Hach H160G, H170G, H280G, H270G, H260G User Manual

...
DOC022.53.80057
H-Series Meters
10/2013, Edition 2
User Manual
Table of Contents
Specifications..............................................................................................................3
Safety information........................................................................................................5
Use of hazard information....................................................................................5
Precautionary labels.............................................................................................5
Certification........................................................................................................... 6
Product overview.........................................................................................................6
Product components....................................................................................................8
Installation.....................................................................................................................9
Electrical installation....................................................................................................9
Connect to AC power...........................................................................................9
Install the batteries.............................................................................................10
Probe and connection types...............................................................................11
User interface and navigation............................................................................11
Keypad description....................................................................................................11
Display description..................................................................................................... 13
Startup........................................................................................................................... 14
Set the power to on.................................................................................................... 14
Configure the meter...................................................................................................14
Operation.....................................................................................................................15
Configure the Bluetooth™ wireless connection..........................................................
15
Send data to a PC.....................................................................................................16
Keep measurement data...........................................................................................16
Examples of measurement data.........................................................................16
Set the data log..................................................................................................17
Recall the data.................................................................................................... 17
Erase a single data measurement......................................................................17
Erase all measurement data............................................................................... 17
Keep calibration data.................................................................................................17
Recall a calibration.............................................................................................18
Set a passcode..........................................................................................................18
Change a passcode............................................................................................ 19
Override an error.......................................................................................................19
Advanced operation................................................................................................19
Set the pH operations................................................................................................19
Set the manual temperature compensation........................................................ 20
Calibrate for pH measurement...........................................................................20
Set the ISE operations...............................................................................................21
Calibrate for ISE measurement..........................................................................21
Set the conductivity options.......................................................................................22
Set the TDS options................................................................................................... 22
Calibrate for conductivity and TDS measurement..............................................23
Set the DO operations...............................................................................................23
Set the Barometric pressure compensation units...............................................24
Calibrate for DO measurement........................................................................... 24
1
Calibrate with a known concentration method............................................. 24
Calibrate with an air-saturated method.......................................................25
Maintenance...............................................................................................................25
Replace the batteries.................................................................................................25
Clean the instrument.................................................................................................. 25
ISFET pH probe maintenance...................................................................................26
Prepare the probe for storage............................................................................26
Calibrate the ISFET probe..................................................................................27
Clean the ISFET probe.......................................................................................27
Repair the ISFET probes....................................................................................27
BNC electrode maintenance......................................................................................28
Clean the electrode............................................................................................28
Troubleshooting.......................................................................................................28
Error codes................................................................................................................29
Replacement parts and accessories...............................................................30
Table of Contents
2
Specifications
Specifications are subject to change without notice.
Specification Details
Dimensions (W x D x H) Handheld meters: 9 x 20 x 5 cm (3.5 x 8 x 2 in.)
Benchtop meters: 20 x 13 x 8 cm (5 x 8 x 3 in.)
Weight Handheld meters: 1300 g (3.0 lb.)
Benchtop meters: 900 g (2.0 lb.)
Battery enclosure Water resistant
Battery requirements 4-ANSI 15 A or IEC-LR6 (AA Alkaline)
Power consumption Backlight on and Bluetooth™ active: 1 W
Backlight on and Bluetooth™ inactive: 50 mW
Power source Internal power source: 4 AA alkaline or rechargeable nickel metal hydride (NiMH)
batteries; battery life: > 200 hours External power source: 100 to 240 VAC, 50/60 Hz input; 4.5 to 7.0 VDC; 100 mA (benchtop meters only)
Storage temperature –20 to +40 °C (4 to 140 °F)
Operating temperature 5 to 40 °C (41 to 104 °F)
Operating humidity Relative humidity: 50% maximum at 25 ºC (77 ºF), non-condensing
Input connectors Handheld meters: 8-pin ISFET, BNC with phono jack temperature, 12-pin conductivity
(H170G only) Benchtop meters: 8-pin ISFET BNC with phono jack temperature, 12-pin conductivity (H270G only), 2 mm reference, USB and external AC
USB adapter Peripheral
Data memory (internal) Up to 999 measurement results at user selectable intervals from 1 to 1999 seconds
Data storage Automatic in store mode; user enables data logging mode; data is user stored, recalled
and deleted
Data export USB connection to PC; transfer the data log or as data is read
Languages English
Temperature correction Off, automatic and manual (parameter dependent)
Measurement Continuous measurement
Protection rating Handheld meters: IP67
Benchtop meters: IP42
Certifications CE
pH
Calibration Up to five points: 1.68, 4.01, 6.86, 7.00, 9.18, 10.01, 12.45
Accuracy ±0.01 pH
Resolution 0.01 pH
Range -2.00 to 19.99
mV
Calibration None
Accuracy ±1 mV
English 3
Specification Details
Resolution Autoranging, 0.1 and 1
Range Autoranging, ±199.9 mV to ±1999 mV
Temperature
Calibration None
Accuracy ±0.5 °C
Resolution 0.1 °C (0.1 °F)
Range -5 to 105 °C (23 to 221 °F)
ISE
Calibration Up to five points
Accuracy Probe dependent
Resolution 0.1 ppm–0.1 ppt
Range Autoranging, -0.0 ppm to 1999 ppt
Conductivity
Calibration Up to five points
Accuracy ±1% full scale or ±1 digit
Resolution 0.01 µS, 0.1 µS, 1 µS, 0.01 mS, 0.1 mS
Range Autoranging: 0.00 to 19.99 µS, 20.0 to 199.9 µS, 200 to 1999 µS, 2.00 to 19.99 mS,
20.0 to 199.9 mS
TDS
Calibration Up to five points
Accuracy ±1% full scale or ±1 digit
Resolution 0.01 ppm, 0.1 ppm, 1 ppm, 0.01 ppt, 0.1 ppt, 1 ptt, 0.1 mg/L, 1 mg/L, 0.01 gal/L,
0.1 gal/L
Range Autoranging, ppm: 0.00 to 9.99 ppm,10.0 to 99.9 pm,100 to 999 ppm,1.00 to 9.99 ppt,
10.0 to 99.9 ppt,100 to 200 ppt mg/L: 0.00 to 199.9 mg/L, 200 to 1999 mg/L, 2.00 to 19.99 gal/L, 20 to 50 gal/L
Salinity
Calibration None (derived from conductivity)
Accuracy ±0.1 ppt (–2 to +35 °C or 28.4 to 95 °F)
Resolution 0.1 ppt, 1%
Range 0 to 42, ppt 0 to 4.2%
Dissolved oxygen
Calibration One or two points, user-selectable to any value
Accuracy ±1.5% full scale
Resolution 0.1%, 0.01 ppm or mg/L
Range 0.0% to 199.9% saturation, 0 to 19.99 ppm or mg/L
Salinity correction: automatic with conductivity probe
Barometric pressure compensation: automatic
4 English
Specification Details
Barometric pressure
Calibration Factory calibration
Accuracy ±1.5 hPa (10 to 40 °C or 50 to 104 °F)
Resolution 1 mm Hg or 1 hPa 0.01 in Hg±
Range 225 to 900 mm Hg or 300 to 1200 hPa (8.86 to 35.43 in. Hg)
General information
In no event will the manufacturer be liable for direct, indirect, special, incidental or consequential damages resulting from any defect or omission in this manual. The manufacturer reserves the right to make changes in this manual and the products it describes at any time, without notice or obligation. Revised editions are found on the manufacturer’s website.
Safety information
N O T I C E
The manufacturer is not responsible for any damages due to misapplication or misuse of this product including, without limitation, direct, incidental and consequential damages, and disclaims such damages to the full extent permitted under applicable law. The user is solely responsible to identify critical application risks and install appropriate mechanisms to protect processes during a possible equipment malfunction.
Please read this entire manual before unpacking, setting up or operating this equipment. Pay attention to all danger and caution statements. Failure to do so could result in serious injury to the operator or damage to the equipment.
Make sure that the protection provided by this equipment is not impaired. Do not use or install this equipment in any manner other than that specified in this manual.
Use of hazard information
D A N G E R
Indicates a potentially or imminently hazardous situation which, if not avoided, will result in death or serious injury.
W A R N I N G
Indicates a potentially or imminently hazardous situation which, if not avoided, could result in death or serious injury.
C A U T I O N
Indicates a potentially hazardous situation that may result in minor or moderate injury.
N O T I C E
Indicates a situation which, if not avoided, may cause damage to the instrument. Information that requires special emphasis.
Precautionary labels
Read all labels and tags attached to the instrument. Personal injury or damage to the instrument could occur if not observed. A symbol on the instrument is referenced in the manual with a precautionary statement.
English 5
This is the safety alert symbol. Obey all safety messages that follow this symbol to avoid potential injury. If on the instrument, refer to the instruction manual for operation or safety information.
This symbol indicates that a risk of electrical shock and/or electrocution exists.
Electrical equipment marked with this symbol may not be disposed of in European public disposal systems after 12 August of 2005. In conformity with European local and national regulations (EU Directive 2002/96/EC), European electrical equipment users must now return old or end-of-life equipment to the Producer for disposal at no charge to the user.
Note: For return for recycling, please contact the equipment producer or supplier for instructions on how to return end­of-life equipment, producer-supplied electrical accessories, and all auxiliary items for proper disposal.
Certification
Canadian Radio Interference-Causing Equipment Regulation, IECS-003, Class A:
Supporting test records reside with the manufacturer.
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de classe A répond à toutes les exigences de la réglementation canadienne sur les équipements provoquant des interférences.
FCC Part 15, Class "A" Limits
Supporting test records reside with the manufacturer. The device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions:
1. The equipment may not cause harmful interference.
2. The equipment must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications to this equipment not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at their expense. The following techniques can be used to reduce interference problems:
1. Disconnect the equipment from its power source to verify that it is or is not the source of the interference.
2. If the equipment is connected to the same outlet as the device experiencing interference, connect the equipment to a different outlet.
3. Move the equipment away from the device receiving the interference.
4. Reposition the receiving antenna for the device receiving the interference.
5. Try combinations of the above.
Product overview
N O T I C E
Always disconnect power to the meter when electrodes are changed. Only use the meter as instructed in this manual or the meter performance can decrease.
The H-series handheld and benchtop meters operate with glass sensor electrodes with BNC connectors or non-glass probes with ISFET (ion sensitive field effect transistor) silicon chip sensors.
6 English
The meters use one pH electrode (a BNC pH electrode or an ISFET pH probe) at a time. When the meter power is set to on, the meter automatically identifies the type of electrode that is attached.
The H-Series meters are available in eight models:
• Waterproof handheld meters with Bluetooth™ technology. Refer to Figure 1:
• H160G—pH and ORP
• H170G—pH, ORP, conductivity, TDS and salinity
Benchtop meters with a USB output. Refer to Figure 2:
• H260G—pH and ORP
• H270G—pH, ORP, conductivity, TDS and salinity
• H280G—pH, ORP, conductivity, TDS, salinity and dissolved oxygen (DO)
• Benchtop meters with Bluetooth™ technology and a USB output. Refer to Figure 2:
• H260GB—pH and ORP
• H270GB—pH, ORP, conductivity, TDS and salinity
• H280GB—pH, ORP, conductivity, TDS, salinity and DO
Note: The difference between the benchtop meters is that the GB benchtop meters have Bluetooth™ technology and a USB output, and the G benchtop meters only have a USB output. Unless noted, when the benchtop series is documented in this manual, the benchtop meter includes all of the H-series benchtop meters (both the G and the GB benchtop meters).
Figure 1 Handheld meter
1 Rubber dust caps 5 ISFET pH probe connector (8-pin)
2 Conductivity probe connection (12-pin, H170G only) 6 LCD display
3 BNC probe connector 7 Power button
4 3.5 mm phono jack for glass pH electrode, ISE,
ORP or DO temperature sensors
8 Battery cover
English 7
Figure 2 Benchtop meter
1 Power button 6 ISFET pH probe connector
2 Conductivity probe connector (12-pin, H270G and
H280G only)
7 AC power connector
3 USB connector 8 External reference connector
4 3.5 phono jack for glass pH electrode, ORP, ISE or
DO temperature sensors
9 LCD display
5 BNC connector for glass pH electrode, ISE, ORP or
DO (H280G only) probes
10 Battery cover
Product components
Make sure that all components have been received. Refer to Figure 3. If any items are missing or damaged, contact the manufacturer or a sales representative immediately.
8 English
Figure 3 Handheld and benchtop meter components
1 Waterproof handheld meter 4 Benchtop meter
2 SmartLogger II software 5 USB cable
3 AA Alkaline batteries (4x) 6 AC-DC power supply kit (power supply and three
plugs: US, EU, UK)
Installation
C A U T I O N
Multiple hazards. Only qualified personnel must conduct the tasks described in this section of the document.
Electrical installation
Connect to AC power
D A N G E R
Electrocution hazard. If this equipment is used outdoors or in potentially wet locations, a Ground Fault Circuit Interrupt (GFCI/GFI) device must be used for connecting the equipment to its main power source.
English 9
Loading...
+ 25 hidden pages
