AMILO Pro
V3525 / V3545 Edition
Your gateway to mobile working
The AMILO Pro V3525 / V3545 Editions are professional companions for the price-conscious, casual user. Th ese
notebooks are the ultimate balance of valuable performance and best-in-class mobility at very attractive prices.
These AMILO Pro V Editions offer a crisp 15.4-inch WXGA display and ergonomic working.
The combination of AMILO Pro V3545 Edition with a large-diagonal 15.4-inch display and the latest NVIDIA
Go 7300 graphics deliver the convenience of display brilliance and outstanding graphics.
Ideal for users working both on the road and in the office, it features a built-in optical disk drive, modem, LAN and
WLAN. The built-in UMTS module offers you unlimited freedom of connectivity wherever you are.
Pages 3
Issue January 2007
® GeForce®
Mobility
Valuable mobility at reasonable price
Excellent price / performance ratio fits suiting all budgets
Ready configured and constantly enhanced with latest technolog y
Convenient technology for mobile working
Power-saving and high performance
Intel® Core™ 2 Duo Processor
Ideal connectivity through built-in UMTS (optional),
Wireless LAN, LAN and modem
Ease of use through built-in DVD writer
Ergonomics and flexibility in- and outside the office
Enjoy the viewing quality of brilliant
15.4-inch WXGA-TFT display
Full-size keyboard for ergonomic working
4 x USB (2.0) ports for easy connectivity to all
peripherals and external storage devices
Robustness on the move
Mechanical and function stability through extensive quality tests
German quality standards
RoHS compliant for environmental friendly working
Award-winning best-in-class manufacturing
Intel® Core™ Duo or
Data Sheet ⏐ Issue: January 2007⏐ AMILO Pro V3525/V3545 Edition Page 2 / 3
Processor
Intel® Core 2™ Duo Processor up to T7600 up to T7600
Second level cache 4 MB 4 MB
Front side bus (FSB) 667 MHz 667MHz
Intel® Core™ Duo Processor T2250, T2400 T2250, T2400
Second level cache 2 MB 2 MB
Front side bus (FSB) 533 / 667 MHz 533 / 667 MHz
Intel® Celeron M™ Processor M520 M520
Second level cache 1 MB 1 MB
Front side bus (FSB) 533 MHz 533 MHz
Chipset
Northbridge Intel 945GM Intel 945PM
Southbridge ICH 7-M ICH 7-M
Memory
DDR2-533 SDRAM, 533 / 667 MHz
DIMM slots 2 2
BIOS
BIOS Flash EPROM Phoenix First BIOS Phoenix First BIOS
Interfaces
Type I/II PC Card slot 1 1
3in1 Card Reader (SD, MMC and memory stick) 1 1
USB 2.0 4 4
S-Video out (TV-out) 1 1
VGA 1 1
Modem RJ-11 1 1
LAN RJ-45 1 1
Audio-in (line-in / microphone) 1 1
Audio-out (line-out / headphone) 1 1
DC-in 1 1
Kensington Lock 1 1
Modem on board
56K V.92 modem MDC1.5 x x
LAN on board
built-in 10/100/1000 Mbps Marvell 88E8055 x x
Wireless Technologies (WLAN)
Import and usage according to country-specific regulations.
Dual band antenna
Intel PRO/Wireless 3945 a/b/g x x
Integrated UMTS (HSDPA 1.8 Mb/s), also supported are GPRS and EDGE optional optional
Bluetooth
Bluetooth V2.0 optional optional
Audio
Stereo speakers x x
Sound chip RealTek ALC861 RealTek ALC861
Internal microphone x x
Keyboard and pointing device
Keyboard
Touchpad with two mouse buttons with two mouse buttons
Launch keys 2 keys 2 keys
Status LED x x
Graphics
Intel GMA 950 with 256-bit graphics core with dynamic video memory
technology up to 224MB, 32-bit color depth
NVIDIA GeForce Go 7300 128 MB VRAM (up to 512 MB Turbo Cache) - x
Direct X9 x x
Pixelshader 2.0 x x
DualView (Windows XP) x x
Display
15.4-inch TFT WXGA / 1280 x 800 pixel x x
Max. resolution for external displays
Hard disk drives (internal) *
Up to 160 GB S-ATA 150 (5400 rpm) x x
* 1 Gbyte equals one billion bytes, when referring to hard disk drive
capacity; accessible capacity may vary, also depending on used software
and tool.
Fixed drives
DVD+/- RW Dual layer (+R) Multiformat DVD writer with
double layer support
Manageability
Supported Standard
PXE x x
System AMILO Pro V3525 Edition AMILO Pro V3545 Edition
up to 2 GB
(maximum 4 GB supported
with future modules )
85 keys, 19mm pitch,
2.5mm key stroke
x -
1600 x 1200 / true color /
85 Hz
x x
up to 2 GB
(maximum 4 GB supported
with future modules )
85 keys, 19mm pitch,
2.5mm key stroke
1600 x 1200 / true color /
85 Hz
Data Sheet ⏐ Issue: January 2007⏐ AMILO Pro V3525/V3545 Edition Page 3 / 3
Security
Physical security
Kensington Lock support x x
System Security
Norton Internet Security Symantec x x
User Security
User and supervisor BIOS password x x
Hard disk password x x
Power supply
st
1
Li-Ion battery 6 cell 4400 mAh (48 Wh) x x
Battery runtime:
First battery * (Mobile Mark 2002) [up to] 4 h (tbc) 3 h (tbc)
AC adapter 20V/65W Adapter or 20V/90W depends on CPU
Rated voltage (AC input) 100 - 240 V
Rated frequency 50 - 60 Hz
DC output 20 V, 3.25 A or 4.5 A
Dynamic charge supported (rapid charge) x x
* Battery life may vary depending on product model, configuration,
applications, power management settings and features utilized. Battery
recharge time depends on usage.
Operating temperatures
Relative humidity (non-condensing) 20% - 85% 20% - 85%
Ambient temperature 5° - 35° C 5° - 35° C
Dimensions / Weight
Dimensions (H x W x D) 24~34 x 355 x 255 mm 24~34 x 355 x 255 mm
Weight* 2.8 kg 2.8 kg
* Weight may vary depending on actual configuration
Certificates
CE according to EU Directives 89/336/EEC (EMC)
73/23/EEC (Product safety)
CE according to 99/5/EEC (R&TTE) x x
CE! (Wireless) x (with integrated WLAN) x (with integrated WLAN)
CE (Emission/Immunity) x x
R&TTE x x
CB Generic Report x x
CB (Safety) x x
RoHS x x
WHQL x x
TBR21 x x
Operating System
Fujitsu Siemens Computers recommends
Microsoft® Windows® XP Professional
Microsoft Windows XP Professional x x
Windows Vista™ capable x x
1)
Windows Vista™ capable x x
(min. 512 MB RAM necessary)
1)
Windows Vista™ Premium Ready
(min. 1GB RAM / DVD reader necessary)
Microsoft Windows XP Home x x
Software (compatibility / preinstalled)
Adobe Acrobat Reader x x
Driver and Utility DVD x x
Easy Guide on-line user documentation x x
Nero x x
Norton Internet Security (incl. Firewall) on Driver and Utility CD x x
Toshiba Stack 4.x with Bluetooth with Bluetooth
Odyssey Client x x
UMTS watcher with UMTS with UMTS
WinDVD for MPEG II decode optional optional
Accessories (order number)
AC-adapter 20V/90W S26391-F321-L400 S26391-F321-L400
Prestige case midi S26391-F119-L60 S26391-F119-L60
Prestige case top L S26391-F119-L64 S26391-F119-L64
Port Replicator S26391-F6007-L100 S26391-F6007-L100
High capacity battery 6 cell 5200 mAh (56 Wh) S26391-F400-L400 S26391-F400-L400
http://www.fujitsu-siemens.com/accessories/
(1) Not all Windows Vista™ features are available for use on all Windows Vista Capable PCs. All Windows Vista Capable PCs will run the core experiences of Windows Vista, such as
innovations in organizing and finding information, security, and reliability. Some features available in premium editions of Windows Vista -- like the new Windows® Aero™ user interface -require advanced or additional hardware. Check www.windowsvista.com/getready for details.
This datasheet describes the highest configurations. The product is offered in fixed configurations which vary from country to country and edition to edition.
System AMILO Pro V3525 Edition AMILO Pro V3545 Edition
x x
x x
x x
All rights, including rights created by patent grant or registration of a utility model or design as well as
rights of technical modifications are reserved. Delivery subject to availability. Designations may be
trademarks, the use of which by third parties for their own purposes may violate the rights of the
trademark owners.
Copyright © Fujitsu Siemens Computers, 01/2007
