DIGITAL
MUSIC PLAYER
MPaxx 900 series
MPaxx 910
MPaxx 920
MPaxx 940
MPaxx 980
en
CONTENTS
--------------------------------------------------------------------------------------------------------------------------------------------
3 MPAxx 900 series
Supplied accessories
Special features
Safety
Environmental note
4 OVERVIEW
Controls
6 CONNECTION AND PREPARATION
Power supply
Connecting to a computer
Disconnecting from the computer
Connecting earphones
8 General functions
Switching on and off
Adjusting the volume
Activating and deactivating the key lock
Resetting the player
9 MUSIC PLAYBACK
Starting music playback
Playback functions
Selecting tracks
Fast forward and reverse search
Selecting sound settings
Repeat Function
Shuffle Function
10 Operating with a computer
System requirements
MP3/WMA data transfers
11 INFORMATION
Technical data
2
MPAXX 900 SERIES
Supplied accessories
1 Stereo earphones
2 USB cable
3 Brief instructions
Note:
The accessory components supplied can change.
Special features
Combined MP3/WMA player and USB removable medium.
Safety
This device is designed to play music files and serves as a removable storage
medium. Any other use is expressly prohibited.
---------------------------------------------------------------------------------------------
Do not drop the device.
Do not place the device near magnetic objects.
Make sure that the equipment is protected from moisture (dripping or splashing
water), sunlight and heat.
Do not expose the batteries to extreme heat, caused for example by direct sunlight, heaters or fire.
Keep the player out of the reach of babies and small children. There is a risk
that they may swallow it.
Never open the device casing. No warranty claims are accepted for damage
caused by improper handling.
Note:
Do not use the player if you are a motorist, cyclist or pedestrian etc. in traffic.
This impairs road safety.
Environmental note
This product has been made from high-quality parts and materials which can be
re-used and recycled.
Therefore, do not dispose of the product along with normal household waste at
the end of its service life. Take it to a collection point for the recycling of electrical
and electronic equipment. The symbol on the product, in the operating manual
or on the packaging indicates that recycling is possible.
Please find out about collection points operated by your local authority.
Help protect the environment by recycling used products.
ENGLISH
3
OVERVIEW
-------------------------------------------------------------------------------------------------------------------------------------------
Controls
1
4
3
5
1
0 Connecting socket for the stereo earphones.
2
+ In playback mode: press briefly to increase the volume incre-
2
6
mentally; press and hold down to switch between various sound
effects.
3
Λ
In playback mode: press briefly to select the previous track;
press and hold down to start the reverse search;
4
Press and hold down to switch the player on and off.
In playback mode: switches to pause; resumes playback.
5
– In playback mode: press briefly to reduce the volume incremen-
tally; press and hold down to activate or deactivate the key lock.
6
V
In playback mode: press briefly to select the next track;
press and hold down to start the forward search.
4
10
OVERVIEW
-------------------------------------------------------------------------------------------------------------------------------------------
7
8
9
7
LED indicator: flashes up during charging or playback; lights up
constantly when the battery is fully charged; lights up constantly
when playback is paused.
(
8
USB socket for connecting the player to the computer or standard
USB charger using a USB cable.
9
RESET Resets the player.
10
Clip for fastening the player to your belt.
ENGLISH
5
CONNECTION AND PREPARATION
Power supply
The player operates with the integrated lithium-polymer battery 1 x 3.7 V,
150 mA.
Charging the battery
Charge the battery for the player on a computer.
You can also charge the battery by connecting it to a USB-compatible hi-fi system using a USB cable.
Note:
When charging with a standard USB adapter, the player is still ready for
operation. Press »
1 Connect the USB socket on the player to the USB socket on the computer or
hi-fi system using the USB cable or plug the charger lead into the USB socket
of the player.
2 Switch on the computer or hi-fi or connect the charger to the power supply.
– The LED on the player flashes during the charging procedure. The charging
time is approximately four hours. When the battery is fully charged, the
LED lights up constantly.
« to switch to playback mode.
-----------
Note:
The playing time is more than 15 hours when the player is fully charged.
Note:
There is a risk of explosion if the battery is not replaced properly. Only use
the same type of battery or an equivalent.
Connecting to a computer
1 Switch on the computer.
2 Switch off the player.
3 Connect the USB socket on the player to the USB socket on the computer
using the USB cable.
– A display appears on the computer screen as soon as the connection is
made.
Note:
If the player is connected to the computer, you can select »
playback mode. The player icon then goes out on the computer screen. If
you want to transfer data again, you must connect the player to the computer again.
« to switch to
6
CONNECTION AND PREPARATION
Disconnecting from the computer
If there is no data transfer in progress, you can disconnect the player from the
computer.
You must first remove the player from the Windows desktop by following the
Windows instructions for “Removing hardware”.
Note:
Do not disconnect the player from the computer while data transfer is in
progress. This can damage the data irreparably.
1 Double click the icon for removing hardware.
– The “Remove hardware” window appears.
2 To continue, follow the instructions on the screen.
Note:
The circuits of the player and the computer can be seriously damaged if
you do not follow the instructions for Windows ME / 2000 / XP / Vista /
Windows 7.
-----------
Connecting earphones
1 Plug the earphones into the »0« socket on the player.
Note:
Prolonged listening at loud volumes with the earphones can damage your
hearing.
ENGLISH
7
GENERAL FUNCTIONS
Switching on and off
1 To switch on the player, press and hold down » «.
– The LED switches on and starts flashing.
– Playback then starts automatically (playback always starts with the first
track in the root directory – if there is one).
– The LED flashes during playback.
-------------------------------------------------------------------------------
2 To switch off the player, press »
– The LED goes out.
Notes:
When you switch the player on again, playback starts at the same point as
when it was switched off.
The player automatically switches off when the battery is low.
« and hold it for 2 seconds.
Adjusting the volume
1 To adjust the volume, press »+« or »–« as many times as necessary during
playback.
Activating and deactivating the key lock
When the key lock is activated, all the buttons on the player are disabled.
1 To activate the key lock, press and hold down »
2 To deactivate the key lock, press and hold down »
«.
–
« again.
–
Resetting the player
In the event of a malfunction during operation or if the player no longer responds to key commands, you can reset the player.
1 To reset the device, use a pointed object such as a paper clip to press
»RESET«.
Note:
When resetting, the player should not be connected to the computer or the
USB charging device.
8
MUSIC PLAYBACK
Starting music playback
When you switch on the player, playback automatically starts with the first track
in the root directory, if there is one.
– The LED flashes during playback.
– All the music files are played in succession.
Playback functions
1 To pause playback, briefly press » «.
– The LED lights up constantly.
----------------------------------------------------------------------------------------------------
2 To resume playback, briefly press »
– The LED flashes.
3 To end playback, switch of the player by pressing »
2 seconds).
– The LED goes out.
« again.
« (and holding it down for
Selecting tracks
1 To select the previous or next track, briefly press »Λ« or »V«.
Fast forward and reverse search
1 To search for a passage in a track, press and hold »Λ« or »V« during playback.
– The fast forward or reverse search begins. Release »
you want.
« or »V« at the position
Λ
Selecting sound settings
You can choose between the preset sound settings Jazz, Rock, Classic, Pop and
Bass.
1 To switch between the sound effects, press and hold »
«.
+
Repeat Function
While music playing is paused
1 Press the »+« button.
2 Press the »
– The player will repeat all songs.
G
« button to resume playing.
Shuffle Function
While music playing is paused
1 Press the »–« button.
2 Press the »
G
« button to resume playing.
ENGLISH
9
OPERATING WITH A COMPUTER
System requirements
When connected to a computer, the player appears as a removable disk drive.
This corresponds to the player’s flash memory. Your computer should meet the
following requirements:
– Windows 2000 / ME / XP / Vista / Windows 7, Mac OS 10 or higher,
Linux Kernel 2.6.
– Microsoft DirectX 9.0 or higher
– Microsoft Media Player 9.0 or higher
– CD-ROM drive 4x or higher
– Pentium MMX 200 or higher
– Minimum 120 MB free hard disk memory
– USB interface
MP3/WMA data transfers
1 Select the MP3/WMA files on your computer for copying.
------------------------
2 Highlight the files.
3 Right-click and select »Copy«.
4 Open a removable disk drive (e.g. H:) on your computer.
5 Right-click the mouse to transfer the files onto the removable disk drive
(e.g. H:).
Note:
WMA files protected by DRM (Digital Rights Management) cannot be played.
10
INFORMATION
Technical data
This product fulfils the European directive 2004/108/EC.
The type plate is located on the back of the device.
--------------------------------------------------------------------------------------------------------------------
Power supply
Rechargeable battery: 1 x 3.7 V,
lithium polymer
Output
2 x 5 mW/32 Ohm (earphones)
Noise voltage ratio
≥ 85 dB
Internal memory
MPaxx 910: 1 GB
MPaxx 920: 2 GB
MPaxx 940: 4 GB
MPaxx 980: 8 GB
Technical and design modifications are reserved.
Technical and design modifications reserved.
MP3/WMA
Formats: MP3, WMA (playback)
MPEG bit rates: 8-320 kbps
WMA: 32-384 kbps
File system: FAT/FAT 32
USB
USB PC: 2.0 High Speed
Frequency response
20 Hz ... 20 kHz
Dimensions and weight
L x W x H: 43.0 x 34.2 x 9.0 mm
(14 mm with clip)
Weight approx. 0.025 kg
ENGLISH
11
www.grundig.com
10/11 72011 408 9000
