PROGRAMMABLE COFFEE
MAKER
KM 7280
KM 7280 W
ENGLISH
EN
________________________________________________________________________________
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
3
SAFETY AND SET-UP _______________________
Please read this instruction
manual thoroughly prior to
using this appliance! Follow all
safety instructions in order to
avoid damage due to improper
use!
Keep the instruction manual for
future reference. Should this
appliance be given to a third
party, this instruction manual
must also be handed over.
█
This appliance is intended to
be used in household only.
It is not designed for professional use in:
- staff kitchen areas in shops,
offices and other working
environments;
-farm houses;
- by clients in hotels, motels,
and other residential type
environment
- bed and breakfast type environment.
█
Do not use the appliance in
the bathroom.
█
Check if the mains voltage on
the rating label corresponds
to your local mains supply.
The only way to disconnect
the appliance from the mains
is to pull the plug from the wall
socket.
4
ENGLISH
█
For additional protection, this
appliance should be connected to a household current
fault protection circuit breaker
of no more than 30 mA. Consult an electrician for advice.
█
Do not immerse the appliance,
power cord, or power plug
in water or any other liquids.
Do not hold it under running
water and do not clean any
parts in the dishwasher. Only
the filter basket and glass jug
can be cleaned safely in the
upper shelf of the dishwasher
or with water and washing-up
liquid.
█
Disconnect the power plug
after using the appliance, before cleaning the appliance,
before leaving the room, or if
a fault occurs. Do not disconnect the plug by pulling on the
cord.
█
Do not squeeze or bend the
power cord and do not rub
it on sharp edges in order to
prevent any damage.
█
Keep the power cord away
from hot surfaces and open
flame.
SAFETY AND SET-UP _______________________
█
Do not use an extension cord
with the appliance.
█
Never use the appliance if the
power cord or the appliance
is damaged.
█
Our GRUNDIG Household
Appliances meet applicable
safety standards, thus if the
appliance or power cord is
damaged, it must be repaired
or replaced by an authorised
service centre to avoid any
dangers. Faulty or unqualified
repair work may be dangerous and cause risk to the user.
█
Do not dismantle the appliance under any circumstances. No warranty claims
are accepted for damage
caused by improper handling.
█
Always keep the appliance
and its cord out of reach of
children aged less than 8
years.
█
This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe
way and understand the hazards involved. Cleaning and
user maintenance shall not be
made by children unless they
are older than 8 and supervised.
█
Children shall not play with
the appliance.
█
Before using the appliance for
the first time, clean all parts
which come into contact with
water or coffee carefully.
Please see full details in the
“Cleaning and Care” section.
█
Dry the appliance and all accessories before connecting it
to mains supply and before attaching any parts.
█
Never operate or place any
part of this appliance on or
near hot surfaces such as a
gas burner, hotplate or heated
oven.
ENGLISH
5
SAFETY AND SET-UP _______________________
█
Do not use the appliance
for anything other than its intended use. The coffee maker
is designed for preparing
coffee. Do not use the appliance to heat any other liquids
or tinned, jarred, and bottled
foods.
█
Never use the appliance in or
near to combustible or inflammable places and materials.
█
Operate the appliance only
with the delivered parts.
█
Do not use the appliance with
damp or wet hands.
█
Always use the appliance on
a stable, flat, clean dry, and
non-slip surface.
█
Make sure that there is no
danger that the power cord
could be accidentally pulled
or that someone could trip
over it when the appliance is
in use.
█
Position the appliance in such
a way that the plug is always
accessible.
█
Avoid contact with hot surfaces and hold the glass jug
by the handle only as there
is the danger of burning. The
glass jug becomes hot during
use.
█
Do not move the appliance
while there is hot liquid in the
glass jug or if the appliance is
still hot.
█
Do not open the cover or filter basket during the brewing
process.
█
Never fill the appliance above
the maximum level indicator.
If it is filled above the maximum level, water flows out of
the appliance through safety
drainage.
█
Never operate the appliance
if no coffee is brewed or kept
warm.
█
Only fill the appliance with
cold and fresh drinking water.
█
The appliance should not be
operated with an external
clock timer or separate remote
control system.
█
Use the glass jug only with the
coffee maker.
█
Never operate the appliance
without water inside.
█
Do not use a cracked glass
jug or a glass jug with a loose
or weakened handle.
6
ENGLISH
AT A GLANCE _____________________________
Dear Customer,
Congratulations on the purchase of your new
GRUNDIG Programmable Coffee Maker
KM 7280 / KM 7280 W.
Please read the following user notes carefully to
ensure full enjoyment of your quality Grundig
product for many years to come.
A responsible approach!
GRUNDIG focusses on contractually agreed social working conditions with fair wages for both
internal employees and suppliers.
We also attach great importance
to the efficient use of raw materials
with continuous waste reduction of several tonnes
of plastic every year. Furthermore, all our accessories are available for at least 5 years.
For a future worth living.
For a good reason. Grundig.
Controls and parts
See the figure on page 3.
A
Water tank cover
B
Filter basket cover
C
Filter basket
D
Ventilation slots
E
Water level indicator
F
Water tank
G
Drip-stop
H
Glass jug
I
Warming plate
J
Program button
K
Auto on button
L
Display
M
Setting button for minutes
N
Setting button for hours
O
Aroma button
P
On/Off button
Accessories
Coffee measuring spoon
ENGLISH
7
OPERATION ______________________________
Preparation
Caution
█
First time use: Run the appliance at least 4
times without adding coffee.
█
Please follow the steps 1 - 2 and 7 - 12 in the
“Brewing Coffee” section.
1 Remove all packaging and stickers and
dispose of them according to applicable legal
regulations.
2 Before using the appliance for the first time,
clean all parts which come into contact with
water carefully. Please see full details in the
“Cleaning and Care” section.
3 Make sure that the appliance is placed in an
upright position and on a stable, flat, clean,
dry and non-slip surface.
Brewing Coffee
1 Pull off and fill the water tank F with the
required amount of water, but do not fill past
the “12” mark. The brewed amount of coffee
will be 10% less than the filled water, because
it is absorbed by the coffee grounds and the
fillter. The scale on the glass jug is marked in
coffee cups, e.g. 4 = 4 cups. For the good
coffee taste it is suggested to operate the
appliance with at least 4 cups coffee serving.
Notes
█
Use only clean, cold and fresh drinking water.
█
There is a drip hole on the back of the water
reservoir to prevent exceeding the capacity of
the coffee maker. If you add too much water, it
will drip out from the back of the unit.
2 Close the water tank cover A and open the
filter basket cover B.
3 Pull out the filter basket C.
4 Take a suitable paper filter (1 x 4) and insert
the paper filter into the filter basket C and
close the filter basket cover B.
Note
█
Use only one paper filter at each time. Make
sure that the paper filter does not bend or fold.
5 Fill the filter with the desired amount of ground
coffee. To do this, you may use the supplied
measuring spoon.
6 Insert the filter basket C back into the housing.
7 Place the glass jug H on the warming plate I.
Caution
█
If the filter basket C is not closed or the glass
jug H is not placed accurately, the drip-stop
function will not work properly. It could cause
hot water or work hot coffee to overflow.
8 Connect the plug to the wall socket.
9 Turn the appliance on by pushing the On/Off
button P.
– The On/Off button P illuminates and the
brewing process begins.
Notes
█
The brewing process can be stopped at any
time by pushing the On/Off button P again.
█
Ventilation slots D allow the steam output. Do
not block these during use.
█
The coffee machine has a stay-warm function
and can keep the brewed coffee warm for up
to 30 minutes when the machine is switched
on. In accordance with eco design guidelines,
the machine will automatically switch itself off
after this time.
█
The appliance is equipped with a drip-stop G
located underneath the filter basket C and
enables you to briefly remove the glass jug H
to pour coffee before the water has finished
running through the machine.
8
ENGLISH
OPERATION ______________________________
Caution
█
Make sure to place the glass jug H on the
warming plate I quickly (max. 30 seconds).
Otherwise the brewed coffee from the filter
could overflow. If you want to use the glass
jug for more than 30 seconds switch off the
appliance.
█
Never pull out the filter basket C during the
brewing process even if no water is draining
from the filter. Extremely hot water or coffee
can spill out from the filter basket and cause
injury.
█
If water/coffee is not draining from the filter
basket C after several seconds with the glass
jug H properly in place I immediately unplug the unit and wait 10 minutes before opening and checking the filter basket C.
█
When the brewing process ends and the water
level indicator E is empty, there will still be
hot liquid in the filter basket C. Wait a few
minutes for the rest of the liquid to drip into the
glass jug H.
10 Remove the glass jug H from the warming
plate I as soon as the brewing process has
finished and the glass jug H is filled. The
coffee is ready.
11 To turn the appliance of, push the On/Off
button P.
12 Disconnect the appliance from the wall
socket.
Notes
█
If you want to continue the brewing process,
repeat the procedure from 1 to 12. Let the appliance cool down at least 15 minutes between
each brewing process.
█
For a better aroma, use aroma button O which
activates a unique brewing process that enhances the flavor and aroma of your coffee.
To reach this rich flavor, the coffee maker advances through several continuous cycles. This
special time-release process saturates grounds
gradually to extract the best favor and aroma.
Hints and Tips
█
Use softened or filtered water to prevent lime
build-up.
█
Store unused coffee in a cool, dry place. After
opening a package of coffee reseal it tightly to
maintain its freshness.
█
Do not reuse the coffee sediment in the filter
since this will reduce the flavour.
█
Reheating coffee is not recommended as coffee
is at its peak flavour immediately after brewing.
Automatic brewing
Note
█
In order to use the auto brew function you must
first set the clock.
Setting the clock
1 Press the settings button for hours N to set the
current hour.
– Press and hold the button to advance the
numbers quickly.
2 Press the settings button for minutes M to set the
current minute.
– Press and hold the button to advance the
numbers quickly.
Setting the auto brew
function
1 Follow the steps 1 - 8 in the “Brewing Coffee”
section.
2 Press the Program button J to set the desired
auto brew time.
– Program button illuminates.
3 Set the time you want the appliance to begin
brewing by using the Settings button for hours
N
and the Settings button for minutes M.
Note
█
To check your auto brew start time, simply press
the Program button J. The set time will be displayed for a few seconds on the display L. It
will automatically return to current time.
ENGLISH
9
OPERATION ______________________________
4 Press the Auto on button K.
– The Auto on button K will illuminate.
5 The coffee maker will automatically begin
brewing at the preset time.
Notes
█
When the brew cycle begins, the Auto on button K will turn off and the On/Off button P
will illuminate to indicate the coffee maker is
in operation.
█
To shut the auto brew function off, simply press
the Auto on button K again. The light will turn
off.
6 Remove the glass jug H from the warming
plate I, as soon as the brewing process
has finished and the glass jug H is filled. The
coffee is ready.
7 To turn the appliance of, push the On/Off
button P.
Note
█
For a better aroma, use aroma button O which
activates a unique brewing process that enhances the flavor and aroma of your coffee.
To reach this rich flavor, the coffee maker advances through several continuous cycles.
INFORMATION ___________________________
Cleaning and care
Caution
█
Never use petrol, solvents, abrasive cleaners,
or metal objects and hard brushes to clean the
appliance.
█
Never put the appliance or power cord in
water or any other liquid.
1 Turn the appliance of and disconnect it from
the wall socket.
2 Allow the appliance to cool down.
3 Remove the glass jug H.
4 Open the filter basket cover B.
5 Pull out the filter basket C. Remove the paper
filter with the coffee sediment and dispose of it.
6 Clean the filter basket C by placing under
running water and using a small amount of
mild cleanser. The filter basket C and glass
jug H can be cleaned in the upper shelf of the
dishwasher or under running water.
7 Use a damp soft cloth and some mild cleanser
to clean the exterior of the appliance.
8 Insert the filter basket C back into the housing
and close the filter basket cover B.
9 Place the glass jug H onto the warming plate
I
.
Note
█
Before using the appliance after cleaning, dry
all parts carefully with a soft cloth or paper
towel.
10
ENGLISH
INFORMATION ___________________________
Descaling the appliance
Descaling extends the life of your appliance.
Descale your coffee maker at least 4 times per
year. The period depends on the water hardness
in your area. The harder the water is, the more
often the appliance has to be descaled.
1 Purchase a suitable descaler from a speciality
store. Please ask naming the device.
2 Prior to commencing the descaling process
thoroughly read the manufacturer’s
package insert of the descaler. Should the
manufacturer’s instructions differ from the ones
listed below, then follow the manufacturer’s
instructions.
Note
█
You can also use white vinegar and lemon acid
instead of a commercially available descaler.
3 Fill the water tank to the “12” mark and add
descaler.
Mixing ratio: 4 parts water to 1 part descaler.
4 Turn the appliance on and allow approximately
one large coffee cup to run through the
appliance.
5 Turn the appliance off.
6 Let the mixture soak for about 15 minutes.
7 Repeat steps 4 – 6.
8 Now turn the appliance on and let the entire
mixture run through.
9 Fill the water tank with cold, fresh drinking
water and run all the water through.
10 Repeat step 9 four times.
11 Now you may brew coffee again.
Environmental note
This product has been made from high-quality
parts and materials which can be re-used and are
suitable for recycling.
Therefore, do not dispose of the product
with normal household waste at the end
of its service life. Take it to a collection
point for the recycling of electrical and
electronic equipment. This is indicated
by this symbol on the product, in the operating
manual and on the packaging.
Please find the closest collection points operated
by your local authority.
Help protect the environment by recycling used
products.
Technical data
This product conforms to the European directives 2004/108/EC,
2006/95/EC, 2009/125/EC and
2011/65/EU.
Power supply: 220 - 240 V ~, 50/60 Hz
Power: 840 -1000 W
Max. water volume: 1.8 L
Technical and design modifications reserved.
Storage
If you do not plan to use the appliance for a long
period of time, please store it carefully. Make
sure the appliance is unplugged and completely
dry.
Store the appliance in a cool, dry place. Make
sure the appliance is kept out of the reach of children.
ENGLISH
11
Grundig Intermedia GmbH
Beuthener Strasse 41
D–90471 Nürnberg
www.grundig.com
72011 908 6600 15/28
Loading...
