Garmin 650t User Manual

Oregon® 600 Series

Owner’s Manual

April 2013 190-01552-00_0A Printed in Taiwan

All rights reserved. Under the copyright laws, this manual may not be copied, in whole or in part, without the written consent of Garmin. Garmin reserves the
right to change or improve its products and to make changes in the content of this manual without obligation to notify any person or organization of such
changes or improvements. Go to www.garmin.com for current updates and supplemental information concerning the use of this product.

Garmin®, the Garmin logo, Auto Lap®, BlueChart®, City Navigator®, Oregon®, and TracBack® are trademarks of Garmin Ltd. or its subsidiaries, registered in
the USA and other countries. ANT+™, BaseCamp™, chirp™, Garmin Connect™, HomePort™, and tempe™ are trademarks of Garmin Ltd. or its subsidiaries.
These trademarks may not be used without the express permission of Garmin.

The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Garmin is under license. Mac® is a registered
trademark of Apple Computer, Inc. Windows® is a registered trademark of Microsoft Corporation in the United States and other countries. microSD™ and the
microSDHC logo are trademarks of SD-3C, LLC. Other trademarks and trade names are those of their respective owners.

Table of Contents

Introduction.................................................................... 1

Getting Started........................................................................... 1

Device Overview........................................................................ 1

Battery Information..................................................................... 1

Installing the NiMH Battery Pack........................................... 1

Installing AA Batteries........................................................... 1

Turning On the Device............................................................... 2

Acquiring Satellites Signals and Recording a Track............. 2

Using the Touchscreen......................................................... 2

Waypoints, Routes, and Tracks ...................................2

Waypoints.................................................................................. 2

Creating a Waypoint.............................................................. 2

Marking a Waypoint Using the Map...................................... 2

Finding a Waypoint............................................................... 2

Editing a Waypoint................................................................ 2

Deleting a Waypoint.............................................................. 2

Increasing the Accuracy of a Waypoint Location.................. 2

Projecting a Waypoint........................................................... 2

Where To? Menu....................................................................... 3

Optional Maps....................................................................... 3

Finding a Location by Name................................................. 3

Finding a Location Near Another Location............................ 3

Finding an Address............................................................... 3

Routes........................................................................................ 3

Creating a Route................................................................... 3

Editing the Name of a Route................................................. 3

Editing a Route...................................................................... 3

Viewing a Route on the Map................................................. 3

Deleting a Route................................................................... 3

Viewing the Active Route...................................................... 3

Reversing a Route................................................................ 3

Tracks........................................................................................ 3

Recording a Track Log.......................................................... 3

Customizing Your Track Log................................................. 3

Navigating Using TracBack®................................................ 3

Saving the Current Track...................................................... 4

Viewing Track Information..................................................... 4

Viewing the Elevation Plot of a Track.................................... 4

Saving a Location on a Track................................................ 4

Changing the Track Color..................................................... 4

Archiving Saved Tracks........................................................ 4

Clearing the Current Track.................................................... 4

Deleting a Track.................................................................... 4

Garmin Adventures.................................................................... 4

Sending Files to BaseCamp.................................................. 4

Creating an Adventure.......................................................... 4

Starting an Adventure........................................................... 4

Navigation.......................................................................4

Navigating to a Destination........................................................ 4

Stopping Navigation.............................................................. 4

Marking and Starting Navigation to a Man Overboard

Location..................................................................................... 4

Navigating with the Map............................................................. 4

Navigating a Driving Route................................................... 5

Navigating with the Compass.................................................... 5

Calibrating the Compass....................................................... 5

Course Pointer...................................................................... 5

Navigating with Sight 'N Go....................................................... 5

Elevation Plot............................................................................. 5

Navigating to a Point on the Plot........................................... 5

Changing the Plot Type......................................................... 5

Resetting the Elevation Plot.................................................. 5

Calibrating the Barometric Altimeter..................................... 5

Trip Computer

Resetting the Trip Computer................................................. 5

............................................................................ 5

Camera and Photos....................................................... 5

Taking a Photo........................................................................... 5

Viewing Photos.......................................................................... 6

Viewing a Slideshow............................................................. 6

Sorting Photos....................................................................... 6

Viewing the Location of a Photo............................................ 6

Setting a Photo as Wallpaper................................................ 6

Deleting a Photo.................................................................... 6

Navigating to a Photo............................................................ 6

Geocaches...................................................................... 6

Downloading Geocaches........................................................... 6

Filtering the Geocache List........................................................ 6

Creating and Saving a Geocache Filter................................ 6

Editing a Custom Geocache Filter........................................ 6

Navigating to a Geocache.......................................................... 6

Logging the Attempt................................................................... 6

chirp™........................................................................................ 6

Enabling chirp Searching...................................................... 6

Finding a Geocache with a chirp........................................... 7

Fitness............................................................................ 7

Running or Cycling with Your Device......................................... 7

History........................................................................................ 7

Viewing an Activity................................................................ 7

Deleting an Activity................................................................ 7

Using Garmin Connect.......................................................... 7

Optional Fitness Accessories..................................................... 7

Pairing Your ANT+ Sensors.................................................. 7

Tips for Pairing ANT+ Accessories with Your Garmin

Device................................................................................... 7

About Heart Rate Zones............................................................ 7

Fitness Goals........................................................................ 7

Setting Your Heart Rate Zones............................................. 8

Applications................................................................... 8

Using the 3D View..................................................................... 8

Sending and Receiving Data Wirelessly.................................... 8

Setting a Proximity Alarm........................................................... 8

Using the Flashlight................................................................... 8

Calculating the Size of an Area.................................................. 8

Using the Calculator................................................................... 8

Viewing the Calendar and Almanacs......................................... 8

Setting an Alarm........................................................................ 8

Starting the Countdown Timer................................................... 8

Opening the Stopwatch.............................................................. 9

Satellite Page............................................................................. 9

Changing the Satellite View.................................................. 9

Turning Off GPS.................................................................... 9

Simulating a Location............................................................ 9

Customizing the Device................................................ 9

Adjusting the Backlight Brightness............................................. 9

Main Menu................................................................................. 9

Customizing the Main Menu.................................................. 9

Locking the Touchscreen...................................................... 9

Rotating the Screen.............................................................. 9

Locking the Screen Orientation............................................. 9

Creating a Shortcut............................................................... 9

Adding a Shortcut to the Main Menu..................................... 9

Custom Data Fields and Dashboards........................................ 9

Enabling the Map Data Fields............................................... 9

Customizing the Data Fields............................................... 10

Customizing Dashboards.................................................... 10

Profiles..................................................................................... 10

Selecting a Profile............................................................... 10

Table of Contents i

Creating a Custom Profile................................................... 10

Editing a Profile Name........................................................ 10

Deleting a Profile................................................................. 10

Customizing the Keys.............................................................. 10

System Settings....................................................................... 10

About GPS and GLONASS................................................. 10

Serial Interface Settings...................................................... 10

Display Settings....................................................................... 10

Appearance Settings................................................................ 10

Turning On Scroll Controls....................................................... 10

Setting the Touchscreen Sensitivity......................................... 11

Setting the Device Tones......................................................... 11

Map Settings............................................................................ 11

Advanced Map Settings...................................................... 11

Tracks Settings........................................................................ 11

Routing Settings....................................................................... 11

Heading Settings...................................................................... 11

Altimeter Settings..................................................................... 11

Position Format Settings.......................................................... 11

Changing the Units of Measure............................................... 12

Time Settings........................................................................... 12

Camera Settings...................................................................... 12

Geocaching Settings................................................................ 12

ANT+ Sensor Settings............................................................. 12

Fitness Settings....................................................................... 12

Setting Your Fitness User Profile........................................ 12

Marking Laps by Distance................................................... 12

Marine Settings........................................................................ 12

Setting Up Marine Alarms................................................... 12

Resetting Data......................................................................... 12

Restoring Default Values for Specific Settings.................... 12

Restoring Default Values for Specific Page Settings.......... 12

Restoring All Default Settings............................................. 12

Device Information.......................................................13

Battery Information................................................................... 13

Maximizing the Battery Life................................................. 13

Turning On Battery Save Mode........................................... 13

Saving Energy While Charging the Device......................... 13

Long-Term Storage............................................................. 13

Device Care............................................................................. 13

Cleaning the Device............................................................ 13

Cleaning the Touchscreen.................................................. 13

Water Immersion................................................................. 13

Specifications........................................................................... 13

Data Management................................................................... 13

File Types............................................................................ 13

Installing a Memory Card.................................................... 13

Connecting the Device to Your Computer........................... 14

Transferring Files to Your Device........................................ 14

Deleting Files...................................................................... 14

Disconnecting the USB Cable............................................. 14

Troubleshooting....................................................................... 14

Viewing Device Information................................................. 14

Updating the Software......................................................... 14

Resetting the Device........................................................... 14

Registering Your Device..................................................... 14

Getting More Information.................................................... 14

Appendix.......................................................................14

Attaching the Carabiner Clip.................................................... 14

Removing the Carabiner Clip.............................................. 14

Optional Maps.......................................................................... 14

tempe....................................................................................... 14

Data Fields............................................................................... 15

Heart Rate Zone Calculations.................................................. 16

Index..............................................................................17

ii Table of Contents

Introduction

WARNING

See the Important Safety and Product Information guide in the
product box for product warnings and other important
information.

Getting Started

When using your device the first time, you should complete
these tasks to set up the device and get to know the basic
features.

Install the batteries (page 1).

1

Turn on the device (page 2).

2

Register the device (page 14).

3

Acquire satellites (page 2).

4

Select to view the status page (page 9).

5

Mark a waypoint (page 2).

6

Navigate to a destination (page 4).

7

Device Overview

Turn the D-ring counter-clockwise, and pull up to remove the

1

cover.
Locate the battery pack À that came in the product box.

2

Insert the battery pack, observing polarity.

3

Gently press the battery pack into place.

4

Replace the battery cover, and turn the D-ring clockwise.

5

Charging the Battery Pack

NOTICE

To prevent corrosion, thoroughly dry the mini-USB port, the
weather cap, and the surrounding area before charging or
connecting to a computer.

Do not attempt to use the device to charge a battery that was
not provided by Garmin®. Attempting to charge a battery that
was not provided by Garmin can damage the device and void
the warranty.

Camera lens (650 and 650t only)

À

Power key

Á

Battery cover D-ring

Â

User key (page 10)

Ã

microSD™ card slot (under battery door)

Ä

Mini-USB port (under weather cap)

Å

Battery Information

WARNING

The temperature rating for the device may exceed the usable
range of some batteries. Alkaline batteries can rupture at high
temperatures.

Do not use a sharp object to remove batteries.

CAUTION

Contact your local waste disposal department to properly
recycle the batteries.

NOTICE

Alkaline batteries lose a significant amount of their capacity as
the temperature decreases. Therefore, use lithium batteries
when operating the device in below freezing conditions.

Installing the NiMH Battery Pack

The device operates using the optional NiMH battery pack (650
and 650t only) or two AA batteries (page 1).

Before you can connect the straight connector of the USB cable
to your device, you may have to remove optional mount
accessories.

NOTE: The battery will not charge when outside the
temperature range of 32 to 122°F (0 to 50°C).

You can charge the battery using a standard wall outlet or a
USB port on your computer.

Pull up the weather cap À from the mini-USB port Á.

1

Plug the small end of the USB cable into the mini-USB port.

2

Plug the USB end of the cable into the AC adapter or a

3

computer USB port.
Plug the AC adapter into a standard wall outlet.

4

When you connect the device to a power source, the device
turns on.

Charge the battery completely.

5

Installing AA Batteries

Instead of the optional NiMH battery pack (page 1), you can use
two alkaline, NiMH, or lithium batteries. This is useful when you
are on the trail and cannot charge the NiMH battery pack. Use
NiMH or lithium batteries for best results.

NOTE: Standard alkaline batteries are not recommended for the
Oregon 650 models when using the camera feature.

Turn the D-ring counter-clockwise, and pull up to remove the

1

cover.

Introduction 1

Insert two AA batteries, observing polarity.

2

Replace the battery cover, and turn the D-ring clockwise.

3

Hold .

4

Select Setup > System > AA Battery Type.

5

Select Alkaline, Lithium, or Rechargeable NiMH.

6

Turning On the Device

Hold .

Acquiring Satellites Signals and Recording a Track

Before you can use the GPS navigation features, such as
recording a track, you must acquire satellite signals. The device
may need a clear view of the sky to acquire satellite signals.

For more information about GPS, go to www.garmin.com

/aboutGPS.

Hold .

1

Wait while the device locates satellites.

2

When turns green, your device has acquired satellite

signals. The time and date are set automatically based on

the GPS position.

Walk around to record a track (page 3).

3

Select an option:

4

• Select Map to view your track on the map.

• Select Compass to view the compass and customizable

data fields.

• Select Trip Computer to view your current speed,

distance, and other helpful statistics.

Using the Touchscreen

• Tap the screen to select an item.

• Drag or swipe your finger across the screen to pan or scroll

the screen.

• Pinch two fingers together to zoom out.

• Spread two fingers to zoom in.

• Make each touchscreen selection a separate action.

• Select to save your changes and close the page.

• Select to close the page and return to the previous page.

• Select to return to the previous page.

• Hold to return to the main menu.

• Select to view specific menu items for the page you are

viewing.

Waypoints, Routes, and Tracks

Waypoints

Waypoints are locations you record and store in the device.

Creating a Waypoint

You can save your current location as a waypoint.

Select the user key.

1

The default function of the user key marks a waypoint.
If necessary, select a field to make changes to the waypoint.

2

Select Save.

3

Marking a Waypoint Using the Map

Select Map.

1

Select a location on the map.

2

Select the information bar at the top of the screen.

3

Select > OK.

4

Finding a Waypoint

Select Waypoint Manager.

1

Select a waypoint from the list.

2

If necessary, select to narrow the search.

3

Select an option:

4

• Select Spell Search to search using the name of the

waypoint.

• Select Select Symbol to search using the symbol of the

waypoint.

• Select Search Near to search near a recently found

location, another waypoint, your current location, or a
point on the map.

• Select Sort to view the list of waypoints based on nearest

distance or alphabetical order.

Editing a Waypoint

Before you can edit a waypoint, you must create a waypoint.

Select Waypoint Manager.

1

Select a waypoint.

2

Select an item to edit, such as the name.

3

Enter the new information, and select .

4

Deleting a Waypoint

Select Waypoint Manager > > Delete.

1

Select a waypoint.

2

Select Delete > Yes.

3

Increasing the Accuracy of a Waypoint Location

You can refine a waypoint location for more accuracy. When
averaging, the device takes several readings at the same
location and uses the average value to provide more accuracy.

Select Waypoint Manager.

1

Select a waypoint.

2

Select > Average Location.

3

Move to the waypoint location.

4

Select Start.

5

Follow the on-screen instructions.

6

When the confidence status bar reaches 100%, select Save.

7

For best results, collect 4 to 8 samples for the waypoint, waiting
at least 90 minutes between samples.

Projecting a Waypoint

You can create a new location by projecting the distance and
bearing from a marked location to a new location.

Select Waypoint Manager.

1

Select a waypoint.

2

Select > Project Waypoint.

3

Enter the bearing, and select .

4

Select a unit of measure.

5

Enter the distance, and select .

6

Select Save.

7

2 Waypoints, Routes, and Tracks

Where To? Menu

You can use the Where To? menu to find a destination to
navigate to. Not all Where To? categories are available in all
areas and maps.

Optional Maps

You can use additional maps with the device, such as BirdsEye
satellite imagery, BlueChart® g2, and City Navigator® detailed
maps. Detailed maps may contain additional points of interest,
such as restaurants or marine services. For more information,
go to http://buy.garmin.com or contact your Garmin dealer.

Finding a Location by Name

Select Where To? > Waypoints > > Spell Search.

1

Enter the name or part of the name.

2

Select .

3

Finding a Location Near Another Location

Select Where To? > > Search Near.

1

Select an option.

2

Select a location.

3

Finding an Address

You can use optional City Navigator maps to search for
addresses.

Select Where To? > Addresses.

1

Select the country or state, if necessary.

2

Enter the city or postal code.

3

NOTE: Not all map data provides postal code searching.

Select the city.

4

Enter the house number.

5

Enter the street.

6

Routes

A route is a sequence of waypoints or locations that leads you
to your final destination.

Creating a Route

Select Route Planner > Create Route > Select First Point.

1

Select a category.

2

Select the first point in the route.

3

Select Use > Select Next Point.

4

Repeat steps 2–4 to add all the points in the route.

5

Select to save the route.

6

Editing the Name of a Route

Select Route Planner.

1

Select a route.

2

Select Change Name.

3

Enter the new name, and select .

4

Editing a Route

Select Route Planner.

1

Select a route.

2

Select Edit Route.

3

Select a point.

4

Select an option:

5

• To view the point on the map, select Review.

• To change the order of the points on the route, select

Move Up or Move Down.

• To insert an additional point on the route, select Insert.

The additional point is inserted before the point you are
editing.

• To remove the point from the route, select Remove.
Select to save the route.

6

Viewing a Route on the Map

Select Route Planner.

1

Select a route.

2

Select View Map.

3

Deleting a Route

Select Route Planner.

1

Select a route.

2

Select Delete Route.

3

Viewing the Active Route

While navigating a route, select Active Route.

1

Select a point in the route to view additional details.

2

Reversing a Route

Select Route Planner.

1

Select a route.

2

Select Reverse Route.

3

Tracks

A track is a recording of your path. The track log contains
information about points along the recorded path, including
time, location, and elevation for each point.

Recording a Track Log

Select Current Track > .
You can select to pause tracking. When paused, the track

log is not recorded.

Customizing Your Track Log

You can customize how your device displays and records
tracks.

Select Current Track > .

1

Select an option:

2

• To change the color of the track line on the map, select

Color.

• To display a line on the map indicating your track, select

Show On Map.

Select > Setup Tracks > Record Method.

3

Select an option:

4

• To record tracks at a variable rate that creates an

optimum representation of your tracks, select Auto.

• To record tracks at a specified distance, select Distance.

• To record tracks at a specified time, select Time.
Select Interval.

5

Complete an action:

6

• If you selected Auto for the Record Method, select an

option to record tracks more or less often.
NOTE: Using the Most Often interval provides the most

track detail, but fills up the device memory quicker.

• If you selected Distance or Time for the Record Method,

enter a value, and select .

Navigating Using TracBack

While navigating, you can navigate back to the beginning of
your track. This can be helpful when finding your way back to
camp or the trail head.

Select Track Manager > Current Track > > TracBack.

1

The map displays your route with a magenta line, start point,
and end point.

Navigate using the map or the compass.

2

®

Waypoints, Routes, and Tracks 3

Saving the Current Track

Select Track Manager > Current Track.

1

Select an option:

2

• Select to save the entire track.

• Select > Save Portion, and select a portion.

Viewing Track Information

Select Track Manager.

1

Select a track.

2

Select .

3

The beginning and the end of the track are marked by flags.

Select the information bar at the top of the screen.

4

Information about the track appears.

Viewing the Elevation Plot of a Track

Select Track Manager.

1

Select a track.

2

Select .

3

Saving a Location on a Track

Select Track Manager.

1

Select a track.

2

Select .

3

Select a location on the track.

4

Select the information bar at the top of the screen.

5

Information about the location appears.

Select > OK.

6

Changing the Track Color

You can change the color of a track to improve the view on the
map or compare it to another track.

Select Track Manager.

1

Select a track.

2

Select Color.

3

Select a color.

4

Archiving Saved Tracks

You can archive saved tracks to save memory space.

Select Setup > Tracks > Auto Archive.

1

Select When Full, Daily, or Weekly.

2

Clearing the Current Track

Select Current Track > > Clear.

Deleting a Track

Select Track Manager.

1

Select a track.

2

Select > Delete > Delete.

3

Garmin Adventures

You can create adventures to share your journeys with family,
friends, and the Garmin community. Group related items
together as an adventure. For example, you can create an
adventure for your latest hiking trip. The adventure could
contain the track log of the trip, photos of the trip, and
geocaches you hunted. You can use BaseCamp™ to create and
manage your adventures. For more information, go to

http://adventures.garmin.com.

Sending Files to BaseCamp

Open BaseCamp.

1

Connect the device to your computer (page 14).

2

Your device and memory card (optional) appear as
removable drives in My Computer on Windows® computers
and as mounted volumes on Mac® computers.

NOTE: Some computers with multiple network drives cannot
display device drives. See your operating system help file to
learn how to map the drive.

Open the Garmin or memory card drive or volume.

3

Select an option:

4

• Select an item from a connected device and drag it to My
Collection or to a list.

• From BaseCamp, select Device > Receive from Device,
and select the device.

Creating an Adventure

Before you can create an adventure and send it to your device,
you must download BaseCamp to your computer and transfer a
track from your device to your computer (page 4).

Open BaseCamp.

1

Select File > New > Garmin Adventure.

2

Select a track, and select Next.

3

If necessary, add items from BaseCamp.

4

Complete the required fields to name and describe the

5

adventure.
If you want to change the cover photo for the adventure,

6

select Change, and select a different photo.
Select Finish.

7

Starting an Adventure

Before you can start an adventure, you must send an adventure
from BaseCamp to your device.

Select Adventures.

1

Select an adventure.

2

Select Start.

3

Navigation

You can navigate routes and tracks, to a waypoint, geocache,
photo, or any saved location in the device. You can use the map
or the compass to navigate to your destination.

Navigating to a Destination

Select Where To?.

1

Select a category.

2

Select a destination.

3

Select Go.

4

The map opens with your route marked with a magenta line.
Navigate using the map (page 4) or compass (page 5).

5

Stopping Navigation

From the map or compass, select > Stop Navigation.

Marking and Starting Navigation to a Man Overboard Location

You can save a man overboard (MOB) location, and
automatically start navigation back to it. You can customize a
key to access the MOB function quickly (page 10).

Select Man Overboard > Start.

1

The map opens showing the route to the MOB location. The
default appearance of the route is a magenta line.

Navigate using the map (page 4) or compass (page 5).

2

Navigating with the Map

Begin navigating to a destination (page 4).

1

4 Navigation

Select Map.

2

A blue triangle represents your location on the map. As you
travel, the blue triangle moves and leaves a track log (trail).
You can change how the track log appears on the map
(page 3).

Complete one or more actions:

3

• Drag the map to view different areas.

• Select and to zoom in and out of the map.

• Select a location on the map (represented by a pin), and
select the information bar at the top of the screen to view
information about the selected location.

Navigating a Driving Route

Before you can navigate street routes, you must purchase and
load City Navigator maps.

Select Profile Change > Automotive.

1

Select a destination.

2

Navigate using the map.

3

Turns appear in the text bar along the top of the map.
Audible tones signal turns in the route.

Navigating with the Compass

When navigating to a destination, points to your destination,
regardless of the direction you are moving.

Begin navigating to a destination (page 4).

1

Select Compass.

2

Turn until points toward the top of the compass, and

3

continue moving in that direction to the destination.

Calibrating the Compass

NOTICE

Calibrate the electronic compass outdoors. To improve heading
accuracy, do not stand near objects that influence magnetic
fields, such as vehicles, buildings, and overhead power lines.

Your device was already calibrated at the factory, and the
device uses automatic calibration by default. If you experience
irregular compass behavior, for example, after moving long
distances or after extreme temperature changes, you can
manually calibrate the compass.

Select Compass > > Calibrate Compass > Start.

1

Follow the on-screen instructions.

2

Course Pointer

The course pointer is most useful if you are navigating on water
or where there are no major obstacles in your path. It also helps
you avoid hazards to either side of the course, such as shoals
or submerged rocks.

To enable the course pointer, from the compass, select Setup >

Heading > Go To Line/Pointer > Course (CDI).

Navigating with Sight 'N Go

You can point the device at an object in the distance, lock in the
direction, and navigate to the object.

Select Sight 'N Go.

1

Point the device at an object.

2

Select Lock Direction > Set Course.

3

Navigate using the compass.

4

Elevation Plot

By default, the elevation plot displays the elevation over the
distance traveled. To customize the elevation settings, see

page 11. You can touch any point on the plot to view details

about that point.

Navigating to a Point on the Plot

Select Elevation Plot.

1

Select an individual point on the plot.

2

Details about the point appear.
Select > View Map.

3

Select the information bar at the top of the screen.

4

Select Go.

5

The map opens with your route marked with a magenta line.
Navigate using the map (page 4) or compass (page 5).

6

Changing the Plot Type

You can change the elevation plot to display pressure and
elevation over time or distance.

Select Elevation Plot > Change Plot Type.

1

Select an option.

2

Resetting the Elevation Plot

Select Elevation Plot > > Reset > Clear Current Track >
Clear.

Calibrating the Barometric Altimeter

Your device was already calibrated at the factory, and the
device uses automatic calibration by default. You can manually
calibrate the barometric altimeter if you know the correct
elevation or the correct barometric pressure.

Go to a location where the elevation or barometric pressure

1

is known.
Select Elevation Plot > > Calibrate Altimeter.

2

Follow the on-screen instructions.

3

Trip Computer

The trip computer displays your current speed, average speed,
maximum speed, trip odometer, and other helpful statistics. You
can customize the trip computer layout, dashboard, and data
fields.

From the main menu, select Trip Computer.

Resetting the Trip Computer

For accurate information, reset the trip information before
beginning a trip.

Select Trip Computer > > Reset > Reset Trip Data >

Reset.

Camera and Photos

The course pointer À indicates your relationship to the course
line leading to the destination. The course deviation indicator
(CDI) Â provides the indication of drift (right or left) from the
course. The scale Á refers to the distance between dots à on
the course deviation indicator, which tell you how far off course
you are.

Camera and Photos 5

You can take photos with the Oregon 650 and 650t. When you
take a photo, the geographic location is automatically saved in
the photo information. You can navigate to the location.

Taking a Photo

Select Camera.

1

Turn the device horizontally or vertically to change the

2

orientation of the photo.
If necessary, select to turn on the flash.

3

You can select Auto to use the flash only when the camera
detects a low light scene.

If necessary, use two fingers on the touchscreen to zoom in

4

or out (page 2).
Hold to focus and hold the device still.

5

A white frame appears on the screen. The device focuses on
the object inside of the frame. When the photo is in focus,
the frame turns green.

Release to take a photo.

6

Viewing Photos

You can view photos you have taken with the camera and
photos you have transferred to the device.

Select Photo Viewer.

1

Select a photo to see a larger view.

2

You can spread two fingers to zoom in or pinch two fingers to
zoom out.

Viewing a Slideshow

Select Photo Viewer.

1

Select a photo.

2

Select > View Slideshow.

3

Sorting Photos

Select Photo Viewer > > Sort Photos.

1

Select an option:

2

• Select Most Recently.

• Select Near A Location, and select a location.

• Select On A Specific Date, and enter a date.

Viewing the Location of a Photo

Select Photo Viewer.

1

Select a photo.

2

Select > View Map.

3

Setting a Photo as Wallpaper

Select Photo Viewer.

1

Select a photo.

2

Select > Set As Wallpaper.

3

Deleting a Photo

Select Photo Viewer.

1

Select a photo.

2

Select > Delete Photo > Delete.

3

Navigating to a Photo

Select Photo Viewer.

1

Select a photo.

2

Select > View Information > Go.

3

Geocaches

A geocache is like a hidden treasure. Geocaching is when you
hunt for hidden treasures using GPS coordinates posted online
by those hiding the geocache.

Downloading Geocaches

Connect your device to a computer using the USB cable.

1

Go to www.opencaching.com.

2

If necessary, create an account.

3

Sign in.

4

Follow the on-screen instructions to find and download

5

geocaches to your device.

Filtering the Geocache List

You can filter your geocache list based on certain factors, such
as the level of difficulty.

Select Geocaching > Quick Filter.

1

Select items to filter.

2

Customize the settings, and select .

3

Select an option:

4

• To apply the filter to the geocache list, select Search.

• To save the filter, select .

Creating and Saving a Geocache Filter

You can create and save custom filters for geocaches based on
specific factors. After you set up the filter, you can apply it in the
geocaches list.

Select Setup > Geocaching > Filter Setup > Create Filter.

1

Select items to filter.

2

Select an option:

3

• To apply the filter to the geocache list, select Search.

• To save the filter, select . After it is saved, the filter is
automatically named. You can access the custom filter
from the geocaches list.

Editing a Custom Geocache Filter

Select Setup > Geocaching > Filter Setup.

1

Select a filter.

2

Select an item to edit.

3

Navigating to a Geocache

Select Geocaching > Find a Geocache.

1

Select a geocache.

2

Select Go.

3

Navigate using the map (page 4) or compass (page 5).

4

Logging the Attempt

After you have attempted to find a geocache, you can log your
results. You can verify some geocaches at

www.opencaching.com.

Select Geocaching > Log Attempt.

1

Select Found, Did Not Find, or Needs Repair.

2

Select an option:

3

• To begin navigation to the geocache nearest you, select
Find Next Closest.

• To stop logging, select Done.

• To enter a comment about looking for the cache or about
the cache itself, select Edit Comment, enter a comment,
and select .

• To rate the geocache, select Rate Geocache, and enter a
rating for each category. You can go to

www.opencaching.com to upload your rating.

chirp™

A chirp is a small Garmin accessory that is programmed and left
in a geocache. You can use your device to find a chirp in a
geocache. For more information about the chirp, see the chirp
Owner's Manual at www.garmin.com.

Enabling chirp Searching

Select Setup > Geocaching.

1

Select chirp Searching > On.

2

6 Geocaches

Finding a Geocache with a chirp

Select Geocaching > Find a Geocache.

1

Select a geocache.

2

Select Go.

3

Navigate using the map (page 4) or compass (page 5).

4

When you are within approximately 32.9 ft (10 m) of the
geocache that contains a chirp, details about the chirp
appear.

If necessary, select Geocaching > Show chirp Details.

5

If available, select Go to navigate to the next stage of the

6

geocache.

Fitness

Running or Cycling with Your Device

Before you go for a run or ride using the device, you must
change the profile to fitness (page 10).

You can customize your dashboards and data fields for your
fitness activities (page 9).

If your device is currently recording a track, select Current

1

Track > .

You can save or delete the current track.
Select Setup > Tracks > Output Format.

2

Select an option:

3

• Select GPX to record your activity as a traditional track

that can be viewed on the map and used for navigation.

• Select FIT to record your activity with fitness information

(for example, laps) that is tailored for Garmin Connect™.

• Select Both to record your data in both formats

simultaneously. This setting uses more memory space.

From the main menu, select Stopwatch > Start.

4

Go for a run or ride.

5

When finished, select Stop.

6

Select Reset > Save.

7

History

History includes date, time, distance, calories, average speed or
pace, ascent, descent, and optional ANT+™ sensor information.

NOTE: History is not recorded while the timer is stopped or
paused.

When the device memory is full, a message appears. The
device does not automatically delete or overwrite your history.
You can upload your history to Garmin Connect (page 7) or
BaseCamp (page 4) periodically to keep track of all your activity
data.

Viewing an Activity

Select Activity History.

1

Select an activity.

2

Select Review.

3

Deleting an Activity

Select Activity History.

1

Select an activity.

2

Select Delete > Yes.

3

Using Garmin Connect

Connect the device to your computer using the USB cable.

1

Go to www.garminconnect.com/start.

2

Follow the on-screen instructions.

3

Optional Fitness Accessories

You can use optional fitness accessories including a heart rate
monitor or a cadence sensor with your device. These
accessories use ANT+ wireless technology to send data to the
device.

Before you can use the fitness accessory with your device, you
must install the accessory according to the instructions included
with the accessory.

Pairing Your ANT+ Sensors

Before you can pair, you must put on the heart rate monitor or
install the sensor.

The device is compatible with the heart rate monitor, GSC™ 10
speed and cadence sensor, and tempe™ wireless temperature
sensor. You can customize a data field to display sensor data.

Bring the device within range (3 m) of the sensor.

1

NOTE: Stay 10 m away from other ANT+ sensors while

pairing.
Select Setup > ANT Sensor.

2

Select your sensor.

3

Select Search for new.

4

When the sensor is paired with your device, the sensor
status changes from Searching to Connected.

Tips for Pairing ANT+ Accessories with Your Garmin
Device

• Verify that the ANT+ accessory is compatible with your
Garmin device.

• Before you pair the ANT+ accessory with your Garmin
device, move 10 m (32.9 ft.) away from other ANT+
accessories.

• Bring the Garmin device within range 3 m (10 ft.) of the
ANT+ accessory.

• After you pair the first time, your Garmin device automatically
recognizes the ANT+ accessory each time it is activated.
This process occurs automatically when you turn on the
Garmin device and only takes a few seconds when the
accessories are activated and functioning correctly.

• When paired, your Garmin device receives data from only
your accessory, and you can go near other accessories.

About Heart Rate Zones

Many athletes use heart rate zones to measure and increase
their cardiovascular strength and improve their level of fitness. A
heart rate zone is a set range of heartbeats per minute. The five
commonly accepted heart rate zones are numbered from 1 to 5
according to increasing intensity. Generally, heart rate zones
are calculated based on percentages of your maximum heart
rate.

Fitness Goals

Knowing your heart rate zones can help you measure and
improve your fitness by understanding and applying these
principles.

• Your heart rate is a good measure of exercise intensity.

• Training in certain heart rate zones can help you improve
cardiovascular capacity and strength.

• Knowing your heart rate zones can prevent you from
overtraining and can decrease your risk of injury.

If you know your maximum heart rate, you can use the table
(page 16) to determine the best heart rate zone for your
fitness objectives.

If you do not know your maximum heart rate, use one of the
calculators available on the Internet. Some gyms and health
centers can provide a test that measures maximum heart rate.

Fitness 7

Setting Your Heart Rate Zones

Before the device can determine your heart rate zones, you
must set up your fitness user profile (page 12).

You can manually adjust the heart rate zones according to your
fitness goals (page 7).

Select Setup > Fitness > HR Zones.

1

Enter the maximum and minimum heart rate for zone 5.

2

The maximum heart rate for each zone is based on the
minimum heart rate of the previous zone. For example, if you
enter 167 as a minimum heart rate for zone 5, the device
uses 166 as the maximum rate for zone 4.

Enter your minimum heart rate for zones 4-1.

3

Applications

Using the 3D View

Select 3D View.

1

Select a category.

2

Select a location.

3

Select Use.

4

Enter a radius, and select .

5

When you enter an area with a proximity alarm, the device
sounds a tone.

Using the Flashlight

NOTE: Using the flashlight can reduce battery life. You can

reduce the brightness or use the strobe light to extend the life of
the batteries.

Select Flashlight > .

1

Select an option:

2

• Use the brightness slider to adjust the brightness.

• Use the strobe slider to select a strobe level.

0 No strobe, constant beam.

1–9 Number of strobes per second.

SOS Emergency strobe.

If necessary, customize a key (page 10) as a shortcut to

3

the flashlight.

Calculating the Size of an Area

Select Area Calculation > Start.

1

Walk around the perimeter of the area you want to calculate.

2

Select Calculate when finished.

3

Select an option:

2

• To increase the angle of elevation, select .

• To decrease the angle of elevation, select .

• To pan the 3D map forward, select .

• To pan the 3D map backward, select .

• To rotate the view to the left, select .

• To rotate the view to the right, select .

Sending and Receiving Data Wirelessly

Before you can share data wirelessly, you must be within
10 feet (3 m) of a compatible device.

Your device can send and receive data when paired with
another compatible device or smartphone using Bluetooth® or
ANT+ wireless technology. You can share waypoints,
geocaches, routes, tracks, and custom maps. You can share
photos with the Oregon 650 and 650t models.

Select Share Wirelessly.

1

Select an option:

2

• Select Send, and select a type of data.

• Select Receive to receive data from another device. The

other compatible device must be attempting to send data.

• Select Connect to pair the device with the BaseCamp

Mobile application on a smartphone.

Follow the on-screen instructions.

3

Setting a Proximity Alarm

Proximity alarms alert you when you are within a specified
range of a particular location.

Select Proximity Alarms > Create Alarm.

1

Using the Calculator

The device has a standard calculator and a scientific calculator.

Select Calculator.

1

Select an option:

2

• Use the standard calculator.

• Select > Scientific to use the scientific calculator

functions.

• Select > Degrees to calculate degrees.

Viewing the Calendar and Almanacs

You can view device activity, such as when a waypoint was
saved, and almanac information for the sun and moon, and
hunting and fishing.

Select an option:

1

• To view device activity for specific days, select Calendar.

• To view the sunrise, sunset, moonrise, and moonset

information, select Sun and Moon.

• To view the predicted best times for hunting and fishing,

select Hunt and Fish.

If necessary, select or to view a different month.

2

Select a day.

3

Setting an Alarm

If you are not currently using the device, you can set the device
to turn on at a specific time.

Select Alarm Clock.

1

Select and to set the time.

2

Select Turn Alarm On.

3

Select an option.

4

The alarm sounds at the selected time. If the device is off at
the alarm time, the device turns on and sounds the alarm.

Starting the Countdown Timer

Select Alarm Clock > > Timer.

1

8 Applications

Select and to set the time.

2

Select Start Timer.

3

Opening the Stopwatch

Select Stopwatch.

Satellite Page

The satellite page shows your current location, GPS accuracy,
satellite locations, and signal strength.

Changing the Satellite View

Select Satellite > .

1

If necessary, select Track Up to orient the satellite view with

2

your current track toward the top of the screen.
If necessary, select Multicolor to assign a specific color to

3

the satellite and to the signal strength bar of that satellite.

Turning Off GPS

Select Satellite > > Use With GPS Off.

Simulating a Location

Select Satellite > > Use With GPS Off.

1

Select > Set Location On Map.

2

Select a location.

3

Select Use.

4

Customizing the Device

Adjusting the Backlight Brightness

Extensive use of screen backlighting can significantly reduce
battery life. You can adjust the backlight brightness to maximize
the battery life.

NOTE: The backlight brightness may be limited when the
battery is low.

Select .

1

Use the slider to adjust the backlight level.

2

The device may feel warm when the backlight setting is high.

Main Menu

• Select Setup > Main Menu, and follow the on-screen
instructions.

Locking the Touchscreen

You can lock the screen to prevent inadvertent screen touches.

Select > .

Unlocking the Touchscreen

Select > .

Rotating the Screen

Rotate your device to view in horizontal (landscape) or
vertical (portrait) mode.

Locking the Screen Orientation

The default setting allows the screen to change orientation
automatically based on the device orientation. You can lock the
screen orientation in portrait or landscape mode.

Select Setup > Display > Orientation Lock.

1

Select an option.

2

Creating a Shortcut

Select Setup > Shortcuts > Create Shortcut.

1

Select Name, and enter a name.

2

Select Icon, and select an icon.

3

Select Profile, and assign the shortcut to a specific profile.

4

Select an option:

5

• Select Setup to add a shortcut to a specific device

setting.

• Select Where To? to add a shortcut that begins

navigation to a specific waypoint.

• Select Application to add a shortcut to a specific

application.

Select the item.

6

Adding a Shortcut to the Main Menu

You can add shortcuts to the main menu, application drawer, or
favorites. If the shortcut does not appear in the list, you can
create it (page 9).

Select Setup > Shortcuts.

1

Select the shortcut.

2

Select Main Menu, Drawer, or Favorites.

3

Custom Data Fields and Dashboards

Data fields display information about your location or other

À
Á
Â
Ã

Status bar

Current time and date

Application icons

Application drawer

Customizing the Main Menu

• Hold any icon on the main menu or application drawer, and
drag it to a new location.

• Open the application drawer, and drag an icon up to the
main menu.

Customizing the Device 9

specified data. Dashboards are a custom grouping of data that
can be helpful to a specific or general task, such as geocaching.

You can customize the data fields and dashboards of the map,
compass, trip computer, elevation plot, and the status page.

Enabling the Map Data Fields

Select Map > > Setup Map > Dashboard.

1

Select Small Data Fields or Large Data Field.

2

Customizing the Data Fields

Before you can change the map data fields, you must enable
them (page 9).

Select a page.

1

Select a data field.

2

Select a data field category and a data field.

3

For example, select Trip Data > Speed - Moving Avg..

Customizing Dashboards

Select a page.

1

Select an option:

2

• From the map, select > Setup Map > Dashboard.

• From the compass, trip computer, or status page, select

> Change Dashboard.

Select a dashboard.

3

Profiles

Profiles are a collection of settings that optimize your device
based on how you are using it. For example, the settings and
views are different when you use the device for hunting than
when geocaching.

When you are using a profile and you change settings, such as
data fields or units of measurement, the changes are saved
automatically as part of the profile.

Selecting a Profile

When you change activities, you can change the setup of the
device by changing the profile.

Select Profile Change.

1

Select a profile.

2

Creating a Custom Profile

You can customize your settings and data fields for a particular
activity or trip.

Select Setup > Profiles > Create New Profile > OK.

1

Customize your settings and data fields.

2

Editing a Profile Name

Select Setup > Profiles.

1

Select a profile.

2

Select Edit Name.

3

Enter the new name, and select .

4

Deleting a Profile

Select Setup > Profiles.

1

Select a profile.

2

Select Delete.

3

Customizing the Keys

You can configure the power key and user key as a shortcut to
a menu, setting, or application.

Select Setup > System > Configure Keys.

1

Select Power Key or User Key.

2

Select Single Tap, Double Tap, or Hold.

3

Select an option.

4

System Settings

Select Setup > System.
Satellite System: Sets the satellite system to GPS, GPS +

GLONASS (page 10), or Demo Mode (GPS off).

WAAS/EGNOS: Sets the system to Wide Area Augmentation

System/European Geostationary Navigation Overlay Service

(WAAS/EGNOS). For more information about WAAS, go to

www.garmin.com/aboutGPS/waas.html.

Text Language: Sets the text language on the device.

NOTE: Changing the text language does not change the

language of user-entered data or map data.

Interface: Sets the format of the serial interface.
Configure Keys: Assigns shortcuts to the user key and power

key (page 10).

AA Battery Type: Allows you to change the type of AA battery

you are using. This setting is disabled when the NiMH
battery pack is installed.

About GPS and GLONASS

The default satellite system setting is GPS. You can use GPS +
GLONASS for increased performance in challenging

environments and faster position acquisition. Using GPS and
GLONASS can reduce battery life more than GPS only.

Serial Interface Settings

Select Setup > System > Interface.
Garmin Spanner: Allows you to use the device USB port with

most NMEA 0183-compliant mapping programs by creating a
virtual serial port.

Garmin Serial: Sets the device to use a Garmin proprietary

format to exchange waypoint, route, and track data with a
computer.

NMEA In/Out: Sets the device to use standard NMEA 0183

output and input.

Text Out: Provides simple ASCII text output of location and

velocity information.

RTCM: Allows the device to accept Differential Global

Positioning System (DGPS) information from a device
supplying Radio Technical Commission for Maritime
Services (RTCM) data in an SC-104 format.

Display Settings

Select Setup > Display.
Backlight Timeout: Adjusts the length of time before the

backlight turns off.

Orientation Lock: Locks the screen orientation in portrait or

landscape mode, or allows the screen to change orientation
automatically based on the device orientation.

Screen Capture: Allows you to save the image on the device

screen.

Battery Save: Saves the battery power and prolongs the

battery life by turning off the screen when the backlight times
out (page 13).

Appearance Settings

Select Setup > Appearance.
Mode: Sets a light background, a dark background, or

automatically switches between the two based on the sunrise
and sunset time for your current location.

Background: Sets the background image.
Day Color: Sets the color for the selections made when in day

mode.

Night Color: Sets the color for the selections made when in

night mode.

Landscape Controls: Places the controls on the left or right

side of the screen when in landscape mode.

Turning On Scroll Controls

Select Setup > Accessibility > Scroll Controls > On.

and appear on the screen when a menu, list, or grid is

scrollable.

10 Customizing the Device

Setting the Touchscreen Sensitivity

You can adjust the touchscreen sensitivity to suit your activity.

Select Setup > Accessibility > Touch Sensitivity.

1

Select an option.

2

TIP: You can test the touchscreen settings with and without

gloves based on your activity.

Setting the Device Tones

You can customize tones for messages, keys, turn warnings,
and alarms.

Select Setup > Tones.

1

Select a tone for each audible type.

2

Map Settings

Select Setup > Map.
Configure Maps: Enables or disables the maps currently

loaded on the device.

Orientation: Adjusts how the map is shown on the page. North

Up shows North at the top of the page. Track Up shows your

current direction of travel toward the top of the page.
Automotive Mode shows an automotive perspective with
the direction of travel at the top.

Dashboard: Sets a dashboard to display on the map. Each

dashboard shows different information about your route or
your location.

Guidance Text: Sets when the guidance text is shown on the

map.

Map Speed: Adjusts the speed at which the map is drawn. A

faster map drawing speed decreases the battery life.

Advanced Map Settings

Select Setup > Map > Advanced Setup.
Detail: Sets the amount of detail shown on the map. Showing

more detail may cause the map to redraw more slowly.

Shaded Relief: Shows detail relief on the map (if available) or

turns off shading.

Vehicle: Sets the position icon, which represents your position

the map. The default icon is a small blue triangle.

Zoom Controls: Sets the auto zoom and the location of the

buttons in portrait or landscape mode.

Zoom Levels: Adjusts the zoom level at which map items will

appear. The map items will not appear when the map zoom
level is higher than the selected level.

Text Size: Sets the text size for map items.

Tracks Settings

Select Setup > Tracks.
Record Method: Sets a track recording method. Auto records

the tracks at a variable rate to create an optimum
representation of your tracks.

Interval: Sets a track log recording rate. Recording points more

frequently creates a more-detailed track, but fills the track log
faster.

Auto Archive: Sets an automatic archive method to organize

your tracks. Tracks are saved and cleared automatically.

Auto Pause: Pauses tracking automatically when you stop

moving.

Auto Start: Starts recording a track automatically when the

device has acquired satellites.

Output Format: Allows you to choose the format for recording a

track log. GPX format is a traditional track that can be viewed
on the device map and used for navigation. Tracks are
reviewed using Track Manager. FIT format is a fitness

activity that records additional information (for example,
laps). Activities can be reviewed on the device, but are
tailored for Garmin Connect. You can select Both to record
your data in both formats simultaneously. This option uses
more storage space.

Routing Settings

The device calculates routes optimized for the type of activity
you are doing. The available routing settings vary based on the
activity selected.

Select Setup > Routing.
Activity: Sets an activity for routing. The device calculates

routes optimized for the type of activity you are doing.

Route Transitions: Sets how the device routes from one point

on the route to the next. This setting is available only for
some activities. Distance routes you to the next point on the
route when you are within a specified distance of your
current point.

Lock On Road: Locks the blue triangle, which represents your

position on the map, onto the nearest road.

Heading Settings

You can customize the compass settings.
Select Setup > Heading.
Display: Sets the type of directional heading shown on the

compass.

North Reference: Sets the north reference used on the

compass.

Go To Line/Pointer: Allows you to use the bearing pointer that

points in the direction of your destination, or use the course
pointer that shows your relationship to the course line
leading to the destination.

Compass: Automatically switches from an electronic compass

to a GPS compass when you are traveling at a higher rate of
speed for a period of time.

Calibrate Compass: Allows you to calibrate the compass if you

experience irregular compass behavior, for example, after
moving long distances or after extreme temperature
changes. See page 5.

Altimeter Settings

Select Setup > Altimeter.
Auto Calibration: Automatically calibrates the altimeter each

time the device is turned on. The device continues to
automatically calibrate the altimeter as long as the device
has GPS signals acquired.

Barometer Mode: Variable Elevation allows the barometer to

measure changes in elevation while you are moving. Fixed
Elevation assumes the device is stationary at a fixed
elevation, so the barometric pressure should only change
due to weather.

Pressure Trending: Sets how the device records pressure

data. Save Always can be useful when you are watching for
pressure fronts.

Plot Type: Records elevation changes over a period of time or

distance, records barometric pressure over a period of time,
or records ambient pressure changes over a period of time.

Calibrate Altimeter: Allows you to calibrate the barometric

altimeter if you know the correct elevation or the correct
barometric pressure. See page 5.

Position Format Settings

NOTE: You should not change the position format or the map

datum coordinate system unless you are using a map or chart
that specifies a different position format.

Customizing the Device 11

Select Setup > Position Format.
Position Format: Sets the position format in which a location

reading appears.

Map Datum: Sets the coordinate system on which the map is

structured.

Map Spheroid: Shows the coordinate system the device is

using. The default coordinate system is WGS 84.

Changing the Units of Measure

You can customize units of measure for distance and speed,
elevation, depth, temperature, pressure, and vertical speed.

Select Setup > Units.

1

Select a measurement type.

2

Select a unit of measure.

3

Time Settings

Select Setup > Time.
Time Format: Sets the device to show time in a 12-hour or 24-

hour format.

Time Zone: Sets the time zone for the device. Automatic sets

the time zone automatically based on your GPS position.

Camera Settings

Select Setup > Camera.
Photo Resolution: Sets the resolution of the photos.
Save Photos To: Sets the photo storage location.
Camera Instructions: Displays brief instructions about taking

photos.

Geocaching Settings

Select Setup > Geocaching.
Geocache List: Allows you to display the geocache list by

names or codes.

Geocache Style: Sets the display style for geocache data.
chirp Searching: Allows the device to search for a geocache

containing a chirp accessory (page 6).

Program chirp: Programs the chirp accessory. See the chirp

owner's manual at www.garmin.com.

Filter Setup: Allows you to create and save custom filters for

geocaches based on specific factors (page 6).

Found Geocaches: Allows you to edit the number of

geocaches found. This number automatically increases as
you log a find (page 6).

ANT+ Sensor Settings

For more information about optional fitness accessories, see

page 7.

Fitness Settings

Select Setup > Fitness.
Auto Lap: Sets the device to automatically mark the lap at a

specific distance.

User: Sets the user profile information (page 12).
HR Zones: Sets the five heart rate zones for fitness activities.
FIT Activity: Sets the fitness activity to running, cycling, or

other. This allows your running activity to appear as a
running activity when you transfer it to Garmin Connect.

Setting Your Fitness User Profile

The device uses information that you enter about yourself to
calculate accurate data. You can modify the following user
profile information: gender, age, weight, height, and lifetime
athlete (page 12).

Select Setup > Fitness > User.

1

Modify the settings.

2

About Lifetime Athletes

A lifetime athlete is an individual who has trained intensely for
many years (with the exception of minor injuries) and has a
resting heart rate of 60 beats per minute (bpm) or less.

Marking Laps by Distance

You can use Auto Lap® to automatically mark the lap at a
specific distance. This feature is helpful for comparing your
performance over different parts of an activity.

Select Setup > Fitness > Auto Lap.

1

Enter a value, and select .

2

Marine Settings

Select Setup > Marine.
Marine Chart Mode: Sets the type of chart the device uses

when displaying marine data. Nautical displays various map
features in different colors so the marine POIs are more
readable and so the map reflects the drawing scheme of
paper charts. Fishing (requires marine maps) displays a
detailed view of bottom contours and depth soundings and
simplifies map presentation for optimal use while fishing.

Appearance: Sets the appearance of marine navigation aids on

the map.

Marine Alarm Setup: Sets alarms for when you exceed a

specified drift distance while anchored, when you are off
course by a specified distance, and when you enter water of
a specific depth.

Setting Up Marine Alarms

Select Setup > Marine > Marine Alarm Setup.

1

Select an alarm type.

2

Select On.

3

Enter a distance, and select .

4

Resetting Data

You can reset trip data, delete all waypoints, clear the current
track, or restore default values.

Select Setup > Reset.

1

Select an item to reset.

2

Restoring Default Values for Specific Settings

Select Setup.

1

Select an item to reset.

2

Select > Restore Defaults.

3

Restoring Default Values for Specific Page Settings

You can restore the default values for settings for the map,
compass, trip computer, and elevation plot.

Open the page for which you will restore the settings.

1

Select > Restore Defaults.

2

Restoring All Default Settings

You can reset all settings back to the factory default settings.

Select Setup > Reset > Reset All Settings > Yes.

12 Customizing the Device
