GIGABYTE XP-P5IM800GV Schematics
SHEET TITLE
D D
C C
01
02
03
04~07
08
09
10
11
12
13
14
15
16
COVER SHEET
BOM & PCB MODIFY HISTORY
BLOCK DIAGRAM
CPU LGA775A
SPRINGDALE HOST
SPRINGDALE DDR
SPRINGDALE AGP, HUB, CSA, VGA
SPRINGDALE PWR
DDR1,2 CHANNEL A
DDR3,4 CHANNEL B
DDR TERMINATION
AGU SLOT
ICH5 PCI, USB, HUB, LAN
SHEET TITLE
26
27
28
29
30
31
32
33
34
35
36
37
KB,MS
USB CONN
AC97 ALC655
AUDIO JACK
FRONT PANEL
POWER,CPU_FAN
VCORE PWM
ATX POWER
DDR POWER
LAN RTL8100C
PCI ROUTING LIST
GPIO LIST
Revision 1.0
17
B B
18
19
20
21
22
ICH5 IDE, GPIO, SATA, CTRL
ICH5 VCC, GND
FWH-BIOS
ICS952603 CLOCK GENERATOR
PCI SLOT1/SLOT2
PCI SLOT3,RESET
SMSC LPC IO23
24
A A
25
IDE
COM,LPT,FDD
5
4
3
2
PROCESS:C
Title
Size Document Number Rev
Custom
Date: Sheet
GIGABYTE
COVER SHEET
XP-P5IM800GV 1.0
1
COMPONENT SIDE
(0.5 oz. Copper)
VCC SIDE
(1 oz. Copper)
GND SIDE
(1 oz. Copper)
SOLDER SIDE
(0.5 oz. Copper)
136
of
Page 2
5
4
3
2
1
Model Name: XP-P5IM800GV
Component history Circuit or PCB layout history
D D
10/11 A11-->FOR AGP CARD MB_DET(8X)AGU NO WORK ISSUE
2004/12/10
Date Change Item ReasonDate Change Item Reason
REV 1.0
10/13 DEL DDRVTT ALL TERMINATOR
10/18 ADD
12/01
防雷擊
IC
改
REV1.0 1.DDR25V 0402-->0603
2.加入S.B
防燒線路及
包裝
USB SIGNAL ESD
12/02 E-BOM:9MP5IM800GV-00-10A 1.DDR25V 0.1U/0402-->0603
2.ATX:24PIN-->20PIN
3.SC431,IDE1,2,FDD
料號建錯
4.CLK GEN:REALTEK-->ICS
5.ADD PROCHOT
12/10 P-BOM:9MP5IM800GV-DG-10A
C C
增刪包材替料
B B
A A
Title
Size Document Number Rev
Custom
5
4
3
2
Date: Sheet
GIGABYTE
BOM & PCB MODIFY HISTORY
XP-P5IM800GV 1.0
1
236
of
Page 3
5
BLOCK DIAGRAM
4
3
2
1
PCB SIZE:305X230 mm.
60 Ohm +- 15% C
INTEL Pentium4 (775)
D D
CLOCK GENERATOR
CKVDD = 3.3V
VCC3=3.3V
PAGE 19
VCCVID=1.2V
VCORE = 1.55V
VCC3
PAGE 4~7
VID0~5
PWM/OTHER POWER
ALL POWER=5VDUAL,DDR25V,VDDQ,VCCVID,
DDRVTT,3VDUAL,VCORE,+12V,V12,VIN,5VSB,
GMCHVCCP
5VSB,-12V,+12V,VCC,VCC3,3VDUAL
VTT_DDR,2_5VSTR
PAGE 31~34
CHANNEL A
GMCH
SPRINGDALE-GV
AGU SLOT
5VSB=5.0V
VDDQ =3V
VCC3 = 3.3V
+12V = 12V
3VDUAL = 3.3V
VCC = 5V
C C
PAGE 15
RTL8100C
AGP BUS
GMCHVCCP=1.45V/1.225V
VCC3=3.3V
VCORE
DDR25V= 2.5V(MEMORY)
VDDQ = 1.5V (AGP POWER 4X, HUBLINK)
HL0~10
CONTROL BUS
PAGE 8~11
HUB LINK
DCLKA0~5
-DCLKA0~5
MAAA0~12
MABA1~5
MDA0~63
-DQSA0~7
DMA0~7
DCLKB0~5
-DCLKB0~5
MAAB0~12
MABB1~5
MDB0~63
-DQSB0~7
DMB0~7
REAR USB PORTS
USB4+/USB4-,USB5+/USB5-
3.3V = 3VDUAL
FUSEVCC=5V
1.8VSB=1.8V
1.2VSB=1.2V
+VSBLAN=3.3V OR 1.2V
PAGE 35
ICH5
DDR SDRAM DIMM X 1
2_5VSTR = 2.5V(MEMORY,SUSPEND POWER)
VTT_DDR = 1.25V
PAGE 12
CHANNEL B
DDR SDRAM DIMM X 1
2_5VSTR = 2.5V(MEMORY,SUSPEND POWER)
VTT_DDR = 1.25V
PAGE 13
IDE Primary and
Secondary
FDD
VCC = 5V
PAGE 24
REAR USB PORTS
USB2+/USB2-,USB3+/USB3-
VCC = FUSEVCC
B B
FRONT USB PORTS
USB0+/USB0-,USB1+/USB1-
PAGE 27
USB6+/USB6-,USB7+/USB7-
VCC = FUSEVCC1
PAGE 27
AC97 CODEC
ALC655
+12V = 12V
VCC = 5V 5VSB = 5V
AVDD = 5V
PAGE 28
AC97 LINK
VCORE
5VSB=5V
VDDQ=1.5V
VCC25 = 2.5V(I/O,MEMORY/I,VLINK/I)
3VDUAL = 3.3V(SUSPEND POWER)
VCC3 = 3.3V
RTCVDD = 3.3V
PCI BUS
PCI SLOT 1,2,3
+12 = 12V
-12 = -12V
VCC = 5V
VCC3 = 3V
3VDUAL = 3V
FRONT PANEL
PVCC = 5V
VCC = 5V
5VSB = 5V
+12 = 12V
P_5VSB = 5V
PAGE 16~18
PAGE 21,22
PAGE 30
LPC BUS
FWH-BIOS
VCC = 5V
VCC3 = 3V
LPC I/O LPC47M997
IR/S_IRQ
VCC3
VCC = 5VVCC3 = 3.3V
VBAT = 3V
PAGE 19
PAGE 23
A A
AUDIO PORTS :
LIN_ OUT
CD_IN
LINE_IN
SPDIF
5
FRONT AUDIO
MIC
PAGE 29
4
3
I/O PORTS :
COMB
COMA
GAMEVCC=5V,5VDUAL=5V,VCC=5V,FUSEVCC=5V,FUSEVCC1=5V,+12V,-12V
LPT
2
PS2
PAGE 25,26
Title
Size Document Number Rev
Custom
Date: Sheet
GIGABYTE
BOM & PCB MODIFY HISTORY
XP-P5IM800GV 1.0
1
of
336
Page 4
5
D D
4
3
2
1
HA[3..16][8]
C C
HA[17..31][8]
B B
VCORE
BC621
10U/12/X/6.3V
BC622
10U/12/X/6.3V
BC623
10U/12/X/6.3V
BC624
10U/12/X/6.3V
HA[3..16]
HA[17..31]
BC625
10U/12/X/6.3V
HA3
HA4
HA5
HA6
HA7
HA8
HA9
HA10
HA11
HA12
HA13
HA14
HA15
HA16
TP13
-HREQ0
-HREQ1
-HREQ2
-HREQ3
-HREQ4
-HADSTB0
-HPCREQ
-HADSTB1
-HREQ0[8]
-HREQ1[8]
-HREQ2[8]
-HREQ3[8]
-HREQ4[8]
-HADSTB0[8]
HA17
HA18
HA19
HA20
HA21
HA22
HA23
HA24
HA25
HA26
HA27
HA28
HA29
HA30
HA31
-HADSTB1[8]
U46A
L5
A03#
P6
A04#
M5
A05#
L4
A06#
M4
A07#
R4
A08#
T5
A09#
U6
A10#
T4
A11#
U5
A12#
U4
A13#
V5
A14#
V4
A15#
W5
A16#
N4
RSVD
P5
RSVD
K4
REQ0#
J5
REQ1#
M6
REQ2#
K6
REQ3#
J6
REQ4#
R6
ADSTB0#
G5
PCREQ#
AB6
A17#
W6
A18#
Y6
A19#
Y4
A20#
AA4
A21#
AD6
A22#
AA5
A23#
AB5
A24#
AC5
A25#
AB4
A26#
AF5
A27#
AF4
A28#
AG6
A29#
AG4
A30#
AG5
A31#
AH4
A32#
AH5
A33#
AJ5
A34#
AJ6
A35#
AC4
RSVD
AE4
RSVD
AD5
ADSTB1#
LGA775/MOLEX/[10SC1-D03775-03]
上
100U/2V/SPCAP
ADS#
BNR#
HIT#
RSP#
BPRI#
DBSY#
DRDY#
HITM#
IERR#
INIT#
LOCK#
TRDY#
BINIT#
DEFER#
EDRDY#
MCERR#
AP0#
AP1#
BR0#
TESTHI08
TESTHI09
TESTHI10
DP0#
DP1#
DP2#
DP3#
GTLREF
RESET#
RS0#
RS1#
RS2#
上
10U/12/X/6.3V X2
C2
D4
H4
G8
B2
C1
E4
AB2
P3
C3
E3
AD3
G7
F2
AB3
U2
U3
F3
G3
G4
H5
J16
H15
H16
J17
H1
G23
B3
F5
A3
-BNR
-HIT
-BPRI
-DBSY
-DRDY
-HITM
-IERR
-HINIT
-HLOCK
-HTRDY
-DEFER
-EDRDY
TP11
TP12
-BR0
TESTHI8
TESTHI9
TESTHI10
TP14
TP15
TP16
TP17
GTLREF
-CPURST
-RS0
-RS1
-RS2
-HADS
D2
*
-HADS [8]
-BNR [8]
-HIT [8]
-BPRI [8]
-DBSY [8]
-DRDY [8]
-HITM [8]
-HLOCK [8]
-HTRDY [8]
-DEFER [8]
TP10
-BR0 [8]
TESTHI8 [6]
TESTHI9 [6]
TESTHI10 [6]
C464
220P/4/N/50V
-RS0 [8]
-RS1 [8]
-RS2 [8]
顆
C463
33P/4/N/50V
C465
22P/4/N/50V
-HINIT [16,18]
-CPURST [8]
VTT_OR
VTT_OL
VTT_OL
VTT_OL
VTT_OL
VTT_OL
R1259
49.9/6/1
BC631
0.01U/4/Y/16V
Closed to
Pin-H1
R1260
100/6/1
R1261 62/6
R1262 62/6
R1263 62/6
R1294 62/6
R1306 62/6
GTLREF
C462
1U/6/Y/10V
-IERR
-BR0
-CPURST
-EDRDY
-HPCREQ
CR87
CPU RETAINTION/X
VCORE
10U/12/X/6.3V
BC626
BC627
10U/12/X/6.3V
BC628
10U/12/X/6.3V
+
EC1
EC3
BC625/626
+
BC621/622
-
A A
EC2
BC623/624
上
+
上
10U/12/X/6.3V X2
顆
EC4
+
BC627/628
5
4
3
100U/2V/SPCAP
Title
Size Document Number Rev
Custom
2
Date: Sheet
GIGABYTE
P4_LGA775-A
XP-P5IM800GV
1
1.0
of
436Thursday, December 16, 2004
Page 5
5
D D
4
3
2
1
HD[0..15][8]
C C
HD[16..31][8]
B B
HD[0..15]
HD[16..31]
HD0
HD1
HD2
HD3
HD4
HD5
HD6
HD7
HD8
HD9
HD10
HD11
HD12
HD13
HD14
HD15
-DBI0[8]
STBN0[8]
STBP0[8]
-DBI1[8]
STBN1[8]
STBP1[8]
-DBI0
STBN0
STBP0
HD16
HD17
HD18
HD19
HD20
HD21
HD22
HD23
HD24
HD25
HD26
HD27
HD28
HD29
HD30
HD31
-DBI1
STBN1
STBP1
U46B
B4
D00#
C5
D01#
A4
D02#
C6
D03#
A5
D04#
B6
D05#
B7
D06#
A7
D07#
A10
D08#
A11
D09#
B10
D10#
C11
D11#
D8
D12#
B12
D13#
C12
D14#
D11
D15#
A8
DBI0#
C8
DSTBN0#
B9
DSTBP0
G9
D16#
F8
D17#
F9
D18#
E9
D19#
D7
D20#
E10
D21#
D10
D22#
F11
D23#
F12
D24#
D13
D25#
E13
D26#
G13
D27#
F14
D28#
G14
D29#
F15
D30#
G15
D31#
G11
DBI1#
G12
DSTBN1#
E12
DSTBP1
LGA775/MOLEX/[10SC1-D03775-03]
D32#
D33#
D34#
D35#
D36#
D37#
D38#
D39#
D40#
D41#
D42#
D43#
D44#
D45#
D46#
D47#
DBI2#
DSTBN2#
DSTBP2
D48#
D49#
D50#
D51#
D52#
D53#
D54#
D55#
D56#
D57#
D58#
D59#
D60#
D61#
D62#
D63#
DBI3#
DSTBN3#
DSTBP3
HD32
G16
HD33
E15
HD34
E16
HD35
G18
HD36
G17
HD37
F17
HD38
F18
HD39
E18
HD40
E19
HD41
F20
HD42
E21
HD43
F21
HD44
G21
HD45
E22
HD46
D22
HD47
G22
-DBI2
D19
G20
G19
D20
D17
A14
C15
C14
B15
C18
B16
A17
B18
C21
B21
B19
A19
A22
B22
C20
A16
C17
STBN2
STBP2
HD48
HD49
HD50
HD51
HD52
HD53
HD54
HD55
HD56
HD57
HD58
HD59
HD60
HD61
HD62
HD63
-DBI3
STBN3
STBP3
-DBI2 [8]
STBN2 [8]
STBP2 [8]
-DBI3 [8]
STBN3 [8]
STBP3 [8]
HD[32..47] [8]
HD[48..63] [8]
A A
Title
Size Document Number Rev
Custom
5
4
3
2
Date: Sheet
GIGABYTE
P4_LGA775-B
XP-P5IM800GV
1
1.0
of
536Thursday, December 16, 2004
Page 6
5
4
3
2
1
Note:
VCCA & VCOREPLL
VTT_GMCH
L20
10UH/8/100mA/S
D D
L21
10UH/8/100mA/S
C467
1U/6/Y/10V
C468
1U/6/Y/10V
BC652
4.7U/8/Y/10V
BC653
4.7U/8/Y/10V
define doesn't same as
old P4 design kit
As close as possible to
CPU socket
VCCA
R1268
0/6/SHT/X
VSSA
VCOREPLL
Trace width doesn't
less than 12 Mil
VID[0..5][22,31]
VTT_OR
VID[0..5]
CPU
C C
FSBSEL3
ICS952603
FS_E
B B
Support 1066 FSB
force 800 CPU
VTT_GMCH
A A
FSB
NA
FSBSEL1
1
0
0
0
0
0
0
1
1
0
FS_3
1
0
1
0
1
0
1
R1487
1K/6
FSA
1
1
1
0
0
0
000
1
1
Clock
100MHz
133MHz
166MHz
200MHz
266MHz
FS_A
0
0
3
D
GS
2
1
FS_A
X
Clock
100MHz
133MHz1
166MHz
200MHz
FS_B
Q223
2N7002/SOT23
FSBSEL0
FS_B
FS_C
0
01
0
VCC
R1486
8.2K/6
Q224
MMBT2222A/SOT23
132
THERM_DP[22]
THERM_DN[22]
1N/4/X/50V
BC654
C470
1N/4/X/50V
FS_A[8,19]
FS_B[8,19]
CPUCLK[19]
-CPUCLK[19]
VCC_SENSE[31]
VSS_SENSE[31]
22U/12/X/6.3V
FS_A
FS_B
BC644
-SYS_RST[16,29]
R1488 0/6
R1489 0/6/X
-SMI[16]
-A20M[16]
-FERR[16]
INTR[16]
NMI[16]
-IGNNE[16]
-STPCLK[16]
CPUCLK
-CPUCLK
R1483 62/6/X
R1484 62/6/X
R1479
49.9/6/1/X
-SMI
-A20M
-FERR
INTR
NMI
-IGNNE
-STPCLK
VCCA
VSSA
VCOREPLL
VID0
VID1
VID2
VID3
VID4
VID5
TP21
TCK
TDI
TDO
TMS
-TRST
-BPM0
-BPM1
-BPM2
-BPM3
-BPM4
-BPM5
-SYS_RST
CPUBSEL0
CPUBSEL1
FS_C
GTLREF1
C912
R1480
1U/6/Y/10V/X
100/6/1/X
U46C
P2
SMI#
K3
A20M#
R3
FERR#/PBE#
K1
LINT0
L1
LINT1
N2
IGNNE#
M3
STPCLK#
A23
VCCA
B23
VSSA
D23
RSVD
C23
VCCIOPLL
AM2
VID0
AL5
VID1
AM3
VID2
AL6
VID3
AK4
VID4
AL4
VID5
AM5
RSVD
F28
BCLK0
G28
BCLK1
AE8
SKTOCC#
AL1
THERMDA
AK1
THERMDC
AN3
VCC_SENSE
AN4
VSS_SENSE
AN5
RSVD
AN6
RSVD
F29
VTT_PKGSENSE
V1
MSID1
W1
MSID0
F6
RSVD_F6
LGA775/MOLEX/[10SC1-D03775-03]
U46D
AE1
TCK
AD1
TDI
AF1
TDO
AC1
TMS
AG1
TRST#
AJ2
BPM0#
AJ1
BPM1#
AD2
BPM2#
AG2
BPM3#
AF2
BPM4#
AG3
BPM5#
AC2
DBR#
AK3
ITPCLK0
AJ3
ITPCLK1
G29
BSEL0
H30
BSEL1
G30
BSEL2
LGA775/MOLEX/[10SC1-D03775-03]
VCC3
FORCEPR#
PROCHOT#
THERMTRIP#
BOOTSELECT
VTTPWRGD
VTT_OUT
VTT_OUT
VTT_SEL
TESTHI00
TESTHI01
TESTHI11
TESTHI12
TESTHI02
TESTHI03
TESTHI04
TESTHI05
TESTHII06
TESTHI07
RSVD
SLP#
RSVD
PWRGOOD
COMP0
COMP1
COMP2
COMP3
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
GTLREF1
LL_ID0
LL_ID1
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
R1307 110/6/1
GTL_DET[7,8]
F26
W3
P1
W2
F25
G25
G27
G26
G24
F24
AK6
G6
L2
AH2
N1
AL2
M2
A13
T1
G2
R1
N5
AE6
C9
G10
D16
A20
E7
N/C
E23
N/C
E24
N/C
F23
N/C
H2
J2
N/C
J3
N/C
Y1
V2
AA2
A29
B25
B29
B30
C29
A26
B27
C28
A25
A28
A27
C30
A30
C25
C26
C27
B26
D27
D28
D25
D26
B28
D29
D30
AM6
AA1
J1
R1290 1K/6/X
F27
R1308
61.9/6/1
TESTHI0
TESTHI1
TESTHI11
TESTHI12
TESTHI2_7
-FORCEPR
RSVD_G6
-CPUSLP
CPUPWROK
-PROCHOT
-THERM
COMP0
COMP1
COMP2
COMP3
TP18
TP19
C913
TP20
220P/4/N/50V/X
BOOTSEL
TP22
R1485 62/6/X
VTT_GMCH
0.1U/6/Y/25V
R1323 249/6/1
3
Q214
D
GS
2
1
-FORCEPR [30]
VTT_GMCH
VTT_PWRGD [30,31]
VTT_OR
VTT_OL
VCC3
C475
2N7002/SOT23
SOT23
-CPUSLP [16]
CPUPWROK [16]
-PROCHOT [8,30]
-THERM [16]
TESTHI0
VCC3
TESTHI0
Locate at ICH6 Side
Place outside of CPU socket
VTT_OL
0.1U/6/Y/25V
VTT_GMCH
VTT_OL
VTT_OR
0.1U/6/Y/25V
0.1U/6/Y/25V
C466
C471
C472
1N/4/X/50V/X
R1264 100/6/1
R1265 100/6/1
R1266 60.4/6/1
R1267 60.4/6/1
R1481 60.4/6/1/X
R1482 60.4/6/1/X
7 8
5 6
3 4
1 2
R1269 62/6
R1271 62/6
R1272 62/6
R1273 62/6/X
R1274 62/6
R1275 62/6
RN124
7 8
5 6
3 4
1 2
62/8P4R
R1276 100/6
RN125 680/8P4R
R1279 680/6
R1280 680/6
R1281 120/6
R1282 62/6/X
R1283 62/6/X
R1284 62/6
R1285 62/6
RN126 62/8P4R
RN127 62/8P4R
R1286 62/6
R1287 62/6
C473
C474
33P/4/N/50V
RN123
470/8P4R/X
7 8
5 6
3 4
1 2
7 8
5 6
3 4
1 2
7 8
5 6
3 4
1 2
VTT_PWRGD
-CPUSLP
FS_A
FS_B
FS_C
TESTHI2_7
-THERM
-FERR
RSVD_G6
TESTHI12
TESTHI1
TESTHI8
TESTHI11
TESTHI10
TESTHI9
CPUPWROK
C469
1N/4/X/50V
COMP2
COMP3
COMP0
COMP1
COMP2
COMP3
TESTHI8 [4]
TESTHI10 [4]
TESTHI9 [4]
VID2
VID5
VID0
VID4
VID1
VID3
-PROCHOT
BOOTSEL
-FORCEPR
-BPM5
-BPM4
-BPM1
-BPM0
-BPM2
-BPM3
TMS
TDI
TDO
-TRST
TCK
Title
Size Document Number Rev
Custom
5
4
3
2
Date: Sheet
GIGABYTE
P4_LGA775-C
XP-P5IM800GV
1
1.0
of
636Thursday, December 16, 2004
Page 7
5
D D
U46E
VCORE
C C
B B
AA8
VCC
AB8
VCC
AC23
VCC
AC24
VCC
AC25
VCC
AC26
VCC
AC27
VCC
AC28
VCC
AC29
VCC
AC30
VCC
AC8
VCC
AD23
VCC
AD24
VCC
AD25
VCC
AD26
VCC
AD27
VCC
AD28
VCC
AD29
VCC
AD30
VCC
AD8
VCC
AE11
VCC
AE12
VCC
AE14
VCC
AE15
VCC
AE18
VCC
AE19
VCC
AE21
VCC
AE22
VCC
AE23
VCC
AE9
VCC
AF11
VCC
AF12
VCC
AF14
VCC
AF15
VCC
AF18
VCC
AF19
VCC
AF21
VCC
AF22
VCC
AF8
VCC
AF9
VCC
AG11
VCC
AG12
VCC
AG14
VCC
AG15
VCC
AG18
VCC
AG19
VCC
AG21
VCC
AG22
VCC
AG25
VCC
AG26
VCC
AG27
VCC
AG28
VCC
AG29
VCC
AG30
VCC
AG8
VCC
AG9
VCC
LGA775/MOLEX/[10SC1-D03775-03]
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
AH11
AH12
AH14
AH15
AH18
AH19
AH21
AH22
AH25
AH26
AH27
AH28
AH29
AH30
AH8
AH9
AJ11
AJ12
AJ14
AJ15
AJ18
AJ19
AJ21
AJ22
AJ25
AJ26
AJ8
AJ9
AK11
AK12
AK14
AK15
AK18
AK19
AK21
AK22
AK25
AK26
AK8
AK9
AL11
AL12
AL14
AL15
AL18
AL19
AL21
AL22
AL25
AL26
AL29
AL30
AL8
AL9
VCORE
VCORE
4
U46F
AM11
VCC
AM12
VCC
AM14
VCC
AM15
VCC
AM18
VCC
AM19
VCC
AM21
VCC
AM22
VCC
AM25
VCC
AM26
VCC
AM29
VCC
AM30
VCC
AM8
VCC
AM9
VCC
AN11
VCC
AN12
VCC
AN14
VCC
AN15
VCC
AN18
VCC
AN19
VCC
AN21
VCC
AN22
VCC
AN25
VCC
AN26
VCC
AN29
VCC
AN30
VCC
AN8
VCC
AN9
VCC
J10
VCC
J11
VCC
J12
VCC
J13
VCC
J14
VCC
J15
VCC
J18
VCC
J19
VCC
J20
VCC
J21
VCC
J22
VCC
J23
VCC
J24
VCC
J25
VCC
J26
VCC
J27
VCC
J28
VCC
J29
VCC
J30
VCC
J8
VCC
J9
VCC
K23
VCC
K24
VCC
K25
VCC
K26
VCC
K27
VCC
K28
VCC
K29
VCC
K30
VCC
K8
VCC
L8
VCC
M23
VCC
M24
VCC
M25
VCC
M26
VCC
M27
VCC
M28
VCC
M29
VCC
M30
VCC
M8
VCC
LGA775/MOLEX/[10SC1-D03775-03]
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
N23
N24
N25
N26
N27
N28
N29
N30
N8
P8
R8
T23
T24
T25
T26
T27
T28
T29
T30
T8
U23
U24
U25
U26
U27
U28
U29
U30
U8
V8
W23
W24
W25
W26
W27
W28
W29
W30
W8
Y23
Y24
Y25
Y26
Y27
Y28
Y29
Y30
Y8
VCORE
3
U46G
A12
VSS
A15
VSS
A18
VSS
A2
VSS
A21
VSS
A24
VSS
A6
VSS
A9
VSS
AA23
VSS
AA24
VSS
AA25
VSS
AA26
VSS
AA27
VSS
AA28
VSS
AA29
VSS
AA3
VSS
AA30
VSS
AA6
VSS
AA7
VSS
AB1
VSS
AB23
VSS
AB24
VSS
AB25
VSS
AB26
VSS
AB27
VSS
AB28
VSS
AB29
VSS
AB30
VSS
AB7
VSS
AC3
VSS
AC6
VSS
AC7
VSS
AD4
VSS
AD7
VSS
AE10
VSS
AE13
VSS
AE16
VSS
AE17
VSS
AE2
VSS
AE20
VSS
AE24
VSS
AE25
VSS
AE26
VSS
AE27
VSS
AE28
VSS
AE29
VSS
AE30
VSS
AE5
VSS
AE7
VSS
AF10
VSS
AF13
VSS
AF16
VSS
AF17
VSS
AF20
VSS
AF23
VSS
AF24
VSS
AF25
VSS
AF26
VSS
AF27
VSS
AF28
VSS
AF29
VSS
AF3
VSS
AF30
VSS
AF6
VSS
AF7
VSS
LGA775/MOLEX/[10SC1-D03775-03]
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
AG10
AG13
AG16
AG17
AG20
AG23
AG24
AG7
AH1
AH10
AH13
AH16
AH17
AH20
AH23
AH24
AH3
AH6
AH7
AJ10
AJ13
AJ16
AJ17
AJ20
AJ23
AJ24
AJ27
AJ28
AJ29
AJ30
AJ4
AJ7
AK10
AK13
AK16
AK17
AK2
AK20
AK23
AK24
AK27
AK28
AK29
AK30
AK5
AK7
AL10
AL13
AL16
AL17
AL20
AL23
AL24
AL27
AL28
AL3
AL7
AM1
AM10
AM13
AM16
AM17
AM20
AM23
AM24
AM27
AM28
AM4
AM7
2
U46H
AN1
VSS
AN10
VSS
AN13
VSS
AN16
VSS
AN17
VSS
AN2
VSS
AN20
VSS
AN23
VSS
AN24
VSS
AN27
VSS
AN28
R1490 62/6
VSS
AN7
VSS
B1
VSS
B11
VSS
B14
VSS
B17
VSS
B20
VSS
B24
VSS
B5
VSS
B8
VSS
C10
VSS
C13
VSS
C16
VSS
C19
VSS
C22
VSS
C24
VSS
C4
VSS
C7
VSS
D12
VSS
D15
VSS
D18
VSS
D21
VSS
D24
VSS
D3
VSS
D5
VSS
D6
VSS
D9
VSS
E11
VSS
E14
VSS
E17
VSS
E2
VSS
E20
VSS
E25
VSS
E26
VSS
E27
VSS
E28
VSS
E29
VSS
E8
VSS
F10
VSS
F13
VSS
F16
VSS
F19
VSS
F22
VSS
F4
VSS
F7
VSS
G1
VSS
H10
VSS
H11
VSS
H12
VSS
H13
VSS
H14
VSS
H17
VSS
H18
VSS
H19
VSS
H20
VSS
H21
VSS
H22
VSS
H23
VSS
H24
VSS
LGA775/MOLEX/[10SC1-D03775-03]
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
1
H25
H26
H27
H28
H29
GTL_DET [6,8]
H3
H6
H7
H8
H9
J4
J7
K2
K5
K7
L23
L24
L25
L26
L27
L28
L29
L3
L30
L6
L7
M1
M7
N3
N6
N7
P23
P24
P25
P26
P27
P28
P29
P30
P4
P7
R2
R23
R24
R25
R26
R27
R28
R29
R30
R5
R7
T3
T6
T7
U1
U7
V23
V24
V25
V26
V27
V28
V29
V3
V30
V6
V7
W4
W7
Y2
Y5
Y7
A A
Title
Size Document Number Rev
Custom
5
4
3
2
Date: Sheet
GIGABYTE
P4_LGA775-D
XP-P5IM800GV
1
1.0
of
736Thursday, December 16, 2004
Page 8
5
4
3
2
1
C10
1U/6/Y/10V
AE14
D26
D30
C30
C31
D34
C32
C34
G27
H27
G30
G26
C29
D28
C19
C17
D12
C15
D24
G24
G22
C27
C25
L23
E29
B32
K23
J25
B31
E30
B33
J24
F25
F28
J27
F29
E28
K24
E32
F31
J26
B29
J23
L22
J21
B30
B7
C7
B19
L19
K19
L17
G9
F9
L14
E12
F27
L21
E23
K21
E25
B24
B28
B26
E27
B27
E8
E24
F23
U1A
HA3#
HA4#
HA5#
HA6#
HA7#
HA8#
HA9#
HA10#
HA11#
HA12#
HA13#
HA14#
HA15#
HA16#
HA17#
HA18#
HA19#
HA20#
HA21#
HA22#
HA23#
HA24#
HA25#
HA26#
HA27#
HA28#
HA29#
HA30#
HA31#
HREQ0#
HREQ1#
HREQ2#
HREQ3#
HREQ4#
HADSTB0#
HADSTB1#
HCLKP
HCLKN
HDSTBP0#
HDSTBN0#
DINV0#
HDSTBP1#
HDSTBN1#
DINV1#
HDSTBP2#
HDSTBN2#
DINV2#
HDSTBP3#
HDSTBN3#
DINV3#
ADS#
HTRDY#
DRDY#
DEFER#
HITM#
HIT#
HLOCK#
BREQ0#
BNR#
BPRI#
DBSY#
RS0#
RS1#
RS2#
CPURST#
PWROK#
HDRCOMP
HDSWING
HDVREF
SPDGV MCH
CPU INTERFACE
HD0#
HD1#
HD2#
HD3#
HD4#
HD5#
HD6#
HD7#
HD8#
HD9#
HD10#
HD11#
HD12#
HD13#
HD14#
HD15#
HD16#
HD17#
HD18#
HD19#
HD20#
HD21#
HD22#
HD23#
HD24#
HD25#
HD26#
HD27#
HD28#
HD29#
HD30#
HD31#
HD32#
HD33#
HD34#
HD35#
HD36#
HD37#
HD38#
FSB
HD39#
HD40#
HD41#
HD42#
HD43#
HD44#
HD45#
HD46#
HD47#
HD48#
HD49#
HD50#
HD51#
HD52#
HD53#
HD54#
HD55#
HD56#
HD57#
HD58#
HD59#
HD60#
HD61#
HD62#
HD63#
PROCHOT#
BSEL0
BSEL1
HD0
B23
HD1
E22
HD2
B21
HD3
D20
HD4
B22
HD5
D22
HD6
B20
HD7
C21
HD8
E18
HD9
E20
HD10
B16
HD11
D16
HD12
B18
HD13
B17
HD14
E16
HD15
D18
HD16
G20
HD17
F17
HD18
E19
HD19
F19
HD20
J17
HD21
L18
HD22
G16
HD23
G18
HD24
F21
HD25
F15
HD26
E15
HD27
E21
HD28
J19
HD29
G14
HD30
E17
HD31
K17
HD32
J15
HD33
L16
HD34
J13
HD35
F13
HD36
F11
HD37
E13
HD38
K15
HD39
G12
HD40
G10
HD41
L15
HD42
E11
HD43
K13
HD44
J11
HD45
H10
HD46
G8
HD47
E9
HD48
B13
HD49
E14
HD50
B14
HD51
B12
HD52
B15
HD53
D14
HD54
C13
HD55
B11
HD56
D10
HD57
C11
HD58
E10
HD59
B10
HD60
C9
HD61
B9
HD62
D8
HD63
B8
-PROCHOT
L20
L13
L12
HA[3..31][4]
D D
C C
+12V
R1312
8.2K/6
GTL_DET[6,7]
R1311
619/6/1
GS
D
2
3
1
Q211
2N7002/SOT23
SOT23
MCH_GTLREF
HRCOMP
R26
20/6/1
VCORE
-HREQ0[4]
-HREQ1[4]
-HREQ2[4]
-HREQ3[4]
-HREQ4[4]
-HADSTB0[4]
-HADSTB1[4]
MCHCLK[19]
-MCHCLK[19]
STBP0[5]
STBN0[5]
-DBI0[5]
STBP1[5]
STBN1[5]
-DBI1[5]
STBP2[5]
STBN2[5]
-DBI2[5]
STBP3[5]
STBN3[5]
-DBI3[5]
-HADS[4]
-HTRDY[4]
-DRDY[4]
-DEFER[4]
-HITM[4]
-HLOCK[4]
B B
VCORE
-BNR[4]
-BPRI[4]
-DBSY[4]
Close to GMCH side
BC555
1U/6/Y/10V
R27
100/6/1
R1313
169/6/1
C9
220P/4/N/50V/X
BC559
1U/6/Y/10V/X
MCH_GTLREF
BC516
0.01U/4/X/16V/X
-CPURST[4]
PWROK[16,21]
HA3
HA4
HA5
HA6
HA7
HA8
HA9
HA10
HA11
HA12
HA13
HA14
HA15
HA16
HA17
HA18
HA19
HA20
HA21
HA22
HA23
HA24
HA25
HA26
HA27
HA28
HA29
HA30
HA31
-HREQ0
-HREQ1
-HREQ2
-HREQ3
-HREQ4
-HADSTB0
-HADSTB1
MCHCLK
-MCHCLK
STBP0
STBN0
-DBI0
STBP1
STBN1
-DBI1
STBP2
STBN2
-DBI2
STBP3
STBN3
-DBI3
-HADS
-HTRDY
-DRDY
-DEFER
-HITM
-HIT
-HIT[4]
-HLOCK
-BR0
-BR0[4]
-BNR
-BPRI
-DBSY
-RS0
-RS0[4]
-RS1
-RS1[4]
-RS2
-RS2[4]
-CPURST
PWROK
HRCOMP
HSWNG
HD[0..63]HA[3..31]
-PROCHOT [6,30]
HD[0..63] [5]
R28
1K/6
R30
8.2K/6
R31
1K/6
R32
8.2K/6
FS_A
FS_B
FS_A [6,19]
FS_B [6,19]
COUPON2
COUPON1
COUPON1 COUPON
COUPON2 COUPON
21
21
VCC
N.B HEATSINK
VCORE
HS1
1
R33
A A
301/6/1
R34
102/6/1
C12
0.01U/4/X/16V
5
HSWNG
C13
1U/6/Y/10V
NEAR MCH
PWROK
C379
2
NB_HEATSINK/[12SP2-04E003-01/02]
4
3
1000P/4/X/50V
2
Title
Size Document Number Rev
Custom
Date: Sheet
SPRINGDALE HOST
XP-P5IM800GV 1.0
1
836
of
Page 9
5
4
3
2
1
DDR 400 1-2-3-4 CPC DISABLE
DDR 333 SIGNAL 1 CPC ENABLE
2 CPC DISABLE
DUAL 2 CPC ENABLE
AJ34
AL33
AK29
AN31
AL30
AL26
AL28
AN25
AP26
AP24
AJ33
AN23
AN21
AL34
AM34
AP32
AP31
AM26
AB34
AC33
AE33
AH34
AA34
W34
AL20
AN19
AM20
AP20
AK32
AK31
AP17
AN17
AK33
AK34
AM16
AL16
AK9
AN9
Y34
Y31
Y32
N33
N34
P31
P32
E34
AL9
U1B
SMAA_A0
SMAA_A1
SMAA_A2
SMAA_A3
SMAA_A4
SMAA_A5
SMAA_A6
SMAA_A7
SMAA_A8
SMAA_A9
SMAA_A10
SMAA_A11
SMAA_A12
SMAB_A1
SMAB_A2
SMAB_A3
SMAB_A4
SMAB_A5
SWE_A#
SCAS_A#
SRAS_A#
SBA_A0
SBA_A1
SCS_A0#
SCS_A1#
SCS_A2#
SCS_A3#
SCKE_A0
SCKE_A1
SCKE_A2
SCKE_A3
SCMDCLK_A0
SCMDCLK_A0#
SCMDCLK_A1
SCMDCLK_A1#
SCMDCLK_A2
SCMDCLK_A2#
SCMDCLK_A3
SCMDCLK_A3#
SCMDCLK_A4
SCMDCLK_A4#
SCMDCLK_A5
SCMDCLK_A5#
SMVREF_A
SMXRCOMP
SMXRCOMPVOH
SMXRCOMPVOL
SPDGV MCH
DDR INTERFACE
SDQS_A0
SDM_A0
SDQ_A0
SDQ_A1
SDQ_A2
SDQ_A3
SDQ_A4
SDQ_A5
SDQ_A6
SDQ_A7
SDQS_A1
SDM_A1
SDQ_A8
SDQ_A9
SDQ_A10
SDQ_A11
SDQ_A12
SDQ_A13
SDQ_A14
SDQ_A15
SDQS_A2
SDM_A2
SDQ_A16
SDQ_A17
SDQ_A18
SDQ_A19
SDQ_A20
DDR Channel A
SDQ_A21
SDQ_A22
SDQ_A23
SDQS_A3
SDM_A3
SDQ_A24
SDQ_A25
SDQ_A26
SDQ_A27
SDQ_A28
SDQ_A29
SDQ_A30
SDQ_A31
SDQS_A4
SDM_A4
SDQ_A32
SDQ_A33
SDQ_A34
SDQ_A35
SDQ_A36
SDQ_A37
SDQ_A38
SDQ_A39
SDQS_A5
SDM_A5
SDQ_A40
SDQ_A41
SDQ_A42
SDQ_A43
SDQ_A44
SDQ_A45
SDQ_A46
SDQ_A47
SDQS_A6
SDM_A6
SDQ_A48
SDQ_A49
SDQ_A50
SDQ_A51
SDQ_A52
SDQ_A53
SDQ_A54
SDQ_A55
SDQS_A7
SDM_A7
SDQ_A56
SDQ_A57
SDQ_A58
SDQ_A59
SDQ_A60
SDQ_A61
SDQ_A62
SDQ_A63
-SWEA[12]
SBAA0[12]
SBAA1[12]
-CSA0[12]
-CSA1[12]
CKEA0[12]
CKEA1[12]
DDRVREFA
SMXRCOMP
SMXRCOMPVOH
SMXRCOMPVOL
R47
42.2/6/1
SMXRCOMP
R49
40.2/6/1
MAAA0
MAAA1
MAAA2
MAAA3
MAAA4
MAAA5
MAAA6
MAAA7
MAAA8
MAAA9
MAAA10
MAAA11
MAAA12
-SWEA
-SCASA
-SRASA
SBAA0
SBAA1
-CSA0
-CSA1
CKEA0
CKEA1
DCLKA0
-DCLKA0
DCLKA1
-DCLKA1
DCLKA2
-DCLKA2
MAAA[0..12][12]
D D
DMA[0..7][12]
MDA[0..63][12]
DQSA[0..7][12]
C C
MAAA[0..12]
DMA[0..7]
MDA[0..63]
DQSA[0..7]
BC46
1U/6/Y/10V
-SCASA[12]
-SRASA[12]
DCLKA0[12]
-DCLKA0[12]
DCLKA1[12]
-DCLKA1[12]
DCLKA2[12]
-DCLKA2[12]
Closed to MCH
B B
DDR25V
BC54
1U/6/Y/10V
Closed to R47
A A
FIX 1.3V(PQI/TWINMOS DDR400)-->REV 1.0
AN11
AP12
AP10
AP11
AM12
AN13
AM10
AL10
AL12
AP13
AP15
AP16
AP14
AM14
AL18
AP19
AL14
AN15
AP18
AM18
AP23
AM24
AP22
AM22
AL24
AN27
AP21
AL22
AP25
AP27
AM30
AP30
AP28
AP29
AP33
AM33
AM28
AN29
AM31
AN34
AF34
AF31
AH32
AG34
AF32
AD32
AH31
AG33
AE34
AD34
V34
W33
AC34
AB31
V32
V31
AD31
AB32
U34
U33
M32
M34
T34
T32
K34
K32
T31
P34
L34
L33
H31
H32
J33
H34
E33
F33
K31
J34
G34
F34
DQSA0
DMA0
MDA0
MDA1
MDA2
MDA3
MDA4
MDA5
MDA6
MDA7
DQSA1
DMA1
MDA8
MDA9
MDA10
MDA11
MDA12
MDA13
MDA14
MDA15
DQSA2
DMA2
MDA16
MDA17
MDA18
MDA19
MDA20
MDA21
MDA22
MDA23
DQSA3
DMA3
MDA24
MDA25
MDA26
MDA27
MDA28
MDA29
MDA30
MDA31
DQSA4
DMA4
MDA32
MDA33
MDA34
MDA35
MDA36
MDA37
MDA38
MDA39
DQSA5
DMA5
MDA40
MDA41
MDA42
MDA43
MDA44
MDA45
MDA46
MDA47
DQSA6
DMA6
MDA48
MDA49
MDA50
MDA51
MDA52
MDA53
MDA54
MDA55
DQSA7
DMA7
MDA56
MDA57
MDA58
MDA59
MDA60
MDA61
MDA62
MDA63
MAAB[0..12][13]
DMB[0..7][13]
MDB[0..63][13]
DQSB[0..7][13]
BC279
1U/6/Y/10V
BC278
1U/6/Y/10V
MAAB[0..12]
DMB[0..7]
MDB[0..63]
DQSB[0..7]
BC47
1U/6/Y/10V
Closed to MCH
DDR25V
R42
150/6/1
DDRVREFB
R45
150/6/1
DDR25V
R48
42.2/6/1
R50
40.2/6/1
-SWEB[13]
-SCASB[13]
-SRASB[13]
SBAB0[13]
SBAB1[13]
-CSB0[13]
-CSB1[13]
CKEB0[13]
CKEB1[13]
DCLKB0[13]
-DCLKB0[13]
DCLKB1[13]
-DCLKB1[13]
DCLKB2[13]
-DCLKB2[13]
SMYRCOMP
DDRVREFB
SMYRCOMP
SMYRCOMPVOH
SMYRCOMPVOL
FIX 1.3V(PQI/TWINMOS DDR400)-->REV 1.0
MAAB0
MAAB1
MAAB2
MAAB3
MAAB4
MAAB5
MAAB6
MAAB7
MAAB8
MAAB9
MAAB10
MAAB11
MAAB12
-SWEB
-SCASB
-SRASB
SBAB0
SBAB1
-CSB0
-CSB1
CKEB0
CKEB1
DCLKB0
-DCLKB0
DCLKB1
-DCLKB1
DCLKB2
-DCLKB2
AG31
AJ31
AD27
AE24
AK27
AG25
AL25
AF21
AL23
AJ22
AF29
AL21
AJ20
AE27
AD26
AL29
AL27
AE23
W27
W31
W26
AA25
W25
AK19
AF19
AG19
AE18
AG29
AG30
AF17
AG17
AJ30
AH29
AK15
AL15
AP9
AA33
Y25
U26
T29
V25
N27
N26
N31
N30
R34
R33
U1C
SMAA_B0
SMAA_B1
SMAA_B2
SMAA_B3
SMAA_B4
SMAA_B5
SMAA_B6
SMAA_B7
SMAA_B8
SMAA_B9
SMAA_B10
SMAA_B11
SMAA_B12
SMAB_B1
SMAB_B2
SMAB_B3
SMAB_B4
SMAB_B5
SWE_B#
SCAS_B#
SRAS_B#
SBA_B0
SBA_B1
SCS_B0#
SCS_B1#
SCS_B2#
SCS_B3#
SCKE_B0
SCKE_B1
SCKE_B2
SCKE_B3
SCMDCLK_B0
SCMDCLK_B0#
SCMDCLK_B1
SCMDCLK_B1#
SCMDCLK_B2
SCMDCLK_B2#
SCMDCLK_B3
SCMDCLK_B3#
SCMDCLK_B4
SCMDCLK_B4#
SCMDCLK_B5
SCMDCLK_B5#
SMVREF_B
SMYRCOMP
SMYRCOMPVOH
SMYRCOMPVOL
SPDGV MCH
AF15
SDQS_B0
AG11
SDM_B0
AJ10
SDQ_B0
AE15
SDQ_B1
AL11
SDQ_B2
AE16
SDQ_B3
AL8
SDQ_B4
AF12
SDQ_B5
AK11
SDQ_B6
AG12
SDQ_B7
AG13
SDQS_B1
AG15
SDM_B1
AE17
SDQ_B8
AL13
SDQ_B9
AK17
SDQ_B10
AL17
SDQ_B11
AK13
SDQ_B12
AJ14
SDQ_B13
AJ16
SDQ_B14
AJ18
SDQ_B15
AG21
SDQS_B2
AE21
SDM_B2
AE19
SDQ_B16
AE20
SDQ_B17
AG23
SDQ_B18
AK23
SDQ_B19
SDQ_B20
SDQ_B21
SDQ_B22
SDQ_B23
SDQS_B3
SDM_B3
SDQ_B24
SDQ_B25
SDQ_B26
SDQ_B27
SDQ_B28
SDQ_B29
SDQ_B30
SDQ_B31
SDQS_B4
SDM_B4
SDQ_B32
SDQ_B33
SDQ_B34
SDQ_B35
SDQ_B36
SDQ_B37
SDQ_B38
SDQ_B39
SDQS_B5
SDM_B5
SDQ_B40
SDQ_B41
SDQ_B42
SDQ_B43
SDQ_B44
SDQ_B45
SDQ_B46
SDQ_B47
SDQS_B6
SDM_B6
SDQ_B48
SDQ_B49
SDQ_B50
SDQ_B51
SDQ_B52
SDQ_B53
SDQ_B54
SDQ_B55
SDQS_B7
SDM_B7
SDQ_B56
SDQ_B57
SDQ_B58
SDQ_B59
SDQ_B60
SDQ_B61
SDQ_B62
SDQ_B63
AL19
AK21
AJ24
AE22
AH27
AJ28
AK25
AH26
AG27
AF27
AJ26
AJ27
AD25
AF28
AD29
AC31
AE30
AC27
AC30
Y29
AE31
AB29
AA26
AA27
U30
U31
AA30
W30
U27
T25
AA31
V29
U25
R27
L27
M29
P29
R30
K28
L30
R31
R26
P25
L32
J30
J31
K30
H29
F32
G33
N25
M25
J29
G32
DDR Channel B
DQSB0
DMB0
MDB0
MDB1
MDB2
MDB3
MDB4
MDB5
MDB6
MDB7
DQSB1
DMB1
MDB8
MDB9
MDB10
MDB11
MDB12
MDB13
MDB14
MDB15
DQSB2
DMB2
MDB16
MDB17
MDB18
MDB19
MDB20
MDB21
MDB22
MDB23
DQSB3
DMB3
MDB24
MDB25
MDB26
MDB27
MDB28
MDB29
MDB30
MDB31
DQSB4
DMB4
MDB32
MDB33
MDB34
MDB35
MDB36
MDB37
MDB38
MDB39
DQSB5
DMB5
MDB40
MDB41
MDB42
MDB43
MDB44
MDB45
MDB46
MDB47
DQSB6
DMB6
MDB48
MDB49
MDB50
MDB51
MDB52
MDB53
MDB54
MDB55
DQSB7
DMB7
MDB56
MDB57
MDB58
MDB59
MDB60
MDB61
MDB62
MDB63
DUAL 4 CPC DISABLE
Closed to R35
DDR25V
R35
BC42
1U/6/Y/10V
10K/6/1
R36
30.9K/6/1
Closed to R38
DDR25V
R38
30.9K/6/1
SMXRCOMPVOL
R37
10K/6/1
Closed to R39
DDR25V
BC277
1U/6/Y/10V
R39
10K/6/1
R40
30.9K/6/1
BC558
1U/6/Y/10V
SMYRCOMPVOH
BC49
1U/6/Y/10V
Closed to R43
DDR25V
BC51
1U/6/Y/10V/X
R43
30.9K/6/1
R46
10K/6/1
SMYRCOMPVOL
BC557
1U/6/Y/10V
SMXRCOMPVOH
BC43
1U/6/Y/10V
BC45
1U/6/Y/10V
BC53
1U/6/Y/10V
Title
Size Document Number Rev
Custom
5
4
3
2
Date: Sheet
SPRINGDALE DDR
XP-P5IM800GV 1.0
1
936
of
Page 10
5
4
3
2
1
HL[0..10][15]
D D
C C
Close to MCH
B B
VDDQ
A A
HL[0..10]
GMCH3V66[19]
GSWING[14]
MCH_AGPREF[14]
HLSTBF[15]
HLSTBS[15]
C27 0.01U/4/X/16V
C28 0.01U/4/X/16V
CLSWING_SPG[11]
CLVREF_SPG[11]
DOTCLK[19]
C916 0.01U/4/X/16V
-PCIRST[15,18,21,22,34]
R69
52.3/6/1
CLRCOMP
GSWING
MCH_AGPREF
C34 0.1U/6/Y/25V
C35 0.01U/4/X/16V
CLOSED TO MCH
VDDQ VDDQ
R74
52.3/6/1
HLRCOMP_MCH GRCOMP
5
HLRCOMP_MCH
HL_SWING_MCH
HL_VREF_MCH
CLRCOMP
CLSWING_SPG
CLVREF_SPG
-ICHSYNC
R75
43.2/6/1
GMCH3V66
GRCOMP
GSWING
MCH_AGPREF
HL0
HL1
HL2
HL3
HL4
HL5
HL6
HL7
HL8
HL9
HL10
HLSTBF
HLSTBS
DOTCLK
-PCIRST
U1D
Y7
GCBE0
W5
GCBE1
AA3
GCBE2
U2
GCBE3
U6
GFRAME
H4
GCLKIN
AB4
GDEVSEL
V11
GIRDY
AB5
GTRDY
W11
GSTOP
AB2
GPAR/ADD_DETECT
N6
GREQ
M7
GGNT
AC2
GRCOMP
AC3
GVSWING
AD2
GVREF
R10
GRBF
R9
GWBF
M4
DBI_HI
M5
DBI_LO
N3
GST0
N5
GST1
N2
GST2
AF5
HI0
AG3
HI1
AK2
HI2
AG5
HI3
AK5
HI4
AL3
HI5
AL2
HI6
AL4
HI7
AJ2
HI8
AH2
HI9
AJ3
HI10
AH5
HISTRF
AH4
HISTRS
AD4
HI_RCOMP
AE3
HI_SWING
AE2
HI_VREF
AK7
CI0
AH7
CI1
AD11
CI2
AF7
CI3
AD7
CI4
AC10
CI5
AF8
CI6
AG7
CI7
AE9
CI8
AH9
CI9
AG6
CI10
AJ6
CISTRF
AJ5
CISTRS
AG2
CI_RCOMP
AF2
CI_SWING
AF4
CI_VREF
G4
DREFCLK
AP8
EXTTS#
AJ8
ICH_SYNC#
AK4
RSTIN#
AG10
RESERVED_1
AG9
RESERVED_2
AN35
RESERVED_3
AP34
RESERVED_4
AR1
RESERVED_5
SPDGV MCH
AGP
HUB
CSA
DOTCLK
C419
10P/4/N/50V/X
GADSTBF0
GADSTBS0
GAD0
GAD1
GAD2
GAD3
GAD4
GAD5
GAD6
GAD7
GAD8
GAD9
GAD10
GAD11
GAD12
GAD13
GAD14
GAD15
GADSTBF1
GADSTBS1
GAD16
GAD17
GAD18
GAD19
GAD20
GAD21
GAD22
GAD23
GAD24
GAD25
GAD26
GAD27
GAD28
GAD29
GAD30
GAD31
GSBSTBF
GSBSTBS
GSBA0#
GSBA1#
GSBA2#
GSBA3#
GSBA4#
GSBA5#
GSBA6#
GSBA7#
DDCA_DATA
DDCA_CLK
RED#
GREEN
GREEN#
VGA
BLUE
BLUE#
HSYNC
VSYNC
REFSET
NC_1
NC_2
NC_3
NC_4
NC_5
NC_6
NC_7
NC_8
NC_9
NC_10
NC_11
NC_12
NC_13
NC_14
NC_15
NC_16
NC_17
NC_18
NC_19
NC_20
AC6
AC5
AE6
AC11
AD5
AE5
AA10
AC9
AB11
AB7
AA9
AA6
AA5
W10
AA11
W6
W9
V7
V4
V5
AA2
Y4
Y2
W2
Y5
V2
W3
U3
T2
T4
T5
R2
P2
P5
P4
M2
U11
T11
R6
P7
R3
R5
U9
U10
U5
T7
H3
F2
F4
RED
E4
H6
G5
H7
G6
G3
E2
D2
A3
A33
A35
AF13
AF23
AJ12
AN1
AP2
AR3
AR33
AR35
B2
B25
B34
C1
C23
C35
E26
M31
R25
10 mil trace with 7 mil space
4
REFSET
HL_SWING_ICH[15]
HL_VREF_ICH[15]
R67 130/6/1
HL_SWING_ICH
VDDQ*0.533V
HL_VREF_ICH
VDDQ*0.233
VGA_R
VGA_G
VGA_B
VGADDCDATA
VGADDCCLK
HSYNC
VSYNC
R1149 0/6/X
R1150 0/6/X
HL_SWING_MCH
R71 0/6/SHT/X
C36
0.1U/6/Y/25V
HL_VREF_MCH
R73 0/6/SHT/X
C38
0.1U/6/Y/25V
R51
75/6/1
VCC3 VCC
R60
R59
8.2K/6
8.2K/6
VDDQ
3
C29
22P/4/N/50V
R444 47/6
R445 47/6
R70
226/6/1
R72
147/6/1
R76
113/6/1
2
VCC3
1
SOT23
Place mid of bus trace
75/6/1
22P/4/N/50V
Q1
2N7002/SOT23
GS
D
VCC3
C30
22P/4/N/50V
75/6/1
3
2
1
R53
R52
C14
22P/4/N/50V
C15
22P/4/N/50V
R57
8.2K/6
Q2
2N7002/SOT23
GS
D
3
SOT23
R63 0/6/SHT/X
R64 0/6/SHT/X
R65 0/6/SHT/X
C31
22P/4/N/50V
FB2 FB100/6/S
FB3 FB100/6/S
FB4 FB100/6/S
C16
470P/4/X/50V/X
R58
8.2K/6
R61 0/6/SHT/X
R62 0/6/SHT/X
VGA_R
VGA_G
VGA_B
HSYNC
VSYNC
C23
C22
470P/4/X/50V/X
2
C21
470P/4/X/50V/X
470P/4/X/50V/X
D18
BAV99/S
132
C17
3.3P/4/N/50V/X
C20
VGADDCDATA
VGADDCCLK
D19
BAV99/S
132
FUSEVCC
BC57
3.3P/4/N/50V/X
C18
3.3P/4/N/50V/X
0.1U/6/Y/25V
C19
VGA/P/S/[11NR6-101015-31/33]
1617
VGA
6
1
11
7
2
8
3
9
4
10
5
12
13
14
15
VGADDCDATA
HSYNC
VSYNC
VGADDCCLK
VGA & COMB DUAL LAYOUT
R1222
0/6/X
D20
BAV99/S
VDDQ
132
C33
C32
1U/6/Y/10V/X
Title
Size Document Number Rev
Custom
Date: Sheet
0.1U/6/Y/25V
SPRINGDALE AGP,HUB,CSA,VGA
XP-P5IM800GV 1.0
1
of
10 36
Page 11
5
4
DDR25V
3
2
1
BC58
VDDQ
VCORE
0.1U/6/Y/25V
BC72
0.1U/6/Y/25V
C52
0.1U/6/Y/25V
J6
VCC
J7
VCC
J8
VCC
J9
VCC
K6
VCC
K7
VCC
K8
VCC
K9
VCC
L6
VCC
L7
VCC
L9
VCC
L10
VCC
L11
VCC
M8
VCC
M9
VCC
M10
VCC
M11
VCC
N9
VCC
N10
VCC
N11
VCC
P10
VCC
P11
VCC
R11
VCC
T16
VCC
T17
VCC
T18
VCC
T19
VCC
T20
VCC
U16
VCC
U17
VCC
U20
VCC
V16
VCC
V18
VCC
V20
VCC
W16
VCC
W19
VCC
W20
VCC
Y16
VCC
Y17
VCC
Y18
VCC
Y19
VCC
Y20
VCC
J1
J2
J3
J4
J5
K2
K3
K4
K5
L1
L2
L3
L4
L5
Y1
D3
C380
4.7U/8/Y/10V
C382
10U/12/Y/10V
4
VDDQ
C51 0.1U/6/Y/25V
15 Mil
30mA
15 Mil
62mA
15 Mil
30mA
40 Mil
1000mA
BC66
0.1U/6/Y/25V
AA35
AM1
AM2
AM3
AM5
AM6
AM7
AM8
AN2
AN4
AN5
AN6
AN7
AN8
AP3
AP4
AP5
AP6
AP7
AR15
AR21
AR31
AR4
AR5
AR7
AG1
AL35
AB25
AC25
AC26
A15
A21
AL6
AL7
E35
R35
Y11
A31
A4
A5
A6
B5
B6
C5
C6
D5
D6
D7
E6
E7
F7
G1
G2
B4
B3
C2
U1E
SPDGV MCH
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VTT
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DDR
VCC_DAC
VCC_DAC
VCCA_AGP
VCCA_AGP
VCCA_FSB
VCCA_FSB
VCCA_DPLL
VCCA_DAC
VCCA_DDR
VCCA_DDR
VCCA_DDR
VCCA_DDR
C57
0.01U/4/X/16V/X
VCCA_FSB
C62
0.1U/6/Y/25V/X
VCCA_SM
C64
0.1U/6/Y/25V
VCCA_DPLL
VCCA_DAC
POWER
VCC_AGP
VCC_AGP
VCC_AGP
VCC_AGP
VCC_AGP
VCC_AGP
VCC_AGP
VCC_AGP
VCC_AGP
VCC_AGP
VCC_AGP
VCC_AGP
VCC_AGP
VCC_AGP
VCC_AGP
VSSA_DAC
C39 0.1U/6/Y/25V
C40 0.1U/6/Y/25V
D D
VCORE
DDR25V
C C
VCC3
BC346
0.1U/6/Y/25V
B B
VDDQ
VDDQ
BC517
1U/6/Y/10V
VDDQ
A A
VDDQ
5
C41 0.1U/6/Y/25V
C42 0.1U/6/Y/25V
C45 0.1U/6/Y/25V
C46 0.1U/6/Y/25V
VDDQ
C47 0.1U/6/Y/25V
VCCA_FSB
VCCA_DPLL
VCCA_DAC
C50 0.1U/6/Y/25V
VCCA_SM
L3
0/8/SHT/X
L4
0/8/SHT/X
L5
0/8/SHT/X
L6
100NH/S/1.4A[10LC3-01100C-01]
C202
4.7U/8/Y/10V
C56
0.1U/6/Y/25V/X
C61
4.7U/8/Y/10V
BC61
0.1U/6/Y/25V
BC73
0.1U/6/Y/25V
CLSWING_SPG[10]
CLSWING_SPG
VDDQ*0.533
10 mil trace with 7 mil space
CLVREF_SPG[10]
CLVREF_SPG
VDDQ*0.233
0.1U/6/Y/25V
C53
C54
0.1U/6/Y/25V
3
BC74
0.1U/6/Y/25V
0.1U/6/Y/25V/X
BC75
0.1U/6/Y/25V/X
C44
0.1U/6/Y/25V
C49
0.1U/6/Y/25V
C55
VDDQ
R77
226/6/1
R78
147/6/1
R79
113/6/1
C58
0.1U/6/Y/25V/X
Close to N/B
U1F
AR32
VSS
AR29
VSS
AR27
VSS
AR25
VSS
AR23
VSS
AR20
VSS
AR16
VSS
AR13
VSS
AR11
VSS
AR9
VSS
AN32
VSS
AN30
VSS
AN28
VSS
AN26
VSS
AN24
VSS
AN22
VSS
AN20
VSS
AN18
VSS
AN16
VSS
AN14
VSS
AN12
VSS
AN10
VSS
AM35
VSS
AM29
VSS
AM27
VSS
AM25
VSS
AM23
VSS
AM21
VSS
AM19
VSS
AM17
VSS
AM15
VSS
AM13
VSS
AM11
VSS
AM9
VSS
AL32
VSS
AL1
VSS
AK28
VSS
AK26
VSS
AK24
VSS
AK22
VSS
AK20
VSS
AK18
VSS
AK16
VSS
AK14
VSS
AK12
VSS
AK10
VSS
AK8
VSS
AK3
VSS
AJ35
VSS
AJ32
VSS
AJ9
VSS
AJ4
VSS
AJ1
VSS
AH33
VSS
AH30
VSS
AH24
VSS
AH22
VSS
AH20
VSS
AH18
VSS
AH16
VSS
AH14
VSS
AH12
VSS
AH10
VSS
AH6
VSS
AH3
VSS
AG35
VSS
AG32
VSS
AG28
VSS
AG26
VSS
AG24
VSS
AG22
VSS
AG20
VSS
AG18
VSS
AG16
VSS
AG14
VSS
AG8
VSS
AG4
VSS
AF33
VSS
AF30
VSS
AF25
VSS
AF24
VSS
AF22
VSS
AF20
VSS
AF18
VSS
AF16
VSS
AF14
VSS
AF11
VSS
AF9
VSS
AF6
VSS
AF3
VSS
AE35
VSS
AE32
VSS
AE26
VSS
AE25
VSS
AE13
VSS
AE12
VSS
SPDGV MCH
2
AE11
VSS
AE10
VSS
AE4
VSS
AE1
VSS
AD33
VSS
AD30
VSS
AD28
VSS
AD10
VSS
AD9
VSS
AD8
VSS
AD6
VSS
AD3
VSS
AC35
VSS
AC32
VSS
AC4
VSS
AC1
VSS
AB33
VSS
AB30
VSS
AB28
VSS
AB27
VSS
AB26
VSS
AB10
VSS
AB9
VSS
AB8
VSS
AB6
VSS
AB3
VSS
AA32
VSS
AA4
VSS
AA1
VSS
Y35
VSS
Y33
VSS
Y30
VSS
Y28
VSS
Y27
VSS
Y26
VSS
Y10
VSS
Y9
VSS
Y8
VSS
Y6
VSS
Y3
VSS
W32
VSS
W18
VSS
W17
VSS
W4
GND
VSS
V33
VSS
V30
VSS
V28
VSS
V27
VSS
V26
VSS
V19
VSS
V17
VSS
V10
VSS
V9
VSS
V8
VSS
V6
VSS
V3
VSS
U32
VSS
U19
VSS
U18
VSS
U4
VSS
T35
VSS
T33
VSS
T30
VSS
T28
VSS
T27
VSS
T26
VSS
T10
VSS
T9
VSS
T8
VSS
T6
VSS
T3
VSS
T1
VSS
R32
VSS
R4
VSS
R1
VSS
P33
VSS
P30
VSS
P28
VSS
P27
VSS
P26
VSS
P9
VSS
P8
VSS
P6
VSS
P3
VSS
N35
VSS
N32
VSS
N4
VSS
N1
VSS
M33
VSS
M30
VSS
M28
VSS
M27
VSS
M26
VSS
M6
VSS
M3
VSS
L35
VSS
Title
Size Document Number Rev
Custom
Date: Sheet
U1G
L31
L26
L25
L24
K33
K29
K27
K25
K22
K20
K18
K16
K14
K12
K11
J35
J32
J28
J22
J20
J18
J16
J14
J12
J10
H33
H30
H26
H24
H22
H20
H18
H16
H14
H12
H9
H8
H5
H2
G35
G31
G28
F26
F24
F22
F20
F18
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
SPDGV MCH
GND
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
SPRINGDALE PWR
XP-P5IM800GV 1.0
1
F16
F14
F12
F10
F8
F5
F3
F1
E3
E1
D35
D33
D31
D29
D27
D25
D23
D21
D19
D17
D15
D13
D11
D9
D1
C28
C26
C24
C22
C20
C18
C16
C14
C12
C10
C8
C4
A32
A29
A27
A25
A23
A20
A16
A13
A11
A9
A7
of
11 36
Page 12
8
7
DDR25V
6
5
4
3
2
1
130
125
122
141
118
115
103
113
157
158
163
107
119
129
149
159
169
177
140
154
111
137
138
181
182
183
184
101
102
173
167
48
43
41
37
32
29
27
59
52
71
97
63
65
21
16
17
76
75
5
14
25
36
56
67
78
86
47
91
92
1
82
9
10
A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
A13
BA0
BA1
BA2
CS0
CS1
NC/CS2
NC/CS3
DQM0
DQM1
DQM2
DQM3
DQM4
DQM5
DQM6
DQM7
DQM8
WE
CAS
RAS
CKE0
CKE1
CK0/DNU
CK0/DNU
CK1
CK1
CK2/DNU
CK2/DNU
DQS0
DQS1
DQS2
DQS3
DQS4
DQS5
DQS6
DQS7
DQS8
SDA
SCL
SA0
SA1
SA2
VREF
VDDID
VDDSPD
NC
NC
NC
NC
NC
NC/FETEN
7
15223054627796
VDDQ
D D
SBAA0[9]
SBAA1[9]
DMA[0..7][9]
C C
-SWEA[9]
-SCASA[9]
-SRASA[9]
CKEA0[9]
CKEA1[9]
DCLKA1[9]
-DCLKA1[9]
DCLKA0[9]
-DCLKA0[9]
DCLKA2[9]
-DCLKA2[9]
DQSA[0..7][9]
B B
SMBDATA[13,16,19,22]
SMBCLK[13,16,19,22]
-RESET_DDR[13]
DDR25V DDR25V
A A
R522
75/6/1
VREF_DDRA -RESET_DDR
R524
75/6/1
8
MAAA0
MAAA1
MAAA2
MAAA3
MAAA4
MAAA5
MAAA6
MAAA7
MAAA8
MAAA9
MAAA10
MAAA11
MAAA12
SBAA0
SBAA1
-CSA0
-CSA0[9]
-CSA1
-CSA1[9]
DMA0
DMA1
DMA2
DMA3
DMA4
DMA5
DMA6
DMA7
-SWEA
-SCASA
-SRASA
CKEA0
CKEA1
DCLKA1
-DCLKA1
DCLKA0
-DCLKA0
DCLKA2
-DCLKA2
DQSA0
DQSA1
DQSA2
DQSA3
DQSA4
DQSA5
DQSA6
DQSA7
SMBDATA
SMBCLK
VREF_DDRA
DDR25V
104
112
128
136
143
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
GND
GND
GND
GND
GND
GND
GND
GND
3111826344250586674818993
156
164
172
VDDQ
VDDQ
GND
GND
VDDQ
GND
VDDQ
GND
180738467085108
VDDQ
GND
GND
100
120
148
168
DDR1
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
D0
D1
D2
D3
D4
D5
D6
D7
D8
D9
D10
D11
D12
D13
D14
D15
D16
D17
D18
D19
D20
D21
D22
D23
D24
D25
D26
D27
D28
D29
D30
D31
D32
D33
D34
D35
D36
D37
D38
D39
D40
D41
D42
D43
D44
D45
D46
D47
D48
D49
D50
D51
D52
D53
D54
D55
D56
D57
D58
D59
D60
D61
D62
D63
CB0
CB1
CB2
CB3
CB4
CB5
CB6
CB7
GND
GND
GND
116
124
132
WP
GND
GND
GND
GND
GND
DDR/GF/BLACK/[11SM1-510184-59/58/55/5A]
139
145
152
160
176
For Register DDR Support
6
MDA0
2
MDA1
4
MDA2
6
MDA3
8
MDA4
94
MDA5
95
MDA6
98
MDA7
99
MDA8
12
MDA9
13
MDA10
19
MDA11
20
MDA12
105
MDA13
106
MDA14
109
MDA15
110
MDA16
23
MDA17
24
MDA18
28
MDA19
31
MDA20
114
MDA21
117
MDA22
121
MDA23
123
MDA24
33
MDA25
35
MDA26
39
MDA27
40
MDA28
126
MDA29
127
MDA30
131
MDA31
133
MDA32
53
MDA33
55
MDA34
57
MDA35
60
MDA36
146
MDA37
147
MDA38
150
MDA39
151
MDA40
61
MDA41
64
MDA42
68
MDA43
69
MDA44
153
MDA45
155
MDA46
161
MDA47
162
MDA48
72
MDA49
73
MDA50
79
MDA51
80
MDA52
165
MDA53
166
MDA54
170
MDA55
171
MDA56
83
MDA57
84
MDA58
87
MDA59
88
MDA60
174
MDA61
175
MDA62
178
MDA63
179
44
45
49
51
134
135
142
144
90
R523
8.2K/6
5
MDA[0..63] [9]MAAA[0..12][9]
-RESET_DDR [13]
REV1.0
改
0603-->0.1U,
不可用
0402,
會漏電
DDR25V
Decouple
DDR25V
BC568
0.1U/6/Y/25V
BC79
0.1U/6/Y/25V
BC81
0.1U/6/Y/25V
BC85
0.1U/6/Y/25V
BC87
0.1U/6/Y/25V
BC89
0.1U/6/Y/25V
BC91
0.1U/6/Y/25V
BC281
0.1U/6/Y/25V
GIGABYTE
Title
Size Document Number Rev
B
4
3
Date: Sheet
2
DDR1 CHANNEL A
XP-P5IM800GV 1.0
12 36
of
1
Page 13
8
7
6
5
4
3
2
1
DDR25V
D D
MAAB[0..12][9]
SBAB0[9]
SBAB1[9]
DMB[0..7][9]
C C
-SWEB[9]
-SCASB[9]
-SRASB[9]
CKEB0[9]
CKEB1[9]
DCLKB1[9]
-DCLKB1[9]
DCLKB0[9]
-DCLKB0[9]
DCLKB2[9]
-DCLKB2[9]
DQSB[0..7][9]
B B
SMBDATA[12,16,19,22]
SMBCLK[12,16,19,22]
DDR25V
C207
0.1U/6/Y/25V
DDR25V
-RESET_DDR[12]
MAAB0
MAAB1
MAAB2
MAAB3
MAAB4
MAAB5
MAAB6
MAAB7
MAAB8
MAAB9
MAAB10
MAAB11
MAAB12
SBAB0
SBAB1
-CSB0
-CSB0[9]
-CSB1
-CSB1[9]
DMB0
DMB1
DMB2
DMB3
DMB4
DMB5
DMB6
DMB7
-SWEB
-SCASB
-SRASB
CKEB0
CKEB1
DCLKB1
-DCLKB1
DCLKB0
-DCLKB0
DCLKB2
-DCLKB2
DQSB0
DQSB1
DQSB2
DQSB3
DQSB4
DQSB5
DQSB6
DQSB7
SMBDATA
SMBCLK
VREF_DDRB
130
125
122
141
118
115
103
113
157
158
163
107
119
129
149
159
169
177
140
154
111
137
138
181
182
183
184
101
102
173
167
48
43
41
37
32
29
27
59
52
71
97
63
65
21
16
17
76
75
5
14
25
36
56
67
78
86
47
91
92
1
82
9
10
VDDQ
A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
A13
BA0
BA1
BA2
CS0
CS1
NC/CS2
NC/CS3
DQM0
DQM1
DQM2
DQM3
DQM4
DQM5
DQM6
DQM7
DQM8
WE
CAS
RAS
CKE0
CKE1
CK0/DNU
CK0/DNU
CK1
CK1
CK2/DNU
CK2/DNU
DQS0
DQS1
DQS2
DQS3
DQS4
DQS5
DQS6
DQS7
DQS8
SDA
SCL
SA0
SA1
SA2
VREF
VDDID
VDDSPD
NC
NC
NC
NC
NC
NC/FETEN
15223054627796
104
112
128
136
143
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
GND
GND
GND
GND
GND
GND
GND
GND
3111826344250586674818993
156
VDDQ
VDDQ
GND
GND
164
VDDQ
GND
172
VDDQ
GND
180738467085108
VDD
VDD
VDD
VDD
VDDQ
GND
VDD
GND
GND
GND
GND
GND
GND
100
116
124
132
139
145
120
148
168
DDR2
VDD
VDD
VDD
VDD
D0
D1
D2
D3
D4
D5
D6
D7
D8
D9
D10
D11
D12
D13
D14
D15
D16
D17
D18
D19
D20
D21
D22
D23
D24
D25
D26
D27
D28
D29
D30
D31
D32
D33
D34
D35
D36
D37
D38
D39
D40
D41
D42
D43
D44
D45
D46
D47
D48
D49
D50
D51
D52
D53
D54
D55
D56
D57
D58
D59
D60
D61
D62
D63
CB0
CB1
CB2
CB3
CB4
CB5
CB6
CB7
WP
GND
GND
GND
DDR/GF/BLACK/[11SM1-510184-59/58/55/5A]
152
160
176
MDB0
2
MDB1
4
MDB2
6
MDB3
8
MDB4
94
MDB5
95
MDB6
98
MDB7
99
MDB8
12
MDB9
13
MDB10
19
MDB11
20
MDB12
105
MDB13
106
MDB14
109
MDB15
110
MDB16
23
MDB17
24
MDB18
28
MDB19
31
MDB20
114
MDB21
117
MDB22
121
MDB23
123
MDB24
33
MDB25
35
MDB26
39
MDB27
40
MDB28
126
MDB29
127
MDB30
131
MDB31
133
MDB32
53
MDB33
55
MDB34
57
MDB35
60
MDB36
146
MDB37
147
MDB38
150
MDB39
151
MDB40
61
MDB41
64
MDB42
68
MDB43
69
MDB44
153
MDB45
155
MDB46
161
MDB47
162
MDB48
72
MDB49
73
MDB50
79
MDB51
80
MDB52
165
MDB53
166
MDB54
170
MDB55
171
MDB56
83
MDB57
84
MDB58
87
MDB59
88
MDB60
174
MDB61
175
MDB62
178
MDB63
179
44
45
49
51
134
135
142
144
90
MDB[0..63] [9]
DDR25V
A A
1 2
1 2
R525
75/6/1
R526
75/6/1
VREF_DDRB
8
7
6
5
4
3
GIGABYTE
Title
Size Document Number Rev
B
Date: Sheet
2
DDR3,4 CHANNEL B
XP-P5IM800GV 1.0
13 36
of
1
Page 14
8
7
6
5
4
3
2
1
A_D[0:31][15,20,21,34]
D D
AGUPCLK=33MHZ
C C
B B
+12V VCC
BC327
0.1U/6/Y/25V/X
VCC3
Place at each pair of 3.3V pins
BC334
+
EC119
1000U/D/6.3V/8C/[11CL1-8E1001-14/11/13]
0.1U/6/Y/25V/X
VDDQ
A A
+
EC79
1000U/D/6.3V/8C/[11CL1-8E1001-14/11/13]
A_D[0:31]
-PIRQB[15]
AGUPCLK[19]
-REQ4[15,20]
3VDUAL
-C_BE2[15,20,21,34]
-IRDY[15,20,21,34]
-DEVSEL[15,20,21,34]
-PERR[15,20,21,34]
-SERR[15,20,21,34]
-C_BE1[15,20,21,34]
BC328
0.1U/6/Y/25V/X
VCC3
VCC3
-PIRQB
AGUPCLK
-REQ4
A_D31
A_D29
A_D27
A_D25
A_D23
A_D21
A_D19
A_D17
-C_BE2
-IRDY
-DEVSEL
-PERR
-SERR
-C_BE1
A_D14
A_D12
A_D10
A_D8
A_D7
A_D5
A_D3
A_D1
VREF_CG
BC330
0.1U/6/Y/25V
3VDUAL
BC522
0.1U/6/Y/25V/X
(Place near AGP slot)
VCC
B1
B2
B3
B4
B5
B6
B7
B8
B9
B10
B11
B12
B13
B14
B15
B16
B17
B18
B19
B20
B21
B22
B23
B24
B25
B26
B27
B28
B29
B30
B31
B32
B33
B34
B35
B36
B37
B38
B39
B40
B41
B46
B47
B48
B49
B50
B51
B52
B53
B54
B55
B56
B57
B58
B59
B60
B61
B62
B63
B64
B65
B66
-REQ4/-GNT4/IDSEL=A_D16(
AGU
OVRCNT#
5V
5V
USB+
GND
INTB#
CLK
REQ#
VCC3.3
ST0
ST2
RBF#
GND
RESV
SBA0
VCC3.3
SBA2
SB_STB
GND
SBA4
SBA6
RESV
GND
3VSB
VCC3.3
AD31
AD29
VCC3.3
AD27
AD25
GND
AD_STB1
AD23
VDDQ3.3
AD21
AD19
GND
AD17
C/BE2#
VDDQ3.3
IRDY#
DEVSEL#
VDDQ3.3
PERR#
GND
SERR#
C/BE1#
VDDQ3.3
AD14
AD12
GND
AD10
AD8
VDDQ3.3
AD_STB0
AD7
GND
AD5
AD3
VDDQ3.3
AD1
VREF_CG
AGP SLOT/GIGABYTE 8X/PURPLE\[11AC1-05R124-81]
TYPEDET#
RESV
INTA#
RST#
GNT#
VCC3.3
RESV
PIPE#
WBF#
SBA1
VCC3.3
SBA3
SB_STB#
SBA5
SBA7
RESV
RESV
VCC3.3
AD30
AD28
VCC3.3
AD26
AD24
AD_STB1#
GC/BE3#
VDDQ3.3
AD22
AD20
AD18
AD16
VDDQ3.3
FRAME#
TRDY#
STOP#
PME#
AD15
VDDQ3.3
AD13
AD11
C/BE0#
VDDQ3.3
AD_STB0
VDDQ3.3
VREF_GC
USBGND
GND
GND
GND
GND
GND
GND
PAR
GND
AD9
AD6
GND
AD4
AD2
AD0
VCC3
12V
ST1
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
A13
A14
A15
A16
A17
A18
A19
A20
A21
A22
A23
A24
A25
A26
A27
A28
A29
A30
A31
A32
A33
A34
A35
A36
A37
A38
A39
A40
A41
A46
A47
A48
A49
A50
A51
A52
A53
A54
A55
A56
A57
A58
A59
A60
A61
A62
A63
A64
A65
A66
內設
R1491
1K/6
VREF_CG
R1492
1K/6
)/-PIRQA/B
+12V
VCC3
VCC3
-PIRQA
-AGPRST
-GNT4
A_D30
A_D28
A_D26
A_D24
-C_BE3
A_D22
A_D20
A_D18
A_D16
-FRAME
-TRDY
-STOP
PAR
A_D15
A_D13
A_D11
A_D9
-C_BE0
A_D6
A_D4
A_D2
A_D0
-PIRQA [15,20,21]
-AGPRST [21]
-GNT4 [15]
C208
22P/4/N/50V/X
-C_BE3 [15,20,21,34]
-FRAME [15,20,21,34]
-TRDY [15,20,21,34]
-STOP [15,20,21,34]
PAR [15,20,21,34]
-C_BE0 [15,20,21,34]
A11-->FOR AGP CARD MB_DET(8X)
5VSB
R1132
8.2K/6/X
GSWING
C209
0.1U/6/Y/25V
MCH_AGPREF
C210
0.1U/6/Y/25V
-ATX_PS_ON
GSWING [10]
MCH_AGPREF [10]
-SLP_S3[16,19,32,33] -ATX_PS_ON [16,19,32,33]
VDDQ
R543
60.4/6/1
R546
39.2/6/1
R550
100/6/1
Place 1 at each pair of VDDQ pins
Place an additional for spread from A14 - A33
8
Title
Size Document Number Rev
Custom
7
6
5
4
3
Date: Sheet
2
GIGABYTE
AGU
XP-P5IM800GV
14 36Thursday, December 16, 2004
1
1.0
of
Page 15
8
7
6
5
4
3
2
1
VCC3
SERIRQ
GPI0
RN60 8.2K/8P4R
1 2
3 4
5 6
7 8
RN61 8.2K/8P4R
1 2
3 4
5 6
7 8
R556 8.2K/6
R557 8.2K/6/X
AC_SDIN0
AC_SDIN1
AC_SDIN2
R553 8.2K/6/X
R554 8.2K/6/X
R555 8.2K/6
-PIRQH
-PIRQD
-PIRQE
D D
-KBRST[16,22]
A20GATE[16,22]
SERIRQ[16,22]
-KBRST
-PIRQB
A20GATE
GPO16
A_D[0..31]
-FRAME[14,20,21,34]
-IRDY[14,20,21,34]
-TRDY[14,20,21,34]
-DEVSEL[14,20,21,34]
-STOP[14,20,21,34]
C C
-PCIRST[10,18,21,22,34]
PAR[14,20,21,34]
-PERR[14,20,21,34]
-PLOCK[20,21]
-SERR[14,20,21,34]
-PCIPME[20,21,34]
C211 100P/4/N/50V
ICH33[19]
-PIRQA[14,20,21]
-PIRQB[14]
-PIRQC[20,21]
-PIRQE[34]
-PIRQF[20,21]
-PIRQG[20,21]
-REQ0[20]
-REQ1[20]
-REQ2[20,21]
-REQ3[20]
-REQ4[14,20]
-REQ5[20,34]
-GNT0[20]
-GNT1[20]
B B
TP9
-GNT2[21]
-GNT4[14]
-GNT5[34]
-FRAME
-IRDY
-TRDY
-DEVSEL
-STOP
PAR
-PERR
-PLOCK
-SERR
-PCIPME
R558 22/6
ICH33
-PIRQA
-PIRQB
-PIRQC
-PIRQD
-PIRQF
-PIRQG
-PIRQH
-REQ0
-REQ1
-REQ2
-REQ3
-REQ4
GPI0
-REQ5
-GNT0
-GNT1
-GNT2
-GNT3
-GNT4
GPO16
-GNT5
U5A
D2
FRAME#
M3
IRDY#
E4
TRDY#
L3
DEVSEL#
E5
STOP#
F1
PAR
K2
PERR#
L2
PLOCK#
L4
SERR#
V2
PME#
V4
PCIRST#
N1
PCICLK
B3
PIRQA#
E1
PIRQB#
A2
PIRQC#
C2
PIRQD#
D7
PIRQE#/GPI2
A6
PIRQF#/GPI3
E2
PIRQG#/GPI4
B1
PIRQH#/GPI5
D5
REQ0#
C1
REQ1#
C5
REQ2#
B6
REQ3#
C6
REQ4#/GPI40
A5
REQA#/GPI0
E7
REQB#REQ5#/GPI1
D4
GNT0#
A3
GNT1#
B7
GNT2#
C7
GNT3#
A4
GNT4#/GPO48
E8
GNTA#/GPO16
B4
GNTB#/GNT5#/GPO17
SPDG ICH5/A3
A_D[0..31] [14,20,21,34]
P2
AD31
F4
AD30
P4
AD29
F5
AD28
N2
AD27
D3
AD26
P3
AD25
E6
AD24
N4
AD23
C4
AD22
N5
AD21
H3
AD20
P5
AD19
B2
AD18
L1
AD17
G4
AD16
G5
AD15
K1
AD14
G2
AD13
L5
AD12
H4
AD11
M4
AD10
F2
AD9
K5
AD8
J2
AD7
J3
AD6
H2
AD5
H5
AD4
K4
AD3
G3
AD2
J5
AD1
J4
AD0
M2
C/BE3#
N3
C/BE2#
J1
C/BE1#
E3
C/BE0#
A_D31
A_D30
A_D29
A_D28
A_D27
A_D26
A_D25
A_D24
A_D23
A_D22
A_D21
A_D20
A_D19
A_D18
A_D17
A_D16
A_D15
A_D14-PIRQE
A_D13
A_D12
A_D11
A_D10
A_D9
A_D8
A_D7
A_D6
A_D5
A_D4
A_D3
A_D2
A_D1
A_D0
-C_BE3
-C_BE2
-C_BE1 -AC_RST
-C_BE0
-C_BE3 [14,20,21,34]
-C_BE2 [14,20,21,34]
-C_BE1 [14,20,21,34]
-C_BE0 [14,20,21,34]
Follow Intel Layout
+USBP0[26]
-USBP0[26]
+USBP1[26]
-USBP1[26]
+USBP2[26]
-USBP2[26]
+USBP3[26]
-USBP3[26]
+USBP4[34]
-USBP4[34]
+USBP5[34]
-USBP5[34]
-USBOC[34]
-USBOC1[26]
Less than 500mils
from ICH5
-USBOC
-USBOC1
USBCLK[19]
+USBP0
-USBP0
+USBP1
-USBP1
+USBP2
-USBP2
+USBP3
-USBP3
+USBP4
-USBP4
+USBP5
-USBP5
R561
22.6/6/1
USBCLK
C368
10P/4/N/50V/X
C23
D23
A22
B22
C21
D21
A20
B20
C19
D19
A18
B18
C17
D17
A16
B16
C15
D15
D14
C14
B14
A14
D13
C13
A24
B24
F24
U5B
USBP0P
USBP0N
USBP1P
USBP1N
USBP2P
USBP2N
USBP3P
USBP3N
USBP4P
USBP4N
USBP5P
USBP5N
USBP6P
USBP6N
USBP7P
USBP7N
OC0#
OC1#
OC2#
OC3#
OC4#/GPI9
OC5#/GPI10
OC6#/GPI14
OC7#/GPI15
USBRBIAS
USBRBIAS#
CLK48
HI10
HI11
HI_STBF
HI_STBS
HIRCOMP
HI_VSWING
HIREF
CLK66
LAN_RXD0
LAN_RXD1
LAN_RXD2
LAN_TXD0
LAN_TXD1
LAN_TXD2
LAN_RSTSYNC
LAN_CLK
LAN_RST#
EE_DIN
EE_CS
EE_SHCLK
EE_DOUT
AC_SYNC
AC_RST#
AC_SDOUT
AC_SDIN0
AC_SDIN1
AC_SDIN2
AC_BIT_CLK
HI0
HI1
HI2
HI3
HI4
HI5
HI6
HI7
HI8
HI9
H20
H21
J20
H23
M23
M21
N21
M20
L22
J22
K21
G22
K23
J24
N24
L20
L24
N22
C10
C9
C11
D9
E9
B12
D10
E10
AA1
B11
B10
A12
B9
B8
C12
A9
E12
D12
A13
D8
HL0
HL1
HL2
HL3
HL4
HL5
HL6
HL7
HL8
HL9
HL10
HL11
HLSTBF
HLSTBS
HLRCOMP_I
HL_SWING_ICH
HL_VREF_ICH
ICH3V66
R562 33/6
R563 33/6
AC_SDIN0
AC_SDIN1
AC_SDIN2
AC_BITCLK
HL[0..10]
HL[0..10] [10]
VDDQ
R559 61.9/6/1 R560
HLSTBF [10]
HLSTBS [10]
ICH3V66 [19]
-AC_RST [27]
AC_SDIN2 [27]
AC_BITCLK [27]
52.3/6/1
0.01U/4/Y/16V
AC_SYNC
AC_SDOUT
New Value
C212
AC_SYNC [27]
AC_SDOUT [27]
HL_SWING_ICH [10]
HL_VREF_ICH [10]
C213
0.01U/4/X/16V
Close to ICH5
SPDG ICH5/A3
A A
GIGABYTE
Title
Size Document Number Rev
B
8
7
6
5
4
3
Date: Sheet
ICH5 PCI, USB, HUB, LAN
2
XP-P5IM800GV 1.0
15 36
of
1
Page 16
8
3VDUAL
D23
BC343
1U/6/Y/10V
D D
C C
3VDUAL
VCC3
B B
BC344 10P/4/N/50V/X
RTCVDD INTRUDER
A A
12
GPI6[32]
GPI7[22]
-LPCPME[22]
GPO21[18]
GPO25[29]
GPO32[18]
-SATA_LED[29]
SMBCLK[12,13,19,22]
SMBDATA[12,13,19,22]
SMLINK0[20]
SMLINK1[20]
VCC3
SPKR[29]
-PWRBTSW[29]
SUSCLK[22]
-SUSTAT[22]
-SLP_S3[14,19,32,33]
-S4_S5[33]
R580 8.2K/6
R581 8.2K/6
CPUPWROK[6]
-THERM[6]
-THRMO[22]
ICHCLK14[19]
R590 1M/6
-SYS_RST[6,29]
VRMGD[31]
8
R573 1K/6
BAT
BAT SOCKET(high)
R577 1K/6/X
-RI[29]
R579 0/6/X
-SYS_RST
SATA0TXP
SATA0TXN
SATA0RXN
SATA0RXP
2
1
BAT54C/SOT23
BATTERY
CR2032
CR2032/[11BL1-032032-06/03/02]
GPI6
GPI7
GPI8
-SMBALRT
GPI12
-LPCPME
GPO20
GPO21
GPO22
GPO23
GPO24
GPO25
GPO27
GPO28
GPO32
-SATA_LED
SMBCLK
SMBDATA
SMLINK0
SMLINK1
LINK_ALT
SPKR
-RI
-PWRBTSW
SUSCLK
-BATLOW
-SUSTAT
-SLP_S3
-S4_S5
-SYS_RST
VRMGD
CPUPWROK
-THERM
-THRMO
INTVRMEN
ICHCLK14
VRMGD
AD10
1
2
3
4
5
6
7
SATA/1*7/HOUSING/BLACK/G-FL
+
R5
U3
AC3
W4
W5
U21
T20
U22
R1
U20
F22
AC1
W3
W2
G23
F21
AD2
AD1
AD3
AA2
E24
AB3
AB2
AB1
W1
U2
AA3
U1
R20
P24
T21
F20
Y12
A11
SATA0
3
U5D
AGPBUSY#/GPI6
GPI7
Y2
GPI8
SMBALERT#/GPI11
GPI12
GPI13
STP_PCI#/GPO18
SLP_S1#/GPO19
STP_CPU#/GPO20
C3_STAT#/GPO21
CPUPERF#/GPO22
SSMUXSEL/GPO23
CLKRUN#/GPIO24
GPIO25
V3
GPIO27
GPIO28
T1
GPIO32
GPIO33
GPIO34
SMBCLK
SMBDATA
SMLINK0
SMLINK1
V5
LINKALERT#
SPKR
RI#
Y4
PWRBTN#
Y1
SUSCLK
BATLOW#
SUS_STAT#
SLP_S3#
SLP_S4#
SLP_S5#
SYS_RESET#
VGATE/VRMPWRGD
CPUPWRGD/GPO49
THRMTRIP#
T2
THRM#
INTVRMEN
CLK14
INTRUDER#
NC
SPDG ICH5/A3
GND
A+
AGND
BB+
GND
7
R566 390K/6
REV1.0
R572 20K/6
C216
1U/6/Y/10V/X
SATARBIASP
SATARBIASN
LDRQ1#/GPI41
PWROK[8,21]
7
A20GATE
A20M#
CPUSLP#
FERR#
IGNNE#
INIT#
INTR
NMI
RCIN#
SERIRQ
SMI#
STPCLK#
DPRSLPVR
DPSLP#
SATA0TXP
SATA0TXN
SATA0RXN
SATA0RXP
SATA1TXP
SATA1TXN
SATA1RXN
SATA1RXP
CLK100P
CLK100N
LAD0
LAD1
LAD2
LAD3
LFRAME#
LDRQ0#
RTCX1
RTCX2
RTCRST#
RSMRST#
PWROK
RTCVDD
INTVRMEN
T22
V23
P22
U24
R21
R23
U23
R22
P23
F23
V24
T24
P20
R24
AA8
AB8
AD7
AC7
AA10
AB10
AD9
AC9
Y11
Y9
AC5
AD5
T5
R4
R3
U4
T4
U5
R2
AC11
AB12
AA12
AB13
AC12
PWROK
SATA1TXP
SATA1TXN
SATA1RXN
SATA1RXP
6
RTCVDD [17]
-RTCRST
A20GATE
-A20M
-CPUSLP
-FERR
-IGNNE
-HINIT
INTR
NMI
-KBRST
SERIRQ
-SMI
-STPCLK
SATA0TXP
SATA0TXN
SATA0RXN
SATA0RXP
SATA1TXP
SATA1TXN
SATA1RXN
SATA1RXP
R578 24.9/6/1
SRCCLK
-SRCCLK
LAD0
LAD1
LAD2
LAD3
-LFRAME
-LDRQ0
R585 8.2K/6/X
-RTCRST
-RSMRST
A20GATE [15,22]
-A20M [6]
-CPUSLP [6]
-FERR [6]
-IGNNE [6]
-HINIT [4,18]
INTR [6]
NMI [6]
-KBRST [15,22]
SERIRQ [15,22]
-SMI [6]
-STPCLK [6]
SRCCLK [19]
-SRCCLK [19]
LAD0 [18,22]
LAD1 [18,22]
LAD2 [18,22]
LAD3 [18,22]
-LFRAME [18,22]
-LDRQ0 [22]
-RSMRST [33]
SATA1
1
GND
2
A+
3
A-
4
GND
5
B-
6
B+
7
GND
SATA/1*7/HOUSING/BLACK/G-FL
6
C214
1U/6/Y/10V
Trace less than
500 mils
VCC3
R588 10M/6
C407
1000P/4/X/50V
SHORT WIRE BRASS/0.64*5.08*6.74mm
34
C218
18P/4/N/50V
X1-SHT
5
X1
32.768KHZ/XTAL CYL [KDS]
C219
18P/4/N/50V
GPO23
VCC3
BC347
0.1U/6/Y/25V/X
5
CLR_CMOS
1
2
3
H1X2(INSERT 1-2)
R1148 330/6
PDA[0..2][23]
BC571
1U/6/Y/10V/X
4
CLR_CMOS:
SHORT
OPEN
PDD[0..15] PDD15
-PDIOW[23]
-PDDACK[23]
PDDREQ[23]
-PDIOR[23]
PIORDY[23]
-PCS3[23]
-PCS1[23]
IRQ14[23] IRQ15 [23]
132
BC561
1U/6/Y/10V
SMLINK0
SMLINK1
4
PDD14
PDD13
PDD12
PDD11
PDD10
PDD9
PDD8
PDD7
PDD6
PDD5
PDD4
PDD3
PDD2
PDD1
PDD0
-PDIOW
-PDDACK
PDDREQ
-PDIOR
PIORDY
PDA2PDA[0..2]
PDA1
PDA0
-PCS3
-PCS1
IRQ14
GPO20
GPO22
GPI6
-THRMO
GPO23
GPI7
-RSMRST
PWROK
PWROK
PWOK
Q192
MMBT2222A/SOT23
R604 0/6/X
R605 0/6/X
CLEAR CMOS
NORMAL
R1464 8.2K/6/X
R583 1K/6
R586 8.2K/6/X
R587 8.2K/6
R1022 8.2K/6/X
R591 8.2K/6
R602 220K/6
R603 22K/6
C220 10P/4/N/50V/X
3
U5C
AB17
PDD15
AA16
PDD14
Y16
PDD13
AC16
PDD12
AA15
PDD11
AD16
PDD10
Y15
PDD9
AD15
PDD8
AB14
PDD7
AD14
PDD6
AC15
PDD5
AA14
PDD4
AC14
PDD3
Y14
PDD2
Y13
PDD1
AB16
PDD0
AA17
PDIOW#
AC18
PDDACK#
AC17
PDDREQ
AD18
PDIOR#
AA18
PIORDY
AC19
PDA2
AD19
PDA1
AA19
PDA0
Y18
PDCS3#
AB19
PDCS1#
Y17
IRQ14
SPDG ICH5/A3
PWOK [21,32,33]
GPI12
SMBCLK
SMBDATA
3
1-2
SDD15
SDD14
SDD13
SDD12
SDD11
SDD10
SDD9
SDD8
SDD7
SDD6
SDD5
SDD4
SDD3
SDD2
SDD1
SDD0
SDIOW#
SDDACK#
SDDREQ
SDIOR#
SIORDY
SDA2
SDA1
SDA0
SDCS3#
SDCS1#
IRQ15
VCC3
3VDUAL
SDD15
AA23
SDD14
AB24
SDD13
AC24
SDD12
AB22
SDD11
AA20
SDD10
AC22
SDD9
AD22
SDD8
Y19
SDD7
AC20
SDD6
AB20
SDD5
AC21
SDD4
AB21
SDD3
AD24
SDD2
AD23
SDD1
AB23
SDD0
AA22
-SDIOW
Y22
-SDDACK
W20
SDDREQ
Y20
-SDIOR
Y23
SIORDY
Y21
SDA2
W21
SDA1
W23
SDA0
W22
-SCS3
V20
-SCS1
V22
IRQ15
Y24
R1055
8.2K/6/X
R1056
8.2K/6
GIGABYTE
Title
Size Document Number Rev
Custom
Date: Sheet
2
SDD[0..15]
SDA[0..2]
LINK_ALT
SMBDATA
SMLINK1
SMLINK0
GPI8
-BATLOW
-RI
SUSCLK
-SLP_S3
-S4_S5
GPO24
GPO27
GPO28
GPO25
-SUSTAT
-LPCPME
SMBCLK
-SMBALRT
SDD[0..15] [23]PDD[0..15][23]
-SDIOW [23]
-SDDACK [23]
SDDREQ [23]
-SDIOR [23]
SIORDY [23]
SDA[0..2] [23]
-SCS3 [23]
-SCS1 [23]
RN66 8.2K/8P4R
RN67 8.2K/8P4R
R596 8.2K/6/X
R597 8.2K/6/X
RN68 8.2K/8P4R/X
RN105 8.2K/8P4R
ICH5 IDE, GPIO, SATA, CTRL
XP-P5IM800GV 1.0
2
12
34
56
78
12
34
56
78
12
34
56
78
12
34
56
78
1
3VDUAL
16 36
of
1
Page 17
8
7
6
5
4
3
2
1
VCC3
D D
BC349
0.1U/6/Y/25V
BC350
0.1U/6/Y/25V
VCC3
B5
F6
G1
H6
K6
L6
M10
N10
P6
R13
V19
W15
W17
C C
3VDUAL
VCC3
VCC
R606
1K/6
D24 1N5817/S
BC368
1U/6/Y/10V
5VSB
BC377
0.1U/6/Y/25V
RTCVDD[16]
B B
RTCVDD
BC380
0.01U/4/X/16V/X
Close to ICH5
W24
AD13
AD20
G19
G21
E18
B15
E11
F10
F11
E13
E14
U6
V6
F16
F17
F18
K15
A8
W14
E16
AD11
BC381
0.047U/4/X/10V
BC609
0.047U/4/X/10V
U5E
VCC3_3
VCC3_3
VCC3_3
VCC3_3
VCC3_3
VCC3_3
VCC3_3
VCC3_3
VCC3_3
VCC3_3
VCC3_3
VCC3_3
VCC3_3
VCC3_3
VCC3_3
VCC3_3
VCC3_3
VCC3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
V5REF
V5REF
V5REF_SUS
VCCRTC
SPDG ICH5/A3
BC351
0.1U/6/Y/25V
VCCSATAPLL
VCCSATAPLL
VCCUSBPLL
VCCSUS1_5_A
VCCSUS1_5_B
VCCSUS1_5_B
VCCSUS1_5_B
VCCSUS1_5_C
VCCSUS1_5_C
3VDUAL VCORE VDDQ
VCORE
BC353
0.1U/6/Y/25V
VDDQ
Close to ICH5
BC354
0.1U/6/Y/25V
VDDQ
VCC3
BC355
0.1U/6/Y/25V
VCC3
3VDUAL
3VDUAL
BC356
0.01U/4/X/16V
BC359 0.1U/6/Y/25V/X
BC361 0.1U/6/Y/25V/X
BC366 0.1U/6/Y/25V/X
BC369 0.1U/6/Y/25V
BC375 0.1U/6/Y/25V
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
VCC1_5
V_CPU_IO
V_CPU_IO
V_CPU_IO
BC352
0.1U/6/Y/25V
K10
K12
K13
L19
P19
R10
R6
H24
J19
K19
M15
N15
N23
E15
F15
F14
W19
R12
W9
W10
W11
W6
W7
W8
E22
AA6
AB6
C24
BC374 0.1U/6/Y/25V
F19
Y5
BC376 0.1U/6/Y/25V
AA4
AB4
BC379 0.1U/6/Y/25V BC378 0.1U/6/Y/25V
F7
F8
R15
R19
T19
BC357
0.1U/6/Y/25V
A1
A7
A10
A15
A17
A19
A21
A23
AA5
AA7
AA9
AA11
AA13
AA21
AA24
AB5
AB7
AB9
AB11
AB15
AB18
AC2
AC4
AC6
AC8
AC10
AC13
AC23
AD4
AD6
AD8
AD17
AD21
AD12
B13
B17
B19
B21
B23
C3
C8
C16
C18
C20
C22
D1
D6
D11
D16
D18
D20
D22
D24
E17
E19
E20
E21
E23
F3
F9
U5F
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
SPDG ICH5/A3
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
G6
G20
G24
H1
H19
H22
J6
J21
J23
K3
K11
K14
K20
K22
K24
L10
L11
L12
L13
L14
L15
L21
L23
M1
M5
M11
M12
M13
M14
M22
M24
N11
N12
N13
N14
N20
P1
P10
P11
P12
P13
P14
P15
P21
R11
R14
T23
T3
T6
U19
V1
V21
W16
W18
Y3
Y6
Y7
Y8
Y10
BC362 0.1U/6/Y/25V
BC367 0.1U/6/Y/25V
BC372 0.1U/6/Y/25V
VCC3
VDDQ
VDDQ
VCC3
A A
GIGABYTE
Title
Size Document Number Rev
B
8
7
6
5
4
3
Date: Sheet
2
ICH5 VCC, GND
XP-P5IM800GV 1.0
17 36
of
1
Page 18
8
7
6
5
4
3
2
1
R1326 8.2K/6
GPO32
GPO32[16]
D D
FWP-
VCC3
R1327
8.2K/6
-MHINIT
VCORE
R1328
8.2K/6
-HINIT
-HINIT[4,16]
C C
BC655
0.1U/6/Y/25V
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
VCC3
VCC3
BC656
0.1U/6/Y/25V
RN129
78
56
34
12
8.2K/8P4R
B B
FGPI1
FGPI0
VCC3
GPO21[16]
S66DET [23]
R1331 8.2K/6/X
R1332
8.2K/6/X
P66DET [23]
VPP
-PCIRST
-PCIRST[10,15,21,22,34] FWH33 [19]
FGPI3
FGPI2
FWPTBLLOCK1
LAD0
LAD0[16,22]
LAD1
LAD1[16,22]
LAD2
LAD2[16,22]
U49
1
VPP
2
RST#
3
FGPI3
4
FGPI2
5
FGPI1
6
FPGI0
7
WP#
8
TBL#
9
ID3
10
ID2
11
ID1
12
ID0
13
FWH0
14
FWH1
15
FWH2
16 17
GND FWH3
49LF002A_2M
MAIN BIOS PLCC
VCC
CLK
FGPI4
IC(VIL)
GND
VCC
GND
VCC
INIT#
FWH4
RFU
RFU
RFU
RFU
RFU
Q215
MMBT2222A/SOT23
SOT23
132
FWH33
FGPI4
IC
-MHINIT
-LFRAME
LAD3
C476
10P/4/N/50V/X
R1329 8.2K/6
R1330 8.2K/6
-LFRAME [16,22]
LAD3 [16,22]
REV 1.0
ADD WINBOUD FWH SEC. SOURCE
U49-SKT
A A
8
7
6
5
BIOS
PLCC32P/SOCKET/SMD/X
4
GIGABYTE
Title
Size Document Number Rev
B
3
Date: Sheet
2
FWH
XP-P5IM800GV 1.0
18 36Thursday, December 16, 2004
of
1
Page 19
5
4
3
2
1
PCLK0
PCLK1
PCLK2
D D
C C
B B
VCORE
VCC3
FB5 30/8/S
BC386
0.1U/6/Y/25V
R658 220/6
1U/8/Y/25V
BC393
0.1U/6/Y/25V
VCC3
VCC3
R651
1K/6
132
FB8 30/8/S
BC671
0.1U/6/Y/25V/X
Q96
MMBT2222A/SOT23
SOT23
BC387
1U/6/Y/10V
BSEL0 Pull-up at another page.
BC519
1U/8/Y/25V/X
CKVDD
-SLP_S3[14,16,32,33]
C255
20P/4/N/50V
C256
20P/4/N/50V
BC394
0.1U/6/Y/25V
BC389
0.1U/6/Y/25V
BC520
0.1U/6/Y/25V
R650 8.2K/6
D27 1N4148/S
BC392
0.1U/6/Y/25V
BC390
0.1U/6/Y/25V
SMBDATA[12,13,16,22]
SMBCLK[12,13,16,22]
X2
14.318MHz/16p/20ppm/H/D
RTM363-205必須FIX
SRCCLK/SRCLKK# 100MHZ, , SATA
JITTER太大,
BC388
0.1U/6/Y/25V
BC391
4.7U/8/Y/10V
SMBDATA
SMBCLK
R661 475/6/1
無法偵測
RTM363-205
CKVDD
U11
3
VDDREF
10
VDDPCI
16
VDDPCI
24
VDD48
27
VDD3V66
34
VDD_SRC
40
VDDCPU
48
VDDCPU
6
GND
11
GND
17
GND
23
GND
28
GND
37
GND
43
GND
20
RST#/PD#
33
VTT_PWRGD#
32
SDATA
31
SCLK
4
X1
5
X2
46
I REF
47
GND
ICS952603
為固定 不可使用有展頻功能 會造成
ISSUE
有
SATA JITTER ISSUE-->REJECT
FS_A/REF1
FS_B/REF0
48MHz_DOT
48MHz_USB
3V66_0
3V66_1
3V66_2/MODE
3V66_3/VCH
FS_C/PCICLK_F0
FS_D/PCICLK_F1
FS_E/PCICLK_F2
PCICLK0
PCICLK1
PCICLK2
PCICLK3
PCICLK4
PCICLK5
CPUCLK0
CPUCLK0#
CPUCLK1
CPUCLK1#
CPUCLK2
CPUCLK2#
SRCCLK
SRCCLK#
FSA
1
FSB
2
MODE1
21
FS3
22
F_GMCH3V66
30
F_AGPCLK
29
MODE
26
FSF
25
FSC
7
FSD
8
FSE
9
MODE2
12
F_PCLK1
13
F_PCLK2
14
F_LAN33CLK LAN33CLK
15
F_AGUPCLK
18
19
CPUCLK_F
39
-CPUCLK_F
38
MCHCLK_F
42
-MCHCLK_F
41
45
44
SRCCLK_F
36
-SRCCLK_F
35
REV1.0
R1439 22/6
R641 22/6
R642 33/6
R643 33/6
R644 33/6
RN70 33/8P4R
1 2
3 4
5 6
7 8
RN103 33/8P4R
7 8
5 6
3 4
1 2
R653 33/6
R1041 33/6
R1440 33/6
R1442 33/6
R662 33/6
R663 33/6
1 2
3 4
5 6
7 8
RN72
33/8P4R
-MCHCLK
-CPUCLK
SRCCLK
-SRCCLK
For P/PE only
Un-POP R643
POP C254 --> 0 Ohm (0402)
LPC14CLK
ICHCLK14
AC97CLK
DOTCLK
USBCLK
GMCH3V66
ICH3V66
LPC33
ICH33
FWH33
PCLK0
PCLK1
PCLK2
AGUPCLK
MCHCLK
CPUCLK
LPC14CLK [22]
ICHCLK14 [16]
AC97CLK [27]
DOTCLK [10]
USBCLK [15]
GMCH3V66 [10]
ICH3V66 [15]
LPC33 [22]
ICH33 [15]
FWH33 [18]
PCLK0 [20]
PCLK1 [20]
PCLK2 [21]
LAN33CLK [34]
AGUPCLK [14]
MCHCLK [8]
-MCHCLK [8]
CPUCLK [6]
-CPUCLK [6]
SRCCLK [16]
-SRCCLK [16]
CPUCLK
-CPUCLK
MCHCLK
-MCHCLK
SRCCLK
-SRCCLK
GMCH3V66
ICH3V66
ICH33
FWH33
LPC33
LAN33CLK
AGUPCLK
USBCLK
DOTCLK
LPC14CLK
CPUCLK
-CPUCLK
MCHCLK
-MCHCLK
SRCCLK
-SRCCLK
SMBDATA
SMBCLK
C242 10P/4/N/50V/X
C243 10P/4/N/50V/X
C244 10P/4/N/50V/X
C234 10P/4/N/50V/X
C235 10P/4/N/50V/X
C236 10P/4/N/50V/X
C237 10P/4/N/50V/X
C240 10P/4/N/50V/X
C241 10P/4/N/50V/X
C245 10P/4/N/50V/X
C246 10P/4/N/50V/X
C248 10P/4/N/50V/X
C249 10P/4/N/50V/XBC518
C250 10P/4/N/50V/X
C908 10P/4/N/50V/X
C909 10P/4/N/50V/X
C253 10P/4/N/50V/X
C254 10P/4/N/50V/X
C907 10P/4/N/50V/X
R655 51.1/6/1
R656 51.1/6/1
R659 51.1/6/1
R660 51.1/6/1
R664 51.1/6/1
R665 51.1/6/1
C905 22P/4/N/50V
C906 22P/4/N/50V
CKVDD
FS_A[6,8]
FS_B[6,8]
R667 1K/6
R668 1K/6
R669 1K/6
R670 1K/6
FSA
FSB
CKVDD
ICS + CYPRESS CO-LAYOUT
MODE2
R1437 8.2K/6
MODE1
R1049 8.2K/6/X
FS3
R1029 8.2K/6/X
R1030 8.2K/6/X
R1031 8.2K/6/X
R1032 8.2K/6 R1033 8.2K/6/X
R1034 8.2K/6/X
FSF
FSC
FSD
FSE
Close to Clock GEN
REV1.0
ICS952603/RTM363-205
A A
FS_E
1
1
1
1
FS_3
0
FS_C
0
FS_B
0
FS_A
000
01
0
0
0
5
1
1
0
0
Clock
100MHz
133MHz1
166MHz
200MHz
MODE
4
R671 8.2K/6/X
3
For Pin 20 PD#
MODE
2
Close to Clock GEN
GIGABYTE
Title
Size Document Number Rev
Custom
Date: Sheet
CLOCK GENERATOR
XP-P5IM800GV 1.0
19 36Thursday, December 16, 2004
1
of
Page 20
8
MODIFY PCI SHORT
ISSUE(10/05)
7
-12V +12VVCC3
VCC -12V VCC
6
5
4
3
2
1
VCC3 +12V
B10
B11
B12
B13
B14
B15
B16
B17
B18
B19
B20
B21
B22
B23
B24
B25
B26
B27
B28
B29
B30
B31
B32
B33
B34
B35
B36
B37
B38
B39
B40
B41
B42
B43
B44
B45
B46
B47
B48
B49
B52
B53
B54
B55
B56
B57
B58
B59
B60
B61
B62
B1
B2
B3
B4
B5
B6
B7
B8
B9
PCI2
-12V
TCK
GND
TDO
+5V
+5V
INTB
INTD
PRSNT1
RESERVED
PRSNT2
GND
GND
RESERVED
GND
CLK
GND
REQ
+5V
AD31
AD29
GND
AD27
AD25
+3.3V
C/BE3
AD23
GND
AD21
AD19
+3.3V
AD17
C/BE2
GND
IRDY
+3.3V
DEVSEL
GND
LOCK
PERR
+3.3V
SERR
+3.3V
C/BE1
AD14
GND
AD12
AD10
GND
AD8
AD7
+3.3V
AD5
AD3
GND
AD1
+5V
ACK64
+5V
+5V
PCI/CO/GF
TRST
+12V
TMS
+5V
INTA
INTC
+5V
RESERVED
+5V
RESERVED
GND
GND
3.3V_AUX
RST
+5V
GNT
GND
PME
AD30
+3.3V
AD28
AD26
GND
AD24
IDSEL
+3.3V
AD22
AD20
GND
AD18
AD16
+3.3V
FRAME
GND
TRDY
GND
STOP
+3.3V
SDONE
SBO
GND
PAR
AD15
+3.3V
AD13
AD11
GND
AD9
C/BE0
+3.3V
AD6
AD4
GND
AD2
AD0
+5V
REQ64
+5V
+5V
A1
A2
A3
A4
TDI
A5
A6
A7
A8
A9
A10
A11
A12
A13
A14
A15
A16
A17
A18
A19
A20
A21
A22
A23
A24
A25
A26
A27
A28
A29
A30
A31
A32
A33
A34
A35
A36
A37
A38
A39
A40
A41
A42
A43
A44
A45
A46
A47
A48
A49
A52
A53
A54
A55
A56
A57
A58
A59
A60
A61
A62
-PTRST
PTMS
-PIRQF
-PIRQA-PIRQG
-PCIRST1
-GNT1
A_D30
A_D28
A_D26
A_D24
A_D22
A_D20
A_D18
A_D16
-FRAME
-TRDY
-STOP
PCI_A40
PCI_A41
PAR
A_D15
A_D13
A_D11
A_D9
-C_BE0
A_D6
A_D4
A_D2
A_D0
-PCI2_REQ64
3VDUAL
-GNT1 [15]
A_D17
-FRAME [14,15,21,34]
-TRDY [14,15,21,34]
-STOP [14,15,21,34]
PCI_A40 [21]
PCI_A41 [21]
PAR [14,15,21,34]
-C_BE0 [14,15,21,34]
PCI1
B1
B10
B11
B12
B13
B14
B15
B16
B17
B18
B19
B20
B21
B22
B23
B24
B25
B26
B27
B28
B29
B30
B31
B32
B33
B34
B35
B36
B37
B38
B39
B40
B41
B42
B43
B44
B45
B46
B47
B48
B49
B52
B53
B54
B55
B56
B57
B58
B59
B60
B61
B62
B2
B3
B4
B5
B6
B7
B8
B9
-12V
TCK
GND
TDO
+5V
+5V
INTB
INTD
PRSNT1
RESERVED
PRSNT2
GND
GND
RESERVED
GND
CLK
GND
REQ
+5V
AD31
AD29
GND
AD27
AD25
+3.3V
C/BE3
AD23
GND
AD21
AD19
+3.3V
AD17
C/BE2
GND
IRDY
+3.3V
DEVSEL
GND
LOCK
PERR
+3.3V
SERR
+3.3V
C/BE1
AD14
GND
AD12
AD10
GND
AD8
AD7
+3.3V
AD5
AD3
GND
AD1
+5V
ACK64
+5V
+5V
PCI/CO/GF
RESERVED
RESERVED
PTCK
D D
-PIRQF[15,21]
-PIRQA
-PIRQA[14,15,21]
PCLK0[19]
-REQ0[15]
-C_BE3[14,15,21,34]
C C
-C_BE2[14,15,21,34]
-DEVSEL[14,15,21,34]
-PLOCK[15,21]
-PERR[14,15,21,34]
-SERR[14,15,21,34]
-C_BE1[14,15,21,34]
PCLK0
-REQ0
A_D31
A_D29
A_D27 A_D26
A_D25
-C_BE3 A_D19
A_D23
A_D21 A_D20
A_D19
A_D17 A_D16
-C_BE2
-IRDY
-IRDY[14,15,21,34]
-DEVSEL
-PLOCK
-PERR PCI_A40
-SERR
-C_BE1 A_D15
A_D14
A_D12 A_D11
A_D10
A_D8 -C_BE0
A_D7
A_D5 A_D4
A_D3
A_D1 A_D0
B B
ACK64[21]
ACK64
TRST
+12V
TMS
INTA
INTC
GND
GND
3.3V_AUX
RST
GNT
GND
PME
AD30
+3.3V
AD28
AD26
GND
AD24
IDSEL
+3.3V
AD22
AD20
GND
AD18
AD16
+3.3V
FRAME
GND
TRDY
GND
STOP
+3.3V
SDONE
SBO
GND
PAR
AD15
+3.3V
AD13
AD11
GND
AD9
C/BE0
+3.3V
AD6
AD4
GND
AD2
AD0
REQ64
+5V
+5V
+5V
+5V
+5V
+5V
+5V
A1
A2
A3
A4
TDI
A5
A6
A7
A8
A9
A10
A11
A12
A13
A14
A15
A16
A17
A18
A19
A20
A21
A22
A23
A24
A25
A26
A27
A28
A29
A30
A31
A32
A33
A34
A35
A36
A37
A38
A39
A40
A41
A42
A43
A44
A45
A46
A47
A48
A49
A52
A53
A54
A55
A56
A57
A58
A59
A60
A61
A62
-PTRST
PTMS
-PIRQC
-PIRQG-PIRQF
-PCIRST1
-GNT0
A_D30
A_D28
A_D24
A_D22
A_D18
-FRAME
-TRDY
-STOP
PCI_A41
PAR
A_D13
A_D9
A_D6
A_D2
-PCI1_REQ64
-PTRST
PTCK
PTCK[21]
PTMS
PTMS[21]
-PIRQC [15,21]
-PIRQG [15,21]
-PTRST[21]
3VDUAL
-GNT0 [15]
-PCIPME [15,21,34] -PCIPME [15,21,34]
-FRAME [14,15,21,34]
-TRDY [14,15,21,34]
-STOP [14,15,21,34]
PCI_A40 [21]
PCI_A41 [21]
PAR [14,15,21,34]
-C_BE0 [14,15,21,34]
RN131
1 2
3 4
5 6
7 8
8.2K/8P4R
VCC
PTCK
-PIRQC
PCLK1[19]
-REQ1[15]
-C_BE3[14,15,21,34]
-C_BE2[14,15,21,34]
-DEVSEL[14,15,21,34]
-PLOCK[15,21]
-PERR[14,15,21,34]
-SERR[14,15,21,34]
-C_BE1[14,15,21,34]
PCLK1
-REQ1
A_D31
A_D29
A_D27
A_D25
-C_BE3
A_D23
A_D21
A_D19
A_D17
-C_BE2
-IRDY
-IRDY[14,15,21,34]
-DEVSEL
-PLOCK
-PERR
-SERR
-C_BE1
A_D14
A_D12
A_D10
A_D8
A_D7
A_D5
A_D3
A_D1
ACK64[21]
ACK64
AD_19/-REQ0,-GNT0/-PIRQC,F,G,A AD_17/-REQ1,-GNT1/-PIRQF,G,A,C
C257
100P/4/N/50V/X
PCI_A40
PCI_A41
-PCIRST1 [21]
VCC3
-FRAME
-IRDY
-TRDY
-DEVSEL
RN74
1 2
3 4
5 6
7 8
8.2K/8P4R
BC401
0.1U/6/Y/25V
VCC3
1
+
EC102
VCC
0.1U/6/Y/25V
BC398
1000U/D/6.3V/8C/[11CL1-8E1001-14/11/13]/X
GIGABYTE
Title
Size Document Number Rev
B
Date: Sheet
2
PCI SLOT 1/2
XP-P5IM800GV 1.0
20 36Thursday, December 16, 2004
of
1
-PIRQF
RN76
1 2
3 4
5 6
7 8
8.2K/8P4R
VCC3
RN79
12
34
56
78
8.2K/8P4R
4
3
-REQ5
-REQ5[15,34]
-REQ3
-REQ3[15]
-REQ4
-REQ4[14,15]
-REQ2
-REQ2[15,21]
-REQ0
-REQ0[15]
-REQ1
-REQ1[15]
6
12
34
56
78
R676 2.2K/6
R678 2.2K/6
5
RN78 2.2K/8P4R
VCC
-STOP
-PLOCK
-PERR
-SERR
-PIRQG
-PIRQG[15,21]
-PIRQF[15,21]
-PIRQC
-PIRQC[15,21]
-PIRQA
-PIRQA[14,15,21]
A_D[0..31][14,15,21,34]
A A
VCC
A_D[0..31]
SMLINK0[16]
SMLINK1[16]
R675 0/6/X
R677 0/6/X
RN77
1 2
3 4
5 6
7 8
-PCI2_REQ64
-PCI3_REQ64
ACK64
-PCI1_REQ64
-PCI3_REQ64 [21]
2.2K/8P4R
VCC
R1441 2.2K/6
8
PAR
7
Page 21
8
7
6
5
4
3
2
1
A_D[0..31][14,15,20,34]
D D
C C
B B
A_D[0..31]
VCC3
BC403
0.1U/6/Y/25V
PCLK2[19]
-C_BE3[14,15,20,34]
-C_BE2[14,15,20,34]
-DEVSEL[14,15,20,34]
-PLOCK[15,20]
-PERR[14,15,20,34]
-SERR[14,15,20,34]
-C_BE1[14,15,20,34]
ACK64[20]
141312111098
I5O5I4O4I3
VCC
PTCK[20]
-PIRQA[14,15,20]
-PIRQF[15,20]
-REQ2[15,20]
-IRDY[14,15,20,34]
O3
PTCK
-PIRQF
PCLK2
-REQ2
A_D31
A_D29
A_D27
A_D25
-C_BE3
A_D23
A_D21
A_D19
A_D17
-C_BE2
-IRDY
-DEVSEL
-PLOCK
-PERR
-SERR
-C_BE1
A_D14
A_D12
A_D10
A_D8
A_D7
A_D5
A_D3
A_D1
ACK64
R684 330/6
U12
74HC14/S
B1
B2
B3
B4
B5
B6
B7
B8
B9
B10
B11
B12
B13
B14
B15
B16
B17
B18
B19
B20
B21
B22
B23
B24
B25
B26
B27
B28
B29
B30
B31
B32
B33
B34
B35
B36
B37
B38
B39
B40
B41
B42
B43
B44
B45
B46
B47
B48
B49
B52
B53
B54
B55
B56
B57
B58
B59
B60
B61
B62
AD_18/-REQ2,-GNT2/-PIRQG,A,C,F
PWOK [16,32,33]
PWROK [8,16]
-12V VCC
PCI3
-12V
TCK
GND
TDO
+5V
+5V
INTB
INTD
PRSNT1
RESERVED
PRSNT2
GND
GND
RESERVED
GND
CLK
GND
REQ
+5V
AD31
AD29
GND
AD27
AD25
+3.3V
C/BE3
AD23
GND
AD21
AD19
+3.3V
AD17
C/BE2
GND
IRDY
+3.3V
DEVSEL
GND
LOCK
PERR
+3.3V
SERR
+3.3V
C/BE1
AD14
GND
AD12
AD10
GND
AD8
AD7
+3.3V
AD5
AD3
GND
AD1
+5V
ACK64
+5V
+5V
PCI/CO/GF
VCC3 +12V
A1
TRST
A2
+12V
A3
TMS
A4
TDI
A5
+5V
A6
INTA
A7
INTC
A8
+5V
+5V
GND
GND
3.3V_AUX
RST
+5V
GNT
GND
PME
AD30
+3.3V
AD28
AD26
GND
AD24
IDSEL
+3.3V
AD22
AD20
GND
AD18
AD16
+3.3V
FRAME
GND
TRDY
GND
STOP
+3.3V
SDONE
SBO
GND
PAR
AD15
+3.3V
AD13
AD11
GND
AD9
C/BE0
+3.3V
AD6
AD4
GND
AD2
AD0
+5V
REQ64
+5V
+5V
A9
A10
A11
A12
A13
A14
A15
A16
A17
A18
A19
A20
A21
A22
A23
A24
A25
A26
A27
A28
A29
A30
A31
A32
A33
A34
A35
A36
A37
A38
A39
A40
A41
A42
A43
A44
A45
A46
A47
A48
A49
A52
A53
A54
A55
A56
A57
A58
A59
A60
A61
A62
RESERVED
RESERVED
-PTRST
PTMS
-PIRQG
-PIRQC-PIRQA
-PCIRST1
-GNT2
A_D30
A_D28
A_D26
A_D24
A_D22
A_D20
A_D18
A_D16
-FRAME
-TRDY
-STOP
PCI_A40
PCI_A41
PAR
A_D15
A_D13
A_D11
A_D9
-C_BE0
A_D6
A_D4
A_D2
A_D0
-PCI3_REQ64
-PTRST [20]
PTMS [20]
-PIRQG [15,20]
-PIRQC [15,20]
3VDUAL
-GNT2 [15]
-PCIPME [15,20,34]
A_D18
-FRAME [14,15,20,34]
-TRDY [14,15,20,34]
-STOP [14,15,20,34]
PCI_A40 [20]
PCI_A41 [20]
PAR [14,15,20,34]
-C_BE0 [14,15,20,34]
-PCI3_REQ64 [20]
A A
1234567
I0O0I1O1I2O2GND
C258
1000P/4/X/50V/X
-AGPRST [14]
TO AGU SLOT
-AGPRST
-PCIRST1
-PCIRST[10,15,18,22,34]
-PCIRST
IDERST
-PCIRST1 [20]
IDERST [23]
TO PCI SLOT
TO IDE SLOT
FROM ICH5
8
7
6
5
4
3
GIGABYTE
Title
Size Document Number Rev
B
Date: Sheet
2
PCI SLOT 3
XP-P5IM800GV 1.0
21 36Thursday, December 16, 2004
of
1
Page 22
5
SMBDATA[12,13,16,19]
SMBCLK[12,13,16,19]
VID0[6,31]
VID1[6,31]
VID2[6,31]
VID3[6,31]
+12V
VCC
VCC3
D D
REV1.0
VCC3
THERM_DP[6]
THERM_DN[6]
R1334
47K/6
R1335
47K/6
VCORE
VCC15IN
DDR25V
VCC3
R1443 47K/6
-THRMOO
SYSTEM_D+
SYSTEM_D-
R1444 47K/6/X
124
NC4 [D1-]
123
114
113
105
NC3 [D1+]
D0- (XNOR_IN)
4
120
119
118
117
116
115
D0+
+5V_IN
+2.5_IN
Vccp_IN
+3.3V_IN
NC2 [+1.5V_IN]
NC1 [+1.8V_IN]
Hardware Mon Blk
3
3VDUAL
R1467
D58
8.2K/6
C484
0.1U/6/Y/25V
-THRMOO
-THRMO[16]
3VDUAL
110
109
108
106
107
103
104
SDA
VID3
VID2
VID0
VID1
SCLK
+12V_IN/VID4
122
121
HVCC
11118936553
HVCC
HVCC
1N4148/S
VCC
C478
VCC
VCC
44
VREF
0.1U/6/Y/25V
VTR
VCC3 3VDUAL
VCC
VCC3
R1336 8.2K/6/X
R1337 8.2K/6
R1338 8.2K/6
THERM_DP
THERM_DNVCC15IN
LPCSMI-
-LDRQ0
LPCPWD-
C477
2.2N/6/X/50V
2
SYSTEM_D+
SYSTEM_D-
C479
2.2N/6/X/50V
132
Q216
MMBT2222A/SOT23
SOT23
C480
0.1U/6/Y/25V
C481
0.1U/6/Y/25V
VCC3
1
C482
0.1U/6/Y/25V
GND
C483
0.1U/6/Y/25V
DENSEL-[24]
INDEX-[24]
MOTEA-[24]
C C
-SUSTAT[16]
B B
A A
DRVB-[24]
DRVA-[24]
MOTEB-[24]
STEP-[24]
WDATA-[24]
WGATE-[24]
TK00-[24]
WPT-[24]
RDATA-[24]
SIDE1-[24]
DSKCHG-[24]
LAD0[16,18]
LAD1[16,18]
LAD2[16,18]
LAD3[16,18]
-LFRAME[16,18]
-LDRQ0[16]
-PCIRST[10,15,18,21,34]
R1466 0/6/X
LPC33[19]
SERIRQ[15,16]
-LPCPME[16]
GPI7[16]
SUSCLK[16]
LPC14CLK[19]
DIR-[24]
R1341 0/6
VID5[6,31]
VID4[6,31]
10P/4/N/50V/X
5
C491
10P/4/N/50V
SYSOP
C492
LPCPWD-
LPCSMI-
SUSCLK
1
GP40/DRVDEN0
2
GP41/DRVDEN1
13
INDEX~
3
MTR0~
42
GP21/P16/DS1~
5
DS0~
43
GP22/P12/MTR1~
8
DIR~
9
STEP~
10
WDATA~
11
WGATE~
14
TRK0~
15
WRTPRT~
16
RDATA~
12
HDSEL~
4
DSKCHG~
20
LAD0
21
LAD1
22
LAD2
23
LAD3
24
LFRAME~
25
LDRQ~
26
PCI_RESET~
27
LPCPD~
29
PCI_CLK
30
SER_IRQ
17
GP42/IO_PME~
50
GP27/IO_SMI~
28
GP43/DDRC
41
GP20/P17
45
GP24/SYSOP
6
CLKI32
19
CLOCKI
Joystick
GP10/J1B1
GP11/J1B2
GP12/J2B1
GP13/J2B2
GP14/J1X
32333435363738
A0/RESET~/THERM~ (XNOR_OUT)
Floppy Interface
LPC Interface
GP15/J1Y
GP16/J2X
GP17/J2Y
39
48
GP60/LED1
GP61/LED2
49
U51
LPC47M997
GP33/FAN1
GP32/FAN2
GP31/FAN_TACH1
GP30/FAN_TACH2
555452
51
4
8042 Keyboard/
Mouse
MDAT
KCLK
KDAT
56
MCLK
63
595857
GP37/A20M
GP36/KBDRST~
64
GP51/DCD2~
GP57/DTR2~
GP54/DSR2~
GP53/TXD2(IRTX)
Serial Port 2Parrel Port Interface
GP52/RXD2(IRRX)
Serial Port 1
STROBE~/DS0~
ALF~/DRVDEN0~
ERROR~/HDSEL~
BUSY/MTR1~
SLCT/WGATE~
PD4/DSKCHG~
PD3/RDATA~
PD2/WRTPRT~
SLCTIN~/STEP~
GP26/MIDI_OUT
GP25/MIDI_IN
GND
GND
GND
AGND
HGND HVCC
HGND
GND
7
316076
40
101 102
112
127
FANIO2
IRTX2/GP35
IRRX2/GP34
GP50/RI2~
GP56/CTS2~
GP55/RTS2~
DCD1~
RI1~
DTR1~
CTS1~
RTS1~
DSR1~
TXD1
RXD1
ACK~/DS1~
PE/WDATA~
PD7
PD6/MTR0~
PD5
PD1/TRK0~
PD0/INDEX~
INIT~/DIR~
NC6 [HGND]
NC5 [HGND]
HGND
HGND
126
125
128
62
61
94
92
100
99
98
97
96
95
91
90
89
88
87
86
85
84
83
82
81
80
79
78
77
75
74
73
72
71
70
69
68
67
66
47
46
A20GATE [15,16]
-KBRST [15,16]
MCLK [25]
MDAT [25]
KCLK [25]
KDAT [25]
FANPWM1 [30]
FANPWM2 [30]
FANIO1 [30]
DCD1RI1DTR1CTS1RTS1DSR1TXD1
RXD1
STBAFDERRACKBUSY
PE
SLCT
PD7
PD6
PD5
PD4
PD3
PD2
PD1
PD0
SLININIT-
3
DCD1- [24]
RI1- [24]
DTR1- [24]
CTS1- [24]
RTS1- [24]
DSR1- [24]
TXD1 [24]
RXD1 [24]
STB- [24]
AFD- [24]
ERR- [24]
ACK- [24]
BUSY [24]
PE [24]
SLCT [24]
PD7 [24]
PD6 [24]
PD5 [24]
PD4 [24]
PD3 [24]
PD2 [24]
PD1 [24]
PD0 [24]
SLIN- [24]
INIT- [24]
1000P/4/X/50V/X
C494
VCC3
213
CVS
SYS_FAN
FAN1x3/WHITE/PRO
SYSOP
R1344
8.2K/6/X
SYSOP
VCC3+12V
R1342
8.2K/6
C493
3.3N/4/X/50V/X
R1345
8.2K/6
R1343 1K/6
FANIO2
Configuration Register Base
Address Selection.
0x2E : SYSOP Pull down
0x4E : SYSOP Pull high
2
GIGABYTE
Title
Size Document Number Rev
Custom
Date: Sheet
ITE LPC I/O
XP-P5IM800GV 1.0
1
of
22 36Thursday, December 16, 2004
Page 23
8
7
6
5
4
3
2
1
VCC
-IDEACTS
-IDEACTP
D D
D56
2
1
SOT23
BAW56/SOT23
3
-HDLED
-HDLED [29]
IDERST[21]
R710 8.2K/6
Q98
2
3
1
MMBT2222A/SOT23
R707
1K/6
C373
1000P/4/X/50V/X
IDERST-
IDERST- -RST1
VCC
C C
B B
A A
PDD[0..15][16]
PDD[0..15]
R1346 33/6
R1348 1K/6
R1349 8.2K/6
R1352 8.2K/6
R1354 8.2K/6
R1356 470/6
PIORDY
IRQ14
PDD7 SDD7
PDDREQ SDDREQ
IDEPU0 IDEPU1
PRIMARY IDE CONNECTOR
-RST1
PDD7 PDD8
PDD6 PDD9
PDD5 PDD10
PDD4 PDD11
PDD3 PDD12
PDD2 PDD13
PDD1 PDD14
PDD0 PDD15
PDDREQ[16]
-PDIOW[16]
-PDIOR[16]
PIORDY[16]
-PDDACK[16]
IRQ14[16]
PDDREQ
-PDIOW
-PDIOR
PIORDY IDEPU0
-PDDACK
IRQ14
PDA1
PDA1[16]
PDA0 PDA2
PDA0[16]
-PCS1 -PCS3
-IDEACTP
REV1.0
IDE1
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
17 18
19
21 22
23 24
25 26
27 28
29 30
31 32
33 34
35 36
37 38
39 40
IDE/[11NH2-000220-13]
PDA2 [16]
-PCS3 [16]-PCS1[16]
C496
0.047U/6/Y/25V
IDERST- -RST2
VCC
R1347 33/6
R1350 1K/6
R1351 8.2K/6
R1353 8.2K/6
R1355 8.2K/6
R1357 470/6
SIORDY
IRQ15
SECONDARY IDE CONNECTOR
SDD[0..15][16]
SDD[0..15]
-RST2
SDD7
SDD6
SDD5
SDD4
SDD3
SDD2
SDD1
SDD0
SDDREQ[16]
-SDIOW[16]
-SDIOR[16]
SIORDY[16]
-SDDACK[16]
IRQ15[16]
-SCS1[16]
SDDREQ
-SDIOW
-SDIOR
SIORDY
-SDDACK
IRQ15
SDA1
SDA1[16]
SDA0
SDA0[16]
-SCS1
-IDEACTS
REV1.0
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
17 18
19
21 22
23 24
25 26
27 28
29 30
31 32
33 34
35 36
37 38
39 40
IDE/[11NH2-000220-13]
SDD8
SDD9
SDD10
SDD11
SDD12
SDD13
SDD14
SDD15
IDEPU1
SDA2
-SCS3
S66DET [18]
SDA2 [16]P66DET [18]
-SCS3 [16]
C495
0.047U/6/Y/25V
IDE2
BIOS:CABLE DETECT AND DEVICE DETECT
GIGABYTE
Title
Size Document Number Rev
B
8
7
6
5
4
3
Date: Sheet
2
IDE CONNECTOR
XP-P5IM800GV 1.0
23 36Thursday, December 16, 2004
1
of
Page 24
8
7
6
5
4
3
2
1
COMA
D D
C C
模組化線路
RI1-[22]
CTS1-[22]
DSR1-[22]
RTS1-[22]
DTR1-[22]
RXD1[22]
TXD1[22]
DCD1-[22]
-12V
ABC1
0.1U/6/Y/25V
AU
19
RY1
18
RY2
17
RY3
16
DA1
15
DA2
14
RY4
13
DA3
12
RY5
11
GND
10
-12V
RA1
RA2
RA3
DY1
DY2
RA4
DY3
RA5
12V
GD75232/SSOP
ACN1
COMA
1
6
2
7
3
8
4
9
5
COM/P
10
11
87
65
43
21
NRIANCTSANDSRANRTSA-
180P/8P4C/[10CN1-001800-11/10/17]
ACN2
87
65
43
21
NDCDA-
NRIA-
2
NCTSA-
3
NDSRA-
4
NRTSA-
5
NDTRA-
6
NSINA
7
NSOUTA
8
NDCDA-
9
20
5V
1
ABC2
0.1U/6/Y/25V
VCC
+12V
ABC3
0.1U/6/Y/25V
NRIA-[29]
NDSRANSINA
NRTSANSOUTA
NCTSANDTRANRIA-
NDTRANSINA
NSOUTA
NDCDA-
180P/8P4C/[10CN1-001800-11/10/17]
FLOPPY
FDD
1 2
3
7 8
9 10
11 12
13 14
15 16
17 18
19
21 22
23 24
25 26
27 28
29 30
31 32
33 34
FLOPPY/[11NH2-000217-21]
RN130
470/8P4R
VCC
R1358
470/6
1 2
3 4
5 6
7 8
4
6
20
DENSEL- [22]
INDEX- [22]
MOTEA- [22]
DRVB- [22]
DRVA- [22]
MOTEB- [22]
DIR- [22]
STEP- [22]
WDATA- [22]
WGATE- [22]
TK00- [22]
WPT- [22]
RDATA- [22]
SIDE1- [22]
DSKCHG- [22]
REV1.0
PRT PORT
PD[0..7][22]
PD[0..7]
LPT3
LPT4
LPT17
LPT5
LPT9
LPT8
ACK-
LPT1
LPT2
ERRLPT16
LPT7
BUSY
PE
SLCT
LPT14
VCC
PC1
0.1U/6/Y/25V
4
PCN1
180P/8P4C/[10CN1-001800-11/10/17]
LPT5
LPT4
LPT17
LPT3
LPT6LPT6
LPT7
LPT8
LPT9
LPT1
LPT2
ERRLPT16
ACKBUSY
PE
SLCT
LPT14
PC2 180P/4/N/50V
LPT1
LPT14
LPT2
ERR-
87
43
65
21
21
43
65
87
21
43
65
87
21
43
65
87
PCN2
180P/8P4C/[10CN1-001800-11/10/17]
PCN3
180P/8P4C/[10CN1-001800-11/10/17]
PCN4
180P/8P4C/[10CN1-001800-11/10/17]
3
LPT3
LPT16
LPT4
LPT17
LPT5
LPT6
LPT7
LPT8
LPT9
ACK-
BUSY
PE
SLCT
GIGABYTE
Title
Size Document Number Rev
B
Date: Sheet
LPT
1
14
2
15
3
16
4
17
5
18
6
19
7
20
8
21
9
22
10
23
11
24
12
25
13
LPT/P
COM & LPT PORT &FLOOPY
XP-P5IM800GV 1.0
2
24 36Thursday, December 16, 2004
of
1
AFD-[22]
B B
A A
8
STB-[22]
INIT-[22]
SLIN-[22]
AFD- LPT14
STB-
INIT-
SLIN- LPT17
PD2 LPT4
PD3
PD4
PD6
PD7
PD5
ERR-[22]
ACK-[22]
BUSY[22]
PE[22]
SLCT[22]
7
PRN1
1 2
3 4
5 6
7 8
33/8P4R
PRN2
1 2
3 4
5 6
7 8
33/8P4R
PRN5
5 6
3 4
1 2
7 8
33/8P4R
ERRACKBUSY
PE
SLCT
LPT1
LPT2PD0
LPT16
LPT3PD1
LPT5
LPT6
LPT8
LPT9
LPT7
6
PRN3
2.2K/8P4R
PRN4
2.2K/8P4R
PRN6
2.2K/8P4R
PRN7
2.2K/8P4R
PR1
2.2K/6
5
PD1 1N4148/S
78
56
34
12
78
34
56
12
78
56
34
12
78
56
34
12
Page 25
8
FUSEVCC,GAMEVCC
7
6
5
4
3
2
1
BC673
0.1U/6/Y/25V/X
5VDUAL
240MILS 160MILS
PSR24251/D/O/[11FP1-31250B-11]
F1
1 2
BC672
0.1U/6/Y/25V
FUSEVCC
FUSEVCC
FUSEVCC
D D
C C
FUSEVCC
123456
78
KRN1
4.7K/8P4R
MSDATA
KRN2
KCLK[22]
MCLK[22]
MDAT[22]
B B
KDAT[22]
5 6
1 2
3 4
7 8
82/8P4R
KCN1
180P/8P4C/[10CN1-001800-11/10/17]
2 1
4 3
6 5
8 7
KBCLK
MSCLK
MSDATA
KBDATA
MSCLK
KBDATA
KBCLK
7
8
11
12
1
2
5
6
KB_MS
1314151617
KB/MS
MS
KB
10
9
4
3
KC2
0.1U/6/Y/25V
A A
GIGABYTE
Title
Size Document Number Rev
B
8
7
6
5
4
3
Date: Sheet
KB & PS2 MOUSE & IR
2
XP-P5IM800GV 1.0
25 36Thursday, December 16, 2004
of
1
Page 26
8
REAR USB
7
6
5
4
3
2
1
D D
+USBP2[15]
-USBP2[15]
+USBP3[15]
-USBP3[15]
+USBP2
-USBP2
+USBP3
-USBP3
FUSEVCC FUSEVCC FUSEVCC FUSEVCC
Q235
BAV99/S/X
FRONT SIDE USB1
C C
-USBP0[15]
+USBP0[15]
REV1.0
132
132
132
132
Q236
Q237
BAV99/S/X
-USBP0
+USBP0
FUSEVCC FUSEVCC FUSEVCC FUSEVCC
Q239
BAV99/S/X
Q238
BAV99/S/X
BAV99/S/X
FUSEVCC
UBC1
0.1U/6/Y/25V
132
132
Q240
BAV99/S/X
REV1.0 REV1.0
F_USB1
132
4
5 6
87
10
JP/2X5/-9/BLACK/[11NH2-000205-73/71]
R_USB
FUSEVCC FUSEVCC
1 2
3 4
5 6
7 8
121011
USB_DOUBLE
UR1 150K/6
UEC1
+
100U/D/10V/57/[11CE2-571000-06/05/02/03]
132
Q241
Q242
BAV99/S/X
BAV99/S/X
3571
132
-USBP2-USBP3
+USBP2+USBP3
2468
9
-USBP1
+USBP1
-USBOC1
UR2
270K/6
-USBP1 [15]
+USBP1 [15]
-USBOC1 [15]
FUSEVCC
BC433
0.1U/6/Y/25V
B B
A A
GIGABYTE
Title
Size Document Number Rev
B
8
7
6
5
4
3
Date: Sheet
2
ICH USB PORT
XP-P5IM800GV 1.0
26 36
of
1
Page 27
5
D D
4
3
2
AVDD
CR88
8.2K/6/X
1
GPIO0 [28]
CC1
22P/4/N/50V/X
CC2
22P/4/N/50V/X
AC_SDIN2[15]
AC_SYNC[15]
-AC_RST[15]
CR89 0/6/SHT/X
X3
1 2
24.576MHZ/X
CR92
1M/6/X
CR93 22/6
CBC6
0.1U/6/Y/25V
Z100
CBC7
0.01U/4/Y/16V
JD2[28]
JD0[28]
VCC3
CR91
2.2/8
CBC3
4.7U/8/Y/10V
CR90 0/6/SHT/X
CBC1
1U/6/Y/10V
1
DVDD1
2
XTL_IN
3
XTL_OUT
4
DVS1
5
SDATA_OUT
6
BIT_CLK
7
DVSS2
8
SDATA-IN
9
DVDD2
10
SYNC
11
RESET#
12
PC_BEEP
Z106
4847464544434241403938
NC
NC
TEST6
TEST5
TEST4
TEST1
TEST3
AVSS2
NC
TEST2
AVDD2
AC'97 CODEC
PHONE
AUX_L
AUX_R
VIDEO_L
VIDEO_R
CD_LNCCD_R
MIC1
MIC2
LINE_IN_L
1314151617181920212223
37
MONO_OUT
LINE_IN_R
24
LINE_JOUT_L
ALC655/D
Z116
Z117
Z121
CU1
VRDA
VRDA
AFILT2
AFILT1
VREF
AVSS1
AVDD1
NC
NC
NC
36
35
34
33
32
31
30
29
28
27
26
25
CBC8
0.1U/6/Y/25V
LINE_OUT_R
CBC13 2.2U/8/Y/16V
CBC14 2.2U/8/Y/16V
CBC15 1U/6/Y/10V
CBC16 1U/6/Y/10V
CBC17 0.1U/6/Y/25V
CBC18 0.1U/6/Y/25V
CBC19 0.1U/6/Y/25V
Z122Z101
Z124
Z125
Z126
Z127
Z128
CBC9
2.2U/8/Y/16V
LINE_IN_R [28]
LINE_IN_L [28]
MIC2 [28]
MIC1 [28]
CD_R [28]
CDGND [28]
CD_L [28]
CBC2
0.1U/6/Y/25V/X
CBC4 1U/6/Y/10V
CBC5 0.01U/4/Y/16V
CC4
1000P/4/X/50V
CLOSE CODEC PIN
LINE_O_R [28]
LINE_O_L [28]
CC5
1000P/4/X/50V
CBC10
1U/6/Y/10V
pin 31,32 pin VRDA,VRAD FOR
1u
LINE IN frequency response
FRONT_MIC [28]
CLOSE TO CODEC
CBC11
1U/6/Y/10V
使
Recording A-D-PC FOR
AUD_REF [28]
CBC12
1U/6/Y/10V/X
AC97CLK[19]
FIX SPDIF
REV 1.0
C C
AC_SDOUT[15]
AC_BITCLK[15]
CC3
22P/4/N/50V
EMIREV 1.0
B B
CQ1
EMI REQUEST
CR94 0/6/X
CBC21
CR95 0/6/X
A A
5
4
3
2
4.7U/8/Y/10V
Title
Size Document Number Rev
Custom
Date: Sheet
78L05/D
TOP
1
OUT GND IN
2
3
GIGABYTE
AUDIO (ALC655)
XP-P5IM800GV
1
+12VAVDD
CBC20
0.1U/6/Y/25V
27 36Thursday, December 16, 2004
1.0
of
Page 28
5
D D
KEY
LNRFLOR
F_AUDIO_S2
CBC26
0.1U/6/Y/25V/X
AVDD
CR107
1K/6
INTEL FRONT AUDIO
FOR EMI REQUEST
CC8
180P/4/N/50V
CR104
FRONT_MIC[27]
8.2K/6
CR106
CBC27
0.1U/6/Y/25V/X
MIC1
AVDD
C C
CR105 0/6/X
Reseved
CC9
180P/4/N/50V
0/6/X
FLOL LNL
CC10
180P/4/N/50V
F_AUDIO_S1
JU1x2/BLACK/[5-6]/11NH1-000102-16/13]
JU1x2/BLACK/[5-6]/11NH1-000102-16/13]
F_AUDIO
1 2
3 4
5 6
7
9 10
JP2x5/-8/H
Not Drill
on pin 8
CD IN
CD_IN
CD_L[27]
CD_R[27]
CDGND[27]
B B
1000P/4/X/50V/X
CC13
1000P/4/X/50V/X
CC14
1
2
3
4
CC15
1000P/4/X/50V/X
WF1x4/B
4
3
LINE OUT
CEC1
100U/D/10V/57/[11CE2-571000-06/05/02/03]/X
LINE_O_R[27]
LINE_O_L[27]
CEC2
100U/D/10V/57/[11CE2-571000-06/05/02/03]/X
2
CBC23
10U/8/Y/10V
1
+
1
+
CBC24
10U/8/Y/10V
FLOR
CR97 22/6
CR99 22/6
FLOL
REV 1.0
CR98
0/6/X
CR100
0/6/X
CR101
22K/6
JD0[27]
CR102
22K/6
CLOSE CONN
CBC22
4.7U/8/Y/10V/X
CC6
180P/4/N/50V
CR96 8.2K/6/X
CC7
180P/4/N/50V
LNR
LNL
1
3RJ+15F/[11NR6-403004-11]
AUDIOB
B5
B4
B3
B2
LINE-IN
AUDIO PANEL
LINE IN(C)
LINE OUT(B)
MIC IN(A)
LINE_IN_R[27]
LINE_IN_L[27]
CR108
CR109
22K/6
22K/6
CC11
180P/4/N/50V
JD2[27]
CC12
180P/4/N/50V
CLOSE CONN
CR1038.2K/6/X
CBC25
4.7U/8/Y/10V/X
AUDIOC
C5
C4
C3
C2
3RJ+15F/[11NR6-403004-11]
MIC
AUD_REF[27]
AUD_REF
CBC28
0.1U/6/Y/25V
CR111
2.2K/6
GPIO0[27]
CR1108.2K/6/X
CBC29
4.7U/8/Y/10V/X
MIC2[27]
MIC1[27]
CC16
CR113
CR112
22K/6
22K/6
A A
Title
Size Document Number Rev
Custom
5
4
3
2
Date: Sheet
180P/4/N/50V
AUDIO OUTPUT
CC17
180P/4/N/50V
GIGABYTE
XP-P5IM800GV
A5
A4
A3
A2
A1
AUDIOA
3RJ+15F/[11NR6-403004-11]
1
28 36Thursday, December 16, 2004
MH1
1.0
of
Page 29
8
7
6
5
4
3
2
1
VCC
VCC
R750
BC431
330/6
0.01U/4/X/16V
D D
-HDLED[23]
C C
R760 75/6
-SP
INTEL FRONT PANEL
+HD +MPD
-HDLED
RESET
VCC
D34
1N4148/S
F_PANEL
1
HD+
3
HD-
5
GND
7
RESET
9
RSV
13
GD+
15
GD-
17
GN+
19
GN-
MSG/PD+
MSG/PD-
PW+
PW-
SP+
2
4
6
8
14
16
NC
18
NC
20
SP-
JP2X10/-10,-11,-12,-13,-15,-17,-19/BLACK
SOT23
1
3
R762 1K/6R761 75/6
2
Q104
MMBT2222A/SOT23
-MPD
-SP
VCC
R1023
330/6
SPKR [16]
5VSB
R754
8.2K/6
C275
0.01U/4/X/16V
-MPD
-PWRBTSW
-PWRBTSW [16]
Q174
BAV99/S
132
MMBT2222A/SOT23
SOT23
132
R772 1K/6
5VSB
Q112
-SYS_RST[6,16]
VCC3
R755 8.2K/6/X
3 PIN POWER LED
PWR_LED
P_LED_1X3
GPO25 [16]
MPD+
MPDMPD-
R751 33/6
Q101
+MPD
1
-MPD
2
-MPD
3
BAT54A/SOT23/X
SOT23
VCC
R749
1K/6/X
RESET
C274
1N/4/X/50V
B B
VCC3VCC3
-RI
D38
1N4148/S
NRIA-[24]
A A
R778 75K/6
R779
8.2K/6
1
+
EC75
22U/D/25V/57/[11CE4-57220A-03/02/04/05]/X
挑
MODEM RING ON
Q115
MMBT2222A/SOT23
132
REV1.0
8
7
6
-RI [16]
R774
R775
1K/6
1K/6
2
-SATA_LED[16]
1
Q114
MMBT2222A/SOT23
3
-HDLED
SOT23
GIGABYTE
Title
Size Document Number Rev
B
5
4
3
Date: Sheet
PANEL & STR LED & RI
2
XP-P5IM800GV 1.0
29 36
of
1
Page 30
5
PROCESSOR HOT
+12V
R1449
10K/6/1
D D
RS2
HR100K/6
U-ATX PROCESSOR HOT NO POP
RS2 CLOSE CPU VR MOSFET
R1448 9.53K/6/1
3
2
C910
0.1U/6/Y/25V
+12V
84
+
-
LM358/SO8
R1450
1.07K/6/1
TSM_5
TSM_6
R1451
1K/6
U53A
TSM_7
1
Plase at PH3 copper
ThermalTake FAN Power Consumption: 0.82A
Intel FAN Power Consumption Spec: 1.1A
CPUFAN_VCC
VCC
R1456
1K/6
FANPWM1[22]
C C
R1460
22K/6
BC675
2.2U/8/Y/16V
+12V
R1455
8.2K/6
84
U53B
5
+
6
-
LM358/SO8
R1461
5.1K/6
AP3310H/P06P03/TO252/PMOS
R1453 8.2K/6
7
Q220
EC139
100U/D/16V/5*11
+12V
1
3
2
1
+
4
-PROCHOT
3
D
GS
2
1
3
D
GS
2
1
GDS
CPUFAN_VCC FANIO1
BC676
0.1U/6/Y/25V/X
-PROCHOT [6,8]
PRESCOTT
Q219
2N7002/SOT23
-FORCEPR
-FORCEPR [6]
Q233
2N7002/SOT23/X
Depend on
location
of RS2
VCC
R1452
8.2K/6
R1458
0/6/X
VCC
213
4
GVS
C
CPU_FAN
FAN/1x4/W/[11NH5-020104-41/43]
R1454 100/6
3
5VSB
R1092
100/6/1
2_5LEVEL
9
13
1
EC112
+
100U/D/10V/57/[11CE2-571000-06/05/02/03]
U33E
TSM104/A
A
C
R
8
asserted at 130 degree (RS2=720 ohm)
deasserted at 115 degree (RS2=1270 ohm)
FANPWM2 [22]
R1462
R1463
22K/6
1K/6
FANIO1 [22]
C911
3.3N/4/X/50V
2
VDDQ FOR AGP 4X/8X
REV 1.0FOR 2.5V FIXED
R1297
330/6
R1299
1K/6
REV1.0
R1093
604/6/1
R1095
1K/6/1
C394
0.1U/6/Y/25V
R1096 1K/6
5
6
3
2
+12V
1
VCC3VCC3
2
Q208
U33B
413
+
-
413
+
-
7
TSM104/A
U33A
1
TSM104/A
R1298 100/6
R790 100/6
C281
1U/6/Y/10V
HUF76107D3S/P3055LD/STD1703LT4/TO252
1
3
VCC28
BC684
10U/12/Y/10V
2
Q117
1
3
HUF76107D3S/P3055LD/STD1703LT4/TO252
BC536
1U/6/Y/10V
+
EC80
1000U/D/6.3V/8C/[11CL1-8E1001-14/11/13]
VDDQ
CPU_FAN PIN3,4 CO-LAYOUT
VTT_GMCH
C401
0.01U/4/Y/16V/X
R1108
1.5K/6/1
Z221
C403
R1110
0.01U/4/X/16V
B B
A A
5
4
3
1K/6/1
2_5LEVEL
R1116
130/6/1
R1120
130/6/1
U33D
413
TSM104/A
14
+
15
-
R1109 8.2K/6
16
12
+
11
-
R1121 33/6
VTT_GMCH=1.4V~1.0V
2
VTT_PWRGD [6,31]
R1111
2.4K/6
U33C
TSM104/A
R1117 100/6
10
+
EC132
1000U/D/6.3V/8C/[11CL1-8E1001-14/11/13]
Title
POWER,CPU_FAN,PROCHOT
Size Document Number Rev
XP-P5IM800GV 1.0
Date: Sheet
C402
0.1U/6/Y/25V
BC441
0.1U/6/Y/25V
VDDQ
2
Q119
HUF76107D3S/P3055LD/STD1703LT4/TO252
GDS
1
3
VTT_GMCH
1
30 36Thursday, December 16, 2004
of
Page 31
5
VCORE VCORE
1
1
1
1
+
+
560U/4V/8K/CHEMICON/X
D D
DD1 :
在
SHORT
MOSFET TURN ON ,
降壓,同時
也會下降
無法提供
TURN ON,
POWER
TURN ON
DR9,DC5 FOR V12 OVER 19V
以上
,SPEC (18V)
DR12
為一個
DELAY :
(DR35,DC13)
DR39:240K
工作頻率
C C
4PHASE=180K(1 PHASE)
VTT_PWRGD[6,30]
VSS_SENSE[6]
VCC_SENSE[6]
約
DR41:
DR36 :TRACER
CHOKE,算出CHOKE
兩端壓降
DEC1
560U/4V/8K/CHEMICON/X
HIGH SIDE 發生S-D
時
(OVP), LOW SIDE
讓
V12
6~7V
POWER TO LOW SIDE
所以加
提供給
保護
VCORE
以下時,造成
DD1 延長PWM
LOW SIDE MOSFET
CPU VOLTAGE 過高.
CYCLE的DUTY(50%)
讓限流時間
才啟動
DELAY
.
=720KHZ /
VRMGD[16]
DR22 0/6/X
DR25 0/6/SHT/X
DR28 0/6/X
DR32 0/6/SHT/X
VCORE
200A
拉到
560U/4V/8K/CHEMICON/X
DEC2
PWM
DC7 1.5N/4/X/50V
DC24
33N/4/X/50V/X
150KHZ
MODIFY CHOKE NOISE
B B
1
1
+
+
DEC3
DEC4
560U/4V/8K/CHEMICON
DD1
1N4148/S
DC23
1U/8/Y/25V/X
DR17 0/6/SHT/X
DR19 0/6/SHT/X
DC5
1U/8/Y/25V
DR29
10/6
DR33
680P/4/X/50V
1K/6/1
VCC3
DRN1 8.2K/8P4R
DR55 8.2K/6
DR57 8.2K/6
DC13 47N/4/Y/16V
1 2
3 4
5 6
7 8
+
+
DEC5
560U/4V/8K/CHEMICON/X
V12
DR10
DR9
22/6
22/6
DR12 510K/6/1
DC8
68P/4/N/50V
DR34
DC9
33K/6/1
DR35 301K/6/1
DR39 432K/6/1
DR41 80.6K/6/1
REV1.0
DEC15
560U/4V/8K/CHEMICON
(MAINSTREAM POWER DESIGN)
DU2
FAN5019
14
RAMPADJ
19
GND
10
PWRGD
11
EN
7
FBRTN
8
FB
9
COMP
12
DELAY
13
RT
15
ILIMIT
DR44
22/6
VID3
VID2
VID1
VID0
VID4
VID5
4
1
+
DEC10
560U/4V/8K/CHEMICON/X
3300U/D/6.3V/SANYO
2728
PWM1VCC
26
PWM2
25
PWM3
24
PWM4
23
SW1
22
SW2
21
SW3
20
SW4
18
CSCOMP
17
CSSUM
16
CSREF
6
VID5
1
VID4
2
VID3
3
VID2
4
VID1
5
VID0
-OD
VID3 [6,22]
VID2 [6,22]
VID1 [6,22]
VID0 [6,22]
VID4 [6,22]
VID5 [6,22]
1
+
560U/4V/8K/CHEMICON
DEC11
PWM1
PWM2
PWM3
DR18 0/6/SHT/X
DR21 0/6/SHT/X
DR23 0/6/SHT/X
DR27 100K/6/THERMISTOR
DR30 39K/6/1
DC11
5.6N/4/X/16V
DC10
0.022uF/4/X/25V/X
DR36 100/6
DC14
0.01U/4/Y/16V
1
+
DEC12
PH1
PH2
PH3
DR27 放到CHOKE
為溫度補償
REV1.0
VID5
VID4
VID3
VID2
VID1
VID0
DC16 680P/4/X/50V/X
VCORE
DR45 0/6
1
+
DEC14
3300U/D/6.3V/SANYO
DR6 120K/6
DR7 120K/6
DR8 120K/6
DR31
100K/6/1
A
CSSUM
CSSUMA
3
DC2 0.1U/6/Y/25V
V12
DR3
0/6/SHT/X
DBC2
1U/8/Y/25V
PH1CSSUM
PH2
PH3
V12
DR16
0/6/SHT/X
DBC4
1U/8/Y/25V
V12
DR40
0/6/SHT/X
DBC6
1U/8/Y/25V
PWM1
-OD
PWM2
-OD
PWM3
-OD
DU1
1
BST
DRVH
SW
4
VCC
DRVL
2
IN
3
OD#
PGND
FAN5009
DC4 0.1U/6/Y/25V
DU3
1
BST
DRVH
SW
4
VCC
DRVL
2
IN
3
OD#
PGND
FAN5009
DC12 0.1U/6/Y/25V
DU4
1
BST
DRVH
SW
4
VCC
DRVL
2
IN
3
OD#
PGND
FAN5009
8
7
5
6
8
7
5
6
8
7
5
6
2SK3638/PHD78NQ03LT/TO252
2SK3638/PHD78NQ03LT/TO252
2SK3638/PHD78NQ03LT/TO252
2
DL1
2.8uH/D/20A/3P
V12
DC1
2.2U/8/Y/16V/X
DQ1
DR62
8.2K/6
PH1
DR5 0/6/SHT/X
2SK3639/PHD98N03LT/TO252
DR63
8.2K/6
PH2
DR24 0/6/SHT/X
2SK3639/PHD98N03LT/TO252
DQ9
DR64
8.2K/6
PH3
DR43 0/6/SHT/X
2SK3639/PHD98N03LT/TO252
DR1 2.2/6
DQ3
DQ5
DR13 2.2/6
DQ7
DR37 2.2/6
DQ11
1
DBC1
1U/8/Y/25V
VIN
1500U/D/16V/MBZ
2
1
3
2
1
3
2SK3639/PHD98N03LT/TO252
VIN
2
1
3
2
1
3
2SK3639/PHD98N03LT/TO252
VIN
2
1
3
2
1
3
2SK3639/PHD98N03LT/TO252
1500U/D/16V/MBZ
DEC6
1
+
DEC7
1500U/D/16V/MBZ
1
+
1500U/D/16V/MBZ
DEC8
1
+
DEC9
+
1
PRO 以上,MOSFET (1 上 2 下)
DQ4
DQ8
DQ12
REV 1.0
0.6uH/D/30A/3PM/[11LC3-30600C-R1/R2/R3/R4]
2
1
3
DBC3
1U/8/Y/25V
REV 1.0
0.6uH/D/30A/3PM/[11LC3-30600C-R1/R2/R3/R4]
2
1
3
DBC5
1U/8/Y/25V
REV 1.0
0.6uH/D/30A/3PM/[11LC3-30600C-R1/R2/R3/R4]
2
1
3
DL2
DR4
2.2/6
DC3
0.01U/4/X/16V
DL3
DR20
2.2/6
DC6
0.01U/4/X/16V
DL4
DR42
2.2/6
DC15
0.01U/4/X/16V
VCORE
CHOKE06U-30A_3PM-2
A A
Title
Size Document Number Rev
Custom
5
4
3
2
Date: Sheet
GIGABYTE
VRD 10.1
XP-P5IM800GV
1
1.0
of
31 36Thursday, December 16, 2004
Page 32
8
5VSB
D D
Q222
MMBT2222A/SOT23
-ATX_PS_ON6,19,33]
C C
B B
PS_ON-
PS_ON-[33]
SOT23
132
R1468
-5V
1K/6
BC501
0.1U/6/Y/25V/X
-12V
R1004
470K/6
BC498
0.1U/6/Y/25V
VCC
5VSB
B
2.5V LEVEL
7
6
ATX POWER CONNECTOR
VCC3
ATX
13
3.3V
14
BC502
0.1U/6/Y/25V/X
0.1U/6/Y/25V/X
BC499
-12V
15
GND
16
PSON
17
GND
18
GND
19
GND
20
-5V
21
5V
22
5V
23
5V
24
GND
ATXPWR_ATX 20PIN/[11NH4-020020-61_11NH4-020020-62]
ATXPWR_24P-1
防燒線路
5VSB_ATX
R1510
1K/6/X
CAR
SOT23
SC431/SOT23/10GL4-15B431-30/10/40/X
R1511
1.8K/6/1/X
R1512
RAC
1K/6/1/X
LM393/SO8/10TA1-800393-06/07/01/X
Q243
3.3V
3.3V
GND
5V
GND
5V
GND
POK
5VSB
12V
12V
3.3V
5VSB_ATX
84
3
+
2
-
1
2
3
4
5
6
7
8
9
10
11
12
U57A
VCC3
1
BC337
0.1U/6/Y/25V
BC503
0.1U/6/Y/25V
BC685
1U/8/Y/25V/X
VCC3
5VSB_ATX
5VSB_ATX
+12V
C361
0.1U/6/Y/25V
R1509
1K/6/X
2
34
D
GS
D
5
5VSB
1
D
D
6
5
VCC
5VSB_ATX
BC506
0.1U/6/Y/25V
R1296
8.2K/6/X
U58
SI3443DV/PMOS/TSOP-6/X
BC686
1U/8/Y/25V/X
LM393/SO8/10TA1-800393-06/07/01/X
PWOK
A
GPI6 [16]
5VSB_ATX
PWOK [16,21,33]
BC505
0.1U/6/Y/25V
RN134
0/8P4R
5VSB_ATX
84
5
+
6
-
U57B
4
5VSB
78
56
34
12
7
V12
BC508
0.1U/6/Y/25V
3
ATX_12V
4
GND
+12V
GND+12V
ATX12V/PROTECT
2
1
23
1
MH1
2
3
8
7
6
5
4
1
HOLE_3/X
MH5
2
3
8
7
6
5
MH4
2
3
8
7
6
5
A A
4
1
HOLE_3/X
4
1
HOLE_3/X
MH2
MH6
2
3
8
7
6
5
2
3
8
7
6
5
4
1
HOLE_3/X
4
1
HOLE_3/X
MH3
MH7
2
3
8
4
7
1
HOLE_3/X
6
5
2
3
8
4
7
1
HOLE_3/X
6
5
K1
K_ICT/X
K2
K_ICT/X
K3
K_ICT/X
1
1
1
1
1
1
K4
K_ICT/X
K5
K_ICT/X
K6
K_ICT/X
1
1
1
1
1
1
I1
HOLD/X
I2
HOLD/X
I3
HOLD/X
1
1
1
1
1
1
(08/12) HOLE_3-2
GIGABYTE
Title
Size Document Number Rev
B
8
7
6
5
4
3
Date: Sheet
Misc. PWR & ATX CONN.
2
XP-P5IM800GV 1.0
32 36
of
1
Page 33
8
7
6
5
4
3
2
1
3VDUAL
D D
Q225
APL1084/TO252
C C
5VDUAL
B B
BC681
1U/6/Y/10V
2
PWOK[16,21,32]
BC683
0.1U/6/Y/25V
5VDUAL
3
1
5VSB
3
2
BC677
0.1U/6/Y/25V
R1494
100/6/1
R1495
169/6/1
BC682
1U/6/Y/10V
84
U55A
+
-
KA393/TO8
BC678
0.1U/6/Y/25V
1
3VDUAL
R1493 22K/6
EC142
+
100U/D/10V/57/[11CE2-571000-06/05/02/03]
U55A_1
U55A_2
4.7U/8/Y/10V/X
5VSB
5
+
6
-
BC679
84
KA393/TO8
U55B
DDR25V
VCC3 3VDUAL
D60
RN132
1N5820/S
2
Q226
3
R1497
619/6/1
R1498
10K/6/1
2.2/8P4R
1 2
3 4
5 6
7 8
+
FDD6530A/TO252
PS_ON-[32]
-SLP_S3[14,16,19,32]
-RSMRST [16]
C914
1U/6/Y/10V
C
R
5VSB
R1505
1K/6/X
5VSB
R1496
SOT23
C
R
D62
330/6
EN
1
+
EC143
22U/D/25V/57/[11CE4-57220A-03/02/04/05]/X
EN
132
Q230
MMBT2222A/SOT23
SOT23
DDR25V
SOT23
Q229
MMBT2222A/SOT23
R1500
1K/6
132
BAT54C/S
GDS
1
REV1.0
Q227
A
A
SC431/SOT23/[10GL4-15B431-10_10GL4-15B431-30]
-S4_S5[16]
Q234
MMBT2222A/SOT23
VCC
+12V
R1506
2.2K/6
7
R1507
1K/6
3
R1503
8.2K/6
132
SOT23
1
2
R1508
200/6
5VSB
VCC
DDR Over voltage Protect
D61
1N5817/S
EC141
1000U/D/6.3V/8C/[11CL1-8E1001-14/11/13]
1
+
EC148
1000U/D/6.3V/8C/[11CL1-8E1001-14/11/13]
2.6V-->387
2.65V-->587
2.7V-->790
R1501
8.2K/6
R1504
8.2K/6
1
+
EC149
1000U/D/6.3V/8C/[11CL1-8E1001-14/11/13]
EN
3
D
Q228
2N7002/SOT23
GS
2
1
Q231
MMBT2222A/SOT23
SOT23
132
C915
0.1U/6/Y/25V/X
DDR25V
RN133 1K/8P4R
1 2
3 4
5 6
7 8
A A
5VSB
8
U55A_2
U55A_2
U55A_1
U56
SI3443DV/PMOS/TSOP-6
7
34
GS
5VSB
+
100U/D/10V/57/[11CE2-571000-06/05/02/03]
2
5
EC147
5VDUAL
1
D
D
D
D
6
1
+
EC146
1000U/D/6.3V/8C/[11CL1-8E1001-14/11/13]
6
3
S
2
D
1
G
Q232
HUF76107/NMOS/TO252
VCC
GIGABYTE
Title
Size Document Number Rev
Custom
5
4
3
Date: Sheet
2
DDR POWER
XP-P5IM800GV 1.0
of
33 36Thursday, December 16, 2004
1
Page 34
A
B
C
D
E
LR1 5.6K/6
LX1
25MHZ/XTAL_HALF
LC1
27P/4/N/50V
4 4
LC2
27P/4/N/50V
3VDUAL
EECS
EESK
EEDI_AUX
EEDO
LR2 8.2K/6/X
LR2:
93C46:N/A
93C56:8.2K/6
LU1
1
CS
VCC
2
SK
3
DI
ORG
4 5
DO GND
93C46/SO8
3VDUAL
DC
LR4:
A_D[0..31]
MDI0+
MDI03VDUAL
GND
MDI1+
MDI13VDUAL
CTRL25
GND
DVDD
GND
3VDUAL
GND
3VDUAL
GND
GND
ISOLATEB
DVDD
-PIRQE
3VDUAL
-PCIRST
LAN33CLK
-GNT5
-REQ5
-PCIPME
DVDD
A_D31
A_D30
GND
A_D29
A_D28
GND
LR20
49.9/6/1
LBC33
0.01U/4/Y/16V
Close to
Chip
LR4
5.6K/6/1
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
LU2
RTL8100C
-C_BE3[14,15,20,21]
LR21
49.9/6/1
GND
GND
123
124
125
126
VSS
DVDDA
CTRL18
VDD33
AD25
AD24
A_D25
A_D24
-C_BE3
1
2
3
4 5
SLVU284/SO8/X
GND
XTAL1
XTAL2
119
120
121
122
HV
VSS
XTAL1
XTAL2
VSSPST
CBE3B
VDD18
IDSEL
AD23
GND
A_D25
A_D23
DVDD
GND
LU3
1
2
3
45
GND
118
A_D22
8
7
6
GND
AD22
YELLOW-
117
A_D21
LED0
AD21
8
7
6
DVDD
116
GND
GREEN-
VDD18
VSSPST
GND
RSET
GND
DVDD
127
128
VSS
RSET
1
MDI0+
2
MDI0-
3
AVDDL
4
VSS
5
MDI1+
6
MDI1-
7
AVDDL
8
CTRL25
9
VSS
AVDDH
HSDAC+
HSDACVSS
MDI2+
MDI2AVDDL
VSS
MDI3+
MDI3AVDDL
VSSPST
GND
ISOLATEB
VDD18
INTAB
VDD33
RSTB
CLK
GNTB
REQB
PMEB
VDD18
AD31
AD30
GND
AD29
AD28
VSSPST
AD27
AD26
39404142434445464748495051525354555657585960616263
A_D27
A_D26
3VDUAL
EEDO
A_D1
EEDI_AUX
DVDD
108
109
110
EEDI
EESK
EEDO
VDD18
VDD33
AD18
AD17
AD16
A_D17
A_D16
A_D18
LBC31
0.1U/6/Y/25V
B
EECS
3VDUAL
106
107
EECS
VDD33
CBE2B
FRAMEB
-FRAME
-C_BE2
A_D0
104
105
LWAKE
SMBDATA
GND
-IRDY
GND
103
AD0
VSSPST
VSSPST
VSSPST
SMBCLK
DEVSELB
VSSPST
CLKRUNB
IRDYB
64
DVDD
AD1
VDD18
VDD33
CBE0B
M66EN
AD10
AD11
AD12
VDD33
AD13
AD14
AD15
VDD18
CBE1B
SERRB
VDD33
PERRB
STOPB
TRDYB
VDD18
GND
GND
PAR
GND
102
AD2
101
100
99
98
AD3
97
AD4
96
AD5
95
AD6
94
93
AD7
92
91
90
AD8
89
AD9
88
87
86
85
84
83
82
81
80
79
78
77
76
75
74
73
72
71
70
69
68
67
66
65
A_D2
GND
GND
DVDD
A_D3
A_D4
A_D5
A_D6
3VDUAL
A_D7
-C_BE0
GND
A_D8
A_D9
A_D10
A_D11
A_D12
3VDUAL
A_D13
A_D14
GND
GND
A_D15
DVDD
-C_BE1
PAR
-SERR
GND
3VDUAL
-PERR
-STOP
-DEVSEL
-TRDY
GND
clkrunb has Internal
Pull-down
-REQ/-GNT(5)
IDSEL 25
-PIRQE
-IRDY [14,15,20,21]
-FRAME [14,15,20,21]
-C_BE2 [14,15,20,21]
USB_LAN
L1
L2
L3
L4
L5
L6
L7
L8
L9
L10
UP
DOWN
USB/LAN[P35-152-11Z9]
-C_BE0 [14,15,20,21]
-C_BE1 [14,15,20,21]
PAR [14,15,20,21]
-SERR [14,15,20,21]
-PERR [14,15,20,21]
-STOP [14,15,20,21]
-DEVSEL [14,15,20,21]
-TRDY [14,15,20,21]
D1
D2
D3
D4
U1
U2
U3
U4
U5
U6
U7
U8
EESK
GND
111
112
113
114
115
GND
LED3
LED2
LED1
GND
AD20
VDD18
AD19
A_D20
A_D19
3VDUAL
DVDD
100M:5.6K/6/1
1G:2.49K/6/1
A_D[0..31][14,15,20,21]
LU2:
100M:RTL8100C
3 3
2 2
1G:RTL8110S
VCC
-PCIRST
LC3
1N/4/X/50V
LR8 1K/6
LR10 15K/6
-PCIRST[10,15,18,21,22]
LAN33CLK[19]
-PCIPME[15,20,21]
-PIRQE[15]
-GNT5[15]
-REQ5[15,20]
A_D[0..31]
Spacing : at least 50 mils between each differential pair
MDI0+
MDI0MDI1+
MDI1-
LR19
LR18
49.9/6/1
1 1
49.9/6/1
LBC32
0.01U/4/Y/16V
Close to
Chip
A
8
7
6
A_D[0..31]
YELLOWYELLOW
GREENORANGE-
3VDUAL
LBC1
0.1U/6/Y/25V
LR16 150/6
LR17 150/6
-USBP4
+USBP4
-USBP5
+USBP5
For EMI
FUSEVCC
C
3VDUAL
1
+
LEC1
100U/D/10V/57/[11CE2-571000-06/05/02/03]
3VDUAL
LBC16
0.1U/6/Y/25V
CTRL25
3VDUAL
LFB4
0/8/SHT/X
3VLED
LBC2
0.1U/6/Y/25V
LBC17
0.1U/6/Y/25V
LQ3
2907A/SOT23
132
3VDUAL
LAN33CLK
LBC26 10P/4/N/50V/X
FUSEVCC
LBC30
0.1U/6/Y/25V
132
Q245
BAV99/S/X
132
FUSEVCC FUSEVCC FUSEVCC FUSEVCC
Q244
BAV99/S/X
REV1.0
LBC3
0.1U/6/Y/25V
LBC18
0.1U/6/Y/25V
1
+
LEC3
100U/D/10V/57/[11CE2-571000-06/05/02/03]
LR6 150K/6
1
+
LEC2
1000U/D/6.3V/8C/[11CL1-8E1001-14/11/13]
132
Q246
Q247
BAV99/S/X
BAV99/S/X
DVDD
+USBP5
-USBP5
+USBP4
-USBP4
132
LBC4
0.1U/6/Y/25V
LBC21
0.1U/6/Y/25V
-USBOC
LR7
270K/6
POWER DECOUPLING CAP.
LBC5
0.1U/6/Y/25V
LBC24
0.1U/6/Y/25V
-USBOC [15]
+USBP5 [15]
-USBP5 [15]
+USBP4 [15]
-USBP4 [15]
D
LBC6
0.1U/6/Y/25V
LBC25
0.1U/6/Y/25V
Dual Color LED
D3D4
LBC7
0.1U/6/Y/25V
LBC8
0.1U/6/Y/25V
Green
D4
D3
Orange
Single Color LED
D2 D1
Yellow
ON
ON
ON
LBC15
0.1U/6/Y/25V
Dual Color LED
Green
OrangeYellow
ON10Mb
ON
Dual Color LED
OrangeGreen
ON100Mb
ON
LBC12
0.1U/6/Y/25V
LBC13
0.1U/6/Y/25V
RTL8100C
LINK
ACTIVE
RTL8110S
LINK/
SPEED
ACTIVE
100Mb
10Mb
10Mb
1Gb
10Mb
100Mb
1Gb
LBC14
0.1U/6/Y/25V
Blink
Blink100Mb
Yellow
Blink
Blink
Blink
10/100 Giga Giga
8110SB8110S8100C
N/A
AVDDH
V_12P
AVDDL
V_DAC
DVDD
DVDD_A
Title
Size Document Number Rev
Custom
Date: Sheet
GIGABYTE
LAN RT L 8110S/8100C
XP-P5IM800GV
2.5V
3.3V
N/A
2.5V
2.5V
E
3.3V
3.3V
N/A
3.3V
2.5V
2.5V
2.5V 2.5V
1.8V
1.3V
1.8V
1.3V
34 36Thursday, December 16, 2004
of
1.0
Page 35
5
XP-P5IM800GV
4
3
2
1
PCI DEVICE IDSEL INT CLOCK
D D
PCI SLOT1
PCI SLOT2
PCI SLOT3
16
17
18
C,F,G,A
F,G,A,C
G,A,C,F
PCLK0 -REQ0 -GNT0
PCLK1
PCLK2
REQ GNT
-GNT1-REQ1
-REQ2 -GNT2
-GNT4-REQ4TI 1394 21 F PCICLK1394
LAN (Marvell) 25 E LANCLK33 -REQ5 -GNT5
C C
B B
A A
Title
Size Document Number Rev
Custom
5
4
3
2
Date: Sheet
GIGABYTE
PCI ROUNT LIST
XP-P5IM800GV 1.0
35 36Thursday, December 16, 2004
1
of
Page 36
5
4
3
2
1
GIGABYTE XP-P5IM800GV GPIO LIST
SHEET TITLE SHEET TITLE
D D
GPIP
GPI0/REQA-
GPI1/REQ5-
I/O
I
FUNCTION
PULL HIGH 8.2K to VCC3, SMB connector.
PULL HIGH 8.2K to VCC, REQ5-.
GPO23
GPO24
I/O
NA
O
FUNCTIONGPIP
PULL 8.2K TO VCC3
INTEL LAN ENABLE/DISABLE.
GPI2/PIRQE-
GPI3/PIRQF-
GPI4/PIRQG-
GPI5/PIRQH-
C C
B B
GPI6/AGPBUSY-
GPI7
GPI8
GPI9/OC4-
GPI10/OC5-
GPI11/-SMBALRT
GPI12
GPI13
GPI14/OC6-
GPI15/OC7-
GPO16/GNTA- GPO16.
NA
NA
NA
NA
NA
NA
NA
PULL HIGH 8.2K to VCC3, PIRQE-.
PULL HIGH 8.2K to VCC3, PIRQF-.
PULL HIGH 8.2K to VCC, PIRQG-.
PULL HIGH 8.2K to VCC
PULL 8.2K TO VCC3, PANEL GREEN_BUTTON
I
DUAL BIOS FIRST BOOT SELECT.
I
PULL 8.2K TO 3VDUAL, -CASPME.
I
USB OC4-.
USB OC5-.
PULL 8.2K TO 3VDUAL,-SMBALERT.
PULL 8.2K TO VCC3,M/B REVERSION ID.
I
LPC PME.
I
USB OC6-.
USB OC7-.
GPO25
GPO27
GPO28
GPO32
GPO33
GPO34
FRONT PANEL -MPD.
O
FRONT PANEL +MPD.
O
GREEN LED
O
BIOS WRITE PROTECT.
O
SATA LED.
O
CLEAR PASSWORD.
I
GPO17/GNT5- GNT5-.
O
O
O
O
GPO18.
DUAL BIOS.
DUAL BIOS.
LED.
Title
Size Document Number Rev
Custom
4
3
2
Date: Sheet
GIGABYTE
GPIO LIST
XP-P5IM800GV 1.0
36 36Thursday, December 16, 2004
1
of
GPO18/STP_PCI-
GPO19/SLP_S1-
A A
GPO20/SLP_CPU-
GPO21/C3_SATA- BLOCK TOP TABLE.
GPO22/CPUPERF- PULL 8.2K TO VCC3,PANEL S3 POWER
5
NA
Loading...
