GME RCU9200 series Instruction Manual

GR9200 SERIES INSTRUCTION MANUAL PAGE 1

INSTRUCTION MANUAL

RCU9200

WIRED REMOTE

PAGE 2 INSTRUCTION MANUAL RCU9200 SERIES

COnTEnTs

CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Mounting ............................4

Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Operation ............................5

Power ...............................5

Mute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Mode ...............................5

MOUNTING DIAGRAM . . . . . . . . . . . . . . . . . . . . . 6

INSTALLATION DIAGRAM . . . . . . . . . . . . . . . . . . . 7

STANDARD COMMUNICATIONS

CONTRACT WARRANTY . . . . . . . . . . . . . . . . . . . . 8

CUTTING TEMPLATE . . . . . . . . . . . . . . . . . . . . . . 11

GR9200 SERIES INSTRUCTION MANUAL PAGE 3

COnTROls

1. Power

2. LCD Window

3. Mute

4. Fast Foward/Tune

5. Volume Up

6. Volume Down

7. Rewind/Tune

8. Mode

1

2

3

4

5

6

7

8

PAGE 4 INSTRUCTION MANUAL RCU9200 SERIES

InsTAllATIOn.

MOUnTIng.

The RCU9200 is designed to be
panel mounted. The mounting
assembly supports mounting into
panels of up to 10 mm thick.
Before mounting, the RCU9200
requires a hole of 76 mm to be cut
in the panel.

Using the supplied template
(page 11) mark the location of the
hole to be cut. Make sure there is
at least 60 mm of clearance behind
the panel to allow for the depth
of the remote unit and its cables.
There should also be at least
another 10 mm clearance around
the hole for the front panel facia
and the U-Bracket mounting clamp.

Cut the 76 mm hole using a hole
saw or similar.

Mount the RCU9200 through
the hole from the front of the
panel. Ensure the rubber gasket
is between the front facia and the
mounting surface.

Remove the two top nuts from the
two bolts on the rear of the unit.

DO NOT remove the two bottom
nuts as these are required to hold
the bolts in place.

Slide the U-Bracket over the bolts
ensuring the clearance slots in the
bracket are positioned as shown.
Slide the bracket forward until
it presses against the rear of the
mounting surface.

Refit the two nuts and tighten.
Do NOT over tighten otherwise
damage to the rear of the
RCU9200 case may occur.

WIRIng

Connect the attached fly lead to
one of the two in-line connectors
at the rear of the GR9200 If
required the cable can be extended
using one or more optional LE024
5 meter extension leads (up to a
maximum of 15 meters).

The single terminal pin on the rear
of the case is used to activate the
back lighting for the RCU9200
display and keypad. Connect this
to a +12 V DC source using an
insulated spade connector (to
prevent the terminal shorting
to the U-Bracket). Connecting

GR9200 SERIES INSTRUCTION MANUAL PAGE 5

this to an accessory point in
your vessel will ensure the back
lighting turns on and off with your
vessels accessory switch.

OPERATIOn

The RCU9200 duplicates most of
the functions of the main GR9200
radio panel.

POWER

Press and hold the Power button
to turn the GR9200 ON or OFF.

Briefly press the Power button to
adjust the display brightness on
the GR9200.

MUTE

Press the MUTE button to mute
the sound. Press again to restore
the previous volume settings.

MODE

The MOD button switches between
the various signal sources such as
Tuner, AUX input or CD player. If
an SD card or USB memory stick is
fitted these will be included in the
list of available Modes.

Rewind/ Tune

In Tuner mode, briefly press
to manually tune downwards in
frequency. Press and HOLD
to scan downwards in frequency.
Scanning will stop when a station
is found.

When playing a CD or MP3, press

to step to the beginning of
the current track. Press again
to skip to the previous track. Press
and HOLD to rewind through
the current track.

Fast Forward

In Tuner mode, briefly press
to manually tune upwards in
frequency. Press and HOLD
to scan upwards in frequency.
Scanning will stop when a station
is found.

When playing a CD or MP3,
press

to advance to the next
track. Press and HOLD to fast
forward through the Current track

UP OR DOWN

Press to increase the volume or

to decrease the volume.

PAGE 6 INSTRUCTION MANUAL RCU9200 SERIES

Nuts

Cut outs

Top

MOUnTIng DIAgRAM

U Bracket

GR9200 SERIES INSTRUCTION MANUAL PAGE 7

Panel

Front
Facia

Rubber

Gasket

Minimum Depth 60mm

U-Bracket

Nut

+ 12 V DC
switched

InsTAllATIOn DIAgRAM

To GR9200

PAGE 8 INSTRUCTION MANUAL RCU9200 SERIES

STANDARD COMMUNICATIONS

CONTRACT WARRANTY

1. sTATUTORY
WARRAnTIEs

1.1 The Trade Practices Act Part V, Division 2A and other

legislation imply conditions, warranties and other
obligations on us to consumers that cannot be
excluded, restricted or modified. Those provisions
apply to the extent required by law.

1.2 We exclude all other conditions, warranties and

obligations which would otherwise be implied
concerning the activities covered by this agreement.

1.3 We limit our liability where we are allowed to do

so. Examples of where we are allowed to limit
liability are ­ (a) you acquire goods from us for re-supply;

(b) the goods or services we supply are not of a

kind ordinarily acquired for personal, domestic
or household use
or consumption.

1.4 Where we are allowed to limit our liability, to the

extent permitted by law, our sole liability for breach
of a condition, warranty or other obligation implied
by law is limited.

(a) in the case of goods we supply, to any one of the

following as we decide -

(i) the replacement of the goods or the supply of

equivalent goods;

(ii) the repair of the goods;

(iii) the payment of the cost of repairing the goods or

of acquiring equivalent goods;

(iv) the payment of the cost of having the goods

repaired; or

(

b) in the case of services we supply, to any one of the

following as we decide -

(i) the supplying of the services again;

(ii) the payment of the cost of having the services

supplied again.

2. ADDITIOnAl
WARRAnTIEs

2.1 The warranties in this clause are in addition to the

statutory warranties referred to in the previous
clause.

2.2 We warrant our goods to be free from defects

in materials and workmanship for one year from the
date of original sale (or another period we agree to
in writing). During this period and as our sole liability
to you under this warranty, we agree to, at our
option, either repair or replace goods which we are
satisfied are defective. We warrant replacement parts
for the remainder of the period of warranty for the
goods into which they are incorporated.

2.3 We warrant our other repairs to be free from defects

in materials and workmanship for three months from
the date of the original repair. During this period and
as our sole liability to you for the repair, we agree
to repair or replace (at our option) repaired goods
which we are satisfied are defective.

2.4 We warrant that we will perform services with

reasonable care and skill and agree to investigate
any complaint made in good faith that we have
performed services unsatisfactorily. If we are satisfied
that the complaint is justified, and as

GR9200 SERIES INSTRUCTION MANUAL PAGE 9

3. OThER lIMITATIOns

3.1 You may not rely on any representation, warranty
or other provision by or for us which is not covered
by clause [ 1 ] or repeated in this agreement in
clear terms.

3.2 We are not liable (nor are our employees, contractors
and agents) for any damage, economic loss or loss
of profits whether direct, indirect, general, special
or consequential -

(a) arising out of any breach of any implied or

express term, condition or warranty; or

(b) suffered as a result of our negligence (or that of

our employees, contractors or agents) apart from
liability as set out in the previous two clauses.

3.3 The liability of a party under this agreement (whether

arising in contract, tort or by statute) is to be reduced by
the same proportion as represents the proportion of the
loss or damage caused or contributed to by the other
party, its contractors
or agents.

Part Number: 310462 Drawing Number: 44629-1 www.gme.net.au

A Division of Standard Communications Pty. Ltd.

Head Office:

Sydney

Locked Bag 2086, North Ryde, NSW 1670, Australia.
T: [phone] F: [phone]

Branches:

MELBOURNE ADELAIDE PERTH

7 Micro Circuit, Unit 1, 14 Phillips St., Unit 1, 10-12 Harvard Way,
DANDENONG STH 3165. THEBARTON 5031. CANNING VALE 6155.
T: [phone] T: [phone] T: [phone]
F: [phone] F: [phone] F: [phone]

BRISBANE SYDNEY AUCKLAND
Unit 1, 89-101 Factory Rd., Unit B, 22-24 College St., Unit 2/24 Bishop Dunn Place,
OXLEY 4075. GLADESVILLE 2111. East Tamaki, MANUKAU 2013 NZ.
T: [phone] T: [phone] T: [phone]
F: [phone] F: [phone] F: [phone]

For customers outside Australia and New Zealand please contact your local GME retailer
or email: [e-mail]

GR9200 SERIES INSTRUCTION MANUAL PAGE 11

CUTTIng TEMPlATE

76mm

90mm

Mounting hole (Push out)

Outer edge of wired remote
(Push out)

Tear off here

CUTTING TEMPLATE
