Giant Telecom LYAE User Manual

Two-Way Radio
R500 Series

Owner’s Manual

Waterproof Radio

Olympia 2-Way radios are intended for recreational (consumer)
use only and are not intended for business use. Olympia offers an
alternate product designed specically for business use - Olympia
P324 Business radio. See below for contact information.

For a list of accessories sold, please contact us.

Contact Us

For further information, call Giant International Ltd. at
1-866-537-0384, e-mail us at [e-mail] or visit us
on the Internet at www.olympiaproducts.com

Safety and General Information

Warning: This manual contains important safety and operating

information.

Please read, understand, and follow the instructions in this
manual. Failure to do so could result in personal injury, death, and/
or damage to the radio, accesories and/or other property.

Transmit and Receive Procedure

The Two-Way radio contains a transmitter and a receiver. To
control your exposure and ensure compliance with the general
population/uncontrolled environment exposure limits, always
adhere to the following procedure:

• Transmit no more than 50% of the time.

• To receive calls, release the Push-to-Talk (PTT) button.

• To transmit (talk), press the PTT button.

Transmitting 50% of the time, or less, is important because the
radio generates measurable RF energy exposure only when
transmitting (in terms of measuring standards compliance).

Exposure to Radio Frequency Energy

The Olympia Two-Way radio complies with the following RF energy
exposure standards and guidelines:

• United States Federal Communications Commission, Code of
Federal Regulations; 47CFR part 2 sub-part J.

• American National Standards Institute (ANSI)/Institute of
Electrical and Electronic Engineer (IEEE) C95. 1-1992.

• Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999
Edition.

• International Commission on Non-Ionizing Radiation Protection
(ICNIRP) 1998.

• Ministry of Health (Canada) Safety Code 6. Limits of Human
Exposure to Radiofrequency Electromagnetic Fields in the
Frequency Range from 3 KHz to 300 GHz, 1999.

To ensure optimal radio performance and make sure human
exposure to radio frequency electromagnetic energy is within the
guidelines set forth in the above standards, always adhere to the
following procedures.

Portable Radio Operation and EME Exposure

Antenna Care
Use only the supplied antenna. Unauthorized antennas,
modications, or attachments could damage the radio and may
violate FCC regulations.

Do NOT hold the antenna when the radio is “IN USE.” Holding
the antenna affects the effective range.

Body-Worn Operation
To maintain compliances with FCC/Health Canada RF exposure
guidelines, if you wear a radio on your body when transmitting,
always place the radio in a Olympia-supplied or approved clip,
holder, holster, case or body harness for this product. Use of
non-Olympia-approved accessories may exceed FCC/Health
Canada RF exposure guidelines.

If you do not use one of the Olympia-supplied or approved body­worn accessories and are not using the radio held in the normal
use position, ensure the radio and its antenna are at least 1 inch

(2.5 cm) from your body when transmitting.

Electromagnetic Interference/Compatibility

Note: Nearly every electronic device is susceptible to

electromagnetic interference (EMI) if inadequately shielded,
designed or otherwise congured for electromagnetic
compatibility. This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

1. This device may not cause harmful interference; and

2. This device must accept any interference received, including
interference that may cause undesired operation.

Facilities
To avoid electromagnetic interference and/or compatibility
conicts, turn off the radio in any facility where posted notices
instruct you to do so. Hospitals, health care facilities or Airports
may be using equipment that is sensitive to external RF energy.

Aircraft
When instructed to do so, turn off the radio when onboard
on aircraft. Any use of a radio must be in accordance with
applicable regulations per airline crew instructions.

Medical Devices – Pacemakers
The Advanced Medical Technology Association recommends
that a minimum separation of 6 inches (15 cm) be maintained
between a handheld wireless radio and a pacemaker. These
recommendations are consistent with the independent
research by and recommendations of the U.S. Food and Drug
Administration.

People with pacemakers should:

• ALWAYS keep the radio more than 6 inches (15 cm) from their
pacemaker when the radio is turned ON.

• Not carry the radio in the breast pocket.

• Use the ear opposite the pacemaker to minimize the potential
for interference.

• Turn the radio OFF immediately if there is any reason to
suspect that interference is taking place.

Medical Devices – Hearing Aids
Some digital wireless radios may interfere with some hearing
aids. In the event of such interference, you may want to consult
your hearing aid manufacturer to discuss alternatives.

Medical Devices - Other
If you use any other personal medical device, consult the
manufacturer of your device to determine if it is adequately
shielded from RF energy. Your physician may be able to assist
you in obtaining this information.

Safety and General Use While Driving

Check the laws and regulations regarding the use of radios in
the area where you drive, and always obey them. If you do use
the radio while driving, please:

• Give full attention to driving and to the road

• Use hands-free operation, if available

• Pull off the road and park before making or answering a call if
driving conditions so require

Do not place a portable radio in the area over an air bag or in the
air bag deployment area. Air bags inate with great force. If a
portable radio is placed in the air bag deployment area and the
air bag inates, the radio may be propelled with great force and
cause serious injury to occupants of the vehicle.

Potentially Explosive Atmospheres
Turn off the radio prior to entering any area with a potentially
explosive atmosphere. Only radio types that are especially
qualied should be used in such areas as “Intrinsically Safe.” Do

not remove, install or charge batteries in such areas. Sparks in
a potentially explosive atmosphere can cause an explosion or
re resulting in bodily injury or even death.

Note: The areas with potentially explosive atmospheres
referred to above include fueling areas such as below decks
on boats, fuel or chemical transfer or storage facilities, areas
where the air contains chemicals or particles (such as grain,
dust or metal powders) and any other area where you would
normally be advised to turn off your vehicle engine. Areas with
potentially explosive atmospheres are often—but not always—
posted.

Blasting Caps and Areas
To avoid possible interference with blasting operations, turn
off the radio when you are near electrical blasting caps, in a
blasting area, or in areas posted “Turn off Two-Way radios.”
Obey all signs and instructions.

Operational Cautions

Antennas
Do not use any portable radio that has a damaged antenna. If
a damaged antenna comes into contact with your skin, a minor
burn can result.

Batteries
All batteries can cause property damage and/or bodily injury

such as burns if a conductive material—like jewelry, keys or
beaded chains—touch exposed terminals. The conductive
material may complete an electrical circuit (short circuit) and
become quite hot. Exercise care in handling any charged
battery, particularly when placing it inside a pocket, purse or
other container with metal objects.

Battery Charger Safety Instructions:

1. Do not expose the charging adaptor to rain or snow.

2. Never alter the AC cord or plug provided with the unit. If the
plug will not t the outlet, have the proper outlet installed by
a qualied electrician. An improper condition can result in a
risk of electric shock.

3. To reduce the risk of electric shock, unplug the charging
adaptor from the outlet before attempting any maintenance
or cleaning.

4. Use of an attachment not recommended or sold by Olympia
may result in a risk of re, electric shock or personal injury.

5. Make sure the cord is located so it will not be stepped on,
tripped over or subjected to damage or stress.

6. The supply cord of the AC adaptor cannot be replaced. If the
cord is damaged, call customer service at 1-866-537-0384 or
e-mail us at [e-mail].

FCC Licensing Information

The Olympia radio operates on General Mobile Radio Service
(GMRS) frequencies and is subject to the Rules and Regulations
of the Federal Communications Commission (FCC). The FCC
requires that all operators using GMRS frequencies obtain a
radio license before operating their equipment. To obtain the
FCC forms, please visit the FCC’s Web site at wireless.fcc.gov/
uls/index.htm?job=home to source form 605 and 159, which
includes all the instructions you will need.

If you wish to have the document faxed or mailed, or if you have
questions, please use the following contact information:

Fax: [phone]
For Mail services: 1-800-418-3676
For FCC License Questions: 1-888-225-5322

Changes or modications not expressly approved by Giant
Intl. Ltd. may void the user’s authority granted by the FCC
to operate this radio and should not be made. To comply
with FCC requirements, transmitter adjustments should be
made only by or under the supervision of a person certied
as technically qualied to perform transmitter maintenance
and repairs in the private land mobile and xed services as
certied by an organization representative of the user of those
services. Replacement of any transmitter component (crystal,
semiconductor, etc.) not authorized by the FCC equipment
authorization for this radio could violate FCC rules.

You can nd the label with the FCC ID on the back of the radio.

Note: Use of this radio outside the country where it was
intended to be distributed is subject to government regulations
and may be prohibited.

Control Buttons

LCD Display Screen Guide

Getting Started

Waterproof

This radio is waterproof to IP-67 standards. It will withstand
submersion under up to 1 meter of water for up to 30 minutes.
The radio is resistant to water, rain, and splashes only when
the battery cover and headset accessory port are sealed. Open
the battery compartment door or headset port cover only when
the radio is dry. Use of a headset accessory should be in dry
environments only.

The charging base and AC adaptor are not waterproof. Do not
expose the charger to rain or snow. Charge the radios only in a
dry location. Do not place wet radios into the charging base.

Floats

This radio is designed to oat with the NiMH batteries included. It
may not oat with some AA batteries. Each radio can use either
1 NiMH rechargeable battery pack or 3 AA alkaline batteries and
beeps when the batteries are low.

Installing NiMH Rechargeable Battery Pack or AA Alkaline
Batteries

1. With the radio off. Ensure that the belt clip is not attached to
the radio.

2. With the back of the radio facing you, loosen the retaining
screw on the battery door and open the cover.

3. Remove the NiMH battery pack from the clear plastic bag (do
not disassemble or unwrap the battery pack) or remove AA
batteries from its packaging.

4. Insert the NiMH battery pack with the diagram facing you or
insert the three AA alkaline batteries with + and - polarity as
shown inside the battery compartment.. (The ribbon should be
underneath the battery pack and should wrap around the right
side of the pack for easy removal.)

5. Close the battery cover and tighten the retaining screw on the
battery door.

Radio Battery Meter

The radio battery icon shows the battery charge level, from full

to empty . When the radio has one segment left

, the radio chirps periodically or after releasing . (see

Low Battery Alert section)

Removing the NiMH Battery Pack or AA Alkaline Batteries

1. With the radio off. Ensure that the belt clip is not attached to
the radio

2. With the back of the radio facing you, loosen the retaining
screw on the battery door to release the battery cover and
open the cover.

3. Remove the NiMH battery pack or remove the AA batteries by
gently pulling the ribbon attached to the radio.

4. Close the battery cover and tighten the retaining screw on the
battery door.

Notes:

• AA Alkaline batteries are optional accessories and are sold
separately.

• Exercise care when removing NiMH or AA batteries. Do not use
sharp or conductive tools to remove either of these batteries.

• Remove the batteries before storing the radio for extended
periods of time. Batteries corrode over time and may cause
permanent damage to the radio.

• The battery door must be tightly closed with the screw to
maintain the waterproof seal of the radio.

Using the Battery Charger

The battery charger provides drop-in charging convenience for
NiMH batteries and can be placed on any at surface, such as a
desk or workbench. Charge the NiMH battery overnight (at least
16 hours) before using it for the rst time. After the initial charge,
an empty battery is fully charged within 14 hours.

1. Follow the steps above to install a NiMH Battery Pack.

2. Plug the AC power supply cord into the jack on the desk stand.

3. Plug the AC power supply into a standard wall outlet.

4. With a radio facing forward, slide it into one of the charging
pockets.

5. When charging in the battery charger, the red light on the
charger base will glow continuously.

Notes

• The light will remain red after the NiMH battery pack is fully
charged.

• When moving between hot and cold temperatures, do not
charge the NiMH battery pack until the battery temperature
acclimates (usually about 20 minutes).

• For optimal battery life, remove the radio from the charger
within 16 hours. Do not store the radio while connected to the
charger.

• If the radio is kept on while charging, the charging time will be
extended.

• Even though the charger is connected, you may not be able to
transmit a message if the battery is completely empty
. Allow time for the battery to charge to 1 bar before
attempting to transmit a message.

• When the radio is wet from rain or snow, thoroughly dry the
surface before charging or removing the batteries.

Low Battery Alert

In addition to the battery meter which visually shows the current
battery charge level, the Low Battery Alert feature produces an
audible chirp when the batteries are low.

Attaching and Removing the Belt Clip

1. Align the belt clip post with the groove on the back of the radio
and slide it into place.

2. Gently push until the clip clicks in place.

To remove:

1. Push down on the release tab at the top of the belt clip to
release the catch.

2. Pull the belt clip away from the back of the radio.

Turning the Radio On and Off

In the ON position, the radio chirps and briey shows all feature
icons available on the radio. The display screen then shows the
current channel, code and all features that are enabled.

1. To turn on, press and hold
and the radio beeps.

2. To turn off, press and hold until the display goes blank.

Setting the Volume

The R500 has 16 volume levels controlled by the

1. Press

2. Press to decrease volume.

3. Hold

to increase volume.

or to rapidly increase or decrease volume.

until a channel number appears

or keys.

Do not hold the radio close to your ear. If the volume is set to an
uncomfortable level, it could hurt your ear.

Transmitting and Receiving Calls

To communicate, all radios in your group must be set to the same
channel and code setting.

1. To talk, press and hold

2. When you are nished talking, release .

For maximum clarity, hold the radio two to three inches away
from your mouth and speak directly into the microphone. Do not
cover the microphone while talking.

Power Boost

To boost the radio’s power up to high power, press the top portion
of the
you can conserve the battery’s energy by pushing the lower part
of the button to use less power.

Note: If you are on an FRS only channel (see Channels and
Frequencies table located at the back of the manual.) the radio

will only use low power when either portion of the

Monitor Button

Use the Monitor function to check if a channel is currently in use
by others. For maximum range performance, the Monitor function
will also help you to hear signals that are weak.

To latch the Monitor function on, press and hold
seconds. When an empty channel is located, you will hear
continuous static and noise on that channel.

To turn the Monitor function off, tap

Push-to-Talk

To prevent accidental transmissions and save battery life, the
radio emits a continuous warning tone and stops transmitting if
you hold for more than 60 seconds.

button when talking. If you know your party is close by,

.

Timeout Timer

.

is pressed.

for three

a second time or press

Menu Options

There are 12 options you may set to your preferences. Each
press of the MENU key advances you to the next option setting.
Press the
automatically close 5 seconds after the last press of any button.
After the last menu item, the radio exits MENU mode and returns
to operation of the radio. A press of the button while setting
any menu option will immediately save all your settings and return
to operation of the radio.

All MENU settings will revert to the factory default values
if the battery is fully discharged or removed for more than
5 minutes.

Menus and Values

1. Channel (1-50 and 15R-22R)

2. Code (1-121 or OFF)

3. Call Tone (1-10 or OFF)

4. iVOX (ON/OFF)

5. VOX sensitivity (1-3)

6. Vibrate (ON/OFF)

7. Keypad Tones (ON/OFF)

8. Roger Beep (ON/OFF)

9. Auto Power Off (30/60/90 minutes or OFF)

10. Repeater Channel Enable (ON/OFF)

11. Repeater Transmitted Code

Selecting the Channel

The radio has 50 simplex channels plus 8 repeater duplex
channels. The channel is the frequency the radio uses to
transmit. (See the Channels and Frequencies table located at the
back of the manual.) Channels are shared by other radio users
and channel selection will vary based on your location. Select
a channel that is not being used from the 50 available simplex
channels. Channels 8-14 and channels 34-37 are low power (FRS

0.5 watt). All other channels are GMRS.

When the radio is on a FRS 0.5 watt channel,
When the radio is on a GMRS 1.5 watt channel, displays.

The 8 GMRS repeater duplex channels 15R – 22R are disabled by
default. See Enabling Repeater Channels on overleaf in order to
select a repeater channel.

1. Press

2. Press

3. Press

or keys to change the setting. The menu will

displays.

. The current channel setting ashes.
or and select the channel.

to save the channel setting orto continue set up.

R500 series

Selecting the Tone/Code

This radio has 121 code settings. When a channel is in use by
2 or more groups, this feature blocks the reception of signals that
do not carry the matching tone or code. There are 121 codes. 0
is the off position, no analog or digital codes are enabled and all
users of that channel will be heard. Codes 1 – 38 are the standard
analog (CTCSS) codes that appear on other FRS/GMRS radios.
Codes 39 – 121 are additional digital (CDCSS) codes added for
superior interference protection. 0 is the off position.

See the Tone/Code Setting Frequency table located at the back of
the manual for details on tone frequencies and code values.

To set the code for a channel:

1. Press

2. Press or to select the code.

twice until the code starts to ash.

3. Press to save the code setting or to continue set up.

You can set a different code for each channel using this
procedure. An extended press of

or allows you to scroll

rapidly so you can quickly reach the code you want.

This menu setting for repeater channels 15R-22R is used for
receiving only. The value must match with the repeater output.
Many repeaters will require a value of 0 or OFF. The transmitted
code is set separately and is often required for repeater access.
See ”Selecting the Repeater Access (TX) Code” section for
additional information.

Note: You must set the code to 0 to communicate with radios that
do not have codes.

Setting and Transmitting Call Tones

The radio can transmit different call tones to other radios in your
group so you can alert them that you want to talk. The radio has
10 call tones from which to choose.

To set a call tone:

1. With the radio on, briey press
current call tone setting ashes.

until appears. The

2. Press or to change and hear the call tone.

3. Press to set the new call tone or to continue set up.

To transmit your call tone to other radios, set to the same channel
and code as the radio, press

.

Note: Setting the call tone to 0 disables the call tone feature.

Hands-Free Use Without Accessories (

)

You can use the iVOX feature to transmit hands-free without the
need for any headset accessories. Once iVOX is turned on, the
radio detects your voice and transmits when you speak into the
internal microphone.

1. Press
setting On/Off will ash.

2. Press

until

or to select On or Off.

appears on the display. The current

3. Press to set or to continue set up.

Hands-Free Use With Accessories (

)

You can transmit hands-free more reliably with the use of optional
headset accessories. Once VOX is turned on, the radio detects
your voice and transmits when you speak.

1. Turn the radio off and plug the

accessory into the

accessory port.

2. Turn the radio on. will show on the display.

3. Adjust the volume appropriately by pressing or . Lower
the volume before placing the accessory on your head or in
your ear.

4. To turn off, simply remove accessory.

Notes:

• There is a short delay between the time you start talking and
when the radio transmits. There is a short delay before the
transmission is completed.

• The accessory port cover must be tightly in place to maintain
the water tight seal of the radio.

Setting the Sensitivity Level When in VOX Mode

Adjusting the radio’s sensitivity level helps minimize the possibility
of unintended noises triggering a transmission and helps the
radio pick up soft voices.

1. Press
display.

2. Press

3. Press

until VOX and the level setting (1 - 3) appear on the

or to select the sensitivity level.

to set or to continue set up.

3 = High Sensitivity for quiet environments
2 = Medium Sensitivity for most environments
1 = Low Sensitivity for noisy environments

Note: When you connect a headset, the radio is automatically set

to the last chosen sensitivity level.

KEM-ML37701-01

Vibrate

Vibrate is a vibrating alert that noties that the radio is receiving
a message. This is useful in noisy environments. When the alert is
on, the radio vibrates once every 30 seconds when you receive a
message on the channel and code you set.

1. To turn vibrating alerts on, press
current setting will ash.

until is displayed. The

2. Press or to change the setting to On/Off.

3. Press to set or to continue set up.

Keypad Tones

You may enable or disable the speaker key tones. You will hear
the key tone each time a button is pushed.

1. Press
will ash.

until appears. The current setting On/Off

2. Press or to turn On or Off.

3. Press to conrm or to continue set up.

Note: When the key tone feature is off, the following are not disabled:

• Transmit timeout alert tone

• Call tone

• Low battery alert tone or

• The transmitted talk conrmation tone

Roger Beep Setting

You can set the radio to transmit a unique tone when you nish
transmitting. It is like saying “Roger” or “Over” to let others know
you are nished talking.

1. With the radio on, briey press
current setting On/Off ashes.

until appears. The

2. Press or to turn On or Off.

3. Press to set the talk conrmation tone or to continue set
up.

Auto Power Off

The radio will save power by automatically turning itself off if
unused after a predetermined amount of time.

1. Activate this setting by pressing
current setting (0, 30, 60 or 90) will ash.

until displays. The

2. Press or to set the time to 30 minutes, 60 minutes or
90 minutes. When this feature is activated, the will remain
on the display.

3. When you exit the Menu mode, the timer will begin. If a button
is pressed, or if there is an incoming signal, the timer will
restart.

4. The screen will show .

5. Press to conrm or to continue set up.

Enabling Repeater Channels

Use of a repeater can greatly increase the radio range and
coverage area. Repeater use must be coordinated with the owner
of the repeater. Be sure to understand and follow the sharing and
usage rules for each repeater system.

1. Press
will ash.

2. Press

3. Press

until the R appears. The current setting ON/OFF

or to select ON or OFF.

to save the setting or to continue set up.

After enabling the repeater channels, you will be able to select
channels 15R-22R. Refer to the “Selecting the Channel” section
on page one.

Selecting the Repeater Access (TX) Code

When a repeater channel is selected, an additional menu option
is available for setting the transmitted code. Many repeaters will
require a specic value setting to activate the repeater on your
transmissions. See the Tone/Code Setting Frequency table for
detailed information.

1. Press
setting ash.

repeatedly until the

, the R, and the current

2. Press or to select the code.

3. Pressor to exit menu mode.

You can set a different code for each channel using this
procedure. An extended press of

or allows you to scroll
through the Interference Code rapidly so you can quickly reach
the code you want. 0 is the off position.

Special Features

LED Flashlight

Press and hold the LED ashlight button to turn and keep the light
on. The switch functions as a momentary control for the light.

Note: Turn off the ashlight when not in use to conserve battery
power.

Keypad Lock

To avoid accidentally changing the radio settings, a keypad lock
feature may be enabled. When in lock mode, you can only turn
the radio OFF, Receive, Transmit, send a call tone, and use the
monitor function. All other functions are locked.

1. Press

2. To unlock the radio, press and hold until the icon is no

and hold until icon displays.

longer displayed.

Scanning Channels

Use scan to search all 58 channels for transmissions from
unknown parties, to nd someone in your group who has
accidentally changed channels, or to quickly nd unused
channels for your own use.

There is a priority feature and 2 modes of scanning (basic and
advanced) to make your search more effective. The basic scan
mode uses the channel and code combinations for each of the
58 channels as you have set them (or with the default code value
of 1). The “Advanced Scan” mode will scan all channels for any
and all codes, detect any code in use, and use that code value
temporarily for that channel.

Priority is given to the “home channel,” i.e., the channel (and
code) the radio is set to when you start the scan. This means the
initial channel (and code setting) is scanned more often than the
other channels, and the radio will respond quickly to any activity
occurring on the home channel as a priority.

To start Basic Scanning:

1. Briey press the
display, and the radio will begin to scroll through the channel

key. The scan will appear in the

and code combinations.

2. When the radio detects channel activity matching the channel
and code combination, it stops scrolling and you can hear the
transmission.

3. To respond and talk to the person transmitting, press within
ve seconds after the end of the transmission.

4. The radio will resume scrolling through the channels ve
seconds after the end of any received activity.

5. To stop scanning, briey press the key.

To start Advanced Scanning:
Advanced Scanning is only available on channels 1-22.

1. Set the code to “zero” or OFF. (the default code is set at 1)

2. Briey press the
display, and the radio will begin to scroll through the channels.

key. The scan will appear in the

No codes will lter what is heard.

3. When the radio detects channel activity with ANY code (or NO
code), it stops scrolling and you can hear the transmission.
Any code that may be in use by that party will be detected and
displayed.

4. To respond and talk to the person transmitting, press within
ve seconds of the end of the transmission. The radio will
transmit using the newly detected code.

5. The radio will resume scrolling through the channels ve
seconds after the end of any received activity.

6. To stop scanning, briey press the

key.

Scanning Notes:

1. If you press
channels, the transmission will be on the “home channel”.

while the radio is scrolling through inactive

Scanning will resume ve seconds after the end of the
transmission. You may press the key to stop scanning at
any time.

2. If the radio stops on an undesired transmission, you may
immediately resume the scan by briey pressing or .

3. If the radio repeatedly stops on an undesired transmission,
you may temporarily remove that channel from the scan list
by pressing and holding or for three seconds. You may
remove more than one channel in this way.

4. To restore the removed channel(s) to the scan list, turn the
radio off and then back on, or exit and re-enter the scanning
mode by pressing .

5. You cannot remove the home channel from the scan list.

6. In Advanced Scan, the detected code will only be used for
one transmission. You must note the code, exit scan, and set
that detected code on that channel to permanently use the
detected code.

Weather Receiver

This radio can tune in to broadcasts by the United States National
Oceanic and Atmospheric Administration (NOAA) Weather Radio.

You can listen to a weather channel (see “Weather Channels
and Frequencies” table for details) or set the radio to alert you to
emergency weather broadcasts that interrupt routine broadcasts.
When you listen to a weather channel, you cannot use the
radio in scan mode or for two-way communications. NOAA
has transmitters located throughout the United States. These
transmitters broadcast watches, forecasts, and other information

24 hours a day.

Note: NOAA weather radio stations are assigned to cover specic
areas and service may be limited. Please check with your local
weather ofce for frequency and details, or visit www.weather.gov/
nwr in the US to view the appropriate transmitter for your area. The
use of the NOAA logo does not provide an endorsement or implied
endorsement by NOAA’s National Weather Service.

Turning Weather Channel Reception On and Off

1. To turn weather reception on, press and hold

2. To turn off, press or turn the radio off and then back on.

for 3 seconds.

Scanning for Weather Channel

The radio can scan for an active NOAA transmission
automatically.

1. After turning weather reception on, briey press the

2. The scan icon will appear in the display, and the channel

key.

will scroll through the NOAA channels 1-7.

3. When the radio detects channel activity, it stops scanning and
you can hear the transmission.

4. You may resume the scan by briey pressing or .

5. To stop scanning, briey press the key. The scan icon
will disappear.

Setting the Weather Channel Manually

If you know which frequency is correct for your location, refer to
the Weather Channels and Frequencies table located at the back
of the manual to manually set the radio to the appropriate weather
channel.

1. After turning weather reception on, press

. The current

channel ashes.

2. Press or to select the appropriate channel with good
reception in your area.

3. Press to save the weather channel setting.

Setting the Weather Alert

The radio can be set to respond to NOAA Weather Radio
emergency messages. A special alarm tone sounds an alert and
turns on the weather receiver to give you immediate weather and
emergency information.

1. After turning weather reception on, press
ashes.

twice. ON or OFF

2. Press or to select ON to activate. If you activate the
Weather Alert and return to two-way mode, will display.

3. Press

4. Press and hold

to save the Weather Alert setting.

for 3 seconds to return to two-way mode.

Package Includes

2 Olympia R500 2-Way radios, an owner’s manual as well as the
following accessories:

• 1 Desktop Dual Charging Base

• 1 Wall Adaptor

• 2 NiMH (Rechargeable) Battery Packs

• 2 Belt Clips

• 1 Owner’s Manual

Warranty

Consumer 2-Way Radio Products and Accessories purchased in
the United States.

What Does this Warranty Cover?

Subject to the exclusions contained to the right, Giant
International Ltd. warrants the Olympia branded consumer 2-Way
radios that operate via Family Radio Service or General Mobile
Radio Service that it manufactures (“Products”), the Olympia
branded or certied accessories sold for use with these products
that it manufactures to be free from defects in materials and
workmanship under normal consumer usage for the period(s)
outlined below. This limited warranty is a consumer’s exclusive
remedy, and applies as follows to new Olympia branded Products
and accessories manufactured by Giant International Ltd.,
and purchased by consumers in the United States, which are
accompanied by this written warranty:

Products and Accessories as dened above, unless otherwise
provided for below:

2-Way Radios: Length of Coverage: Three (3) years from the date
of purchase by the rst consumer purchaser of the product unless
otherwise provided for below.

Accessories as dened above: Ninety (90) days from the date of
purchase by the rst consumer purchaser of the product.

Products and Accessories that are repaired or replaced: The
balance of the original warranty or for ninety (90) days from the

date returned to the consumer, whichever is longer.

EXCLUSIONS
Normal Wear and Tear. Periodic maintenance, repair and

replacement of parts due to normal wear and tear are excluded
from coverage.

Batteries. Only batteries whose fully charged capacity falls
below 80% of their rated capacity and batteries that leak are
covered by this limited warranty.

Abuse & Misuse. Defects or damage that result from: (a)
improper operation, storage, misuse or abuse, accident or
neglect, such as physical damage (cracks, scratches, etc.) to
the surface of the product resulting from misuse; (b) exposure
to extreme heat and cold; (c) exposure beyond the IP ratings
to liquid, water, rain, sand, dirt, dust, food, or the like, when the
battery door or accessory port seals are not closed; (d) use of
the Products or Accessories for business purposes or subjecting
the Product or Accessory to abnormal usage or conditions; or (e)
other acts which are not the fault of Giant International Ltd., are
excluded from coverage.

Use of Non-Olympia branded Products and Accessories. Defects
or damage that result from the use of Non-Olympia branded or
certied Products, Accessories, or other peripheral equipment
are excluded from coverage.

Unauthorized Service or Modication. Defects or damages
resulting from service, testing, adjustment, installation,
maintenance, alteration, or modication in any way by someone
other than Giant International Ltd. or its authorized service
centers, are excluded from coverage.

Altered Products. Products or Accessories with (a) serial
numbers or date tags that have been removed, altered or
obliterated; (b) broken seals or that show evidence of tampering;
(c) mismatched board serial numbers; or (d) nonconforming
or non-Olympia branded housings, or parts, are excluded from
coverage.

Who is covered?

This warranty extends only to the rst consumer purchaser, and
is not transferable.

What will GIANT INTERNATIONAL LTD. do?

GIANT INTERNATIONAL LTD., at its option, will at no charge
repair, replace or refund the purchase price of any Products
or Accessories that does not conform to this warranty.
We may use functionally equivalent reconditioned/refurbished/
pre-owned or new Products, Accessories or parts.

How to Obtain Warranty Service or Other Information?

To obtain service, information or to obtain a Return Authorization
(RMA) #, please call:

USA Two-Way Radios
1-866-537-0384
[e-mail]

You will receive instructions on how to ship the Products or
Accessories at your expense, to a GIANT INTERNATIONAL LTD.
Authorized Repair Center. To obtain service, you must include:

(a) A copy of your receipt, bill of sale or other comparable proof

of purchase
(b) A written description of the problem
(c) RMA #
(d) Your address and telephone number

What Other Limitations Are There?

ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED
TO THE DURATION OF THIS LIMITED WARRANTY, OTHERWISE
THE REPAIR, REPLACEMENT, OR REFUND AS PROVIDED
UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE
REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU
OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN
NO EVENT SHALL GIANT INTERNATIONAL LTD. BE LIABLE,
WHETHER IN CONTRACT OR TORT (INCLUDING NEGLIGENCE)
FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE
PRODUCT OR ACCESSORY, OR FOR ANY INDIRECT, INCIDENTAL,
SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR
LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF
INFORMATION OR OTHER FINANCIAL LOSS ARISING OUT OF
OR IN CONNECTION WITH THE ABILITY OR INABILITY TO USE
THE PRODUCTS OR ACCESSORIES TO THE FULL EXTENT THESE
DAMAGES MAY BE DISCLAIMED BY LAW.

Some states and jurisdictions do not allow the limitation or
exclusion of incidental or consequential damages, or limitation
on the length of an implied warranty, so the above limitations or
exclusions may not apply to you. This warranty gives you specic
legal rights, and you may also have other rights that vary from
state to state or from one jurisdiction to another.

Channels and Frequencies

FREQ

CH #

1 462.5625 ANY GMRS 34 467.5625 48 FRS

2 462.5875 ANY GMRS 35 467.6125 51 FRS

3 462.6125 ANY GMRS 36 467.6625 54 FRS

4 462.6375 ANY GMRS 37 467.7125 57 FRS

5 462.6625 ANY GMRS 38 462.5750 60 GMRS

6 462.6875 ANY GMRS 39 462.6250 63 GMRS

7 462.7125 ANY GMRS 40 462.6750 66 GMRS

8 467.5625 ANY FRS 41 462.7250 69 GMRS

9 467.5875 ANY FRS 42 462.5625 14 GMRS

10 467.6125 ANY FRS 43 462.6125 11 GMRS

11 467.6375 ANY FRS 44 462.6625 8 GMRS

12 467.6625 ANY FRS 45 462.7125 5 GMRS

13 467.6875 ANY FRS 46 462.5500 2 GMRS

14 467.7125 ANY FRS 47 462.6000 37 GMRS

15 462.5500 ANY GMRS 48 462.6500 34 GMRS

16 462.5750 ANY GMRS 49 462.7000 31 GMRS

17 462.6000 ANY GMRS 50 462.5875 40 GMRS

18 462.6250 ANY GMRS

19 462.6500 ANY GMRS 467.5500 ANY TX GMRS

20 462.6750 ANY GMRS

21 462.7000 ANY GMRS 467.5750 ANY TX GMRS

22 462.7250 ANY GMRS

23 462.5625 38 GMRS 467.6000 ANY TX GMRS

24 462.6125 35 GMRS

25 462.6625 32 GMRS 467.6250 ANY TX GMRS

26 462.7125 29 GMRS

27 462.5500 26 GMRS 467.6500 ANY TX GMRS

28 462.6000 23 GMRS

29 462.6500 20 GMRS 467.6750 ANY TX GMRS

30 462.7000 17 GMRS

31 462.5875 39 GMRS 467.7000 ANY TX GMRS

32 462.6375 42 GMRS

33 462.6875 45 GMRS 467.7250 ANY TX GMRS

CODE TYPE CH #

(MHz)

FREQ

(MHz)

462.5500 ANY RX GMRS

15R

462.5750 ANY RX GMRS

16R

462.6000 ANY RX GMRS

17R

462.6250 ANY RX GMRS

18R

462.6500 ANY RX GMRS

19R

462.6750 ANY RX GMRS

20R

462.7000 ANY RX GMRS

21R

462.7250 ANY RX GMRS

22R

CODE TYPE

Tone/Code Setting Frequency (Hz)

CODE CTCSS (Hz) CODE

1 67.0 39 023 81 315
2 71.9 40 025 82 331
3 74.4 41 026 83 343
4 77.0 42 031 84 346
5 79.7 43 032 85 351
6 82.5 44 043 86 364
7 85.4 45 047 87 365
8 88.5 46 051 88 371

9 91.5 47 054 89 411
10 94.8 48 065 90 412
11 97.4 49 071 91 413
12 100.0 50 072 92 423
13 103.5 51 073 93 431
14 107.2 52 074 94 432
15 110.9 53 114 95 445
16 114.8 54 115 96 464
17 118.8 55 116 97 465
18 123.0 56 125 98 466
19 127.3 57 131 99 503
20 131.8 58 132 100 506
21 136.5 59 134 101 516
22 141.3 60 143 102 532
23 146.2 61 152 103 546
24 151.4 62 155 104 565
25 156.7 63 156 105 606
26 162.2 64 162 106 612
27 167.9 65 165 107 624
28 173.8 66 172 108 627
29 179.9 67 174 109 631
30 186.2 68 205 110 632
31 192.8 69 223 111 654
32 203.5 70 226 112 662
33 210.7 71 243 113 664
34 218.1 72 244 114 703
35 225.7 73 245 115 712
36 233.6 74 251 116 723
37 241.8 75 261 117 731
38 250.3 76 263 118 732

CDCSS
(Octal)

77 265 119 734
78 271 120 743
79 306 121 754
80 311

CODE

CDCSS
(Octal)

Weather Channels and Frequencies

CHANNEL RX (MHz) CHANNEL RX (MHz) CHANNEL RX (MHz)

WX1 162.550 WX5 162.450 WX9 161.775

WX2 162.400 WX6 162.500 WX10 161.750
WX3 162.475 WX7 162.525 WX11 162.000
WX4 162.425 WX8 161.650

Patent and Copyright Information

©2014 Giant International Limited. All rights reserved. All
registered trademarks and trade dress are the property of the
respective owners.

R500 series
