DOC022.53.00619
Digital Reactor Block 200
(DRB 200)
Instrument Manual
© Hach Company, 2003. All rights reserved. Printed in Germany. eac/dk 8/03 1ed
2
Table of Contents
Safety Precautions................................................................................................5
Specifications ........................................................................................................7
Section 1 Introduction....................................................................................9
1.1 Front Display ..............................................................................9
Operation..........................................................................................................13
Section 2 Instrument Use............................................................................15
2.1 Starting-up.................................................................................15
2.2 Routine Operation....................................................................16
2.3 Using the Reducing Adapters ................................................17
2.4 Selecting the Program..............................................................17
2.5 Setting User Programs.............................................................19
2.6 Error Messages..........................................................................19
Section 3 Maintenance.................................................................................21
3.1 Cleaning the Instrument..........................................................21
3.2 Instrument Test.........................................................................21
3.3 Changing the Protective Covers.............................................22
General Information.....................................................................................23
Parts and Accessories ........................................................................................25
How To Order.....................................................................................................26
Repair Service.....................................................................................................27
Warranty..............................................................................................................28
Certification ........................................................................................................29
3
4
Safety Precautions
Please read this entire manual before unpacking, setting up,
or operating this instrument. Pay particular attention to all
danger and caution statements. Failure to do so could result
in serious injury to the operator or damage to the equipment.
To ensure the protection provided by this equipment is not
impaired, do not use or install this equipment in any
manner other than that which is specified in this manual.
Use of Hazard Information
If multiple hazards exist, this manual will use the signal
word (Danger, Caution, Note) corresponding to the
greatest hazard.
DANGER
Indicates a potentially or imminently hazardous situation
which, if not avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation that may
result in minor or moderate injury.
NOTE
Information that requires special emphasis.
Precautionary Labels
Read all labels and tags attached to the instrument.
Personal injury or damage to the instrument could occur if
not observed.
This symbol, if noted on the instrument, references
the instruction manual for operational and/or safety
information.
Hot Surfaces. Touching the reactor block surfaces and
vials while hot can cause serious burns.
Protective Earth Ground. This product requires a
protective earth connection. If not provided with a
plug on a cord, connect positive earth to this terminal
(U.S. cord set provides ground).
5
Safety Precautions
Safety Equipment
Use protective clothing when operating the reactor,
including goggles or face mask, and gloves.
Reagent Spills
Clean up spilled reagents immediately. If reagent contacts
skin, rinse the affected area thoroughly with water. Avoid
breathing released vapors. Read the Material Safety Data
Sheets (MSDS) supplied with each reagent for complete
chemical information.
Fire Hazard
Avoid the presence of flammable liquids near the operating
reactor. A fire hazard could be created.
Power Cord
A power cord suitable for 115 V ac line voltage is supplied
with the DRB
200.
DANGER:
Do not allow the power cord to pass under the instrument.
6
Specifications
Specifications are subject to change without notice.
Dimensions 250 x 145 x 310 mm (W x H x D)
LTV082.53.30001: 2 kg instrument, 3.5 kg with packaging
Weight
Ambient Operating
Temperature
Storage Temperature – 40–60 °C
Relative Humidity maximum 90% non-condensing
Stored Programs
LTV082.53.40001: 2 kg instrument, 3.5 kg with packaging
LTV082.53.42001: 2.8 kg instrument, 4.3 kg with packaging
10–45 °C
COD program (150 °C, 120 minutes)
TOC program (105 °C, 120 minutes)
100 °C program (100 °C, 30, 60, 120 minutes)
105 °C program (105 °C, 30, 60, 120 minutes)
150 °C program (150 °C, 30, 60, 120 minutes)
165 °C program (165 °C, 30, 60, 120 minutes)
Easily selected 37–165 °C (no cooling)
Programmable
Temperature Range
Programmable Timer
Range
Heating Rate From 20 to 150 °C in 10 minutes
Temperature Stability ± 2 °C
Number of Vials
Power Requirements 100–240 V, +5%/–15%, 50/60 Hz, Protection Class I
Power Input 600 VA
Safety Checks CE, GS, and cTUVus
37–165 °C
Easily selected 0–480 min; acoustic signal when the set time
expires, heating stops when time expires.
LTV082.53.30001: 9 holes for 16 vials, 2 holes for 20 mm vials
LTV082.53.40001: 15 holes for 16 mm vials
LTV082.53.42001: 21 holes for 16 mm vials, 4 holes for
20 mm vials
7
8
Section 1 Introduction
The DRB 200 is supplied as two models, with either one or
two heating blocks (
solutions in round vials of various sizes at 37–165 °C for a
period of 0–480 minutes. The small, 16 mm diameter
openings on the heating block are suitable for Hach COD,
Unicell, TOC, and Test N’ Tube tests. The larger, 20 mm
diameter openings are intended for sample preparation
reaction vessels, using the Metals Prep Set.
The DRB 200 has 6 stored and 3 programmable
temperature programs.
Figure 1 Front View of the DRB 200 Digital Reactor Block (2 Block Version)
Figure 1). The heating blocks can heat
1
7
6
1.1 Front Display
The instrument is operated using three touch-sensitive
keys located below the display (
the key depends on the display. If no function is shown for
a specific key, that key is not currently active.
232
4
5
1. Protective Lid
2. 20 mm Metal Prep Vials
3. 16 mm Digestion Vials
4. Right Heating Block
5. Keys
6. Display
7. Left Heating Block
Figure 1). The function of
9
Introduction
The actual temperatures of the heating blocks and the
remaining time are visible in the display while temperature
programs are active.
Figure 2 DRB 200 Display and Keys
1
2
1. Display 2. Touch-sensitive Keys
10
Introduction
Figure 3 Menu Structure
PRG3
Select program
PRG1 PRG2
Select program
?
OK
165°C: 165°C 60’
V 1.0
Initializing
Start Start
COD TOC
right
left
Select block
Select program
COD TOC
OK
COD: 150°C 120’
11
OK
TOC: 105°C 120’
150° 165°
Select program
105°
Select program
100°
120’ 60’ 30’
Digestion period
120’ 60’ 30’ 120’ 60’ 30’
Digestion period Digestion period
OK
100°C: 100°C 60’
OK
150°C: 150°C 60’
120’ 60’ 30’
Digestion period
105°C: 105°C 60’
OK
12
Operation
DANGER
Handling chemical samples, standards, and reagents can be dangerous. Review
the necessary Material Safety Data Sheets and become familiar with all safety
procedures before handling any chemicals.
DANGER
La manipulation des échantillons chimiques, étalons et réactifs peut être
dangereuse. Lire les Fiches de Données de Sécurité des Produits (FDSP) et se
familiariser avec toutes les procédures de sécurité avant de manipuler tous les
produits chimiques.
PELIGRO
La manipulación de muestras químicas, estándares y reactivos puede ser
peligrosa. Revise las fichas de seguridad de materiales y familiarícese con los
procedimientos de seguridad antes de manipular productos químicos.
GEFAHR
Das Arbeiten mit chemischen Proben, Standards und Reagenzien ist mit Gefahren
verbunden. Es wird dem Benutzer dieser Produkte empfohlen, sich vor der Arbeit
mit sicheren Verfahrensweisen und dem richtigen Gebrauch der Chemikalien
vertraut zu machen und alle entsprechenden Materialsicherheitsdatenblätter
aufmerksam zu lesen.
PERICOLO
La manipolazione di campioni, standard e reattivi chimici può essere pericolosa.
La preghiamo di prendere conoscenza delle Schede Techniche necessarie legate
alla Sicurezza dei Materiali e di abituarsi con tutte le procedure di sicurezza
prima di manipolare ogni prodotto chimico.
13
14
Section 2 Instrument Use
2.1 Starting-up
DANGER
The ventilation
slits in the lid must
not be covered, or
overheating may
occur.
Figure 4 Back View of the DRB 200 Digital Reactor Block
Initializing
VX.X
1. Place the instrument on a stable, level, heat-resistant
surface.
2. Plug in the power cord into a power socket (100–230 V
+5%/–15%, 50/60 Hz).
3. Switch on the instrument by switching the power
switch (
4. After initialization, the instrument will beep once,
indicating that it is ready for operation. The display
always shows the most recent setting of the
temperature programs after initialization.
Figure 4).
1. Power Switch 2. Power Plug 3. Nameplate
2.1.1 Setting the Language
The default factory setting is English. To change the
default setting:
1. Hold down the left key while switching on the
instrument.
15
Instrument Use
Language
GB D
Language
FI
Language
ENL
Language
SPL
2. Press the right arrow key to scroll through the menu.
Select the required language (see
3. The instrument is automatically initialized and is then
ready for operation.
Abbreviation Country
GB English
D Germany
F France
I Italy
E Spain
NL Netherlands
S Sweden
PL Poland
DK Denmark
2.1.2 Adjusting the Contrast
1. Hold down the middle key while switching on the
instrument.
Tab l e 1 ).
Tabl e 1 Language Settings
2. Use the up and down arrow keys to adjust the contrast.
3. Press OK to accept the changes.
2.2 Routine Operation
1. Switch on the instrument.
COD TOC
Start Start
80°C TOC
150°C TOC
Start Start
150°C TOC
Start
87’ Start
2. Select the required temperature program using the
appropriate keys (see section
3. Prepare the test vials as described in the analysis
procedure.
4. The instrument will be heated to the set temperature.
Two beeps indicate that the required temperature has
been reached.
2.4 on page 17).
16
Instrument Use
5. Place the vials in the appropriate heating block and
close the protective lid.
6. Start the program using the left key.
7. The time automatically counts down to zero (0). The
actual temperature and the remaining time are visible
on the display.
Clock Symbol Description
The remaining time counts down to zero (0).
8. The instrument will beep three times to indicate the
temperature program is complete. It will turn off the
heater and cool.
During operation, the display will indicate the status of the
thermometer.
Table 2 Thermometer Symbols
Thermometer Symbol Description
Heating block is heating.
Heating block has reached the set temperature.
Heating block is cooling.
2.3 Using the Reducing Adapters
If using 16 mm tubes (COD, TNT, etc.) with a heating block
with 20 mm diameter holes, insert the reducing adapters
into the holes to reduce the diameter to fit the 16 mm tubes.
2.4 Selecting the Program
The temperature programs can be selected independently
for the right and left heating blocks. If a change of setting is
selected, the user is prompted to specify whether the
change concerns the right or left heating block. Six
permanently programmed temperature programs are
available (
appropriate temperature program.
Tab l e 3 ). Use the touch-sensitive keys to select the
17
Instrument Use
Tabl e 3 Stored Programs
Program Description
COD Program
Select program
COD TOC
COD: 150°C 120’
OK
TOC Program
Select program
COD TOC
TOC: 105°C 120’
OK
100 °C Program
Select program
100°
Digestion period
100°C: 100°C 60’
105 °C Program
Select program
100°
Digestion period
105°C: 105°C 60’
150 °C Program
Select program
Digestion period
150°C: 150°C 60’
105°
120’ 60’ 0’
OK
105°
120’ 60’ 0’
OK
150° 165°
120’ 60’ 0’
OK
Heats vials for 2 hours at 150 °C. In the cooling phase, 4 beeps
indicates that the vials have cooled to 120 °C. Remove and
carefully invert the vials several times, before allowing them to
cool further in a rack.
Heats the vials for 2 hours at 105 °C. This setting is suitable for
all Hach TOC vial tests.
Heats vials for 30, 60, or 120 minutes at 100 °C. For example,
the “100 °C, 60 minutes” setting is needed to digest samples
3
using the Methods Prep Set.
Heats vials for 30, 60, or 120 minutes at 105 °C.
3
Heats vials for 30, 60, or 120 minutes at 150 °C.
3
18
Instrument Use
Table 3 Stored Programs (Continued)
Program Description
165 °C Program
Select program
150° 165°
Digestion period
120’ 60’ 10’
165°C: 165°C 60’
OK
2.5 Setting User Programs
Select program
PRG1 PRG2
PRG1: 100°C 60’
OK Prog
Heats vials for 30, 60, or 120 minutes at 165 °C.
The DRB 200 can accommodate three user programs in
storage locations PRG1, PRG2, and PRG3.
1. Select PRG1 from the Select Program menu.
2. Press Prog to enter the programming mode.
Program name?
Program name?
5(11 ) OK
Temperature?
100°C OK
Temperature?
115°C OK
Time?
60’ OK
115 : 115°C 60’
OK Prog
3. Assign a 4-character program name using the
OK( RG1)P
appropriate keys. Press OK to confirm the entry.
4. Use the up and down arrow keys to set the
temperature value between 37–165 °C. Press OK to
confirm the entry.
5. Use the up and down arrow keys to set the time
between 0-480 minutes. Press OK to confirm the entry.
6. Press OK to confirm the program. The program can be
changed by pressing Prog. Press the up arrow key to
return to the program selection screen.
2.6 Error Messages
Error Message Problem
“Block is too hot,
Please Wait”
“Init Error” The instrument is defective. Contact Customer Service.
The temperature of the heating block is higher than the
target temperature. Wait until the heating block cools.
19
20
Section 3 Maintenance
There are no scheduled maintenance requirements for the
instrument. To ensure reliable and precise operation, it
must be kept clean.
3.1 Cleaning the Instrument
DANGER
Strong acids and
bases can cause
burns.
1. Switch off the instrument, unplug the power cord and
allow the instrument to cool.
2. Wipe the instrument with a soft, damp cloth. Make
sure no water penetrates into the instrument.
If a vial overflows or breaks, or a small amount of liquid is
spilled, proceed as follows:
1. Switch off the instrument, unplug the power cord and
allow the instrument to cool.
2. Draw off the liquid with a pipette, avoiding any
contact with the skin.
3. Transfer liquid residues to a proper disposal.
4. Remove broken glass with tweezers and wipe out any
remaining liquid, avoiding any contact with the skin.
3.2 Instrument Test
The temperature shown in the display corresponds to the
temperature in a closed HACH vial filled with an aqueous
medium. During the heating phase, the real block
temperature in the vicinity of the heater may be higher
than the temperature shown on the display.
An empty Hach vial, glycerol (approximately 5 mL), and a
calibration stem-type thermometer (95–155 °C) are needed
to check the block temperature.
21
Maintenance
1. Fill a clean, empty vial with glycerol at room
temperature, and insert the thermometer until it
touches the bottom of the vial.
2. When the thermometer is in the vial, the level of the
glycerol must be 51 mm ± 0.5 mm from the bottom.
3. Insert the vial in the center opening of the second row
of the test block.
4. Start the temperature program for 150 °C, 60 minutes
(or the COD program) for this block.
5. When the heating phase is complete, the thermometer
temperature should be the same as the temperature
shown on the display.
3.3 Changing the Protective Covers
1. Open the protective cover approximately 45°. Hold the
inside of the external hinge with your thumb.
2. Press your thumb against the inside of the cover.
Carefully lift each side of the cover out of its mounting.
3. Fit a new protective cover by following steps 1-2 in
reverse order.
Figure 5 Changing the Protective Covers
22
General Information
At Hach Company, customer service is an important
part of every product we make.
With that in mind, we have compiled the
following information for your convenience.
23
24
Parts and Accessories
Description Part No.
DRB200-1 with 9 holes for 16 mm vials and 2 holes for
20 mm vials ....................................................LTV082.53.30001
DRB200-1 with 15 holes for 16 mm vials ..... LTV082.53.4001
DRB200-2 with 21 holes for 16 mm vials and
4 compartments for 20 mm vials ..................LTV082.53.4200
Operating Manual US Version .................. DOC022.53.00619
Operating Manual EU Version.................. DOC022.98.00619
Protective Cover Replacement....................................LZT048
Reducing Adapter 20 > 16 mm diameter ................HAA155
Thermometer, 0 to 200 °C...........................................45655-00
Tube, Culture DSPL 16x100 mm, Pk/1 ..................... 2275800
Tube, Culture DSPL 16x100 mm, Pk/6 ..................... 2275806
25
How To Order
By Telephone: By Mail:
6:30 a.m. to 5:00 p.m. MST
Monday through Friday
(800) 227-HACH
(800-227-4224)
By Fax: (970) 669-2932
Ordering information by E-mail: orders@hach.com
Information Required
• Hach account number (if available) • Billing address
• Your name and phone number • Shipping address
• Purchase order number • Catalog number
• Brief description or model number • Quantity
Technical and Customer Service (U.S.A. only)
Hach Technical and Customer Service Department
personnel are
products and their use. Specialists in analytical methods,
they are happy to put their talents to work for you.
Call 1-800-227-4224 or E-mail techhelp@hach.com.
eager to answer questions about our
Hach Company
P.O. Box 389
Loveland, CO 80539-0389
U.S.A.
International Customers
Hach maintains a worldwide network of dealers and
distributors. To locate the representative nearest you, send
E-mail to intl@hach. com or contact:
In Canada, Latin America, Africa, Asia, Pacific Rim:
HACH Company
P.O. Box 389, Loveland, CO 80539-0389 U.S.A.
Telephone: (970) 669-3050; FAX: (970) 669-2932
In Europe, the Middle East, or Mediterranean Africa:
HACH Company, c/o
Dr. Bruno Lange GmbH
Willstätterstr. 11,
D-40549 Düsseldorf, Germany
Telephone: +49/[0]211.52.88.0; Fax: +49/[0]211.52.88.231
26
Repair Service
Authorization must be obtained from Hach Company
before sending any items for repair. Please contact the
HACH Service Center serving your location.
In the United States:
Hach Company
100 Dayton Avenue
Ames, Iowa 50010
(800) 227-4224 (U.S.A. only)
Telephone: (515) 232-2533
FAX: (515) 232-1276
In Canada:
Hach Sales & Service Canada Ltd.
1313 Border Street, Unit 34
Winnipeg, Manitoba
R3H 0X4
(800) 665-7635 (Canada only)
Telephone: (204) 632-5598
FAX: (204) 694-5134
E-mail: canada@hach.com
In Latin America, the Caribbean, the Far East, the
Indian Subcontinent, Africa, Europe, or the Middle East:
Hach Company World Headquarters
P.O. Box 389
Loveland, Colorado, 80539-0389 U.S.A.
Telephone: (970) 669-3050
FAX: (970) 669-2932
E-mail: intl@hach.com
27
Warranty
Hach Company warrants this product to the original purchaser against any defects
that are due to faulty material or workmanship for a period of one year from date
of
shipment.
In the event that a defect is discovered during the warranty period, Hach Company
agrees that, at its option, it will repair or replace the defective product or refund the
purchase price, excluding original shipping and handling charges. Any product
repaired or replaced under this warranty will be warranted only for the remainder
of the original product warranty period.
This warranty does not apply to consumable products such as chemical reagents; or
consumable components of a product, such as, but not limited to, lamps
and
tubing.
Contact Hach Company or your distributor to initiate warranty support. Products
may not be returned without authorization from Hach Company.
Limitations
This warranty does not cover:
• damage caused by acts of God, natural disaster, labor unrest, acts of war
(declared or undeclared), terrorism, civil strife or acts of any governmental
jurisdiction
• damage caused by misuse, neglect, accident or improper application
or installation
• damage caused by any repair or attempted repair not authorized by
Hach Company
• any product not used in accordance with the instructions furnished by
Hach Company
• freight charges to return merchandise to Hach Company
• freight charges on expedited or express shipment of warranted parts or product
• travel fees associated with on-site warranty repair
This warranty contains the sole express warranty made by Hach Company in
connection with its products. All implied warranties, including without limitation,
the warranties of merchantability and fitness for a particular purpose, are expressly
disclaimed.
Some states within the United States do not allow the disclaimer of implied
warranties and if this is true in your state the above limitation may not apply to
you. This warranty gives you specific rights, and you may also have other rights
that vary from state to state.
This warranty constitutes the final, complete, and exclusive statement of warranty
terms and no person is authorized to make any other warranties or representations
on behalf of Hach Company.
Limitation of Remedies
The remedies of repair, replacement or refund of purchase price as stated above are
the exclusive remedies for the breach of this warranty. On the basis of strict liability
or under any other legal theory, in no event shall Hach Company be liable for any
incidental or consequential damages of any kind for breach of warranty or
negligence.
28
Certification
Hach Company certifies this instrument was tested
thoroughly, inspected and found to meet its published
specifications when it was shipped from the factory.
The DRB 200 has been tested and is certified as indicated to
the following instrumentation standards:
Product Safety:
Certified to EN 61010-1 A1 / A2 & EN 61010-2-010 A/1 per
73/23/EEC LVD by TUV (Rheinland) with TUV-GS safety
mark.
Listed to UL 61010A-1/UL 61010A-2-010 and CSA C22.2
No. 1010.1 A2 and CSA C22.2 No. 1010.2.010A by TUV
(Rheinland) with cTUVus safety mark.
Immunity:
EN 61326 A1/ & A2 (EMC Requirements for equipment
for measurement, control and laboratory use) per 89/336/
EEC EMC: Supporting test records by Hach Company,
certified compliance by Hach Company.
Required Standard/s include:
EN 61000-4-2 (IEC 1000-4-2) Electro-Static Discharge
EN 61000-4-3 (IEC 1000-4-3) Radiated RF Electro-Magnetic
Fields
EN 61000-4-4 (IEC 1000-4-4) Electrical Fast Transients/
Burst
EN 61000-4-5 (IEC 1000-4-5) Surge
EN 61000-4-6 (IEC 1000-4-6) Conducted Disturbances
Induced by RF Fields
EN 61000-4-11 (IEC 1000-4-11) Voltage Dips, Interruptions
and Variations
Emissions:
Per 89/336/EEC EMC: EN 61326:1998 (Electrical
Equipment for measurement, control and laboratory useEMC requirements) Class "B" emission limits. Supporting
29
Certification, continued
test records by REICHL (Report No. 030028) and certified
compliance by Hach Company.
Standards include:
EN 61000-3-2 Harmonic Disturbances Caused by Electrical
Equipment
EN 61000-3-3 Voltage Fluctuation (Flicker) Disturbances Caused by
Electrical Equipment
Additional Emissions Standard/s include:
CANADIAN INTERFERENCE-CAUSING EQUIPMENT
REGULATION, IECS-003, Class A: Supporting test records records
by REICHL (Report No. 030028) and certified compliance by Hach
Company.
This Class A digital apparatus meets all requirements of the
Canadian Interference- Causing Equipment Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences
du Règlement sur le matériel brouilleur du Canada.
FCC PART 15, Class "A" Limits: Supporting test records by REICHL
(Report No. 030028) and certified compliance by Hach Company.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications to this unit not expressly approved by
the party responsible for compliance could void the user's
authority to operate the equipment.
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference, in which
30
Certification, continued
case the user will be required to correct the interference at his own
expense. The following techniques of reducing the interference
problems are applied easily:
1. Disconnect the Model DRB 200 Digital Reactor Block from it's
power source to verify that it is or is not the source of the
interference.
2. If the Model DRB 200 Digital Reactor Block is connected into
the same outlet as the device with which it is interfering, try
another outlet.
3. Move the DRB 200 Digital Reactor Block away from the device
receiving the interference.
4. Reposition the receiving antenna for the device receiving the
interference.
5. Try combinations of the above.
31
32
Loading...
