LifeBook V Series Notebook BIOS
V Series BIOS
BIOS SETUP UTILITY
The BIOS Setup Utility is a program that sets up the
operating environment for your notebook. Your BIOS
is set at the factory for normal operating conditions,
therefore there is no need to set or change the BIOS
environment to operate your notebook.
The BIOS Setup Utility configures:
■
Device control feature parameters, such as changing
I/O addresses and boot devices.
■
System Data Security feature parameters, such
as passwords.
Entering the BIOS Setup Utility
To enter the BIOS Setup Utility, do the following (or use
the TrustedCore Menu, as detailed in the next section):
1. Turn on or restart your notebook.
2. Press [F2] once the Fujitsu logo appears on the
screen. This will open the main menu of the BIOS
Setup Utility with the current settings displayed.
3. Press the [RIGHT ARROW] or [LEFT ARROW] key
to scroll through the other setup menus to review or
alter the current settings.
Using the TrustedCore Menu
When the Fujitsu logo appears on the screen. press the
[Enter] key or click on the left mouse or touchpad
button; the TrustedCore Menu will appear.
The TrustedCore Menu provides shortcuts to the
following menus and information screens:
■
BIOS Setup
■
Diagnostic Screen
■
Boot Menu
■
Patent Information
■
System Information
■
Continue Booting
Clicking on any of the fields will invoke the screen,
information, or action described.
The Boot Menu can also be invoked by pressing the
[F12] key when the Fujitsu logo appears on the screen.
Navigating through the Setup Utility
The BIOS setup utility consists of six menus: Info,
System, Advanced, Security, Boot, and Exit. This document explains each menu in turn, including all
submenus and setup items.
The following procedures allow you to navigate the
setup utility menus:
1. To select a menu, use the cursor keys:
[ ], [ ]
2. To select a field within a menu or a submenu, use the
cursor keys:
[ ], [ ].
3. To select the different values for each field, press the
[Spacebar] or [+] to change to the next lower
selection and [F5] or [-] to go to the next higher
selection.
4. To activate a submenu press the [Enter] key.
5. To return to a menu from a submenu, press the [Esc]
key.
6. To go to the Exit menu from any other menu,
press the [Esc] key.
■
Selecting a field causes a help message
about that field to be displayed on the
right-hand side of the screen.
■
Pressing the Enter key with the highlight
on a selection that is not a submenu or
auto selection will cause a list of all
options for that item to be displayed.
Pressing the Enter key again will select
the highlighted choice.
7. Pressing the [F9] key resets all items in the BIOS to
the default values.
8. Pressing the [F10] key saves the current configuration and exits the BIOS Setup Utility. You will be
asked to verify this selection before it is executed.
9. Pressing the [F1] key gives you a general help screen.
Entering the Setup Utility After a Configuration Change or System Failure
If there has been a change in the system configuration
that does not agree with the parameter settings stored in
your BIOS memory, or there is a failure in the system,
the system beeps and/or displays an error message after
the Power On Self Test (POST). If the failure is not too
2
severe, it will give you an opportunity to modify the
setup utility settings, as described in the following steps:
1. When you turn on or restart the computer there is a
beep and/or the following message appears on the
screen:
Error message - please run SETUP
program Press <F1> key to continue,
<F2> to run SETUP
2. If an error message is displayed on the screen, and
you want to continue with the boot process and start
the operating system anyway, press the [F1] key.
■
If your notebook emits a series of beeps
that sounds like a code and the display is
blank, please refer to the Troubleshooting Section in the system User’s Guide.
The Troubleshooting Section includes a
list of error messages and their meanings.
■
If your data security settings require it,
you may be asked for a password before
the operating system will be opened.
3. If an error message is displayed on the screen, and
you want to enter the setup utility, press the [F2] key.
4. When the setup utility starts with a fault present, the
system displays the following message:
Warning!
Error message
[Continue]
5. Press any key to enter the setup utility. The system
will then display the Info Menu with current parameters values.
BIOS Setup Utility
3
LifeBook V Series Notebook BIOS
MAIN MENU – SETTING STANDARD SYSTEM PARAMETERS
The Main Menu allows you to set or view the current
system parameters. Follow the instructions for Navigating Through The Setup Utility to make any changes.
(See Navigating through the Setup Utility on page 2 for
more information.)
The following tables show the names of the menu fields
for the Main menu and its submenus, all of the options
for each field, the default settings and a description of
PhoenixBIOS Setup Utility
Main Advanced Security Boot Info Exit
System Time: [14:57:01]
System Date: [09/20/2007]
▲▲
Drive0 [FUJITSU MHV2080BH]
Drive1 [HL-DT-ST DVDRAM_GSA-T20N]
Language: [English (US)]
the field’s function and any special information needed
to help understand the field’s use.
System Time and System Date can also be
set from your operating system without
using the setup utility. Use the Date and
Time icon on your Windows Control panel
or type time or date from the MS-DOS
prompt.
Item Specific Help
Adjust calendar clock.
<Tab>, <Shift-Tab>, or
<Enter> selects field.
F1 Help
ESC Exit
Select Item
Select Menu
-/Space Change Values
Enter Select Sub-Menu
Figure 1. Main Menu
▲
F9 Setup Defaults
F10 Save and Exit
Table 1: Fields, Options and Defaults for the Main Menu
Note that the parameters listed in the following table may vary depending upon your system’s configuration.
Menu Field Options Default Description
System Time: –— –— Sets and displays the current time. Time is in a 24 hour format
System Date: –— –— Sets and displays the current date. Date is in a month/day/year
4
of hours:minutes:seconds with 2 digits for each. (HH:MM:SS).
Example: 16:45:57. You may change each segment of the time
separately. Move between the segments with the [Tab] key and/
or [Shift] + [Tab] keys.
numeric format with 2 digits each for month and day and 4 digits
for year. (MM/DD/YYYY) for example: 03/20/2006. You may
change each segment of the date separately. Move between the
segments with the [Tab] key and/or [Shift] + [Tab] keys.
Main Menu
Table 1: Fields, Options and Defaults for the Main Menu
Note that the parameters listed in the following table may vary depending upon your system’s configuration.
Menu Field Options Default Description
Drive0
Drive1
Language:
Selects Drive0
submenu
Selects Drive1
submenu
■
English (US)
■
Japanese (JP)
The product number of
the hard drive.
The product number of
the CD-ROM drive.
[English (US)] The default setting differs between the US/European and the
Display the type of device on this ATA/ATAPI interface, if there is
one. Pressing the Enter key selects the Drive0 submenu allowing
additional device configuration options for this interface.
Display the type of device on this ATA/ATAPI interface, if there is
one. Pressing the Enter key selects the Drive1 submenu allowing
additional device configuration options for this interface
Japanese model. Selects the display language for the BIOS. (Note
that this field may appear blank until the first time it is selected.)
5
LifeBook V Series Notebook BIOS
Drive0 Submenu of the Main Menu
The Drive0 submenu identifies what ATA devices are installed.
PhoenixBIOS Setup Utility
Main
Drive0 [FUJITSU MHV2080BH]
Type: [Auto]]
LBA Format
Item Specific Help
Select Serial ATA/ATAPI
drive installed here.
Total Sectors: 156301488
Maximum Capacity: 80026MB SATA1
[Auto]
The BIOS auto-types the
drive on boot time.
[None]
The drive is disabled.
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
Figure 2. Drive0 Submenu
Change Values
▲
Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
Table 2: Fields, Options and Defaults for the Drive0 Submenu of the Main Menu
Menu Field Options Default Description
Typ e:
LBA Format Logical Block Addressing (LBA)
Tot al S ect ors:
■
■
---
Auto
None
[Auto] Automatically selects the ATA/ATAPI device type. To change the
--- The total number of sectors on your hard disk
selection, press the spacebar. Select Auto to have the type automatically identified by the BIOS at POST. Select None if you don’t want
to select a primary master.
Maximum
Capacity:
6
---
--- The maximum capacity of your hard disk
Main Menu
Drive1 Submenu of the Main Menu
The Drive1 submenu allows you to configure secondary ATA devices, such as an optical drive.
PhoenixBIOS Setup Utility
Main
Drive1 [HL-DT-ST DVDRAM_GSA-T20N]
Type: [Auto]
Multi-Sector Transfers: [Disabled]
LBA Mode Control: [Disabled]
Transfer Mode: [Standard]
Ultra DMA Mode: [Disabled]
Item Specific Help
Select Serial ATA/ATAPI
drive installed here.
[Auto]
The BIOS auto-types the
drive on boot time.
[None]
The drive is disabled.
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
Figure 3. Drive1 Submenu
Change Values
▲
Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
Table 3: Fields, Options and Defaults for the Drive1 Submenu of the Main Menu
Menu Field Options Default Description
Typ e:
Multi-Sector
Transfers:
LBA Mode
Control:
■
Auto
■
None
■
Disabled
■
2 Sectors
■
4 Sectors
■
8 Sectors
■
16 Sectors
■
Disabled
■
Enabled
[Auto] NOTE: The Type field does not appear as a drop-down menu. Tap
[Disabled] This option cannot be changed when Auto is selected. Specify the
[Disabled] Enables or disables Logical Block Addressing in place of Cylinder,
the spacebar to cycle through the selections.
Selects the ATA/ATAPI device type. Select Auto to have the type
automatically identified by the BIOS at POST. If None is selected, all
of the following Set-up items do not appear.
number of sectors per block for multiple sector transfer.
Head, Sector addressing. This option cannot be changed when Auto
is selected.
7
LifeBook V Series Notebook BIOS
Table 3: Fields, Options and Defaults for the Drive1 Submenu of the Main Menu
Menu Field Options Default Description
Transfer Mode:■Standard
Ultra DMA
Mode:
■
Fast PIO 1
■
Fast PIO 2
■
Fast PIO 3
■
Fast PIO 4
■
Multiword DMA 1
■
Multiword DMA 2
■
Disabled
■
Mode 0
■
Mode 1
■
Mode 2
■
Mode 3
■
Mode 4
■
Mode 5
[Standard] This option cannot be changed when Auto is selected.Selects the
method for moving data to/from the drive. Autotype the drive to
select the optimum transfer mode. Multiword DMA is automatically
set to mode 1 for Fast PIO 1, Fast PIO 2, Fast PIO 3, and set to
mode 2 for Fast PIO 4 / DMA.
[Disabled] This option cannot be changed when Auto is selected. Selects the
method for moving data to/from the drive. Autotype the drive to
select the optimum transfer mode.
8
Advanced Menu
ADVANCED MENU – SETTING DEVICE FEATURE CONTROLS
The Advanced Menu allows you to:
■
Set the keyboard and mouse features.
■
Select between the display panel and an external CRT
display or video projector.
■
Enable or disable compensation for your display.
■
Enables or disables the internal controllers.
■
Configure CPU and USB features in your system.
PhoenixBIOS Setup Utility
Main Advanced Security Boot Info Exit
▲ ▲ ▲ ▲ ▲
Keyboard/Mouse Features
Video Features
Internal Device Configurations
▲
CPU Features
USB Features
▲
Miscellaneous Configurations
Event Logging
Follow the instructions for Navigating Through the
Setup Utility to make any changes.
The following tables show the names of the menu fields
for the Advanced Menu and its submenus, all of the
options for each field, the default settings and a description of the field’s function and any special information
needed to help understand the field’s use.
Item Specific Help
Configures keyboard/
mouse features.
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
Figure 4. Advanced Menu
Change Values
▲
Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
Table 4: Fields, Options and Defaults for the Advanced Menu
Menu Field Description
Keyboard/Mouse Features When selected, opens the Keyboard/Mouse Features submenu, which allows turning NumLock on or off.
Video Features When selected, opens the Video Features submenu, which allows setting of the display parameters,
Internal Device
Configurations
CPU Features When selected, opens the CPU Features submenu to allow you to enable or disable the SpeedStep® Tech-
USB Features When selected, opens the USB Features submenu to allow you to enable or disable the legacy support and
including routing of video signals to different displays.
When selected, opens the Internal Device Configuration submenu, which allows enabling or disabling the
Serial ATA, IDE, and LAN Controllers.
nology feature and XD Bit functionality.
SCSI SubClass support (e.g., floppy disk drive, external optical drive).
9
LifeBook V Series Notebook BIOS
Table 4: Fields, Options and Defaults for the Advanced Menu
Menu Field Description
Miscellaneous
Configurations
Event Logging When selected, opens the event logging submenu.
When selected, opens the Miscellaneous Configurations submenu to allow you to enable or disable the
power button and the Wake Up On LAN feature, and to set the Volume Setting.
10
Advanced Menu
Keyboard/Mouse Features Submenu of the Advanced Menu
The Keyboard Features submenu is for enabling or disabling the NumLock feature.
PhoenixBIOS Setup Utility
Main Advanced Security Power Savings Exit
Numlock:
Keyboard/Mouse Features
[Off]
Item Specific Help
[On] or [Off]
Numlock in On or Off.
* Windows XP preserves
Numlock state when the
user logs off.
F1 Help
ESC Exit
Select Item
Select Menu
Figure 5. Keyboard Features Submenu
-/Space
Enter
Change Values
▲
Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
Table 5: Fields, Options and Defaults for the Keyboard Submenu of the Advanced Menu
Menu Field Options Default Description
Numlock:
■
On
■
Off
[Off] Sets the NumLock function state when the computer completes
booting.
11
LifeBook V Series Notebook BIOS
Video Features Submenu of the Advanced Menu
The Video Features Submenu is for setting the display parameters.
PhoenixBIOS Setup Utility
Main Advanced Security Power Savings Exit
Video Features
Display: [Auto]
Item Specific Help
Select display terminal.
Compensation: [Enabled]
* This setting is not
effective after
operating system
starts up.
F1 Help
ESC Exit
Select Item
Select Menu
Figure 6. Video Features Submenu
-/Space
Enter
Change Values
▲
Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
Table 6: Fields, Options and Defaults for the Video Features Submenu of the Advanced Menu
Menu Field Options Default Description
Display:
Compensation:
■
Internal Flat Panel
■
External
■
Auto
■
Disabled
■
Enabled
[Auto] Selects where the video signal will be routed.
[Enabled] Enables or disables compensation which controls spacing on the
Note: The Windows video driver overrides this setting.
display. When enabled, displays with less than pixel resolution
1024 x 768 or 800 x 600 will still cover the entire screen. A resolution below 800 x 600 will fill the screen, but due to the low resolution, will appear blocky and may not be acceptable.
12
Advanced Menu
Internal Device Configurations Submenu of the Advanced Menu
The Internal Device Configuration submenu allows the user to configure other internal devices.
PhoenixBIOS Setup Utility
Main Advanced Security Power Savings Exit
Internal Devices Configurations
Serial ATA Controller: [Enabled]
AHCI Configuration: [Enabled]
IDE Controller: [Enabled]
LAN Controller: [Enabled]
Wireless LAN: [Enabled]
Item Specific Help
[Disabled]
Serial ATA port is
disabled.
[Enabled]
Serial ATA port is
enabled.
F1 Help
ESC Exit
Select Item
Select Menu
Figure 7. Internal Device Configuration Submenu
-/Space
Enter
Change Values
▲
Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
Table 7: Fields, Options and Defaults for the Internal Device Configuration Submenu of the Advanced Menu
Menu Field Options Default Description
Serial ATA Controller:
AHCI Configuration:
IDE Controller:
LAN Controller:
Wireless LAN:
■
Disabled
■
Enabled
■
Disabled
■
Enabled
■
Disabled
■
Enabled
■
Disabled
■
Enabled
■
Disabled
■
Enabled
[Enabled] Enables or disables the Serial ATA port.
[Enabled] Enables or disables the AHCI (Advanced Host Controller Interface).
[Enabled] Enables or disables selected IDE devices.
[Enabled] Enables or disables the LAN controller.
[Enabled] Enables or disables the Wireless LAN controller.
13
LifeBook V Series Notebook BIOS
CPU Features Submenu of the Advanced Menu
The CPU Features Submenu provides options for enabling or disabling the SpeedStep® Technology feature.
PhoenixBIOS Setup Utility
Main Advanced Security Power Savings Exit
CPU Features
Core Multi-Processing:
[Enabled]
SpeedStep(R) Technology: [Enabled]
Item Specific Help
Select Core
Multi-Processing
enabled or disabled.
On Battery: [Battery Optimized]
On AC: [Maximum Performance]
XD Bit functionality: [Enabled]
F1 Help
ESC Exit
Select Item
Select Menu
Figure 8. CPU Features Submenu
-/Space
Enter
Change Values
▲
Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
Table 8: Fields, Options and Defaults for the CPU Features Submenu of the Advanced Menu
Menu Field Options Default Description
■
®
Disabled
■
Enabled
■
Disabled
■
Enabled
■
Maximum
Performance
■
Battery Optimized
■
Automatic
■
Maximum
Performance
■
Battery Optimized
■
Automatic
[Enabled] Enables or disables the multi-processing functionality of the
Core processor.
[Enabled] When Enabled is selected, CPU speed and battery use can be
selected from On Battery and On AC. When Disabled is
selected, SpeedStep Technology is disabled.
[Battery
Optimized]
When Maximum Performance is selected, CPU speed is maximized. When Battery Optimized is selected, CPU power require-
ments are optimized for battery operation. When Automatic is
selected, CPU speed is determined by the power source used.
[Maximum
Performance]
When Maximum Performance is selected, CPU speed is maximized. When Battery Optimized is selected, CPU power require-
ments are optimized for battery operation. When Automatic is
selected, CPU speed is determined by the power source used.
Core MultiProcessing
SpeedStep
Technology:
On Battery:
On AC:
14
Advanced Menu
Table 8: Fields, Options and Defaults for the CPU Features Submenu of the Advanced Menu
Menu Field Options Default Description
■
XD Bit
functionality:
Disabled
■
Enabled
[Enabled]
Allows the user to enable and disable the Execute Disable Bit
functionality. Execute Disable Bit allows the processor to classify
areas in memory where application code can and cannot
execute. In the event an internet worm attempts to insert code
in the buffer, the processor disables code execution to prevent
damage or worm propagation.
15
LifeBook V Series Notebook BIOS
USB Features Submenu of the Advanced Menu
The USB Features Submenu provides options for enabling or disabling legacy USB support.
PhoenixBIOS Setup Utility
Main Advanced Security Power Savings Exit
USB Features
Legacy USB Support:
[Enabled]
SCSI SubClass Support: [Enabled]
Item Specific Help
[Disabled]
The feature is disabled.
[Enabled]
Legacy USB Emulation
is enabled and USB
devices are available
without USB aware OS.
F1 Help
ESC Exit
Select Item
Select Menu
Figure 9. USB Features Submenu
-/Space
Enter
Change Values
▲
Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
Table 9: Fields, Options and Defaults for the USB Features Submenu of the Advanced Menu
Menu Field Options Default Description
Legacy USB Support:
SCSI SubClass Support:
■
Disabled
■
Enabled
■
Disabled
■
Enabled
[Enabled] When Enabled is selected, Legacy USB Emulation is enabled and
the USB devices are available without a USB-aware OS. When
Disabled is selected, Legacy USB support is disabled.
[Enabled] When Enabled is selected, USB devices that belong to the SCSI
subclass in the mass storage class (e.g., USB Memory Key) are
enabled. Note that enabling this feature may cause the system to
hang during POST, depending on the device that is connected.
16
Advanced Menu
Miscellaneous Configurations Submenu of the Advanced Menu
The Miscellaneous Configurations Submenu provides options for enabling or disabling the power button and the
Wake Up On LAN or USB features, and for setting the volume.
Main Advanced Security Power Savings Exit
PhoenixBIOS Setup Utility
Miscellaneous Configurations
Power Button:
Wake up on LAN:
Force LAN Boot:
Volume Setting: [Middle]
UMA Video Memory Size: [128MB]
F1 Help
ESC Exit
Select Item
Select Menu
[Disabled]
[Disabled]
[Disabled]
-/Space
Enter
Change Values
▲
Select Sub-Menu
Item Specific Help
Configures the power
button.
*ACPI OS ignores this
setting.
F9 Setup Defaults
F10 Save and Exit
Figure 10. Miscellaneous Configurations Submenu
Table 10: Fields, Options and Defaults for the Miscellaneous Configurations Submenu of the Advanced
Menu
Menu Field Options Default Description
Power Button:
Wake up on LAN:
Force LAN Boot:
Volume Setting:
UMA Video
Memory Size:
■
Disabled
■
Power Off
■
Disabled
■
Enabled
■
Disabled
■
Enabled
■
Off
■
Minimum
■
Middle
■
Maximum
■
64MB
■
128MB
■
224MB
[Disabled] Selecting Disabled disables the power button. Selecting Power Off allows you to
turn off system power with the power button.
[Disabled] Selecting Enabled allows the system to wake up when the internal LAN device
[Disabled] This is only active when Wake up on Lan: is enabled. When enabled, the system
receives a signal while in power-off state. Select Disabled to disables the feature.
will attempt to boot up from the LAN before attempting to boot from any other
device. This occurs regardless of the BIOS boot priority settings or if Preboot
Execution Environment is disabled.
[Middle] Allows you to set or disable the system volume level.
Note that once the operating system initializes, the volume settings will be
determined by the OS volume settings.
[128MB] Maximum size allocated for shared video memory. Video memory is dynamically
allocated as needed by Intel(R) Dynamic Video Memory Technology (DVMT).
17
LifeBook V Series Notebook BIOS
Event Logging Submenu of the Advanced Menu
The Event Logging Submenu configures event logging features for DMI events.
PhoenixBIOS Setup Utility
Main Advanced Security Power Savings Exit
Event Logging
Event Log Capacity: Space Available
Event Log Validity: Valid
Item Specific Help
Press <Enter> key to
view the contents of
the event log.
View Event Log: [Enter]
Event Logging: [Enabled]
System Boot Event: [Disabled]
Clear All Event Logs: [No]
Mark Events as Read: [Enter]
F1 Help
ESC Exit
Select Item
Select Menu
Figure 11. Event Logging Submenu
-/Space
Enter
Change Values
▲
Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
Table 11: Fields, Options and Defaults for the Event Logging Submenu of the Advanced Menu
Menu Field Options Default Description
Event Log Capacity: Space Available Display only
Event Log Validity: Valid Display only
■
View Event Log:
Event Logging:
System Boot Event:
Clear All Event
Logs:
Mark Events as
Read:
Enter [Enter] Allows you to view content of event log
■
Disabled
■
Enabled
■
Disabled
■
Enabled
■
No
■
Yes
■
Enter [Enter] Allows you to mark all events currently in the event log as having
[Enabled] Turns event logging on and off for all DMI events.
[Disabled] Turns event logging on and off for DMI system boot events.
[No] When set to [Yes] all event logs will be cleared at next boot.
been read.
18
Security Menu
SECURITY MENU – SETTING THE SECURITY FEATURES
The Security menu allows you to set up the data security
features of your notebook to fit your operating needs
and to view the current security configuration. Follow
the instructions for navigating through the Setup Utility
to make any changes. (See Navigating through the Setup
Utility on page 2 for more information.)
The following tables show the names of the menu fields
for the Security menu and its submenus, all of the
options for each field, the default settings and a
description of the field's function and any special
information needed to help understand the field's use.
The default condition is no passwords required and no
write protection.
If you set a password, write it down and
keep it in a safe place. If you forget the
password you will have to contact your
support representative to regain access to
your secured functions and data.
PhoenixBIOS Setup Utility
Main Advanced Security Boot Info Exit
Supervisor Password Is: Clear
User Password Is: Clear
Set Supervisor Password [Enter]
Set User Password [Enter]
Minimum User Password Length: [0]
Password on Boot: [Disabled]
On Automatic Wake up: [Disabled]
KB Lock on Resume: [Disabled]
Boot from Removable Media: [All]
Flash Write: [Enabled]
▲ ▲
Hard Disk Security
Owner Information
■
If you make an error when re-entering
the password a [Warning] will be displayed on the screen. To try again press
the Enter key and then retype the password. Press the Esc key to abort the
password setting process.
■
Entering a password incorrectly 3 times
in a row will cause the keyboard and
mouse to be locked out and the warning
[System Disabled] to be displayed.
If this happens restart the computer by
turning off and on the power with the
power switch and use the correct password on reboot.
■
If the Power Management Security is
Enabled and the Password on Boot is
Disabled you will not have to type your
password upon resuming the system
from the Standby or Hibernate modes.
Power Management Security will work
only if Password boot is enabled.
Item Specific Help
Press <Enter> key to
set Supervisor Password
to enable any password
features.
Then password entry is
required to enter BIOS
Setup.
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
Figure 12. Security Menu
Change Values
▲
Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
19
LifeBook V Series Notebook BIOS
Table 12: Fields, Options and Defaults for the Security Menu
Menu Field Options Default Description
Supervisor
Password is:
User Password is: –— Clear A display-only field. Set is displayed when the general user
Set Supervisor
Password
Set User Password –— [Enter] This field can only be accessed if the Supervisor Password is set. Sets, changes
–— Clear A display-only field. Set is displayed when the system supervisor password is set
and Clear when it is not.
password is set, and Clear when it is not.
–— [Enter] Sets, changes or cancels the Supervisor Password. Supervisor’s Password may
be up to seven characters long and must include only letters or numbers (no
symbols). Passwords are NOT case- sensitive. To cancel a password press the
Enter key instead of entering characters in the Enter New Password field and in
the Re-enter New Password field. When a Supervisor Password is set it must be
used to access the BIOS setup utility.
or cancels the User Password. The User Password may be up to seven characters long and must include only letters or numbers (no symbols). Passwords are
NOT case-sensitive. To cancel a password press the Enter key instead of entering characters in the Enter New Password field and in the Re-enter New Password field. When a User Password is set it must be used to access the BIOS
setup utility.
Minimum User
Password Length:
Password on Boot:
On Automatic
Wake up:
KB Lock on
Resume:
Boot from
Removable Media:
Flash Write:
–— [0] Supervisor can set password length (0 to 8) for user password. User cannot set a
■
Disabled
■
First Boot
■
Every Boot
■
Disabled
■
Enabled
■
Disabled
■
Enabled
■
All
■
Supervisor
only
■
Disabled
■
Enabled
[Disabled] When set to First Boot, a password (User or Supervisor) is required just once
[Disabled]
[Disabled] When set to Enabled, the PS/2 mouse and keyboard inputs are locked out upon
[All] When All is selected, booting from removable media is not restricted. When
[Enabled] When set to [Disabled], the BIOS Flash memory is write protected.
password shorter than the minimum length.
after the Power On Self Test (POST) before the operating system will be read
from a disk. When set to Every Boot, a password (User or Supervisor) is required
every time after the Power On Self Test (POST) before the operating system will
be read from a disk. When set to Disabled no password is required.
When set to Disabled, it is not necessary to enter a password to wake up from
LAN or Real Time Clock (RTC). When Enabled, it is still necessary to enter a
password after automatic wake-up.
Resume from
When set to Disabled no password is required. If no Supervisor Password is set,
this feature is not available and no password is required.
Supervisor Only is selected, only the Supervisor (i.e., the user who enters Supervisor password), can boot from removable media.
Standby or Hibernate mode until you enter the password.
Hard Disk Security: –— –— Configures hard disk security features
Owner
–— –— Sets Owner information.
Information:
Exiting from the Security Menu
When you have finished setting the parameters on the Security Menu, you can either exit from setup utility or move to
another menu. If you wish to exit from setup utility, press the Esc key to go to the Exit Menu. If you wish to move to
another menu, use the cursor keys.
20
Hard Disk Security Submenu of the Security Menu
The Hard Disk Security Submenu is for configuring hard disk security features.
PhoenixBIOS Setup Utility
Main Advanced Security Power Savings Exit
Security Menu
Hard Disk Security
Item Specific Help
Drive0: Clear
Set Master Password [Enter]
Set User Password [Enter]
Password Entry on Boot: [Enabled]
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
Figure 13. Hard Disk Security Submenu
Change Values
▲
Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
Table 13: Fields, Options and Defaults for the Hard Disk Security Submenu of the Security Menu
Menu Field Options Default Description
Drive0:
Set Master
Password:
Set User
Password
Password Entry
on Boot:
---
---
--- [Enter] When the User Password has been set, the field can be changed. When enabled,
■
Disabled
■
Enabled
Clear The default is Clear. When the Drive0 Password has been set in the field below, the
[Enter] When the Master Password has been set, the field can be changed. When enabled,
[Enabled] When disabled, the master password entry is not required before booting the oper-
field changes to Set.
the hard disk is locked with the password. Data in the locked disk cannot be read on
any systems other than the original system on which it is locked or systems that
have the identical password setting.
the hard disk is locked with the password. Data in the locked disk cannot be read on
any systems other than the original system on which it is locked or systems that
have the identical password setting.
ating system, but the hard disk is still password-protected without password entry.
21
LifeBook V Series Notebook BIOS
Owner Information Submenu of the Security Menu
The Owner Information Submenu is for setting owner information. Note that the owner information cannot be set
without having entered a Supervisor password.
PhoenixBIOS Setup Utility
Main Advanced Security Power Savings Exit
Owner Information
Item Specific Help
Owner Information Is: Clear
Set Owner Information [Enter]
Foreground Color: [Gray]
Background Color: [Black]
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
Change Values
Select Sub-Menu
Figure 14. Owner Information Submenu
▲
F9 Setup Defaults
F10 Save and Exit
Table 14: Fields, Options and Defaults for the Owner Information Submenu of the Security Menu
Menu Field Options Default Description
Owner Information Is: –— Clear Display only.
Set Owner Information:
Foreground Color:
Background Color:
–— [Enter] Field to write owner
information, (i.e., name).
■
Black
■
Blue
■
Green
■
Cyan
■
Red
■
Magenta
■
Black
■
Blue
■
Green
■
Cyan
■
Red
■
Magenta
■
Brown
■
White
■
Gray
■
Light Blue
■
Light Green
■
Brown
■
White
■
Gray
■
Light Blue
■
Light Green
■
Light Cyan
■
Light Red
■
Light
Magenta
■
Yellow
■
Bright White
■
Light Cyan
■
Light Red
■
Light
Magenta
■
Yellow
■
Bright White
[Gray] Set foreground color.
[Black] Set background color.
22
Boot Menu
BOOT MENU – SELECTING THE OPERATING SYSTEM SOURCE
The Boot Menu is used to select the order in which the
BIOS searches sources for the operating system. Follow
the instructions for Navigating Through the Setup
Utility to make any changes. (See Navigating through the
Setup Utility on page 2 for more information.)
PhoenixBIOS Setup Utility
Main Advanced Security Power Savings Boot
Quick Boot:
Boot Time Diagnostic Screen: [Disabled]
Boot Menu:
Preboot Execution Environment: [Enabled]
▲
Boot Device Priority
[Enabled]
[Enabled]
The following tables show the names of the menu fields
for the Boot menu and its submenu, all of the options
for each field, the default settings and a description of
the field's function and any special information needed
to help understand the field's use.
Item Specific Help
[Disabled]
All diagnostic tests
will be done.
[Enabled]
Some diagnostic tests
may be skipped while
booting to speed up.
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
Change Values
▲
Select Sub-Menu
Figure 15. Boot Menu
Table 15: Fields, Options and Defaults for the Boot Menu
Menu Field Options Default Description
QuickBoot:
Boot-time
Diagnostic Screen:
Boot Menu:
Preboot Execution
Environment:
Boot Device
Priority
■
Disabled
■
Enabled
■
Disabled
■
Enabled
■
Disabled
■
Enabled
[Enabled] Turns on and off booting with a truncated set of Power On Self Test.
[Disabled] Turns on and off display of test results instead of Fujitsu logo screen
(Fewer tests mean faster booting.)
during Power On Self Test.
[Enabled] This field is not active unless the Supervisor’s Password has
been set. When disabled, access to the Boot Menu with the
[F12] key is disabled. When enabled, the Boot Menu is enabled
and the [F12] key will allow you to display it.
■
Disabled
■
Enabled
— — This menu allows setting up the source for the operating system.
[Enabled] Turns on and off the preboot execution environment feature.
See “The Boot Device Priority Submenu” in the following section.
F9 Setup Defaults
F10 Save and Exit
23
LifeBook V Series Notebook BIOS
Boot Device Priority Submenu of the Boot Menu
The Boot Device Priority Submenu is for setting the order of checking of sources for the operating system.
PhoenixBIOS Setup Utility
Main Advanced Security Power Savings Boot
Boot Device Priority
Boot priority order:
1: Floppy Disk Drive
2. Drive0: FUJITSU MHV2080BH
3. CD/DVD Drive
4. NETWORK: MBA vXX.X.XX Slot 0400
5:
6.
7:
8:
Item Specific Help
Keys used to view or
configure devices:
<+>/<Space> or <->
moves the device up or
down.
<x> excludes or includes
the device to boot.
Excluded from boot order:
: USB MEMORY: None
: USB HDD: None
F1 Help
ESC Exit
■
Be aware of the operating environment when booting from a CD-ROM/DVD-ROM or you may overwrite files by mistake.
■
A bootable CD-ROM/DVD-ROM has either a floppy disk format or a hard drive format. When the boot-
Select Item
Select Menu
-/Space
Enter
Figure 16. Boot Device Priority Submenu
Change Values
▲
Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
able CD-ROM/DVD-ROM is used, the drive allocations change automatically without changing the BIOS
setup. If a floppy disk format is used, the CD-ROM/DVD-ROM becomes Drive A. The CD-ROM/DVDROM will only take drive C: (hard drive format) if the internal hard drive is not present or is disabled. The
bootable CD-ROM/DVD-ROM can never use a C: designation if a formatted internal hard drive is
present since the C: designator is always reserved for the internal hard drive. The boot sequence ignores
the new drive designations, however, your application software will use the new designations.
Table 16: Fields, Options and Defaults for the Boot Device Priority Submenu of the Boot Menu
Menu Field Description
1; Floppy Disk Drive
2: Drive0
3: CD/DVD Drive
4: NETWORK
5:
6:
7:
8:
Excluded from boot
order:
: USB MEMORY: None
: USB HDD: None
24
The boot selections determine the order in which the BIOS searches for the operating system during a
startup sequence. To change the order, highlight one source by using the [up] or [down] cursor keys and
then press the [+] or [-] key to change the order number. The selections that appear above may be different
for your system, depending upon configuration.
NOTE: Be aware that if you use the CD-ROM drive as the first boot device, certain files may be
overwritten, depending upon your operating environment.
Boot Menu
Exiting from Boot Menu
When you have finished setting the boot parameters with the Boot menu, you can either exit from the setup utility or
move to another menu. If you wish to exit from the setup utility press the Esc key to go to the Exit menu. If you wish to
move to another menu, use the cursor keys.
25
LifeBook V Series Notebook BIOS
INFO MENU - DISPLAYS BASIC SYSTEM INFORMATION
The Info menu is a display only screens that provides the
configuration information for your notebook.
The following table shows the names of the menu fields
for the Info menu and the information displayed in
those fields. These fields are for information purposes
only, and cannot be modified by the user.
PhoenixBIOS Setup Utility
Main Advanced Security Power Savings Boot Info
BIOS Version: 1.05
BIOS Date: 09/06/2007
BIOS Area: E000h - FFFFh
CPU Type: Intel(R) Core(TM)2 CPU T5500
CPU Speed: 1.66 GHz
L1 Cache: 128 KB
L2 Cache: 2048 KB
Total Memory: 1024 MB
Memory Slot 1: 512 MB DDR2 SDRAM
Memory Slot 2: 512 MB DDR2 SDRAM
The information, including CPU type and
speed, and total memory, displayed on this
screen varies according to the unit you
purchased.
F1 Help
ESC Exit
Select Item
Select Menu
-/Space Change Values
Enter Select Sub-Menu
Figure 17. Info Menu
▲
F9 Setup Defaults
F10 Save and Exit
Table 17: Fields, Options and Defaults for the Info Menu
Note that the parameters listed in the following table may be different, depending upon the system configuration.
Menu Field Default Menu Field Default
BIOS Version: X.XX L1 Cache: 128 KB
BIOS Date: XX/XX/XXXX L2 Cache: 2048 KB
BIOS Area: E000h – FFFFh Total Memory: 1024 MB
CPU Type: Genuine Intel(R) Core(TM)2 CPU T5500 Memory Slot 1: 512 MB DDR2 SDRAM
CPU Speed: 1.66 GHz Memory Slot 2: 512 MB DDR2 SDRAM
26
EXIT MENU – LEAVING THE SETUP UTILITY
Exit Menu
The Exit Menu is used to leave the setup utility. Follow
the instructions for Navigating Through the Setup
Utility to make any changes. (See Navigating through the
Setup Utility on page 2 for more information.)
PhoenixBIOS Setup Utility
Main Advanced Security Power Savings Boot Exit
Exit Saving Changes
Exit Discarding Changes
Load Setup Defaults
Discard Changes
Save Changes
Save Changes and Power Off
F1 Help
ESC Exit
Select Item
Select Menu
-/Space Change Values
Enter Select Sub-Menu
Figure 18. Exit Menu
Table 18: Fields, Options and Defaults for the Exit Menu
The following table shows the names of the menu fields
for the Exit menu, the default settings and a description
of the field's function and any special information
needed to help understand the field's use.
Item Specific Help
Exit System Setup and
save your changes to
CMOS.
▲
F9 Setup Defaults
F10 Save and Exit
Menu Field Description
Exit Saving
Changes
Exit Discarding
Changes
Load Setup
Defaults
Exit Saving Changes will store the entries on all setup utility menus to the BIOS memory and then
exit the setup utility. A confirmation message Save Configuration changes and exit now? [Yes] [No]
will be displayed.
Selecting Exit Discarding Changes will exit the setup utility with out writing to the BIOS memory.
When the BIOS recognizes this selection it will load the operating system and begin operation.
Selecting Load Setup Defaults will load the factory preset default values for all menu fields, then display the message Load default configuration now? [Yes] [No]. When confirmed the setup utility will
return to the Exit Menu. To return to another menu follow the directions in the Navigating Through
the Setup Utility Section.
27
LifeBook V Series Notebook BIOS
Table 18: Fields, Options and Defaults for the Exit Menu
Menu Field Description
Discard Changes Selecting Discard Changes will load the previous values in BIOS memory for all menu fields. The
message Load previous now? [Yes] [No] will be displayed. When confirmed the setup utility will
return to the Exit menu. To return to another menu, follow the directions in the Navigating Through
the Setup Utility Section.
Save Changes Selecting Save Changes will cause the new settings in all menus to be written to the BIOS memory.
The message Save configuration changes now? [Yes] [No] will be displayed. When confirmed, the
setup utility will return to the Exit menu. To return to another menu, follow the directions in the
Navigating Through the Setup Utility section.
Save Changes
and Power Off
Selecting Save Changes and Power Off will cause the new settings in all menus to be written to the
BIOS memory, after which the system will power itself off. The message Save configuration changes
and power off now? [Yes] [No] will be displayed. When confirmed, the setup utility save the settings
and the system will power off.
28
Loading...
