GEMINI CDX-2400 User Manual

DUAL CD PLAYER

CDX-2400

OPERATIONS MANUAL
MANUAL DE INSTRUCCIONES
MANUEL D’INSTRUCTIONS
BEDIENUNGSHANDBUCH

FOR ENGLISH READERS Page 2 ~ Page 5
PARA LECTORES EN ESPAÑOL Página 6~ Página 9
UTILISATEURS FRANCAIS Page 10 ~ Page 13
FÜR DEUTSCHE LESER Seite 14 ~ Seite 17

PLEASE READ BEFORE USING APPLIANCE

IMPORTANT WARNING AND SAFETY INSTRUCTIONS!

RISK OF ELECTRIC

CAUTION

CAUTION: This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to other equipment. To prevent electromagnetic interfer-

ence with electric appliances such as radios and televisions, use shielded cables and connectors for connections.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the liter-

ature accompanying the appliance.

he lightening flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the prod-

T
uct’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

EAD INSTRUCTIONS: All the safety and operating instructions should be read before the product is operated.

R
RETAIN INSTRUCTIONS: The safety and operating instructions should be retained for future reference.
HEED WARNINGS: All warnings on the product and in the operating instructions should be adhered to.
FOLLOW INSTRUCTIONS: All operating and use instructions should be followed.

LEANING: The product should be cleaned only with a polishing cloth or a soft dry cloth. Never clean with furniture wax, benzine, insecticides or other volatile liquids since

C

they may corrode the cabinet.

ATTACHMENTS: Do not use attachments not recommended by the product manufacturer as they may cause hazards.
WATER AND MOISTURE: Do not use this product near water, for example, near a bathtub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming

pool; and the like.

CCESSORIES: Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious dam-

A

age to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the product should fol­low the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

CART: A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to over-

turn. See Figure A.

ENTILATION: Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating, and these open-

V

ings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be
placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

OWER SOURCES: This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your

P

home, consult your product dealer or local power company.

LOCATION: The appliance should be installed in a stable location.
NON-USE PERIODS: The power cord of the appliance should be unplugged from the outlet when left unused for a long period of time.
GROUNDING OR POLARIZATION:

• If this product is equipped with a polarized alternating current line plug (a plug having one blade wider than the other), it will fit into the out­let only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still
fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

• If this product is equipped with a three-wire grounding type plug, a plug having a third (grounding) pin, it will only fit into a grounding type
power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete out­let. Do not defeat the safety purpose of the grounding type plug.

POWER-CORD PROTECTION: Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying par-

ticular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.

OUTDOOR ANTENNA GROUNDING: If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide

some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit,
connection to grounding electrodes, and requirements for the grounding electrode. See Figure B.

LIGHTNING: For added protection for this product during a lightening storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and

disconnect the antenna or cable system. This will prevent damage to the product due to lightening and power-line surges.

POWER LINES: An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits,

or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them might be fatal.

OVERLOADING: Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric

shock.

OBJECT AND LIQUID ENTRY: Never push objects of any kind into this product through openings as they may touch dangerous voltage points

or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.

SERVICING: Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other haz-

ards. Refer all servicing to qualified service personnel.

DAMAGE REQUIRING SERVICE: Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions:

• When the power-supply cord or plug is damaged.

• If liquid has been spilled, or objects have fallen into the product.

• If the product has been exposed to rain or water.

• If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper
adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation.

• If the product has been dropped or damaged in any way.

• When the product exhibits a distinct change in performance, this indicates a need for service.

REPLACEMENT PARTS: When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same

characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

SAFETY CHECK: Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper op-

erating condition.

WALL OR CEILING MOUNTING: The product should not be mounted to a wall or ceiling.
HEAT: The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

SHOCK DO NOT

OPEN!

Fig. A

Fig. B

2

CDX-2400

FRONT

BACK

9

21

7

10

22

20

19

7

6

5

8

14

13

12

11

18

6

15

16

17

4

4

1

2

3

REAR PANEL OF

MIXER

3

(NOT INCLUDED)

3

CDX-2400

INTRODUCTION:

Congratulations on purchasing the Gemini CDX-2400 Dual CD Player.
This state of the art 2U professional Dual CD player is backed by a 1 year
warranty*. Prior to use, we suggest that you carefully read all the instructions.

FEATURES:

- Audio CD, CD-R CD-RW compatible

- Anti-shock using RAM buffer memory

- 2 Selectable Jog modes Pitch Bend/Search

- Instant-start & cue with preview

- Single auto-cue/continuous play modes

- One seamless loop per side with reloop

- Pitch bend via jog wheel or buttons

- Three mode time selection

- Frame accurate search

- Large blue backlit LCD display

- Coaxial RCA digital output

- Rubber jog wheels with finger grips

- Variable pitch control with a 16% range

SAFETY SPECIFICATIONS:

Laser Diode Properties
Material: Ga - Al - As
Wavelength: 755 - 815 nm (25° C)
Laser Output: Continuous Wave, max. 0.5 mW

PRECAUTIONS:

LINE OUTPUT JACKS Plug one end of the included RCA cable into

3

LINE OUTPUT JACKS on the rear panel. Plug the other end of the
RCA connectors into any available line input jacks on your mixer.

If you are connecting the CDX-2400 through a reciever, you can
plug the RCA connectors into the CD or AUX INPUT JACKS on your
reciever. If there are no CD or AUX INPUTS use any line level
(not phono) inputs.

CONTROL CABLES Plug the CONTROL CABLES to each side of the

4

CDX-2400 be careful when plugging in these cables, never force
the cable into its socket, making sure that the DIN connector at the
end of the cable properly aligns with the drawing on the back of
the CDX-2400.

FUNCTIONS:

POWER: Once you have connected all your cables and made sure

5

that the VOLTAGE SELECTION SWITCH is set correctly, you can turn
the CDX-2400 on by pressing the POWER button, pressing the

CDX-2400’s POWER button a second time will turn off the unit.

DISC TRAY: The DISC TRAY is where the CD is held during loading,

6

unloading and playback, and holds both 12 cm and 8cm CD’s.
(DO NOT FORCE THE CD TRAY TO CLOSE EXCESSIVE FORCE WILL

DAMAGE THE CD MECHANISM, USE THE OPEN AND CLOSE BUT­TONS)

EJECT BUTTON: Pressing the EJECT BUTTON will open or close the

7

DISC TRAY, unless the CDX-2400 is in play mode, then you must first
stop the side you wich to eject.

1. Do not use this CD player at temperatures below 41°F/5°C or
higher than 95°F/35°C.

2. The apparatus should not be exposed to dripping or splashing,
and no objects filled with liquids such as vases should be
placed on the apparatus.

3. Place the unit in a clean and dry location.

4. Do not place the unit in an unstable location.

5. When disconnecting the power cord from the AC outlet,
always grasp it by the plug. Never pull the power cord.

6. To prevent electric shock, do not remove the cover or the bottom
screws.

7. There are NO USER SERVICEABLE PARTS INSIDE. Please
refer to a qualified technician.

IN THE USA ~ IF YOU EXPERIENCE PROBLEMS WITH THIS UNIT CALL GEMINI

CUSTOMER SERVICE AT: 1 [phone]. DO NOT ATTEMPT TO RETURN THIS EQUIPMENT

8. Do not use chemical solvents to clean the unit.

9. Keep the laser pickup clean by keeping the tray closed.

10. Keep this manual in a safe place for future reference.

TO YOUR DEALER.

CONNECTIONS:

VOLTAGE SELECTION SWITCH Before plugging the CDX-2400 into any

1

wall outlet, make sure that the VOLTAGE SELECTION SWITCH is set to
the proper voltage.
To change this selection unscrew the hard plastic protective top with a
Phillips head screw driver. Then use a flat head screw driver to move
the switch to the proper selection (115V or 230V) .
Do not force or twist the switch. Excessive force may cause damage, if
the switch does not move smoothly, contact a qualified technician.

POWER After you have properly set the VOLTAGE LINE SELECTOR

2

SWITCH you may plug in the power cord of the CDX-2400.

JOG WHEEL : In SEARCH MODE the JOG WHEEL can be used to

8

search forward or bacwards in the music track, as well as for fine
adjustments to a CUE point in PAUSE mode. In PITCH BEND mode the
JOG WHEEL will function the same as the PITCH BEND allowing you
to speed up (FORWARD) or slow down (REWIND) the music clock­wise bieng (FORWARD) and counter clockwise being (REWIND).

JOG MODE BUTTON: When the JOG MODE BUTTON is illuminated

9

it indicates the the JOG WHEEL is in SEARCH MODE, and when not
illuminated it indicates that the JOG WHEEL is in PITCH BEND

MODE.

DISPLAY: The DISPLAY shows the track number, pitch value, pitch

10

bend, single, continue (for continuous play), play/pause modes, fast
forward/reverse modes, loop mode, reloop mode, PGM, repeat
modes, the playback display bar, and three diffirent time displays.
These times displays are TIME ELAPSED on the track, TIME REMAIN-
ING on the disc and and TIME REMAINING on the track. Time is
measured in minutes, seconds and frames.

PGM: Allows you to create a set playlist. To program a set list into

11

the CDX-2400 memory, begin by stopping the unit from play and
pressing PGM to begin the set list. Select a track by using the track
selection button to scan to the first track to be placed in the set list.
When you have selected the proper track press PGM and the
CDX-2400 will be ready to set your next selection. Repeat the previ­ous steps until you have completed your playlist, then press play to
begin the set list.

REPEAT: Press the repeat button once to engage 1 or repeat the

12

selected track. Press REPEAT again to engage ALL setting wich will
repeat all the tracks on the CD. Press REPEAT again to disengage
the repeat function

4

CDX-2400

FUNCTIONS: (CONTINUED)

SINGLE: Pressing the SINGLE button engages SINGLE mode, in this

13

mode the CDX-2400 will play one song and then stop. Pressing the
SINGLE button again will then activate CONTINUOUS mode causing
the unit to play continuously (after the last track, the unit will return to
the first track of the disc and continue to play).

TIME: The TIME BUTTON switches the time display between three

14

available sources, these three are TIME ELAPSED on the track, TIME

REMAINING on the disc and and TIME REMAINING on the track.
TIME ELAPSED indicates how much time has currently gone by since the

play button was pressed, TIME REMAING ON DISC will count down the
time remaining on the entire disc and TIME REMAINING ON TRACK
counts down the time that is left before the end of the track.

PITCH: Pushing the PITCH button (the button will light up blue) activates

15

the PITCH CONTROL SLIDE. The pitch or speed of the CD will change
plus or minus 12% depending on the position of the PITCH CONTROL

SLIDER. Push the PITCH button again to deactivate this mode.

PITCH CONTROL SLIDE: Moving the PITCH CONTROL SLIDE

16

up or down will lower or raise the pitch percentage + or - 12%.

PITCH BEND: Pushing the PITCH BEND BUTTONS will automatically

17

raise the pitch up to +16% or lower the pitch down to -16% from the
existing pitch setting. Releasing the buttons will return the pitch
to the original pitch setting. You can use this function to match the beat
when mixing from one song to another

LOOP SECTION: A LOOP repeats the section between the entry point

18

(IN) and the exit point (OUT). To set a loop while the unit is playing,
start by pressing the IN BUTTON (it will light up) and when you reach
the desired end loop point press the OUT BUTTON (it will also light up).
The loop will continue playing until you press the OUT BUTTON again
allowing the music to continue from that point on, to re-engage the loop
you must press the RELOOP BUTTON. When you have released your
loop the OUT BUTTON will turn OFF and the IN BUTTON will remain lit
to indicate that your loop is stored in the CDX-2400 memory. Pressing
the IN BUTTON again while the unit is playing will erase the previously
saved loop while saving your new loop entry point. Press OUT to exit the
loop and save a new complete loop.
Press RELOOP to return to the beginning of the previously saved loop
from normal play. Press RELOOP repeatedly to cause the loop to stutter.

NOTE: THE FIRST LOOP WILL HAVE A PAUSE AT THE EXIT POINT,
WHILE ALL OTHERS WILL BE SEAMLESS.

PLAY/PAUSE: Each press of the PLAY/PAUSE BUTTON

19

causes the operation to change from PLAY to PAUSE or from PAUSE
back to PLAY. The PLAY/PAUSE BUTTON remains lit when in PLAY
mode, while it blinks in PAUSE mode.

TRACK SELECTION: The TRACK SELECTION buttons let you select

22

the track to play. +10 allows you to scan through the track selection
in increments of 10. TRACK SKIP allows you to scan through each
track one at a time.

OTE : ONCE YOU HAVE SKIPPED TO ANOTHER TRACK, YOU MAY NOT GO BACK

N

O YOUR PROGRAMMED CUE POINT. YOU MUST BEGIN YOUR CUE SELECTION

T
OVER AGAIN, THE CUE WILL BE PRESET TO THE BEGINNING OF THE NEWLEY SE­LECTED TRACK.

TROUBLESHOOTING:

- If a disc will not play, check to see if the disc was loaded correctly
(label side up). Also check the disc for excessive dirt, scratches, etc.

- If the disc turns but there is no sound, check the cable connections,
if they are ok, check your amplifier or reciever.

-If the CD skips, check the CD for dirt or scratches. Do not assume that
the CD player is defective. Many cd’s are recorded out of spec and
will skip on most or all CD players. Before sending the unit for repair,
try playing a CD that you are sure plays properly.

SPECIFICATIONS:

GENERAL:

Type................................................................................Compact Disc Player

Disc Type...................................Standard Compact discs (12 cm & 8 cm)

Time Display......................Track Elapsed, Track Remain, or Total remain

Variable Pitch.......................................± 12% Slider with Resume Switch

Pitch Bend............................................................................± 16% Maximum

Instant Start....................................................................Within 0.03 seconds

Installation...........................................................................................19" each

Dimensions.........Main unit: 19" x 3.5" x 10" (482.6 x 88.9 x 254 mm)

…..............…Remote unit: 19" x 3.5" x 2.75" (482.6 x 133 x 70 mm)

Weight Per Unit................................................Main unit: 13.7 lbs. (5.2 kg)

…............................................................................Remote unit: 4 lbs.(1.5kg)

AUDIO SECTION:

Quantization.....................................1 Bit Linear/Channel, 3 Beam Laser

Oversampling Rate..............................................................................8 Times

Sampling Frequency..........................................................................44.1 kHz

Frequency Response............................................................20 Hz to 20 kHz

Total Harmonic Distortion...................................................Less Than 0.05%

Signal to Noise Ratio..............................................................................85 dB

Dynamic Range........................................................................................85 dB

Channel Separation.................................................................85 dB (1 KHz)

Output Level...................................................................2.0 +/- 0.2V R.M.S.

Power Supply.......................................................AC 115/230V, 60/50 Hz

SPECIFICATIONS AND DESIGN ARE SUBJECT TO CHANGE WITH-

OUT NOTICE FOR PURPOSE OF IMPROVEMENT.

CUE: While the unit is playing and after the cue point has been

20

programmed, pressing CUE will cause the CD player to enter the
PAUSE mode (PLAY/PAUSE BUTTON blinks) at the programmed cue
point (the CUE LED is lit). Holding down the CUE button
changes the function to preview , and allows you to stutter start or play
from the programmed CUE POINT Releasing the CUE button will return
the CD to the preset CUE point.

STOP BUTTON: When pressed the STOP BUTTON stops the playback

21

of the CD player.

5

POR FAVOR LEA ANTES DE UTILIZAR, INSTRUCCIONES

IMPORTANTES DE SEGURIDAD

RIESGO DE SHOCK

CAUTION

ATENCIÓN: Este producto cumple con la normativa legal si se utilizan cables y conectores blindados para conectar la unidad a otro equipo. Para evitar interferencias electro-

magnéticas con otros aparatos eléctricos, como radios y televisores, deben emplearse cables y conectores blindados.

os signos de exclamación dentro de un triángulo que puedan aparecer en la documentación que acompaña a la unidad pretenden alertar al usuario de instrucciones de op-

L

eración o mantenimiento importantes.

l signo de un rayo dentro de un triángulo pretende alertar al usuario de la presencia de "voltaje peligroso" no aislado en el inte-rior de la unidad, que podría ser de suficiente

E

ntensidad como para constituir riesgo de descarga eléctrica.

i
LEA LAS INSTRUCCIONES: Deben leerse todas las indicaciones de uso y seguridad antes de usar este producto.
CONSERVE LAS INSTRUCCIONES: Las instrucciones de uso y seguridad deben conservarse para referencias futuras.

TIENDA A LAS ADVERTENCIAS: Deben seguirse todas las advertencias sobre este producto que figuran en el manual de instrucciones.

A
SIGA LAS INSTRUCCIONES: Deben seguirse todas las instrucciones del manual.
LIMPIEZA: Este producto debe limpiarse con una mopa suave o con un paño seco. Nunca utilice cera para muebles, gasolina, insecticidas u otros líquidos volátiles, ya que

podrían corroer la carcasa.

OMPLEMENTOS: No utilice accesorios que no estén recomendados por el fabricante, pues podrían dañar la unidad.

C
AGUA Y HUMEDAD: No use este producto cerca de medios acuáticos, como una bañera, un cubo de agua, un fregadero o un lavadero;

tampoco en un sótano húmedo, ni cerca de una piscina o similar.

ACCESORIOS: No coloque el producto sobre un carrito, soporte, trípode, brazo o mesa. Podría caer y causar graves daños a un niño o
dulto, así como a la propia unidad. Úsese sólo con un carrito, soporte, trípode, brazo o mesa recomendado por el fabricante. Al montar la

a
unidad deben seguirse siempre las instrucciones y emplearse accesorios recomendados por el fabricante.

CARRITO: Si el producto va sobre un carrito, debe moverse el conjunto con cuidado. Detenciones bruscas, una fuerza excesiva o superfi­ies inadecuadas pueden provocar la caída de todo el conjunto. Véase Figura A.

c

ENTILACIÓN: Las aperturas y ranuras de la carcasa están diseñadas para la ventilación, aseguran un manejo fiable y lo protegen de

V
cualquier sobrecalentamiento, por tanto, nunca deben cubrirse ni bloquearse. Estas aperturas no deben taparse colocando el producto sobre
un sofá, una cama, una alfombra o superficies similares. Nunca debe colocarse en una estructura prefabricada, como una caja o un rack, a menos que tengan la ventilación
adecuada o lo permitan las instrucciones del fabricante.

FUENTES DE ALIMENTACIÓN: Esta unidad debe utilizarse exclusivamente con el tipo de suministro eléctrico indicado en la etiqueta correspondiente. Consúltelo antes de
enchufar el producto si no está seguro del tipo de suministro del lugar donde lo va a usar.

UBICACIÓN: Este aparato debe colocarse en una ubicación estable.

PERIODOS SIN USARLO: Si no se va a usar la unidad durante un tiempo prolongado, desenchúfelo de la corriente eléctrica.

TOMA DE TIERRA O POLARIZACIÓN:

- Si este producto lleva una clavija de corriente alterna polarizada (con un pivote más grueso que otro, tipo inglés), sólo entrará en una posición. Es una medida de seguri-

dad. Si no puede introducir la cla-vija en el enchufe, gírela. En ningún caso debe forzarse. Si sigue sin entrar, un electricista debería cambiar el enchufe.

- Si la unidad lleva una clavija con tres pivotes (el tercero corres-ponde a la toma de tierra), sólo entrará en un tipo de enchufe. Se trata de una medida de seguridad. Si el

enchufe y la clavija no son compatibles, un electricista deberá cambiar el enchufe. En ningún caso deberá forzarse.

PROTECCIÓN DEL CABLE DE CORRIENTE: Los cables de corriente deben protegerse para que nadie los pise ni corran el riesgo de pin­zarse por elementos colocados encima o que los aprisionen. Debe prestarse especial atención al cable, al enchufe, a los extensores de cable
y al punto por donde el cable sale de la unidad.

TIERRA DE LAANTENA EXTERIOR: Si el producto lleva conectada una antena exterior o sistema de cables, asegúrese de que cuenta con
la toma de tierra correspondiente, a fin de proteger la unidad de variaciones de voltaje y cargas de electricidad estática. Existe docu­mentación oficial acerca de la correcta utilización de la toma de tierra y de las medidas de seguridad pertinentes, conexión de los electrodos
de descarga y sus requisitos. Véase Figura B.

RAYOS: Como protección adicional del producto durante una tormenta eléctrica, o durante periodos prolongados sin usarlo, desenchúfelo
de la corriente y desconecte la antena o sistema de cables. De este modo se protegerá el producto de los daños que pueda producir la caída
de un rayo o las fluctuaciones de la red eléctrica.

LÍNEAS ELÉCTRICAS: Nunca debe situarse un sistema de antena cerca de líneas eléctricas u otros circuitos de corriente. Tampoco debe
colocarse en lugares donde pueda caer sobre dichos circuitos eléctricos. Al instalar un sistema de antenización exterior, debe tomarse la extrema precaución de no tocar
dichas líneas eléctricas, pues el mas minimo contacto puede ser fatal.

SOBRECARGA: No sobrecargue los enchufes de la pared con ladrones o instalando enchufes múltiples, pues correría el riesgo de electrocución o incendio.

ENTRADA DE OBJETOS O LÍQUIDOS: Nunca introduzca objetos de ningún tipo en el interior del producto, pues podrían tocar una parte eléctrica y cortocircuitar el
aparato, lo que resultaría en un incendio o descarga eléctrica. No verter nunca ningún líquido sobre el producto.

REPARACIÓN: No intente reparar el producto por cuenta propia, ya que abrir o retirar la carcasa le expondría a un voltaje peligroso u otros peligros. Diríjase siempre a un
centro de servicio técnico autorizado.

DAÑOS QUE REQUIEREN REPARACIÓN: Desenchufe el aparato de la corriente y diríjase a un servicio técnico autorizado si se da alguna de las siguientes situaciones:

- El cable de alimentación o la clavija están dañados.

- Se ha vertido líquido o ha caído algún objeto sobre la unidad.

- El aparato se ha expuesto a la lluvia o a salpicaduras.

- La unidad se ha caído al suelo o dañado de algún modo.

- El aparato no funciona con normalidad, ni aun siguiendo las instrucciones. Ajuste sólo los mandos que se indican en las instrucciones, ja que la manipulación inadecuada

de otros controles podría dañar la unidad y requeriría un mayor trabajo de un técnico para restablecer su funcionamiento normal.

- Si el producto muestra anomalías en su funcionamiento, necesita revisión por parte de un servicio técnico autorizado.
RECAMBIOS: Cuando se necesite alguna pieza de recambio, asegúrese de que el servicio técnico utilice piezas originales autori-zadas o que tengan las mismas características

que las originales. Los reemplazos no autorizados pueden causar descargas eléctricas, incendios u otros daños.

COMPROBACIÓN DE SEGURIDAD: Tras la reparación, solicite al técnico que efectúe las comprobaciones de seguridad necesarias para determinar que el producto se en-

cuentra en las condiciones adecuadas para su funcionamiento.

MONTAJE EN UNA PARED O TECHO: Este producto nunca debe montarse en una pared o en el techo.
CALOR: Este producto debe alejarse de fuentes de calor, como radiadores, estufas u otros aparatos que irradien calor, incluyendo amplificadores.

ELECTRICO - NO

ABRIR!

Fig. A

Fig. B

6
