Haan MS-35 User Manual

name: Complete

model number: MS-35

Professional steam cleaner

for multipurpose cleaning.

Instruction Manual

HAAN® Corporation

1828 William Penn Way Lancaster, PA 17601

phone: 877-422-6347

www.HAANusa.com

MS35_IS0036

HAAN® is a registered trademark of the HAAN® Corporation.

HAAN® Experience Steam. Discover Clean.™ is a trademark of the HAAN® Corporation.

Notice

The information contained in this document is subject to change without notice.

HAAN® Corporation assumes no responsibility for any errors that may appear in this document nor does it make expressed or implied warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and ﬁtness for a particular purpose.

HAAN® Corporation shall not be liable for incidental or consequential damages in connection with or arising out of the furnishing, performance, or use of this document and the program materials which it describes.

Introduction

Congratulations on purchasing the HAAN® MS-35 Complete Multi-Function steam cleaner. From the house to the garage, the Complete brings you an easy way to steam clean your hard surface floors, as well as dozens of other surfaces, including all the nooks and crannies throughout your home.

The Complete uses steam to remove tough grease, dirt and grime. Steam is nature’s purest and most powerful cleaner for safely cleaning all hard surfaces in your home without harsh chemicals, for a perfectly ecological approach. No film, no residue – just clean, germ-free surfaces.

The HAAN® Complete is so easy to assemble, you can put it to use right away – anywhere you want to clean and sanitize – from your kitchen and living room to your bathroom floors.

Look for the HAAN® “steamlet” symbol in this manual for Helpful HAAN® Hints that will help you make the most of your new HAAN® Complete Steam Cleaner.

Backed with a one-year limited warranty, your quality HAAN® Complete is sure to give you years of dependability. And our Customer Care representatives are available to answer any of your questions about your new steam cleaner.

Thousands of customers have already fallen in love with HAAN® steam products. We’re conﬁdent you will, too.

Thank you again for purchasing the HAAN® Complete Multi-Function steam cleaner.

The HAAN® Team

www.haanusa.com 877-HAAN DIRECT / 877-422-6347 pg 1

Clean and sanitize nearly every surface in your home with the awesome power of steam!

Important Safety Information

pg 2 877-HAAN DIRECT / 877-422-6347 www.haanusa.com

Basic precautions should be observed when using an electrical appliance, including the following:

1. Do not direct steam at people, animals, or at electrical

outlets.

2. Do not expose to rain or use outdoors. Store indoors.

3. Never leave your product in one spot on any surface for any period of time. Always place on the ﬂoor protector pad and make sure that the product is turned off.

4. Unplug from outlet when not in use and before conducting maintenance or troubleshooting.

5. Do not leave product unattended.

6. Do not leave the product connected to an electrical outlet when not in use.

7. Do not service product when it is plugged in.

8. Do not use with damaged cord or plug.

9. Do not use product if it has been dropped, damaged, left outdoors or dropped into water. Return to a service center.

10. Do not handle product with wet hands.

11. Do not pull or carry by cord, use cord as a handle, close door on cord, bend the cord excessively, pull cord around sharp corners, place heavy objects on it or expose cord to heated surfaces. If the power cord has become knotted and, or worn, contact the service center for a replacement power cord.

12. Do not unplug by pulling on cord. Unplug by grasping the plug, not the cord.

13. Do not use appliance in an enclosed space ﬁlled with vapor given off by oil-base paint thinner, some moth-prooﬁng substances, ﬂammable dust, or other explosive or toxic vapors. When is use, never turn the product over on its side.

14. Do not allow to be used as a toy. Pay close attention when used near children, pets or plants. Do not leave your product unattended while plugged in.

15. Do not use on leather, wax polished furniture or ﬂoors, synthetic fabrics, velvet or other delicate, steam-sensitive materials.

FOR MULTIPURPOSE CLEANING

IMPORTANT

Be sure to read ALL instructions and warnings before use.

SAVE THESE INSTRUCTIONS

CAUTION

The MS-35 emits steam at 212˚F to sanitize the area of use. This means that the steam head, UltraMicroFiber Pads and attachments get very hot during use. Care should be taken when using this appliance and DO NOT touch them during use except in the approved manner as outlined in this manual.

Risk of electrical shock be sure to read and follow all instructions and warnings.

WARNING

16. Do not immerse in water or any other liquids.

17. Do not use for any purpose other than described in this User Manual. Use the product only for its intended use and only as described in this manual.

18. Use only manufacturer’s recommended attachments – use of attachments not provided or sold by HAAN® may cause ﬁre, electric shock or injury.

19. Never put any aromatic oils or perfumes, chemicals, alcohol or detergent products into the steam cleaner, except those approved by HAAN®. Non-approved additives may damage the unit or make it unsafe for use.

20. Do not put any foreign objects into openings. Do not use with any opening blocked.

21. If the circuit breaker activates while using the steam function, discontinue product use immediately and contact the customer support center. (Beware of the risk of electrical shock.)

22. Do not allow the product to be disassembled and/ or modiﬁed by anyone other than an authorized service technician. (Doing so can result in ﬁre and/ or electrical shock.)

23. Never use your product on hard surface ﬂoors without the Ultra-Microﬁber Pad or the Carpet/Rug attachment in place.

Grounding Instructions:

The HAAN® MS-35 must be connected to a grounded (3-prong) wiring system. Grounding provides a safe path of least resistance for electrical current, in the event the unit should malfunction or break down, thereby reducing the risk of electrical shock. The cord for this product has an equipmentgrounding conductor and a grounding plug. Do not plug it into an outlet that is not properly installed and grounded in accordance with all local codes and ordinances.

Check with a qualified electrician or service person if you aren’t sure if the outlet is properly grounded. If it will not fit the outlet, have a proper outlet installed by a qualified electrician. This appliance is designed for use on a nominal 120-volt circuit and has a grounding attachment plug as illustrated above. Make certain that the appliance is connected to an outlet having the same configuration as the plug. No

plug adapter should be used with this appliance.

WARNING

IMPORTANT

DO NOT modify the plug. Improper connection of the equipment-grounding conductor can result in a risk of electrical shock.

www.haanusa.com 877-HAAN DIRECT / 877-422-6347 pg 3

Grounded Outlet

Grounded Pin

WARNING

To avoid circuit overload, DO NOT operate another appliance on the same electrical outlet (circuit).

CAUTION

DO NOT operate your product if the power indicator light ﬂickers. Contact the

HAAN® Customer Care

Center at the number shown below.

Important Safety Information

Product Description

pg 4 877-HAAN DIRECT / 877-422-6347 www.haanusa.com

➟

1. Power Button - for easy ON/OFF steam operation.

2. Power Light - indicates when the unit is on.

3. Steam Ready Light - lets you know when the unit is ready to begin steaming.

4. Water Tank Cap - extra-large for a sure grip when removing to fill tank and when tightening before use.

5. Storage Compartment - for convenient storage of many MS-35 accessories.

6. Ergonomic Handle - designed to be comfortable and stay cool.

7. Steam Trigger - releases the steam in a hot, pentrating spray to tackle your sanitizing, ﬂoor to ceiling.

8. Steam Lock Switch - pushes forward easily to lock the Steam Trigger down and provide continuous steam.

9. Carry Handle -perfect for carrying the unit up stairs or from one room to another.

10. Steam Hose - ribbed for ﬂexibilty it stays cool while channeling the ﬂow of steam from the main unit to the Steam Nozzle or Steam Head.

11. Snap-Lock Connection - found inside at the handle and on each Extension Pole, they are specially designed to connect all MS-35 attachments.

12. Connection PUSH Buttons (3) - quick, secure connections click poles together, attach accessories with ease and allow for easy changes.

13. Extension Poles (2) - to attach individual accessories for special cleaning tasks or click together to create a long pole for ﬂoor cleaning.

14. Floor and Countertop Steam Head - for cleaning hard-surface ﬂoors and other large surfaces.

15. Cord Storage Compartment - convenient storage for power cord

FEATURES:

www.haanusa.com 877-HAAN DIRECT / 877-422-6347 pg 5

HELPFUL HAAN® HINT:

12 Powerful Steam Jets are spaced perfectly to cover more ﬂoor in less time. Be assured you are steam cleaning when you push the machine forward, as well as when you are pulling it back.

HELPFUL HAAN® HINT:

To extend the life of your Ultra-MicroFiber Pads, always place your unit on the ﬂoor protector/resting pad while the unit heats up, and attach the UltraMicroFiber pad when the unit is ready to use.

HELPFUL HAAN® HINT:

Using the product with the Carpet Attachment will not lift all set-in stains from your carpet but our patented Ultra-MicroFiber Pad may be used to act as a “blotter” for removing most fresh, wet spills and stains.

Product Description

Deluxe Accessory Kit

Product Description

pg 6 877-HAAN DIRECT / 877-422-6347 www.haanusa.com

➟

Snap ON; Snap OFF

Connection PUSH Button

Items packaged in white accessory bag:

8, 9, 10, 11, 12, 13, 14

Items packaged in storage compartment of canister:

3, 4, 5, 6, 7

1. Extension Poles (2) - to attach individual accessories for special cleaning tasks or click together to create the perfect length for every steaming job.

2. Floor and Countertop Steam Head (1) - for cleaning hard-surface ﬂoors and other large surfaces.

3. Attachment/Steam Jet Nozzle (1) - focuses the spray of steam from the unit and serves as the base to which all other accessories are connected.

4. Large Scrub Brush (1) - makes fast work cleaning larger surfaces and objects.

5. Angled Nozzle (1) -gets under rims and into corners.

6. Small Detail Brush (1) - perfect for delicate surfaces and small nooks & crannies.

7. Round Wire Bristle Brush (1) - for tough scrubbing chores, including brick or cement.

8. Ultra-Microber Cleaning Sock - attaches to Garment/Surface Attachment to clean counter tops and other hard surfaces.

9. Garment/ Flat Surface Attachment (1) - use for steaming out wrinkles in clothing, sanitizing upholstery, bedding and soft surfaces; use with cleaning sock to clean counter tops and other hard surfaces.

10. Concentrator Nozzle (1) - the copper-tipped head concentrates the steam for even more cleaning power. All brush and nozzle accessories attach to this for use.

11. Steel Wool Brush Attachment (1) - adds extra scrubbing power for surfaces that resist normal cleaning, like removing baked on food from grill and oven racks.

12. HAAN® MicroCham™ Towel (1) - designed to easily wipe away the dirt and absorb the moisture after the MS-35 steams it loose.

13. HAAN® MicroCham™ Sponge (1) - has the cleaning power of our Ultra-Microﬁber and the super absorbency of our specially-developed chamois.

14. Rubber Squeegee Panel for Window Cleaning (1) - attaches to Flat Surface Attachment to clean mirrors and windows.

15. Tile, Grout & Rough Surface Brush (1) - gets down into areas that normally get passed over by other surface attachments and breaks up hard-to-reach dirt.

16. Carpet & Rug Tray (1) - glides over carpet and rugs to freshen, sanitize and steam away many spots.

17. Floor Protector Resting Mat (1) - keeps your ﬂoors safe and dry while waiting for your Steam Head to heat up.

18. Multi-layer Microber Glass & Mirror Cleaning Sock (1) - slips on Steam Head for cleaning windows, mirrors, glass shower doors and much more.

19. Ultra-Microber Pad (2) - easily attach to the Steam Head for safely steam cleaning hard-surface ﬂoors.

20. Precision Filling Cup (1) - one cupfull ﬁlls the tank correctly.

21. Funnel (1) - allows for ﬁlling the water tank without spills.

www.haanusa.com 877-HAAN DIRECT / 877-422-6347 pg 7

Product Description

The MS-35 Complete includes the Deluxe Accessory Kit. Make sure to check for all your accessories:

Assembling Your Product

To make sure you are completely satisfied with the operation of your MS-35 Complete, be sure to follow the assembly and operating instructions included in this manual. Read this manual thoroughly before assembling your unit.

Pay specific attention to the product description and familiarize yourself with all the parts of your product. Locate and organize the parts of the unit before assembling. No additional tools are needed to put the unit together. It is quick and easy.

Look for the small orange button that says PUSH on the handle of the unit. Align one of the extension poles (with the hole in the front) with the orange button and slide it onto the end of the handle until the orange PUSH button snaps up into place in the hole. You will notice the PUSH button is sloped on the bottom to allow it to slide into the pole easily. Be careful not to pinch your fingers between the pieces when pushing the two together.

Align the second extension pole in the same manner and repeat the process by snapping it into place. There are ridges on the sides that correspond to indents inside to assist in sliding the pieces together.

pg 8 877-HAAN DIRECT / 877-422-6347 www.haanusa.com

Finally, attach the Floor /Countertop Steam Head to the end of two joined extension poles by sliding the front of the head onto the orange PUSH button until it snaps into place. Use the side ridges and internal indents to guide it into place.

To assemble the MS-35 for use as a steam cleaning ﬂoor sanitizer, follow these easy steps:

PUSH

➟

Sloped for ease

www.haanusa.com 877-HAAN DIRECT / 877-422-6347 pg 9

WARNING

Your product is designed to clean hard floor surfaces that will withstand high heat. Do not use on unsealed wood or unglazed ceramic ﬂoors. On surfaces that have been treated with wax or some no-wax floors, the sheen may be removed by the heat and steam action. It is always recommended to test an isolated area of the surface to be cleaned before proceeding. We also recommend that you check the use and care instructions from the ﬂoor manufacturer.

HELPFUL HAAN® HINT:

Never leave the appliance in one spot on any surface for any period of time. Always place your product on the Floor Protector/ Resting Mat when stationary and make sure the product is turned off not in use.

CAUTION

Use a grounded receptacle. Use only a heavy duty extension cord rated for 15 amps minimum – DO NOT use an ordinary extension cord. To provide continued protection against the risk of electric shock, connect to properly grounded outlet only.

This product is NOT for space heating purposes.

IMPORTANT

HELPFUL HAAN® HINT:

DO NOT add cleaning solutions, scented perfumes, oils or any other chemicals to the water used in this appliance except for those authorized by HAAN®. While it is acceptable to use regular tap water, if the tap water in your area is hard, we recommend you use distilled/puriﬁed water to extend the life of your appliance. Always empty water from water tank after use and before storing.

Always be sure that your product is UNPLUGGED from the wall receptacle prior to ﬁlling the water tank.

Never use your MS-35 on your ﬂoors without the Ultra-Microﬁber Pad attached to the base, unless you are using the Carpet & Rug Attachment for carpet and soft surfaces.

The MS-35 emits steam at 212˚F to sanitize the area of use. This means that the steam head, Ultra-Microfiber Pads and attachments get very hot during use. Care should be taken when using this appliance and DO NOT touch them during use except in the approved manner as outlined in this manual.

IMPORTANT

Be sure to read ALL instructions and warnings before using your HAAN® product.

CAUTION

Before Using Your Product

This unit uses a grounded (3-prong) electrical plug. Use only in properly installed 3-prong electrical outlets. DO NOT attempt to alter plug or circumvent safety feature in any way.

CAUTION

Using Your Product

pg 10 877-HAAN DIRECT / 877-422-6347 www.haanusa.com

1) Remove all parts from the packaging.

2) Assemble the unit as described on page 6, attaching both extension poles (a & b)and the Steam Head (c).(Fig 1)

3) Place the canister on a flat, level surface.

4) Place the Steam Head on the black Floor Protector Mat; be sure the “bumpy” side is facing up(Fig 2). Never rest the Steam Head on an unprotected surface

5) Remove the Water Tank Cap. The tank becomes pressurized with use so you will need to press down as you turn at first. After the first couple of turns you will be able to remove the cap easily.

The ﬁll cup included holds 450 ml /15 oz of water. Using the provided fill cup, pour one cupful of water at a time into the tan through the fill hole. DO NOT ﬁll the cup above the 450 ml line. A funnel is provided among the accessories to help eliminate spillage. Depending on how long you intend to steam, you may add additional water to have a maximum of 900ml/30 oz. (2 ﬁll cups) of water in the tank without overﬁlling. (Fig 3)

NOTE: 296ml/10 ounces of water will give you about

15 minutes of steam while 591ml/20 ounces of water will provide approximately 30 minutes of steam.

Do not overﬁll. You can see the water level by looking into the opening to the Water Tank. You do not want to allow the water level to come above the threads in the screw opening.

IMPORTANT: One problem with a steamer appliance is the mineral deposits caused by the high mineral content in many municipal water supplies. Mineral residue inside of the internal system and heater can cause intermittent steaming or, in some cases, no steam at all.

To reduce or eliminate the occurrence of mineral deposits, we recommend the use of de-mineralized or distilled water in the unit. However, regular tap water may be used.

6) Replace the cap tightly when you have finished filling the water tank.

Using the product

to sanitize your oor:

Fig 1

Fig 2

Fig 3

Opening to Tank

Always be sure that your product is UNPLUGGED from the wall receptacle prior to ﬁlling the water tank.

IMPORTANT

➟
