OLYMPIA®® OL5800
OWNER’S MANUAL
OL5800 User Manual
1
Copyright
© 2003, Wave Industries Ltd. All Rights Reserved.
Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright
laws.
First Edition: September 2003
Trademark Information
Olympia® is a registered trademark of Olympia International Holdings Ltd.
Disclaimer
The information contained in this document is subject to change without notice. Wave Industries makes no warranty of any
kind with respect to this information. Wave Industries shall not be liable for any direct, indirect, incidental, consequential, or
other damage alleged in connection with the furnishing or use of this information.
Printed in China
OL5800 User Manual
2
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS..........................................................4
SAFETY INSTRUCTIONS FOR BATTERIES....................................................5
1 Cordless Phone Features................................................................................6
2 Caller ID Features..........................................................................................6
3 Set Up...........................................................................................................7
4 Olympia OL5800 – Quick Programming Guide ..............................................7
5 Installation and Charging of the Battery Pack ..................................................8
6 Power Up....................................................................................................10
7 Answering Calls ...........................................................................................10
8 Make a Call.................................................................................................10
9 Terminate a Call...........................................................................................10
10 Short Paging (To Locate the Handset)..........................................................10
11 Long Paging.................................................................................................11
12 Selecting System Language...........................................................................11
13 Setting Local Area Code..............................................................................11
14 Setting Tone/Pulse (Preset to Tone)..............................................................11
15 Setting RINGER ON/OFF...........................................................................12
16 Setting Display Contrast...............................................................................12
17 Caller ID Operation.....................................................................................12
18 Visual Message Notification.........................................................................17
19 Speed Dial Memory (0…9) .........................................................................18
20 Pre-dialing ( Handset OFF ).........................................................................20
21 Redial with Handset OFF.............................................................................21
22 Dialing Digits................................................................................................21
23 Call Timer....................................................................................................21
24 Battery/Voltage Low Detection....................................................................23
25 Mute............................................................................................................23
26 Changing Volume.........................................................................................23
27 Translation Table..........................................................................................24
28 Consumer Information (including Warranty) ..................................................25
OL5800 User Manual
3
IMPORTANT SAFETY INSTRUCTIONS
BEFORE USING YOUR TELEPHONE EQUIPMENT, BASIC SAFETY PRECAUTIONS SHOULD
ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND INJURY TO
PERSONS, INCLUDING THE FOLLOWING
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
4. Do not use this product near water, for ex ample, near a bath tub, wash bowl, kitchen sink, laundry tub, in a wet
basement, or near a swimming pool.
5. Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious damage to the
product.
6. Slots and openings in the cabinet and the back or bottom are provided for ventilation. To protect it from
overheating, these openings must not be blocked or covered. The openings should never be blocked by placing
the product on the bed, sofa, rug, or other similar surface. This product should never be placed near or over a
radiator or heat register. This product should not be placed in a built -in installation unless proper ventilation is
provided.
7. This product should be operated only from the type of power source in dicated on the marking label. If you are
not sure of the type of power supply to your home, consult your dealer or local power company.
8. Do not allow anything to rest on the power cord. Do not locate this product where the cord will be damaged by
persons walking on it.
9. Do not overload wall outlet extension cords, as this can result in the risk of fire or electric shock.
10. Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage
points or short out parts that could result in a risk of fire or electric shock. Never spill liquid of any kind on this
product.
11. To reduce the risk of electric shock, do not disassemble this product. Instead, when some repair work is
required, take the unit to a qualif ied technician. Opening or removing covers may expose you to dangerous
voltages or other risks. Incorrect reassembly can cause electric shock when the appliance is subsequently used.
12. Unplug this product from the wall outlet and refer servicing to qualified service personnel under the
following conditions:
a) When the power supply cord or plug is damaged or frayed.
b) If liquid has been spilled into the product.
c) If the product has been exposed to rain or water.
d) If the product does not operate normally by following the operating instructions. Adjust only those controls that
are covered by the operating instructions because improper adjustment of other controls may result in damage
and will often require extensive work by a qualified technician to restore the product to normal operation.
e) If the product has been dropped or cabinet has be damaged.
f) If the product exhibits a distinct change in performance.
13. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of
electrical shock from lightning.
14. Do not use the telephone to report a gas leak in the vicinity of the leak.
OL5800 User Manual
4
SAFETY INSTRUCTIONS FOR BATTERIES
Safety Instructions for Batteries
Handset Battery Pack
CAUTION:
Danger of explosion if battery is incorrectly replaced. Use only an Olympia Phone approved battery pack in the handset of
your OL 5800 Cordless Telephone. To reduce the risk of fire or injury, always do the following when replacing, discarding, or
charging battery, When handling the batteries, be careful not to short the battery with conducting materials such as rings,
bracelets, and keys. The Battery or conducting material may overheat and cause burns. Use only the following type and size
of battery pack:
FOR HANDSET UNIT:
GP60AAAH3BMX 3.6V 600mAh GPI INTERNATIONAL LIMITED
CONTAINS NICKEL-METAL HYDRIDE BATTERY. BATTERY MUST BE
RECYCLED OR DISPOSED OF PROPERLY
Do not dispose of the battery in a fire. The cell may explode. Check with local codes for possible special disposal
instructions.
Do not open or mutilate the battery. Released electrolyte is corrosive and may cause damage to the eyes or skin. It may
be toxic if swallowed.
Exercise care in handling batteries in order not to short the battery with conducting materials such as rings, b racelets
and keys. The battery or conductor may overheat and cause burns.
Charge the batteries provided with or identified for use with this product only in accordance with the instructions and
limitations specified in this manual.
Observe proper polarity orientation between the battery(ies) and battery charger.
Do not mix old and new batteries in this product.
Do not mix batteries of different sizes or from different manufacturers in this product.
OL5800 User Manual
SAVE THESE INSTRUCTIONS
5
1 Cordless Phone Features
Allows the user to answer a call by just removing the handset from the base, so you don’t have
l
1. 5.8GHz/900MHz, 40 channel auto scanning operation
2. Manual channel selection
3. 65536 Random combinations of security codes
4. Last number redial (32 digits max.)
5. Power saving in standby mode. ( handset )
6. Page in base unit to locate the handset ( short and long page )
7. Temporary touch tone (pulse to tone dialing)
8. Tone / Pulse dialing mode selection in handset
9. Ringer ON /OFF selection in handset
10. 10 number speed dial memory in handset (up to 16-digits / phone no.)
11. Flash key for call waiting and call transfer - 600ms.
12. 3 level Volume control
13. Pause key ( pause time is 4 seconds )
14. Low battery warning tone
15. Backlit LCD
16. Auto Answer
17. Any key answer
18. Direct number dial out
19. Memory direct dial out
20. Redial & CID transfer to memory ( up to 16 digits long )
Auto
Standby
Auto
Answer
Allows the user to hang up by simply returning the handset to the base.
to waste time pushing buttons. The ‘Talk’ key will be disabled for 5 seconds to avoid accidenta
hang up.
2 Caller ID Features
1. Type I + Type II (call waiting)
2. 64 name and number caller ID
3. 3-line display
4. Total call counter
5. New call LED indicator on handset
6. Repeat call indication (LCD icon)
7. 3-language operation (English, Spanish & French)
8. Scroll review of CID records
9. Selective erase / ‘Erase all’ function
10. Real time clock (date & time)
11. Private/ out-of-area indication
12. LCD contrast control 6 levels, default at 3.
13. Call back (CID dial back)
14. Battery low indication (‘Battery Low’ text display on the 3rd line )
OL5800 User Manual
6
3 Set Up
Connect the power supply to an electrical outlet and base unit.
Remove the handset battery cover and connect the battery back. Replace cover.
Charge the handset for at least 10 hours before using your phone.
Connect the modular phone cord to a live phone jack and the base unit.
4 Olympia OL5800 – Quick Programming Guide
Initial Setup (or any time the phone is powered up)
SET LANGUAGE will appear on the display.
Press #. ENGLISH or SPANISH or FRENCH is displayed. Press
* or # to set the desired language; then press MEM.
AREA CODE ? is now displayed. If you live in a 7 digit local dialing area, enter your Area Code. If you live in a 10 digit area
for local dialing, enter 000 for the Area Code, then press MEM.
SET T/P? T (Set Tone/Pulse) is now displayed. Press * or # to change the dialing mode; then press MEM.
RINGER ON ( or OFF ) is now displayed. Press * or # to change the ringer mode; then press MEM.
CONTRAST is displayed. Press * or # to adjust the display contrast; then press MEM.
PROGRAMMING IS COMPLETE!!
Programming after Initial Setup
With the Handset in the idle (Off) mode, press and hold MEM. SET LANGUAGE will appear on the display. Follow the steps
listed above, or press MEM. repeatedly to find the featur e you wish to program.
OL5800 User Manual
7
5 Installation and Charging of the Battery Pack
1. Open the battery compartment by sliding the cover down.
2. Plug the Battery Pack connector into the Handset battery socket. Place the battery pack and wires in the
compartment.
3. Close the battery compartment.
4. You may change the face panel with one of the color options provided.
5. Choose the appropriate mounting bracket. The smaller bracket is for desk or countertop installations. The larger bracket
is for wall mounting. You must use one of these brackets. If you are using the wall mounting bracket, thread the
telephone cord and DC power cord through the large opening in the bracket. Plug the two cords into the correspondi ng
jacks on the bottom of the Base.
6. Snap the bracket into place on the back of the Base. If you are using the desk top bracket, run the two cords through
the channel at the back of the bracket. If you are wall mounting the Base, carefully line up the slots on the wall mount
bracket with the studs on the telephone wall plate, and carefully mount the telephone on the wall.
7. Connect the telephone line cord to the telephone jack, and the power supply to a live power outlet. Make sure you
are not using an outlet controlled by a switch.
OL5800 User Manual
8
