Glarefighter™ Asymmetric (GFPS & GFPT)
imagination at work
Product Features
GE floodlights bring the security and safety of high quality illumination to a variety of outdoor areas. With a great look,
performance and durability, these fixtures offer versatility while meeting your outdoor lighting requirements.
Applications
• Parking lots, building security, shipping yards, rail yards,
and many more floodlighting applications
• Engineered for situations requiring high performance
with low aiming angle and reduced glare optics
Housing
• Die-cast aluminum housing with polyester powder
paint finish
• Enclosed, gasketed and activatedcharcoal filtered
optical assembly
Ratings
• Listed Suitable for Wet Locations
/
Reflectors
• Hydroformed aluminum reflector with ALGLAS™ finish
Unique Features
• Designed for low aiming angles and low glare
applications
• Heavy duty steel trunnion with degree indicator
• Built-in “Sight-Track”, quick aiming sight
• Heat and shock resistant tempered glass lens
• Front access via hinged/removable door
• Corrosion-resistant external hardware
• Terminal board
• Mogul base socket – E39 standard
Ordering Number Logic
Glarefighter™ Asymmetric (GFPS & GFPT)
_ _ _ _ - _ _ - _ - _ - _ - _ - _ _ _ - _ _ - _
PROD. ID
GFPS =
Glarefighter
Standard
GFPT =
With Tray
Mounted
Ballast
NOTE:
200-400W
Mag-Reg not
available on
tray.
wATTAGE
15 = 150
17 = 175
20 = 200
24 = 250/
400
25 = 250
40 = 400
NOTE:
250/400
connected
for 250W
(HPS only)
LIGHT
SOURCE
E = Energy Act
Compliant Pulse
MH (EPMH)
S = HPS
M = MH
Standard: Lamp
not included.
VOLTAGE
60Hz
0 = 120/208/
240/277
Multivolt
1 = 120
2 = 208
3 = 240
4 = 277
5 = 480
D = 347
F = 120X347*
T = 220
50Hz
6 = 220
R = 230
Y = 240
*Connected for
120V
BALLAST
TYPE
See Ballast
Selection Table
A = Autoreg
G = Mag-Reg
with
Grounded
Socket
Shell
H = HPF
Reactor
or Lag
M = Mag-Reg
FUNCTION
1 = None
2 = PE
Receptacle
NOTE:
Receptacle
connected same
voltage as unit.
Order PE Control
separately.
PE
NEMA TYPE BEAM
HORIZ X VERT
Select NEMA Type
from Photometric
Selection Table
Example:
6X6 = 6X6
Ballast Selection Table
Ballast Type/Voltage
60Hz 50Hz
Light 240, 277 347,
wattage Source Multivolt 480 120X347 220 220 230 240
150 (55V) HPS H H, M* H N/A M N/A N/A
200 HPS A, M A, M N/A A A A ,H,N A
250 HPS A, M, G A, M, G A A A A ,H,N A
250/400 HPS A A N/A N/A N/A N/A N/A
400 HPS A, M A, M A A A,H,N H A,H,N
175 EPMH A A A** N/A N/A N/A N/A
250 EPMH A A A** N/A N/A N/A N/A
400 EPMH A A A** N/A N/A N/A N/A
CANADA & EXPORT ONLY
175 MH A A A** N/A N/A N/A N/A
250 MH A A A** N/A N/A N/A N/A
400 MH A A A** N/A N/A N/A N/A
NOTES: N/A = Not Available
*For 150W HPS, 480V use A or M ballast only.
**347, 120X347 = May use M (MH) Ballast/Lamp Code
120, 208,
SPREAD
DB = Dark Bronze
(Standard)
GR = Gray
OPTIONSCOLOR
F = Fusing (Not
available with
multivolt or
120X347V)
G = Top Trunnion
J = Line Surge Protector,
Expulsion Type
(UL not available)
K = Knuckle Slipfitter
for 1.9-in. to 2.38-in.
(48-60 mm) OD
Tenon
L = Latch for door
P = Prewired with 6 ft
(2 meters) #14/3
S = Knuckle Slipfitter for
1.9 to 3.0 in.
(48-76mm) OD
Tenon
V = Knuckle Wall Mount
Y = Dual Wattage Units
Connect Higher
Wattage
Photometric Selection Table
All light sources are clear unless other wise indicated.
Light Beam Spread Number
wattage Source Horizontal X Vertical (Degrees) 35-
150 (55V) HPS 7X6 (131X108) 179872
200 HPS 6X6 (127X112) 179873
250 HPS 6X6 (126X113) 179874
400 HPS 6X6 (125X108) 179876
175 EPMH 7X6 (140X112) 179877
250 EPMH 7X6 (132X113) 179878
400* EPMH 6X6 (130X144) 179879
NOTE: *Lamp for 400 watt MH must be E-18 or ED-28 (reduced envelope) only.
For cutoff at aiming angles 15° or less, order accessory TSV**-P4F separately.
NEMA Type
Photometric Curve
Product Dimensions
CAUTION:
Position illustrated is
not recommended for
Glarefighter applications.
This illustration should
only be used for
dimensional purposes.
• Approximate Net Weight: 45 lbs (20 kgs)
• Effective Projected Area: 1.5 sq ft max (.14 sq M max)
DATA
• Suggested Mounting Height: 20-60 ft (6-18 M)
