Graco STREETPILOT 2610 User Manual
®
StreetPilot
portable car navigation
owner’s manual
2610/2650
StreetPilot 2610 pictured
StreetPilot 2650 not shown
© Copyright 2004, 2005 Garmin Ltd. or its subsidiaries
Garmin International, Inc.
1200 East 151st Street, Olathe, Kansas 66062, U.S.A.
Tel. 913/397.8200 or 800/800.1020
Fax 913/397.8282
Garmin (Europe) Ltd.
Unit 5, The Quadrangle, Abbey Park Industrial Estate, Romsey, SO51 9DL, U.K.
Tel. 44/1794.519944
Fax 44/1794.519222
Garmin Corporation
No. 68, Jangshu 2nd Road, Shijr, Taipei County, Taiwan
Tel. 886/2.2642.9199
Fax 886/2.2642.9099
All rights reserved. Except as expressly provided herein, no part of this manual may be reproduced, copied, transmitted, disseminated, downloaded or stored in any
storage medium, for any purpose without the express prior written consent of Garmin. Garmin hereby grants permission to download a single copy of this manual
and of any revision to this manual onto a hard drive or other electronic storage medium to be viewed and to print one copy of this manual or of any revision hereto,
provided that such electronic or printed copy of this manual must contain the complete text of this copyright notice and provided further that any unauthorized
commercial distribution of this manual or any revision hereto is strictly prohibited.
Information in this document is subject to change without notice. Garmin reserves the right to change or improve its products and to make changes in the content
without obligation to notify any person or organization of such changes or improvements.
Visit the Garmin web site (www.Garmin.com) for current updates and supplemental information concerning the use and operation of this and other Garmin products.
Garmin®, AutoLocate®, MapSource®, StreetPilot®, and MetroGuide® are registered trademarks of Garmin Ltd. or its subsidiaries and may not be used without the
express permission of Garmin. Garmin Corporation is an authorized licensee of the CompactFlash®and ™ trademarks.
December 2005 190-00257-00 Rev C Printed in Taiwan
Preface
Congratulations on choosing one of the most advanced GPS navigation systems available! The Garmin
StreetPilot 2610/2650 utilizes the proven performance of Garmin GPS and full-featured mapping to create
an unsurpassed mobile navigation system.
This manual covers instructions for the StreetPilot 2610 and Street Pilot 2650. Unit operation and
specifications are the same on both models, unless otherwise specified. To get the most out of your
new navigation system, take the time to go through this owner’s manual and learn the operating procedures
for your unit. This manual is arranged to teach you how to use, customize, and care for your StreetPilot.
• Introduction: The introductory material contains a wealth of information that shows you how to
operate, clean, and store your StreetPilot. Follow the three easy steps on page iv in order to begin
using your StreetPilot quickly and efficiently. If you have never operated a StreetPilot or any type of
GPS navigation unit, try the “Tutorial” on page vi.
• Reference: The reference material begins with introductory mapping basics and then moves toward
learning how to find places and create routes with your StreetPilot. Learn what the Map page looks
like as you are navigating a route or if you are just moving around the Map page for fun. After you
learn the basics, read the sections on customizing your StreetPilot to suit your navigational and
personal needs. Lastly, learn the basics of GPS navigation as well as how to understand the features
on the StreetPilot’s GPS Information Page.
• Appendix: Read the special sections on vehicle installation as well as other important information.
Read the Safety and Regulatory section to learn how to use your StreetPilot responsibly.
• Index: Use the handy Index as a key word search to help you find information more quickly.
Customer Service Product Registration
Help us better support you by completing our online registration today! Have the serial number of
your StreetPilot 2610/2650 handy and connect to our Web site (www.garmin.com). Look for the Product
Registration link on the Home page. Also, be sure to record your serial number in the right-hand column
for a quick reference.
Introduction
Product Registration
Serial Number
Use this area to record the serial number (8-digit number
located on the bottom of the unit) in case it is lost, stolen,
or needs service. Be sure to keep your original sales
receipt in a safe place or attach a photocopy inside the
manual.
Serial Number:
The Garmin StreetPilot 2610/2650 has no user-serviceable parts. Should you ever encounter a problem with
your unit, please take it to an authorized Garmin dealer
for repairs.
The StreetPilot 2610/2650 is fastened shut with screws.
Any attempt to open the case to change or modify the
unit in any way voids your warranty and may result in
permanent damage to the equipment.
iii
Introduction
Packing List
I just bought a StreetPilot.
What do I do now?
For answers, see page iv.
Before installing and getting started with your unit, please check to see that your package includes the
following items. If any parts are missing, please contact your Garmin dealer immediately.
Standard Package:
• StreetPilot 2610 or 2650
• MapSource City Navigator CD-ROM with Unlock Certificate
• CompactFlash® Memory Card
• Dash Mount
• Portable Bean Bag Mount (Friction Mount)
• External Speaker with 12/24-volt Adapter Cable (vehicle adapter)
• A/C Power Adapter
• PC/USB Interface Cable
• DR (Dead Reckoning) Installation Cable (2650 Only)
• Alphanumeric Remote Control (Requires two alkaline AAA batteries; not included)
• Owner’s Manual
• Quick Reference Guide
• Setup Guide
Optional Accessories:
• Remote GPS Antenna (GA 27C) and antenna mounts
• Deluxe Carrying Case
• 128 and 256 MB CompactFlash® Memory Cards
Visit our Web site at www.garmin.com for a complete list of StreetPilot 2610/2650 accessories.
iv
Preface ....................................................................i
Customer Service Product Registration ...................i
Packing List ...........................................................ii
TABLE OF CONTENTS ...............................................iii
GETTING STARTED ...................................................
iv
WHERE DO I BEGIN? ..........................................iv
A Tutorial: Finding and Routing to a Restaurant ...vi
Manual Conventions ..........................................viii
INTRODUCING THE STREETPILOT 2610/2650 ............1
Front and Rear View of the StreetPilot ...................1
Caring for your StreetPilot ....................................2
Turning the StreetPilot On and Off ........................3
Using the Keypad ..................................................3
Using the Touchscreen ..........................................4
Calibrating the Touchscreen ..................................4
Using the Remote Control .....................................4
Adjusting the Speaker Volume ...............................5
LEARNING HOW TO USE THE MAP PAGE ...................6
Viewing the Map Page for the First Time ...............6
Using the Map Page Features .................................7
Viewing the Map Page While Driving ..................12
FINDING PLACES ....................................................
19
Finding a City .....................................................19
Finding an Address or Intersection ......................21
Finding an Exit ....................................................23
Finding a Waypoint .............................................24
Advanced Find Features ......................................25
Planning a Trip ...................................................26
Finding “Recently-Found” Places .........................27
CREATING YOUR OWN ROUTES .............................28
Creating your First Route ....................................29
Setting a HOME Waypoint ..................................30
Saving a Route .....................................................31
Deleting or Renaming a Saved Route ...................32
Modifying a Route ...............................................32
Measuring Distances Between Two Places ...........36
CUSTOMIZING YOUR STREETPILOT 2610/2650 .......38
Adjusting the Backlight and Contrast ..................38
Turning off Satellite Reception for Indoor Use .....38
Customizing your Map Page ................................39
Hiding/Showing Data Tabs on your Map Page .....41
Customizing the Overall Setup of Your StreetPilot 44
Obtaining the latest Software Upgrades ...............55
Introduction
Table of Contents
APPENDIX A: VEHICLE INSTALLATION .....................61
APPENDIX B: DR CABLE WIRING (2650 ONLY) ........
APPENDIX C: USING DIACRITICAL MARKS ..............
APPENDIX D: COMPACTFLASH® DATA CARDS ........
APPENDIX E:
APPENDIX F: MESSAGES .........................................
APPENDIX G: SPECIFICATIONS ................................
APPENDIX H:
75
ADDING MAPS TO YOUR STREETPILOT
SAFETY AND REGULATORY INFORMATION
Limited Warranty ................................................79
65
66
68
..69
71
73
DRIVING WITH DEAD RECKONING (2650 ONLY) .....18
UNDERSTANDING THE GPS INFORMATION PAGE ....56
What is GPS? .......................................................56
The GPS Information Page...................................56
v
Introduction
Getting Started
READ THE SETUP
GUIDE BEFORE USING
YOUR STREETPILOT
Follow the instructions in the Setup Guide brochure for
installing MapSource City Navigator and for transferring
map data to your StreetPilot.
vi
GARMIN
StreetPilot 2610/2650
Setup Guide
READ THIS
FIRST!
Where Do I Begin?
In order to begin using the StreetPilot efficiently and quickly, follow these steps:
Step 1:
Check the packing list on page ii to make certain all of your items are included in your StreetPilot package.
Step 2:
Add maps to your StreetPilot so you can view thousands of restaurants, hotels, parks, lakes, businesses,
services, or other points of interest. You will also be able to route to these places.
In addition to your StreetPilot, you will need the following items that are included in the StreetPilot
package:
• Setup Guide. This is located in the plastic bag that also contains the StreetPilot 2610/2650 owner’s
manual and the MapSource owner’s manual.
• MapSource Setup CD. This is a single CD located in the package entitled “StreetPilot 2610/2650:
OPEN FIRST.”
• MapSource City Navigator CDs. This is the two-pack set of CDs that is located in the package
entitled “StreetPilot 2610/2650: OPEN FIRST.”
• Unlock Certificate. This is a gold sheet that states “IMPORTANT! UNLOCK CODE ENCLOSED” at
the top and includes an actual unlock code at the bottom.
• USB Cable. Do NOT connect this cable to your computer until after you have downloaded the
drivers for the cable. Follow the instructions in your Setup Guide for complete details.
• AC Power Adapter. This adapter allows you to add power to your StreetPilot while you are indoors.
In order to ensure a successful installation, carefully follow the instructions outlined in the Setup
Guide; do not skip steps. The Setup Guide shows you how to load the MapSource City Navigator mapping
software to your computer. Then, it tells you how to download the required software drivers for the USB
cable that you will use to transfer map information to your StreetPilot. Lastly, the Setup Guide instructs
you on selecting map information and then downloading it to your StreetPilot.
Note:
This manual assumes that you have transfered maps to your StreetPilot. If you do not download City
Navigator maps to your StreetPilot, you will not see some of the information or features described
throughout this manual. Additionally, you will see minimal detail of major roads and highways on your
StreetPilot.
Step 3:
Try out your StreetPilot! Use the Tutorial on page vi to learn how to find a nearby restaurant and create
a route to it. In addition to your StreetPilot, you will need the following items that are included in the
StreetPilot package:
• Vehicle adapter. This is a 12/24 volt DC adapter with an external speaker system that connects
to your vehicle and your StreetPilot.
• Dash mount or portable bean bag mount. If you would like to mount your StreetPilot to your
vehicle right away, see the instructions on page 61.
Once you complete these three steps, you will be set up and ready to enjoy the full operation of the
StreetPilot!
Further Recommendations:
Read the StreetPilot 2610/2650 owner’s manual to learn how to create routes that include multiple
destinations, how to specify areas or road segments to avoid when calculating routes, and how to use a
variety of other exciting features.
Read the MapSource owner’s manual to learn how to create routes and waypoints on your computer
and then transfer this information to your StreetPilot.
Introduction
Getting Started
Garmin USB Cable
DO NOT connect the Garmin USB
cable to your computer until you have
followed the instructions in the Setup
Guide. Garmin-specific drivers must
be installed on your computer before
you connect the USB cable to your
computer.
vii
Introduction
Where to find it
• To learn how to attach your vehicle
adapter to your StreetPilot, see page 64.
• Learn how to create and customize
routes, beginning on page 28.
• Learn more about GPS navigation
beginning on page 56.
• To find a city, address, intersection,
park, or other point of interest, see
Finding Places, beginning on page 19.
• To learn how to use the keypad on your
StreetPilot as well as the remote control
unit, see page 4.
• To change the street detail level on your
StreetPilot, see page 39 (map detail).
• If you do not want your StreetPilot to
automatically switch to “night” colors at
sunset, see page 39 (color mode).
• Learn about the Map page and its many
features, beginning on page 6.
A Tutorial: Finding and Routing to a Restaurant
The tutorial below guides you through the steps for finding a restaurant in your area and then creating a
route to it. If you have never used a StreetPilot or a GPS navigation unit before, try this simple task. You’ll
see that using your StreetPilot is fast and easy. Make certain you complete Step 2 on page iv before
you begin this tutorial. Otherwise, you will not be able to view restaurant names.
Step 1: If you have not already done so, attach the vehicle adaptor to your StreetPilot
and plug it in to your vehicle’s cigarette lighter. Turn on the StreetPilot so that it can find
satellites. When your StreetPilot has established a satellite fix, your screen should display a
“Ready to Navigate” message, as shown below:
Note: Make certain your StreetPilot’s view
is unobstructed as it looks for satellites.
For example, it cannot establish a satellite
fix if your vehicle is parked in a garage.
Step 2: Press the FIND key on the
StreetPilot. The Find menu will appear:
press the FIND key
then, touch the Food
& Drink icon
viii
Step 3: Touch the Food & Drink icon located on the Find menu (from
Step 2). The list of restaurants in your area will appear on a page
similar to the one shown below:
scroll bar arrow
Step 4: Scroll down the list of restaurants by tapping the down
arrow on the scroll bar, shown above. When you see a restaurant you
like, touch its name. Information about the restaurant will appear
on a Food/Drink page similar to the one shown below:
Introduction
Step 6: View your route to the restaurant:
Step 5: To create a route to
this restaurant, touch the
Go To button located at the
bottom of the Food/Drink
page. A Route Preference
window will appear. Touch
the Faster Time icon:
touch Go To
to create a
route to this
restaurant.
What’s Next?
Read the manual to learn how to use your StreetPilot
accurately, efficiently, and responsibly.
ix
Introduction
PRACTICE USING THE STREETPILOT
WHILE IN SIMULATOR MODE
Thoroughly familiarize yourself with the routing
features of the StreetPilot by practicing creating
routes in simulator mode.
Simulator mode only works when the GPS navigation is turned off. To do this, press the MENU key
on the StreetPilot. A Menu page will appear. Select
the ‘Use Indoors’ icon. GPS will be turned off. Now,
when you create a route, the unit will ask if you
want to simulate driving the route. Select Yes, and
the StreetPilot will give driving instructions for the
entire route.
Manual Conventions
• This manual refers to the StreetPilot as a “StreetPilot,” “unit,” or “GPS receiver.” It makes no
distinction between these terms. “StreetPilot” refers to both the 2610 and 2650 models unless
specifically stated.
• This manual uses the term “Map page” when referring to pages that have maps. In all other instances,
the terms “page,” “screen,” and “window” are used interchangeably.
• This manual uses the words “button” and “key” interchangeably.
• This manual uses the term “press” when you need to activate the keys on the StreetPilot or on the
remote control.
• Although you can either touch the screen to activate commands or use the remote control, most
instructions in this manual assume that you are using the touchscreen.
• This manual uses “touch” and “select” interchangeably. When asked to touch or select an icon or tab,
simply tap the icon or tab with your finger. Or, press in on the thumb stick that is located on your
remote control. Practice using the remote control unit to improve your accuracy when activating
commands. See page 4 to learn how to use it.
OPERATE YOUR STREETPILOT IN “SAFE MODE” WHILE DRIVING
Your StreetPilot is equipped with a ‘Safe Mode’
feature to improve driver safety. By default, this feature is enabled, but it can be turned off to allow a
passenger to operate the unit. When your vehicle is
moving, Safe Mode disables certain StreetPilot functions which require significant operator attention
and may become a distraction to use while driving.
NOTE: If you have previously registered a Garmin product purchase, we invite you to re-reg-
ister using our online system. Many services provided by our new product registration system
are now being automated and re-registering your purchase ensures you the best possible
x
support from Garmin.
Introducing the StreetPilot 2610/2650
PAGE
MARK
MENU
ROUTE
FIND
RECENT
SPEAK
VOLUME
StreetPilot 2650
Front and Rear View of the StreetPilot
Introduction
Infrared Window
Receives signals from
remote control. Do
not block.
8-Bit Color LCD Touchscreen
Display
On-screen information is referred
to as a ‘page,’ ‘window,’ or
‘screen.’ Press the PAGE/MARK
key to select a different page.
Internal Patch
Antenna
Receives signals from GPS
satellites to determine
position. Do not block.
Front View
Keypad
Controls unit
operation.
Power Switch
Toggle DOWN to turn
unit on and UP to
turn off.
USB Connector
Connects unit with a PC
to add maps to the CF
card, or to upload software
upgrades.
External Antenna
Connector
Connection for optional
external antenna.
Power/Speaker
Connector
Connector for power,
speaker, and Dead
Reckoning cable (2650
only).
Automatically adjusts
Back View
Adjustable Mount
Allows the unit to con-
nect to the mounting
base and tilt forward/
backward.
Light Sensor
backlight level.
CompactFlash® Card
Door
Insert the CF card for
increased map detail
and information lookup
capability. Keep door shut
to prevent water entry.
1
Introduction
Maintenance
Caring for your StreetPilot
Cleaning the Case and Remote Control
The StreetPilot 2610/2650 case and remote are constructed of high quality materials and do not require
user maintenance other than cleaning. Clean the unit’s outer casing (except for the touchscreen) using a
cloth dampened with a mild detergent solution and then wipe dry. Avoid chemical cleaners and solvents
that may damage plastic components.
Cleaning the Touchscreen
The StreetPilot 2610/2650 touchscreen is intended primarily for finger operation. Although a PDA stylus
may also be used to operate touchscreen, never attempt this while operating a vehicle. Never use a hard or
sharp object to operate the touchscreen or damage may result. The touchscreen should be cleaned using a
soft, clean, lint-free cloth. Water, isopropyl alcohol, or eyeglass cleaner can be used if needed. If these are
used, apply the liquid to the cloth and then gently wipe the touchscreen with the moistened cloth.
Storage
Do not store the StreetPilot 2610/2650 where prolonged exposure to temperature extremes may occur
(such as in the trunk of a car) as permanent damage may result. User information such as waypoints and
routes are retained in the unit’s memory without the need for external power. Back up important user data
by manually recording it or downloading it to a PC (transferring it to MapSource).
Storing alkaline batteries in the remote control for extended periods is not recommended. In order to
reduce the chance for battery leakage in the battery compartment, remove the batteries when storing the
remote control for more than six months.
2
Turning the StreetPilot On and Off
Toggle the power switch on the right side down to turn the unit ON and up to turn it OFF. When turned
on, the Welcome screen appears briefly, followed by the Map Information and Copyright page. Touch OK
on the screen to acknowledge, or wait briefly until the Safe Driving Warning Message page appears. Touch
OK once more or wait until the Map page appears.
Using the Keypad
Use the StreetPilot’s keypad to select specific tasks such as finding places or creating routes. Each keypad
button’s primary function appears in larger text above the secondary function. Always press and release a
key to perform its primary function. Press and hold a key to activate its secondary function (if available).
For example, if you press the MENU/ROUTE key, a Menu page will appear. If you press and hold the
MENU/ROUTE key for more than two seconds, a Routes page will appear.
• PAGE/MARK Key — PAGE switches between a variety a pages that you can view on your
StreetPilot. It also returns you to a main page if you have previously selected an option window.
Thus, if you want to exit out of a current page option, press PAGE. MARK captures your present
position and saves it as a waypoint.
• MENU/ROUTE Key — MENU displays a menu of options for your current page. It also displays
sub-menu options. ROUTE displays a menu of available route navigation features.
• FIND/RECENT Key — FIND allows you to search for cities, hotels, restaurants, banks, and a host
of other places. RECENT allows you to view a list of places you have recently found.
• SPEAK/VOLUME Key — SPEAK triggers your StreetPilot’s “voice” to repeat the next turn or
current destination while you are navigating a route. VOLUME displays an adjustment slide on the
page to change the speaker volume.
Introduction
Keypad Usage
Activate the
primary functions
(PAGE, MENU,
FIND, SPEAK) by
pressing the key
once.
Activate the
secondary functions (MARK,
ROUTE, RECENT,
VOLUME) by
pressing and holding down the key.
3
QUIT
PAGE
FIND
MENU
IN
OUT
ROUTE SPEAK
1
ABC
2
DEF
3
GHI
4
JKL5MNO
6
PQRS
7
TUV
8
WXYZ
9
0
ZOOM
4
Introduction
Remote Usage
IR window
thumb stick
To disable the remote
(the IR port), press
MENU and select
‘Options.’ Select the
‘General’ tab and
press the MENU
key. Select ‘Disable
Remote.’
To enable the remote
again, press MENU
and select ‘Options.’
Select the ‘General’
tab and press the
MENU key. Select
‘Enable Remote.’
Using the Touchscreen
The StreetPilot 2610/2650’s touchscreen features allow you to make menu selections, position the map
pointer, scroll through menu selections, and enter data with the touch of your finger.
To use the touchscreen control, touch the desired object on the screen with your finger, applying just enough
pressure to activate the function. It is not necessary to apply excessive pressure to the touchscreen. If
the Touchscreen Tone setting is set to ON, you will hear a click from the speaker with every finger press. If you
sense that the touchscreen is not responding properly, it may need to be calibrated.
Calibrating the Touchscreen
To calibrate the touchscreen:
1. Press the remote or unit MENU key. Select ‘Display.’
2. Press the remote or unit FIND
key to begin calibration. Follow the on-screen instructions.
Using the Remote Control
The StreetPilot 2610/2650’s alphanumeric remote control allows you to perform functions similar to the
unit’s keypad controls. You will notice only subtle differences between the two. As on the keypad, the remote
control features PAGE, MENU, FIND, and SPEAK keys. Thus, you can use them the same way you use the
keypad. Similarly, press and hold each key in order to use each key’s secondary function (MARK, ROUTE,
RECENT, and VOLUME).
The remote differs from the keypad in that it has additional function keys that allow you to quickly enter
data and perform other operations on the unit:
• (ZOOM) IN Key — Zooms in to adjust the Map page scale to show a smaller area with more detail.
• (ZOOM) OUT Key — Zooms out to adjust the Map page scale to show a larger area with less detail.
• QUIT Key — Returns the display to your previous page (much like the “Back” button on an Internet
browser window). Also, when you are entering data, pressing QUIT restores the previous value
(cancels data entry.)
• ROUTE Key— Displays a menu of available route navigation features.
• THUMB STICK — Selects menu options, changes settings, and enters data. Also it controls
movement of the map pointer on the Map page. Press in (or down) on the thumb stick to select or
activate a highlighted item or to begin data entry. Move the thumb stick from side to side for moving
around the Map page. Use this feature as an alternative to using your finger on the touchscreen.
Practice using it to increase your accuracy.
• ALPHANUMERIC KEYS — Used when you wish to enter numbers for values such as an address
or waypoint name. These keys can be used in conjunction with the thumb stick. For letters, press
the appropriate number key as many times as necessary to get to the correct letter. The number will
appear after the last letter option has been shown. For example, if you wish to input the letter B,
press the number 2 key twice. If you wish to input the number 2, press the number 2 key four times.
When you have selected the correct letter or number, pause, and the unit will automatically advance
the cursor to the next character. Note that the 1 key only accepts one press and SPACE/0 only
accepts two key presses.
In order for the remote to operate properly, be sure to point the IR (infrared) window on the remote towards
the unobstructed IR window on the left front of the StreetPilot.
Adjusting the Speaker Volume
Introduction
Installing the Remote Control
Batteries
NOTE: The remote control requires
two AAA alkaline batteries. To
install the batteries, press up on
the battery door clip, then pull the
battery door away from the remote.
Install the batteries, observing
the correct polarity (see the inside
compartment). Replace the cover.
To adjust the external speaker volume:
1. Press and hold the SPEAK/VOLUME key. A speaker volume adjustment page appears.
2. Adjust the speaker volume by moving the slider’s thumb up or down with either your finger (on the touch
screen) or by pressing the thumb stick up or down once the scroll box appears. The loudest setting is ten;
the softest setting is one. Each press activates the audio number. All the way down turns off the speaker.
(Alternatively, volume can be cycled between three settings by repeatedly pressing the SPEAK/VOLUME
key from this screen. The three settings are volume off, user setting, and maximum volume.)
3. When finished, touch the X on the touchscreen or press in once on the thumb stick.
-
Adjusting the Volume
slider thumb
speaker volume
slider
5
Reference
Using the Map Page
NOTE: Your StreetPilot unit cannot
acquire satellites from inside a building. Thus, you may want to consider
setting your unit to ‘Use Indoor’
status. To do this, press the MENU
key on your unit. You will see a Menu
page that includes a variety of setup
options. Select the Use Indoors icon.
Learning how to use the Map Page
The Map page is your StreetPilot’s main operating page. This page is the first image you see after the
startup screens, and it’s what you view as you navigate to a destination. Many features make up the Map
page. Whether you’re navigating a route or simply driving with your StreetPilot turned on, you will see
a map that displays your current location as well as surrounding street detail. Additionally, depending
on your current driving mode, tabs that appear on the Map page will provide such information as your
current speed, your driving direction, and names of upcoming streets. You can look beyond your current
position by “panning,” or moving around the Map page. You can also zoom into locations to view greater
street detail or you can zoom out to see what’s ahead on your route.
This section shows the many types of Map page views as well as how to use the features on the Map page.
Practice using these features before navigating an actual route so that you can quickly understand what
you are seeing on the Map page and thus limit time looking away from the road while driving.
Viewing the Map Page for the First Time
When you turn on your StreetPilot for the first time, you see a map image as well as a tab which shows
that the StreetPilot is attempting to locate satellites. Once your StreetPilot locates the satellites, it
establishes a “fix” on your location. It is then ready to navigate and you are ready to begin.
When you turn on your StreetPilot, it searches for
6
satellites.
Once the satellites have been acquired, your
StreetPilot is ready to navigate.
Touch the screen anywhere with your finger and move it
around to view a variety of locations on your StreetPilot.
QUIT
PAGE
FIND
MENU
IN
OUT
ROUTE SPEAK
1
ABC
2
DEF
3
GHI
4
JKL5MNO
6
PQRS
7
TUV
8
WXYZ
9
0
ZOOM
Using the Map Page Features
The Map page comes with many useful features that can help you as you view cities or places, and as
you navigate routes. If you are a new StreetPilot owner, practice using these features while your vehicle is
stationary.
Map Tools Bar
The StreetPilot comes with a “map tools” bar, which is a series of icons on the left-hand side of the Map page
that enable you to zoom in to and out of the current areas shown on your Map page. To activate the map
tools bar, simply touch any part of the Map page and the map tools bar will appear:
map tools bar
Touch the arrow to toggle between activating and
hiding the map tools bar
Reference
Using the Remote or the
Touchscreen
map tools
bar
Touch the + to zoom in to an area, up to 120 feet
Touch the - to zoom out of an area, up to 800 miles
When the panning hand is present, you can move
across the map area with your finger and the map will
move. Touch the hand to toggle to a special “box”
The white arrow at the top of the map tools bar allows you to toggle between activating and hiding the map
tools bar. The zoom icons feature a “+” magnifying glass that allows you to zoom in to an area on your Map
page, and a “-” magnifying glass that lets you zoom out of an area. The panning hand allows you to move
around the Map page by touching the screen (touchscreen) with your finger; this action is called “panning.”
(thus providing greater detail)
(thus providing less detail)
zoom feature
map scale map pointer
vehicle icon; shows your
current location
Panning allows you to “move” the viewing area on the Map page in order to view areas beyond the displayed
thumb stick
An alternative to using the touchscreen for zooming in
and out of an area on the Map page is to use the IN and
OUT zoom buttons located at the top of your remote
control. An alternative to “panning,” or touching the map
with your finger and moving the map, is to use the thumb
stick on your remote control.
7
Reference
‘North Up’ versus ‘Track Up’
The presence of the
arrow shown at
right indicates that
the map tools bar is
activated. Touch the
arrow, and the map
tools bar disappears.
An orientation icon
will appear.
The middle image
shows an N with
an arrow pointing
upwards, or ‘North
Up.’ Touch the N and
the direction changes
to ‘Track Up.’
8
Map page showing map tools bar
Map page showing ‘North Up’
Map page showing ‘Track Up’
area. The white arrow, or “map pointer,” serves as a target marker and provides information for
a specific location or object if any is available. The black triangle, or “vehicle icon,” shows your
current physical location on the Map page. While in panning mode, the data tabs on the right of the
screen are hidden.
In addition to zooming in to or out of the Map page, you can also define a particular area to enlarge
on the Map page by drawing a “box” on the touchscreen, then lifting your finger from the screen.
Before you can do this, make certain the boxed magnifying glass icon is showing at the bottom of
the map tools bar, as shown in the diagram below. If the map tools bar displays a hand, simply touch
the hand and the boxed magnifying glass icon will appear.
Use your finger to draw
a box on the Map page.
The boxed-in area will be
zoomed in to show greater
detail.
boxed
magnifying
glass icon
map scale
North Up and Track Up
Map orientation icons appear at the top left side of the Map page. They show
how roads appear on your Map page. North Up shows your Map page with
North Up Track Up
North always at the top, as if you were reading a paper map. Thus, as you are
driving, the vehicle icon on your Map page will move to the left if you are going West, right if you
are going East, and so forth. With Track Up, your Map page shifts so that your direction of travel
always appears at the top of the Map page. Thus, if you are headed South, the Map page will shift so
that South appears at the top of the Map page. Change the orientation from North Up to Track Up
(or vice versa) by touching the orientation icon. Note that the map tools bar must be hidden before you can
change these icons.
Map Scale
A map scale appears on the lower left of the Map page. It shows you the current zoom level showing on
the Map page (such as 500 miles, .8 miles, or 200 feet) as well as what map your StreetPilot is using to
create the current image. Your StreetPilot uses either a “base map” or a “detail map.” The base map is a
built-in map that provides only general information such as city names and highway exits. The detail map
includes information that you transferred from the City Navigator to the CF card in your StreetPilot (see
the setup information on page iv). It features specific details such as addresses, businesses, parks, and other
points of interest. Thus, if you are viewing Denver at a map scale of 800 feet, your StreetPilot will display
information from its base map. If you have transferred Denver map data from the City Navigator CD-ROM
to your StreetPilot, the map scale will switch from “base map” to “detail map” as you continue to zoom in to
Denver.
If you continue to zoom even more in to Denver or any city, “overzoom” will appear on the map scale.
Displaying at between 500 - 300 feet, “overzoom” indicates that the current scale exceeds the optimum
resolution of available map detail. Some detail, such as roads, are drawn using widely-spaced points and
the actual layout of these details may differ from the map presentation.
Reference
Using the Map Scale
base map of Denver at 20-mile zoom
detail map of Denver at 800-foot zoom
detail map of Denver at 300-foot “overzoom”
9
Reference
Information Icon
When multiple Points of Interest appear at one point
(shown above) a selection list will display (shown
below).
Information Icon “i”
As was discussed earlier in this section, you can pan across the Map page by using the touchscreen with
your finger or by using your remote control. As you pan, the map pointer appears. It serves as a target
marker for the map. If you change the scale, the map is redrawn with the pointer at the center. When the
pointer is placed on a map object, the name of that object is highlighted and an “i” (Information) icon
appears in the upper right corner.
When the “i” icon appears, touch it and information about the object or location to which your are
pointing will appear.
The Map page shows the panning arrow (circled)
which is highlighting a point of interest.
In the example above, the Gateway Arch in St. Louis has been
highlighted. Touch the “i” icon, and the information page at right
appears. The page displays information about the Gateway Arch as
well as feature options.
From the information page, you can touch Show Map to show a
information page
different Map page, as shown below. This page includes coordinates as well as the Arch’s distance and
bearing from your current physical location.
This view of the Gateway Arch appears when you touch Show
Map. The coordinates of the Arch appear at top right. The Arch’s
distance and bearing from your current physical location appear
at top left.
10
From the information page, you can also touch Go To to create a route to the Arch. A
Route Preference window will appear. Once you select a preference, your StreetPilot
will create a route to the Arch. (See Creating your own Routes, page 28, for more
information on creating routes)
Waypoints
As was discussed on the previous page, an “i” icon appears as the Map pointer hovers over an existing map
object such as a business, park, lake, church, or other point of interest. When the Map pointer points to an
area where no map data exists, a flag icon appears in the upper right side of the Map page:
When the map pointer is not placed on an object, a flag
icon appears in the upper right-hand corner. Touch the icon
to create a new waypoint. You can also create a route to it.
If you decide that this is an area you want to remember (perhaps it is a particular location on a lake or
in a National Park), you can mark this area by creating a waypoint for it. Touch the flag icon and a New
Map Waypoint will appear, as shown below. The coordinates for the marked area are displayed. A random
number also appears. If you wish to name it something else, touch the current name (011) and a mini
keyboard page will appear, allowing you to type in a new name. You can also touch the icon to the left of
the name to change the icon.
Touch the blue dot icon to reveal a scrollable list of colorful icons to use to mark
your waypoint.
Touch the 011 text to display a new screen
that serves as a mini keyboard. Use this
keyboard to enter a new name for the
waypoint.
Reference
Using the Mini Keyboard
The mini keyboard shown above appears when you
wish to change the name of the waypoint as discussed
in this section. Touch the letters to spell out a name.
To use numbers, touch the 0-9 tab and numbers will
appear. The Space, <, >, and Delete keys use standard
word processing functions. When you have entered all
text, touch OK.
The mini keyboard is used in a variety of places with
your StreetPilot. It’s appearance may alter, depending
on your purpose for using it. On some mini
keyboards, letters or numbers that are not needed will
not appear on your keyboard.
11
Reference
Viewing the Map Page
Map page in driving mode
Map page in routing mode
Although the information varies slightly between a
Map page in driving mode and one in routing mode,
you can use the features discussed in this section for
both Map page types. Note that the Next Turn page
and Current Route pages only appear when you are in
routing mode.
12
Viewing the Map Page While Driving
Map Pages in Driving and Routing Mode
While driving, you will see one of two types of Map pages: a Map page in “driving” mode, which appears
when you have the StreetPilot turned on but you are not navigating a route, and a Map page in “routing”
mode, which appears when you have created a route and are currently navigating to it.
In driving mode, the Map page shows map details, the map scale, and your current location. Customizable
data tabs are pre-set to show your speed, current direction of travel, address of your current position, and
the name of the next road ahead.
Map Orientation
Your Current Position
Map Scale
Your current speed
Current driving direction
Street address at your current location
The next road ahead
In routing mode, the Map page displays more information. It graphically shows you map details and your
current location, and it marks your route to a destination with a magenta-colored route line. It tells you
what direction to go as well as the direction in which you are traveling. Customizable data tabs are pre-set
to display information such as your speed, the distance you have traveled, distance to the next turn, time
remaining before reaching the next turn, and more.
Map Orientation
Route Line
Next Turn Arrow
Your Current Position
Map Scale
Your current speed
Distance until your next turn
Estimated arrival time to your destination
Time until your next turn
Driving instructions
Both types of Map pages display a vehicle icon which indicates your present position and direction of
movement as a triangular icon in the center of the map. Depending upon your map scale setting, you can
see a variety of geographic detail such as lakes, rivers, highways, and towns.
If you would like to see more detail at your current driving position, or if you would like to see a broader
view of the area, you can change the Map scale to zoom in to or out of your current position as the Map
page continues to follow the vehicle icon. Simply touch the map scale and the map tools bar will appear.
Use the zoom icons (+ or - magnifying glasses) to select your new detail level. To return to the previous
page, simply touch the white arrow at the top of the map tools bar. Note that you can use this feature
whether you are in driving or in routing mode.
Reference
Viewing the Map Page
For maximum map display, hide some or all of the data
tabs. Simply touch the tab to make it disappear.
Touch the map scale to activate the map tools
bar and hide the data tabs.
Use the zoom icons to view a new level of detail. Touch
the arrow to return to the Map page in routing mode.
In the example above, your current driving position always appears on the Map page. Another StreetPilot
feature allows you to “look ahead” on the Map page so that you can view areas beyond your current
position, but without interrupting the function of the Map page. Simply touch any area on the Map page
EXCEPT for the map scale. As in the example above, the map tools bar will appear. The differences are that
the map pointer will also appear on the Map page, and the Map page itself will stay stationary until you
move (pan) the Map page. The vehicle icon will continue to move along your route, but you will be able to
move beyond your current position as you pan.
As shown above, the Map page viewing area is
greater with the data tabs hidden. Touch the tab
placeholders to show the tabs again.
See page 42 for more information on hiding/
showing data tabs.
13
Reference
Next Turn Page
Your StreetPilot safely navigates you through roundabouts,
interstate traffic, and all other types of road navigation.
The NEXT TURN page announces the same instructions
for an upcoming turn 3 times:
· Immediately after you make a turn, the Next Turn
page announces the next upcoming turn, as well as
the distance to that turn. Thus, if the next turn is not
for 20 miles, you do not need to worry about navigation instructions for quite a while.
· As you are close to approaching the upcoming turn,
the Next Turn page appears again. This message is
announced in order to alert you to change lanes if
necessary and start looking for signs in anticipation
of the upcoming turn.
· Just before the upcoming turn, the Next Turn page
appears one last time for that particular turn. You
should be in view of the turn.
14
Touch anywhere on the Map page (except the map
scale) to activate the map tools bar and map pointer,
and hide the data tabs.
Touch the arrow to return to the previous Map page.
Use this feature whether you are simply driving with your StreetPilot turned on (driving Map page) or
navigating a route (routing Map page). To return to the Map page with the original navigation so that you
can see the vehicle icon, touch the arrow in the top left corner.
Next Turn Page
As you are driving during an active route, the Map page continues to display in routing mode until your
StreetPilot alerts you that you are near a turn. When this happens, a Next Turn page appears. It provides a
graphic visual and gives text instructions, as shown below:
Route Line
An upcoming turn is placed here. This screen disappears after a few seconds. If you need to see it
again, simply press SPEAK and it will reappear.
Shows how many miles until you reach the
upcoming turn.
Shows the approximate time left until you reach
the upcoming turn.
An added bonus to the Next Turn feature is that the StreetPilot “voice” announces upcoming turns. Thus, if
you cannot safely view the Next Turn page, you can hear the directions.
The Next Turn page above disappears after a few seconds and then the page which you were previously
viewing will reappear. If you wish to clear the Next Turn page and return to the previous page, press
PAGE (you can also press QUIT on the remote). If you wish to see the Next Turn page again, simply press
SPEAK and it will reappear. You will also be able to hear the announcement.
When you are not navigating a route, the Next Turn page is no longer available.
Current Route Page
Still another bonus while navigating a route is the Current Route page, which provides step-by-step route
instructions, all on one page. Simply press PAGE from your StreetPilot (or from the remote control) and
the Current Route page appears:
Scroll bar
The bottom number gives the approximate time that you should
reach the next turn.
The top number shows how much time (in minutes or in hours) until
the next turn.
The text column explains the upcoming driving instructions.
Reference
Current Route Page
The Current Route page keeps a log of your entire
route. It keeps the directions even when you have
completed the turn.
When you are not navigating a route, the Current
Route page is no longer available.
Direction of turn
The numbered column shows how many miles until the next turn.
The Current Route page keeps a log of your entire route. Thus, you can look beyond the next turn and
even get an estimated idea of what time you will reach an upcoming turn provided you don’t make stops
along the way.
You can scroll through the entire list by moving the scroll bar up or down. Highlight and touch any of the
turns on the list to view the Next Turn page for that turn.
15
Reference
Trip Information Page
Access the Trip Information page anytime during an
active route by pressing PAGE on your StreetPilot.
Select from different Mileage Logs.
16
Trip Information Page
While navigating a route, you can access yet another page, the Trip Information page. If you are making
a long trip, you may find the Trip Information page to be very useful. It indicates your current speed and
many helpful statistics about your trip.
Be certain to reset the Trip Computer before beginning a trip (see next page). If you make frequent stops,
leave the StreetPilot powered on in order to receive satellites. This allows the unit to accurately measure
elapsed time during the trip. Note, however, that this might be impossible since some vehicles disconnect
power to the cigarette lighter when the ignition is turned off.
The following trip information is displayed on the Trip Information page:
Time of Day – Current time. This appears at the top left-hand side of the page.
Compass Ribbon – Shows your current compass heading while moving with a red indicator arrow.
Speed – This is the current vehicle speed, displayed in miles or kilometers per hour.
Odometer – A running total of distance traveled, based upon the distance between second-by-second
location readings, since the Trip Computer was last reset.
Mileage Log – Allows you to use up to four different mileage odometers for recording trip distances. You
can also rename each mileage log (see next page).
Driving Avg – Your average speed of travel during the time the vehicle has been in motion since the Trip
Computer was last reset.
Overall Avg – Your average speed of travel (including time stopped) during the time the StreetPilot has
been tracking your location since, the Trip Computer was last reset.
Max Speed – The maximum speed recorded since the Trip Computer was last reset. Max Speed can also be
reset individually without resetting other Trip Computer information.
Driving Time – The length of time that the vehicle has been in motion since the Trip Computer was last
reset.
Stopped Time – The length of time that the vehicle has been stopped (or stationary) during the time the
StreetPilot has been tracking your location since the Trip Computer was last reset.
Total Time – The total length of time that the StreetPilot has been tracking your location since the Trip
Computer was last reset. This is always equal to Driving Time plus Stopped Time.
To reset the Trip Computer or the Maximum Speed:
1. Press the unit or remote MENU key to display a ‘Menu’ page.
You can also select the blue round buttons to the right of the
main odometer or Max Speed (in which case you can skip to
step 3.)
2. From the ‘Menu’ page, select ‘Reset Trip’ to reset the Trip
Computer or ‘Reset Max Spd’ to reset the Maximum Speed.
3. Select ‘Yes’ at the verification page to complete the reset.
Touch the appropriate blue button above to
reset the Trip Computer or Maximum Speed.
To select a Mileage Log:
1. Select the ‘Job 1’ (or ‘None’) field on the Trip Information page. A box containing various log names (Job
1, Job 2, Job 3, OTHER, None) will appear.
2. Select the desired Mileage Log name. All mileage will be recorded in this log.
To rename a Mileage Log:
1. Make certain the desired Mileage Log name is displayed. Then, press the unit or remote MENU key to
display a ‘Menu’ page.
2. Select ‘Rename Log.’
3. Enter the new name by using the mini keyboard that will appear.
To reset a Mileage Log:
1. Make certain the desired Mileage Log name is displayed. Then, press the unit or remote MENU key to
display a ‘Menu’ page. You can also select the round blue button to the right of the Mileage log.
2. Select ‘Reset Log’ and select ‘Yes’ at the verification page to complete the reset.
Reference
Trip Information Page
You can reset the Maximum Speed or the Trip Computer by pressing MENU while on the Trip Information
page.
Use the mini keyboard to rename a Mileage Log.
17
Reference
Driving with Dead Reckoning
The only way you can tell that your StreetPilot is using
Dead Reckoning is to view the GPS Information page.
See page 56 for more information on GPS.
Driving with Dead Reckoning (2650 Only)
The StreetPilot 2650 comes with dead reckoning capabilities, which means that you continue to get
navigation guidance even if you lose GPS reception, such as when you are travelling in dense urban
environments with tall buildings and tunnels.
To achieve dead reckoning, the 2650 utilizes an internal angular rate sensor, an external speed sensor
input, and an external reverse light sensor input. A special dead reckoning cable is connected to your
vehicle’s speedometer and backup lights (it must be professionally installed by an authorized Garmin
installer). Thus, when you lose GPS reception, your StreetPilot can acknowledge your turns as well as your
distance travelled while you are driving. In this way, it can continue to accurately give navigation guidance
until your GPS reception returns. Driving with dead reckoning capabilities is so seamless, you will not
even know that you do not have GPS reception.
You can simply unplug the dead reckoning cable from the vehicle adapter if you want to use the StreetPilot
2650 in another vehicle. It will navigate the same way as the StreetPilot 2610.
18
Finding Places
Use the FIND feature on your StreetPilot unit (or remote) to take the guess work out of locating a city
street, restaurant, or hotel. You can even use FIND to see what rest areas are approaching as you near an
exit on the Interstate.
Finding a City
Select the Cities icon from the Find menu. A list of cities will appear, as well as each city’s direction and
distance from your current position as indicated by the Near Here tab. Use the scroll bar on the right side
of the page to view the entire list of cities. The Near Here tab lists cities that are closest to your current
physical location or, if you have panned to an area away from your current location, to your map pointer.
You can find cities in many ways. Touch the down arrow (▼) on the Near Here tab and you will see a
variety of options. (Note that these options appear depending upon whether you are currently navigating a
route or panning your Map page).
• By Name: Use By Name if you want to spell out the name of the city you seek; use the mini
keyboard that appears when you select By Name. Note that when you use By Name, all city names
that are loaded in your mapping software will be searched. For example, if you are searching for
Greensboro, N.C., your search (using By Name) will return a list of all Greensboros in the U.S.
• Near Other: Use Near Other to find a city that is not in your immediate location. For example, of
you are physically in Kansas and you want to find a city in Colorado, select Near Other and a map
of the U.S. will appear. Touch an area in Colorado that is close to the city you wish to identity, and
then touch the check mark that appears in the upper right-hand corner of your Map page. A new list
of cities in Colorado will appear. (Note that when the list of cities appears, the tab will change from
Near Other to Near Map Pointer. This is because the StreetPilot is searching for cities that are located
near the current position of your map pointer, not your current physical location.)
Reference
Finding Places
scroll bar
Access this menu by selecting FIND on your
StreetPilot unit or remote. Use the scroll bar to see
the third line of options, which are not shown above.
‘Near Here’ tab
In this example, nearest cities are listed in order
according to their respective mileage from your present position.
19
Loading...
