Garmin 400 User Manual 2
GPS 400
Pilot’s Guide and Reference
RECORD OF REVISIONS
Revision Date of Revision Description
A 8/99 Initial Release
B 8/00 Revised and Redrawn
C 11/06
Changed to 8 inch x 8.5 inch format. Added TERRAIN,
Additional Features section, and misc. changes
D 2/07 Updated per Main SW v5.02
E 10/07 Updated per Main SW v5.03
F 05/08 Removed Proximity Advisory info from Section 10
G 08/08 Converted format of figures to accommodate printing process
H 12/09 Added Section 10.2, GTS 8XX Traffic Systems
190-00140-60 Rev. H
GPS 400 Pilot’s Guide and Reference
i
COPYRIGHT
Copyright © 2009 Garmin Ltd. or its subsidiaries. All rights reserved.
This manual reflects the operation of Main System Software version 5.03 or later. Some differences may be observed when
comparing the information in this manual to other software versions.
Garmin International, Inc., 1200 East 151st Street, Olathe, Kansas 66062 USA
p: 913.397.8200 f: 913.397.8282
Garmin AT, Inc., 2345 Turner Road SE, Salem, Oregon 97302 USA
p: 503.391.3411 f: 503.364.2138
Garmin (Europe) Ltd., Liberty House, Bulls Copse Road, Hounsdown Business Park, Southampton, SO40 9RB, U.K.
p: +44/ (0) 870.8501241 f: +44/ (0) 870.8501251
Garmin (Asia) Corp., No. 68, Jangshu 2nd Road., Shijr, Taipei County, Taiwan
p: 886/2.2642.9199 f : 886/2.2642-9099
Website Address: www.garmin.com
Visit the Garmin website for the latest updates and supplemental information concerning the operation of this and other Garmin
products.
Except as expressly provided herein, no part of this manual may be reproduced, copied, transmitted, disseminated, downloaded, or
stored in any storage medium, for any purpose without the express written permission of Garmin. Garmin hereby grants permission
to download a single copy of this manual and of any revision to this manual onto a hard drive or other electronic storage medium to
be viewed for personal use, provided that such electronic or printed copy of this manual or revision must contain the complete text
of this copyright notice and provided further that any unauthorized commercial distribution of this manual or any revision hereto is
strictly prohibited.
Garmin® and AutoLocate® are registered trademarks of Garmin Ltd. or its subsidiaries and may not be used without the express
permission of Garmin.
GDL™, GPS 400™, GTX™, PhaseTrac12™ and Spell’N’Find™ are trademarks of Garmin Ltd. or its subsidiaries and may not be used
without the express permission of Garmin.
NavData® is a registered trademark of Jeppesen, Inc.
December 2009 190-00140-60 Rev. H Printed in the U.S.A..
ii
GPS 400 Pilot’s Guide and Reference
190-00140-60 Rev. H
TABLE OF CONTENTS
SECTION 1: INTRODUCTION ........................................... 1-1
1.1 Accessories and Packing List ................................. 1-1
1.2 Key and Knob Functions ......................................... 1-2
1.3 Takeoff Tour ............................................................... 1-5
SECTION 2: NAV PAGES .................................................. 2-1
2.1 Main Page Groups ....................................................2-1
2.2 NAV Page Group ....................................................... 2-2
2.3 Default NAV Page .....................................................2-2
2.4 Map Page ...................................................................2-5
2.5 TERRAIN Page .......................................................... 2-15
2.6 NAV/COM Page ........................................................ 2-18
2.7 Position Page ..........................................................2-20
2.8 Satellite Status Page ............................................. 2-23
2.9 Vertical Navigation Page ...................................... 2-25
SECTION 3: DIRECT-TO NAVIGATION ......................... 3-1
3.1 Overview .................................................................... 3-1
SECTION 4: FLIGHT PLANS..............................................4-1
4.1 Flight Plan Catalog Page ........................................ 4-1
4.2 Active Flight Plan Page ...........................................4-9
SECTION 5: PROCEDURES ............................................... 5-1
5.1 Approaches, Departures, and Arrivals .................5-1
5.2 Non-Precision Approach Operations .................... 5-3
5.3 Points to Remember for All Approaches........... 5-26
SECTION 6: WPT PAGES .................................................... 6-1
6.1 WPT Page Group ....................................................... 6-1
6.2 Airport Location Page ............................................. 6-4
6.3 Airport Runway Page .............................................. 6-5
6.4 Airport Frequency Page ..........................................6-6
6.5 Airport Approach Page ........................................... 6-8
6.6 Airport Arrival Page ...............................................6-10
6.7 Airport Departure Page ........................................6-12
6.8 Intersection Page ................................................... 6-13
6.9 NDB Page .................................................................. 6-14
6.10 VOR Page ................................................................ 6-14
6.11 User Waypoint Page.............................................6-15
SECTION 7: NRST PAGES ................................................. 7-1
7.1 NRST Page Group .....................................................7-1
7.2 Nearest Airport Page ............................................... 7-4
7.3 Nearest Intersection Page ...................................... 7-5
7.4 Nearest NDB Page .................................................... 7-6
7.5 Nearest VOR Page ....................................................7-6
7.6 Nearest User Waypoint Page .................................7-7
7.7 Nearest Center (ARTCC) Page ................................ 7-8
7.8 Nearest Flight Service Station (FSS) Page ..........7-8
7.9 Nearest Airspace Page ............................................ 7-9
SECTION 8: AUX PAGES .................................................... 8-1
8.1 AUX Page Group .......................................................8-1
8.2 Flight Planning Page ................................................ 8-2
8.3 Utility Page .............................................................. 8-12
8.4 Setup 1 Page ...........................................................8-20
8.5 Setup 2 Page ...........................................................8-28
SECTION 9: TERRAIN ..........................................................9-1
9.1 Introduction ............................................................. 9-1
9.2 TERRAIN Page ..........................................................9-3
9.3 TERRAIN Alerts ........................................................9-4
9.4 Database Information for TERRAIN .................... 9-9
SECTION 10: ADDITIONAL FEATURES ..................... 10-1
10.1 Traffic Information Service (TIS) ......................10-1
10.2 GTS 8XX Traffic Systems .................................. 10-11
10.3 Weather Data Link Interface ........................... 10-18
SECTION 11: FAULT DETECTION & EXCLUSION .. 11-1
11.1 Detection and Exclusion ..................................... 11-1
11.2 Pre-Departure Verification of FDE ....................11-2
SECTION 12: MESSAGES, ABBREVIATIONS, &
NAV TERMS ............................................................................ 12-1
12.1 Messages ................................................................ 12-1
12.2 Abbreviations ........................................................12-8
12.3 Navigation Terms ...............................................12-11
Appendix A: Data Card Use ..........................................A-1
190-00140-60 Rev. H
Appendix B: Specifications ........................................... B-1
Appendix C: Troubleshooting Q & A ........................C-1
GPS 400 Pilot’s Guide and Reference
iii
WARNINGS,
CAUTIONS, AND NOTES
WARNING: Navigation and terrain separation must NOT be predicated upon the use of the TERRAIN function.
The TERRAIN feature is NOT intended to be used as a primary reference for terrain avoidance and does not
relieve the pilot from the responsibility of being aware of surroundings during flight. The TERRAIN feature is
only to be used as an aid for terrain avoidance and is not certified for use in applications requiring a certified
terrain awareness system. Terrain data is obtained from third party sources. Garmin is not able to independently
verify the accuracy of the terrain data.
WARNING: The terrain data should be used only as an aid for situational awareness. Terrain data must not
be used as the sole basis for decisions or maneuvers to avoid terrain or obstacles. Terrain data must not be
used for navigation.
WARNING: The altitude calculated by GPS 400 GPS receivers is geometric height above Mean Sea Level and
could vary significantly from the altitude displayed by pressure altimeters in aircraft. GPS altitude should never
be used for vertical navigation. Always use pressure altitude displayed by pressure altimeters in the aircraft.
WARNING: The Jeppesen database used in the GPS 400 system must be updated regularly in order to ensure
that its information remains current. Updates are released every 28 days. A database information packet is
included in the GPS 400 package. Pilots using an outdated database do so entirely at their own risk.
WARNING: The basemap (land and water data) must not be used for navigation, but rather only for nonnavigational situational awareness. Any basemap indication should be compared with other navigation
sources.
WARNING: For safety reasons, GPS 400 operational procedures must be learned on the ground.
WARNING: The United States government operates the Global Positioning System and is solely responsible for
its accuracy and maintenance. GPS is subject to changes which could affect the accuracy and performance of all
GPS equipment. Portions of the Garmin GPS 400 utilize GPS as a precision electronic NAVigation AID (NAVAID).
Therefore, as with all NAVAIDs, information presented by the GPS 400 can be misused or misinterpreted and,
therefore, become unsafe.
iv
GPS 400 Pilot’s Guide and Reference
190-00140-60 Rev. H
WARNINGS,
CAUTIONS, AND NOTES
WARNING: Use the GPS 400, Weather Data Link Interface, TIS, and TERRAIN at your own risk. To reduce the risk
of unsafe operation, carefully review and understand all aspects of the GPS 400 Pilot’s Guide documentation and
the Flight Manual Supplement. Thoroughly practice basic operation prior to actual use. During flight operations,
carefully compare indications from the GPS 400 to all available navigation sources, including the information
from other NAVAIDs, visual sightings, charts, etc. For safety purposes, always resolve any discrepancies before
continuing navigation.
CAUTION: The GPS 400 display screen is coated with a special anti-reflective coating that is very sensitive to
skin oils, waxes, and abrasive cleaners. CLEANERS CONTAINING AMMONIA WILL HARM THE ANTI-REFLECTIVE
COATING. It is very important to clean the screen using a clean, lint-free cloth and an eyeglass lens cleaner
that is specified as safe for anti-reflective coatings.
CAUTION: The Garmin GPS 400 does not contain any user-serviceable parts. Repairs should only be made by
an authorized Garmin service center. Unauthorized repairs or modifications could void both the warranty and
the pilot’s authority to operate this device under FAA/FCC regulations.
NOTE: All visual depictions contained within this document, including screen images of the GPS 400 panel and
displays, are subject to change and may not reflect the most current GPS 400 system. Depictions of equipment
may differ slightly from the actual equipment.
NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and (2) this device must accept any interference received,
including interference that may cause undesired operation.
NOTE: This product, its packaging, and its components contain chemicals known to the State of California to
cause cancer, birth defects, or reproductive harm. This notice is being provided in accordance with California’s
Proposition 65. If you have any questions or would like additional information, please refer to our website at
www.garmin.com/prop65.
190-00140-60 Rev. H
GPS 400 Pilot’s Guide and Reference
v
WARRANTY
AVIATION LIMITED WARRANTY
All Garmin avionics products are warranted to be free from defects in materials or workmanship for: two years from the date of
purchase for new Remote-Mount and Panel-Mount products; one year from the date of purchase for new portable products and any
purchased newly-overhauled products; six months for newly-overhauled products exchanged through a Garmin Authorized Service
Center; and 90 days for factory repaired or newly-overhauled products exchanged at Garmin in lieu of repair. Within the applicable
period, Garmin will, at its sole option, repair or replace any components that fail in normal use. Such repairs or replacement will be
made at no charge to the customer for parts or labor, provided that the customer shall be responsible for any transportation cost.
This warranty does not apply to: (i) cosmetic damage, such as scratches, nicks and dents; (ii) consumable parts, such as batteries,
unless product damage has occurred due to a defect in materials or workmanship; (iii) damage caused by accident, abuse, misuse,
water, flood, fire, or other acts of nature or external causes; (iv) damage caused by service performed by anyone who is not an
authorized service provider of Garmin; or (v) damage to a product that has been modified or altered without the written permission of
Garmin. In addition, Garmin reserves the right to refuse warranty claims against products or services that are obtained and/or used
in contravention of the laws of any country.
THE WARRANTIES AND REMEDIES CONTAINED HEREIN ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, WHETHER
EXPRESS, IMPLIED OR STATUTORY, INCLUDING ANY LIABILITY ARISING UNDER ANY WARRANTY OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE, STATUTORY OR OTHERWISE. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, WHICH MAY VARY
FROM STATE TO STATE.
IN NO EVENT SHALL GARMIN BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES, WHETHER
RESULTING FROM THE USE, MISUSE OR INABILITY TO USE THE PRODUCT OR FROM DEFECTS IN THE PRODUCT. SOME STATES DO
NOT ALLOW THE EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS MAY NOT APPLY TO
YOU.
Garmin retains the exclusive right to repair or replace (with a new or newly-overhauled replacement product) the product or software
or offer a full refund of the purchase price at its sole discretion. SUCH REMEDY SHALL BE YOUR SOLE AND EXCLUSIVE REMEDY FOR
ANY BREACH OF WARRANTY.
Online Auction Purchases: Products purchased through online auctions are not eligible for warranty coverage. Online auction
confirmations are not accepted for warranty verification. To obtain warranty service, an original or copy of the sales receipt from the
original retailer is required. Garmin will not replace missing components from any package purchased through an online auction.
International Purchases: A separate warranty may be provided by international distributors for devices purchased outside the
United States depending on the country. If applicable, this warranty is provided by the local in-country distributor and this distributor
provides local service for your device. Distributor warranties are only valid in the area of intended distribution. Devices purchased in
the United States or Canada must be returned to the Garmin service center in the United Kingdom, the United States, Canada, or
Taiwan for service.
To obtain warranty service, contact your local Garmin Authorized Service Center. For assistance in locating a Service Center near you,
visit the Garmin Website at ‘http://www.garmin.com’ or contact Garmin Customer Service at 800-800-1020.
vi
GPS 400 Pilot’s Guide and Reference
190-00140-60 Rev. H
SECTION 1
INTRODUCTION
SECTION 1: INTRODUCTION
1.1 ACCESSORIES AND PACKING LIST
Congratulations on choosing the finest, most advanced
panel mount IFR navigation/communication system
available. The GPS 400 represents Garmin’s commitment
to provide accurate, easy-to-use avionics.
Before installing and getting started with the GPS 400,
please check to see that the package includes the following
items. If any parts are missing or damaged, please contact
a Garmin dealer immediately.
Standard Package:
• GPS 400 Unit
• NavData® Card
• Terrain Data Card
• Installation Rack
• Connectors
The Garmin dealer installs and configures the GPS
400. The GPS 400 is secured in the installation rack
with the proper wiring connections performed. After
installation, the NavData Card and the TERRAIN Data
Card are installed into their correct slots on the front of
the unit (see Appendix A). A Garmin dealer can answer
any questions about the installation, such as location of
antennas or any connections to other equipment in the
panel.
NOTE: Help Garmin provide better support by
completing on-line registration. Registration
ensures notification of product updates, new
products, and provides for lost or stolen unit
tracking. Have the serial number of the GPS
400 available and connect to the website (www.
garmin.com). Look for the product registration
link on the home page.
• GPS Antenna
• Pilot’s Guide
• Quick Reference Guide
• Database Subscription Packet
• Warranty Registration Card
• GPS 400 Simulator CD-ROM
190-00140-60 Rev. H
GPS 400 Pilot’s Guide and Reference
1-1
SECTION 1
P
INTRODUCTION
1.2 KEY AND KNOB FUNCTIONS
The GPS 400 is designed to make operation as simple
as possible. The key and knob descriptions (Figure
1-1) provide a general overview of the primary function(s)
for each key and knob. The takeoff tour (Section 1.3)
is intended to provide a brief overview of the primary
functions of the GPS 400.
1
2
3
Experiment with the unit and refer to the reference
sections for more information.
Data is entered using the large and small knobs.
Experiment with them to become efcient at entering data.
This greatly reduces the amount of time spent operating
the GPS 400 in flight.
4
5
7
6
8
1-2
1
NavData Card Slot
2
Power
3
TERRAIN Data Card Slot
4
CLR (clear)
5
Direct-to
9
10
Figure 1-1 Keys and Knobs
6
7
8
9
10
GPS 400 Pilot’s Guide and Reference
11
12
RNG (map range)
MENU
ENT (enter)
NRST (nearest)
OBS
13
15
14
11
MSG (message)
12
FPL (ight plan)
13
PROC (procedures)
14
Large right knob
15
Small right knob
190-00140-60 Rev. H
SECTION 1
INTRODUCTION
Left-hand Knob
(1, 3) – See Appendix A for NavData and TERRAIN
Data Card insertion and removal.
(2) Power Knob – Controls unit power, turn clockwise
to turn the unit on.
Right-hand Keys and Knobs
(4) CLR Key – Used to erase information, remove map
detail, or to cancel an entry. Press and hold the CLR Key
to immediately display the Default NAV Page.
(5) Direct-to Key – Allows the pilot to enter a destination
waypoint and establishes a direct course to the selected
destination (Section 3).
(6) RNG Key – Allows the pilot to select the desired map
range. Use the up arrow to zoom out to a larger area, or
the down arrow to zoom in to a smaller area.
(7) MENU Key – Displays a context-sensitive list of
options. This options list allows the pilot to access
additional features or make settings changes which relate
to the currently displayed page.
(8) ENT Key – Used to approve an operation or complete
data entry. It is also used to confirm information during
power on.
(14) Large Right Knob (CRSR) – Used to select page
groups: NAV, WPT, AUX, or NRST. With the on-screen
cursor enabled, the large right knob allows the pilot to
move the cursor about the page. The large right knob is
also used to move the target pointer right (turn clockwise)
or left (counterclockwise) when the map panning function
is active.
(15) Small Right Knob (CRSR) – Used to select pages
within one of the groups listed above. Press this knob
momentarily to display the on-screen cursor. The cursor
allows the pilot to enter data and/or make a selection from
a list of options. When entering data, the small knob is
used to select the desired letter or number and the large
knob is used to move to the next character space. The
small right knob is also used to move the target pointer
up (turn clockwise) or down (counterclockwise) when the
map panning function is active.
`
NOTE: Data is entered using the large and
small right knobs (Figure 1-2). Experiment with
them to become efficient at entering data. This
will greatly reduce the amount of time spent
operating the GPS 400 in flight.
Figure 1-2 Blank Direct-to Page
190-00140-60 Rev. H
GPS 400 Pilot’s Guide and Reference
1-3
SECTION 1
INTRODUCTION
NOTE: When the GPS 400 displays a list of
information that is too long for the display
screen, a scroll bar appears along the right-hand
side of the display (Figure 1-3). The scroll bar
graphically indicates the number of additional
items available within the selected category. To
scroll through the list, press the small right knob
to activate the cursor, then turn the large right
knob.
Scroll
Bar
Figure 1-3 Scroll Bar
Bottom Row Keys
(9) NRST Key – Displays the Nearest Airports Page.
Then, turning the small right knob steps through the
NRST pages.
(10) OBS Key – Selects OBS mode, which retains the
current ‘active to’ waypoint as the navigation reference
even after passing the waypoint (i.e., prevents sequencing
to the next waypoint). Pressing the OBS Key again returns
the unit to normal operation, with automatic sequencing
of waypoints. When OBS mode is selected, the pilot may
set the desired course to/from a waypoint using the ‘Select
OBS Course’ pop-up window, or an external OBS selector
on the HSI or CDI.
(11) MSG Key – Used to view system messages and to
alert the pilot to important warnings and requirements.
See Section 12.1 for more information on messages.
(12) FPL Key – Allows the pilot to create, edit, activate,
and invert flight plans, as well as access approaches,
departures, and arrivals. A closest point to ight plan
feature is also made available by pressing the FPL Key.
See Section 4 for more information on flight plans.
(13) PROC Key – Allows the pilot to select and remove
approaches, departures, and arrivals from the flight plan.
When using a ight plan, available procedures for the
departure and/or arrival airport are offered automatically.
Otherwise, the pilot may select the desired airport, then
the desired procedure.
1-4
GPS 400 Pilot’s Guide and Reference
190-00140-60 Rev. H
SECTION 1
INTRODUCTION
1.3 TAKEOFF TOUR
reading within this Pilot’s Guide includes:
Overview
The Garmin GPS 400 provides the pilot accurate
navigational data, along with non-precision and precision
approach certification in the IFR environment. The takeoff
tour is designed to familiarize the pilot with:
• Powering up the unit
• Entering data
• Performing a simple direct-to
• Selecting IFR procedures
• Using some limited flight plans
In addition, this section briey covers the Default NAV
Page, the Map Page, and the NAV/COM Page, which are
available as part of the NAV Page Group. These pages are
used for most of the in-flight navigation.
The takeoff tour assumes that the unit and antennas
have been properly installed and that the GPS 400’s
default settings have not been changed. If any of the
factory default settings (position format, units of measure,
selectable elds, etc.) have been changed, the pictures
shown here may not exactly match what is shown on
the GPS 400. Prior to using the GPS 400 for the first
time, Garmin recommends that the aircraft be moved to a
location that is well away from buildings and other aircraft
so the unit can collect satellite data without interruption.
This takeoff tour is intended to provide a brief
introduction of the GPS 400’s major features. Sections
2 through 12 of this manual describe these features, and
others, in additional detail. Refer to these sections, as
needed, to learn or review the details regarding a particular
feature.
Service staff is available during normal business hours
(U.S. Central time zone) at the phone and fax numbers
listed on page ii. Garmin can also be reached by mail
(page ii) or at our website address, www.garmin.com.
Powering up the GPS 400
left corner of the unit. Turning it clockwise turns unit
power on. After turning the unit on, a welcome page
appears briefly while the unit performs a self test,
followed sequentially by the Unit Type Page (Figure
1-4) and the Software Versions Page. Then (depending
on conguration) the Weather Page, the Trafc Page, the
Aviation Data Page, the Land/Terrain/Obstacles Database
Page, and the Situational Awareness Page are sequentially
displayed.
After becoming familiar with the basics, some suggested
• Flight plan features - Section 4
• IFR procedures - Section 5
• Waypoint information pages (database
information) - Section 6
• Unit settings (conguring the unit to the pilot’s
preferences) - Section 8
If more information is needed, Garmin’s Customer
The GPS 400’s Power Knob is located at the top
Figure 1-4 Unit Type Page
190-00140-60 Rev. H
GPS 400 Pilot’s Guide and Reference
1-5
SECTION 1
INTRODUCTION
The Database Versions Page (Figure 1-5) appears
next, which shows the current database information
on the NavData Card and Terrain Data cards. Database
information highlighted in yellow indicates the database
is not within its effective dates. The NavData database is
updated every 28 days and must be current for approved
instrument approach operations. Information on database
subscriptions is available inside the GPS 400 package.
Figure 1-5 Database Versions Page
Acknowledging the database information:
Press the ENT Key.
Instrument Panel Self-test Page
To ensure that the GPS 400 and any connected
instruments are working properly, check for the following
indications on the CDI/HSI, RMI, external annunciators,
and other connected instruments:
• Course deviation - half left/no ag
• TO/FROM ag - TO
• Bearing to destination - 135°
• Distance to destination - 10.0 nm
• All external annunciators (if installed) - on
• Glideslope - half up/no ag
• Time to destination - 4 minutes
• Desired track - 149.5°
• Ground speed - 150 knots
The Instrument Panel Self-test Page (Figure 1-6)
indicates the currently selected OBS course, fuel capacity
(CAP), fuel on board (FOB), and fuel ow (FF). The fuel
capacity, fuel on board, and fuel flow may be manually
entered if the installation does not include connection to
sensors which automatically provide these figures.
Once the database has been acknowledged, the
Instrument Panel Self-test Page appears (Figure 1-6).
Figure 1-6 Instrument Panel Self-Test Page
1-6
GPS 400 Pilot’s Guide and Reference
Entering fuel capacity, fuel on board,
or fuel flow figures (if not provided by
sensors):
1) Turn the large right knob to select the ‘CAP’,
‘FOB’, or ‘FF’ field.
2) Turn the small and large right knobs to enter
the desired figure (Figures 1-6 and 1-7), then
press the ENT Key.
190-00140-60 Rev. H
Figure 1-7 Fuel Flow Selected
The Instrument Panel Self-test Page includes selections
to set fuel on board (FOB) to full capacity and access the
Checklists Page. This allows the pilot to quickly set fuel
to full limits and display any checklists that have been
entered, such as start up or takeoff checklists.
Setting fuel on board to full (if not
provided by sensor):
1) Turn the large right knob to highlight ‘Set Full
Fuel?’ (Figure 1-8).
SECTION 1
INTRODUCTION
Viewing the Checklists Page:
1) Turn the large right knob to highlight ‘Go To
Chklist?’ (Figure 1-9) and press the ENT Key.
Figure 1-9 ‘Go To Chklist?’ Highlighted
2) Turn the large right knob to select the desired
checklist, then execute each step (Section
8.3, Utility Page: Checklists) in the selected
checklist.
3) After completing the desired checklist(s), press
the small right knob to return to the Checklists
Page. Press the small right knob again to
return to normal operation on the Satellite
Status Page or the Map Page.
Figure 1-8 ‘Set Full Fuel?’ Highlighted
2) Press the ENT Key and verify that fuel on board
(‘FOB’) now matches the fuel capacity (CAP)
figure. Fuel on board is reduced, over time,
based on the fuel flow (FF) figure.
190-00140-60 Rev. H
GPS 400 Pilot’s Guide and Reference
4) Once instrument operation has been verified
with the Instrument Panel Self-test Page
displayed, press the ENT Key.
NOTE: The GPS 400 can hold up to nine checklists
with up to 30 entries in each checklist.
1-7
SECTION 1
INTRODUCTION
Satellite Status Page
The Satellite Status Page (Figure 1-10) appears as the
GPS 400 attempts to collect satellite information.
An ‘Acquiring’ status is displayed on the Satellite Status
Page, and the signal strengths of any satellites received
appear as ‘bar graph’ readings. This is a good indication
that the unit is receiving signals and a position x is being
determined. Following the first-time use of the GPS 400,
the time required for a position x varies, usually from
one to two minutes.
Figure 1-10 Satellite Status Page
If the unit can only obtain enough satellites for 2D
navigation (no altitude), the unit uses the altitude provided
by the altitude encoder (if one is connected).
The ‘INTEG’ annunciator (bottom left corner of the
screen) indicates that satellite coverage is insufcient to
pass built-in integrity monitoring tests. In the example
above, not enough satellites are being received to determine
a position. The Satellite Status Page shows the ID numbers
for the satellites and the relative signal strength of each
satellite received (as a bar graph reading).
‘Searching Sky’ indicates that satellite almanac data is
not available or has expired (if the unit hasn’t been used
for six months or more). This means the unit is acquiring
satellite data to establish almanac and satellite orbit
information, which can take five to ten minutes. The data
is recollected from the first available satellite. The Satellite
Status Page displays a ‘Search Sky’ status, and the message
annunciator (MSG), above the MSG Key also flashes to
alert the pilot of a system message, ‘Searching the Sky’.
Viewing a system message:
Press the MSG Key (Figure 1-11).
The Message Page appears and displays the status or
warning information applicable to the receiver’s current
operating condition.
Figure 1-11 Message Page
Returning to the previous page after
viewing a message:
Press the MSG Key again.
NOTE: The GPS 400 utilizes certain software
algorithms to ensure reliable GPS receiver
operation. Receiver Autonomous Integrity
Monitoring (RAIM) and Fault Detection and
Exclusion (FDE) are two examples. These features
allow navigation during Oceanic/Remote legs of
a flight using the GPS 400. For further details,
please refer to Sections 8.3 and 11.
1-8
GPS 400 Pilot’s Guide and Reference
190-00140-60 Rev. H
SECTION 1
INTRODUCTION
Page Groups
Page Groups
NAV Group WPT Group AUX Group NRST Group
see Section 2 see Section 6 see Section 8 see Section 7
Table 1-1 Page Groups
The bottom right corner of the screen (Figure 1-12)
indicates which page group (Table 1-1) is currently being
displayed (NAV, WPT, AUX, or NRST), the number of
pages available within that group (indicated by square
icons), and the placement of the current page within that
group (indicated by a highlighted square icon).
In addition to the NAV Page Group, additional page
groups are available for waypoint information (WPT),
auxiliary (AUX) functions such as ight planning or unit
settings, and listings for nearest (NRST) airports or other
facilities.
NOTE: The NRST Page Group may be accessed
by using the large right knob as described in the
preceding procedure or by pressing the NRST
Ke y.
NAV Pages
There are seven pages available under the NAV Page
Group*:
• Default NAV Page
• Map Page
• TERRAIN Page (if congured)
• NAV/COM Page
• Position Page
• Satellite Status Page
• Vertical Navigation Page
The Default NAV Page, the Map Page, and the NAV/
COM Page are used for most of the in-ight navigation.
Position of
Current Page
within Current
Current Page Group
Figure 1-12 Current Page and Page Group
Number of Pages in
Current Page Group
Page Group
Selecting the desired page group and page:
1) Turn the large right knob until a page from the
desired page group is displayed (Figure 1-12).
2) Turn the small right knob until the desired page
is displayed (Figure 1-12).
190-00140-60 Rev. H
GPS 400 Pilot’s Guide and Reference
NOTE: *The NAV Page Group may have eight
or nine NAV pages available when the GPS 400
installation includes connection to traffic and/or
weather information sources. See Section 10 of
this manual for more information.
Selecting the NAV Page Group and display
the Default NAV Page:
Press and hold the CLR Key.
Selecting the desired NAV Page:
Turn the small right knob until the desired
page is displayed.
1-9
SECTION 1
INTRODUCTION
Map Page
After the GPS 400 acquires satellites and computes
a position, the Map Page (Figure 1-13) appears
automatically.
Map Display
Map Range
Present Position
Figure 1-13 Map Page
The Map Page displays the present position (using an
airplane symbol) relative to nearby airports, VORs, NDBs,
intersections, user waypoints, and airspace boundaries.
The route is displayed as a solid line.
Data elds for destination waypoint (WPT), distance
to waypoint (DIS), desired track (DTK), and ground speed
(GS) appear on the right-hand side of the display. These
elds are user selectable (Section 2.4, Selecting Desired
On-screen Data) to allow the pilot to congure the unit.
Available settings include: altitude, bearing, enroute safe
altitude, estimated time of arrival, minimum safe altitude,
and ground track.
A Map Setup Page is provided to designate the
maximum range at which each map feature appears.
These settings provide an automatic decluttering of the
map (based upon preferences) while adjusting the range.
See Section 12.3 for definitions of these navigation terms.
While viewing the Map Page, the pilot can quickly
declutter and remove many of the background map details
by pressing the CLR Key (repeatedly) until the desired
detail is depicted.
Desired Track
Data Fields
To change the map range, press the up arrow (to zoom
out) or the down arrow (to zoom in) of the RNG (map
range) Key. The current map range is depicted in the
lower left corner of the Map Display.
Direct-to Navigation
The GPS 400 can use direct point-to-point navigation
to provide guidance from takeoff to touchdown, even
in the IFR environment. Once a destination is selected,
the unit provides speed, course, and distance data based
upon a direct course from the present position to the
destination. A destination can be selected from any page
with the Direct-to Key.
Selecting a direct-to destination:
1) Press the Direct-to Key. The Select Direct-to
Waypoint Page appears with the destination
field highlighted.
2) Turn the small right knob to enter the first
letter of the destination waypoint identifier.
The destination waypoint may be an airport,
VOR, NDB, intersection, or user waypoint,
as long as it is in the database or stored in
memory as a user waypoint.
3) Turn the large right knob to the right to move
the cursor to the next character position.
4) Repeat steps 2 and 3 to spell out the rest of
the waypoint identifier (Figure 1-14).
Figure 1-14 Direct-to Waypoint Page
1-10
GPS 400 Pilot’s Guide and Reference
190-00140-60 Rev. H
SECTION 1
INTRODUCTION
5) Press the ENT Key to confirm the identifier. The
‘Activate?’ function field is highlighted (Figure
1-15).
Figure 1-15 ‘Activate?’ Highlighted
6) Press the ENT Key to activate a direct-to course
to the selected destination.
Once a direct-to destination is selected, press and hold
the CLR Key to display the Default NAV Page.
Default NAV Page
During most ights, the Default NAV Page, the Map
Page, and the NAV/COM Page are the primary pages used
for navigation.
Selecting the Default NAV Page:
Press and hold the CLR Key (Figure 1-16).
Active Leg of
Flight Plan
TO/FROM Flag Course Deviation
Indicator (CDI)
The Default NAV Page displays a graphic course
deviation indicator (CDI), the active leg of the flight plan
(as dened by the current ‘from’ and ‘to’ waypoints), and
six user-selectable data fields. The default settings for
these fields are distance to waypoint (DIS), desired track
(DTK), bearing to waypoint (BRG), ground speed (GS),
ground track (TRK), and estimated time enroute (ETE).
See Section 12.3 for definitions of these navigation terms.
Changing the data fields:
1) From the Default NAV page, press the MENU
Key and select ‘Change Fields?’ (Figure 1-17).
Figure 1-17 Default NAV Page Menu
2) Turn the large right knob to select the data
field to be changed.
3) Turn the small right knob to display a list of
data options (Figure 1-18).
Figure 1-16 Default NAV Page
190-00140-60 Rev. H
User-selectable
Data Fields
Figure 1-18 ‘Select Field Type’ Window
4) Press the ENT Key to select the desired data
item and return to the Default NAV Page.
GPS 400 Pilot’s Guide and Reference
1-11
SECTION 1
INTRODUCTION
NAV/COM Page
From the Default NAV Page, simply turn the small
right knob until the NAV/COM Page (Figure 1-19) is
displayed.
Departure, Enroute, or
Arrival Airport
Frequency Type
Figure 1-19 NAV/COM Page
The NAV/COM Page displays the available frequencies
(communication and navigation frequencies are shown
for reference only) for the departure airport, any enroute
airports which are included in the flight plan, and the final
destination airport. When using the direct-to function,
frequencies are listed for the airport nearest to the starting
position and the destination airport.
Frequency List
Displaying the frequency list for the
desired flight plan or direct-to airport:
1) Press the small right knob to activate the
cursor on the airport identifier field (in the GPS
Window).
2) Turn the small right knob to display the list
of airports (departure, arrival, and enroute) for
the flight plan or direct-to. Continue to turn
the small right knob until the desired airport
is selected.
3) Press the ENT Key to display the frequency list
for the selected airport.
Displaying frequencies for a different
airport along the flight plan.
1) Press the small right knob to highlight the
airport identifier field.
2) Turn the small right knob to display the list of
airports within the flight plan (Figure 1-20).
1-12
3) Continue turning the small right knob to select
the desired airport and press the ENT Key.
GPS 400 Pilot’s Guide and Reference
Figure 1-20 Airport Window
190-00140-60 Rev. H
SECTION 1
INTRODUCTION
IFR Procedures
Once the direct-to or ight plan is conrmed, the whole
range of instrument procedures is available to the pilot.
Departures (SIDs), arrivals (STARs), and non-precision
and precision approaches are stored within the NavData
Card and are available using the PROC (procedures) Key.
Displaying the Procedures Page:
Press the PROC Key (Figure 1-21).
Figure 1-21 Procedures Page
This introductory section shows examples of the steps
required to select and activate a departure, arrival, or an
approach.
Selecting a departure, arrival, or an
approach:
1) Turn the large right knob to select the desired
option (‘Select Departure?’, ‘Select Arrival?’
or ‘Select Approach?’) from the Procedures
Page.
4) For approaches, a window appears (Figure
1-22) to select the desired initial approach
fix (IAF) or provide a ‘vectors’ option to select
just the final course segment of the approach.
Turn the small right knob to select the desired
option and press the ENT Key. The ‘vectors’
option extends the final inbound course beyond
the final approach fix, allowing the pilot to
intercept the final course segment beyond its
normal limits.
Figure 1-22 Approach Window
5) For departures and arrivals, a window appears
to select the desired transition. Turn the small
right knob to select the desired option and
press the ENT Key.
In the flight plan or direct-to, the departure or arrival
airport is replaced with the sequence of waypoints
contained within the selected procedure.
2) Press the ENT Key to display a list of available
procedures for the departure (when using SIDs)
or arrival (when using approaches or STARs)
airport.
3) Turn the small right knob to select the desired
procedure and press the ENT Key.
190-00140-60 Rev. H
GPS 400 Pilot’s Guide and Reference
1-13
SECTION 1
INTRODUCTION
Nearest (NRST) Pages
The NRST Page Group provides detailed information
on the nine nearest airports, VORs, NDBs, intersections,
and user-created waypoints within 200 nm of the current
position. In addition, pages are also provided to display
the ve nearest center (ARTCC/FIR) and Flight Service
Station (FSS) points of communication, plus alert the
pilot to any nearby special-use or controlled airspaces.
There are eight pages available in the NRST group:
• Nearest Airport Page
• Nearest NDB Page
• Nearest User Waypoint Page
• Nearest FSS Page
• Nearest Intersection Page
• Nearest VOR Page
• Nearest ARTCC Page
• Nearest Airspace Page
The communication frequencies and runway
information may both be examined directly from the
Nearest Airport Page.
Displaying the NRST pages:
1) Press the NRST Key to select the Nearest
Airport Page (Figure 1-23).
2) Turn the small right knob to select the desired
NRST Page.
Displaying a list of nearby airports:
1) Press the NRST Key to select the Nearest
Airport Page (Figure 1-23).
Figure 1-23 Nearest Airport Page
2) To scroll through the list, press the small right
knob, then turn the large right knob (Figure
1-24).
1-14
Figure 1-24 Scrolling the Nearest Airport List
GPS 400 Pilot’s Guide and Reference
190-00140-60 Rev. H
SECTION 1
INTRODUCTION
Viewing additional information for a
nearby airport:
1) Press the small right knob to activate the
cursor.
2) Turn the large right knob to select the desired
airport from the list.
3) Press the ENT Key to display waypoint (WPT)
information pages for the selected airport
(Figure 1-25).
Figure 1-25 Airport Location Page
4) To display runway and frequency information,
press the small right knob to remove the
cursor and turn the small right knob to display
the desired information page.
The Nearest Airport Page may be used in conjunction
with the Direct-to Key to quickly set a course to a nearby
facility in an in-flight emergency. Selecting a nearby
airport as a direct-to destination overrides the flight plan
or cancels a previously selected direct-to destination. The
pilot will still have the option of returning to the flight
plan by cancelling the direct-to; see Section 3.1, Cancelling
Direct-to Navigation.
Selecting a nearby airport as a direct-to
destination from the Nearest Airport Page:
1) Press the small right knob to activate the
cursor.
2) Turn the large right knob to select the desired
airport from the list.
3) Press the Direct-to Key.
4) Press the ENT Key twice to navigate to the
nearby airport.
Selecting a nearby airport as a direct-to
destination from the Airport Information
Page:
1) Press the Direct-to Key.
2) Press the ENT Key (Figure 1-26).
Figure 1-26 ‘Activate?’ Highlighted
3) Press the ENT Key again to navigate to the
nearby airport.
190-00140-60 Rev. H
GPS 400 Pilot’s Guide and Reference
1-15
SECTION 1
INTRODUCTION
Nearest (NRST) Airspace Page
The last page in the NRST Page Group, the Nearest
Airspace Page (Figure 1-27), provides information for
up to nine controlled or special-use airspaces near or in
the flight path. Airspace information appears on this
page based on the same criteria used for airspace alert
messages:
• If the projected course will take the aircraft inside
an airspace within the next ten minutes, the
message ‘Airspace ahead -- less than 10 minutes’
appears.
• If the aircraft is within 2 nm of an airspace and
the current course will take the aircraft inside, the
message ‘Airspace near and ahead’ appears.
• If the aircraft is within 2 nm of an airspace and
the current course will not take the aircraft inside,
the message ‘Near airspace less than 2nm’ appears.
• If the aircraft has entered an airspace, the message
‘Inside airspace’ appears.
Figure 1-27 Nearest Airspace Page
By default, airspace alert messages are turned off.
When turned on, the message (MSG) annunciator located
directly above the MSG Key flashes to alert the pilot to
the airspace message. See Section 8.4, Setup 1 Page:
Airspace Alarms for information on enabling airspace alert
messages.
Viewing an airspace alert message:
1) Press the MSG Key. The Messages Page appears
with the alert message (Figure 1-28).
Figure 1-28 Message Page
2) Press the MSG Key again to return to the
previous display.
Note that the airspace alerts are based upon threedimensional data (latitude, longitude, and altitude) to
avoid nuisance alerts. The alert boundaries for controlled
airspace are also sectorized to provide complete information
on any nearby airspace. Additional information about a
nearby airspace (such as controlling agency, frequency, and
oor/ceiling limits) is available from the Nearest Airspace
Page (Section 7.9).
1-16
Viewing additional airspace information:
1) Press the small right knob to activate the
cursor.
2) Turn the large right knob to select the desired
airspace from the list.
3) Press the ENT Key to view the airspace
information.
GPS 400 Pilot’s Guide and Reference
190-00140-60 Rev. H
SECTION 1
INTRODUCTION
Flight Plans (FPL)
The GPS 400 lets the pilot create up to 20 flight plans,
with up to 31 waypoints in each flight plan. Flight plans
are created, edited, and activated using the FPL Key. The
FPL Page Group includes two pages: the Active Flight Plan
Page and the Flight Plan Catalog Page (Figures 1-29 and
1-30). The Active Flight Plan Page provides information
and editing features for the flight plan currently in use
(referred to as ‘ight plan 00’). The Flight Plan Catalog
Page serves as the main page for creating new flight plans,
as well as editing or activating previously created flight
plans.
Figure 1-29 Active Flight Plan Page
Since using flight plans is arguably one of the more
complex features of the GPS 400, it will only be discussed
briefly here, with focus on creating a new flight plan and
activating it to use for navigation. After reading through
this brief introduction, answers to additional questions
about flight plans can be found in Section 4, Flight Plans.
Creating a new flight plan:
1) Press the FPL Key.
2) Turn the small right knob to select the Flight
Plan Catalog Page.
3) Press the MENU Key to display the Flight Plan
Catalog Page Menu (Figure 1-31).
Figure 1-31 Flight Plan Catalog Page Menu
Figure 1-30 Flight Plan Catalog Page
190-00140-60 Rev. H
4) Turn the large right knob to select ‘Create New
Flight Plan?’ and press the ENT Key.
5) The cursor appears on the first waypoint identifier
field (located directly below ‘WAYPOINT’). Use
the large and small right knobs to enter the
identifier of the first waypoint in the flight plan.
(The small knob is used to select the desired
letter or number and the large knob is used to
move to the next character space.)
6) Press the ENT Key once the identifier has been
selected. The cursor moves to the next blank
waypoint identifier field.
GPS 400 Pilot’s Guide and Reference
1-17
SECTION 1
INTRODUCTION
7) Repeat steps 5 and 6 until all waypoints for the
flight plan have been entered (Figure 1-32).
Figure 1-32 Enter Flight Plan Waypoints
Once the ight plan is created, it may be activated from
the Flight Plan Catalog Page Menu. Activating the ight
plan places it into ‘flight plan 00’ (a copy of it still resides
in the original catalog location) and replaces any ight
plan which currently exists in ‘ight plan 00’.
Activating the new flight plan:
1) Press the MENU Key to display the Flight Plan
Catalog Page Menu.
2) Turn the small right knob to select ‘Activate
Flight Plan?’ (Figure 1-33) and press the ENT
Key
Figure 1-33 Flight Plan Catalog Page Menu
1-18
GPS 400 Pilot’s Guide and Reference
190-00140-60 Rev. H
SECTION 2: NAV PAGES
2.1 MAIN PAGE GROUPS
SECTION 2
NAV PAGES
The GPS 400’s main pages are divided into four
separate page groups: NAV, WPT, AUX, and NRST (Table
2-1). Each page group is comprised of multiple pages.
The page groups are selected using the large right knob.
The individual pages are selected using the small right
knob.
Page Groups
NAV Group WPT Group AUX Group NRST Group
7 NAV Pages see Section 6 see Section 8 see Section 7
Table 2-1 Page Groups
The bottom right corner of the screen (Figure 2-1)
indicates which page group is currently being displayed
(e.g., NAV, WPT, AUX, or NRST), the number of pages
available within that group (indicated by the square icons)
and the placement of the current page within that group
(indicated by a highlighted square icon).
The bottom right corner of the screen is also used to
display the GPS 400’s turn advisories (‘Turn to 230°’) and
waypoint alerts (‘Next DTK 230°’) during flight plan and
approach operations. See Section 5 for more information.
Position of
Current Page
within Current
Page Group
Current Page Group
Figure 2-1 Current Page and Page Group
Number of Pages in
Current Page Group
Selecting the desired page group (from any
page):
Press and hold the CLR Key to select the
Default NAV Page. Turn the large right knob
to select the desired page group (Table 2-1 and
Figure 2-1).
Selecting the desired page within the
group:
Turn the small right knob to select the desired
page (Figures 2-1 and 2-2).
190-00140-60 Rev. H
GPS 400 Pilot’s Guide and Reference
2-1
SECTION 2
Default NAV
Map
TERRAIN
NAV/C O M
Position
Satellite Status
VNA V
(if configured)
NAV PAGES
2.2 NAV PAGE GROUP
The NAV Page Group includes seven pages (Figure
3-2). While viewing any NAV page, turn the small right
knob to select a different NAV page. The pilot may
find this selection process convenient to cycle between
the Default NAV Page and the Map Page, two of the
most frequently used pages. Other pages are provided
for terrain information, (if congured for TERRAIN) to
list frequencies for the flight plan, to show the current
position, to display current satellite reception, and to
make vertical navigation settings.
Figure 2-2 NAV Pages
NOTE: The NAV Page Group may have eight or
nine NAV pages available when the GPS 400
installation includes connection to traffic and/or
weather information sources. See Section 10 of
this manual for more information.
2.3 DEFAULT NAV PAGE
The rst NAV page is the Default NAV Page (Figure
2-3). This page may be quickly selected from any page by
pressing and holding the CLR Key.
Active Leg of Flight Plan
TO/FROM Flag
User-selectable
Data Fields
Current Page Group
Figure 2-3 Default NAV Page
The Default NAV Page displays a graphic course
deviation indicator (CDI) across the top of the page.
Unlike the angular limits used on a mechanical CDI
coupled to a VOR or ILS receiver, full scale limits for this
CDI are dened by a GPS-derived distance (0.3, 1.0, or
5.0 nm), as indicated at both ends of the CDI. By default,
the CDI scale automatically adjusts to the desired limits
based upon the current phase of flight: enroute, terminal
area, or approach. The pilot may also manually select the
desired scale setting as outlined in Section 8.4.
The graphic CDI shows the aircraft’s position at the
center of the indicator, relative to the desired course (the
moving course deviation needle). As with a traditional
mechanical CDI, when off course simply steer toward the
needle. The TO/FROM arrow in the center of the scale
indicates whether the aircraft is heading TO (up arrow)
the waypoint or FROM the waypoint (down arrow).
Course Deviation
Indicator (CDI)
Position of
Current Page
within Current
Page Group
Number of Pages in
Current Page Group
2-2
GPS 400 Pilot’s Guide and Reference
190-00140-60 Rev. H
SECTION 2
NAV PAGES
NOTE: The GPS 400 always navigates TO a
waypoint unless the OBS switch is set (preventing
automatic waypoint sequencing), or the aircraft
has passed the last waypoint in the flight plan.
Directly below the CDI appears the active leg of the
flight plan, or the direct-to destination when using the
Direct-to Key. This automatically sequences to the next
leg of the flight plan as the aircraft reaches each interim
waypoint. If no flight plan or direct-to destination has
been selected, the destination field remains blank.
The symbols in Table 2-2 are used on the Default NAV
Page (directly below the CDI), to depict the ‘active leg’ of
a flight plan or direct to:
Symbol Description
Direct-to a Waypoint
Course to a Waypoint, or Desired Course
between Two Waypoints
Procedure Turn
Procedure Turn
Vectors-to-Final
Selecting Desired On-Screen Data
At the bottom of the Default NAV Page there are six
user-definable fields which display the data needed as
the ight progresses (Figure 2-3). By default these elds
display: distance to destination (DIS), desired track
(DTK), bearing to destination (BRG), ground speed (GS),
ground track (TRK) and estimated time enroute (ETE).
However, each of these elds can be customized to display
a different data item. Available data items include:
• Bearing to destination (BRG)
• Course to steer (CTS)
• Cross track error (XTK)
• Desired track (DTK)
• Distance to destination (DIS)
• Enroute safe altitude (ESA)
• Estimated time of arrival (ETA)
• Estimate time enroute (ETE)
• Fuel ow (FLOW) (when congured)
• Ground speed (GS)
• Ground track (TRK)
DME Arc to the Left
DME Arc to the Right
Left-hand Holding Pattern
Right-hand Holding Pattern
Table 2-2 NAV Page Symbols
190-00140-60 Rev. H
• Minimum safe altitude (MSA)
• Track angle error (TKE)
• Vertical speed required (VSR)
If no flight plan or direct-to destination has been
selected, only speed, track, altitude, and minimum safe
altitude data may be displayed. All other data types appear
as blank lines on the Default NAV Page until a destination
is selected.
GPS 400 Pilot’s Guide and Reference
2-3
SECTION 2
NAV PAGES
Selecting a different data item for any data
field:
1) Starting with the Default NAV Page, press the
MENU Key to display the Default NAV Page
Menu (Figure 2-4).
Figure 2-4 Default NAV Page Menu
2) The ‘Change Fields?’ option is already
highlighted, so press the ENT Key to select
this option.
3) Use the large right knob to highlight the data
field to be changed (Figure 2-5).
4) Turn the small right knob to display the list
of available data items (Figure 2-6). Continue
turning the small right knob to select the
desired data item from the list.
Figure 2-6 Select Field Type Window
5) Press the ENT Key to select the desired data
item and return to the Default NAV Page.
6) Press the small right knob momentarily to
remove the cursor from the page.
2-4
Figure 2-5 ‘DIS’ Field Highlighted
GPS 400 Pilot’s Guide and Reference
190-00140-60 Rev. H
