Data Sheet FUJITSU Desktop ESPRIMO Q558
Fujitsu recommends Windows 10 Pro.
Data Sheet
FUJITSU Desktop ESPRIMO Q558
Powerful PC functionality in small package
The FUJITSU ESPRIMO Q558, featuring full desktop PC functionality in a stylish and compact mini PC, is
a real eye-catcher on your desk. The latest 8th Gen Intel® Core™ processors (with up to 6 cores and 12
threads) provide the performance to meet your daily ofce needs. The Zero Noise PC function ensures
silent operation. With its integrated, energy-efcient power supply and an innovative Low Power
Active Mode feature, this mini PC helps reduce your energy bill while ensuring instant communication
capabilities in your ofce. Its compact size and wide range of interfaces make the FUJITSU ESPRIMO
Q558 an ideal choice for ofces where space saving is critical for the business.
An elegant mini PC for standard office applications
Eye-catching exclusive modern design
Fully equipped PC with a volume of ~2.0 liters - based on standard desktop technology
Zero Noise PC
Pleasant working environment due to completely quiet system (solid state disk required)
Fan stop in standard operations
Superb usability
Efcient working environment due to a tidy desk with perfect access to front connectors
Horizontal or vertical operations and an optional VESA mount, easy upgrade of major components
Always Available Office PC - stay connected and save power
Be ready for instant communication and a signicantly reduced energy bill
Innovative Low Power Active Mode and energy-efcient, integrated power supply
Manageability and Ease of Use
‘”Plug & work” PC that ensures smooth system administration
Easy to integrate into existing IT landscapes and reliable DeskView manageability tools
Page 1 / 8 www.fujitsu.com/fts/ESPRIMO
Data Sheet FUJITSU Desktop ESPRIMO Q558
Fujitsu recommends Windows 10 Pro.
Components
Processor Intel® Core™ i7-8700T processor (6 Cores / 12 Threads, 2.40 GHz, up to 4.0 GHz, 12 MB, Intel® UHD Graphics 630) *
Intel® Core™ i5-8500T processor (6 Cores / 6 Threads, 2.10 GHz, up to 3.5 GHz, 9 MB, Intel® UHD Graphics 630) *
Intel® Core™ i5-8400T processor (6 Cores / 6 Threads, 1.70 GHz, up to 3.3 GHz, 9 MB, Intel® UHD Graphics 630) *
Intel® Core™ i3-8100 processor (4 Cores / 4 Threads, 3.60 GHz, 6 MB, Intel® UHD Graphics 630)
Intel® Pentium® Gold G5400 processor (2 Cores / 4 Threads, 3.70 GHz, 4 MB, Intel® UHD Graphics 610)
*with Intel® Turbo Boost Technology (clock speed and performance will vary depending on workload and other
variables)
Operating systems
Operating system pre-installed Windows 10 Pro. Fujitsu recommends Windows 10 Pro.
Windows 10 Home
Memory modules 4 GB (1 module(s) 4 GB) DDR4, non-ECC, 2,666 MHz, SO DIMM
8 GB (1 module(s) 8 GB) DDR4, non-ECC, 2,666 MHz, SO DIMM
16 GB (1 module(s) 16 GB) DDR4, non-ECC, 2,666 MHz, SO DIMM
Hard disk drives (internal) SSD PCIe, 1024 GB M.2 NVMe module
SSD PCIe, 512 GB M.2 NVMe module
SSD PCIe, 256 GB M.2 NVMe module
SSD PCIe, 1024 GB M.2 NVMe module, SED
SSD PCIe, 512 GB M.2 NVMe module, SED
SSD PCIe, 256 GB M.2 NVMe module, SED
SSD SATA III, 1024 GB, 2.5-inch
SSD SATA III, 512 GB, 2.5-inch
SSD SATA III, 256 GB, 2.5-inch
SSD SATA III, 128 GB, 2.5-inch
HDD SATA III, 7,200 rpm, 500 GB, 2.5-inch
HDD SATA II, 5,400 rpm, 1,000 GB, 2.5-inch*
HDD SATA II, 5,400 rpm, 500 GB, 2.5-inch*
Hard disk notes SSD (Solid State Disk)
SED (Self-Encrypting Drive)
Graphics DP to DVI-D (single link) Adapter Cable
Drives (optional) BD Triple Writer SATA ultra slim (tray)
DVD Super Multi ultra slim (tray)
Interface add on cards/components
(optional)
Serial Port
M.2 WLAN 802.11ac (2x2) and BT 5 (dedicated regions only)
Base unit
Base unit ESPRIMO Q558
Mainboard
Mainboard type D3603
Formfactor proprietary
Chipset Intel® H310
Page 2 / 8 www.fujitsu.com/fts/ESPRIMO
Data Sheet FUJITSU Desktop ESPRIMO Q558
Mainboard
Processor socket LGA 1151
Processor quantity maximum 1
Supported capacity RAM (max.) 32 GB
Memory slots 2 DIMM (DDR4)
Memory frequency 2,666 MHz
Memory notes Dual channel support
For dual channel performance, 2 memory modules have to be ordered. Capacity per channel has to be the same.
2666 MHz may be clocked down to 2400 MHz depending on processor and memory conguration
LAN 10/100/1,000 MBit/s Realtek RTL8111GN
Integrated WLAN 1 (optional with Bluetooth together)
BIOS version AMI Aptio V
UEFI Specication 2.6
BIOS features BIOS Flash EPROM update by software
Recovery BIOS
Unied Extensible Firmware Interface (UEFI)
Audio type On board
Audio codec Realtek ALC671
Audio features Internal speaker supports audio playback (optional), High Denition audio
Fujitsu recommends Windows 10 Pro.
I/O controller on board
Serial ATA total 2
thereof SATA III 2
Controller functions Serial ATA III (6 Gbit)
NCQ
AHCI
Interfaces
Audio: line-out 1
Front audio: microphone 1
Front audio: headphone 1
USB 2.0 total 4
USB 3.1 Gen1 (USB 3.0) total 4
USB front 2x USB 3.0
USB rear 4x USB 2.0 and 2x USB 3.0
VGA optional: via external active adapter cable
DisplayPort 2
DVI 1 (DVI-D)
Serial (RS-232) optional: serial port (9pin, 16 byte FIFO, 16550 compatible)
Mouse / Keyboard (PS/2) 0/1 optional (with PC on/off function on Pin6)
Ethernet (RJ-45) 1
Interface Module notes Anytime USB charge functionality
Input device / components
Input devices (optional) Keyboard
Mouse
KBPC PX ECO
Mouse M440 ECO
Drive bays
Drive bays total 3
2.5-inch bays 1
2.5-inch internal bays 1
5.25-inch external bays 1
M.2-2280 1 x on mainboard for SSD NVMe (PCIe 2.0 x2; up to 10Gbit/s)
Mini PCI slots
Page 3 / 8 www.fujitsu.com/fts/ESPRIMO
Data Sheet FUJITSU Desktop ESPRIMO Q558
M.2-2230 on mainboard for WLAN module
Graphics on board
Graphics brand name Intel® UHD Graphics 610, Intel® UHD Graphics 630
Shared video memory up to 1,782 MB
TFT resolution (DVI) 1,280 x 1,024 pixel
1,360 x 768 pixel
1,440 x 900 pixel
1,600 x 900 pixel
1,680 x 1,050 pixel
1,920 x 1,080 pixel
1,920 x 1,200 pixel
TFT resolution (DisplayPort) 1,280 x 1,024 pixel
1,360 x 768 pixel
1,440 x 900 pixel
1,600 x 900 pixel
1,680 x 1,050 pixel
1,920 x 1,080 pixel
1,920 x 1,200 pixel
2,560 x 1,440 pixel
2,560 x 1,600 pixel
3,440 x 1,440 pixel
3,840 x 2,160 pixel
4,096 x 2,304 pixel
Graphics features Dual display support
DirectX® 12
HDCP support
OpenCL™ 2.0 (requires Intel® Core™ i3, i5 or i7 processors)
OpenGL® 4.4
DisplayPort interface supports Ver. 1.2 incl. Multi-Stream
DVI-D interface supports audio output for HDMI monitors
Graphics notes up to 1 GB dedicated video memory (main memory owned and locked for graphics use)
Tested resolutions, depending on display type additional resolutions and frequencies possible
Shared memory depending on main memory size and operating system
Resolution (color depth up to 32 Bit/pixel)
For TFT we recommend using 60Hz
Fujitsu recommends Windows 10 Pro.
Electrical values
Power efciency note power supply efciency (at 230V; 2 Watt/ 10% / 20% / 50% / 100% load) : > 85%/ 90% / 90% / 92% / 92%
Rated voltage range 100 V - 240 V
Rated frequency range 50 Hz - 60 Hz
Operating voltage range 90 V - 264 V
Operating line frequency range 47 Hz - 63 Hz
Max. output of single power supply 65 W (integrated in system)
Power factor correction/active power No (meets input harmonic current according EN61000-3-2)
Power consumption
Power consumption note See white paper Energy Consumption
Heat dissipation
Heat dissipation notes See white paper Energy Consumption
Noise emission
Related Processors for noise Intel® Core™ i7 8700T
Standard noise emission 2x4 GB, HDD, ODD, Windows
According to ISO 7779:2010, ECMA-74
Standard noise notes / description A-weighted sound power level Lwad (in B) / Workplace related A-weighted sound pressure level LpAm (in dB(A))
Standard noise operation mode: CPU
50% load
Standard noise operation mode: HDD
load
tbd
tbd
Page 4 / 8 www.fujitsu.com/fts/ESPRIMO
Data Sheet FUJITSU Desktop ESPRIMO Q558
Noise emission
Standard noise operation mode: Idle
mode
Standard noise operation mode: ODD
load
Standard noise operation mode: Ofce
applications 2.0
Dimensions / Weight / Environmental
Dimensions (W x D x H) 185 x 190 x 54 mm; with VESA cover: 185 x 190 x 56.2 mm
Operating position Vertical / horizontal (no feet needed)
VESA mount optional VESA cover required
Weight 1.6 kg
Weight (lbs) 3.53 lbs
Weight notes Actual weight may vary depending on conguration
Operating ambient temperature 10 - 35 °C (50 - 95 °F)
Operating relative humidity 5 - 85 % (relative humidity)
Compliance
Product ESPRIMO Q558
Model MPC3
Germany GS (planned)
Europe CE
USA/Canada FCC Class B
Global RoHS (Restriction of hazardous substances)
China CCC (planned)
Compliance notes This product is free of polyvinyl chloride (PVC) when ordered with the optional PVC free power cord
Compliance link https://sp.ts.fujitsu.com/sites/certicates
tbd
tbd
tbd
7.29 x 7.49 x 2.13 inch
cTUVus
WEEE (Waste electrical and electronic equipment)
Microsoft Operating Systems (HCT / HCL entry / WHQL)
ENERGY STAR® in progress
EPEAT® in progress (dedicated regions)
CCC (depending on conguration)
CEL (Chinese energy label)
TPM 2.0 for China (optional)
Fujitsu recommends Windows 10 Pro.
Additional Software
Additional software (preinstalled) Adobe® Reader® (pdf reader)
McAfee Multi Access Security (anti-virus and internet security software; 60 days trial version)
Microsoft Ofce (buy license to activate the pre-installed Microsoft Ofce)
Additional software (optional) Recovery DVD for Windows®
Drivers & Utilities DVD (DUDVD)
CyberLink PowerDVD BD (playback software for Blu-ray Disc™)
CyberLink PowerDVD DVD (playback software for DVD)
Nero Essentials XL
Manageability
Manageability technology DeskUpdate Driver management
PXE 2.1 Boot code
Wake up from S5 (off mode)
WoL (Wake on LAN)
Manageability software DeskView Client
DeskView Instant BIOS Management
DeskView components BIOS Management incl. Security
Inventory Management
Driver Management
Alarm Management
Page 5 / 8 www.fujitsu.com/fts/ESPRIMO
Data Sheet FUJITSU Desktop ESPRIMO Q558
Manageability
Supported standards DMI (Desktop Management Interface)
SMBIOS (System Management BIOS)
PXE (Preboot Execution Environment)
WMI (Windows Management Instrumentation)
WBEM (Web Based Enterprise Management)
CIM (Common Information Model)
Manageability link http://www.fujitsu.com/fts/manageability
Physical Security Kensington Lock support
Eye for padlock
Housing Lock Spring (to use with Kensington lock), (optional)
System and BIOS Security Embedded security (TPM 2.0)
EraseDisk (optional)
Credential Guard Ready and Device Guard Capable (Windows 10, v. 1709)
Boot sector virus protection
Write protect option for the Flash EPROM
Control of all USB interfaces
External USB ports can be disabled separately
Control of external interfaces
User Security User and supervisor BIOS password
Hard disk password
Access protection via internal SmartCard reader (optional)
Access protection via external SmartCard reader (optional)
Workplace Protect (secure authentication solution)
Workplace Embedded Tools Auto BIOS Update via Fujitsu Server
Auto BIOS Update via customer server
Easy PC Protection
Fujitsu recommends Windows 10 Pro.
Miscellaneous
Keyboard on (Special Fujitsu keyboard required)
Keyboard on with one key (KBPX Eco, KB521)
Keyboard on with 2 keys (CTRL+CTRL) with PS2 or special USB keyboards
Keyboard on with any key (USB)
Thermal management
Low Power Active Mode
Extended lifetime
Serviceability
EasyChange for HDD
EasyChange for optical drives
Packaging information
Packaging dimension (mm) 395 x 198 x 284 mm
Packaging dimension (inch) 15.55 x 7.8 x 11.18 inch
Max. quantity / pallet 84
Material - Weight (g) Carton 670 g
Material - Weight (lbs) Carton 1.48 lbs
Material - Weight (g) EPS / PS 10 g
Material - Weight (lbs) EPS / PS 0.02 lbs
Material - Weight (g) PE 125 g
Material - Weight (lbs) PE 0.28 lbs
Packaging notes If keyboard is inlcuded in packaging: 1.)packaging dimension is increasing to: 500 x 208 x 290mm / (19.69 x
8.19 x 11.42 inch); 2.) material weight of carton will increase to 880g; 3.) max. quantity/pallet = 56; printed user
documentation is bleached in chlorin free process;
Warranty
Warranty period 1 year (for countries in EMEIA)
Warranty type Bring-In / Onsite Service (for countries within region EMEIA, for all other countries depending on local regulations)
Warranty Terms & Conditions http://support.ts.fujitsu.com/warranty
Product Related Services - the perfect extension
Page 6 / 8 www.fujitsu.com/fts/ESPRIMO
Data Sheet FUJITSU Desktop ESPRIMO Q558
Warranty
Recommended Service - 9x5, Onsite Response Time: Next Business Day
Spare Parts availability 5 years after end of product life
Service Weblink http://www.fujitsu.com/fts/services/support
Recommended Accessories
Fujitsu recommends Windows 10 Pro.
Wireless Mouse Touch WI910 The Fujitsu Wireless Mouse Touch WI910 has a special touch sensitive
surface that recognizes when your hand touches the mouse even
before you move it. This provides nearly instantaneous wake-up from
the intelligent energy saving sleep mode. Unbeatable responsiveness
combines with features like switchable resolution, and three programmable
buttons for a unique user experience.
Keyboard KB950 Phone The KB950 Phone is a modern and slim line USB keyboard with integrated
Skype for business features. This extremely reliable, high-speed input
device is the perfect way to manage incoming and outgoing calls, even
when the system is locked. Three additional keys make it easy to accept
and end calls and mute your microphone during a call. Easy number dialing
is assured with the numpad. The integrated 61 x 12 mm display shows the
time and date, the user status and shows incoming call data in the form of
the calling number and caller ID.
Order Code:
S26381-K465-L100
S26381-F950-L4** (**:
Country specic variation)
Page 7 / 8 www.fujitsu.com/fts/ESPRIMO
Data Sheet FUJITSU Desktop ESPRIMO Q558
More information
Fujitsu recommends Windows 10 Pro.
Fujitsu products, solutions & services
In addition to FUJITSU Desktop ESPRIMO Q558,
Fujitsu provides a range of platform solutions.
They combine reliable Fujitsu products with
the best in services, know-how and worldwide
partnerships.
Fujitsu Portfolio
Build on industry standards, Fujitsu offers a full
portfolio of IT hardware and software products,
services, solutions and cloud offering, ranging
from clients to datacenter solutions and
includes the broad stack of Business Solutions,
as well as the full stack of Cloud offering. This
allows customers to leverage from alternative
sourcing and delivery models to increase
their business agility and to improve their IT
operation’s reliability.
Computing Products
www.fujitsu.com/global/products/computing/
Software
www.fujitsu.com/software/
More information
Learn more about FUJITSU Desktop ESPRIMO
Q558, please contact your Fujitsu sales
representative or Fujitsu Business partner, or
visit our website.
www.fujitsu.com/fts/ESPRIMO
Fujitsu green policy innovation
Fujitsu Green Policy Innovation is our
worldwide project for reducing burdens on the
environment.
Using our global know-how, we aim to
contribute to the creation of a sustainable
environment for future generations through IT.
Please nd further information at http://www.
fujitsu.com/global/about/environment
Copyrights
All rights reserved, including intellectual
property rights. Changes to technical data
reserved. Delivery subject to availability.
Designations may be trademarks and/or
copyrights of the respective manufacturer,
the use of which by third parties for their
own purposes may infringe the rights of such
owner. For further information see http://www.
fujitsu.com/fts/resources/navigation/terms-ofuse.html
Copyright 2018 Fujitsu Technology Solutions
GmbH
Disclaimer
Technical data is subject to modication and
delivery subject to availability. Any liability
that the data and illustrations are complete,
actual or correct is excluded. Designations
may be trademarks and/or copyrights of the
respective manufacturer, the use of which
by third parties for their own purposes may
infringe the rights of such owner.
Contact
Fujitsu Technology Solutions GmbH
Website: www.fujitsu.com/fts
2018-07-04 EM-EN
Page 8 / 8 www.fujitsu.com/fts/ESPRIMO
All rights reserved, including intellectual property rights. Changes to technical data reserved. Delivery subject to availability.
Designations may be trademarks and/or copyrights of the respective manufacturer, the use of which by third parties for
their own purposes may infringe the rights of such owner. For further information see http://www.fujitsu.com/fts/resources/
navigation/terms-of-use.html
Copyright 2018 Fujitsu Technology Solutions GmbH
Loading...
