Operating Instructions

SECUTEST®SII

Test Instrument for DIN VDE 0701, 0702 and 0751

3-349-223-03

8/11.05

SECUTEST SI I

14 15

SONDERS232 5 4

VDE 0701

T. 200

T. 240

VDE 0702

VDE 0751

OFF

FUNCTION-TEST

230 V

45678910

Feature F01

T. 1

Note Contact problems with exposed conductive parts when using the standard probe with test tip

In order to assure good contact, surface coatings must be removed from devices under test with special tools at a suitable location so that the surface has a metallic shine.

☞

19 18

The tip of the test probe is not suitable for

scratching away paint, because this may impair its coating and/or mechanical strength. The brush probe may be more suitable than the test probe in certain individual cases.

These operating instructions describe an instrument with firmware version 6xx.

2 GOSSEN METRAWATT GMBH

Upper left figure

1 Jack for protective conductor at device under test (feature F01) 2 Jack for neutral conductor at device under test (feature F01) 3 Jack for phase conductor at device under test (feature F01) 4 Jack for connecting the probe 5 Jack for connecting the probe 6 Function selector switch

– VDE-…: Automatic test sequence according to selected standard – OFF: Instrument is switched off (no disconnection from mains) – MENU: Setup: Device configuration

… : Individual tests

– FUNCTION TEST: Function test

7 scroll key for menu and parameter selection

scroll key for menu and parameter selection

9 LCD panel 10 Socket connector for RS 232 interface 11 Signal lamp for mains connection error

key for entry, for starting test sequences and for finger contact

help key (context sensitive)

13 14 Key next to the symbol for switching test voltage to

the test socket (only possible if symbol LED is blinking)

15 Signal lamp for the functions text

Lower Left figure

16 Push-buttons (left and right) for releasing the handle from its snap-in position 17 Standard outlet socket (test socket) for connecting the device under test 18 Push-buttons (left and right) for releasing the lid 19 Compartment for probe and accessories 20 Lid 21 Test probe 22 Carrying handle and tilt stand 23 Cover or printer module (feature E01)

Overview of Available Probe Types

Probe Type Application Special Features

Standard probe (test probe with coil-cable and alligator clip)

SK2

SK5 option (feature KD01 or accessory)

Brush probe Can be plugged onto all above listed probes and test probes

☞

Accessory

Note Use of probes other than those specified above:

Text current: 200 mA

Test current: 200 mA

Leakage current, protective conductor resistance

none

Probe with plain cable (not coil-cable), 2meters long

Special probe in combination with “automatic recognition of measuring point change” function (see

For contacting devices under test with rotating, vibrating, exposed conductive parts

chapter 13).

Cables plugged into jacks 4 and 5 must be short-circuited in order to perform the probe test, either by plugging the cable ends together or by means of a conductive surface at the device under test (4-wire measurement). Remove any corrosion from the device under test.

Data Security

Measurement data, report data and user entries are stored to RAM at the SECUTEST

PSI printer module (feature E01), as long as the respective

battery supplies the required amount of voltage. Save your data to a PC on a regular basis in order to prevent any loss of

data at the printer module. We assume no liability for data loss.

We recommend the following PC programs for data processing and data management:

• PS3 (transmission of measurement data to a PC, documentation, management, report generating and deadline follow-up)

• SECU 601 (program for activating the data base function in the instrument (DBmed option), if not already available as a feature)

• PC.doc-WORD (report and list generation

• PC.doc-ACCESS (test data management)

GOSSEN METRAWATT GMBH 3

Contents Page Contents Page

1 Applications ...................................................................................6

1.1 Table: Types of DUTs – Tests – Regulations ....................................................6

1.2 Table: Individual Measurements and Regulations ............................................6

1.3 Table: Leakage Current Types ........................................................................7

1.4 List of Possible Options for SECUTEST

SII Device Series .................................7

2 Safety Features and Precautions ...................................................8

9 Individual Measurements ............................................................16

9.1 Measuring Protective Conductor Resistance ................................................. 16

9.2 Insulation Resistance R

9.3 Measuring Leakage Current ......................................................................... 19

9.3.1 Contact Current I

9.3.2 Residual Current ΔI ..................................................................................... 19

9.3.3 Device Leakage Current I

. .......................................................................... 17

ISO

(probe current, housing leakage current) ...................19

Contact

per DIN VDE 0751 .............................................19

9.4 Equivalent Leakage Current ......................................................................... 20

3 Initial Start-Up ................................................................................9

3.1 Connection to the Mains (230 V, 50 Hz) ..........................................................9

3.2 Automatic Recognition of Mains Connection Errors ........................................10

4 General Notes ..............................................................................10

4.1 Online Instructions .......................................................................................10

4.1.1 Automatic Safety Class Selection ..................................................................10

4.1.2 Manual or Automatic Operating Sequences ...................................................10

4.2 Online Help .................................................................................................10

4.3 Adjusting Contrast .......................................................................................11

4.4 Configuring Device Parameters, Setting Date and Time ..................................11

4.5 Configuring Measurement and Sequence Parameters .................................... 11

4.6 Setting Limit Values ..................................................................................... 11

4.7 Saving the Settings ......................................................................................11

9.5 Probe Voltage U

9.6 Alternating / Direct Voltage U

9.7 Resistance R (feature F01) ........................................................................... 22

9.8 Measurements with Accessories (feature F01) .............................................. 22

9.8.1 Alternating Current I

9.8.2 Temperature T with Pt100/1000 Sensor (feature F01) .................................. 23

10 Function Test ...............................................................................24

11 Measurements – Selector Switch Settings for Standards ...........26

11.1 Test Sequences .......................................................................................... 26

11.2 Setting Up Test Sequences .......................................................................... 27

11.3 Configuring Measuring Parameters ..............................................................27

11.4 Testing Devices in Accordance with DIN VDE 0701, Parts 1 and 200 ............. 28

– Max. 300 V .............................................................. 21

probe

with Clip-On Transformer (feature F01) ........................22

– Max. 253 V (feature F01) ...................... 22

AC/DC

11.5 Testing Devices in Accordance with DIN VDE 0701, Part 240 ........................30

5 Classification of Devices Under Test ............................................12

5.1 Safety Classes ............................................................................................12

5.2 Application Parts (electrical medical devices) .................................................12

6 Abbreviations ...............................................................................13

11.6 Testing Devices in Accordance with DIN VDE 0702:2004 .............................. 32

11.7 Testing Extension Cables for VDE 0701, Part 1, and VDE 0702

(option: EL1 adapter) ................................................................................... 34

11.8 Testing Multiple Outlets for VDE 0702 (optional EL1 adapter) ......................... 35

11.9 Testing in Accordance with DIN VDE 0751 .................................................... 36

7 Connecting the Device Under Test ...............................................14

8 Configuring Device Parameters ...................................................15

4 GOSSEN METRAWATT GMBH

Contents Page Contents Page

12 Storage in PSI Module (Feature E01)

19 Maintenance - Calibration ........................................................... 46

and Database Operations (Feature KB01 or DBmed option) ........ 38

12.1 Storing Measurement Data in the PSI Module ................................................38

12.2 Database Operations ...................................................................................38

12.2.1 Setting Up Test Sequences with PC Software ................................................38

12.2.2 Storing Test Results to the SECUTEST

‚

SII ......................................................38

20 Repair and Replacement Parts Service

DKD Calibration Laboratory and Rental Instrument Service ........ 46

21 Product Support .......................................................................... 47

13 Remote Control (Feature KD01 or SK5 Option) ............................ 38

14 Printing via PSI Module (Feature E01)

or with the Printer Adapter (DA-II accessory) ............................. 39

14.1 Print Out Test Data at the PSI Module ...........................................................39

14.2 Printing Test Results in Report Form .............................................................39

15 Direct Print-Out (feature KE01, SECU-dd option) ......................... 39

16 Characteristic Values .................................................................. 40

17 RS 232 Interface .......................................................................... 43

17.1 Transmission of Measurement Results to the SECUTEST®PSI ........................43

17.2 PC Connection ............................................................................................43

17.2.1 Software Evaluation of Measurement Results ................................................43

17.2.2 Instrument Control via Interface Commands ..................................................43

17.3 Interface Configuration and Protocol .............................................................43

18 Appendix ......................................................................................44

18.1 Evaluation of Measured Values for Individual Measurements

as well as for Calculated Quantities ..............................................................44

18.2 Index ..........................................................................................................45

Condensed instructions for PS3 software for maintenance and equipment management are provided with the PS3 CD ROM.

They include important instructions regarding the following topics:

• PS3 demo with additional instructions

• Special features for reading measured values in from a data file

GOSSEN METRAWATT GMBH 5

1 Applications

1.1 Table: Types of DUTs – Tests – Regulations

Start-up and Modifications

Testing after Repairs

Periodic Tes ti ng

Attention!

The test instrument may not be used for measurements within electrical systems!

Devices under test to be tested in accordance with the following regulations

DIN VDE 0751:2001

DIN VDE 0701 Part 1:2000

DIN VDE 0701 Part 240

DIN VDE 0751:2001

DIN VDE 0702:2004

DIN VDE 0751:2001

Laboratory instruments ••

Measuring and control instruments

Voltage generation devices

Electric tools ••

Electric heating devices ••

Electric motor devices ••

Lamps ••

Devices for entertainment electronics, information and communications technology

Cable reels, extension and connection leads

Data processing and office equipment

Electrical medical devices, application parts

••

•••

1.2 Table: Individual Measurements and Regulations

Individual Measurements per Regulation

Test current [A]

DIN VDE 0701,

part 1

DIN VDE 0701,

part 200

DIN VDE 0701,

part 240

DIN VDE 0702

Protective conductor resistance

Insulation resistance

Equivalent leakage current

Equivalent (device) leakage current

Residual current

Contact current

Absence of voltage (exposed conductive parts)

Patient leakage current

Device leakage current

0.2 ••••

•• •

••••

•••

••

•

Key

• Required test

DIN VDE 0751

•

6 GOSSEN METRAWATT GMBH

1.3 Table: Leakage Current Types

DIN VDE 0701-1

Equivalent leakage current

Contact current / measurement for absence of voltage

Protective conductor current with differential current measurement

DIN VDE 0702-1

Equivalent leakage current

Contact current / measurement for absence of voltage

Protective conductor current with differential current measurement

DIN VDE 0751-1 (2001)

Equivalent device leakage current

Probe to PE

Device leakage current during operation

Device leakage current during operation, differential current method

The following is measured:

PROBE (connected to protective conductor) to L & N

PROBE (open protective conductor) to L & N

Protective conductor to PE

Protective conductor interrupted, probe to PE

See chapter

9.3.2

Key

NC = Normal conditions PAT = Patient application part PE = Potential earthing DPE = Protective conductor of the device under test

, mains protective conductor

1.4 List of Possible Options for SECUTEST®SII Device Series

Example for complete type designation (article number) of a SECUTEST

SII: M7030 E01 KD01 KE01 (only the designation of the basic device, M7030, and features other than 00 are specified)

Features

Design AGM

Mains Connection for Respective Country

User Interface Language

Configuration (settings in the setup menu)

Printer Module

SECUTEST

Additional Test Sockets (cannot be retrofitted)

Database DBmed Option (Z853H)

Remote Control SK5 Special Cable (Z745K)

Direct Printing After Each Measurement for Automatic Test Sequences Read-Out via SECU-dd Option (Z853L)

DKD calibration certificate

PSI

RS 232

Each measured value is documented in this case, as opposed to the results of a test sequence for which the poorest value for each given test is displayed. Adapter set for international use (feature B00 - earthing contact socket - included) With configuration for hospital beds of Safety Class 2 (pre-adjusted) For multimeter functions, for measurements with accessories and for devices under test without plug, including 3 plug-on quick clips

00 01 02 03 04 05 06 07 08 09 10 11 99

DGB

w/o with

w/o

w/o with

with

F CH

GOSSEN METRAWATT GMBH 7

2 Safety Features and Precautions

The SECUTEST®SII test instrument has been manufactured and tested in accordance with the following safety regulations:

IEC 61010-1 / DIN EN 61010-1 / VDE 0411-1 and DIN VDE 0404 DIN VDE 0413 Part 2 and 4

When used for its intended purpose, the safety of the user, the test instrument and the device under test (electrical equipment or electrical medical device) is assured.

Read the operating instructions carefully and completely before placing your test instrument into service. Follow all instructions contained therein. Make sure that the operating instructions are available to all users of the instrument.

Tests may only be performed by a qualified electrician or under the supervision and direction of a qualified electrician. The user must be instructed by a qualified electrician in the execution and evaluation of tests.

☞

Observe the following safety precautions:

• The instrument may only be connected to electrical systems with a

• Measurements within electrical systems are prohibited.

• Be prepared for the occurrence of unexpected voltages at devices

• Make certain that the measurement cables are in flawless condition,

• Grip the test probe firmly, for example during insertion into a jack

• Measuring of insulation resistance (equivalent leakage current)

Note

Manufacturers and importers of electrical medial devices must provide documentation for the performance of maintenance by trained personnel.

maximum of 230 V which are protected with a fuse or circuit breaker with a maximum rating of 16 A.

under test (for example, capacitors can be dangerously charged).

e.g. no damage to insulation, no interruptions in cables or plugs etc.

socket. Tensioning at the coil cord may otherwise cause the test probe to snap back resulting in possible injury.

The test is conducted with up to 500 V, with a current limit of I < 10 mA. However, when touching the terminals (L or N), you will get an electric shock which, in turn, may lead to accidents. Feature F01: When connecting the DUT via jacks 1 to 3, special care must be taken to avoid touching the open cables.

• Leakage current measurement During leakage current measurement it is essential to ensure that the DUT is operated at mains voltage. Exposed conductive parts may be subject to hazardous contact voltage during the test and may not be touched under any cricumstances. (A mains shutdown takes place when the leakage current exceeds approx. 10 mA).

Attention!

The function test may only be performed after the DUT has successfully passed the safety test!

The measuring and test instrument may not be used:

• If it demonstrates visible damage

• With damaged connector cables, measuring cables or patient ports

• If it no longer functions properly

• After extraordinary stresses due to transport

In such cases, the instrument must be removed from operation and secured against unintentional use.

Meanings of Symbols on the Instrument

The symbols on the instrument have the following meanings:

Warning regarding dangerous electrical voltage

Warning concerning a point of danger (attention: observe documentation!)

Test socket

VDE testing authority approval mark

This device may not be disposed with the trash. For further details on the WEEE marking, please refer to our website www.gossenmetrawatt.de and enter search key ’WEEE’.

8 GOSSEN METRAWATT GMBH

3 Initial Start-Up

3.1 Connection to the Mains (230 V, 50 Hz)

➭ Connect the mains plug at the test instrument to the mains power

outlet. The function selector switch can be set to any position. If a mains outlet (earthing contact outlet) is not available, or if only a 3-phase outlet is available, the adapter socket can be used to connect the phase conductor, the neutral conductor and the protective conductor. The adapter socket has three permanently attached cables and is included with the KS13 cable set

Attention!

If connection is not possible via an earthing contact outlet: Shut down mains power first. Then connect the cables from the coupling socket to the mains using pick-off clips in accordance with the diagram. Disconnection from mains power is only possible with the mains plug.

= 230 V

L–N

green-yellow

Mains Connection

GOSSEN METRAWATT GMBH 9

3.2 Automatic Recognition of Mains Connection Errors

The device automatically recognizes mains connection errors if the conditions in the following table have been fulfilled. The user is informed of the type of error, and all measuring functions are disabled in the event of danger.

Typ e of Ma i n s

Connection Error

Voltage at protective

conductor PE to finger

contact

(key)

Protective conductor PE

and phase conductor L

reversed and/or

neutral conductor N

interrupted

Contact voltage at

protective conductor PE

to neutral conductor N

or phase conductor L

Mains voltage

too low lamp

In SETUP – test sequence – IT system

Attention!

In either of the first two cases listed in the table above, immediately disconnect the test instrument from the mains and eliminate the error!

Message Condition Measurements

Text appears at

LCD

lamp

lights up

Text appears at

LCD

lights up

Press

key

U > 40 V

Voltage at PE

>65V

U > 25 V

< 90/180 V

L-N

disabled

impossible

(no supply power)

disabled, although

disabling can be

deactivated

possible

under certain

circumstances

4 General Notes

4.1 Online Instructions

The performance of measurements and tests is quick and easy with the SECUTEST required connections, necessary work steps, operator errors, measurement results and more in all measuring modes. Information and test results appear at the dot matrix LCD in plain text.

4.1.1 Automatic Safety Class Selection

Depending upon the type of mains plug or the connection configuration for the device under test, the test instrument recognizes the respective safety class and recommends its use for the measurement to be performed.

4.1.2 Manual or Automatic Operating Sequences

Depending upon selections made in the setup menu (selector switch in the Auto position), the next measurement is started automatically after the current measurement has been completed, or can only be started after manual acknowledgement. The integrated online instructions are adequate for most tests and measurements. However, the contents of these operating instructions should nevertheless be read and observed.

4.2 Online Help

Online help can be queried and displayed at the LCD for all measuring and test functions, and for almost all settings. Schematic diagrams which illustrate proper connection of devices under test to the SECUTEST can be displayed as well.

➭ Press the following key in order to query online help:

SII. Integrated online instructions inform the user regarding all

SII

☞

10 GOSSEN METRAWATT GMBH

Note

Voltage at the electrical system’s protective conductor PE may result in distorted measurement values during testing for the absence of voltage, or during leakage voltage measurements.

➭ Press the same key again in order to exit online help.

☞

Note

Online help can be queried during measurement by pressing and holding the help key.

4.3 Adjusting Contrast

Set the selector switch to MENU.

Select the Setup menu, “back” is highlighted.

Activate contrast adjustment.

Press and hold the key.

Adjust contrast.

Return to the menu.

Store the contrast setting to permanent memory with the save function in the setup menu.

4.4 Configuring Device Parameters, Setting Date and Time

Device parameters and functions which are valid for all selector switch positions can be activated or deactivated with the selector switch in the

MENU position using the Setup parameter (see chapter 8 on page 15).

4.5 Configuring Measurement and Sequence Parameters

Measurement and sequence parameters, as well as functions, can be activated or deactivated in the Setup menu (selector switch in the VDE position) for the respective test regulation. Refer to chapter 11.3 on page 27 for the significance of the various parameters.

4.6 Setting Limit Values

Upon delivery, the limit values set forth (at the point in time of issue) in applicable national and international standards are stored to the test instrument. Limit values for each of the respective standards can be queried and changed if required with the Setup > Limit Values menu (selector switch in the VDE... position), but changes can only be made which result in even stricter testing than is required by the respective standard.

Newly entered limit values become effective immediately. However, these are only stored to memory permanently after activating the Store function in the Setup menu for the respective standard.

If the limit values set forth in the standards for certain safety classes need to be restored despite individualized settings, the All Values per Standard menu function in the Limit Values submenu must be selected and acknowledged with the Enter key.

If the limit values set forth in the standards are changed, the instrument’s device software can be updated via the RS 232 interface.

4.7 Saving the Settings All of the settings and changes which have been entered to the Sequence,

Limit Values (selector switch in the VDE... position) and Zero Point (tempera- ture measurement) (selector switch in the MENU position) menus, as well as

the selected contrast setting are retained until the selector switch is turned, or the test instrument is disconnected from mains power. If settings and changes should be retained even after mains power has been interrupted, they must be saved in the Setup menu for the respective test regulation or selector switch position (acknowledge the “Save” function).

GOSSEN METRAWATT GMBH 11

5 Classification of Devices Under Test

5.1 Safety Classes

Devices assigned to all of the following safety classes are equipped with basic insulation, and provide for protection against electrical shock by means of various additional precautions as well.

Safety Class I Devices

Exposed, conductive parts are connected to the protective conductor so that they are not charged with voltage if the basic insulation should fail.

Safety Class II Devices

These devices are equipped with double insulation or reinforced insulation.

Safety Class III Devices

These devices are powered with safety extra-low voltage (SELV). Beyond this, no voltages are generated which exceed SELV. These devices may not be connected to the mains.

Note: The DUT may only be connected to the test instrument at jacks 1 through 3 (Feature F01). Only a visual inspection, an insulation resistance measurement or a measurement of the supply voltage can be performed, see parameter “SC II I U

” on page 27.

The test is failed by a DUT with 300 kW with deactivated classification function (= _), but it is passed with activated classification function (= x) if the question is answered accordingly.

Similar possibilities for passing the test, although it might otherwise be failed, are included in DIN VDE 0701, part 1.

If the DUT is connected via the jacks instead of the test socket, other limit values apply because higher power consumption is possible in this case (e.g. part 1 specifies a limit value of 1 mA per kW for equivalent leakage current).

See also table: “Maximum Allowable Limit Values for Equivalent

Leakage Current in mA” on page 20.

5.2 Application Parts (electrical medical devices)

Type B Application Parts (body)

Devices of this type are suitable for both internal and external patient applications, except for use in direct proximity to the heart.

These devices provide for adequate protection against shock especially as regards:

• Reliable leakage current

• Reliable protective conductor connection if utilized

Devices of the following safety classes are allowable: I or II.

Parameter Classification (in the Sequence... menu)

The SECUTEST ues of the respectively selected safety class. The test is failed if this limit value is exceeded. However, devices under test exist for which higher limit values are allowable.

If parameter classification is activated (= x), the user is asked if higher limit values are allowable for the DUT. If “Yes” is entered, reevaluation ensues and the DUT may pass the test.

Examples

If the insulation resistance test is failed, or if interference suppression capacitors have been replaced, equivalent leakage current measurement must be performed on DUTs with heating elements in accordance with DIN VDE 0702.

12 GOSSEN METRAWATT GMBH

SII always tests in accordance with the strictest limit val-

Type BF Application Parts (body float)

Same as type B, but with type F insulated application parts.

Type CF Application Parts (cardiac float)

Devices of this type are suitable for use directly at the heart. The application part may not be grounded.

Devices of the following safety classes are allowable: I or II.

6 Abbreviations

AE Error condition: application part grounded B, BF, CF Classifications for application parts OE Operational earth

ΔI Differential current, residual current ΔI

max

EDL

A1/A2

EDL

PX±PE

EDL

SCII

HE Error condition: housing grounded I

, I , IHL, I

, I

EDL

IT system The IT system has no direct contact between active

Lmax

L Phase conductor PF Power factor MedGV German medical device ordinance MPG German medial product law MSELV Medical safety extra-low voltage N Neutral conductor NC Normal conditions P Active power PA Functional earth (equipotential bonding)

Maximum residual current (during function test) Equivalent device leakage current with designation A1/A2

(cross-reference in the standard) Equivalent device leakage current for portable x-ray

+PE: with additional PE conductor –PE: without additional PE conductor

Equivalent device leakage current for devices with additional safety class 2 components

Leakage current (differential, probe or contact current)

probe

Residual current Equivalent device leakage current Earth leakage current (current at protective conductor)

conductors and grounded parts: bodies within the electrical system are grounded.

Maximum load current (during function test) Current at clip-on meter

R Resistance (only with feature F01) R

R-ISO Insulation resistance

ISO,

R-ISO APP-PE Insulation resistance: application part to PE R-ISO

INT. CARD.

Insulation resistance: intracardiac

(application at the heart) R-ISO NL-PE Insulation resistance: neutral/phase conductor to PE R

, R-PE Protective conductor resistance

R-SL±Mains Protective conductor resistance limit value for

+mains: DUT with mains power cable

–mains: DUT without mains power cable

(protective conductor resistance limit value for mains

power cable only = 0.1 Ω) S Apparent power SELV Safety extra-low voltage SFC Single-fault condition PE Protective conductor U

AC/DC

REF

AC/DC voltage (only with feature F01)

Reference voltage: voltage to which all leakage voltages

make reference (as a rule nominal line voltage) U-ISO Test voltage for insulation measurement U U

L-N

MEAS

probe

Line voltage

Voltage with which testing was executed.

Displayed for all leakage current measurements.

Probe voltage tOn-time Temp Resistance temperature (only with feature F01) W Electrical energy ZVEH General Association of German Electricians

GOSSEN METRAWATT GMBH 13

7 Connecting the Device Under Test

➭ Connect the DUT in accordance with the schematic diagrams included

in the online help function.

Connection of the DUT to the test instrument depends upon:

• Type of connection: – With plug (“to test socket” parameter), applies to EL1 adapter as well – Without plug, single or multi-phase connection

(“to jacks” parameter), only with feature F01

– No connection to tester (“permanent connection” parameter)

• Whether or not an adapter is used: – Adapter to socket (customer specific adapter) – AT3-med to socket, adapter for devices

which are equipped with 5-pole, 16 A CEE plugs

– AT3-III to socket, adapter for devices

which are equipped 5-pole, 32 A CEE plugs, see AT3-III operating instructions for test sequence.

• The DUT’s safety class (I, II or I I I)

☞

Note

The DUT must be switched on for all tests. Switches, relays, temperature regulators etc. must all be taken into consideration.

If the test instrument is unable to automatically recognize how the DUT has been connected, the recommended connection setup should be double checked and determined manually if necessary.

➭ Position the

sequence.

➭ A selection of possible connection setups can be displayed by activat-

ing the

➭ Select the desired connection setup with the

acknowledge with the

Omitting the Protective Conductor Test in the Case of Fully Insulated Devices

You are testing a fully insulated safety class I device (e. g. screen, submersible pump, etc.), which is not equipped with an external protective conductor contact.

The decision as to the necessity of a protective conductor test in this case is to be taken by a qualified electrician who should also assume responsibility.

You can omit the protective conductor test by pressing the key soon as the following instruction is shown: „Please connect the probe with the protective conductor of the DUT“.

cursor at the second line in the start menu for the test

key.

cursor and

key.

The test instrument automatically recognizes whether or not the DUT is connected to jacks 1 through 3. If the instrument is equipped with feature B00, 01 or 03, the instrument also recognizes whether or not a DUT has been connected to the test socket. As a default setting, the program sequence assumes that the plug from the DUT has been connected to the test socket.

☞

14 GOSSEN METRAWATT GMBH

Note Safety Class II Devices with Safety Class I Mains Plugs

If the device under test is equipped with a safety class I plug although it complies with safety class II, safety class I is recognized by the test instrument. If this is the case, switch from safety class I to safety class II in the initial menu.

Protective Conductor and Insulation Resistance Measurements for Permanently Installed Devices Under Test

Attention!

Deactivate the electrical system which supplies power to the device under test before connecting the test instrument!

➭ Remove the mains fuses from the device under test and disconnect

the neutral conductor N inside the device under test.

Measuring Contact Current (absence of voltage)

Make sure that the contacted parts are not grounded.

8 Configuring Device Parameters

General device parameters can be configured and saved using Setup with the selector switch in the MENU position.

Select Setup/Menu and acknowledge.

Select parameter and acknowledge, change setting and acknowledge. Settings x / – … = function activated / deactivated

Limit values ...

Illumination Background illumination for the LCD. One of three

different conditions can be selected with the up and down scroll keys: x: continuously on, –: off Numbers 1 through 9: duration in minutes after

which illumination is automatically deactivated. Test time Duration of a single test (0 … 255 s) Reference voltage: Voltage to which leakage current makes reference

(as a rule nominal line voltage) Earth fault During the short-circuit test, testing is also performed

to determine whether or not a connection exists

between L/N and PE (short-circuit to exposed

conductive part). We assume that a short-circuit to

an exposed conductive part exists in the event of

leakage current greater than 15 mA from L/N to PE.

This value should be increased for some DUTs (in

particular high-current consumers), because greater

leakage currents are present.

Mains wait Line voltage is initially applied to the test socket.

However, testing does not begin until after the number of seconds selected in “Mains wait” has elapsed, e.g. in order to suppress measured values during the warm-up phase.

Modem... Modem function available upon request Test Sequence ...

Settings x / – … = function activated / deactivated Single-fault

If the single-fault condition has been activated, the test is interrupted as a failure as soon as an error occurs.

Auto Class PSI Test results (passed or failed ) for the various selector

switch positions are automatically assigned to the 8 statistics channels.

inc. Service Error Measurement results are compensated by taking

service error into consideration (measuring error).

IT Network

Testing in IT systems can be performed by suppressing tests for U not voltage is present at PE. (Leakage current measure-

PE-N

. The U

test determines whether or

PE-N

ment results may otherwise be distorted.)

Acst Sig, Seq An acoustic signal is generated for: incorrect con-

nection of the DUT, error in the electrical supply system and the next test step.

Acst Sig, Meas An acoustic signal is generated for: measured value

fluctuations and test current polarity reversal.

Auto Point This function can be enabled with the help of an

upgrade program, e.g. Z745K (see chapter 13 on page 38). An acoustic signal indicates whether or not the probe is connected to the protective conductor. The test sequence is run automatically. Rapid signal frequency: probe connected

Slow signal frequency: next measuring point Direct Printing See chapter 15 on page 39. Reports ... Reports which have been saved to memory can be

selected from a list with an ID number and displayed

(see

chapter 14.2 on page 39

Service ... – Time and date settings

(if a printer module is used, the same time and date must also be entered to the PSI- menu)

– Service functions (password required)

GOSSEN METRAWATT GMBH 15

9 Individual Measurements

9.1 Measuring Protective Conductor Resistance

Definition

Protective conductor resistance is the sum of the following resistances:

• Connector cable or device connector cable resistance

• Contact resistance at plug and terminal connections

• Extension cable resistance if utilized

Resistance is measured:

• Between each exposed conductive part of the housing and the earthing contacts at the mains and the device plug (if a removable mains connector cable is used), or the protective conductor terminal for permanently installed devices.

• As a 4-pole measurement

• Between the earthing contacts at the mains plug and the earthing contacts at the device plug for device connector cables

• Between the earthing contacts at the mains plug and the earthing contacts at the coupling socket for extension cables

Connecting Safety Class I Devices to the Test Socket

When the DUT is connected, resistance is measured between the protective conductor terminal at the test socket or at the PE jack, and the probe connection at the DUT (contact with conductive parts of the housing).

➭ In order to measure protective conductor resistance, contact a

conductive part of the housing with the probe, which is connected to the protective conductor.

During measurement, the connector cable must only be moved to the extent it is accessible during repair, modification or testing. If a change in resistance occurs during the manual test step of the continuity test, it must be assumed that the protective conductor is damaged, or that one of the connector contacts is no longer in flawless condition.

Testing Extension Cables

See test sequence in chapter 11.7 on page 34.

☞

Note

“DUT connection: SC I/II” is not displayed when the test is performed individually, but rather only during the automatic test sequence.

16 GOSSEN METRAWATT GMBH

Combined Test – Differential Protective Conductor Resistance Zero balancing is also possible for protective conductor measurement. With

zero balancing, all subsequent measurements are adjusted with an offset such that 0 Ω is displayed for a selected reference point which is connected to the protective conductor. When test points are contacted with the probe which are electrically connected to this reference point, differential resistance ΔR test point is displayed.

between the reference point and the contacted

The mains release key must be activated during measurement in order to perform zero balancing. The acquired value can either be applied (the value remains in memory until the instrument is disconnected from mains power), permanently saved or deleted.

Maximum Allowable Limit Values for Protective Conductor Resistance for Connector Cables with Lengths of up to 5 m

Test Standard Test Current

VDE 0701 Part 1:2000 VDE 0702:2004 VDE 0751:2001

VDE 0751:2001 0.2 Ω

This value may not exceed 1 Ω for permanently connected data processing systems (DIN VDE 0701, part 240).

Total protective conductor resistance: max. 1 Ω

> 200 mA 4 V < U

Open-

Circuit Voltage

< 24 V

Housing –

Device Plug

Housing –

Mains Plug

0.3 Ω

+ 0.1 Ω

for each

additional 7.5 m

9.2 Insulation Resistance R

ISO

Definition

Safety Class I

Insulation resistance is measured between short-

circuited mains terminals and the protective conductor.

Safety Classes II and I II

Insulation resistance is

measured between shortcircuited mains terminals and external conductive parts which can be contacted with the probe.

Exception for Permanently Installed Safety Class I Devices

Attention!

Deactivate the electrical system which supplies power to the device under test before connecting the test instrument!

➭ Remove the mains fuses from the device under test and disconnect

the neutral conductor N inside the device under test.

➭ Connect the probe to phase conductor L at the device under test in

order to measure insulation resistance.

GOSSEN METRAWATT GMBH 17

Sequence

☞

R-ISO

Start measurement.

Nominal voltage is 500 V DC in this case. Nominal voltage can be adjusted within a range of 50 V to 550 V DC.

Note

All switches at the device under test must be set to the on position during measurement of insulation resistance, including temperature controlled switches and temperature regulators as well. Measurement must be performed in all program stages for devices equipped with program controllers.

Minimum Allowable Limit Values for Insulation Resistance

Test Standard Test Voltage

VDE 0701 Part 1:2000

VDE 0702: 2004

VDE 0751: 2001

* with activated heating elements

(if heating power > 3 kW and R required)

Notes Concerning Test Standard 0702

If the measured value is less than 0.3 MΩ for safety class I devices which include a heating element, equivalent leakage current must be measured as described in chapter 9.4 on page 20, and this test must be passed. The same applies to mains powered safety class II electronic devices if the required value of 2 MΩ is not complied with. All exposed, conductive parts of safety class II and III devices, as well as of battery-powered devices must be scanned with the probe and insulation resistance and/or leakage current must be measured.

Batteries must be disconnected from their terminals during testing of battery powered devices.

500 V

SCI SCII SC III Heat

1MΩ 2MΩ 0.25 MΩ 0.3 MΩ

2MΩ 7MΩ

70 MΩ 70 MΩ

< 0.3 MΩ: leakage current measurement

ISO

∗

☞

18 GOSSEN METRAWATT GMBH

Note

When insulation measurement is first started from the menu, nominal voltage is always set to 500 V. Open-circuit voltage is always greater than nominal voltage.

9.3 Measuring Leakage Current

Attention!

During leakage current measurement it is essential to ensure that the DUT is operated at mains voltage. Exposed conductive parts may be subject to hazardous contact voltage during the test and may not be touched under any cricumstances. (A mains shutdown takes place when the leakage current exceeds approx. 10 mA).

Select the I

measurement and start.

Each time line voltage is applied to the test socket, L and N are reversed, if this function has been se-

+20

lected in the leakage current menu (see chapter

–20

9.3 on page 19). Frequency response is

taken into consideration in accordance with the diagram to the right when leakage current is measured.

9.3.1 Contact Current I

Contact

(probe current, housing leakage current)

–40

–60

U(f)

U(f=10)

Relative Magnitude (dB):

10 10210310410510

20 log

Frequency (f) in Hz

Current which flows from housing parts which are not connected to the protective conductor via an external conductive connection to earth or another part of the housing. Flow of current via the protective conductor is excluded in this case.

μΑ

1 Test socket (w/o protective conductor contact) 2Device housing

The current’s AC component is measured. The DC component can also be measured by means of individual measurement (but not with a test sequence).

9.3.2 Residual Current ΔI

Sum of instantaneous current values which flow via the L and N conductors at the device mains connection (also known as differential current). Residual current is practically identical to fault current in the event of an error. Fault current: Current which is caused by an insulation defect, and which flows via the defective point.

Attention: Residual current also includes contact current.

9.3.3 Device Leakage Current I

per DIN VDE 0751

Device leakage current is determined by means of differential current measurement.

Maximum Allowable Limit Values for Leakage Current in mA

Tes t Standard

VDE 0701

-1: 2000

VDE 0701

-240

VDE 0702: 2004

VDE 0751: 2001

* for devices with a heating power > 3.5 kW

Note 1: Devices which do not have any exposed conductive parts which are

Note 2: Permanently connected devices with protective conductor Note 3: Portable x-ray devices with mineral insulation

connected to the protective conductor, and which correspond with I

shielded power pack

NC SFC NC SFC

SC I: 3.5 1 mA/kW

and, if applicable, IPL, e.g. data processing equipment with

Contact

0.5

0.25

0.5 3.5

SCI: 3.5

1 mA/kW

SC II: 0.5

ΔII

General 0.5

Notes 1 & 3 2.5

Note 2 5.0

SC II 0.1

Key

Housing leakage current (probe or contact current)

Contact

ΔI Residual current

Device leakage current

GOSSEN METRAWATT GMBH 19

9.4 Equivalent Leakage Current

General

Measurement of equivalent leakage current is required for:

• DIN VDE 0701 and 0702, after passing the insulation test

Equivalent Device Leakage Current I

(DIN VDE 0751)

EDL

L N

DUT

Probe

Measurement of equivalent device leakage current is required for:

• Electrical medial devices in accordance with DIN VDE 0751, part 1

Tes t S e tup

A high-impedance power supply is connected between the shortcircuited mains terminals and all exposed metal parts of the housing (which are connected to one another).

L N

DUT

PE Probe

Measurement

Current which flows over the insulation at the device under test is measured.

Maximum Allowable Limit Values for Equivalent Leakage Current in mA

Test Standard I

VDE 0701-1: 2000

VDE 0702: 2004

VDE 0751: 2001

IELEquivalent leakage current

Equivalent housing leakage current

EHL

PE Protective conductor

For devices with heating power of greater than 3.5 kW

This limit value is not taken into consideration in the DIN VDE 0751 standard.

SC I: 3.5

1 mA/kW

SC II: 0.5

3.5

1 mA/kW

Permanently connected devices with PE 10

Portable x-ray devices with additional PE 5

Portable x-ray devices without additional PE 2

EHL

SC II 0.2

SC I (PE or parts connected to PE)

Devices with mineral insulation 5

Connection

Refer to the schematic diagrams included with the online help for connection instructions.

Connection Exception for Permanently Installed Safety Class I Devices

Current is measured between the probe, with which the L and N conductors must be contacted, and the protective conductor terminal PE at the device under test for permanently installed safety class I devices under test.

Attention!

Disconnect mains power before connecting the test instrument!

➭ Remove the mains fuses from the device under test and disconnect

the neutral conductor N inside the device under test.

➭ Connect the probe to phase conductor L and neutral conductor N at

the device under test in order to measure equivalent leakage current.

Connection Exception for Multi-phase Devices

Equivalent leakage current measurement is not appropriate for multiphase devices.

20 GOSSEN METRAWATT GMBH

Sequence

Current, which would flow during leakage current measurement conducted in accordance with device regulations and with nominal line voltage, is displayed during this type of equivalent leakage current measurement. Leakage current measurement in accordance with the respective device regulations is usually not possible, because the device would have to be set up in an electrically isolated fashion, or connected to an earth isolated power supply to this end.

Equivalent Leakage Current I

DIN VDE 070x / 2 K

Select the I-EL measurement and start.

Equivalent leakage current is measured between short-circuited N and L, and the protective conductor PE.

Measuring circuit resistance is equal to 2 kΩ for VDE 0701/0702 for simulation of mean body resistance of a human being.

9.5 Probe Voltage U

– Max. 300 V

probe

Voltage is measured between the mains PE terminal at the test instrument and the probe. In this case the probe can also be used as a phase finder.

Start the U

measurement.

probe

Equivalent Device Leakage Current I

for VDE 0751 / 1 K

EDL

Select the I-EDL measurement and start. Equivalent device leakage current is measured between short-circuited N

and L, and the probe. Measuring circuit resistance is equal to 1 kΩ for VDE 0751 for the

simulation of mean patient resistance.

GOSSEN METRAWATT GMBH 21

9.6 Alternating / Direct Voltage U

– Max. 253 V (feature F01)

AC/DC

Direct, alternating and pulsating voltages of up to 253 V can be measured between the N (2) and L (3) connector jacks.

9.8 Measurements with Accessories (feature F01)

9.8.1 Alternating Current I

with Clip-On Transformer (feature F01)

Connection

Select the U

measurement and start.

AC/DC

9.7 Resistance R (feature F01)

Resistance of up to 150 kΩ can be measured between the PE (1) and N (2) connector jacks.

Select the R measurement and start.

Alternating current can be measured in two measuring ranges (1 mA … 10 A ~, 1 A … 100 A~) with a clip-on current-voltage transformer connected to the N (2) and L (3) jacks (e.g. the WZ12C).

Start the IZ measurement.

Select measuring range.

22 GOSSEN METRAWATT GMBH

9.8.2 Temperature T with Pt100/1000 Sensor (feature F01) Connection

Temperature can be measured within a range of –200 °C to + 850 °C with a Pt100 or Pt1000 sensor (default setting) connected to the PE (1) and N (2) jacks.

Select the Tem p measurement and start. Select Pt100 or Pt1000 by means of

“select measuring range” with the key. The temperature unit of measure can be selected in the “TEMPERATURE” setup menu. Selection can be made amongst °C (Celsius), °F (Fahrenheit) or Kelvin. Zero balancing is also accessible via the “TEMPERATURE” setup menu.

Zero Balancing

Sensor cable resistance can be compensated with this function:

➭ Short circuit the ends of the sensor leads and determine resistance as

shown below.

Zero Balancing

The determined value can be stored directly ( data entry menu is opened with the key.

➭ Change the measured value

key) or changed first. The

manually with the help of the

and

keys.

➭ Press the

acknowledge the selected value, and to display other menu functions at the bottom of the window.

Save the selected value by activating the “store value” key exiting the balancing function with the

The “delete value” command can only be accessed via the “change value” menu. The “no zero balancing” setting is saved at the same time by activating the

key in order to

before

key.

GOSSEN METRAWATT GMBH 23

10 Function Test

The device under test can be subjected to a function test with line voltage via the integrated test socket.

Function Test

In addition to testing with the selector switch in the function test position, or with the Function parameter in the MENU position (feature F01 only), a function test can also be performed immediately after safety testing has been passed in accordance with the selected standard (not possible for safety class III devices).

Attention!

The function test may only be performed after the DUT has successfully passed the safety test.

☞

Note

Each time line voltage is applied to the test socket, phase conductor L and neutral conductor N are automatically reversed, if the “mains polarity reversal” function has been activated (= x) in the I leakage selector switch position.

Note

The function test is only possible if the device under test has been connected to the test socket (21).

Measurements

The function test includes the following measurements:

– Voltage U-LN between the L and N conductors – Residual current ΔI

(corresponds to fault current between L and N) – Load current I – Active power P – Apparent power S (calculated) – Power factor PF (cos ϕ calculated, display > 10 W) – Electrical energy W – On-time t for U

The following values are also displayed for all selector switch positions except MENU, after the function test has been completed:

– Maximum residual current ΔI – Maximum load current I – Maximum active power P

Power factor is calculated from active power and apparent power. Power factor corresponds to cos ϕ for sinusoidal quantities (line voltage and load current).

Attention! Starting the Function Test

For reasons of safety, the device under test must be switched off before the function test is started. This precaution prevents inadvertent start-up of a device under test which may represent a hazard during operation, e.g. a circular saw or a disc grinder.

Ending the Function Test

After completion of the function test, devices under test must be turned off with their own switch – especially devices with relatively high inductivity.

at the socket (21)

L–N

Lmax

max

24 GOSSEN METRAWATT GMBH

Short-Circuit Test

1 Test for shorts between conductors

N and L.

2 Test to determine whether or not

the N or L conductors are shortcircuited to the protective conductor.

The test socket can be rendered voltage-free with the key (14), or the

function test can be ended with the

key (12).

☞

If the lamp blinks (15), line voltage can be switched to the test socket with the key (14), and the measurement can be started. If the lamp (15) is lit continuously, line voltage is present at the test socket.

GOSSEN METRAWATT GMBH 25

Note

A short-circuit at the device under test is recognized automatically by the test instrument. A message appears at the display (9), and the function test is disabled.

11 Measurements – Selector Switch Settings for Standards

If measurements need to be performed in accordance with given standards which require specific tests, and if results need to be documented with a test report, an automatic test sequence is advisable instead of individual measurements.

➭ Connect the SECUTEST

A mains connection test is initialized (see chapter 3.2 on page 10).

➭ Connect the DUT to the test socket at the SECUTEST

ter 7 on page 14). The test instrument initializes connection type recognition.

➭ Set the selector switch

If the test instrument is equipped with features B00, 01 or 03, and if the DUT has been connected to the test socket, safety class recognition is performed. Otherwise, the safety class must be specified manually. Move the cursor up into the third line in the initial window with the key, and acknowledge with the key. A safety class can now be selected with the

➭ The test sequence can be configured in the Setup… menu, limit values

can be changed if necessary and database options can be selected.

➭ The test sequence is started by selecting Start test and acknowledging

with the

Tests which have already been included in chapters 9 through 14 are not described here again. The only exception is measurement of extension cables.

key (see following chapter, “Test Sequences”.

SII to mains power.

SII (see chap-

to the appropriate standard.

and keys and acknowledged with the key.

11.1 Test Sequences

Test sequences for the various standards are always run in the same order, assuming that the device under test has been properly connected and the mains connection test has been passed. The test sequence can be run step by step with manual activation of each subsequent step if this function has been specified, or automatically. Step by step manual operation can be selected if “Manual Sequence” has been activated under Sequence... in the setup menu in the initial window.

• Visual inspection: If “Visual Inspection” has been activated under

If a part is recognized as defective by the user, it must be identified as such by selecting it with the cursor and acknowledging with the key.

• Protective conductor measurement (for SC I devices under test only)

☞

• Evaluation of protective conductor testing

• Insulation resistance measurement

• Evaluation of insulation test

• Leakage current measurement

• Evaluation of each individual leakage current measurement

• Evaluation of the overall test

• Perform function test if required:

• Display test results

• Save test results and print if required

Note

If a protective conductor connection is not possible, the measurement can be skipped with probe to protective conductor“ is shown on the display).

DIN VDE 0751: Only if ISO-R is activated under Sequence…

DIN VDE 0702: Only if ISO-R is activated in the initial window

The function test can be performed each time a safety test has been successfully completed. The blinking signal lamp indicates that the function test should be started. Beyond this, the function test can also be started from the Function Test selector switch position. See chapter 10 on page 24 regarding performance of the function test.

(the worst measured values for the test sequence)

Sequence…

(when the message „Connect

in the setup menu

26 GOSSEN METRAWATT GMBH

11.2 Setting Up Test Sequences

All possible sequence settings for all of the regulations are listed below.

Select the Setup... menu from the initial program window and acknowledge

Repair tests, periodic testing

Save All of the settings in the setup menu, i.e.

configuration of measuring parameters and current limit values, can be saved with this command. These values remain active even after setting the selector switch to a different position, and after disconnection

from mains power. Sequence … See page 27. Limit values … See chapter 4.6 on page 11. Database … Start with ID No.

x: Before each measurement is started, an entry prompt appears requesting entry of an ID no. An individual number can be entered (max. 20 characters) with the keypad at the PSI module (optional), read in with a barcode scanner (optional) or directly selected from a list. If an incorrect entry is made: Only complete lines can be deleted, and deletion is only possible with the

key at the instrument.

ID no. = test sequence (feature KB01 or DBmed option)

See chapter 12 on page 38.

11.3 Configuring Measuring Parameters

Depending upon the test regulation, various measuring parameters can be configured for the test sequence (settings: x / – = function activated / deactivated). All possible parameters for all of the regulations are listed below. The Sequence ... menu is accessed via the setup parameter in the initial program window for the respective regulation.

Select the Sequence ... menu and acknowledge.

Select a parameter, acknowledge, change and acknowledge the change.

General Parameters

Visual inspection This menu appears at the very beginning of the test

sequence.

Manual sequence Each test step must be acknowledged with the

key (see test sequence in chapter 8 on page 15 regarding test duration for automatic sequence)

Auto-store After testing is finished, test data are automatically

stored to the SECUTEST Dbmed option), or the SECUTEST

SII (feature KB01 or

PSI (accessory).

Polarity reversal L an N are reversed each time line voltage is applied

to the test socket.

Classification Questions regarding classification appear if limit

values are exceeded (see chapter 5 on page 12).

SC III U

Supply voltage is measured instead of insulation resistance for active devices under test.

R-ISO LN-PE Insulation resistance measurement is performed

between phase/neutral conductors and the protective conductor.

Additional Parameters for DIN VDE 0702/0751

Auto test method

The instrument recognizes whether or not the device under test can be switched on: Leakage or residual current, or insulation resistance and earth leakage current, are measured accordingly

Adapter for socket Limit values are activated for permanently connected

devices. A device under test which is normally permanently installed can be connected to the test socket via an adapter. No voltage may be applied to the

test socket when this test method is used.

GOSSEN METRAWATT GMBH 27

11.4 Testing Devices in Accordance with DIN VDE 0701, Parts 1 and 200

The following measurements can be performed in accordance with the above mentioned standard:

• Protective conductor measurement R

with plug)

– Part 1/200: Test current: ±200 mA DC

• Insulation resistance measurement R

Part 1

The following safety class I through III appliances and electrical equipment can be tested in this selector switch position, for example:

• Devices with electric motors

• Electrical heating devices

• Electrical tools

• Light fixtures SC I extension cables can also be tested (see chapter 11.7 on page 34).

Part 200

Mains powered, safety class I through III electronic devices, e.g. consumer electronics, can be tested in this selector switch position:

• Stereo equipment, televisions The following maximum values for equivalent leakage current apply for

mains powered electronic devices per DIN VDE 0701, part 200:

– Devices with single-phase power supply:1 mA – Devices with multi-phase power supply: 0.5 mA

(permanent connection or

ISO

Check connection parameters and start test.

To Socket This is the default setting. Refer to chapter 7 on page

14 for other types of connection.

Class If the test instrument is equipped with features B00,

01 or 03, and if the DUT has been connected to the test socket, safety class recognition is performed (SC I or SC II). Otherwise, the safety class must be specified manually.

Ext. Cable x: Extension cables or connector cables which are

longer than 5 m can be tested with the help of the EL1 adapter (optional), either separately or in combination with a device.

ID No. See parameters database in chapter 11.2 on page

Setup … See chapter 11.2 on page 27 regarding setup of the

☞

28 GOSSEN METRAWATT GMBH

Note

Extension cables can only be tested in the VDE 0701 part 1 and VDE 0702 selector switch positions if the EL1 accessory adapter is used (see chapter 11.7 on page 34).

27.

measuring sequence.

Test Sequence per VDE 0701

Select connection, select test regulation VDE 0701 part 1 or 200, classify the DUT (SC I, II or I II), part 1: extension cable X/– (with/without)

Visual inspection

Yes

Short-circuit

OK?

function test

Display results, save/print report

OK?

at DUT?

SC I: RPE

OK?

Yes

Tes t OK?

Start

Yes /No

Yes

RISO+I

OK?

Tes t OK?

Switch DUT on

Safety Class I only: Contact all exposed, conductive parts with the probe. The test can be repeated as often as desired for various protective conductor parts with the manual sequence*

Switch line voltage to test socket, start function test

Framed with dashed line: The test is only run if it has been activated in the initial program window, or in the Setup menu under Sequence ...

* If it is not clear whether or not all

exposed, conductive parts are connected to one another or to the protective conductor, testing can be performed in the manual mode.

GOSSEN METRAWATT GMBH 29

11.5 Testing Devices in Accordance with DIN VDE 0701, Part 240

Testing safety class I and II data processing equipment and office machines as individual devices and in combination with one another.

The following measurements can be performed in accordance with the above mentioned standard:

• Protective conductor R Test current: DC ±200 mA

• Housing leakage current I

• According to DIN VDE 0701, part 240, the device protective conductor must be tested after maintenance, repair or modification of data processing equipment and office machines, and exposed, conductive parts must be tested for the absence of voltage. This applies to:

• Safety class I devices for all exposed, conductive parts which are accessible to the user, and which are not connected to the protective conductor

• Safety class II devices (totally insulated devices) for all exposed, conductive parts which are accessible to the user

with the mains plug poled in both directions

Setting Up the Test Sequence

See chapter 11.4 regarding the test sequence.

Special Parameters

Combined Testing

Safety class I and II devices can be tested individually or in combination. All protective conductor connections are tested first for interconnected safety class I devices, and then – as is also the case for interconnected safety class II devices – all exposed, conductive parts.

Connecting the Device Under Test

➭ Connect the test instrument and the DUT as described below:

– Connect both devices to separate mains outlets.

The outlets to which the test instrument and the safety class I DUT are connected must share a common protective conductor!

– Or connect the test instrument to the mains and the DUT to the

test socket at the test instrument.

(permanent connection or with plug)

Data Processing / Office Machines

Permanently connected or with plug

To test socket at the instrument

The requirement for testing with the mains plug poled in both directions can be fulfilled

by connecting the DUT to the test socket at the instrument, and by activating mains polarity reversal under “Sequence” in the setup menu. Each time the key (14) is activated, phase conductor L and neutral conductor N are reversed at the test socket.

Attention!

Testing with mains polarity reversal or with the mains plug poled in both directions results in interruption of supply power to the affected data processing equipment or office machine. This test may thus only be conducted with the consent of the operator of the data processing equipment or office machine. If the DUT is defective, the electrical system’s RCCB may be tripped during testing which would also result in interruption of supply power to the affected equipment or office machine. The manufacturer of the test instrument assumes no liability for loss of data or other damage which results from use of the test instrument.

30 GOSSEN METRAWATT GMBH

Test Sequence per VDE 0701, Part 240

Select connection, select test regulation VDE 0701, part 240, classify the DUT (SC I, II or III), combination testing X/– (yes/no)

Yes

Visual inspection

OK?

Yes /No

Short-circuit

at DUT?

SC I: RPE

OK?

Yes

OK?

Yes

Start

function test

Tes t OK?

Switch DUT on

Contact all exposed, conductive parts with the probe. The test can be repeated as often as desired for various protective conductor parts with the manual sequence*.

Switch line voltage to test socket, start measurement

Reverse mains polarity, perform measurement again

Switch line voltage to test socket, start function test

Framed with dashed line: The test is only run if it has been activated in the initial program window, or in the Setup menu under

Sequence ...

* If it is not clear whether or not all

exposed, conductive parts are connected to one another or to the protective conductor, testing can be performed in the manual mode.

Display results (for combination testing: additional display of differential resistance), save/print report

GOSSEN METRAWATT GMBH 31

11.6 Testing Devices in Accordance with DIN VDE 0702:2004

The following measurements can be performed in accordance with the above mentioned standard:

• Protective conductor R Test current: DC ±200 mA

• Insulation measurement R

e.g. if danger exists that voltage sensitive components in data

(permanent connection or with plug)

(can be deactivated,

ISO

processing systems might be damaged) plus equivalent leakage current

• Contact current for safety class I I

• Differential current

Check connection parameters and start test.

To Socket This is the default setting. Refer to chapter 7 on page

14 for other types of connection.

Class If the test instrument is equipped with features B00,

01 or 03, and if the DUT has been connected to the test socket, safety class recognition is performed (SC I or SC II). Otherwise, the safety class must be specified manually.

Ext. Cable x: Extension cables or connector cables which are

longer than 5 m can be tested with the help of the EL1 adapter (optional), either separately or in combination with a device.

ISO-R x: Insulation resistance measurement is performed.

ID No. See parameters database in chapter 11.2 on page

27.

Setup … See chapter 11.2 on page 27 regarding setup of the

measuring sequence.

32 GOSSEN METRAWATT GMBH

Test Sequence per VDE 0702:2004

Select connection, select test regulation VDE 0702, classify DUT (SC I, II or II I), extension cable X/– (with/without)

and IL OK?

ISO

Yes

and IL OK: Yes

ISO

Visual inspection

OK?

Yes /No

Short-circuit

at DUT?

SC I: RPE

OK?

Yes

ISO

OK?

Yes /No

OK?

Start

function test

Switch DUT on

Contact all exposed, conductive parts with the probe

If there are reservations against an insulation measurement

OK?

Switch line voltage to test socket, start function test

Yes

Tes t OK?

Framed with dashed line: The test is only run if it has been activated in the initial program window, or in the Setup menu under Sequence ...

* Residual current,

contact current (direct) or equivalent leakage current

Display results, save/print report

GOSSEN METRAWATT GMBH 33

11.7 Testing Extension Cables for VDE 0701, Part 1, and VDE 0702

(option: EL1 adapter)

Extension Cables up to 5 m Long

Protective conductor resistance between the earthing contact at the mains plug and all exposed metal parts may not exceed 0.3 Ω for safety class I devices. This value may not exceed 1 Ω for permanently connected data processing systems (DIN VDE 0701, part 240).

Extension and Connector Cables Longer than 5 m

Per DIN VDE 0702, an additional cable resistance of 0.1 Ω, however, not more than 1 Ω, is allowable as of a length of 5 m for each additional

7.5 m.

Resistance testing for cables longer than 5 m is thus advisable (see also limit values on page 17).

Performing the Test

➭

Connect the extension cable to the EL1 adapter as shown in the figure above.

➭

Select the “Ext. Cable” test from the initial menu with the cursor and acknowledge with the

➭

Select “Start Test” with the key.

➭

Start the measurement sequence with the key.

➭

First perform and acknowledge visual inspection of the extension cable.

➭

Enter the length of the cable with the and keys. Acknowledge with the

key.

key: Ext. Cable x WITH EL1.

☞

Connecting the Extension Cable or the Multiple Outlet

☞

34 GOSSEN METRAWATT GMBH

Note

The EL1 accessory adapter is required for testing for shortcircuiting and interruption of single-phase extension cables.

PROBE 5 4

(21)

SECUTEST

EL1

Note

The keys in the adapter’s handle have no function.

Device Under Test = Extension Cable

11.8 Testing Multiple Outlets for VDE 0702 (optional EL1 adapter)

➭ up to version 5.10:

Do not select “WITH EL1” in the initial menu. The following must appear in the line: Ext. Cable – WITH EL1. “Manual seque nc e” mu st be selected.

➭ from version 5.11 onwards:

Select “X WITH EL1” in the initial menu. The following must appear in the line: Ext. Cable X WITH EL1. “Manual seque nc e” mu st be selected.

➭ A visual inspection must always be performed. It may thus be

necessary to unreel the cable from its drum or reel.

➭ Protective conductor resistance measurement: Contact the first outlet

with the EL1 adapter. Each time you are ready to contact the next outlet, press the

➭ After measurement has been completed for all outlets, reinsert the test

probe in order to continue with the performance of subsequent tests as described in chapter 11.6.

key to repeat the test.

GOSSEN METRAWATT GMBH 35

11.9 Testing in Accordance with DIN VDE 0751

The following measurements can be performed in accordance with the above mentioned standard:

• Protective conductor measurement R

• Insulation measurement R – R-ISO LN-PE

(can be additionally activated)

ISO

, test current: 200 mA DC

(Insulation resistance LN to protective conductor)

• Equivalent device leakage current I

EDL

• Device leakage current (direct measurement or by means of differential current)

• Patient leakage current with probe

(Patient leakage current is not possible with SFC „Mains at Application Part“)

• Equivalent patient leakage current with probe

Leakage current is converted to reference voltage (see limit values, chapter 8 on page 15). Reference voltage must be matched to the supply voltage range.

Check connection parameters and start test.

To Socket This is the default setting. Refer to chapter 7 on page 14 for

other types of connection.

Class If the test instrument is equipped with features B00, 01 or 03,

and if the DUT has been connected to the test socket, safety class recognition is performed (SC I or SC II). In all other cases, or if it is not clear whether or not all exposed, conductive parts are connected to one another or to the protective conductor, the safety class can be selected manually.

Type Select the type of device under test from a list (device type).

If “Old devices” is selected, limit values specified in DIN VDE 0702 are used.

Ap. parts... (BF): The type of application parts can be changed manually:

Select the “Ap. Parts” line with the with the

key and change with the or key.

or key, acknowledge

ID No. See parameters database in chapter 11.2 on page 27. Setup … Refer to chapter 11.2 on page 27 regarding setup of the

measuring sequence.

36 GOSSEN METRAWATT GMBH

Test Sequence per VDE 0751

Select connection, select test regulation VDE 0751, classify the DUT (SC I or II), application part? (type B/BF/CF)

Yes

NoNo

Visual inspection

OK?

Yes /No

Short-circuit

at DUT?

SC I: R

OK?

Yes

ISO

OK?

Yes

EDL

OK?

ΔI

Yes

EPL

OK?

Yes

Start

function test

Tes t OK?

Switch DUT on

Contact all exposed, conductive parts with the probe. The test can be repeated as often as desired for various protective conductor parts with the manual sequence*.

Contact all exposed, conductive parts with the probe.

ΔI or IDL: only if the device is switched electronically

Application parts B, BF, CF

Switch line voltage to test socket, start function test

Framed with dashed line: The test is only run

–

If it has been activated in the initial

program window, or in the Setup menu under Sequence ...

or – If at all possible

* If it is not clear whether or not all

exposed, conductive parts are connected to one another or to the protective conductor, testing can be performed in the manual mode.

Display results, save/print report

GOSSEN METRAWATT GMBH 37

12 Storage in PSI Module (Feature E01)

and Database Operations (Feature KB01 or DBmed option)

12.1 Storing Measurement Data in the PSI Module

Upon completion of a measurement – „Test passed/Test failed“ is shown on the display – you can save the measurement data to the memory of the PSI module.

➭ Press the STORE key at the PSI module to this end.

A text entry field is shown.

➭ You may now enter your comments on the measurement and/or an

identification number.

➭ Press the STORE key once more to save the measurement data and

your comments. The message: „Data are stored“ is displayed.

A detailed description is given in the operating instructions of your PSI module under chapter „How to display, print and store protcol“.

12.2 Database Operations

12.2.1 Setting Up Test Sequences with PC Software

This function must be activated with the help of upgrade software, e.g. the Z853H program.

Up to 99 test sequences can be uploaded for each of the selector switch positions from a PC via the serial port at the SECUTEST ment. After testing has been performed, the test results are saved to the same database, if a PSI module has not been connected. The maximum possible sum of test sequences and test results is 127.

Test results are stored to the PSI module if one has been connected. The database can be used in different ways:

(see also chapter 11.2 on page 27)

1. Stored test results can be displayed

(select the ID no. and then activate the “from database” function). The desired test sequence can be selected with the scroll keys.

2. If “ID no. = test sequence” has been activated (X), the first two

characters of the ID number determine the test sequence.

SII test instru-

Example: ID number = 037890sk3r

If this number does not exist, the default sequence is executed.

3. Executed test sequences are stored to memory at the instrument as

☞

12.2.2 Storing Test Results to the SECUTEST

This function must be activated with the help of upgrade software, e.g. the Z853H program.

If no PSI module has been connected, up to 99 reports can be stored to the test instrument. The reports can be viewed as required at the instrument and can be printed out, for example with the help of DA-II software or a terminal program.

The reports are sorted by time and date and are displayed with the ID number. If no ID number was assigned, date and time are automatically saved instead.

Test sequence number 03 is executed. Test sequence 03 is the test sequence which appears at the third position from the top of the list.

test results. The test results can also be displayed at a later point in time with the “test sequence settings” submenu in the “general setup” menu.

Note

The database can only be generated or deleted with the help of a PC with a terminal program, or appropriate application software.

SII

13 Remote Control (Feature KD01 or SK5 Option)

This function must be activated with the help of upgrade software, e.g. the Z745K program.

The protective conductor measurement is expanded to include the function: “automatic recognition of measuring point change”. During protective conductor measurement, the instrument recognizes whether or not the probe is in contact with the protective conductor, and indicates these two possible conditions by means of different acoustic signals.

This function is helpful if several protective conductor connections need to be tested. The function can be activated with the “auto measuring point” function in the “test sequence setup” menu (see “changes to the switch position menu” above).

38 GOSSEN METRAWATT GMBH

14 Printing via PSI Module (Feature E01)

or with the Printer Adapter (DA-II accessory)

14.1 Print Out Test Data at the PSI Module

Upon completion of a measurement – „Test passed/Test failed“ is shown on the display – you can print out the measurement data via your PSI module.

➭ Press the PRINT key at the PSI module to this end.

The print menue is displayed.

➭ Select „Protocol“ with your cursor and acknowledge with

➭ Press the PRINT key once more to start the print-out.

A detailed description is given in the operating instructions of your PSI module.

14.2 Printing Test Results in Report Form

Test instruments can be connected to commercially available printers with the DA-II printer adapter (Z745M), even if they are not equipped with a parallel port, thus allowing for on-site print-out of test reports etc.

The only prerequisite is that the printer module is set up for direct report generation.

Measurement results for the current test can be stored to memory, the results of the current test can be printed out to the corresponding report form, previously stored test results can be queried (scroll: DBmed option, see chapter 12) and all saved measurement results can be printed out from this menu.

Print-out is executed directly to the Centronics printer via printer adapter DA-II.

The matching report form is automatically selected for the standard selected with the selector switch.

15 Direct Print-Out (feature KE01, SECU-dd option)

After completion of each test (individual test or at the end of a test sequence), test results are read out directly via the RS 232 interface. If the SE-

CUTEST

PSI has been connected, the results are printed directly to paper.

☞

Connecting a Centronics Printer

Connect the test instrument to a Centronics printer via the RS 232 port with the help of the DA-II adapter. The PSI module may not be connected.

You can shift to the Report menu from any of the displayed test results (1

GOSSEN METRAWATT GMBH 39

Note

Only printers disposing of the ASCII type font are suitable for use.

page) with the help of the key.

16 Characteristic Values

Func-

Measured Quantity Measuring Range /

tion

Device Protective

Conductor

Resistance R

Insulation Resistance

ISO

Equivalent Leakage

IEL or. I

Current

Equivalent Patient Leakage Current

EPL

Contact Current or

Housing Leakage

Current I

Probe

or I

Patient Leakage

Current I

AC/DC Compo-

Tests per DIN VDE 0701 / 0702 / 0751

nents Measured

Resolu-

Nominal Range of

Use

tion

Nominal

Voltage

0.000 … 2.100 Ω 1mΩ

2.11 … 31.00 Ω 10 mΩ

0.050 … 1.500 MΩ 1kΩ

1.01 … 10.00 MΩ 10 kΩ

50 … 500

10.1 … 310.0 MΩ 100 kΩ±(10% rdg. +10 d) ±(10% rdg. +10d)

0.00 … 21.00 mA 10 μA

20.1 … 120.0 mA 100 μA

0.0 ... 310.0 μA100nA

2.00 ... 11.00 mA 10 μA

0 … 310 μA

0.300 … 3.500 mA

0.1 μA 1 μA

0.0 ... 310.0 μA100nA

0.300 ... 3.100 mA 1 μA

3.10 ... > 15.00 mA 10 μA

Open-Cir-

cuit Volt-

4.5 … 9V

—

1.0 • U

1.5 • U

VDC

—

————1/2kΩ

————1kΩ — ±(5% rdg. +10 d)

Separately Differential Current ΔI

between L and N

Line Voltage U

Load Current I

Active Power P 0 ... 3700 W

Apparent Power S 0 ... 4000 VA 1 VA Calculated value U

Power Factor LF,

Function Test

sinusoidal: cos

Differential Current

ΔI between L and N

per DIN VDE 0702

The device leakage current step of the test sequence is executed by means of

40 GOSSEN METRAWATT GMBH

Probe voltage

Probe

differential current measurement for testing per DIN VDE 0751. As of 25 mA: shutdown by residual current measurement within 100 ms Measured value P and calculated value S are compared and the smaller of the two is displayed.

0.000 … 3.100 mA

3.00 … 31.00 mA~

207.0 ... 253.0 V~ 0.1 V — — — — ±(2.5% rdg. +5 d) 253 V cont.

L–N

0 ... 16.00 A

0.00 ... 1.00 0.01 Calculated value P / S, display > 10 W ±(10% rdg. +5 d)

1 μA

10 μA

10 mA — — — — ±(2.5% rdg. +5 d) 20 A 10 min.

RMS

1W — — — —

— — ————

0.00 ... 31.00 mA~ 10 μA— ——

0 ... 253.0 V

, and

0.1 V — — —

age U

230 V~

– 20/

+10 % 230 V~

– 20/

+10 %

Nominal

Current

…

Short-

Circuit

Cur. I

—

>200 mA

>1mA <10mA — —

— < 3.5 mA > 72 kΩ 1/2 kΩ

— < 3.5 mA > 72 kΩ

Measuring circuit becomes highly resistive, indication at display

For DIN VDE 0701/0702: 2 kΩ, for DIN VDE 0751: 1 kΩ

This measuring range with DIN VDE 0751 only

Internal

Reference

Resis-

Resist.

tance R

REF

——

1kΩ

±10 Ω

— ±(5% rdg. +10 d)

• I

L–N

Measuring

Error

±(5% rdg. + 10 d)

>10d

±(5% rdg. +10 d)

±(10% rdg. +10 d)

> 10 d

±(10% rdg. +10 d)

> 10 d

Intrinsic Error Overload Capacity

Value Duration

±(2.5% rdg. + 5d)

> 10 d

±(2.5% rdg. +5 d)

> 10 d

±(2.5 % rdg. +5 d)

> 10 d

±(2.5% rdg. +5 d)

> 10 d

±(2.5% rdg. +5 d)

> 10 d

±(2.5% rdg. +5 d)

> 10 d

±(5% rdg. +5 d)

> 10 d

±(5% rdg. +10 d)

>20d

±(5% rdg. +10 d)

>20s

±(5% rdg. +5 d)

±(2.5% rdg. +5 d)

>10d

253 V cont.

253 V cont.0.300 ... 2.100 mA 1 μA

253 V cont.

253 V

253 V cont.

20 A 10 min.

253 V cont.

cont.

2 4

Multimeter Measurements for Devices with Feature F01

Func-

Measured Quantity Measuring Range /

tion

AC/DC

R Resistance 0 ... 150.0 k

Clip

Tem p.

Voltage

Low Voltage, SC II I

Current with

Clip-On Current-

Voltage Transformer

WZ12C

Tem pe ra tu re

with Pt100/Pt1000

Sensor

Nominal Range of Use

0 ... 253.0 V

0.000 ... 10.00 A 1mA — — 1.5MΩ —

0 ... 100 A

– 200 ... – 50

– 50.1 ... + 300.0

+300 ... +850

and

Resolution

0.1 V — — —

OpenCircuit Voltage U

ShortCircuit Current I

Internal Resistance R

Measuring Error

—

±(5% rdg. +10 d)

Intrinsic Error Overload Capacity

Value Duration

±(2.5 % rdg. +5 d)

>10d

253 V cont.

Ω 100 Ω <20V– 1.1mA — — ±(1% rdg. +3 d) 253 V cont.

±(3% rdg. +10 d)

1A — — 1.5MΩ — 253 V cont.

°C1°C

°C0.1°C ±(1% rdg. +1 °C) 10 V cont.

<20V– 1.1mA — —

>10d without clip-on device

±(2% rdg. +1 °C) 10 V cont.

253 V cont.

°C1°C ±(2% rdg. +1 °C) 10 V cont.

Reference Ranges

Line Voltage 230 V ±0.2 % Line Frequency 50 Hz ±0.1 % Waveshape Sine (deviation between effective and rectified

value < 0.5%) Ambient Temperature +23 °C ±2K Relative Humidity 40 … 60% Load Resistance Linear

Nominal Ranges of Use

Line Voltage 207 V … 253 V Line Frequency 50 Hz Line Voltage

Wave shape Sine Temperature

0 °C … +50 °C

Ambient Conditions

Storage Temperature – 20 °C ... + 60 °C Operating Temperature – 10 °C ... + 50 °C Accuracy Range 0 °C ... + 50 °C Relative Humidity Max. 75%, no condensation allowed Elevation Max. 2000 m

Influencing Quantities and Influence Error

Influencing Quantity / Sphere of Influence

Position Change E1 —

Change in Test Setup Supply Power E2 2.5

Temperature Fluctuation

0 … 21

°C and 25 … 40 °C

Current at Device Under Test E4 2.5

Low-Frequency Magnetic Fields E5 2.5

Impedance at Device Under Test E6 2.5

Capacitance, Insulation Measurement E7 2.5

Waveshape of Measured Current

49 … 51 Hz 2 for capacitive load (for equivalent

45 … 100 Hz 1 (for contact current)

Designation per DIN VDE 0404

Influence Error ± … % of Measured Value

Specified influence error applies per 10 K change in temperature:

1 in case of PE measurement

0.5 for all other measuring ranges

leakage current)

2.5 for all other measuring ranges

Deployment Indoors, except within specified ambient

conditions

GOSSEN METRAWATT GMBH 41

Power Supply

Line Voltage 207 V … 253 V Line Frequency 50/60 Hz Power Consumption Approx. 30 VA

for function test Continuous max. 3600 VA,

power is conducted through the instrument only, switching capacity ≤ 16 A

Electrical Safety

Safety Class I per IEC 61010-1/EN 61 010-1/VDE 0411-1 Nominal Voltage 230 V Test Voltage 3.7 kV 50 Hz Measuring Category II Fouling Factor 2 Safety Shutdown Where differential current at the

DUT > 25 mA Shutdown time: < 100 ms Probe current: > 10 mA, < 1 ms

Electromagnetic Compatibility

Generic Standard DIN EN 61 326:2002

Interference Emission Class

EN 55022 B

Interference Immunity Test value Feature

EN 61000-4-2 Contact/atmos. - 4 kV/8 kV A

EN 61000-4-3 10 V/m C

EN 61000-4-4 Mains connection - 2 kV B

EN 61000-4-5 Mains connection - 1 kV A

EN 61000-4-6 Mains connection - 3 V A

EN 61000-4-11 0.5 period / 100% A

Mechanical Design

Display Multiple dot matrix display, 128 x 128 pixels Dimensions LxWxH: 292 mm x 138 mm x 243 mm Weight Standard instrument: approx. 4.0 kg Protection Housing: IP 40

Terminals: IP 20 per DIN VDE 0470 part 1 / EN 60529

Extract from table on the significance of IP codes

IP XY

digit X)

0 not protected 0 not protected 1 ≥ 50.0 mm dia. 1 vertically falling drops

2 ≥ 12.5 mm dia. 2

3 ≥ 2.5 mm dia. 3 spraying water 4 ≥ 1.0 mm dia. 4 splashing water

Protection against

foreign object entry

IP XY

(2nd digit Y)

Protection against the

penetration of water

vertically falling drops with

enclosure tilted 15°

RS 232 Interface

Type RS 232C, serial, per DIN 19241 Configuration 9600, N, 8, 1 Connection 9-pin subminiature socket connector

42 GOSSEN METRAWATT GMBH

17 RS 232 Interface

The RS 232 port is used to connect the SECUTEST®PSI module (accessory), which can be installed to the lid of the SECUTEST barcode scanner.

17.1 Transmission of Measurement Results to the SECUTEST

Test results – except for results from individual measurements (selector switch in MENU position) and the function test – can be transmitted from the SECUTEST

SII to the SECUTEST®PSI module, where they can be stored and printed out in the form of measuring, test and statistical reports at any time.

17.2 PC Connection

Connection to an IBM compatible PC is also possible. The PC is connected to the interface at the test instrument, or to the interface port at a previously installed SECUTEST

PSI module.

17.2.1 Software Evaluation of Measurement Results

Convenient software programs such as PC.doc-WORD, ACCESS or PS3 allow for easy generation of measuring and test reports, as well as archiving of measured data.

17.2.2 Instrument Control via Interface Commands

All key functions included with the SECUTEST

the help of interface protocols, and the following parameters can be queried:

• Type of measurement and measuring range

• Test setup

• Measurement sequence progress

• Detailed measurement results

SII, to a PC or a

PSI

SII can be simulated with

17.3 Interface Configuration and Protocol

The interface included with the SECUTEST

SII is in compliance with the

RS 232 standard. Technical Data: Baud Rate 9600 baud, permanently set

Character Length 8 bits Parity none Stop Bits 1 Data Protocol per DIN 19244, X_ON / X_OFF protocol

Connector Pin Assignments for 9-Pin Subminiature Socket Connector:

1: External in + (for internal use only) 2: TXD (transmitter output) 3: RXD (receiver input) 4: External in + 5: GROUND 6: +5 V (500 mA output, for barcode scanner only) 7: Ext. in – 8: Control output 9: +9 V (1.5 A output, for PSI module only)

876

GOSSEN METRAWATT GMBH 43

18 Appendix

18.1 Evaluation of Measured Values for Individual Measurements as well as for Calculated Quantities

In order to assure that the limit values for the individual measurements are always observed, device measuring error must be taken into consideration. The table in the appendix allows for calculation of the required minimum display value for each respective measurement which must appear at the instrument in consideration of measuring error (under nominal conditions of use), in order to assure that the required limit value is not fallen short of (DIN VDE 0413, part 1). Intermediate values can be interpolated.

Measuring Error for Test Sequences

The test instrument takes respective measuring error into consideration during automatic test sequences, and corrected results are entered into the test report, as long as this function has been activated in the setup switch position under “include service error”.

Tables for the calculation of minimum display values for insulation resistance and maximum display values for protective conductor resistance, equivalent leakage current, probe current and residual current in consideration of device measuring error:

MΩ RPE Ω

ISO

Limit Value

0.100 0.115 0.100 0.085

0.250 0.273 0.200 0.180

0.500 0.535 0.300 0.275

1.000 1.060 0.400 0.370

2.000 2.200 0.500 0.465

5.000 5.350 0.600 0.560

7.000 7.450 0.700 0.655

10.00 10.60 or 12.5

20.00 23.00 0.900 0.845

75.00 83.50 1.000 0.940

Depending upon resolution

Minimum

Display Value

Limit Value

0.800 0.750

1.100 1.035

Maximum

Display Value

mA I

Limit Value

1.00 0.85 0.100 0.085 0.25 0.12

3.50 3.23 0.250 0.227 0.50 0.35

7.00 6.55 0.500 0.465 1.00 0.80

10.00 9.40 1.000 0.940 2.00 1.70

15.00 14.15 2.000 1.890 3.50 3.05

20.00 18.90 3.500 3.315 5.00 4.40

44 GOSSEN METRAWATT GMBH

Maximum

Display Value

Limit Value

mA IRI mA

probe

Maximum

Display Value

Limit Value

7.00 6.20

10.00 8.90

15.00 13.40

20.00 17.90

25.00 22.40

Maximum

Display Value

18.2 Index

Absence of Voltage ................................................ 6, 7

Acoustic Signal, Measurement ................................. 15

Acoustic Signal, Sequence ....................................... 15

Adapter for Socket ................................................... 27

Alternating / Direct Voltage UAC/DC ......................... 22

Auto Class PSI ........................................................ 15

Auto Point ............................................................... 15

Auto Test Method .................................................... 27

Auto-Store .............................................................. 27

Classification ..................................................... 12, 27

Configuring Device Parameters .......................... 11, 15

Configuring Measurement Parameters ...................... 11

Connecting the Device Under Test ............................ 14

Contact Current ......................................... 6, 7, 14, 19

Contrast Adjustment ................................................ 11

DBmed Option ......................................................... 38

Device Leakage Current ................................... 6, 7, 19

Differential Current Method ........................................ 7

Direct Printing ......................................................... 15

Earth Fault .............................................................. 15

Equivalent Device Leakage Current ............. 6, 7, 20, 21

Equivalent Leakage Current .............................. 6, 7, 21

Extension Cables ..................................................... 34

Features ................................................................... 7

Finger Contact ........................................................ 10

First Measured Values ............................................. 28

Frequency Response ............................................... 19

Function Test .......................................................... 24

Illumination ..............................................................15

Incl. Service Error ....................................................15

Individual Measurements .......................................... 16

Insulation Resistance ...........................................6, 17

Insulation Resistance Limit Values ............................18

Interface ..................................................................43

IT Network ...............................................................15

Limit Values ............................................................15

Mains Connection Errors ..........................................10

Mains Power Outlet ....................................................9

Mains Wait ..............................................................15

Manual Sequence ....................................................27

Measurements with Accessories ............................... 22

Measuring Error ....................................................... 44

Modem ...................................................................15

Online Help .............................................................10

Patient Leakage Current ............................................. 6

Periodic Testing ......................................................... 6

Polarity Reversal ...................................................... 27

Printer Adapter ........................................................ 39

Probe Voltage Uprobe ..............................................21

Protective Conductor Resistance ................................. 6

Reference Voltage ..............................................15, 36

Reports ...................................................................15

Residual Current ..................................................6, 19

Residual Current Method ............................................ 7

Resistance R ...........................................................22

R-ISO LN-PE ............................................................27

Safety Class I Devices .............................................. 12

Safety Class II Devices ............................................. 12

Safety Class III Devices ............................................ 12

Saving Settings to Memory ...................................... 11

SC I I I UV ............................................................... 27

Service ................................................................... 15

Setting Date and Time ............................................. 15

Setting Limit Values ................................................. 11

Short-Circuit Test .................................................... 25

Single Fault ............................................................. 15

SK5 Option ............................................................. 38

Test Current .............................................................. 6

Test Sequence ........................................................ 15

Test Time ............................................................... 15

Testing after Repairs ................................................. 6

Type B Application Parts .......................................... 12

Type BF Application Parts ........................................ 12

Type CF Application Parts ........................................ 12

Visual Inspection ..................................................... 27

Zero Balancing .................................................. 17, 23

GOSSEN METRAWATT GMBH 45

19 Maintenance - Calibration

Housing Maintenance

No special maintenance is required for the housing. Keep outside surfaces clean. Use a slightly dampened cloth for cleaning. Avoid the use of cleansers, abrasives or solvents.

Calibration

According to the new DIN VDE 0702:2004-06 standard the following applies as from 1/6/2004:

„Measuring instruments used for periodic testing must be inspected and calibrated at regular intervals.“

Please contact us to fix an appointment for the inspection and calibration of your test instruments: GOSSEN METRAWATT Calibration Center, Phone 0911-8602-256, address see below.

Device Return and Environmentally Compatible Disposal

The instrument is a category 9 product (monitoring and control instrument) in accordance with ElektroG (German Electrical and Electronic De- vice Law). This device is not subject to the RoHS directive.

We identify our electrical and electronic devices (as of August 2005) in accordance with WEEE 2002/96/EG and ElektroG with the symbol shown to the right per DIN EN 50419 .

These devices may not be disposed with the trash. Please contact our service department regarding the return of old devices.

20 Repair and Replacement Parts Service

DKD Calibration Laboratory* and Rental Instrument Service

If required please contact:

GOSSEN METRAWATT GMBH Service Center Thomas-Mann-Str. 20 90471 Nürnberg, Germany Phone: +49-(0)-911-8602-0 Fax: +49-(0)-911-8602-253 E-mail: service@gossenmetrawatt.com

This address is only valid in Germany. Please contact our representatives or subsidiaries for service in other countries.

* Calibration Lab for Measured Electrical Quantities: DKD – K – 19701

Accredited per DIN EN ISO/IEC 17025

Accredited quantities: direct voltage, direct current value, direct current resistance, alternating voltage, alternating current value, AC active power, AC apparent power, DC power, capacitance, frequency

46 GOSSEN METRAWATT GMBH

Competent Partner

GOSSEN METRAWATT GMBH is certified in accordance with DIN EN ISO 9001:2000.

Our DKD calibration lab is accredited by the Physikalisch-Technischen Bundesanstalt (German Federal Institute of Physics and Metrology) and the Deutscher Kalibrierdienst (German Calibration Service) in accordance with DIN EN ISO/IEC 17025 under registration number DKD–K–19701.

We offer a complete range of expertise in the field of metrology: from test

reports and factory calibration certificates, right on up to DKD calibration certificates. Our spectrum of offerings is rounded out with free test equipment management.

Our service department includes an are discovered during calibration, our specialized personnel are capable of completing repairs using original replacement parts. As a full service calibration lab, we can calibrate instruments from other manufacturers as well.

on-site DKD calibration bench

. If errors

21 Product Support

If required please contact:

GOSSEN METRAWATT GMBHProduct Support Hotline Phone: +49-(0)-911-8602-112 Fax: +49-(0)-911-8602-709 E-mail support@gossenmetrawatt.com

GOSSEN METRAWATT GMBH 47

Edited in Germany • Subject to change without notice • PDF version available from the Internet

GOSSEN METRAWATT GMBH Thomas-Mann-Str. 16-20 90471 Nürnberg •

Germany

Phone: +49-(0)-911-8602-0 Fax: +49-(0)-911-8602-669 E-mail: info@gossenmetrawatt.com www.gossenmetrawatt.com

Gossen 702 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1 Applications

1.2 Table: Individual Measurements and Regulations

1.3 Table: Leakage Current Types

2 Safety Features and Precautions

3 Initial Start-Up

3.1 Connection to the Mains (230 V, 50 Hz)

3.2 Automatic Recognition of Mains Connection Errors

4 General Notes

4.1 Online Instructions

4.1.1 Automatic Safety Class Selection

4.1.2 Manual or Automatic Operating Sequences

4.2 Online Help

4.3 Adjusting Contrast

4.4 Configuring Device Parameters, Setting Date and Time

4.5 Configuring Measurement and Sequence Parameters

4.6 Setting Limit Values

4.7 Saving the Settings All of the settings and changes which have been entered to the Sequence,

5 Classification of Devices Under Test

5.1 Safety Classes

5.2 Application Parts (electrical medical devices)

6 Abbreviations

7 Connecting the Device Under Test

8 Configuring Device Parameters

9 Individual Measurements

9.1 Measuring Protective Conductor Resistance

9.3 Measuring Leakage Current

9.4 Equivalent Leakage Current

9.8 Measurements with Accessories (feature F01)

9.7 Resistance R (feature F01)

9.8.2 Temperature T with Pt100/1000 Sensor (feature F01) Connection

10 Function Test

11.1 Test Sequences

11.2 Setting Up Test Sequences

11.3 Configuring Measuring Parameters

11.4 Testing Devices in Accordance with DIN VDE 0701, Parts 1 and 200

11.5 Testing Devices in Accordance with DIN VDE 0701, Part 240

11.6 Testing Devices in Accordance with DIN VDE 0702:2004

11.8 Testing Multiple Outlets for VDE 0702 (optional EL1 adapter)

11.9 Testing in Accordance with DIN VDE 0751

12.1 Storing Measurement Data in the PSI Module

12.2 Database Operations

12.2.1 Setting Up Test Sequences with PC Software

13 Remote Control (Feature KD01 or SK5 Option)

14.1 Print Out Test Data at the PSI Module

14.2 Printing Test Results in Report Form

15 Direct Print-Out (feature KE01, SECU-dd option)

16 Characteristic Values

17 RS 232 Interface

17.2 PC Connection

17.2.1 Software Evaluation of Measurement Results

17.2.2 Instrument Control via Interface Commands

17.3 Interface Configuration and Protocol

18 Appendix

18.1 Evaluation of Measured Values for Individual Measurements as well as for Calculated Quantities

18.2 Index

19 Maintenance - Calibration

21 Product Support
