USB 2.0 Individual Card Reader/Writer
User’s Manual
HO97929
HO97930
HO97931
HO97948
www.jascoproducts.com
1. Introduction
Thank you for purchasing the GE USB 2.0 Individual Card Reader &
Writer! You can now easily read from or write to your memory card:
HO97929 SmartMedia & xD™
HO97930 Compact Flash & IBM MicroDrive
HO97931 Secure Digital & MultiMedia Card
HO97948 Memory Stick, Memory Stick Pro, Memory Stick Duo,
Memory Stick Magic Gate
2. Package Includes
¾ USB 2.0 Card Reader/Writer
¾ 6 ft USB Extension Cable
¾ CD with Driver and Manual
¾ Instruction Manual
3. Features
¾ Easier than connecting digital devices to your computer
¾ Conserves the battery life of your digital devices
¾ Portable and easily accessible on your desktop
¾ Drag and drop capability: as easy to use as a floppy drive
¾ Supports data transfer rates up to 480 Mbps
¾ USB 1.1 and 2.0 Compatible*
*
Connecting to a USB 1.1 port limits data transfer rates to a maximum of 12 Mbps
4. System Requirements
¾ One USB port (USB 1.1 or 2.0)
¾ Compatible with Windows® 98SE, 2000, ME, and XP
¾ Compatible with Mac® OS 9.X or 10.X
5. Installation
Windows® 98 SE
1. DO NOT connect the card reader to your computer until the driver is
installed.
2. Make sure all Microsoft® updates and patches for your operating
system are installed. These can be found at
www.microsoft.com.
3. Close all open applications before beginning.
4. Insert the “GE USB 2.0 Individual Card Reader Drivers” CD into
your CD drive.
5. Follow the onscreen instructions to complete the driver installation.
6. You will need to restart your computer after installation is complete.
7. After your computer has rebooted, plug the card reader into a USB
port on your computer or hub directly or via the extension cable.
8. Your computer will detect your card reader, and may load additional
drivers for it.
9. Insert your card into the card slot on your card reader. The card is
correctly inserted when the blue LED light remains on.
10. When you insert a card into the card reader it will show up as a new
removable storage drive on your computer. (This can be found with
“My Computer”.)
Note 1:
If the card is not able to be read or you incur an error, you may not have
allowed enough time for all of the additional drivers to load. Remove and
re-insert the card.
Note 2:
Do not force the card into any slot. The card must be inserted with the
correct orientation to avoid damage to your card and the card reader.
Windows® 2000, ME or XP & Mac® OS 9.X or 10.X
NO DRIVER IS REQUIRED.
1. Plug the card reader into a USB port on your computer or hub.
(Optionally you may choose to use the included USB extension
cable.)
2. Your computer will detect your card reader, and may load additional
drivers for it.
3. Insert your card into the card slot on your card reader. The card is
correctly inserted when the blue LED light remains on.
4. When you insert a card into the card reader it will show up as a new
removable storage drive on your computer. (This can be found with
“My Computer”.)
Note 1:
If the card is not able to be read or you incur an error, you may not have
allowed enough time for all of the additional drivers to load. Remove and
re-insert the card.
Note 2:
Do not force the card into any slot. The card must be inserted with the
correct orientation to avoid damage to your card and the card reader.
90 DAY LIMITED WARRANTY
Jasco Products Company warrants this product to be free from
manufacturing defects for a period of ninety days from the original date
of consumer purchase. This warranty is limited to the repair or
replacement of this product only and does not extend to consequential or
incidental damage to other products that may be used with this unit. This
warranty is in lieu of all other warranties express or implied. Some states
do not allow limitations on how long an implied warranty lasts or permit
the exclusion or limitation of incidental or consequential damages, so the
above limitations may not apply to you. This warranty gives you
specific rights, and you may also have other rights which vary from state
to state. If unit should prove defective within the warranty period,
return prepaid with dated proof of purchase to:
Jasco Products Company
10 East Memorial
Oklahoma City, OK 73114
