Garmin 120 User Manual

®

120

2-way radio & personal navigator

owner’s manual

®

© Copyright 2002–2006 Garmin Ltd. or its subsidiaries

Garmin International, Inc.
1200 East 151st Street
Olathe, Kansas 66062, U.S.A.
Tel. [phone] or 800/800.1020
Fax [phone]

All rights reserved. Except as expressly provided herein, no part of this manual may be reproduced, copied, transmitted, disseminated,
downloaded or stored in any storage medium, for any purpose without the express prior written consent of Garmin. Garmin hereby grants
permission to download a single copy of this manual onto a hard drive or other electronic storage medium to be viewed and to print one copy
of this manual or of any revision hereto, provided that such electronic or printed copy of this manual must contain the complete text of this
copyright notice and provided further that any unauthorized commercial distribution of this manual or any revision hereto is strictly prohibited.

Information in this document is subject to change without notice. Garmin reserves the right to change or improve its products and to make
changes in the content without obligation to notify any person or organization of such changes or improvements. Visit the Garmin Web site
(www.garmin.com) for current updates and supplemental information concerning the use and operation of this and other Garmin products.

Garmin®, AutoLocate®, Personal Navigator®, MapSource®, TracBack®, BlueChart®, and Rino® are registered trademarks of Garmin Ltd. or its
subsidiaries and may not be used without the express permission of Garmin.

March 2006 Part Number 190-00418-00 Rev. C Printed in Taiwan

Garmin (Europe) Ltd.
Unit 5, The Quadrangle
Abbey Park Industrial Estate
Romsey, SO51 9DL, U.K.
Tel. [phone]
Fax [phone]

Garmin Corporation
No. 68, Jangshu 2nd Road
Shijr, Taipei County, Taiwan
Tel. [phone]
Fax [phone]

INTRODUCTION

INTRODUCTION

Thank you for choosing the Garmin® Rino® 120 (Radio
Integrated with Navigation for the Outdoors). To get the

most from your new Rino 120, read through the Quick
Start Guide first, then this Owner’s Manual to understand

all of the operating features.

The Quick Start Guide describes the process of setting
up your Rino 120 and some basic unit operations to
familiarize you with your new Rino 120 right out of the
box. The small size of the guide makes it perfect to take
with you!

This Owner’s Manual describes the Main Pages of the
Rino 120 and their options in detail. While the Owner’s
Manual provides some direction on how to select and
change items, its main intention is to describe each Main
Page, Option Menu, and feature in detail.

Rino® 120 Owner’s Manual i

This manual is organized into the following sections:

The Introduction section provides the Table of Contents
and safety information.

The Getting Started section provides basic information
about the Rino 120.

The Unit Operation section provides information on
each of the five Main Pages, listed in the same order as
viewed on the unit. The section for each Page provides
an overview that discusses the page, how it functions,
and step-by-step instructions for using the page and its
features. It also includes an overview of some additional
features and step-by-step instructions for using the
features.

The Appendix includes additional information about the
Rino 120.

The Index provides keywords and the pages on which
they appear.

INTRODUCTION > TABLE OF CONTENTS

Introduction .............................................................i

Getting to Know Your Rino 120 ............................

Front of the Rino 120 ...............................................2

Back of the Rino 120 ................................................3

Main Page Sequence ................................................ 4

Operating the Rino 120 ............................................5

Status Bar Overview ................................................6

Understanding GPS .................................................7

1

Unit Operation ........................................................8

Radio Page ................................................................ 8

Initializing the Rino 120 ................................................ 8

Using My ID and Symbol Fields ................................... 9

Setting the Channel and Squelch Code ........................ 11

Scanning and Monitoring ............................................ 13

Radio Page Option Menu ............................................ 15

Setup Radio ............................................................ 15

Setup Tones ............................................................ 17

Setup Scanlist ......................................................... 17

Turn Radio/GPS On/Off ........................................ 17

Informational Picture ................................................... 18

GPS Status ............................................................. 18

Radio Transmission Status .................................... 18

ii Rino® 120 Owner’s Manual

Mark Waypoint’s Indicators ...................................

Using the Rino 120 Radio Features ......................20

Peer-to-Peer Positioning .............................................. 20

New Contact Page Overview ....................................... 20

Sending a Location ...................................................... 23

Map Page ................................................................. 24

Map Page Options ....................................................... 26

Using the Pan Map Option .......................................... 27

Programming the Data Fields ...................................... 28

Data Field Options ................................................. 28

Setting up the Map ....................................................... 29

General Setup ......................................................... 30

Tracks Setup ........................................................... 30

Map Features Setup ................................................ 30

Text Setup .............................................................. 31

Map Data Setup ...................................................... 31

Measuring Distance ..................................................... 31

Navigation Page .....................................................32

Using the Navigation Page .......................................... 32

Navigation Page Options ............................................. 34

Trip Computer Page ...............................................35

Trip Computer Page Options ....................................... 35

Main Menu Page ..................................................... 36

19

INTRODUCTION > TABLE OF CONTENTS

Using the Main Menu .................................................. 36

Main Menu Options ..................................................... 38

Page Sequence Setup ............................................. 38

Shortcuts Menu ...................................................... 39

Waypoints ............................................................... 40

Mark Waypoint Page ................................................... 40

Creating Waypoints ..................................................... 41

Projecting a Waypoint .................................................. 42

Editing a Waypoint ......................................................42

Find ‘N Go ............................................................... 44

Finding a Waypoint ...................................................... 45

Finding a Contact ......................................................... 47

Finding a City .............................................................. 48

Finding an Exit ............................................................ 49

Finding a Point of Interest ........................................... 50

Finding an Address or Intersection .............................. 52

Finding a Last Found Place ......................................... 54

Sending a Note ....................................................... 55

Using a Goto ...........................................................56

Route Page .............................................................. 57

Creating and Using a Route ......................................... 57

Editing a Route ............................................................ 58

Adding or Editing from the Route Map Page .............. 61

Rino® 120 Owner’s Manual iii

Navigating a Route ...................................................... 62

Stopping Navigation .................................................... 63

Data Fields for the Route Page .................................... 63

Data field options for Route Page: ......................... 63

Tracks Page ............................................................ 64

Using the TracBack Feature ........................................ 65

Setting up the Track Log ............................................. 66

Proximity Page .......................................................67

Satellite Page ..........................................................68

Sky View graphic ................................................... 68

WAAS .......................................................................... 69

Satellite Strength .................................................... 69

Satellite Page Options .................................................. 70

Setup Pages ............................................................ 72

Time Setup Page .......................................................... 72

Units Setup Page .......................................................... 73

LORAN TD Format ..................................................... 74

Display Setup Page ...................................................... 75

Heading Setup Page ..................................................... 76

Interface Setup Page .................................................... 77

System Setup Page ....................................................... 79

Calendar ..................................................................80

Alarm Clock ............................................................82

INTRODUCTION > TABLE OF CONTENTS

Calculator ................................................................ 83

Stopwatch ............................................................... 84

Stopwatch Lap Options ............................................... 84

Sun & Moon ............................................................85

Hunt & Fish ............................................................. 86

Area Calculator ....................................................... 87

Games .....................................................................88

Memory Race .............................................................. 88

Waypoint Bomber ........................................................ 89

Clothesline ................................................................... 90

Assimilation ................................................................. 90

Beast Hunt ................................................................... 90

Appendix ..............................................................91

Specifications .........................................................91

Physical ........................................................................ 91

Performance ................................................................. 91

Radio ............................................................................ 92

Power ........................................................................... 92

Accessories ............................................................ 93

Transferring MapSource Data ...............................94

What is FRS? .......................................................... 96

FRS Features ................................................................ 96

FRS Limitations ........................................................... 97

iv Rino® 120 Owner’s Manual

GMRS .......................................................................... 97

GPS Troubleshooting Guide ................................. 98

Radio Troubleshooting Guide ............................... 99

FRS Frequency Chart ........................................... 100

GMRS Frequency Chart .......................................101

CTCSS Frequency Chart ...................................... 102

Data Field Definitions ........................................... 103

Interface Information ............................................ 105

FCC Compliance Information .............................. 106

FCC Licensing Information .................................107

Limited Warranty ..................................................108

Software License Agreement .............................. 110

Product Registration ............................................ 110

Contact Garmin .......................................................... 110

Warnings and Cautions ....................................... 111

Index ...................................................................114

GETTING STARTED > GETTING TO KNOW YOUR RINO 120

GETTING TO KNOW YOUR RINO 120

you to save up to 20 tracks with up to 250 points per
track. The unit contains built-in cartography of a North

The Rino 120 (Radio Integrated with Navigation for
the Outdoors) is a 7.6 ounce, 12-channel, GPS-enabled
handheld device. It also has integrated radio functionality
to provide two-way communications for up to two
miles using 14 FRS (Family Radio Service) channels.
The Rino 120 also provides eight high-performance
GMRS (General Mobile Radio Service) channels and
eight GMRS repeater channels for up to five miles.
GMRS repeater channels are not approved for use by the
Canadian government, so they are disabled on Rino 120

American basemap that includes Interstate and State
Highways and Exit Information. Using MapSource®,
Garmin’s map data software (not included), the Rino 120
could display up to 8 MB of a variety of different map
information. We currently offer several mapping options
that are compatible with the Rino 120 including our
MetroGuide®, Topo, Fishing Hot Spots, and BlueChart

®

data. Check your local dealer or the Garmin Web site
(www.garmin.com) for a complete listing of MapSource
products.

units sold in Canada.

Garmin designed your Rino 120 with you, the user, in

You can transmit your GPS position to other Rino
users on FRS and GMRS bands with the peer-to-peer
positioning feature, as well as receive other Rino users’
locations, manually poll GPS locations from other
Rino users, and keep track of up to 50 contacts from
Rino users. The Rino 120 stores up to 500 waypoints
with a 10-character name and graphic symbol. The
active track log stores up to 2,048 points and allows

Rino® 120 Owner’s Manual 1

mind. The Rino 120 is
standards and is rugged enough to endure the most trying
use. Garmin’s user-friendly interface allows you to start
navigating with your new GPS in no time. With your
Rino 120 you know where you are, where you’ve been,
and where you’re going. And since you’ll always know
the way back home, you can concentrate on what you set
out to do: explore the great outdoors.

waterproof to IEC 60529 IPX7

GETTING STARTED > FRONT OF THE RINO 120

Front of the Rino 120

LCD Display

Power button:

• Press and hold to turn the unit On/Off

• Press to adjust contrast and backlighting

Call button:

• Press to send out Call Tone

• Sends position when released
(if enabled)

Talk button:

• Press and hold to talk

• Sends position when released
(if enabled)

Page/Quit button:

• Press to cycle through main pages

• Used to quit or escape menu items

Volume (V) button:

• Press to open volume control window

Speaker

2 Rino® 120 Owner’s Manual

• Press IN to enter highlighted options and to
confirm messages

• Move UP, DOWN, RIGHT or LEFT to move
through lists, highlight fields,
on-screen buttons, icons, enter
data, or move the map panning
arrow

• Press IN and hold to display Shortcuts Menu.

• From the Map Page, press to open Zoom
control window

• From any other page, press to display Map
Page and press again to open Zoom control

• Hold unit 3-4 inches away when talking

Thumb Stick

Zoom/Map (Z) button:

Microphone:

Back of the Rino 120

GETTING STARTED > BACK OF THE RINO 120

2-way FRS/GMRS Antenna

Belt Clip Connector Mount

Headset Connector with

Weather cap

Mount Alignment Notches

Rino® 120 Owner’s Manual 3

GPS Antenna

External Power And

Data Connector with

Weather cap

Battery Compartment D-Ring

Battery Compartment Cover

GETTING STARTED > MAIN PAGE SEQUENCE

Main Page Sequence

All of the information you need to operate the Rino 120 can be found on five default main pages (or display screens).
Press and release the Page key to cycle through the Radio Page, Map Page, Navigation Page, Trip Computer, and Main
Menu Page. You can also access the Main Pages by pressing the on-screen Main Page button . Customize the Main
Page sequence through the Main Menu (refer to the “Main Menu Page” section later in this guide).

Radio Page

Main Menu

4 Rino® 120 Owner’s Manual

Map Page

Navigation Page

Trip Computer

GETTING STARTED > OPERATING THE RINO 120

Operating the Rino 120

For best results, you should initialize the GPS receiver in
your Rino 120 unit before you use it the first time. Refer
to the “Initializing the Rino 120” section later in this
manual for instructions on initializing the unit.

The Rino 120 is programmed to provide “pop-up”
messages concerning operational characteristics and
conditions. Press the Thumb Stick In to acknowledge a
message and return to the current feature.

To use the

• Press In to enter highlighted options and to
confirm messages

• Move Up, Down, Right or Left to move through
lists, highlight fields, on-screen buttons, icons,
enter data, or move the map panning arrow

• Press In and hold to display the Shortcuts Menu.

Thumb Stick:

2. Highlight the desired menu option and press the
Thumb Stick In to activate the option.

3. To close without making a selection, move the

Thumb Stick to the Right.

To lock/unlock the keys:

1. Press and hold the Thumb Stick In to access the
Shortcuts Menu. Highlight Enable Keylock and
press the Thumb Stick In. The Talk key is now
locked.

2. To unlock, press and hold the Page key until
“Keylock Disabled” is displayed (about 5 seconds).

Keylock Pop-up Message

To use the page Option Menu:

1. Highlight the Option Menu on-screen button
at the top of the display screen and then press the
Thumb Stick In to open the menu.

Rino® 120 Owner’s Manual 5

GETTING STARTED > STATUS BAR OVERVIEW

Status Bar Overview

The Status Bar at the top of the screen displays on all

Transmitting Radio signal

Backlight On

the available Main Pages. As you move around any of
the Main Pages, the current page’s title briefly displays
(3 seconds) and then is replaced by the Status Bar. The
current settings and operational icons on the Status Bar
are displayed as you use your Rino. The icons you may
see are shown and described below:

Option Menu button

Status Bar

Main Page Menu

button/ Exit button

Radio On

Peer-To-Peer On/Location Ready to Send

Keylock On

Alarm Clock On

GPS On, Position Ready

GPS On, Position Not Ready

New batteries installed

Batteries are about 1/2 discharged

Batteries are fully discharged.

Install new batteries or recharge batteries.

Using External Power

Receiving Radio signal

6 Rino® 120 Owner’s Manual

GETTING STARTED > UNDERSTANDING GPS

Understanding GPS

The Global Positioning System (GPS) consists of 24
satellites that circle the earth twice a day in a very precise
orbit and transmit information to Earth. The Rino 120
must continuously “see” at least three of these satellites
to calculate your location and track your movement. If
some of the satellites in view get blocked or “shaded,” the
receiver simply uses an alternate satellite to maintain the
location fix.

Because the Rino 120 relies on satellite signals to provide
you with navigation guidance, the receiver needs to
have an unobstructed, clear view of the sky for best
performance. In a nutshell, the GPS receiver’s view of the
sky generally determines how fast you get a location fix
or if you get a fix at all. GPS signals are relatively weak
and do not travel through rocks, buildings, people, or
metal: So, remember to keep a clear view of the sky at all
times for best performance.

Rino® 120 Owner’s Manual 7

Your Rino 120 needs to be given the opportunity to find
or AutoLocate itself: This is also called initializing the
receiver or unit.

Longer initialization (AutoLocate) is only necessary:

• The first time you use your Rino 120 (new from the
factory).

• After the receiver has been moved over 500 miles
with the power off from the last time you used it.

Once you initialize the unit to a location, it typically
computes a fix within a couple minutes.

Visit the Garmin Web site at
information on GPS.

www.garmin.com for more

UNIT OPERATION > RADIO PAGE

UNIT OPERATION

Initialization is automatic and should only take a few
minutes.

Radio Page

The Radio Page is the first of the default Main Pages.
This page provides the user interface for FRS (Family
Radio Service) and GMRS (General Mobile Radio
Service) radio operations. Garmin Rino units work
with 3rd party FRS/GMRS radios, provided the other
radios use standard FRS/GMRS frequencies. To take full
advantage of the Rino features, communicate with other
Rino users.

To

initialize the unit (acquire satellites):

1. Take the Rino 120 outside where it has an
unobstructed view of the sky and turn it on.

2. The unit begins to search for satellite signals.
“Tracking Satellites” is displayed while the unit is
initializing.

3. Initialization should take no more than five
minutes. When the GPS is initialized and ready
for navigation, the message “3D Accuracy” is
displayed on the Radio Page.

Also use the Radio Page to control and setup the radio,
view current settings, and see informational graphics of
the unit’s operation.

Initializing the Rino 120

To take full advantage of all of the Rino 120 features,
the GPS receiver must be initialized. The initialization
process allows the Rino 120 to receive and store satellite
information and begin using the satellites for navigation.

8 Rino® 120 Owner’s Manual

Radio Page

UNIT OPERATION > RADIO PAGE

Using My ID and Symbol Fields

3. To enter a new ID, use the

The My ID field allows you to enter a name and symbol
that appears on other Rino units as you communicate with
them. You may enter a name using a combination of up to
10 letters, numbers, or spaces. The Symbol field allows
you to choose a face icon (symbol) from a list to further

the cursor to the desired character (letter, number,
or a space). Press the Thumb Stick In to select
that highlighted character. Choose Back to delete
the character to the left of the cursor. You may
enter up to 10 characters for your ID.

Thumb Stick to move

personalize your ID.

Entering a name

My ID Field

Symbol

4. When you have entered your new ID, highlight

with the on-screen

keyboard

OK

and press the Thumb Stick In.

To enter a name:

1. Using the Thumb Stick, highlight the My ID field.
Press the Thumb Stick In to activate the field and
display the keyboard.

2. Move the Thumb Stick Up, Down, Left, or Right
to highlight the Clear field, then press the Thumb
Stick In to clear the default Name ID.

Rino® 120 Owner’s Manual 9

UNIT OPERATION > RADIO PAGE

To change the user symbol:

1. Using the Thumb Stick, highlight the face symbol
to the right of the My ID field. Press the Thumb
Stick In to show a list of available face symbols
(icons).

2. Move the Thumb Stick Up or Down to scroll
through the selections. Because not all the
selections can fit in the window, a slider bar on the
right side indicates your current position in the list.

Changing the user symbol

10 Rino® 120 Owner’s Manual

TIP: Hold the Thumb Stick Up or Down to scroll
through the list more quickly. Once you reach the
end of the list, you can “wrap” back to the top or
bottom by releasing the Thumb Stick then pressing
in the same direction again. This same method may
also be used on other selection windows.

3. Once you have highlighted the desired symbol,
press the Thumb Stick In.

Setting the Channel and Squelch Code

The Rino 120 has a total of 22 channels (not including
GMRS repeater channels) and 38 squelch codes to select
from using the Channel and Code fields. Channels 1–14
are FRS channels, 15–22 are GMRS channels (disabled
by default in U.S. units), and 15R–22R are GMRS
repeater channels (U.S. units only, disabled by default).
To communicate with other Rino and FRS/GMRS users,
you must be on the same channel and squelch code.
Garmin Rino units work with 3rd party FRS/GMRS
radios, provided the other radios use standard FRS/
GMRS frequencies. A chart of Rino frequencies can be
found in the “Appendix.”

Squelch codes allow you to hear calls from only specific
persons. Thirty-eight (38) Squelch Codes (also called
Continuous Tone Coded Squelch System or
allow your Rino 120 to ignore unwanted calls from other
persons using the same channel. Be sure everyone you
will communicate with using your Rino has selected the
same squelch code (number).

CTCSS)

UNIT OPERATION > RADIO PAGE

Select from FRS 1–14, GMRS 15–22 (with GMRS
enabled), and 15R–22R GMRS repeater channels

(with GMRS and Repeater Channels enabled;

available in U.S. units only).

NOTE: Squelch codes do not cause your conversa­tion to be private. They only allow you to filter out
other users on the same channel, so you only hear
the radios you want to hear. Squelch Codes are not a
scrambling system!

Rino® 120 Owner’s Manual 11

UNIT OPERATION > RADIO PAGE

Setting the squelch code to 0 (squelch code off) allows
you to hear all activity on the selected channel, but
you must be set to the same squelch code as the other
person(s) to transmit back. See the “Appendix” for a table
listing all of the 38 Squelch Codes and their frequencies.

2. Scroll through the selections and highlight the
desired selection. Because not all the items fit in
the window, a slider bar on the right side indicates
your current position in the list.

3. Once you have highlighted the desired selection,
press the Thumb Stick In.

As you change the main channels, the Rino 120
remembers the last channel/squelch code combination
that you were using. For example, you may set the unit
channel to 5 and squelch code to 21, then change the
main channel to 8 and squelch code to 2. If you change
the channel back to 5, the squelch code changes back to
its previous setting of 21. See the “Appendix” for more
information on FRS/GMRS and its operational aspects.

To change the Channel and/or Squelch Code:

1. Using the Thumb Stick, highlight the Channel
or Code field and then press In to show a list of
available channels/squelch codes.

12 Rino® 120 Owner’s Manual

Choose from 38 squelch codes. Setting the unit
to zero will allow you to hear all transmissions

on that channel, but you must be on the same

squelch code to communicate back.

UNIT OPERATION > RADIO PAGE

Scanning and Monitoring

The Scan option allows you to scan through the available
channels for voice activity. As the unit scans and
receives a signal (or if you transmit), it stops on that
channel/squelch code for a few seconds, then continues
scanning. When the Rino 120 is scanning and it receives
an incoming signal, the Rino 120 automatically decodes
the Squelch Code used by the incoming signal. The Rino
120 then uses that Squelch Code when it transmits back
to that unit.

helps prevent the chances of missing a transmission.
The Scanlist also has Option Menu choices to
Scan Current Codes or Scan All Codes. Choosing Scan
Current Codes scans only the Channel and Squelch Code
combinations in memory.

The Monitor option lets you listen to a single channel
for any activity, including static and weak voice signals.
The Rino series automatically squelches a frequency
to filter out unwanted noise. Using the Monitor option
temporarily turns off the automatic squelch, allowing you
to hear all activity on channel.

The Code field is

blank when the unit is

scanning or monitoring

channels.

If you see a broken transmission symbol ( ), there is
activity on your selected channel, but the incoming signal
does not match the Squelch Code your unit is using.

You may use the Set Scanlist option to pick which
channels/squelch codes to scan. Scanning through the
all the channels can take time: Selecting only specific
channels/squelch codes decreases the scan time and

Rino® 120 Owner’s Manual 13

UNIT OPERATION > RADIO PAGE

To scan or monitor a channel(s):

1. Using the Thumb Stick, highlight the Scan or
Monitor button and then press In. Scan starts

searching through the available channels.
Monitor opens the channel to listen to any radio
transmissions on that channel.

2. To stop using either option, highlight the button
again and press the Thumb Stick In.

3. To begin scanning the codes you selected,
highlight the Option Menu and press the
Thumb Stick In. Choose Scan Current Codes and
press the Thumb Stick In.

To setup a Scanlist:

1. Using the Thumb Stick, highlight the Option
Menu on-screen button and press In.
Highlight Setup Scanlist and press the Thumb
Stick In.

2. To add/remove a channel from the list, highlight
the channel and press the Thumb Stick In to
add/remove the check mark in front of the name.
Only channels that are checked are scanned.

To select all channels or clear all channels, select

either the Select All or Clear All buttons and
press the Thumb Stick In.

14 Rino® 120 Owner’s Manual

The Radio Page Option Menu provides the following:
Setup Radio, Setup Tones, Setup Scanlist, Turn Radio
Off/On, and Turn GPS Off/On. Refer to the following
pages for explanations of each item in the Radio Page
Option Menu.

Scanlist PageRadio Page Option Menu

UNIT OPERATION > RADIO PAGE

Radio Page Option Menu

The Radio Page Option Menu allows you to
customize aspects of your Rino 120, such as setting up
the radio, programming call and ring tones, and setting up
a scanlist.

Setup Radio

The Setup Radio option displays the Radio Setup Page.
This page determines how the radio functions and enables
you to adjust the radio operation to your needs. The
following options are available:

Allow Polling—Enables/disables the Rino 120’s ability
to respond to a poll from another Rino.

VOX Level

—Controls the sensitivity level of any
Voice Operated Transmission (VOX) accessory.
VOX accessories allow you to use the unit hands­free. A lower VOX setting is recommended for quiet
environments while a higher VOX setting should be
used in noisy environments. Setting the VOX level to 5
is recommended for most environments, but it may be
necessary to adjust the level to achieve the desired voice
trigger level. You will hear yourself talking in the headset
when transmitting successfully using VOX.

Scramble—Adds a level of security to your
conversations with other Rino 120 or 130 users only.
When On, the voice transmission sounds garbled to other

Setup Radio Page

non-scrambled Rino units, as well as other 3rd party
radios.

Send Location—Enables/disables the peer-to-peer
positioning feature. See the “Peer-to-Peer” section for
more on this feature.

Rino® 120 Owner’s Manual 15

UNIT OPERATION > RADIO PAGE

NOTE: When Scramble is set to On, in order for
peer-to-peer and Send Location features to work, the
receiving radio must have Scramble enabled also.

Repeater Channel—Use this option to turn On/Off
GMRS repeater channels 15R–22R. This option is only
available when GMRS is enabled and is not available at
all in Canadian Rino units.

GMRS Radio—Use this option to turn On/Off GMRS
channels 15–22. See the “FCC Licensing Information”
section and the “Appendix” for more information on
using GMRS channels.

Headset Type

—Allows you to choose which accessory
headset or microphone you are using with the unit, or
have the unit automatically detect the type. If you use
more than one type of headset or microphone, you need
to set the unit to Ask When Detected before changing
accessories.

NOTE: If the headset has a PTT (Push to Talk)
button, it must be pressed for the unit to detect the
headset.

You must obtain a license to

operate on GMRS channels

15–22 in the US.

Microphone Sensitivity—Allows you to set the
sensitivity of the internal microphone and the sensitivity
of a headset microphone.

16 Rino® 120 Owner’s Manual

UNIT OPERATION > RADIO PAGE

Setup Tones

Call Tone—When the Call key is pressed, an attention

Message Tone—Choose from On or Off to have the unit

emit a tone when a message or note is received.
tone is transmitted. This option allows you to choose one
of ten tones.

Setup Scanlist

Refer to “Scanning and Monitoring” previously in this

Roger Tone

sent to signify the end of the transmission. This option

—When the Talk key is released, a tone is

manual for complete information about this feature and

the options in this page.
allows you to choose one of four tones or set the tone to

Off.

Ring Tone

—When an incoming transmission is received,
an attention tone sounds. This option allows you to
choose one of ten tones or set the tone to Off. The Ring
Tone will not sound again until there has been 45 seconds

Turn Radio/GPS On/Off

Press the Thumb Stick In on either of these two options
to toggle them from on to off. For example, to turn GPS
Off, press the Thumb Stick In when Turn GPS Off is
highlighted.

of radio inactivity.

Vibrate—Choose from On or Off to have the unit
vibrate when an incoming transmission is received. Once
received, the unit will not vibrate again until there has
been 45 seconds of radio inactivity.

On/Off Tone

—Enable or disable the tone the unit makes

Setup Tones Page

when it is turned on and off.

Rino® 120 Owner’s Manual 17

UNIT OPERATION > RADIO PAGE

Informational Picture

The Informational Picture on the bottom half of the
Radio Page features Garmin’s Mr. Mark Waypoint figure
showing current GPS and radio status, and radio actions.
As you operate the unit, the graphics change depending
on what actions you are taking and the unit settings.

GPS Status

Four satellites are shown on at the top of the picture along
with descriptive text to indicate GPS reception status.
As the unit collects satellite information, the satellite
symbols flash alternately until all four are steady to
indicate a 3D position fix. The more satellites that are
steady, the better your position fix.

Radio Transmission Status

As radio signals come in, signal wave symbols
( ) display to the left of Mark Waypoint. Fragmented
(or broken) signal symbols ( ) are shown to indicate

Informational Picture showing

Mark Waypoint

Informational Picture Legend

Radio in Mark’s hand = radio is ready to use.

Flag in his other hand = unit ready to transmit its position

(GPS must be On to use this feature.)

Radio waves around Mark’s radio = you are transmitting

Raised flag in his hand = peer-to-peer transmission is sent

Flag on top of the hill = a position was received

18 Rino® 120 Owner’s Manual

activity on that channel. Audio remains muted because
the incoming signal does not match the squelch code your
unit is set to.

UNIT OPERATION > RADIO PAGE

Mark Waypoint’s Indicators

The Mark Waypoint figure displays several different icons, depending on what you are doing. See the illustrations for
more information.

GPS and FRS/GMRS Radio On;
Ready to transmit Position

GPS and FRS/GMRS Radio On;
Ready to transmit Position;
Transmitting on FRS

GPS and FRS/GMRS Radio On;
Position not ready;
Transmitting on GMRS

GPS and FRS/GMRS Radio On;
Position transmitted

GPS and FRS/GMRS Radio On;
Ready to transmit Position;
Receiving transmission

Rino® 120 Owner’s Manual 19

GPS and FRS/GMRS Radio On;
Ready to transmit Position;
Activity on channel;
Broken transmission.

GPS and FRS/GMRS Radio On;
Ready to transmit Position;
Position received from Rino user

GPS Off;
FRS/GMRS Radio On;
Position sending not available

GPS On;
FRS/GMRS Radio Off;
GPS operation only

UNIT OPERATION > USING THE RINO 120 RADIO FEATURES

Using the Rino 120 Radio Features

Your Rino 120 unit provides many features to enhance
your radio experience, such as transmitting locations and
receiving contact information. This section reviews some
of the advanced radio features. Refer to the “Features”
section for information on the features of the Rino 120.

To transmit your location to other Rino users:

1. Enable Send Location (see the “Setup Radio”
section).

2. Press and release either the Talk or Call key.
A flag on the top Status Bar or in Mark’s hand
indicates the unit is ready to transmit its position.

New Contact Page Overview

Peer-to-Peer Positioning

The Rino 120’s most unique feature is being able to send
its location to another Rino, which is called Peer-to-Peer
positioning. With peer-to-peer positioning enabled (see

page 15) and a GPS position (see the “Initializing the

Rino 120” section), whenever you press and release either
the Call key or the Talk key, the Rino 120 automatically
sends out its location. This information is available to all
other Rino users that are monitoring the same channel
and squelch code. This feature allows you to track the
movement of other Rino users and even navigate to
their location. Locations may only be sent once every 30
seconds due to FCC restrictions. Your Rino 120 responds
to polling requests from other units more frequently.

20 Rino® 120 Owner’s Manual

The first time that a signal is received from another Rino
user, the New Contact Page is displayed. From the New
Contact Page you can show their location on your Map,
Goto their location, or add them to your contact list
(select OK). Press Page to ignore this contact.

Name and Symbol

Contact

Information Field

New Contact Page

The Rino 120 can manage up to 50 contacts at any time.
Each time you receive a signal from a contact, your map
is updated showing their new position. A Track Log
of their movement is created and shown on your map
(see the “Track Logs” section). After a contact has been
established, a “<contact name> Updated” message briefly
appears at the bottom of your display each time the
contact updates.

All contacts are listed on the Contact List Page and also

To accept a new contact:

1. When a new contact is received, the New Contact

displayed in the Contact Bar on the Map Page (see the
“Map Page” section). Contacts behave like waypoints

2. Highlight OK and press the Thumb Stick In. If you

and count towards the 500 maximum waypoint total.
If the contact did not have a GPS location on the last
transmission, a ? (question mark) appears below the flag.
To view the contact details (such as Direction, Elevation,
Timestamp, Location, and Notes that have up to 30
characters), highlight the details field and press Left or
Right on the Thumb Stick to change to the next data
field.

UNIT OPERATION > USING THE RINO 120 RADIO FEATURES

Press Left or Right on the Thumb

Stick to view different contact data.

Page automatically appears.

do not select OK, the contact is not saved.

Rino® 120 Owner’s Manual 21

UNIT OPERATION > USING THE RINO 120 RADIO FEATURES

To review a contact and contact details:

1. From the Map Page, highlight the desired contact
on the Contact Bar and press the Thumb Stick In.
As you highlight the contacts on the Contact Bar,
the Map Page centers the map on that contact
and display its name, direction, and distance near
the top of the screen.

Or Press the Thumb Stick In and hold it until the

Shortcuts Menu is displayed. Highlight Find ‘N Go
and press the Thumb Stick In.

2. Highlight Contacts and press the Thumb
Stick In.

3. From the Contacts List, select the desired contact
and press the Thumb Stick In.

For Notes, highlight

entering data, up to 30 characters. For other
fields, highlight the field and press the Thumb
Stick In to start changing the data.

2. Highlight OK and press In when done.

To view a contact on the Map Page:

1. From the Contact Review Page, highlight Map and
press the Thumb Stick In.

2. Press the Page key when done to return to the
Contact Review Page.

Edit and press In to start

Contact Bar

To change contact details:

1. The Elevation, Position, and Note fields may be
manually edited. Select the desired field and press
the Thumb Stick In.

22 Rino® 120 Owner’s Manual

Contacts also show on the Map

Page. Highlight the contact and the

map centers on their last position.

UNIT OPERATION > USING THE RINO 120 RADIO FEATURES

Sending a Location

Another handy feature is the ability to send a specific
location to other Rino users. This comes in handy when
you are trying to round up the group or you want to meet
at a specific location. You may send any point found from
the Find ‘N Go menu. If the unit needs to wait until 30
seconds have elapsed since the last position transmission,
a “Waiting to send location...” message appears until the
unit is able to transmit. If a location is sent more than
once, a number is automatically added to the end of the
name, such as CAMP, CAMP 1, and CAMP 2.

To

send a location:

1. Press the Thumb Stick In and hold it until the
Shortcuts Menu is displayed.

2. Highlight Find ‘N’ Go and press the Thumb
Stick In.

3. Highlight the desired category and press the
Thumb Stick In. (For the Contacts List, select the
desired contact and press the Thumb Stick In.)

Rino® 120 Owner’s Manual 23

4. Depending on which category you select, highlight
the desired item and press the Thumb Stick In to
display the Information Page for that item.

5. From the Information Page, highlight the Option

Menu in the upper right and press the Thumb
Stick In.

6. Highlight Send Location and press In again.
The unit now sends the point to the other Rino
users on your channel/squelch code. If using the
Scramble feature, receiving radios must also have
Scramble enabled.

Choose Send Location and press In.

UNIT OPERATION > MAP PAGE

Map Page

The Map Page displays your present position and
direction of movement using a triangular Position Icon
that is centered on the map. As you travel the map display
leaves a “trail” (track log) of your movements.

The map displays geographic details such as rivers, lakes,
highways, and towns. The map can display a higher level
of detail than the basemap provided with the unit (i.e.
residential streets, parks, etc.), if Garmin MapSource
data has been loaded into the unit using a CD-ROM

map resolution and GPS accuracy in defining your
location to a point within the circle. The smaller the
circle, the more accurate your location.

When using the Pan Map feature, a small outline arrow
(Map Pointer) can be moved about the page to
highlight and identify map items or to scroll the map to
view areas not shown on the display screen.

Four optional data fields on the right side of the page
can be programmed to provide a variety of travel and
navigation information.

mapping program. When using MapSource data, the word
“mapsource” displays below the map scale whenever you
zoom in to view map details.

Status Bar

Option Menu and Main

Page Menu Buttons

On the right side of the Map Page, you can choose to
show either the Contact Bar, Data Fields, or only the
Map. As you highlight the contacts on the Contact
Bar, the Map Page centers the map on that contact and
displays its name, direction, and distance.

Accuracy Circle

Map Scale

Contact Bar

Position Icon

In many instances the map displays an Accuracy Circle
surrounding the Position Icon. The Rino 120 uses both

24 Rino® 120 Owner’s Manual

UNIT OPERATION > MAP PAGE

To view a Contact from the Map Page:

1. Highlight the desired Contact icon using the
Thumb Stick. As you highlight the contact on the
Contact Bar, the Map Page centers the map on
that contact and displays its name, direction, and
distance near the top of the screen.

2. Press the Thumb Stick In to view the details of
the Contact.

3. Press the Thumb Stick to the Left or Right to re­center the map on your current position.

The scale can be changed from 20 feet to 500 miles. A
lower zoom scale displays less area but more map detail,
while a higher zoom scale shows you a larger area with
less map detail. The Thumb Stick and Zoom (Z) key
on the front right of the unit
allow you to zoom in and out

To change

1. Press the Zoom (Z) key to open the Zoom

2. Use the Thumb Stick to change the map scale to

Press and hold Up or Down on the Thumb Stick

The map scale in the lower left hand side of the display
is shown in the units of measurement selected in the
Units field of the Unit Setup Page (accessed through the
Main Menu Setup Page). If you zoom in so far that the
resolution of the map data is exceeded and the appearance
of the map is no longer accurate, the word, “overzoom”
displays just below the map scale.

window.

show more map area with less detail or less map
area with more detail.

to zoom the map scale rapidly. Press the Thumb

Stick Left, Right, or In to close the Zoom window.

scales on the Map Page:

on the map. Press the Zoom
(Z) key from any page (other
than the Map Page) to open
the Map Page.

Press Up to Zoom Out;
press Down to Zoom In

Rino® 120 Owner’s Manual 25

UNIT OPERATION > MAP PAGE

Map Page Options

Map Page options allow a variety of operating and
custom features for your Rino 120. The Map Page options
are listed below. Highlight an option then press the

Thumb Stick In to select.

Show...—Allows you to choose to show

either the Contact Bar, four programmable
Data Fields, or show the Map Only.
Choosing either Contact Bar or Data Fields
reduces the map area.

Setup Map—Displays the Setup Map Pages, which
allow you to tailor the map to your requirements such
as changing text size, map orientation, and map detail.
Refer to the “Setting up the Map” section for complete
instructions.

Map Page Option Menu

Measure Distance

—Displays the distance from one

point on the map to another.

Pan Map—Allows you to move the Panning Arrow (Map
Pointer) about on the map. Refer to the “Using the Pan
Map Option” section for complete instructions.

Restore

factory settings (defaults).

Defaults—Returns the Map Page to the original

Stop Navigation—Quits navigation of a Goto, Route,

or Track in progress. When you are not navigating to a
destination, the Stop Navigation option is “grayed out”
and is non-functional.

26 Rino® 120 Owner’s Manual

UNIT OPERATION > MAP PAGE

Using the Pan Map Option

The Map Page pan function allows you to display an
arrow used to point at and identify items on the map,
and to move the map in order to view areas beyond the
current viewing area on the display.

The map panning function is activated from the Option
Menu on the Map Page. Use the Thumb Stick to
move the panning arrow (also referred to as the map
pointer) in the desired direction. If the arrow moves to
the edge of the map display, the map also moves to reveal
more area and a busy hourglass appears by the cursor
while the data is drawn on the screen.

Whenever you place the panning arrow on a map item,

circle around it, add it to a route, or view the Sun & Moon
or Hunt & Fish information for it. On-screen buttons at
the bottom of the page allow you to Goto the map item,
display it on the Map, or to select OK and return to the
Map Page. Press the Page key to stop panning the map.

To find an item near the map pointer:

1. When using the panning arrow, press and hold the
Thumb Stick In to display the Shortcuts Menu.

2. Select Find ‘N Go to display items. Select the
category you wish to search (waypoints, contacts,
etc.), then select Near Map Pointer from the pop­up list. The Rino 120 then searches for the items
nearest the location of the map pointer instead of
your actual location.

the name of that item is highlighted. This feature applies
to waypoints, roads, lakes, rivers; nearly everything that
is displayed.

Map Page with
Panning Arrow

Press the Thumb Stick In to mark the arrow location or
display the map item Information Page. The Option Menu

allows you to send the location of that item, project

a waypoint from it, save it as a waypoint, set a proximity

Rino® 120 Owner’s Manual 27

UNIT OPERATION > MAP PAGE

Programming the Data Fields

Select Show... Data Fields to view four optional
Data Fields on the right side of the screen that can be
programmed to provide a variety of travel and navigation
information. A list of the choices is shown to the right.
Not all data types are available on every page.

To program a data field:

1. Use the Thumb Stick to highlight the data field
and then press In to display the list of data
options.

2. Highlight the desired option and then press the
Thumb Stick In to change the data field.

Changing Data Fields

28 Rino® 120 Owner’s Manual

Data Field Options

Thee data field options apply to the data fields on the
Map Page, Navigation Page, and the Trip Computer. For
definitions of these data fields, refer to the “Appendix.”

Bearing Course Current Destination

Current Distance Current ETA Current ETE

Elevation Final Destination Final Distance

Final ETA Final ETE GPS Accuracy

Heading Max Speed Moving Avg. Speed

Odometer Off Course Overall Avg. Speed

Pointer Speed Sunrise

Sunset Time of Day To Course

Trip Odometer Trip Time—Movg. Trip Time—Stopped

Trip Time—Total Turn Velocity Made Good

Vertical Speed Trip Computer Only Location (lat/lon)

Location (selected)

UNIT OPERATION > MAP PAGE

Setting up the Map

Setup Map displays the five Map Setup Pages, each
accessed by an on-screen button.

Setup Items

Options

Sub-Page Buttons

General Setup
Lines Setup
Points Setup

Text Setup
Map Data Setup

3. Press Left, then Up or Down on the
to highlight an item on the list. Press Right to
return to the sub-page buttons.

4. Use the Thumb Stick to highlight the desired
option and press In to activate.

5. Press the Page key or the on-screen X button to
return to the Map Page.

Thumb Stick

To use Map Setup options:

1. Select Setup Map from the Option Menu and
then press the Thumb Stick In to display the Map
Setup Page.

2. Press Up or Down on the Thumb Stick to
highlight the desired sub-page button, which
displays the options list for that sub-page to
the left.

Rino® 120 Owner’s Manual 29

UNIT OPERATION > MAP PAGE

General Setup

Orientation—Track Up or North Up; fixes the top of
the map display to the current track heading or to a north
heading.

Auto Zoom—On or Off; automatically scales the map to
display both your current location and the next point to
which you are navigating.

Detail—Most, More, Normal, Less, or Least; controls

Tracks Setup

Saved Tracks and Track Log—Scale options; Off, Auto,
or 20 ft.–500 miles, sets the maximum scale at which the
feature should appear on the screen. Some types of data
display only at certain zoom scales.

Goto Line—Bearing or Course.

Track Points

—Select the number of track points per

track. Up to 2,048 active Track Points allowed
how much map detail you see. This setting only applies
to a map feature set to Auto. Those features which have
a specified scale or are turned Off are unaffected by this
setting.

Map Features Setup

Points of Interest, Waypoints, Street Label, and Land

Cover—Off, Auto, or 20 feet to 500 miles; sets the

maximum scale at which that feature should appear on
Lock on Road—On or Off; available only if MapSource

data is loaded; when On, the triangle icon locks to the

the screen. Some types of data display only at certain

zoom scales.
road that you are traveling.

Display Mode—Land or Water.

30 Rino® 120 Owner’s Manual

UNIT OPERATION > MAP PAGE

Text Setup

2. Use the

Points of Interest, Waypoints, Street Label, and Land
Cover—None, Small, Medium, or Large; control the

screen size of the name.

Map Data Setup

Show—Check box; check mark determines if map data is

3. To begin measuring from a different point, press

used or not. Option Menu allows you to choose to show
all, show none, or show specific MapSource data. See

4. To stop measuring, press the Page key.

also the “Appendix.”

Page until you reach the point to which you want
to measure. A new Map Pointer field displays
showing the location of the pointer and the
direction and distance from where you began the
measuring.

the Thumb Stick In at the desired location.

Thumb Stick to move about on the Map

Map Pointer Field

Measuring Distance

To use the Measure Distance option:

1. Select Measure Distance from the Option Menu
and then press the Thumb Stick In to display

the Panning Arrow. Ref displays under the arrow.

Rino® 120 Owner’s Manual 31

Measuring distance

UNIT OPERATION > NAVIGATION PAGE

Navigation Page

The Navigation Page provides active guidance with a

Destination Name

(Waypoint)

Straight Line

Distance to
Destination

rotating compass ring that shows your course (track)
while you are moving and a bearing pointer to indicate
the current direction to your destination (bearing) relative
to the course.

The Data Field at the top of the page, by default shows
you the name of your destination. All five Data Fields can
be programmed to display a variety of navigation data.
The list of data field choices can be found in the “Map
Page” section listed in the “Data Field Options” heading
and definitions may be found in the “Appendix.”

When you are moving, the heading of the Compass Ring
is controlled by the GPS receiver (based upon settings

Using the Navigation Page

The two main components of the Navigation Page are the
Bearing Pointer and Compass Ring. The Bearing Pointer
always points directly to the destination, no matter what
your current location might be. The Compass Ring
displays your heading.

Bearing

Pointer

Compass Ring

Times to

Destination

Selectable

Data Fields

customized in the Heading Setup Page).

32 Rino® 120 Owner’s Manual

UNIT OPERATION > NAVIGATION PAGE

While you are navigating a route, the pointer indicates the
direction (a bent arrow) of the turn to the next point in the
route as well as the direction to the current point when
you get within 15 seconds Estimated Time of Arrival of

destination related data, such as the Estimated Time of
Arrival.

CDI Scale

the current point.

For example, if the arrow is pointing straight up, you
are going directly to your destination. If it points any
direction other than up, turn and move towards the
direction the arrow is pointing until it points up, and
then continue in that direction. If you are using the
Course Pointer option instead and you drift away from

Navigation Page with Course
Pointer and Course Deviation

Indicator (CDI) Scale active.

the original line of travel to your destination, the Course
Deviation Indicator (CDI) provides graphic indication of
drift (right or left) and displays the distance off course.

When you are not on an active Goto, Track, or Route
(in other words, you are not traveling to a recorded
destination), the window at the top of the page is blank

To stop navigating:

1. Highlight the on-screen Option Menu button
at the top of the Navigation or Map Page and
press the Thumb Stick.

2. Select Stop Navigation, then press the
Thumb Stick.

when Destination is selected. The Compass Ring
displays your heading while you are moving, but the
data fields to the right of the page will not display any

Rino® 120 Owner’s Manual 33

UNIT OPERATION > NAVIGATION PAGE

Navigation Page Options

Sight ‘N Go—Use the Sight ‘N Go feature to locate a

Restore

to factory designations.

Defaults—Returns options and data field choices

landmark visually and then lock in a magnetic heading to
it.

Stop Navigation—Cancels navigation. “Grayed out” or
disabled unless you are navigating on a Goto, Track, or
Route.

Bearing Pointer/Course Pointer—Toggles between

Navigation Page Option Menu

Bearing (always directed at destination) and Course
(distinctive with dots across center of compass ring,
shows amount of correction needed to be back on
course.). Refer to the image on the previous page for an
example of the compass with the Course Pointer. Refer
to the image below for an example of a compass with a
Bearing Pointer.

Show Data Fields/Big Compass—Toggles to display

To change data fields:

1. Use the Thumb Stick to highlight the desired data
field and then press it In to display the list of data
options.

2. Select the desired option from the list and press
the Thumb Stick In. The list of data field choices
may be found on page 28 and definitions may be
found in the “Appendix.”

data fields on the right side of the display or removing the
data fields and showing a larger compass.

34 Rino® 120 Owner’s Manual

UNIT OPERATION > TRIP COMPUTER PAGE

Trip Computer Page

The Trip Computer Page by default displays up to seven
different types of navigation data. Choose Big Numbers
to display two (2) large data fields.

By selecting the information options that you prefer
and arranging them in a desired order on the page, you
can customize the Trip Computer Page to meet your
navigation needs.

Trip Computer Page Options

The Option Menu allows you to reset the Trip Computer
data when you are ready to start a new trip, choose
between Big or Small Numbers, and Restore Defaults.

Trip Computer Page,

Small Numbers

Trip Computer Page,

Big Numbers

Each data field is selectable and can contain one of many
data information options. The default settings for these
fields are shown in the top-right image. The list of data
field choices may be found on

page 28 and definitions may be

found in the “Appendix.” When
the data field title is selected, press
the Thumb Stick In to select a
new data field choice.

Rino® 120 Owner’s Manual 35

Selecting a data field

Reset—Clears recorded data from the page to begin
recording new data.

Big/Small Numbers—Changes the display from seven
small data fields to two large data fields.

Restore

Defaults—Returns the Trip Computer Page to

the original factory settings (defaults).

UNIT OPERATION > MAIN MENU PAGE

Main Menu Page

The Main Menu provides access to additional Rino
120 feature pages. The pages listed below provide
enhancements to Rino 120 operation. Press the Page key
repeatedly to cycle to the Main Menu or select it from the
Main Page Menu at the top of each main page.

Using the Main Menu

The Main Menu allows access to many features and
pages in the Rino 120. Please refer to the “Features”
section for a complete description of the items accessed
through the Main Menu.

Mark Waypoint Page

—Allows you to mark and store
a waypoint for your current location or a map pointer
location.

Find ‘N Go Menu—Allows you to locate and Goto
Waypoints, Favorite Locations, Cities, Interstate Exits,
Points of Interest, Addresses, and Intersections. (Some
require MapSource data.)

Main Menu Page

Routes Page—Allows you to create and store routes for
repeated use.

Tracks Page

—Provides access to the track log, saved

tracks, and contact tracks.

36 Rino® 120 Owner’s Manual

UNIT OPERATION > MAIN MENU PAGE

Proximity Page—Allows you to set a proximity alert
distance around contacts or waypoints.

Satellite Page—Provides a picture of the satellite signal
tracking and tells you when the unit is ready to navigate.

Setup Page—Allows tailoring of items such as time
format, units of measure, display backlighting timeout
and contrast adjustment, heading selection, interface
setups, and system software information.

Calendar Page

—Provides you with a monthly calendar

Hunt & Fish Page—Provides you with a listing of best
times for hunting and fishing for a chosen location.

Area Calculation Page

—Use this function to calculate

area as you move around.

Games Page—Games are provided as an entertainment
feature.

Many of the items in the Main Menu Page are discussed
in-depth in the “Features” section. Refer to the specific
section for more information.

with programmable reference notes.

Alarm Clock—Provides a settable 24-hour alarm clock.

Calculator—Provides a calculator feature available in

two forms: Standard or Scientific.

Stopwatch Page—Allows you to use the unit as a
stopwatch, including a lap timer.

Sun & Moon Page—Shows a graphic display of both
the Sun & Moon locations at various times, dates, and
locations.

Rino® 120 Owner’s Manual 37

UNIT OPERATION > MAIN MENU PAGE

Main Menu Options

Through the Main Menu you can establish the sequence
of pages.

Page Sequence Setup

You may add, remove, or reorder any of the Main Pages,
plus additional pages. The default Main pages are Radio,

To insert a new page, highlight the page you wish

to insert it before and press In. Select Insert, then
choose a page from the list and press the Thumb
Stick In.

To remove a page in the order, highlight the page

and press In. Select Remove and press the
Thumb Stick In.

Map, Navigation, Trip Computer, and Main Menu. The
Main Menu cannot be removed from the page sequence.
If a page is added to the Main Page Sequence, it does not
appear in the Main Menu.

To move, insert, or remove a Main Page:

1. From the Main Menu, highlight the Option Menu
on-screen button and press the Thumb Stick
In. Highlight Page Sequence Setup and press In.

2. To move a page in the page sequence, highlight
the page and press In. Select Move then move
the Menu item Up or Down using the Thumb
Stick. When the desired position is displayed,
press the Thumb Stick In.

38 Rino® 120 Owner’s Manual

Inserting a new page in

the Page Sequence

UNIT OPERATION > SHORTCUTS MENU

Shortcuts Menu

The Shortcuts Menu is accessed by pressing the Thumb
Stick In until the menu pops up on the middle of the

display. The Shortcuts Menu can be accessed from most
pages.

Find ‘N Go—Opens the Find ‘N Go Page. From the Find
‘N Go Page, you can find waypoints, contacts, cities, and
exits. You may also find Points of Interest, addresses, and
intersections if MapSource data is loaded into the
Rino 120.

Send Note—Sends a note to other Rino 120 users.

Enable Keylock—Enables keylock so keys are not

inadvertently pushed. Press and hold the Page key to
unlock the keys.

Shortcuts Menu

Mark Waypoint—Marks your current location as a
waypoint. Opens the Mark Waypoint Page that allows
you to customize the waypoint information as well as
Goto or show on the Map.

Rino® 120 Owner’s Manual 39

UNIT OPERATION > WAYPOINTS

Waypoints

There are numerous ways to create, edit, and use
waypoints. The Mark Waypoint Page and the Find ‘N Go
Menu are two common pages for creating and editing
waypoint. You can also create a waypoint using the Map
Page. The Rino 120 holds up to 500 waypoints.

Mark Waypoint Page

The Mark Waypoint Page allows you to mark and record
any location as a waypoint. It appears with a graphic
name block that displays the assigned number for that
waypoint and a waypoint symbol.

To mark your current location and open the
Mark Waypoint Page:

1. Press and hold the Thumb Stick In until the
Shortcuts Menu opens.

2. Highlight Mark Waypoint and press the Thumb
Stick In. The Mark Waypoint Page opens. You
can also access this page by highlighting Mark
on the Main Menu Page and pressing the Thumb
Stick In.

3. To save the waypoint, highlight OK and press the
Thumb Stick In. If you do not want to save it as a
new waypoint, press the Page key to cancel.

To change Mark Waypoint Page Options:

Waypoint

Name

Mark Waypoint Page

40 Rino® 120 Owner’s Manual

Symbol

Waypoint

Details

• To change the name of the waypoint, use the
Thumb Stick to highlight the waypoint name field.

• To assign an identifying symbol to a waypoint, use
the Thumb Stick to highlight the symbol block just
above the waypoint name.

• To view the waypoint details, highlight the details
field and press Left or Right on the Thumb Stick
to change to the next data field.

UNIT OPERATION > WAYPOINTS

Creating Waypoints

There are many ways to create a waypoint. You can use
any of the methods listed below.

To create a waypoint for a map feature:

1. With the Pan Map feature active, move the
panning arrow (map pointer) to the map item you
want and highlight it.

2. Press In and release the Thumb Stick to display
the item Information Page.

3. With the Information Page displayed, highlight the
Option Menu button at the top of the page
and then press the Thumb Stick to open.

4. Highlight Save As Waypoint and press the
Thumb Stick to save the item as a waypoint.

Saving a map feature as a waypoint

Rino® 120 Owner’s Manual 41

To create a waypoint using the panning
arrow:

1. With the Pan Map feature active, move the
panning arrow (map pointer) on the map to the
location you want to mark, then press the Thumb
Stick.

2. The Mark Waypoint Page displays, automatically
assigning a number to the waypoint.

To create a waypoint by manually entering its
coordinates (lat/lon):

1. Press In and hold the Thumb Stick to access the
Shortcuts Menu. Highlight Mark Waypoint and
press In. You can also use the Find ‘N Go to view
a previous waypoint.

2. Highlight the details field and press Left or Right
on the Thumb Stick to change to the Location
field. Press In and enter the new coordinates
using the on-screen numerical keyboard. Highlight
OK and press In when finished.

3. You may also change the waypoint name and/or
symbol or add notes.

UNIT OPERATION > WAYPOINTS

Projecting a Waypoint

Projecting a waypoint from any map item (another
waypoint, etc.) allows you to establish a new waypoint on
a bearing and distance projected from that map item.

To project a waypoint:

1. Select a map item from the Find ‘N Go Menu.

2. Highlight the Option Menu on-screen button
at the top of the Information Page and press the

Thumb Stick In to display the options. Highlight
Project Waypoint and press In.

3. Highlight either the bearing or distance field, then
press the Thumb Stick In to display the numerical
keyboard. Enter the new bearing or distance, then
highlight OK and press In to finish.

Project Waypoint Page

42 Rino® 120 Owner’s Manual

Editing a Waypoint

A waypoint or contact can be edited to add notes or
change the map symbol, name, coordinates, or elevation.
You can also delete a waypoint or contact.

To edit a waypoint:

1. Use the Find ‘N Go Menu to display the waypoint/
contact or highlight it on the Map Page and press
the Thumb Stick In.

2. To make changes to the waypoint map symbol,
name, location coordinates, elevation fields and
notes, highlight the desired field and press the
Thumb Stick In to display the keyboard. (For
Notes, highlight Edit and press In to start entering
data, up to 30 characters.) Select OK and press
the Thumb Stick In to finish.

3. Highlight the OK button the press the Thumb
Stick to save the changes.

UNIT OPERATION > WAYPOINTS

To delete a waypoint or contact:

1. Use the Find ‘N Go feature to display the point.

2. Highlight the Delete button and then press the
Thumb Stick In. Confirm the deletion.

4. Use the panning arrow to drag the waypoint to the
new location and then press the Thumb Stick In
to place it.

Press the Page key before pressing the Thumb

Stick to cancel moving the waypoint and return to
the Main Pages.

To save Map or Find ‘N Go items as
waypoints:

1. Access the Information Page for the desired item

Deleting a waypoint

To move a waypoint by dragging it:

1. Use the Find ‘N Go Menu to display the Waypoint
Page for the waypoint you want to move.

2. Highlight and press the Map on-screen button to
display the waypoint on the map.

3. With the waypoint highlighted by the panning
arrow, press In and release the Thumb Stick. The
word “Move” displays beneath the panning arrow.

Rino® 120 Owner’s Manual 43

(highlighted from the map or selected from the
Find ‘N Go Menu).

2. Open the Option Menu at the top of the page,
select Save As Waypoint.

3. Press the Thumb Stick In to save the item to the
Waypoints List.

4. Highlight Save As Waypoint and press the
Thumb Stick In.

UNIT OPERATION > FIND 'N GO

Find ‘N Go

The Find ‘N Go Menu allows you to find stored locations
(waypoints) and map items (cities, exits, etc.). They can
be found by name or by those nearest to your current
location. If you are using certain MapSource data, the
list of find locations is expanded to include categories for
Points of Interest, Street Addresses, and Intersections.
If you would like to use an option that is grayed out
(disabled), you need to load detailed maps using
MapSource.

To access the Find ‘N Go Menu:

1. Press and hold the Thumb Stick In to access the
Shortcuts Menu.

2. Highlight Find ‘N Go and press In.

Or

1. Press the Page key or the on-screen Main Page
Menu button to display the Main Menu.

2. Highlight the Find ‘N Go icon and press the
Thumb Stick In.

Categories are listed in two different ways: By Name and
Nearest. The By Name list contains every item in the map
database for the selected category, while the Nearest list
contains only those items that are near to your Current
Location or the Map Pointer.

These pages are structured with a set of sub-menus and
location information pages that guide you through the
process of finding locations.

Find ‘N Go Menu

44 Rino® 120 Owner’s Manual

UNIT OPERATION > FIND 'N GO

Finding a Waypoint

Waypoints that you have created and stored in the Rino
120 can be found by selecting the Waypoint option from
the Find ‘N Go Menu. You can find a waypoint from the
list of waypoints using the By Name or Nearest options
as explained on the previous page. When selected
from the list, the waypoint displays on the Waypoint
Information Page.

The Waypoint Information Page displays the waypoint
name or number, a map symbol, the location in lat/lon,
elevation, distance, bearing, and three on-screen buttons
for Goto, Map, and OK functions.

Nearest Waypoints selected

in Find N’ Go Menu

Rino® 120 Owner’s Manual 45

To find a waypoint near your current location:

1. Use the Thumb Stick to select Waypoint from the
Find ‘N Go Menu. Press the Thumb Stick In to
select Nearest from the pop-up menu. Press the
Thumb Stick In to display the Waypoints List.

2. Use the Thumb Stick to select the desired
waypoint from the list and then press the Thumb
Stick In to display the Information Page for that
waypoint.

3. With the Information Page displayed, select Goto
to create a direct line of travel to the waypoint.
Select Map to view the waypoint location on the
map, or select Delete to delete the waypoint.

4. Press the Option Menu button to access
additional features. You can select: Send Location
(to other Rino users), Project Waypoint, Set
Proximity (alarm), Add to Route, View Sun & Moon
(reports for that waypoint), View Hunt & Fish
(reports for that waypoint), or Reposition Here.

UNIT OPERATION > FIND 'N GO

To find a waypoint by name:

1. Use the Thumb Stick to select Waypoint from the
Find ‘N Go Menu. Press the Thumb Stick In to
select By Name from the pop-up menu. Press the
Thumb Stick In to display the Waypoints List.

3. Select

4. Select the desired waypoint from the list and

OK when you are finished entering the
name. The waypoint list opens with the name
closest to the name you entered on the top.

then press the Thumb Stick In to display the
Information Page for that waypoint.

5. With the Information Page displayed, select Goto
to create a direct line of travel to the waypoint.
Select Map to view the waypoint location on the
map or select Delete to delete the waypoint.

Find ‘N Go Menu

2. Use the Thumb Stick to enter the name of the
waypoint that you would like to find.

6. Press the Option Menu button to access
additional features. You can select: Send Location
(to other Rino users), Project Waypoint, Set
Proximity (alarm), Add to Route, View Sun & Moon
(reports for that waypoint), View Hunt & Fish
(reports for that waypoint), or Reposition Here.

Entering a waypoint

name to find By Name

46 Rino® 120 Owner’s Manual

UNIT OPERATION > FIND 'N GO

Finding a Contact

Contacts that you have received in the Rino 120 can be
found by selecting the Contacts option from the Find ‘N
Go Menu.

Contact List

To find a contact:

1. From the Find ‘N Go Menu, highlight Contacts
and press the Thumb Stick In.

2. From the Contacts List, select the desired contact
and press the Thumb Stick In.

3. With the Contact Information Page displayed,
select Goto to create a direct line of travel to the
contact. Select Map to view the contact’s location
on the map, or select Delete to delete the contact.

Rino® 120 Owner’s Manual 47

If the contact did not have a GPS location on the

last transmission, a question (?) mark appears
below the flag. To view the contact details,
highlight the details field and press Left or Right
on the Thumb Stick to change to the next data
field.

Contact Information Page

4. Press the Option Menu button to access
additional features. You can select: Poll Location,
Send Location (to other Rino users), View Track,
Project Waypoint, Save as a waypoint, or Set
Proximity (alarm).

UNIT OPERATION > FIND 'N GO

Finding a City

Cities can be found by selecting the Cities option of
the Find ‘N Go Menu, selecting the city from the list
of Nearest or By Name, and then displaying the City
Information Page.

The City Information for the selected city displays,
including the city name, the size by population, and
distance from your location. You can view it on the map
or create a Goto direct route to the city from your current
location or from a location defined by the panning arrow
(map pointer). You can also save the city as a waypoint or
add it to an existing route.

To find a

1. Use the Thumb Stick to select the Cities option,

48 Rino® 120 Owner’s Manual

city:

then press it In to display the find Nearest or find
By Name prompt. Selecting By Name displays

the keyboard as an alternative scrolling through
the list of nearest cities. If you are currently
panning the map, the option Near Map Pointer
appears in place of the Nearest option.

2. If using find
of the city by using the keyboard. When you have
entered enough characters to define the name,
a match list displays. If you are using find By
Nearest or Near Map Pointer scroll through the
list to find the city you want. Use the Thumb Stick
to select the desired city from the list and then
press it In to display the Information Page for
that city.

3. With the Information Page displayed, you can
select Goto, Map, or OK options.

4. Press the Option Menu button to access
additional features. You can select: Send Location
(to other Rino users), Project Waypoint, Save as
a Waypoint, Set Proximity (alarm), Add to Route,
View Sun & Moon (reports
for that waypoint), or View
Hunt & Fish (reports for
that waypoint).

By Name, begin spelling the name

Find Nearest Cities List

UNIT OPERATION > FIND 'N GO

Finding an Exit

You can use the Find Exit option to locate a nearby exit
on an interstate highway. Exits are listed only by Nearest.
Exit Information Pages provide a variety of information
about services near each exit, such as rest stops, lodging,
restaurants, and service stations. Some services such as
service stations on this page can be selected. A separate
Information Page displays with specific information
concerning what types of fuel, mechanical, and food
services are available.

To find an exit:

1. Use the Thumb Stick to highlight Exits and then
press it In to display the types list.

2. Highlight and select an exit type by pressing the
Thumb Stick In.

3. A list of exits nearest to you displays. The title box
indicates the interstate highway that is served
by the exits. Two fields at the bottom of the page
indicate distance and bearing to the exit. Scroll
through the list to highlight the desired exit.

Rino® 120 Owner’s Manual 49

4. Press the
Information Page for that exit. This page contains
the exit description with a list of available services
near that exit along with the distance and bearing
fields.

5. Use the Thumb Stick to highlight a service from
the list.

6. Press the Thumb Stick In to display the
Information Page for the selected service.

At the bottom of these Information Pages are on-

screen buttons for Goto, Map, and OK.

7. Press the Option Menu button to access
additional features. You can select: Send Location
(to other Rino users), Project Waypoint, Save as
a Waypoint, Set Proximity (alarm), Add to Route,
View Sun & Moon (reports for that waypoint), or
View Hunt & Fish (reports for that waypoint).

Thumb Stick In to display the

UNIT OPERATION > FIND 'N GO

Finding a Point of Interest

You can use the Find Points of Interest option to locate
a nearby restaurant, lodging, landmark, public building,
park, etc. However, you must have transferred a
MapSource MetroGuide map to the unit map database.
Otherwise, this option, plus Address and Intersection
options, are grayed out and are not functional. Here is a
list of Point of Interest categories:

• Food & Drink • Services

• Lodging • Transportation

• Attractions • Emergency & Govt.

• Entertainment • Manmade Places

• Shopping

In many instances, these categories are subdivided into
types. For example, when you select Food & Drink from
the list of categories, you are then presented with a list of
types that includes All Types and cuisine options such as
American, Asian, Barbecue, and Chinese.

Once you have selected an item, you can display the
Information Page for that item. You can then use the on­screen buttons to Goto or view the location on the Map;
or use the Option Menu for more choices.

Food & Drink types

50 Rino® 120 Owner’s Manual

To find a point of interest:

1. Use the Thumb Stick to highlight Points of
Interest and then press it In to display the Points

of Interest Categories List.

2. Use the Thumb Stick to select the desired
category and then press it In to display the
Types List.

If necessary, use the Thumb Stick to select the

desired type and then press it In to display the list
for that type.

3. Use the Option Menu at the top of page to
select from either By Name or Nearest options.
Selecting By Name displays a keyboard allowing
you to enter the characters of the name you want.
A list of matches displays when enough characters
are entered.

4. Use the Thumb Stick to highlight your selection
from the list and then press it In to display the
Information Page for that item.

5. Use the on-screen buttons to Goto or view on the
Map, or use the page Option Menu.

UNIT OPERATION > FIND 'N GO

Nearest Food & Drink

6. Press the
additional features. You can select: Send Location
(to other Rino users), Project Waypoint, Save as
a Waypoint, Set Proximity (alarm), Add to Route,
View Sun & Moon (reports for that waypoint), or
View Hunt & Fish (reports for that waypoint).

Option Menu button to access

Rino® 120 Owner’s Manual 51

UNIT OPERATION > FIND 'N GO

Finding an Address or Intersection

You can enter a street number, choose a street name
from a list and find an address within the area of map
data coverage or enter two street names and locate the
intersection. To use these options, however, you must be
using a MapSource product that provides this type of
map data.

To locate an address:

1. Use the Thumb Stick to highlight Address and
press it In to display the Find Address Page.

2. Highlight the Number field and use the keyboard
for entering numbers.

Entering an Address

52 Rino® 120 Owner’s Manual

3. Move to the

4. Press the Thumb Stick In to display the Select
Street Name list. Find the street by using the
keyboard to enter characters until a list appears.

5. With the desired street highlighted, press the
Thumb Stick In to place the street name on the
Find Address Page. Repeat this process for city
and postal codes, if desired. A window at the
bottom of the page displays a list of matches and
the quality of each match. You may also use the
Option Menu to Clear City, Clear Postal Code, or
Clear All.

6. Use the on-screen buttons at the bottom of the
page to Goto, view the item on the Map, OK to
close, or use the Option Menu for other choices.

Street field using the Thumb Stick.

To locate an intersection:

1. Display the Find ‘N Go Menu and use the Thumb
Stick to highlight the Intersection category and

press it In to display the Find Intersection Page.

2. Highlight the First Street field and press the
Thumb Stick In to display the Street list.

3. Enter the name of the street in the name field at
the top of the list using the keyboard data entry
method discussed in the Quick Start Guide. Once
you have spelled enough of the street name, a
list of matches displays, often with several streets
on the list. Press the Thumb Stick In to move
the highlight to the street list and then scroll up
or down until you find the street name you want.
Press it In to place the name in the field.

UNIT OPERATION > FIND 'N GO

Finding an Intersection

4. Highlight the
the Thumb Stick In to display the Street list.
Repeat step 3 above.

5. Use the on-screen buttons at the bottom of the
page to Goto, view the item on the Map, OK to
close, or use the Option Menu for other choices.

Second Street field and then press

Rino® 120 Owner’s Manual 53

UNIT OPERATION > FIND 'N GO

Finding a Last Found Place

You can use the Recently Found Places option to
locate Points of Interest, Cities, Waypoints or Contacts,
Intersections, and other locations you have recently
retrieved. The process for finding recent points from the
Find ‘N Go list is the same as finding a regular waypoint.

To find a Last Found Place:

1. Use the Thumb Stick to select the Last Found
Places option from the Find ‘N Go List and then

press it In.

Sub-page

buttons

Last Found Places Page

54 Rino® 120 Owner’s Manual

2. Press Up or Down on the Thumb Stick to
highlight the desired sub-page button, which
will display the options list for that sub-page
(Points of Interest, Cities, Waypoints/Contacts, or
Intersections) to the left.

3. Press Left then Up or Down on the Thumb Stick
to highlight an item on the list and press the
Thumb Stick In to display the Information Page
for that item. Press Right to return to the sub-page
buttons.

4. With the Information Page displayed, you can
select Goto to create a direct line of travel to the
item. Select Map to view the waypoint location or
select OK. For Waypoints and Contacts, you may
also choose to Delete to permanently remove
that item.

5. Use the page Option Menu to send the location of
that point, project a new waypoint from its location,
set a proximity circle, add the item to an existing
route, or view sun/moon or hunt/fish position data
for this time and date.

UNIT OPERATION > SENDING A NOTE

Sending a Note

You may send a note to other Rino 120 users. When you
send a note, it appears along the bottom of the display on
every Rino 120 user who is using the same Channel and
Squelch Code that you are using. The Send Note feature
is great when you are trying to get the group to meet at a
certain location or tell everyone in the group something in
a silent manner.

To send a saved note:

1. Press the Thumb Stick In
until the Shortcuts Menu
appears.

2. Select Send Note and press
the Thumb Stick In to open
the Send Note Page.

3. Select a note from the Saved Notes list and press
the Thumb Stick In.

4. The selected note appears in the Edit Note field.
Press the Thumb Stick In to edit the Saved Note.
Refer to the Quick Start Guide for information on
entering data using the on-screen keyboard.

Rino® 120 Owner’s Manual 55

Send Note Page

When you are done editing the note, push the

Thumb Stick In when OK is highlighted on the
keyboard.

5. Select Send to send the note to all users. Select
Save to save the note. Select Clear to delete
the note.

To send a new note:

1. Press the Thumb Stick In until the Shortcuts
Menu appears in the middle of the screen.

2. Select Send Note and press the Thumb Stick In
to open the Send Note Page.

3. The Edit Note field is highlighted when the page
opens. Press the Thumb Stick In to create a note.
When you are done editing the note, push the
Thumb Stick In when OK is highlighted on the
keyboard.

4. Select Send to send the note to all users. Select
Save to save the note. Select Clear to delete the
note.

UNIT OPERATION > USING A GOTO

Using a Goto

The Goto function allows you to create a direct route to a
destination (waypoint, city, or point of interest). Once you
have accessed the Information Page for an item, use the
Goto button at the bottom of the page to initiate travel,
using the Map and Navigation Pages for guidance.

To activate a

1. Use the Find ‘N Go Menu to access the
Information Page for any desired destination and
use the Thumb Stick to highlight the Goto button.

2. Press the Thumb Stick In to start navigation.

3. Observe the Navigation Page: it displays the
name of your destination, the distance from your
current location, and a Bearing Pointer indicating
the direction you should travel. The time required
to reach your destination displays when you
begin to travel and establish a predictable rate of
movement. The Data Fields to the right of the
page display information relative to your travel.

56 Rino® 120 Owner’s Manual

Goto:

4. Use the Page key or Main Page Menu to access
the Map Page and observe your movements and
a dark line indicating the direct path from your
current location to your destination.

5. Use the Bearing Pointer on the Navigation Page
to maintain travel in the right direction and observe
distance and time information to monitor your
progress.

When you are close to your destination, an “Arriving
at Destination” message appears. If you move past the
destination, the Bearing Pointer reverses and the distance
increases.

To stop navigation, select the on-screen Option Menu
button at the top of the Navigation or Map Page.
Select Stop Navigation, then press the Thumb Stick In.

Viewing a Goto on the Map Page

Route Page

Route navigation allows you to create a sequence of
intermediate waypoints that leads you to your final
destination. The Rino 120 stores 20 routes, each with up
to 50 waypoints. A route can be created and modified
from the Route Page, and waypoints can be added to a
route from the Find ‘N Go Menu. More complex routes
can be created using a PC and MapSource mapping
programs and then transferred to the unit’s memory.

Creating and Using a Route

Create a route from the Routes Page. You can then use
that route to get to your destination.

To create a route:

1. Access the Routes Page from the Main Menu. The
page has a New button, a list of routes, and the
number of unused routes.

2. Use the Thumb Stick to highlight the New button
and press it In to display the route Setup Page.

You can add waypoints to the end of an existing route at
any time by using the Find ‘N Go Menu.

UNIT OPERATION > ROUTE PAGE

Routes List Page

3. With an empty row (dashed) in the route list
highlighted, press the Thumb Stick In to display
the Find ‘N Go Menu.

4. Select a route waypoint from one of the Find ‘N
Go Menu categories and display the Information
Page for the selected waypoint, city, exit, point of
interest, etc. Highlight the on-screen Use button
and press the Thumb Stick In to place it on
the route.

5. To add more waypoints to the route, repeat the
process in Steps 3 and 4. The route is named for
the first and last waypoints on the route.

Rino® 120 Owner’s Manual 57

UNIT OPERATION > ROUTE PAGE

To add a Find ‘N Go Menu item to a route:

1. Select an item from the Find ‘N Go Menu and
display its Information Page. If a contact is used
in a route, the route changes as the contact’s
position is updated, or it may be saved as a
Waypoint to serve as a stationary point.

2. Select the page Option Menu and select Add To
Route to display the list of routes.

3. Highlight and select the route desired and then
press the Thumb Stick In. A “Waypoint Added
Successfully” message displays.

Editing a Route

To remove all waypoints:

1. From the Route Page, select the on-screen

Option Menu button and press the Thumb
Stick In to access the Option Menu.

2. Highlight the Remove All option and then press
the Thumb Stick In to remove all waypoints from
the list. When you see the prompt “Do you really
want to remove all waypoints from the route?”,
select Yes.

Route Options

To reverse the route:

1. From the Route Page, select the on-screen page

Option Menu button and press the Thumb
Stick In to access the Option Menu.

2. Highlight the Reverse Route option and then
press the Thumb Stick In to reverse the order of
waypoints in the list. To change the route back to
the original order, repeat this process.

58 Rino® 120 Owner’s Manual

UNIT OPERATION > ROUTE PAGE

To copy the route:

1. From the Route Page, select the on-screen page

Option Menu button and press the Thumb
Stick In to access the Option Menu.

2. Highlight the Copy Route option and then press
the Thumb Stick In to copy. The copied route
displays on the Route Page and is named the
same but followed by the numeral 1 (one). You
may then rename and/or modify the copied route.

2. Select

To review a route point:

1. Select the point from the Route Points List and

2. Highlight Review and then press the Thumb

3. Highlight the on-screen OK button and then press

To delete the route:

1. From the Route Page, select the on-screen page

Option Menu button and press the Thumb
Stick In to access the Option Menu.

2. Select Delete and then press the Thumb Stick In.
When you see the prompt “Do you really want to
delete route?”, select Yes.

To insert a new point on the route list:

1. Select the row where you want the new point

2. Highlight Insert and press the Thumb Stick In

To restore default settings for the route:

1. From the Route Page, select the on-screen page

Option Menu button and press the Thumb
Stick In to access the Option Menu.

Rino® 120 Owner’s Manual 59

Restore Defaults and then press the

Thumb Stick In to restore factory settings.

press the Thumb Stick In to access the Option
Menu for the waypoint.

Stick In to display the Information Page.

the Thumb Stick In to return to the Route
Points List.

inserted before. Press the Thumb Stick In.

to display the Find ‘N Go Menu and select a new
waypoint, city, exit, point of interest, etc.

UNIT OPERATION > ROUTE PAGE

Route point review options

2. Highlight
to display the Find ‘N Go Menu or create a new
waypoint and add it to the points list.

3. Select a new waypoint, access its Information
Page and press the on-screen Use button to
replace the old route waypoint.

Change and press the Thumb Stick In

To move a route point:

3. With the new point highlighted, press the
Stick In to display the Information Page for the
new point and then select the on-screen OK
button to add it the route.

To remove a point from the route list:

1. Select the point that you want to remove from the
Route Points List and press the Thumb Stick In.

2. Highlight Remove and press the Thumb Stick In
to remove the waypoint from the list.

Thumb

1. Select the point from the Route Points List and
press the Thumb Stick In.

2. Highlight the Move option and press the Thumb
Stick In to select the waypoint.

3. Use the Thumb Stick to move the point up or
down in the list. Press the Thumb Stick In to
leave the waypoint in the new list order.

To change a route point:

1. Select the waypoint that you want to change from
the Route Points List and press the Thumb
Stick In.

60 Rino® 120 Owner’s Manual

UNIT OPERATION > ROUTE PAGE

Adding or Editing from the Route Map Page

You can use the panning arrow with the Route Map Page
displayed to add or edit route waypoints.

To add a point at either end of a route:

1. Select the Route from the list of routes. Press the
Thumb Stick In to display the Route Page.

2. Highlight the on-screen Map button at the bottom
of the page and press the Thumb Stick In to
display the Route Map Page.

3. Use the Thumb Stick to move the panning arrow
to either end of the displayed route until the end
point is highlighted. Then press the Thumb Stick
In and select Add Turns. This option appears only
when highlighting the end point of a route.

4. Move the panning arrow to a map item or
location where you would like to extend the route
and press the Thumb Stick In to display the
Information Page for the new point.

Rino® 120 Owner’s Manual 61

5. Press the on-screen
Map Page and then press the Thumb Stick In
again to place the new waypoint.

To add a route point within a route:

1. Follow steps 1 and 2 in the previous instructions.

2. Use the Thumb Stick to move the panning arrow
to a route line. When the arrow touches the line,
the line becomes thin. Press the Thumb Stick In
to display the word ADD next to the line.

3. Drag the line to a map item or other location
where you want to establish a new waypoint and
then press the Thumb Stick In to place the new
waypoint. A Waypoint Information Page displays.
Press the on-screen OK button to save the new
waypoint, then press it again after returning to the
Route Map.

Use button to return to the

UNIT OPERATION > ROUTE PAGE

To review or remove a route point:

1. Select the Route from the list of routes. Press the
Thumb Stick In to display the Route Page.

2. Use the Thumb Stick to highlight Map and press
In to display the route on the map.

3. Use the Thumb Stick to move the map panning
arrow to the point you want to review and press In.

Select Review or Remove and press In again to

either display the Information Page or remove it
from the route.

Select Next and press In again to view the next

waypoint.

Select Add Turns to manually add a turn to the

route using the map and map pointer.

To navigate a route:

1. Select a route from the list of routes and then
press the Thumb Stick In.

2. Highlight the on-screen Navigate button at the
bottom of the page and then press the Thumb
Stick In to begin navigating the route. The screen
changes to the Navigation Page.

3. Move to the Map Page to view the route and your
current location.

4. Begin moving, watching directional information on
the Navigation Page or your progress on the Map
Page.

Navigating a Route

A Route can be navigated using the Map Page or
the Navigation Page. The Map Page displays your
movement, the route line, and waypoints on the route.
The Navigation Page shows compass direction and a
bearing pointer.

62 Rino® 120 Owner’s Manual

Stopping Navigation

To stop navigation, highlight the Stop Navigation option
on either the Navigation or Map Page’s Option Menu or
select the Stop button on the Route Page.

UNIT OPERATION > ROUTE PAGE

Data Fields for the Route Page

Changing the Route Data Fields

When navigating a Route, the data displayed in the data
fields on the Route Page may be customized to provide
useful navigation information.

To select data field options:

1. Use the Thumb Stick to highlight a data field on
the Route Page and then press In to display the
data field options.

2. Use the Thumb Stick to highlight the desired
option and press In to select that option for the
selected data field.

Data field options for Route Page:

• Distance to Point

• ETA To Point

• ETE To Point

• Leg Course

• Leg Distance

• Leg Time

• Pointer

• Sunrise At Point

• Sunset At Point

Rino® 120 Owner’s Manual 63

UNIT OPERATION > TRACKS PAGE

Tracks Page

The Rino 120 draws an electronic bread crumb trail on
the Map Page as you travel along. This bread crumb trail
is the Track Log. The Track Log contains information
about points along its path, including time and position.
The Rino 120 uses this information to allow you to
navigate using the saved track. You may also save tracks
from other Rino users as they communicate with you.

To open the Tracks Page:

1. Access the Menu Page by using the on-screen
menu button or the Page key.

2. Select the Tracks icon and press the Thumb

Stick In. The Tracks Page opens.

Tracks Page

64 Rino® 120 Owner’s Manual

To save and use a Track:

1. Access the Tracks Page from the Main Menu.

Press the on-screen Off button In to pause track

logging. When track logging is active the On
button appears to be recessed.

2. Highlight the Save on-screen button and then
press the Thumb Stick In to display the track log
Save Back Through list.

3. Use the Thumb Stick to select the time and date
that you would like to save the track through.

4. Press the Thumb Stick In to save the track log
and display the Tracks Page. The Tracks Page
shows the track name (which can be renamed
using the keyboard for data entry), the total
distance of the track, track area (if available), a

Show on Map option, and on-screen buttons for
Map, OK, and Tracback.

UNIT OPERATION > TRACKS PAGE

Using the TracBack Feature

The TracBack feature allows you to return along a
traveled path (or another Rino user’s path) without
marking any waypoints. When you are ready to return
to where you started, the Rino 120 takes you back by
following the Track Log that you left behind. You can
save a total of 20 tracks in the unit memory. The Track
Log starts recording as soon as the unit gets a satellite
location fix and the Track Log feature is turned on. When
you no longer need a Track Log you can press the on­screen Clear button to remove it.

When the display reaches 100%, the most recent track
points start to overwrite the least recent if the default
setting Wrap When Full remains selected on the track
log setup. To avoid losing track points you want, save the
Track Log when it approaches the 99% mark. The active
track log stores up to 2,048 points.

The Saved Track Page displays the track and it can also
be displayed on the Main Map Page as you navigate. You
may save up to 20 tracks with 250 points per track in the
unit. Saved Contact tracks count towards this total. Tracks
are marked BEGIN and END.

If you want to keep a record of a certain track log or use
the TracBack feature, it is recommended that you clear
the Track Log before you start traveling. The percentage
of memory used by the current track log is displayed in
a window at the top of the page. After the Track Log is
cleared, it displays zero percent.

Rino® 120 Owner’s Manual 65

UNIT OPERATION > TRACKS PAGE

To use the TracBack feature:

1. Highlight the Tracback button on the Tracks Page
and press the Thumb Stick In. The Tracback
Menu options (To Beginning and To End) are
displayed.

2. Highlight the desired option and press the Thumb
Stick In to enable.

3. Use the Map Page or the Navigation Page to
navigate the Track.

Setting up the Track Log

You can set the track recording interval to Distance,

To use Track Log Setup options:

1. Highlight the Tracks Page Option Menu button
at the top of the page and press the Thumb

Stick In to display the menu.

2. Highlight the Tracks Log Setup option and then

press the Thumb Stick In.

You can check the Wrap When Full option by

highlighting it and then pressing the Thumb Stick
In. You can highlight the Record Method and
Interval fields and press the Thumb Stick In to
display their options. Interval options change to
accommodate the Record Method choices.

Time, or Automatic. You can set the Track display
resolution to High, Medium, Low, and Lowest. You can
also use the Option Menu to delete all saved tracks.

66 Rino® 120 Owner’s Manual

UNIT OPERATION > PROXIMITY PAGE

Proximity Page

The Proximity Page lets you define an alarm circle around
a stored waypoint/contact position, and can be used to
help you avoid dangerous areas or to alert you when you
have strayed too far away from other Rino users. Up
to ten waypoints may be listed, with a maximum alarm
radius of 99.99 nautical or statute miles or kilometers.
If entering a proximity alarm circle, a “Near Proximity

To add a proximity point:

1. Use the Thumb Stick to highlight an empty space
on the Proximity list and press the Thumb Stick
In to display the Find ‘N Go screen. Highlight an
item from the list and press the Thumb Stick In to
open the item.

2. From the Review Page, select Use. Press In again
to begin entry of the proximity radius. Use the
Thumb Stick to enter a distance and press In.

Point <name>” message appears. If leaving a proximity
alarm circle, a “Leaving Proximity Point <name>”
message appears.

To access the Proximity Page:

1. Press the Page key or the Menu icon to open
the Main Menu.

2. In the Main Menu,
scroll down and
select Proximity.

Proximity Waypoints Page

Rino® 120 Owner’s Manual 67

To clear one or all proximity point(s) from the
list:

1. To clear a single alarm, use the Thumb Stick to
highlight the proximity point to clear and press In.
Choose Remove and press In.

2. To clear all proximity waypoints, highlight the

Option Menu and press In. Choose Remove
All and press the Thumb Stick In.

To turn proximity alarms on or off:

1. Use the Thumb Stick to highlight Proximity
Alarms and press In to place a check mark.

UNIT OPERATION > SATELLITE PAGE

45°

90°

Outer ring ­the horizon

Inner ring- 45°
above the horizon

Center dot - 90°
above the horizon

Satellite Page

The Satellite Page provides a picture of satellite signal
tracking, tells you when the unit is ready for navigation,
and shows your location coordinates.

the horizon around you. The inner ring represents a
view above you at a 45° angle from vertical. The center
represents directly overhead. Signal Strength Bars for
each satellite are shown to the left of the Sky View.
Satellites and their signals appear as hollow shapes until

To access the Satellite Page:

1. Press the Page key or the Menu icon to open
the Main Menu.

2. In the Main Menu, scroll down and select
Satellite.

Signal

Strength Bars

Sky View graphic

The Sky View graphic represents a view looking up at
the sky from your current location showing satellites
and their assigned numbers. The outer ring represents

68 Rino® 120 Owner’s Manual

Satellite Page

Skyview

Graphic

a signal is received and then they appear darkened in. The
stronger the signal, the taller the signal bar.

UNIT OPERATION > SATELLITE PAGE

WAAS

WAAS system is only available in the U.S.

The Wide Area Augmentation System (WAAS) capability
produces a more accurate position fix. When enabled
(GPS set to Normal and WAAS set to Enabled through
the System Setup Page; also the interface must be set to
something other than RTCM mode), this feature searches
for WAAS satellites near your location and then receives
data for correcting differentials in the GPS satellite
signals. WAAS satellite numbers begin at number 33
or above and are displayed on the Satellite Page. When
differential correction data has been received for GPS
satellites (numbers 32 or below), a D displays in the
signal bar. It is helpful to orient the unit antenna toward
the WAAS satellite shown in the skyview. To learn more
about the WAAS System, refer to the Federal Aviation
Administration Web site (http://gps.faa.gov/). Because
the Rino 120 relies on satellite signals to provide you
with navigational guidance, the unit’s view of the sky

Satellite Strength

At least three satellite signals are needed to determine
your location; otherwise the unit displays a “Poor
Satellite Reception” message with four options:

Use with GPS Off—Select this option if you want
GPS off.

New Location—Select this option if you have moved
more than 600 miles (from where you last used the unit).

Satellite Page using WAAS

determines how fast you achieve navigational status. GPS
signals do not travel through heavy objects or people. For
best results, keep the unit in clear view of the sky. The

Rino® 120 Owner’s Manual 69

UNIT OPERATION > SATELLITE PAGE

Restart Search—Select this option if today is not date
provided.

Continue Acquiring

—Select this option if no other

option applies. The unit attempts to gather GPS signals.

Satellite Page Options

Use With GPS Off—Use this option when you are
indoors, your view of the sky is obstructed, or you want
to save battery power. You can enter data, create routes,
etc., but cannot navigate in this mode.

Track Up/

skyview by selecting Track Up (your direction of travel)
or North Up (the satellite skyview oriented to the north).

New Location—If you are more than 600 miles (from
where you last used the unit), select the New Location

North Up—You can orient the satellite

To select the Use With GPS Off option:

1. Use the Thumb Stick to highlight the Option
Menu button at the top of the page and then

press it In.

2. Use the Thumb Stick to highlight the Use With
GPS Off option and then press it In.

The Rino 120 stops tracking satellites and cannot

be used for navigation. However, the next time
you turn the unit on, it returns to Normal GPS
operation.

Satellite Page Option Menu

and then the Use Map options to approximate your
location. This gives the unit reference information and
speeds satellite acquisition.

70 Rino® 120 Owner’s Manual

To select Track Up or North Up:

1. Use the Thumb Stick to highlight the Option
Menu button at the top of the page and then

press it In to display the Option Menu.

2. Highlight either the Track Up or North Up option
(depending on which is currently in use), and
press the Thumb Stick In to activate.

To enter a new location:

1. Use the Thumb Stick to highlight the Option
Menu button at the top of the page and then

press it In.

2. Highlight New Location and press the Thumb
Stick In to display choices of Auto or Use Map.

If you choose Automatic the Rino 120 determines

your new location automatically.

If you choose Use Map, a map page displays with

instructions stating, “Point to your approximate
location and press ENTER.” Use the Thumb Stick
to move the map pointer to your location on the
map and press the Thumb Stick In.

UNIT OPERATION > SATELLITE PAGE

Rino® 120 Owner’s Manual 71

UNIT OPERATION > SETUP PAGES

Setup Pages

The Setup Pages allow you to customize the Rino 120 to
your personal preferences. You can choose time settings,
units of measure, display backlighting and contrast
settings, heading measurement, interface options and
system operating mode.

To access the Time Setup Page:

1. Press the Page key or the Menu icon to open
the Main Menu.

2. In the Main Menu, scroll down and select Setup.

3. Select the Time icon to open the Time Setup
Page.

By highlighting the icons on the Setup Menu and then
pressing the Thumb Stick In, you can display the Setup
Page for each of the menu items.

To access the Setup Menu:

1. Press the Page key or the Menu icon to open
the Main Menu.

2. In the Main Menu, scroll down and select Setup.
There are then several more icons to choose from
in the Setup Menu.

Time Format—Allows you to choose from 12-hour (like
a standard clock with 12-hour AM and PM cycles) or 24­hour time format ( a 24-hour cycle, also called Military

Time Setup Page

Time).

Time Setup Page

You can set the time to match your location or for a
projected location anywhere in the world.

72 Rino® 120 Owner’s Manual

UNIT OPERATION > SETUP PAGES

Time Zone—Can be set to one of the eight US Time
Zones or 24 International Time Zones (nearest city or
geographical region). Select Other so you can enter the
UTC Time Offset.

Daylight Savings Time—Can be turned On or Off or set
to Automatic.

6. If you choose
value. The correct time displays at the bottom of
the page.

Units Setup Page

The Units features are best used by individuals with a
working knowledge of map grids and datums. To learn

Other, you must enter a UTC offset

more about these subjects, visit the National Imagery and

To set the time:

1. Use the Page key to access the Main Menu.

2. Use the Thumb Stick to highlight the Setup Icon.
Press the Thumb Stick In to display the Setup
Menu.

3. Use the Thumb Stick to highlight the Time Icon.
Press the Thumb Stick In to display the Time
Page.

4. Use the Thumb Stick to highlight the Time Zone
field. Press the Thumb Stick In to display the time
zone list.

5. Highlight a time zone from the list and then press
the Thumb Stick In.

Rino® 120 Owner’s Manual 73

Mapping Agency at http://www.nima.mil or inquire at
your local library.

To access the Units Setup Page:

1. Press the Page key or the Menu icon to open
the Main Menu.

2. In the Main Menu, scroll down and select Setup.

3. Select the Units icon to open the Units Setup
Page.

Units Setup Page

UNIT OPERATION > SETUP PAGES

Position Format—Allows you to choose from different
grid formats. The default position format, ‘hddd°mm.
mmm’ displays the latitude and longitude in degrees
and minutes and is most commonly used. The following
additional formats are available:

hddd.ddddd°—latitude/longitude in decimal degrees;
hddd°mm.mmm’—latitude/longitude in decimal
numbers; hddd°mm’ss.s”—latitude/longitude in degrees,
minutes, seconds; British Grid; Dutch Grid; EOV
Hungarian Grid; Finnish Grid; German Grid; Icelandic
Grid; India Zones; Irish Grids; Loran TD; Maidenhead;
MGRS; New Zealand; QNG Grid; RT90; South African
Grid; Swedish Grid; Swiss Grid; Taiwan Grid; US
National Grid; UTM/UpS—Universal Transverse
Mercator / Universal Polar Stereographic grids; W
Malayan RSO; and User UTM Grid.

LORAN TD Format

When creating new waypoints using LORAN TD
coordinates, you must set the correct LORAN chain

before storing the waypoint. After the waypoint is stored
in unit memory, it always references the LORAN chain
number and secondary stations currently selected in the
Setup TD field. If you enter a different LORAN chain
number or change the secondary stations or offsets in the
Setup TD field, the active waypoint information reflects
those changes. Because the unit does not rely on the
LORAN signal for navigation, it can reference a different
GRI chain and/or secondary stations and still navigate to
the location stored in memory.

To adjust the Loran TD settings, select Loran TD

as the
Position Format to open the Loran TD setup window. To
change the settings of any fields, highlight the field, and
press the Thumb Stick In. When done, highlight Save
and press In.

For more information on Loran TDs, you may download
Garmin’s

Loran TD Position Format Handbook from
the Garmin Web site at http://www.garmin.com/support/

userManual.jsp.

number and secondary stations in the Setup TD field

74 Rino® 120 Owner’s Manual

UNIT OPERATION > SETUP PAGES

Map Datum—Offers a selection of nearly all map
datums in common use. Every map is based on a map
datum (a reference model of the earth’s shape) and is
usually listed in the title block of the map. If you are
comparing GPS coordinates to a paper map, chart, or

NOTE: The User datum is based on a WGS-84-Lo­cal datum and is an advanced feature for unlisted
or custom datums. To learn more, check your local
library or the Internet for educational materials on
datums and coordinate systems.

other reference, the map datum in this field must match
the horizontal map datum used to generate the map or
other reference. The default datum is WGS-84 (World

Distance/Speed—Choose from three units of measure to
display your rate of travel.

Geodetic Survey 1984) and should only be changed when
using maps or charts specifying a different datum. If a
map does specify a datum, use the options list to find
datums applicable to the region of the map, selecting the
one that provides the best positioning at a known point.

Elevation/Vertical Speed

measure to record your elevation and vertical speed.

Pressure

the pressure.

—Choose from millibars or Inches to measure

—Choose from two units of

If necessary, you also may choose the User datum for
custom designed grids.

Display Setup Page

You can adjust the amount of time that the backlighting
feature stays on and adjust the screen contrast.

Backlighting Timeout

—Choose from Stays On or
delays of 15 seconds, 30 seconds, one minute, or two
minutes before timing out.

Rino® 120 Owner’s Manual 75

UNIT OPERATION > SETUP PAGES

Contrast Adjustment—Can be adjusted from light to
dark using the slider adjacent to the contrast bar.

To access the Display Setup Page:

1. Press the Page key or the Menu icon to open
the Main Menu.

2. In the Main Menu, scroll down and select Setup.

3. Select the Display icon to open the Display Setup
Page.

To adjust the contrast:

1. Highlight the contrast slider and then press the
Thumb Stick In.

2. Move the Thumb Stick Up or Down to move the
slider to increase or decrease the contrast.

Heading Setup Page

You can select the type of heading displays, the types of
North References, or enter the magnetic variation.

To access the Heading Setup Page:

1. Press the Page key or the Menu icon to open
the Main Menu.

2. In the Main Menu, scroll down and select Setup.

3. Select the Heading icon to open the Heading

Display Setup Page

Setup Page.

To set the backlighting timeout:

1. Highlight the Backlight Timeout field and then
press the Thumb Stick In.

2. Highlight the desired option and then press the
Thumb Stick In.

76 Rino® 120 Owner’s Manual

Heading Setup Page

UNIT OPERATION > SETUP PAGES

Display—Allows you to choose from Cardinal Letters,
Degrees or Mils.

North Reference—You can choose from True, Magnetic,
Grid or User options. If User is chosen, you must correct
for the Magnetic Variation.

To access the Interface Setup Page:

1. Press the Page key or the Menu icon to open
the Main Menu.

2. In the Main Menu, scroll down and select Setup.

3. Select the Interface icon to open the Interface
Setup Page.

To select either option:

1. Highlight the field and then press the Thumb
Stick In to display the options.

2. Highlight the option and press the Thumb Stick In
to activate.

Interface Setup Page

The Interface Setup Page allows you to choose from
different input/output serial data formats. This feature
is used when connecting to external NMEA devices, a
DGPS beacon receiver, a personal computer, etc. See the
“Appendix” for using the Rino 120 with MapSource.

The available interface formats are:

Garmin—The proprietary format used to exchange
waypoint, track, and map data with a PC. Use this setting
for transferring data when using a MapSource product.

Interface Setup Page

Garmin DGPS—Allows DGPS input using a Garmin
beacon receiver and a standard RTCM SC-104 and DGPS
tuning.

Rino® 120 Owner’s Manual 77

UNIT OPERATION > SETUP PAGES

NMEA In/NMEA Out—Supports the output of standard
NMEA 0183 version 3.0 data. Use this for real-time
plotting with MapSource or 3rd party programs.

Text Out—Allows ASCII text output of location and
velocity information without input capabilities.

RTCM IN—Allows DGPS input using a standard RTCM

If Garmin DGPS or RTCM In/NMEA Out format
is selected, additional fields are provided to control
a Garmin differential beacon receiver (e.g. GBR 23)
directly from your unit. Tuning is automatic with Scan
or you can enter the beacon frequency and bit rate when
you select User from the Beacon list to manually tune the
receiver. Refer to the beacon receiver instructions.

SC-104 format without output capabilities.

To select a serial data format:

RTCM In/NMEA Out

standard RTCM SC-104 format and supports the output
of standard NMEA 0183 version 3.0 data.

RTCM In/Text Out

—Allows DGPS input using a

—Allows DGPS input using a

1. Highlight the Serial Data Format field and then
press the Thumb Stick In.

2. Highlight an option and then press the Thumb
Stick In to activate it.

standard RTCM SC-104 format and simple ASCII text
output of location and velocity information.

None—Provides no interfacing capabilities.

Interface Setup Page

78 Rino® 120 Owner’s Manual

UNIT OPERATION > SETUP PAGES

System Setup Page

The System Setup Page allows you to change GPS
operation modes, use the WAAS capabilities, turn the
Message Beep on or off, and choose the battery type. See
the “Appendix” for WAAS capability information.

To access the System Setup Page:

1. Press the Page key or the
Menu icon to open the

Main Menu.

2. In the Main Menu, scroll
down and select Setup.

3. Select the System icon to
open the System
Setup Page.

System Setup Page

Choose one of the four GPS options other than Normal
to significantly save battery power. The Battery Saver
mode reduces the rate of satellite signal position updating
and the GPS Off option stops satellite signal reception
altogether. The Demo Mode simulates navigation.

To

change the battery type:

1. Use the Thumb Stick to highlight the Battery
Type field and then press In.

2. Then use the Thumb Stick to select the desired
option and press In.

The Option Menu allows you restore defaults or
display the current version of unit operating software and
the Unit I.D. Number. Software updates and instructions
for downloading are available from the Garmin Web site
(www.garmin.com).

Rino® 120 Owner’s Manual 79

UNIT OPERATION > CALENDAR

Calendar

This feature provides you with a monthly calendar with
programmable reference notes. You can display one
monthly calendar at a time and add reference notes using
the data entry keypad. Days that are shaded have notes
added. You can create reference notes for multiple months
and for months in years yet to come. You can record 100
notes with up to 18 characters each.

To change the month and year:

Highlight the left or right arrows on either side

of the date and press the Thumb Stick In. The
left arrow shows past months/years and the right
arrow shows future months/years.

To use the current month and year

Choose Set To Current Date from the Option

Menu .

To create a reference note for a selected date:

1. Use the Thumb Stick to highlight the day of the
month and then press In to display the pop-up
Menu (containing New Note, View Sun & Moon,
and View Hunt & Fish).

2. Highlight and select New Note to begin entering

Calendar Page

text from the keyboard.

To access the Calendar:

1. Press the Page key or the Menu icon to open
the Main Menu.

2. In the Main Menu, scroll down and select
Calendar.

80 Rino® 120 Owner’s Manual

UNIT OPERATION > CALENDAR

To edit or delete a note:

1. To edit or delete a note previously created,
highlight the date and press the Thumb Stick In.

2. Select Edit Note, or Delete Note, from the pop-up
menu. To complete the deletion of the note, press
the Thumb Stick In when Yes is highlighted in the
pop-up window.

3. To edit the note, change the desired characters
using the keyboard as shown in the image to the
right. Press OK when you are finished editing the
note.

Editing a note

Rino® 120 Owner’s Manual 81

To delete notes by week:

1. Choose Delete Notes... from the Option
Menu .

2. From the Older Than... window, choose the
desired option and press the Thumb Stick In.

To view information for a date:

1. In the calendar, select the desired date using the
Thumb Stick.

2. Review the note in the note window below the
calendar.

3. Press the Thumb Stick In to display the pop-up
menu.

4. Select View Sun & Moon to view the Sun & Moon
Page for that date. Select View Hunt & Fish to
view the Hunt & Fish Page for that date.

UNIT OPERATION > ALARM CLOCK

Alarm Clock

This feature provides an alarm for the system clock. Enter
a time in the time field and turn the alarm on and off from
the control field menu. Remember to enter alarm times
in the same time format (UTC or local) you are using for
your system. The unit must be on for the alarm clock to
work.

To turn the alarm clock On/Off:

To access the Alarm Clock:

1. Press the Page key or the Menu icon to open
the Main Menu.

2. In the Main Menu, scroll down and select

Alarm Clock.

To set an alarm clock time:

1. Use the Thumb Stick to highlight the time field
and then press In to display the keyboard.

2. Use the Thumb Stick to enter the desired time,
choose OK and press In.

1. Use the Thumb Stick to highlight the Alarm

2. Choose On or Off and press the Thumb Stick In.

When the alarm sounds, a brief tone is heard (unless
Message Beep is Off under System Setup) and “Alarm
Clock” appears on the screen. Press the Thumb Stick In
to acknowledge the alarm.

Alarm Clock Page

Mode field and then press In to display the

options.

82 Rino® 120 Owner’s Manual

UNIT OPERATION > CALCULATOR

Calculator

This feature provides you with all the basic functions of
both a standard or scientific calculator. You can perform
most calculations identified by the function symbols
along the sides of the keypad and can save the results
temporarily in the memory. The memory is cleared either
manually or when you turn off the Rino 120.

To access the Calculator:

1. Press the Page key or the Menu icon to open
the Main Menu.

2. In the Main Menu, scroll down and select

Calculator.

Calculator Page

Rino® 120 Owner’s Manual 83

To change calculator options:

1. Highlight the page Option Menu and press
the Thumb Stick In to display the Scientific/
Standard and Radian/Degrees options.

2. Highlight the option you want to change and then
press the Thumb Stick In.

3. Use the Thumb Stick to move about the
calculator, enter numbers, and perform
calculations.

UNIT OPERATION > STOPWATCH

Stopwatch

This feature allows you to use the unit as a stopwatch,
including using it as a lap timer. You may also have the
unit record the lap time based on distance. For example,
if you set the lap distance to one mile, the unit records the
time it takes you to travel one mile.

To access the Stopwatch:

1. Press the Page key or the Menu icon to open
the Main Menu.

2. In the Main Menu, scroll down and select the

Stopwatch icon.

To use the Stopwatch:

1. Use the Thumb Stick to highlight the Start field
and then press In. You may also press the Volume
(V) key to start the stopwatch.

2. Use the Thumb Stick to highlight the Stop field
and then press In. You may also press the Volume
(V) key to stop the stopwatch.

84 Rino® 120 Owner’s Manual

3. To mark a lap, use the Thumb Stick to highlight
the Lap field and then press In with the stopwatch
running. You may also press the Zoom (Z) key to
capture the lap time.

4. Reset the stopwatch when the timer is stopped.
Use the Thumb Stick to highlight the Reset field
and then press In. You may also press the Zoom
(Z) key to reset the times.

Stopwatch Lap Options

You can set the stopwatch to Lap by Distance so that
each time a certain distance has been travelled, the
stopwatch automatically marks a lap. You can enter a
specific lap distance by selecting Set Lap Distance. To
return to manually marking each lap, open the Option
Menu and select the Lap by Button Press option.

Stopwatch Page

UNIT OPERATION > SUN & MOON

Sun & Moon

This feature provides you with a graphic display of both
sun and moon positioning for a certain date, time and
location with times for sunrise, sunset, moonrise, and
moonset.

To access the Sun & Moon Page:

1. Press the Page key or the Menu icon to open
the Main Menu.

2. In the Main Menu, scroll down and select the Sun

& Moon icon.

To view information for a different date and

To set the location:

1. Highlight the Location field and then press the
Thumb Stick to display the New Location

options list.

2. Highlight the option desired and then press In
on the Thumb Stick to activate. If you choose
Current Location, the field values displayed on
the page displays your location. If you choose Use
Map, a map page displays. Use the map pointer
to identify the desired location and then press In
on the Thumb Stick. If you choose Use Find ‘N
Go Menu follow instructions in the “Find ‘N Go”
section.

time:

1. To view the sun and moon information for a
specific date or time, highlight each field, then
press the Thumb Stick In to begin data entry of
individual characters.

2. To display the current date and time, highlight the
page Option Menu and press the Thumb

Stick In to display Use Current Time. Press the
Thumb Stick In.

Rino® 120 Owner’s Manual 85

Sun & Moon Page

UNIT OPERATION > HUNT & FISH

Hunt & Fish

This feature provides you with a listing of best times for
hunting and fishing for a chosen location and date.

To access the Hunt & Fish Page:

1. Press the Page key or the Menu icon to open
the Main Menu.

2. In the Main Menu, scroll down and select the Hunt
& Fish icon.

2. Highlight the option desired and then press In
on the Thumb Stick to activate. If you choose
Current Location, the field values displayed on
the page reflect the times at your current location.

3. If you choose Use Map, a map page displays. Use
the map pointer to identify the desired location and
then press In on the Thumb Stick. If you choose
Use Find ‘N Go Menu, follow instructions for
using the Find ‘N Go Menu.

To view information for a different date:

1. Highlight the date field and then press In on the
Thumb Stick to begin data entry of individual
characters.

2. To display the current date, highlight the page
Option Menu and press the Thumb Stick In to
display the Use Current Date option. Press the

Thumb Stick In.

To set the location:

1. Highlight the Location field and then press In on
the Thumb Stick to display the New Location
options list.

86 Rino® 120 Owner’s Manual

NOTE: The times displayed are the recognized best
and good times for hunting and fishing. Be certain
that they are not in conflict with state and local game
laws, which may vary from location to location. It is
your responsibility to know and abide by these laws.

Hunt & Fish Page

Area Calculator

This feature provides you an area calculation as you
move about a location or view a saved track. The area
calculation displays in acres, hectares, and square feet,
square yards, square meters, square kilometers, and
square miles.

UNIT OPERATION > AREA CALCULATOR

Area Calculation Page

To access the Area Calculator:

1. Press the Page key or the Menu icon to open
the Main Menu.

2. In the Main Menu, scroll down and select the Area

Calculator icon.

To review the area of a saved track:

1. On the Tracks Page, highlight a Saved Track.

2. Press the Thumb Stick In to see a map with the
area shown in a data field at the bottom.

To calculate the area:

1. Be sure the Rino 120 has a GPS fix.

2. Press Start when you are ready to begin.

3. Begin walking or traveling the perimeter (edge) of
the area you want to measure.

4. Use the Thumb Stick to stop the calculation when
you have traveled the desired distance.

5. Use the Thumb Stick to store the area as a saved
track.

Rino® 120 Owner’s Manual 87

UNIT OPERATION > GAMES

Games

The Games Page includes Memory Race, Waypoint

Play by yourself or race against others. Press Page to quit
at any time.

Bomber, Clothesline, Assimilation and Beast Hunt.
Highlight the appropriate icon and then press the Thumb
Stick In to play the desired game. Brief instructions are
displayed when you start each game. All players must be
on the same channel/squelch code to play.

Memory Race

To adjust the Grid Size or Square Size:

1. Highlight the Grid Size or Square Size field and
press In on the Thumb Stick.

Games Menu

2. Choose the desired size and press In.

3. Highlight Start and press In to begin the game.

Memory Race

Be the first to clear the board by matching all of the two
symbols sets together. Each symbol is in a square (you
can adjust the size) that you need to walk or travel to.
Once your position appears in a square, highlight Open at
the bottom of the screen and press the Thumb Stick In.

88 Rino® 120 Owner’s Manual

UNIT OPERATION > GAMES

Waypoint Bomber

In this game, it is good to stay on the move! Two or
more players attempt to “bomb” each other. Move your

HINT: Mark stationary objects such as trees and
poles, and drop a bomb when an opposing player is
near that object! Adjust the rules to your liking!

cursor around on the Map Page using your Thumb Stick.
When you think an opponent is close to your cursor,
drop a bomb. The receiving radio shows an “Incoming”
message. If the receiving radio is within the blast circle
(about 45 feet), it displays a message that you have been
hit. You must wait 30 seconds between shots to reload.
Either have a timed game with the winner being the one

• To fire at the cursor location, press the Thumb
Stick In.

• To fire at your current location, press the Talk key.

• Press

• Press

Call to view the scoreboard at any time.

Page to quit the game at any time.

with the least amount of hits on their radio, or play until
someone gets a specified number of hits (that person
loses).

Waypoint Bomber

Rino® 120 Owner’s Manual 89

UNIT OPERATION > GAMES

Clothesline

Team members select the same user symbol and then
attempt to “hit” or “clothesline” other players by pressing
the Talk key when an opposing team member is between
them. You may also mark a point and assign it a symbol
to be used as a stationary team member. Wait 30 seconds
between attempts. Press Call to view the score and Page
to quit the game.

pits while navigating a maze of platforms. You can be
transported by slides that curve or move diagonally.
When you think you know where the beast is press the
Thumb Stick In to initiate aiming when you are in an
adjacent spot. With the Thumb Stick, point the arrow
in the direction where you think the beast is and press
the Thumb Stick In to fire. When you lose a game, the
layout of hazards, slides, warning platforms, and the
location of the beast is shown. A scoreboard keeps track

Assimilation

Think of this as a high-tech game of tag. Team members
select the same user symbol and then attempt to

of your wins and losses. Press Page any time during the
game for further instructions, to turn the sound On/Off, or

to quit.
assimilate others into their team by getting within 30 feet
of them and pressing the Talk key. Press Call to show the
score and Page to quit the game. You can set a time limit
so the largest team wins, or play until the other team is
completely assimilated. Set your own rules and enjoy!

Beast Hunt

Beast Hunt

The objective is to find and kill the beast with an arrow
before it incinerates you or you fall into one of several

90 Rino® 120 Owner’s Manual

APPENDIX > SPECIFICATIONS

Specifications

Acquisition time:
Approx. 15 seconds (warm start)

Physical

Case: Fully-gasketed, high-impact plastic alloy,

Approx. 45 seconds (cold start)
Approx. 5 minutes (First Time/AutoLocate®)

waterproof to IPX7 standards
(waterproof to one meter for 30 minutes)

Size: 4.5” H x 2.3” W x 1.6” D; 7” H with antenna
(11.4 x 5.8 x 4.1; 17.8 cm)

Weight: Approx. 7.6 ounces (236 g) with batteries

Temperature Range:

-4° to 158° F (-20° to 70° C) (operating range)

Update Rate: 1/second, continuous

GPS Accuracy: <15 meters (49 ft) RMS, 95% typical

DGPS (USGC) Accuracy: 3–5 meters (10–16 ft), 95%

typical with DGPS corrections

2

DGPS (WAAS) Accuracy:
<3 meters (10 ft), 95% typical with
DGPS corrections

2

Display: 1.4” H x 1.4” W (3.6 cm x 3.6 cm)
160 x 160 pixels, high-contrast LCD

Performance

GPS Receiver:
WAAS Enabled, Differential-ready,
12 parallel channel

Velocity Accuracy: 0.05 meter/sec steady state

Dynamics: Performs to specifications to 6 g’s

Interfaces: NMEA 0183, RTCM 104

(for DGPS corrections)
and RS-232 for PC interface

Antenna: Quad-helix

Rino® 120 Owner’s Manual 91

1

APPENDIX > SPECIFICATIONS

Radio

Channels: 1–14 FRS,
15–22 GMRS (GMRS requires FCC license)
15R–22R GMRS Repeater Channels

Squelch Codes: 1–38

Range: Up to 2 miles on FRS; up to 5 miles on GMRS

Radio Output Power:

FRS 0.5 watt; GMRS 1.0 watt

Power

Input: Three 1.5 Volt AA batteries

Battery Life:

GPS only: up to 41 hours;
FRS only: up to 20 hours;
FRS and GPS: up to 14 hours

92 Rino® 120 Owner’s Manual

3

4

Specifications are subject to change without notice.

1

Subject to accuracy degradation to 100m 2DRMS under the U.S.

DoD-imposed Selective Availability program.

2

With optional Garmin Differential Beacon Receiver Input (such as

Garmin GBR 23).

3

The temperature rating for the Rino 120 may exceed the usable
range of some batteries. Alkaline batteries can rupture at high
temperatures. External power can only be applied using the
Garmin Auto Power Adapter or PC Interface Cable with Auto
Power Adapter. These cables contain a 12 VDC to 4.5 VDC
voltage regulator. Modifications or other applications voids the
product warranty. Alkaline batteries lose a significant amount of
their capacity as temperature decreases. Extensive use of screen
backlighting and the radio significantly reduces battery life.
Different brands of batteries vary in performance.

4

5, 5, 90 Duty Cycle - 5% receive with audio unmuted, 5%
transmit and 90% standby (receive with audio muted)

APPENDIX > ACCESSORIES

Accessories

To obtain accessories, see your local dealer or visit the
Garmin Web site at www.garmin.com.

12-Volt Adapter Cable

automobile cigarette lighter.

2.5 to 3.5 mm Jack Adapter

party headsets with your Rino unit.

Bash Guard Kit—Helps protect the Rino’s edges against
hard shocks. Includes 2 bash guards, quick-release neck
lanyard, and belt clip.

Carrying Case—Protects the Rino and permits use while
in the case.

Earbud with PTT (Push To Talk) Mic

clip-on mic with PTT button.

Flexible Ear Receiver

easier to hear your Rino.

Rino® 120 Owner’s Manual 93

—Provides unit power from an

—Allows you to use 3rd

—Earbud and a

—Comfortable ear piece makes it

Headset with VOX Boom Mic

Utilize the Rino’s VOX (Voice Operated Transmission)
feature with this headset and voice activated boom mic.

Instructional Video

Rino basic operations quickly.

MapSource Map Data CD-ROMs

tool for creating waypoints and routes on your PC and
downloading them to your Rino.

NiMH Battery Charger—Includes NiMH battery
charger and 4 AA NiMH batteries.

PC Data Cable and 12-Volt Adapter

of waypoints and routes from a PC to the Rino and
provides unit power from an automobile cigarette lighter.

Rail/Handlebar Mount

Rino on most rails or handlebars.

Suction Cup Mount—Allows you to mount your Rino
on most smooth surfaces or windshields.

—For getting accustomed to your

—Hands-free at its best!

—An excellent

—Allows transfer

—Allows you to mount your

APPENDIX > TRANSFERRING MAPSOURCE DATA

Transferring MapSource Data

If you have purchased a Garmin MapSource CD-ROM
mapping program, you may want to transfer detailed
map data before beginning use to provide your unit with
maximum Find features and mapping capability. The
Rino 120 accepts up to 8 MB of map data from most
MapSource products. It is not possible to transfer 3rd
party maps into Garmin products.

You cannot view multiple types of MapSource data in the
same location at the same time (one replaces the other if
there is an overlap). When you leave a MetroGuide area
for example and enter the area of a topographic map, the
display changes to contour lines. The same is true when
moving from a topo map to a MetroGuide map. The
BlueChart maps are at the top of the hierarchy and will
replace any other map information. Here is the list of the
hierarchy for your reference:

94 Rino® 120 Owner’s Manual

1. BlueChart

2. MetroGuide

3. Fishing Hot Spots

4. Points of Interest

5. U.S. Waterways & Lights

6. U.S. Topo

7. Roads and Recreation

8. WorldMap

Map data transfer requires the use of a PC, a Garmin
MapSource CD-ROM, and the PC Interface Cable with
RS-232 serial port connector supplied with this unit.
Follow detailed instructions for data transfer in the
MapSource User’s Manual.
