COLOR GPS/PLOTTER/SOUNDER

GP-3500F

9-52 Ashihara-cho,9-52 Ashihara-cho,

*00014678100**00014678100*

*OME44212D00**OME44212D00*

Nishinomiya, JapanNishinomiya, Japan

Telephone :Telephone : 0798-65-21110798-65-2111 faxfa

ll rights reserved.

PUB.No.PUB.No. OME-44212OME-44212

0798-65-42000798-65-4200

Printed in JapanPrinted in Japan

Your Local Agent/DealerYour Local Agent/Dealer

IRST EDITION :

IRST EDITION : JUL.JUL. 20032003

DD :: SEP.SEP. 24,200324,2003

(( HIMAHIMA ))

GP-3500FGP-3500F

* 0 0 0 1 4 6 7 8 1 0 0 ** 0 0 0 1 4 6 7 8 1 0 0 *

*OME44212D00**OME44212D00*

* O M E 4 4 2 1 2 D 0 0 ** O M E 4 4 2 1 2 D 0 0 *

SAFETY INSTRUCTIONS

WARNING

ELECTRICAL SHOCK HAZARD

Do not open the equipment.

Only qualified personnel should work inside the equipment.

Do not disassemble or modify the equipment.

Fire, electrical shock or serious injury can result.

Immediately turn off the power at the switchboard if the equipment is emitting smoke or fire.

Continued use of the equipment can cause fire or electrical shock. Contact a FURUNO agent for service.

Make sure no rain or water splash leaks into the equipment.

Fire or electrical shock can result if water leaks in the equipment.

Do not operate the unit with wet hands.

Erectlic shock can result.

Do not maneuver the vessel based on the depth indication alone.

Grounding may result.

CAUTION

Use the proper gain seting.

Incorrect gain may produce wrong depth indication, possibly resulting in a dangerous situation.

The picture is not refreshed when picture advancement is stopped.

Maneuvering the vessel in this condition may result in a dangerous situation.

Do not turn on the equipment with the transducer out of water.

The transducer may be damaged.

No single navigation aid should even be relied upon as the exclusive means for navigating your vessel.

The navigator is responsible for checking all aids (including nautical charts) available to confirm his position. Electronic aids are intended to assist, not replace, the navigator.

No one navigation device should ever be solely replied upon for the navigation of a vessel.

Always confirm position against all available aids to navigation, for safety of vessel and crew.

WARNING LABEL

A warning label is attached to the equipment. Do not remove the label. If the label is missing or damaged, contact a FURUNO agent or dealer about replacement.

To avoid electrical shock, do not remove cover. No user-serviceable parts inside.

WARNING

Name: Warning Label (1) Type: 86-003-1011-1 Code No.: 100-236-231

Do not use the equipment for other than its intended purpose.

About the TFT LCD

The TFT LCD is constructed using the latest LCD techniques, and displays

99.99% of its pixels. The remaining 0.01% of the pixels may drop out or blink, however this is not an indication of malfunction.

FOREWORD

Congratulation on your choice of the FURUNO COLOR G PS/PLOTTER/ SOUNDER GP-3500F. For over 50 years FURUNO Electric Company has enjoyed an enviable reputation for innovative and dependable marine electronics equipment. This dedication to excellence is furthered by our extensive global network of agents and dealers.

The equipment is designed and constructed to meet the rigorous dem ands of the marine environment. However, no machine can perform its int ended function unless installed, operated and maintained properly. Please carefully read and follow the recommended procedures for operation and maintenance.

Feature

The GP-3500F is a totally integrated GPS receiver, color video plotter and color video sounder consisting of a display unit, antenna unit and transducer.

The GPS receiver tracks up to 13 satellites (GPS: 12, WAAS: 1) simultaneously, and an 8-state Kalman filt er ensures optimum accuracy in determination of vessel position, course and speed.

Main features of the GP-3500F

• Bright 10.4-inch color TFT LCD with temperature compensated tone and brilliance control

• Simplified operation using individual keys, ENTER knob and trackball

• Three lines (main and sub of own ship’s track, other ship’s track) can be displayed simultaneously.

• Accepts FURUNO and NavCharts (NAVIONICS) charts, or C-MAP NT/NT+ charts (C-MAP), depending on specification. All names mentioned are registered trademarks of their respective companies.

• Fast chart redraw

• Built-in backup memory stores 80,000

points total of own ship’s tracks and marks

• Stores 3500 waypoints and 200 routes with up to 35 waypoints

• Man overboard feature records latitude and longitude coordinates at time of man overboard.

• Alarms: Arrival, Anchor Watch, Cross-track Error, Proximity, Speed, Trip, Temperature, Current, Depth and Fish.

• User programmable PROG key

• Own ship and cursor positions may be

shown in latitude and longitude, Loran A, Loran C or Decca LOPs.

• Data storage on memory cards.

• Improved position accuracy with optional

DGPS beacon receiver.

• 50 and 200 kHz dual frequency transducer available

• Automatic function permits unatt ended adjustment of range, gain and clutter.

• Past sounder display can be shown.

SYSTEM CONFIGURATION.............................................................................. viii

1. BASIC OPERATION ......................................................................................1-1

1.1 Controls Description..................................................................................................1-1

1.1.1 Display unit .....................................................................................................1-1

1.1.2 Remote controller............................................................................................1-2

1.2 Loading a Mini Chart Card.........................................................................................1-3

1.3 Turni ng the Power On/Off..........................................................................................1-4

1.4 Adjusting Brilliance and Hue......................................................................................1-6

1.4.1 Adjusting display brilliance ..............................................................................1-6

1.4.2 Adjusting control panel dimmer.......................................................................1-7

1.4.3 Selecting hue..................................................................................................1-9

1.5 Selecting a Display.................................................................................................. 1-10

1.6 MOB Mark...............................................................................................................1-12

1.7 Using PROG Key.....................................................................................................1-13

1.8 Simulation Mode......................................................................................................1-14

1.9 Menu Overview........................................................................................................1-17

2. PLOTTER AND PILOT DISPLAY DESCRIPTION ........................................2-1

2.1 Plotter and Pilot Displays...........................................................................................2-1

2.1.1 Plotter display..................................................................................................2-1

2.1.2 Pilot display.....................................................................................................2-2

2.1.3 NAV INFO 1 display ........................................................................................2-3

2.1.4 Compass plotter (or pilot) display....................................................................2-4

2.1.5 GPS status display..........................................................................................2-6

2.2 Operating the Cursor................................................................................................. 2-7

2.3 Shifting the Display....................................................................................................2-8

2.4 Changing Chart Scale................................................................................................2-8

2.5 Measuring Range and Bearing Between two Points ..................................................2-9

2.6 Using the VRM (Variable Range Marker)................................................................. 2-11

2.7 Mini Chart Cards......................................................................................................2-12

3. TRACK...........................................................................................................3-1

3.1 Displaying Track........................................................................................................3-1

3.1.1 Own ship’s track..............................................................................................3-1

3.1.2 Sub track.........................................................................................................3-3

3.1.3 Other ship’s track ............................................................................................3-4

3.2 Stopping, Restarting Plotting of Own Ship Track........................................................3-5

3.2.1 Displaying on ship’s track while track plotting is stopped.................................3-6

3.2.2 Connecting own ship’s track when resuming plotting.......................................3-7

3.3 Changing Track Color................................................................................................3-8

3.3.1 Changing own ship’s track color......................................................................3-8

3.3.2 Changing sub track color.................................................................................3-8

iii

3.3.3 Changing target track color............................................................................. 3-8

3.3.4 Automatically changing own ship’s track color by water temperature.............. 3-9

3.3.5 Changing own ship’s track color according to depth.......................................3-11

3.4 Changing Trac k Line Type........................................................................................3-13

3.5 Track Plotting Method, Interval.................................................................................3-13

3.5.1 Track plotting method.....................................................................................3-13

3.5.2 Track plotting interval.....................................................................................3-14

3.6 Erasing Tracks.........................................................................................................3-15

3.6.1 Erasing tracks by color...................................................................................3-15

3.6.2 Erasing tracks by line type.............................................................................3-18

3.7 Editing Tracks...........................................................................................................3-19

3.8 Changing Track Memory Capacity............................................................................3-20

4. MARKS & LINES ...........................................................................................4-1

4.1 Entering Marks.......................................................................................................... 4-1

4.2 Changing Mark Color ................................................................................................ 4-3

4.3 Changing Mark Size.................................................................................................. 4-4

4.4 Entering Lines........................................................................................................... 4-5

4.5 Selecting Line Type................................................................................................... 4-5

4.6 Erasing Marks, Lines................................................................................................. 4-6

4.7 Editing Marks, Lines.................................................................................................. 4-9

4.8 Displaying Mark Data...............................................................................................4-10

4.9 Target Mark (TLL).....................................................................................................4-10

5. WAYPOINT.....................................................................................................5-1

5.1 Entering Waypoints................................................................................................... 5-1

5.1.1 Entering waypoints at own ship’s position....................................................... 5-1

5.1.2 Entering waypoints by the cursor.................................................................... 5-2

5.1.3 Entering waypoints by latitude and longitude position..................................... 5-3

5.1.4 Entering waypoints by range and bearing....................................................... 5-6

5.1.5 Entering waypoints by Loran A or Loran C LOPs............................................ 5-7

5.1.6 Entering waypoints by Decca LOPs................................................................ 5-8

5.2 Editing Waypoint Data............................................................................................... 5-9

5.3 Erasing Individual Waypoints....................................................................................5-10

5.4 Searching Waypoints................................................................................................5-11

5.5 Setting Ship’s Speed for TTG...................................................................................5-12

5.6 Displaying Waypoint Data ........................................................................................5-13

5.7 Changing Waypoint Mark Size .................................................................................5-14

6. ROUTE ..........................................................................................................6-1

6.1 Entering Routes ........................................................................................................ 6-1

6.1.1 Entering routes using existing waypoints ........................................................ 6-1

6.1.2 Creating track-based routes............................................................................ 6-4

6.2 Editing Routes........................................................................................................... 6-5

6.2.1 Inserting waypoints......................................................................................... 6-5

6.2.2 Removing waypoints from routes.................................................................... 6-5

6.3 Erasing Routes.......................................................................................................... 6-6

6.4 Setting Ship’s Speed for TTG.................................................................................... 6-6

7. NAVIGATION..................................................................................................7-1

7.1 Navigating to Quick Points.........................................................................................7-1

7.2 Navigating to a Waypoint...........................................................................................7-7

7.3 Following a Route .................................................................................................... 7-10

7.4 Canceling Navigation...............................................................................................7-12

8. ALARMS ........................................................................................................8-1

8.1 Audio Alarm On/Off....................................................................................................8-2

8.2 Arrival Alarm/Anchor Watch Alarm.............................................................................8-3

8.3 XTE (Cross Track Error) A l a rm/B order Alarm............................................................8-4

8.4 Proximity Alarm .........................................................................................................8-5

8.5 Speed Alarm..............................................................................................................8-6

8.6 Trip Log Alarm...........................................................................................................8-6

8.7 Temperature Alarm....................................................................................................8-7

8.8 Shear Alarm...............................................................................................................8-7

8.9 Bottom Alarm.............................................................................................................8-8

9. CUSTOMIZING YOUR UNIT..........................................................................9-1

9.1 CHART SETUP Menu................................................................................................9-1

9.1.1 Offsetting the chart..........................................................................................9-1

9.1.2 CHART SETUP menu items description..........................................................9-4

9.1.3 CONTOUR LINES SETUP menu....................................................................9-6

9.2 PLOTTER SETUP Menu ...........................................................................................9-7

9.2.1 Setting TD display...........................................................................................9-7

9.2.2 Resetting trip distance.....................................................................................9-9

9.2.3 Selecting range of PLOTTER (PILOT) display.................................................9-9

9.3 DISPLAY SETUP Menu ........................................................................................... 9-11

9.4 NAVIGATOR SETUP Menu .....................................................................................9-16

9.5 PROGRAMMABLE KEYS & REMOTE CONTROLLER SETUP Menu.....................9-21

9.5.1 Programmable key setup...............................................................................9-21

9.5.2 Remote controller (option) setup ...................................................................9-24

9.6 DISPLAY MODES & NAV DATA WINDOW SETUP Menu ....................................... 9-26

9.6.1 Setting the DISPLAY MODE screen..............................................................9-26

9.6.2 Setting the navigation data window...............................................................9-29

9.7 I/O PORT SETUP Menu..........................................................................................9-33

9.8 TEST & MEMORY CLEAR Menu ............................................................................9-36

9.8.1 Setting the password..................................................................................... 9-36

9.8.2 Removing the password................................................................................9-38

10. RECORDING & PLAYING BACK DATA ...................................................10-1

10.1 Recording Data........................................................................................................10-1

10.2 Memory Card Operation..........................................................................................10-2

10.2.1 Formatti ng memory cards..............................................................................10-2

10.2.2 Saving data to a memory card.......................................................................10-4

10.2.3 Displaying data from a memory card.............................................................10-6

10.2.4 Playing back data from a memory card.........................................................10-7

10.2.5 Deleti ng files..................................................................................................10-8

10.3 Automatic Backup Function.....................................................................................10-9

10.3.1 Backup to a memory card..............................................................................10-9

10.3.2 Backup by internal memory..........................................................................10-10

10.4 Internal Memory..................................................................................................... 10-11

10.4.1 Saving data to internal memory ...................................................................10-11

10.4.2 Displaying tracks and marks stored in the internal memory..........................10-12

10.4.3 Playing back data from the internal memory................................................10-14

10.5 Uploading, Downloading Data................................................................................10-15

10.5.1 Downloading data........................................................................................10-15

10.5.2 Uploading data.............................................................................................10-17

11. VIDEO SOUNDER OPERATION ............................................................... 11-1

11.1 Principle of Operation............................................................................................... 11-1

11.2 Sounder Displays .....................................................................................................11-2

11.2.1 Single frequency display (50 kHz or 200 kHz)................................................11-2

1 1.2.2 Dual- frequency display ..................................................................................11 -3

11.2.3 Marker-zoom display (50 kHz or 200 kHz).....................................................11-4

11.2.4 Bottom-zoom display (50 kHz or 200 kHz).....................................................11-4

11.2.5 Bottom-lock display (50 kHz or 200 kHz).......................................................11-5

11.2.6 Bottom discrimination display (50 kHz or 200 kHz)........................................11-5

11.2.7 A-scope display (Single display only).............................................................11-6

1 1.2.8 Mix display.....................................................................................................1 1-7

11.2.9 Plotter (or Pilot)/sounder display....................................................................11-8

11.3 Automatic Sounder Operation .................................................................................. 11-9

11.4 Manual Sounder Operation .................................................................................... 11-12

11.4.1 Sel e cti n g the manual mode..........................................................................1 1 -12

11.4.2 Selecting display range................................................................................11-13

11.4.3 Shifting the basic range...............................................................................11-14

1 1.4.4 Adjustin g gain..............................................................................................11-1 5

11.5 Measuring Depth, Time .......................................................................................... 11-16

11.6 Entering Mark on the Display .................................................................................11-18

11.7 Reducing Interference ............................................................................................11-19

11.8 Reducing Low-Level Noise.....................................................................................11-20

11.9 White Marker.......................................................................................................... 11-21

11.10 Display Colors.......................................................................................................11-22

11.11 Customizing Colors...............................................................................................11-23

11.12 Erasing Weak Echoes...........................................................................................11-24

11.13 Picture Advance Speed.........................................................................................11-25

11.14 Reviewing Past Picture.........................................................................................11-26

11.15 Alarms ..................................................................................................................11-27

11.15.1 Audio alarm on/off......................................................................................11-28

11.15.2 Fish alarm..................................................................................................11-29

11.15.3 Fish alarm (B/L).........................................................................................11-30

11.16 Programmable Key Setup.....................................................................................11-31

11.17 Setting the DISPLAY MODE Screen.....................................................................11-33

11.18 ECHO SOUNDER SYSTEM SETUP Menu...........................................................11-35

11.19 ECHO SOUNDER RANGE SETUP Menu.............................................................11-38

11.20 Interpreting the Sounder Display...........................................................................11-39

12. MAINTENANCE & TROUBLESHOOTING................................................12-1

12.1 Maintenance ............................................................................................................12-1

12.2 Replacement of Fuse...............................................................................................12-2

12.3 Replacement of Battery...........................................................................................12-2

12.4 Trackball Maintenance.............................................................................................12-3

12.5 Simple Troubleshooting ........................................................................................... 12-4

12.6 Diagnostics ..............................................................................................................12-6

12.6.1 Memory I/O test.............................................................................................12-6

12.6.2 Keyb oard test................................................................................................ 12-8

12.6.3 T est pattern...................................................................................................12-9

12.7 Clearing the Working Memory................................................................................12-10

12.8 Cold Start .............................................................................................................. 12-11

MENU TREE....................................................................................................AP-1

WORLD TIME CHART....................................................................................AP-7

GEODETIC CHART LIST ...............................................................................AP-8

ICONS .............................................................................................................AP-9

WHAT IS WAAS?..........................................................................................AP-10

SPECIFICATIONS........................................................................................... SP-1

INDEX............................................................................................................... IN-1

vii

SYSTEM CONFIGURATION

Display unit GP-3500F

GPA-017S/GPA-019S*1

(option)

External monitor

Matching box

MB-1000*2

Transducer

Speed/ temperature sensor ST-02MSB/ ST-02PSB

12-24 VDC

*1: Only when the optional beacon receiver kit is installed.

*2: For 1 kW

Remote controller

External equipment (Autopilot, radar, etc.)

: Standard supply : Option : User supply

viii

1. BASIC OPERATION

1.1 Controls Description

1.1.1 Display unit

When you correctly execute an operation, t he unit generates a beep. Invalid operation causes the unit to emit three beeps.

Card slot

Opens the BRILLIANCE window.

Momentary press: Registers

Long press: (more than 3 seconds)

Opens the DISPLAY MODE screen.

Opens the SHIFT window (sounder).

Opens the ECHO SOUNDER RANGE window.

Enlarges/shrinks display.

• Enters numeric data.

• Enters mark.

• Selects menu item.

Opens the CHANGE MARK COLOR window.

• Displays/erases the cursor.

• Switches + to - and vice vevsa.

• Switches N to S, E to W and vice vevsa.

Moves own ship's position or cursor position to center.

own ship's

positions. Marks man overboard position.

BRILL

SAVE

MOB

DISP

PROG

SHIFT

RANGE

ZOOM

OUT

789

MARK

COLOR

CURSOR

ON/OFF

WPT

CLEAR

VRM

CENTER

POWER

GOTO

GAIN

TRACK COLOR

PLOT

INTVL

Turns power on/off. Opens the SAVE WPT window.

Sets/releases the destination.

Executes program assigned. Opens/closes the main menu.

Opens the GAIN window (sounder). ENTER knob

Push: Registers numeric data

or operation.

Rotate: Selects menu items.

• Silences the alarm.

• Erases marks and waypoints.

• Clears alphanumeric data.

Mesures the bearing and range between two points.

Opens the CHANGE SHIP'S TRACK COLOR window. Shows the VRM.

Changes the track plotting method and plotting interval.

Trackball

• Moves the cursor.

• Selects the menu item.

Control panel

1-1

1. BASIC OPERATION

1.1.2 Remote controller

The remote controller provides for armchair control of the display unit. It has six keys, all of which may be programmed by the user.

Hole for hanging on a hook.

ZOOM IN

ZOOM OUT

Label

Record the function registered to key. Record the function registered to key.

Note: When programming the or key, make a mental note of their programs, as there is no space on the remote controller for recordings its program.

A B

C D

Remote controller

The default key functions are as below.

Key Function

Enter a waypoint with the next consecutive waypoint

number at the own ship (or cursor) position. B Same as pressing the [ENTER] knob on the control panel. C Same as [CLEAR] key function. D Same as [1] key function.

Same as [ZOOM IN] key function. Same as [ZOOM OUT ] key function.

For how to program the remote controller, see paragraph 9.5.2. You can program other function t o each key. (See paragraph 9.5.2.) Record the function name on the label on the remote controller, using an oil-based felt-tip pen.

1-2

1.2 Loading a Mini Chart Card

Your unit reads FURUNO and NavCharts (NAVIONICS) chart cards, or C-MAP (available in near future) chart cards, depending on the type of display unit you have. Insert the appropriate chart card for your area before turning the power on to show chart data automatically.

Note: Static electricity can be passed through your fingers to a card and destroy

the contents of the card. To prevent this, always touch a metallic object, such as a steel desk, before handling a memory card.

1. Push down the lid catch to open the mini chart card slot cover.

(triangle) mark

1. BASIC OPERATION

COLOR GPS PLOTTER/SOUNDER

GP-3500F

Card slot

Card slot cover

2. I nsert appropriate mini chart card groove side up in the right side slot.

Left-side: Memory card or Mini chart card

Right-side: Mini chart card only

Card slot

Inside chart card groove side up.

Mini chart card

Chart card

3. Close t he slot cover to protect the chart drive. (Keep the slot cover closed at all times.)

Press the center of the lid catch to close it.

1-3

1. BASIC OPERATION

1.3 Turning the Power On/Off

Turning the power on

▪ Press the [POWER] key.

When the unit is turned on, it proceeds in the sequence shown in the figure below.

GP-3500F

GPS PLOTTER SOUNDER

FURUNO ELECTRIC CO. LTD.,

START UP TEST PLOTTER ROM : OK RAM : OK BACKUP DATA : OK INTERNAL BATTERY : OK INTERNAL GPS : OK

ECHO SOUNDER ROM : OK RAM : OK

--- CAUTION --NO NATIONAL HYDROGRAPHIC OFFICE HAS VERIFIED THE INFORMATION IN THIS COASTLINE DATA CARD AND NONE ACCEPT LIABILITY FOR THE ACCURACY OF REPRODUCTION OR ANY MODIFICATIONS MADE THEREAFTER. THIS PRODUCT WITH THIS COASTLINE DATA CARD DOES NOT REPLACE THE REQUIREMENT TO USE THE APPROPRIATE PRODUCTS FOR NAVIGATION ACCORDING TO NATIONAL AND INTERNATIONAL REGULATIONS. CHART CARD. US603S32, US223S32

PROGRAM NO. PLOTTER : GPS : SOUNDER :

1451713-XX.XX 48502370XX 1451716-XX.XX

XX: Program Version No.

In about 30 seconds the Last-used display appears. You can go the last-used display faster by pressing any key .

Start-up sequence

Note 1: The example screens shown in this manual may not match the screens

you see on your display. The screen you see depends on your system configuration and equipment settings.

Note 2: If the message "SYSTEM HAS FAILED START UP TEST. PLEASE

CONTACT A LOCAL FURUNO REPRESENTATIVE FOR REPAIR. PRESS ANY KEY TO CONTINUE." appears, contact your dealer for advice.

This equipment takes about 90 seconds to find its position when turned on for the very first time. Thereafter it takes about 12 seconds to find position each time the power is turned on. The message "NO FIX", which means the equipment is now findings its position, appears at the bottom of the Plotter (or Pilot) display immediately after turning the power on. When the GPS receiver finds its position, "NO FIX" changes to "2D" or "3D" to show that position data is now accurate.

1-4

1. BASIC OPERATION

Position-fixing indications and their meanings

Indication Meaning Indication Meaning 2D

W2D

W3D

2D (dimension) GPS position fix 3D (dimension) GPS position fix 2D (dimension) WAAS position fix 3D (dimension) WAAS position fix

D2D*

D3D*

DEMO Simulation mode

2D (dimension) DGPS position fix 3D (dimension) DGPS position fix

*: T he int ernal beacon receiver board (option) is necessary.

Note: If the password window appears, follow the procedure in paragraph 9.8.1.

Turning the power off

▪ Press the [POWER] key.

After the turning power off, attach the LCD cover to prevent it.

1-5

1. BASIC OPERATION

1.4 Adjusting Brilliance and Hue

You can adjust display brilliance, panel dimmer and hue as shown below.

1.4.1 Adjusting display brilliance

1. Press t he [BRILL] key.

The brilliance adjustment window appears.

BRILLIANCE 8

TURN KNOB TO ADJUST DISPLAY BRILLIANCE.

Brilliance adjustment window

Note: The adjustment window disappears when there is no operation for

three seconds.

2. Rotate the [ENTER] knob to adjust the brilliance, in eight levels

Rotate the knob clockwise to raise the sett ing or counterclockwise to decrease it. Also you can adjust brilliance by pressing the [BRILL] key. In this case brilliance is changed cyclically 1→2

→8→7→ …1→2….

…

3. Press the [ENTER] knob to manually close the adj ustment window, or wait three seconds to let the equipment close it automatically.

Note: The brilliance of an external monit or cannot be adjusted from the display

unit. Adjust it at the external monitor.

1-6

1.4.2 Adjusting control panel dimmer

1. Press the [MENU] key to open the main menu.

1. W AYPOINT LIST

2. ROUTES LIST

3. MEMORY CARD OPERATIONS & DATA TRANSFER

4. MARKS/SHIP'S TRACKS SETUP

5. MARKS/SHIP'S TRACKS EDITION

6. ALARM SETUP

7. CHART SETUP

8. PLOTTER SETUP

1. BASIC OPERATION

9. ECHO SOUNDER SETUP

0. SYSTEM SETUP

TURN KNOB TO SELECT MENU AND PRESS KNOB TO ENTER. OR PRESS APPROPRIATE NUMERIC KEY TO SELECT MENU.

Main menu

2. Press t he [8] key to display the PLOTTER SETUP menu.

1-7

1. BASIC OPERATION

8. PLOTTER SETUP

LORAN-A GRI 00-01 CORRECTION 1 +000.0 µs CORRECTION 2 +000.0 µs LORAN-C GRI 00:11-29 CORRECTION 1 +000.0 µs CORRECTION 2 +000.0 µs DECCA CHAIN 01 R-G CORRECTION 1 +00.00 LANE CORRECTION 2 +00.00 LANE TD DISPLAY 1. LORAN-A 2. LORAN-C 3. DECCA RESET TRIP LOG 1. YES 2. NO PLOTTER RANGE SETUP PANEL DIMMER 1 2 3 4 5 6 7 8 HUE 1. DAY 2. NIGHT 3. TWILI 4. MANUAL

00:1L0 01:1L1 02:1L4 03:1L5 04:1L6 05:1L7 06:1S1 07:1S2 08:1S3 09:1S4 10:1S6 11:2H3 12:2H4 13:2H5 14:2H6 15:2S0 16:2S1 17:2S2 18:2S3 19:2S4 20:2S5 21:2S6 22:2S7

1. YES 2. NO

TURN KNOB TO SELECT MENU. SELECT THE ITEM OF EACH MENU BY TRACKBALL.

Plotter setup menu

3. Rotate the [ENTER] knob to choose PANEL DIMMER.

4. Roll the trackball in the right-left direction to choose the illumination desired. You m ay also choose the setting by pressing the appropriate numeric key.

The larger the number the greater the illumination.

5. Press t he [MENU] key several times to close the menu.

1-8

1.4.3 Selecting hue

1. Press t he [MENU] key to display the main menu.

2. Press t he [8] key to display the PLOTTER SETUP menu.

3. Rotate the [ENTER] knob to choose HUE.

4. Roll the trackball in the right-left direction to choose the hue desired. You m ay also choose the hue by pressing the appropriat e numeric key.

Refer to the table shown below to choose appropriate hue settings.

Day Night Twilight Manual Landmass Yellow Yellow Yellow Land edge Black Yellow Black

Background White Black Gray Menu

background Character Black White Black Black

5. Press t he [MENU] key several times to close the menu.

1. BASIC OPERATION

Hue setting and item color

Depending on the setting of CHART SETUP menu

White Black Gray White

1-9

1. BASIC OPERATION

1.5 Selecting a Display

Five full-screen displays are available: Plotter, Pilot, Navigation, Compass and Sounder. In addition to the full-screen display, you can divide the screen into half-screen combination displays. See Chapter 2 for Plotter, Pilot, Navigation and Compass displays, Chapter 11 for Sounder display.

1. Press t he [ DISP] key.

A DISPLAY MODE screen appears. There are four pages of DISPLAY MODE screens.

2. Press t he [0] key several times to show the page desired. You m ay also choose a page by using the [E NTER] knob as below.

a) Rotat e t he [ENTER] knob to select "0. GOTO PAGE X" at the bottom of t he

screen.

b) Press t he [ ENTER] knob to choose page.

1-10

DISPLAY MODE PAGE 1/4

1. BASIC OPERATION

DISPLAY MODE PAGE 2/4

1. PLOTTER NAV INFO 1

4. PLOTTER E/S 50 kHz

7. E/S 50 kHz SINGLE

TURN KNOB TO SELECT DISPLAY MODE AND PRESS KNOB TO ENTER. OR PRESS APPROPRIATE NUMERIC KEY TO SELECT DISPLAY MODE. PRESS "0" KEY TO GOTO PAGE 2.

DISPLAY MODE PAGE 4/4

1. PLOTTER

2. PILOT NAV INFO 2

5. PLOTTER E/S 200 k

8. E/S 200 k SINGLE

0. GO TO PAGE 2.

[0] key

2. PLOTTER NAV INFO 1

3. PLOTTER E/S DUAL

6. E/S DUAL

9. E/S 200 k BTTM Lock

3. PLOTTER NAV INFO 2

[0] Key

1. E/S DUAL

4. E/S 50 kHz BTTM Zoom

7. NAV INFO 1 E/S 50 kHz

TURN KNOB TO SELECT DISPLAY MODE AND PRESS KNOB TO ENTER. OR PRESS APPROPRIATE NUMERIC KEY TO SELECT DISPLAY MODE. PRESS "0" KEY TO GOTO PAGE 3.

DISPLAY MODE PAGE 3/4

1. E/S DUAL

2. E/S 50 kHz SINGLE

5. E/S 50 kHz BTTM Lock

8. PLOTTER E/S 50 kHz

0. GO TO PAGE 3

[0] key

2. E/S 200 k SINGLE

3. E/S 50 Hz MRKR Zoom

6. 50 kHz DSCRMMNATN

9. E/S 50 kHz A-SCOPE

3. E/S 200 k MRKR Zoom

4. PILOT 5. PILOT

7. E/S DUAL

TURN KNOB TO SELECT DISPLAY MODE AND PRESS KNOB TO ENTER. OR PRESS APPROPRIATE NUMERIC KEY TO SELECT DISPLAY MODE. PRESS "0" KEY TO GOTO PAGE 1.

NAV INFO 1

8. COMPASS PLOTTER

0. GO TO PAGE 1

6. PILOT NAV INFO 2

9. GPS STATUS

3. Press appropriat e numeric key to choose a display.

Selected display replaces display mode page.

Note: The DISPLAY MODE screens can store a total of 36 displays, nine on

each of four pages. You may program the DI SPLAY MODE screens as desired. For further derails, see paragraph 9.6.1 for plotter displays and paragraph 11.17 for sounder displays.

[0] key

4. E/S 200 k BTTM Zoom

7. NAV INFO 1 E/S 200 k

0. GO TO PAGE 4

TURN KNOB TO SELECT DISPLAY MODE AND PRESS KNOB TO ENTER. OR PRESS APPROPRIATE NUMERIC KEY TO SELECT DISPLAY MODE. PRESS "0" KEY TO GOTO PAGE 4.

DISPLAY MODE screen

5. E/S 200 k BTTM Lock

8. PLOTTER E/S 200 k

6. E/S 200 k DSCRMNATN

9. E/S 200 k A-SCOPE

1-11

1. BASIC OPERATION

1.6 MOB Mark

The MOB (Man Overboard) mark functions to mark man overboard position. You can inscribe this mark from any mode, except while playing back data, recording data or conducting a diagnostic test.

Man overboard

Range, bearing

Current position

MOB mark

(MOB)

O B

162.5°

0.49

MOB data box Bearing and range to MOB position.

MOB concept

1. Press and hold down the [SAVE/MOB] key immediately for about three seconds when someone falls onboard.

The display shows the waypoint number being saved (youngest empty waypoint number) under the MOB position followed by the MOB confirmat ion window.

WAYPOINT XXXXXX IS SAVED. CONTINUE PRESSING FOR MOB!

After several seconds.

MAN OVER BOARD!

SET (MOB) AS DESTINATION? YES … PRESS KNOB NO … PRESS CLEAR KEY

MOB mark messages

2. Push the [ENTER] knob to select the MOB position as the destinat ion, or press the [CLEAR] key to only mark current ship's position as a waypoint.

If you select the MOB position as the destination;

a) A full-screen PLOTTER NAV INFO 1 display replaces the display in use. b) The MOB mar k "M" appears at the MOB position and a dashed line runs

between it and current position. This line shows the shortest course t o the MOB position.

c) Range and bearing t o the MOB position are shown in the MOB data box.

1-12

Note: The MOB mark can be deleted as follows.

a) Press the [CURSOR ON/OFF] key to show the cursor. b) Oper at e the trackball to place the cursor on the MOB mar k. c) Press the [CLEAR] key.

The following message appears on the screen:

WAYPOINT NAME XXXXXX

WILL BE DELETED. ARE YOU SURE? YES … PRESS KNOB NO … PRESS CLEAR KEY

Confirmation message

d) Press t he [ ENTER] knob.

Then, the waypoint entered at step 1 on the previous page is erased. e) Oper at e the trackball to place the cursor on the MOB mar k. f) Press the [CLEAR] key. g) A new message appears on t he scr een:

1. BASIC OPERATION

WAYPOINT NAME (MOB)

WILL BE DELETED. ARE YOU SURE? YES … PRESS KNOB NO … PRESS CLEAR KEY

When MOB is not set as destination

h) Press t he [ ENTER] knob to erase the MOB mark.

1.7 Using PROG Key

Less-often used functions are provided in the menu. To avoid opening m enus to access a particular function, the [PROG] key may be assigned any of the function in the menu. Note that the function for [SHIFT], [RANGE ], [GAIN] and [VRM] keys can also be programmed. The default program of the [PROG] key is as shown in the table below.

Key Functions

PROG Displays the WAYPOINT LIST.

•Note 1: To program plotter functions to the [PROG] key ([SHIFT], [RANGE], [GAIN] or [VRM] keys), see paragraph 9.5.1. For echo sounder f unctions, see paragraph 11.16.

Note 2: If the [PROG] key is programmed for a sounder function it may only be

used on the sounder display or a menu entered from the sounder display only.

THIS WAYPOINT (MOB)

IS USED FOR NAVIGATION. WILL IT BE DELETED? YES … PRESS KNOB NO … PRESS CLEAR KEY

When MOB is set as destination

Confirmation message

1-13

1. BASIC OPERATION

1.8 Simulation Mode

The simulation m ode provides simulated plotter and sounder operation of this unit. All controls are operative.

“DEMO” appears at the bottom of the plotter (pilot) display (top of the sounder display) when any simulation mode is active.

Plotter

Own ship's mark tracks from the default position at the course and speed set.

1. Press t he [MENU] key to display main menu.

2. Press t he [0] key to display the SYSTEM SETUP menu.

0. SYSTEM SETUP

1. DISPLAY SETUP

2. NAVIGATOR SETUP

3. PROGRAMMABLE KEYS & REMOTE CONTROLLER SETUP

4. DISPLAY MODES & NAV DATA WINDOW SETUP

5. I/O PORT SETUP

6. TEST & MEMORY CLEAR

7. SIMULATION MODE

8. ECHO SOUNDER SYSTEM SETUP

TURN KNOB TO SELECT MENU AND PRESS KNOB TO ENTER. OR PRESS APPROPRIATE NUMERIC KEY SELECT MENU.

System setup menu

1-14

1. BASIC OPERATION

3. Press t he [7] key to display the SIMULATION MODE menu.

0-7. SIMULATION MODE SETUP

PLOTTER 1. SIM 2. LIVE SPEED 09.9 kt COURSE 1. DIRECTION 2. 8 FIGURE DIRECTION 000.0° LATITUDE 45°35.000'N LONGITUDE 125°00.000'W DATE & TIME 03.01.01 00:00 ECHO SOUNDER 1. SIM 2. LIVE

TURN KNOB TO SELECT MENU. SETUP SIMULATION MODE BY TRACKBALL.

Simulation mode setup menu

4. Rotate the [ENTER] knob to choose PLOTTE R.

5. Press t he [1] key to choose "1. SIM."

6. Rot ate the [ENTER] knob to choose SPEED.

7. Ent er speed (setting range: 0.0 to 99.9 kt) with the numeric keys, then press the [ENTER] knob.

8. Rotate the [ENTER] knob to choose COURSE.

9. Press t he [1] or [2] key to choose "1. DIRECTION" or "2. 8 FIGURE."

DIRECTION: Track is traced according to course set. Go to step 10. 8 FIGURE: Track is traced in a figure-eight course. Go to step 12.

10. Rotate the [ E NTER] knob to choose DIRECTION.

11. Enter course (setting range: 0.0 t o 359.9) with the numeric keys, then press the [ENTER] knob.

12. Rotate the [ E NTER] knob to choose LATITUDE.

13. Enter latitude with the numeric keys, and press the [ENTER] knob.

Press the [CURSOR ON/OFF] key to switch from north to south and vice

versa.

14. Rotate the [ E NTER] knob to choose LONGITUDE.

15. Enter longitude with the numeric keys, and then press the [ENTER] knob.

Press the [CURSOR ON/OFF] key to switch from east to west and vice

versa.

16. Rotate the [ E NTER] knob to choose DATE & TIME.

1-15

1. BASIC OPERATION

17. Enter start dat e and time with the numeric keys, in 24-hour notation and t hen press the [ENTER] knob.

18. Press the [MENU] key several times to close the menu.

Note: To terminate the simulation mode, select "2. LIVE" at step 5.

Echo sounder

1. Press t he [MENU] key to display the main menu.

2. Press t he [0] key to show the SYSTEM SETUP menu.

3. Press t he [7] key to display the SIMULATION MODE menu.

4. Rot ate the [ENTER] knob to choose ECHO SOUNDER.

5. Press t he [1] key to choose "1. SIM."

6. Press t he [MENU] key several times to close the menu.

Note: To terminate the simulation mode, select "2. LIVE" at step 5.

1-16

1.9 Menu Overview

Secondary operations are carried out through the menu. This section provides basic menu operating information.

1. Press t he [MENU] key to display the main menu.

Red cursor

1. W AYPOINT LIST

2. ROUTES LIST

3. MEMORY CARD OPERATIONS & DATA TRANSFER

4. MARKS/SHIP'S TRACKS SETUP

5. MARKS/SHIP'S TRACKS EDITION

1. BASIC OPERATION

6. ALARM SETUP

7. CHART SETUP

8. PLOTTER SETUP

9. ECHO SOUNDER SETUP

0. SYSTEM SETUP

TURN KNOB TO SELECT MENU AND PRESS KNOB TO ENTER. OR PRESS APPROPRIATE NUMERIC KEY TO SELECT MENU.

Main menu

2. Select a menu item.

There are three ways to select a menu item. T his m anual uses m ethod a).

Press the appropriat e num eric key.

Rotate the [ENTER] knob to select the menu item desired, and then press the

[ENTER] knob. The red cursor appears at lef t side of the item selected. Rotate t he [ ENTER]

knob clockwise to move the red cursor upward; counterclockwise f or downward.

Roll the track ball in up-down direction to select item, and then press the

[ENTER] knob.

1-17

1. BASIC OPERATION

For example, press the [8] key to display the PLOTTER SETUP menu.

Cursor (red rectangle)

8. PLOTTER SETUP

LORAN-A GRI 00-01 CORRECTION 1 +000.0 µs CORRECTION 2 +000.0 µs LORAN-C GRI 00:11-29 CORRECTION 1 +000.0 µs CORRECTION 2 +000.0 µs DECCA CHAIN 01 R-G CORRECTION 1 +00.00 LANE CORRECTION 2 +00.00 LANE TD DISPLAY 1. LORAN-A 2. LORAN-C 3. DECCA RESET TRIP LOG 1. YES 2. NO PLOTTER RANGE SETUP PANEL-DIMMER 1 2 3 4 5 6 7 8 HUE 1. DAY 2. NIGHT 3. TWILI 4. MANUAL

1. YES 2. NO

00:1L0 01:1L1 02:1L4 03:1L5 04:1L6 05:1L7 06:1S1 07:1S2 08:1S3 09:1S4 10:1S6 11:2H3 12:2H4 13:2H5 14:2H6 15:2S0 16:2S1 17:2S2 18:2S3 19:2S4 20:2S5 21:2S6 22:2S7

TURN KNOB TO SELECT MENU. SELECT THE ITEM OF EACH MENU BY TRACKBALL.

Plotter setup menu

3. Rotate the [ENTER] knob to select item which you want to change t he set ting. You can also select item by rolling the trackball in up-down direction.

4. Roll t he trackball in left-right direction to select option (with the red rectangle).

When the opt ion is pr efixed with numeral, you can select it by pressing the appropriate numeric key. In this manual selection by numeric key is used when both selection methods are available.

5. Press t he [MENU] key several times to close the menu.

1-18

1. BASIC OPERATION

Entering numeric data

Cursor

8. PLOTTER SETUP

LORAN-A GRI 00-01 CORRECTION 1 +000.0 µs CORRECTION 2 +000.0 µs

TURN KNOB TO SELECT MENU. SELECT THE ITEM OF EACH MENU BY TRACKBALL.

Plotter setup menu

1. Press t he appropriate numeric key.

2. Press t he [ENTER] knob.

You m ay also enter a value rot at ing the [ENTER] knob.

Note: If you enter a wrong value, move the cursor to the that position and then

re-enter the proper value. The cursor for entering value is moved by rolling the trackball in left-right direction. To clear a line of data, place the red cursor on the line and press the [CLEAR] key.

1-19

1. BASIC OPERATION

Entering character

1. Roll the trackball in up-down direction to select the first alphanumeric character with the cursor (red square).

Numeric may also be entered by pressing numeric key.

2. Press t he [ENTER] knob.

Note: If you enter a wrong character, move the cursor to that location and then

re-enter the proper character. To move the digit cursor, select ◄ and then press the [ENTER] knob for left direction, or select ► and then press the [ENTER] knob for right direction. Press the [CLEAR] key to erase the all characters.

3. Repeat steps 1 and 2 to complete the naming.

4. F inally, select "END" and then press the [ENTER] knob.

Digit cursor Cursor

PASSWORD ENT AGAIN

END ABCDE FGHIJ KLMNO PQRST UVWXY Z,-!? /&^=# 12345 67890 _____ abcde fghij klmno pqrst uvwxy z____ _____ _____ ______ _ __

SELECT ALPHANUMERIC CHARACTER BY TRACKBALL AND PRESS KNOB TO ENTER. OR PRESS NUMERIC KEY TO NAME WAYPOINT. MOVE THE CURSOR TO "END" ONCE THE EDITION IS FINISHED.

Ex. Set password, entering characters

1-20

2. PLOTTER AND PILOT DISPLAY DESCRIPTION



2.1 Plotter and Pilot Displays

The plotter and pilot displays can be shown with full-screen or in a half screen combined with the nav information window, compass or echo sounder display.

To choose a plotter or pilot display, press the [DISP] key, and t hen press the [0] key several times to show the DISPLAY MODE PAGE 4/4 screen. Press the appropriate numeric key to show the display desired.



2.1.1 Plotter display

The plotter display shows chart data, tracks, waypoints and marks on the display. The plotter display orientation is always north-up. North (zero degree) is at the top of the display and own ship (filled circle) is at the center of t he screen.



When selecting PLOTTER NAV INFO 1 (or 2), NAV INFO window appears here.

Grid

Heading marker (white)

Other ship's track

Own ship's mark Mark information

(appears when the cursor is on a mark)

Cursor

Mark

20 21 22

000001

37˚04.640'N 135˚21.047'E + 4.5˚C 13.7m

WGS84

GPS2D

GPS/DGPS status

Geodetic datum

Icons

PLOTTER display

FISH



0.3nm

S A V E

Waypoint mark Waypoint name

Course bar (light-blue)

Own ship's track (main)

Own ship's track (sub)

Scale



 2-1

2. PLOTTER AND PILOT DISPLAY DESCRIPTION



2.1.2 Pilot display

The pilot display is similar to the plotter display, with the following differences.

1) The pilot display orientation is always auto course-up. The course is at the top of screen at the m oment the pilot display is selected. A f illed triangle marks own ship’s position. When own ship is off its intended course by 22.5° or more, it is automatically brought back to perpendicular.

2) The north mark (

3) The grid lines denote the distance from own ship, not longitude/latitude.



Note: When north is not at the top of screen, the distance error may be larger

than on the plotter display since the Mercator projection is used.



When selecting PILOT NAV INFO 1 (or 2), the NAV INFO window appears here.

) appears at the bottom of the screen and points to north.

FISH

Waypoint mark Waypoint name

Other ship's track

Grid

Heading marker (white)

Own ship's mark

Own ship's track (main)

Own ship's track (sub)



0.5

GPS2D

GPS/DGPS status

000001

0.5

37˚03.640'N 135˚20.047'E + 4.5˚C 13.7m

WGS84

0.5

Geodetic datum

Pilot display

Icons



0.5

0.2nm

S A V E

Course bar (light-blue)

Mark information Cursor

Mark

Scale



2-2

2. PLOTTER AND PILOT DISPLAY DESCRIPTION

2.1.3 NAV INFO 1 display

Select “PLOTTER (or PILOT) NAV INFO 1 (or 2)” from the DISPLAY MODE screen to show the NAV INFO 1(or 2) window at the top of the screen. When setting a destination, the NAV INFO 1 (2) window changes to the WPT INFO 1 (2) window.

This color shows the selected mark color. Black means the selection of "KEY'S COLOR." (See paragraph 4.2.)

NAV INFO 1 window (Default data)



Latitude, Longitude

34 44.1447'N 135 21.0758'E

Speed over ground

Latitude, Logitude

34 44.1447'N

135 21.0758'E

9.9

350.2

Speed over ground

Track plottings interval

9.9

350.2

TRKS 00M01s

2003. 4. 12

00:01



L/L of cursor position

34 43.1447'N 135 21.0758'E

00:01

Date

TimeCourse



NAV INFO 2 window (Default setting)

Latitude, Longitude

3444.1447'N



21.0758'E

135

000001

Waypoint Name

Range to Waypoint

0.60

L/L of cursor position

34 43.1447'N

＋

135 21.0758'E

284.2

Bearing to Waypoint

ETA 1, 3:19

TTG 0D 0H 4M

TimeCourse



Estimated time of arrival at Wa ypoint

Time-to-Go to destination



NAV INFO 1 window on setting a destination (default data)





2-3

2. PLOTTER AND PILOT DISPLAY DESCRIPTION



Latitude, longitude

34 44.1447'N 135 21.0758'E

Speed over ground

Course

SOG 9.9kt COG 350.2 T DPT 16.2 m TEMP 5.3 C

2003. 4. 13 00:01

TRIP 0nm TRKS 00M01s

Depth

Date

Time Trip distance

Tracking interval

2.1.4

Water temp.

NAV INFO 2 window on setting a destination (default data)



Note: You can choose the data to display in the NAV. INFO windows. For

further details, see paragraph 9.6.2.





Compass plotter (or pilot) display



The compass display, displayed at the top of the screen in a com bination display, provides steering information.

Range to destination waypoint

Destination waypoint

Time-to-go to destination

Bearing to destination waypoint (black)

Depth graph

000001

TTG

0D 9H 59M

DEPTH

14. 9 m

Speed over ground

RANGE

SOG

BRG TO WPT

359.9˚M

COG

359.9˚M

Speed through water

0.43

9. 9 ETA

STW

1st 23 : 59

TEMP

4. 9˚C

10. 5

Estimated time of

arrival at destination

Ship's course (red)

Water temperature graph (Required water temperature sensor.)



Shown in red when direction to steer is left.



Bearing scale

XTE monitor

Compass display

Direction to steer (green)

Own ship mark (Black when the ship is within XTE range, yellow when over.)



2-4



2. PLOTTER AND PILOT DISPLAY DESCRIPTION

Compass indicator

The black inverted triangle shows the bearing to the destination waypoint, and the red triangle shows own ship’s course.



Note: The course means the direction of own ship’s movement, it is not the

direction of heading. The cursor includes the aff ect of current and wind.



Depth and water temperature graphs

The depth and water temperature graphs, which require appropriate sensors, show the latest 10 minutes of depth and water temperature data. The range of the depth graph is 50 feet and it is automatically adjusted with depth.



XTE (cross-track error) monitor

The black boat-shaped (own ship mark) mark shows ship’s cross-track from the intended course and direction, and amount to st eer to return to course. It is shown in black when the amount of cross-track error is within the XTE monitor range and yellow when it is over. An arrow appears at the right or lef t side of the XTE monitor and it shows the direction to steer to return to t he intended course. The arrow is shown in red when you should steer left, and green when you should steer right. In the example on the previous page you would steer right to return to course set. To maintain course, steer the vessel so the own ship marker stays at the center of the XTE monitor.









  



2-5

2. PLOTTER AND PILOT DISPLAY DESCRIPTION



2.1.5 GPS status display

The GPS status display provides data about the GPS satellites and GEO satellite (for WAAS).

Receiving signal level Bars show satellite signal levels. Satellites whose signal level extends 40 are used to fix position.



Estimated position of satellite in the sky. Satellites used for fixing position are circled.

SNR

SAT

No.

30 40 50

21 07 06 11 03 05 12 08 20 28 30 01

123

01 : 00 : 15 APR 1 2003

GPS 2D DOP

1. 2

ALT

12 m

FREQ

310.0 kHz

75.0 dB

22.0 dB

Time

Date GPS fix status

DOP value

GPS antenna height

DGPS beacon frequency

Signal strength

WAAS satellite (GEO)

GPS status display

Appears when the internal DGPS beacon receiver is installed.



 

DOP value: DOP stands for Dilution of Precision and is an indication of the

quality of the satellite constellation. T he smaller value means the higher accuracy. (For your reference, the positioning accuracy is approx. 10 m when the value is less than “4”.)



SS: SS (Signal Strength) displays a numeric representation of elect r ical field

strength of the received signal on the selected f r equency. The higher the number the stronger the received signal, and a f igure above 60 is normal.

SN: SN (Signal-to-Noise) ratio displays the ratio between the desired signal

and unwanted noise on the selected frequency. The higher the SN ratio the better the quality of the signal, and a figure above 21 is normal.





2-6

2. PLOTTER AND PILOT DISPLAY DESCRIPTION

2.2 Operating the Cursor

1. Press t he [CURSOR ON/OFF] key.

The cursor is turned on, and the cursor appear s at the own ship’s position. To hide the cursor, press the [CURSOR ON/OFF] key again.

Cursor position in L/L

34 43.1447'N

＋

135 21.0758'E

Cursor

20 21



000001

TRKS HOLD

2003. 4. 1

00:01

FISH

9.9

350.2

PLOTTER NAV INFO 1 display (appearing the cursor)



2. Operate the trackball.

The cursor moves in the direction the trackball is operated and the cursor position is indicated at the top of the scr een.



Note: T he chart display moves in the opposite direction when it reaches an edge

of the screen.



To return the cursor to the screen center

▪ Press the [CENTER] key to return the cursor to t he screen cent er.





2-7

2. PLOTTER AND PILOT DISPLAY DESCRIPTION



2.3 Shifting the Display

The display can be shifted on the plotter display and pilot display.

1. I f the cursor is turned on, press the [CURSOR ON/OFF] key to turn it off.

2. Operate the trackball.

The display shifts in the direction which the trackball is rolled.

3. Press t he [CENTER] key to return the own ship position to the screen center. (On the pilot display, the own ship’s mark is positioned slightly below the center of the screen.)

Note: When own ship reaches an edge of the screen, it is ret urned to the

center of the screen autom atically.





2.4 Changing Chart Scale

It is useful to change chart scale to

Show destination on the display

•

Find how close you are to your destination

•

View ship’s tracks around a fishing ground

•

When cursor is off







Own ship is at the screen center. The display is enlarge or shrunk from the screen center.

When cursor is on

The range scale is enlarged or shrunk with the cursor position as center.

Press the [ZOOM IN] key to enlarge the scale, or [ZOOM OUT] key to shrink.

•

After pressing the [ZOOM IN] or [ZOOM OUT] key, the current range appears at the center of the screen for a second. The range value shows the distance between the left-side and right-side edges of the screen.

0.125 0.25 0.50 0.75 1.00 1.50 2.00 3.00 4.00 6.00

8.00 12.0 16.0 24.0 32.0 48.0 72.0 96.0 128 256 512 1024

(The larger value may be different f r om the above depending on latitude of own ship.)

Note 1: When the display is expanded or shrunk beyond the range of the chart

card in use warning icon appears, along with the appropriate chart icon. See paragraph 2.7.

Note 2: You can choose the ranges t o use. See paragraph 9.2.3. Note 3: The width of the screen can be shown with scales instead of the

distance. See paragraph 9.3.



Ranges (default setting)



2-8

2. PLOTTER AND PILOT DISPLAY DESCRIPTION

2.5 Measuring Range and Bearing Between two Points



You can m easure the range and bearing between two points as follows.



1. I f the cursor is turned on, press the [CURSOR ON/OFF] key to turn it off.

2. Press t he [0] key.

The “X” mark is entered at the own ship’s position at the moment the [0] key is pressed, and a data box appears at the top of the display.

Data box

RULER 0.00nm 0.0 T

FISH

"X" mark

20 21

000001

Data box



3. Use the trackball to place the cursor on the starting point. 

When the cursor is moved, a dashed circle appears, with the “X” mark at its center and a dashed line intending from the “X” mark to the cursor.

4. Press t he [ENTER] knob, and the

“+” mark moves to the cursor position.

5. Use the trackball to place the cursor on the ending point.

The data box shows range and bearing between the starting and ending point s .



2-9

2. PLOTTER AND PILOT DISPLAY DESCRIPTION



Range and bearing between starting and ending points

RULER 0.61nm 90.1 T

FISH

Starting point (X mark)

20 21

000001

GPS2D

WGS84

GPS2D

Range and bearing between two points

Ending point (Cursor)

0.3nm



6. Press t he [0] key to terminate the measurement and erase the dashed circle and line, and data.

  

2-10



2. PLOTTER AND PILOT DISPLAY DESCRIPTION

2.6 Using the VRM (Variable Rang e Marker)

The VRM function to measure t he distance between two points, like using dividers to measure distance on a nautical chart.

1. Press the [VRM] key to show the VRM.

Each pressing this key makes the seq uence shown below.

VRM off → VRM (floating VRM) → VRM (fixed VRM) → VRM off …

VRM off: VRM is turned off. VRM (floating VRM): You can adjust its position and radius. VRM (fixed VRM): VRM is fixed at position selected with floating VRM. Its radius

is also fixed.

When cursor is t ur ned on, VRM appears around it. When cur sor is turned off, VRM appears around own ship’s position. Also, a data box appears at the top of the display to show the radius of VRM.

Cursor

VRM (Yellow)

Radius of VRM

0.27nm

20 21

GPS2D

WGS84

VRM

000001

FISH

0.3nm

2. Use the trackball to place the VRM where desired.

3. Rotate the [ENTER] knob to adjust t he radius of VRM. Clockwise rotation: Increase radius. Counterclockwise rotation: Decrease radius.



2-11

2. PLOTTER AND PILOT DISPLAY DESCRIPTION



4. When it is not necessary to change the VRM’s location and size, simply press the [ENTER] knob.

VRM is fixed at the selected position.

5. To turn off the VRM, press the [VRM] key to hide VRM.

The data box disappears immediately.

Note: The [VRM] key’s default function is to turn the VRM on and off. Its function

can be changed as desired. For details, see paragraph 9.5.1.



2.7 Mini Chart Cards

This equipment uses both FURUNO and NAVIONICS chart cards or C-MAP NT mini chart cards depending on its specificat ions. When you insert a suitable chart card in the right side slot and turn on the power, a chart appears. If a wrong card is inserted or a wrong chart scale is selected, landmasses will be hollow. Insert the proper card and select a suitable chart scale. Chart icons appear at the bottom of the plotter (or pilot) display to help you select a suitable chart size. The table below shows the chart icons and their meanings.



Chart icons and their meanings

Icon Meaning





Proper card is not inserted or chart scale is too small. Operate the [ZOOM IN] key to adjust chart scale.

Chart scale is too large. Operate the [ZOOM OUT] key to adjust chart scale.

Suitable chart scale is selected.



2-12



2. PLOTTER AND PILOT DISPLAY DESCRIPTION

Indices and chart enlargement

When the [ZOOM OUT] key is used, you will see several frames appear on the chart. These frames are called indices and they show you what parts of the chart can be zoomed. The areas circumscribed with sm aller frames can show more detailed information.





Indices





2-13

  

(This page intentionally left blank.)

2-14

3. TRACK

Your ship’s track (main and sub tr acks) is plotted on the screen using navigation data fed from the built-in GPS navigator. When connecting with an ARPA-equipped radar, other ship’s track can also be plotted. This chapter shows you how to turn track on or off, and change its color and plotting interval. Own ship’s track is displayed in red in the default setting.

Own ship's track (sub)

Own ship's track (main)

3.1 Displaying Track

3.1.1 Own ship’s track

Own ship’s track can be turned on or off as follows.

1. Press the [MENU] key to display the main menu.

2. Press the [4] key to open the 4. MARKS/SHIP’S TRACKS SETUP menu.

This menu has two pages. If PAGE 2/2 appears, rotate the [ENTER] knob clockwise to select “PREVIOUS PAGE.”

3. Rotate the [ENTER] knob to choose “SHIP’S TRACKS DISP.”

Tracks

Other ship's track

3-1

3. TRACKS

4. MARKS/SHIP'S TRACKS SETUP PAGE 1/2 NEXT PAGE

MARKS SIZE 1. L 2. L+ 3. S LINES STYLE 1. 2. 3. 4. TRACK INTERVAL 1 TIME (00M10s) DIST (0.10nm) TRACK INTERVAL 2 TIME (00M10s) DIST (0.10nm) SHIP'S TRACKS DISP 1. ON 2. OFF DISP TRACKS (HOLD) 1. ON 2. OFF PLOT TRACKS (HOLD) 1. ON 2. OFF TRACKS COLOR 1. 2. 3. 4. TRACKS BY TEMP RANGE GRDNT (0.2˚F 2.0˚F)

WHITE: 005.0˚F BELOW BLUE: 005.0˚F ~ PURPLE 010.0˚F ~ LIGHT BLUE: 012.5˚F ~ GREEN: 015.0˚ F ~ YELLOW: 017.5˚ F ~ RED: 020.0˚F ABOVE

TRACKS BY DEPTH RANGE GRDNT (2ft 20ft 200ft)

WHITE: 0032.8 ft SHALLOWER BLUE: 0032.8 ft ~ PURPLE 0164.0 ft ~ GREEN: 0656.2 ft ~ YELLOW: 0984.3 ft ~

RED: 1312.3 ft DEEPER SHIP'S TRACKS 12,000 MARKS 04,000/16,000

TURN KNOB TO SELECT MENU. SELECT THE ITEM OF EACH MENU BY TRACKBALL.

Marks/ship’s tracks setup menu (page 1)

4. Press the [1] key to choose ON or the [2] key to choose OFF as appropriate.

5. Press the [MENU] key several times to close the menu.

Note: The number of track points used appears at the bottom of the

MARKS/SHIP’S TRACKS EDITION menu. (See page 3-16.)

3-2

3.1.2 Sub track

A second track of own ship’s track, called sub track, may be shown, using data from a second navigator.

Note that the sub track is not stored in the memory; it is erased when it goes off the screen or when the power is turned off.

1. Press the [MENU] key to display the main menu.

2. Press the [4] key to show the MARKS/SHIPS TRACKS SETUP menu.

3. If PAGE 1/1 appears, rotate the [ENTER] knob clockwise to select “NEXT PAGE to show page 2/2.”

4. Rotate the [ENTER] knob to choose “DISP SUB TRACKS.”

4. MARKS/SHIP'S TRACKS SETUP PAGE 2/2 PREVIOUS PAGE

DISP T ARGET TRACKS

TARGET TRACK COLOR

T ARGET TRACK STYLE

DISP SUB TRACKS 1. ON 2. OFF SUB TRACK COLOR 1. 2. 3. 4. 5. 6. 7. SUB TRACK STYLE 1. 2. 3. 4. SUB TRACK TALKER 1.GP 2.II 3.IN 4.SN 5.TR

3. TRACKS

1. ON 2. OFF

1. 2. 3. 4. 5. 6. 7.

1. 2. 3. 4.

6.LA 7.LC 8.DE 9.EC

TURN KNOB TO SELECT MENU. SELECT THE ITEM OF EACH MENU BY TRACKBALL.

Marks/ship’s tracks setup menu (page 2)

5. Press the [1] key to choose ON or the [2] key to choose OFF as appropriate.

6. Press the [MENU] key several times to close the menu.

Note: The position data used to trace the sub track may be chosen with “SUB

TRACK TALKER” on page 2 of the MARKS/SHIP’S TRACKS SETUP menu. For further details, refer to the installation manual.

3-3

3. TRACKS

3.1.3 Other ship’s track

You may show the tracks of ARPA targets tracked in auto tracking. Note that this track is not stored in the memory; it is erased when it goes off the screen a when the power is trued off

1. Press the [MENU] key to display the main menu.

2. Press the [4] key to show the MARKS/SHIP’S TRACKS SETUP menu.

3. If PAGE 1/1 appears, rotate the [ENTER] knob clockwise to select “NEXT PAGE.”

4. Rotate the [ENTER] knob to choose “DISP TARGET TRACKS.”

5. Press the [1] to choose ON or the [2] key to choose OFF as appropriate.

6. Press the [MENU] key several times to close the menu.

3-4

3. TRACKS

3.2 Stopping, Restarting Plotting of Own Ship Track

When your boat is at anchor or ret urning to port, you probably won’t need to record its track. You can st op recording the track, to conserve the track memory, as follows.

1. Press the [PLOT INTVL] key several times t o show the “H” (Hold) icon (at the bottom of the screen). Each time the key is pressed the track funct ion available changes in the sequence shown below.

TRACK INTERVAL 1 -> TRACK INTERVAL 2 -> HOLD -> TRACK INTERVAL 1 Track plotting interval or “HOLD” appears at the top right corner of the NA V INFO

1 (or 2) display. W hen plot ting is stopped, own ship’s mark changes from a solid circle to a hollow one and track is not stored in the mem ory.

34° 44.1447'N

21.0758'E

135

9.9

350.2

TRKS HOLD

2003. 1. 1

00:01

FISH

Current interval or "TRKS HOLD"

Own ship's mark

20 21

GPS2D

WGS84

000001

0.3nm

Stopping plotting track (ex. PLOTTER NAV INFO 1 display)

Note:

If the track plotting interval is not shown in the NAV INFO window, see

paragraph 9.6.2.

2. To restart plotting, press the [PLOT INTVL] key.

Note:

Plotting can also be stopped or restarted from the full screen echo

sounder display.

HOLD icon

3-5

3. TRACKS

3.2.1 Displaying own ship’s track while track plotting is stopped

You can show or hide own ship’s track on the PLOTTER (or PILOT) display while track plotting is stopped.

1. Press the [MENU] key to show the main menu.

2. Press the [4] key to show the MARKS/SHIP’S TRACKS SETUP menu.

3. If PAGE 2/2 appears, rotate the [ENTER] knob clockwise to select “PREVIOUS PAGE.”

4. Rotate the [ENTER] knob to choose “DISP TRACKS (HOLD).”

5. Press t he [1] key to choose ON or the [2] key to choose OFF as appropriate

ON: Own ship’s track is displayed while recording is stopped. In this case own ship’s track is not recorded; it is erased when it goes off scr een or when the power is turned off.

OFF: Own ship’s track is not displayed while recording is stopped.

Own Ship

Set to "ON"

Resumed

Stopping

Display enlarged Display shrunk

Own Ship

Track disappears.

Resumed

Stopped

Display while stopping recording of track

(When “ON” is selected at step 5 above)

5. Press the [MENU] key several times to close the menu.

3-6

3.2.2 Connecting own ship’s track when resuming plotting

When you resume plotting of own ship’s track, the point where plotting was stopped and restarted can be connected with a straight line.

1. Press the [MENU] key to show the main menu.

2. Press the [4] key to display the MARKS/SHIP’S TRACKS SETUP menu.

3. If PAGE 2/2 appears, rotate the [ENTER] knob clockwise to select “PREVIOUS PAGE.”

4. Rotate the [ENTER] knob to choose the “PLOT T RACKS (HOLD).”

5. Press t he [1] key to choose ON or the [2] key to choose OFF as appropriate

ON: Stopping and resuming points ar e connected with a straight line. OFF: Stopping and resuming points ar e not connected.

Track shown by dashed lines not displayed.

Plotting Restarted

Own Ship

3. TRACKS

Plotting

Actual Track

Suspended

Track points where plotting was suspended and restarted are not connected.

Own Ship

Track connected

Track points where track plotting was stopped and restarted are connected with a straight line.

Display after stopping

5. Press the [MENU] key several times to close the menu.

3-7

3. TRACKS

3.3

Changing Track Color

Track can be displayed in red, yellow, green, light-blue, purple, blue or white. It can be useful to change track color on a regular basis to discrim inate between previous day’s track, etc. For own ship’s track, track color can be changed automatically according to water temperature or dept h.

3.3.1 Changing own ship’s track color

1. Press the [TRACK COLOR] key to show the CHANGE SHIP’S TRACK COLOR window.

CHANGE SHIP'S TRACK COLOR

1. 2. 3. 4. 5. 6. 7. 8. TMP 9. DEPTH

PRESS APPROPRIATE NUMERIC KEY TO SELECT COLOR. PRESS "0" KEY TO DELETE SHIP'S TRACK.

Change ship’s track color window

Note: This window disappears if there is no operation in ten seconds.

2. Press the appropriate numeric key to choose color.

1 through 7 keys: Own ship’s track is colored accordingly. 8: Own ship’s track color changes with water temperature. (Requires water

temperature sensor.) 9: Own ship’s track color changes with depth.

Own ship’s track color changes from the moment .

3.3.2 Changing sub track color

1. Press the [MENU] key to show the main menu.

2. Press the [4] key to show the MARKS/SHIP’S TRACKS SETUP menu.

3. If PAGE 1/2 appears, rotate the [ENTER] knob to select NEXT PAGE.

4. Rotate the [ENTER] knob to select SUB TRACKS COLOR.

5. Press the appropriate numeric key to choose color.

6. Press the [MENU] key several times to close the menu.

3.3.3 Changing target track color

1. Press the [MENU] key to show the main menu.

2. Press the [4] key to show the MARKS/SHIP’S TRACKS SETUP menu.

3. If PAGE 1/2 appears, rotate the [ENTER] knob to select NEXT PAGE.

4. Rotate the [ENTER] knob to select TARGET TRACK COLOR.

5. Press the appropriate numeric key to choose color.

6. Press the [MENU] key several times to close the menu.

3-8

3. TRACKS

3.3.4 Automatically changing own ship’s track color by water temperature

There are two methods by which own ship’s track color may be changed according to water temperature: by preset temperature range or temperature variation.

Changing own ship ’s track color by preset temperature range

This method changes the color of track when the water temperature is within a preset range. For example, you can set up to paint t he track yellow when the water temperature is between 17 and 20°C.

1. Press the [MENU] key to show the main menu.

2. Press the [4] key to show the MARKS/SHIP’S TRACKS SETUP menu.

3. If PAGE 2/2 appears, rotate the [ENTER] knob to select PREVIOUS PAGE.

4. MARKS/SHIP'S TRACKS SETUP PAGE 1/2 NEXT PAGE

WHITE: 005.0˚F BELOW BLUE: 005.0˚F ~ PURPLE 010.0˚F ~ LIGHT BLUE: 012.5˚F ~ GREEN: 015.0˚ F ~ YELLOW: 017.5˚ F ~ RED: 020.0˚F ABOVE

TRACKS BY DEPTH RANGE GRDNT (2ft 20ft 200ft)

WHITE: 0032.8 ft SHALLOWER BLUE: 0032.8 ft ~ PURPLE 0164.0 ft ~ GREEN: 0656.2 ft ~ YELLOW: 0984.3 ft ~

RED: 1312.3 ft DEEPER SHIP'S TRACKS 12,000 MARKS 04,000/16,000

TURN KNOB TO SELECT MENU. SELECT THE ITEM OF EACH MENU BY TRACKBALL.

Marks/ship’s tracks setup menu (Page 1/1)

3-9

3. TRACKS

4. Rotate the [ENTER] knob to select TRACKS BY TEMP.

5. Roll the trackball leftward to select “RANGE.”

6. Set the temperature range desired for each color. For example, if you want to paint the track red when the water temperature is higher than 18°C, do the following:

a) Rotate the [ENTER] knob to select “RED: xxx.x°C ABOVE.” b) Press the [0], [1], [8], [0] in that order, and then press the [ENTER] knob.

Note: To erase, press the [CLEAR] key.

c) Set ranges for other colors sim ilar ly. You cannot enter the r ange for WHITE. It

becomes the same range as BLUE automatically.

7. Press the [MENU] key several times to close the menu.

Changing own ship ’s track color according to temperature variation

This setting paints the track in up to f ive colors according to temperature variation. When you select “0.2ºF”, for example, the track is painted red when the water temperature is between 17.0 and 17.2 degrees; yellow when the water temperature is between 17.2 and 17.3 degrees. Thus, t he track color changes green, blue and purple in 0.2 degree steps. When the water temperature becomes 18.0 degrees, the track color returns t o red.

Own Ship

YEL

18.2

18.0

17.8

RED

YEL

17.0˚C

GRN

17.2

RED

PPL

BLU

17.6

17.4

Example, presetting unit 0.2°

1. Press the [MENU] key to show the main menu.

2. Press the [4] key to show the MARKS/SHIP’S TRACKS SETUP menu.

3. If PAGE 2/2 appears, rotate the [ENTER] knob to select PREVIOUS PAGE.

4. Rotate the [ENTER] knob to select TRACKS BY TEMP.

5. Roll the trackball rightward to select 0.2ºF or 2.0ºF of “G RDNT.”

6. Press the [ENTER] knob.

7. Press the [MENU] key several times to close the menu.

3-10

3.3.5 Changing own ship’s track color according to depth

The color of the own ship’s track can be changed according to depth range or depth variation.

Changing track color by preset depth range

This method changes the color of track when the depth is within a preset range. For example, you can set up to paint the tr ack yellow when the depth is between 200 and 300 feet.

1. Press the [MENU] key to show the main menu.

2. Press [4] key to show the MARKS/SHIP’S TRACKS SETUP menu.

3. If the PAGE 2/2 appears, rotate the [ENTER] knob to select PREVIOUS PAGE.

4. MARKS/SHIP'S TRACKS SETUP PAGE 1/2 NEXT PAGE

WHITE: 005.0˚F BELOW BLUE: 005.0˚F ~ PURPLE 010.0˚F ~ LIGHT BLUE: 012.5˚F ~ GREEN: 015.0˚F ~ YELLOW: 017.5˚F ~ RED: 020.0˚F ABOVE

TRACKS BY DEPTH RANGE GRDNT (2ft 20ft 200ft)

WHITE: 0032.8 ft SHALLOWER BLUE: 0032.8 ft ~ PURPLE 0164.0 ft ~ GREEN: 0656.2 ft ~ YELLOW: 0984.3 ft ~

RED: 1312.3 ft DEEPER SHIP'S TRACKS 12,000 MARKS 04,000/16,000

3. TRACKS

TURN KNOB TO SELECT MENU. SELECT THE ITEM OF EACH MENU BY TRACKBALL.

Marks/ship’s tracks setup menu (Page 1/2)

3-11

3. TRACKS

4. Rotate the [ENTER] knob to select “TRACKS BY DEPTH”.

5. Roll the trackball leftward to select “RANGE.”

6. Set the depths as desired. For example, t o change t r ack color to red when the depth is more than 500 feet:;

a) Rotate the [ENTER] knob to select “RED xxxx.xx ft DEEPER.” b) Press the [0], [5], [0], [ 0] , [0], [0] keys in that order, and then press the

[ENTER] knob.

Note: To erase, press the [CLEAR] key.

c) Set depths for other colors similarly. You cannot enter the depth for WHITE:

it is automatically set for the sam e dept h as BLUE.

7. Press the [MENU] key several times to close the menu.

Changing own ship’s track color by depth variation

This setting paints the track in up to seven colors according to depth variation selected. For example, you could set up to change the tr ack color for every 20 feet of depth change.

Own Ship

Purple

140

Red

200

180

160

Depth steadily increasing.

Green

Yellow

Red

100 ft

Light-blue

120

Example, track color changes with every 20 ft of depth change

1. Press the [MENU] key to show the main menu.

2. Press the [4] key to show the MARKS/SHIP’S TRACKS SETUP menu.

3. If PAGE 2/2 appears, rotate the [ENTER] knob to select PREVIOUS PAGE.

4. Rotate the [ENTER] knob to select TRACKS BY DEPTH.

5. Roll the trackball rightward to select 2 ft, 20 ft or 200 ft of “GRDNT.”

6. Press the [MENU] key several times to close the menu.

3-12

3.4 Changing T rack Line Type

Tracks may be traced on the display with a solid line, dashed line, dotted line or dot-dash line. Choose line type desired as follows:

1. Press the [MENU] key to show the main menu.

2. Press the [4] key to show the MARKS/SHIP’S TRACKS SETUP menu.

3. To set own ship’s track line, select LINE STYLE on PAGE 1/2.

For the sub track or target track lines, select the appropr iat e item on the PAGE 2/2.

4. Press appropriate numeric key to select the line type desired.

5. Press the [MENU] key several times to close the menu.

3.5 Track Plotting Method, Inter val

In drawing the track, the ship’s position is stored into the unit’s memory at an interval of time or distance. A shorter int erval provides better reconstruction of the track, but the storage time of the track is reduced. When the track memory becomes full, the oldest track is erased to make room for the latest.

3.5.1 Track plotting method

3. TRACKS

● Press the [P LOT INTVL] key to select the track plotting method.

Each time the key is pressed the plotting met hod changes in the sequence shown below.

Track interval 1→Track interval 2→Hold→Track interval 1 … The PLOTTER (or PILO T) NAV INFO 1 display shows the current plotting

method. Distance is useful for conserving tr ack memory, since no track is recorded when

the boat is stationary. To change t he t rack plotting method (for time and distance) and interval, see the

next paragraph.

"00M10s" "0.10nm" "TRKS HOLD" "00M10s" ...

TRKS 00M01s

2003. 1. 1

00:01

FISH

34 44.1447'N 135 21.0758'E

350.2

9.9

Plotter display showing location of track plotting interval indication

Note: If the plotting method does not appear, see paragraph 9.6.2.

3-13

3. TRACKS

3.5.2 Track plotting interval

The track plotting interval can be changed as you like.

1. Press the [MENU] key to show the main menu.

2. Press the [4] key to show the MARKS/SHIP’S TRACKS SETUP menu.

3. If PAGE 2/2 appears, rotate the [ENTER] knob to select PREVIOUS PAGE.

4. Rotate the [ENTER] knob to select “TRACK INTE RVAL 1” or “TRACK INTERVAL 2”.

5. Roll the trackball in left-right direction to select “TIME” or “DIST (distance)” as appropriate.

6. Press the numeric keys to enter value.

Setting range is 00M00S to 99M59S (Time), 0.00 nm to 9.99 nm (Dist ance).

Note 1: To clear data, press the [CLEAR] key. Note 2:You may remove a plotting interval from the [PLOT INTVL] key’s

selection sequence by entering all zeroes as the plotting interval. For example, if TRACK INTE RVAL 2 is set as 00M00S (or 0.00 nm), the sequence [PLOT INTVL] key’s sequence is as shown below.

TRACK INTERVAL 1 → Hold → TRACK INTERVAL 1 → Hold

7. Press the [ENTER] knob.

8. Press the [MENU] key several times to close the menu.

3-14

3.6 Erasing Tracks

There are two methods to erase tracks: by color and by line type. Be absolutely sure you want to erase track; erased track cannot be restored.

Note 1: Files set to “YES” on the DISPLAY DATA FROM MEMORY CARD menu

cannot be erased. (See paragraph 10.2.3.) Also, files set to “YES” on the DISPLAY DATA FROM INTERNAL MEMORY menu cannot be erased. (See paragraph 10.4.2.)

Note 2: Tracks set to change according to water temperature or depth cannot be

erased. (See paragraph 3.3.1.)

3.6.1 Erasing tracks by color

You may erase tracks according to color, within an area or all same color track.

Erasing all track

1. Press the [TRACK COLOR] key to show the CHANGE SHIP’S TRACK COLOR window.

2. Press the [0] key within 10 seconds to show the DELETE SHIP’S TRACK window.

3. TRACKS

DELETE SHIP'S TRACK

1. 2. 3. 4. 5. 6. 7.

PRESS APPROPRIATE NUMERIC KEY TO DELETE SHIP'S TRACK.

Delete ship’s track window

3. Press the appropriate numeric key to choose the color to erase.

The following message appears.

DELETE ALL SHIP'S TRKS IN XXXX (type of color).

ARE YOU SURE? YES ... PRESS KNOB NO ... PRESS CLEAR KEY

4. Press the [ENTER] knob to clear all tracks of t he color chosen.

3-15

3. TRACKS

Erasing tracks by area

You can erase tracks within an area you specify.

1. Press the [MENU] key to show the main menu.

2. Press the [5] key to show the MARKS/SHIP’S TRACKS EDITION menu.

5. MARKS/SHIP'S TRACKS EDITION

1. EDIT MARKS

2. DELETE MARKS

3. ENTER MARKS

4. EDIT SHIP'S TRACKS

5. DELETE SHIP'S TRACKS Used points

NUMBER OF TRACKS 6,886/12,000 NUMBER OF MARKS 3/4,000

TURN KNOB TO SELECT MENU AND PRESS KNOB TO ENTER. OR PRESS APPROPRIATE NUMERIC KEY TO SELECT MENU.

Points available

Marks/ship’s track edition menu

3. Press the [5] key to show the DELETE SHIP’S TRACKS window.

5-5. DELETE SHIP'S TRACKS

ENTER SELECT 1. 2PTS 2. AREA 3. INSIDE 4. OUTSIDE 5. ALL COLOR STYLE 1. 2. 3. 4. 5. ALL

SET "SELECT", "COLOR" AND "STYLE". PLACE CURSOR ON "ENTER".

1. 2. 3. 4. 5. 6. 7. 8. ALL

Delete ship’s tracks window

4. Rotate the [ENTER] knob to select COLOR.

5. Roll the trackball in left-right direction to select the color to erase.

6. Rotate the [ENTER] knob to choose SELECT.

7. Roll the trackball in left-right direction to select a method.

2 PTS: All tracks between two points entered on the plot t er screen are erased. AREA: All tracks within an area you set are erased. INSIDE: All tracks curr ent ly displayed are erased. OUTSIDE: All tracks other than currently displayed ones are erased. ALL: All tracks in the memor y are er ased.

8. Rotate the [ENTER] knob to select ENTER.

3-16

9. Do the follows depending on selection made at step 7.

2 PTS Squares (memory points) appear on the t r ack.

Own Ship

Memory point

Track

a) Operate the trackball to place the cursor on the starting memory point to

erase. b) Press the [ENTER] knob. A gr een dot appear s on t he starting point. c) Operat e t he trackball to place the square on the ending memory point to

erase. d) Press the [ENTER] knob twice. e) Press the [MENU] key several times to close the menu.

AREA

a) Operate the trackball to move the cursor t o the starting point of the ar ea t o

erase. b) Press the [ENTER] knob. c) Operat e t he trackball to move the cursor to the ending point of the area to

erase. A green rectangle appears.

Starting point

3. TRACKS

Cursor

Green rectangle (All tracks in this area are erased.)

Erasing area

d) Press the [ENTER] knob to change th e color of rectangle from green to

white. e) Press the [ENTER] knob again. f) Press the [ENTER] knob several times to close t he menu.

INSIDE, OUTSIDE or ALL a) Press the [ENTER] knob. b) Press the [MENU] key several times to close the menu.

3-17

3. TRACKS

3.6.2 Erasing tracks by line type

You can erase tracks by line type as follows:

1. Press the [MENU] key to show the main menu.

2. Press the [5] key to show the MARKS/SHIP’S TRACKS EDITION menu.

3. Press the [5] key to show the DELETE SHIP’S TRACKS window.

5-5. DELETE SHIP'S TRACKS

ENTER SELECT 1. 2PTS 2. AREA 3. INSIDE 4. OUTSDE 5. ALL COLOR 1. 2. 3. 4. 5. 6. 7. 8. ALL STYLE 1. 2. 3. 4. 5. ALL

SET "SELECT", "COLOR" AND "STYLE". PLACE CURSOR ON "ENTER".

Delete ship’s tracks window

4. Rotate the [ENTER] knob to select STYLE.

5. Press appropriate number key to chose line type to erase ALL erases all track.

6. Rotate the [ENTER] knob to choose SELECT.

7. Press appropriate numeric key to select a met hod.

2 PTS: All tracks between two points entered on the plotter screen are erased.

AREA: All tracks within an area you set are erased. INSIDE: All tracks currently displayed are erased. OUTSIDE: All tr acks other than those currently displayed are erased. ALL: All tracks in the memor y are er ased.

8. Rotate the [ENTER] knob to select ENTER.

9. Follow step 9 in paragraph 3.6.1.

3-18

3.7 Editing Tracks

The color and style of tracks may be edited as desired.

Note 1: Files set to “YES” on the DISPLAY DATA FROM MEMORY CARD menu

cannot be edited. (See paragraph 10.2.3.) Also, files set to “YES” on the DISPLAY DATA FROM INTERNAL MEMORY menu cannot be edited. (See paragraph 10.4.2.)

Note 2: Tracks set to change according to water temperature or depth cannot be

erased. (See paragraph 3.3.1.)

1. Press the [MENU] key to show the main menu.

2. Press the [5] key to show the MARKS/SHIP’S TRACKS EDITION menu.

3. Press the [4] key to show the EDIT SHIP’S TRACKS window.

5-4. EDIT SHIP'S TRACKS ENTER

SELECT 1. PTS 2. AREA 3. INSIDE 4. OUTSIDE COLOR 1. 2. 3. 4. 5. 6. 7. 8. NONE STYLE 1. 2. 3. 4. 5. NONE

3. TRACKS

SET "SELECT", "COLOR" AND "SHAPE". PLACE CURSOR ON "ENTER".

Edit ship’s tracks window

4. Rotate the [ENTER] knob to choose SELECT.

5. Press appropriate numeric key to select the m et hod.

6. Rotate the [ENTER] knob to select COLOR.

7. Press appropriate numeric key to select the color to be changed.

8. Rotate the [ENTER] knob to select STYLE.

9. Press appropriate numeric key to select the line type.

10. Rotate the [ENTER] knob to select ENTER.

11. Do the follows depending on your selection at step 5. For details, see paragraph 3.6.2.

3-19

3. TRACKS

3.8 Changing Track Memory Capacity

The equipment stores a total of 16,000 points of track and marks, and the default setting allocates 12,000 points for track and 4,000 points for marks and lines. If you require a different apportion you may change it as shown in the procedure below. Note that when the track memory capacity is changed, all tracks and marks in the m emory are erased. Save them to a memory card (See paragraph 10.2.2) or internal memory (See paragraph 10.4.1) if necessary. The internal memory which has five memory brocks can store maximum 80,000 points of track and marks.

1. Press the [MENU] key to show the main menu.

2. Press the [4] key to show the MARKS/SHIP’S TRACKS SETUP menu.

3. If the PAGE 2/2 appears, rotate the [ENTER] knob to select PREVIOUS PAGE.

4. Rotate the [ENTER] knob to select SHIP’S TRACKS.

5. Press the numeric keys to enter the track memory points.

Note: To clear entry, press the [CLEAR] key.

6. Press the [ENTER] knob, and the f ollowing window appears.

ALL TRACKS, MARKS & LINES WILL BE DELETED.

ARE YOU SURE? YES ... PRESS KNOB NO ... PRESS CLEAR KEY

Note: If the number more than 16,000 or “_ “ is entered at step 5, an error

beep sounds and the [ENTER] knob is inoperative.

7. Press the [ENTER] knob.

At this time all tracks, marks and lines in the memory are erased.

Note: To cancel, press the [CLEAR] key.

8. Press t he [MENU] key several times to close the menu.

3-20

4. MARKS & LINES

Marks are useful for denoting import ant points such as a good fishing spot. The default setting allows you to enter 4,000 marks and line points. Marks can be inscribed in 11 shapes and seven colors of red, yellow, green, light-blue, purple, blue and white.

4.1 Entering Marks

You can enter marks three ways:

Enter a mark at own ship position

•

Enter a mark at the cursor position

•

Enter mark by latitude and longitude position

•

Note:

The number of marks and lines used appears at the bottom of the

MARKS/SHIP’S TRACKS EDITION menu. (See page 4-2.)

Entering a mark at own ship position

1. Press the [CURSOR ON/OFF] key to turn off the cursor.

2. Press the numeric key corresponding to the mark you wish to enter.

[1] key: [2] key: [3] key: [4] key: Y [5] key: [6] key: [7] key: [8] key:

The water temperature and depth at the m ar k position are memorized automatically when the appropriate sensors are connected.

Entering a mark at the cursor posi t ion

1. Press the [CURSOR ON/OFF] key to show the cursor.

2. Operate the trackball to place the cursor at the location where you want to enter a mark.

3. Press t he numeric key corresponding to the mark you wish to enter.

4-1

4. MARKS & LINES

Entering a mark by manual input of latitude and longitude position

1. Press the MENU key to display main menu.

2. Press the [5] key to display the MARKS/SHIP’S TRACKS EDITION menu.

5. MARKS/SHIP'S TRACKS EDITION

1. EDIT MARKS

2. DELETE MARKS

3. ENTER MARKS

4. EDIT SHIP'S TRACKS

5. DELETE SHIP'S TRACKS Used points

NUMBER OF TRACKS 6,886/12,000 NUMBER OF MARKS 3/4,000

TURN KNOB TO SELECT MENU AND PRESS KNOB TO ENTER. OR PRESS APPROPRIATE NUMERIC KEY TO SELECT MENU.

Points available

Marks/ship’s tracks edition menu

3. Press the [3] key to choose “ENTER MARKS.”

5-3. ENTER MARKS LAT/LON 00°00.000'N 000°00.000'E

COLOR 1. 2. 3. 4. 5. 6. 7. SHAPE LINE 1.YES 2. NO

TURN KNOB TO SELECT MENU. PRESS APPROPRIATE NUMERIC KEY TO ENTER LAT/LON OF A MARK. CURSOR ON/OFF KEY: SWITCH N/S AND E/W

Enter marks menu

4. Rotate the [ENTER] knob to choose “COLO R. ”

5. Press appropriate numeric key to choose a color.

6. Rotate the [ENTER] knob to choose SHAPE.

7. Roll the trackball in the right-left direct ion to choose the shape desired.

8. Rotate the [ENTER] knob to choose LINE.

9. Press t he [1] key to connect marks with lines; [2] key to inscribe marks without interconnection lines.

10. Rotate t he [ENTER] knob to choose “LAT/LON.”

11. Press the numeric keys to enter latitude of mark position.

To enter 34° 38.838 latitude, for example, press [3], [4], [3], [8], [8], [3], [8] keys in that order. You can switch co-ordinates (N <- > S) by pressing the [CURSOR ON/OFF] key before entering latitude.

12. Press the numeric key to enter longitude of m ark posit ion.

To enter 135° 34. 638 longitude, for example, press [1] , [3], [5], [3], [4], [6], [3], [ 8] keys in that order. You can switch co-ordinates (E <-> W) by pressing the [CURSOR ON/OFF] key bef ore entering longitude.

13. Press the [ENTER] knob to inscribe the mark at the locat ion entered.

14. Press the [MENU] key several times to close the menu.

4-2

4.2 Changing Mark Color

Mark can be displayed in red, yellow, green, light-blue, purple, blue, or white.

1. Press the [MARK COLOR] key to show the CHANGE MARK COLOR window.

CHANGE MARK COLOR

1. 2. 3. 4. 5. 6. 7. 8. KEY'S COLOR

PRESS APPROPRIATE NUMERIC KEY TO SELECT COLOR.

Change mark color window

2. Press the appropriate numeric key to choose a color.

[1] through [7]: The mark or line is entered at own ship’s position (or cursor position) in the color selected.

[8]: The mark is ent er ed at own ship’s position (or cursor position) in the color and shape shown on the label of the numeric key.

You may show mark s in one color or the colors shown on the numeric key.

4. MARKS & LINES

4-3

4. MARKS & LINES

4.3 Changing Mark Size

You may choose mark size as follows:

1. Press the [MENU] key to display main menu.

2. Press the [4] key to display the MARKS/SHIP’S TRACKS SETUP menu.

3. If PAGE 2/2 appears, rotate the [ENTER] knob clockwise to select “PREVIOUS PAGE.”

4. MARKS/SHIP'S TRACKS SETUP PAGE 1/2 NEXT PAGE

WHITE: 041.0˚F BELOW BLUE: 041.0˚F ~ PURPLE 050.0˚F ~ LIGHT BLUE: 054.5˚F ~ GREEN: 059.0˚ F ~ YELLOW: 063.5˚ F ~ RED: 068.3˚F ABOVE

TRACKS BY DEPTH RANGE GRDNT (2 ft 20 ft 200 ft)

WHITE: 0032.8 ft SHALLOWER BLUE: 0032.8 ft ~ PURPLE 0164.0 ft ~ GREEN: 0656.2 ft ~ YELLOW: 0984.3 ft ~

RED: 1312.3 ft DEEPER SHIP'S TRACKS 15,000 MARKS 1,000/16,000

4-4

TURN KNOB TO SELECT MENU. SELECT THE ITEM OF EACH MENU BY TRACKBALL.

Marks/ship’s tracks setup menu (page 1)

4. Rotate the [ENTER] knob to choose “MARKS SIZE.”

5. Press appropriate numeric key to choose size.

1. L: Large

2. L+: Large with dot at center of mark

3. S: Small

6. Press the [MENU] key several times to close the menu.

4.4 Entering Lines

Lines can be drawn on the screen to depict important locations such as fishing spots and danger areas.

1. Press the [CURSOR ON/OFF] key to show the cursor.

2. Operate the trackball to m ove the cursor t o the starting point of the line.

3. Press appropriate numeric key (1 to 8) to choose the m ark you wish to show between line points.

[1] key: [2] key: [3] key: [4] key: Y [5] key: [6] key: [7] key: [8] key:

4. Operate the trackball to m ove the cursor t o the next point for the line.

5. Press the [9] key.

6. Repeat steps 4 and 5 to complete the line.

4. MARKS & LINES

Ending point

Starting point

Starting a new line

To start a new line, press appropriate numeric key (1 to 8) at t he start point. For example, press one of numeric keys (1 to 8) at point D and the [9] key for points E and F.

4.5 Selecting Line Type

Lines are available in four styles: solid, dashed, dash-dot and dash-double dot line.

1. Press the [MENU] key to show the main menu.

2. Press the [4] key to show the MARKS/SHIP’S TRACKS SETUP menu.

3. If PAGE 2/2 appears, rotate the [ENTER] knob to select PREVIOUS PAGE.

4. Rotate the [ENTER] knob to select LINE STYLE.

5. Press appropriate numeric key to choose line style.

6. Press the [MENU] key several times to close the menu.

Line

Two lines

New line

4-5

4. MARKS & LINES

4.6 Erasing Marks, Lines

Marks and lines can be erased individually, by color and by type. Note that the erased marks and lines cannot be ret urned.

Note :

Erasing marks and lines individually

1. Press the [CURSOR ON/OFF] key to show the cursor.

2. Operate the trackball to place the cursor on the mark (or line) to erase.

3. Press the [CLEAR] key.

Erasing marks and lines by color

Files set to “YES” on the DISPLAY DATA FROM MEMORY CARD menu

cannot be erased. (See paragraph 10.2.3.) Also, files set to “YES” on the DISPLAY DATA FROM INTERNAL MEMORY menu cannot be erased. (See paragraph 10.4.2.)

The flashing diamond appears. When erasing lines, place the cursor on the mark of line.

If the selected mark or line is not erased, press the [CLEAR] key several times; multiple marks may occupy the same location.

1. Press the [MENU] key to show the main menu.

2. Press the [5] key to show the MARKS/SHIP’S TRACKS EDITION menu.

3. Press the [2] key to show the DELETE MARKS window.

5-2. DELETE MARKS ENTER

SELECT 1. CURSOR 2. AREA 3. INSIDE 4. OUTSDE 5. ALL COLOR 1. 2. 3. 4. 5. 6. 7. 8. ALL SHAPE ALL

SET "SELECT", "CURSOR" AND "SHAPE". PLACE CURSOR ON "ENTER".

Delete marks window

4. Rotate the [ENTER] knob to select COLOR.

5. Roll the trackball in left-right direction to select the color to erase.

6. Rotate the [ENTER] knob to choose SELECT.

7. Press the appropriate numeric key to choose how to erase.

CURSOR: The mark select ed by the cur sor is erased. AREA: Marks and lines in the area you set ar e er ased. INSIDE: All marks and lines currently displayed are erased. OUTSIDE: All mar ks and lines which are not currently displayed are erased. ALL: All marks and lines stored in the memory are erased.

8. Rotate the [ENTER] knob to select ENTER.

9. Do one of the following depending on the selection you made at step 7.

4-6

4. MARKS & LINES

CURSOR

a) Operate the trackball t o place the cursor on the mark you want to erase. b) Press the [ENTER] knob. c) Press the [MENU] key several times to close the menu.

AREA

a) Operate the trackball t o move the cursor to the starting point of the area. b) Press the [ENTER] knob. c) Operate the trackball to move the cur sor to the ending point of the area.

A green rectangle appears.

Starting point

Cursor

Area (green)

Erased area

d) Press the [ENTER] knob. The color of the rectangle changes from green to

white. e) Press the [ENTER] knob again. f) Press the [MENU] key several times to close the menu.

INSIDE, OUTSIDE and ALL

a) Press the [ENTER] knob. b) Press the [MENU] key several times to close the menu.

4-7

4. MARKS & LINES

Erasing marks and lines by shap e

1. Press the [MENU] key to show the main menu.

2. Press the [5] key to show the MARKS/SHIP’S TRACKS EDITION menu.

3. Press the [2] key to show the DELETE MARKS window.

4. Rotate the [ENTER] knob to select SHAPE.

5. Roll the trackball in left-right direction to select the shape.

6. Rotate the [ENTER] knob to choose SELECT.

7. Press the appropriate numeric key to select the method.

8. Rotate the [ENTER] knob to select ENTER.

9. Do step 9 in the “Erasing marks and lines by color” on page 4-6.

5-2. DELETE MARKS ENTER

SELECT 1. CURSOR 2. AREA 3. INSIDE 4. OUTSDE 5. ALL COLOR 1. 2. 3. 4. 5. 6. 7. 8. ALL SHAPE ALL

SET "SELECT", "CURSOR" AND "SHAPE". PLACE CURSOR ON "ENTER".

Delete marks menu

4-8

4.7 Editing Marks, Lines

You can edit the shape and color of marks and lines.

Note:

Files set to “YES” on the DISPLAY DATA FROM MEMORY CARD menu

cannot be erased. (See paragraph 10.2.3.)

Also, files set to “YES” on the DISPLAY DATA FROM INTERNAL

MEMORY menu cannot be erased. (See paragraph 10.4.2.)

1. Press the [MENU] key to show the main menu.

2. Press the [5] key to show the MRKS/SHIP’S TRACKS EDITION menu.

3. Press the [1] key to show the EDIT MARKS window.

5-1 EDIT MARKS ENTER

SELECT 1. CURSOR 2. AREA 3. INSIDE 4. OUTSIDE COLOR 1. 2. 3. 4. 5. 6. 7. 8. ALL SHAPE NONE

4. MARKS & LINES

SET "SELECT", "COLOR" AND "SHAPE" PLACE CURSOR ON "ENTER".

Edit marks window

4. Rotate the [ENTER] knob to choose SELECT.

5. Press the appropriate numeric key to select the method.

CURSOR: Use the cursor to choose mar k to edit. AREA: Edit marks and lines in the area you set.

INSIDE: Edit m ar ks and lines currently displayed. OUTSIDE: Edit m ar ks and lines which are not currently displayed.

6. Rotate the [ENTER] knob to select COLOR.

7. Press the appropriate numeric key to select the color to be changed.

8. Rotate the [ENTER] knob to select SHAPE.

9. Roll the trackball in left-right direction t o select the shape to edit.

10. Rotate the [ENTER] knob to select ENTER.

11. Refer to page 4-7 to edit .

4-9

4. MARKS & LINES

4.8 Displaying Mark Data

You can display mark dat a as follows;

Note: Files set to “YES” on the DISPLAY DATA FROM MEMORY CARD menu

cannot be displayed. (See paragraph 10.2.3.) Also, files set to “YES” on the DISPLAY DATA FROM INTERNAL MEMORY menu cannot be displayed. (See paragraph 10.4.2.)

1. Press the [CURSOR ON/OFF] key to show the cursor.

2. Operate the trackball to place the cursor on the mark for which you want to display its data. Water temperature data requires an appropriate sensor.

Cursor

Mark

Note: If mark data does not appear, press [MENU], [0], [1] in that order, and then

turn on MARK STATUS on PAGE 2/2 of the DISPLAY SETUP menu.

37˚04.640'N 135˚21.047'E + 4.5˚C 13.7m

Water temperature*

Latitude Longitude

Depth*

*: For own ship's position

Mark data

4.9 Target Mark (TLL)

Target position data can be output from certain radars and shown on your plotter with the TLL mark (x). For details, see the Operator’s Manual for your radar.

4-10

5. WAYPOINT

In navigation terminology, a waypoint is a particular location on a voyage whether it be a starting, intermediate or destinat ion point. A waypoint is the simplest piece of information your equipment requires t o get you a destination, in the shortest distance possible.

5.1 Entering Waypoints

This unit has 3500 waypoints into which you can enter position information. There are seven methods by which you can enter a waypoint: at own ship’s position, by cursor, by latitude and longitude, by range and bearing, by Loran-C LOP, by Loran-A LOP and by Decca LOP.

5.1.1 Entering waypoints at own ship’s position

Press the [SAVE/MOB] key momentarily.

•

The message “WAYPOINT XXXXXX IS SAVED! CONTINUE PRESSING FOR MOB!” appears for three seconds to let you k now that ship’s position is saved as a waypoint. The default waypoint mark is a yellow solid circle. You can know the shape and color of the selected waypoint by the icon ( plotter (or pilot) display. This new waypoint will automatically be saved in the waypoint list under the next consecutive waypoint number.

Note: If the waypoint icon does not appear at the bottom of the plotter (or pilot)

display, do the following. a) Press the [MENU], [0], [1] in that order to show the DISPLAY SETUP menu. b) Select “1. ON” at “WAYPOINT STATUS” from page 2/2.

) at the bottom of the

5-1

5. WAYPOINT

5.1.2 Entering waypoints by the cursor

1. If the cursor is off, press the [CURSOR ON/OFF] key to display the cursor.

2. Operate the trackball to position the cursor where desired.

3. Press the [WPT] key.

The SAVE WAYPOINT window appears.

Cursor

SAVE WAYPOINT

WAYPOINT NAME

PRESS NUMERIC KEY TO ENTER WAYPOINT NAME. PRESS KNOB TO SAVE WAYPOINT.

0 0 0 0 0 1

Save waypoint window

Note: The SAVE WAYPOINT WINDOW will be erased automatically if there is

no operation within 10 seconds.

4. If desired, press the num eric keys to change the waypoint number (max. six digits).

The waypoint is named automatically under the next consecutive waypoint number. If you do not need to change the waypoint name, go to step 5. To reset t he waypoint name to 000000, pr ess the [CLEAR] key. Each time a number key is pressed the cursor jum ps one place leftward.

5. Press the [ENTER] knob.

The message “WAYPOINT XXXXXX IS SAVED!” appears on the screen for three seconds. The waypoint icon ( (or pilot) display shows current waypoint shape and color.

default setting) at the bottom of the plott er

Note 1: If the waypoint icon does not appear at the bottom of the plotter (or pilot)

display, do the following. a) Press the [MENU], [0], [1] in that order to show the DISPLAY SETUP menu. b) Select “1. ON” at “WAYPOINT STATUS” on page 2/2.

Note 2: If the above operation is done when the cursor is off, the waypoint is

entered at own ship’s position.

Note 3: If the waypoint name entered at step 4 already exists, the message

“WAYPOINT XXXXXX ALREADY EXISTS. ENTER ANOTHER NAME.” appears. Enter another name for it after returning to the SAVE WAYPOINT window.

5-2

5. WAYPOINT

5.1.3 Entering waypoints by latitude and longitude position

1. Press the [MENU] key to show the main menu.

2. Press the [1] key to show the WAYPOINTS LIST.

Red cursor

1. WAYPOINTS LIST 1/1 NAME LATITUDE LONGITUDE PRXMTY COMMENT

------ --˚--.---'N ---˚--.---'E -.--nm -------------

Current page

No. of pages

SORT 1.ALPHA 2. DIST 3. MARK SPD TO CALC TTG 1.ACTUAL SPD SIM SPD 00.0kt SEARCH

ETA: --D--:-- TTG: ----H--M

TURN KNOB TO SELECT WAYPOINT. KNOB: EDIT WPT WPT: ADD WPT GOTO: SET WPT TO NAVIGATE ZOOM IN: PREVIOUS PAGE ZOOM OUT: NEXT PAGE CLEAR: DEL

ETA and TTG for the waypoint selected with the red cursor

Waypoints list

The number of pages in the WAYPOINTS LIST depends on the number of waypoints entered. The current and total number of pages are shown at the top of the list. When the total is more than t wo pages, press the [ZOOM OUT] key to go to the next page. To go to the previous page, press the [ZOOM IN] key.

5-3

5. WAYPOINT

3. Press the [W PT] key to show the waypoint edit window.

Character cursor

WAYPOINT NAME 000001 LATITUDE 3 4 43.483'N LONGITUDE 135 24.759'E

MARK COLOR 1. 2. 3. 4. 5. 6. 7. MARK SHAPE

MARK DISPLAY 1. ON 2. OFF COORDINATE 1. LAT/LON 2. RNG/BRG 3. TD PRXMTY RADIUS 0.00 nm COMMENT _ _ _ _ _ _ _ _ _ _ _ _ _

END A B C D E F G H I J K L M N O P Q R S T U V W X Y Z , - ! ? / & = # _ 1 2 3 4 5 6 7 8 9 0 _ _ _ _ _ a b c d e f g h i j k l m n o p q r s t u v w x y z _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

TURN KNOB TO SELECT MENU. SELECT THE ITEM OF EACH MENU BY TRACKBALL.

Waypoint edit list

4. Rotate the [ENTER] knob to select COORDINATE.

5. Press the [1] key to select “1. LAT/LON”.

6. Rotate the [ENTER] knob to select LATITUDE.

7. Use the numeric keys to enter the latit ude of the waypoint.

To switch from North to South and vice versa, press the [CURSOR ON/OFF] key.

8. Rotate the [ENTER] knob to select LONGITUDE.

9. Use the numeric keys to enter the longitude of the waypoint.

To switch fr om East to West and vice versa, press the [CURSOR ON/O FF] key. To change waypoint name, m ar k color, mark display, ma r k shape, proximity radius and comment, go to step 10. I f you do not need to change those items go to step 23.

5-4

5. WAYPOINT

10. Rotate the [ENTER] knob to select WAYPOINT NAME.

11. Operate the trackball to enter the waypoint name. (Max. six characters)

a) Operate the trackball to select the first character. You can enter numer ic

data with the numeric keys.

b) Press the [ENTER] knob.

Note: If you enter a wrong character, re-enter the correct character after

placing the character cursor on the wrong character. To move the character cursor, select ◄ or ► and then press the [ENTER] knob. To erase all characters, press the [CLEAR] key.

c) Repeat steps a) and b) t o complete the waypoint name.

12. Select “END” by operating the tr ackball, and then press the [ENTER] knob.

13. Rotate the [ENTER] knob to select MARK COLOR.

14. Press the appropriate numeric key to choose color.

Note: Waypoint mark color and shape cannot be selected when PRXMTY

RADIUS is other than 0.00.

15. Rotate the [ ENTER] knob to select MARK SHAPE.

16. Roll the trackball in left-right direction to select a shape.

17. Rotate the [ E NTER] knob to select MARK DISPLAY.

18. Press appropriate numeric key to select “1. ON” or “2. OFF.”

Press the [1] key to show waypoints on the plotter (or pilot) display; [2] key to hide waypoints. (For “2. OFF,” waypoint mark is gray in the WAYPOINT LIST.)

19. Rotate the [ E NTER] knob to select PRXMTY RADIUS.

20. Use the numeric keys to enter the proximity radius.

This is the alarm range that will be used f or this waypoint when the proximity alarm is active. W hen t he proximity radius is other than 0.00, the waypoint mark becomes

8.4.

automatically. For how to set the proximity alarm, see paragraph

21. Rotate the [ENTER] knob to select COMMENT.

22. Operate the trackball to enter the comment (max. 13 characters).

23. Select “END,” and then press the [ENTER] knob to finish.

24. Press the [ENT ER] knob again.

The waypoint edit window disappears, and the waypoint is registered in the WAYPOINTS LIST.

25. To enter another waypoint, repeat steps 3 through 24.

26. Press the [MENU] key several tim es to close the menu.

5-5

5. WAYPOINT

5.1.4 Entering waypoints by range and bearing

This method is useful when you want to enter a waypoint by using range and bearing to a target found on a radar.

1. Press the [MENU] key to show the main menu.

2. Press the [1] key to show the WAYPOINTS LIST.

3. Press the [W PT] key to show the waypoint edit window.

4. Rotate the [ENTER] knob to select COORDINATE.

5. Press the [2] key to select “2. RNG/BRG”.

6. Rotate the [ENTER] knob to select “RANGE.”

WAYPOINT NAME 000001 RANGE 001.3 nm BEARING 182.5

Waypoint edit window (Range/Bearing)

7. Use the numeric keys to enter the range from own ship to the waypoint.

8. Rotate the [ENTER] knob to select “BEARING.”

9. Use the numeric keys to enter the bearing from own ship to the waypoint.

10. Follow from step 10 in “5.1.3 Entering waypoints by longitude and latitude position.”

5-6

5.1.5 Entering waypoints by Loran A or Loran C LOPs

1. Press the [MENU] key to show the main menu.

2. Press the [8] key to show the PLOTTER SETUP menu.

3. Rotate the [ENTER] knob to select TD DI SPLAY.

8. PLOTTER SETUP

LORAN-A GRI 81-01 CORRECTION 1 +000.0µs CORRECTION 2 +000.0µs LORAN-C GRI 00:19-29 CORRECTION 1 +000.0µs CORRECTION 2 +000.0µs DECCA CHAIN 01 R-G CORRECTION 1 +00.00 LANE CORRECTION 2 +00.00 LANE TD DISPLAY 1. LORAN-A 2. LORAN-C 3. DECCA RESET TRP LOG 1. YES 2. NO PLOTTER RANGE SETUP 1. YES 2. NO PANEL DIMMER 1 2 3 4 5 6 7 8 HUE 1. DAY 2. NIGHT 3. TWILI 4. MANUAL

5. WAYPOINT

TURN KNOB TO SELECT MENU. SELECT THE ITEM OF EACH MENU BY TRACKBALL.

Plotter setup menu

4. Press the [1] or [2] key as appropriate to select “1. LORAN-A” or “2. LORAN-C.”

5. Press the [MENU] key to return to the main menu.

6. Press the [1] key to show the WAYPOINTS LIST.

7. Press the [WPT] key to show the waypoint edit window.

8. Rotate the [ENTER] knob to select “COO RDINATE.”

9. Press the [3] key to select “3. TD.”

10. Rotate the [ E NTER] knob to select TD1 LORAN-C (or A).

WAYPOINT NAME 0000001 TD1 LORAN-C 14512.3 TD2 LORAN-C 29348.1 GRI 9970 11-30

Waypoint edit window (Loran-C TD)

WAYPOINT NAME 000001 TD1 LORAN-A 1825.3 TD2 LORAN-A 3631.5 STATION 2S3-2S4

Waypoint edit window (Loran-A TD)

5-7

5. WAYPOINT

11. Use the numeric keys to enter the TD1 LORAN-C (or A).

12. Rotate the [ E NTER] knob to select TD2 LORAN-C (or A).

13. Use the numeric keys to enter the TD2 LORAN-C (or A).

14. Follow from step 10 in of “5.1.3 Entering waypoints by longitude and latitude position.”

5.1.6 Entering waypoints by Decca LOPs

1. Press the [MENU] key to show the main menu.

2. Press the [8] key to show the PLOTTER SETUP menu.

3. Rotate the [ENTER] knob to select “TD DI SPLAY.”

4. Press the [3] key to select “3. DECCA.”

5. Press the [MENU] key to return to the main menu.

6. Press the [1] key to show the WAYPOINTS LIST.

7. Press the [W PT] key to show the waypoint edit window.

8. Rotate the [ENTER] knob to select “COORDINATE”.

9. Press the [3] key to select “3. TD.”

WAYPOINT NAME 000001 LANE1 1A:06.68 LANE2 2A:41.90 CHAIN 01 S BALTIC R-G

Waypoint edit window (DECCA)

10. Rotate the [ E NTER] knob to select “LANE 1”.

11. Use the numeric keys to enter the LANE 1 value.

Enter the alphabet of the lane by pressing t he appr opriate numeric key referring to the table below.

Numeric key Alphabet Numeric key Alphabet

[1] key A [6] key F [2] key B [7] key G [3] key C [8] key H [4] key D [9] key I [5] key E [0] key J

To enter “1F22.01”, for example, press [1], [6] (F), [2], [2], [0], [1] in that order.

12. Rotate the [ENTER] knob to select LANE 2.

13. Use the numeric keys to enter the LANE 2 value.

14. Follow from step 10 in “5.1.3 Entering waypoints by longitude and latitude position.”

5-8

5.2 Editing Waypoint Data

You can edit waypoint data through the WAYPOINTS LIST.

1. Press the [MENU] key to show the main menu.

2. Press the [1] key to show the WAYPOINTS LIST.

3. Rotate the [ENTER] knob to select the waypoint you want to edit.

4. Press the [ENTER] knob.

5. Edit the waypoint data on the waypoint edit window as appropriate.

Note 1: The color and shape of a waypoint whose PRXMTY RADIUS is other

than 0.00 cannot be changed.

Note 2: After changing the color and shape of waypoint, these settings are used

for waypoint entered at own ship’s position.

6. Press the [ENTER] knob. The waypoint edit window disappears, and the waypoint data is changed.

7. Press the [MENU] key to close the menu.

5. WAYPOINT

5-9

5. WAYPOINT

5.3 Erasing Individual Waypoints

Individual waypoints can be erased by the cursor or through the WAYPOINTS LIST.

Erasing waypoints by the cursor

1. Press the [CURSOR ON/OFF] key to show the cursor.

2. Operate the trackball to place the cursor on the waypoint you want to erase.

A flashing diamond mark appears over the waypoint when it is correctly selected.

3. Press the [CLEAR] key.

You are asked if you are sure to erase the waypoint.

WAYPOINT NAME XXXXXX WIL BE DELETED. ARE YOU SURE? YES ... PRESS KNOB NO ... PRESS CLEAR KEY

Normal waypoint

THIS WAYPOINT XXXXXX USED FOR NAVIGATION. WILL IT BE DELETED? YES ... PRESS KNOB NO ... PRESS CLEAR KEY

Destination waypoint

Erasing message

4. Press the [ENTER] knob.

The waypoint is erased from both the plotter scr een and the WAYPOINTS LIST.

Erasing waypoints through the WAYPOINTS LIST

1. Press the [MENU] key to show the main menu.

2. Press the [1] key to show the WAYPOINTS LIST.

3. Rotate the [ENTER] knob to select t he waypoint you want to erase.

You can sort waypoints in alphabetical or distance order, or by mark shape. (See paragraph 5.4.)

4. Press the [CLEAR] key.

5. Press the [ENTER] knob.

The waypoint is erased from both the WAYPOINTS LIST and the plotter screen.

6. Press t he [MENU] key several times to close the menu.

5-10

5.4 Searching Waypoints

You can search for a waypoint through the WAYPOINTS LIST.

Searching by sorting

1. Press the [MENU] key to show the main menu.

2. Pres the [1] key to show the WAYPOINTS LIST.

3. Rotate the [ENTER] knob to select “SORT”.

4. Press the appropriate key among 1, 2 and 3 to select the sort ing method.

1. ALPHA: Sorting waypoints and MOB in alphanumeric order.

2. DIST: Sorting waypoints in order of decreasing distance to own ship.

3. MARK: Sorting waypoints in order of MOB mark, PROXIMITY RADIUS mark and other mark shapes.

5. Press the [MENU] key several times to close the menu.

Searching by waypoint name

5. WAYPOINT

1. Press the [MENU] key to show the main menu.

2. Press the [1] key to show the WAYPOINTS LIST.

3. Rotate the [ENTER] knob to select SORT.

4. Press the [1] key to select “1. ALPHA.”

5. Rotate the [ENTER] knob to select SEARCH to show the character window.

6. Operate the trackball to enter the first 1 to 3 characters.

7. Operate the trackball to select “END”, and then press the [ENTER] knob.

Matching waypoint name appears at the top of the list.

8. Press the [MENU] key several times to close the menu.

5-11

5. WAYPOINT

5.5 Setting Ship’s Speed for TTG

Calculation of TTG is based on ship’s speed data. This data can be set manually or automatically.

1. Press the [MENU] key to show the main menu.

2. Press the [1] key to show the WAYPOINTS LIST.

3. Rotate the [ENTER] knob to select “SPD TO CALC TTG”.

4. Roll the trackball in left-right direction to select “ACTUAL SPD” or “SIM SPD.” For ACTUAL SPD, go step 6. For SIM SPEED, go to step 5.

ACTUAL SPD: Calculating with the actual ship’s speed. SIM SPD: Calculating with a simulated value.

5. Press the numeric keys to enter a ship’s speed value.

TTG for the waypoint selected with the red cursor is calculat ed by using t he speed value entered.

6. Press the [MENU] key several times to close the menu.

5-12

5.6 Displaying Waypoint Data

You can show waypoint data on the plotter screen as follows:

1. Press the [CURSOR ON/OFF] key to show the cursor.

2. Operate the trackball to place the cursor on the waypoint for which you want to know its data.

The data (L/L and comment) window for the selected waypoint appears next to the waypoint mark.

5. WAYPOINT

Cursor

37˚04.640'N 135˚21.047'E 01:51 0301.01

000001

Waypoint

Latitude

Longitude

Comment

Waypoint data window

Note: If the data window does not appear, do the following.

a) Press the [MENU], [0], [1] key in that order. b) Rotate the [ENTER] knob to select WAYPOINT INFO on page 2/2 of

DISPLAY SETUP menu.

c) Press the [ 1] key to select “1. ON, ” and then press the [ MENU] k ey several

times to close the menu.

5-13

5. WAYPOINT

5.7 Changing Waypoint Mark Size

You m ay change the size of all waypoint marks to small or large, or turn them off.

1. Press the [MENU] key to show the main menu.

2. Press the [7] key to show the CHART SETUP menu.

If the CHART SETUP menu does not appear, rotate the [ENTER] knob clockwise.

3. Rotate the [ENTER] knob to select “WAYPOINTS.”

7. CHART SETUP GOTO CONTOUR LINES SETUP

OFFSET CHART POS 1. YES 2. NO LAT/LON GRID 0. OFF TEXT INFORMATION 1. YES 2. NO WAYPOINTS 1. LARGE 2. SMALL 3. SMALL WAYPOINT NAME 1. YES 2. NO CHART BORDER LINE 1. YES 2. NO LANDMASS 0. OFF

TRIMMING BORDER LINE 0. OFF

BACKGROUND 0. OFF

TURN KNOB TO SELECT MENU. SELECT THE ITEM OF EACH MENU BY TRACKBALL.

Chart setup menu

4. Press the appropriate numeric key to select “1. LARGE”, “2. SMALL” or “3. OFF.”

LARGE: Waypoints are shown in actual mar k shape. SMALL: Waypoints are displayed with an “x” regardless of mark shape

selected.

OFF: All waypoints are off except the waypoint destination and route.

5. Press the [MENU] key several times to close the menu.

5-14

6. ROUTE

Often a trip fr om one place to another involves several course changes, requiring a series of route points (waypoints) which you navigate to, one after another. The sequence of waypoints leading to the ultimate destination is called a route.

6.1 Entering Routes

You can store up to 200 routes and a rout e may consist of 35 points. There are two methods to enter a route:

Using existing waypoints

•

Track based route using own ship positions recorded at preset intervals

•

6.1.1 Entering routes using existing waypoints

1. Press the [MENU] key to show the main menu.

2. Press the [2] key to show the ROUTES LIST.

6-1

6. ROUTE

Red cursor

2. ROUTES LIST DIR: FOLLOW 1/1 ROUTE NAME COMMENT GO TO (FOLLOW)

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

BACK TRACK 1. YES 2. NO RECORD TYPE DISTANCE 00.1nm TIME 00H01M SPD TO CALC TTG ACTUAL SPD SIM SPD 00.0kt

Current page

No. of pages

TOTAL DIST 0.00nm ETA: 1D 0: 1 TTG: 0H 1M

PRESS KNOB: EDIT ROUTE WPT: ADD ROUTE GOTO: SET RTE TO NAVI CLEAR: DEL COURSE: SWITCH FLLW/RVRS

Total distance, ETA and TTG for the route selected with the red cursor

Routes list

The current page no. and total num ber of pages are shown at the top of t he list . When the list has m or e than two pages, press the [ZOOM OUT] key to go to the next page, [ZOOM IN] key to return to the previous page.

3. Press the [W PT] key to show the route name entry window.

4. Operate the trackball to enter the route name. (Max. 6 characters)

5. Operate the trackball to select “END”, and then press the [ENTER] knob.

6. Operate the trackball to enter a comment. (Max. 13 characters)

7. Operate the trackball to select “END, ” and then press the [ENTER] knob.

The waypoints window appears.

6-2

6. ROUTE

Route name

000002 ROUTE LIST PAGE 1/2

NO. WPT NAME LATITUDE LONGITUDE DISTANCE TTG 1 ------ --˚--.---'N ---˚--.---'E ---.--nm -----.-H 2 ------ --˚--.---'N ---˚--.---'E ---.--nm -----.-H 3 ------ --˚--.---'N ---˚--.---'E ---.--nm -----.-H 4 ------ --˚--.---'N ---˚--.---'E ---.--nm -----.-H 5 ------ --˚--.---'N ---˚--.---'E ---.--nm -----.-H 6 ------ --˚--.---'N ---˚--.---'E ---.--nm -----.-H 7 ------ --˚--.---'N ---˚--.---'E ---.--nm -----.-H 8 ------ --˚--.---'N ---˚--.---'E ---.--nm -----.-H 9 ------ --˚--.---'N ---˚--.---'E ---.--nm -----.-H 10 ------ --˚--.---'N ---˚--.---'E ---.--nm -----.-H 11 ------ --˚--.---'N ---˚--.---'E ---.--nm -----.-H 12 ------ --˚--.---'N ---˚--.---'E ---.--nm -----.-H 13 ------ --˚--.---'N ---˚--.---'E ---.--nm -----.-H 14 ------ --˚--.---'N ---˚--.---'E ---.--nm -----.-H 15 ------ --˚--.---'N ---˚--.---'E ---.--nm -----.-H 16 ------ --˚--.---'N ---˚--.---'E ---.--nm -----.-H 17 ------ --˚--.---'N ---˚--.---'E ---.--nm -----.-H 18 ------ --˚--.---'N ---˚--.---'E ---.--nm -----.RNG=---.--nm BRG=---.-˚

WPT NAME LATITUDE LONGITUDE COMMENT 000001 34˚44.041'N 135˚21.255'E 00:29 0301.01 000002 34˚44.237'N 135˚20.936'E POINT A 000003 33˚43.878'N 134˚20.049'E 00:20 0301.02 000004 32˚33.678'N 133˚21.029'E 03:29 0301.02 000005 33˚40.591'N 134˚20.628'E POINT B

Waypoints in the route

Distance and bearing between the waypoint selected with the red cursor and preceding waypoint. When the first waypoint is selected, distance and bearing between own ship's position and it are shown.

Waypoints window

PRESS KNOB: ADD WPT CLEAR KEY: DELETE WPT CURSOR ON/OFF KEY: SKIP MENU KEY: RETURN ZOOM IN: PREVIOUS PAGE ZOOM OUT: NEXT PAGE

Waypoints window

8. Roll the trackball in up-down direction to select the starting waypoint.

When more t han five waypoints are entered, press the [ZOOM IN] or [ZOOM OUT] key to change the page.

9. Press the [ENTER] knob. The selected waypoint is entered in the route as starting point.

10. Repeat steps 8 and 9 t o complete the route.

11. Press the [WPT] or [MENU] key.

The ROUTE LIST shows total distance, ETA and TTG of the route.

12. Press the [MENU] key several tim es to close the menu.

6-3

6. ROUTE

6.1.2 Creating track-based routes

You can create routes based on your ship’s track by entering waypoints at own ship’s position up to 35 points, manually or automat ically. For automatic entry, you will need to set interval of time or distance. This feature is useful when you wish to retrace a track. The SAVE icon ( when creating a track based route.

1. Press the [MENU] key to show the main menu.

2. Press the [2] key to show the ROUTES LIST.

3. Rotate the [ENTER] knob to select RECORD T YPE.

4. Roll the trackball in left-right direction to select “DISTANCE” or “TIME.”

5. Press the numeric keys to enter value for distance (or time). Note: If you enter a wrong value, press the [CLEAR] key, and then re-enter

the correct value.

6. Press the [ENTER] knob.

7. Rotate the [ENTER] knob to select BACK TRACK.

8. Press the [1] key to select “1. YES.”

The route creation starts, and it is named automatically.

9. Press the [MENU] key several times to close the menu.

10. To create a track-based route manually, follow the steps shown below.

a) Press the [SAVE/MOB] momentarily to enter a waypoint at own ship’s position. b) Repeat step a) whenever you change course.

Stopping the creating track-based routes

S A V E

) appears at the bottom of the screen

To manually stop creat ing a track-based route, follow the procedure below. When 35 waypoints have been entered, creation is stopped automatically.

1. Press the [MENU] key to show the main menu.

2. Press the [2] key to show the ROUTES LIST.

3. Rotate the [ENTER] knob to select BACK TRACK.

4. Press the [2] key to select “2. NO.”

5. Press the [MENU] key several times to close the menu.

6-4

6.2 Editing Routes

6.2.1 Inserting waypoints

Waypoints can be inserted in routes as follows:

1. Press the [MENU] key to show the main menu.

2. Press the [2] key to show the ROUTES LIST.

3. Rotate the [ENTER] knob to select the route in which you want to insert a waypoint.

4. Press the [ENTER] knob three tim es to show the waypoints window.

5. Rotate the [ENTER] knob to place the red cursor at the waypoint which will follow the waypoint you wish to insert.

6. Roll the trackball in up-down direction to select the waypoint you want to insert.

7. Press the [ENTER] knob.

6. ROUTE

Note: If a wrong waypoint is inserted, press the [CLEAR] key to delete.

8. Press the [MENU] key several times to close the menu.

6.2.2 Removing waypoints from routes

1. Press the [MENU] key to show the main menu.

2. Press the [2] key to show the ROUTES LIST.

3. Rotate the [ENTER] knob to select t he route in which you want to remove a waypoint.

4. Press the [ENTER] knob three tim es to show the waypoints window.

5. Rotate the [ENTER] knob to select t he waypoint you want to remove.

6. Press the [CLEAR] key to remove the waypoint.

7. Press the [MENU] key several times to close the menu.

6-5

6. ROUTE

6.3 Erasing Routes

1. Press t he [MENU] key to show the main menu.

2. Press the [2] key to show the ROUTES LIST.

3. Rotate the [ENTER] knob to select t he route you want to erase.

4. Press the [CLEAR] key to show the following message.

ROUTE NAME XXXXXX

WILL BE DELETED. ARE YOU SURE? YES ... PRESS KNOB NO ... PRESS CLEAR KEY

Normal route

ROUTE NAME XXXXXX

IS USED FOR NAVIGATION WILL IT BE DELETED? YES ... PRESS KNOB NO ... PRESS CLEAR KEY

Erasing message

5. Press the [ENTER] knob.

6. Press the [MENU] key several times to close the menu.

6.4 Setting Ship’s Speed for TTG

Calculation of TTG is based on ship’s speed data. This data can be set manually or automatically.

1. Press the [MENU] key to show the main menu.

2. Press the [2] key to show the ROUTES LIST.

3. Rotate the [ENTER] knob to select SPD TO CALC TTG.

4. Roll the trackball in left-right direction to select “ACTUAL SPD” or SIM SPD.” For ACTUAL SPD, go step 6. For SIM SPEED, go to step 5.

ACTUAL SPD: The actual ship’s speed is used. SIM SPD: The simulated speed is used.

5. Press the numeric keys to enter the speed value, and then pres the [ E NTER] knob.

6. Press t he [MENU] key several times to close the menu.

Destination route

6-6

7. NAVIGATION

This section shows you how to get to a desired destination by using “quick points,” waypoints, port services and routes.

7.1 Navigating to Quick Points

The quick point feature allows you to navigate to point(s) without retaining the date indefinitely in your unit’s memory. Each time a quick point is entered, previous quick points having the same numbers as newly entered ones are written over.

Selecting quick point entry method

You need to tell your unit how to set the quick point: 1 POINT or 35 POINTS (up to 35 points), NEAR SERVICE or PORT SERVICE. (For NEAR SERVICE and PORT SERVICE, see page 7-5.)

1. Press the [MENU] key to show the main menu.

2. Press the [0] key to show the SYSTEM SETUP menu.

3. Press the [1] key to show the DISPLAY SETUP menu.

4. If page 2/2 appears, rotate the [ENTER] knob to select PREVIOUS PAGE to show page 1/2.

7-1

7. NAVIGATION

5. Rotate the [ENTER] knob to select SET G O TO METHOD.

0-1 DISPLAY SETUP 1/2 NEXT PAGE

LANGUAGE 1. ENGLISH KEY BEEP 1. ON 2. OFF SPEED SOURCE 1. INT GPS 2. NMEA SOG 3. NMEA STW

4. INTERNAL E/S NMEA SPEED CALIB +00% (-50 ∼ +50%) TEMPERA TURE SOURCE1. NMEA 2. INTERNAL E/S NMEA TEMP CALIB +00.0°F (-40 ∼ +40°F) DEPTH SOURTH 1. NMEA 2. INTERNAL E/S NMEA DEPTH CALIB +000.0 ft (-15 ∼ +100ft) LAT/LON DISPLAY 1.DD˚MM.MM' 2.DD˚MM.MMM'

3.DD˚MM.MMMM' 4.DD˚MM'SS.S RANGE & SPEED UNITS1.nm,kt 2.km,km/h 3.sm,mph DEPTH UNIT 1.m 2.ft 3.fa 4.pb TEMPERATURE UNIT 1.˚C 2.˚F TIME DISPLAY 1. 12 HOURS 2. 24 HOURS BEARING READOUT 1. TRUE 2. MAGNETIC MAGNETIC VARIATION 1. AUTO 2. MANUAL 07.0°W HEADING MARKER 1. ON 2. OFF COURSE VECTOR 1. LINE 2. VECT OR 3. OFF WAYPOINT SWITCHING 1. PERPENDICULAR2. ARRIVAL CIRCLE RNG & BRG MODE 1. RHUMB LINE 2. GREAT CIRCLE SET GOTO METHOD 1. 1 POINT 2. 35 POINTS

3. NEAR SERVICE 4. PORT SERVICE RANGE/SCALE 1. RANGE 2. SCALE SCALE DISPLAY 1. ON 2. OFF GPS STATUS 1. ON 2. OFF

TURN KNOB TO SELECT MENU. SELECT THE ITEM OF EACH MENU BY TRACKBALL.

Display setup menu

6. Press the appropriate numeric key to select the method to use:

1 POINT: Setting a single quick point as waypoint. 35 POINTS: Setting multiple quick points (up to 35) as a route. NEAR SERVICE, PORT SERVICE: See page 7-5.

7. Press the [MENU] key several times to close the menu.

7-2

7. NAVIGATION

Navigating to a single quick waypoint

1. Referring to page 7-1 for the procedure, set G O TO METHOD to “1. 1POINT”.

2. Press the [DISP] key, and then select the PLOTTER NAV INFO 1 or PILOT NAV INFO 1 display.

3. Press the [DISP] key to close the DISP MODE display.

If the cursor is not displayed, press t he [CURSOR ON/OFF] key to display it.

4. Operate the trackball to place the cursor on the location where you want to enter the quick point.

5. Press the [GOTO] key.

A light-blue line connects between own ship and destination, marked “Q P<01>,” and it shows the shortest course to the destination.

Arrows on the line show the direction to follow to get t o t he quick point. Range and bearing from own ship to the destination appear at t he top of screen. This location is saved to the WAYPOINT LIST as waypoint “QP01.”

Note 1: Each time a quick point is entered previous quick points having the

same numbers as newly entered ones are written over.

Note 2: If range and bearing from own ship to the destination do not appear on

the screen, refer to paragraph 9.6.2.

Note 3: When waypoint data (L/L) is received from an external navigator, the

quick waypoint is erased and the waypoint data becomes the new destination.

7-3

7. NAVIGATION

Navigating a quick route

1. Referring to page 7-1 for the procedure, set SET GO TO METHOD to “2. 35

2. Press t he [DISP] key, and then select the PLOTTER NAV INFO 1 or PILOT

3. Press t he [DISP] key. If the cursor is not displayed, press the [CURSOR

4. Press the [GOTO] key to show the following window.

5. Operate the trackball to place the cursor on an existing waypoint or a new

6. Press the [ENTER] knob.

7. Repeat steps 5 and 6 to complete the route.

8. After entering all waypoints, press the [ENTER] knob twice.

Note 1: Each time a quick route is entered, previous quick route is written over.

Note 2: If range and bearing from own ship to the first destination do not appear

POINT.”

NAV INFO 1 display.

ON/OFF] key to display it.

Waypoint name appears here.

PRESS KNOB TO SET QUICK POINT IN QUICK ROUTE. PRESS KNOB TWICE TO START NAVIGATION. PRESS CLEAR KEY TO DELETE THE PREVIOUS QUICK POINT.

Operation guidance

location.

When selecting a new location, “ Q P<01>” appear s at the cursor position.

Maximum 35 points can be entered. To erase last - entered waypoint, press the [CLEAR] key.

A light-blue line connects between own ship and the first q uick point of the route, and green lines connect between other quick points. The line shows the shortest course to destination. Arrows on the line show the direction to follow the route. Range and bearing from own ship to the first destination appear at the top of screen. The unit saves the points as a route, under the nam e “ Q <RTE (Quick Route).”

When entering a new quick waypoint, QP<01> is removed from the Q<RTE.

on the screen, refer to paragraph 9.6.2.

7-4

7. NAVIGATION

Navigating to ports, port service

Some Nav-Chart™ chart cards have a port service list which shows services available at ports or harbors. You can use the list to set destination as follows.

1. Referring to page 7-1 for the procedure, set SET TO GO TO METHOD to “3. NEAR SERVICE” or “4. PORT SERVICE.”

NEAR SERVICE displays the port service list. PORT shows a list of ports in your area.

2. Press t he [DISP] key, and then select PLOTTER NAV INFO 1 or PILOT NAV

INFO 1 display.

3. Press t he [DISP] key. If the cursor disappears, press the [CURSOR ON/OFF]

key.

4. Press the [GOTO] key.

A list of ports or port ser vices appear depending on what you selected at st ep 1.

PORT SERVICE

¡

▼

¡     ¡

¡ 

PORT SERVICE

▲

ACCIAROLI

ACQUAMORTA AGNONE S. NICOLA AGROPOLI AMALFI BAIA CAPRI CASA MICCIOLA-ISCHIA

Port service list

(NavChart , Italy)

▼

Near service list (NavChart )

Port service lists

5. Do one of the following depending on selection made at step 1.

PORT SERVICE

Rotate the [ENTER] knob to select port and t hen press the [ENTER] knob. Make a route using the trackball and [ENTER] key. (If you want to go directly to that port, simply press the [ENTER] knob twice.

7-5

7. NAVIGATION

NEAR SERVICE

Select service mark desired with the [ENTER] knob, and then press the [ENTER] knob. Then, the display shows the locations of those services nearest you. (The figure below shows the location of a filling station in an area in southern Italy.) Use the cursor pad to place the “hand cursor” on the port service icon desired and press the [ENTER] knob. Make a route using the trackball and [ENTER] knob. (If you want to go directly to location desired, simply press the [ENT ER] knob twice.)

PUNTA CORNACCHIA

ACCO AMENO

CASAMICCIOLA

ISCHIA PORTO

I. ISCHIA

Sample fitting station locations (southern Italy)

7-6
