Owner's Manual

Owner’s Manual

DVD Recorder

Before you start Connections

Getting started

FDR-90E

Recording

Playing discs

VCR Plus+ and PlusCode are registered trademarks of Gemstar Development Corporation.The VCR Plus+ system is manufactured under license from Gemstar Development Corporation.

INSTRUCCIONES EN ESPAÑOL INCLUIDAS

INSTRUCTIONS EN FRANÇAIS INCLUSES

Supplied Accessory

• Remote control (NA816UD) with two AA batteries

• RF cable (WPZ0901TM002 or WPZ0901CAB01)

• Audio/Video cables (WPZ0102TM015 or

WPZ0102LTE01)

• Owner’s Manual (1VMN20268)

• Quick Use Guide (1VMN20269)

Please read before using this equipment.

If you need additional operating assistance after reading this owner’s manual or to

order replacement accessories, please call

TOLL FREE : 1-800-605-8453

or visit our web site at http://www.funai.us

Before you use this unit, you need to complete connections. Refer to “Connections” on pages 13-15.

To r ecord a program easily, refer to “Easy DVD recording” on pages 16-17 after connections are completed.

(You CANNOT record on any copyright protected DVD disc with this DVD recorder.)

Editing

Changing the SETUP menu

Others Español

Français

Before you start

Precautions

WARNING

CAUTION

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLI-

ANCE TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

Laser Safety

This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device, due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED

CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE INTO BEAM. LOCATION: INSIDE, NEAR THE DECK MECHANISM.

FCC WARNING- This equipment may generate or use radio frequency energy. Changes or modifica-

tions to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual.The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

RADIO-TV INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates, uses,and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

CAUTION:TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES,INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE

DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

Make your contribution to the environment!!!

• Used up batteries do not belong in the dust bin.

• You can dispose of them at a collection point for used up batteries or special waste. Contact your council for details.

For Customer Use: Read carefully the information located at the back of this unit and enter below the Serial No.Retain this information for future reference.

Model No. Serial No. _____________________

_____________________

Before you start

Precautions (cont’d)

Important Safeguards

1. Read Instructions - All the safety and operating instructions should be read before the appliance is operated.

2. Retain Instructions- The safety and operating instructions should be retained for future reference.

3. Heed Warnings - All warnings on the appliance and in the operating instructions should be adhered to.

4. Follow Instructions - All operating and use instructions should be followed.

5. Cleaning - Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. EXCEPTION:A product that is meant for uninterrupted service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter,is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.

6.Attachments - Do not use attachments not recommended by the product manufacturer as they may cause hazards.

7.Water and Moisture- Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool,and the like.

8.Accessories - Do not place this product on an unstable cart, stand, tripod, bracket, or table.The product may fall,causing serious injury to a child or adult, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the appliance should follow the manufacturer's instructions and should use a mounting accessory recommended by the manufacturer. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

9.Ventilation - Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating,and these openings must not be blocked or covered.The openings should never be blocked by placing the product on a bed, sofa, rug,or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer's instructions have been adhered to.

10. Power Sources - This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home,consult your appliance dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.

11. Grounding or Polarization - This product is equipped with a polarized alternating-current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way.This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

12. Power Cord Protection - Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them,paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

13. Outdoor Antenna Grounding - If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges.Article 810 of the National Electrical Code,ANSI/NFPA No.70, provides information with regard to proper grounding of the mast and sup-

porting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig.A)

FIGURE A

EXAMPLE OF ANTENNA GROUNDING

AS PER NATIONAL ELECTRICAL CODE

GROUND CLAMP

ELECTRIC SERVICE EQUIPMENT

NEC – NATIONAL ELECTRICAL CODE

S2898A

ANTENNA LEAD WIRE

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMP

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

14. Lightning - For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.

15. Power Lines - An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits,or where it can fall into such power lines or circuits.When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16. Overloading - Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

17. Object and Liquid Entry - Never push objects of any kind into this product through any openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.

18. Servicing - Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19. Damage Requiring Service - Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a. When the power-supply cord or plug is damaged. b.If liquid has been spilled, or objects have fallen into the product. c.If the product has been exposed to rain or water. d.If the product does not operate normally by following the oper-

ating instructions.Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation.

e.If the product has been dropped or damaged in any way. f. When the product exhibits a distinct change in performance this

indicates a need for service.

20. Replacement Parts - When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards.

21. Safety Check - Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.

22. Heat - This product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

Before you start Connections

Getting started

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Français

Before you start

MP3

Precautions (cont’d)

Installation Location

For safety and optimum performance of this unit:

• Install the unit in a horizontal and stable position. Do not place anything directly on top of the unit. Do not place the unit directly on top of the TV.

• Shield it from direct sunlight and keep it away from sources of intense heat. Avoid dusty or humid places. Avoid places with insufficient ventilation for proper heat dissipation. Do not block the ventilation holes on the sides of the unit. Avoid locations subject to strong vibration or strong magnetic fields.

Avoid the Hazards of Electrical Shock and Fire

• Do not handle the power cord with wet hands.

• Do not pull on the power cord when disconnecting it from AC wall outlet. Grasp it by the plug.

• If, by accident, water is spilled on this unit, unplug the power cord immediately and take the unit to our Authorized Service Center for servicing.

Moisture Condensation Warning

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place, or after heating a cold room or under conditions of high humidity. Do not use this unit at least for 2 hours until its inside gets dry.

Symbol in this owner's manual

Many functions of this DVD recorder are depending on the disc type or the recording mode. To specify for what disc type or recording mode each function is, we put the following symbols at the beginning of each item to operate.

Symbol

DVD-V

DVD-RW

DVD-R

MP3

Video

Description

Available to DVD Video discs

Avaialble to DVD-RW in Video mode

Avaialble to DVD-RW in VR mode

Available to DVD-R discs

Available to Audio CDs

Available to CD-R/RW discs with MP3 files

Maintenance

SERVICING

• Please refer to relevant topics on the Troubleshooting Guide on pages 96-99 before returning the product.

• If this unit becomes inoperative, do not try to correct the problem by yourself.There are no user-serviceable parts inside.Turn off, unplug the power plug, and please call our help line mentioned on the front page to locate an Authorized Service Center.

About Copyright

Unauthorized copying, broadcasting, public performance and lending of discs are prohibited. This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

Notice for progressive scan outputs

Consumers should note that not all high definition television sets are fully compatible with this product and may cause artifacts to be displayed in the picture. In case of 525 progressive scan picture problems, it is recommended that the user switch the connection to the ‘standard definition’ output. If there are questions regarding our TV set compatibility with this model 525p DVD recorder, please contact our customer service center.

CLEANING THE CABINET

• Use a soft cloth slightly moistened with a mild detergent solution. Do not use a solution containing alcohol, spirits, ammonia or abrasive.

CLEANING DISCS

• When a disc becomes dirty, clean it with a cleaning cloth.Wipe the disc from the center out. Do not wipe in a circular motion.

• Do not use solvents such as benzine, thinner, commercially available cleaners, detergent, abrasive cleaning agents or antistatic spray intended for analogue records.

CLEANING THE DISC LENS

• If this unit still does not perform properly although you refer to the relevant sections and to “TROUBLESHOOTING GUIDE” in this Owner’s Manual, the laser optical pickup unit may be dirty. Consult your dealer or an Authorized Service Center for inspection and cleaning of the laser optical pickup unit.

DISC HANDLING

• Handle the discs so that fingerprints and dust do not adhere to the surfaces of the discs.

• Always store the disc in its protective case when it is not used.

Before you start

Ta b le of contents

Before you start Connections

Before you start . . . . . . . . . . . . . . . . . . .2

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Ta b le of contents . . . . . . . . . . . . . . . . . . . . . . . . . .5

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Functional overview . . . . . . . . . . . . . . . . . . . . . . .7

Installing batteries in the remote control . . . . . . . . . .9

Using a remote control . . . . . . . . . . . . . . . . . . . . . . .9

SETUP/DISC/CD menu . . . . . . . . . . . . . . . . . . . . . .10

DISPLAY menu . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Connections . . . . . . . . . . . . . . . . . . . . .13

Connection to a TV . . . . . . . . . . . . . . . . . . . . . . .13

Connection to a cable box or satellite box . . . .14

When connecting to a cable box or satellite box with

only a few scrambled channels . . . . . . . . . . . . . . . . .14

When connecting to a cable box or satellite box with

many scrambled channels . . . . . . . . . . . . . . . . . . . . .14

Connection to an Audio System . . . . . . . . . . . . .15

Getting started . . . . . . . . . . . . . . . . . . .16

Easy DVD recording . . . . . . . . . . . . . . . . . . . . . .16

Channel setting . . . . . . . . . . . . . . . . . . . . . . . . . .18

Getting channels automatically . . . . . . . . . . . . . . . . .18

Adding/deleting channels . . . . . . . . . . . . . . . . . . . . .19

Guide channel setting . . . . . . . . . . . . . . . . . . . . . . .20

Selecting the TV stereo or SAP . . . . . . . . . . . . .22

Clock setting . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Auto Clock Setting . . . . . . . . . . . . . . . . . . . . . . . . .23

Manual Clock Setting . . . . . . . . . . . . . . . . . . . . . . . .24

Setting the daylight saving time . . . . . . . . . . . . . . . .26

Selecting the TV aspect ratio . . . . . . . . . . . . . . .27

Recording . . . . . . . . . . . . . . . . . . . . . . .28

Information on DVD recording . . . . . . . . . . . . . .28

Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Recording speed . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Restrictions on recording . . . . . . . . . . . . . . . . . . . .28

Information on copy control . . . . . . . . . . . . . . . . . .29

Making discs playable in other DVD player (Finalize) 29

Formatting a disc . . . . . . . . . . . . . . . . . . . . . . . .30

Settings for the recording format to a blank disc . . .30

Reformatting a disc . . . . . . . . . . . . . . . . . . . . . . . . .32

Basic recording . . . . . . . . . . . . . . . . . . . . . . . . . .33

Checking the recording picture quality . . . . . . . . . .34

One-touch timer recording . . . . . . . . . . . . . . . .35

Timer recording . . . . . . . . . . . . . . . . . . . . . . . . .36

Hints for timer recording . . . . . . . . . . . . . . . . . . . . .38

Timer recording using VCR Plus+®system . . . . .39

Settings for an external source . . . . . . . . . . . . . .40

Connection to an external source . . . . . . . . . . . . . .40

Recording from an external source . . . . . . . . . . . . .41

Finalizing the discs . . . . . . . . . . . . . . . . . . . . . . .42

Setting a disc to protect . . . . . . . . . . . . . . . . . . .43

Playing discs . . . . . . . . . . . . . . . . . . . . .44

Information on DVD play . . . . . . . . . . . . . . . . . .44

Guide to displays . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Basic playback . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Playing discs using the disc menu . . . . . . . . . . . . . . .47

Playing discs using the title menu . . . . . . . . . . . . . . .48

Special playback . . . . . . . . . . . . . . . . . . . . . . . . .49

Resume play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Fast forward / Fast reverse . . . . . . . . . . . . . . . . . . .49

Skipping TV commercials during play . . . . . . . . . . . .50

Pause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

Step by step playback . . . . . . . . . . . . . . . . . . . . . . . .51

Slow forward / Slow reverse play . . . . . . . . . . . . . . .51

Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Spatializer setting (Virtual surround) . . . . . . . . . . . .52

Marker Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

Title/Chapter search . . . . . . . . . . . . . . . . . . . . . . . .54

Track search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

Time search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

Repeat/Random/Program playback . . . . . . . . . .56

Repeat play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56

Random playback . . . . . . . . . . . . . . . . . . . . . . . . . . .56

Program play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

Selecting the format of audio and video . . . . . .58

Switching audio soundtrack . . . . . . . . . . . . . . . . . . .58

Switching subtitles . . . . . . . . . . . . . . . . . . . . . . . . . .59

Switching camera angles . . . . . . . . . . . . . . . . . . . . . .60

Reducing block noise . . . . . . . . . . . . . . . . . . . . . . . .60

Editing . . . . . . . . . . . . . . . . . . . . . . . . .61

Information on disc editing . . . . . . . . . . . . . . . . .61

Guide to a title list . . . . . . . . . . . . . . . . . . . . . . . . . .61

Editing discs with Video mode . . . . . . . . . . . . . . . . .61

Editing discs with VR mode . . . . . . . . . . . . . . . . . . .62

Editing DVD-RW discs in Video mode . . . . . . . .63

Deleting titles . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63

Putting names on titles . . . . . . . . . . . . . . . . . . . . . .64

Setting or clearing chapter markers . . . . . . . . . . . . .66

Editing DVD-RW discs in VR mode (Original) . .67

Deleting titles . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

Deleting parts of titles . . . . . . . . . . . . . . . . . . . . . . .68

Putting names on titles . . . . . . . . . . . . . . . . . . . . . .69

Setting or clearing chapter markers . . . . . . . . . . . . .71

Setting pictures for thumbnails . . . . . . . . . . . . . . . . .72

Setting titles to protect . . . . . . . . . . . . . . . . . . . . . .74

Releasing titles from protecting . . . . . . . . . . . . . . . .75

Editing DVD-RW discs in VR mode (Playlist) . . .76

Deleting titles . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76

Deleting parts of titles . . . . . . . . . . . . . . . . . . . . . . .77

Putting names on titles . . . . . . . . . . . . . . . . . . . . . .78

Setting or clearing chapter markers . . . . . . . . . . . . .80

Setting pictures for thumbnails . . . . . . . . . . . . . . . . .81

Adding titles to a Playlist . . . . . . . . . . . . . . . . . . . . .83

Deleting a Playlist . . . . . . . . . . . . . . . . . . . . . . . . . . .84

Editing DVD-R discs . . . . . . . . . . . . . . . . . . . . . .85

Deleting titles . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85

Putting names on titles . . . . . . . . . . . . . . . . . . . . . .86

Changing the SETUP menu . . . . . . . . .87

Tour of the SETUP menu . . . . . . . . . . . . . . . . . .87

Settings for Language . . . . . . . . . . . . . . . . . . . . .88

Settings for Display . . . . . . . . . . . . . . . . . . . . . . .90

Settings for Audio . . . . . . . . . . . . . . . . . . . . . . . .92

Settings for Parental lock level . . . . . . . . . . . . . .94

Others . . . . . . . . . . . . . . . . . . . . . . . . .96

Tr oubleshooting . . . . . . . . . . . . . . . . . . . . . . . . .96

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . .101

Language code . . . . . . . . . . . . . . . . . . . . . . . . .101

Español . . . . . . . . . . . . . . . . . . . . . . . .102

Françaisl . . . . . . . . . . . . . . . . . . . . . . .104

Getting started

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Français

Before you start

Features

This DVD unit not only plays DVDs and CDs but also offers features for you to record to DVD discs and edit them after that. The following features are offered with this DVD recorder.

Recording

This DVD recorder is compatible with both DVD-RW, which is rewritable repeatedly and DVD-R, which is available for recording once.You can choose either one for your convenience.

Up to 8 program recording:

You can program the DVD recorder to record up to 8 programs, up to a year in advance. Daily or weekly program recordings are also available.

One-touch timer recording:

You can easily set a recording time as you prefer. Every time the REC/OTR button on the remote control or the REC button on the front panel pressed during recording, the recording time will be increased by 30 minutes up to 4 hours.The recording automatically stops when the recording time you set is reached.

The VCR Plus+ system:

You can program the automatic timer recording using the PlusCode programming numbers that are printed in most newspaper TV listings and TV Guide magazine.

REC MONITOR:

You can confirm the picture quality for recording in the current recording speed which you set. If you want to change the recording speed, press REC SPEED button to set the desired recording mode.

Automatic Chapter marker setting:

Chapter markers will be put on recordings as you set in SETUP menu before attempting to record.

Automatic Title menu making:

The DVD recorder makes title menus automatically when finalizing the disc which are recorded in Video mode.

Automatic PLAYLIST making (VR mode):

A Playlist will be prepared from an Original list, so that you can edit titles in a Playlist as you prefer. An Original list is kept as it is.

Play Spatializer:

You can enjoy stereophonic virtual sound of Spatializer® N-2-2 ultra™ method provided by Desper Products, Inc.

Theater surround sound in your home:

When connecting the DVD recorder to an amplifier or a decoder which is compatible with Dolby Digital or DTS, you are allowed to experience the theater surround sound from discs with surround sound system.

Quick search for what you want to watch:

You can easily find the part you want to watch using the search function. Search for a desired point on a disc by title, chapter or time.

Editing Setting/Clearing chapter markers:

You can easily add chapter markers anywhere in your recordings for easy editing. (VR mode)

Making your own Playlist:

With the original remains as it is, you can edit titles on various Playlist as you prefer. Putting names on titles Setting pictures for thumbnails Setting/clearing chapter markers Deleting parts of titles etc

Protecting titles:

To avoid editing or erasing titles, the protect function is useful when it is ON in the original list.

Compatibility Available for playing discs recorded in Video mode on a regular DVD player (Video mode):

Discs recorded in Video mode can be played on regular DVD players, including computer DVD drives compatible with DVD-Video playback*.You will need to finalize the discs recorded in Video mode to play in other DVD players.

* DVD-Video Format (Video mode) is a new format for recording on DVD-R/RW discs that was approved by the DVD Forum in 2000. Adoption of this format is optional for manufactures of DVD playback devices and there are DVD-Video players, DVD-ROM drives or other DVD playback devices that do not play DVD-R/RW discs recorded in the DVD-Video Format.

Others Progressive Scan system

Unlike conventional interlace scanning, the progressive scan system provides less flickering and images in higher resolution than that of traditional television signals.

Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

“DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.

Certain audio features of this product manufactured under a license from Desper Products, Inc.

Spatializer® N-2-2 Ultra™ and the circle-in-square device are trademarks owned by Desper Products, Inc.

Start to play from Original and Playlist:

Title playing is available from either an Original list or Playlist.

Front Panel

OUT

TV ANTENNA

COMPONENT

VIDEO OUTPUT

PR/CR

PB/CB

VIDEO

OUTPUT

INPUT

AUDIO

DIGITAL AUDIO OUTPUT PCM / BITSTREAM

COAXIAL

O P T I C A L

S-VIDEO

VIDEO

(L1)

S-VIDEO

R L

1362

10 9

485

POWER

S-VIDEO VIDEO

STOP REV PLAY FWD CHANNEL

OPEN/CLOSE

L - AUDIO - R

REC REC SPEED

1234567

1215 1314

Before you start

Functional overview

Before you start Connections

1.POWER button

Press to turn the DVD recorder on and off.

If timer programmings have been set, press to set the unit in timer-standby mode.

2.STOP C button

Press to stop play or recording.

3. REV H button

Press to skip to the previous chapter or track. Press and hold for

1.5 seconds to fast reverse.

4. PLAY B button

Press to start or resume play.

5. FWD G button

Press to skip to the next chapter or track. Press and hold for

1.5 seconds to fast forward.

6. CHANNEL L / K button

Press to change the channel up and down.

7. A OPEN/CLOSE button

Press to open or close the disc tray.

8.Disc tray

Place a disc when open.

Rear Panel

9. Display

Refer to “Guide to Displays on the front panel” on page 12.

10. Remote control sensor

Receive signals from your remote control so that you can control the DVD recorder from a distance.

11. REC SPEED button

Press to switch the recording speed.

12. REC button

Press once to start a recording. Press repeatedly to start a One-Touch Recording.

13.AUDIO (L/R) input jacks (LINE2)

Use to connect external equipment with standard audio cables.

14. VIDEO input jack (LINE2)

Use to connect external equipment with a standard video cable.

15. S-VIDEO input jack (LINE2)

Use to connect the S-Video output of external equipment with an S-Video cable.

Getting started

Recording

Playing discs

Editing

Changing the SETUP menu

1.AC Power Cord

Connect to a standard AC outlet to supply power to this unit.

2.AUDIO OUTPUT jacks 1, 2

Use to connect a TV monitor,AV receiver or other equipment with standard audio cables.

3. VIDEO OUTPUT jack

Use to connect a TV monitor,AV receiver or other equipment with a standard video cable.

4. S-VIDEO OUTPUT jack

Use to connect the S-Video input of a TV monitor,AV receiver or other equipment with an S-Video cable.

5. COMPONENT VIDEO OUTPUT jacks

Use to connect a TV monitor with component video inputs with component video cables.

6. TV ANTENNA IN jack

Use to connect an antenna.

Note

• Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent damage to

the DVD recorder.

• This unit does not have the RF modulator

7. TV ANTENNA OUT jack

Use to connect an antenna cable to pass the signal from the TV ANTENNA IN to your TV monitor.

8. S-VIDEO INPUT jack(LINE1)

Use to connect the S-Video output of external equipment with an S-Video cable.

9. VIDEO INPUT jack(LINE1)

Use to connect external equipment with a standard video cable.

10.AUDIO INPUT jacks(LINE1)

Use to connect external equipment with standard audio cables.

11. DIGITAL AUDIO OUTPUT jacks

Use to connect an AV receiver, Dolby Digital decoder, DTS decoder or other equipment with digital input jacks with a digital coaxial cable or a digital optical cable.

Others Español

Français

Remote Control

1.POWER button

Press to turn the DVD recorder on and off. If timer programmings have been set, press to set the unit in timer-standby mode.

2. VCR Plus+ button

Press to set a timer recording with the VCR Plus+ programming system. Press to display the timer program setting menu.

3. CLEAR button

Press to clear the password once entered or to cancel the programming for CD or to clear the selecting marker number in the marker setup mode or to clear the program once entered in the timer recording setting mode,etc.

4. REPEAT button

Press to display the repeat setting menu.

5. CM SKIP button

During playback, press to skip the 30 seconds.

Before you start

Functional overview (cont’d)

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

OPEN/ CLOSE

ABC

DEF

JKL

TUV

SPACE

ZOOM

MNO

WXYZ

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

REC

SPEED

REC/OTR

FWDREV

PAUS E

6. MENU/LIST button

Press to display the Disc menu. To change ORIGINAL and PLAYLIST on the TV screen. (VR mode only)

7. K / L / { / B buttons

Press to select items or settings.

8. RETURN button

Press to return to the previously displayed menu screen.

9. REC MONITOR button

Press to check the video to be recorded before attempting.

10. SKIP H button

During playback, press to skip to the previous chapter or track. Or during play is paused, press to play reverse step by step.

SKIP G button

During playback, press to skip to the next chapter or track. Or during playback is paused, press to play forward step by step.

11. REV E button

During playback, press to play fast reverse. Or during playback is paused, press to play slow reverse.

12.STOP C button

Press to stop play or recording.

13.PAUSE F button

Press to pause play or recording.

14. OPEN/CLOSE A button

Press to open or close the disc tray.

15. Number buttons

Press to select channel numbers. Press to select a title/chapter/track on display or a TV channel. Press to enter the VCR Plus+ programming number. Or press to enter values for the settings in the SETUP menu.

16. DISPLAY button

Press to display or change the on-screen display.

17. ZOOM button

During playback, press to enlarge the picture on the screen.

18.TOP MENU button

Press to display the top menu.

19. ENTER button

Press to confirm or select menu items.

20. SETUP button

Press to display the setup menu. During DVD playback, press and hold for more than 3 seconds to switch to the progressive scanning mode or the interlace mode.

21. REC SPEED button

Press to switch the recording speed.

22. REC/OTR button

Press once to start a recording. Press repeatedly to start a One-Touch Recording.

23. CH K / L buttons

Press to change the channel up and down.

24. FWD D button

During playback, press to play fast forward. Or during playback is paused, press to play slow forward.

25. PLAY B button

Press to start or resume play.

Before you start

POWER

O P E

N /

C L O S

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

RS CL EA

V C R

P l u s

ZOOM

L A Y

C M

S K

I P

R E P

E A T

T O

P M E N

N U / L I

S T

Functional overview (cont’d)

Before you start Connections

Installing batteries in the remote control

Install two AA batteries (supplied) matching the polarity indicated inside battery compartment of the remote control.

Using a remote control

Keep in mind the following when using the remote control:

•Make sure that there is no obstacle between the remote control and the remote sensor on the DVD recorder.

•Use within the operating range and angle as shown.

• Remote operation may become unreliable if strong sunlight or fluorescent light is shining on the remote sensor of the DVD recorder.

• Remote control for different devices can interfere with each other. Avoid using remote control for other equipment located close to the DVD recorder.

•Replace the batteries when you notice a fall off in the operating range of the remote control.

Within about 23feet (7m)

60˚

Getting started

Recording

Playing discs

Note:

Incorrect use of batteries can result in hazards such as leakage and bursting. Please observe the following:

• Do not mix new and old batteries together.

•Do not use different kinds of batteries together, although they may look similar, different batteries may have different voltages.

•Make sure that the plus and minus ends of each battery match the indications in the battery compartment.

• Remove batteries from equipment that is not going to be used for a month or more.

•When disposing of used batteries, please comply with governmental regulations or environmental public instruction's rules that apply in your country or area.

• Do not recharge, short-circuit, heat, burn or disassemble batteries.

Remote control

Editing

Changing the SETUP menu

Others Español

Français

Before you start

Functional overview (cont’d)

Guide to On Screen Menu

The DVD recorder uses the following types of display for most operations. SETUP/DISC/CD menu, Title list, and DISPLAY, which allows you to change the playing status of disc during play. DISPLAY also gives you some disc information for checking the status of the disc.

SETUP/DISC/CD menu

Press SETUP button to display the setup main menu, then choose either of SETUP/DISC/CD by { / B button. Then, press ENTER button to display each menu. These provides entries to all main functions of the DVD recorder.

“SETUP” is available only in the Stop mode.

“DISC” is available only when a DVD-R/RW disc is inserted into the DVD recorder. When a DVD-Video disc (commercially available), a new DVD-R disc or the finalized DVD-R disc is inserted into the DVD recorder, you cannot select “DISC”.

“CD” is available only when an Audio CD disc or a CD-R/RW disc with MP3 files is inserted into the DVD recorder.

Setup Menu

Setup

1 2 3

4 5 6

Playback Setting

1. Playback:

To set up the DVD recorder to play discs as you prefer.

2. Recording:

To set up the DVD recorder to record to discs as you prefer.

3. Display:

To set up the OSD screen and the front display of the DVD recorder as you prefer.

4. Select Video:

To choose a line input to record to DVD discs from other video equipment.

5. Clock:

To set up the clock of the DVD recorder as you need.

6. Channel:

To make the channel setting of the DVD recorder as youprefer.

Disc Setting

Disc

Edit

Format

Finalize

Disc Protect OFF ON

1 2 3

1. Edit:

Turns on a title list, (When a disc with VR mode is inserted, 'Original' or 'PlayList' is available.), which shows the recorded titles on the disc.

2. Format:

Allows you to erase all of the recorded content on the disc. The disc will be completely blank.

3. Finalize:

Allows you to finalize a disc recorded titles.

4. Disc Protect (VR mode only) :

Allows you to protect a disc from accidental editing or recording.

CD Playback Mode

Random Play

Program Play

1 2

1. Random Play:

To set the random play programming.

2. Program Play:

To set the program playing.

DISPLAY menu

Press DISPLAY button to call up the display menu.This menu will give you the information on the playing disc. Some operations are available while disc is playing.

Details are on page 44.

11 00:00:00

DVD-RW

Video mode

SP 1:25 Rem.

Before you start

Functional overview (cont’d)

1. Indicates a disc type and a

format mode. Note: In some descriptions on this manual, only one disc type is indicated as an example.

2. Indicates a recording mode

and possible recording time left/lndicates a channel number.

3. Indicates a title number, chap-

ter number and the time elapsed of disc play.

4. Each icon means:

: Search

: Audio

: Subtitle

: Angle (except VR mode)

: Repeat

: Marker

: Noise Reduction

: Zoom

: Spatializer

Before you start Connections

Getting started

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Français

Before you start

1 6

3 7

Functional overview (cont’d)

Guide to Displays on the front panel

1. Current status of the DVD recorder

: Appears when a disc play

is paused.

: Appears when playing a

disc.

: Appears when the timer

programming has been set and is proceeding.

: Appears during recording

process.

: Appears when repeat play.

Display message

2. Disc type

: Appears when an audio

CD or a disc with MP3 files is inserted in the disc tray.

: Appears when a DVD

disc is inserted in the disc tray.

: Appears when a DVD-R disc is inserted in the disc tray.

: Appears when a DVDRW disc is inserted in the disc tray.

3. Recording speed

Indicates the recording speed of the disc.

4. Title/Track and Chapter mark

: Appears when indicating

a title/track number.

: Appears when indicating

a chapter number.

5. Displays the following

• Playing time / remaining time

• Current title / chapter / track number

• Recording time

• Clock

• Channel number

•OTR remaining time

6. : Appears in the after-

noon with the clock displaying.

7. :

Appears when the progressive scan system is activated.

1. Appears when the DVD

recorder is powered on.

2. Appears when the DVD

recorder is powered off.

3. Appears when the disc tray is

opening.

4. Appears when the disc tray is

closing.

5. Appears when a disc is load-

ing in the disc tray.

6. Appears when recording data

is writing on to the disc.

Connections

OUT

TV ANTENNA

COMPONENT

VIDEO OUTPUT

PR/CR

PB/CB

VIDEO

OUTPUT

INPUT

AUDIO

DIGITAL AUDIO OUTPUT PCM / BITSTREAM

COAXIAL

O P T I C A L

S-VIDEO

VIDEO

(L1)

S-VIDEO

R L

AUDIO IN

OUTPUT

AUDIO

R L

OUTPUT

AUDIO

R L

S-VIDEO IN

OUTPUT

S-VIDEO

PB/CB

R/CR

COMPONENT

VIDEO IN

COMPONENT

VIDEO OUTPUT

PR/CR

PB/CB

OUT

TV ANTENNA

COMPONENT

VIDEO OUTPUT

PR/CR

PB/CB

VIDEO

OUTPUT

INPUT

AUDIO

AUDIOCOAXIAL

O P T I C A L

S-VIDEO

VIDEO

(L1)

S-VIDEO

R L

DIGITAL AUDIO OUTPUT PCM / BITSTREAM

AUDIO IN VIDEO

RF Cable (supplied)

Video Cable

(supplied)

Audio Cable

(supplied)

(Back of TV)

Plug in the AC power cord of the DVD recorder.

Cable

Signal

Cable

Signal

Connect

ConnectConnect

Disconnect

Antenna

(Back of DVD recorder)

(Back of TV)

SETUP

RETURN

Connection to a TV

Make one of the following connections, depending on the capabilities of your existing equipment.

Method 1 Method 2

Basic Audio

Better picture Best picture

Before you start Connections

Getting started

Recording

Playing discs

Audio cable

(supplied)

S-Video

cable

(commercially

available)

Component Video cables (commercially available)

DVD Recorder

S-VIDEO OUT

AUDIO OUT

Note

•

Connect this unit directly to the TV. If the A/V cables are connected to a VCR, pictures may be distorted due to the copy protection system.

•

When progressive scanning mode is selected, no video signal will be output from the VIDEO OUT or S-VIDEO OUT jack.

If your TV is compatible with 525p (480p) progressive scanning and you want to enjoy that high quality picture;

You must select the connection Method 2 above and progressive scanning mode.To set the mode, press and hold the SETUP button on the remote control for more than 3 seconds during DVD playback, so that “P.SCAN” will appear on the display of this unit.

If your TV is not compatible with progressive scanning;

Use this unit in interlace mode. Make sure that no “P.SCAN” is on the display of this unit. If not, press and hold the SETUP button on the remote control for more than 3 seconds during DVD playback, so that “P.SCAN” on the display of this unit will disappear.

COMPONENT VIDEO OUT

more than 3 seconds

during DVD playback

[Interlace mode]

[Progressive scanning mode]

Editing

Changing the SETUP menu

Others Español

Français

Connections

DIGITAL AUDIO OUTPUT PCM / BITSTREAM

OUT

TV ANTENNA

COMPONENT

VIDEO OUTPUT

PR/CR

PB/CB

VIDEO

OUTPUT

INPUT

AUDIO

AUDIOCOAXIAL

O P T I C A L

S-VIDEO

VIDEO

(L1)

S-VIDEO

R L

AUDIO IN VIDEO

RF cable (supplied)

Video cable

(supplied)

Audio

cable

(supplied)

(Back of TV)

Cable Signal

Connect

ConnectConnect

(Back of DVD recorder)

OUT

(Cable box or

Satellite box)

RF cable

OUT

TV ANTENNA

COMPONENT

VIDEO OUTPUT

PR/CR

PB/CB

VIDEO

OUTPUT

INPUT

AUDIO

AUDIOCOAXIAL

O P T I C A L

S-VIDEO

VIDEO

(L1)

S-VIDEO

R L

DIGITAL AUDIO OUTPUT PCM / BITSTREAM

AUDIO IN VIDEO

Video

cable

(supplied)

Audio

cable

(supplied)

(Back of TV)

Cable Signal

ConnectConnect

(Back of DVD recorder)

RF cable

Connect

RF cable (supplied)

RF cable

OUT

(Cable box or

Satellite box)

Connect

Connection to a cable box or satellite box

When connecting to a cable box or satellite box with only a few scrambled

channels

If you are using a cable box or satellite box with only a few scrambled channels, follow the setup on this page. If many or all the channels are scrambled, we recommend using the setup on the following page.

With this setup:

•You can record any unscrambled channel by selecting the channel on the DVD recorder.

•You cannot record scrambled channels that require a cable box or satellite box.

When connecting to a cable box or satellite box with many scrambled

channels

If many or all the channels you receive by cable or satellite are scrambled, we recommend using this setup.

With this setup:

•You can record any unscrambled channel by selecting the channel on the cable box or satellite box. Be sure that the cable box or satellite box is turned on.

•You cannot record one channel while watching another channel.

Note to the Cable TV System Installer :

This reminder is provided to call the Cable TV system installer’s attention to Article 820-40 of the National Electrical Code, which provides guidelines for proper grounding - in particular, specifying that the cable ground shall be connected to the grounding system of the building, as close to the point of cable

entry as possible.

Connections

OUTPUT

AUDIO

R L

OUTPUT

AUDIO

R L

COAXIAL

OPTICAL

DIGITAL AUDIO OUTPUT PCM / BITSTREAM

COAXIAL

O P T I C A L

Connection to an Audio System

• When you change the connections, all devices should be turned off.

• Refer to each owner’s manual for further information on other devices.

Before you start Connections

Stereo system

AUDIO

DVD Recorder

Method 1

Audio cable

(supplied)

AUDIO OUT

Analog audio input jacks

Method 2

Dolby Digital decoder, DTS

decoder, MD deck or DAT deck

Digital audio input jacks

Audio Coaxial

Digital cable

(commercially

available)

Audio Optical

Digital cable

(commercially

available)

DIGITAL AUDIO OUT

Note

• If output is Dolby Digital encoded audio, connect to a Dolby Digital decoder and set “Dolby Digital” to “Stream” for the “Digital Out” setting in the SETUP menu. (Refer to pages 92-93.)

• If output is DTS encoded audio, connect to a DTS decoder and set “DTS” to “ON” for the “Digital Out” setting in the SETUP menu. (Refer to pages 92-93.)

• The audio source on a disc in a Dolby Digital 5.1 channel surround format cannot be recorded as digital sound by an MD or DAT deck.

• Unless connected to a Dolby Digital decoder or a DTS decoder, set “Dolby Digital” to “PCM” and “DTS” to “OFF” for the “Digital Out” setting in the SETUP menu. Playing a DVD using incorrect settings may generate noise distortion and may also damage the speakers.(Refer to pages 92-93.)

• Set “Dolby Digital” to “PCM” for the “Digital Out” setting in the SETUP menu for connecting to an MD deck or DAT deck. (Refer to pages 92-93.)

• By hooking this unit up to a Multi-channel Dolby Digital decoder, you can enjoy high-quality Dolby Digital 5.1 channel surround sound as heard in the movie theaters.

• By hooking this unit up to the DTS decoder, you can enjoy 5.1 channel surround system which reproduces the original sound as truthfully as possible. 5.1 channel surround system is developed by the Digital Theater System, Inc.

Getting started

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Optical cable (not supplied)

• Optical cable (not supplied) may be damaged when bent at sharp angles. Ensure cables are coiled in loops with a diameter of 15 cm or more when storing them.

• Use a cable which is 3 m or shorter.

• Insert cable plugs firmly into the connectors when making connections.

• If a plug has minor scratches or is dirty, clean it with a soft cloth before inserting it into a connector.

Français

Getting started

Easy DVD recording

The following will help you to understand easily how to record to DVD discs.

Note:

Make sure batteries are in the remote control and you have connected this unit and the TV correctly.

Step 1:

Choose a disc type

There are several types of recordable DVD discs to choose from. Choose a recordable DVD disc type based on your playing/recording/editing requirements. See “DVD disc type” below.

This unit can record on the following type of discs only.

(or)

* This unit cannot record on the fol-

lowing discs.

•DVD-R General Ver 2.0 / 8x

•DVD-RW Ver 1.2 / 2-4x CPRM compatible

For example, when you want to record repeatedly on the same disc, or when you want to edit the disc after recording, select the rewritable DVD-RW type disc.

When you want to save recordings without any alteration, a nonrewritable DVD-R can be your choice.

Step 2: Insert a blank disc

Turn on the unit

Open the disc tray

Close the disc tray

Remote Control

POWER

ABC DEF

.@/:

VCR Plus

POWER

ABC DEF

.@/:

VCR Plus

This operation may take a while to be recognized.

OPEN/

OPEN/ CLOSE

Step 3: Select the Recording speed

TUV WXYZ

PQRS

SPACE

CLEAR

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

REC

SPEED

STOP PLAY

PAUSE

SETUP

REC/OTR

FWDREV

SP 2:01 Rem.

RETURN

REC

MONITOR

SKIP

DVD disc types

Format the disc

Insert the disc in the unit. Then format the disc from SETUP menu.Video format (Video mode) or Video recording format (VR mode) will be available depending on the disc type inserted.

This is necessary to prepare the disc for recording. Details are on pages 30-32.

* When you format, the entire contents on that disc will be erased.

Getting started

Easy DVD recording (Cont’d)

Before you start Connections

Step 4: Select the desired channel

.@/:

GHI

PQRS

CLEAR

STOP PLAY

SPACE

ZOOM

OPEN/

ABC

DEF

JKL

MNO

TUV

WXYZ

DISPLAYCM SKIPREPEAT

FWDREV

CH 1

POWER

VCR Plus

SKIP

Step 5: Record to DVD discs

TOP MENUMENU/LIST

REC

SPEED

STOP PLAY

SETUP

REC/OTR

RETURN

REC

MONITOR

SKIP

Step 6: Stop the Record

REC

REC/OTR

MONITOR

SPEED

SKIP

STOP PLAY

FWDREV

PAUSE

Writing to Disc

This operation may take a while to be completed.

58%

Hint 1: Play the recorded contents

You can select the title you want to play from a displayed menu and immediately start to play. Recorded contents are very accessible on a disc, the procedure is really simple as you choose a title on a chapter from the menu screen.

What are titles and chapters?

The contents of DVD disc are generally divided into titles.Titles may be further subdivided into chapters.

Start Rec. Stop/Start Stop Rec.

Title 1 Title 2

Chapter 1 Chapter 1Chapter 2 Chapter 3 Chapter 2

Hint 2: Edit the recorded disc

You will find editing discs very easy.This unit offers convenient edit functions, which are possible only with DVD-R/RW discs.

You can edit the following from a title list.

• Putting names on titles

• Setting pictures for thumbnails (VR mode)

• Setting/clearing chapter markers

• Deleting parts of titles or scenes (VR mode)

Title Delete :This deletes an entire scene permanently from the disc. Scene Delete :This allows a user to edit within a specific scene (ex. commercials).

Original and Playlist (VR mode)

You can edit the recordings in Playlist without changing the original recordings. A Playlist does not take up much disc space.

What “Original” or “Playlist” is for?

Throughout this manual, you will find Original and Playlist to refer to the actual content and the edited version.

• Original content refers to what’s actually recorded on the disc.

• Playlist content refers to the edited version of the disc; how the Original content is to be played.

Finalizing a Disc

• This will allow a disc that is recorded on our unit to be played back on a different DVD player- without finalization it will not be playable on another player.

•

After finalizing a disc if the recording was in video mode, you can not edit any information that is on that disc.

•If you have recorded in VR mode on DVD-RW disc then editing is still permitted after finalizing.

Getting started

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Français

All channels are stored in the

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

REC

MONITOR

REC

SPEED

REC/OTR

DVD recorder when purchased. We recommend that you program available channels in your area using “Auto Preset” in the Channel Preset of the SETUP menu.

Getting started

Channel setting

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Getting channels automatically

Press POWER button to turn on the DVD recorder.

Turn the TV on and be sure to select the input to which the DVD recorder is connected.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Setup Menu

Setup

Playback Setting

Select “Channel” using K / L / { / B buttons, then press ENTER button.

Channel Preset menu will appear.

Setup > Channel Preset

Auto Preset

Manual Preset

Guide Channel Setting

TV Audio Select

Stereo

Select “Auto Preset” using K / L buttons, then press ENTER button.

The DVD recorder will start getting channels available in your area.

CH 18

Auto Presetting Now

Press SETUP button to exit.

•You can select only the channels memorized in this unit by using the CHANNEL buttons.

4 5

To select a channel

You can select a channel by directly entering channel using the Number buttons on the remote control.

Notes for using the Number buttons:

• When selecting cable channels which are higher than 99, enter channel numbers as a three-digit number.(For example: 117, press 1,1,7)

• You must precede single-digit channel numbers with a zero (For example: 02, 03, 04 and so on).

• You can select the line input mode (“L1” or “L2”). To select “L1” by pressing [0], [0], [1].To select “L2” by pressing [0], [0], [2]. Details are on page 41.

Note

• If the auto presetting is can-

celled during presetting, some channels not yet preset may not be received.

• The selection will depend on

how you receive the TV channels.

To cancel the auto presetting during scanning:

Press RETURN button or SETUP button to cancel.

Adding/deleting channels

The channels you no longer receive or seldom watch can be deleted from the memory.You also may add channels into memory.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Setup Menu

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Getting started

Channel setting (cont’d)

Select “Manual Preset” using K / L buttons, then press

ENTER button.

Manual Preset menu will appear.

Setup > Channel Preset > Manual Preset

CH2

Add Delete

Select the channel number to add or delete.

Press { button to move to a lower channel number.

B button to move to a

Press higher channel number.

Setup > Channel Preset > Manual Preset

CH18

Add Delete

2 3 4 5 6

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

REC

SPEED

PAUSE

ABC

TUV

SPACE

ZOOM

JKL

REC/OTR

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

OPEN/

DEF

MNO

WXYZ

SETUP

FWDREV

Before you start Connections

Getting started

Recording

Playing discs

Editing

Setup

Playback Setting

Select “Channel” using K / L / { / B buttons, then press ENTER button.

Channel Preset menu will appear.

Setup > Channel Preset

Auto Preset

Manual Preset

Guide Channel Setting

TV Audio Select

Stereo

Select “Add” or “Delete”

K / L buttons, then

using press ENTER button.

The channel number will be added or deleted from the channel memory.Then a next channel number will appear so that you can continue adding or deleting channels.

Press SETUP button to exit.

Changing the SETUP menu

Others Español

Français

Getting started

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUS E

REC

MONITOR

REC

SPEED

REC/OTR

Channel setting (cont’d)

Guide channel setting

First, fill in the boxes on this page:

1. Write your local channel numbers in “TV Channel” column, which you can receive in your area by channel preset.

2. Write local TV stations corresponding TV Channel in “Call letters” column, and write guide channel numbers corresponding call letters in “Guide Channel” column, consulting your TV guide magazine or the TV listings of your local newspaper.

Now, compare the channel numbers you have written in the Guide Channel and TV Channel columns. You must set all of these channel numbers that don’t match using the following procedure before you program the automatic timer recording using the VCR Plus+ system.

• This setting only needs to be set once, but must be done again if you have moved to a different area and channel numbers have been changed.

Call letters (Local TV station)

Channel Line-Up Chart

Guide Channel (Guide channel number)

TV Channel (Local channel number)

Press SETUP button to display SETUP/DISC menu.

Screen:

Setup Menu

SETUP/DISC menu will appear.

Select SETUP using { / B buttons, then press ENTER button.

SETUP menu will appear.

Setup

Playback Setting

Select “Channel” using K / L / { / B buttons, then press ENTER button.

Channel Preset menu will appear.

Setup > Channel Preset

Auto Preset

Manual Preset

Guide Channel Setting

TV Audio Select

Stereo

2 3

Getting started

Channel setting (cont’d)

Before you start Connections

Select “Guide Channel Setting” using

K / L buttons,

then press ENTER button.

Guide Channel Setting list will appear.

Setup> Channel Preset> Guide Channel Setting

Guide Channel

TV Channel

CH1

: :

CH---

Assign channel numbers to the guide channels as necessary.

Look in your TV guide to see which channel numbers should be assigned to which guide channels.

1. Choose a guide channel number using press ENTER button.

A cursor will move to a TV channel. If the channel you wish to set is not on the screen, press buttons to change the displayed page until you reach the correct page.

2. Select an external input (L) or CATV/TV (CH) using B buttons.

3. Enter a TV channel using L buttons or number but-

tons, then press ENTER button.

The channel number is assigned.

K / L buttons, then

{ / B

{ /

K /

Press SETUP button to exit SETUP menu.

4 5

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

REC

SPEED

PAUSE

ABC

TUV

SPACE

ZOOM

JKL

REC/OTR

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

OPEN/ CLOSE

DEF

MNO

WXYZ

SETUP

FWDREV

Getting started

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

To continue assigning, repeat the steps 1-3.

Note

•To erase a TV channel, press { button at step 5-3.

Français

Selecting the TV stereo or SAP

You can select a sound channel to output from TV. “Stereo” has been selected as the default.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Setup Menu

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Setup

Getting started

Select “TV Audio Select”

K / L buttons, then

using press ENTER button.

Option window will appear.

Setup > Channel Preset

Auto Preset

Manual Preset

Guide Channel Setting

TV Audio Select

Stereo

SAP

Select “Stereo” or “SAP”

K / L buttons, then

using press ENTER button.

Stereo:

Outputs main-audio.

SAP: (Secondary Audio Program)

Outputs Sub-audio. Refer to the item in “Glossary” on page 100 for more information.

2 3 4 5

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

SPEED

PAUS E

OPEN/

ABC

DEF

JKL

MNO

TUV

WXYZ

SPACE

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

REC

REC/OTR

FWDREV

Playback Setting

Select “Channel” using K / L / { / B buttons, then press ENTER button.

Channel Preset menu will appear.

Setup > Channel Preset

Auto Preset

Manual Preset

Guide Channel Setting

TV Audio Select

Stereo

Press SETUP button to exit.

Notes on TV channel audio

• When you record a TV program which has Stereo and Secondary Audio Programs on a DVD-RW/R, you have to select the TV channel audio (Stereo or SAP) beforehand. Only the selected channel audio will be recorded. Refer to the following table to check an appropriate setting.

Selected Broadcast Disc Audio audio audio recording output

Stereo STEREO+SAP STEREO STEREO

STEREO STEREO STEREO MONO+SAP MONO MONO MONO MONO MONO

SAP STEREO+SAP SAP SAP

STEREO STEREO STEREO MONO+SAP SAP SAP MONO MONO MONO

•As can be seen in the above table, if your TV channel audio is set to SAP and the recorded TV program has Stereo and Secondary Audio Programs, you can only view the program in the sub-audio.

Set the clock before you try the

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

timer recording. If a Public Broadcasting Station (PBS) is available in your area, follow Auto Clock Setting below. If not, follow Manual Clock Setting on pages 24-25.

Auto Clock Setting

Make sure

• The antenna/Cable TV connections are correct.

• If this unit is connected to a Cable Box or Satellite Box, select the local PBS station on them to set the clock automatically.

Getting started

Clock setting

Select “Auto Clock Setting”

K / L buttons, then

using press ENTER button.

Option window will appear.

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

OFF

Auto

Auto Manual

Off

Before you start Connections

Getting started

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Setup Menu

Select “SETUP” using tons, then press ENTER button.

SETUP menu will appear.

Setup

Playback Setting

{ / B

Select “Clock” using buttons, then press ENTER button.

Clock menu will appear.

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

K / L / { / B

Auto

but-

• If you do not know your PBS channel number, select “Auto” using

K / L buttons,

then press ENTER button.

• If you know your PBS channel number, select “Manual”

K / L buttons, then

using press ENTER button.

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

OFF

Set Channel No.

Auto

CH1

Manual

Off

Enter your PBS channel number using Number or

/ L buttons, then press ENTER button.

Press SETUP button to exit.

Press POWER button to turn off the DVD recorder.

will search for the time only when the power is off. Leave it off for several minutes to give this unit time to set the clock on the front display of the front panel.

This unit

3 4 5

Note

• The clock may set itself automatically after you connect the antenna/cable signal to this unit and plug in the power cord. In this case, the current time will appear on the front display on the front panel.

• The current time is not displayed or the displayed clock is not correct, set the clock manually.

1 6

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Français

Manual Clock Setting

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUS E

REC

MONITOR

REC

SPEED

REC/OTR

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Setup Menu

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Setup

Getting started

Clock setting (cont’d)

Select “Clock Setting” using K / L buttons, then press

ENTER button.

A clock setting window will appear.

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

- - - / - - / - - - - ( - - - )

- - : - -

Auto

Press ENTER button again.

Default date will appear.

Enter the date (month / day / year) using

Press { / B button to move the cursor.

K / L buttons.

2 3

4 5 6

Playback Setting

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

Select “Clock” using K / L / { / B buttons, then press

ENTER button.

Clock menu will appear.

Auto

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

JAN / 12 / 2004 (MON)

12 : 00AM

Auto

Enter the time (hour / minute) using then press

A cursor will move on AM or PM.

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

K / L buttons,

{ / B buttons.

JAN / 12 / 2004 (MON)

09 : 24 AM

Auto

Note

•

Your clock setting will be lost if either there is a power failure or this unit has been unplugged for more than 30 seconds when you set the clock manually.

Getting started

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

Clock setting (cont’d)

Before you start Connections

Press K / L buttons to select AM or PM, then press ENTER button.

Clock menu will appear, then the settings will be activated.

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

Auto

Press SETUP button to exit.

Although seconds are not displayed, they begin counting from zero.

Getting started

Recording

Playing discs

When “Auto Clock Setting” is selected to “Auto” or “Manual”, change it to “OFF” as following steps.

Repeat steps (1) to (3) in “Manual Clock Setting”.

Select “Auto Clock Setting” using

press ENTER button.

Option window will appear.

K / L buttons, then

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

OFF

Auto

Auto Manual

Off

Select “OFF” using K / L buttons, then press ENTER button.

Press SETUP button to exit.

Editing

Changing the SETUP menu

Others Español

4 5

Français

Setting the daylight saving time

When Daylight Saving Time is ON, the DVD recorder clock will automatically move forward one hour on the first Sunday in April and move back one hour on the last Sunday in October.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Setup Menu

Getting started

Clock setting (cont’d)

Select “Daylight Saving Time” using

K / L buttons,

then press ENTER button.

Daylight Saving Time options will appear.

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

Auto

ON OFF

Select “ON” or “OFF” using K / L buttons, then press

ENTER button.

Choose “ON” when currently observing the daylight saving time.

2 3 4 5

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

SPEED

PAUS E

OPEN/

ABC

DEF

JKL

MNO

TUV

WXYZ

SPACE

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

REC

REC/OTR

FWDREV

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Setup

Playback Setting

Select “Clock” using K / L / { / B buttons, then press

ENTER button.

Clock menu will appear.

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

Auto

Press SETUP button to exit.

You can select the TV aspect ratio

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

to match the formats of what you are playing with the DVD recorder and your TV screen (4:3 standard or 16:9 widescreen TV). “4:3 Letter Box” has been selected as the default.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Setup Menu

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Setup

Playback Setting

Select “Playback” using K / L / { / B buttons, then press ENTER button.

Getting started

Selecting the TV aspect ratio

Playback menu will appear.

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

4:3 Letter Box

All

English

Original

OFF

Select “TV Aspect” using K / L buttons, then press ENTER

button.

Option window will appear.

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

16:9 Wide

4:3 Letter Box

4:3 Pan & Scan 16:9 Wide

English Original

OFF

Refer to the Note on this page.

Select a desired option using K / L buttons, then press

ENTER button.

Press SETUP button to exit.

2 3

Note

If you have a standard TV:

Select “4:3 Letter Box”, so that black bars appear on the top and bottom of the screen. Select “4:3 Pan & Scan” for a full height picture with both sides trimmed.

If you have a widescreen TV:

Select “16:9 Wide”.

Before you start Connections

Getting started

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Français

Recording

Information on DVD recording

Information

This DVD recorder can record to DVD-R and DVD-RW discs. When recording, you will need to select a recording format between Video mode and VR mode depending on the disc format.The disc format for DVD-R is always “Video format,” so a recording format will be “Video mode”. On the other hand, when recording to DVD-RW, a recording format will be “Video mode” or “VR mode” because a disc format is available between “Video Recording format” and “Video format” for DVD-RW.

Logo Attributes

12cm, single-sided, single layer disc Approx. max. recording time (SEP mode):

DVD-RW

DVD-R

* This unit cannot record on the following discs.

• DVD-R General Ver 2.0/8x

• DVD-RW Ver 1.2/2-4x CPRM compatible

About Video mode and VR (Video Recording) mode

Video mode is the same recording format as DVDVideo discs purchased locally, so that you can play in most DVD players.To play in other DVD players, you will need to finalize (see page 42). Unless finalized, you can play, record additionally or edit discs recorded in Video mode with this unit. VR (Video Recording) mode is a basic recording format for DVD-RW.You can record and edit repeatedly.

DVD players with are capable of playing DVD-RW recorded in VR mode.

Disc type Disc format

DVD-RW

DVD-R

600 minutes (4.7GB)

12cm, single-sided, single layer disc Approx. max. recording time (SEP mode): 600 minutes (4.7GB)

Functions

Video mode

Video

DVD-RW

VR mode

DVD-RW

Video mode

DVD-R

Playing, limited recording, limited editing

Playing, recording, Original/Playlist editing

Playing, limited recording, limited editing

Recording speed

You can select a recording speed among 6 options, and the recording time will depend on the recording speed you select as follows.

Recording speed

XP (1H)

SP (2H)

LP (4H)

EP (6H)

SLP (8H)

SEP (10H)

Recording time *

60 min

120 min

240 min

360 min

480 min

600 min

Video/Sound Quality

* This table is designed for a new single-sided 12cm

disc as the standard.The recording time are estimates and actual recording time may differ.

*The audio and video quality is getting poorer as

the Recording time becomes longer.

Restrictions on recording

You cannot record copy-protected video using this DVD recorder. Copy-protected video includes DVD-Video discs and some satellite broadcasts. If copy-protected material is encountered during a recording, recording will pause or stop automatically and an error message will be displayed on-screen. Video that is “copy-once only” can only be recorded using a DVD-RW disc in VR mode with CPRM (see below). When recording a TV broadcast or through an external input, you can display copy control information on screen.

What is “CPRM”?

CPRM is a copy protection system with scramble system regarding the recording of “copy once” broadcast programs. CPRM stands for Content Protection for Recordable Media. This DVD recorder is CPRM compatible, which means that you can record copy-once broadcast programs, but you cannot then make a copy of those recordings. CPRM recordings can only be made on DVD-RW discs formatted in VR mode, and CPRM recordings can only be played on players that are specifically compatible with CPRM.

Recording

Information on DVD recording (cont’d)

Before you start Connections

Information on copy control

Some satellite broadcasts include copy-protected information. For recording these, refer to the following.

Disc type / format

ver.1.1

DVD-RW

DVD-R

ver.1.1 CPRM compatible

ver.1.1

Video

ver.1.1 CPRM compatible

ver.2.0

Recordable Not Recordable

Copy-free Copy-once

Note

• The audio and video quality gets poorer as the Recording time becomes longer.

• This recorder cannot record CD-R or CD-

RW discs.

•DVD-R/RW and CD-R/RW discs recorded on a personal computer or a DVD or CD recorder may not play if the disc is damaged or dirty, or if there is dirt of condensation on the player’s lens.

• If you record a disc using a personal computer, even if it is recorded in a compatible format, there are cases in which it may not play because of the settings of the application software used to create the disc. (Check with the software publisher for more detailed information.)

• Discs recorded in Video mode on this DVD recorder cannot record additionally using other DVD recorders.

Copyprohibited

Making discs playable in other DVD player (Finalize)

After recording, you must finalize a disc in order to play on any other unit. (Refer to page 39.)

Playable

DVD recorder DVD player

Not Playable

After finalizing:

• Once DVD-R/RW (Video mode) is finalized, you cannot record additionally or edit.

•Even if DVD-RW (VR mode) is finalized, you can record additionally to or edit.

• When DVD-R/RW (Video mode) is finalized, title menu will be created automatically.

To play in other DVD players, finalize discs recorded on this DVD recorder with the following condition.

Disc type Mode

DVD-R

ver.2.0

DVD-RW

ver.1.1 ver.1.1 CPRM compatible

Video mode

Video mode VR mode

Getting started

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Français

Recording

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUS E

REC

MONITOR

REC

SPEED

REC/OTR

Formatting a disc

Settings for the recording format to a blank disc

Video

DVD-RW

When inserting a blank disc, the DVD recorder starts to initialize the blank disc. After that, you can record to the disc with the recording format selected in SETUP menu. You are allowed to set a specified time for chapter marks.

DVD-RW

Select “Recording” using K / L / { / B buttons, then press

ENTER button.

Recording menu will appear.

Setup > Recording

DVD-RW Recording Format

Auto Chapter

Timer Programming

Video mode

10 minutes

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Setup Menu

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Setup

Playback Setting

Select “DVD-RW Recording Format” using

K / L buttons,

then press ENTER button.

Option window will appear.

Setup > Recording

DVD-RW Recording Format

Auto Chapter

Timer Programming

Video mode DVD Player Compatibility mode. VR mode Editing possibility mode.

Video mode

VR mode

10 minutes

Video mode has been selected as the default.

Select “Video mode” or “VR mode” using

then press ENTER button.

The recording mode will be set.

K / L buttons,

2 3 4 5

Note

• The recording format setting is effective only for DVD-RW discs.You cannot change the recording format on a DVD-R disc. DVD-R discs will always be in Video mode.

•

You cannot mix two formats on one DVD-RW disc.When you load a disc once recorded before, the recording format cannot be changed even if you change it in SETUP menu.

• When inserting a blank DVD+R or DVD+RW disc, the error message ("Disc Error") will appear.This DVD recorder is not compatible with a DVD+R/RW disc.

• PLAYLIST will be created automatically when recording on DVD-RW in VR mode.

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

Select “Auto Chapter” using K / L buttons, then press

ENTER button.

Option window will appear.

Recording

Formatting a disc (cont’d)

Before you start Connections

Setup > Recording

DVD-RW Recording Format

Auto Chapter

Timer Programming

VR mode

OFF 5 minutes

10 minutes

10 minutes 15 minutes 30 minutes 60 minutes

“10 minutes” has been selected as the default.

Select a desired time option

K / L buttons, then

using press ENTER button.

Chapter marks will be put as you specified.

Press SETUP button to exit SETUP menu.

6 7

Getting started

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Note

• The time for chapter marks is not accurate in Video mode.

Français

Reformatting a disc

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUS E

REC

MONITOR

REC

SPEED

REC/OTR

Video

DVD-RW

If you are using a DVD-RW disc, by default it will be Video mode. Yo u can change this to VR mode from SETUP menu.

DVD-RW

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Setup Menu

Select “DISC” using { / B buttons, then press ENTER button.

DISC menu will appear.

Recording

Formatting a disc (cont’d)

Select “Yes” using { / B buttons, then press ENTER button.

Option window will appear.

Disc

Edit

Format

Finalize

Disc Protect OFF ON

Yes No

Are you sure?

Yes No

* VR mode only

Select “Yes” using { / B buttons, then press ENTER button.

Formatting will start.

2 3

4 5

Disc

Edit

Format

Finalize

Disc Protect OFF ON

* VR mode only

Select “Format” using K / L buttons, then press ENTER button.

Option window will appear.

* VR mode only

Disc

Edit

Format

Finalize

Disc Protect OFF ON

Yes No

Formatting

Formatting is complete.

100% will be indicated.

100%

Formatting

This operation may take a while to be completed.

58%

Note

• When you reformat the disc, the contents of the disc will be erased.

• If you want to cancel format at step 5, select "No".

Recording

Basic recording

Before you start Connections

DVD-R

Video

DVD-RW

Follow the steps below to record TV programs.

Turn on the DVD recorder and load a recordable disc.

Make sure that the TV input is set on the DVD recorder.

This operation may take a while to be recognized.

Select a recording speed using REC SPEED button.

SP 2:01 Rem.

Select a desired channel to record using CH

K / L but-

tons or number buttons.

CH 1

Press REC/OTR button to start recording.

REC mark will be displayed for 5 seconds.

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

REC

SPEED

PAUSE

ABC

TUV

SPACE

ZOOM

JKL

REC/OTR

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

OPEN/ CLOSE

DEF

MNO

WXYZ

SETUP

FWDREV

Getting started

Recording

5 4

Playing discs

Refer to “Recording speed” on page 28.

Make sure that the recording format is set to the desired mode.

Refer to “Formatting a disc” on pages 30-32.

When a DVD-RW disc is loaded:

You can choose Video mode or VR mode from SETUP menu. “Video mode” has been selected as the default. Refer to “Settings for the recording format to a blank disc” on pages 30-32.

When a DVD-R disc is loaded:

DVD-R discs will always be in Video mode.

To pause the recording, press PAUSE

F button. Press REC/OTR

button to restart the recording.

Press STOP C button to stop the recording.

This operation may take a while to be completed.

Note

• Recording starts immediately and continues until the disc becomes full or you stop recording.

•When the clock setting has not been made, the space for a date and time of title names in the original or playlist will be blank.

•

You cannot mix two formats on one DVD-RW disc. When you load a disc once recorded before, the recording format cannot be changed even if you change it in SETUP menu.

•You cannot change the recording speed during the REC pause mode.

•You can change a channel during the REC pause mode.

Editing

Changing the SETUP menu

Others Español

Français

Recording

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUS E

REC

MONITOR

REC

SPEED

REC/OTR

Basic recording (cont’d)

Checking the recording picture quality

DVD-R

Video

DVD-RW

You can confirm the recording picture quality with the recording speed you have selected before attempting to record to a DVD disc.

DVD-RW

Press REC MONITOR button again to exit.

While the DVD recorder is in STOP or REC with a DVD disc to record inserted, press REC MONITOR button.

The TV program will be on the screen in the recording picture quality with the recording speed you have selected.

CH 18

Rec Monitor

If you want to change the recording speed, press REC SPEED button repeatedly.

The recording speed will be changed as you press the button as shown. Refer to “Recording speed” on page 28.

•You cannot change the recording speed during recording.

XP SP LP

EPSLPSEP

Note

•You cannot check the recording sound with the Rec monitor function.

Recording

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

One-touch timer recording

Before you start Connections

DVD-R

Video

DVD-RW

This is a simple way to set the recording time in blocks of 30 minutes. Check that the disc you are recording onto has enough space for the time you set. When the recording finishes the recorder automatically goes into standby.

Turn on the DVD recorder and load a recordable disc.

Make sure that the TV input is set on the DVD recorder.

This operation may take a while to be recognized.

Select a recording speed using REC SPEED button.

Refer to "Recording speed" on page 28.

Make sure that the recording format is set to the desired mode.

Refer to "Formatting a disc" on pages 30-32.

When a DVD-RW disc is loaded:

You can choose Video mode or VR mode from SETUP menu. "Video mode" has been selected as the default. Refer to pages 3031 "Settings for the recording format to a blank disc."

When a DVD-R disc is loaded:

DVD-R discs will always be in Video mode.

Select a desired channel to

0:30

C button.

K / L but-

1:00

Note

• The remaining recording time will appear on the display panel during an OTR. Press DISPLAY button to see it on the TV screen.

•You cannot pause an OTR.

The DVD recorder will be turned off automatically under the conditions following.

• No space remained on the disc.

•When a power failure occurs.

Getting started

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Français

record using CH tons or number buttons.

Press REC/OTR button on the remote control or REC button on the front panel, then press REC/OTR or REC button repeatedly until a desired recording time (30 minutes to 4 hours) appears on the TV screen.

Recording will start.

0:30

(Normal Recording)

4:00 3:30

When the DVD recorder reaches the specified time, it will be turned off automatically.

To cancel the one-touch timer recording within the specified time, press STOP

This operation may take a while to be completed.

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUS E

REC

MONITOR

REC

SPEED

REC/OTR

DVD-R

Video

DVD-RW

You can program the unit to record up to 8 programs, up to a year in advance. Daily or weekly program recordings are also available.

• Be sure to set the clock before making a timer programming.

• Insert a recordable disc.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Recording

Timer recording

Select “Timer Programming”

K / L buttons, then

using press ENTER button.

Timer Programming list will appear.

Setup > Recording > Timer Programming

Date Start End CH Speed

- - -

Select the program which is not set up using

tons, then press ENTER button.

K / L but-

You can choose the timer programming menu by pressing VCR Plus+ button twice. In this case, continue with step 5.

2 3

Setup Menu

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Setup

Select “Recording” using K / L / { / B buttons, then press

ENTER button.

Recording menu will appear.

Playback Setting

Setup > Recording

DVD-RW Recording Format

Auto Chapter

Timer Programming

Video mode

10 minutes

Enter the date using K / L buttons, then press B button.

Setup > Recording > Timer Programming

Date Start End CH Speed

JAN / 01

- - -

- - : - -AM- - : - -AM CH8

e.g. January 1st

JAN/01

When pressing L button at the

current date, timer recording

Daily

MON-SAT

MON-FRI

SAT

FRI

SUN

DEC/31

mode will change as follows.

Enter the time to start and to end using then press

Setup > Recording > Timer Programming

Date Start End CH

2.3.- - -

- - -

K / L buttons,

B button.

- - : - -AM

CH810 :00PMJAN/12

Speed

5 6 7

Note

• If you have not set the clock yet:

A clock setting window will appear after step 4. Continue with the step 4 in “Auto Clock Setting” on page 23 or “Manual Clock Setting” on page 24 before making a timer programming.

•Press { or B buttons to move the cursor to the left and the right in the timer

programming menu.

Recording

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

REC

MONITOR

REC

SPEED

REC/OTR

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

Timer recording (cont’d)

Before you start Connections

Select the channel number to record using then press

K / L buttons,

B button.

Press ENTER button when all information required is entered.

Your program setting

will be stored.

Setup > Recording > Timer Programming

Date Start End CH Speed

2. - - -

CH810:30PM10:00PMJAN/12

To r ecord from external input, L1

•To set another program, repeat steps 5 to 10.

•To exit, press SETUP button.

or L2.

Select a recording speed

K / L buttons.

using

Setup > Recording > Timer Programming

Date Start End CH Speed

2. - - -

Refer to “Recording speed” on page 28.

Checking, canceling, or correcting the timer programming information

CH810:30PM10:00PMJAN/12

Press POWER button to turn off.

indicator will appear on

the front display.

Note

• After step 11, the DVD recorder will be turned on automatically 2 minutes in advance of the recording time to start and waits to start. Then the recording will start at the recording time you set.

Getting started

Recording

Playing discs

Press POWER button so that

indicator disappears from

the front display.

To clear the timer programming, select your desired program

K / L buttons.Then,

using CLEAR button.

Press VCR Plus+ button twice.

Timer Programming list will appear.

To correct the timer programming, select your desired program using

K / L buttons.Then,

press ENTER button.

Setup > Recording > Timer Programming

Date Start End CH Speed

2. - - -

Check the information on the list you will need.

Press STOP C button on the front panel of the main unit. STOP C button on the remote control is not effective.

To stop the timer recording in process

CH810:30PM10:00PMJAN/12

rect the timer programming by using

K/L/{/B buttons.

press Finally, press ENTER button again.

Press VCR Plus+ button to exit.

Press POWER button to return to the timer standby mode.

Next, cor-

1 6

2 5

Note

•Press VCR Plus+ button to check the timer programming in process. When the timer recording is proceeding, that program will be highlighted with red. In this case, you cannot select any

other program.

Editing

Changing the SETUP menu

Others Español

Français

Recording

Timer recording (cont’d)

Hints for timer recording

•

If there is a power failure or this unit has been unplugged for more than 30 seconds, the clock setting and all timer settings will be lost.

•

If a disc is not on the tray, the indicator flashes and timer recording cannot be performed. Please insert a recordable disc.

• When all the timer recording is completed, the indicator flashes.To play or eject the recorded disc, press POWER button first, and then press PLAY

During timer recording or timer standby ( indicator is on the front display), any operations on the unit will not be

• available.To make these operations available, cancel the timer recording or timer standby first ( indicator disappears).

• To cancel the timer standby mode, press POWER button.

• When the Start and the End time are the same, the length of the recording will be set for 24 hours.When the disc reaches at the end during the recording, the DVD recorder turns itself off.

• When the programmed Start and End time are earlier than the current time, the recording will be set on the same date in the next year.

• If your programmed Start time for DVD recording is within 2 minutes from the current time, the power will turn on for recording standby right after you turn the power off.

The priority of overlapped settings

This unit records the programs according to priority if the timer programmings are overlapped.The timer programming set previously has priority. A timer recording of lower priority will be canceled, start from the middle or stop on the way. Check the overlapped timer programmings and change the priority if necessary.

B or OPEN/CLOSE A button.

A programming set previously has priority

When the starting time is same:

A program set previously (PROG.A) has priority.

ex.1

PROG. A

PROG. B

Actual recording

When the recording time is partially overlapped:

PROG. A will start after PROG. B is complete to be recorded.

PROG. A

PROG. B Actual

recording

PROG. A PROG. B

The first 20-90 seconds will be cut off.

PROG. B PROG. A

The first 20-90 seconds will be cut off.

Note

• When the recording time of two programs are overlapped, or the End time of a program and the Start time of another is the same, the first 20-90 seconds of the subsequent program will be cut off.

Example: When the end time of the programming currently being recorded and the starting time of the one to be recorded sequentially are same:

PROG. A

PROG. B

Actual recording

When some programming have been made at the end time of the programming currently being recorded:

A program set previously (PROG. B) has priority.

ex. 2

PROG. A

PROG. B

PROG. C Actual

recording

When the recording time is entirely overlapped:

PROG. A will not be recorded.

PROG. A

PROG. B Actual

recording

PROG. A PROG. B

The first 20-90 seconds will be cut off.

PROG. B

PROG. BPROG. A

The first 20-90 seconds will be cut off.

Recording

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

Timer recording using VCR Plus+®system

Before you start Connections

DVD-R

Video

DVD-RW

The VCR Plus+ system lets you set timer recordings very simply. Just enter the PlusCode number listed in the TV program guide. The date, time, and channel for the TV program to record will set automatically. Before setting timer recording using VCR Plus+ system, read “Guide channel setting” on pages 20-21.

In stop mode, press VCR Plus+ button.

VCR Plus+ setting menu will appear.

Screen:

VCR Plus+

Please enter a Plus Code No.

- - - - - - - - -

Note:

When eight timer recordings have been scheduled, the Timer Programming list will appear instead.

Enter the PlusCode number correctly using number buttons.

VCR Plus+

Please enter a Plus Code No.

1 2 3 4 - - - - -

Press ENTER button.

The Timer Programming list will

appear.

When the Guide channel has not been assigned:

The CH area has been selected, then enter the channel number to record using

Setup

2. - - -

K / L buttons

> Recording > Timer Programming

Date Start End CH Speed

- - -

10:30PM10:00PMJAN/12

1 5

Getting started

Recording

When the Guide channel has been assigned:

The programming you made with VCR Plus+ system is hilighted to check.

Setup

> Recording > Timer Programming

Date Start End CH Speed

2. - - -

- - -

CH810:30PM10:00PMJAN/12

• If you want to change the setting, use

K / L / { / B but-

tons.

Note

•Press { button to erase the latest number entered incor-

Playing discs

Editing

Changing the SETUP menu

rectly at step 2.

Press ENTER button after you entered or confirm the information.

Your VCR Plus+ program setting will be stored.

•Press CLEAR button to erase all numbers entered incorrectly at step 2.

• If you enter an incorrect PlusCode number at step 2 or the programming is not

Others Español

available, the error message “Code Error!” will appear.

Press VCR Plus+ button to exit.

Enter the correct PlusCode number.

Remember:

If your cable box or satellite

Press POWER button to return to the timer standby mode.

box is connected as in “Connection B” on page 14, set your cable box or satellite box to the channel you want to record; leave your cable

Français

box or satellite box on for the timer recording.

Recording

Front of DVD recorder

Rear of DVD recorder

OUT

TV ANTENNA

COMPONENT VIDEO OUTPUT

PR/CR

PB/CB

VIDEO

OUTPUT

INPUT

AUDIO

DIGITAL AUDIO OUTPUT PCM / BITSTREAM

COAXIAL

O P T I C A L

S-VIDEO

VIDEO

(L1)

S-VIDEO

R L

POWER

S-VIDEO VIDEO

STOP REVPLAYFWD CHANNEL

OPEN/CLOSE

L - AUDIO - R

REC REC SPEED

S-VIDEO VIDEO L - AUDIO - R

To LINE 2 IN To LINE 1 IN

Audio cable

Another source (VCR camcorder etc.)

S-Video

cable

Video

cable

VIDEOS- VIDEO AUDIO

OUTPUT

Audio

cable

S-Video cable

Video cable

VIDEO S -VIDEOAUDIO

OUTPUT

INPUT

AUDIO VIDEO

(L1)

S-VIDEO

Settings for an external source

Connection to an external source

DVD-R

Video

DVD-RW

Connect the external source properly to the DVD recorder by using input jacks either LINE2 (Front) or LINE1 (Rear). Use commercially available S-Video or Video cable and an Audio cable for this connection.

DVD-RW

1. Press SETUP button to display SETUP/DISC

menu.

2. Select “SETUP” using { / B buttons, then press ENTER button.

3. Select “Select Video” using K / L / { / B but-

, then press ENTER button.

tons

Setup > Select Video

L1 (Rear)

L2 (Front)

Select “L2 (Front)”

using K / L buttons

Video In

, then

press ENTER button.

Setup > Select Video

L1 (Rear)

L2 (Front)

5. Select the input jack type to connect using

Video In

Video In S-Video In

Video In

K / L buttons, then press ENTER button.

If you want to use S-VIDEO input, select “S-Video In”. If you want to use VIDEO input (Composite), select “Video In”.

1. Press SETUP button to display SETUP/DISC menu.

2. Select “SETUP” using { / B buttons, then press ENTER button.

3. Select “Select Video” using K / L / { / B but-

, then press ENTER button.

tons

Setup > Select Video

L1 (Rear)

L2 (Front)

Select “L1 (Rear)”

using K / L buttons

Video In

, then

press ENTER button.

Setup > Select Video

L1 (Rear)

L2 (Front)

5. Select the input jack type to connect using

Video In

Video In S-Video In

Video In

K / L buttons, then press ENTER button.

If you want to use S-VIDEO INPUT, select “S-Video In”. If you want to use VIDEO INPUT (Composite), select “Video In”.

Setup > Select Video

L1 (Rear)

L2 (Front)

Video In

S-Video In

Setup > Select Video

L1 (Rear)

L2 (Front)

S-Video In

Video In

Recording

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

Settings for an external source (cont’d)

Recording from an external source

DVD-R

Video

DVD-RW

Before recording from an external source, see the instructions for the connection on page 40.

1. Turn the TV and the DVD recorder on, and be sure to select the input of the TV to which the DVD recorder is connected.

DVD-RW

Before you start Connections

2.Press OPEN/CLOSE A button to open the disc tray, then

place the disc to record properly.

This operation may take a while to be recognized.

3. Select the input of the DVD recorder which the external equipment is connected. (L2 or L1)

• To use the input jacks on the back of this unit, select “L1” position by pressing [0], [0], [1] on the remote control or the CH L / K buttons.

• To use the input jacks on the front of this unit, select “L2” position by pressing [0], [0], [2] on the remote control or the CH

L / K buttons.

4. Select a recording speed using REC SPEED button. Refer to

“Recording speed” on page 28.

XP SP LP

EPSLPSEP

5.Press REC button on the DVD recorder to start recording.

6.Press Play button on the external source to record from.

7.Press STOP C button on the DVD recorder to stop record-

ing.

This operation may take a while to be completed.

5 3

Getting started

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Français

Recording

SPACECLEAR

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUS E

REC

MONITOR

REC

SPEED

REC/OTR

Finalizing the discs

DVD-R

Video

DVD-RW

You will need to finalize discs recorded in Video mode to play in other DVD players. Finalizing may take several minutes up to an hour. (A disc recorded in Video mode can take up to15 minutes.A disc recorded in VR mode can take up to 60 minutes.) A shorter recording period on the disc will require a longer time period for finalization. Do not unplug the power cord during finalization. Details are on pages 28-29.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Setup Menu

Select “DISC” using { / B buttons, then press ENTER button.

DISC menu will appear.

Disc

Edit

Format

Finalize

Disc Protect OFF ON

* VR mode only

Select “Finalize” using K / L buttons, then press ENTER button.

Option window will appear.

* VR mode only

Disc

Edit

Format

Finalize

Disc Protect OFF ON

Yes No

Select “Yes” using { / B buttons, then press ENTER button.

Finalizing will start.

2 3

Finalizing

58%

To cancel finalizing, press STOP button.

Do you want to cancel?

Yes No

Finalizing

58%

Select “Yes” using { / B buttons, then press ENTER button.

Finalizing is cancelled, then the DVD recorder will be in stop mode.

Finalizing is complete.

Finalizing

This operation may take a while to be completed.

100%

Note

•

Finalizing discs in Video mode automatically creates title menus.

• Once you have finalized a disc recorded in Video mode, you cannot edit or record anything else on that disc. Discs recorded in VR mode can still be recorded and edited on this recorder even after finalized.

• When you insert a DVD-RW disc finalized with this DVD recorder, “Undo Finalize” will appear instead of “Finalize”.

Disc

Edit

Format

Undo Finalize

To r elease the finalizing for the disc, select “Undo Finalize” at step 3.

• If appear when pressing STOP button at step 4, you cannot cancel finalizing because the finalizing has been in certain progress.

•When selecting “No” at step 4 and press ENTER or RETURN button, finalizing will be continued.

•You cannot cancel finalizing the DVD-R disc once it has started.

* DO NOT power off during

finalizing, this will result in malfunction.

Disc

Edit

Format

Finalize

Disc Protect ON OFF

Yes No

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

DVD-RW

To prevent accidental recording, editing or erasing the titles, you can protect them from DISC menu.

Recording

Setting a disc to protect

Select “Disc Protect OFF ➔ ON” using K / L buttons,

then press ENTER button.

Option window will appear.

Before you start Connections

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Setup Menu

Select “DISC” using { / B buttons, then press ENTER button.

DISC menu will appear.

Disc

Edit

Format

Finalize

Disc Protect OFF ON

Disc

Edit

Format

Finalize

Disc Protect OFF ON

Yes No

Select “Yes” using { / B buttons, then press ENTER button.

A disc will be protected.

Writing to Disc

This operation may take a while to be completed.

58%

2 3 4

Note

• The Disc Protect setting is available only when a disc with VR mode is inserted.

•You can select only Disc Protect Menu when a protected disc is inserted.

To cancel the disc protect:

• When you insert a disc protected with this unit,“Disc Protect ON → OFF” will appear instead of “OFF → ON”.

Getting started

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

To r elease the protect for the disc, select “Disc Protect ON → OFF” at step 3, then select

Français

“Yes”.

Playing discs

Start Rec. Stop/Start Stop Rec.

Title 1 Title 2

Chapter 1 Chapter 1Chapter 2 Chapter 3 Chapter 2

Information on DVD play

Before you attempt to play DVD discs, read the following information.

Playable discs

This DVD recorder is compatible to play the following discs. To play a DVD, make sure that it meets the requirements for Region Codes and Color Systems as described below. Discs that have the following logos will play on the DVD recorder. Other Disc types are not guaranteed to play.

LogoDisc

DVD VIDEO

DVD-RW (VIDEO/VR mode)

DVD-R (VIDEO mode)

CD-DA (AUDIO CD)

Region codes

This DVD recorder has been designed to play DVD discs with Region One ( for ALL regions or for Region 1 in order to play on the DVD recorder.You cannot play DVDs that are labeled for other regions. Look for the symbols below on your DVDs. If these region symbols do not appear on your DVD, you cannot play the DVD in this DVD recorder.

The number inside the globe refers to region of the world. Region Canada, Bermuda, the U.S.Virgin Islands and small regions near Australia. A DVD labeled for a specific region can only play on the DVD recorder with the same region code.

1). DVDs must be labeled

1 represents the United States,

CD-R (CD-DA FORMAT, MP3 files)

CD-RW (CD-DA FORMAT, MP3 files)

Color systems

DVDs are recorded in different color systems throughout the world.The most common color systems are NTSC (which is used primarily in the United States and Canada), PAL and SECAM. This DVD Recorder uses NTSC, so DVDs you play must be recorded in the NTSC system.You cannot play DVDs recorded in other color system .

Guide to displays

Press DISPLAY button to call up the display menu.This menu will give you the information on the playing disc. Some operations are available while disc is playing.

11 00:00:00

DVD-RW

Video mode

SP 1:25 Rem.

Hint for DVD playback

The contents of DVD disc are generally divided into titles.Titles may be further subdivided into chapters.

1. Indicates a disc type and a

format mode.

2. Indicates a recording speed

and possible recording time left. / Indicates a channel number.

3. Indicates a title number, chap-

ter number and the time elapsed of disc play.

4. Each icon means:

: Search

: Audio

: Subtitle

: Angle (except VR mode)

: Repeat

: Marker

: Noise Reduction

: Zoom

: Spatializer

CH9612:24AMJAN/1

Title Menu

Playback

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

Playing discs

Basic playback

Before you start Connections

DVD-R

Video

DVD-RW

Press POWER button on the remote control or the front panel of the DVD recorder.

When you are playing a DVD, turn the TV on and be sure to select the input to which the DVD recorder is connected.

Press OPEN/CLOSE A button to open the disc tray.

The disc tray will open.

Place the disc onto the disc tray with its label facing up and make sure to align the disc to the disc tray guide.

VR mode:

Original

1 1 32

JAN/1 12:00AM

JAN/1 3:00AM

JAN/1 1:00AM JAN/1 2:00AM

JAN/1 4:00AM

MENU / LIST button

Playlist

1 1 32

JAN/1 12:00AM

JAN/1 3:00AM

JAN/1 1:00AM JAN/1 2:00AM

JAN/1 4:00AM

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Playing will start.

2 6

Getting started

Recording

Playing discs

Editing

This operation may take a while to be recognized.

Press TOP MENU button to display the title menu.

You can change “Original” or “Playlist” of VR mode using MENU / LIST button.

Video mode:

Title List

JAN/1 12:00AM

JAN/1 3:00AM

1 1 32

JAN/1 1:00AM JAN/1 2:00AM

JAN/1 4:00AM

disc tray guide

Press STOP C button to stop play.

To e j ect the disc, press OPEN/CLOSE

the disc tray, then remove the disc before turning off the DVD recorder.

A button to open

Note

•For DVD-R (Video mode) and DVD-RW (Video mode) discs which are already finalized, a title list will be displayed instead of thumbnails.

•You can resume play from where you stopped playing the disc. (Resume play) Refer to page 49 for details about resume play.

• Some discs may start playing automatically.

Changing the SETUP menu

Others Español

Français

Playing discs

MP3

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

Basic playback (cont’d)

DVD-V

MP3

Press POWER button on the remote control or the front panel of the DVD recorder.

When you are playing a DVD, turn the TV on and be sure to select the input to which the DVD recorder is connected.

Press OPEN/CLOSE A button to open the disc tray.

The disc tray will open.

For MP3 playback

Place the disc onto the disc tray with its label facing up and make sure to align the disc to the disc tray guide.

Press PLAY B button to start playing.

Playing will start.

If you are playing a DVD-Video disc, a menu may appear. Refer to pages 47-48 for details about a disc menu.

Press STOP C button to stop playing.

OPEN/

DEF

ABC

MNO

JKL

GHI

WXYZ

TUV

SPACE

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

REC

REC/OTR

SPEED

FWDREV

PAUS E

POWER

VCR Plus

RETURN

MONITOR

.@/:

PQRS

CLEAR

REC

SKIP

STOP PLAY

Note

• Some discs may start playing automatically.

In stop mode, press TOP MENU button to call up the MP3 menu.

List of MP3 Files

DISC NAME

FOLDER NAME 1 FOLDER NAME 2 FOLDER NAME 3 FOLDER NAME 4 FOLDER NAME 5 FOLDER NAME 6 1 FILE NAME 1 2 FILE NAME 2

1/2

•To exit the menu, press TOP MENU button again.

Press KK/ LLbuttons to select a desired folder (group) or track, then press ENTER button.

When selecting track:

Playback will start.

When selecting the folder:

The files in folder will appear. Press K / L buttons to select the track you want, then press button.

ENTER

•When selecting a folder, press

PLAY B, ENTER or B button to go to the lower hierarchy.

•Press s button or RETURN button to the previous hierarchy.

•Press STOP button to return to the first to the first item.

Hints for MP3 files:

•Folders are known as Groups, files are known as Tracks.

•

Folders are accompanied by icon.

•

MP3 files are accompanied by icon. Reproduction will start from the selected track and go to the next one in turn.

•

The system can recognize up to 255 groups (or folders) and up to 255 tracks.

•

The name of group and track can be displayed in up to 32 characters. Unrecognizable characters will be replaced with asterisks.

• If there are no files in the folder, “No Files” will be displayed.

This unit recommends the files recorded under the following circumstances:

•

Sampling frequency: 44.1kHz or 48kHz.

•

Constant bit rate: 112kbps - 320kbps.

Note

• The audio source of MP3 files cannot be recorded as digital sound by an MD or DAT deck.

• Files whose extension is other than “.mp3(MP3)” will not be listed in the MP3 menu.

• Some unplayable folders or tracks may be listed in the MP3 menu due to the recording status.

Playing discs

Basic playback (cont’d)

Playing discs using the disc menu

DVD-V

A DVD disc contains a disc menu that describes the contents or allows you to customize the playback. For example, the menu may offer choices for subtitle languages, special features, or chapter selection. Sometimes these are displayed automatically when you start playback, otherwise only appear when you press MENU/LIST button.

Press MENU/LIST button.

The DVD main menu will appear.

If the feature is not available, may appear on the TV screen.

Select an item using K / L / { / B buttons, then press

ENTER button to confirm.

Continue this step to set up all the features you want or to start playing the disc from the menu.

MENU/LIST button:

Displays a DVD disc menu which varies with the disc and may be the same as the ‘Title menu.’

K / L / { / B buttons:

Moves the cursor around screen.

Enter button:

Selects the currently highlighted menu option.

1 2

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

REC

SPEED

PAUSE

ABC

TUV

SPACE

ZOOM

JKL

REC/OTR

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

OPEN/ CLOSE

DEF

MNO

WXYZ

SETUP

FWDREV

Before you start Connections

Getting started

Recording

Playing discs

Number buttons:

Selects a numbered menu option (some discs only). (Press ENTER button after.)

Press MENU/LIST button to exit the menu.

Editing

Changing the SETUP menu

Others Español

Note

• Menus vary among discs. Refer to the information accompanying the disc for details.

Français

Playing discs

Basic playback (cont’d)

Playing discs using the title menu

DVD-V

Some DVDs have a title menu, which lists the titles available on them. It helps you to start play at a specific title.

Press TOP MENU button.

The title menu will appear.

If the feature is not available, may appear on the TV screen.

Select a title to play using the K / L / { / B buttons, then

press ENTER button.

Play will begin at the title you selected.

TOP MENU button:

Displays the ‘Title menu’ of a DVD disc which varies with the disc.

K / L / { / B buttons:

Moves the cursor around screen.

Enter button:

Selects the currently highlighted menu option.

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

SPEED

PAUS E

OPEN/

ABC

DEF

JKL

TUV

SPACE

ZOOM

MNO

WXYZ

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

1 2

SETUP

REC

REC/OTR

FWDREV

Number buttons:

Selects a numbered menu option (some discs only). (Press ENTER button after.)

Press TOP MENU button to exit the title menu.

Note

• The TOP MENU button will not always be active with all DVDs.

• Menus vary among discs. Refer to the information accompanying the disc for details.

Resume play

MP3

SPACECLEAR

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

DVD-V

DVD-RW

DVD-R

You can resume play from where you stopped playing the disc last.

Video

DVD-RW

MP3

During play, press STOP C button.

The resume message will appear.

Screen:

Resume ON

Playing discs

Special playback

Press PLAY B button.

In a few seconds, play will resume from the point at which it stopped last.You can resume play at the same point even if you turn off the DVD recorder.

To cancel the resume play and start playing the disc from the beginning, press STOP the second time while the play is stopped.

C button

1 2

Note

•For MP3 files, playback will resume from the beginning of the track at which playback was stopped.

Before you start Connections

Getting started

Recording

Playing discs

Fast forward / Fast reverse

DVD-V

DVD-R

Video

DVD-RW

MP3

During play, press FWD D or REV E button.

Every time you press FWD D or REV E button, approximate speed will be changed as follows. (For DVD discs, the sound will be output during playback in fast forward of x2 only if you set “Fast Forward with Audio” to “ON” for the “Playback” setting in the SETUP menu.)

FWD

REV

For Audio CDs, approximate speed is fixed at x8 with sound. For MP3 files, approximate speed is fixed at x16. To r eturn to the normal play, press PLAY

x20

FWD

REV

FWD

REV

Normal

speed

playback

FWD

REV

FWD

REV

x2 x20x5 x40x40

B button.

Editing

Changing the SETUP menu

FWD

REV

Others Español

Note

•Forward/reverse speed will be indicated with icons as follows. Forward (Approx. Speed) x2: x20: x40: Reverse (Approx. Speed) x5: x20: x40:

Français

Playing discs

MP3

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUS E

REC

MONITOR

REC

SPEED

REC/OTR

Special playback (cont’d)

Skipping TV commercials during play

DVD-R

Video

DVD-RW

You can skip TV commercials by pressing CM SKIP button, so that you can enjoy the recorded programs without interrupting.

During play, press CM SKIP button.

Normal play will start at 30 seconds ahead from the point you press CM SKIP button. Every time you press CM SKIP button, the searching point will be extended by 30 seconds ahead. You can press up to 6 times ( seconds).

DVD-RW

180

e.g. Press CM SKIP button once

CM Skip 30 sec.

(forwarding 30 seconds.)

Playback will restart automatically.

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

SPEED

PAUS E

OPEN/

ABC

DEF

JKL

MNO

TUV

WXYZ

SPACE

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

REC

REC/OTR

FWDREV

Pause

DVD-V

DVD-RW

DVD-R

DVD-RW

MP3

During play, press PAUSE F button.

Play will pause and sound will be muted.

Video

Press PLAY B button to resume play.

Step by step playback

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

DVD-V

DVD-RW

DVD-R

Video

DVD-RW

During play, press PAUSE F button.

Play will pause and sound will be muted.

Playing discs

Special playback (cont’d)

Press SKIP G button repeatedly.

The play will advance one frame (or step) at a time when you press the SKIP button with the sound muted.

VCR Plus

Before you start Connections

ABC

TUV

SPACE

ZOOM

DEF

JKL

MNO

WXYZ

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

.@/:

GHI

PQRS

CLEAR

Getting started

To play step by step backward:

Press SKIP H button repeatedly. Every time you press the button, the play will go backward by one frame.

Press PLAY B button to resume play.

Slow forward / Slow reverse play

DVD-V

DVD-R

Video

DVD-RW

During play, press PAUSE k button, then press FWD D or

E button.

REV

Every time you press FWD D or REV E button, approximate speed will be changed as follows. (The sound will remain mute.)

FWD

REV

To r eturn to the normal play, press PLAY

FWD

REV

x1/8

FWD

REV

Pause

FWD

REV

FWD

REV

x1/16 x1/8x1/16 x1/2x1/4

FWD

REV

B button.

1 1

RETURN

REC

MONITOR

SKIP

REC

SPEED

STOP PLAY

PAUSE

REC/OTR

SETUP

FWDREV

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Note

•Forward/reverse speed will be indicated with icons as follows. Forward (Approx. Speed) x1/16: x1/8: x1/2: Reverse (Approx. Speed) x1/16: x1/8: x1/4:

Français

Zoom

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUS E

REC

MONITOR

REC

SPEED

REC/OTR

DVD-V

DVD-RW

DVD-R

Video

DVD-RW

During play, press ZOOM button.

Zoom menu will appear.

Screen:

01:23:45

x1.2 x1.5 x2.0

There are four options (x1.0,x1.2,x1.5 and x2.0), these are displayed excluding the current zoom rate.

DVD-Video

Playing discs

Special playback (cont’d)

Select a desired zoom factor to zoom using { / B buttons, then press ENTER button.

The zoom area will be displayed.

Select a desired zoom position

K / L / { / B buttons, then

using press ENTER button.

The zoom play will start.

Note

•When selecting a smaller factor than the current one, the zoom area will not be displayed.

•To remove the zoom menu, press ZOOM button again at step 1.

•To cancel the zoom function, select x1.0 using { / B buttons,

then press ENTER button.

Spatializer setting (Virtual surround)

DVD-V

DVD-RW

DVD-R

Video

DVD-RW

During playback, press DISPLAY button.

The display menu will appear.

Select icon using { / B buttons, then press ENTER button.

Spatializer menu will appear.

Screen:

1101:23:45

DVD-Video

Select a desired option using K / L buttons, then press

ENTER button.

Your setting will be activated. ON: Outputs the virtual surround

OFF: Outputs the original sound.

1100:00:00

sound.

ON OFF

DVD-Video

2 3

Note

• This feature is not available for some discs.

•Select “OFF” at step 3 if the sound is distorted.

Marker Setup

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

DVD-V

DVD-RW

DVD-R

This feature allows you to assign a specific point on a disc to be called back later.

Video

DVD-RW

Playing discs

Special playback (cont’d)

Select a desired marker number using

When it reaches the desired point, press ENTER button.

{ / B buttons.

Before you start Connections

During play, press DISPLAY button.

The display menu will appear.

Screen:

1101:23:45

Select icon using { / B buttons, then press ENTER button.

Marker setup menu will appear.

Screen for DVD:

1101:23:45

1 2 3 4 5 6

Screen for CD:

1 01:23:45

1 2 3 4 5 6

DVD-Video

Audio CD

To r eturn to the marker later, select the desired marker number using then press ENTER button.

{ / B buttons,

2 3 4

Note

•To clear a marker, select the marker number to be cleared, then press CLEAR button.

• All markers will be erased when you operate these operations listed below. – Opening the disc tray. – Turning off the power. – Recording to a recordable

disc.

–

Changing the mode between Original and Playlist. (VR mode)

•You can mark up to 6 points.

Getting started

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Français

Title/Chapter search

DVD-V

DVD-RW

DVD-R

Video

DVD-RW

Using SKIP H / G buttons

During play, press SKIP G button to skip the current title or chapter and move to the next.

The title or chapter will move forward by one at a time.

To go back to the previous title or chapter, press SKIP

ton.The title or chapter will move backward one title at a time.

H but-

Playing discs

Using DISPLAY button

During play, press DISPLAY button.

The display menu will appear.

Screen:

1101:23:45

DVD-Video

Select icon using { / B buttons, then press ENTER button.

‘T’ for title will be highlighted.

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

SPEED

PAUS E

OPEN/

ABC

DEF

JKL

MNO

TUV

WXYZ

SPACE

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

REC

REC/OTR

FWDREV

Title: Enter a desired title number to search using

K / L buttons or number buttons, then press ENTER button.

Title search will start.

Chapter:

To move to ‘C’ for chapter, press B button.

Enter a desired chapter number to search using

K / L buttons or number buttons, then press ENTER button.

Chapter search will start.

Track search

MP3

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

MP3

Using SKIP H / G buttons

Playing discs

Search (cont’d)

Using DISPLAY button

Before you start Connections

During play, press SKIP G button to skip the current track and move to the next.

The track will move forward one at a time.

To go back to the previous track, press SKIP

will move backward one at a time.

H button.The track

During play, press DISPLAY button.

The display menu will appear.

Screen:

1 01:23:45

Audio CD

Select icon using { / B buttons, then press ENTER button.

‘T’ for track will be highlighted.

Enter a desired track number to search using

or number buttons, then press ENTER button.

Track search will start.

K / L buttons

Getting started

Recording

Playing discs

Editing

DVD-V

DVD-RW

DVD-R

Time search

During play, press DISPLAY button.

The display menu will appear.

Screen for DVD:

1101:23:45

Screen for CD:

1 01:23:45

Video

DVD-RW

DVD-Video

Audio CD

Select icon using { / B buttons, then press ENTER button.

‘T’ for title or track will be highlighted. To move to the clock icon, press B button.

Enter a desired time to search using

number buttons, then press ENTER button.

Time search will start.

K / L buttons or

2 3

Note

• Time search function is available only in the same track or title.

Changing the SETUP menu

Others Español

Français

Repeat/Random/Program playback

MP3

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

Repeat play

DVD-V

DVD-RW

DVD-R

Video

DVD-RW

MP3

During play, press REPEAT button.

Repeat menu will appear.

Screen:

Playing discs

Chapter:

The current chapter will be played repeatedly. (DVD only)

All:

The current disc will be played repeatedly. (CD, MP3, DVD-RW (VR mode) only)

POWER

VCR Plus

OPEN/

.@/:

PQRS

CLEAR

DEF

ABC

MNO

JKL

GHI

WXYZ

TUV

SPACE

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

1101:23:45

OFF Title Chapter A-B

DVD-Video

Select a desired option to repeat using

K / L buttons,

then press ENTER button.

The selected repeat play will start.

Title:

The current title will be played repeatedly. (DVD only)

Random playback

MP3

With this function, you can play a disc randomly instead of playing in the original order.

Press SETUP button to display SETUP/CD menu.

SETUP/CD menu will appear.

Screen:

Setup Menu

A-B:

The A-B point will be played repeatedly. When pressing ENTER button while A-B is highlighted, the starting point (A) will be decided.

Press ENTER button again to select the ending point (B).

Track:

The current track will be played repeatedly. (CD, MP3 only)

Group:

The current group will be played repeatedly. (MP3 only)

Select “CD” using { / B but- tons, then press ENTER button.

CD Playback Mode menu will appear.

CD Playback Mode

Random Play

Program Play

Select “Random Play” using K / L buttons, then press

ENTER button.

Random play will start.

REC

SPEED

SETUP

REC/OTR

RETURN

REC

MONITOR

SKIP

Note

• The A-B Repeat playback can only be set with in the current title (for DVDs), or current track (for Audio CDs).

•To cancel the repeat playback, select OFF at step 2.

•You cannot select “Group” during the random playback of MP3 files.

2 3

Note

•To cancel random play, press STOP C button twice during

random play.

Repeat/Random/Program playback (cont’d)

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

Program play

You can program the disc to play in your desired order.

Press SETUP button to display SETUP/CD menu.

SETUP/CD menu will appear.

Screen:

Playing discs

Select “Program Play” using K / L buttons, then press

ENTER button.

Program play list will appear.

CD Playback Mode > Program Play

- - - - - - - - - - - - - - - - - - - -

Tot a l 00:00:00

3 4

Before you start Connections

Getting started

Recording

Setup Menu

Select “CD” using { / B but- tons, then press ENTER button.

CD Playback Mode menu will appear.

CD Playback Mode

Random Play

Program Play

Select a desired track using K / L buttons, then press ENTER button or

B button.

A cursor will move to next.

CD Playback Mode > Program Play

- - - - - - - - - - - - - -- -- -

- -

- - - - - - - - - - - - - -- -- -

- -

- - - - - - - - - - - - - -- -- -

- -

- - - - - - - - - - - - - -- -- -

- -

Tot a l 00:04:30

Press PLAY B button to start program play.

Program play will start.

Note

•To erase tracks you selected, press CLEAR button.

•You can make program settings up to 50.

•To cancel program play, press STOP C button twice during program play.

•You may also select a desired track using Number buttons at step 4.

Playing discs

Editing

Changing the SETUP menu

Others Español

Français

Playing discs

Selecting the format of audio and video

You can select an audio or video format as you prefer depending on the contents of the disc you are playing.

Switching audio soundtrack

DVD-V

When playing a DVD-Video disc recorded with two or more soundtracks (these are often in different languages), you can switch them during play. On DVD-RW discs recorded in VR mode, you can switch to main (L), sub audio (R) or a mix of both (L/R).

DVD-RW

<DVD-RW VR mode>

1100:00:00

1Dolby Digital Dual L/R 2Dolby Digital 2ch ----

DVD-RW VR Original

POWER

VCR Plus

OPEN/

ABC

.@/:

PQRS

CLEAR

DEF

JKL

MNO

GHI

TUV

WXYZ

SPACE

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

During play, press DISPLAY button.

The display menu will appear.

Screen:

1101:23:45

DVD-Video

Select icon using { / B buttons, then press ENTER button.

Audio menu will appear.

<DVD-Video>

1100:00:00

1Dolby Digital 5.1ch English 2Dolby Digital 2ch Japanese

DVD-Video

Select a desired audio soundtrack using

K / L buttons,

then press ENTER button.

<DVD-Video> Audio soundtrack will switch.

<DVD-RW VR mode>

L/R L R

DVD-RW VR Original

1100:00:00

1Dolby Digital Dual 2Dolby Digital 2ch

Audio channel menu will appear. Follow the step 4.

Select a desired audio channel using

press ENTER button.

Audio channel will switch.

K / L buttons, then

REC

SPEED

STOP PLAY

PAUS E

SETUP

REC/OTR

FWDREV

3 4

RETURN

REC

MONITOR

SKIP

Note

•

Some discs will only allow you to change the soundtrack from the disc’s menu. Press TOP MENU button or MENU / LIST button to display the disc’s menu.

•

On DVD-RW discs recorded in VR mode that may have both a main and a sub audio channel, you can switch to main (L), sub audio (R) or a mix of both (L/R).

•

This unit CANNOT record in both stereo and SAP (Secondary Audio Program) at the same time.

Selecting the format of audio and video (cont’d)

MP3

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

REC

MONITOR

REC

SPEED

REC/OTR

MP3

When playing Audio CDs or MP3 files you can switch between stereo, just the left channel or just the right channel.

During play, press DISPLAY button.

The display menu will appear.

Screen:

1 00:00:00

Audio CD

Playing discs

Select icon using { / B buttons, then press ENTER button.

Audio menu will appear.

Select a desired audio channel using

press ENTER button.

Audio channel will switch.

K / L buttons, then

1 00:00:00

L/R L R

Audio CD

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

REC

SPEED

PAUSE

ABC

TUV

SPACE

ZOOM

JKL

REC/OTR

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

OPEN/ CLOSE

DEF

MNO

WXYZ

SETUP

FWDREV

Before you start Connections

Getting started

Recording

Playing discs

Switching subtitles

DVD-V

Many DVD Video discs have subtitles in one or more languages – the case usually tells you which subtitle languages are available. You can switch subtitle languages anytime during playback.

DVD-RW

During play, press DISPLAY button.

The display menu will appear.

Screen:

1101:23:45

DVD-Video

Select icon using { / B buttons, then press ENTER button.

Subtitle menu will appear.

1100:00:00

OFF 1English 2Japanese

DVD-Video

Select a desired subtitle language using

then press ENTER button.

Subtitle will be displayed in the selected language.

When selecting “OFF,” subtitle will disappear.

K / L buttons,

2 3

Note

• Some discs will only allow you to change the subtitle from the disc menu. Press TOP MENU button or MENU / LIST button to display the disc menu.

Editing

Changing the SETUP menu

Others Español

Français

Selecting the format of audio and video (cont’d)

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUS E

REC

MONITOR

REC

SPEED

REC/OTR

Switching camera angles

DVD-V

Some DVD Video discs feature scenes shot from two or more angles, check the case for details: it should be marked with a angle icon if it contains multi-angle scenes.

During play, press DISPLAY button.

The display menu will appear.

Screen:

1101:23:45

DVD-Video

Playing discs

Select icon using { / B buttons, then press ENTER button.

Angle will switch each time you press ENTER button.

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

SPEED

PAUS E

OPEN/

ABC

DEF

JKL

MNO

TUV

WXYZ

SPACE

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

REC

REC/OTR

FWDREV

Angle icon appears when a switching camera angle is available.

Reducing block noise

DVD-V

DVD-RW

DVD-R

DVD-RW

During play, press DISPLAY

Screen:

1101:23:45

DVD-Video

button.

The display menu will appear.

Select icon using { / B buttons, then press ENTER button.

NR menu will appear.

Video

OFF Type 1 Type 2

DVD-Video

1100:00:00

Select a desired option using K / L buttons, then press

ENTER button.

Your setting will be activated.

This function reduces noise in the playback picture.When playing back discs recorded in long time mode such as SLP or SEP mode, select "Type 1" or "Type 2". ("Type 2" is more effective.) When playing back discs with a few noises such as DVD-Video discs, select "OFF".

2 3

Editing

Information on disc editing

Before you start Connections

Guide to a title list

Title list allows you to check the titles recorded on the disc easily.You can choose a title to edit from this screen and easily edit the titles as you prefer.

Disc > Edit > Original

1 1 32

JAN/1 1:00AM

JAN/1

4:00AM

Disc > Edit > Original

JAN/1 1:00AM CH12 XP

JAN/1 2:00AM JAN/1 3:00AM

JAN/1

5:00AM

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

JAN/1 6:00AM

0:01:25

Editing discs with Video mode

You can edit discs with Video mode for the following items. Be sure that once you edit titles, they will not remain as original.

• Deleting titles (Refer to page 63)

• Putting names on titles (Refer to pages 64-65)

• Setting or clearing chapter markers (Refer to page 66)

Note

•

Once a disc is finalized, editing the disc or recording to the disc will not be available. (Except DVD-RW discs in VR mode.)

•

A playlist is not available with the DVD-R discs

and DVD-RW discs in Video mode.

Getting started

Recording

Playing discs

6 5

1. Titles recorded on the disc can be selected to

edit by pressing ENTER button with the cursor on the title.

2. Protect icon, which appears when the title has

been protected.

3. The arrow icon, which means the title list

includes a next or a previous page. Press B or { button by following direction of the icon.

4. The menus in here for editing titles as you pre-

fer. The available menus depends on the disc type and the format type.

5. The details of the title, which can be changed to

the title name you will edit.

6. Time status bar of the title.

7. The selected title thumbnails from the title list.

8. Playback status of the current disc.

Editing

Changing the SETUP menu

Others Español

Français

Editing

Information on disc editing (cont’d)

Editing discs with VR mode

For discs with VR mode, you can edit from “Original” menu or “Playlist” menu, which is created from the original.

Editing original titles

The following items can be used to edit the original titles.

•Deleting titles (Refer to page 67)

• Deleting parts of titles (Refer to pages 68-69)

• Putting names on titles (Refer to pages 69-70)

• Setting or clearing chapter markers (Refer to pages 71-72)

• Setting pictures for thumbnails (Refer to pages 72-73)

• Setting titles to protect (Refer to page 74)

•Releasing titles from protecting (Refer to page 75)

Editing playlists

You can create a playlist from original titles, so that you can edit as you prefer without losing original titles. The following items you can edit with a playlist.

•Deleting titles (Refer to page 76)

• Deleting parts of titles (Refer to pages 77-78)

•Putting names on titles (Refer to pages 78-79)

• Setting or clearing chapter markers (Refer to pages 80-81)

• Setting pictures for thumbnails (Refer to pages 81-82)

•Adding titles to a playlist (Refer to page 83)

•Deleting a playlist (Refer to page 84)

Note

•

Original titles once edited will not remain as recorded originally.When you want to leave the original as

it is, edit the playlist as you prefer. (Refer to pages 76-84)

Editing DVD-RW discs in Video mode

Deleting titles

Video

DVD-RW

You can delete titles which you do not need anymore. Be advised that the titles once deleted cannot be brought back to the disc. When the last title in the title list in Video mode is deleted, the disc space to record will be increased.

Editing

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Edit menu will appear.

Disc > Edit

Title Delete

Edit Title Name Chapter Mark

POWER

VCR Plus

Before you start Connections

OPEN/ CLOSE

ABC

TUV

SPACE

ZOOM

DEF

JKL

MNO

WXYZ

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

Getting started

.@/:

GHI

PQRS

CLEAR

Press SETUP button. Select “DISC” using

{ / B buttons,

then press ENTER button.

DISC menu will appear.

Disc

Edit

Format

Finalize

Select “Edit” using K / L buttons, then press ENTER button.

Titlelist will appear.

Screen:

Disc > Edit

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

JAN/ 1 1:00AM CH12 XP

0:01:25

Select “Title Delete” using K / L buttons, then press ENTER button.

Option window will appear.

Disc > Edit

JAN/ 1 1:00AM CH12 XP

Title Delete

Edit Title Name Chapter Mark

Yes No

0:01:25

Select “Yes” using { / B buttons, then press ENTER button.

Title will be deleted.

Disc > Edit

Title Delete

Edit Title Name Chapter Mark

1 2 3 4 5

RETURN

REC

MONITOR

SKIP

REC

SPEED

STOP PLAY

PAUSE

REC/OTR

SETUP

FWDREV

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

JAN/ 1 1:00AM CH12 XP

Yes No

Writing to Disc

This operation may take a while to be completed.

After writing to disc is completed, press SETUP button to exit DISC menu.

Français

Editing DVD-RW discs in Video mode (cont’d)

Putting names on titles

Video

DVD-RW

You can put title names on the titles and change the names from this menu. The names you put on the titles will be displayed on a titlelist.

Press SETUP button. Select “DISC” using

then press ENTER button.

DISC menu will appear.

Disc

Edit

Format

Finalize

{ / B buttons,

Editing

Select “Edit Title Name”

K / L buttons, then

using press ENTER button.

A window for entering a title name will appear.

Disc > Edit > Edit Title Name

JAN/ 1 1:00AM CH12 XP

A B C

a b c 1 2 3 @ ! ?

0:01:25

To enter a title name, follow the steps of “Guide to edit title name” on this page.

character set

2 3 4 5

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

SPEED

PAUS E

OPEN/

ABC

DEF

JKL

MNO

TUV

SPACE

ZOOM

WXYZ

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

REC

REC/OTR

FWDREV

Select “Edit” using K / L buttons, then press ENTER button.

Titlelist will appear.

Screen:

Disc > Edit

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Edit menu will appear.

Disc > Edit

Title Delete

Edit Title Name Chapter Mark

Disc > Edit > Edit Title Name

A B C

a b c 1 2 3 @ ! ?

JAN/ 1 1:00AM CH12 XP

0:01:25

area for entering title names

When you finish entering a title name, press ENTER button.

[

Guide to edit title name

[

Step1]: Select a desired character set using K/L

buttons, then press ENTER button.

[

]

Step2

: Press Number buttons following by the list

below.

Select

ABC

Press

<space>

ABC

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

*1 Press button, character set will be changed to the " @

*2 Press to buttons, character set will be changed to the previous input mode automatically.

To delete letters, press CLEAR button repeatedly. Holding CLEAR button to delete all letters. To go on to the next entering area for letters,

press button.

You can enter up to 30 letters.

abc

(*1) (*1)

abc

def

ghi

jkl

mno

pqrs

tuv

wxyz

" mode automatically.

123

]

A B C a b c 1 2 3 @ ! ?

@ ! ?

! ” # $ % & ’ ( ) * + , - . / : ;

< = > ? @ [ ] ^ _ { | }

(*2)

JAN/ 1 1:00AM CH12 XP

0:01:25

Editing

Editing DVD-RW discs in Video mode (cont’d)

Before you start Connections

Select “Yes” using { / B buttons, then press ENTER button.

The name you entered will be activated for the title.

Disc > Edit > Edit Title Name

abc

Writing to Disc

A B C

a b c 1 2 3

@ ! ?

Yes No

This operation may take a while to be completed.

After writing to disc is completed, press SETUP button to exit DISC menu.

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

REC

SPEED

PAUSE

ABC

TUV

SPACE

ZOOM

JKL

REC/OTR

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

OPEN/ CLOSE

DEF

MNO

WXYZ

SETUP

FWDREV

Getting started

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Français

Editing DVD-RW discs in Video mode (cont’d)

Setting or clearing chapter markers

Video

DVD-RW

You can put chapter markers in each title. Once a chapter is marked, you can use it for the chapter search feature. You can set chapter markers at a specified time you selected for titles with more than 5 minutes.

Press SETUP button. Select “DISC” using

then press ENTER button.

DISC menu will appear.

Disc

Edit

Format

Finalize

{ / B buttons,

Disc > Edit

JAN/ 1 1:00AM CH12 XP

Select “Chapter Mark” using K / L buttons, then press

ENTER button.

Option window will appear.

Disc > Edit

JAN/ 1 1:00AM CH12 XP

Editing

Title Delete

Edit Title Name Chapter Mark

Title Delete

Edit Title Name Chapter Mark

0:01:25

OFF 5 minutes 10 minutes 15 minutes 30 minutes 60 minutes

0:01:25

1 2 3 4 5

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

SPEED

PAUS E

OPEN/

ABC

DEF

JKL

MNO

TUV

WXYZ

SPACE

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

REC

REC/OTR

FWDREV

Select “Edit” using K / L buttons, then press ENTER button.

Titlelist will appear.

Screen:

Disc > Edit

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Edit menu will appear.

Select a desired time using K / L buttons, then press ENTER button.

Option window will appear.

Disc > Edit

JAN/ 1 1:00AM CH12 XP

Title Delete

Edit Title Name Chapter Mark

OFF 5 minutes 10 minutes 15 minutes 30 minutes 60 minutes

Yes No

0:01:25

Select “Yes” using { / B buttons, then press ENTER button.

Chapter markers will be added at the specified time.

After writing to disc is completed, press SETUP button to exit DISC menu.

Note

•You cannot select a time for putting markers beyond a length of a title.

• When recording at the recording speed other than XP or SEP, the leugth of chapters may be slightly longer or shorter than the one specified at the step 5.

•A chapter marker may be delayed according to the recording content.

Editing DVD-RW discs in VR mode (Original)

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

Deleting titles

DVD-RW

When a title is deleted from an original list in VR mode, the disc space to record will be increased. Be advised that the titles once deleted cannot be brought back to the disc.

Deleting titles

Press SETUP button. Select “DISC” using

then press ENTER button.

DISC menu will appear.

Disc

Edit

Format

Finalize

Disc Protect OFF ON

{ / B buttons,

Editing

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Original menu will appear.

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

0:01:25

Select “Title Delete” using K / L buttons, then press ENTER button.

Option window will appear.

1 2 3 4 5

Before you start Connections

Getting started

Recording

Playing discs

Select “Edit” using K / L buttons, then press ENTER button.

Original/PlayList menu will appear.

Select “Original” using { / B buttons, then press ENTER button.

Original list will appear.

Screen:

Disc > Edit > Original

JAN/1 1:00AM

JAN/1 4:00AM

Disc > Edit

Original

1 1 32

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Protect OFF

Yes No

Select “Yes” using { / B buttons, then press ENTER button.

Title will be deleted.

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Protect OFF

Yes No

This operation may take a while to be completed.

After writing to disc is completed, press SETUP button to exit DISC menu.

0:01:25

Editing

Changing the SETUP menu

Others Español

Français

Editing DVD-RW discs in VR mode (Original) (cont’d)

Deleting parts of titles

DVD-RW

You can delete part of a title, the disc space to record will be increased. Be advised that the parts once deleted cannot be brought back to the disc.

Press SETUP button. Select “DISC” using

then press ENTER button.

DISC menu will appear.

Disc

Edit

Format

Finalize

Disc Protect OFF ON

{ / B buttons,

Editing

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Original menu will appear.

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

0:01:25

Select “Scene Delete” using K / L buttons, then press

ENTER button.

Option window will appear.

1 2 3 4 5

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

SPEED

PAUS E

OPEN/

ABC

DEF

JKL

MNO

TUV

WXYZ

SPACE

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

REC

REC/OTR

FWDREV

Select “Edit” using K / L but- tons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Disc > Edit

Original

Select “Original” using { / B buttons, then press ENTER button.

Original list will appear.

Disc > Edit > Original

1 1 32

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Protect OFF

Start End Preview Delete

0:00:55

Press ENTER button to decide a start point, then press ENTER button to decide an end point.

A cursor will move to “Preview.” You can check a preview.

Before editing

Start point End point

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Edited

Editing

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

REC

MONITOR

REC

SPEED

REC/OTR

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

Editing DVD-RW discs in VR mode (Original) (cont’d)

Before you start Connections

Select “Delete” using K / L buttons, then press ENTER button.

Option window will appear.

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Putting names on titles

DVD-RW

You can put title names on the titles and change the names from this menu. The names you put on the titles will be displayed on a titlelist.

Disc

Edit

Format

Finalize

Disc Protect OFF ON

Press SETUP button. Select “DISC” using

then press ENTER button.

DISC menu will appear.

Title Delete

Scene Delete

Start

Edit Title Name

End

Chapter Mark

Preview

Index Picture

Delete

Protect OFF

Yes No

{ / B buttons,

0:01:25

Select “Yes” using { / B buttons, then press ENTER button.

Part of a title will be deleted.

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Protect OFF

Start End Preview Delete

Yes No

This operation may take a while to be completed.

After writing to disc is completed, press SETUP button to exit DISC menu.

Select “Edit” using K / L buttons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Disc > Edit

Original

7 8

Note

•You cannot select “Scene Delete” when the number of chapter markers in the original or playlist is more than 900.

1 2

Getting started

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Français

Editing

Editing DVD-RW discs in VR mode (Original) (cont’d)

Select “Original” using { / B buttons, then press ENTER button.

Original list will appear.

Disc > Edit > Original

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Original menu will appear.

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

0:01:25

Select “Edit Title Name”

K / L buttons, then

using press ENTER button.

A window for entering a title name will appear.

Disc > Edit > Original > Edit Title Name

JAN/ 1 1:00AM CH12 XP

A B C

a b c 1 2 3

@ ! ?

0:01:25

To enter a title name, follow the steps of “Guide to edit title name” on this page.

character set

Disc > Edit > Original > Edit Title Name

A B C

a b c 1 2 3

@ ! ?

JAN/ 1 1:00AM CH12 XP

0:01:25

area for entering title names When you finish entering a title name, press ENTER button.

Select “Yes” using { / B buttons, then press ENTER button.

The name you entered will be activated for the title.

Disc > Edit > Original > Edit Title Name

abc

Writing to Disc

A B C a b c 1 2 3 @ ! ?

Yes No

This operation may take a while to be completed.

After writing to disc is completed, press SETUP button to exit DISC menu.

POWER

VCR Plus

.@/:

PQRS

CLEAR

OPEN/

ABC

DEF

JKL

MNO

GHI

TUV

WXYZ

SPACE

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

3 4 5 6

RETURN

REC

MONITOR

SKIP

[

Guide to edit title name

[

Step1]: Select a desired character set using K/L

buttons, then press ENTER button.

[

]

Step2

: Press Number buttons following by the list

below.

Select

ABC

Press

<space>

(*1) (*1)

ABC

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

*1 Press button, character set will be changed to the " @

*2 Press to buttons, character set will be changed to the previous input mode automatically.

To delete letters, press CLEAR button repeatedly. Holding CLEAR button to delete all letters. To go on to the next entering area for letters,

press button.

You can enter up to 30 letters.

" mode automatically.

SETUP

REC

REC/OTR

SPEED

STOP PLAY

FWDREV

PAUS E

A B C

a b c 1 2 3

@ ! ?

abc

123

abc

def

ghi

jkl

mno

pqrs

tuv

wxyz

! ” # $ % & ’ ( ) * + , - . / : ;

< = > ? @ [ ] ^ _ { | }

]

@ ! ?

(*2) (*2)

(*2)

Editing DVD-RW discs in VR mode (Original) (cont’d)

Setting or clearing chapter markers

DVD-RW

You can put chapter markers in each title. Once a chapter is marked, you can use it for the chapter search feature. You can put a chapter marker anywhere you want. When the number of chapter markers in the original list comes to 999 in total, you cannot add any more chapter markers.

Press SETUP button. Select “DISC” using

then press ENTER button.

DISC menu will appear.

Disc

Edit

Format

Finalize

Disc Protect OFF ON

{ / B buttons,

Disc > Edit > Original

JAN/1 1:00AM

JAN/1 4:00AM

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Original menu will appear.

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Editing

1 1 32

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

0:01:25

Before you start Connections

.@/:

PQRS

OPEN/ CLOSE

ABC

DEF

JKL

MNO

GHI

TUV

WXYZ

SPACE

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

Getting started

POWER

VCR Plus

CLEAR

REC

SPEED

PAUSE

REC/OTR

SETUP

FWDREV

Recording

Playing discs

2 3 4

RETURN

REC

MONITOR

SKIP

STOP PLAY

Select “Edit” using K / L buttons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Disc > Edit

Original

Select “Original” using { / B buttons, then press ENTER button.

Original list will appear.

Select “Chapter Mark” using K / L buttons, then press

ENTER button.

Option window will appear.

Disc > Edit > Original

Chapter 1/1

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Protect OFF

Add Delete

0:01:25

Select “Add” or “Delete”

K / L buttons, then

using press ENTER button.

Option window will appear.

<Add>:

Disc > Edit > Original

Chapter 1/1

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Protect OFF

Add Delete

Yes No

0:01:25

Editing

Changing the SETUP menu

Others Español

Français

Editing

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUS E

REC

MONITOR

REC

SPEED

REC/OTR

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

REC

MONITOR

REC

SPEED

REC/OTR

Editing DVD-RW discs in VR mode (Original) (cont’d)

<Delete>:

Disc > Edit > Original

Chapter 2/2

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Protect OFF

Add Delete

Yes No

0:01:25

•You cannot delete the first chapter marker of each title.

Select “Yes” using { / B but- tons, then press ENTER button.

<Add>: A chapter marker will be added.

Disc > Edit > Original

Chapter 1/1

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Protect OFF

Add Delete

Yes No

<Delete>: The chapter marker which you selected will be deleted.

Disc > Edit > Original

Chapter 2/2

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Protect OFF

Add Delete

Yes No

This operation may take a while to be completed.

After writing to disc is completed, press SETUP button to exit DISC menu.

This operation may take a while to be completed.

Setting pictures for thumbnails

You can set a picture to each title for a thumbnail. It helps you to remember the contents of the title you are playing.The beginning picture has been selected as

DVD-RW

the default.

Disc

Edit

Format

Finalize

Disc Protect OFF ON

{ / B buttons,

Press SETUP button. Select “DISC” using

then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L buttons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Disc > Edit

Original

1 2

Note

• If a selected picture for a thumbnail is deleted by deleting a part of a title, a default picture will be selected.

Editing

Editing DVD-RW discs in VR mode (Original) (cont’d)

Before you start Connections

Select “Original” using { / B buttons, then press ENTER button.

Original list will appear.

Disc > Edit > Original

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Original menu will appear.

Disc > Edit > Original

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

Select “Yes” using { / B buttons, then press ENTER button.

A picture for thumbnail will be set.

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

Yes No

This operation may take a while to be completed.

After writing to disc is completed, press SETUP button to exit DISC menu.

3 4 5 6

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

REC

SPEED

PAUSE

ABC

TUV

SPACE

ZOOM

JKL

REC/OTR

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

OPEN/ CLOSE

DEF

MNO

WXYZ

SETUP

FWDREV

Getting started

Recording

Playing discs

Editing

JAN/ 1 1:00AM CH12 XP

0:01:25

Select “Index Picture Set”

K / L buttons. Use SKIP

using

H / G, REV E, FWD D,

B and PAUSE F but-

PLAY tons to decide the picture you want to select as a thumbnail.Then press ENTER button.

Option window will appear.

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

Yes No

0:01:25

Changing the SETUP menu

Others Español

Français

Editing DVD-RW discs in VR mode (Original) (cont’d)

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUS E

REC

MONITOR

REC

SPEED

REC/OTR

Setting titles to protect

DVD-RW

To prevent accidental editing, or erasing the titles, you can protect them from the original menu.

Press SETUP button. Select “DISC” using

{ / B buttons,

then press ENTER button.

DISC menu will appear.

Disc

Edit

Format

Finalize

Disc Protect OFF ON

Select “Edit” using K / L buttons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Disc > Edit

Disc > Edit > Original

JAN/1 1:00AM

JAN/1 4:00AM

Original

1 1 32

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Select “Original” using { / B buttons, then press ENTER button.

Original list will appear.

Editing

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Original menu will appear.

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

0:01:25

Select “Protect OFF ➔ ON” using K / L buttons, then press ENTER button.

Option window will appear.

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

Yes No

0:01:25

Select “Yes” using { / B but- tons, then press ENTER button.

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

Yes No

This operation may take a while to be completed.

After writing to disc is completed, press SETUP button to exit DISC menu.

To protect a whole disc (DVD-RW VR mode Only):

Select “Disc Protect” from Disc menu, then select “Yes”.

1 2

4 5 6

Editing DVD-RW discs in VR mode (Original) (cont’d)

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

Releasing titles from protecting

DVD-RW

You are allowed to release the titles protecting feature once protected.

Press SETUP button. Select “DISC” using

{ / B buttons,

then press ENTER button.

DISC menu will appear.

Disc

Edit

Format

Finalize

Disc Protect OFF ON

Select “Edit” using K / L buttons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Disc > Edit

Original

Select “Original” using { / B buttons, then press ENTER button.

Original list will appear.

Disc > Edit > Original

JAN/1 1:00AM

JAN/1 4:00AM

1 1 32

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Editing

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Original menu will appear.

Disc Edit > Original

JAN/ 1 2:00AM CH12 XP

“Protect ON

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

OFF

Protect ON

0:01:25

→ OFF” is selected.

Press ENTER button.

Option window will appear.

Disc Edit > Original

JAN/ 1 2:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect ON

Yes No

OFF

0:01:25

Select “Yes” using { / B buttons, then press ENTER button.

Disc Edit > Original

JAN/ 1 2:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect ON

Yes No

OFF

This operation may take a while to be completed.

After writing to disc is completed, press SETUP button to exit DISC menu.

1 2 3 4 5

Before you start Connections

Getting started

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Français

Editing DVD-RW discs in VR mode (Playlist)

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUS E

REC

MONITOR

REC

SPEED

REC/OTR

Deleting titles

DVD-RW

In VR mode, even when a title is deleted from a Playlist, the original title will remain in an Original list. The disc space to record will not be increased.

Editing

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Playlist menu will appear.

Press SETUP button. Select “DISC” using

{ / B buttons,

then press ENTER button.

DISC menu will appear.

Disc

Edit

Format

Finalize

Disc Protect OFF ON

Select “Edit” using K / L buttons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Select “PlayList” using { / B buttons, then press ENTER button.

Playlist will appear.

Disc > Edit > Playlist

JAN/1 1:00AM

JAN/1 4:00AM

Disc > Edit

Original

1 1 32

JAN/1 2:00AM JAN/1 3:00AM

Add New

Delete

JAN/1 5:00AM

Title

Playlist

Disc > Edit > Playlist

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

0:01:25

Select “Title Delete” using K / L buttons, then press ENTER button.

Option window will appear.

Disc > Edit > Playlist

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Yes No

0:01:25

Select “Yes” using { / B but- tons, then press ENTER button.

Title will be deleted.

Disc > Edit > Playlist

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Yes No

This operation may take a while to be completed.

After writing to disc is completed, press SETUP button to exit DISC menu.

1 2

4 5 6

Editing DVD-RW discs in VR mode (Playlist) (cont’d)

Deleting parts of titles

DVD-RW

You can delete a specific part of a title. Even when a title is deleted from the playlist, the original title will remain. The disc space to record will not be increased.

Press SETUP button. Select “DISC” using

then press ENTER button.

DISC menu will appear.

Disc

Edit

Format

Finalize

Disc Protect OFF ON

{ / B buttons,

Editing

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Playlist menu will appear.

Disc > Edit > Playlist

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

0:01:25

Select “Scene Delete” using K / L buttons, then press

ENTER button.

Option window will appear.

1 2 3 4 5

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

REC

SPEED

PAUSE

ABC

TUV

SPACE

ZOOM

JKL

REC/OTR

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

OPEN/ CLOSE

DEF

MNO

WXYZ

SETUP

FWDREV

Before you start Connections

Getting started

Recording

Playing discs

Select “Edit” using K / L but- tons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Disc > Edit

Original

Select “PlayList” using { / B buttons, then press ENTER button.

Playlist will appear.

Disc > Edit > Playlist

1 1 32

Disc > Edit > Playlist

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture

Start End Preview Delete

0:00:55

Press ENTER button to decide a start point, then press ENTER button to decide an end point.

A cursor will move to “Preview”. You can check a preview.

Before editing

Start point End point

Editing

Changing the SETUP menu

Others Español

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

Add New

Title

Delete

JAN/1 5:00AM

Playlist

Edited

Instructions continue to the next page.

Français

Editing

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

REC

MONITOR

REC

SPEED

REC/OTR

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUS E

REC

MONITOR

REC

SPEED

REC/OTR

Editing DVD-RW discs in VR mode (Playlist) (cont’d)

Part of a title will be deleted.

Select “Delete” using K / L buttons, then press ENTER button.

Option window will appear.

Disc > Edit > Playlist

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture

Start End Preview Delete

Yes No

0:01:25

Select “Yes” using { / B buttons, then press ENTER button.

Putting names on titles

DVD-RW

You can put names on the titles and change the names from this menu. The names you put on the titles will be displayed on a titlelist.

Disc > Edit > Playlist

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture

Start End Preview Delete

Yes No

This operation may take a while to be completed.

After writing to disc is completed, press SETUP button to exit DISC menu.

Screen:

Disc > Edit

7 8

Note

•You cannot select “Scene Delete” when the number of chapter markers in the original or playlist is more than 900.

Press SETUP button. Select “DISC” using

then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L buttons, then press ENTER button.

Disc

Edit

Format

Finalize

Disc Protect OFF ON

{ / B buttons,

Original/PlayList menu will appear.

Original

Select “PlayList” using { / B buttons, then press ENTER button.

Playlist will appear.

Disc > Edit > Playlist

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

Add New

Title

Delete

JAN/1 5:00AM

Playlist

1 2

Editing

Editing DVD-RW discs in VR mode (Playlist) (cont’d)

Before you start Connections

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Playlist menu will appear.

Disc > Edit > Playlist

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

0:01:25

Select “Edit Title Name”

K / L buttons, then

using press ENTER button.

A window for entering a title name will appear.

Disc > Edit > Playlist > Edit Title Name

JAN/ 1 1:00AM CH12 XP

A B C

a b c 1 2 3

@ ! ?

0:01:25

To enter a title name, follow the steps of “Guide to edit title name” on this page.

character set

Disc > Edit > Playlist > Edit Title Name

A B C

a b c 1 2 3 @ ! ?

JAN/ 1 1:00AM CH12 XP

area for entering title names

When you finish entering a title name, press ENTER button.

0:01:25

Select “Yes” using { / B buttons, then press ENTER button.

The name you entered will be activated for the title.

Disc > Edit > Playlist > Edit Title Name

abc

Writing to Disc

A B C

a b c 1 2 3 @ ! ?

Yes No

This operation may take a while to be completed.

After writing to disc is completed, press SETUP to exit DISC menu.

.@/:

PQRS

OPEN/ CLOSE

ABC

DEF

JKL

MNO

GHI

TUV

WXYZ

SPACE

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

POWER

VCR Plus

CLEAR

4 5 6 7

[

Step1]: Select a desired character set using K/L

buttons, then press ENTER button.

[

Step2

below.

Select

Press

*1 Press button, character set will be changed to the " @

*2 Press to buttons, character set will be changed to the previous input mode automatically.

To delete letters, press CLEAR button repeatedly. Holding CLEAR button to delete all letters. To go on to the next entering area for letters,

press button.

You can enter up to 30 letters.

RETURN

REC

MONITOR

SKIP

STOP PLAY

[

Guide to edit title name

]

: Press Number buttons following by the list

ABC

<space>

(*1) (*1)

ABC

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

" mode automatically.

SETUP

REC

REC/OTR

SPEED

FWDREV

PAUSE

]

A B C a b c 1 2 3 @ ! ?

abc

abc

def

ghi

jkl

mno

pqrs

tuv

wxyz

123

@ ! ?

! ” # $ % & ’ ( ) * + , - . / : ;

< = > ? @ [ ] ^ _ { | }

(*2)

Getting started

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Français

Editing DVD-RW discs in VR mode (Playlist) (cont’d)

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUS E

REC

MONITOR

REC

SPEED

REC/OTR

Setting or clearing chapter markers

DVD-RW

You can put chapter markers in each title. Once a chapter is marked, you can use it for the chapter search feature. You can put a chapter marker anywhere you want. When the number of chapter markers in the playlist comes to 999 in total, you cannot add any more chapter markers.

Press SETUP button. Select “DISC” using

then press ENTER button.

DISC menu will appear.

Disc

Edit

Format

Finalize

Disc Protect OFF ON

{ / B buttons,

Disc > Edit > Playlist

JAN/1 1:00AM

JAN/1 4:00AM

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Playlist menu will appear.

Disc > Edit > Playlist

JAN/ 1 1:00AM CH12 XP

Editing

1 1 32

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Add New

Delete

0:01:25

Title

Playlist

1 2

3 4 5 6

Screen:

Disc > Edit

Original

Select “Edit” using K / L buttons, then press ENTER button.

Original/PlayList menu will appear.

Select “PlayList” using { / B buttons, then press ENTER button.

Playlist will appear.

Select “Chapter Mark” using K / L buttons, then press

ENTER button.

Option window will appear.

Disc > Edit > Playlist

Chapter 1/1

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Add Delete

0:01:25

Select “Add” or “Delete”

K / L buttons, then

using press ENTER button.

Option window will appear.

<Add>:

Disc > Edit > Playlist

Chapter 1/1

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Yes No

Add Delete

0:01:25

Editing

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

REC

MONITOR

REC

SPEED

REC/OTR

Editing DVD-RW discs in VR mode (Playlist) (cont’d)

Before you start Connections

<Delete>:

Disc > Edit > Playlist

Chapter 2/2

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Yes No

Add Delete

0:01:25

•You cannot delete the first chapter of each title.

Select “Yes” using { / B but- tons, then press ENTER button.

A chapter marker will be added.

<Add>:

Disc > Edit > Playlist

Chapter 1/1

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Yes No

Add Delete

The chapter marker which you selected will be deleted.

<Delete>:

Disc > Edit > Playlist

Chapter 2/2

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Yes No

Add Delete

This operation may take a while to be completed.

After writing to disc is completed, press SETUP button to exit DISC menu.

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

REC

SPEED

PAUSE

ABC

TUV

SPACE

ZOOM

JKL

REC/OTR

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

OPEN/ CLOSE

DEF

MNO

WXYZ

SETUP

FWDREV

Getting started

Recording

Playing discs

This operation may take a while to be completed.

Setting pictures for thumbnails

DVD-RW

You can set a picture to each title for a thumbnail. It helps you to remember the contents of the title you are playing.The beginning picture has been selected as the default.

Disc

Edit

Format

Finalize

Disc Protect OFF ON

{ / B buttons,

Press SETUP button. Select “DISC” using

then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L buttons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Disc > Edit

Original

1 2

Note

• If a selected picture for a thumbnail is deleted by deleting a part of a title, a default picture will be selected.

Editing

Changing the SETUP menu

Others Español

Français

Editing

Editing DVD-RW discs in VR mode (Playlist) (cont’d)

Select “PlayList” using { / B buttons, then press ENTER button.

Playlist will appear.

Disc > Edit > Playlist

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

Add New

Title

Delete

JAN/1 5:00AM

Playlist

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Playlist menu will appear.

Disc > Edit > Playlist

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Select “Yes” using { / B buttons, then press ENTER button.

A picture for thumbnail will be set.

Disc > Edit > Playlist

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Yes No

This operation may take a while to be completed.

After writing to disc is completed, press SETUP button to exit DISC menu.

3 4 5 6

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

SPEED

PAUS E

OPEN/

ABC

DEF

JKL

MNO

TUV

WXYZ

SPACE

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

REC

REC/OTR

FWDREV

JAN/ 1 1:00AM CH12 XP

0:01:25

Select “Index Picture Set”

K / L buttons. Use SKIP

using

H / G, REV E, FWD D,

B and PAUSE F but-

PLAY tons to decide the picture you want to select as a thumbnail.Then press ENTER button.

Option window will appear.

Disc > Edit > Playlist

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Yes No

0:01:25

Editing DVD-RW discs in VR mode (Playlist) (cont’d)

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

Adding titles to a Playlist

DVD-RW

You can add or delete a title in the playlist as you prefer. You can add titles to a Playlist up to 99.

Editing

Select “Add New Title” using K / L / { / B buttons, then

press ENTER button.

Original list will appear.

Before you start Connections

Press SETUP button. Select “DISC” using

{ / B buttons,

then press ENTER button.

DISC menu will appear.

Disc

Edit

Format

Finalize

Disc Protect OFF ON

Select “Edit” using K / L buttons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Disc > Edit

Original

Select “PlayList” using { / B buttons, then press ENTER button.

Playlist will appear.

Disc > Edit > Playlist

JAN/1 1:00AM

JAN/1 4:00AM

1 1 32

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Add New

Delete

Title

Playlist

Disc > Edit > Playlist > Add New Title

1 1 32

JAN/12 5:00PM JAN/12 8:00PMJAN/10 10:30AM

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Disc > Edit > Playlist > Add New Title

Writing to Disc

Disc > Edit > Playlist

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM

JAN/1 5:00AM

58%

JAN/1 3:00AM

JAN/12 8:00PM

After writing to disc is completed, press SETUP button to exit DISC menu.

To delete a title from Playlist, refer to “Deleting titles” on page

76. To delete a Playlist, refer to “Deleting a Playlist” on page 84.

1 2 3 4 5

Getting started

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Français

Editing DVD-RW discs in VR mode (Playlist) (cont’d)

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUS E

REC

MONITOR

REC

SPEED

REC/OTR

Deleting a Playlist

DVD-RW

A Playlist can be deleted if no longer needed.

Press SETUP button. Select “DISC” using

then press ENTER button.

DISC menu will appear.

Disc

Edit

Format

Finalize

Disc Protect OFF ON

{ / B buttons,

Editing

Select “Delete Playlist” using K / L / { / B buttons, then

press ENTER button.

Option window will appear.

Disc > Edit > Playlist

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

Add New

Title

Delete

Playlist

JAN/1 5:00AM

Yes No

1 2

Select “Edit” using K / L buttons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Disc > Edit

Original

Select “PlayList” using { / B buttons, then press ENTER button.

Playlist will appear.

Select “Yes” using { / B buttons, then press ENTER button.

Playlist will be erased. After writing to disc is completed, the DVD recorder will be in stop mode.

4 5

Disc > Edit > Playlist

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Add New

Title

Delete

Playlist

Note

• Deleting a Playlist will not increase the available recording time.

Deleting titles

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUSE

REC

MONITOR

REC

SPEED

REC/OTR

DVD-R

You can delete titles which you do not need, however the disc space to record will not be changed. Be sure to know that the titles once deleted cannot be brought back to the disc.

Editing

Editing DVD-R discs

Disc > Edit

JAN/ 1 1:00AM CH12 XP

You cannot select “Chapter Mark”.

Title Delete

Edit Title Name Chapter Mark

0:01:25

Before you start Connections

Getting started

Press SETUP button. Select “DISC” using

{ / B buttons,

then press ENTER button.

DISC menu will appear.

Disc

Edit

Format

Finalize

Select “Edit” using K / L buttons, then press ENTER button.

Titlelist will appear.

Screen:

Disc > Edit

JAN/1 1:00AM

JAN/1 4:00AM

1 1 32

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Select “Title Delete” using K / L buttons, then press ENTER button.

Option window will appear.

Disc > Edit

JAN/ 1 1:00AM CH12 XP

Title Delete

Edit Title Name Chapter Mark

Yes No

0:01:25

Select “Yes” using { / B buttons, then press ENTER button.

Title will be deleted.

Disc > Edit

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Edit Title Name Chapter Mark

Yes No

1 2 3 4 5

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Edit menu will appear.

This operation may take a while to be completed.

After writing to disc is completed, press SETUP button to exit DISC menu.

Français

Editing DVD-R discs (cont’d)

Putting names on titles

DVD-R

You can put names on the titles and change the names from this menu. The names you put on the titles will be displayed on a titlelist.

Press SETUP button. Select “DISC” using

{ / B buttons,

then press ENTER button.

DISC menu will appear.

Disc

Edit

Format

Finalize

Select “Edit” using tons, then press ENTER button.

Titlelist will appear.

Screen:

Disc > Edit

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

K / L

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

but-

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Edit menu will appear.

Disc > Edit

JAN/ 1 1:00AM CH12 XP

You cannot select “Chapter Mark”.

Title Delete

Edit Title Name Chapter Mark

0:01:25

Editing

Select “Edit Title Name” using K / L buttons, then press ENTER button.

A window for entering a title name will appear.

Disc > Edit > Edit Title Name

JAN/ 1 1:00AM CH12 XP

A B C

a b c 1 2 3 @ ! ?

0:01:25

To enter a title name, follow the steps of “Guide to edit title name” on this page.

character set

Disc > Edit > Edit Title Name

A B C

a b c 1 2 3 @ ! ?

JAN/ 1 1:00AM CH12 XP

0:01:25

area for entering title names When you finish entering a title name, press ENTER button.

Select “Yes” using { / B buttons, then press ENTER button.

Disc > Edit > Edit Title Name

abc

Writing to Disc

A B C a b c 1 2 3 @ ! ?

Yes No

This operation may take a while to be completed.

After writing to disc is completed, press SETUP button to exit DISC menu.

POWER

VCR Plus

.@/:

PQRS

CLEAR

OPEN/

ABC

DEF

JKL

MNO

GHI

TUV

WXYZ

SPACE

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

REC

SPEED

STOP PLAY

PAUS E

SETUP

REC/OTR

FWDREV

2 3 4 5

RETURN

REC

MONITOR

SKIP

[

Guide to edit title name

[

Step1]: Select a desired character set using K/L

buttons, then press ENTER button.

[

]

Step2

: Press Number buttons following by the list

below.

Select

ABC

Press

<space>

ABC

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

*1 Press button, character set will be changed to the " @

*2 Press to buttons, character set will be changed to the previous input mode automatically.

To delete letters, press CLEAR button repeatedly. Holding CLEAR button to delete all letters. To go on to the next entering area for letters,

press button.

You can enter up to 30 letters.

abc

(*1) (*1)

abc

def

ghi

jkl

mno

pqrs

tuv

wxyz

" mode automatically.

123

]

A B C

a b c 1 2 3 @ ! ?

@ ! ?

! ” # $ % & ’ ( ) * + , - . / : ;

< = > ? @ [ ] ^ _ { | }

(*2)

1 7

Changing the SETUP menu

Tour of the SETUP menu

The following table is the contents which you can set and the default settings. Refer to the following table for useful operation.

SETUP menu ContentsItems (highlight is the default)

Before you start Connections

1.Language setting Pages 88-89

2.Display setting Pages 90-91

Disc Menu Language Set the language for disc menu.

Audio Language

Subtitle Language

OSD Background Transparency

OSD Background Color

OSD Language

FL Dimmer

Screen Saver

English French Spanish

Original English French

OFF English French

100%

35% 25%

1 2 3

English

Français Español

Auto Bright Dark

OFF 5 minutes 10minutes

Set the language for audio.

Set the language for subtitle.

Set the background transparency of OSD screen.

Set the OSD screen color. 1 (Green), 2 (Blue), 3 (Red)

Set the language for OSD (On Screen Display).

Set the brightness of front display.

Set the time to work the screen saver on the screen.

Getting started

Recording

Playing discs

Editing

3.Audio setting Pages 92-93

4.Parental setting Pages 94-95

Digital Out

Dynamic Range Control

Fast Forward with Audio

Parental Lock

(Change password)

PCM Auto

48kHz 96kHz

Dolby Digital PCM

Stream

DTS ON

OFF

ON OFF

ALL level 8 to 1

Enter the current four-digit password

Set whether the sound recorded in 96kHz will be down sampled in 48kHz.

Set the type of sound signal which outputs from the digital audio output jack.

Set wether DTS signal will be output or not.

Compressing the range of sound volume.

Outputting the sound during play in fast forward.

Set the parental level of your DVD discs.

Set and change the password.

Note

•

If you change the setting in SETUP menu, the information of contents stays on even when the power is switched off.

Changing the SETUP menu

Others Español

Français

Changing the SETUP menu

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUS E

REC

MONITOR

REC

SPEED

REC/OTR

Settings for Language

Press STOP button if you are playing a disc.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Setup Menu

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Setup

Playback Setting

Select “Playback” using K / L / ENTER button.

Option window will appear.

{ / B

buttons, then press

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

4:3 Letter Box

All

English

Original

OFF

2 3 4

1 5

Select a desired item using K / L buttons, then press ENTER button.

Note

• Only the languages supported by the disc can be selected.

• Audio Language setting may not be available to some discs.

•You can change or switch off the subtitles on a DVD disc also from the disc menu if it

is available.

Changing the SETUP menu

All

Settings for Language (cont’d)

Disc Menu Language (Default : English)

Set the language for Disc Menu.

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

Audio Language (Default : Original)

Set the Audio language.

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

4:3 Letter Box

All

English

Original

OFF

4:3 Letter Box

All

English

Original

OFF

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

4:3 Letter Box

All

English

French

Original

Spanish

OFF

Other

OFF

4:3 Letter Box

All

Original

English

Original

French

OFF

Spanish Other

OFF

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated.

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated.

Before you start Connections

Getting started

Recording

Playing discs

Subtitle Language (Default : OFF)

Set the subtitle language.

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

4:3 Letter Box

All

English

Original

OFF

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

4:3 Letter Box

All

OFF

English

Original

French

OFF

Spanish Other

OFF

If “Other” is selected, press 4-digit code using number buttons.

ontrol

English

French

Original

Spanish

OFF

Other

Code Input

- - - -

•

When you finish entering the code, press ENTER button. Refer to the language code table on page

101.

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated.

Editing

Changing the SETUP menu

Others Español

Press SETUP button to exit SETUP menu.

Français

Changing the SETUP menu

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUS E

REC

MONITOR

REC

SPEED

REC/OTR

Settings for Display

Press STOP button if you are playing a disc.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Setup Menu

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Setup

Playback Setting

Select “Display” using K / L / ENTER button.

Option window will appear.

{ / B

buttons, then press

Setup > Display

OSD Background Transparency

OSD Background Color

OSD Language

FL Dimmer

Screen Saver

35%

English

Bright

10 minutes

2 3 4

Select a desired item using K / L buttons, then press ENTER button.

Changing the SETUP menu

Settings for Display (cont’d)

OSD Background Transparency (Default : 35%)

Set the background transparency of OSD screen. You can choose one among 0% through 100%.

Setup > Display

OSD Background Transparency

OSD Background Color

OSD Language

FL Dimmer

Screen Saver

35%

English

Bright

10 minutes

OSD Background Color (Default : 1 Green)

Set the OSD screen color. You can choose one among 1(Green), 2(Blue), and 3(Red).

Setup > Display

OSD Background Transparency

OSD Background Color

OSD Language

FL Dimmer

Screen Saver

35%

English

Bright

10 minutes

Setup > Display

OSD Background Transparency

OSD Background Color

OSD Language

FL Dimmer

Screen Saver

Setup > Display

OSD Background Transparency

OSD Background Color

OSD Language

FL Dimmer

Screen Saver

100%

35%

85%

70%

English

50%

Bright

35% 25%

10 minutes

10% 0%

35%

1 2

English

Bright

10 minutes

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated.

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated.

Before you start Connections

Getting started

Recording

OSD Language (Default : English)

Set the language for OSD.

Setup > Display

OSD Background Transparency

OSD Background Color

OSD Language

FL Dimmer

Screen Saver

35%

English

Bright

10 minutes

Setup > Display

OSD Background Transparency

OSD Background Color

OSD Language

FL Dimmer

Screen Saver

35%

English

English Français

Bright

Español

10 minutes

FL Dimmer (Default : Bright)

Set the brightness of front display. You can choose one among “Auto”, ”Bright” and ”Dark”. When “Auto” is selected, the display dims after 15 seconds of no use.

Setup > Display

OSD Background Transparency

OSD Background Color

OSD Language

FL Dimmer

Screen Saver

35%

English

Bright

10 minutes

Setup > Display

OSD Background Transparency

OSD Background Color

OSD Language

FL Dimmer

Screen Saver

35%

English

Bright

Auto

10 minutes

Bright Dark

Screen Saver (Default : 10 minutes)

Set the time to work the screen saver function on the screen.

Setup > Display

OSD Background Transparency

OSD Background Color

OSD Language

FL Dimmer

Screen Saver

35%

English

Bright

10 minutes

Setup > Display

OSD Background Transparency

OSD Background Color

OSD Language

FL Dimmer

Screen Saver

35%

English

OFF

Bright

5 minutes 10 minutes

10 minutes 15 minutes 30 minutes

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated.

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated.

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated.

Playing discs

Editing

Changing the SETUP menu

Others Español

Français

Press SETUP button to exit SETUP menu.

Changing the SETUP menu

Settings for Audio

Choose the appropriate Audio settings for your equipment.

It will only affect DVD discs during playback.

Press STOP button if you are playing a disc.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Setup Menu

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Setup

2 3 4

POWER

VCR Plus

RETURN

MONITOR

.@/:

GHI

PQRS

CLEAR

REC

SKIP

STOP PLAY

SPEED

PAUS E

OPEN/

ABC

DEF

JKL

MNO

TUV

WXYZ

SPACE

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

REC

REC/OTR

FWDREV

Playback Setting

Select “Playback” using K / L / ENTER button.

Option window will appear.

{ / B

buttons, then press

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

4:3 Letter Box

All

English

Original

OFF

Select a desired item using K / L buttons, then press ENTER button.

Digital Out

Set the digital audio output.

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

4:3 Letter Box

All

English

Original

OFF

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

4:3 Letter Box

All

English

Original

OFF

PCM Dolby Digital

DTS

OFF

Note

• Dynamic Range Control function is available only on the discs which are recorded in the Dolby Digital format.

•

Select a setting using K / L buttons, then press ENTER button.

Option window will appear. Proceed to steps A, B or C.

Changing the SETUP menu

Settings for Audio (cont’d)

Settings for PCM (Default :Auto)

•

Original

OFF

PCM Dolby Digital

trol

DTS

dio

Settings for Dolby Digital (Default : Stream)

OFF

Auto 48kHz 96kHz

Original

OFF

PCM Dolby Digital

trol

dio

PCM

DTS

Stream

OFF

Settings for DTS (Default : OFF)

Original

OFF

PCM Dolby Digital

trol

dio

DTS

OFF

ON OFF

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated. Auto : Select “Auto” usually. 48kHz : If your amplifier/decoder is NOT com-

patible with 96kHz PCM, select “48kHz”. 96kHz sound will be output in 48kHz.

96kHz : If your amplifier/decoder is compatible

with 96kHz PCM, select “96kHz”. 96kHz sound will be output.

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated.

PCM : Convert the Dolby Digital into PCM(2

channel).

When your amplifier/decoder is NOT compatible with Dolby Digital, s

Stream : Outputs Dolby Digital signals

When your amplifier/decoder is compatible with Dolby Digital,

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated. ON : Outputs DTS signals.

When your amplifier/decoder is compatible with DTS, set to “ON”.

OFF : No DTS signal is output.

When your amplifier/decoder is NOT compatible with DTS, set to “OFF”.

et to “PCM”

set to “Stream”.

Note

When playing disc with copyright protection

• If you select “Auto”, the sound will be down sampled at 48kHz.

• If you select “96kHz”, no digital sound will be output. Select “Auto”, so that outputting

48kHz digital sound.

Note

When playing a DVD-RW disc recorded in VR mode

• If the audio source on a disc is Dolby Digital format, set “Dolby Digital” to “PCM” so that you

can switch to main (L), sub audio (R), or a mix of both (L/R) with your amplifier/decoder.

Before you start Connections

Getting started

Recording

Playing discs

Editing

Dynamic Range Control (Default : ON)

Set to ON to compress the range between soft and loud sounds.

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

4:3 Letter Box

All

English

Original

OFF

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

Fast Forward with Audio (Default : OFF)

Set to ON to output the sound during play in fast forward of x2.

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

4:3 Letter Box

All

English

Original

OFF

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

Press SETUP button to exit SETUP menu.

4:3 Letter Box

All

English

Original

OFF

4:3 Letter Box

All

English

Original

OFF

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated.

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated.

Changing the SETUP menu

Others Español

Français

Changing the SETUP menu

POWER

OPEN/ CLOSE

ABC

JKL

TUV

DEF

MNO

WXYZ

SPACE

.@/:

GHI

PQRS

CLEAR

VCR Plus

ZOOM

DISPLAYCM SKIPREPEAT

TOP MENUMENU/LIST

SETUP

RETURN

SKIP

STOP PLAY

FWDREV

PAUS E

REC

MONITOR

REC

SPEED

REC/OTR

Settings for Parental lock level

Some DVD-Video discs feature a Parental Lock level. Playback will stop if the ratings exceed the levels you set, it will require you to enter a password before the disc will playback.This feature prevents your children from viewing inappropriate material.

Press STOP button if you are playing a disc.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Setup Menu

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Setup

Playback Setting

{ / B

buttons, then press

Select “Playback” using K / L / ENTER button.

Option window will appear.

2 3 4

1 5

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

Select “Parental Lock” using K / L buttons, then press ENTER button.

4:3 Letter Box

All

English

Original

OFF

Note

• Parental lock function may not be available to some discs.

•With some DVDs, it may be difficult to find if they are compatible with parental lock. Be sure to check if the parental lock function operates in the way that you have set.

• Record the password in case you forget it.

Changing the SETUP menu

Settings for Parental lock level (cont’d)

Parental Lock (Default : All)

Set the Parental Lock level.

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

4:3 Letter Box

All

English

Original

OFF

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

4:3 Letter Box

All 8

All 7

English 6 Original

5 OFF

4 3 2

ON 1

OFF

•

Change the parental level using K / L buttons, then press ENTER button.

Option window will appear Proceed to steps A or B.

Before you start Connections

Getting started

• If you

A password has not been set yet

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

select “No”, proceed

4:3 Letter Box

Change Password?

All

Yes No

All

English

Original

OFF

4 3 2

OFF

to Step 5.

•

A password has been set already

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

Enter the current password

4:3 Letter Box

All

Password

All

* * * *

English

Original

OFF

4 3 2

OFF

using Number buttons.

Ye s

• If you

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

select “No”, proceed

to Step 5.

4:3 Letter Box

Change Password?

All

Yes No

All 7

English 6 Original

5 OFF

4 3 2

ON 1

OFF

4:3 Letter Box

Password

All

- - - -

All 7

English 6 Original

5 OFF

4 3 2

ON 1

OFF

•

Select “Yes” using s / B buttons, then enter a new password using Number buttons.

Your setting will be activated.

Change the password

Setup > Playback

Ye s

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

•

Select “Yes” using s / B buttons, then enter a new password using Number buttons.

Your setting will be activated.

4:3 Letter Box

Password

All

- - - -

All 7

English 6 Original

5 OFF

4 3 2

ON 1

OFF

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Press SETUP button to exit SETUP menu.

Note

•Press CLEAR button to erase numbers entered incorrectly.

• When you forget the password or you want to clear all settings in Parental lock, enter 4,7,3,7 using Number buttons in option window. Password will be cleared and parental

levels will be set to All.

Français

Others

Troubleshooting

Before requesting service for this DVD recorder, check the table below for a possible cause of the problem you are experiencing. Some simple checks or a minor adjustment on your part may eliminate the problem and restore proper operation.

Symptom Remedy

Power

The power does not turn on. • Check that the AC power cord is connected securely.


There is no picture. • Re-connect the connecting cord securely.

Picture noise appears. • The disc is dirty or flawed.

TV program reception does not fill the screen.

TV program pictures are distorted. • Adjust TV antenna.

TV channels cannot be changed. • Switch the input to TV.

The playback picture or TV program from the equipment connected through the DVD recorder is distorted.

Sound

There is no sound. • The disc is dirty or flawed.

Sound is noisy.

• The connecting cords are damaged.

• The Setup Display appears. Press SETUP or RETURN button to turn off the display.

• Check the connection to your TV (page 13).

• Check if the INTERLACE/PROGRESSIVE mode is set correctly according to your TV. See page 13.

•

Switch the input selector on your TV (such as to "LINE1") so that the signal from the DVD recorder appears on the TV screen.

• If the picture output signal from the DVD recorder passes

through your VCR to get to your TV, or if you are connected to a combination TV/VIDEO player, the copy-protection signal applied to some DVD programs could affect picture quality. If you still experience this problem even when you connect the DVD recorder directly to your TV, try connecting the DVD recorder to your TV's S-VIDEO input.

•Try to set the channels with "Auto Preset" in SETUP menu

(page 18).

• Select a channel of any TV program using the CH

buttons.

• Adjust the picture (see the TV's instruction manual).

• Place the DVD recorder and TV farther apart.

• Place the TV and any bunched antenna cables farther apart.

• Connect the antenna cable correctly (page 13).

• If the playback picture output from a DVD player, VCR, or tuner

goes through the DVD recorder before reaching your TV, the copy-protection signal applied to some programs could affect picture quality. Disconnect the playback equipment in question and connect it directly to your TV.

• Re-connect all connections securely.

• The connecting cord is damaged.

• Check the connections to the amplifier input.

• The input source setting on the amplifier is incorrect.

• The recorder is in pause mode or in Slow-motion Play mode.

• The recorder is in fast forward or fast reverse mode.

• If the audio signal does not come through the DIGITAL AUDIO

OUT jacks, check the Audio Setup settings (pages 92-93).

• The disc is dirty or flawed.

o /

Others

Troubleshooting (cont’d)

Symptom Remedy

Playback

The disc does not play.

The disc does not start playback from the beginning.

The DVD recorder starts playing from the disc automatically.

Some functions such as Stop, Search, or Slow-motion Play cannot be performed.

The language for the sound track cannot be changed.

The subtitle language cannot be changed or turned off.

The angles cannot be changed.

Recording/Timer recording/Editing

The channel cannot be changed from the channel you are recording.

Recording does not start immediately after you press REC button or REC/OTR button.

Nothing was recorded even though you set the timer setting correctly.

Recording does not stop immediately after you press STOP C button.

Timer recording is not complete or did not start from the beginning.

• No disc is inserted.

•A blank disc is inserted.

• The disc is upside down. Insert the disc with the labeled side

facing up.

• The disc is not correctly inserted.

• The DVD recorder cannot play certain discs (such as a CD-

ROM) (page 44).

• The region code on the DVD VIDEO does not match the DVD

recorder (page 44).

• Moisture has condensed inside the DVD recorder. Remove the

disc and leave the DVD recorder turned on at least for 2 hours until the moisture evaporates (page 4).

• If the disc was recorded on another recorder, the DVD

recorder cannot play the disc if it was not finalized (page 42).

• Resume play was activated (page 49). Press STOP C button

twice.

•You have inserted a disc whose Title menu or DVD menu

automatically appears on the TV screen when it is first insert.

• The DVD VIDEO features an auto playback function.

• Depending on the disc, you may not be able to do some of the

operations above. See the instruction manual supplied with the disc.

• Multilingual tracks are not recorded on the DVD VIDEO,

DVD-R or DVD-RW being played.

• The DVD VIDEO prohibits the changing of the language for the

sound track.

•Try changing the language using the DVD VIDEO's menu.

• Multilingual subtitle are not recorded on the DVD VIDEO.

• The DVD VIDEO prohibits changing of the subtitles.

•Try changing the subtitle using the DVD VIDEO's menu.

• Multi-angles are not recorded on the DVD VIDEO being played.

•You are trying to change the angles when icon does not

appear on the TV screen (page 60).

• The DVD VIDEO prohibits changing angles.

•Try changing the angle using the DVD VIDEO's menu.

• Set the TV's input to "TV".

• An unused DVD-R or DVD-RW was inserted. It takes a while

for the DVD recorder to automatically format a DVD-RW.

•There was a power failure during recording.

• The DVD recorder's internal clock stopped due to a power

failure that lasted for more than 30 seconds. Reset the clock (pages 24-25).

• Disconnect the AC power cord from the AC outlet, and

connect it again.

• The program contains copy protection signals that restricts

copying.

• The timer setting overlapped with another setting that was set

later or has priority.

• It will take a few seconds for the DVD recorder to input disc

data before recording can stop.

• The timer setting overlapped with another setting that was set

later or has priority (page 38).

• Disc space was not enough.

Before you start Connections

Getting started

Recording

Playing discs

Editing

Changing the SETUP menu

Others Español

Français

Others

Troubleshooting (cont’d)

Symptom Remedy

Remote control

The remote contorl does not function. • Batteries are weak.

Others

The DVD recorder does not operate properly.

The disc tray does not open when you press OPEN/CLOSE A button.

• There are obstacles between the remote contorl and the DVD

recorder.

• The remote contorl is far from the DVD recorder.

• There are no batteries in the remote contorl.

•Turn on the DVD recorder.

• The remote contorl is not pointed at the remote sensor on the

DVD recorder.

• When static electricity, etc., causes the DVD recorder to

operate abnormally, unplug the DVD recorder and then plug it in again.

• It may take a few seconds for the disc tray to open after you

have recorded or edited a disc.

• This is because the DVD recorder is adding disc data to the

disc.

"Repairing" appears on the display. • If there is a power failure or unplugging during recording,

Repairing

Disc Error

--- Please eject the disc. --- Playback feature may not be

available on this Disc.

Region Error

--- Please eject the disc. --- Playback is not authorized in your

region.

Parental Lock On

--- Please eject the disc. --- The current selected parental level

Prohibits playback.

Recording Error

This program is not allowed to be recorded.

Recording Error

This program is not recordable in Video mode.

Recording Error

Can not record on this disc.

Recording Error

This program is not allowed to be recorded on this disc.

Recording Error

This disc is protected and not recordable.

Unplayable disc is inserted in the DVD recorder.

Playback is not authorized because the region code of the DVD video disc you inserted is different.

The current selected parental level in the SETUP Menu prohibits playback.

The recording function encountered the copy prohibited program.

You are trying to record the copyonce program onto the DVD-RW disc in Video mode or the DVD-R disc.

You are trying to record onto the disc which is unrecordable, or the disc status prevents recording.

You are trying to record a copyonce program onto a DVD-RW disc which is not compatible with CPRM.

You are trying to record on to the protected disc which is set in the Disc Setting Menu.

finalizing, formatting or editing, a Repairing process will begin automatically just after turning the DVD recorder on again.

It may take several minutes up to about four hours.

CauseError message Solution

Insert the standardized disc which bear the marks on page 44.

Insert the DVD-Video disc with region codes 1 or ALL.

Check the "Parental Lock" setting (pages 94-95).

You cannot record copy prohibited programs.

Set "DVD-RW Recording Format" to "VR mode" (page 30).

Insert the recordable disc, and ensure the disc status satisfies the recording requirements (pages 28-43).

Insert a ver.1.1 CPRM compatible DVD-RW disc (page 29).

Release the disc protect setting in the Disc Setting menu (page 43).

Others

Troubleshooting (cont’d)

CauseError message Solution

Before you start Connections

Recording Error

Disc is full.

(No area for new recording)

Recording Error

You cannot record more than 99 titles on one disc.

(The maximum is 99)

Recording Error

You cannot record more the 999 chapters on one disc.

(The maximum is 999)

Recording Error

You cannot record on this disc as Control Information is full.

Recording Error

You cannot record on the disc as Power Calibration Area is full.

Recording Error

This disc is already finalized.

You are trying to record onto the disc which has no space for recording.

You are trying to record onto the disc on which the number of recording titles comes up to the maximum (99).

You are trying to record onto the VR mode DVD-RW disc on which the number of recording chapters comes up to the maximum (999).

This disc has no space to write the Control Information when recording or deleting contents.

When editing has been repeatedly performed, the control Information area may come up to be full even the recording area has enough space.

This disc's working area for recording is full.

When recordings are performed repeatedly onto an unstable disc, this area may come up to be full.

You are trying to record onto the disc already finalized.

Insert the recordable disc with enough recording space.

Delete unnecessary titles (pages 63, 67, 76).

Delete unnecessary chapter markers (pages 71, 80).

Delete unnecessary titles (pages 63, 67, 76).

Insert a new disc.

Release the finalizing for this disc (page 42).

Getting started

Recording

Playing discs

Editing

* If you are still having trouble with the DVD recorder after checking Troubleshooting, write down the error code

and the error description for calling our help line mentioned on the front page to locate an Authorized service center.

Changing the SETUP menu

Others Español

Français

Analog audio

An electrical signal that directly represents sound. Compare this to digital audio which can be an electrical signal, but is an indirect representation of sound. See also Digital audio.

Aspect ratio

The width of a TV screen relative to its height. Conventional TVs are 4:3 (in other words, the screen is almost square); widescreen models are 16:9 (the screen is almost twice as wide as it is high).

Chapter

Just as a book is split up into several chapters, a title on a DVD disc is usually divided into chapters. See also Title.

Component video output

Each signal of luminance(Y) and component(PB/CB,PR/CR) is inde- pendent to output so that you can experience picture color as it is. Also, due to compatibility with progressive video (525p/480p), you can experience higher-density picture than that in interlace (525i/480i).

CPRM (Content Protection for Recordable Media)

CPRM is a copy protection system with scramble system regarding the recording of “copy-once” broadcast programs (e.g. some satellite broadcasts).

Digital audio

An indirect representation of sound by numbers. During recording, the sound is measured at discrete intervals (44, 100 times a second for CD audio) by an analog-to-digital converter, generating a stream of numbers. On playback, a digital-to-analog converter generates an analog signal based on these numbers. See also Sampling frequency and Analog audio.

Others

Glossary

Dolby Digital

The system to compress digital sound developed by Dolby Laboratories. It offers you sound of stereo(2ch) or multi-channel audio (up to 5.1ch).

DTS (Digital Theater System)

DTS is a 5.1 channel surround sound system, but it is different from Dolby Digital.The formats were developed by Digital Theater System, Inc.

MP3 (MPEG Audio Layer 3)

MP3 is a method of compressing files.You can copy MP3 files on CD-R/RW discs from the computer and play the files on this unit.

Finalize

To make DVD discs, which have been recorded on, possible to play in DVD players.With this DVD recorder, it is possible to finalize DVD-R/DVD-RW discs.

PCM (Pulse Code Modulation)

The most common system of encoding digital audio, found on CDs and DAT. Excellent quality, but requires a lot of data compared to formats such as Dolby Digital and MPEG audio. For compatibility with digital audio recorders (CD, MD and DAT) and AV amplifiers with digital inputs, this unit can convert Dolby Digital and MPEG audio to PCM. See also Digital audio.

Playlist

From this list you can play contents of a disc as your desired order or in sequence.Also it is allowed to search a specific scene directly.

Progressive Scan (525p/480p)

A type of display that does not split each frame into fields, and instead scans directly through all the scanlines of each frame in order. Progressive Scan provides less flickering and higher image resolution than traditional (525i/480i) TV signals.Refer to page 13 for instructions on selective Progressive Scan mode.

Regions code

Regions associate discs and players with particular areas of the world.This unit will only play discs that have compatible region codes.You can find the region code of your unit by looking on the rear panel. Some discs are compatible with more than one region (or all regions).

Sampling frequency

The rate which sound is measured by a specified interval to turn into digital audio data.The numbers of sampling in one second defines as sampling frequency.The higher the rate, the better the sound quality as possible as it is.

SAP (Secondary Audio Program)

Sub-audio channel which is delivered separately from main-audio channel.This audio channel is used as an alternate in bilingual broadcasting.

S-Video output

It delivers independently each signal of color(C) and luminance(Y) to TV as video signals, so that higher-quality picture will be gained.

Title (DVD only)

A collection of chapters on DVD disc. See also chapter.

Track

Audio CDs use tracks to divide up the content of a disc.The DVD equivalent is called a chapter. See also Chapter.

VCR Plus+ system

Allows you to set a timer recording by entering a PlusCode number found in participating TV listings.

100

FUNAI FDR-90E User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
