Funai SRC2213E User Manual
OWNER’S
As an ENERGY STAR
Partner, our company has
determined that this product meets
the E
NERGY STAR guidelines for
energy efficiency. E
NERGY STAR
is a U.S. registered mark.
®
®
®
MANUAL
13 INCH COLOR TV/VCR
SRC2213E
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.
If you need additional assistance for set-up or operating
after reading owner’s manual, please call
TOLL FREE : 1-800-968-3429
Please read before using this equipment
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
The caution marking is located on the rear of the cabinet.
IMPORTANT SAFEGUARDS
1.Read instructions-All the safety and operating instructions
should be read before the appliance is operated.
2.Retain Instructions-The safety and operating instructions
should be retained for future reference.
3.Heed Warnings-All warnings on the appliance and in the
operating instructions should be adhered to.
4.Follow Instructions-All operating and use instructions
should be followed.
5.Cleaning-Unplug TV/VCR from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners. Use
a damp cloth for cleaning.
EXCEPTION: A product that is meant for uninterrupted
service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to
unplugging the appliance in the cleaning description otherwise required in item 5.
6.Attachments-Do not use attachments not recommended by
the TV/VCR manufacturer as they may cause hazards.
7.Water and Moisture-Do not use this TV/VCR near water-
for example, near a bath tub, wash bowl, kitchen sink, or
laundry tub, in a wet basement, or near a swimming pool,
and the like.
8.Accessories-Do not place this TV/VCR on an unstable cart,
stand, tripod, bracket, or table. The TV/VCR may fall, causing serious injury to someone, and serious damage to the
appliance. Use only with a cart, stand, tripod, bracket, or
table recommended by the manufacturer, or sold with the
TV/VCR. Any mounting of the
appliance should follow the manufacturer’s instructions and should
use a mounting accessory recommended by the manufacturer. An
appliance and cart combination
should be moved with care.
Quick stops, excessive force, and
uneven surfaces may cause the
appliance and cart combination to
overturn.
PORTABLE CART WARNING
S3126A
THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A
RISK OF ELECTRIC SHOCK IS PRESENT
WITHIN THIS UNIT.
THIS SYMBOL INDICATES THAT THERE
ARE IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS IN THE
LITERATURE ACCOMPANYING THE
APPLIANCE.
AMEUBLES- Cet appareil ne doit être
placé que sur un meuble (avec ou sans
roulettes) recommandé par le fabricant.
Si vous l’installez sur un meuble à
roulettes, déplacez les deux ensembles
avec précaution. Un arrêt brusque, l’utilisation d’une force excessive et des surfaces irrégulières
risquent de déstabiliser l’ensemble et de le renverser.
9.Ventilation-Slots and openings in the cabinet and the back
or bottom are provided for ventilation and to ensure reliable
operation of the TV/VCR and to protect it from overheating, and these openings must not be blocked or covered.
The openings should never be blocked by placing the
TV/VCR on a bed, sofa, rug, or other similar surface. This
TV/VCR should never be placed near or over a radiator or
heat register. This TV/VCR should not be placed in a builtin installation such as a bookcase or rack unless proper
ventilation is provided or the manufacturer’s instructions
have been adhered to.
10.Power Sources-This TV/VCR should be operated only
from the type of power source indicated on the marking
label. If you are not sure of the type of power supply to
your home, consult your appliance dealer or local power
company. For TV/VCRs intended to operate from battery
power, or other sources, refer to the operating instructions.
11.Grounding or Polarization-This TV/VCR is equipped
with a polarized alternating-current line plug(a plug having
one blade wider than the other). This plug will fit into the
power outlet only one way. This is a safety feature. If you
are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not defeat the
safety purpose of the polarized plug.
12.Power-Cord Protection-Power-supply cords should be
routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles,
and the point where they exit from the appliance.
SYMBOLE D'AVERTISSEMENT POUR
LES COMPOSANTES
APPAREIL ET MEUBLE A ROULETTES
S3126A
- 2 - EN
9I03
EXAMPLE OF ANTENNA GROUNDING AS P ER
NATIONAL ELECT RICAL CODE
S2898A
FIGURE A
ELECTRIC
SERVICE
EQUIPMENT
NEC - NATIONAL ELECTRICAL CODE
GROUND
CLAMP
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNI T
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDI NG
ELECTRODE SYSTEM
(NEC ART 250, PART H)
13.Outdoor Antenna grounding-If an outside antenna or
cable system is connected to the TV/VCR, be sure the
antenna or cable system is grounded so as to provide some
protection against voltage surges and built-up static
charges. Article 810 of the National Electrical Code,
ANSI/NFPA No. 70, provides information with respect to
proper grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna discharge unit,
size of grounding conductors, location of antenna-discharge
unit, connection to grounding electrodes, and requirements
for the grounding electrode. (Fig. A)
14.Lightning-For added protection for this TV/VCR receiver
during a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall
outlet and disconnect the antenna or cable system. This will
prevent damage to the TV/VCR due to lightning and
power-line surges.
15.Power Lines-An outside antenna system should not be
located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into
such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them
might be fatal.
16.Overloading-Do not overload wall outlets and extension
cords as this can result in a risk of fire or electric shock.
17.Object and Liquid Entry-Never push objects of any kind
into this TV/VCR through openings as they may touch dangerous voltage points or short out parts that could result in
a fire or electric shock. Never spill liquid of any kind on
the TV/VCR.
18.Servicing-Do not attempt to service this TV/VCR yourself
as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
19.Damage Requiring Service-Unplug this TV/VCR from
the wall outlet and refer servicing to qualified service per-
sonnel under the following conditions:
a. When the power-supply cord or plug is damaged or frayed.
b. If liquid has been spilled, or objects have fallen into the
TV/VCR.
c. If the TV/VCR has been exposed to rain or water.
d. If the TV/VCR does not operate normally by following the
operating instructions. Adjust only those controls that are
covered by the operating instructions, as improper adjust-
ment of other controls may result in damage and will often
require extensive work by a qualified technician to restore
the TV/VCR to its normal operation.
e. If the TV/VCR has been dropped or damaged in any way.
f. When the TV/VCR exhibits a distinct change in perfor-
mance-this indicates a need for service.
20.Replacement Parts-When replacement parts are required,
be sure the service technician has used replacement parts
specified by the manufacturer that have the same character-
istics as the original part. Unauthorized substitutions may
result in fire, electric shock, injury to persons or other haz-
ards.
21.Safety Check-Upon completion of any service or repairs to
this TV/VCR, ask the service technician to perform routine
safety checks to determine that the TV/VCR is in proper
operating condition.
22.Heat-This TV/VCR product should be situated away from
heat sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce heat.
CAUTION:TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE
LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.
- 3 - EN
9I03
PRECAUTIONSPRECAUTIONS
LOCATION
For safe operation and satisfactory performance of
your TV/VCR, keep the following in mind when
selecting a place for its installation:
Shield it from direct sunlight and keep it away
•
from sources of intense heat.
Avoid dusty or humid places.
•
Avoid places with insufficient ventilation for proper
•
heat dissipation. Do not block the ventilation holes
at the top and bottom of the unit. Do not place the
unit on a carpet because this will block the ventilation holes.
Install unit in a horizontal position.
•
Avoid locations subject to strong vibration.
•
Do not place the TV/VCR near strong magnetic fields.
•
Avoid moving TV/VCR to locations where temper-
•
ature differences are extreme.
AVOID THE HAZARDS OF
ELECTRICAL SHOCK AND FIRE
Do not handle the power cord with wet hands.
•
Do not pull on the power cord when disconnecting
•
it from an AC wall outlet. Grasp it by the plug.
If, by accident, water is spilled on your unit, unplug
•
the power cord immediately and take the unit to an
Authorized Service Center for servicing.
Do not put your fingers or objects into the
•
TV/VCR cassette holder.
Do not place anything directly on top of the unit.
•
WARNING
Moisture condensation may occur inside the unit
when it is moved from a cold place to a warm place,
or after heating a cold room or under conditions of
high humidity. If a tape is played in a TV/VCR
which has moisture, it may damage the tape and
TV/VCR. Therefore if condensation occurs inside the
unit, turn the POWER button on and allow at least 2
hours for the unit to dry out.
IMPORTANT COPYRIGHT INFORMATION
Unauthorized recording or use of broadcast television programming, video tape, film or other copyrighted material may violate applicable copyright
laws. We assume no responsibility for the unauthorized duplication, use, or other acts which infringe
upon the rights of copyright owners.
FCC WARNING- This equipment may generate or use radio frequency energy. Changes or
modifications to this equipment may cause
harmful interference unless the modifications
are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change
or modification is made.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
1) Reorient or relocate the receiving antenna.
2) Increase the separation between the equipment
and receiver.
3) Connect the equipment to an outlet on a circuit
different from that to which the receiver is connected.
4) Consult the dealer or an experienced radio/TV
technician for help.
The serial number of this product may be found on the back of the unit. No other TV/VCR has the same serial
number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.
Date of Purchase
Dealer name
Dealer Address
Dealer Phone No.
Model No.
Serial No.
- 4 - EN
9I03
TABLE OF CONTENTS
C IMPORTANT SAFEGUARDS . . . . . . . . . . . . .2
C PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . .4
C TABLE OF CONTENTS . . . . . . . . . . . . . . . . . .5
C FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
C SUPPLIED ACCESSORIES . . . . . . . . . . . . . . .6
C OPERATING CONTROLS AND FUNCTIONS 7
C PREPARATION FOR USE . . . . . . . . . . . . . . . .9
ANTENNA/CABLE CONNECTIONS . . . . . . .9
FRONT A/V INPUT . . . . . . . . . . . . . . . . . . . .10
INSTALLING THE BATTERIES . . . . . . . . . . .10
C SET UP FOR USE . . . . . . . . . . . . . . . . . . . . .10
SELECTING THE LANGUAGE . . . . . . . . . . .10
CLOCK SET UP (AUTO / MANUAL) . . . . . .10
DAYLIGHT-SAVING TIME . . . . . . . . . . . . . .12
CHANNEL SET UP . . . . . . . . . . . . . . . . . . . .13
DELETING (OR ADDING) CHANNEL . . . . .13
C TV OPERATION . . . . . . . . . . . . . . . . . . . . . . .14
WATCHING ATV PROGRAM . . . . . . . . . . . .14
GAME MODE . . . . . . . . . . . . . . . . . . . . . . . . .14
DEGAUSSING . . . . . . . . . . . . . . . . . . . . . . . .14
PICTURE CONTROL . . . . . . . . . . . . . . . . . . .14
CLOSED CAPTION SYSTEM . . . . . . . . . . . .15
V-CHIP SET UP . . . . . . . . . . . . . . . . . . . . . . . .15
C PLAYBACK . . . . . . . . . . . . . . . . . . . . . . . . . . .17
NORMAL PLAYBACK . . . . . . . . . . . . . . . . . .18
AUTO REPEAT PLAYBACK . . . . . . . . . . . . .18
SEARCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
RENTAL PLAYBACK . . . . . . . . . . . . . . . . . . .19
NOISE CANCEL (in the Still mode) . . . . . . . .19
VERTICALHOLD CONTROL . . . . . . . . . . . .20
STILL PICTURE . . . . . . . . . . . . . . . . . . . . . . .20
TRACKING ADJUSTMENT . . . . . . . . . . . . . .20
C RECORDING . . . . . . . . . . . . . . . . . . . . . . . . .20
NORMAL RECORDING . . . . . . . . . . . . . . . . .20
OTR (One Touch Recording) . . . . . . . . . . . . . .21
TIMER RECORDING . . . . . . . . . . . . . . . . . . .21
TIMER PROGRAM EXTENSION . . . . . . . . .22
HINTS FOR AUTOMATIC TIMER
RECORDING . . . . . . . . . . . . . . . . . . . . . . . . .23
AUTO RETURN . . . . . . . . . . . . . . . . . . . . . . .23
WAKE UP TIMER . . . . . . . . . . . . . . . . . . . . . .23
SLEEP TIMER . . . . . . . . . . . . . . . . . . . . . . . . .24
C COPYING A VIDEO TAPE . . . . . . . . . . . . . . .24
C ON SCREEN DISPLAY . . . . . . . . . . . . . . . . .25
C SPECIAL FEATURES . . . . . . . . . . . . . . . . . .25
REAL TIME TAPE COUNTER . . . . . . . . . . . .25
AUTO REWIND-EJECT . . . . . . . . . . . . . . . . .25
C MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . .25
C TROUBLESHOOTING GUIDE . . . . . . . . . . .26
C SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . .27
C CABLE CHANNEL DESIGNATIONS . . . . . .27
C WARRANTY . . . . . . . . . . . . . . . . . . .Back Cover
INDICE
CONTROLES DE OPERACIÓN Y
SUS FUNCIONES . . . . . . . . . . . . . . . . . . . . . . . .28
CONEXIONES DE ANTENA/CABLE . . . . . . . .30
MODO DE ENTRADA EXTERNA . . . . . . . . . . .30
A NOTE ABOUT RECYCLING
Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.
SELECCION DE IDIOMA . . . . . . . . . . . . . . . . .30
AJUSTE DE CANAL . . . . . . . . . . . . . . . . . . . . . .31
AJUSTE DEL RELOJ . . . . . . . . . . . . . . . . . . . . .31
- 5 - EN
9I03
FEATURES
Infrared remote control
•
Trilingual on screen menu display selectable in
•
English, Spanish, or French
Real time counter–This shows the elapsed record-
•
ing or playback time in hours, minutes, and seconds. The “–” indication will appear when the tape
is rewound further than the tape counter position
“0:00:00”.
181 channel capability PLL frequency synthesiz-
•
er tuner with direct station call–
be necessary to view scrambled cable channels.)
Auto Clock Setting–Allows you to set the clock
•
from a PBS broadcast station.
Closed caption system–You may view specially
•
labeled (cc) TV programs, movies, news, prerecorded tapes, etc. with either a dialogue caption or
text display added to the program.
Game mode–Automatically selects front A/V input
•
mode and allows the TV/VCR display to be suitable for use with TV games.
Auto power on and off system–Automatically
•
turns on the TV/VCR when you insert the cassette,
turns off after auto-rewind, and ejects when the
beginning of the tape is reached.
Auto rewind when the end of a tape is
•
reached–
timer recording.
2 Step picture search operation–You can view a
•
video program at a high speed or super high speed
in either a forward or reverse direction in LP and
SLP mode. For SP mode only high speed.
Three different playback tape speeds : SP/LP/SLP
•
Two different recording tape speeds : SP/SLP
•
Auto Head Cleaner–Automatically cleans video
•
heads as you insert or remove a cassette.
This function doesn’t occur when using
(A converter may
Zero Return–The tape returns to counter of
•
0:00:00 by rewinding or fast forwarding.
Still–“Freeze” the picture at any time, for close
•
viewing of a particular scene. Only tapes recorded
in SLP mode will show a fairly clear picture.
Digital Auto Tracking (DTR)–Automatically
•
adjusts the tracking for each tape you play.
Rental play mode–Improves playback picture
•
quality from worn tapes, such as rental tapes.
Auto repeat–Allows you to repeat the playing of a
•
tape indefinitely without pressing the PLAY button.
Time search–Lets you set the TV/VCR to advance
•
the tape by entering the desired playback time you
want to skip.
OTR (One Touch Recording)–Instant recording in
•
30 to 480 minutes increments is possible at the
push of the REC/OTR button.
1 Year, 8 events (including Daily and Weekly
•
Timer Recording)–
record up to 8 programs at different times on different channels up to 1 year in advance. The Daily
timer allows recordings to be made of daily broadcasts, and the Weekly timer allows recording to be
made once a week up to the end of the tape.
Auto return–After timer recording is finished, the
•
TV/VCR can return to the beginning of the recording.
Wake-up/Sleep timer–Allows you to have the
•
TV/VCR automatically turn on or off at a desired
time.
Timer Program Extension–Allow you to shift the
•
time schedule for automatic timer recording.
V-CHIP–Enables parents to prevent their children
•
from watching inappropriate material on TV.
The built-in timer allows you to
SUPPLIED ACCESSORIES
Remote Control Unit 2 AABatteries Rod Antenna
PART NO.
(N0154UD or N0123UD) PART NO. (0EMN00673 or
0EMN01599 or 0EMN01755)
If you need to replace these accessories, please refer to the PART NO. under the illustrations and call 1-800-
•
968-3429.
Depending on your antenna system, you may need different types of Combiners (Mixer) or Separators
•
(Splitter). Contact your local electronics store for these items.
We do not recommend the use of universal remote controls. Not all of the functions may be controlled with
•
a universal remote control. If you decide to use a universal remote control with this unit, please be aware
that the code number given may not operate this unit. In this case, please call the manufacturer of the universal remote control.
- 6 - EN
9I03
OPERATING CONTROLS AND FUNCTIONS
1 92 3 4 5 6 7 8 131011 1412
AUDIO EARPHONEVIDEO STOP/EJECT REW PLAY F.FWD REC/OTRCHANNELVOLUMEPOWER
NOTE:
We do not recommend the use of universal remote controls. Not all of the functions may be controlled with
•
a universal remote control.
If you decide to use a universal remote control with this unit, please be aware that the code number given
may not operate this unit. In this case, please call the manufacturer of the universal remote control.
- TV/VCR FRONT PANEL -
- REMOTE CONTROL -
1 VIDEO input jack– Connect to the video output
jack of your video camera, video game or another
VCR.
2 AUDIO input jack– Connect to the audio output
jack of your video camera, video game or another
VCR.
3 POWER button– Press to turn TV/VCR on and off.
Press to activate timer recording.
4
VOLUME XX/ YYbuttons– Adjust the volume level.
5 CHANNEL K / L buttons–
Press to select the
desired channels for viewing or recording.
You may display the main menu on the TV screen
by pressing repeatedly this button on the TV/VCR
until you go below the lowest memorized channel.
TRACKING function– Press to minimize video
‘noise’ (lines or dots on screen) during playback.
6 Remote Sensor Window– Receives the infrared
signals from the remote control.
7 STOP / EJECT button (TV/VCR)– Press to stop the
tape motion. Press in the Stop mode to remove tape
from TV/VCR.
EJECT button (remote control)– Press to remove
tape from TV/VCR.
L button–
Press to select setting modes from the on
•
screen menu.
Press to enter digits when setting program.
•
(for example: setting clock or timer program)
15
16
17
11
18
19
20
3
POWER
123
456
789
MENU
WAKE-UP
/SLEEP
+100
0
DISPLAY MUTE
EJECT
CHANNEL
RETURN
CHANNEL
VOLUME
25
7
24
5
4
23
9
10
22
21
8
7
RECORD
REW
PLAY
STOP
T-PROG.
CLEAR
COUNTER
RESET
F.FWD
SPEED
GAME
PAUSE/STILL
TIME SEARCH
- 7 - EN
9I03
- REAR VIEW -
ANT.
2627
8 REW button– Press to rewind the tape, or to view
the picture rapidly in reverse during playback
mode. (Rewind Search)
s button–
Press to select a mode from a particular menu.
•
(for example: LANGUAGE or USER’S SET
UP)
9 PLAY button– Press to begin playback.
K button–
Press to select setting modes from the on
•
screen menu.
Press to enter digits when setting program.
•
(for example: setting clock or timer program)
10 F.FWD button– Press to rapidly advance the tape,
or to view the picture rapidly in forward during
playback mode. (Forward Search)
B button–
When setting program (for example: setting
•
clock or timer program), press to determine
your selec
want to input.
Press to determine setting modes from on screen
•
menu.
Press to select a mode from a particular menu.
•
(for example: LANGUAGE or USER’S SET
UP)
11 REC button–
OTR button–Activates One Touch Recording.
(only on the TV/VCR)
12 RECORD indicator– Flashes during recording.
Lights up in the Stand-by mode for Timer Recording.
13 EARPHONE jack– Connects to earphones (not
supplied) for personal listening. The size of jack is
1/8” monaural (3.5mm).
14 Cassette compartment
15 Number buttons– Press to select desired channels
for viewing or recording. To select channels from
1 to 9, first press the 0 button and then 1 to 9.
tion and proceed to the next step you
Press for manual recording.
+100 button– When selecting cable channels which
are higher than 99, press this button first, then press
the last two digits. (To select channel 125, first press
the “+100” button then press “2” and “5”).
16 MENU button– Press to display the main menu on
the TV screen.
17 DISPLAY button– Display the counter or the cur-
rent channel number and current time on the TV
screen. (See page 25.)
18 SPEED button– Press to choose the desired
recording speed:SP/SLP.
19 T-PROG. CLEAR button– Press to cancel a setting
of timer program. (See page 23.)
COUNTER RESET button– Press to reset counter
to 0:00:00.
20 GAME button–
A/V input mode at the same time. (See page 14.)
21 TIME SEARCH button–
Search mode.
22 PAUSE/STILL button– Press to temporarily stop
the tape during the recording or to view a still picture during playback.
23 MUTE button– Mutes the sound. Press it again to
resume sound.
24 CHANNEL RETURN button– Press to go back to
the previously viewed channel. For example,
pressing this button once will change channel display from 3 (present channel) to 10 (previously
viewed channel), and pressing it a second time
will return from 10 to 3.
25 WAKE-UP/SLEEP button– Sets the Wake up or
Sleep Timer. (See pages 23 and 24.)
26 ANT. terminal– Connect to an antenna or cable
system.
27 Power cord– Connect to a standard AC outlet.
(120V/60Hz)
Sets the game mode and selects front
Press to activate Time
- 8 - EN
9I03
Satellite Box or
Cable Box
(Not supplied)
PREPARATION FOR USE
ANTENNA/CABLE CONNECTIONS
From Cable System
or Satellite Dish
OUT
IN
Rod Antenna
(Supplied)
VHF/UHF Antenna
(Not supplied)
VHF Antenna
(Not supplied)
From
Cable System
ANT.
ANT.
75-ohm Coaxial
Cable (Not supplied)
or
VHF/UHF COMBINED ANTENNA
The VHF/UHF Rod Antenna (supplied) is detachable.
Insert the stem of the antenna into the hole on the
upper-back portion of the TV/VCR. Connect the
VHF/UHF Rod Antenna or VHF/UHF Combination
Antenna to the ANT. terminal of the TV/VCR as
shown in the diagram. For the best reception, fully
extend the VHF/UHF Rod Antenna and make the
necessary adjustments. (Avoid touching the top section when adjusting.)
NOTE:
Before connecting the Rod antenna into antenna terminal, check that the pin is not bent. If it is bent,
straighten the pin as illustrated, then plug the pin into
antenna terminal.
Bent pin
Cable Plug
(Needs to be straightened)
NOTE:
The connection of an Rod antenna may not always
give acceptable TV reception.
(Straight pin)
UHF Antenna
or
VHF/UHF
Combiner
or
(Not supplied)
or
Flat twin-lead cable
(Not supplied)
VHF/UHF SEPARA TE ANTENNAS
In some areas it will be necessary to use an outdoor
antenna.
CABLE WITHOUT CONVERTER/
DESCRAMBLER BOX
Use this connection if your cable system connects
directly to your TV/VCR without a converter box.
By using this connection you can:
1)
Use the TV/VCR Remote Control to select channels
2) Program one or more unscrambled channels for
Timer Recording.
NOTE: This unit will ONLY record and view the
same channel.
CABLE WITH CONVERTER/
DESCRAMBLER BOX OR SATELLITE
BOX
If your cable service supplies you with a converter
box or if you use a satellite system, you can use the
basic connection shown in the diagram.
By using this connection you can also record scrambled channels. However, channel selection must be
made with the converter box or satellite box. This
means that channels cannot be changed using the
TV/VCR Remote Control. Unattended timer recording is limited to one channel at a time.
.
Note to CATV system installer:
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that
provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.
- 9 - EN
9I03
TO RECORD A SCRAMBLED/UNSCRAMBLED
CHANNEL
1) Set the TV/VCR channel selector to the output
channel of the Cable Converter Box or Satellite
Box. (Example: CH3)
2) Select the channel to record from your Cable
Converter Box or Satellite Box.
FRONT A/V INPUT
When using an external input signal (another VCR,
video game or video camera), connect the player’s
audio/video output cables to the AUDIO IN/ VIDEO
IN jacks of your TV/VCR. Then press the CHANNEL K or L button until “AUX” appears on the
screen.
NOTE: “AUX” is found below the
AUX
lowest memorized channel.
(Example: CH2)
SET UP FOR USE
INSTALLING THE BATTERIES
1)Open the battery compartment cover by pressing
the cover on the remote unit in the direction of the
arrow.
2)Insert 2 “AA” penlight batteries into the battery
compartment in the direction indicated by the
polarity (+/-) markings.
3)Replace the cover.
SELECTING THE LANGUAGE
1 Plug in the TV/VCR power cord
Plug the TV/VCR power cord into a
standard AC outlet.
NOTE:
If some digits appear in the corner of
•
the screen, press the POWER button
without unplugging the power cord.
Make sure ...
Press the POWER button to turn on the TV/VCR.
•
NOTE: This function effects only the language on
the screen menu and not the audio source.
2 Select “LANGUA GE”
Press the MENU button on the
remote control.
Press the PLAY/
K or STOP/L but-
ton to point to “LANGUAGE”.
3 Select “ENGLISH”,“ESP AÑOL”or
“FRANÇAIS”
Select “ENGLISH”, “ESPAÑOL”= Spanish or
“FRANÇAIS”= French using the F.FWD/B or
REW/s button.
– M E N U –
TIMER PROGRAMMING
PICTURE CONTROL
SETTING CLOCK
CHANNEL SET UP
USER’S SET UP
V-CHIP SET UP
B LANGUAGE [ENGLISH]
CAPTION [OFF]
ZERO RETURN
TIME SERARCH
4 Exit the Language mode
Press the MENU button on the remote control to
return to TV mode.
NOTE: If for some reason the menu is in Spanish or
French, press the MENU button on the remote control, press the PLAY/K button to point to “IDIOMA
[ESPAÑOL]” or “LANGAGE [FRANÇAIS]”, then
press the F.FWD/B button, then press the MENU
button on the remote control.
CLOCK SET UP
(AUTO / MANUAL)
The TV/VCR clock must be set correctly before timer
recording is possible. It is suggested that the clock be
set manually when first setting up the TV/VCR. Then,
set to [ON] the auto clock setting which will periodically correct the setting if necessary.
NOTE: If you cannot receive a station with time
signals, auto clock setting cannot be performed. Use
manual setting only.
MANUAL CLOCK SETTING
Make sure ...
The TV/VCR is turned on.
•
- 10 - EN
9I03
Loading...
