OWNER’S MANUAL
SAFETY INFORMATION .......3-6
USING YOUR OVEN
Features ..............................7
Controls ..............................8
Power Levels ..........................9
Time and Auto Features ............10-13
Sensor Features ................... 14-16
Other Features .......................17
Microwave Terms .....................18
CARE AND CLEANING
Care and Cleaning ....................18
TROUBLESHOOTING
Things that are Normal ............... 20
CONSUMER SUPPORT
Warranty ............................21
Consumer Support ....................22
PEB7227
PES7227
Write the model and serial
numbers here:
Model # _________________
Serial # _________________
You can find them on a label inside
the oven.
MICROWAVE OVEN
GE is a trademark of the General Electric Company. Manufactured under trademark license.
49-40780-1 01-18 GEA
THANK YOU FOR MAKING GE APPLIANCES A PART OF YOUR HOME.
Whether you grew up with GE Appliances, or this is your first, we’re happy to have you in the family.
We take pride in the craftsmanship, innovation and design that goes into every GE Appliances
product, and we think you will too. Among other things, registration of your appliance ensures that we
can deliver important product information and warranty details when you need them.
Register your GE appliance now online. Helpful websites and phone numbers are available in the
Consumer Support section of this Owner’s Manual. You may also mail in the pre-printed registration
card included in the packing material.
2 49-40780-1
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
SAFETY INFORMATION
WARNING
When using electrical appliances, basic safety precautions should be followed, including the following:
Read all instructions before using this appliance.
Read and follow the specific precautions in the
PRE
CAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY section on
page 5.
Use this appliance only for its intended use as described
in this manual. Do not use corrosive chemicals or
vapors in this appliance. This microwave oven is
specifically designed to heat, dry or cook food, and is
not intended for laboratory or industrial use.
This appliance should be serviced only by qualified
service personnel. Contact nearest authorized service
facility for examination, repair, or adjustment.
INSTALLATION
Install or locate this appliance only in accordance with
the provided installation instructions.
This appliance must be grounded. Connect only to
a properly grounded outlet. See the GROUNDING
INSTRUCTIONS section on page 5.
Be certain to place the front surface of the door 3
inches or more back from the counter top edge to avoid
accidental tipping of the appliance in normal usage.
Recommended clearances: 3 inches on each side, 3
inches on the top, and 1 inch in the rear.
Do not operate this appliance if it has a damaged power
cord or plug, if it is not working properly, or if it has been
damaged or dropped.
Keep power cord away from heated surfaces.
Do not let cord hang over edge of table or counter.
Do not immerse power cord or plug in water.
Do not cover or block any opening on the appliance.
Do not store this appliance outdoors. Do not use this
product near water - for example, in a wet basement,
near a swimming pool, or in a similar location.
Do not mount over a sink.
To reduce the risk of burns, electric shock, fire, injury to persons, or exposure to
excessive microwave energy:
TO REDUCE THE RISK OF FIRE IN THE CAVITY:
— Do not overcook food. Carefully attend appliance when
paper, plastic or other combustible materials are placed
inside the oven while cooking.
— Remove wire twist-ties and metal handles from paper or
plastic containers before placing them in the oven.
— If materials inside the oven ignite, keep the oven door
closed, turn the oven off and disconnect the power cord,
or shut off power at the fuse or circuit breaker panel.
— Do not store any materials in the oven when not in use.
Do not leave paper products, cooking utensils, or food in
the cavity when not in use. All racks should be removed
from oven when not in use.
— Do not operate the microwave feature without food in
the oven.
TO REDUCE THE RISK OF BURNS
Be careful when opening containers of hot food. Use
pot holders and direct steam away from face and hands.
Vent, pierce, or slit containers, pouches or plastic bags to
prevent build-up of pressure.
Be careful when touching the turntable, door, rack or walls
of the oven which may become hot during use.
Liquids and certain foods heated in the microwave oven
can present a risk of burn when removing them from the
microwave. The potential for a burn is greater in young
children, who should not be allowed to remove hot items
from the microwave.
READ AND SAVE THESE INSTRUCTIONS
49-40780-1 3
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
WARNING
OPERATING
As with any appliance, close supervision is necessary
when used by children.
Do not operator the oven without the turntable in place.
The turntable must be unrestricted so it can turn.
Make sure all cookware used in your microwave oven
is suitable for microwaving. Most glass casseroles,
cooking dishes, measuring cups, custard cups, pottery
or china dinnerware which does not have metallic trim or
SAFETY INFORMATION
glaze with a metallic sheen can be used in compliance
with cookware manufacturers’ recommendations.
Do not store anything directly on top of the microwave
surface when the microwave is in operation.
Some products such as whole eggs and sealed
containers - for example, closed jars - are able to
explode and should not be heated in the microwave
oven.
Do not overcook potatoes. The could dehydrate and
catch fire.
Do not cover any other part of the oven with metal foil.
This will cause overheating of the oven.
Cook meat and poultry thoroughly—meat to at least an
INTERNAL temperature of 160°F and poultry to at least
an INTERNAL temperature of 180°F. Cooking to these
temperatures usually protects against foodborne illness.
SUPER HEATED WATER
Ŷ /LTXLGVVXFKDVZDWHUFRIIHHRUWHDDUHDEOHWR
be overheated beyond the boiling point without
appearing to be boiling. Visible bubbling or boiling
when the container is removed from the microwave
oven is not always present. THIS COULD RESULT
IN VERY HOT LIQUIDS SUDDENLY BOILING
OVER WHEN THE CONTAINER IS DISTURBED
OR A SPOON OR OTHER UTENSIL IS INSERTED
INTO THE LIQUID.
Ŷ 7RUHGXFHWKHULVNRILQMXU\WRSHUVRQV
- Do not overheat the liquid.
- Stir the liquid both before and halfway through
heating it.
- Do not use straight-sided containers with narrow
necks.
- After heating, allow the container to stand in the
microwave oven for a short time before removing
the container.
- Use extreme care when inserting a spoon or other
utensil into the container.
This oven is not approved or tested for marine use.
CLEANING
Keep the oven free from grease buildup.
Do not clean with metal scouring pads. Pieces can burn
off the pad and touch electrical pars involving risk of
electric shock.
When cleaning surfaces of door and oven that comes
together on closing the door, use only mild, nonabrasive
soaps, or detergents applied with a clean sponge or soft
cloth. Rinse well.
READ AND SAVE THESE INSTRUCTIONS
4 49-40780-1
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
SAFETY INFORMATION
(a) Do Not Attempt to operate this oven with the
door open since open-door operation can result
in harmful exposure to microwave energy. It is
important not to defeat or tamper with the safety
interlocks.
(b) Do Not Place any object between the oven front
face and the door or allow soil or cleaner residue to
accumulate on sealing surfaces.
(c) Do Not Operate the oven if it is damaged.
(1) door (bent),
(2) hinges and latches (broken or loosened),
(3) door seals and sealing surfaces.
(d) The Oven Should Not be adjusted or repaired by
GROUNDING INSTRUCTIONS
WARNING
Ensure proper ground
exists before use.
This appliance is equipped with a power cord having a
grounding wire with a grounding plug. The plug must
be plugged into an outlet that is properly installed and
grounded.
Consult a qualified electrician or service technician if
the GROUNDING INSTRUCTIONS are not completely
understood, or if doubt exists as to whether the
appliance is properly grounded.
Improper use of the grounding plug can result in a risk of electric shock.
This appliance must be
grounded. In the event of
an electrical short circuit,
grounding reduces the
risk of electric shock by
providing an escape wire
for the electric current.
If the outlet is a standard 2-prong wall outlet, it is
your personal responsibility and obligation to have it
replaced with a properly grounded 3-prong wall outlet.
Do not under any circumstances cut or remove the
third (ground) prong from the power cord.
Do not use an extension cord. If the power cord is too
short, have a qualified electrician or service technician
install an outlet near the appliance.
For best operation, plug this appliance into its own
electrical outlet to prevent flickering of lights, blowing
of fuse or tripping of circuit breaker.
It is particularly important that the oven door close
properly and that there is no damage to the:
anyone except properly qualified service personnel.
NOTICE: PACEMAKERS
Most pacemakers are shielded from interference from electronic products, including microwaves. However,
patients with pacemakers may wish to consult their physicians if they have concerns.
READ AND SAVE THESE INSTRUCTIONS
49-40780-1 5
Features
Throughout this manual, features and appearance may vary from your model.
1100 Watts
USING YOUR OVEN
1 Door Latches
2 Window with Metal Shield. Screen allows cooking
to be viewed while keeping microwaves confined
in the oven.
3 Convenience Guide
4 Touch Control Panel Display
5 Door Latch Release. Press latch release to open
door.
Optional Accessories
Installation Kit (to convert your unit to a built-in wall oven):
you must purchase separately. Available only for PEB7227
models, and not available for PES7227 models.
Model Kit
PES7227SDLWW not available
PES7227SDLBB not available
PES7227SDLES not available
PES7227SDLSS not available
PES7227SBLTS not available
PES7227FMDS not available
6 Removable Turntable. Turntable and support must
be in place when using the oven. The turntable may
be removed for cleaning.
7 Removable Turntable Support. The turntable
support must be in place when using the oven. The
turntable support may be removed for cleaning.
8 Rating Label. Rating plate is located on the front
of the microwave oven.
For 27” installations:
Model Kit Color
PEB7227DLWW JX7227DLWW White
PEB7227DLBB JX7227DLBB Black
PEB7227BLTS JX7227BLTS
PEB7227SLSS
For 30” installations:
Model Kit Color
PEB7227DLWW JX7230DLWW White
PEB7227DLBB JX7230DLBB Black
PEB7227BLTS JX7230BLTS
PEB7227SLSS
JX7227FMDS
JX7227SLSS
JX7227ELES
JX7230FMDS
JX7230SLSS
JX7230ELES
Black Stainless Steel
Black Slate
Stainless Steel
Slate
Black Stainless Steel
Black Slate
Stainless Steel
Slate
6 49-40780-1
Controls
You can microwave by time or with the convenience features.
SENSOR AUTO COOK TIME MUTE
WEIGHT DEFROST TIMER
MELT/SOFTEN LOCK
Sensor Cooking
Healthy
Menu
Reheat Potato Popcorn
Melt/
Soften
Defrost
Weight/Time
USING YOUR OVEN
Beverage
Vegetable
Express Cook
30 Sec
Timer
On/Off
Cook
Time
Power
Level
Cancel
Off
Lock Controls
Hold 3 Sec
Clock
Start
Pause
Set
Clock
Display
Sound
Control buttons’ functions are explained on the following pages.
Add
49-40780-1 7
About the features
Power Level
The power level may be entered or changed immediately after entering the feature time for Cook Time or Express
Cook the power level may also be changed during the cooking.
1. Press Cook Time and enter cooking time.
2. Press the Power Level button and select power level
1-10.
3. Press the Start/Pause button to start cooking.
Variable power levels add flexibility to microwave
USING YOUR OVEN
cooking. The power levels on the microwave oven can
be compared to the surface units on a range. Each
power level gives you microwave energy a certain
percent of the time. Power level 7 is microwave energy
70% of the time. Power level 3 is energy 30% of the
time. Most cooking will be done on Power Level 10
which gives you 100% power.
Power Level 10 will cook faster but food may need more
frequent stirring, rotating or turning over. A lower setting
will cook more evenly and need less stirring or rotating of
the food.
Some foods may have better flavor, texture or
appearance if one of the lower settings is used. Use
a lower power level when cooking foods that have a
tendency to boil over, such as scalloped potatoes.
Rest periods (when the microwave energy cycles off)
give time for the food to “equalize” or transfer heat to
the inside of the food. An example of this is shown with
power level 3—the defrost cycle. If microwave energy did
not cycle off, the outside of the food would cook before
the inside was defrosted.
Here are some examples of uses for various power
levels::
Power Level 10: Fish, bacon, vegetables, heating
liquids.
Med-High 7: Gentle cooking of meat and poultry;
baking casseroles and reheating.
Medium 5: Slow cooking and tenderizing for stews and
less tender cuts of meat.
Low 2 or 3: Defrosting; simmering; delicate sauces.
Warm 1: Keeping food warm; softening butter.
8 49-40780-1
About the features
Cook Time
Allows you to microwave for any time up to 99 minutes
and 99 seconds.
1. Press Cook Time.
2. Enter cooking time.
3. The power level is automatically set to 10, but if you
want to reduce it, press Power Level, then select a level
from 1 to 9.
4. Press Start/Pause.
You may open the door during Cook Time to check the
food. Close the door and press Start/Pause to resume
cooking.
USING YOUR OVEN
Multi-Stage Cooking
At most 2 stages can be set for cooking. In multi-stage
cooking, if one stage is defrosting, then defrosting shall be
placed at the first stage automatically.
Note: Auto cooking cannot work in the multi-stage cooking.
Example: if you want to cook with 80% microwave power
for 5 minutes + 60% microwave power for 10 minutes. The
cooking steps are as following:
1. Press Time Cook once, then press “5”,”0”,”0” to set the
cooking time;
2. Press Power once,then press “8” to select 80%
microwave power.
3. Press Time Cook once,then press “1”,”0”,”0”,”0” to set
the cooking time;
4. Press Power once,then press “6” to select 60%
microwave power.
5. Press Start/Pause.
49-40780-1 9
About the features
Cooking Guide for Cook Time
NOTE: Use power level 10 (High) unless otherwise noted.
Vegetable Amount Time Comments
Asparagus
(fresh spears) 1 lb. 5 to 8 min., In 1¼-qt. oblong glass baking dish, place 1/4 cup water.
Med-High (7) Rotate dish after half of time.
(frozen spears) 10-oz. package 4 to 7 min. In 1-qt. casserole.
Beans
(fresh green) 1 lb. cut in half 10 to 14 min. In 1¼-qt. casserole, place 1/2 cup water.
(frozen green) 10-oz. package 4 to 8 min.
(frozen lima) 10-oz. package 4 to 8 min. In 1-qt. casserole, place 1/4 cup water.
Beets
USING YOUR OVEN
(fresh, whole) 1 bunch 16 to 21 min. In 2-qt. casserole, place 1/2 cup water.
Broccoli
(fresh cut) 1 bunch (1¼ to 1¼ lbs.) 5 to 9 min. In 2-qt. casserole, place 1/2 cup water.
(fresh spears) 1 bunch (1¼ to 1¼ lbs.) 7 to 10 min. In 2-qt. oblong glass baking dish, place 1/4 cup water.
Rotate dish after half of time.
(frozen, chopped) 10-oz. package 4 to 7 min. In 1-qt. casserole.
(frozen spears) 10-oz. package 4 to 7 min.
Cabbage
(fresh) 1 medium head (about 2 lbs.) 6 to 9 min. In 1¼- or 2-qt. casserole, place 1/4 cup water.
(wedges) 5 to 9 min. In 2- or 3-qt. casserole, place 1/4 cup water.
Carrots
(fresh, sliced) 1 lb. 4 to 8 min. In 1¼-qt. casserole, place 1/4 cup water.
(frozen) 10-oz. package 3 to 7 min.
Cauliflower
(flowerets) 1 medium head 7 to 10 min. In 2-qt. casserole, place 1/2 cup water.
(fresh, whole) 1 medium head 7 to 14 min. In 2-qt. casserole, place 1/2 cup water.
(frozen) 10-oz. package 3 to 7 min.
Corn
(frozen kernel) 10-oz. package 2 to 6 min.
Corn on the cob
(fresh) 1 to 5 ears 2-1/4 to 4 min. In 2-qt. oblong glass baking dish, place corn. If corn
per ear is in husk, use no water; if corn has been husked,
add 1/4 cup water. Rearrange after half of time.
(frozen) 1 ear 3 to 6 min. Place in 2-qt. oblong glass baking dish.
2 to 6 ears 2 to 3 min. Cover with vented plastic wrap. Rearrange after
per ear half of time.
Mixed vegetables
(frozen) 10-oz. package 2 to 6 min.
Peas
(fresh, shelled) 2 lbs. unshelled 7 to 9 min. In 1-qt. casserole, place 1/4 cup water.
(frozen) 10-oz. package 2 to 6 min.
Potatoes
(fresh, cubed,
white) (8 oz. each) casserole with 1/2 cup water. Stir after half of time.
(fresh, whole, 1 (8 oz.) 2 to 4 min. Pierce with cooking fork. Place in the oven, 1 inch
sweet or white) 2 (8 oz. each) 6 to 7 min. apart, in circular arrangement. Let stand 5 minutes.
3 8 to 9 min.
4 11 to 12 min.
Spinach
(fresh) 10 to 16 oz. 3 to 6 min. In 2-qt. casserole, place washed spinach.
(frozen, chopped 10-oz. package 3 to 6 min.
and leaf)
Squash
(fresh, summer 1 lb. sliced 3 to 5 min. In 1¼-qt. casserole, place 1/4 cup water.
and yellow)
(winter, acorn 1 to 2 squash 5 to 9 min. Cut in half and remove fibrous membranes. In 2-qt.
or butternut) (about 1 lb. each) oblong glass baking dish, place squash cut-side-down.
Turn cut-side-up after 4 minutes.
4 potatoes 9 to 11 min. Peel and cut into 1 inch cubes. Place in 2-qt.
In 1-qt. casserole, place 2 tablespoons water.
In 1-qt. casserole, place 3 tablespoons water.
In 1-qt. casserole, place 2 tablespoons water.
In 1-qt. casserole, place 2 tablespoons water.
In 1-qt. casserole, place 2 tablespoons water.
In 1-qt. casserole, place 3 tablespoons water.
In 1-qt. casserole, place 2 tablespoons water.
In 1-qt. casserole, place 3 tablespoons water.
10 49-40780-1
About the features
USING YOUR OVEN
Time Defrost
Time Defrost allows you to defrost for a selected length
of time. See the Defrosting Guide for suggested times.
1. Press Defrost twice (display must show Time
Defrost).
2. Enter defrosting time.
3. Press Start/Pause.
When the oven signals, turn food over and break apart
or rearrange pieces for more even defrosting. Shield
any warm areas with small pieces of foil. The oven will
continue to defrost if you don’t open the door and turn
the food.
Power level is automatically set at 3, but can be
changed. You can defrost small items quickly by raising
the power level after entering the time. Power level 7
cuts the total defrosting time in about half; power level
10 cuts the total time to approximately 1/3. However,
food will need more frequent attention than usual.
A dull thumping noise may be heard during defrosting.
This is normal when oven is not operating at High
power.
Defrosting Tips
• Foods frozen in paper or plastic can be defrosted in
the package. Closed packages should be slit, pierced
or vented AFTER food has partially defrosted. Plastic
storage containers should be partially uncovered.
• Family-size, prepackaged frozen dinners can be
defrosted and microwaved. If the food is in a foil
container, transfer it to a microwave-safe dish.
• For more even defrosting of larger foods, such as
roasts, use Defrost Weight. Be sure large meats are
completely defrosted before cooking.
• Foods that spoil easily should not be allowed to sit
out for more than one hour after defrosting. Room
temperature promotes the growth of harmful bacteria.
• When defrosted, food should be cool but softened in all
areas. If still slightly icy, return to the microwave very
briefly, or let it stand for a few minutes.
Weight Defrost
Weight defrost automatically sets the defrosting times
and power levels to give even defrosting results for
meats, poultry and fish weighing up to six pounds.
1. Press Defrost (display must show Weight Defrost).
2. Using the conversion guide, enter food weight. For
example, press pads 1 and 2 for 1.2 pounds (1 pound,
3 ounces).
3. Press Start/Pause.
There is a cooking guide located on the inside front of
the oven.
• Remove meat from package and place on microwavesafe dish.
• When the oven signals, turn the food over. Remove
defrosted meat or shield warm areas with small pieces
of foil.
• After defrosting, most meats need to stand 5 minutes
to complete defrosting. Large roasts should stand for
about 30 minutes.
Conversion Guide
If the weight of food is stated in pounds and
ounces, the ounces must be converted to
tenths (.1) of a pound.
Ounces Pounds
1–2 .1
3 .2
4–5 .3
6–7 .4
8 .5
9–10 .6
11 .7
12–13 .8
14–15 .9
Cooking Guide
49-40780-1 11
About the features
Defrosting Guide
Food Time Comments
Breads, Cakes
Bread, buns or rolls (1 piece) 1/4 min.
Sweet rolls (approx. 12 oz.) 2 to 4 min. Rearrange after half of time.
Fish and Seafood
Fillets, frozen (1 lb.) 6 to 9 min.
Shellfish, small pieces (1 lb.) 3 to 7 min. Place block in casserole.
Turn over and break up after first half of time.
Fruit
Plastic pouch—1 or 2 1 to 5 min.
(10-oz. package)
USING YOUR OVEN
Meat
Bacon (1 lb.) 2 to 5 min.
Franks (1 lb.) 2 to 5 min. Place unopened package in oven. Microwave just until franks can be
separated. Let stand 5 minutes, if necessary, to complete defrosting.
Ground meat (1 lb.) 4 to 6 min. Turn meat over after first half of time.
Roast: beef, lamb, veal, pork 9 to 12 min. per lb. Use power level Warm (1).
Steaks, chops and cutlets 4 to 8 min. per lb. Place unwrapped meat in cooking dish. Turn over after first half
of time and shield warm areas with foil. After second half of time,
separate pieces with table knife. Let stand to complete defrosting.
Poultry
Chicken, broiler-fryer, cut up 14 to 19 min. Place wrapped chicken in dish. Unwrap and turn over after first
(21¼2 to 3 lbs.) half of time. After second half of time, separate pieces and place in
cooking dish. Microwave 2 to 4 minutes more, if necessary. Let stand
a few minutes to finish defrosting.
Chicken, whole (2
and turn chicken over. Shield warm areas with foil. To complete
defrosting, run cool water in cavity until giblets can be removed.
Cornish hen 7 to 12 min. per lb. Place unwrapped hen in oven breast-side-up. Turn over after first half
of time. Run cool water in cavity until giblets can be removed.
Turkey breast (4 to 6 lbs.) 3 to 8 min. per lb. Place unwrapped breast in microwave-safe dish breast-side-down.
After first half of time, turn breast-side-up and shield warm areas
with foil. Defrost for second half of time. Let stand 1 to 2 hours in
refrigerator to complete defrosting.
1
¼2 to 3 lbs.) 20 to 24 min. Place wrapped chicken in dish. After first half of time, unwrap
Place unopened package in oven. Let stand 5 minutes after defrosting.
12 49-40780-1
About the features
Express Cook
This is a quick way to set cooking time from 1-6 minutes.
Press one of the Express Cook pads (from 1-6) for 1-6 minutes of cooking at power level 10. For example, press
the 2 pad for 2 minutes of cooking time.
The power level can be changed as time is counting down. Press Power Level and enter 1-10.
NOTE: Express Cook function pertains to pads 1-6 only.
Add 30 Sec
It will add 30 seconds to the time counting down each time the pad is pressed. Each touch will add 30 seconds, up to
99 minutes and 99 seconds.
The oven will start immediately when pressed.
USING YOUR OVEN
49-40780-1 13
About the features
Humidity Sensor
The Sensor Features detect the increasing humidity
released during cooking. The oven automatically adjusts
the cooking time to various types and amounts of food.
Do not use the Sensor Features twice in succession
on the same food portion—it may result in severely
overcooked or burnt food. Be sure to let the oven cool
down for 5-10 minutes before starting the next sensor
cook.
If food is undercooked after the countdown, use Cook
Time for additional cooking time.
USING YOUR OVEN
Beverage (Sensor Feature)
Press Beverage to select 1 or 2 cups (8 to 10 oz each).
Drinks heated with the Beverage feature may be very
hot. Remove the container with care.
If beverage is not hot enough for you, do not use the
Beverage button again to continue heating it. Use the
Cook Time button for further heating.
Ŷ7KHSURSHUFRQWDLQHUVDQG
covers are essential for best
sensor cooking.
Ŷ$OZD\VXVHPLFURZDYH
safe containers and cover
them with lids or vented
plastic wrap. Never use tight
sealing plastic containers
- they can prevent steam
from escaping and cause
food to overcook.
Ŷ%HVXUHWKHRXWVLGHRIWKH
cooking containers and the
inside of the microwave
oven are dry before placing
food in the oven. Beads of
moisture turning into steam
can mislead the sensor.
Covered
Vented
Dry off dishes so they don’t
mislead the sensor.
Vegetable (Sensor Feature)
Use the Vegetable feature to cook 4–16 ounces of
fresh or frozen vegetables.
1. For fresh vegetables, add 2 tablespoons of water
per serving. For frozen vegetables, follow package
instructions for adding water. Cover with lid or plastic
wrap. Place vegetables in the oven.
2. Press Vegetable once for fresh vegetables or twice for
frozen vegetables.
If you open the door, ERR will appear. It will scroll until
Cancel/Off is pressed.
14 49-40780-1
If the vegetables are not cooked to your satisfaction, do not
use the Vegetable button again. Use Cook Time.
About the features
Reheat (Sensor Feature)
The Reheat feature reheats 8-24 ounces of
previously cooked foods or a plate of leftovers.
1. Place covered food in the oven. Press Reheat. The
display will show REH. Press Start.
2. When the Reheat cycle is almost complete, the control
will beep and display the remaining seconds until the
Reheat cycle is complete.
If you open the door during the Reheat cycle, the oven
will turn off and the display will show ERR. You must
press Cancel/Off to clear the display and then you can
use the oven again.
After removing food from the oven, stir, if possible, to
even out the temperature. If the food is not hot enough,
don’t use the Reheat button again. Use Cook Time to
reheat. Reheated foods may have wide variations in
temperature. Some areas may be extremely hot.
Potato (Sensor Feature)
The Potato feature cooks one or two 8 oz potatoes.
1. Pierce skin with fork and place potatoes on the
turntable. If cooking three or more potatoes, arrange in
a star pattern.
2. Press Potato button. The display will show POT. Press
the Potato button to select 1 or 2 potatoes. Then press
Start.
USING YOUR OVEN
It is best to use Cook Time for these foods:
• Bread products.
• Foods that must be reheated uncovered.
• Foods that need to be stirred or rotated.
• Foods calling for a dry look or crisp surface after
reheating.
If you open the door during the Potato cycle, the oven will
turn off and the display will show ERR. You must press
Cancel/Off to clear the display and then you can use the
oven again.
If the potatoes are not cooked to your satisfaction, do not
use the Potato button again. Use Cook Time.
Popcorn (Sensor Feature)
1. If you want to cook a package that is less than 1.75
oz, or more than 3.5 oz, then use Cook Time and
follow the instructions on the package.
2. Press Popcorn to select ounces and then press Start/
Pause.
If the popcorn is not to your satisfaction. Use the Cook
Time button for further cooking.
49-40780-1 15
About the features
Healthy Menu
Use Healthy Menu feature to cook healthy food choices
by servings or with sensor.
1. Place food in the oven and press Healthy Menu pad.
2. Enter the food code. See Cooking Guide for Healthy
Menu for codes.
3. Enter the number of servings (1-4) for codes 1-3.
For Code 4-10, the oven can start with no serving
selection needed.
4. Press Start/Pause pad.
USING YOUR OVEN
If you open the door while the food code of Healthy
Menu feature is displayed, “ERR” will appear. It will
scroll until Cancel/Off is pressed.
Cooking Guide for Healthy Menu Feature
Note: Use power level 10 unless otherwise noted.
Enter
Code
1 Rice 1-4 Servings
2 Oatmeal 1-4 Servings
3 Pasta 1-4 Servings
4 Asparagus Sensor Menu
5 Broccoli Sensor Menu
6 Green
7 Carrots Sensor Menu
8 Green
9 Spinach Sensor Menu
10 Potato Sensor Menu
Food
Choice
Beans
Peas
Weight Setting
(Power Level 7 for 1
Serving)
Sensor Menu
Sensor Menu
Melt/Soften
Use Melt/Soften feature to melt/soften food choices by
serving.
1. Place food in the oven and press Melt/Soften pad.
2. Enter the food code. See Cooking Guide for Melt/
Soften for codes.
3. Enter the number of servings.
4. Press Start/Pause pad.
Cooking Guide for Melt/Soften Feature
Note: Use power level 10 unless otherwise noted.
Enter
Code
Melt or
Soften
1 Melt Butter
2 Melt Chocolate 4-8 Oz
3 Melt Cheese 8-16 Oz
4 Melt Marshmallows 5-10 Oz
5 Soften Butter 1-3 Sticks
6 Soften Ice Cream
7 Soften Cream Cheese 1-2 Oz
Food Choice Weight
Setting
1-3 Sticks
Margarine
1-3 Oz
Frozen Juice
16 49-40780-1
Other Features
Cooking Complete Reminder
To remind you that you have food in the oven, the
oven will display “END” and beep once a minute until
you either open the oven door or press the Cancel/Off
button.
USING YOUR OVEN
Lock Controls
You may lock the control panel to prevent the microwave
from being accidentally started or used by children.
Clock Display
To turn the clock display on or off, press Clock Display.
The Display On/Off feature cannot be used while a cooking
feature is in use.
Set Clock
Press to enter the time of day or to check the time of day
while microwaving.
1. Press Set Clock.
2. Enter time of day.
3. Press Start or Set Clock.
Start/Pause
In addition to starting many functions, Start/Pause allows
you to stop cooking without opening the door or clearing the
display. Press Start/Pause again to restart the oven.
To lock or unlock the controls, press and hold Cancel/Off
for about three seconds. When the control panel is locked,
“LOC” will appear in the display.
Timer On/Off
Timer On/Off operates as a minute timer and can be used
at any time, even when the oven is operating.
1. Press Timer On/Off.
2. Enter the amount of time you want to count down.
3. Press Timer On/Off to start.
When the time is up, the oven will signal. To turn off the
timer signal, press Timer On/Off.
The display shows the Timer countdown time even when
the oven is operating.
Sound
You can turn off all beeping sounds by pressing the Sound
button so that MUTE shows on the display. Pressing the
Sound button again will remove MUTE from the display and
turns all beeping sounds back on.
49-40780-1 17
Microwave Terms
Term Definition
Arcing Arcing is the microwave term for sparks in the oven. Arcing is caused by:
Ŷmetal or foil touching the side of the oven.
Ŷfoil that is not molded to food (upturned edges act like antennas).
Ŷmetal such as twist-ties, poultry pins, gold-rimmed dishes.
Ŷrecycled paper towels containing small metal pieces.
Ŷplates or dishes with a metallic trim or glaze with a metallic sheen.
Covering Covers hold in moisture, allow for more even heating and reduce cooking time. Venting plastic wrap or
USING YOUR OVEN
Shielding In a regular oven, you shield chicken breasts or baked foods to prevent over-browning. When
Standing Time When you cook with regular ovens, foods such as roasts or cakes are allowed to stand to finish
Venting After covering a dish with plastic wrap, you vent the plastic wrap by turning back one corner so excess
covering with wax paper allows excess steam to escape.
microwaving, you use small strips of foil to shield thin parts, such as the tips of wings and legs on
poultry, which would cook before larger parts.
cooking or to set. Standing time is especially important in microwave cooking. Note that a microwaved
cake is not placed on a cooling rack.
steam can escape.
18 49-40780-1
Care and Cleaning
Helpful Hints
An occasional thorough wiping with a solution of baking soda
and water keeps the inside fresh.
Be certain the oven control is turned off before cleaning any
part of this oven.
How to Clean the Inside
CARE AND CLEANING
Walls, Floor, Inside Window, Metal and Plastic Parts
on the Door
Some spatters can be removed with a paper towel;
others may require a damp cloth. Remove greasy
spatters with a sudsy cloth, then rinse with a damp cloth.
Do not use abrasive cleaners or sharp utensils on oven
walls.
To clean the surface of the door and the surface of the
oven that come together upon closing, use only mild,
nonabrasive soaps or detergents using a sponge or soft
cloth. Rinse with a damp cloth and dry.
Never use a commercial
oven cleaner on any part of
your microwave.
How to Clean the Outside
Do not use cleaners containing ammonia or alcohol on
the microwave oven. Ammonia or alcohol can damage
the appearance of the microwave.
Case
Clean the outside of the microwave with a sudsy cloth.
Rinse with a damp cloth and then dry. Wipe the window
clean with a damp cloth.
Control Panel and Door
Wipe with a damp cloth. Dry thoroughly. Do not use
cleaning sprays, large amounts of soap and water,
abrasives or sharp objects on the panel—they can
damage it. Some paper towels can also scratch the
control panel.
Removable Turntable and Turntable Support
To prevent breakage, do not
place the turntable into water
just after cooking. Wash it
carefully in warm, sudsy water
or in the dishwasher. The
turntable and support can be
broken if dropped. Remember, do not operate the oven
in the microwave mode without the turntable and support
seated and in place.
Power Cord
If the cord becomes soiled, unplug and wash with a
damp cloth. For stubborn spots, sudsy water may be
used, but be certain to rinse with a damp cloth and dry
thoroughly before plugging cord into outlet.
Stainless Steel (on some models)
Do not use a steel-wood pad; it will scratch the surface.
To clean the stainless steel surface, use a hot, damp
cloth with a mild detergent suitable
for stainless steel surfaces. Use a clean, hot, damp cloth
to remove soap. Dry with a dry, clean cloth. Always
scrub lightly in the direction of the grain.
Door Surface
It is important to keep the area clean where the door
seals against the microwave. Use only mild, nonabrasive detergents applied with a clean sponge or soft
cloth. Rinse well.
49-40780-1 19
Troubleshooting Tips
PROBLEM POSSIBLE CAUSE
OVEN WILL NOT COME ON A fuse in your home may be blown or the circuit breaker tripped. Replace fuse or
reset circuit breaker.
Unplug your microwave oven, then plug it back in.
Make sure 3-prong plug on oven is fully inserted into wall receptacle.
CONTROL PANEL
LIGHTED, YET OVEN WILL
NOT START
TROUBLESHOOTING TIPS
“ERR” APPEARS ON
DISPLAY
“LOC” APPEARS ON
DISPLAY
FOOD AMOUNT TOO
LARGE FOR SENSOR
REHEAT
“FOOD” APPEARS ON
DISPLAY
“PF” APPEARS ON
DISPLAY
“F3” APPEARS ON
DISPLAY
Door not securely closed.
Start/Pause
Another selection entered already in oven and Cancel/Off not pressed to cancel
it.
Make sure you have entered cooking time after pressing Cook Time.
Cancel/Off was pressed accidentally. Reset cooking program and press Start/
Pause.
Make sure you entered food weight after pressing Defrost Weight.
Oven was paused accidentally. Press Start/Pause to restart the cooking program.
During a Sensor Cooking program, the door was opened before steam could be
detected. “ERR” will display until Cancel/Off is pressed.
Steam was not detected in maximum time. Use
The control panel has been locked. (When the control panel is locked, “LOC”
will be displayed.) Press and hold Cancel/Off for about 3 seconds to unlock the
control panel.
Sensor Reheat is for single servings of recommended foods. Use Cook Time for
large amounts of food.
The control detected that the door has not been opened (food/beverage has not
been placed inside).
A Power Failure has occurred. Press Cancel/Off to clear the display.
A key has been activated for more than 60 seconds. Press Cancel/Off to clear
the display. This can happen if liquid is on the control panel. Dry the control panel
thoroughly after cleaning.
must be pressed after entering cooking selection.
Cook Time
to heat for more time.
Things That Are Normal With Your Microwave Oven
Ŷ Steam or vapor escaping from around
the door.
Ŷ Light reflection around door or outer case.
Ŷ Dimming oven light and change in the blower sound at
power levels other than high.
Ŷ Dull thumping sound while oven is operating.
Ŷ TV/radio interference might be noticed while using the
microwave. Similar to the interference caused by other
small appliances, it does not indicate a problem with the
microwave. Plug the microwave into a different electrical
circuit, move the radio or TV as far away from the
microwave as possible, or check the position and signal
of the TV/radio antenna.
20 49-40780-1
GE Appliances Microwave Oven Warranty
Staple your receipt here.
Proof of the original purchase
date is needed to make a
warranty claim.
For the period of GE Appliances Will Choose to Repair or Replace:
One year
From the date of the
original purchase
In Order to Make a Warranty Claim:
Call GE Appliances at 800 GE CARES (800 432-2737). Have the model number and serial number available.
What GE Appliances Will Not Cover:
Any product which fails due to a defect in materials or workmanship. The exchange unit
is warranted for the remainder of your product’s original one-year warranty period.
WARRANTY
• Customer instructions. This owner’s manual
provides information regarding operating
instructions and user controls. The Owner’s Manual
is available online at GEAPPLIANCES.com
• Improper installation, delivery or maintenance.
• Failure of the product or damage to the product if it
is abused, misused (for example, cavity arcing from
wire rack or metal/foil), or used for other than the
intended purpose or used commercially.
• Replacement of house fuses or resetting of circuit
breakers.
• Damage to the product caused by accident, fire,
floods or acts of God.
• Incidental or consequential damage caused by
possible defects with this appliance.
• Damage caused after delivery.
EXCLUSION OF IMPLIED WARRANTIES
Your sole and exclusive remedy is product repair as provided in this Limited Warranty. Any implied warranties,
including the implied warranties of merchantability or fitness for a particular purpose, are limited to one year or
the shortest period allowed by law.
This limited warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within the
USA.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This limited warranty gives you specific
legal rights, and you may also have other rights which vary from state to state. To know what your legal rights are, consult your local or
state consumer affairs office or your state’s Attorney General.
Exclusion of implied warranties: Except where prohibited or restricted by law, there are no warranties, whether express, oral or statutory
which extend beyond the description on the face hereof, including specifically the implied warranties of merchantability or fitness for a
particular purpose.
Staple your receipt here. Proof of the original purchase
date is needed to obtain service under the warranty.
Warrantor: GE Appliances, a Haier company
49-40780-1 21
Consumer Support
GE Appliances Website
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any day of the year!
You can also shop for more great GE Appliances products and take advantage of all our on-line support services designed for
your convenience. In the US: GEAppliances.com
Register Your Appliance
Register your new appliance on-line at your convenience! Timely product registration will allow for enhanced communication and
prompt service under the terms of your warranty, should the need arise. You may also mail in the pre-printed registration card
included in the packing material. In the US: GEAppliances.com/register
Schedule Service
Expert GE Appliances repair service is only one step away from your door. Get on-line and schedule your service at your
convenience any day of the year. In the US: GEAppliances.com/ge/service-and-support/service.htm
CONSUMER SUPPORT
or call 800.432.2737 during normal business hours.
Parts and Accessories
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
(VISA, MasterCard and Discover cards are accepted). Order on-line today 24 hours every day.
In the US: GEApplianceparts.com or by phone at 877.959.8688 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing generally should
be referred to qualified service personnel. Caution must be exercised, since improper servicing may cause unsafe
operation.
Contact Us
If you are not satisfied with the service you receive from GE Appliances, contact us on our Website with all the details including
your phone number, or write to:
In the US: General Manager, Customer Relations | GE Appliances, Appliance Park | Louisville, KY 40225
GEAppliances.com/ge/service-and-support/contact.htm
22 49-40780-1
Printed in China
Loading...
