General GCP-40, GCP-60, GCP-100 Instruction Manual

INSTRUCTION

MANUAL

PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USE

English

GENMAN 092009 RevA

R

R

GENERAL COOKING

GCP-40, GCP-60, GCP-100
Coffee Percolator

U

L

R

C

L

A

S

S

I

F

I

E

D

Introduction

Thank you for choosing our high quality Automatic Coffee Percolator. We are cer­tain you will be pleased with the performance of this product. Please read the fol­lowing instructions carefully before use.

 Warnings & Precautions:

The following warnings and precautions must be observed.

CAUTION! Never immerse the machine in water. If the machine has been soaked, it
must be dried and checked by a technician before being put back into use.
Before installation, please review all of the technical data noted in this manual.

CAUTION! During use the brewer can get very hot. Please use the appropriate han­dles when operating or handling the machine.

• Do not leave the brewer unattended while in operation for extended periods of
time.

• Be sure to unplug the power cord when the machine is not in use.

• Use care during cleaning not to damage, bend or break the individual compo­nents.

• In the following pages, extremely important items are marked by ► for your atten­tion.
► Disclaimer: The Manufacturer will accept no liability for any injury or damage
caused by incorrect usage of the machine or by improper operation contrary to in­formation given in this Instruction Manual.

 Technical Data:

► Specification and information for reference only.

Specification MCP40 MCP60 MCP100

Voltage 120V/220V 120V/220V 120V/220V

Wattage

1350W
80W

1350W
160W

1350 W
160W

Frequency 50/60Hz 50/60Hz 50/60Hz

Volume 6.5 L / 40 Cups 12 L / 60 Cups 15 L / 100 Cups

Brewing Time Approximately 25 Min. Approximately 45 Min. Approximately 65 Min.

Temp. when Brewing
Process Complete

94-97 °C 201-206°F 93-96 °C 199-205°F 92-95 °C 198-203°F

Warming Temperature after 1 hrs 88 °C/190°F after 1 hrs 88 °C/190°F after 1 hrs 88 °C/190°F

Brewing

Holding

RR

GENERAL COOKING

 Parts:

Please check the following Packing List
before installation.

(1) Cover
(2) Urn Body
(3) Level Indicator
(4) Faucet
(5) Power Switch
(6) Indicator Light with Two Functions

Green and Yellow

(7) Urn Base
(8) Basket Cover
(9) Filter Basket
(10) Basket Tray (Optional)
(11) Percolator Tube

 Operation Instruction:

To Brew Coffee, follow these instructions:

1. Fill with cool water not less than half of total capacity of the Urn.

2. Cover the Filter Basket

(8)

with the Basket Cover (7).

3. Center the Percolator Tube (10)into the Basket Tray (9), and make sure that the
foot of the Tube is positioned firmly on the well of the Urn.

4. Center the Filter Basket

(8)

into the Percolator Tube (10)and place the ground

coffee in to the Basket. Cover with the Basket Cover (8)and the Cover of the Urn (1).

5. Plug the cord into the electric outlet and turn the Power Switch

(5)

"ON". The

switch should light up.

6. When the Indicator Light turns Green(6), the brewing process is completed.

7. The secondary Heating System will start to operate automatically after the brew­ing process completes to keep coffee at service temperature.

8. When there are only about 3 cups of coffee left in the Urn, turn the Power Switch

(5)

"OFF" and unplug the power cord from the electric outlet.

NOTE: To reheat cold coffee in the Urn, ensure there is at least 12 cups of coffee in
the tank to reheat safely. Plug the cord into the electrical outlet and turn the Power

Switch (5)"ON".

CAUTION! When in use the brewer is very hot. Use care when handling!

Operation Instruction (continued):

 Cleaning

It is important that the Machine and its accessories be kept clean after use.

For dirt or smudges on the Machine, clean with a soft damp cloth, and if necessary,
with a non-corrosive and/or non-abrasive detergent or cleaner.

Fort Lauderdale, FL 33331, U.S.A.

Phone:[phone] · Fax:[phone]

RR

GENERAL COOKING

 Sediment Indicator

► The Indicator Light (6)will turn Yellow to alert the user that there is scale or sedi-
ment and the machine needs to be de-scaled.

In areas near the heating element, hard water will cause chalk and limestone to
accumulate over time. To keep the machine in its best condition and to ensure cof­fee brewing will result in the best-tasting coffee, we recommend performing a de­scale when you find there are scale sediments at the bottom of the machine or
when the de-sediment Indicator Light turns Yellow.

1. Use one pack of powerful de-sediment powder (provided) to a solution of 500
ml/2 pints water.

2. You may also use 500 ml/2 pt distilled white vinegar on the heating element
in the Urn.

3. Wait 5 to 6 minutes to allow the vinegar to run through the sediments/scale.

4. You may use a brush with soft bristles to brush the heating element.

5. Repeat steps 1 thru 3 until the scale is removed.

6. Use a dry cloth to wipe the vinegar away.

7. Pour clean water into the Urn, brush the heating element lightly to remove any
additional remaining sediment/scale.

8. The brewer is ready for use.

NOTE: To purchase a more powerful de-scaler than we recommend; please
contact your dealer or Asbury Foodservice.

Contact Us:

FOR WARRANTY, SERVICE OR PARTS, PLEASE CONTACT:
Asbury Service Warranty & Parts
Toll Free: 1.877.368.2797

Or visit:

www.asburyfoodservice.com

!

Read & Keep

these instructions

Indoor use only Do not discard
