Garmin 2001.2101 Quick Reference
R
Apollo NMS 2001/2101
Quick Reference Guide
How To Use This Guide
SEL
Press the button shown
Turn the Data (small) knob
Turn the Control (large) knob
Selecting Position Sensor For Navigation
NAV
ENT
Accesses Navigation Mode
Turn Large knob to display
Latitude/Longitude page.
Turn Small knob to display
the sensor to be used.
Press SEL to select for use.
SEL
Press ENT to verify sensor.
GPS IN USE(A)
45 11.87 PDOP
122 53.30 0.0
LORAN STANDBY
36 11.90
0 95 53.28
GPS USE?
36 11.90
D
ENT
Direct-TO Navigation
Accesses Direct-TO feature
Use Large and Small knobs
to retrieve your desired
destination waypoint.
Press ENT to verify
destination waypoint
0 95 53.28
LIT AIRPORT
LITTLE ROCK
CITY AR USA
ETE LIT 00:53
BRG134 91.5NM
Flight Plan Entry
FPL
SEL
ENT
SEL
ENT
Accesses Flight Plan Mode
Turn Large knob to the
"Create a New Flight Plan"
display.
Press SEL to begin.
Use Large and Small knobs
to name flight plan.
Press ENT to enter flight
plan name.
Turn Small knob clockwise
one click. Press SEL and
ENT to insert waypoint and
access waypoint retriever.
PRESS SEL TO
CREATE A NEW
FLIGHT PLAN
________
ENTER A NEW
PLAN NAME
______ TO_____
1 PRESS SEL
TO EDI T LEG
ENT
SEL
FPL
Retrieve first waypoint
using Large and Small
knobs.
Continue with ENT and
rotary knobs until last
waypoint has been inserted.
After last waypoint has
been retrieved and entered,
press SEL.
Activate A Flight Plan
Accesses Flight Plan Mode.
Turn Large knob to display
desired flight plan.
HOU AIRPORT
HOUSTON
CITY TX USA
MSP TO INS?
4___ __._NM
LEG ETE? __:__
TRIP 1 930NM
HOU TO MSP
INACTIVE
SEL
ENT
Press SEL and ENT
buttons to activate.
For more detailed information on using the Flight Plan see Flight Plan Mode
in the NMC 2001 Operation Manual.
