, adjust to a warmer setting.

Moisture build up on interior or exterior of the wine cellar:

• This is normal during high humidity periods.

• Prolonged or frequent door openings.

• Check door gaskets for proper seal.

Wine Cellar door does not shut properly:

• Level the wine cooler.

• Check for blockages e.g. wine bottles, shelves.

English

limited warranty

What is covered and for how long?

This warranty covers all defects in workmanship or materials for a period of:

12 months for labor 12 months for parts (Functional Parts Only) Carry In

The warranty commences on the date of item purchase. Customer shall provide Haier with proof of the date of purchase, brand, model and serial number for veriﬁcation prior to any warranty service being provided.

EXCEPTIONS: Commercial or Rental Use warranty 90 days for labor 90 days for parts No other warranty applies

What is covered/Not covered?

1. The mechanical and electrical parts of the appliance which serve the functional purpose of this appliance are covered for a period of 12 months. This includes all parts except ﬁnish and trim.

2. The limited warranty does not cover any credit or refund for any loss or injury caused by the product or defects to the product including but not limited to incidental or consequential damages.

What will be done?

1. Any mechanical or electrical part that proves to be defective in normal usage during the speciﬁed warranty period will be repaired or replaced at Haier’s discretion.

A&E factory service is the authorized

service provider for Haier.

If it is determined that repair is not

appropriate or replacement part is unavailable for repair, Haier will exchange the product with a refurbished or new product the same or similar to the original at its discretion.

2. There will be no charge to the purchaser for functional replacement parts and labor on any covered items during the initial 12- month period.

3. To have your product serviced, contact Haier customer service 1-877-337-3639.

THIS WARRANTY COVERS APPLIANCES WITHIN THE CONTINENTAL UNITED STATES, PUERTO RICO AND CANADA. IT DOES NOT COVER THE FOLLOWING:

Damages from improper installation Damages incurred during shipping. Defects other than manufacturing. Damage from misuse, abuse, accident,

alteration, lack of proper care and maintenance or incorrect current or voltage.

Damage from other than household use. Damage from service by other than an

authorized dealer or service center. Decorative trims or replaceable light bulbs. Transportation and shipping. Labor (after the initial 12 months). Credit or Refund for products over 30 days

past date of purchase. Food loss for food spoiled as a direct result

of mechanical failure of the product or of any delay in providing service, repair, replacement.

This limited warranty doesn’t apply to refurbished product or unit purchased as/like new or second-hand.

THIS LIMITED WARRANTY IS GIVEN IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE

The remedy provided in this warranty is exclusive and is granted in lieu of all other remedies.

This warranty does not cover incidental or consequential damages, so the above limitations may not apply to you. Some states do not allow limitations on how long an implied warranty lasts, so the above limitations may not apply to you.

This warranty gives you speciﬁc legal rights, and you may have other rights which vary from state to state.

Haier America

New York, NY 10018
