ENCOUNTER
SERVICE MANUAL
AMPLIFIER MODEL
EN−AM6001
1/4
Part Number Items Q'ty Position
0
ASY-ENAM6001
1…
WZ-ENAM6001
2…
DIO1N4004R diode 1 D1
2…
DIO1N4148R diode 7 D3.D5~6.D8~11
2…
ECT016V107MDR capacitor 1 C118
2…
ECT016V226MDR capacitor 1 C11
2…
ECT016V477MDR capacitor 1 C22
2…
ECT025V107MBR capacitor 1 C14
2…
ECT025V226MDR capacitor 1 C10
2…
ECT050V100KTR capacitor 1 C104
2…
ECT050V101KTR capacitor 1 C109
2…
ECT050V103KTR capacitor 1 C40
2…
ECT050V104KTR capacitor 9 C2~3.C5.C17.C20~21.C113.C117.C119
2…
ECT050V105MBR capacitor 1 C15
2…
ECT050V105MDR capacitor 3 C12~13.C120
2…
ECT050V221KTR capacitor 1 C112
2…
ECT050V470KTR capacitor 3 C114~116
2…
ECT050V680KTR capacitor 1 C103
2…
ECT050V681KTR capacitor 1 C16
2…
ECT050V684MDR capacitor 2 C102.C202
2…
ECT100V104DSR capacitor 2 C6.C121
2…
ECT100V154DSR capacitor 1 C108
2…
ECT100V224DSR capacitor 1 C107
2…
ECT100V472DSR capacitor 1 C7
2…
ECT100V473DSR capacitor 2 C8~9
2…
ECT100V823DSR capacitor 1 C105
2…
PCBEN60011AR PCB 1
2…
RESCF121Y101JR Resistor 7 R9.R130~131.R135~136.R151~152.
2…
RESCF121Y102JR Resistor 11
R27~28.R32~33.R45.R126.R128~129.R133~134.R14
4
2…
RESCF121Y103JR Resistor 12
R6.R11~12.R18.R20.R22.R107.R113.R125.R132.R13
7.R154
2…
RESCF121Y104JR Resistor 3 R7.R19.R122
2…
RESCF121Y113JR Resistor 1 R111
2…
RESCF121Y122JR Resistor 1 R15
2…
RESCF121Y123JR Resistor 2 R3.R143
2…
RESCF121Y152JR Resistor 2 R24.R153
2…
RESCF121Y181JR Resistor 1 R1
2…
RESCF121Y182JR Resistor 1 R108
2…
RESCF121Y183JR Resistor 1 R17
2…
RESCF121Y203JR Resistor 2 R104.R204
2…
RESCF121Y205JR Resistor 1 R16
2…
RESCF121Y222JR Resistor 4 R30~31.R42.R127
2…
RESCF121Y223JR Resistor 1 R106
2…
RESCF121Y242JR Resistor 1 R117
2…
RESCF121Y272JR Resistor 1 R139
EN-AM6001 Material List
2/4
2…
RESCF121Y302JR Resistor 2 R10.R25
2…
RESCF121Y331JR Resistor 1 R142
2…
RESCF121Y332JR Resistor 1 R116
2…
RESCF121Y392JR Resistor 2 R46.R114
2…
RESCF121Y393JR Resistor 1 R48
2…
RESCF121Y432JR Resistor 1 R138
2…
RESCF121Y470JR Resistor 2 R140~141
2…
RESCF121Y472JR Resistor 5 R4.R13.R109.R149~150
2…
RESCF121Y473JR Resistor 3 R5.R115.R118
2…
RESCF121Y4R7JR Resistor 5 R2.R8.R21.R26.R119
2…
RESCF121Y563JR Resistor 2 R29.R110
2…
RESCF121Y564JR Resistor 1 R121
2…
RESCF121Y681JR Resistor 1 R120
2…
RESCF251Y100JR Resistor 4 R34~37
2…
RESCF251Y102JR Resistor 1 R47
2…
RESCF251Y103JR Resistor 2 R39~40
2…
TRA2N4401R Triode 2 Q1.Q115
2…
TRA2N4403R Triode 4 Q3~6
2…
TRAA06R Triode 3 Q102~103.Q108
2…
TRAA56R Triode 3 Q104~106
2…
WIR060R6R Jumper 8 J1~2.J9.J11~12.J23.J26.J43
2…
WIR100R6R Jumper 11 J3~6.J8.J10.J20.J25.J27.J31~32
2…
WIR12R50R6R Jumper 8 J14~15.J21~22.J28~29.J33.J46
2…
WIR17R50R6R Jumper 9 J13.J16.J30.J34.J41~42.J47.J49~50
2…
WIR200R6R Jumper 8 J7.J17.J18~19.J24.J35.J44~45
2…
WIR220R6R Jumper 5 J36~37.J39~40.J48
2…
ZD1N4744R diode 2 ZD3~4
2…
ZD1N5239BR diode 1 ZD2
2…
ZD1N5241BR diode 1 ZD1
1…
WS-ENAM6001 1
2…
DIO1N5402R diode 1 D14
2…
DIOFMG22RR diode 1 D13
2…
DIOFMG22SR diode 1 D12
2…
ECT016V108MDR capacitor 1 C23
2…
ECT025B228MER capacitor 2 C1.C4
2…
ECT050B228MDR capacitor 2 C18~19
2…
ERT154KR varistor 1 RT1
2…
FAN01602RR pipe 1
2…
FUS1JK202R fuse holder 1 FUSE1
2…
ICBA4558D8PR IC 1 IC1
2…
ICBA4558S8PR IC 3 IC101~103
2…
ICKIA494PR IC 1 IC2
2…
ICPC17K1R IC 1 IC3
2…
IND3U1R2P5R Inductor 1 L1
2…
LEDRGR302R LED 1 LED1
2…
MOSIRFZ44NR mosfet 4 Q7~10
2…
RCAJU4RWAR RCA 1 RCA1
2…
RESCEM502NR10KR Resistor 4 R145~148
2…
RESMO102P220JR Resistor 1 R38
2…
RESMO102P4R7JR Resistor 1 R155
3/4
2…
RESMO102P681JR Resistor 2 R43~44
2…
ST3DOWHI002R Terminals 1 CON1
2…
ST4DOWHI002R Terminals 1 CON2
2…
SW12P3T06002R Power switch 1 SW1
2…
TRA2SA1694R Transistor 2 Q113~114
2…
TRA2SC4467R Transistor 2 R111~112
2…
TRA2SC945R Transistor 1 Q101
2…
TRAA06R Triode 1 Q107
2…
TRAKTB631KR Transistor 1 Q110
2…
TRAKTD600KR Transistor 1 Q109
2…
TRR29618001R Transformer 1 TR1
2…
VRRB50301J1501R VR 2 VR2.VR4
2…
W020831002R copper pad 1 01~02
2…
W051P2207001R ground wire 1 GND
1…
E-ENAM6001
2…
FUS0430R032VR fuse 1
1…
A-ENAM6001
2…
BRA0300102R BAR 3
2…
BRA0420102R BAR 2
2…
BRAPP400201R Bracket 4
2…
BZB20100T5R BZ 1 For slide switch
2…
ECEN300201R plastic endcap 1
2…
ECEN300202R plastic endcap 1
2…
EVA08125TR EVA foam 1 Q107
2…
FPEN6001R front panel 1
2…
HSEN6001R heatsink 1
2…
INN08030T7R insulation pad 4 For copper pole
2…
RPEN6001R rear panel 1
2…
SC5R0901R copper pole 4 To fix PCB
2…
SD3R3LZR pad 1 For ground wire
2…
SD8R0GZR pad 1 For varistors
2…
SF3R0DHR screw nut 4 For panels
2…
SIP035240101R pad 2
2…
SIP048290101R pad 2
2…
SM3R006PKR screw 8 For copper pole and side panel
2…
SM3R008SKR screw 4 For end caps
2…
SM3R014SKR screw 1 For plastic ones
2…
SM4R013GKR screw 5 For bars
2…
SP2R006PKR screw 2 For fuse holder
2…
SP3R005PKR screw 2 For varistors and ground wire
SP3R006PKR screw 4 For bracket
SP3R008PKR screw 11
For front panel、RCA、terminal
1…
B-ENAM6001
2…
BCEN6001R Bottom chassis 1
2…
BGF350360R PE bag 1
2…
BOXEN6001R master carton 0.25
2…
EVA081750T5R EVA pad 2 For bottom chassis
2…
GIBEN6001R Giftbox 1
2…
INSEN6001R manual 1
