Giant Telecom LYAA User Manual

Printed in China

Part No. KEM-ML34903A

English

Introduction

Making Life Easier and Safer

Staying in touch with your family and friends is convenient and
easy when using your microTALK
uses you will discover include:

Communicating with others while hiking, biking, and working; keeping track of
family and friends at a crowded public event; checking with travel companions
in another car; talking with neighbors; arranging meeting spots with others
while shopping at the mall.

Belt Clip

Secure your microTALK® radio while on the
go.

Carrying your microTALK® radio with you is easy when
using the belt clip or optional wrist strap.

The belt clip easily attaches to your belt, purse, or
backpack.

Customer Assistance

®

radio. Some of the many

Product Service & Support

For any questions about operating this new Olympia branded product, PLEASE
CONTACT US FIRST… do not return this product to the retail store. The contact
information for support will vary depending on the country in which you
purchased and utilize the product.

To obtain warranty service or other information for products purchased from us
itself or through its authorized reseller or agent and utilized in the U.S.A.,
please call our consumer support line at [phone]. You will receive
instructions on how to ship the products at your expense to an our Authorized
Service Center. To obtain service, you must include: (a) a copy of your receipt,
bill of sale or other comparable proof of purchase; (b) a written description of
the problem; and, most importantly; (c) your address and telephone number.

For warranty and customer service information outside the US, please contact
your local dealer.

Introduction

Product Features

1. Antenna

2. External Speaker/Microphone Jack

3. Charge Jack

4. Mode/Power Button

5. Call/Keypad Button

6. Up Button

7. Weather/Down Button

8. Monitor/Scan Button

9. Talk Button

10. Speaker/Microphone

11. Wrist Strap Connection

12. Belt Clip

13. Battery Compartment

14. Battery Door Screw

LCD Display

1. Scan Icon

2. Transmitting Icon

3. Call Tone/Keypad Tone Icon

4. Keypad Lock Icon

5. Battery Meter Icon

6. On/Off for each feature Icon

7. Auto Power Off Icon

8. Roger Beep Icon

9. Weather Alert Icon

10. Privacy Code Numbers

11. Volume Icon

12. Receiving Icon

13. Channel Numbers

Maximum range may vary and is based on
unobstructed line-of-sight communication under
ideal conditions.

Operation

Using Your Radio

Quick Start

1. Press and hold the Mode/Power button to turn on
your radio.

2. Press once on the mode button to change
channels.

Both radios must be tuned to the same channel /
privacy code to communicate.

3. Press and hold the Talk button while speaking into
the microphone.

4. When nished talking, release the Talk button and
listen for a response.

Getting Started

Waterproof This radio is waterproof to IP54 standards. It is

dust/splashproof from any direction. The radio is resistant to water
and rain splashes only when the battery cover, headset accessory
and micro-USB ports are sealed. Open the battery compartment door
or headset port cover only when the radio is dry. Use of a headset
accessory should be in dry environments only. The micro-USB cable
and plug is not waterproof. Do not expose the charger to rain or
snow. Charge the radios only in a dry location. The battery door must
be tightly closed with the screw to maintain the weatherproof seal of
the radio.

Installing NiMH Rechargeable Batteries

1. With the radio off. Ensure that the belt clip is not attached to the
radio.

2. With the back of the radio facing you, loosen the retaining screw
on the battery door and open the cover.

3. Remove the NiMH batteries from its packaging.

4. Insert the NiMH batteries with + and - polarity as shown inside
the battery compartment. (The ribbon should be underneath the
batteries and should wrap around the right side of the batteries for
easy removal.)

5. Reposition the battery door onto the radio and tighten the screw.

Radio Battery Meter

The radio battery icon shows the radio battery charge level, from full
to empty . When the radio has one segment left
the radio chirps periodically or after releasingthe Talk Button.

,

(see

Low Battery Alert section)

Removing the NiMH or AA Alkaline Batteries

1. With the radio off. Ensure that the belt clip is not attached to the
radio.

2. With the back of the radio facing you, loosen the retaining screw
on the battery door and open the cover.

3. Remove the NiMH battery or Alkaline AA batteries by gently pulling
the ribbon attached to the radio.

4. Reposition the battery door onto the radio and tighten the screw.

Notes:

• Non-rechargeable Alkaline batteries can also be used in your radio.

• AA Alkaline batteries are optional accessories and are sold
separately.

• Exercise care when removing NiMH or AA batteries. Do not use
sharp or conductive tools to remove either of these batteries.

• Do not attempt to charge Alkaline batteries.

• Do not mix old and new batteries.

• Do not mix Alkaline, standard (carbon-zinc), or
rechargeable(Ni-Cd, Ni-MH, etc) batteries.

• Use only the supplied rechargeable batteries and charger for
recharging your Olympia radio

• Remove the batteries before storing the radio for extended periods
of time. Batteries corrode over time and may cause permanent
damage to the radio.

• The battery door must be tightly closed with the screw to maintain
the water resistant seal of the radio.

Using the micro-USB Charging Connector

The micro-USB charging connector is a handy port that allows you to
conveniently charge the rechargeable NiMH batteries.If using a
computer, the computer must be turned on.

1. Plug the micro-USB cable or charger into a power source as is

appropriate for your accessory.

2. Plug the cable into the micro-USB port on the bottom of the radio.

3. An empty battery will be fully charged in 14 hours.

4. The battery icon will scroll as the battery is being charged. The

scrolling icon will stop when the battery is fully charged.

Notes

• Olympia recommends your radio is turned off while being charged.

• When moving between hot and cold temperatures, do not charge
the NiMH battery until the battery temperature acclimates (usually
about 20 minutes).

• For optimal battery life, remove the radio from the charger within
16 hours. Do not store the radio while connected to the charger.

• If the radio is kept on while charging, the charging time will be
extended.

• Even though the charger is connected, you may not be able to
transmit a message if the battery is completely empty .
Allow time for the battery to charge to 1 bar before
attempting to transmit a message.

Low Battery Alert

In addition to the battery meter which visually shows the current
battery charge level, the Low Battery Alert feature produces an
audible chirp when the batteries are low.

Attaching and Removing the Belt Clip

1. Align the belt clip post with the groove on the back of the radio
and slide it into place.

2. Gently push until the clip clicks in place.

To remove:

1. Push down on the release tab at the top of the belt clip to release
the latch.

2. Slide the belt clip away from the back of the radio.

Turning the Radio On and Off

In the ON position, the radio chirps and briefly shows all feature icons
available on the radio. The display screen then shows the current
channel, code and all features that are enabled.

1. To turn on, press and hold until a channel number appears
and the radio beeps.

2. To turn off, press and hold until the display goes blank.

Setting the Volume

The radio has 16 volume levels controlled by the or .

1. Press to increase volume.

2. Press to decrease volume.

3. Hold or to rapidly increase or decrease volume.

Do not hold the radio close to your ear. If the volume is set to an
uncomfortable level, it could hurt your ear.

Transmitting and Receiving Calls

Operation

To communicate, all radios in your group must be set to the same
channel and code setting.

1. To talk, press and hold the Talk Button.

2. When you are finished talking, release the Talk Button.
For maximum clarity, hold the radio two to three inches away from

your mouth and speak directly into the microphone. Do not cover the
microphone while talking.

Monitor Button

Use the Monitor function to check if a channel is currently in use by
others. For maximum range performance, the Monitor function will
also help you to hear signals that are weak.

To latch the Monitor function on, press and hold for three
seconds. When an empty channel is located, you will hear continuous
static and noise on that channel.

To turn the Monitor function off, releas .

Push-to-Talk Timeout Timer
To prevent accidental transmissions and save battery life, the radio

emits a continuous warning tone and stops transmitting if you hold
the Talk Button for more than 60 seconds.

Mode Functions

There are 6 options you may set to your preferences. Each press of
the Mode key advances you to the next option setting. Press the
or keys to change the setting. The menu will automatically close
5 seconds after the last press of any button. After the last menu item,
the radio exits MENU mode and returns to operation of the radio. A
press of the Talk button while setting any menu option will
immediately save all your settings and return to operation of the radio.

1. Channel (1-22)

2. Codes

3. Call Tone (1-10 or OFF)

4. Roger Beep (ON/OFF)

5. Keypad Tones (ON/OFF)

6. Auto Power Off (30/60/90 minutes or OFF)

Selecting the Channel

The radio has 22 channels that are compatible with all brands of
2-Way radios. The channel is the frequency the radio uses to
transmit. (See the Channels and Frequencies table) Channels are
shared by other radio users and channel selection will vary based on
your location. Select a channel that is not being used from the 22
available simplex channels:

1. Briefly press and release . The channel number flashes.

2. Press or to select a channel.

3. Press the Talk Button to confirm or to continue set up.

Selecting the Tone/Code

This radio has 121 code settings. When a channel is in use by 2 or
more groups, this feature blocks the reception of signals that do not

of other Olympia models, code 40 is same as CDCSS code 2, and so
on.

To set the code for a channel:

1. Press twice until the code starts to flash.

2. Press or to select the code.

3. Press the Talk Button to save the code setting or to continue
set up.

You can set a different code for each channel using this procedure.
An extended press of or allows you to scroll through the
Interference Codes rapidly so you can quickly reach the code you
want.

Note: You must set the code to 0 on a radio that uses codes to
communicate with radios that do not have Codes. Select 0 for “no
tone, no code” and OFF will flash on the radio’s display.

Setting and Transmitting Call Tones

The radio can transmit different call tones to other radios in your
group so you can alert them that you want to talk. You have 10 call
tones from which to choose.

To set a call tone:

1. With the radio on, briefly press until appears. The

current call tone setting flashes.

2. Press or to change and hear the call tone.

3. Press the Talk Button to set the new call tone or to continue

set up.

To transmit your call tone to other radios set to the same channel as
the radio, press .

Note: Setting the call to 0 disables the call tone feature.

carry the matching tone or code. There are 121 privacy codes. 0 is
the off position, no analog or digital codes are enabled and all users
of that channel will be heard. Codes 1-38 are the standard analog
(CTCSS) codes that appear on other radios. Codes 39-121 are 83
additional digital (CDCSS) codes added for superior interference
protection. 0 is the off position. Code 39 is same as CDCSS code 1

Special Features

Keypad Lock

To avoid accidentally changing the radio settings, a keypad lock
feature may be enabled. When in lock mode, you can only turn the
radio OFF, Receive, Transmit, send a call tone, and use the monitor
function. All other functions are locked.

1. Press and hold until displays.

2. To unlock the radio, press and hold until the icon is no
longer displayed.

Scanning Channels

Use scan to search the 22 channels for transmissions from unknown
parties, to find someone in your group who has accidentally changed
channels, or to quickly find unused channels for your own use.

There is a priority feature and 2 modes of scanning (basic and
advanced) to make your search more effective. The basic scanmode
uses the channel and code combinations for each of the22 channels
as you have set them (or with the default codevalue of 0). The
“Advanced Scan” mode will scan all channelsfor any and all codes,
detect any code in use, and use thatcode value temporarily for that
channel.Priority is given to the “home channel,” i.e., the channel
(andcode) the radio is set to when you start the scan. This meansthe
initial channel (and code setting) is scanned more oftenthe other
channels, and the radio will respond quickly toany activity occurring
on the home channel as a priority.To start Basic Scanning:

1. Briefly press the key. The scan will appear in the
display, and the radio will begin to scroll through the channel and
code combinations.

2. When the radio detects channel activity matching the channel and
code combination, it stops scrolling and you can hear the
transmission.

3. To respond and talk to the person transmitting, press Talk Button
within five seconds after the end of the transmission.

4. The radio will resume scrolling through the channels five seconds
after the end of any received activity.

5. To stop scanning, briefly press the key.

To start Advanced Scanning:

1. Set the Interference Eliminator Code to “0” or OFF.

2. Briefly press the key. The scan will appear in the
display, and the radio will begin to scroll through the channels. No
Interference Eliminator Codes will filter what is heard.

3. When the radio detects channel activity with ANY code (or NO
code), it stops scrolling and you can hear the transmission. Any
Interference Eliminator Code that may be in use by that party will
be detected and displayed.

4. To respond and talk to the person transmitting, press Talk button
within five seconds at the end of the transmission. The radio will
transmit using the newly detected Interference Eliminator Code.

5. The radio will resume scrolling through the channels five seconds
after the end of any received activity.

6. To stop scanning, briefly press the key.

Scanning Notes

1. If you press the Talk Button while the radio is scrolling through
inactive channels, the transmission will be on the “home
channel”. Scanning will resume five seconds after the end of the
transmission. You may press the Talk Button to stop scanning at
any time.

2. If the radio stops on an undesired transmission, you may
immediately resume the scan by briefly pressing or .

3. In Advanced Scan, the detected code will only be used for one
transmission. You must note the code, exit scan, and setthat
detected code on that channel to permanently use the detected
code.

Use With Accessories

You can transmit more reliably with the use of optional PTT headset
accessories. A PTT headset allows privacy to others around you while
listening.

1. Turn the radio off and plug the PTT accessory into the accessory
jack.

2. Turn the radio on. Press the PTT on the accessory microphone
instead of the radio.

3. Adjust the volume appropriately by pressing or Lower the
volume before placing the accessory on your head or in your ear.

Note:The R100 Series does not have VOX capabilities, and is only
compatible with PTT headset accessories.

Roger Beep Setting

You can set the radio to transmit a unique tone when you finish
transmitting. It is like saying “Roger” or “Over” to let others know
you are finished talking.

1. With the radio on, briefly press until appears. The

current setting On/Off flashes.

2. Press or to turn On or Off.

3. Press the Talk Button to set the talk confirmation tone or to

continue set up.

11

Keypad Tones

You may enable or disable the speaker keytones. You will hear the
key tone each time a button is pushed.

1. Press until appears. The current setting On/Off will
flash.

2. Press or to turn On or Off.

3. Press the Talk Button to confirm or to continue set up

Note: When the keytone feature is off, the following are not disabled:

• Transmit timeout alert tone

• Power-down alert tone

• Low battery alert tone

• The transmitted talk confirmation tone

Auto Power Off

The radio will save power by automatically turning itself off if unused
after a predetermined amount of time.

1. Activate this setting by briefly pressing until displays.
The current setting (0, 30, 60, 90) will flash.

2. Press or to set the time to 30 minutes, 60 minutes or 90
minutes.

3. When you exit the Menu mode, the setting timer will begin if you
are not using the radio.

4. The screen will show .

5. Press the Talk Button to confirm or to exit Menu mode.

Weather Receiver

This radio can tune in to broadcasts by the United States National
Oceanic and Atmospheric Administration (NOAA) Weather Radio.

You can listen to a weather channel (see “Weather Channels and
Frequencies” table for details) or set the radio to alert you to
emergency weather broadcasts that interrupt routine broadcasts.
When you listen to a weather channel, you cannot use the radio in
scan mode or for two-way communications. NOAA has transmitters
located throughout the United States. These transmitters broadcast
watches, forecasts, and other information 24 hours a day.

Note: NOAA weather radio stations are assigned to cover specific
areas and service may be limited. Please check with your local
weather office for frequency and details, or visit
www.weather.gov/nwr in the US to view the appropriate transmitter
for your area. The use of the NOAA logo does not provide an
endorsement or implied endorsement by NOAA’s National Weather
Service.

Setting the Weather Channel Manually

If you know which frequency is correct for your location, refer to the
Weather Channels and Frequencies table located at the back of the
manual to manually set the radio to the appropriate weather channel.

1. After turning Weather Reception on, press . The current
channel flashes.

2. Press or to select the appropriate channel with good
reception in your area.

3. Press Talk button to save the weather channel setting.

Setting the Weather Alert

The radio can be set to respond to NOAA Weather Radio emergency
messages. A special alarm tone sounds an alert and turns on the
weather receiver to give you immediate weather and emergency
information.

1. After turning Weather Reception on, press twice. ON or OFF

.

flashes.

Turning Weather Channel Reception On and Off

1. To turn weather reception on, press and hold Weather button
for 3 seconds.

2. To turn off, press and hold Weather button or turn the radio
off and then back on.

2. Press or to select ON to activate. If you activate the
Weather Alert and return to two-way mode, WX will display.

3. Press Talk button to save the Weather Alert setting.

4. Press and hold for 3 seconds to return to two-way mode.

Scanning for Weather Channel

The radio can scan for an active NOAA transmission automatically.

1. After turning “Weather Reception” on, briefly press the key.

2. The scan icon will appear in the display, and the channel will
scroll through the NOAA channels 1-7.

3. When the radio detects channel activity, it stops scanning and you
can hear the transmission.

4. You may resume the scan by briefly pressing or .

CHANNEL RX (MHz) CHANNEL RX (MHz) CHANNEL RX (MHz)

WX1 162.550 WX5 162.450 WX9 161.775

WX2 162.400 WX6 162.500 WX10 161.750

WX3 162.475 WX7 162.525 WX11 162.000

WX4 162.425 WX8 161.650

Weather Channels and Frequencies

5. To stop scanning, briefly press . The scan icon will
disappear.

Operation

General Specications

Frequency Allocation and Compatibility

A = Channel No. for 22 Channel Models

B = Frequency in MHz

C = Power Output

A B C

1 462.5625 High
2 462.5875 High
3 462.6125 High
4 462.6375 High
5 462.6625 High
6 462.6875 High
7 462.7125 High
8 467.5625 Low
9 467.5875 Low
10 467.6125 Low
11 467.6375 Low
12 467.6625 Low
13 467.6875 Low
14 467.7125 Low
15 462.5500 High
16 462.5750 High
17 462.6000 High
18 462.6250 High
19 462.6500 High
20 462.6750 High
21 462.7000 High
22 462.7250 High

IMPORTANT NOTICE: FCC LICENSE REQUIRED
WARNING: Changes or modications to this unit not expressly approved by the

party responsible for compliance could void the user’s authority to operate the
equipment.

This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: 1) This device may not cause harmful interference,
and 2) this device must accept any interference received, including
interference that may cause undesired operation.

NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Safety Information For microTALK

Your wireless handheld portable transceiver contains a low power transmitter.
When the Talk button is pushed, it sends out radio frequency (RF) signals. The
device is authorized to operate at a duty factor not to exceed 50%. In August
1996, the Federal Communications Commissions (FCC) adopted RF exposure
guidelines with safety levels for handheld wireless devices.

Important:

FCC RF Exposure Requirements: For body-worn operation, this radio has been
tested and meets the FCC RF exposure guidelines when used with Olympia
accessories supplied or designated for this product. Use of other accessories
may no ensure compliance with FCC RF exposure guidelines. Use only

the supplied antenna. Unauthorized antennas, modications, or attachments
could damage the transmitter and may violate FCC regulations.

Normal Position:

Hold the transmitter approximately 25 mm from your face and

antenna pointed up and away.

ISEDC WARNING

This device complies with ISEDC license-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.

Under ISEDC regulations, this radio transmitter may only operate using an
antenna of a type and maximum (or lesser) gain approved for the transmitter
by ISEDC. To reduce potential radio interference to other users, the antenna
type and its gain should be so chosen that the equivalent isotropically radiated
power (e.i.r.p.) is not more than that necessary for successful communication.

The applicant is responsible for providing proper instructions to the user of the
radio device, and any usage restrictions, including limits of exposure durations.
The user manual shall provide installation and operation instructions, as well
as any special usage conditions, to ensure compliance with SAR and/or RF eld
strength limits. For instance, compliance distance shall be clearly stated in the

®

Radios

speak in a normal voice, with the

user manual.
Cet appareil est conforme aux normes RSS exemptes de licence ISEDC. Son

fonctionnement est soumis aux deux conditions suivantes: (1) cet appareil ne
doit pas provoquer d'interférences et (2) cet appareil doit accepter toute
interférence, y compris les interférences pouvant entraîner un fonctionnement
indésirable de l'appareil. En vertu des réglementations ISEDC, cet émetteur
radio ne peut fonctionner qu'avec une antenne d'un type et un gain maximal
(ou inférieur) approuvé pour l'émetteur par l'ISEDC. Pour réduire les
interférences radio potentielles avec d’autres utilisateurs, le type d’antenne et
son gain doivent être choisis de manière à ce que la puissance isotrope
rayonnée équivalente (e.i.r.p.) ne soit pas supérieure à celle nécessaire à une
communication réussie. Le demandeur est responsable de fournir des
instructions appropriées à l'utilisateur du dispositif radio et de toute restriction
d'utilisation, y compris les limites de la durée d'exposition. Le manuel de
l'utilisateur doit fournir des instructions d'installation et d'utilisation, ainsi que
des conditions d'utilisation spéciales, pour assurer la conformité avec les
limites de champ de SAR et / ou RF. Par exemple, la distance de conformité
doit être clairement indiquée dans le manuel d'utilisation.

Important:

Exigences de la FCC/ISEDC concernant l’exposition aux champs électro­magnétiques RF (radiofréquences): En ce qui concerne le fonctionnement de
l’appareil porté sur le corps de l’utilisateur, les tests effectués ont permis de
vérier que cet émetteur-récepteur satisfait aux directives FCC/ISEDC limitant
l’exposition aux champs électro-magnétiques RF lorsqu’il est utilisé avec les
accessoires Olympia fournis ou conçus pour ce produit; l’utilisation d’autres
accessoires peut ne pas garantir le respect des critères des directives
FCC/ISEDC limitant l’exposition aux champs électro-magnétiques RF. Utiliser
l’appareil uniquement avec l’antenne fournie. L’emploi d’une antenne non
homologuée ou modiée, ou d’accessoires non autorisés, pourrait faire subir

des dommages à l’appareil, et peut violer les prescriptions de la
réglementation FCC/ISEDC.

Position normale:

Tenir l'émetteur à environ 25 mm de la bouche et parler normalement,
l'antenne étant éloignée et dirigée vers le haut.

MODEL R100:

This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: 1) This device may not cause harmful
interference, and 2) this device must accept any interference
received,including interference that may cause undesired operation.
FCC Warnings: Replacement or substitution of transistors, regular diodes
or other parts of a unique nature, with parts other than those
recommended by Olympia may cause a violation of the technical
regulations of part 95 of the FCC rules, or violation of type acceptance
requirements of part 2 of the rules.

LIMITATION OF REMEDIES AND DAMAGES. REPAIR OR REPLACEMENT AS
PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE

Warranty & Trademark Acknowledgment

Limited One-Year Warranty

We warrants to the original consumer purchaser only that this product and the
component parts thereof, will be free from defects in workmanship and
materials for a period of one year from the date of rst consumer purchase.
During this period, we will, repair or replace, at its sole option and discretion,
this product or any defective parts. Our’ liability hereunder shall be limited to
repair or replacement of the defective part or parts, and such correction shall
constitute a fulllment of all of our’ warranties hereunder.

This limited warranty is only valid for the original consumer purchaser in
limited jurisdictions and is not transferrable. This limited warranty will
automatically terminate prior to expiration if this product is sold or otherwise
transferred to another party. The product must be purchased from us or an
authorized dealer or the warranty is void. This limited warranty is valid only for
products purchased and utilized in specic jurisdictions.

This limited warranty does not cover damage due to misuse, abuse,
negligence, acts of God, accident, commercial use or modication of, or to any
part of this product. This warranty does not cover damage due to improper
operation, maintenance or installation; ordinary wear and tear; or attempted
alterations or repairs by anyone other than we or someone authorized by us to
do warranty work. Any unauthorized alterations or repairs will void this
warranty. This limited warranty does not cover product sold AS IS or WITH ALL
FAULTS. This limited warranty is invalid if the factory applied serial number or
date stamp has been altered, defaced or removed from this product. This
limited warranty does not cover product purchased or utilized in a jurisdiction
not covered.

The procedure for obtaining service and support, and the applicability of this
warranty, will vary depending on the country or jurisdiction in which you
purchase and utilize the product. For details on obtaining product service,
support and other warranty information please visit our website.

This warranty gives you specic legal rights, and you may also have other
rights which vary from state to state and country to country.

EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, WE MAKES NO OTHER
WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING ANY IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. WE EXPRESSLY DISCLAIMS ALL WARRANTIES NOT STATED IN THIS
LIMITED WARRANTY. ANY IMPLIED WARRANTIES THAT MAY BE IMPOSED BY
LAW ARE LIMITED TO THE TERMS OF THIS EXPRESSED WARRANTY.

17

18 19 20

CONSUMER. WE SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO ATTORNEYS’
FEES AND/OR COSTS OF LITIGATION, FOR BREACH OF ANY EXPRESS OR
IMPLIED WARRANTY ON THIS PRODUCT. WE ARE NOT LIABLE FOR ANY
DAMAGES CAUSED BY THE PRODUCT OR BY THE PRODUCT TO PERFORM,
INCLUDING ANY LOST PROFITS, LOST SAVINGS, INCIDENTAL DAMAGES, OR
CONSEQUENTIAL DAMAGES. WE IS NOT LIABLE FOR ANY CLAIM MADE BY A
THIRD PARTY OR MADE BY YOU FOR A THIRD PARTY. THIS LIMITATION
APPLIES WHETHER DAMAGES ARE SOUGHT, OR A CLAIM MADE, UNDER THIS
WARRANTY OR AS A TORT CLAIM (INCLUDING NEGLIGENCE OR STRICT
PRODUCT LIABILITY), A CONTRACT CLAIM, OR ANY OTHER CLAIM. THIS
LIMITATION CANNOT BE WAIVED OR AMENDED BY ANY PERSON. THIS
LIMITATION OF LIABILITY WILL BE EFFECTIVE EVEN IF WE OR AN AUTHORIZED
REPRESENTATIVE OF WE HAS BEEN ADVISED BY YOU OF THE POSSIBILITY OF
ANY SUCH DAMAGES.

Some states and countries do not allow limitations on how long an implied
warranty lasts and do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitations may not apply to you. This
warranty gives you specic legal rights, and you may also have other rights
which vary from state to state and country to country.

Provided that the product was purchased from us itself or through its
authorized reseller or agent and utilized in the U.S.A., We will, without charge,
repair or replace, at its option, defective products, products or component parts
upon delivery to the authorized Service Center, accompanied by proof of the
date of rst customer purchase, such as a duplicated copy of a sales receipt.

You must pay any initial shipping charges required to ship the product for
warranty service, but the return charges, to an address in the U.S.A, will be at
us’ expense, if the product is under warranty.

For Products Purchased Outside the U.S.A.

Please contact your authorized local reseller or agent for warranty information.
