Preparing Your Computer

Computer motherboards and expansion cards contain very delicate Integrated Circuit (IC) chips.
To protect them against damage from static electricity, you should follow some precautions when­ever you work on your computer.

1. Unplug your computer when working on the inside.

2. Use a grounded wrist strap before handling computer components. If you do not have one,
touch both of your hands to a safely grounded object or to a metal object, such as the
power supply case.

3. Hold components by the edges and try not touch the IC chips, leads or connectors, or
other components.

4. Place components on a grounded antistatic pad or on the bag that came with the compo­nents whenever the components are separated from the system.

5. Ensure that the ATX power supply is switched off before you plug in or remove the ATX
power connector on the motherboard.

Installing the motherboard to the chassis

If the motherboard has mounting holes, but they don't line up with the holes on the base and
there are no slots to attach the spacers, do not become alarmed you can still attach the spacers to
the mounting holes. Just cut the bottom portion of the spacers (the spacer may be a little hard to
cut off, so be careful of your hands). In this way you can still attach the motherboard to the base
without worrying about short circuits. Sometimes you may need to use the plastic springs to iso­late the screw from the motherboard PCB surface, because the circuit wire may be near by the
hole. Be careful, don't let the screw contact any printed circuit write or parts on the PCB that are
near the fixing hole, otherwise it may damage the board or cause board malfunctioning.

Table of Contents

English

Chapter 1 Introduction ................................................................................................. 5

Chapter 2 BIOS Setup ............................................................................................... 19

Features Summary ................................................................................................................. 5

7VM400M-RZ Motherboard Layout ........................................................................................ 6

Block Diagram ........................................................................................................................ 7

Hardware Installation Process ................................................................................................ 8

Step 1: Set System Jumper (JP1) .......................................................................................... 8

Step 2: Install the Central Processing Unit (CPU) ................................................................. 9

Step 2-1: CPU Installation ........................................................................................................... 9

Step 2-2: CPU Cooling Fan Installation ...................................................................................... 9

Step 3: Install Memory Modules ........................................................................................... 10

Step 4: Install AGP Card....................................................................................................... 11

Step 5: Install I/O Peripherals Cabels .................................................................................. 11

Step 5-1: I/O Back Panel Introduction ....................................................................................... 11

Step 5-2: Connectors Introduction ............................................................................................. 12

The Main Menu (For example: BIOS Ver. : F5) .................................................................... 19

Standard CMOS Features .................................................................................................... 21

Advanced BIOS Features ..................................................................................................... 23

Integrated Peripherals ..........................................................................................................24

Power Management Setup ................................................................................................... 26

PnP/PCI Configurations ........................................................................................................ 27

PC Health Status .................................................................................................................. 28

Frequency/Voltage Control ................................................................................................... 29

Load Fail-Safe Defaults ........................................................................................................ 30

Load Optimized Defaults ...................................................................................................... 30

Set Supervisor/User Password............................................................................................. 31

Save & Exit Setup ................................................................................................................. 32

Exit Without Saving .............................................................................................................. 32

Chapter 3 Driver Installation....................................................................................... 33

- 4 -7VM400M-RZ Motherboard

Chapter 1 Introduction

Features Summary

CPU y Socket A for AMD Sempron™ / Athlon™ XP / Athlon™ / Duron™ processor

y 200/266/333MHz FSB
y Supports 1.4GHz and faster

Chipset y Northbridge : VIA KM400

y Southbridge : VIA VT8235 / VT8237R

Memory y 2 184-pin DDR DIMM sockets, supports up to 2GB DRAM (Max)

y Supports DDR333/DDR266/DDR200 DIMM
y Supports only 2.5V DDR SDRAM

Slots y 1 AGP slot supports 8X/4X(1.5V) mode

y 3 PCI slots support 33MHz & PCI 2.2 compliant

On-Board IDE y 2 IDE controller provide IDE HDD/CD-ROM(IDE1, IDE2) with PIO, Bus

Master (Ultra DMA33/ATA66/ATA100/ATA133) operation modes

y Can connect up to 4 IDE devices
On-Board Floppy y 1 Floppy port supports 2 FDD with 360K, 720K,1.2M, 1.44M and 2.88M bytes
On-Board Peripherals y 1 Parallel port supports Normal/EPP/ECP mode

y 1 Serial port (COMA), 1 VGA port, COMB on-board

y 6 USB 2.0/1.1 ports (2 x Rear, 4 x Front by cable)

y 1 Front Audio connector

y 1 PS/2 Keyboard

y 1 PS/2 Mouse

On-Board VGA y Built-in VIA KM400
On-Board LAN y Builit-in VIA VT6103 chipset

y 1 RJ45 port
On-Board Sound y VIA VT1617

y Supports 2/4/6-channel

y Line Out / Line In / Mic In

y SPDIF Out

y CD In / Game connector
BIOS y Licensed AWARD BIOS

y Supports Q-Flash

I/O Control y ITE8705
Hardware Monitor y CPU/System fan revolution detect

y CPU/System temperature detect

y System voltage detect

y CPU/System fan fail warning
Additional Features y Supports @BIOS

y Supports EasyTune
Overclocking y Over clock (CPU/DDR) by BIOS

y Over voltage (DDR/AGP) br BIOS

Form Factor y Micro ATX size form factor, 24.4cm x 22.3cm

™

™

English

Introduction- 5 -

7VM400M-RZ Motherboard Layout

English

KB_MS

COMA

22.3 cm

CPU_FAN

FDD

ATX

VGA

USB

MIC_IN

LPT

LINE_OUT

CODEC

LAN

LINE_IN

F_AUDIO

VT6103

CD_IN

SUR_CEN

IT8705

BIOS

SPDIF

AGP

COMB

SOCKET A

AGP 8X

GAME

VIA KM400

PCI3

PCI1

PCI2

BAT

F_USB1

7VM400M-RZ

DDR1

JP1

F_USB2

PWR_LED

DDR2

VIA

VT8235 /

VT8237R

IDE1

SYS_FAN

CLR_CMOS

F_PANEL

24.4 cm

IDE2

- 6 -7VM400M-RZ Motherboard

Block Diagram

English

AGP 4X/8X

3 PCI

PCICLK
(33MHz)

VGA Port

AGPCLK

66MHz

RJ45

PCI BUS 33MHz

6 Channel

VT6103

CODEC

MIC

LINE-IN

AC97 Link

6 USB

LINE-OUT

AMD-K7
Host CPU

System Bus
200/266/333MHz FSB

VIA

KM400

66MHz V_Link

VIA
VT8235 /
VT8237R

Ports

IDE Channels

TM

48 MHz

ATA33/66/

100/133

CPUCLK+/- (100/133/166MHz)

200/266/333MHz

HCLK+/- (100/133/166MHz)

NBGCLK66 MHz

33 MHz

14.318 MHz

BIOS

LPC BUS

IT8705

24 MHz

33 MHz

PS/2 KB/Mouse

DDR

Game Port

Floppy

LPT Port

2 COM Ports

PCICLK (33MHz)

USBCLK (48MHz)

14.318 MHz
33 MHz

CLK
GEN

HCLK+/- (100/133/166MHz)
CPUCLK+/- (100/133/166MHz)
AGPCLK (66MHz)

V_Link (66MHz)

Introduction- 7 -

Hardware Installation Process

To set up your computer, you must complete the following steps:

English

Step 1- Set System Jumper (JP1)
Step 2- Install the Central Processing Unit (CPU)
Step 3- Install Memory Modules
Step 4- Install Expansion Cards
Step 5- Install I/O Peripherals Cables

Step 2

Step 3

Step 5

Step 5

Step 4

Step 1

Step 1: Set System Jumper (JP1)

The system bus frequency can be switched at 100/133/166MHz by adjusting system jumper (JP1).
(The internal frequency depend on CPU.)

Short: 100MHz

1

Open: 133/166MHz

1

JP1

100MHz : Fix FSB 200MHz CPU
133/166MHz : Supports FSB 266/333MHz CPU

If you want to use a CPU with 200MHz FSB,
please set JP1 to 100MHz.

- 8 -7VM400M-RZ Motherboard

Step 2: Install the Central Processing Unit (CPU)

Before installing the processor, adhere to the following warning:

1. Please make sure the CPU type is supported by the motherboard.

2. The processor will overheat without the heatsink and/or fan, resulting in permanent
irreparable damage.

3. If you do not match the CPU socket Pin 1 and CPU cut edge well, it will cause improper
installation. Please change the insert orientation.

4. Apply thermal grease between the processor and cooling fan.

5. Never run the processor without the heatsink properly and firmly attached. Permanent damage
will result.

6. Please set the CPU host frequency in accordance with your processor's specifications.
We don't recommend you to set the system bus frequency over the CPU's specification
because these specific bus frequencies are not the standard specifications for CPU, chipset
and most of the peripherals. Whether your system can run under these specific bus frequencies
properly will depend on your hardware configurations, including CPU, Memory, Cards…etc.

Step 2-1: CPU Installation

Socket Actuation Lever

Figure 2.
Locate Pin 1 in the socket and look
for a cut edge on the CPU upper

corner. Insert the CPU into the
Figure 1.
Pull the rod to the 90-degree
directly.

socket. (Do not force the CPU into the socket.) Then move the socket
lever to the locked position while holding pressure on the center of the
CPU.

English

Step 2-2: CPU Cooling Fan Installation

Figure 1.
Apply the thermal tape(or grease)
to provide better heat conduction
between your CPU and cooling
fan.

Figure 2.
Fasten the cooling fan support­ing-base onto the CPU socket on
the motherboard.

- 9 -

Figure 3.
Make sure the CPU fan is plugged
to the CPU fan connector, than the
install completely.

Hardware Installation Process

Step 3: Install Memory Modules

English

The motherboard has 2 dual inline memory module (DIMM) sockets. The BIOS will automatically detects
memory type and size. To install the memory module, just push it vertically into the DIMM socket. The DIMM
module can only fit in one direction due to the notch. Memory size can vary between sockets.

Before installing the memory modules, adhere to the following warning:

1. Please note that the DIMM module can only fit in one direction due to the one notch. Wrong
orientation will cause improper installation. Please change the insert orientation.

Notch

DDR

1. The DIMM socket has a notch, so the DIMM memory
module can only fit in one direction.

2. Insert the DIMM memory module vertically into the
DIMM socket. Then push it down.

3. Close the plastic clip at both edges of the DIMM
sockets to lock the DIMM module.
Reverse the installation steps when you wish to re­move the DIMM module.

- 10 -7VM400M-RZ Motherboard

Step 4: Install AGP Card

1. Read the relate AGP card's instruction document before install the AGP card into the computer.

2. If your AGP card has "AGP 4X/8X(1.5V) notch"(show below), please make sure your AGP card is AGP
4X/8X(1.5V).

AGP 4X/8X notch

3. Please carefully pull out the small white-drawable bar at the end of the AGP slot when you try to install/
uninstall the AGP card. Please align the AGP card to the onboard AGP slot and press firmly down on the
slot. Make sure your AGP card is locked by the small white-drawable bar.

Step 5: Install I/O Peripherals Cables

Step 5-1: I/O Back Panel Introduction

X

Y

\

^

English

[

Z

]

X PS/2 Keyboard and PS/2 Mouse connector

This connector supports standard PS/2 keyboard and PS/2 mouse.

Y Parallel port (LPT)

Device like printer can be connected to Parallel port.

Z Serial port (COMA)

Mouse and modem etc. can be connected to Serial port.

[ VGA port

Monitor can be connected to VGA port.

\ LAN port

LAN is fast Ethernet with 10/100Mbps speed.

] USB port

Before you connect your device(s) into USB connector(s), please make sure your device(s) such as USB
keyboard, mouse, scanner, zip, speaker...etc. Have a standard USB interface. Also make sure your OS
supports USB controller. If your OS does not support USB controller, please contact OS vendor for
possible patch or driver upgrade. For more information please contact your OS or device(s) vendors.

^ Line In jack

Devices like CD-ROM, walkman etc. can be connected to Line In jack.

- 11 -

Hardware Installation Process

_

`

_ Line Out jack

` MIC In jack

English

Step 5-2: Connectors Introduction

Connect the stereo speakers or earphone to this connector.

Microphone can be connect to MIC In jack.
After installation of the audio driver, you are able to use 2/4/6-channel audio feature by software selection.
You can connect "Front speaker" to "Line Out" jack, Connect "Rear speaker" to "Line In" jack and con­nect "Center/Subwoofer" to "MIC In" jack.

2

1

4

5

8

11

9

1) ATX

2) CPU_FAN

3) SYS_FAN

4) FDD

5) IDE1 / IDE2

6) PWR_LED

7) F_PANEL

8) F_AUDIO

1210 14

9) SUR_CEN

10) SPDIF

11) CD_IN

12) COMB

13) GAME

14) F_USB1 / F_USB2

15) CLR_CMOS

16) BAT

- 12 -7VM400M-RZ Motherboard

3

15

16

613

7

1) ATX (ATX Power)

AC power cord should only be connected to your power supply unit after ATX power cable and other
related devices are firmly connected to the mainboard.

English

Pin No. Definition

11

20

1

1 3.3V

2 3.3V

3 GND

4 VCC

5 GND

6 VCC

7 GND

8 Power Good

9 5V SB (stand by +5V)

10

10 +12V

Pin No. Definition

11 3.3V

12 -12V

13 GND

14 PS_ON(soft on/off)

15 GND

16 GND

17 GND

18 -5V

19 VCC

20 VCC

2) CPU_FAN (CPU Fan Connector)

Please note, a proper installation of the CPU cooler is essential to prevent the CPU from running under
abnormal condition or damaged by overheating. The CPU fan connector supports Max. current up to
600 mA.

1

Pin No. Definition

1 GND

2 +12V

3 Sense

3) SYS_FAN (System Fan Connector)

This connector allows you to link with the cooling fan on the system case to lower the system temperature.

1

- 13 -

Pin No. Definition

1 GND

2 +12V

3 Sense

Hardware Installation Process

4) FDD (Floppy Connector)

English

5) IDE1 / IDE2 (IDE1 / IDE2 Connector)

Please connect the floppy drive ribbon cables to FDD. It supports 360K, 1.2M, 720K, 1.44M and

2.88M bytes floppy disk types.
The red stripe of the ribbon cable must be the same side with the Pin1.

33

34

1

2

Please connect first hard disk to IDE1 and connect CD-ROM to IDE2.
The red stripe of the ribbon cable must be the same side with the Pin1.

40

2

IDE1

39

1

IDE2

6) PWR_LED

PWR_LED is connect with the system power indicator to indicate whether the system is on/off.
It will blink when the system enters suspend mode.

1

Pin No. Definition

1 MPD+

2 MPD-

3 MPD-

- 14 -7VM400M-RZ Motherboard

7) F_PANEL (2 x 10 pins Connector)

Please connect the power LED, PC speaker, reset switch and power switch etc. of your chassis front
panel to the F_PANEL connector according to the pin assignment below.

Message LED/Power/
Sleep LED

Power
Switch

Speaker Connector

PW+

MSG+

PW-

SPEAK+

MSG-

1

1

2
1

1

1

HD-

RES+

HD+

RES-

SPEAK-

1

20

19

NC

English

IDE Hard Disk

Active LED

Reset Switch

HD (IDE Hard Disk Active LED) Pin 1: LED anode(+)

Pin 2: LED cathode(-)

SPK (Speaker Connector) Pin 1: VCC(+)

Pin 2- Pin 3: NC

Pin 4: Data(-)

RES (Reset Switch) Open: Normal Operation

Close: Reset Hardware System

PW (Power Switch) Open: Normal Operation

Close: Power On/Off

MSG (Message LED/ Power/ Sleep LED) Pin 1: LED anode(+)

Pin 2: LED cathode(-)

NC NC

8) F_AUDIO (Front Audio Connector)

If you want to use Front Audio connector, you must remove 5-6, 9-10 Jumper.
In order to utilize the front audio header, your chassis must have front audio connector. Also please
make sure the pin assigment on the cable is the same as the pin assigment on the MB header. To find
out if the chassis you are buying support front audio connector, please contact your dealer. Please note,
you can have the alternative of using front audio connector or of using rear audio connector to play
sound.

1

2

109

Pin No. Definition

1 MIC

2 GND

3 MIC_BIAS

4 Power

5 Front Audio (R)

6 Rear Audio (R)

7 Reserved

8 No Pin

9 Front Audio (L)

10 Rear Audio (L)

- 15 -

Hardware Installation Process

9) SUR_CEN (Surround Center Connector)

Please contact your nearest dealer for optional SUR_CEN cable.

English

10) SPDIF (SPDIF Out Connector)

2

1

5

6

Pin No. Definition

1 SUR OUTL

2 SUR OUTR

3 GND

4 No Pin

5 CENTER_OUT

6 BASS_OUT

The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to
an external Dolby Digital Decoder. Use this feature only when your stereo system has digital input
function. Be careful with the polarity of the SPDIF connector. Check the pin assignment carefully while
you connect the SPDIF cable, incorrect connection between the cable and connector will make the
device unable to work or even damage it. For optional SPDIF cable, please contact your local dealer.

Pin No. Definition

261

5

1 VCC

2 No Pin

3 SPDIF

4NC

5 GND

6 GND

11) CD_IN (CD In Connector)

Connect CD-ROM or DVD-ROM audio out to the connector.

- 16 -7VM400M-RZ Motherboard

1

Pin No. Definition

1 CD-L

2 GND

3 GND

4 CD-R

12) COMB (COM B Connector)

Be careful with the polarity of the COMB connector. Check the pin assignment carefully while you
connect the COMB cable, incorrect connection between the cable and connector will make the device
unable to work or even damage it. For optional COMB cable, please contact your local dealer.

Pin No. Definition

1 NDCDB-

2

19

10

2 NSINB

3 NSOUTB

4 NDTRB-

5 GND

6 NDSRB-

7 NRTSB-

8 NCTSB-

9 NRIB-

10 No Pin

13) GAME (Game Connector)

This connector supports joystick, MIDI keyboard and other relate audio devices. Check the pin assign­ment while you connect the game cables. Please contact your nearest dealer for optional game cables.

English

2

115

16

Pin No. Definition

1 VCC

2 GRX1_R

3 GND

4 GPSA2

5 VCC

6 GRX2_R

7 GRY2_R

8 MSI_R

Pin No. Definition

9 GPSA1

10 GND

11 GRY1_R

12 VCC

13 GPSB1

14 MSO_R

15 GPSB2

16 No Pin

14) F_USB1 / F_USB2 (Front USB Connector)

Be careful with the polarity of the front USB connector. Check the pin assignment carefully while you
connect the front USB cable, incorrect connection between the cable and connector will make the de­vice unable to work or even damage it. For optional front USB cable, please contact your local dealer.

Pin No. Definition

1 Power

2

1

10

9

- 17 -

2 Power

3 USB Dx-

4 USB Dy-

5 USB Dx+

6 USB Dy+

7 GND

8 GND

9 No Pin

10 NC

Hardware Installation Process

15) CLR_CMOS (Clear CMOS)

You may clear the CMOS data to its default values by this jumper. To clear CMOS, temporarily short
1-2 pin. Default doesn't include the "Shunter" to prevent from improper use this jumper.

English

16) BAT (Battery)

Close: Clear CMOS

1

Open: Normal

1

CAUTION

Danger of explosion if battery is incorrectly
replaced.
Replace only with the same or equivalent type
recommended by the manufacturer.
Dispose of used batteries according to the
manufacturer's instructions.

If you want to erase CMOS...

1. Turn OFF the computer and unplug the power cord.

2. Remove the battery, wait for 30 seconds.

3. Re-install the battery.

4. Plug the power cord and turn ON the computer.

- 18 -7VM400M-RZ Motherboard

Chapter 2 BIOS Setup

BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the
basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it
retains the Setup information when the power is turned off.

ENTERING SETUP

Powering ON the computer and pressing <Del> immediately will allow you to enter Setup. If you require
more advanced BIOS settings, please go to "Advanced BIOS" setting menu. To enter Advanced BIOS
setting menu, press "Ctrl+F1" key on the BIOS screen.

CONTROL KEYS

< >< >< >< > Move to select item
<Enter> Select Item
<Esc> Main Menu - Quit and not save changes into CMOS Status Page Setup Menu

and Option Page Setup Menu - Exit current page and return to Main Menu
<+/PgUp> Increase the numeric value or make changes
<-/PgDn> Decrease the numeric value or make changes
<F1> General help, only for Status Page Setup Menu and Option Page Setup Menu
<F2> Item Help
<F5> Restore the previous CMOS value from CMOS, only for Option Page Setup Menu
<F6> Load the file-safe default CMOS value from BIOS default table
<F7> Load the Optimized Defaults
<F8> Q-Flash utility
<F9> System Information
<F10> Save all the CMOS changes, only for Main Menu

Main Menu

The on-line description of the highlighted setup function is displayed at the bottom of the screen.

Status Page Setup Menu / Option Page Setup Menu

Press F1 to pop up a small help window that describes the appropriate keys to use and the possible
selections for the highlighted item. To exit the Help Window press <Esc>.

English

The Main Menu (For example: BIOS Ver. : F5)

Once you enter Award BIOS CMOS Setup Utility, the Main Menu (as figure below) will appear on the
screen. The Main Menu allows you to select from eight setup functions and two exit choices. Use
arrow keys to select among the items and press <Enter> to accept or enter the sub-menu.

CMOS Setup Utility-Copyright (C) 1984-2004 Award Software

` Standard CMOS Features

` Advanced BIOS Features

` Integrated Peripherals

` Power Management Setup

` PnP/PCI Configurations

` PC Health Status

` Frequency/Voltage Control

ESC: Quit KLJI: Select Item

F8: Q-Flash F10: Save & Exit Setup

Time, Date, Hard Disk Type...

Load Fail-Safe Defaults

Load Optimized Defaults

Set Supervisor Password

Set User Password

Save & Exit Setup

Exit Without Saving

- 19 - BIOS Setup

If you can't find the setting you want, please press "Ctrl+F1" to search the advanced

option hidden.

English

• Standard CMOS Features

• Advanced BIOS Features

• Integrated Peripherals

• Power Management Setup

• PnP/PCI Configuration

• PC Health Status

• Frequency/Voltage Control

• Load Fail-Safe Defaults

• Load Optimized Defaults

• Set Supervisor Password

• Set User Password

• Save & Exit Setup

• Exit Without Saving

This setup page includes all the items in standard compatible BIOS.

This setup page includes all the items of Award special enhanced features.

This setup page includes all onboard peripherals.

This setup page includes all the items of Green function features.

This setup page includes all the configurations of PCI & PnP ISA resources.

This setup page is the System auto detect Temperature, voltage, fan, speed.

This setup page is control CPU clock and frequency ratio.

Fail-Safe Defaults indicates the value of the system parameters which the system would be in safe
configuration.

Optimized Defaults indicates the value of the system parameters which the system would be in
best performance configuration.

Change, set, or disable password. It allows you to limit access to the system and Setup, or just
to Setup.

Change, set, or disable password. It allows you to limit access to the system.

Save CMOS value settings to CMOS and exit setup.

Abandon all CMOS value changes and exit setup.

- 20 -7VM400M-RZ Motherboard

Standard CMOS Features

CMOS Setup Utility-Copyright (C) 1984-2004 Award Software

Date (mm:dd:yy) Tue , Nov 2 2004
Time (hh:mm:ss) 22:31:24

` IDE Primary Master [None]
` IDE Primary Slave [None]
` IDE Secondary Master [None]
` IDE Secondary Slave [None]

Drive A [1.44M, 3.5"]
Drive B [None]
Floppy 3 Mode Suport [Disabled]

Halt On [All, But Keyboard]

Base Memory 640K
Extended Memory 127M
Total Memory 128M

KLJI: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help

F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

Date

The date format is <week>, <month>, <day>, <year>.

Week The week, from Sun to Sat, determined by the BIOS and is display only
Month The month, Jan. Through Dec.
Day The day, from 1 to 31 (or the maximum allowed in the month)
Year The year, from 1999 through 2098

Time

The times format in <hour> <minute> <second>. The time is calculated base on the 24-hour

military-time clock. For example, 1 p.m. is 13:00:00.

IDE Primary Master, Slave / IDE Secondary Master, Slave

The category identifies the types of hard disk from drive C to F that has been installed in the
computer. There are two types: auto type, and manual type. Manual type is user-definable; Auto type
which will automatically detect HDD type.
Note that the specifications of your drive must match with the drive table. The hard disk will not work
properly if you enter improper information for this category.
If you select User Type, related information will be asked to enter to the following items. Enter the information
directly from the keyboard and press <Enter>. Such information should be provided in the documenta­tion form your hard disk vendor or the system manufacturer.

Cylinder Number of cylinders
Head Number of heads
Precomp Write precomp
Landing Zone Landing zone
Sector Number of sectors

If a hard disk has not been installed, select NONE and press <Enter>.

Standard CMOS Features

Item Help

Menu Level `
Change the day, month,
year

<Week>
Sun. to Sat.

<Month>
Jan. to Dec.

<Day>
1 to 31 (or maximum
allowed in the month)

<Year>
1999 to 2098

English

- 21 - BIOS Setup

computer.

English

Drive A / Drive B

The category identifies the types of floppy disk drive A or drive B that has been installed in the

None No floppy drive installed
360K, 5.25" 5.25 inch PC-type standard drive; 360K byte capacity.

1.2M, 5.25" 5.25 inch AT-type high-density drive; 1.2M byte capacity
(3.5 inch when 3 Mode is Enabled).

720K, 3.5" 3.5 inch double-sided drive; 720K byte capacity

1.44M, 3.5" 3.5 inch double-sided drive; 1.44M byte capacity.

2.88M, 3.5" 3.5 inch double-sided drive; 2.88M byte capacity.

Floppy 3 Mode Support (for Japan Area)

Disabled Normal Floppy Drive. (Default value)
Drive A Drive A is 3 mode Floppy Drive.
Drive B Drive B is 3 mode Floppy Drive.
Both Drive A & B are 3 mode Floppy Drives.

Halt on

The category determines whether the computer will stop if an error is detected during power up.

No Errors The system boot will not stop for any error that may be detected and you

will be prompted.
All Errors Whenever the BIOS detects a non-fatal error the system will be stopped.
All, But Keyboard The system boot will not stop for a keyboard error; it will stop for all other

errors. (Default value)
All, But Diskette The system boot will not stop for a disk error; it will stop for all other errors.
All, But Disk/Key The system boot will not stop for a keyboard or disk error; it will stop for all

other errors.

Memory

The category is display-only which is determined by POST (Power On Self Test) of the BIOS.

Base Memory

The POST of the BIOS will determine the amount of base (or conventional) memory installed
in the system.
The value of the base memory is typically 512K for systems with 512K memory installed on
the motherboard, or 640K for systems with 640K or more memory installed on the motherboard.

Extended Memory

The BIOS determines how much extended memory is present during the POST.
This is the amount of memory located above 1 MB in the CPU's memory address map.

Total Memory

This item displays the memory size that used.

- 22 -7VM400M-RZ Motherboard

Advanced BIOS Features

CMOS Setup Utility-Copyright (C) 1984-2004 Award Software

First Boot Device [Floppy]
Second Boot Device [HDD-0]
Third Boot Device [CDROM]
Password Check [Setup]

KLJI: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help

F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

First / Second / Third Boot Device

Floppy Select your boot device priority by Floppy.
LS120 Select your boot device priority by LS120.
HDD-0~3 Select your boot device priority by HDD-0~3.
SCSI Select your boot device priority by SCSI.
CDROM Select your boot device priority by CDROM.
ZIP Select your boot device priority by ZIP.
USB-FDD Select your boot device priority by USB-FDD.
USB-ZIP Select your boot device priority by USB-ZIP.
USB-CDROM Select your boot device priority by USB-CDROM.
USB-HDD Select your boot device priority by USB-HDD.
LAN Select your boot device priority by LAN.
Disabled Select your boot device priority by Disabled.

Password Check

System The system can not boot and can not access to Setup page will be denied if the

Setup The system will boot, but access to Setup will be denied if the correct password

correct password is not entered at the prompt.

is not entered at the prompt. (Default value)

Advanced BIOS Features

Item Help

Menu Level `
Select Boot Device
priority

[Floppy]
Boot from floppy

[LS120]
Boot from LS120

[HDD-0]
Boot from First HDD

[HDD-1]
Boot from Second HDD

English

- 23 - BIOS Setup

Integrated Peripherals

English

card is used, please set at "Disabled".

card is used, please set at "Disabled".

CMOS Setup Utility-Copyright (C) 1984-2004 Award Software

OnChip IDE Channel0 [Enabled]
OnChip IDE Channel1 [Enabled]
AC97 Audio [Auto]
VIA Onboard LAN [Enabled]
USB 1.1 Controller [Enabled]
USB 2.0 Controller [Enabled]
USB Keyboard Support [Disabled]
USB Mouse Support [Disabled]
On-Chip LAN Boot ROM [Disabled]
Onboard Serial Port 1 [3F8/IRQ4]
Onboard Serial Port 2 [2F8/IRQ3]
Onboard Parallel Port [378/IRQ7]
Parallel Port Mode [SPP]
Game Port Address [201]
Midi Port Address [Disabled]

x Midi Port IRQ 10

KLJI: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help

F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

Integrated Peripherals

Item Help

Menu Level `

If a hard disk
controller card is
used, set at Disabled

[Enabled]
Enable onboard IDE
channel

[Disabled]
Disable onboard IDE
channel

OnChip IDE Channel0

When set at "Enabled", it allows you to use the onboard primary PCI IDE. If a hard disk controller

Enabled Enable onboard 1st channel IDE port. (Default value)
Disabled Disable onboard 1st channel IDE port.

OnChip IDE Channel1

When set at "Enabled", it allows you to use the onboard secondary PCI IDE. If a hard disk controller

Enabled Enable onboard 2nd channel IDE port. (Default value)
Disabled Disable onboard 2nd channel IDE port.

AC97 Audio

Enabled Enable onboard AC'97 audio function. (Default value)
Disabled Disable this function.

VIA Onboard LAN

Enabled Enable onboard LAN function. (Default value)
Disabled Disable this function.

USB 1.1 Controller

Disable this function if you are not using the onboard USB feature.

Enabled Enable USB 1.1 controller. (Default value)
Disabled Disable USB 1.1 controller.

USB 2.0 Controller

Disable this function if you are not using the onboard USB feature.

Enabled Enable USB 2.0 controller. (Default value)
Disabled Disable USB 2.0 controller.

USB Keyboard Support

Enabled Enable USB keyboard support.
Disabled Disable USB keyboard support. (Default value)

- 24 -7VM400M-RZ Motherboard

USB Mouse Support

Enabled Enable USB mouse support.
Disabled Disable USB mouse support. (Default value)

On-Chip LAN Boot ROM

This function decide whether to invoke the boot ROM of the onboard LAN chip.

Disabled Disable this function. (Default Value)
Enabled Enable this function.

Onboard Serial Port 1

Auto BIOS will automatically setup the port 1 address.
3F8/IRQ4 Enable onboard Serial port 1 and address is 3F8. (Default value)
2F8/IRQ3 Enable onboard Serial port 1 and address is 2F8.
3E8/IRQ4 Enable onboard Serial port 1 and address is 3E8.
2E8/IRQ3 Enable onboard Serial port 1 and address is 2E8.
Disabled Disable onboard Serial port 1.

Onboard Serial Port 2

Auto BIOS will automatically setup the port 2 address.
3F8/IRQ4 Enable onboard Serial port 2 and address is 3F8.
2F8/IRQ3 Enable onboard Serial port 2 and address is 2F8. (Default value)
3E8/IRQ4 Enable onboard Serial port 2 and address is 3E8.
2E8/IRQ3 Enable onboard Serial port 2 and address is 2E8.
Disabled Disable onboard Serial port 2.

Onboard Parallel port

This feature allows you to select from a given set of parameters if the parallel port uses the onboard

I/O controller.

378/IRQ7 Enable onboard LPT port and address is 378/IRQ7. (Default value)
278/IRQ5 Enable onboard LPT port and address is 278/IRQ5.
Disabled Disable onboard LPT port.
3BC/IRQ7 Enable onboard LPT port and address is 3BC/IRQ7.

Parallel Port Mode

SPP Using Parallel port as Standard Parallel Port. (Default value)
EPP Using Parallel port as Enhanced Parallel Port.
ECP Using Parallel port as Extended Capabilities Port.
ECP+EPP Using Parallel port as ECP & EPP mode.

Game Port Address

201 Set Game Port Address to 201. (Default value)
209 Set Game Port Address to 209.
Disabled Disable this function.

Midi Port Address

300 Set Midi Port Address to 300.
330 Set Midi Port Address to 330.
Disabled Disable this function. (Default value)

Midi Port IRQ

5 Set Midi Port IRQ to 5.
10 Set Midi Port IRQ to 10. (Default value)

English

- 25 - BIOS Setup

Power Management Setup

English

CMOS Setup Utility-Copyright (C) 1984-2004 Award Software

ACPI Suspend Type [S1(POS)]

x USB Device Wake-Up from S3 Disabled

Power LED in S1 state [Blinking]
Soft-Off by PWRBTN [Instant-Off]
AC BACK Function [Soft-Off]
Keyboard Power On [Disabled]
Mouse Power On [Disabled]
PME Event Wake Up [Enabled]
ModemRingOn/WakeOnLan [Enabled]

Resume by Alarm [Disabled]

x Date (of Month) Alarm Everyday
x Time (hh:mm:ss) Alarm 0 : 0 : 0

KLJI: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help

F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

Power Management Setup

Item Help

Menu Level `
[S1]
Set suspend type to
Power On Suspend under
ACPI OS

[S3]
Set suspend type to
Suspend to RAM under
ACPI OS

ACPI Suspend Type

S1(POS) Set ACPI suspend type to S1. (Default value)
S3(STR) Set ACPI suspend type to S3.

USB Device Wake-Up From S3

This function will available when "ACPI Suspend Type" set at "S3/STR".

Disabled USB device can't wake up system from S3.
Enabled USB device can wake up system from S3. (Default value)

Power LED in S1 state

Blinking In standby mode(S1), power LED will blink. (Default value)
Dual/Off In standby mode(S1):

a. If you use single color LED, power LED will ture off.
b. If you use dual color LED, power LED will ture to another color.

Soft-off by PWR-BTTN

Instant-off Press power button then Power off instantly. (Default value)
Delay 4 Sec. Press power button 4 sec to Power off. Enter suspend if button is pressed

less than 4 sec.

AC BACK Function

Soft-Off Always in Off state when AC back to the system. (Default value)
Full-On Always power on the system when AC back.
Memory System power on depends on the status before AC lost.

Keyboard Power On

Disabled Disable this function. (Default value)
Password Enter from 1 to 5 characters to set the keyboard power on password.
Keyboard 98 If your keyboard has a "POWER Key" button, you can press the key to

power on your system.

Mouse Power On

Disabled Disabled this function. (Default value)
Enabled Power on system by mouse event.

- 26 -7VM400M-RZ Motherboard

PME Event Wake Up

When set at Enabled, any PCI-PM event can awake the system from a PCI-PM controlled stated.

This feature requires an ATX power supply that provides at least 1A on the +5VSB lead.

Disabled Disable this function.
Enabled Enable PME as wake up event. (Default value)

ModemRingOn/WakeOnLan

An incoming call via modem or an input signal comes from the other client server on the LAN can

awake the system from any suspend state.

Disabled Disable Modem Ring on function.
Enabled Enable Modem Ring on function. (Default value)

Resume by Alarm

You can set "Resume by Alarm" item to enabled and key in Data/time to power on system.

Disabled Disable this function. (Default Value)
Enabled Enable alarm function to POWER ON system.

If RTC Alarm Lead To Power On is Enabled.
Date (of Month) Alarm : Everyday, 1~31
Time (hh: mm: ss) Alarm : (0~23) : (0~59) : (0~59)

KB Power ON Password

Enter Input password (from 1 to 5 characters) and press Enter to set the keyboard

power on password.

PnP/PCI Configurations

CMOS Setup Utility-Copyright (C) 1984-2004 Award Software

PCI 1 IRQ Assignment [Auto]

PCI 2 IRQ Assignment [Auto]

PCI 3 IRQ Assignment [Auto]

PnP/PCI Configurations

Item Help

Menu Level `

Device(s) using this
INT:

Display Cntrlr

-Bus 1 Dev 0 Func 0

English

KLJI: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help

F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

PCI 1 IRQ Assignment

Auto Auto assign IRQ to PCI 1. (Default value)
3,4,5,7,9,10,11,12,14,15 Set IRQ 3,4,5,7,9,10,11,12,14,15 to PCI 1.

PCI 2 IRQ Assignment

Auto Auto assign IRQ to PCI 2. (Default value)
3,4,5,7,9,10,11,12,14,15 Set IRQ 3,4,5,7,9,10,11,12,14,15 to PCI 2.

PCI 3 IRQ Assignment

Auto Auto assign IRQ to PCI 3. (Default value)
3,4,5,7,9,10,11,12,14,15 Set IRQ 3,4,5,7,9,10,11,12,14,15 to PCI 3.

- 27 - BIOS Setup

PC Health Status

English

CMOS Setup Utility-Copyright (C) 1984-2004 Award Software

Vcore OK
25VSTR OK
+3.3V OK
+12V OK
Current System Temperature 32oC
Current CPU Temperature 45oC
Current CPU FAN Speed 4687 RPM
Current SYSTEM FAN Speed 0 RPM

CPU FAN Fail Warning [Disabled]
SYSTEM FAN Fail Warning [Disabled]

KLJI: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help

F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

PC Health Status

Item Help

Menu Level `

Current Voltage (V) Vcore / 25VSTR / +3.3V / +12V

Detect system's voltage status automatically.

Current System/CPU Temperature

Detect system/CPU temperature automatically.

Current CPU/SYSTEM FAN Speed (RPM)

Detect CPU/system Fan speed status automatically.

CPU FAN Fail Warning

Disabled Fan warning function disable. (Default value)
Enabled Fan warning function enable.

SYSTEM FAN Fail Warning

Disabled Fan warning function disable. (Default value)
Enabled Fan warning function enable.

- 28 -7VM400M-RZ Motherboard

Frequency/Voltage Control

CMOS Setup Utility-Copyright (C) 1984-2004 Award Software

Auto Detect PCI/DIMM Clk [Enabled]

Spread Specturm [Enabled]

CPU Host Clock Control [Disabled]

x CPU Clock 133MHz

DRAM Clock(MHz) [By SPD]

AGP OverVoltage Control [Auto]

DIMM OverVoltage Control [Auto]

KLJI: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help

F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

Incorrect using these features may cause your system broken. For power End-User use only!

Auto Detect PCI/DIMM Clk

Disabled Disable this function.
Enabled Auto detect PCI/DIMM clock. (Default value)

Spread Spectrum

Disabled Disable this function.
Enabled Enable clock spread spectrum. (Default value)

CPU Host Clock Control

Note: If system hangs up before enter CMOS setup utility, wait for 20 sec for times out reboot.

When time out occur, system will reset and run at CPU default Host clock at next boot.

Disabled Disable CPU Host Clock Control. (Default value)
Enabled Enable CPU Host Clock Control.

CPU Clock

133MHz ~ 165MHz Set CPU Host Clock from 100MHz to 165MHz.

DRAM Clock (MHz)

Wrong frequency may make system can't boot, clear CMOS to overcome wrong frequency issue.

By SPD Set memory frequency by DRAM SPD data. (Default value)
133-DDR266 If you use DDR266 DRAM module, please set at "133-DDR266".
166-DDR333 If you use DDR333 DRAM module, please set at "166-DDR333".

AGP OverVoltage Control

Increase AGP voltage may get stable for over-clock. But it may damage to AGP card when enable

this feature.

Auto Supply voltage as AGP required. (Default value)
+0.1V Increase AGP voltage +0.1V.
+0.2V Increase AGP voltage +0.2V.
+0.3V Increase AGP voltage +0.3V.

Frequency/Voltage Control

Item Help

Menu Level `

English

- 29 - BIOS Setup

when enable this feature.

English

Load Fail-Safe Defaults

Fail-Safe defaults contain the most appropriate values of the system parameters that allow minimum
system performance.

DIMM OverVoltage Control

Increase DIMM voltage may get stable for over-clock. But it may damage to memory module

Auto Supply voltage as DIMM required. (Default value)
+0.1V Increase DIMM voltage +0.1V.
+0.2V Increase DIMM voltage +0.2V.
+0.3V Increase DIMM voltage +0.3V.

CMOS Setup Utility-Copyright (C) 1984-2004 Award Software

` Standard CMOS Features

` Advanced BIOS Features

` Integrated Peripherals

` Power Management Setup

` PnP/PCI Configurations

` PC Health Status

` Frequency/Voltage Control

ESC: Quit KLJI: Select Item

F8: Q-Flash F10: Save & Exit Setup

Load Fail-Safe Defaults (Y/N)? N

Load Fail-Safe Defaults

Load Fail-Safe Defaults

Load Optimized Defaults

Set Supervisor Password

Set User Password

Save & Exit Setup

Exit Without Saving

Load Optimized Defaults

CMOS Setup Utility-Copyright (C) 1984-2004 Award Software

` Standard CMOS Features

` Advanced BIOS Features

` Integrated Peripherals

` Power Management Setup

` PnP/PCI Configurations

` PC Health Status

` Frequency/Voltage Control

ESC: Quit KLJI: Select Item

F8: Q-Flash F10: Save & Exit Setup

Load Optimized Defaults (Y/N)? N

Load Optimized Defaults

Selecting this field loads the factory defaults for BIOS and Chipset Features which the system automatically
detects.

Load Fail-Safe Defaults

Load Optimized Defaults

Set Supervisor Password

Set User Password

Save & Exit Setup

Exit Without Saving

- 30 -7VM400M-RZ Motherboard

Set Supervisor/User Password

CMOS Setup Utility-Copyright (C) 1984-2004 Award Software

` Standard CMOS Features

` Advanced BIOS Features

` Integrated Peripherals

` Power Management Setup

` PnP/PCI Configurations

` PC Health Status

` Frequency/Voltage Control

ESC: Quit KLJI: Select Item

F8: Q-Flash F10: Save & Exit Setup

Enter Password:

Change/Set/Disable Password

When you select this function, the following message will appear at the center of the screen to assist you
in creating a password.
Type the password, up to eight characters, and press <Enter>. You will be asked to confirm the password.
Type the password again and press <Enter>. You may also press <Esc> to abort the selection and not
enter a password.
To disable password, just press <Enter> when you are prompted to enter password. A message
"PASSWORD DISABLED" will appear to confirm the password being disabled. Once the password is
disabled, the system will boot and you can enter Setup freely.
The BIOS Setup program allows you to specify two separate passwords:
SUPERVISOR PASSWORD and a USER PASSWORD. When disabled, anyone may access all BIOS
Setup program function. When enabled, the Supervisor password is required for entering the BIOS
Setup program and having full configuration fields, the User password is required to access only basic
items.
If you select "System" at "Password Check" in Advance BIOS Features Menu, you will be prompted
for the password every time the system is rebooted or any time you try to enter Setup Menu.
If you select "Setup" at "Password Check" in Advance BIOS Features Menu, you will be prompted only
when you try to enter Setup.

Load Fail-Safe Defaults

Load Optimized Defaults

Set Supervisor Password

Set User Password

Save & Exit Setup

Exit Without Saving

English

- 31 - BIOS Setup

Save & Exit Setup

English

Type "Y" will quit the Setup Utility and save the user setup value to RTC CMOS.
Type "N" will return to Setup Utility.

Exit Without Saving

CMOS Setup Utility-Copyright (C) 1984-2004 Award Software

` Standard CMOS Features

` Advanced BIOS Features

` Integrated Peripherals

` Power Management Setup

` PnP/PCI Configurations

` PC Health Status

` Frequency/Voltage Control

ESC: Quit KLJI: Select Item

F8: Q-Flash F10: Save & Exit Setup

CMOS Setup Utility-Copyright (C) 1984-2004 Award Software

` Standard CMOS Features

` Advanced BIOS Features

` Integrated Peripherals

` Power Management Setup

` PnP/PCI Configurations

` PC Health Status

` Frequency/Voltage Control

ESC: Quit KLJI: Select Item

F8: Q-Flash F10: Save & Exit Setup

Save to CMOS and EXIT (Y/N)? Y

Save & Exit Setup

Quit Without Saving (Y/N)? N

Abandon all Data

Load Fail-Safe Defaults

Load Optimized Defaults

Set Supervisor Password

Set User Password

Save & Exit Setup

Exit Without Saving

Load Fail-Safe Defaults

Load Optimized Defaults

Set Supervisor Password

Set User Password

Save & Exit Setup

Exit Without Saving

Type "Y" will quit the Setup Utility without saving to RTC CMOS.
Type "N" will return to Setup Utility.

- 32 -7VM400M-RZ Motherboard

Revision History

Chapter 3 Install Drivers

Install Drivers

Pictures below are shown in Windows XP

Insert the driver CD-title that came with your motherboard into your CD-ROM drive, the driver
CD-title will auto start and show the installation guide. If not, please double click the CD-ROM
device icon in "My computer", and execute the setup.exe.

Install Chipset Drivers

This page shows the drivers that need to be installed for the system. Click each item to install the driver
manually or switch to the to install the drivers automatically.

English

The "Xpress Install" uses the"Click and Go" technology to install the drivers automatically. Just select the
drivers you want then click the "GO" button. The will finish the installation for you automatically.

Massage: Some device drivers will restart
your system automatically. After restarting
your system the "Xpress Install" will
continue to install other drivers.

We recommend that you install all components in the list.

Driver Installation- 33 -

English

Item Description

 VIA 4IN1 Driver

 VIA KM400 VGA Driver

 USB Patch for WinXP

 VIA Lan Driver

 VIA AC97 Audio Driver

 VIA USB 2.0 Controller

Driver install finished !
You have to reboot system !

For INF, AGP, IDE and DMA driver.

For KM400 drvier.

This patch driver can help you to resolve the USB device wake up S3 hang up issue in XP.

For VIA Phy family Lan driver.

Audio driver for VIA codec chipset.

For VIA VT8233 (VT6203) / VIA VT8235 / VIA VT8237 / VIA VT8237R south bridge.

For USB2.0 driver support under Windows XP operating system, please use Windows Service
Pack. After install Windows Service Pack, it will show a question mark "?" in "Universal Serial Bus
controller" under "Device Manager". Please remove the question mark and restart the system
(System will auto-detect the right USB2.0 driver).

7VM400M-RZ Motherboard

- 34 -

Contact Us

English

 

 Taiwan (Headquarters)

 

GIGA-BYTE TECHNOLOGY CO., LTD.

Address: No.6, Bau Chiang Road, Hsin-Tien, Taipei Hsien,

Taiwan.

TEL: [phone]

FAX: [phone]

Tech. Support :

http://tw.giga-byte.com/TechSupport/ServiceCenter.htm

Non-Tech. Support(Sales/Marketing) :

http://ggts.gigabyte.com.tw/nontech.asp

WEB address (English): http://www.gigabyte.com.tw

WEB address (Chinese): http://chinese.giga-byte.com

 

 U.S.A.

 

G.B.T. INC.

Address: 17358 Railroad St, City of Industry, CA 91748.

TEL: [phone]

FAX: [phone]

Tech. Support :

http://www.giga-byte.com/TechSupport/ServiceCenter.htm

Non-Tech. Support(Sales/Marketing) :

http://ggts.gigabyte.com.tw/nontech.asp

WEB address : http://www.giga-byte.com

 

 Germany

 

G.B.T. TECHNOLOGY TRADING GMBH

Address: Friedrich-Ebert-Damm 112 22047 Hamburg

Deutschland

TEL: [phone] (Sales)

[phone] (Tech.)

FAX: [phone] (Sales)

[phone] (Tech.)

Tech. Support :

http://de.giga-byte.com/TechSupport/ServiceCenter.htm

Non-Tech. Support(Sales/Marketing) :

http://ggts.gigabyte.com.tw/nontech.asp

WEB address : http://www.gigabyte.de

 

 Japan

 

NIPPON GIGA-BYTE CORPORATION

WEB address : http://www.gigabyte.co.jp

 

 Singapore

 

GIGA-BYTE SINGAPORE PTE. LTD.

Tech. Support :

http://tw.giga-byte.com/TechSupport/ServiceCenter.htm

Non-Tech. Support(Sales/Marketing) :

http://ggts.gigabyte.com.tw/nontech.asp

 

 U.K.

 

G.B.T. TECH. CO., LTD.

Address: GUnit 13 Avant Business Centre 3 Third Avenue,

Denbigh West Bletchley Milton Keynes, MK1 1DR, UK, England

TEL: [phone]

FAX: [phone]

Tech. Support :

http://uk.giga-byte.com/TechSupport/ServiceCenter.htm

Non-Tech. Support(Sales/Marketing) :

http://ggts.gigabyte.com.tw/nontech.asp

WEB address : http://uk.giga-byte.com

 

 The Netherlands

 

GIGA-BYTE TECHNOLOGY B.V.

TEL: [phone]

NL Tech.Support: 0900-GIGABYTE (0900-44422983)

BE Tech.Support: 0900-84034

FAX: [phone]

Tech. Support :

http://nz.giga-byte.com/TechSupport/ServiceCenter.htm

Non-Tech. Support(Sales/Marketing) :

http://ggts.gigabyte.com.tw/nontech.asp

WEB address : http://www.giga-byte.nl

Driver Installation- 35 -

 

 China

 

NINGBO G.B.T. TECH. TRADING CO., LTD.

Tech. Support :

http://cn.giga-byte.com/TechSupport/ServiceCenter.htm

English

Non-Tech. Support(Sales/Marketing) :

http://ggts.gigabyte.com.tw/nontech.asp

WEB address : http://www.gigabyte.com.cn

Shanghai

TEL: [phone]

FAX: [phone]

Beijing

TEL: [phone]

FAX: [phone]

Wuhan

TEL: [phone]

FAX: [phone]

GuangZhou

TEL: [phone]

FAX: [phone]

Chengdu

TEL: [phone]

FAX: [phone]

Xian

TEL: [phone]

FAX: [phone]

Shenyang

TEL: [phone]

FAX: [phone]-809

 

 Australia

 

GIGABYTE TECHNOLOGY PTY. LTD.

Tech. Support :

http://www.giga-byte.com.au/TechSupport/ServiceCenter.htm

Non-Tech. Support(Sales/Marketing) :

http://ggts.gigabyte.com.tw/nontech.asp

WEB address : http://www.giga-byte.com.au

 

 France

 

GIGABYTE TECHNOLOGY FRANCES S.A.R.L.

Tech. Support :

http://tw.giga-byte.com/TechSupport/ServiceCenter.htm

Non-Tech. Support(Sales/Marketing) :

http://ggts.gigabyte.com.tw/nontech.asp

WEB address : http://www.gigabyte.fr

 

 Russia

 

Moscow Representative Office Of Giga-Byte Technology Co.,

Ltd.

Tech. Support :

http://tw.giga-byte.com/TechSupport/ServiceCenter.htm

Non-Tech. Support(Sales/Marketing) :

http://ggts.gigabyte.com.tw/nontech.asp

WEB address : http://www.gigabyte.ru

 

 Poland

 

Representative Office Of Giga-Byte Technology Co., Ltd.

POLAND

Tech. Support :

http://tw.giga-byte.com/TechSupport/ServiceCenter.htm

Non-Tech. Support(Sales/Marketing) :

http://ggts.gigabyte.com.tw/nontech.asp

WEB address : http://www.gigabyte.pl

7VM400M-RZ Motherboard

- 36 -
