FREEZER / COOLER CONVERT
USER MANUAL
"Protection of Environment" is one of the core values of Godrej and we seek your co-operation to make sure that this
product is not disposed as unsorted municipal waste.
This symbol is known as the “Crossed-out Wheelie Bin Symbol”. It means that the product should not
be disposed of with your general house-hold waste.
It should be disposed of only through the company’s collection centres with special treatment so as to
prev ent any d amage to the envi ronment . Please c all: 1800 209 5511 or visit
www.godrejappliances.com/green-think for details about Godrej Appliances authorised
collection centres or any applicable buy back arrangement.
Protection of Environment:
CONTENT
1 Safety Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
• Meaning of safety warning symbols . . . . . . . . . . . . . . . . . . . 3
• Electricity related warnings . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
• Warnings related to use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
• Safety warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
• Warnings related to placing items . . . . . . . . . . . . . . . . . . . . . 5
• Warnings related to disposal . . . . . . . . . . . . . . . . . . . . . . . . . 5
• Proper use of Freezer/Cooler . .. .. . . . . . . . . . . . . . . . . . . . . 6
2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Important Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4 Transportation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5 Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
6 Freezer/Cooler Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-12
7 Maintenance of Freezer/Cooler. . . . . . . . . . . . . . . . . . . . . . . . . . .
• Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
• Do’s and Don’ts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
8 Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
9 Handle Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
10 Wheels Installation . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . 15-16
11 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
1
Dear customer,
Welcome to the Godrej family!
Thank you for buying this freezer and giving us an opportunity to serve you.
To ensure that you get the best results from your new freezer, please take time to read
through the simple instructions in this user manual. If you need any further
assistance at any time, feel free to call us on 1800 209 5511 or write to us at
smartcare@godrej.com.
We urge you to ensure that the packing material is disposed off in accordance with the
current environmental requirements. When disposing off any freezer equipment,
please contact your local waste disposal department for advice on safe disposal.
This appliance must only be used for its intended purpose.
We thank you again for giving us the privilege to serve you, and look forward to a long
and delightful association.
2
• Safety warnings
• Do not allow children to enter or climb the freezer to avoid
injury.
• Do not spray or wash the freezer. Do not put the freezer in
moist places as this may affect the electrical insulation
properties of the freezer.
• Do not place heavy objects on top of the freezer considering
that the object may fall when opening or closing the door, and
accidental injuries might be caused.
• Please unplug the appliance while cleaning.
• Avoid switching on / off the appliance consecutively to prevent
damage to the compressor.
• Warnings related to use
• Demolition or renovation of the refrigerator is prohibited. It is
forbidden to damage the refrigerant lines. The repair and
maintenance of the refrigerator must be carried out by
professionals.
• Damaged power cord must be replaced by the manufacturer,
its maintenance department or related professionals, in order
to avoid danger.
• The surroundings of the freezer should not be obstructed in
order to maintain proper ventilation around the appliance.
Keep a minimum space of 300mm all around the freezer.
• The gaps between doors and freezer body are small. Please
do not put your hand in these areas to prevent squeezing of
fingers.
• Do not pick/put foods or containers from/in the freezing
chamber when the refrigerator is running, especially metal
containers in order to avoid frostbite.
• To ensure safety, it is not recommended to place regulators,
rice cookers, microwave ovens or other appliances on top of
the freezer. Do not use electrical appliances in the food pantry
or any atmosphere where the ambient temperature is above
43°C.
4
• Please use a dedicated three-hole power socket which is 16A
or more.
• The power cord should be firmly contacted with the socket to
prevent fires. Please ensure that the grounding electrode of
the power socket is equipped with a reliable grounding line.
• The refrigerator adopts 230V/50Hz AC power. Voltage
fluctuations over the range of 230V+/-10% will cause
malfunctioning or even damage. Hence, an appropriate
automatic voltage regulator must be installed in concert with
the AC power.
• In case of gas leakage, please open the doors and windows.
Do not unplug the refrigerator and other electrical appliances,
considering that any spark may cause a fire.
16A
3
SAFETY WARNINGS
This symbol indicates prohibited matters and behaviors that are
forbidden. Non-compliance with the instructions may result in
product damage or endanger the personal safety of users.
This symbol indicates matters that must be followed, and behaviors
that must be strictly executed in line with the operation requirements.
Non-compliance with the instructions may result in product damage
or endanger the personal safety of users.
This symbol indicates matters that need attention. Due precautions
are needed or injuries /damages will be caused.
• Meaning of safety warning symbols
• Electricity related warnings
• Do not pull the power cord when pulling the power plug of the
freezer. Please firmly grasp the plug and pull out it from the
socket directly.
• Do not damage the power cord under any condition, so as to
ensure safety use. Do not use freezer when the power cord is
damaged or the plug is worn.
• Worn or damaged power cord shall be replaced in
manufacturer-authorized maintenance stations.
5
•
Warnings related to placing items
• Do not put explosive, volatile and highly corrosive
items in the freezer to prevent damage to the product or cause
e.
• This product is a freezer and is suitable only for the storage of
foods. According to standards, when using for commercial
purpose freezers shall not be used for other purposes, such as
storage of blood, drugs or biological products.
• While placing items in the freezer/cooler following thermostat
operation should be maintained:
i) Thermostat should be set to “Cooler” operation for storage
of beverages and dairy products.
ii) Thermostat should be set to “Freezer” operation for storage
of ice creams and frozen foods.
•
Warnings related to disposal
• The freezer’s R 600a/R290 refrigerant and Cyclopentane foam material are
combustible material and the discarded freezer should be isolated from
e
sources. It cannot be burned. Please transfer the freezer to
professional
recycling companies for processing in order to avoid damage to the environment
or other hazards.
• Please remove the door and shelves of the freezer and place them away to avoid
accidents if children enter and play in the freezer.
6
•
Proper use of Freezer/Cooler
MODEL SPECIFICATIONS
Description/Model 100L 200L 300L 510L
Model Code 24131601
SD00006
24131601
SD00007
24131601
SD00008
24131601
SD00010
Model DpFrzr 100L
GCHW110R6SIB
Htop
DpFrzr 200L
GCHW210R6
SIB Htop
DpFrzr 300L
GCHW310R6
SIB Htop
DpFrzr 510L
GCHW520R2
DIB Htop
Volume 100L 200L 300L 510L
Climate Class T T T T
Rated Voltage 230V AC 230V AC 230V AC 230V AC
Rated Frequency 50 Hz 50 Hz 50 Hz 50 Hz
Refrigerant/Amount R 600a/40g R 600a/56g R 600a/62g R 290/90g
Net Weight 23 Kg 32 Kg 42 Kg 64 Kg
Foam Blowing Agent
Cyclopentane Cyclopentane Cyclopentane Cyclopentane
Keep away from heat and direct sunlight. Do not place the
freezer in moist or wet places to prevent rust or reduction of
insulating effect.
The space between the top of the freezer shall be greater than
80cm. The distance from both sides and the back shall be more
than 30cm. This facilitates the opening & closing and heat
dissipation.
Wipe the freezer inside and outside with a warm moist rag (add
a small amount of detergent in the warm water. Use plain water
for the
cleanse).
Do not switch on the connection 220~240V/50Hz(230V/50Hz)
power until 6 hours after moving the freezer. The refrigerant
needs time to settle.
Before placing frozen foods in your freezer, turn the freezer on
and wait for 24 hours to make sure it is working properly and to
allow the freezer to chill down to the optimum temperature.
Temperature can be measured using a thermometer. Take care
to maintain the temperature as recommended by food
suppliers.
The appliance should be transported only in an upright position. The packing as
supplied must be intact during transportation.
1. Failure to comply with the above instructions could result in damage to the
appliance. The manufacturer will not be held responsible if these instructions are
not followed.
2. The appliance must be protected against rain, moisture and other atmospheric
IMPORTANT: Care must be taken while cleaning / carrying the appliance.
IMPORTANT: This appliance is not designed for stacking with any other appliance.
Do not attempt to sit or stand on top of your appliance as it is not designed for such
use. You could injure yourself or damage the appliance.
IMPORTANT: Make sure that the mains cable is not caught under the appliance
during and after carrying / moving the appliance, to avoid the mains cable getting cut
or damaged.
When positioning your appliance take care not to damage your pipes, wall
coverings etc. Do not move the appliance by pulling by the lid or handle. Do not allow
children to play with the appliance or tamper with the controls. Our company declines
to accept any liability should the instructions not be followed.
TRANSPORTATION INSTRUCTIONS
1. Avoid placing the appliance near cookers, radiators or in direct sunlight as this will
cause the compressor to run for long periods.
2. Make sure that suf
room is provided around the appliance to ensure free air
circulation. Ideally, a space of no less than a foot must be left around the freezer,
and ensure you allow gaps.
3. The appliance should be installed on a
surface.
4. Although Godrej Chest Freezers come with ZOP technology, it is advised to avoid
placing the freezer in moist spaces since it can lead to rusting of the metal parts.
5. Don’t spray water on the freezer since it will weaken the insulation and cause
electricity leakage.
6. Please refer ‘Cleaning and Care’ section for daily maintenance of your freezer.
7. If the Chest Freezer is installed in areas with high humidity; for e.g. basements,
garages etc. in cold weather, then there are chances of water droplet formation on
the outer surface due to condensation. This is quite normal and is not a fault.
Remove the condensation by wiping with a dry cloth.
INSTALLATION INSTRUCTIONS
87
WARNING!!
To obtain the best possible performance and trouble free operation from your
appliance it is very important to read these instructions carefully.
• Don’t connect the appliance to the electricity supply until all packing and transit
protectors have been removed.
• Don’
• Switch On the machine at least for 6 hours before initial loading or after long
power off.
t switch on the freezer for at least 6 hours, post arrival.
• If you are discarding an old product, remove or break the lock as a safety measure,
to avoid children from getting trapped inside.
• This freezer must only be used for its intended purpose i.e. the storing and freezing
of edible foodstuff.
• Do not dispose off the appliance in e.
• Take care not to damage the cooling circuit/pipes of the appliance in
transportation and in use. In case of damage, do not expose the appliance to
e
or potential ignition source and immediately ventilate the room where the
appliance is kept.
• On delivery, check to ensure that the product is not damaged and that all the parts
and accessories are in perfect condition.
• Godrej Appliances is committed towards the protection & care of our planet. This
appliance is environment friendly.
• We do not recommend the use of extension boards and multi-way adapters.
• Failure to observe these instructions may invalidate your right to free service
during the guarantee period.
WARNING! Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
WARNING! Do not damage the refrigerant circuit.
WARNING! Do not use electrical appliances inside the food storage compartments of
the appliance, unless they are of the type recommended by the manufacturer.
• We suggest you keep this instruction booklet in a safe place for easy reference.
IMPORTANT INSTRUCTIONS
Indicator light
Control panel
Indicator Light
Thermostat Adjustment Knob
Handle
Door
Hinge
Basket
Trim
Cabinet
Ventilation Cover
Foot
º
90
FREEZER / COOLER OPERATION
Temperature adjustment
Indicator lights
The indicator light -set is placed on the front side of the freezer for easy visibility.
Indicator lights mean the following:
• Red Light – Shows that the appliance is supplied with electric energy.
• Green Light – Shows that the compressor is working.
9 10
Operation
Before you start using the CONVERT (Freezer/Cooler), please go through the below
mentioned guidelines to get optimum performance from your appliance.
1. The interior needs to be dry with free air circulation.
2. Clean the interior as recommended under ‘CLEANING AND CARE’.
3. Insert the plug into the wall socket and switch on the electricity supply the red light
will switch on. After sometime the green light will glow, indicating that the
compressor is running.
4. You will hear a noise as the compressor starts up. The liquid and gases sealed
within the refrigeration system may also give rise to noise, whether the
compressor is running or not which is quite normal.
5. If you plan to store already frozen food, then open the freezer lid and check if the
freezer has reached the correct temperature. Once the correct temperature has
been reached, you can start storing your already frozen food. (See ‘Storing Frozen
Food’- Page <11>).
6. Do not load the appliance immediately after it is switched on. Wait until the correct
storage temperature has been reached. We recommend that you check the
temperature with an accurate thermometer (See ‘Freezer/Cooler operation’).
INSTALLATION INSTRUCTIONS
Important Notes:
• Avoid opening the lid in case of a power failure. It will lead to cooling loss. If the
failure lasts longer, then the food should be checked and eaten immediately or
cooked and then re-frozen.
• If you that the lid of the freezer is dif to open just after you have closed it,
don’t worry. This is due to the pressure difference which will equalize and allow the
lid to be opened normally after a few minutes. Do not use a knife or any sharp
objects to open door or break vacuum at such instances.
Connect the freezer to power supply and “Power” Indicator (the green light) will
turn on. “Run” indicator (the red light) will turn on operation.
The temperature of the chamber is adjusted through the thermostat knob.
the number is the higher the temperature, inside will be and verse versa.
The user can choose the right temperature zone according to their needs.
For refrigeration, temperature control knob should be set to COOLING;
For freezing, temperature control knob should be set to FREEZING;
For quick-freezing, temperature control knob should be set to SUPER;
CLEANING AND CARE
• We recommend that you switch off the freezer from the main power outlet and
pull out the mains plug before cleaning.
• Never use any sharp abrasive instrument, soap, household cleaner, detergent
or wax polish for cleaning.
• Use lukewarm water to clean the cabinet of the freezer and wipe it dry.
• Use a damp cloth which has been dipped & squeezed in a solution of one
teaspoon of soda bicarbonate mixed in a pint of water, to clean the interior and
wipe it dry.
• Excess deposit of ice should be removed on a regular basis using a plastic ice
scraper available. Large accumulation of ice will affect the performance of the
freezer as it acts as an insulation.
• If the freezer is not going to be used for a long period of time, switch it off,
remove all food and clean it.
• Check lid seals (gasket) regularly to ensure they are clean and free from food
particles.
Important Notes:
Never use water to wash the compressor position and wipe it with a dry cloth
thoroughly after cleaning to prevent rust.
MAINTENANCE OF FREEZER/COOLER
3. Twist the water conduit until the arrow points downward.
4. After defrosting is done, make sure there is no more water coming out from the
water conduit before putting it back in place. Once the water conduit has been
put in place make its arrow point upward.
Important Notes:
• Do not use pointed or sharp-edged objects such as knives or forks to remove
the frost.
• Never use hairdryers, electrical heaters or other such electrical appliances for
defrosting.
11 12
FREEZING FRESH FOOD
For freezing fresh food, store it near the side walls & away from already frozen food.
This ensures fast freezing.
Do not freeze too large a quantity at a time.
The quality of the food is best preserved when it is frozen right through to the center as
quickly as possible. Take special care not to mix already frozen food and fresh food.
DEFROSTING
• Defrost twice a year or when a frost layer of around 7mm (1/4”) has formed.
• You can defrost by switching off the freezer at the socket outlet and pulling out
the mains plug.
• Extract the water conduit and put in a water container.
• 6 hours before the defrosting, please set the thermostat knob at ‘MAX’ position
to make sure the food is at the lowest temperature when you get it out. All food
should be wrapped in several layers of newspaper and stored in a cool place.
• Remove the freezer basket. Leave the lid open. Containers of warm water may
be placed carefully in the freezer to speed up the defrosting.
• Never use hair dryers, electrical heaters or other such electrical appliances for
defrosting. When defrosting has nished, drain out the defrost water which
collects at the bottom of the freezer.
STORING FROZEN FOOD
Pre-packaged commercially frozen food should be stored in accordance with the
frozen food manufacturer’s instructions.
To ensure that high quality is achieved by the frozen food manufacturer and the food
retailer, please remember the following things:
1. After purchase, put packets in the freezer as quickly as possible to prevent defrosting.
2. Don’t exceed the expiry dates of the food products.
1. There is a water conduit at the bottom of the freezer. When defrosting, extract
the rubber cover, defrosted water will ow out of the hole. (NOTE: PLEASE
REMOVE THE RUBBER COVER DURING THE DEFROSTING AND PUT IT
BACK AFTER DEFROSTING IS DONE)
2. Extract the water conduit by 20-25mm until the water hole can be seen.
If the appliance does not operate when switched on, check that:
• The plug is inserted properly in the socket and that the power supply is on. (To
check the power supply to the socket, plug in another appliance)
• The fuse has blown / circuit breaker has tripped / main distribution switch has been
turned off.
• The temperature control has been set correctly.
• New plug is wired correctly if you have changed the tted molded plug. If the
appliance is still not operating after the above checks, please call the toll free
service helpline number- 1800 209 5511.
• Take out the handle and four screws from the poly bag.
• Remove the cover from the handle. The cover is slightly tightening t to the handle.
Small slotted screwdriver (not included) is recommend to use to remove the cover
• Hold the handle and align hole to match the freezer cover.
• Fix the four screws securely.
• Put the cover back to the handle.
• Check that the handle is xed securely before use.
PROBLEM SOLVING/TROUBLE SHOOTING
INSTRUCTION FOR HANDLE INSTALLATION
Take care when handling the assembly of the handle.
Accessories Provided:
Scraper
Basket
Handle
Castor Wheels
Screws
Keys
NO. Name Qty.
1 Cover 1
2 Bolt N5*16 4
3 Handle 1
4 Door 1
1
2
3
4
DO’S AND DON’TS
Do’s
• Defrost food from the freezer thoroughly in a fridge or in a microwave oven. Follow
defrosting and cooking instructions as given on food packet.
• Ensure that Chest Freezer lid is completely closed after each use.
• Defrost frozen meat completely before cooking.
• Close the lid gently.
• Check contents of the freezer at regular intervals.
• Clean and defrost your freezer regularly (See ‘Defrosting’).
• Adhere to ‘Best Before’, ‘Use By’ dates when you store.
• Store commercially frozen food in accordance with the instructions given on the
packets that you buy.
• Always choose high quality fresh food and be sure it is thoroughly clean before you
freeze it.
• Prepare foodstuff for freezing in small portions to ensure rapid freezing.
• Wrap all foods in aluminum foil or freezer quality plastic bags and make sure any air
is excluded.
• Wrap frozen food when you buy it and put it in to the freezer as soon as possible.
• Store small items in the basket provided.
• Remove ice cream from the freezer about 10 minutes before serving.
Don’ts
• Don’t leave the lid open for long periods as this will make the freezer costlier to run
and cause excessive ice formation.
• Don’t use pointed or sharp edged objects such as knives, forks etc. to remove the ice.
• Don’t put hot food in the freezer.
• Don’t put liquid-lled bottles or sealed cans containing carbonated liquids into the
freezer as they may burst.
• Don’t store poisonous or dangerous substances in the freezer. Your freezer has
been designed for the storage of edible foodstuffs only.
• Don’t consume ice-cream and ice-cubes directly from the freezer. The low
temperature may cause ‘freezer burns’ on lips.
• Don’t freeze zzy drinks.
• Don’t keep frozen food which is thawed. It should be eaten within 24 hours or
cooked and refrozen.
• Don’t remove items from the freezer with wet hands.
• Don’t shut the lid with force.
13 14
15 16
*
*Applicable for 300L & 500L models.
NOTES
This warranty is valid only if it is filled in and stamped by our authorized dealer on the date of purchase.
Overall warranty stands null and void if
1. The warranty card is not completed properly at the time of the purchase. 2. The completed warranty card is not presented to the
authorized personnel at the time of service of the product. 3. The appliance is not operated according to instructions given in the
User's Guide. 4. Defects are caused by improper use, which shall be determined by the company personnel. 5. Unauthorized person
carries out any repair work. 6. Defects are caused by reasons beyond control, like abnormal voltage, acts of God, or while in transit to
service centre or purchaser's residence. 7. The serial number is deleted, defaced or altered. 8. Damage is caused to the appliance or
any parts due to transportation or shifting.
Warranty automatically expires after the stipulated period from the original date of purchase, even if the appliance was not in use for
any time for whatever reasons.
Customer’s Signature:
The Godrej Chest Freezer comes with a FIVE year warranty on COMPRESSOR and a ONE year warranty on the
appliance
from the date of purchase, against defective material or workmanship. In case of any such defect found
to the warranted part free of charge, subject to the terms and conditions below. In the warranty period beyond the
repaired on payment of necessary charges.
INSTRUCTIONS FOR THE CUSTOMER
1.
2. You should retain the warranty card for record and produce the same in the event of any warranty repairs.
3. In the event of a defect developing in the product, contact the nearest authorized Godrej & Boyce Service Centre for obtaining
warranty service and provide the defect, model details & serial no.
4. Earthing of the appliance is necessary to ensure safety.
5.
responsible and the warranty stands terminated.
6. Frequency must be between 5% variation of 50Hz. Beyond this, the company shall not be liable for any unforeseen hazards like
7. The product must be maintained to ensure hygiene. If there are any insects, rodents etc. in it, obstructing the functioning of the
product, the company shall not be responsible and in turn, the warranty stands terminated.
8.
If you are moving house, it is essential that a Godrej service representative inspects the chest freezer at the time of re-installation
at the new address. The warranty on the product/optional service contract for the sealed system of the appliance continues to
be effective only if the product is found to be in working condition. The re-inspection will be done on the payment of necessary
charges. We would also recommend that the product be insured against damage in transit.
TERMS AND CONDITIONS
1. Repairs and replacements of parts will be carried out through the authorized Customer Service Centre.
2. All transportation and handling expenses incurred while repairing will be payable by the customer.
3. For any appliance installed beyond the municipal limits of the jurisdiction of the authorized customer service centre, charges
towards technician’s visit will be borne by the customer.
4. While the company will make every effort to carry out the repairs at the earliest, it however is made explicitly clear that the
5. The company/its authorized personnel will collect any parts, compressor or other components replaced.
6. Warranty does not cover accessories to the appliance.
7. Sealed system gas charging and consumables will be charged for any such repairs after one year from the date of purchase.
8.
spare parts of the Appliance with them. However, in certain cases where the appliance cannot be repaired due to non availability of
the spare parts, the company, at its sole discretion, may offer a replacement of the appliance to the purchaser of such an
appliance, under a replacement offer. The replacement offer is subject to change from year to year and any discount given shall be
applicable on the MRP of the product to be purchased as a replacement. A table giving the details of the replacement offer is
available on www.godrejsmartcare.com.
9. The liability of the company is limited only to the chest freezer, and it would not be responsible for any goods being spoilt due to
non-functioning of the product.
10.
Mumbai shall have exclusive jurisdiction in case of any disputes
Godrej & Boyce Mfg. Co. Ltd.- Appliance Division
CUSTOMER COPY
MODEL NO.
UNIT SR. NO.
CUSTOMER’S NAME & ADDRESS
TEL. TEL.
DATE OF PURCHASE
DEALER’S NAME & ADDRESS
WARRANTY
17
NOTESNOTES
Loading...
