6EA
TABLE OF CONTENTS
1. INTRODUCTION
1.1. PREFACE............................................................................................................ 1-1
1.2. KEY FEATURES................................................................................................. 1-1
1.3. PERFORMANCE LIST........................................................................................ 1-2
1.4. BLOCK DIAGRAM............................................................................................... 1-3
1.5. INTRODUCE THE Pentium II Processor ......................................................... 1-4
1.6. What is AGP?...................................................................................................... 1-6
2. SPECIFICATION
2.1. HARDWARE ....................................................................................................... 2-1
2.2. SOFTWARE........................................................................................................ 2-2
2.3. ENVIRONMENT.................................................................................................. 2-2
3. HARDWARE INSTALLATION
3.1. UNPACKING....................................................................................................... 3-1
3.2. MAINBOARD LAYOUT....................................................................................... 3-2
3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS................................ 3-2
3.4. DRAM INSTALLATION....................................................................................... 3-5
3.5. CPU SPEED SETUP........................................................................................... 3-6
3.6. CMOS RTC & ISA CFG CMOS SRAM............................................................... 3-7
3.7. SPEAKER CONNECTOR INSTALLATION........................................................ 3-7
3.8. HARDWARE RESET SWITCH CONNECTOR INSTALLATION...................... 3-7
3.9. POWER LED CONNECTOR INSTALLATION................................................... 3-7
1
Table Of Contents
3.10. IDE & ATAPI DEVICE INSTALLATION............................................................ 3-7
3.11. PERIPHERAL DEVICE INSTALLATION.......................................................... 3-8
3.12. KEYBOARD & PS/2 MOUSE INSTALLATION................................................. 3-8
4. BIOS CONFIGURATION
4.1. ENTERING SETUP............................................................................................. 4-1
4.2. CONTROL KEYS ................................................................................................ 4-1
4.3. GETTING HELP.................................................................................................. 4-2
4.3.1. Main Menu............................................................................................... 4-2
4.3.2. Status Page Setup Menu / Option Page Setup Menu.............................. 4-2
4.4. THE MAIN MENU................................................................................................ 4-2
4.5. STANDARD CMOS SETUP MENU.................................................................... 4-4
4.6. BIOS FEATURES SETUP .................................................................................. 4-8
4.7. CHIPSET FEATURES SETUP........................................................................... 4-12
4.8. POWER MANAGEMENT SETUP...................................................................... 4-15
4.9. PNP/PCI CONFIGURATION .............................................................................. 4-19
4.10. LOAD BIOS DEFAULTS................................................................................... 4-21
4.11. LOAD SETUP DEFAULTS................................................................................ 4-22
4.12. INTEGRATED PERIPHERALS......................................................................... 4-23
4.13. SUPERVISOR / USER PASSWORD............................................................... 4-27
4.14. IDE HDD AUTO DETECTION.......................................................................... 4-28
4.15. SAVE & EXIT SETUP ....................................................................................... 4-29
4.16. EXIT WITHOUT SAVING ................................................................................. 4-30
2
6EA
1. INTRODUCTION
1.1. PREFACE
Welcome to use the 6EA motherboard. It is a Pentium II / Celeron Processor
based PC / AT compatible system with AGP / PCI / ISA Bus, and has been
designed to be the fastest PC / AT system. There are some new features allow
you to operate the system with just the performance you want.
This manual also explains how to install the motherboard for operation, and
how to set up your CMOS CONFIGURATION with BIOS SETUP program.
1.2. KEY FEATURES
q Intel Pentium
mainboard.
II / Celeron Processor based PC / AT compatible
q Slot 1 supports Pentium
q Intel 440LX chipset, Supports AGP / SDRAM / Ultra DMA/33 IDE /
II / Celeron processor running at 233-633 MHz.
Keyboard and PS/2 Mouse Power On.
q Supports 3xDIMMs using 3.3V EDO or SDRAM DIMM module.
q Supports 8MB ~ 768 MB EDO / 384 MB SDRAM memory on board.
q Supports ECC or Non-ECC type DRAM module.
q 1xAGP slot, 3xPCI Bus slots, 2xISA Bus slots.
q Supports 2 channels Ultra DMA/33 IDE ports for 4 IDE Devices.
q Supports 2xCOM (16550), 1xLPT (EPP / ECP), 1x1.44MB Floppy port.
q Supports USB port & PS/2 Mouse port.
q Licensed AWARD BIOS, 2M bits FLASH ROM.
q 22 cm x 25 cm Baby AT SIZE form factor, 4 layers PCB.
1-1
Introduction
1.3. PERFORMANCE LIST
The following performance data list is the testing results of some popular
benchmark testing programs.
These data are just referred by users, and there is no responsibility for different
testing data values gotten by users. (The different Hardware & Software
configuration will result in different benchmark testing results.)
• CPU
• DRAM (64x 2) MB SDRAM (LGS GM72V66841CT7J)
• CACHE SIZE 128/512 KB included in CPU
• DISPLAY GA-612 AGP Display Card (8MB SGRAM)
• STORAGE Onboard IDE (Seagate ST34520A)
• O.S. Windows NT™ 4.0
• DRIVER Display Driver at 1024 x 768 x 64K colors x 75Hz.
Pentium II / Celeron processor
TRIONES Bus Master IDE Driver 3.70
Celeron Pentium
Processor
333MHz(66x5) 333MHz(66x5)
Winbench98
CPU mark32 667 845
FPU Winmark 1790 1720
Business Disk 2100 2140
Hi-End Disk 5130 5150
Business Graphics 94.8 94.3
Hi-End Graphics 147 142
II
Winstone98
Business 30.6 31.4
Hi-End 32.2 32.5
1-2
6EA
DIMM Sockets
SLOT
SLOT 1
1.4. BLOCK DIAGRAM
AGP
AGP Bus
66MHz
Ultra DMA/33
IDE Ports
PCI Bus
IDE Bus
ISA Bus
66MHz
Host Bus
PAC
82443LX
CHIPSET
PIIX4E
82371EB
CHIPSET
DRAM Bus
33MHz
33MHz
33MHz
48MHz
14.318MHz
USB Bus
14.318MHz
3.3V EDO/SDRAM
66MHz
WINBOND
83193R-04
I/O
CHIPSET
ITE8671F
14.318MHz
24MHz
USB Ports
COM Ports
LPT Port
Floppy Port
1-3
Keyboard
PS/2 Mouse
1.5. INTRODUCE THE Pentium II Processor
Figure 1:Retention Mechanism & attach Mount
Introduction
Figure 2:OEM Pentium II Processor
1-4
6EA
Figure 3:Heatsink / FAN & Heat sink support for OEM Pentium II Processor
Figure 4:Boxed Pentium II Processor & Heat sink support
1-5
Introduction
1.6 What is AGP
?
The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge
device that supports an AGP port. The main purpose of the AGP port is to
provide fast access to system memory.
The AGP port can be used either as fast PCI port (32-bits at 66MHz vs. 32-bits
at 33MHz) or as an AGP port which supports 2x data-rate, a read queue, and
side band addressing. When the 2x-data rate is used the port can transmit data
at 533MB/sec (66.6*2*4). The read-queue can be used to pipeline reads –
removing the effects of the reads-latency. Side band addressing can be used to
transmit the data address on a separate line in order to speed up the
transaction.
1-6
6EA
2. SPECIFICATION
2.1. HARDWARE
• CPU
• SPEED
• DRAM MEMORY
• CACHE MEMORY
• I/O BUS SLOTS
• IDE PORTS
• I/O PORTS
− Pentium
− 242 pins 66MHz slot1 on board.
− 66 MHz system speed.
− 66 MHz AGP bus speed. (2X mode 133MHz)
− 33 MHz PCI-Bus speed.
− 8 MHz AT bus speed.
− 3 banks 168 pins DIMM module sockets on board.
− Use 8 / 16 / 32 / 64 / 128 / 256 MB DIMM module
DRAM.
− Supports 8MB ~ 768MB EDO / 384 MB SDRAM.
− Supports 3.3V SDRAM / EDO type DRAM.
− Supports ECC or Non-ECC type DRAM.
− 32 KB 1st cache memory included in CPU.
− 256KB / 512 KB L2 cache memory included in CPU.
− Supports DIB speed mode for L2 Cache.
− 3 33MHz Master / Slave PCI-BUS.
− 2 8MHz 16 bits ISA BUS.
− 1 66MHz / 133MHz AGP bus.
− 2 Ultra DMA/33 Bus Master IDE channels on
board.(Using IRQ14,15)
− Supports Mode 3,4 IDE & ATAPI CD – ROM.
− Supports 2 16550 COM ports.
− Supports 1 EPP/ECP LPT port.
− Supports 1 1.44/2.88 MB Floppy port.
− Supports 2 USB ports.
− Supports PS/2 Mouse & Keyboard.
II / Celeron processor 233 – 633 MHz.
2-1
Specification
• GREEN FUNCTION
• BIOS
• DIMENSION
− Suspend mode support.
− Green switch support.
− IDE & Display power down support.
− Monitors all IRQ / DMA / Display / I/O events.
− 2M bits FLASH ROM.
− Supports Plug & Play, DMI Function.
− Baby AT Form Factor, 4 layers PCB.
2.2. SOFTWARE
• DRIVER
• BIOS
• O.S.
− Bus Master IDE Driver.
− Suspend to HD utility.
− Licensed AWARD BIOS.
− AT CMOS Setup, BIOS / Chipset Setup, Green
Setup, Hard Disk Utility included.
− Operation with MS-DOS
, Windows95,
Windows98, WINDOWS NT, OS/2, NOVELL
and SCO UNIX.
2.3. ENVIRONMENT
• Ambient Temp. − 0°C to +50°C (Operating).
• Relative Hum. − 0 to +85% (Operating).
• Altitude − 0 to 10,000 feet (Operating).
• Vibration − 0 to 1,000 Hz.
• Electricity − 4.9 V to 5.2 V. (Max. 20A current at 5V.)
1-2
6EA
3. HARDWARE INSTALLATION
3.1. UNPACKING
The mainboard package should contain the following:
• The 6EA main board.
• The Retention Mechanism & Attach Mount
• USER'S MANUAL for main board.
• Cable set for IDE, Floppy & I/O devices.
• CD for mainboard Utility. (Bus Master IDE Driver, Suspend to HD Utility,
Patch 95)
The main board contains sensitive electric components, which can be easily
damaged by static electricity, so the mainboard should be left in its original
packing until it is installed.
Unpacking and installation should be done on a grounded anti-static mat. The
operator should be wearing an anti static wristband, grounded at the same
point as the anti-static mat.
Inspect the main board carton for obvious damage. Shipping and handling
may cause damage to your board. Be sure there are no shipping and handling
damages on the board before proceeding.
After opening the main board carton, extract the system board and place it only
on a grounded anti-static surface component side up. Again inspect the board
for damage. Press down on all of the socket IC's to make sure that they are
properly seated. Do this only on with the board placed on a firm flat surface.
M
DO NOT APPLY POWER TO THE BOARD IF IT HAS BEEN DAMAGED.
3-1
3.2. MAINBOARD LAYOUT
JP2
JP3
IDE 1
IDE 2
PWR
TD
TB
GN
HD
SOFT
JP10
Hardware Installation
ISA 2
ISA 1
PCI 3
PCI 2
PCI 1
COM A
LPT
USB
ITE
IT8671F-A
PS2
COM B
KB
JP1
WAKE
ON
LANE
J18
SW
Power
FAN
FLOPPY
ATX POWER
POWER
BAT1
CPU
FAN
J10
BIOS
SYS
FAN
PIIX4E
J17
6EA
SB-LINK
1
JP4
BANK 2
BANK 1
BANK 0
J6
AGP
Intel 440LX
82443LX
CPU
×Figure 3.1Ø
3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS
t I/O Ports Connector
USB USB port.
IDE1 For Primary IDE port.
IDE2 For Secondary IDE port.
KB For Keyboard port.
PS/2 For PS/2 Mouse port.
FLOPPY For Floppy port
COMB For Serial port2 (COM B).
COMA For Serial port1 (COM A).
ATX Power For ATX Power Connector.
Power For AT Power Connector.
LPT For LPT port.
t Slot 1
For Pentium II /Celeron Processor installed
3-2
6EA
t IR : INFRARED Connector (IR) -- Function Option
Pin No. Function
1 IR Data Output
2 GND
3 IR Data Input
4 Signal
5 POWER (+)
t PWR : POWER ON LED ( PW-LED)
Pin No. Function
1 LED POWER (+)
2
3
t SPK : SPEAKER Connector
LED POWER (−)
LED POWER (−)
Pin No. Function
1 VCC
2 NC.
3 NC.
4 Signal
t TD : Turbo LED Connector
Pin No. Function
1 LED POWER (+)
2
LED POWER (−)
t TB : Turbo Switch Connector
Pin No. Function
1 Signal
2 GND
t RST : RESET Switch
Pin No. Function
Open RESET Input
Close GND
t GD : Green LED Connector
Pin No. Function
1 LED anode (+)
3-3
Hardware Installation
2
t GN : GN-SW
LED cathode (−)
Pin No. Function
Open CTRL-Signal
Close GND
t HD : Hard Disk active LED (HD-LED)
Pin No. Function
1 LED POWER (+)
2
t Soft PWR : Soft Power Switch
LED POWER (−)
Pin No. Function
1 CTRL-Signal
2 GND
t J6 : CPU FAN(CPU cooling FAN Power Connector)
Pin No. Function
1 GND.
2 +12V
3 SENSE
t J18 : Power Fan Connector
Pin No. Function
1 GND.
2 +12V
3 SENSE
t J17 : System FAN Connector
Pin No. Function
1 GND.
2 +12V
3 SENSE
t J10 : System After Ac Back
Pin No. Function
Open Soft Off.
Close Full On.
3-4
6EA
t JP1 : Keyboard Power On Selection
Pin No. Function
1-2 Enabled Keyboard power on.
2-3 Disabled Keyboard power on.(Default)
t Wake on LAN
Pin No. Function
1 +5V SB
2 GND
3 Signal
t SB-LINK : For PCI Audio / Sound Card use only
Pin No. Function
1 Signal
2 GND
3 NC
4 Signal
5 GND
6 Signal
t JP10 : RING Power On
Pin No. Function
1 Signal.
2 GND.
3.4. DRAM INSTALLATION
The main board can be installed with 8 / 16 / 32 / 64 / 128 / 256 MB 168 pins
DIMM module DRAM, and the DRAM speed must be 50 or 60 ns for EDO &
67MHz for SDRAM when system bus speed is set to 66MHz. The DRAM
memory system on main board consists of bank 0 and bank 1& bank2 .
Since 168 pins DIMM module is 64 bits width, therefore 1 piece of DIMM
module may match a 64 bits system. The total memory size is 8 MB ~ 768MB
SDRAM. The DRAM installation position refer to Figure 3.1, and notice the Pin
1 of DIMM module must match with the Pin 1 of DIMM socket. Insert the DRAM
3-5
Hardware Installation
DIMM module into the DIMM socket at Vertical angle. If there is a wrong
direction of Pin 1, the DRAM DIMM module could not be inserted into socket
completely.
3.5. CPU SPEED SETUP
The system bus speed can be set to 66.6MHz form the jumper (JP2,JP3,
JP4). The user can change the DIP SWITCH (SW) selection to set up the CPU
speed for different processors. The CPU speed must match with the frequency
RATIO and Front Side Bus (FSB) speed. It will cause system hanging up if the
frequency RATIO and FSB Speed do not match with the CPU.
DIP SWITCH (SW)FREQ. RATIO
SW1 SW2 SW3 SW4
X 3
X 3.5
X 4
X 4.5
X 5
X 5.5
X 6
X 6.5
ON OFF ON ON
OFF OFF ON ON
ON ON OFF ON
OFF ON OFF ON
ON OFF OFF ON
OFF OFF OFF ON
ON ON ON OFF
OFF ON ON OFF
MAIN CLOCK JP2 JP3 JP4
66MHz
75MHz
83MHz
2-3 2-3 2-3
2-3 1-2 2-3
1-2 2-3 1-2
M The CPU is a sensitive electric component and it can be easily
damaged by static electricity, so users must keep it away from metal
surface when the CPU is installed onto main board.
M
We don’ t recommend you to setup your system speed to 75 or
83MHz because these frequencies are not the standard
specifications for CPU, Chipset and most of the peripherals.
3-6
6EA
Whether your system can run under 75 or 83MHz properly will
depend on your hardware configurations: CPU, SDRAM, Cards, etc.
3.6. CMOS RTC & ISA CFG CMOS SRAM
There're RTC & CMOS SRAM on board; they have a power supply from
external battery to keep the DATA inviolate & effective. The RTC is a REALTIME CLOCK device, which provides the DATE & TIME to system. The CMOS
SRAM is used for keeping the information of system configuration, so the
system can automatically boot OS every time. Since the lifetime of internal
battery is 5 years, the user can change a new Battery to replace old one after it
cannot work.
M Danger of explosion if battery is incorrectly replaced.
M Replace only with the same or equivalent type recommended by the
manufacturer.
M Dispose of used batteries according to the manufacturer’ s instructions.
3.7. SPEAKER CONNECTOR INSTALLATION
There is a speaker in AT system for sound purpose. The 4 - Pins connector
SPK is used to connect speaker. Anode connects +. Cathode connects−.
3.8. HARDWARE RESET SWITCH CONNECTOR INSTALLATION
The RESET switch on panel provides users with HARDWARE RESET function.
The system will do a cold start after the RESET switch is pushed and released
by user. The RESET switch is a 2 PIN connector and should be installed to
RST on main board.
3.9. POWER LED CONNECTOR INSTALLATION
System has power LED lamp on the panel of case. The power LED will light on
off or flash to indicate which step on the system. The connector should be
connected to PWR of main board in a correct direction.
3.10. IDE & ATAPI DEVICE INSTALLATION
There are two-Enhanced PCI IDE ports (IDE1, IDE2) on board, which following
3-7
Hardware Installation
ATAPI standard SPEC. Any one IDE port can connected to two ATAPI devices
(IDE Hard Disk, CD-ROM & Tape Driver), so total four ATAPI devices can exist
in a system. The HD is the active LED port for ATAPI devices.
3.11. PERIPHERAL DEVICE INSTALLATION
After the I/O device installation and jumpers setup, the mainboard can be
mounted into the case and fixed by screw. To complete the mainboard
installation, the peripheral device could be installed now. The basic system
needs a display interface card. If the PCI - Bus device is to be installed in the
system, any one of four PCI - Bus slots can be used.
3.12. KEYBOARD & PS/2 MOUSE INSTALLATION
The main board supports PS/2 Mouse. The BIOS will auto detect whether the
PS/2 Mouse is installed or not & assign IRQ12 for PS/2 Mouse port if it is
installed. After installing the peripheral device, the user should check
everything again, and prepare to power-on the system.
3-8
Loading...
