GE
Lighting Solutions
Flood Lighting
Versaflood™ II (V2FN, V2FS, V2FC & V2FD)
imagination at work
Product Features
GE offers reliable Signlighter fixtures for signlighting, recreational, security, facade (ground, structure or wall mounted) and
billboard lighting applications.
Applications
• For signlighting, recreational, security and facade
(ground, structure or wall mounted) lighting
Housing
• Heavy-duty (NEMA) die-cast aluminum housing
Finish
• Polyester powder paint finish
Ratings
• Listed Suitable for Wet Locations
/
Mounting
• Surface mounted through back with 3/4-inch threaded
conduit
Unique Features
• Sealed and activated charcoal filtered optical assembly
• Stippled, heat and shock resistant tempered glass
V2FN/V2FC units
• Clear, heat and shock resistant tempered glass V2FS/
V2FD units
• Convex borosilicate glass lens, used with high wattage
lamps, in V2FS/V2FD units
• 3/4-inch threaded conduit openings–top and sides for
through wiring
• Adjustable mogul base E39 socket standard except
150W PMH furnished with medium socket
• Stainless steel door latch is standard construction
• Brace to hold door open when relamping is standard
Ordering Number Logic
Versaflood™ II (V2FN, V2FS, V2FC & V2FD)
_ _ _ _ - _ _ - _ - _ - _ - _ - _ - _ - _ _ - _
PROD. ID
V2FN =
Versaflood II
Signliter
V2FS =
Versaflood II
Signliter–
Improved
Optics
V2FC =
Versaflood II
Signliter–
Topmount
V2FD =
Versaflood II
Signliter–
Toplighter
and Improved
Optics
WATTAGE
07 = 70
10 = 100
15 = 150
(55V)
17 = 175
20 = 200
25 = 250
40 = 400
LIGHT
SOURCE
E = Energy Act
Compliant Pulse
MH (EPMH)
P = Pulse MH
S = HPS
VOLTAGE
60Hz
0 =
120/208/
240/277
Multivolt
1 = 120
2 = 208
3 = 240
4 = 277
5 = 480
C =
120X240
X277
D = 347
F =
120X347
T = 220
50Hz
Y = 240
NOTE: 120X347
connected for
120V
BALLAST
TYPE
SELECTION
See Ballast and
Photometric
Selection Table
A = Autoreg
E = Induction
G = Mag-Reg
H = HPF Reactor
K = Hot Restart
M = Mag-Reg
P = CWI with
Grounded
Socket Shell
Ballast
with
Grounded
Socket
Shell
or Lag
PE
FUNCTION
1 = None
2 = PE Receptacle
NOTE: Receptacle
connected same
voltage as unit
except as noted.
Order PE Control
separately.
MOUNTING
OPTIONS
S = Standard–
uses knockouts for
mounting
C = 3/4-inch
conduit
entrance
through
mounting
bracket
P = 2-inch
(60mm)
pipe mount
*Standard
Mounting not
available with
top mounting
Ballast Selection Table
60HZ 50HZ
Light
Wattage Source Multivolt 277,480 120 x 347 220 200-277 240
V2FN, V2FC
70, 100, 150 (55V)
175, 250 EPMH A A N/A N/A N/A N/A
(Coated)
250 EPMH A A
V2FS, V2FD
70, 100, 150 (55V)
200, 250, 400 HPS A A A
175 EPMH A A N/A N/A N/A N/A
250 EPMH A A N/A N/A N/A N/A
400 EPMH A A N/A N/A N/A N/A
85 Induction N/A E (120V only) N/A N/A E N/A
150 PMH H** H
HPS H G, H, K, M, P G*, H, M* N/A N/A H
HPS H G, H, K, M, P G*, H, M* N/A N/A H
Ballast Type / Voltage
120,208,240,
2
H N/A N/A N/A
347
N/A
1
, G1, M1 A N/A A, H
N/A N/A N/A
IES DISTRIBUTION
TYPE
See Ballast and
Photometric Selection
Table
S = Short
M = Medium
N = Non-cutoff
4 = Type IV
1
NOTE:
*Not available in 120X347V
**150W PMH 120X240X277
1
Not available in 200W.
2
150W PMH Not Available 480V.
COLOR
DB = Dark Bronze
Standard
GR = Gray
OPTIONS
B = Time Delay
Automatically
Switched Quartz
F = Fusing (Not available
with multivolt or
120X347V)
P = Prewired with 6 ft (2M)
#14/3
Photometric Selection Table
PHOTOMETRIC SELECTION TABLE
Light IES Socket Photometric
Wattage Source Distribution Position Curve Number 35-
V2FN/V2FC-Signliter with Stippled, Flat Door Glass
70, 100, 150 (55V) HPS MN4 4 177884
175, 250 EPMH (Coated) SN4 1 17452859
175, 250 EPMH SN4 1 17452860
150** PMH SN4 1 17454147
V2FS/V2FD-Signliter with Improved Optics
70, 100, 150 (55V) HPS SN4 B 178372
200, 250, 400 HPS SN4 Fixed 178421 (Convex Glass)
175, 250 EPMH SN4 A 178373
175, 250 EPMH (Coated) SN4 A 178374
400 EPMH SN4 Fixed 178377 (Convex Glass)
400 EPMH (Coated) SN4 B 178378 (Convex Glass)
85 QL Induction SN4 Fixed 17453295
150 (Med Base) PMH SN4 A 17454148
Product Dimensions
S = STANDARD MOUNTING
C = 3/4 inch Conduit Entrance Mounting P = 2-inch Pipe Mounting
• Approximate Net Weight: 27-50 lbs. (12-16 kgs)
• Suggested Mounting Height: 0-20 ft. (0-6 M)
DATA
GE Lighting Solutions • 1-888-MY-GE-LED • www.gelightingsolutions.com
1 - 8 8 8 - 6 9 - 4 3 - 5 3 3
GE Lighting Solutions, LLC is a subsidiary of the General Electric Company. The GE brand and logo are trademarks of the General Electric Company.
© 2012 GE Lighting Solutions, LLC. Information provided is subject to change without notice. All values are design or typical values when measured under laboratory conditions.
OLP-2970 (Rev. 06/14/12)
