FUJITSU SEMICONDUCTOR CONTROLLER MANUAL

CM41-00313-6E

F2MC-16 FAMILY

SOFTUNE

Workbench

USER'S MANUAL

F2MC-16 FAMILY

SOFTUNE

Workbench

USER'S MANUAL

FUJITSU SEMICONDUCTOR LIMITED

PREFACE

■ What is the SOFTUNE Workbench?

SOFTUNE Workbench is support software for developing programs for the F2MC-16 family of microprocessors / microcontrollers.

It is a combination of a development manager, simulator debugger, emulator debugger, m onitor debugger, and an integrated development environment for efficient development.

■ Purpose of this manual and target readers

This manual explains functions of SOFTUNE Workbench. This manual is intended for engineers designing several kinds of products using SOFTUNE Workbench. Other company names and products names are trademarks or registered trademarks of their respective

companies.

■ Trademarks

REALOS, SOFTUNE are trademark of Fujitsu Semiconductor Limited, Japan.

Note: F Microsoft, Windows and Windows Media are either registered trademarks of Microsoft Corporation in the

United States and/or other countries. The company names and brand names herein are the trademarks or registered trademarks of their respective

owners.

MC is the abbreviation of FUJITSU Flexible Microcontroller.

■ Organization of This Manual

This manual consists of the following 2 chapters.

CHAPTER 1 BASIC FUNCTIONS

This chapter describes the basic functions on the SOFTUNE Workbench.

CHAPTER 2 DEPENDENCE FUNCTIONS

This chapter describes the functions dependent on each Debugger.

• The contents of this document are subject to change without notice. Customers are advised to consult with sales representatives before ordering.

• The information, such as descriptions of function and application circuit examples, in this document are presented solely for the purpose of reference to show examples of operations and uses of FUJITSU SEMICONDUCTOR device; FUJITSU SEMICONDUCTOR does not warrant proper operation of the device with respect to use based on such information. When you develop equipment incorporating the device based on such information, you must assume any responsibility arising out of such use of the information. FUJITSU SEMICONDUCTOR assumes no liability for any damages whatsoever arising out of the use of the information.

• Any information in this document, including descriptions of function and schematic diagrams, shall not be construed as license of the use or exercise of any intellectual property right, such as patent right or copyright, or any other right of FUJITSU SEMICONDUCTOR or any third party or does FUJITSU SEMICONDUCTOR warrant non-infringement of any third-party's intellectual property right or other right by using such information. FUJITSU SEMICONDUCTOR assumes no liability for any infringement of the intellectual property rights or other rights of third parties which would result from the use of information contained herein.

• The products described in this document are designed, developed and manufactured as contemplated for general use, including without limitation, ordinary industrial use, general office use, personal use, and household use, but are not designed, developed and manufactured as contemplated (1) for use accompanying fatal risks or dangers that, unless extremely high safety is secured, could have a serious effect to the public, and could lead directly to death, personal injury, severe physical damage or other loss (i.e., nuclear reaction control in nuclear facility, aircraft flight control, air traffic control, mass transport control, medical life support system, missile launch control in weapon system), or (2) for use requiring extremely high reliability (i.e., submersible repeater and artificial satellite). Please note that FUJITSU SEMICONDUCTOR will not be liable against you and/or any third party for any claims or damages arising in connection with above-mentioned uses of the products.

• Any semiconductor devices have an inherent chance of failure. You must protect against injury, damage or loss from such failures by incorporating safety design measures into your facility and equipment such as redundancy, fire protection, and prevention of over-current levels and other abnormal operating conditions.

• Exportation/release of any products described in this document may require necessary procedures in accordance with the regulations of the Foreign Exchange and Foreign Trade Control Law of Japan and/or US export control laws.

• The company names and brand names herein are the trademarks or registered trademarks of their respective owners.

READING THIS MANUAL

■ Configuration of Page

In each section of this manual, the summary about the section is described certainly, so you can grasp an outline of this manual if only you read these summaries.

And the title of upper section is described in lower section, so you can grasp the position where you are reading now.

iii

iv v

CONTENTS

CHAPTER 1 BASIC FUNCTIONS ..................................................................................... 1

1.1 Workspace Management Function ..................................................................................................... 2

1.2 Project Management Function ...... .... ... ... ... ....................................... ... ... .... ... ... .................................. 3

1.3 Project Dependence ............................................................ ... .... ........................................................ 5

1.4 Make/Build Function ........................................................................................................................... 6

1.4.1 Customize Build Function .............................................................................................................. 7

1.5 Include Dependencies Analysis Function ........................................................................................... 9

1.6 Functions of Setting Tool Options ..................................................................................................... 10

1.7 Error Jump Function ......................................................................................................................... 11

1.8 Editor Functions ................................................................................................................................ 13

1.9 Storing External Editors .................................................................................................................... 14

1.10 Storing External Tools ...................................................................................................................... 16

1.11 Macro Descriptions Usable in Manager ............................................................................................ 17

1.12 Setting Operating Environment .. ....................................... ... ... .... ... ...................................... . ............ 21

1.13 Debugger Types ............................................................... ... ... ....................................... ................... 22

1.14 Memory Operation Functions ....................... ....................................... ... .... ... ... ................................ 23

1.15 Register Operations .......................................................................................................................... 24

1.16 Line Assembly and Disassembly ...................................................................................................... 25

1.17 Symbolic Debugging ......................................................................................................................... 26

1.17.1 Referring to Local Symbols ......................................................................................................... 28

1.17.2 Referring to Variable of C Language .......................................................................................... 29

CHAPTER 2 DEPENDENCE FUNCTIONS ..................................................................... 31

2.1 Simulator Debugger ................ ... ... .... ... ... ....................................... ... ... ... .... ... ................................... 32

2.1.1 Setting Operating Environment ................................................................................................... 34

2.1.1.1 Boot ROM File Automatic Execution ........................................... ... .... ...................................... 35

2.1.2 Instruction Simulation .................................................................................................................. 36

2.1.3 Memory Simulation ...................................................................................................................... 37

2.1.4 I/O Port Simulation .................. .... ...................................... .... ... ... ... ............................................. 38

2.1.5 Interrupt Simulation ................. ....................................... ... .... ... ... ................................................ 39

2.1.6 Reset Simulation .................. ... .... ... ... ....................................... ... ... ... .... ... ................................... 40

2.1.7 Low-Power Consumption Mode Simulation ................................................................................. 41

2.1.8 STUB Function ..................................................... .... ... ... ....................................... ... ... ................ 42

2.1.9 Break ........................................................................................................................................... 43

2.1.9.1 Code Break ............................................................................................................................... 44

2.1.9.2 Data Break ................................................................................................................................ 46

2.1.9.3 Trace-Buffer-Full Break .................................................. .... ... ... ... ... .......................................... 47

2.1.9.4 Guarded Access Break ............................................................................................................. 48

2.1.9.5 Forced Break ............................ ... ....................................... ... ... ... ... .......................................... 49

2.1.10 Measuring Execution Cycle Count .... ... ... ....................................... ... .... ... ... ................................ 50

2.1.11 Trace ........................................................................................................................................... 52

2.1.11.1 Setting Trace ............................................................... ....................................... ...................... 53

2.1.11.2 Displaying Trace Data .............................................................................................................. 54

2.1.11.3 Searching Trace Data ............................................................................................................... 55

2.1.11.4 Saving Trace Data .................................................................................................................... 56

2.1.12 Measuring Coverage ................................................................................................................... 57

2.1.12.1 Coverage Measurement Procedures ........................................................................................ 58

2.1.13 Checking Debugger Information ........................... .... ... ... ... .... ...................................... ... .... ......... 61

2.2 Emulator Debugger (MB2141) ...... .... ... ....................................... ... ... ... ... .......................................... 63

2.2.1 Setting Operating Environment ................................................................................................... 64

2.2.1.1 MCU Operation Mode ............................................................................................................... 65

2.2.1.2 Debug Area .............................................................................................................................. 67

2.2.1.3 Memory Area Types ........................................................... ... ... ... ............................................. 68

2.2.1.4 Memory Mapping ............... ... ....................................... ... .... ... ... ................................................ 71

2.2.1.5 Timer Minimum Measurement Unit .......... ... ... ....................................... ... ... .... ... ...................... 73

2.2.2 Notes on Commands for Executing Program .............................................................................. 74

2.2.3 Commands Available during Execution of User Program ........................................................... 76

2.2.4 On-the-fly Memory Access ....................................... ... ... ... ....................................... ... ... .... ......... 77

2.2.5 Break ........................................................................................................................................... 79

2.2.5.1 Code Break ............................................................................................................................... 80

2.2.5.2 Data Break ................................................................................................................................ 82

2.2.5.3 Sequential Break ...................................................................................................................... 83

2.2.5.4 Guarded Access Break ............................................................................................................. 84

2.2.5.5 Trace-Buffer-Full Break .................................................. .... ... ... ... ... .......................................... 85

2.2.5.6 Performance-Buffer-Full Break ................................................................................................. 86

2.2.5.7 Forced Break ............................ ... ....................................... ... ... ... ... .......................................... 87

2.2.6 Events ............................. ......................... .......................... .......................... ................................ 88

2.2.6.1 Operation in Normal Mode ....................... ... ....................................... ... ... ... .... ......................... 90

2.2.6.2 Operation in Multi Trace Mode .............................................. ... ... ... .... ... ................................... 92

2.2.6.3 Operation in Performance Mode .............. ... ... ... .... ...................................... .... ... ... ... ... ............. 94

2.2.7 Control by Sequencer .................................................................................................................. 96

2.2.7.1 Setting Sequencer ....................... ... ....................................... ... ... ... .... ...................................... 97

2.2.7.2 Break by Sequencer ................................................................................................................. 99

2.2.7.3 Trace Sampling Control by Sequencer ............................... ... ... ....................................... ... ... . 100

2.2.7.4 Time Measurement by Sequencer ......................................................................................... 102

2.2.7.5 Sample Flow of Time Measurement by Sequencer ................................................................ 103

2.2.8 Real-time Trace ......................................................................................................................... 105

2.2.8.1 Single Trace ........................................................................................................................... 106

2.2.8.2 Setting Single Trace .............................................................. ................................................. 108

2.2.8.3 Multi trace ............................. .... ... ... ... ... ....................................... ... .... ... ... ... ........................... 110

2.2.8.4 Setting Multi Trace ....... ... ... ....................................... ... ... .... ... ................................................. 112

2.2.8.5 Displaying Trace Data Storage Status ................................................................................... 113

2.2.8.6 Specify Displaying Trace Data Start ....................................................................................... 114

2.2.8.7 Display Format of Trace Data ................................................................................................. 115

2.2.8.8 Reading Trace Data On-the-fly .............................. ... ... ... ....................................... ... ... .... .. ..... 119

2.2.8.9 Saving Trace Data .................................................................................................................. 121

2.2.9 Measuring Performance ............................................................................................................ 122

2.2.9.1 Performance Measurement Procedures ................................................................................. 123

2.2.9.2 Display Performance Measurement Data ............................................................................... 125

2.2.10 Measuring Coverage ................................................................................................................. 126

2.2.10.1 Coverage Measurement Procedures ...................................................................................... 127

2.2.11 Execution Time Measurement ................................................................................................... 131

2.2.12 Sampling by External Probe ...................................................................................................... 133

2.2.13 Checking Debugger Information ........................... .... ... ... ... .... ...................................... ... .... ....... 135

2.3 Emulator Debugger (MB2147-01) .............................. .... ... ... ... .... ...................................... ... .... .. ..... 137

2.3.1 Setting Operating Environment ................................................................................................. 138

2.3.1.1 Monitoring Program Automatic Loading ...................................... ... ....................................... . 139

2.3.1.2 MCU Operation Mode ............................................................................................................. 140

2.3.1.3 Debug Area ............................................................................................................................ 141

2.3.1.4 Memory Area Types ........................................................... ... ... ... ........................................... 142

2.3.1.5 Memory Mapping ............... ... ....................................... ... .... ... ... .............................................. 144

2.3.1.6 Debug Function ...................................................................................................................... 146

2.3.1.7 Event Mode ............................................................................................................................ 147

2.3.2 Notes on Commands for Executing Program ............................................................................ 148

2.3.3 Commands Available during Execution of User Program ......................................................... 150

2.3.4 Break ......................................................................................................................................... 152

2.3.4.1 Code Break ............................................................................................................................. 153

2.3.4.2 Data Break .............................................................................................................................. 155

2.3.4.3 Monitoring Data Break .......... .... ...................................... .... ... ... ... ........................................... 156

2.3.4.4 Sequential Break .................................................................................................................... 157

2.3.4.5 Guarded Access Break ........................................................................................................... 158

2.3.4.6 Trace-Buffer-Full Break .................................................. .... ... ... ... ... ........................................ 159

2.3.4.7 Performance-Buffer-Full Break ............................................................................................... 160

2.3.4.8 External Trigger Break ............................................................................................................ 161

2.3.4.9 Forced Break ............................ ... ....................................... ... ... ... ... ........................................ 162

2.3.5 Control by Sequencer ................................................................................................................ 163

2.3.5.1 Setting Sequencer ....................... ... ....................................... ... ... ... .... .................................... 165

2.3.6 Real-time Trace ......................................................................................................................... 167

2.3.6.1 Setting Single Trace .............................................................. ................................................. 170

2.3.6.2 Multi Trace ......................... ... ....................................... ... .... ... ... .............................................. 171

2.3.6.3 Setting Methods of Multi Trace ............................................................................................... 174

2.3.6.4 Displaying Trace Data Storage Status ................................................................................... 176

2.3.6.5 Specify Displaying Trace Data Storage Status ....................................................................... 177

2.3.6.6 Display Format of Trace Data ................................................................................................. 178

2.3.6.7 Reading Trace Data On-the-fly .............................. ... ... ... ....................................... ... ... .... .. ..... 182

2.3.6.8 Saving Trace Data .................................................................................................................. 183

2.3.7 Measuring Performance ............................................................................................................ 184

2.3.7.1 Performance Measurement Procedures ................................................................................. 185

2.3.7.2 Display Performance Measurement Data ............................................................................... 187

2.3.8 Measuring Coverage ................................................................................................................. 188

2.3.8.1 Coverage Measurement Procedures ...................................................................................... 189

2.3.9 Real-time Monitoring ................................................................................................................. 192

2.3.10 Execution Time Measurement ................................................................................................... 193

2.3.11 Power-on Debugging ................................................................................................................. 195

2.3.12 RAM Checker .................................................... ... .... ... ....................................... ... ... .. ............... 196

2.3.13 Checking Debugger Information ........................... .... ... ... ... .... ...................................... ... .... ....... 200

2.4 Emulator Debugger (MB2147-05) .............................. .... ... ... ... .... ...................................... ... .... .. ..... 202

vii

2.4.1 Setting Operating Environment ................................................................................................. 203

2.4.1.1 Monitoring Program Automatic Loading ...................................... ... ....................................... . 204

2.4.1.2 MCU Operation Mode ............................................................................................................. 205

2.4.1.3 Debug Area ............................................................................................................................ 206

2.4.1.4 Memory Area Types ........................................................... ... ... ... ........................................... 207

2.4.1.5 Memory Mapping ............... ... ....................................... ... .... ... ... .............................................. 209

2.4.2 Notes on Commands for Executing Program ............................................................................ 211

2.4.3 Commands Available during Execution of User Program ......................................................... 213

2.4.4 Break ......................................................................................................................................... 214

2.4.4.1 Code Break ............................................................................................................................. 215

2.4.4.2 Data Break .............................................................................................................................. 217

2.4.4.3 Guarded Access Break ........................................................................................................... 218

2.4.4.4 Trace-Buffer-Full Break .................................................. .... ... ... ... ... ........................................ 219

2.4.4.5 Forced Break ............................ ... ....................................... ... ... ... ... ........................................ 220

2.4.5 Real-time Trace ......................................................................................................................... 221

2.4.5.1 Setting Trace ............................................................ ... ... .... .................................................... 223

2.4.5.2 Displaying Trace Data Storage Status ................................................................................... 224

2.4.5.3 Specifying Displaying Trace Data Start .................................................................................. 225

2.4.5.4 Display Format of Trace Data ................................................................................................. 226

2.4.5.5 Reading Trace Data On-the-fly .............................. ... ... ... ....................................... ... ... .... .. ..... 230

2.4.5.6 Saving Trace Data .................................................................................................................. 231

2.4.6 Measuring Execution Cycle Count .... ... ... ....................................... ... .... ... ... .............................. 232

2.5 Emulator Debugger (MB2198) ...... .... ... ....................................... ... ... ... ... ........................................ 233

2.5.1 Setting Operating Environment ................................................................................................. 234

2.5.1.1 Monitoring Program Automatic Loading ...................................... ... ....................................... . 235

2.5.1.2 Boot ROM File Automatic Execution ........................................... ... .... .................................... 236

2.5.1.3 MCU Operation Mode ............................................................................................................. 237

2.5.1.4 Operation Frequency Control ............................................. ...................................... ... .... .. ..... 238

2.5.2 Notes on Commands for Executing Program ............................................................................ 239

2.5.3 Commands Available during Execution of User Program ......................................................... 240

2.5.4 Break ......................................................................................................................................... 242

2.5.4.1 Code Break ............................................................................................................................. 243

2.5.4.2 Data Break .............................................................................................................................. 245

2.5.4.3 Guarded Access Break ........................................................................................................... 246

2.5.4.4 Sequential Break .................................................................................................................... 247

2.5.4.5 Trace-Buffer-Full Break .................................................. .... ... ... ... ... ........................................ 248

2.5.4.6 Performance-Buffer-Full Break ............................................................................................... 249

2.5.4.7 External Trigger Break ............................................................................................................ 250

2.5.4.8 Forced Break ............................ ... ....................................... ... ... ... ... ........................................ 251

2.5.5 Control by Sequencer ................................................................................................................ 252

2.5.5.1 Operating of sequencer .................. ....................................... ... ... ... .... .................................... 254

2.5.6 Real-time Trace ......................................................................................................................... 256

2.5.6.1 Setting Trace ............................................................ ... ... .... .................................................... 258

2.5.6.2 Displaying Trace Data Storage Status ................................................................................... 260

2.5.6.3 Specifying Displaying Trace Data Start .................................................................................. 261

2.5.6.4 Display Format of Trace Data ................................................................................................. 262

2.5.6.5 Saving Trace Data .................................................................................................................. 265

viii

2.5.7 Measuring Performance ............................................................................................................ 266

2.5.7.1 Performance Measurement Procedures ................................................................................. 267

2.5.7.2 Display Performance Measurement Data ............................................................................... 268

2.5.8 Execution Time Measurement ................................................................................................... 269

2.5.9 Power-On Debugging ................................................................................................................ 271

2.6 Emulator Debugger (MB2100-01) .............................. .... ... ... ... .... ...................................... ... .... .. ..... 272

2.6.1 Starting debugging .................................................................................................................... 273

2.6.1.1 Operating Environments of the Target ................................................................................... 274

2.6.1.2 Security ........................ ............. ............ ............. ............. .......... ............. ............. .................... 276

2.6.2 Ending debugging ...................................................................................................................... 277

2.6.3 Efficiently Executing Debugging ................................................................................................ 278

2.6.3.1 Increasing Communication Speed during Debugging ............................................................ 279

2.6.3.2 Switching Debug Function ...................................................................................................... 280

2.6.4 Executing Program .................................................................................................................... 281

2.6.4.1 Setting/Release of Debug Functions ...................................................................................... 282

2.6.4.2 Monitoring .......................... ................................................. .................................................... 284

2.6.4.3 Power-on Debug ..................................................................................................................... 285

2.6.4.4 Notes on Commands for Executing Program ......................................................................... 287

2.6.5 To Access the Flash Memory .................................................................................................... 289

2.6.6 To Interrupt the Program Execution [Break] .............................................................................. 293

2.6.6.1 Code Break (Hardware) .......................................................................................................... 294

2.6.6.2 Code Break (Software) ........................................................................................................... 296

2.6.6.3 Data Break .............................................................................................................................. 297

2.6.6.4 Forced Break ............................ ... ....................................... ... ... ... ... ........................................ 298

2.6.6.5 Data Watch Break .................................................................................................................. 299

2.6.6.6 Sequencer .............................................................................................................................. 301

2.6.7 Measuring the Program Execution Cycle Count ........................................................................ 304

2.6.8 Measuring Event-to-Event Execution Cycle Count [Performance Measurement] ..................... 306

2.6.8.1 Measuring Performance .............................................. ... .... ... ... ... ........................................... 308

2.6.9 Viewing Program Execution History [Trace] .............................................................................. 310

2.6.9.1 Displaying Trace Data ............................................................................................................ 312

2.6.9.2 Trace Data Display Examples (RAW Data) ............................................................................ 314

2.6.9.3 Trace Data Display Example (Instruction) .............................................................................. 315

2.6.9.4 Trace Data Display Example (Source) ................................................................................... 316

2.6.9.5 Saving Trace Data .................................................................................................................. 317

2.6.9.6 Searching for Trace Data ....................................................................................................... 318

2.6.10 How to Display the Output Message from User Program to the Debugger ............................... 319

2.6.11 Checking Debugger Information ........................... .... ... ... ... .... ...................................... ... .... ....... 321

2.7 Monitor Debugger ............................. ... ....................................... ... ... ... ... ........................................ 323

2.7.1 Resources Used by Monitor Program ....................................................................................... 324

2.7.2 Break ......................................................................................................................................... 325

2.7.2.1 Software Break ....................................................................................................................... 326

2.7.2.2 Forced Break ............................ ... ....................................... ... ... ... ... ........................................ 327

INDEX...................................................................................................................................329

CHAPTER 1

BASIC FUNCTIONS

This chapter describes the basic functions on the SOFTUNE Workbench.

1.1 Workspace Management Function

1.2 Project Management Function

1.3 Project Dependence

1.4 Make/Build Function

1.5 Include Dependencies Analysis Function

1.6 Functions of Setting Tool Options

1.7 Error Jump Function

1.8 Editor Functions

1.9 Storing External Editors

1.10 Storing External Tools

1.11 Macro Descriptions Usable in Manager

1.12 Setting Operating Environment

1.13 Debugger Types

1.14 Memory Operation Functions

1.15 Register Operations

1.16 Line Assembly and Disassembly

1.17 Symbolic Debugging

CHAPTER 1 BASIC FUNCTIONS

1.1 Workspace Management Function

This section explains the workspace management function of SOFTUNE Workbench.

■ Workspace

SOFTUNE Workbench uses workspace as a container to manage two or more projects including subprojects. For example, a project that creates a library and a project that creates a target file using the project can be

stored in one workspace.

■ Workspace Management Function

To manage two or more projects, workspace manages the following information:

• Project

• Active project

• Subproject

■ Project

The operation performed in SOFTUNE Workbench is based on the project. The project is a set of files and procedures necessary for creation of a target file. The project file contains all data managed by the project.

■ Active Project

The active project is basic to workspace and undergoes [Make], [Build], [Compile/Assemble], [Start Debug], and [Update Dependence] in the menu. [Make], [Build], [Compile/Assemble], and [Update Dependence] affect the subprojects within the active project.

If workspace contains some project, it always has one active project.

■ Subproject

The subproject is a project on which other projects depend. The target file in the subpr oject is linked with the parent project of the subproject in creating a target file in the parent project.

This dependence consists of sharing target files output by the subproject, so a subproject is first made and built. If making and building of the subproject is unsuccessful, the parent project of the subproject will not be made and built.

The target file in the subproject is however not linked with the parent project when:

• An absolute (ABS)-type project is specified as a subproject.

• A library (LIB)-type project is specified as a subproject.

■ Restrictions on Storage of Two or More Projects

Only one REALOS-type project can be stored in one workspace.

CHAPTER 1 BASIC FUNCTIONS

1.2 Project Management Function

This section explains the project management function of SOFTUNE Workbench.

■ Project Management Function

The project manages all information necessary for development of a microcontroller system. Especially, its major purpose is to manage information necessary for creation of a target file.

The project manages the following information:

- Project configuration

- Active project configuration

- Information on source files, include files, other object files, library files

- Information on tools executed before and after executing language tools (customize build function)

■ Project Format

The project file supports two formats: a 'workspace project format,' and an 'old project format.' The differences between the two formats are as follows:

Workspace project format

- Supports management of two or more project configurations

- Supports use of all macros usable in manager

- Does not support early Workbench versions(*)

Old project format

- Supports management of just one project configuration

- Limited number of macros usable in manager For details, see Section "1.11 Macro Descriptions Usable in Manager".

- Supports early Workbench versions(*)

When a new project is made, the workspace project format is used. When using an existing project, the corresponding project format is used. If a project made by an early Workbench version(*) is used, a dialog asking whether to convert th e file t o the

workspace project format is displayed. For details, refer to Section "2.13 Reading SOFTUNE Project Files of Old Versions" of "SOFTUNE Workbench Operation Manual".

To open a project file in the workspace project format with an early Workbench version(*), it is necessary to convert the file to the old project format. For saving the file in other project formats, refer to Section "4.2.7 Save As" of "SOFTUNE Workbench Operation Manual".

MC-16: V30L26 or earlier

*: F

■ Project Configuration

The project configuration is a series of settings for specifying the characteristics of a target file, and making, building, compiling and assembling is performed in project configurations.

Two or more project configurations can be created in a project. The default project configuration name is Debug. A new project configuration is created on the se tting of the selected existing project configuration. In the new project configuration, the same files as those in the original project configuration are always used.

By using the project configuration, the settings of programs of different versions, such as the optimization

CHAPTER 1 BASIC FUNCTIONS

level of a compiler and MCU setting, can be created within one project. In the project configuration, the following information is managed:

- Name and directory of target file

- Information on options of language tools to create target file by compiling, assembling and linking source files

- Information on whether to build file or not

- Information on setting of debugger to debug target file

■ Active Project Configuration

The active project configuration at default undergoes [Make], [Build], [Comp ile/Assemble], [Start Debug], and [Update Dependence].

The setting of the active project configuration is used for the file state displayed in the SRC tab of proj ect window and includes files detected in the Dependencies folder.

Note:

If a macro function newly added is used in old project format, the macro description is expanded at the time of saving in old project format. For the macro description newly added, refer to Section "1.11 Macro Descriptions Usable in Manager".

CHAPTER 1 BASIC FUNCTIONS

1.3 Project Dependence

This section explains the project dependence of SOFTUNE Workbench.

■ Project Dependence

If target files output by other projects must be linked, a subproject is defined in the project required in [Project] - [Project Dependence] menu. The subproject is a project on which other projects depend.

By defining project dependence, a subproject can be made an d built to link its target file b efore making and building the parent project.

The use of project dependence enables simultaneous making and building of two or m ore projects developed in one workspace.

A project configuration in making and building a subproject in [Project] - [Project Configuration] - [Build Configuration] menu can be specified.

CHAPTER 1 BASIC FUNCTIONS

1.4 Make/Build Function

This section explains the make/build function of SOFTUNE Workbench.

■ Make Function

Make function generates a target file by compiling/assembling only u pdated source files from all sou rce files registered in a project, and then joining all required object files.

This function allows compiling/assembling only the minimum of required files. The time required for generating a target file can be sharply reduced, especially, when debugging.

For this function to work fully, the dependence between source files and include files should be accurately grasped. To do this, SOFTUNE Workbench has a function for analyzing include dependence. To perform this function, it is necessary to understand the dependence of a source file and include file. SOFTUNE Workbench has the function for analyzing the include file dependence. For details, see Section "1.5 Include Dependencies Analysis Function".

■ Build Function

Build function generates a target file by compiling/assembling all source files registered with a project, regardless of whether they have been updated or not, and then by joining all required object files. Using this function causes all files to be compiled/assembled, resulting in the time re quired for gener ating the targ et file longer. Although the correct target file can be generated from the current source files.

The execution of Build function is recommended after completing debugging at the final stage of program development.

Note:

When executing the Make function using a source file restored from backup, the integrity between an object file and a source file may be lost. If this happens, executing the Build function again.

CHAPTER 1 BASIC FUNCTIONS

1.4.1 Customize Build Function

This section describes the SOFTUNE Workbench to set the Customize Build function.

■ Customize Build function

In SOFTUNE Workbench, different tools can be operated automatically before and after executing the Assembler, Compiler, Linker, Librarian, Converter, or Configurator started at Compile, Assemble, Make, or Build.

The following operations can be performed automatically during Make or Build using this function:

- starting the syntax check before executing the Compiler,

- after executing the Converter, starting the S-format binary Converter (m2bs.exe) and converting Motorola S-format files to binary format files.

■ Setting Options

An option follows the tool name to start a tool from SOFTUNE Workbench. The options include any file name and tool-specific options. SOFTUNE Workbench h a s the macros indicating that any file name and toolspecific options are specified as options.

■ Macro List

If any character string other than parameters is specified, it is passed directly to the tool. For details abo ut the parameters, see Section "1.11 Macro Descriptions Usable in Manager".

The Setup Customize Build dialog provides a macro list for macro input. The build file, load module file, project file submenus indicate their sub-parameters specified.

The environment variable brackets must have any item; otherwise, resulting in an error.

Table 1.4-1 Macro List

Macro List Macro Name

Build file %(FILE) Load module file %(LOADMODULEFILE) Project file %(PRJFILE) Workspace file %(WSPFILE) Project directory %(PRJPATH) Target file directory %(ABSPATH) Object file directory %(OBJPATH) List file directory %(LSTPATH) Project construction name %(PRJCONFIG) Environment variable %(ENV[]) Temporary file %(TEMPFILE)

CHAPTER 1 BASIC FUNCTIONS

Note:

When checking [Use the Output window], note the following:

• Once a tool is activated, Make/Build is suspended until the tool is terminated.

• The Output window must not be used with a tool using a wait state for user input while the tool is executing. The user can not perform input while the Output window is in use, so the tool cannot be terminated. To forcibly terminate the tool, select the tool on the Task bar and input Control - C, or Control - Z.

CHAPTER 1 BASIC FUNCTIONS

1.5 Include Dependencies Analysis Function

This section describes the function of the Include Dependencies Analysis of SOFTUNE Workbench.

■ Analyzing Include Dependencies

A source file usually includes some include files. When only an include file has been modified leaving a source file unchanged, SOFTUNE Workbench cannot execute the Make function unless it has accurate and updated information about which source file includes which include files.

For this reason, SOFTUNE Workbench has a built-in Include Dependencies Analysis function. Th is function can be activated by selecting the [Project] - [Include Dependencies] menu. By using this function, uses can know the exact dependencies, even if an include file includes another include file.

SOFTUNE Workbench automatically updates the dependenci e s of the com piled/assembled files.

Note:

When executing the [Project] - [Include Dependencies] menu, the Output window is redrawn and replaced by the dependencies analysis result.

If the contents of the current screen are important (error message, etc.), save the contents to a file and then execute the Include Dependencies command.

CHAPTER 1 BASIC FUNCTIONS

1.6 Functions of Setting Tool Options

This section describes the functions to set options for the language tools activated from SOFTUNE Workbench.

■ Function of Setting Tool Options

To create a desired target file, it is necessary to specify options for the language tools such as a compiler, assembler, and linker. SOFTUNE Workbench stores and manages the options specified for each tool in project configurations.

Tool options include the options effective for all sou rce files (common options) and th e options effective for specific source files (individual options). For details about the option setting, refer to Section "4.5.5 Setup Project" of "SOFTUNE Workbench Operation Manual".

- Common options These options are effective for all source files (excluding those for which individual options are specified) stored in the project.

- Individual options These options are compile/assemble options effective for specific source files. The common options specified for source files for which individual options are specified become invalid.

■ Tool Options

SOFTUNE Workbench the macros indicating that any file name and directory name are specified as options. If any character string other than parameters is specified, it is passed directly to the tool. For details abo ut the

parameters, see Section "1.11 Macro Descriptions Usable in Manager". For details about the tool option s for each tool, see the manual of each tool.

CHAPTER 1 BASIC FUNCTIONS

1.7 Error Jump Function

This section describes the error jump function in SOFTUNE Workbench.

■ Error Jump Function

When an error, such as a compile error occurs, double-clicking the error message displayed in the Output window, opens the source file where the error occurred, and automatically moves the cursor to the error line. This function permits efficient removal of compile errors, etc.

The SOFTUNE Workbench Error Jump function analyzes the source file names and line number inform ation embedded in the error message displayed in the Output window, opens the matching file, and jumps automatically to the line.

The location where a source file name and line number information are embedded in an error message, varies with the tool outputting the error.

An error message format can be added to an existing one or modified into an new one. However, th e modify error message formats for pre-installed Fujitsu language tools are defined as part of the system, these can not be modified.

■ Syntax

A new error message format should be added when working the Error Jump function with user register. To set Error Jump, execute the [Setup] - [Error Jump Setting] me nu.

An error message format can be described in Syntax. SOFTUNE Workbench uses macro descriptions as shown in the Table 1.7-1 to define such formats.

To analyze up to where %f, %h, and %* continue, SOFTUNE Workbench uses the character immediately after the above characters as a delimiter. Therefore, in Syntax, the description until a character that is used as a delimiter re-appears, is interpreted as a file name or a keyword for help, or i s skipped over. To use % as a delimiter, describe as %%. The %[char] macro skips over as long as the specified character continues in parentheses. To specify "]" as a skipped character, describe it as "\]". Blank characters in succession can be

specified with a single blank character.

Table 1.7-1 List of Special Characters String for Analyzing Error Message

Characters Semantics

%f Interpret as source file name and inform editor. %l Interpret as line numb er and inform editor. %h Become keyword when searching help file. %* Skip any desired character. %[char] Skip as long as characters in [ ] continues.

CHAPTER 1 BASIC FUNCTIONS

[Example]

*** %f(%l) %h: or, %[*] %f(%l) %h:

The first four characters are "*** ", followed by the file name and parenthesized page number, and then the keyword for help continues after one blank character.

This represents the following message:

***C :\Sample\sample.c(100) E4062C: Syntax Error: near /int.

■ Reference Section

Setup Error Jump

CHAPTER 1 BASIC FUNCTIONS

1.8 Editor Functions

This section describes the functions of the SOFTUNE Workbench built-in standard editor.

■ Standard Editor

SOFTUNE Workbench has a built-in editor called the standard editor. The standard editor is activated as the Edit window in SOFTUNE Workbench. As many Edit windows as are required can be opened at one time.

The standard editor has the following functions in addition to regular editing functions.

- K e yword marking function in C/assembler source file Displays reserved words, such as if and for, in different color

- Error line marking function The error line can be viewed in a different color, when executing Error Jump.

- Bookmark setup function A bookmark can be set on any line, and instantaneously j umps to the line. Once a book mark is set, the line is displayed in a different color.

- Ruler, line number display function The Ruler is a measure to find the position on a line; it is displayed at the top of the Edit window. A line number is displayed at the left side of the Edit window.

- Automatic indent function When a line is inserted using the Enter key, the same indent (indentation) as the preceding line is set automatically at the inserted line. If the space or tab key is used on the preceding line, the same use is set at the inserted line as well.

- Function to display, Blank, Line Feed code, and Tab code When a file includes a Blank, Line Feed code, and Tab code, these codes are displayed with special symbols.

- Undo function This function cancels the preceding editing action to restore the previous state. When more than one character or line is edited, the whole portion is restored.

- Tab size setup function Tab stops can be specified by defining how many digits to skip when Tab codes are inserted. The default is 8.

- Font changing function The font size for character string displayed in the Edit window can be selected.

■ Reference Section

Edit Window (The Standard Editor)

CHAPTER 1 BASIC FUNCTIONS

1.9 Storing External Editors

This section describes the function to set an external editor to SOFTUNE Workbench.

■ External Editor

SOFTUNE Workbench has a built-in standard editor, and use of this standard editor is recommended. However, another accustomed editor can be used, with setting it, instead of an edit window. There is no particular limit on which editor can be set, but some precautions (below) may be necessary. Use the [Setup] [Editor setting] menu to set an external editor.

■ Precautions

- Error jump function The error jump cannot move the cursor to an error line if the external editor does not have a functi on to specify the cursor location when activated the external editor.

- File save at compiling/assembling SOFTUNE Workbench cannot control an external editor. Always save the file you are editing before compiling/assembling.

■ Setting Options

When activating an external editor from SOFTUNE Workbench, options must be add ed immediately after the editor name. The names of file to be opened by the editor and the initial location of the cursor (the li ne number). can be specified. SOFTUNE Workbench has a set of special parameters for specifying any file name and line number, as shown in the Table 1.9-1. If any other character string are described by these parameters, such characters string are passed as is to the editor.

%f (File name) is determined as follows:

1. If the focus is on the SRC tab of Project window, and if a valid file name is selected, the selected file

2. When a valid file name cannot be acquired by the above procedure, the file name w ith a focus in the

%x (project path) is determined as follows:

1. If a focus is on the SRC tab of project w indow and a valid file name is selected, the project path is a

2. If no path is obtained, the project path is a path to the active project.

Also file name cannot be given double-quotes in the expansion of %f macros. Therefore, it is necessary for you to provide double-quotes for %f. Depending on the edi tor, there are line

numbers to which there will be no correct jump if the entire option is not given double-quotes.

name becomes the file name.

built-in editor becomes the file name.

path to the project in which the file is stored.

Table 1.9-1 List of Special Characters for Analyzing Error Message

Parameter Semantics

%% Means specifying % itself

%f Means specifying file name %l Means specifying line number

%x Means specifying project path

■ Example of Optional Settings

Table 1.9-2 Example of Optional Settings

Editor name Argument

WZ Editor V4.0 %f /j%l MIFES V1.0 %f+%l UltraEdit32 %f/%l/1

CHAPTER 1 BASIC FUNCTIONS

TextPad32 %f(%l) PowerEDITOR %f -g%l Codewright32 %f -g%l Hidemaru for Win3.1/95 /j%l:1 %f ViVi /line=%l %f

■ Reference Section

Editor Setup

Note:

Regarding execution of error jump in Hidemaru: To execute error jump in Hidemaru used as an external editor, use the [Others] - [Operating Environment] - [Exclusive Control] menu, and then set "When opening the same file in Hidemaru" and "Opening two identical files is inhibited".

CHAPTER 1 BASIC FUNCTIONS

1.10 Storing External Tools

This section describes the function to set an external tool to SOFTUNE Workbench.

■ External Tools

A non-standard tool not attached to SOFTUNE Workbench can be used by setting it as an external tool and by calling it from SOFTUNE Workbench. Use this function to coordinate with a source file version control tool.

If a tool set as an external tool is designed to output the execution result to the standard output and the standard error output through the console application, the result can be specified to output the SOFTUNE Workbench Output window. In addition, the allow description of additional parameters each time the tool is activated.

To set an external tool, use the [Setup] - [Setting Tool] menu. To select the title of a set tool, use the [Setup] - [Activating Tool] menu.

■ Setting Options

When activating an external tool from SOFTUNE Workbench, options must be added immediately after the external tool name. Specify the file names, and unique options, etc.

SOFTUNE Workbench has a set of special parameters for specifying any file name and unique tool options. If any characters string described other than these parameters, such characters string are passed as is to the

external tool. For details about the parameters, see Section "1.11 Macro Descriptions Usable in Manager".

Note:

When checking [Use the Output window], note the following:

• Once a tool is activated, neither other tools nor the compiler/assembler can be activated until the tool is terminated.

• The Output window must not be used with a tool using a wait state for user input while the tool is executing. The user cannot perform input while the Output window is in use, so the tool cannot be terminated. To forcibly terminate the tool, select the tool on the Task bar and input Control - C, or Control - Z.

■ Reference Section

Setting Tools Starting Tools

CHAPTER 1 BASIC FUNCTIONS

1.11 Macro Descriptions Usable in Manager

This section explains the macro descriptions that can be used in the manager of SOFTUNE Workbench.

■ Macros

SOFTUNE Workbench has special parameters indicating that any file name and tool-specific options are specified as options.

The use of these parameters as tool options eliminates the need for options specified each time each tool is started.

The type of macro that can be specified and macro expansion slightly vary depending on where to describe macros. The macros usable for each function are detailed below. For the macros that can be specified for "Error Jump" and "External Editors" see Sections "1.7 Error Jump Function" and "1.9 Storing External Editors".

■ Macro List

The following is a list of macros that can be specified in SOFTUNE Workbench. The macros usable for each function are listed below.

- E xternal tools: Table 1.11-1 and Table 1.11-2

- Customize build: Table 1.11-1 and Table 1.11-2

- T ool options: Table 1.11 -2

The directory symbol \ is added to the option directories in Table 1.11-1 but not to t he macro directories in Table 1.11-2.

The sub-parameters in Table 1.11-3 can be specified in %(FILE), %(LOADMOUDLEFILE), %(PRJFILE). The sub-parameter is specified in the form of %(PRJFILE[PATH]). If the current directory is on the same drive, the relative path is used. The current directory is the workspace

directory for %(PRJFILE), and %(WSPFILE), and the project directory for other than them.

CHAPTER 1 BASIC FUNCTIONS

Table 1.11-1 List of Macros That Can Be Specified 1

Parameter Meaning

%f Passed as full-path name of file. (*1) %F Passed as main file name of file. (*1) %d Passed as directory of file. (*1) %e Passed as extension of file. (*1) %a Passed as full-path name of load module file.

%A Passed as main file name of load module file. (*2) %D Passed as directory of load module file. (*2) %E Passed as extension of load module file. (*2)

%x Passed as directory of project file. (*2)

%X Passed as main file name of project file. (*2) %% Passed as %.

Table 1.11-2 List of Macros That Can Be Specified 2

Parameter Meaning

%(FILE) Passed as full-path name of file. (*1) %(LOADMODULEFILE) Passed as full-path name of load module file. (*2) %(PRJFILE) Passed as full-path name of project file. (*2) %(WSPFILE) Passed as full-path name of workspace file. (*3) %(PRJPATH) Passed as directory of project file. (*2) %(ABSPATH) Passed as directory of target file. (*2) %(OBJPATH) Passed as directory of object file. (*2) %(LSTPATH) Passed as directory of list file. (*2) %(PRJCONFIG) Passed as project configuration name. (*2) (*3) %(ENV [Environment

variable]) %(TEMPFILE) Temporary file is created and its full-path name is passed. (*4)

The macros in (*1) are determined as follows:

Environment variable specified in environment variable brackets is passed.

- Customize build

1. Source file before and after executing compiler and assembler

2. Target file before and after executing linker, librarian and converter

3. Configuration file before and after executing configuration

CHAPTER 1 BASIC FUNCTIONS

- T ool options

• Null character

-Others

1. File as focus is on the SRC tab of project window and valid file name is selected

2. File on which focus is in internal editor as no valid file name can be obtained in 1

3. Null character if no valid file name can be obtained

The macros in (*2) are determined as follows:

- Customize build and tool options

• Information on configuration of project under building, making, compiling and assembling

-Others

1. Information on active configuration of project in which file is stored as focus is on the SRC tab of project window and valid file name is selected

2. Information on active configuration of active project if no valid file name can be obt ained in 1

*3: The macro can use only the project of the workspace project format. *4: The content of a temporary file can be specified only with customize build.

Table 1.11-3 List of Sub parameters 1

Sub parameter Meaning

[PATH] Directory of file [RELPATH] Relative Path of file [NAME] Main file name of file [EXT] Extension of file [SHORTFULLNAME] Full path name of short file [SHORTPATH] Directory of short file [SHORTNAME] Main file name of short file [FOLDER] Name of folder in which files are stored in the SRC tab of project window

*: The macro can be used only the project of workspace project format.

■ Examples of Macro Expansion

If the following workspace is opened, macro expansion is performed as follows:

Workspace : C:\Wsp\Wsp.wsp Active project : C:\Wsp\Sample\Sample.prj

Active project configuration Debug

Object directory : C:\Wsp\Sample\Debug\Obj\

(Can be specified only in %(FILE).)(*)

Subproject : C:\Subprj\Subprj.prj

Active project configuration Release

Object directory : C:\Subprj\Release\Obj\ Target file : C:\Subprj\Release\Abs\Subprj.abs

CHAPTER 1 BASIC FUNCTIONS

[Example] Macro expansion in external tools

Focus is on Subprj project file in the SRC tab of project window.

%a : C:\Subprj\Release\Abs\Subprj.abs %A : SUBPRJ.abs %D : C:\Subprj\Release\Abs\ %E : .abs %(FILE[FOLDER]) : Source Files\Common %(PRJFILE) : C:\Subprj\Subprj.prj

Focus is not in the SRC tab of project window.

%a : C:\Wsp\Sample\Debug\Abs\Sample.abs %A : Sample.abs %D : C:\Wsp\Sample\Debug\Abs\ %(PRJFILE) : C:\Wsp\Sample\Sample.prj

[Example] Macro expansion in customize build

Release configuration of Subprj project is built.

%(FILE) : C:\Subprj\LongNameFile.c %(FILE[PATH]) : C:\Subprj %(FILE[RELPATH]) : . %(FILE[NAME]) : LongNameFile %(FILE[EXT]) : .c %(FILE[SHORTFULLNAME]) : C:\Subprj\LongFi = ~1.c %(FILE[SHORTPATH]) : C:\Subprj %(FILE[SHORTNAME]) : LongFi~1 %(PRJFILE[RELPATH]) : ..\Subprj %(PRJPATH) : C:\Subprj %(OBJPATH) : C:\Subprj\Release\Obj %(PRJCONFIG) : Release %(ENV[FETOOL]) : C:\SOFTUNE %(TEMPFILE) : C:\Subprj\Release\Opt\_fs1056.TMP

[Example] Macro expansion in tool options

Release configuration of Subprj project is built.

%(FILE) : %(PRJFILE[RELPATH]) : ..\Subprj %(PRJPATH) : C:\Subprj %(OBJPATH) : C:\Subprj\Release\Obj %(PRJCONFIG) : Release %(ENV[FETOOL]) : C:\SOFTUNE

CHAPTER 1 BASIC FUNCTIONS

1.12 Setting Operating Environment

This section describes the functions for setting the SOFTUNE Workbench operating environment.

■ Operating Environment

Set the environment variables for SOFTUNE Workbench and some basic setting for the Project. To set the operating environment, use the [Setup]-[Setup Development Environment] menu.

● Environment Variables

Environment variables are variables that are referred to mainly using the language tools activated from SOFTUNE Workbench. The semantics of an environment variable are displayed in the lower part of the Setup dialog. However, the semantics are not displayed for environment variables used by tools added later to SOFTUNE Workbench.

When SOFTUNE Workbench and the language tools are installed in a same directory, it is not especially necessary to change the environment variable setups.

● Basic setups for Project

The following setups are possible.

- Open the previously worked-on Project at start up

When starting SOFTUNE Workbench, it automatically opens the last worked-on Project.

- Display options while compiling/assembli ng

Compile options or assemble options can be viewed in the Output window.

- Save dialog before closing Project

Before closing the Project, a dialog asking for confirmation of whether or not to save the Project to the file is displayed. If this setting is not made, SOFTUNE Workbench automatically saves the Project without any confirmation message.

- S ave dialog before compiling/assembling

Before compiling/assembling, a dialog asking for confirmation of whether or not to save a source file that has not been saved is displayed. If this setting is not made, the file is saved automatically before compile/assemble/make/build.

- Termination message is highlighted at Make/Build

At Compile, Assemble, Make, or Build, the display color of termination messages (Abort, No Error, Warning, Error, Fatal error, or Failing During start) can be changed freely by the user.

■ Reference Section

Development Environment

Note:

Because the environment variables set here are language tools for the SOFTUNE Workbench, the environment variables set on pr evious versions of SOFTUNE cannot be used. In particu lar, add the set values of [User Include Directory] and [Librar y Sea rc h Dire ctory] to [Tool Options Settings].

CHAPTER 1 BASIC FUNCTIONS

1.13 Debugger Types

This section describes the types of SOFTUNE Workbench debuggers.

■ Type of Debugger

SOFTUNE Workbench integrates three types of debugger: a simulator debugger, emulator debugger, and monitor debugger. Any one can be selected depending on the requirement.

■ Simulator Debugger

The simulator debugger simulates the MCU operations (executing instructions, memory space, I/O ports, interrupts, reset, etc.) with software to evaluate a program.

It is used for evaluating an uncompleted system and operation of individual units, etc.

■ Emulator Debugger

The emulator debugger is software to evaluate a program by controlling an emulator from a host through a communications line (RS-232C, LAN, USB).

Before using this debugger, the emulator must be initialized.

■ Monitor Debugger

The monitor debugger evaluates a program by putting it into an evaluation system and by communicating with a host. An RS-232C interface and an area for the debug program are required within the evaluation system.

1.14 Memory Operation Functions

This section describes the memory operation functions.

■ Functions for Memory Operations

- Display/Modify memory data

Memory data can be display in the Memory window and modified.

- Fill

The specified memory area can be filled with the specified data.

- Copy

The data in the specified memory area can be copied to another area.

- Compare

The data in the specified source area can be compared with data in the destination area.

- Search

Data in the specified memory area can be searched. For further details of the above functions, refer to "3.11 Memory Window" in "SOFTUNE Workbench Operation Manual".

- Display/Modify C variables

The names of variables in a C source file can be displayed in the Watch window and modified.

- Setting Watch point

By setting a watch point at a specific address, its data can be displayed in the Watch window. For further details of the above functions, refer to "3.13 Watch Window" in "SOFTUNE Workbench Operation Manual".

CHAPTER 1 BASIC FUNCTIONS

1.15 Register Operations

This section describes the register operations.

■ Register Operations

The Register window is opened when the [View] - [Register] menu is ex ecuted. The register and flag values can be displayed in the Register window.

For further details about modifying the register value and the flag value, refer to "4.4.4 Register" in "SOFTUNE Workbench Operation Manual".

The name of the register and flag displayed in the Register window varies depending on each MCU in use. For the list of register names and flag names for the MCU in use, refer to "Appendix A Register Name List" of " SOFTUNE Workbench Operational Manual".

■ Reference Section

1.16 Line Assembly and Disassembly

This section describes line assembly and disassembly.

■ Line Assembly

To perform line-by-line assembly (line assembly), right-click anywhere in the Disassembly window to display the short-cut menu, and select [Line Assembly]. For further details about assembly operation, refer to "4.4.3 Assembly" in "SOFTUNE Workbench Operation Manual".

■ Disassembly

To display disassembly, use the [View]-[Disassembly] menu. By default, disassembly can be viewed starting from the address pointed by the current program counter (PC). However, the address can be changed to any desired address at start-up.

Disassembly for an address outside the memory map range cannot be displayed. If this is attempted, "???" is displayed as the mnemonic.

■ Reference Section

Disassembly Window

CHAPTER 1 BASIC FUNCTIONS

1.17 Symbolic Debugging

The symbols defined in a source program can be used for command parameters (address). There are three types of symbols as follows:

• Global Symbol

• Static Symbol within Module (Local Symbol within Module)

• Local Symbol within Function

■ Types of Symbols

A symbol means the symbol defined while a program is created, and it usually has a type. Symbols become usable by loading the debug information file.

Furthermore, a type of the symbol in C language is recognized and the command is executed. There are three types of symbols as follows:

• Global symbol

A global symbol can be referred to from anywhere within a program. In C language, variables and functions defined outside a function without a static declaration are in this category. In assembler, symbols with a PUBLIC declaration are in this category.

• Static symbol within module (Local symbol wit hi n modul e)

A static symbol within module can be referred to only within the module where the symbol is defined. In C language, variables and functions defined outside a function with a static declaration are in this

category. In assembler, symbols without a PUBLIC declaration are in this category.

• Local symbol within function

A local symbol within a function exists only in C language. A static symbol within a function and an automatic variable are in this category.

- Static symbol within function

Out of the variables defined in function, those with static declaration.

- Automatic variable

Out of the variables defined in function, those without static declaration and parameters for the function.

■ Setting Symbol Information

Symbol information in the file is set with th e symbol information table by loadi ng a debug information file. This symbol information is created for each module.

The module is constructed for each source file to be compiled in C language, in assembler for each source file to be assembled.

The debugger automatically selects the symbol information for the module to wh ich the PC belongs to at abortion of execution (Called "the current module"). A program in C language also has information about which function the PC belongs to.

■ Line Number Information

Line number information is set with the line number information tab le in SOFTUNE Workbench when a debug information file is loaded. Once registered, such information can be used at anytime thereafter. Line

number is defined as follows:

CHAPTER 1 BASIC FUNCTIONS

[Source File Name] $Line Number

CHAPTER 1 BASIC FUNCTIONS

1.17.1 Referring to Local Symbols

This section describes referring to local symbols and Scope.

■ Scope

When a local symbol is referred to, Scope is used to indicate the module and function to which the local symbol to be referred belongs.

SOFTUNE Workbench automatically scopes the current modu le and function to refer to local symbols in the current module with preference. This is called the Auto-scope function, and the module and function currently being scoped are called the Current Scope.

When specifying a local variable outside the Current Scope, the variable name shoul d be specified by the module and function to which the variable belongs. This m ethod of specifying a variable is called a symbol path name or a Search Scope.

■ Moving Scope

As explained earlier, there are two ways to specify the reference to a variable: by adding a Search Scope when specifying the variable name, and by moving the Cu rrent Scope to the function with the symbol to be referred to. The Current Scope can be changed by displaying the Call Stack dialog and selecting the parent function. For further details of this operation, refer to "4.6.7 Stack" in "SOFTUNE Workbench Operation Manual". Changing the Current Scope as described above does not affect the value of the PC.

By moving the current scope in this way, you can search a local symbol in parent function with precedence.

■ Specifying Symbol and Search Procedure

A symbol is specified as follows:

[[Module Name] [\Function Name] \] Symbol Name

When a symbol is specified using the module and function names, the symbol is searched. However, when only the symbol name is specified, the search is made as follows:

1. Local symbols in function in Current Scope

2. Static symbols in module in Current Scope

3. Global symbols If a global symbol has the same name as a local symbol in the Current Scope, specify "\" or "::" at the start of global symbol. By doing so, you can explicitly show that is a global symbol.

An automatic variable can be referred to only when the variable is in memory. Otherwise, specifying an automatic variable causes an error.

CHAPTER 1 BASIC FUNCTIONS

1.17.2 Referring to Variable of C Language

C language variables can be specified using the same descriptions as in the source program written in C language.

■ Specifying C Language Variables

C language variables can be specified using the same descriptions as in the source program. The address of C language variables should be preceded by the ampersand symbol "&". Some examples are shown in the Table

1.17-1.

Table 1.17-1 Examples of Specifying Variables

Example of

Example of Variables

Regular Variable int data; data Value of data

Specifying

Variables

Semantics

Pointer char *p; *p Value pointed to by p

Array char a[5]; a[1] Value of second element of a

Structure struct stag {

char c; int i; }; struct stag st; struct stag *stp;

Union union utag {

char c; int i; } uni;

Address of variable int data; &data Address of data

Reference type int i;

int &ri = i;

st.c

stp- >c

uni.i Value of member i of uni

ri Same as i

Value of member c of st Value of member c of the structure to which stp points

CHAPTER 1 BASIC FUNCTIONS

■ Notes on C Language Symbols

The C compiler outputs symbol information with "_" prefixed to global symbols. For example, the symbol main outputs symbol information _main. However, SOFTUNE Workbench permits access using the symbol name described in the source to make the debug of program described by C language easier.

Consequently, a symbol name described in C language and a symbol name described in assembler, which should both be unique, may be identical.

In such a case, the symbol name in the Current Scope normally is preferred. To refer to a symbol name outside the Current Scope, specify the symbol with the module name.

If there are duplicated symbols outside the Current Scope, the symbol name searched first becomes valid. To refer to another one, specify the symbol with the module name.

CHAPTER 2

DEPENDENCE FUNCTIONS

This chapter describes the functions dependent on each Debugger.

2.1 Simulator Debugger

2.2 Emulator Debugger (MB2141)

2.3 Emulator Debugger (MB2147-01)

2.4 Emulator Debugger (MB2147-05)

2.5 Emulator Debugger (MB2198)

2.6 Emulator Debugger (MB2100-01)

2.7 Monitor Debugger

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1 Simulator Debugger

This section describes the functions of the simulator debugger for the F2MC-16 Family.

■ Simulator Debugger

The simulator debugger simulates the MCU operations (executing instructions, memory space, I/O ports, interrupts, reset, etc.) with software to evaluate a program.

It is used to evaluate an uncompleted system, the operation of single units, etc.

There are 2 types of simulator debuggers.

- Normal simulator debugger (normal)

- High-speed simulator debugger (fast)

This high-speed simulator debugger provides substantial reductions in simulation time due to a dramatic review of normal simulator debugger's processing methods.

The high-speed simulator debugger can be instruction processing performance for 10MIPS when it is operated by PC equipped with Pentium4 2.0GHz.

External I/F for simulator are equipped to high-speed simulator debugger to create peripheral simulation modules.

Please refer to "Appendix I External I/F DLL for Simulator" in "SOFTUNE Workbench Operation Manual".

■ Operating Condition of High-speed Simulator Debugger

The high-speed simulator debugger requires much more RAM space on the host PC than that of normal simulator debugger.

The required RAM size depends largely on your program size. For the required available RAM space, see the table below:

Basic use Fs907s.exe (This product) 20MB CODE size of target program per 64 KB 6MB DATA size of target program per 64 KB 1.5MB

Insufficient RAM space will lead to an extreme decrease in simulation speed. Target program size

CODE XX(KB) DATA YY(KB)

Required RAM space (MB) = 20 + (XX / 64) × 6 + (YY / 64) × 1.5

However, RAM space larger than the above may be needed depending on program allocation. Consecutive areas should be reserved as much as possible.

Example: Program with 1 MB of CODE and DATA sizes

Required RAM space (MB) = 20 + (1024 / 64) × 6 + (1024 / 64) × 1.5 = 140MB

■ Simulation Range

The simulator debugger simulates the MCU operations (instruction operations, memory space, I/O ports, interrupts, reset, power-save consumption mode, etc.) Peripheral I/Os, such as a timer, DMAC and serial I/O, other than the CPU core of the actual chip are not supported as peripheral resources. I/O space to which peripheral I/Os are connected is treated as memory space. There is a method for simulating interrupts like timer interrupts, and data input to memory li ke I/O ports. For details, see the sections concerning I/O port simulation and interrupt simulation.

- I nstruction simulation

- Memory simulation

- I /O port simulation (Input port)

- I /O port simulation (Output port)

- I nterrupt simulation

- Reset simulation

- Power-save consumption mode simulation

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.1 Setting Operating Environment

This section explains the operating environment setup.

■ Setting Operating Environment

For the simulator debugger for F2MC-16FX, it is necessary to set the following operating environment. Its predefined default settings are enabled at startup. Therefore, setup is not required when using the default settings. Adjusted settings can be used as new default settings from the next time.

• Boot ROM file automatic execution

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.1.1 Boot ROM File Automatic Execution

The simulator debugger for F2MC-16FX automatically loads and executes the Boot ROM file at the start of debugging.

■ Boot ROM File Automatic Execution

When the simulator debugger for F2MC-16FX is specified, the Boot ROM file is automatically loaded and then executed at the start of debugging. The Boot ROM file is stored in Lib\907\BootROM under the directory where Workbench is installed.

The directory containing the Boot ROM file can be disp layed using the [Project] - [Setup Project] menu , and can be modified in the setup project dialog. In addition, it is also possi ble to automatically execute the Boot ROM file during the debugger startup or reset of MCU. For details, see the "SOFTUNE Workbench Operation Manual".

Notes:

• When MCU reset is performed in the simulator debugger, the PC value varies, as shown below,

depending on whether it is F

MC-16FX: Starting address of the Boot ROM file

Other than F

• As the simulator debugger does not support fixed boot vectors, it always jumps to the reset vector after the execution of the Boot ROM file. For the operation after the execution of the Boot ROM file, see the LSI Specification Manual.

MC-16FX: Entry point in the target file (reset vector)

MC-16FX or not:

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.2 Instruction Simulation

This section describes the instruction simulation executed by SOFTUNE Workbench.

■ Instruction Simulation

This simulates the operations of all instructions supported by the F2MC-16/16L/16LX/16H/16F. It also simulates the changes in memory and register values due to such instructions.

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.3 Memory Simulation

This section describes the memory simulation executed by SOFTUNE Workbench.

■ Memory Simulation

The simulator debugger must first secure memory space to simulate instructions because it simulates the memory space secured in the host PC memory.

The following operation is required.

- To secure the memory area, either use the [Setup] - [Memory Map] menu, or the SET MAP command in the Command window.

- L oad the file output by the Linkage Editor (Load Module File) u sing either the [Debug] - [Load target file] menu, or the LOAD/OBJECT command in the Command window.

■ Simulation Memory Space

Memory space access attributes can be specified byte-by-byte using the [Setup] - [Memory Map] menu. The access attribute of unspecified memory space is Undefined using the [Setup] - [Memory Map] menu.

■ Memory Area Access Attributes

Access attributes for memory area can be specified as shown in Table 2.1-1. A guarded access break occurs if access is attempted against such access attribute while executing a program. When access is made by a program command, such access is allowed regardless of the attribute, CODE, READ or WRITE. However,

access to memory in an undefined area causes an error.

Table 2.1-1 Types of Access Attributes

Attribute Semantics

CODE Instruction operation enabled READ Data read enabled WRITE Data write enabled undefined Attribute undefined (access prohibited)

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.4 I/O Port Simulation

This section describes I/O port simulation executed by SOFTUNE Workbench.

■ I/O Port Simulation (Input Port)

There are two types of simulations in I/O port simulation: input port simulation, and output port sim ulation. Input port simulation has the following types:

- Whenever a program reads the specified port, data is input from the pre-defined data input source.

- W henever the instruction execution cycle count exceeds the specified cycle count, data is input to the port.

To set an input port, use the [Setup] - [Debug Environment] - [I/O Port] menu, or the SET INPORT command in the Command window.

Up to 4096 port addresses can be specified for the input port. The data input source can be a file or a terminal. After reading the last data from the file, the data is read again from the beginning of the f ile. If a terminal is specified, the input terminal is displayed at read access to the set port.

A text file created by an ordinary text editor, or a binary file containing direct code can be used as the data input file. When using a text file, input the input data inside commas (,). When using a binary file, select the binary radio button in the input port dialog.

■ I/O Port Simulation (Output Port)

At output port simulation, whenever a program writes data to th e specified port, writing is executed to the data output destination.

To set an output port, either use the [Setup] - [Debug Environment] - [I/O Port ] menu, or the SET OUTPORT command in the Command window.

Up to 4096 port addresses can be set as output ports. Select either a file or terminal (Output Terminal window) as the data output destination.

A destination file must be either a text file that can be referred to by regular editors, or a binary file. To output a binary file, select the Binary radio button in the Output Port dialog.

Note:

The following method is not supported by high-speed simulator debugger.

• Whenever the instruction execution cycle count exceeds the specified cycle count, data is input to the port.

Furthermore the setting of memo ry map is necessar y to set I/O port. When deleting memory ma p, I/O port is also deleted.

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.5 Interrupt Simulation

This section describes the interrupt simulation executed by SOFTUNE Workbench.

■ Interrupt Simulation

Simulate the operation of the MCU (including intel ligent I/O service*) in response to an interrupt request. Note that intelligent I/O service does not support any end request from the resource.

Provisions for the causes of interrupts and interrupt control registers are made by referencing data in the install file read at simulator start up.

*: Automatic data transfer function between I/O and memory is called an intelligent I/O service. This function allows exchange of data between memory and I/O, which was done previously by the interrupt handling program, using DMA (Direct Memory Access). (For details, refer to the user manual for each model.)

The methods of generating interrupts are as follows:

- Execute instructions for the specified number of cycles while the program is runn ing (during execution of executable commands) to generate interrupts corresponding to the specified interrupt numbers and cancel the interrupt generating conditions.

- Continue to generate interrupts each time the number of instruction execution cycles exceeds the specified number of cycles.

Note:

The method of generating interrupts is set by the [Setup]-[Debug envi ronment]-[Interrup t] menu. If interru pts are masked by the interrupt enable flag when the interrupt generating conditions are established, the interrupts are generated after they are unmasked.

MCU operation in response to an interrupt request is also supported for the following exception handling:

- E xecution of undefined instructions

- A ddress error in program access (Program access to internal RAM area and internal I/O area)

- S tack area error (only for F

When an external interrupt is generated while under an interrupt mask at high-speed simulator debugger, that interrupt factor is eliminated.

MC-16F)

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.6 Reset Simulation

This section describes the reset simulation executed by SOFTUNE Workbench.

■ Reset Simulation

The simulator debugger simulates the operation when a reset signal is inp ut to the MCU using the [Debug][Reset MCU] menu and initializes the registers. Th e function for perform ing reset processing by operation of MCU instructions (writing to RST bit in standby control register) is also suppo rted. In this case, the reset message (Reset) is displayed on the status bar.

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.7 Low-Power Consumption Mode Simulation

This section describes the low-power consumption SOFTUNE Workbench mode simulation executed by SOFTUNE Workbench.

■ Low-Power Consumption Mode Simulation

The MCU enters the low-power consumption mode in accordance with the MCU instruction operation (Write to SLEEP bit or STOP bit of standby control register). Once in the sleep mode or stop mode, a message ("sleep" for sleep mode, "stop" for stop mode) is displayed on the Status Bar. The loop keeps running until either an interrupt request is generated, or the [Debug] - [Abort] menu is executed. Each cycle of the loop increments the count by 1. During this period, I/O port processin g can be operated. Writing to the standby control register using a command is not prohibited.

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.8 STUB Function

This section describes the STUB function which executes commands automatically when the breakpoint hit occurs.

■ STUB Function

The STUB function is supported so that a series of commands in the command list can automatically be executed when a specified breakpoint is hit. The use of this function enables spot processing, such as simple I/O simulation, external interrupt generation, and memory reprogramming, without changing the main program. This function is effective only when the simulator debugger is used.

■ Setting Method

The STUB function can be set by the following commands.

execution starts

Program execution

execution ends

Breakpoint is hit

Execution restarts

Execution stops

Break (STUB) processing

Yes

Is there a command list

in breakpoint?

Yes

Process a command list in

breakpoint (execute commands).

Re-execute (is NOBREAK

specified)?

• Dialog

1. Breakpoint Set Dialog - [Code] tab

2. Breakpoint Set Dialog - [Data] tab

• Command

1. SET BREAK

2. SET DATABREAK

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.9 Break

In the simulator debugger, five types of break functions can be used. When the program execution is aborted by each break function, the address and the break factor to do the break are displayed.

■ Break Functions

In this simulator debugger, the following five types of break functions are supported.

• Code break

• Data break

• Trace-buffer-full break

• Guarded break

• Forced break

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.9.1 Code Break

It is a function that the simulator debugger aborts the program execution when the code access specified while executing the program is done.

■ Flow of Code Break

When the program reaches the breakpoint (Immediately before an instruction memory positional is executed), the simulator debugger does the following processing.

1) The execution of the program is aborted (Before executing the instruction).

2) When the attainment frequency is checked, and it doesn't reach the attainment frequency of the specified breakpoint, the program execution is restarted. It moves to 3) when it reaches the attainment frequency.

3) The memory position in which execution was aborted is displayed in the status bar.

The breakpoint can be set up to 65535 points or less. When a break occurs due to a code break, the following message is displayed on the Status Bar.

Break at Address by breakpoint

■ Setting Method

The code break is controlled by the following method.

• Command

- SET BREAK Refer to "3.1 SET BREAK (type 1)" in "SOFTUNE Workbench Command Reference Manual".

• Dialog

- Breakpoint Set Dialog [Code] tab Refer to "4.6.4 Breakpoint" in "SOFTUNE Workbench Operation Manual".

•Window

- S ou rce window/Disassembly window

■ Notes on Code Break

There are several points to note in using code break. First, some points affecting code break are explained.

● Invalid Breakpoints

• No break occurs when a breakpoint is set at the instruction immediately after the following instructions.

MC-16/16L/16LX/16H: • PCB • DTB • NCC • ADB • SPB • CNR

MC-16F: • PCB • DTB • NCC • ADB • SPB • CNR

• No break occurs when breakpoint set at address other than starting address of instruction.

• MOV ILM,#imm8 • AND CCR,#imm8

• OR CCR,#imm8 • POPW PS

Here are some additional points about the effects on other commands.

Note:

CHAPTER 2 DEPENDENCE FUNCTIONS

● Dangerous BreakPoints

• Never set a breakpoint at an address other than the instruction starting address.

• If a breakpoint is the last 1 byte of an instruction longer than 2 bytes length, and i f such an address is even, the following abnormal operation will result:

- If instruction executed by STEP command, instruction execution not aborted.

- If breakpoint specified with GO command, set at instruction immediately after such instruction, the breakpoint does not break.

[High-speed version simulator debugger]

• When the break function is used, it is necessary to set the memory map beforehand. When the memory map is deleted, the setting of the breakpoint is deleted.

• When the breakpoint with pass count is set to the reset vector in 16FX, hit count is cleared after the Boot ROM file is executed. For details of the execution of the Boot ROM file, refer to "■ Setting Options in [Boot ROM] (Only MB2198)" of section "4.5.5.9 Setting Debug Options" in "SOFTUNE Workbench Operation Manual".

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.9.2 Data Break

It is a function that the simulator debugger aborts the program execution when the data access (read and write) specified while executing the program is done.

■ Flow of Data Break

The simulator debugger does the following processing when the program writes in the breakpoint or it reads it.

1) After the execution of the instruction is completed, the execution of the program is aborted.

2) It moves to 3) when the program execution is restarted when the access frequency is checked, and it doesn't reach the access frequency of the specified data break, and it reaches the access frequency.

3) When it reaches the access frequency and the program execution is aborted, the memory position of the instruction in which it is writing (Or, read it) is displayed to the memory position o f the data breakpoint and the memory position in the status bar.

4) Next, the executed memory position is displayed.

The breakpoint can be set up to 65535 points or less. When a break occurs due to a data break, the following message is displayed on the Status Bar.

Break at Address by databreak at Access address

■ Setting Method

The data break is controlled by the following method.

• Command

- SET DATABREAK

• Dialog

- Breakpoint Set Dialog [Data] tab

Note:

[High-speed version simulator debugger]

• When the break function is used, it is necessary to set the memory map beforehand. When the memory map is deleted, the setting of the breakpoint is deleted.

Refer to "3.10 SET DATABREAK (type 2)" in "SOFTUNE Workbench Command Reference Manual".

Refer to "4.6.4 Breakpoint" in "SOFTUNE Workbench Operation Manual".

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.9.3 Trace-Buffer-Full Break

It is a function to abort the program execution when the trace buffer becomes full.

■ Trace-Buffer-Full Break

It is a function to abort the program execution when the trace buffer becomes full. When a break occurs due to a trace-buffer-full break, the following message is displayed on the Status Bar.

Break at Address by trace buffer full

■ Setting Method

The trace-buffer-full break is controlled by the following method.

• Command

- SET TRACE/BREAK Refer to "4.29 SET TRACE(type 1)" in "SOFTUNE Workbench Command Reference Manual".

• Dialog

- Trace Set Dialog Refer to "4.4.8 Trace" in "SOFTUNE Workbench Operation Manual".

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.9.4 Guarded Access Break

It is a function to abort the program execution when the violation to the access attribute, doing the access, and guarded (An undefined area cannot be accessed) area are accessed.

■ Guarded Access Break

It is a function to abort the program execution when the violation to the access attribute, doing the access, and guarded (An undefined area cannot be accessed) area are accessed.

Guarded access break functions as follows.

• Code guarded When the instruction execution to the area without the code attri bute

• Read guarded When read the area without the read attribute

• Write guarded When writing it in the area without the write attribute

When a break occurs due to a guarded break, the following message is displayed on the Status Bar.

Break at Address by guarded access {code/read/write} at Access address

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.9.5 Forced Break

It is a function to abort the execution of the program compulsorily.

■ Forced Break

It is a function to abort the execution of the program compulsorily. When a break occurs due to a forced break, the following message is displayed on the Status Bar.

Break at Address by command abort request

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.10 Measuring Execution Cycle Count

This function measures the program execution cycle count.

■ Measurement Items

Measures program execution cycle count and step counts.

● Execution Cycle Count

This is calculated based on the basic cycle count of each instruction described in the Programming Manual. A compensation value (a, b), which is described in the list of an instruction in Programming Manual, is

calculated as 1. The maximum measurable value varies, as shown below, whether the normal or the high-speed simulator

debugger is used. Normal debugger: Max. (2 to the power of 32 - 1) = 4,294,967,295 cycles High-speed debugger: Max. (2 to the power of 64 - 1) = 18,446,744,073,709,551,615 cycles

● Execution Step Count

Measures program execution step counts. For both the normal simulator debugger and the high-speed sim ulator debugger, the maximum measurable

count is "2 to the power of 32 - 1", in other words, up to 4,294,967,295 steps. The measurement is performed whenever a program is executed, and the measurement result displays the

following two values:

• Step counts spent on the previous program execution

• Total step counts spent on the program execution since the previous clearing

■ Displaying Measurement Results

Either of the following methods can be used to display the measurement results.

● Display by dialog

The results appear in the time measurement dialog, which can be displayed by selecting [Debug] – [Time Measurement] menu.

For details, refer to Section "4.6.8 Time Measurement" in "SOFTUNE Workbench Operation Manual".

● Display by command

Enter the SHOW TIMER command in the command window. For deta i l s , ref e r to S e c tion " 4 .27 S H O W TIME R " in "SOFTUNE Workbench Command Reference Manual".

■ Clearing Measurement Results

Either of the following methods can be used to clear the measurement results.

● Operation by dialog

Click the [Clear] button in the time measurement dialog, which can be displayed by selecting [Debug] – [Time Measurement] menu.

For details, refer to Section "4.6.8 Time Measurement" in "SOFTUNE Workbench Operation Manual".

● Clearing by command

Enter the CLEAR TIMER command in the command window. For details, refer to Section "4.28 CLEAR TIMER" in "SOFTUNE Workbench Command Reference Manual".

Note:

Because no simulation was done on pipeline process or cache operation inside the chip, it may differ from an actual chip for normal simulator debugger and/or high-speed simulator debugger.

CHAPTER 2 DEPENDENCE FUNCTIONS

. . . .

-3

-2

-1 0 (Trigger point)

2.1.11 Trace

The address and status information can be sampled during program execution to record it in a trace buffer. This function is called a trace.

■ Trace

The address and status information can be sampled during program execution to record it in a trace buffer. This function is called a trace. Data of the trace buffer can be used to make a detailed analysis of a program execution history.

The trace buffer is in the form of a ring. When it becomes full, it records the next data by automatically overwriting the buffered data at the beginning.

■ Trace Data

The simulator debugger can sample 1000 frames of trace data for the address of the executed instruction.

■ Abortion of Trace Measurement

While the trace function is enabled, data is always sampled and recorded in the trace buffer during execution of a user program.

The program execution aborts due to a break factor such as a breakpoint, terminating the trace. Furthermore, when the trace buffer becomes full, a program break can be invoked. This break is called a

trace buffer full break.

■ Frame Number

A number is assigned to each frame of sampled trace data. This number is called a frame number. The frame number is used to specify the display start position of the trace buffer. The number 0 is assigned to the last-sampled trace data. Negative values are assigned to trace data that have

been sampled before the arrival at the triggering position.

Figure 2.1-1 Frame Numbering at Tracing

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.11.1 Setting Trace

You must set the following two items to perform a trace. After that, trace data will be sampled with the execution of the program.

■ Setting Trace

1. Enable the trace function. This program will startup and will be enabled.

•Dialog

This is done by [Setup] - [Trace] in the trace window shortcut menu.

• Command

Enter the ENABLE TRACE command.

2. Set the trace buffer full break. When the trace buffer is full, you can make a break. When starting up this program, it is setup for no breaks.

•Dialog

This is done using the trace window shortcut menu [Setup] - [Trace].

• Command

Enter the SET TRACE/BREAK command.

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.11.2 Displaying Trace Data

Data recorded in the trace buffer can be displayed.

■ Displaying Trace Data

The trace window or command window displays how much trace data is stored in the trace buffer.

• Trace window Select [Refresh] in the trace window shortcut menu.

• Command window Enter the SHOW TRACE command.

■ Display Format of Trace Data

There are two display formats of the trace data.

• Instruction: The instruction operation is displayed in disassembly units.

• Source: This mode only displays source lines.

■ Clearing Trace Data

Either of the following methods can be used to clear data in the trace buffer.

•Window Select [Clear] in the trace window shortcut menu.

• Command Enter the CLEAR TRACE command.

2.1.11.3 Searching Trace Data

The trace buffer can be searched to locate target data.

■ Searching Trace Data

The trace buffer has 1000 frames, so the target data may not be found immediately. Therefore the trace data can be searched from data in the trace buffer by specifying an address.

■ How to Search Trace Data

Either of the following methods can be used to search the trace data.

•Window Select [Find] in the trace window shortcut menu.

• Command Enter the SEARCH TRACE command.

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.11.4 Saving Trace Data

This section explains how to save trace data.

■ Saving Tr ace Data

Trace data can be saved in a specified file. The following two methods are available to save trace data: using GUI (window or dialog) and using only the

command. The same result is obtained from both methods.

● Using GUI for Saving Trace Data

1. Display the trace window.

- S elect [View] - [Trace] menu.

2. Specify the name of the file in which to save trace data.

- Right-click on the trace window, and select [Save] from the shortcut menu. The [Save as] dialog appears. Specify the file name and where to save trace data. For details, refer to Section "4.4.8 Trace" in "SOFTUNE Workbench Operation Manual".

● Using Command for Saving Trace Data

1. Save trace data.

- Execute the SHOW TRACE/FILE command. For details, refer to Section "4.33 SHOW TRACE (type 3)" in "SOFTUNE Workbench Command Reference Manual". When additionally saving trace data in an existing file, execute the SHOW TRACE/FILE/APPEND command.

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.12 Measuring Coverage

In the high-speed version simulator debugger, the C0 coverage measurement function is provided. Use this function to find what percentage of an entire program has been executed.

■ Coverage Measurement Function

When testing a program, the program is executed with various test data input and the results are checked for correctness. When the test is finished, every part of the entire program should have been executed. If any part has not been executed, there is a possibility that the test is insufficient.

It can know what percentage of the entire program executed when the coverage function for the high-speed version simulator debugger to have is used.

In addition, details such as which addresses were not accessed can be checked. In this debugger, the range to measure coverage can be set. Please set the time base range only to the code area when you do the C0 coverage. Moreover, the access of the variable can be examined as the variable not used is searched out by setting the

time base range to the data area.

■ Coverage Measurement Procedures

The procedure for coverage measurement is as follows:

• Set range for coverage measurement: SET COVERAGE

• Measuring coverage: GO, STEP, CALL

• Displaying measurement result: SHOW COVERAGE

■ Coverage Measurement Operation

The following operation can be made in coverage measurement:

• Load/Save of coverage data: LOAD/COVERAGE. SAVE/COVERAGE

• Clearing coverage data: CLEAR COVERAGE

• Canceling coverage measurement range: CANCEL COVERAGE

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.12.1 Coverage Measurement Procedures

The procedure for coverage measurement is as follows:

• Set range for coverage measurement:SET COVERAGE

• Measure coverage:GO, STEP, CALL

• Display measurement result:SHOW COVERAGE

■ Setting Range for Coverage Measurement

Use the SET COVERAGE command to set the measurement range. Up to 32 ranges can be specified. By specifying /AUTOMATIC for the command qualifier, the code area for the loaded module is set

automatically. However, the library code area is not set when the C compiler library is linked.

[Example]

>SET COVERAGE FF0000..FFFFFF

■ Measuring Coverage

When preparing for coverage measurement, execute the program. Measurement starts when the program is executed by using the GO, STEP, or CALL command.

■ Displaying Coverage Measurement Result

To display the coverage measurement result, use the SHOW COVERAGE command. The following can be displayed:

• Display coverage rate of total measurement area

• Displaying coverage rate of load module

• Summary of 16 addresses as one block

• Details indicating access status of each address

• Displaying coverage measurement result per source line

• Displaying coverage measurement result per machine instruction

● Displaying coverage rate of total measurement area (specify /TOTAL for the command qualifier)

>SHOW COVERAGE/TOTAL

total coverage : 82.3%

● Displaying coverage rate of load module (specify /MODULE for the command qualifier)

>SHOW COVERAGE/MODULE

sample.abs . . . . . . . . . . . . . . (84.03%)

+- startup.asm . . . . . . . . . . . (90.43%)

+- sample.c . . . . . . . . . . . . . (95.17%)

+- samp.c . . . . . . . . . . . . . . (100.00%)

Displays the load modules and the coverage rate of each module.

● Summary (Specify /GENERAL for command qualifier)

>SHOW COVERAGE/GENERAL (HEX)0X0 +1X0 +2X0

+---------------+---------------+------ -----address 0123456789ABCDEF0123456789ABCDEF0123456 ... ABCDEF C0(%)

FF0000 **3*F*....... 32.0

Display the access status of every 16 addresses

. : No access

: Display the number accessed in 16 addresses by the hexadecimal number.

1 to F

: Access all of the 16 addresses.

● Details (Specify /DETAIL for command qualifier)

>SHOW COVERAGE/DETAIL FF0000

CHAPTER 2 DEPENDENCE FUNCTIONS

Display one line of a coverage rate

address +0 +1 +2 +3 +4 +5 +6 +7 +8 +9 +A +B +C +D +E +F C0(%) FF0000 - - - - - - - - - - - - - - - - 100.0 FF0010 - - - - - - - - - - - - - - - - 100.0

FF0020 . . . . - - - . . . . . . . . . 18.6

FF0030 - - - - - - - - - - - - - - - - 100.0 FF0040 - . - - - - - - - - - - - - - - 93.7 FF0050 - - - - - - - - - - - - - - - - 100.0

FF0060 . . . . . . . . . . . . . . . . 0.0

FF0070 . . . . . . . . . . . . . . . . 0.0

FF0080 . . . . . . . . . . . . . . . . 0.0

Display the access status of every 1 address

: No access

- : Access

CHAPTER 2 DEPENDENCE FUNCTIONS

>SHOW COVERAGE/SOURCE main * 70: { 71: int i; 72: struct table *value[16]; 73: * 74: for (i=0; i<16; i++) * 75: value[i] = &target[i]; 76: * 77:

sort_val(value, 16L);

. 78: }

Displays execution status of each source line.

. :

No executing

Executing

Blank : Line which the code had not been generated or is outside

the scope of the coverage measurement

● Displays per source line (specify /SOURCE for the command qualifier)

● Displays per machine instruction (specify /INSTRUCTION for the command qualifier)

>SHOW COVERAGE/INSTRUCTION F9028F sample.c$70 {

* F9028F \main: * F9028F 0822 * F90291 4F01 sample.c$74 for (i=0; i<16; i++) . F90293 D0 . F90294 CBFE . F90296 BBFE . F90298 3B1000 . F9029B FB18 sample.c$75 value[i] = &target[i]; . F9029D BBFE MOVW . F9029F 0C . F902A0 98 . F902A1 71F3DE . F902A4 7700 . F902A6 4214 . F902A8 7833FE . F902AB 38A001

Displays execution status of each machine command line.

. : *

Blank :

No executing Executing

Instruction outside the scope of the coverage measurement

LINK PUSHW

MOVN MOVW

MOVW CMPW BGE

LSLW MOVW MOVEA ADDW MOV

MULUW

ADDW

#22 RW0

A,#0 @RW3-02,A

A,@RW3-02 A,#0010 F902B5

A,@RW3-02 A RW0,A A,@RW3-22 RW0,A A,#14 A,@RW3-02 A,#01A0

CHAPTER 2 DEPENDENCE FUNCTIONS

2.1.13 Checking Debugger Information

This section explains how to check information about the simulator debugger.

■ Debugger Information

This simulator debugger enables you to check the following information at startup.

• SOFTUNE Workbench file information If any errors have been discovered during SOFTUNE Workbench operations, check this information and contact our sales department or support department.

■ How to Check

Use one of the following methods to check debugger information.

• Command

- SHOW SYSTEM Refer to Section "1.19 SHOW SYSTEM" in "SOFTUNE Workbench Command Reference Manual".

• Dialog

- Version information dialog Select [Help] - [Version Information] menu. For details, refer to Section "4.9.3 Version Information" in "SOFTUNE Workbench Operation Manual".

■ Displayed Contents

LICENCED MATERIAL -

PROGRAM PROPERTY OF FUJITSU SEMICONDUCTOR LIMITED ======================================================= Cpu information file path: CPU information file path Cpu information file version: CPU information file version ======================================================= Add in DLLs

-------------------------------------------------------

SiCmn Product name: SOFTUNE Workbench File Path: SiC907.dll path Version: SiC907.dll version

----------------------------

SiiEd File Path: SiiEd3.ocx path Version: SiiEd3.ocx version

-------------------------------------------------------

SiM907 Product name: SOFTUNE Workbench File Path: SiM907.dll path Version: SiM907.dll version

CHAPTER 2 DEPENDENCE FUNCTIONS

---------------------------Language Tools

- F2MC-16 Family SOFTUNE C Compiler version File Path: fcc907s.exe path

- F2MC-16 Family SOFTUNE Assembler version File Path: fasm907s.exe path

- F2MC-16 Family SOFTUNE Linker version File Path: flnk907s.exe path

- F2MC-16 Family SOFTUNE Librarian version File Path: flib907s.exe path

- SOFTUNE FJ-OMF to S-FORMAT Converter version File Path: f2ms.exe path

- SOFTUNE FJ-OMF to INTEL-HEX Converter version File Path: f2is.exe path

- SOFTUNE FJ-OMF to INTEL-EXT-HEX Converter version File Path: f2es.exe path

- SOFTUNE FJ-OMF to HEX Converter version File Path: f2hs.exe path

------------------------------------------------------SiOsM Product name: Softune Workbench File Path: SiOsM907.dll path Version: SiOsM907.dll version

------------------------------------------------------F2MC-16 Series Debugger DLL Product name: SOFTUNE Workbench File Path: SiD907.dll path Version: SiD907.dll version

----------------------------

Debugger type : Current debbuger type MCU type : Currently selected target MCU VCpu dll name : Path and name of the currently used VCpu dll VCpu dll version : Version of the currently used virtual debugger DLL REALOS version : REALOS version

------------------------------------------------------SiIODef Product name: Softune Workbench File Path: SiIODef.dll path Version: SiIODef.dll version

======================================================= Current path: Path of the currently used project Language: Currently used language Help file path: Help file path

CHAPTER 2 DEPENDENCE FUNCTIONS

2.2 Emulator Debugger (MB2141)

This section explains the functions of the emulator debuggers for the MB2141.

■ Emulator Debugger

When choosing the emulator debugger from the setup wizard, select one of the following emulators. The following description explains the case when MB2141 has been selected.

MB2141 MB2147-01 MB2147-05 MB2198

The emulator debugger for the MB2141 is software that controls an emulator from a host computer via a communications line (RS-232C or LAN) to evaluate programs.

The following series can be debugged: When MB2141-506 pod used

MC-16/16H

MC-16F

MC-16L

MC-16LX

When MB2141-507 pod used

MC-16F

MC-16L

MC-16LX

Before using the emulator, the emulator must be initialized. For further details, refer to "Appendix B Download Monitor Program", and "Appendix C Setting up LAN

Interface" in "SOFTUNE Workbench Operation Manual".

CHAPTER 2 DEPENDENCE FUNCTIONS

2.2.1 Setting Operating Environment

This section explains the operating environment setup.

■ Setting Operating Environment

For the emulator debugger for the MB2141, it is necessary to set the following operating environment. Predefined default settings for all these setup items are enabled at startup. Therefore, setup is not required when using the default settings. Adjusted settings can be used as new default settings from the next time.

- MCU operation mode

- Debug area

- Memory mapping

- Timer minimum measurement unit

2.2.1.1 MCU Operation Mode

There are two MCU operation modes as follows:

• Debugging Mode

• Native Mode

■ Setting MCU Operation Mode

Set the MCU operation mode. There are two operation modes: the debugging mode, and the native mode. Choose either one using the SET

RUNMODE command. At emulator start-up, the MCU is in the debugging mode. When the MCU operation mode is changed, all the following are initialized:

- Data breakpoints

- E vent condition settings

- S equencer settings

- Trace measurement settings and trace buffer

CHAPTER 2 DEPENDENCE FUNCTIONS

- Performance measurement settings and measured result

● Debugging Mode

All the operations of evaluation chips can be analyzed, but their operating speed is slower than that of massproduced chips.

● Native Mode

Evaluation chips have the same timing as mass-produced chips to control the operating speed. Note that the restrictions the shown in Table 2.2-1 are imposed on the debug functions.

Table 2.2-1 Restrictions on Debug Functions in Native Mode

Applicable series Restrictions on debug functions

MC-16/16H

Common to all series - When a data read access occurs on the MCU internal bus, the internal bus

- Memory mapping setting is disabled and each area is accessed to the MCU specifications.

- Traces cannot be disassembled.

access information is not sampled and stored in the trace buffer.

- Even when a data break or event (data access condition) is set for data on the MCU internal bus, it may not become a break factor or sequencer-triggering factor.

- The coverage function may fail to detect an access to data on the MCU internal bus.

CHAPTER 2 DEPENDENCE FUNCTIONS

■ MCU Operation Speed

To support a broader range of MCU operation speeds, the emulator adjusts control of the MCU according to the MCU operation speed.

Normally, set the low-speed operation mode. If the F malfunctions occur, change the setting to the high-speed operation mode.

Also, to start at low speed and then change to high speed because of the gear setting, etc., use the SET RUNMODE command to change the setting.

MC-16H/16F series is operated at high speed and

CHAPTER 2 DEPENDENCE FUNCTIONS

2.2.1.2 Debug Area

Set the intensive debugging area out of the whole memory space. The area functions are enhanced.

■ Setting Debug Area

There are two debug areas: DEBUG1, and DEBUG2. A continuous 512KB area (8 banks) is set for each area.

Set the debug area using the SET DEBUG command. Setting the debug area enhances the breakpoints/data breakpoints and the coverage measurement function.

- Enhancement of Breakpoints

Up to six breakpoints (not including temporary breakpoints set using GO command) can be set when the debug area has not been set yet.

When setting the debug area as the CODE attribute, up to 65535 breakpoints can be set if they are within the area. At this time, up to six breakpoints can be set for an area other than the debug area, but the total count of breakpoints must not exceed 65535.

- Enhancement of Data Breakpoints

Up to six data breakpoints can be set when the debug area has not been set yet. When setting the debug area of the data attribute (READ, WRITE), up to 65535 data b reakpoints can be

set if they are within the area and have the same attribute. At this time, up to six data breakpoints can be set for an area other than the area or for a different attribute, but the total number of data breakpoints must not exceed 65535.

- Enhancement of Coverage Measurement Function

Setting the debug area enables the coverage measurement function. In coverage measurement, the measurement range can be specified only within the area specified as the debug area.

The attributes for the debug area are "Don't care" as long as it is being used for coverage measurement. The coverage measurement attribute can be set, regardless of the debug area attributes.

CHAPTER 2 DEPENDENCE FUNCTIONS

2.2.1.3 Memory Area Types

A unit in which memory is allocated is called an area. There are seven different area types.

■ Memory Area Types

A unit to allocate memory is allocated is called an area. There are seven different area types as follows:

- User Memory Area

Memory space in the user system is called the user memory area and this memory is called the user memory. Up to eight user memory areas can be set with no limit on the size of each area.

Access attributes can be set for each area; for example, CODE, READ, etc., can be set for ROM area, and READ, WRITE, etc. can be set for RAM area. If the MCU attempts access in violation of these attributes, the MCU operation is suspended and an error is displayed (guarded access break).

To set the user memory area, use the SET MAP command. The F the debugging mode.

- Emulation Memory Area

Memory space substituted for emulator memory is called the emulation memory area, and this memory is called emulation memory.

As emulation memory area, Using MB2145-506 emulation pod, up to seven areas (including mirror area and internal ROM area described below) each with a maximum size of 64 KB can be set. An area larger than 64 KB can be set, but the areas are managed internally in 64 KB units.

Using MB2145-507 emulation pod, up to seven areas (including mirror area and internal ROM area described below) each with a maximum size of 512 KB can be set.

The memory operation command can be executed for this area while executing MCU. To set the emulation memory area, use the SET MAP command. Attributes are set as for user memory

area.

MC-16/16H only allows this setup in

Note:

Even if the MCU internal resources are set as emulation memory area, access is made to the internal

resources. The F

- Mirror Area

The mirror area is a region in the emulator memory that makes copies of user memory accesses. The memory in this area is called a mirror region.

The mirror area is used while it overlaps with a user memory area or undefined area. It is implemented by the emulation memory. Up to five mirror areas can be defined including emulation memory areas.

Mirror areas are used to reference the user memory during on-the-fly execution (For further details, refer to Section "2.2.4 On-the-fly Memory Access").

Mirror areas can be set using the SET MAP command. If the memory contents copy option is selected when a mirror area is set, the contents of the mirror area are always the same contents as the user memory.

MC-16/16H only allows this setup in the debugging mode.

Note:

CHAPTER 2 DEPENDENCE FUNCTIONS

When the F

MC-16/16H is used, mirror area setup can be performed only in the debu gging mode.

- Internal ROM Area

The area where the emulator internal memory is substituted for internal ROM is called the in ternal ROM area, and this memory is called the internal ROM memory.

Only one internal ROM area with a size up to 128 KB can be specified. The internal ROM area is capable to set by the "Setup Map" dialog opening by "Debugger Memory Map... " from "Setup".

The internal memory area, it is set a suitable area automa tically by the selected MCU.

- Internal ROM Image Area (F2MC-16L, F2MC-16LX, F2MC-16F only)

Some types of MCUs have data in a specific area of internal ROM appearing to 00 bank. This specific area is called the internal ROM image area.

The internal ROM image area is capable to set by the "Setup Map" dialog opening by "Debugger Memory Map... " from "Setup". This area attribute is automatically set to READ/CODE. The same data as in the internal ROM area appears in the internal ROM image area.

Note that the debug information is only enabled for either one (one specified when linked). To debug onl y the internal ROM image area, change the creation type of the load module file.

Note:

The internal memory area, it is set a suitable area automa tically by the selected MCU.

- Internal Instruction RAM Area (F2MC-16H only)

Some types of MCUs have the internal instruction RAM, and this area is call ed the internal instruction RAM area.

The internal instruction RAM area, it is capable to set by the "Internal Instruction RAM area" tab in the "Setup CPU Information" dialog (select menu "project"-"setup project...", select the "MCU" tab, and push the "CPU Information..." button). The size must be specified to either H'100, H'200, H'400, H'800, H'1000, H'2000 or H'4000 bytes.

The internal memory area, it is set a suitable area automa tically by the selected MCU.

- Undefined Area

A memory area that does not belong to any of the areas described above is part of the user memory area. This area is specifically called the undefined area.

The undefined area can be set to either NOGUARD area, which can be accessed freely, or GUARD area, which cannot be accessed. Select either setup for the whole undefined area. If the area attribute is set to GUARD, a guarded access error occurs if access to this area is attempted.

CHAPTER 2 DEPENDENCE FUNCTIONS

Note:

The F

MC-16/16H only allows this setup in the debugging mode.

CHAPTER 2 DEPENDENCE FUNCTIONS

2.2.1.4 Memory Mapping

Memory space can be allocated to the user memory, the emulation memory, etc., and the attributes of these areas can be specified. However, the MCU internal resources are not dependent on this mapping setup and access is always made to the internal resources.

■ Access Attributes for Memory Areas

The access attributes shown in Table 2.2-2 can be specified for memory areas. A guarded memory access break occurs if access is attempted in violation of these attributes while executing

a program. When access to the user memory area and the emulation memory area is made using program commands,

such access is allowed regardless of the CODE, READ, WRITE attributes. However, access to memory with the GUARD attribute in the undefined area, causes an error.

Table 2.2-2 Types of Access Attributes

Area Attribute Description

User Memory Emulation Memory

Undefined GUARD Access Disabled

When access is made to an area without the WRITE attribute by executing a program, a guarded access break occurs after the data has been rewritten if the access target is the user memory. However, if the access target is the emulation memory, the break occurs before rewriting. In other words, write-protection (memory data cannot be overwritten by writing) can be set f or the emulation memory area by not specifying the WRITE attribute for the area.

This write-protection is only enabled for access made by executing a program, and is not applicable to access by commands.

■ Creating and Viewing Memory Map

Use the following commands for memory mapping. SET MAP: Set memory map. SHOW MAP: Display memory map. CANCEL MAP: Ch ange mem or y map setting to undef ined .

CODE Instruction Execution Enabled READ Data Read Enabled WRITE Data Write Enabled

NOGUARD No check of access attribute

CHAPTER 2 DEPENDENCE FUNCTIONS

[Example]

>SHOW MAP address attribute type 000000 .. FFFFFF noguard The rest of setting area numbers user = 8 emulation = 5

>SET MAP/USER H'0..H'1FF

>SET MAP/READ/CODE/EMULATION H'FF0000..H'FFFFFF

>SET MAP/USER H'8000..H'8FFF

>SET MAP/MIRROR/COPY H'8000..H'8FFF

>SET MAP/GUARD

>SHOW MAP address attribute type 000000 .. 0001FF read write user 000200 .. 007FFF guard 008000 .. 008FFF read write user 009000 .. FEFFFF guard FF0000 .. FFFFFF read write code emulation mirror address area 008000 .. 008FFF copy The rest of setting area numbers user = 6 emulation = 3

■ Internal ROM Area Setting

The [Setup Map] dialog box is displayed using [En vir onment] - [Debug ger Memo ry Map] m enu. Yo u can set the internal ROM area using the [Internal ROM Area] tab after the [Map Adding] dialog box is displayed by clicking on the [Setting] button. Two areas can be set. Both ones require empty Emulation area to be set. Require empty area is shown below.

(Empty space of the emulation area) × (one area size)

You can specify the size up to the size shown above. Specify the internal ROM area from the ending address H'FFFFFF (fixed) for area 1. Also, it is possible to

delete the internal ROM area.

CHAPTER 2 DEPENDENCE FUNCTIONS

2.2.1.5 Timer Minimum Measurement Unit

The timer minimum measurement unit affects the sequencer, the emulation timer and the performance measurement timer.

■ Setting Timer Minimum Measurement Unit

Choose either 1 μs or 100 ns as the timer minimum measurement unit for the emulator for measuring time. The minimum measurement unit for the following timers is changed dep en ding on this setup.

• Timer values of sequencer (timer conditions at each level)

• Emulation timer

• Performance measurement timer Table 2.2-3 shows the maximum measurement time length of each timer when 1 μs or 100 ns is selected as the minimum measurement unit.

When the minimum measurement unit is changed, the measurement values of each timer are cleared as well. The default setting is 1 μs.

Table 2.2-3 Maximum Measurement Time Le ngth of Each Timer

1 μs selected 100 ns selected

Sequencer timer About 16 seconds About 1.6 seconds Emulation timer About 70 minutes About 7 minutes Performance measurement timer About 70 minutes About 7 minutes

Use the following commands to control timers. SET TIMERSCALE : Sets minimum measurement unit for timers SHOW TIMERSCALE : Displays status of minimum measurement unit setting for timers

[Example]

>SET TIMERSCALE/100N >SHOW TIMERSCALE Timer scale : 100ns >

CHAPTER 2 DEPENDENCE FUNCTIONS

2.2.2 Notes on Commands for Executing Program

When using commands to execute a program, there are several points to note.

■ Notes on GO Command

For the GO command, two breakpoints that are valid only while executing commands can be set. However, it is required to be careful in setting these breakpoints.

- Invalid Breakpoints

No break occurs when a breakpoint is set at the instruction immediately after the following instructions.

PCB

MC-16L/16LX/16/16H

MC-16F

- N o break occurs when breakpoint set at address other than starting address of instruction.

- No break occurs when both following conditions met at one time.

- I nstruction for which breakpoint set starts from odd-address,

- P receding instruction longer than 2 bytes length, and breakpoint already set at last 1-byte address of preceding instruction (This "already-set" breakpoint is an invalid breakpoint that won't break, because it has been set at an address other than the starting address of an instruction).

NCC SPB MOV ILM,#imm8 OR CCR,#imm8

PCB NCC SPB

DTB ADB CNR AND CCR,#imm8 POPW PS

DTB ADB CNR

CHAPTER 2 DEPENDENCE FUNCTIONS

- Abnormal Breakpoint

Setting a breakpoint at the instruction immediately after string instructions listed below, may cause a break in the middle of the string instruction without executing the instruction to the end.

MC-16L/16LX/16/16H

MC-16F

■ Notes on STEP Command

- Exceptional Step Execution

When executing the instructions listed in the notes on the GO command as invalid breakpoints and abnormal breakpoints, such instructions and the next instruction are executed as a single instruction. Furthermore, if such instructions are continuous, then all these continuous instructions and the next instruction are executed as a single instruction.

- Step Execution that won't Break

Note that no break occurs after step operation when both the following conditions are met at one time.

- When step instruction longer than 2 bytes and last code ends at even address

- W hen breakpoint already set at last address (This "already-set" breakpoint is an invalid b reakpoint that won't break, because it has been set at an address other than the starting address of an instruction.)

MOVS SECQ WBTS MOVSWI SECQWI MOVSD SECQD FILS FILSW

MOVS SECQ WBTS MOVSWI SECQWI MOVSD SECQD FILS FILSW MOVM

MOVSW SECQW MOVSI SECQI WBTC MOVSWD SECQWD FILSI FILSWI

MOVSW SECQW MOVSI SECQI WBTC MOVSWD SECQWD FILSI FILSWI MOVMW

■ Controlling Watchdog Timer

It is possible to select "No reset generated by watchdog timer counter overflow" while executing a program using the GO, STEP, CALL commands.

Use the ENABLE WATCHDOG, DISABLE WATCHDOG commands to control the watchdog timer.

- E NABLE WATCHDOG : Reset generated by watchdog timer counter overflow

- D ISABLE WATCHDOG : No reset generated by watchdog timer counter overflow

The start-up default in this program is "Reset generated by watchdog timer counter overflow".

[Example]

>DISABLE WATCHDOG >GO

CHAPTER 2 DEPENDENCE FUNCTIONS

2.2.3 Commands Available during Execution of User Program

This section explains the commands available during the execution of a user program.

■ Commands Available during Execution of User Program

This emulator debugger allows you to use certain commands during the execution of a user program. For more details, see "■ Debugger" in "SOFTUNE Workbench Command Reference Manual". The double circle indicates that it is available during the execution of a user program. Table 2.2-4 shows the commands available during the execution of a user program.

Table 2.2-4 Commands Available during Execution of User Program

Function Restrictions Major Commands

MCU reset - 1.3 RESET Memory operation (Read/Write) Emulation memory only operable

Read only enabled in mirror area

Line assembly, Disassembly Emulation memory only enabled

Mirror area, Disassembly only enabled

Displaying coverage measurement data

Displaying event Disabled in performance mode 3.23 SHOW EVENT

Notes:

• The conditions which allow you to use the commands in Table 2.2-4 are limited to the following cases when a user program is executed.

- [Debug] - [Run] - [Go] menu

- [Go] button on the debug toolbar The commands in Table 2.2-4 cannot be used when the GO command is entered in the command

window.

• An error message appears if you enter a command that cannot be used during the execution of a user program.

"E4404S Command error (MCU is busy)."

5.1 EXAMINE,

5.2 ENTER,

5.3 SET MEMORY,

5.4 SHOW MEMORY,

5.5 SEARCH MEMORY,

5.8 COMPARE,

5.9 FILL,

5.10 MOVE,

5.11 DUMP

6.1 ASSEMBLE,

6.2 DISASSEMBLE

4.19 SHOW COVERAGE

CHAPTER 2 DEPENDENCE FUNCTIONS

2.2.4 On-the-fly Memory Access

While on-the-fly, the area mapped to the emulation memory is Read/Write enabled, but the area mapped to the user memory area is Read-only enabled.

■ Read/Write Memory while On-the-fly

The user memory cannot be accessed while on-the-fly (when execute the MCU). However, the emulation memory can be accessed. (The using cycle-steal algorithm eliminates any negative effect on the MCU speed.)

This emulator allows the user to use part of the emulation memory as a mirror area. The mirror area holds a copy of the user memory. Using this mirror area makes the Read-only enabled function available while onthe-fly.

Each memory area operates as follows:

- User Memory Area

Access to the user memory is permitted only when the operation is suspended by a break.

- Emulation Memory Area

Access to the emulation memory is permitted regardless of whether the MCU is suspended, or while onthe-fly.

- Mirror Area

The emulation memory with the MIRROR setting can be set up for the user memory area to be referred to while on-the-fly. This area is specifically called the mirror area.

As shown in Figure 2.2-1, the mirror area performs access to the user memory while the MCU is stopped, and such access is reflected simultaneously in the emulation memory specified as the mirror area. (Read access is also reflected in the emulation memory specified as the mirror area).

In addition, as shown in Figure 2.2-2, access to the user memory by the MCU is reflected "as it is" in the emulation memory of the mirror area.

While on-the -fly, the user memory cannot be accessed. However, the emulation memory specified as the mirror area can be read instead. In other words, identical data to that of the user memory can be read by accessing the mirror area.

However, at least one time access must be allowed before the emulation memory of the mirror area has the same data as the user memory. The following copy types allow the emulation memory of the mirror area to have the same data as the user memory.

(1) Copying all data when setting mirror area

When, /COPY is specified with the mirror area set using the SET MAP command, the whole area is specified, as the mirror area is copied.

(2) Copying only required portion using memory access commands

Data in the specified portion can be copied by executing a command that accesses memory.

CHAPTER 2 DEPENDENCE FUNCTIONS

The following commands access memory.

- Memory operation commands

SET MEMORY, SHOW MEMORY, EXAMINE, ENTER, COMPARE, FILL, MOVE, SEARCH MEMORY, DUMP, COPY, VERIFY

- Data load/save commands

LOAD, SAVE

Figure 2.2-1 Access to Mirror Area while MCU Suspended

Executing command

MCU

operation

(Suspended)

Executing command

Memory access

Emulation memory

(Mirror setting)

Reflected

User memory

Figure 2.2-2 On-the-fly Access to Mirror Area

Memory read

Emulation memory

(Mirror setting)

Note:

Reflected

MCU

operation

(Operating)

Memory access

User memory

Memory access by a bus master other than the MCU is not reflected in the mirror area.

CHAPTER 2 DEPENDENCE FUNCTIONS

2.2.5 Break

In this emulator debugger, seven types of break functions can be used. When the program execution is aborted by each break function, the address and the break factor to do the break are displayed.

■ Break Functions

In this emulator debugger, the following seven types of break functions are supported.

• Code break

• Data break

• Sequential break

• Guarded access break

• Trace-buffer-full break

• Performance-buffer-full break

• Forced break

CHAPTER 2 DEPENDENCE FUNCTIONS

2.2.5.1 Code Break

It is a function to abort the program execution by observing the specified address. The break is done before an instruction the specified address is executed.

■ Code Break

It is a function to abort the program execution by observing the specified address. The break is done before an instruction the specified address is executed. It is possible to set it in this 65535 debuggers. However, it is necessary to set the debugging area as a code break area.

When a break occurs due to a code break, the following message is displayed on the Status Bar.

Break at Address by breakpoint

■ Setting Method

The code break is controlled by the following method.

• Command

- SET BREAK Refer to "3.1 SET BREAK (type 1)" in "SOFTUNE Workbench Command Reference Manual".

• Dialog

- Breakpoints set dialog [Code] tab Refer to "4.6.4 Breakpoint" in "SOFTUNE Workbench Operation Manual".

•Window

- S ou rce window/Disassembly window

■ Notes on Code Break

There are several points to note in using code break. First, some points affecting code break are explained.

● Invalid Breakpoints

• No break occurs when a breakpoint is set at the instruction immediately after the following instructions.

MC-16/16L/16LX/16H: • PCB • DTB • NCC • ADB • SPB • CNR

MC-16F: • PCB • DTB • NCC • ADB • SPB • CNR

• No break occurs when breakpoint set at address other than starting address of instruction.

• No break occurs when both following conditions met at one time.

- I nstruction for which breakpoint set starts from odd-address

• MOV ILM,#imm8 • AND CCR,#imm8

• OR CCR,#imm8 • POPW PS

● Abnormal Breakpoint

• Setting a breakpoint at the instruction immediately after string instructions listed below, may cause a break in the middle of the string instruction without executing the instruction to the end.

MC-16/16L/16LX/16H: • MOVS • MOVSW • SECQ • SECQW • WBTS

MC-16F: Above plus • MOVM • MOVMW

Here are some additional points about the effects on other commands.

● Dangerous Breakpoints

Never set a breakpoint at an address other than the instruction starting address. If a breakpoint is the last 1 byte of an instruction longer than 2 bytes length, and if such an address is even, the following abnormal operation will result:

- If instruction executed by STEP command, instruction execution not aborted.

- If breakpoint specified with GO command, set at instruction immediately after such instruction, the breakpoint does not break.

CHAPTER 2 DEPENDENCE FUNCTIONS

• MOVSI • MOVSWI • SECQI • SECQWI • WBTC

• MOVSD • MOVSWD • SECQD • SECQWD

• FILS • FILSI • FILSW • FILSWI

Note:

When the debugging area is set again, all breakpoints in the area are cleared.

CHAPTER 2 DEPENDENCE FUNCTIONS

2.2.5.2 Data Break

The data break is a function to abort the program execution when the data access (read or write) is done to the address specified while executing the program.

■ Data Break

The data break is a function to abort the program execution when MCU accesses data as for a specified address.

When a break occurs due to a data break, the following message is displayed on the Status Bar.

Break at Address by databreak at Access address

The number to which the data break can be set is as follows.

In debugging area of data attribute: 65535 pieces Other areas:6 pieces

■ Setting Method

The data break is controlled by the following method.

Note:

• Command

- SET DATABREAK Refer to "3.10 SET DATABREAK (type 2)" in "SOFTUNE Workbench Command Reference Manual".

• Dialog

- Breakpoints set dialog [Data] tab Refer to "4.6.4 Breakpoint" in "SOFTUNE Workbench Operation Manual".

When the debugging area is set again, all breakpoints in the area are cleared.

CHAPTER 2 DEPENDENCE FUNCTIONS

2.2.5.3 Sequential Break

A sequential break is a function to abort a executing program, when the sequential condition is met by event sequential control.

■ Sequential Break

It is a function to discontinue the program execution wh en the sequential condit ion consists by the sequential control of the event. Use a sequential break when the event mode is set to normal mode using the SET MODE command.

When a break occurs due to a sequential break, the following message is displayed on the Status Bar.

Break at Address by sequential break (level = Level No.)

For details of the sequential break function, refer to Section "2.2.7 Control by Sequencer".

■ Setting Method

The sequential break is controlled by the following method.

1. Set event mode (SET MODE)

2. Set events (SET EVENT)

3. Set sequencer (SET SEQUENCE)

CHAPTER 2 DEPENDENCE FUNCTIONS

2.2.5.4 Guarded Access Break

The guarded access break is an abortion of the program execution that happens when the violation to the set access attribute, doing the access, and guarded (An undefined area cannot be accessed) area are accessed.

■ Guarded Access Break

A guarded access break aborts a executing program when access is made in violation of the access attribute set by using the [Setup] - [Memory Map] menu, and access is attempted to a guarded area (access-disabled area in undefined area).

There are three types of the following in Guarded access break.

Code guarded

When the instruction execution is done to the area without the code attribute, the break is done.

Read guarded

When the area without the read attribute is read, the break is done.

Write guarded

Note:

When the area without the write attribute is write, the break is done.

If a guarded access occurs while executing a program, the following message is displayed on the Status Bar and the program is aborted.

Break at Address by guarded access {code/read/write} at Access address

Code Guarded is affected by pre-fetching.

The F mapping, set a little larger area (5 bytes max.) than the program area actually used.

Similarly, the F set a little larger area (9 bytes max.) than the program area actually used.

MC-16L/16LX/16/16H family pre-fetch up to 4 bytes. So, when setting the program area

MC-16F family pre-fetch up to 8 bytes. So, when setting the program area mapping,

CHAPTER 2 DEPENDENCE FUNCTIONS

2.2.5.5 Trace-Buffer-Full Break

It is a function to abort the program execution when the trace buffer becomes full.

■ Trace-Buffer-Full Break

It is a function to abort the program execution when the trace buffer becomes full. When a break occurs due to a trace-buffer-full break, the following message is displayed on the Status Bar.

Break at Address by trace buffer full

■ Setting Method

The trace-buffer-full break is controlled by the following method.

• Command

- SET TRACE/BREAK Refer to "4.29 SET TRACE (type 1)" in "SOFTUNE Workbench Command Reference Manual".

• Dialog

- Trace Set Dialog Refer to "4.4.8 Trace" in "SOFTUNE Workbench Operation Manual".

CHAPTER 2 DEPENDENCE FUNCTIONS

2.2.5.6 Performance-Buffer-Full Break

It is a function to abort the program execution when the buffer for the performance measurement data storage becomes full.

■ Performance-Buffer-Full Break

It is a function to abort the program execution wh en the buffer for the performance measurement data storage becomes full.

When a break occurs due to a performannce-buffer-full break, the following message is displayed on the Status Bar.

Break at Address by performance buffer full

■ Setting Method

The performance-buffer-full break is controlled by the following method.

• Command

- SET PERFORMANCE/BREAK Refer to "4.7 SET PERFORMANCE (type 1)" in "SOFTUNE Workbench Command Reference Manual".

• Dialog

- Performance set dialog Refer to "4.4.13 Performance" in "SOFTUNE Workbench Operation Manual".
