Genaray MB-WRT User manual

MonoBright™

WIRELESS TRANSMITTER

USER MANUAL

MonoBright Wireless Transmitter - USER MANUAL

1

MonoBright
WIRELESS TRANSMITTER
INTRODUCTION

MonoBright Wireless Transmitter - USER MANUAL

2

Thank you for choosing Genaray.

The Genaray MB-WRT MonoBright Wireless
Transmitter is a dedicated remote control for Genaray
MonoBright LED lights. With the ability to use any of
99 channels, the transmitter operates at 2.4 GHz to
provide up to 98′ (30 m) of untethered freedom.

The MB-WRT Wireless Transmitter facilitates color
temperature adjustment from 32–56 K (±300 K) on Bi-Color
units, as well as brightness adjustment from 100%–10%
on any MonoBright model. You can even control color
temperature or brightness on multiple units that are set at
different values, making this a convenient tool for use in a
sophisticated lighting setup. During the course of a shoot,
use the transmitter to turn off your MonoBright, and the
unit will retain your settings the next time you turn it on.

PRECAUTIONS

· Please read and follow these
instructions and keep this
manual in a safe place.

· Keep this product away from water
and any flammable gases or liquids.

· Do not attempt to disassemble
or repair this product.

· Always install AAA batteries of the
same type and age. Do not combine
different types or old and new
batteries. This can cause the batteries
to leak, overheat, or explode.

· Install the batteries in the
proper orientation, as indicated
by the markings in the battery
compartment. Installing batteries
in the reverse orientation can cause
them to leak, overheat, or explode.

· Keep this product away from children.

· All photos are for illustrative
purposes only.

MonoBright Wireless Transmitter - USER MANUAL

3

Status LEDs

Transmitting
indicator LED

PRODUCT
OVERVIEW

Power button

Minus (-) button

Mode button

Plus (+) button

MonoBright Wireless Transmitter - USER MANUAL

4

Display

Power Output

)

Blue (

Bi-Color

Orange (

Channel

None

)

Press the Mode button to cycle through the

three modes. The status LEDs indicate the

current mode.

TURNING ON THE
TRANSMITTER AND
SETTING THE CHANNEL

You can use the wireless transmitter to
control your MonoBright unit remotely
from a distance of up to 98′ (30 m).
The transmitter lets you adjust power
output and activate sleep mode. You
can also use the transmitter to control
multiple MonoBright units, even if
they are set to different channels.

The wireless transmitter runs on two AAA
batteries (available separately). Install
the batteries in the proper orientation.

Before using the transmitter, make
sure your MonoBright is turned on.

To turn on the transmitter, press
the transmitter’s power button.

To set the transmitter’s channel,
follow these steps:

1. Make sure the transmitter and the
MonoBright are set to the same channel.

2. Press the transmitter’s mode ( )
button repeatedly to cycle through
the modes until the channel mode
appears on the transmitter’s display.
In channel mode, neither of the
transmitter’s status indicators will glow.

3. Use the plus ( ) and minus ( )
buttons to select the channel.

For setting the MonoBright unit’s channel,
refer to your MonoBright’s user manual.

MonoBright Wireless Transmitter - USER MANUAL

INSTRUCTIONS

5
