Fujitsu Q702 Instruction Manual



User’s Guide

Learn how to use your Fujitsu STYLISTIC® Q702 Hybrid Tablet



Guide

d’utilisation

Découvrez comment utiliser votre tablette Hybride Fujitsu STYLISTIC® Q702

User’s

Guide

Learn how to use your

Fujitsu STYLISTIC Hybrid Tablet

Q702

Fujitsu America, Inc.has made every effort to ensure the accuracy and completeness of this document. Because ongoing development efforts are made to continually improve the capabilities of our products, however, the data contained herein represents Fujitsu design objectives and is provided for comparative purposes; actual results may vary based on a variety of factors. This product data does not constitute a warranty. Specifications are subject to change without knowledge.

Fujitsu and the Fujitsu logo are registered trademarks of Fujitsu Limited; STYLISTIC is a registered trademark of Fujitsu America, Incorporated.

Microsoft and Windows are registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. The SD Logo is registered with the U.S. Patent and Trademark Office and with other trademark offices around the world by SD-3C, LLC. Intel and Intel Core are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. OmniPass is a trademark of Softex, Inc. Google is a trademark or registered trademark of Google Incorporated.

Atheros is a registered trademark of Atheros Communications, Inc.

Norton Internet Security is a trademark of Symantec Corporation in the United States and other countries.

AirPrime is a trademark of Sierra Wireless Inc.

Roxio is a trademark of Roxio, a division of Sonic Solutions.

Gobi3000 is a trademark of Qualcomm Inc.

Nuance and XT9 are either registered trademarks or trademarks of Nuance Communications, Incorporated.

Adobe and Adobe Reader are registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.

Bluetooth and the Bluetooth logo are registered trademarks of Bluetooth SIG, Inc.

Realtek is a trademark of Realtek Semiconductor Corp.

Wi-Fi is a trademark of the Wireless Ethernet Compatibility Alliance (WECA).

All other products are trademarks or registered trademarks of their respective companies. All other trademarks mentioned herein are the property of their respective owners

Copyright 2012 Fujitsu America, Inc. All rights reserved. No part of this publication may be copied, reproduced, or translated, without the prior written consent of Fujitsu America, Incorporated. No part of this publication may be stored or transmitted in any electronic form without the prior consent of Fujitsu America, Inc. B6FJ-8761-01ENZ0-00

USER GUIDE FOR WIRELESS BROADBAND CONNECTION

IF YOU HAVE THE OPTIONAL WIRELESS WAN (WWAN) DEVICE INSTALLED IN YOUR HYBRID TABLET, THE WWAN USER’S GUIDE IS LOCATED AT:

http://solutions.us.fujitsu.com/www/content/support/mobile/support_notices

LEASE CLICK “3G MINI-CARD GOBI3000 REGULATORY AND SAFETY INFORMATION” TO OPEN THE FULL USER GUIDE CONTAINING WARNINGS AND

PRECAUTIONS ASSOCIATED WITH RF SAFETY WHEN USING THE WWAN DEVICE.

DECLARATION OF CONFORMITY

according to FCC Part 15

Responsible Party Name: Fujitsu America, Inc.

Address: 1250 E. Arques Avenue

Sunnyvale, CA 94085

Telephone: (408) 746-6000

Declares that product: Base Model Configuration: STYLISTIC Q702 Hybrid Tablet

Complies with Part 15 of the FCC Rules.

This device complies with Part 15 of the FCC rules. Operations are subject to the following two conditions:

(1) This device may not cause harmful interference, (2) This device must accept any interference received, including interference that may cause undesired operation.

IMPORTANT SAFETY INSTRUCTIONS

AC adapter output polarity:

This unit requires an AC adapter to operate. Use only UL Listed I.T.E. Adapters with an output rating of 19 VDC, with a current of 3.16A (60 W).

When using your Hybrid Tablet, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following:

CAUTION: HOT SURFACE: THE BOTTOM OF THIS COMPUTER CAN BECOME HOT WHEN USED FOR LONG PERIODS OF TIME. WHEN USING THIS

DEVICE, TAKE CAUTION TO LIMIT LONG TERM OR CONTINUOUS USE WHILE RESTING IT ON EXPOSED SKIN, SUCH AS THE LAP.

• Do not use this product near water for example, near a bathtub, washbowl, kitchen sink or laundry tub, in a wet basement or near a

swimming pool.

• Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with local

codes for possible special disposal instructions.

For Authorized Repair Technicians Only

CAUTION: R

ANGER OF EXPLOSION IF LITHIUM (CLOCK) BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE

RECOMMENDED BY THE MANUFACTURER. DISPOSE OF USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTION.

OR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY WITH THE SAME TYPE AND RATING FUSE.

ISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

SAVE THESE INSTRUCTIONS

Contents

Chapter 1 Getting to Know Your Hybrid Tablet

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Locating the Connectors and Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Front Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Back Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Left features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Right Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Status Indicator Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Display Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Adjusting Display Panel Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Active Digitizer/Touchscreen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Active Digitizer Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Using the Capacitive Touchscreen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Accessing the OnScreen TouchPad. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Using the Nuance SoftKeyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Caring for the Pen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Hybrid Tablet Buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Chapter 2 Getting Started with Your Hybrid Tablet

Power Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Connecting the Power Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Starting Your STYLISTIC Hybrid Tablet. . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Power On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Boot Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Hard Disk Drive Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

BIOS Setup Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Booting the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Starting Windows the First Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Power/Suspend/Resume Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Sleep Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Hibernation Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Windows Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Restarting the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Powering Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Chapter 3 User-Installable Features

Secure Digital Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Installing SD Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Removing an SD Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Keyboard Docking Station. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Docking Station Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Attaching the Docking Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Detaching Docking Station. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Changing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Docking Station Status Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Docking Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Battery Charge Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Battery Level Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

NumLk Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

CapsLock Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

ScrLk Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Chapter 4 Troubleshooting Your Hybrid Tablet

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Identifying the Problem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Specific Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Power On Self Test Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Restoring Your System Image and Software. . . . . . . . . . . . . . . . . . . . . . . 61

Saving and Recovering Your Factory and System Images . . . . . . . . . . . . 61

Backing Up a System Image . . . . . . . . . . . . . . . .

Recovery and Utility tabs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Recovering your Factory Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Downloading Driver Updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Chapter 5 Care and Maintenance

Caring for your Hybrid Tablet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Cleaning your Hybrid Tablet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Storing your Hybrid Tablet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Traveling with your Hybrid Tablet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Media Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Secure Digital Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

. . . . . . . . . . . . . . . . . . . 63

Chapter 6 System Specifications

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Microprocessor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Chipset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Mass Storage Device Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Security Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Device Ports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Dimensions and Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Environmental Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Popular Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Included Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Learning About Your Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Appendix A: WLAN User’s Guide

Before Using the Optional Wireless LAN . . . . . . . . . . . . . . . . . . . . . . . . . 88

Wireless LAN Device Covered by this Document . . . . . . . . . . . . . . . . . . . 88

Characteristics of the WLAN Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Wireless LAN Modes Using this Device. . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Deactivating/Disconnecting the WLAN Device. . . . . . . . . . . . . . . . . . . . . 91

Deactivation Using the Wireless On/Off Switch . . . . . . . . . . . . . . . . . . . . 92

Disconnection Using the Icon in the Taskbar. . . . . . .

Activating the WLAN Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

. . . . . . . . . . . . . . . 92

Configuring the Wireless LAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Configuring the WLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Connection to the network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Troubleshooting the WLAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

WLAN Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Using the Bluetooth Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

What is Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Where to Find Information About Bluetooth . . . . . . . . . . . . . . . . . . . . . . 97

Appendix B: Fingerprint Sensor Device

Introducing the Fingerprint Sensor Device. . . . . . . . . . . . . . . . . . . . . . . . 99

Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Installing OmniPass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

User Enrollment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

Using OmniPass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Configuring OmniPass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

OmniPass Control Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Preface

About This Guide

The STYLISTIC® Q702 Hybrid Tablet is a high-performance pen-based computer that has been designed to support Microsoft® Windows® 7 Professional edition.

This manual explains how to operate your Hybrid Tablet hardware and built-in system software. The STYLISTIC Q702 Hybrid Tablet is a completely self-contained unit with a 11.6” HD IPS display with 160 degree

vertical and horizontal viewing angles. It has a powerful interface that enables it to support a variety of optional features.

Conventions Used in the Guide

Pages with additional information about a specific topic are cross-referenced within the text. On screen buttons or menu items appear in bold. Example: Click OK to restart your Hybrid Tablet.

THE INFORMATION ICON HIGHLIGHTS INFORMATION THAT WILL ENHANCE YOUR UNDERSTANDING OF THE SUBJECT MATERIAL.

HE CAUTION ICON HIGHLIGHTS INFORMATION THAT IS IMPORTANT TO THE SAFE OPERATION OF YOUR COMPUTER, OR TO THE INTEGRITY OF YOUR

FILES. PLEASE READ ALL CAUTION INFORMATION CAREFULLY.

THE WARNING ICON HIGHLIGHTS INFORMATION THAT CAN BE HAZARDOUS TO EITHER YOU, YOUR HYBRID TABLET, OR YOUR FILES. PLEASE READ ALL

WARNING INFORMATION CAREFULLY.

Fujitsu Contact Information

Service and Support

You can contact Fujitsu Service and Support in the following ways:

• Toll free: 1-800-8FUJITSU (1-800-838-5487)

• Website:

U.S.A. - us.fujitsu.com/solutions

Canada - www.fujitsu.ca Before you place the call, you should have the following information ready so that the customer support representative can provide you with the fastest possible solution:

• Product name

• Product configuration number

• Product serial number

• Purchase date

• Conditions under which the problem occurred

• Any error messages that have occurred

• Type of device connected, if any

Fujitsu Shopping Online

You can go directly to the online by going to the website at: www.shopfujitsu.com.

- About This Guide

Maintaining Latest Configuration

To ensure that you always have the most current driver updates related to your system, you should occasionally access the Fujitsu Software Download Manager (FSDM) utility. The FSDM utility is available to allow you to download the latest drivers, utilities, and applications from the Fujitsu Support site. If you have a Windows 7 operating system, you will need to go to the Support Site (http://support.fujitsupc.com/CS/Portal/support.do?srch=DOWNLOADS).

Limited Warranty

Your Hybrid Tablet is backed by a Fujitsu International Limited Warranty. Check the service kit that came with your tablet for the Limited Warranty period and terms and conditions.

- About This Guide

Chapter 1

Getting to Know Your Hybrid Tablet

Overview

The STYLISTIC® Q702 Hybrid Tablet is a high-performance pen-based computer that has been designed to support Microsoft® Windows® 7 Professional edition.

The Q702 Hybrid Tablet is called a “hybrid” because when used with the optional keyboard docking station, it has the looks and functionality of a traditional laptop.

This chapter provides an overview of the STYLISTIC Q702 Hybrid Tablet and its many features.

Figure 1. STYLISTIC Q702 Hybrid Tablet

Locating the Connectors and Controls

Front Web Camera

Display

Speaker

Web Cam Access LED

Windows Button

Speaker

Docking Cradle Connector

Features and controls that you use to operate your Hybrid Tablet are outlined below and illustrated in Figures 2 and

3. Details on using these features and controls are provided later in this manual.

Figure 2. STYLISTIC Q702 Hybrid Tablet Features (Bottom, Right View)

Front Features

Front Web Camera

The front-facing HD (1280x720 pixel) web camera allows you to take pictures of yourself to send over the internet. For information on using the microphone and web cam, see the documentation associated with the YouCam application.

Web Cam Access LED

The web cam access LED indicates when the web camera is in use.

- Locating the Connectors and Controls

Display

The 11.6” HD IPS display offers 160 degree vertical and horizontal viewing angles.

Speakers

The speakers allow you to hear stereo sound from the system.

Windows Button

Pressing the Windows button gives you quick access to the Start menu.

Docking Cradle Connector

Allows you to connect the optional STYLISTIC Keyboard Docking Station.

- Locating the Connectors and Controls

Figure 3. STYLISTIC Q702 Hybrid Tablet Features (Back View)

Rear Web Camera

Fingerprint Sensor

Back Features

Rear Web Camera

The FHD (1920x1080 pixel) rear web camera allows you to take pictures of objects in front of you for sharing over the internet. For information on using the camera, see the documentation associated with the YouCam application.

Fingerprint Sensor

The fingerprint sensor allows you to start your system by swiping your finger over the sensor. See “Introducing the Fingerprint Sensor Device” on page 99.

- Locating the Connectors and Controls

Air Vents USB 3.0 Connector

SD Card Slot

DC In Jack

Figure 4. STYLISTIC Q702 Hybrid Tablet Features (Left View)

Left features

Air Vents

The air vents are used to cool the system to prevent overheating.

TO PROTECT YOUR TABLET FROM DAMAGE AND TO OPTIMIZE PERFORMANCE, BE SURE TO KEEP ALL AIR VENTS UNOBSTRUCTED, CLEAN, AND CLEAR

OF DEBRIS. THIS MAY REQUIRE PERIODIC CLEANING, DEPENDING UPON THE ENVIRONMENT IN WHICH THE SYSTEM IS USED.

O NOT OPERATE THE TABLET IN AREAS WHERE THE AIR VENTS CAN BE OBSTRUCTED, SUCH AS IN TIGHT ENCLOSURES OR ON SOFT SURFACES LIKE A

BED OR CUSHION.

USB 3.0 Connector

Allows you to connect Universal Serial Bus-compliant devices (compliant with USB Standard Revision 3.0) to the Hybrid Tablet.

DC In Jack

Allows you to connect the AC adapter or auto adapter.

SD Card Slot

The Secure Digital (SD) card slot allows you t

o insert a flash memory card for data storage. Flash memory cards allow

you to transfer data to and from a variety of different digital devices. See “Secure Digital Cards” on page 44.

- Locating the Connectors and Controls

Figure 5. STYLISTIC Q702 Hybrid Tablet Features (Right View)

USB 2.0 Connector

HDMI Connector

Power/Suspend/Resume Switch

Volume Down Button

Volume Up Button

Rotate Display Button

Wireless Device Switch

Pen Attachment Slot

Headphone/Line Out Jack

Microphone/ Line In Jack

Pen Tether Attachment Point

Right Features

USB 2.0 Connector

Allows you to connect Universal Serial Bus-compliant devices (compliant with USB Standard Revision 2.0) to the Hybrid Tablet. Two additional USB 2.0 ports are located on the optional Keyboard Docking Station.

Power/Suspend/Resume Switch

Allows you to turn on, off, sleep, resume, hibernate or wake the Hybrid Tablet in order to optimize battery life. See “Starting Your STYLISTIC Hybrid Tablet” on page 37.

Volume Up / Volume Down Buttons

The Volume Up and Volume Down buttons allow you to control the volume of the tablet.

Pen Attachment Slot

The pen attachment slot allows you to attach an optional pen holder to secure your pen.

Pen Tether Attachment Point

The pen tether attachment point is used to connect your pen -- or stylus -- to the system to prevent its loss.

- Locating the Connectors and Controls

Headphone/Line Out Jack

The headphone jack allows you to connect headphones. See “Headphone Jack” on page 81.

Microphone/Line In Jack

The microphone jack allows you to connect an external stereo microphone. See “Microphone Jack” on page 81.

Wireless Device On/Off switch

The wireless device on/off switch is used to turn the optional WLAN, WWAN, and Bluetooth devices on and off. Switching the device off when not in use will help to extend battery life.

Rotate Display Button

The Rotate Display button allow you to change the orientation of the display from horizontal to vertical.

HDMI Connector The HDMI port is used to connect compatible digital devices with your computer (such as a high-definition television

or AV receiver).

- Locating the Connectors and Controls

Status Indicator Panel

PowerBattery

Battery

SSD Access

harge

Level

Icons appear under each of the system status LEDs in the status display indicating the status of the solid state drive, system power, battery charge and battery level status. The location of icons in the Status display is shown in Figure 6.

Table 1 explains how the LEDs associated with the individual icons are displayed, and describes what the variations of the displays indicate. (If an icon is not displayed, it indicates that the related system function is off or inactive.

Figure 6. Status Display Icons

- Status Indicator Panel

Table 1 . Status Display Conditions

In the following table, a “blinking” LED flashes at the rate of once per second; an LED that is “blinking, slow” flashes at the rate of one second on, five seconds off.

Icon LED State Remarks

Green, solid The indicator lights up green: The hard disk drive is being accessed.

Hard Drive Access

Battery Level

Charging Indicator

Power

Green, solid The battery is fully charged.

Orange, solid

The battery is partially charged.

Red, solid The battery is nearly discharged.

Off The Tablet is switched off or in Save-to-Disk mode.

Green, solid

Orange, solid

Red, blinking

The AC Adapter is connected.

The battery is being charged.

Battery charging error

Off AC Adapter is disconnected.

Blue, solid, The system is turned on.

Blue, blinking

Off

The notebook is in sleep mode (Save-to-RAM).

The notebook is switched off or in Save-to-Disk mode.

- Status Indicator Panel

Figure 7. Hybrid Tablet Display Panel

Display Panel

Your STYLISTIC Q702 Hybrid Tablet contains an LCD display panel that is backlit for easier viewing in bright environments. The slate design of your Hybrid Tablet allows you to easily hold the unit and rotate it 90o, 180o, or 270o in either direction. This display is used as a tablet, much as you would a pad of paper. The tablet can also be used in conjunction with the optional keypad dock to create a traditional notebook form.

Adjusting Display Panel Brightness

To adjust brightness with the power management utility: Click Start -> Control Panel. In View by:, select one of the icon views. Select Display, then click Adjust brightness in

the left pane. Under Select a power plan, select the plan settings you want to use. Drag Screen brightness: bar (at the bottom of the window) to the left or right, depending on your preference.

- Display Panel

Holding the Hybrid Tablet

The STYLISTIC Q702 can be held in any of three orientations, depending upon how you would like to use it. There is primary landscape orientation (secondary landscape orientation is non-functional) and primary and secondary portrait orientations. (The orientation nomenclatures reflect those used in the button utility). When you rotate the system using the Rotation button, the order in which it rotates is illustrated below.

Primary Landscape Orientation

Secondary Portrait

ntation

Orie

- Display Panel

Secondary Landscape Orientation

(Non-functional)

Primary Portrait

Orientation

Active Digitizer/Touchscreen

Active Digitizer Display

The integrated active digitizer allows you to use the included stylus (also called a “pen”) as a pointing device. (For detailed information about caring

for your stylus, go to “Caring for the Pen” on page 30.)

You can use the stylus to click, double-click, drag items and icons, write text, or to draw like a pen or pencil in applications that support this behavior, such as drawing or painting programs. See the documentation that came with your application for details.

• DO NOT USE EXCESSIVE FORCE WHEN TAPPING OR WRITING ON THE SCREEN WITH THE STYLUS. EXCESSIVE FORCE COULD RESULT IN DAMAGE TO

THE LED AND/OR ACTIVE DIGITIZER.

• TO PURCHASE ADDITIONAL OR REPLACEMENT STYLUSES, VISIT THE FUJITSU ACCESSORIES WEBSITE AT: WWW.SHOPFUJITSU.COM.

Figure 8. Using the Active Digitizer Display

- Active Digitizer/Touchscreen

Clicking on Active Digitizer Display

To left-click, touch the object you wish to select and then lift the stylus tip immediately.

Figure 9. Clicking on the Active Digitizer Display

Figure 10. Right-clicking Active Digitizer

Right-Clicking on Active Digitizer

Right-click can be accomplished by holding the front of the toggle button down while tapping on the screen. To change the settings for the right-click feature, go to Start -> Control Panel -> Pen and Touch. In the Pen Options tab, select “Press and Hold” then click the [Settings] button.

- Active Digitizer/Touchscreen

Double-Clicking

To double-click, touch the item twice, and then immediately remove the stylus tip.

Dragging

Draggin g means moving an item with t he st ylus by touching the screen, moving and then lifting the stylus. To drag, touch the Active Digitizer Display with your stylus on the item you wish to move. While continuing to touch the screen with the stylus, drag the item to its new location by moving the stylus across the screen, and then lifting the stylus to release it.

Figure 11. Double-clicking the Display

- Active Digitizer/Touchscreen

Figure 12. Dragging on the Display

Calibrating the Display

In order to ensure accurate tracking between the stylus and cursor, you must run the Calibration Utility before you use the system for the first time, or after you change the display resolution.

To run the calibration utility:

1 Go to Start -> Control Panel. 2 Double-click the Tablet Settings icon and select the Display tab 3 Click the [Calibrate] button, then select whether you want to calibrate pen input or touch input. 4 Adjust the display of your Hybrid Tablet to a comfortable angle and find the (+) symbol in the upper-left corner

of the display.

DO NOT USE EXCESSIVE FORCE WHEN TAPPING ON THE SCREEN DURING CALIBRATION. USE OF EXCESSIVE FORCE COULD RESULT IN DAMAGE TO THE

AND/OR TOUCH PANEL.

LED

5 Using the stylus or your finger (depending upon which type of input you are calibrating), firmly touch the screen

directly on the (+) symbol. Lift the stylus from the screen and the target will move to a different location on the screen.

6 Repeat step 5 until you have selected all of the (+) symbols. 7 Once you have selected all the symbols, press the [OK] button. 8 Touch the stylus to various points on the screen to verify that the screen is correctly calibrated. If you are not

satisfied with the screen’s calibration, press the [Calibrate]) button to begin again.

- Active Digitizer/Touchscreen

Using the Capacitive Touchscreen

Certain configurations of this Hybrid Tablet have an optional dual digitizer that allows you to use either the stylus or your finger(s) as a pointing device. This type of display also allows you to use “gestures” to perform such actions as scroll, zoom, and rotate.

• GESTURE SUPPORT IS DETERMINED BY THE APPLICATION IN USE.

• THE STYLUS TAKES PRECEDENCE OVER FINGER TOUCH. IF THE STYLUS IS WITHIN ACTIVE RANGE OF THE SCREEN, FINGER TOUCH WILL BE DISABLED.

• WHEN ONE FINGER IS USED ON THE TOUCHSCREEN, IT BEHAVES IN THE SAME MANNER AS A STYLUS.

Right-clicking the touchscreen

To perform a right-click action using two fingers, press the first finger at the location you want to perform a right-click, then quickly tap and release the second finger on the screen.

Gesture Mode

To initiate gesture mode, two fingers must touch the screen within 200 ms of each other. If the second finger touches the screen after 200 ms has elapsed, the second finger is ignored. If more than two fingers touch the screen in that time, Advanced Gesture Mode is activated instead. When Gesture Mode is activated, no cursor movement is sent to the system.

When both fingers are removed, Gesture mode ends. When a third finger is added, gesture mode ends and Advanced gesture mode is activated. Note that if a gesture can’t be recognized, no action is taken. In that case, remove both fingers from the screen and try again.

Scrolling Gesture

To scroll through long documents or on a web page, place both fingers on the screen (one finger quickly followed by the second). If at least one finger has moved at least 3 mm, a scroll is considered. If both fingers are moving in the same direction and parallel (given a tolerance of 5 mm), Scroll Mode is activated. If one finger is stationary, it is not considered a scroll. If either finger is lifted, Scroll Mode is canceled.

- Active Digitizer/Touchscreen

Zoom Gesture

The zoom gesture is especially helpful when viewing pictures. To zoom in, place two fingers on the item you want to enlarge (one finger quickly followed by the second), then spread them away from each other.

If at least one finger has moved at least 10 mm, a zoom event is considered. If the distance between the fingers has changed by at least 10 mm, and both fingers have stayed on approximately the same line, Zoom Mode is entered. If either finger strays more than 10 mm from the "zoom line" created when the fingers first made contact, the zoom is canceled.

To zoom out, place two fingers on the item you want to reduce (one finger quickly followed by the second), then move them towards each other.

Rotate Gesture

To change the orientation of an object on the screen, place two fingers on the image you want to rotate (one finger quickly followed by the second), then move them in opposite directions (as if you were turning a knob). The direction the item turns is dependant upon the direction you move your fingers.

If at least one finger moves at least 12 mm, a rotate is considered. If one finger is stationary (moving less than 5 mm in any direction), and the other is moving, a rotate is considered. If the fingers begin moving in the same direction, the rotation is canceled. If the distance between the fingers changes by more than 10 mm, the rotation is canceled.

Accessing the OnScreen TouchPad

Your tablet has a handy on-screen touchpad that offers a variety of helpful functions. Features of the OnScreen TouchPad include:

• Virtual Mouse Emulator: The Virtual Mouse Emulator works in much the same manner as a hardware mouse.

With the virtual mouse, you can scroll, drag, and click, as well as perform [Ctl]+[Click] and [Shift]+[Click] actions.

• Application Launch/Key Macro: This window provides access to five pages, each of which can contain up to

twenty buttons. Each button can be programmed to open an application, a folder, document, or key (such as [Esc], [ Alt+X] and [Page Up]).

• Digital Keyboard: This window provides a soft keyboard for use in mathematical procedures. It works in much

the same way as the Windows standard calculator.

- Active Digitizer/Touchscreen

+ 208 hidden pages
