Fujitsu Q584 Instruction Manual

Operating Manual

FUJITSU Tablet STYLISTIC Q584

System

Contact address in North America

FUJITSU AM

ERICA INC:

1250 East Arques Avenue Sunnyvale

CA 94085-3470, U.S.A.

e: 800 831 3183 or 408 746 6000

Telephon

http://solutions.us.fujitsu.com"

"

"http://solutions.us.fujitsu.com/contact"

Have a qu

estion? Email us at: "

[e-mail] m "

Copyright

ujitsu America, Inc. All rights reserved.

©2013F

B5FK-2441-01ENZ0

FUJITSU Tablet STYLISTIC Q584

Operating Manual

Fujitsu Contact Information 7
Notational conventions 8
Ports and controls 9
Important notes 12
First-time setup of your device 17
WorkingwiththeTabletPC 21
Accessories for your Tablet PC

(optional) 43
Security functions 56
Connecting external devices 63
Settings in BIOS Setup Utility 67
Troubleshooting and tips 70
Technical data 78
Manufacturer’s notes 83
Appendix 88
Index 97

Copyright and Trademark Information

Fujitsu America, Inco rporated has made every effort to ensure the accuracy and completeness
of this document; however, as ongoing development efforts are continually improving the
capabilities of our products, we cannot guarantee the accuracy of the contents of this
document. We disclaim liability for errors, omissions, or future changes.

Fujitsu, the Fujitsu logo and LIFEBOOK are registered trademarks of Fujitsu Limited
or its subsidiaries in the United States and other countries.

Intel and Intel Core are trademarks or registered trademarks of Intel Corporation or
its subsidiaries in the United States and other countries.

Microsoft and Windows are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.

The ExpressCard word mark and logo are owned by the Personal Computer
Memory Card International Association (PCMCIA) and any use of such marks by
Fujitsu America, Incorporated is under license.

Google is a trademark or registered trademark of Google Incorporated.

Bluetooth is a trademark of Bluetooth SIG, Inc., USA.

OmniPass is a trademark of Softex, Inc.

Roxio is a trademark of Roxio, a division of Sonic Solutions.

PowerDirector, PowerDVD, YouCam, and MakeDisc are trademarks of CyberLink Corp.

Adobe, Acrobat, and Ad obe Reader are either a reg istered trademarks or trademarks of
Adobe Systems Incorporated in the United States and/or other coun tries.

Made under license from DTS Licensing Limited. D T S and the symbol are registered trademarks and
& DTS Boost is a trademark of DTS, Inc. Product contains software. © DTS, Inc. All rights reserved.

The DVD player found in some models of the LIFEBOOK notebook incorporates copyright
protection technology that is protected by method claims of certain U.S. patents and other
intellectual property rights owned by Macrovision Corporation and other rights users. Use
of this copyright prote ction technology must be authorized by Macrovision Corporation, and
is intended for home and other limited viewing uses only unless authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.

All other trademarks specified here are the property of their respective owners.

Contents

Contents

Fujitsu Contact Information ............................................................ 7

Notational conventions ................................................................ 8

Ports and controls ..................................................................... 9

Important notes ........................................................................ 12

Safetyinstructions ...................................................................... 12

Additional safety note
Protecting the display

Energysaving .......................................................................... 13

Energy saving under Wi

Traveling with your T

Beforeyou travel ................................................................... 14

Transporting the T
Storing your Table
Cleaning the Table

Further informat
Cleaning with dis

First-time setup ofyour device ......................................................... 17

Unpacking and checking the device . . . ................................................... 17

Choose a location . ...................................................................... 18

Connecting the AC adapter . . . ........................................................... 18

Switching on the device for the first time .................................................. 19

Installing Bonus Apps . . . . . ........................................................... 20

Working with

Battery char
Switching t

Switching t
Handwriti
Touchscr
Select di
Tou c h c om

Using t

Tab l
Webc
Rec

ng the energy saving functions . .......................................................

Usi

mory cards ..........................................................................

Me

ging indicator ................................................................

he Tablet PC on ..............................................................

Programing

he Tablet PC off ..............................................................

ng recognition ..................................................................

een ............................................................................

splay orientation (portrait or landscape format) ....................................

mands .......................................................................

te the Dual Digitizer for finger-based operation of the device. .....................

Calibra

with one finger (Windows 8.1 Modern) . ........................................

Actions

with one finger (Windows 8.1 Desktop) ........................................

Actions

s with two fingers (Windows 8.1 Desktop) . . . ....................................

Action

he stylus .........................................................................

location ......................................................................

Stylus

ting the stylus ..................................................................

Adjus

ratingthe stylus ................................................................

Calib

cing the stylus tip ..............................................................

Repla

allingastylus tether ..............................................................

Inst

et buttons ..........................................................................

am ...............................................................................

hargeable battery ...................................................................

rging and maintaining thebattery .................................................

Cha

s for devices with radio components . . . . . .............................

screen ............................................................

ndows .......................................................

ablet PC ............................................................

ablet PC ...........................................................

tPC ..................................................................

tPC ..................................................................

ion on cleaningthe Tablet PC .........................................

infectant wipes ..........................................................

the TabletPC ............................................................

the ON/OFF button ......................................................

12
13

13
13

15
15
16
16
16

21

21
22
22
23
23
24
25
25
25
26
28
29
31
32
32
32
33
33
34
35
35
35
36
37

Fujitsu 3

Contents

Supported formats .................................................................. 37

Inserting the memory card ........................................................... 37

Removing the memory card .......................................................... 38

SIM card ............................................................................... 39

Inserting aSIMcard ................................................................. 39

Removing aSIM card ............................................................... 40

Wireless LAN/Bluetooth/UMTS/4G radio components . . . . .................................. 40

Switching the wireless components on and off ......................................... 40

Setting up WLAN access ............................................................ 41

Further information on WLAN and Bluetooth ........................................... 41

Accessvia UMTS ................................................................... 41

Accessvia Wireless WAN ............................................................ 41

Ethernet and LAN(only with docking cradle) .............................................. 42

GPS ................................................................................... 42

Accessories for your Tablet PC (optional) . ............................................. 43

Your dockingcradle (optional) ............................................................ 43

Docking cradle components . . ........................................................ 43

Setting up thecradle ................................................................ 44

Connecting the Tablet PC to the cradle . . ............................................. 44

Disconnecting the Tablet PC from the cradle . ......................................... 46

Keyboard cover (optional) . . . ............................................................ 47

Keyboard cover ports ................................................................ 47

Connecting the Tablet PC to the keyboard cover . . . . . .................................. 48

Separating the Tablet PC from the keyboard cover . . .................................. 49

VESA mount (optional) . . ................................................................ 50

Shoulder strap (optional) ................................................................ 51

Folio case (optional) . . . . . ................................................................ 53

Micro USB adapters ..................................................................... 54

Security functions ..................................................................... 56

Configuring the fingerprint sensor ........................................................ 57

Configuringpasswordprotection inBIOS Setup Utility ...................................... 58

Protecting BIOS Setup Utility (supervisor HDD password and user HDD password) . . . .... 58

Password protection for booting the operating system .................................. 59

Password protection for the harddisk ................................................. 60

SmartCard reader (optional) . ............................................................ 61

Inserting the SmartCard ............................................................. 61

Trusted Platform Module - TPM (device dependent) . . . . . . .................................. 62

Enabling TPM ....................................................................... 62

Disabling TPM ...................................................................... 62

Connecting externaldevices ........................................................... 63

Connecting an external monitor . . ........................................................ 64

HDMI port (viaoptional docking cradle) ............................................... 64

VGA monitor port (via optional docking cradle) ......................................... 64

Connecting USB devices ................................................................ 65

How to remove USB devices correctly ................................................ 65

Headphones port ....................................................................... 66

Settings in BIOS Setup Utility . ......................................................... 67

Starting theBIOS Setup Utility ........................................................... 67

BIOS Setup Utility operation . ............................................................ 68

Exiting BIOSSetup Utility ................................................................ 69

4 Fujitsu

Contents

Exit Saving Changes - save changes and exit BIOS Setup Utility . . ..................... 69

Exit Discarding Changes - Reject changes and exit BIOS Setup Utility . . . . . .............. 69

Load Setup Defaults – load default value s . ............................................ 69

Discard Changes - Discard Changes without exiting BIOS Setup Utility . . . . .............. 69

Save Changes - save changes without exiting the BIOS Setup Utility . . . . . . .............. 69

Save changes andpower off ........................................................ 69

Troubleshooting and tips .............................................................. 70

Help ifproblemsoccur ................................................................... 70

Recovering your Factory Image ...................................................... 70

The Tablet PC’s date or time is incorrect .................................................. 71

Battery indicator does not illuminate . . . ................................................... 71

The Tablet PC’s touchscreen remains dark ................................................ 71

The display on the Tablet PC’s touchscreen is difficult to read. . ............................. 71

The externalmonitor remains blank ...................................................... 72

The externalmonitor isblank ortheimage isunstable ..................................... 72

The cursor does not correctly follow the stylus movements . . . . ............................. 72

Stylusinput not working ................................................................. 73

The Tablet PC does not start after switchon ............................................... 73

The Tablet PC stops working ............................................................. 73

The printer does not p rint . . . . . ........................................................... 74

The wireless connection to a network does not work . . . .................................... 74

The battery discharges too quickly ........................................................ 74

SmartCard reader is not recogn ized . . . ................................................... 75

SmartCard PINforgotten ................................................................ 75

User and/or supervisor SmartCard lost ................................................... 75

SmartCard lost ......................................................................... 75

Acoustic warning ........................................................................ 76

Error messages on the screen ........................................................... 76

Technical data ......................................................................... 78

TabletPC .............................................................................. 78

WLAN specifications .................................................................... 79

Rechargeablebattery ................................................................... 80

AC adapter (36 W) ...................................................................... 80

Dockingcradle(optional) ................................................................ 80

Keyboard cover (optional) ............................................................... 81

VESA mount (optional) .................................................................. 81

Shoulder strap (optional) . . . . . ........................................................... 81

Folio case (optional) ..................................................................... 81

USB adapters .......................................................................... 82

Manufacturer’s notes .................................................................. 83

Disposal andrecycling .................................................................. 83

Recycling your battery ............................................................... 83

DeclarationsofConformity ............................................................... 83

Regulatory notices ...................................................................... 84

FCC Notices ........................................................................ 84

DOC (IndustryCANADA)notice ...................................................... 84

ENERGY STAR Compliance ............................................................. 87

Appendix .............................................................................. 88

Image Backup and Recovery Procedures ................................................. 88

Creating aBackup of Bootable Diskand Recovery Image .............................. 88

Fujitsu 5

Contents

RECOVERYOUR SYSTEM WHENTHEHARD DRIVE IS STILL ACCESSIBLE ............. 89

Using the Recovery and Utility Tools .................................................. 89

Restore the Recovery Image from Hidden Partition . . . .................................. 91

RECOVERYOUR SYSTEM WHENTHEHARD DRIVE IS NOTBOOTABLE ................ 92

Restore the Recovery Imagefor FullHard Drive ....................................... 92

Recovering Your Recovery Image Using Recovery and Utility (for new hard drive or

non-bootable harddrive) ............................................................. 93

Installing theSoftware after the Recovery Imageis Restored ............................ 94

Index .................................................................................. 97

6 Fujitsu

Fujitsu Contact Information

Fujitsu Contact Information

Service and Support

You can contact Fujitsu Service and Support in the following ways:

• Toll free phone: 1-800-Fujitsu (1-800-838-5487)

• Website: "

Fujitsu Shopping Online

Please go to "

Maintaining Latest Configuration

To ensure that you always have the most current driver updates related to your system, occasionally
access the Fujitsu Software Download Manager (FSDM) utility. The FSDM utility is available from
the Fujitsu Support site. FSDM will allow you to view a list of the most current drivers, utilities,
and applications to determine whether you have the latest versions. If you have a Windows 7
or Windows 8/8.1 operating system, you will need to go to the Support Site to download the
FSDM Utility: "

Limited Warranty

Your LIFEBOOK notebook is backed by a Fujitsu International Limited Warranty. Check the service
kit that came with you r notebook for the Limited Warranty period and terms and conditions.

http://solutions.us.fujitsu.com/www/content/support/contact/ index.php"

Before you place the call, have the following information ready so that the customer
support representative can provide you with the fastest possible solution:

• Product name

• P roduct configuration number

• Prod uct serial number

• Purchase date

• Con ditions under which the problem occurred

• Any error messages that have occurred

• Type of device connected, if any

http://www.shopfujitsu.com/store/ ".

http://support.fujitsupc.com/CS/Portal/support.do?srch=DOWNLOADS".

Fujitsu 7

Notational conventions

Notational conventions

Pay particular attention to text marked with this symbol. Failure to observe
these warnings could pose a risk to h ealth, damage the device or lead
to loss of data. The w arranty will be invalidated if the device becomes
defective through failure to observe these warnings.

Indicates important information for the proper use of the device.

►



This font

This font

This font

"This font"

Key

This font

Indicates an activity that must be performed.

Indicates a result.

Indicates data entered using the keyboard in a program dialog or at the
command line, e.g. your password (Name123)oracommandusedtostart
a program (start.exe)

Indicates information that is displayed on the screen by a program, e.g.:

Installation is complete.

Indicates

• terms and texts used in a software interface, e.g.: Click on Save

• names of program

Indicates

• cross-refere

• cross-references to an external source, e.g. a web address: For more
information, go to "

• names of CDs
"CD/DVD Dri

Indicates

Indicate

not switc

a key on the keyboard, e.g:

s terms and texts that are emphasized or highlighted, e.g.: Do

h off the device.

sorfiles, e.g. Windows or setup.exe.

nces to another section, e.g. "Safety information"

http://solutions.us.fujitsu.com/"

, DVDs and titles or designations for other materials, e.g.:

vers & Utilities" or "Safety/Regulations" manual

F10

.

8 Fujitsu

Ports and controls

Ports and controls

This chapter presents the individual hardware components of your device. It gives an
overview of the indicators and connections of the device. Please familiarize yourself
with these items before you start t o work w ith the device .

Front

1

2

3

8

7

1 = Ambient light sensor
2 = Webcam LE
3 = Webcam
4 = Battery c

D

harging indicator

4

6

5

5 = Eyelet for s tylus tether
6 = Recess fo
7 = Docking port for cradle or keyboard cover
8 = Recess fo

rcradle

rcradle

Fujitsu 9

Ports and controls

Left-hand side

1 2 3 4 5

1 = Headphones port
2 = ON/OFF button
3 = Volume buttons

Right-hand side (with and without covers)

1

1

1 = Speaker
2=Sto
3 = SIM card slot ( prot ected by cover)

rage card slot (pro tected by cover)

2 3 4 5 6

2 4 5 6

3

4 = Shortcut button
5 = Speaker

4 = USB port (USB 3.0, protected by cover)
5=Mic
6 = DC jack (DC IN, protected by cover)

ro USB port (protected by cover)

10 Fujitsu

Ports and controls

Back (2 options: Standard shell with flat back and no screw hole attachment points or Smart

Card shell with integrated Smart Card reader and screw hole attachment points.)

7

6

1 = Stylus holder
2 = Fingerprint sensor
3 = Webcam
4 = Camera light

5

4

1

3

2

6

5

4

3

6

1

2

6

5 = Webcam LED
6 = Screw holes (device-dependent) for

securing accessories

7 = SmartCard reader (device dependent)

Fujitsu 11

Important notes

Important notes

ImportantnotesNotes

This chapter contains essential safe ty information which must be followed when working
with your Tablet PC. The other notes provide useful information on your Tablet PC.

Safety instructions

SafetyinformationInformation,

Please follow the safety notes provided in the "Safety/Regulations" manual
as well as the safety notes given below.

Please pay special attention to the sections in the manual marked
with the symbol on the left.

When connecting and disconnecting cables, observe the relevant
notes in this operating manual.

Read the information on the ambient conditions in the "
and the information in the "
preparing your Tablet PC for use and switching it on for the first time.

When cleaning the device, please observe the relevant notes in the section .

Pay attention to the additional safety notes for devices with radio compo nents
provided in the "Safety/Regulations" manual.

When handling this device, you come into contact with lead, a chemical which in
California is held to be a possible cause of birth defects and other damage to fertility.

Wash your hands after using the device.

First-time setup of your device", Page 17 chapter before

Technical data", Page 78 chapter

This Tablet PC
you have ques
please conta

complies with the relevant safety regulations for data processing equipment. If

tions as to whether you can set up the Tablet PC in the intended environment,

ct your sales outlet or our hotline/service desk.

Additional safety notes for devices with radio c om ponents

RadiocomponentsWirelessLANBluetooth,Safetynotes

If a radio component (Wireless LAN, Bluetooth, UMTS/4G) is integrated in your Tablet PC, you
must be sure to observe the following safety precautions when using your Tablet PC:

• Sw itch off the radio components when you are in an aircra ft or driving in a car.

• Sw itch off the radio components when you are in a hospital, an operating room or near a medical
electronics system. The transmitted radio waves can impair the operation of medical devices.

• Sw itch off the radio c omponent s, when you let the device get near flammable gases
or into hazardous environments (e.g. gas station, paintshops), as the transmitted
radio waves can cause an explosion or a fire.

For further information on how to switch the radio components on and off, refer
to chapter "

12 Fujitsu

Switching the wireless components on and off", Page 40.

Important notes

Protecting the display screen

Depending on your device configuration, where applicable your device is not waterproof.
In this event, do not pour liquids onto the device and do not wash it with a wet cloth.
Do not place items on the top of the display, or damage may occur.

During normal use of the device, small particles from the environment
can become embedded in the stylus tip and scratch the screen. The
warranty does not cover a scratched screen.

Energy saving

NotesEnergyPowersaving

If you will not b e using your Tablet PC, switch it off. Switch off any connected external devices when
they are not in use. If you use the energy saving functions, the Tablet PC uses less power. If you do
this, you will be able to work longer with the Tablet PC before having to recharge the battery.

The energy efficiency is increased and environmental pollution is reduced.
You save money and help protect the environment.

Energy saving under Windows

► Make use of the available energy saving functions as described in chapter

Using the energy saving functions", Page 36.

"

Traveling with your Tablet PC

MobileoperationNotesTran sportTabletPC

Please follow the instructions below when traveling with your Tablet PC.

Fujitsu 13

Important notes

Before you travel

► Switch off the radio component for data security reasons. With data traffic via a wireless

connection, it is also possible for unauthorized third parties to receive data.

Information on activating data encryption is provided in the docu m entation
for your radio component.

► If you want t o use your Tablet PC during a flight, ask the flight attendants to see if it is safe to use it.

When traveling in other countries

► If you are traveling abroad, check that the AC adapter can be operated with the

local AC voltage. If this is not the case, obtain the appropriate AC adapter for
your Tablet PC. Do not use any other converter!

► Check whet her the local AC voltage and the AC cable are c ompa tible. If this is not

the case, buy an AC cable that suits the local conditions.

► Enquire with the appropriate government office of the country you will be travelling in as to

whether you may operate the radio component integrated in your Tablet PC there.

► Take the necessary travel adapters with you when traveling abroad. Check in the following

table for which travel adapte rs you will n eed, or ask your travel organizer.

Power connection Travel destination

United States, Canada, Mexico, parts of Latin
America, Japan, Korea, Philippines, Taiwan

Russia and the Commonwealth of Independent
States (CIS), much of Europe, parts of Latin
America, the Middle East, parts of Africa, Hong
Kong, India, much of south-east Asia

United Kin
parts of A

China, A

14 Fujitsu

gdom, Ireland, Malaya, Singapore,

frica

ustralia, New Zealand

Transporting the Tablet PC

Protect the Tablet PC from severe shocks and extreme temperatures
(e.g. direct sunlight in a car).

• Do not transport your Tablet PC while it is turned on.

• Carry your Tablet PC with you while traveling, rather than checking it in as baggage.

• Never put your Tablet PC through a metal detector; have it hand-inspected by
security personnel. You can however, put your Tablet PC through a properly
tuned X-ray machine. To avoid problems, place it close to the entrance of
the machine and remove it as soon as possible or have it hand-inspected
by security personnel. Security officials may require you to turn your Tablet
PC on, so make sure you have a charged battery on hand.

Important notes

► Switch the Tablet PC off
► Unplug the AC plug of the AC adapt er and all external devices from the power outlets.
► Disconnect the AC ad
► To protect the Tablet PC against damaging jolts and bumps, use a suitable Tablet

PC carrying case to transport your Tablet PC.

.

apter cable and the data cables for all external devices.

Storing your Tablet PC

• If storing your Ta
then remove and

• S tore your Tablet PC in a cool, dry location. Temperatures should remain
between 13ºF / -25ºC and 140ºF / 60ºC.

• Store your Tab
a battery inst
addition, a f

• Always power

• It is possible that the Tablet PC may not automatically go to power-off or hibernate

• Attem p ti

blet PC for a month or longer, turn it off, fully charge the battery,

store all Lithium Polymer batteries.

let PC and batteries separately. If you s tore your Tablet PC with

alled, the battery will discharge, and battery life will be reduced. In

aulty battery might damage your Tablet PC.

off the Tablet PC before transporting and/or packaging it.
After shutt
power off c

mode when you close the lid. This situation may occur due to pre-operating system
boot password security settings or some other application running on the Tablet PC.

the Table

ing down the Tablet PC, wait until the status led panel indicates

ondition (i.e., no lights are illuminated).

ng to transport the Tablet PC while power is o n may damage

t PC due to shock or overheating.

Fujitsu 15

Important notes

Cleaning the Tablet PC

• Use of incorrect cleaners can result in optical impairment of the LCD and / or
damage to the computer. Always refer to the cleaner manufacturer ’s guidelines and
material safety data sheets fo proper handling and use of the product s.

• N ever use ammonia, acidic, or alkaline cleaners or orga nic chemicals
such as paint thinner, acetone or kerosene. It may damage surface
finishes and the coating of the LCD screen.

• N ever u se compressed air for cleaning your comput er.

• If your Tablet PC has a Smart Card slot, be very careful to avoid any
liquid entering the slot as this can damage the unit.

Further information on cleaning the Tablet PC

The Tablet PC does not float.

If the Tablet PC is exposed to water or other liquids with its connections open, liquid
can penetrate the Tablet PC and cause a malfunction. Do not continue to use the
Tab let PC. Switch it off and contact our hotline / our service desk (see enclosed list of
service desks or visit our website at: "

http://www.fujitsu.com/us/support/").

Cleaning with disinfectant wipes

There are many ways of disinfecting surfaces. The following disinfectant wipes
have been tested successfully w ith the Tablet PC:

• MG Chemicals Multipurpose Alcohol Wipes (alcohol-based)

• PR OSAT® Sterile™ PS-911EB/EtOH Life Sciences W ipes (alcohol-based)

• C lorox® Healthcare Bleach Germicidal Wipes (without alcohol)

Remember, if your Tablet PC is configured with the Smart Card shell, it does not
have a cover to close the port and liquid could enter and damage the device. Take
extra precautions when cleaning around the Smart Card reader.

For proper use of disinfectant wipes, please read the manufacturer’s instructions.

Before cleaning, please test the disinfectant wipe on a small area of the Tablet
PC. Some medical disinfectant wipes may leave residue on the Tablet PC which
is difficult to remove again, or they may dry out quickly. Therefore dispose of
the wipes after one single use and do not reuse them.

16 Fujitsu

First-time setup of your device

First-time setup of your devic

First-timesetu pGettingstarted

The battery must be charged if you want to operate your device using the battery.

When used on the move, the built-in battery provides the device with the necessary power. You
can increase the operat ing time by using the available energy-saving functions.

For instructions on how to connect external devices (e.g. mouse, printer) to your Tablet
PC, please refer to the operating manual for your device.

Unpacking and c

► Unpack all the individual parts.

► Check your d

Please read the chapter " Important notes", Page 12.

If your de vice is equipped with a Windows operating system, the necessary
hardware drivers and supplied software are already pre-installed.

Before switching it on for the first time, connect the device to the AC voltage using
the AC adapter, see "
remain connected during the whole of the installation process.

A system test is performed when your device is first switched on. Various messages
can appear. The display may remain dark for a short time or may flicker.

Please follow the instructions on the screen.

NEVER switch off your device during the first-time setup process.

Connecting the AC adapter", Page 18. The AC adapter must

hecking the device

If you find that damage has occurred during transport, please notify
your local sales outlet immediately!

PackagingTransport

evice for any visible damage which may have occurred during transportation.

e

You may nee
need to tr

Fujitsu 17

d to reuse the packaging in future, for example if yo u

ansport your device.

First-time setup of your device

Choose a location

ChoosealocationSetupACadapter

Choose a suitable location for the device before setting it up. In doing
so, please follow these instructions:

• Never place the device or the AC adapter on a heat-sensitive surface.
The surface could be damaged as a result.

• N ever place the device on a soft surface (e.g. carpeting, upholstered furniture,
bed). This can result in damage caused by overheating.

• The underside of the device heats up during normal operation. Prolonged contact
with the skin can become unpleasant or even result in burns.

• P lace the device on a stable, flat, non-slippery surface. Please note that the
rubber feet of the device may mark certain types of delicate surfaces.

• K eep other objects a t least 100 mm / 4 inches away from the device
and its AC adapter to ensure adequate ventilation.

• Do not expose the device to extreme environmental conditions. Protect
the device against dust, humidity and heat.

Connecting the AC adapter

MakingreadytouseACadapter

Observe the safet

ThesuppliedACc
you purchased yo
use in the count

y notes in the enclosed "Safety/Regulations" manual.

able conforms to the requirements of the country in which

ur device. Make sure that the AC cable is approved for

ry in which you intend to use it.

2

► Open the cover of the DC jack

socket (DC IN).

► Connect the AC cable (1) to the AC adapter.
► Plug the AC cable (2) into a po wer outlet.
► Connect the AC adapter cable (3) to the

DC jack socket (DC IN) of the device.

18 Fujitsu

First-time setup of your device

Switching on the device for the first time

Switchingonforthefirsttime

To make it easier to use your device for the first time, the operating system
is pre-installed on the hard disk.

1

► Press the ON/OFF button (1) for about one second to switch the device on.
► During the installation process, follow the on-screen instructions.

You c a n find information and help on the Windows operating system functions
on the Inte rnet at "

http://windows.microsoft.com".

If a Windows 8.1 operating system is installed on your Tablet PC, a tutorial is
automatically started when a new user logs on for the first time, which sho ws
you how to use the new functions of W i ndows 8.1.

Fujitsu 19

First-time setup of your device

Installing Bonus Apps

After you have started your system the first time, you will see a Bonus Apps icon on your desktop.

► Click on the icon to see which additional applications are available for you to install.

Applications that are already installed appear in grey, those that are



available for installation appear in blue.

► Select the applications you wish to install by selecting the checkbox adjacent to your selection.

or

► Click Select All if you would like to install all available applications

► To c o nfirm your selection click Install.

Note that in some cases (depending upon which application was selected for
installation) after installation completes, the system will prompt you to reboot.

There are also cases in which if multiple applications are selected to install
but one of them needs a reboot, the system will reboot and continue
installing the rest of the selected applications.

20 Fujitsu

Working with the Tablet PC

Working with the Tablet PC

Tablet,operationTablet

This chap ter describes the basics for operating your Tablet PC. You can find instructions
on how to connect external devices (e.g. mouse, flash storage) to the Tablet PC in
the chapter "

Battery charging indicator

StatusindicatorsSymbols

The battery charging indicator (4) provides information about the status of the power supply.

Connecting external devices", Page 63.

Please refer to the notes in the chapter "Important notes", Page 12.

1

2

3

8

7

6

5

Status / color Description

On (White)

Off The Ta

Fujitsu 21

The battery is being charged.

blet PC is switched off or in Save-to-Disk mode.

4

Working with the Tablet PC

Switching the Tablet PC on

Tablet:SwitchingonPower-onPower-onindicatorSuspend/Resumebutton

1

► Press the ON/OFF button (1) for about one second to switch the device on.

Programing the ON/OFF button

You can program the ON/OFF button:

Operating

Windows 8

22 Fujitsu

system

.1

If you have assigned a password, you must enter this when requested to
do so, in order to start the operating system. Detailed information can be
found in the chapter "

Security functions", Page 56.

Menu

Windows 8
and Soun

.1 Desktop - Control Panel - Hardware

d - Power Options

Working with the Tablet PC

Switching the Tablet PC off

Back up your data and close all applications before you sw itch off your
device. Otherwise data might be lost.

► Shut down the operating system correctly.

Notebook

or

► Press the ON/OFF button for < 2 seconds to switch into connected standby mode.

or

► Press the ON/OFF button

"Sweep downwards to sw

or

► If the Tablet PC is not switched off automatically, press the ON/OFF button

for about 10 seconds (forced shutdown).

for > 2 seconds to < 10 seconds to display the

itch off" popup.

Handwriting recognition

For detailed informa tion on handwriting recognition, see the documentation for your operating system.
Under Windows 8.1 you can set the required language under Control Panel –

Time, Language and Region – Language.

Fujitsu 23

Working with the Tablet PC

Touchscreen

Touchsc reenNotes

High-quality LCD screens (TFT) are installed in Fujitsu Tablet PCs. For technical reasons,
these screens are manufactured for a specific resolution. An optimal, clear picture can
only be ensured in the resolution intended for the particular screen. A screen resolution
which differs from the specification can result in an unclear pictu re.

The screen resolution of your Tablet PC’s touchscreen is optimally set at the factory.

Current production technology cannot guarantee an absolutely fault-free screen display. A few
isolated constantly lit or unlit pixels (picture elements) may be present. The maximum permitted
number of such faulty pixels is speci fie d in the international standard ISO 9241-307 (Class II).

Example:

A screen with a resolution of 1280 x 80 0 has 1280 x 800 = 1024000 pixels. Each pixel consists of
three subpixels (red, green and blue), so there are almost 3 million subpixels in total. According to ISO
9241-307 (class II), a maximum of 2 light and 2 dark pixels and in addition 5 light or 10 dark subpixels
or an equivalent mix (1 light subpixel counts as 2 dark subpixels) are allowed to be defective.

Pixel

Subpixel

Cluster A cluster contain

Background lighting

LCD screens are operated w ith background lighting. The luminosity of the b ackground
lighting can decrease over the period of use o f the Tablet PC. However, you can
set the brightness of your screen manually.

A pixel consists of 3 subpixels, normally red, green and
blue. A pixel is the smallest element that can be generated
by complete functionality of the display.

A subpixel is a separately addressable internal structure
within a pixel that enhances the pixel function.

s two or more defective pixels or

subpixels in a 5 x

5 pixel block.

Ambient light sensor

If your Tablet PC was shipped with the Windows operating system, the screen brightness is
regulated by means of the ambient light sensor and depending on the respective light conditions.
This results in optimum readability and longer battery life at the same time.

If your Tablet PC was shipped with Windows 8.1, the adaptive brightness setting is deactivated. To
change the ambient light sensor settings, select Control Panel - System and Security - Power Options -
Change plan settings - Change advan ced power settings - Display - Activate adaptive brightness setting..

Select On to activate the adaptive brightness setting with the help of the ambient light sensor.

Synchronizing the display on the touchscreen and an external monitor

In Windows 8.1 wipe your finger over the screen from the right-hand edge. The setting
Charms - Devices - Second monitor opens. Select the desired output type.

You can also use the Fujitsu Display Manager in the Windows Mobility Center to set the output type.

24 Fujitsu

Working with the Tablet PC

Select display orientation (portrait or landscape format)

LandscapeformatPortraitformatDisplayorientation

You can choose to use either portrait or landscape format for the display.

Windows 8.1

You can change these settings under Windows 8.1 Desktop - Control Panel ­Hardware and Sound - Windows Mobility Center / Rotate screen.

To switch off the automatic changing between portrait and landscape format, select Control
Panel - Appearance and Perso nalization - Display - Screen Resolution.

In the Fujitsu Tablet Controls settings, profiles are saved for operation
with different screen orientations. These profiles have preset standard
configurations that can be modified as desired.

These settings do not just affect the monitor settings on the Tablet PC,
but also on external monitors that are connected .

Touch commands

You can execute c

ertain commands by using your finger tip on the touchscreen of your device.

Alternatively
tip can also be

Calibrate th

, everything which you can select or activate using your finger

selected or activated using the s ty lus.

e Dual Digitizer for finger-based

operation of the device.

If W indows 8.1 is installed on your Tablet PC, your Tablet PC is
already calibrated at initial setup.

If a different operating system is installed on your Tablet PC, you must calibrate it with
your fingers before first use, so that it recognizes your fingertips as accurately as possible.

As soon as you ascertain that the accuracy is deteriorating, you
must recalibrate the device.

Operating system Menu

Windows 8.1 Desktop

Fujitsu 25

To calibrate, run the Hardware and Sound / Tablet PC Settings function in the
Control Panel. You need to calibrate both portrait and landscape formats.

Working with the Tablet PC

Actions with one finger (Windows 8.1 Modern)

Action Description

Wipe your finger over the screen from the
right-hand edge.

► Open Charms with system commands

(equivalent to pressing the Windows button +

C

button).

► Working with the mouse: Position the mouse

pointer at the bottom right-hand edge of the
screen.

Wipe your finger over the screen from the
left-hand edge.

Wipe your finger over the screen from the top
or bottom edge.

► Switch between the most recently used

applications (equivalent to pressing the
Windows button +

► Working with the mouse: Position the mouse

pointer at the bottom left-hand edge of the
screen.

► Open the App commands (equivalent to

pressing the Window s button +
Wipe from the top to the bottom of the scre en
to dock or close the current App.

► Working

Apptod

with the mouse: Right-click on the

isplay the App commands.

Ctrl

+Space).

Z

button).

26 Fujitsu

Action Description

Press and hold

► Keep your finger pressed on an object on the

screen to display a menu with further options.

► Working with the mouse: Move the mouse

pointer over the object to display a men u with
further options.

Working with the Tablet PC

Taponanobject

► Tap y o ur finger on an o

to open an App or a lin

bject on the screen
k or to execute a

command.

► Working with the mouse: Left-click on the

object.

Scroll / Move object / Swivel object ► Use this function to scroll through lists or

websites or to swivel or move an object.

► Working with the mouse: Left-click on the

object, keep the mouse button pressed and
move / swivel the object or scroll.

Fujitsu 27

Working with the Tablet PC

Actions with one finger (Windows 8.1 Desktop)

Action Description

Selecting objects (click with the left mouse
button)

Starting programs (double-click with the left
mouse button)

Moving objects/windows (while holding the left
mouse button pressed, drag & drop)

Opening a context menu (click with the right
mouse button)

Moving the cur

sor

► Tap once briefly with the finger on the object.

► Use one finger to tap twice in quick

succession on the program symbol.

► Place your finger on the object/window,

keep your fingertip p resse d against
the touchscreen and move the desired
object/window.

► Tap your finge r on the desired item.

Keep your fingertip pressed against the
touchscreen.

The context me

► Position one finger on the touchscreen and

move your fingers in the desired direction.

nu appears.

28 Fujitsu

Working with the Tablet PC

Actions with two fingers (Windows 8.1 Desktop)

Action Description

Scrolling

► Place two fingers on the touchscreen.
► Move the fingers up to s

or

► Move the fingers down to scroll down.

Rotating

croll up.

► Position your thumb on the touchscreen and

rotate the image clockwise or anticlockwise
using your index finger.

Fujitsu 29

Working with the Tablet PC

Action Description

Increase or decre ase zoom

► Put two fingers on the touchscreen and

move them apart to increase the size of the
zoom.

or

► Put two fingers on the touchscreen and

move them together to decrease the size
of the zoom/view.

Lock context-sensitive menus

► Use two fingers to tap twice in quick

succession on the touchscreen.

30 Fujitsu

Working with the Tablet PC

Using the stylus

Stylus

3

2

1

You can use the stylus on your Tablet PC as an electronic writing tool, to select menu items, and to
navigate through the programs. Programs that support handwriting recognition also allow you to
write directly on the screen with the stylus. You can also use the stylus as a drawing tool.

The Tablet PC is supplied with a stylus tether which you can attach to the
eyelets on the stylus and on the Tablet PC.

Use only the stylus that was provided with your Tablet PC. Do not use any other pointed
object as a substitute, that was not specially designed for your Tablet PC. Replace
the stylus tip if it is worn. The warranty does not cover a scratched screen.

While writing, take care that you do not scratch the surface of the
display (e.g. with a wristwatch or bracelet).

1 = stylus tip

2 = stylus button (= right mouse button)

3 = eyelet for stylus tether

The stylus of th
if used impro pe

Our recommend

• Do not gestur

e Tablet PC is an electronic instrument that can be damaged
rly. Handle the stylus with care.

ations for proper han dling of the stylus are as follows:

e with the stylus.

• Do not use the stylus as a pointer.

•Donotuseth

e stylus on surfaces other than the screen of the Tablet PC.

• Do not try to turn the grip of the stylus. The grip is u sed to put the
stylus into its slot and to take it out of its slot.

• Never stor
containe
adverse e
this cas
avoid da

e the stylus with its weight on the tip (e.g. with the tip down in a stylus

r). If the stylus is stored with the tip pointing down, this may have an

ffect on the stylus mechanism (particularly under high temperatures). In

e the stylus tip may react as though it is constantly being pressed down. To

mage, the stylus should be stored in the stylus slot when not in use.

The stylus can be influenced by electromagnetic fields (cursor quivers or
jumps). There may be a few areas on the screen where the cursor quive rs
slightly in spite of pressing the stylus down firmly.

The screen responds to entries made with the tip of the finger or the stylus when the
tip of the finger or the stylus directly touches the screen.

You can use the stylus to perform almost all functions for which you would otherwise use a mouse.

Fujitsu 31

Working with the Tablet PC

Delete functions are not supported by the stylus.

Action Mouse

Selecting menu
items

Starting programs Double-click with the left mouse

Moving an object
or window

Opening a co ntext
menu

Moving the cursor Move the mouse

Click with the left mouse button. Tap on the menu entry with the tip of

button.

Drag with the left mouse bu
pressed.

Click with the right mou

se button.

Stylus location

On delivery, the stylus is located in the stylus
holder:

tton

Stylus

the stylus.

Tap on the program symbol twice in
rapid succession using the stylus tip.

Place the stylus tip directly on the
object or window. Keep the stylus tip
held against the screen. Drag the
desired object or window.

Tap on the desired element with the
stylus and keep the stylus pressed
against the screen.

Place the tip of the st
the screen.

1

ylus directly on

Adjusting the stylus

Operating system Menu

Windows 8.1 Under Windows 8.1 Desktop - Control Panel - Hardware and Sound - Pen and

Touch Input you can make various settings for the stylus (assignment

and function of the stylus button).

Calibrating the stylus

If Windows 8.1 is installed on your Tablet PC, your Tablet PC is already calibrated at initial setup.

If a different operating system is installed on your Tablet PC, you must calibrate it with the
stylus before first use, so that it recognizes the stylus as accurately as possible.

You should also always repeat the calibration if the co-ordination between the
stylus and the cursor movement deteriorate s.

Operating system Menu

Windows 8.1 Desktop

32 Fujitsu

To calibrate, run the Hardware and Sound / Tablet PC Settings function in the
Control Panel. You need to calibrate both portrait and landscape fo rmats.

Working with the Tablet PC

Replacing the stylus tip

With use, the stylus tip may become worn or may pick up foreign particles that can scratch the screen.
A damaged or worn tip may not move freely, causing unpredictable results when using the stylus.

If your stylus exhibits these problems, replace the stylus tip. To do th is, use the supplied tool (1).

► To remove the tip, position it in the gap

between the two ends of the tool supplied.

► Pinch the two ends of the supplied tool

together so that the tip is firmly clasped,
then pull it from the barrel.

► Replace the tip with one of the new tips

that were supplied with your stylus. Insert
the flat end of the tip into the barrel
and exerting gentle pressure, push it
in until it is firmly in place.

1

If the tip is worn or damaged, discard it.

Installing a stylus tether

Attach the stylus with a stylus tether to prevent accidentally dropping it or losing it.

► Fasten the stylus tether to the stylus eyelet and to the eyelet on the Tablet PC.

Fujitsu 33

Working with the Tablet PC

Tablet buttons

Your Tablet PC is fitted with three tablet bu ttons.

Symbol Description Functions

+
–

–––

34 Fujitsu

Volume + button Increase volume

Volume - button Decrease the volume

Shortcut button Call the status area by pressing or start a screenshot

function by a long press (depends on configuration)

Webcam

Webcam

Your device has two webcams: one on the front of the device and one on the rear.

Working with the Tablet PC

The webcam has i ts own statu

Depending on the software
record video clips or take

• The picture quality depe

s indicator. The indicator lights up when the webcam is active.

used, you can use your webcam to take pictures,

part in web chats.

nds on the lighting conditions and the software being used.

• You can only operate the webcam with a particular application (e.g. an Internet telephony
program or a video conferencing program which supports a webcam).

• When using the webcam th

e support of the Tablet PC must not wobble.

• The webcam automatically adjusts itself to the current light level. For this reason,
the touchscreen may flicker w hile the light level is adjusted.

Further information on use of the webcam and additional settings for your webcam
can be found in the help function of the program using the webcam.

Rechargeable battery

BatteryBatteryServicelife,batteryRechargeablebatteryBattery

The built-in battery provides the Tablet PC with the necessary power for use on the move.
You can increase the service life of the battery by caring for the battery properly. T he
average battery service life is around 500 charge/discharge cycles.

You can extend the batt ery service life by taking advantage of the available energy saving funct ions.

Charging and maintaining the battery

BatteryBattery

The Tablet P
between 5°C

You can char
(see "

If the batt
within fiv

C battery can only b e charged when the ambient temperatu re is

/ 41 °F and max. 35°C / 95°F.

ge the battery by connecting the Tablet PC to the AC adapter

ecting the AC adapter", Page 18).

Conn

ery is running low you will hear a warning a larm. If you do not connect the AC adap ter

e minutes of hearing the warning alarm, your Tablet PC will switch off automatically.

ing the battery state of charge

Monitor

Batterybatterychargemeter

y symbol for monitoring the battery capacity is displayed in the system bar /

A batter

ndicator. The battery symbol sho ws you the battery charge.

status i

Fujitsu 35

Working with the Tablet PC

Using the energy saving functions

EnergyEnergyBattery

The Tablet PC uses less power when the power management featu res are enabled. You will
then be able to work longer when using the battery before having to recharge it.

The energy efficiency is increased and environmental pollution is reduced.
By choosing the best power options, you can make significant savings and
at the same time help protect the environment.

We recommend the following settings:

Function Operating on AC power Operating on battery power

Turn off display After 10 minutes After 5 minutes

Turn off hard disk(s) After 15 minutes After 10 minutes

Energy saving

► Set the energy saving functions in your Control Panel.
► Set the screen saver in your Control Panel.

or

► Keep a finger pressed on the desktop to display the context menu. Configure the screen

saver under Change screen saver.

If you need further information about an option, you can get help w ith most settings by

pressing the

After 20 minutes After 15 minutes

?

symbol in the upper right of the screen to open the Microsoft Help.

When the Tablet PC is in an energy saving mode, you must remember the following:

When the Tablet PC is in energy saving mode, open data is held in main
memory or in a swap file o n the hard disk.

Never switch off the Tablet PC while it is in an energy saving mode. If the built-in battery
is nearly drained, close all open files and do not go into energy saving mode.

If you do not intend to use your Tablet PC for a long period of time:

► Exit the energy saving mode if necessary via touching the screen or by switching on the

Tablet PC.

► Close all opened programs and completely shut down the Tablet PC.

36 Fujitsu

Working with the Tablet PC

Memory cards

Slot

Your Tablet PC is equipped with an integrated storage card reader. Use storage
cards to enlarge the storage of your Tablet PC.

Follow the manufacturer’s instructions when handling the memo ry cards.

Memorycard

Supported formats

It supports the following formats:

• M icro Secure Digital (SD

•MicroSDHC

•MicroSDXC

Inserting the memory card

TM

Card)

2

1

► Open the slot cover (1).
► Care

fully slide the s torage card into the slot (2). The label area must be facing upward. Do
pply any force, otherwise the delicate contact surfaces could be damaged.

not a

Memorycard

► Close the slot cover.

Fujitsu 37

Working with the Tablet PC

Removing the memory card

Memorycard

To avoid any loss of data, always follow the correct procedure for removing the
card (see the documentation for your o perating system).

► Open the slot cover.

1

2

► Pull the storage card out of the slot (1).
► Close the slot cover (2).

38 Fujitsu

Working with the Tablet PC

SIM card

A SIM Card (Subscriber Identity Module) is a chip card which is inserted in a cellular phone or Tablet
PC and, together with an integrated UMTS/4G module, enables access to a cellular radio network.

Follow the instructions supplied by the provider of the SIM card. If you do not feel the
the SIM card engage as you insert it, use a pointed object to insert the SIM card.

Please note that the SIM card format must be micro-SIM (3FF). Other SIM
card formats, such as full-size (1FF), mini-SIM (2FF) or nano-SIM (4FF) do
not fit in the SIM card slot of your Tablet PC.

Please do not insert any other format of SIM card as they may become
twisted, they could even damage the system.

Inserting a SIM card

2

1

► Open the slot cover (1).
► Carefully push the SIM card into the slot (2) until the SIM card clicks into place.

The label area must be facing upward. Do not apply any force, otherwise the
delicate contact surfaces could be damaged.

► Close the slot cover.

Fujitsu 39

Working with the Tablet PC

Removing a SIM card

► Open the slot cover.

1

2

► Pull the SIM card out of the slot (1).
► Close the slot cover (2).

Wireless LAN/Bluetooth/UMTS/4G radio components

The installation of radio components not approved by Fujitsu will invalidate
the certifications issued for this device.

Switching the wireless components on and off

The radio components are switched on and off using the appropriate functions of the operating system.

► To switch radio componen ts on and off individually, select Settings – Change

PC settings – Network – Airplane mode.

40 Fujitsu

Working with the Tablet PC

Setting up WLAN access

• Requirement: A WLAN must be available and you must have the
corresponding access information.

Information on configuring the WLAN access can be found in the
documentation for your operating system.

Further information on WLAN and Bluetooth

For further information about WLAN or Bluetooth, see "Appendix: Miscellaneous Information".

For W LAN specifications, see chapter "

WLAN specifications", Pag e 79.

Access via UMTS

If you ordered an integrated UMTS module with your system, you can enjoy optimum
reception and maximum energy efficiency without awkward cables or antenn as. The
optional UMTS module is ready for use immediately.

You wi l l find information on establishing the connection with the UMTS network
in the documentation for the hardware used.

Your device can connect to the Internet via UMTS. To do this, use one of
the following types of connection:

• Integrated UMTS module (availability dependent on your configuration)

• a USB dongle (a

• a mobile end-device (e.g. mobile phone with Bluetooth or cable connection)

USB stick with your mobile phone provider’s SIM card)

Access via Wireless WAN

You can purchase the accessories for W ireless WAN reception from your Fujitsu dealer.

If you have ordered a Wireless WAN module, your device will already
be prepared when you receive it.

You w i l l find information on establishing the connection with th e Wireless WAN
network in the documentation for the hardware you plan to use.

Fujitsu 41

Working with the Tablet PC

Ethernet and LAN (only with docking cradle)

EthernetLAN

The internal network module of your Tablet PC supports Ethernet LAN. You can use it to
establish a connection to a local network (LAN = Local Area Network).

► Connect the network cable to the LAN

port of the cradle (1).

► Connect the network cable to your

network connection (2).

1

2

GPS

GPS

Your network admin

The network cable i
cable can be ob tai

istrator can help you to configure and use the LAN connections.

s not included in the delivery scope. This type of

ned from a specialist dealer.

Whether your device has this function depends on the chosen equipment level.

42 Fujitsu

Accessories for your Tablet PC (opti

onal)

Accessories for your Tablet PC

The following accessories are available for your Tablet PC:

• Docking cradle fo r charging the Tablet PC and with additional ports

• Keyboard cover

• VESA mount

• Shoulder strap

• Folio case

• Micro USB adapter cables

The following sections provide more information on handling the accessories.

Your docking cradle

As well as fast charging, your docking cradle is a device that a lso allows you to quickly connect
your Tablet PC to your peripherals such as a monitor, keyboard, mouse, etc. You only need
to dock the Tablet PC to be able to work with your peripheral devices.

(optional)

(optional)

Docking cradle components

PortsPortsCradle

1

3

3

2

1 = Connector on the cradle for the docking

port of the Tablet PC
2=USBport2.0
3=USBport2.0
4 = VGA monitor port

Fujitsu 43

5=HDMI
6 = LAN port
7 = DC jack socket (DC IN)

4

5

6

7

Accessories for your Tablet PC (opti

onal)

Setting up the cradle

Select a suitable location for the cradle before setting it up. In doing
so, please follow these instructions:

• Placethecradleonaflat, stable, non-slippery surface.

• N eve r place the cradle or the AC adapter on a heat-sensitive surface.

• D o not expose the cradle to extreme environmental conditions.
Protect the cradle from dust, moisture and heat.

Connecting the Tablet PC to the cradle

It is possible to connect the Tablet PC to the cradle while it is running. To prevent
problems, we recommend that you switch the Tablet PC off first.

Disconnect the AC adapter from the Tablet PC before connecting
the Tablet PC to the cradle.

When the Tablet PC i
the AC adapt er to t

Information for u

• If your Tablet PC
Tablet PC canno

• The HDMI and VGA ports of the docking cradle cannot be used at the same time. If
devices are connected to both ports, only the device at the HDMI port can be used.

Cradle

► Switch the Tablet PC off.
► Remove the AC
► Remove the AC adapter cable from the DC jack (DC IN) of the Tablet PC.

• The maximum supported resolution for VG A /HD M I is 1920 x 1080 pixels.

plug of the AC adapter from the power outlet.

s connected to the cradle, you must connect

he cradle.

sing the docking cradle:

is connected to the docking cradle, the micro USB port of the

t be used. Use the alternative ports of the cradle.

44 Fujitsu

Accessories for your Tablet PC (opti

onal)

2

1

4

3

► Position the Tablet PC so that it lies against the storage surface of the cradle.
► Push the Tablet PC on to the cradle in the direction of the arrow (1) until

you feel it engage on the connector.

► Plug the AC adapter cable into the DC jack (DC IN) on the cradle (2).
► Connect the AC cable to the AC adapter (3).
► Plug the AC cable into the power outlet (4).

Fujitsu 45

Accessories for your Tablet PC (opti

onal)

Disconnecting the Tablet PC from the c radle

It is possible to separate the Tablet PC from the cradle while it is running. However,
to prevent any problems, we recommend that you switch the Tablet PC off first or that
you execute the appropriate undocking function provided by the operating system.

► Switch the Tablet PC off.

1

► While holding down the lower part of the cradle, lift the Tablet PC from

the cradle in the dire ction of the arrow (1).

46 Fujitsu

Accessories for your Tablet PC (opti

Keyboard cover (optional)

The keyboard cover is an optimized device for the convenient input of text. It
only needs to be docked with the Tablet PC.

Keyboard cover ports

keyboardcoverPorts

onal)

1=Releasebu
2 = Sliding foot (pu lled out)
3 = Connecto

the Tabl

tton

r for the docking port of

et PC

1

2

3

4 = Status ind

Lock, Scr

4

icators (Num Lock, Caps

oll Lock)

Fujitsu 47

Accessories for your Tablet PC (opti

Connecting the Tablet PC to the keyboard cover

keyboardcover

onal)

► Position the keyboard cover on a flat, even surface.

2

1

3

1

To avoid topp
the sliding f

ling of the Tablet PC and resu lting damage, always pull out

oot when using the keyboard cover.

► Fully pull out the sliding foot cover (1).
► Press the release button (2) until it firmly remains in pressed position (red marking visible).
► Push the Tablet PC on to the keyboard cover in the direction of the arrow

until you feel it engage on the connector (3).

48 Fujitsu

Accessories for your Tablet PC (opti

Separating the Tablet PC from the keyboard cover

1

2

onal)

► Press and hold the release button on the keyboard cover (1).
► Lift the Tablet PC away from the keyboard cover in the direction of the arrow (2).

Fujitsu 49

Accessories for your Tablet PC (opti

onal)

VESA mount (optional)

Use the VESA mount to secure the Tablet PC to a mount with the appropriate screw holes.

• When you attach the screws, use the correct tool and the correct tool size.

• K eep the screws out of the reach of children.

1

1

1

1

3

3

► Remove the four screws (1).
► Position the VESA mount on the Tablet PC (2). Make sure that the screw holes of the

VESA mount and of the Tablet PC lie exactly on top of each other.

► Secure the VESA mount using the screws (3).

3

2

3

50 Fujitsu

Shoulder strap (optional)

• When you attach the screws, use the correct tool and the correct tool size.

• Keep the screws and mounts out of the reach of children.

• Do not use motorized screw driver so to not damage the screws

Accessories for your Tablet PC (opti

1

onal)

1

► Remove the
► Position the fittings (2).
► Secure th

screws (1).

e fittings using the screws (3).

3

2

3

2

Fujitsu 51

Accessories for your Tablet PC (opti

► Secure the shoulder strap to the fittings.

onal)

52 Fujitsu

Folio case (optional)

• The f olio case c ontains magnets. Keep away from ob jects that may be
easily affected by the influence of magnetism.

• LCD may be accidently turned on if the cover is not properly closed.

• Make sure the unit is firmly fitted into the folio case fasteners so it will not fall out.

• This folio case is only designed to contain and carry this unit.
Do not use it for any other purpose.

• Do not put the folio case in a direct sunlight or expose to high
temperature and humidity.

Accessories for your Tablet PC (opti

onal)

► Position the Tablet PC on the folio case as shown.
► Engage the top edge and then press it down.

The following illustration shows you the many ways in which the folio case can be used:

Fujitsu 53

Accessories for your Tablet PC (opti

onal)

Micro USB adapters

5 USB adapters are available for the device:

Micro USB to USB adapter

Micro USB to HDMI ada

Micro USB to VGA adapter

pter

54 Fujitsu

Micro USB to Display Port adapter

Micro USB to LAN adapter

Accessories for your Tablet PC (opti

onal)

For technical s

pecifications, see chapter "

USB adapters", Page 82.

Fujitsu 55

Security functions

Security functions

Securityfunctions

Your Tablet PC has several security features that you can use to secure your system
and your personal data fro m unauthorized access.

This chapter explains how to use these functions, and what the benefits are.

Please remember that in some cases, for example, forgetting your password,
you may be locked out of the system and unable to access your data.
Therefore, please note the following information:

• B ack up your data on external data carriers at regular intervals.

• S ome security functio
of the passwords and ke

If you forget your passwords you will need to contact our Service Desk.
Deletion or resetting of passwords are not covered by your warranty
and a charge will be made for assistance.

ns need you to choose passw ords. Make a note

ep them in a safe place.

56 Fujitsu

Security functions

Configuring the fingerprint sensor

FingerprintsensorFingerprintsens or

The finge rprint sensor can record the image of a fingerprint. With additional fingerprint
software, this image c an be processed and used instead of a password.

1

1

► Install the fingerprint software to be able to use the fingerprint sensor (1).

You can obtain further information on the fingerprint sensor in the
"appendix: Miscellaneous Information".

Fujitsu 57

Security functions

Configuring password protection in BIOS Setup Utility

Before using the various options for password protection in the BIOS Setup
Utility, please proceed as follows to increase data security:

Make a n ote of the passwords and keep them in a safe place. If you forget your supervisor
HDD password you will not be able to access your Tablet PC. Deletion of passwords is
not covered by your warranty and a charge will therefore be made for assistance.

Passwordprotection

Your password can be up to
numbers. No distinction

Protecting BIOS Setup Utility (supervisor HDD password and user HDD password)

If you have opened these operating instructions on the screen, we recommend
that you print them out. You cannot call up the instructions on the screen
while you are s etting up the password.

BIOSSetupUtility

The supervisor HDD password and the user HDD password both prevent unauthorized use of the

BIOS Setup Utility. The supervisor HDD password allows you to access all of the functions of the BIOS
Setup Utility, while the user HDD password will only give you access to some of the functions. You

can only set a user HDD password when a supervisor HDD password has already been assigned.

Calling and using the BIOS Setup Utility is described in the chapter

Settings in BIOS Setup Utility", Pag e 67.

"

eight characters long and can contain letters and

is made between uppercase and lowercase.

Assigning the supervisor and user passwords

► Start the BI
► Select the Set Supervisor Password field and press the Enter key.

With Enter



► Enter the password and press the Enter key.

Confirm ne



► Enter the password again and press the Enter key.

Changes



► To set the user password, select Set User Password and proceed exactly as

when confi guring the supervisor password.
If you d



► In the Exit menu, select the option Save Changes & Exit.
► Selec

word

rvisorpassword

password
Pass

Supe

User

The Tablet PC is rebooted and the new password is effective. It will now be necessary to



first enter you r supervisor or user password in order to open the BIOS Setup Utility. Please
note that the user password only provides access to a few of the BIOS settings.

58 Fujitsu

OS Setup Utility and go to the Security menu.

new Password: y ou are asked to enter a password.

w Password requires you to confirm the password.

have been saved is displayed as a confirmation that the new password has been saved.

o not want to change any other settings, you can exit BIOS Setup Utility.

t Yes and press the Enter key.

Security functions

Changing the supervisor HDD password or user HDD password

You can only change the supervisor HDD password when you have logged into the
BIOS Setup Utility with the supervisor HDD password.

PasswordSupervisorHDDpasswordUserHDDpassword

► Start the BIOS Setup Utility and go to the Security menu.
► When changing the password, proceed exactly as when assigning a password.

Removing passwords

To remove a password (without setting a new password) perf orm the following steps:

PasswordSupervisorpasswordUserpassword

► Start the BIOS Setup Utility and go to the Security menu.
► Highlight the Set Supervisor Password or Set User Password field and press the Enter key.

You will be requested to enter the current password by the Enter Current Password prompt.



Enter New Password will appear and you will be requested to enter a new password.

► Press the Enter k ey twice at this request.
► In the Exit menu, select the option Save Changes & Exit.
► Select Yes and press the Enter key.

The Tablet PC is rebooted and the password is removed.



Removing the supervisor password simultaneously deactivates the user password.

Password protection for booting the operating system

You can also pre
HDD password yo

the superviso

Operatingsystem

vent booting of the operating system with the supervisor

uhavesetintheBIOS Setup Utility (see s ecti on "

r and user passwords", Page 58).

Assigning

Activating system protection

► Start the BIOS Setup Utility and go to the Security menu.

Operatingsystem

► Select the PasswordonBootoption and press the Enter key.
► Select the option you require ( Disabled, First Boot or Every Boot) and press the enter key
► Select the Save Changes & Exit option under Exit.

The Tablet PC reboots. You will be prompted to enter your password (the supervisor password).



Deactivating system protection

► Start the BIOS Setup Utility and go to the Security menu.

Operatingsystem

► Select the PasswordonBootoption and press the Enter key.
► Select the Disabled option and press the Enter key.

If you do not want to change any other settings, you can exit BIOS Setup Utility.



► Select the Save Changes & Exit option under Exit.

The Tablet PC reboots. The system is no longer password-protected.



Fujitsu 59

Security functions

Password protection for the hard disk

Passwordprotection

The hard disk password prevents unauthorized access to the hard disk drives
and is checked internally each time the system is boote d. The condition for this
is that you have assigned at least the supervisor HDD password.

Activating hard disk protection

► Call up the BIOS Setup and select the Security menu.

If you have not assigned BIOS passwords yet, define the supervisor and the user



password now, if desired (see "

► Mark the Hard Disk Security field and press the Enter key.
► In the area Drive0, mark the field Set Master Password and press the Enter key.

Enter new Password then appears and you are asked to enter a password.



► Enter the password and press the Enter key.

Confirm new Password requires you to confirm the password.



► Enter the password again and press the Enter key.

With Setup Notice: Changes have been saved you receive confirmation that



the new password has been saved.

► If you wish to enter a password fo r a second hard disk (Drive 1), in the area

Drive1 mark the field Set Master Password and proceed in exactly the same way

as for the set up of the first hard disk (Drive0).
The field Password Entry on Boot is set to Enabled by default. You can exit the BIOS



Setup once you have finished changing the settings.

► From the Exit menu, choose t he option Exit Saving Changes.
► Press the Enter key a nd select Yes.

The Tablet PC reb oots and your hard disk is now protected with a password. The



password prompt is enabled as soon as the Tablet PC has rebooted.

Security functions", Page 56).

Deactivating hard disk protection

To cancel a password (without setting a new password) proceed as follows:

► Call up the BIOS Setup and select the Security menu.
► Mark the Hard Disk Security field and press the Enter key.
► In the area Drive0, mark the field Set Master Password and press the Enter key.

With the prompt Enter current Password you are first asked to enter the old password again.



With Enter new Password you are then prompted to enter a new password.

► After the request, press the Enter key three times.
► From the Exit menu, choose t he option Exit Saving Changes.
► Press the Enter key a nd select Yes.

The Tablet PC reboots and there is no longer any password protection for this hard disk.



► If you wish to remove a password for a second hard disk (Drive1), in the area

Drive1 mark the field Set Master Password and proceed in exactly the same way

as for the removal of the first hard disk (Drive0).

60 Fujitsu

Security functions

SmartCard reader (optional)

SecurityfunctionsSecurityfunctions

SmartCards are not supplied as standard equipment. You can use all SmartCards that comply with
the ISO standard 7816-1, -2 or -3. These SmartCards are available from various manufacturers.

With the appropriate software you can use your SmartCard as an alternative to password protection,
but also as a digital signature, for encrypting your e-mails or for home banking.

We recommend that you always use two SmartCards. Always keep one of the SmartCards
in a safe place if you are carrying the other SmartCard with you.

In order to be able to take advantage of all the security features of your Tablet
PC, you will need a CardOS SmartCard from Fujitsu.

The SmartCard can only be used with a PIN, so maximum protection is maintained
even when the SmartCard is lost. In order to maximize your security, the CardOS
SmartCard is disabled if three incorrect attempts are made to enter the PIN.

During first time use of your CardOS SmartCard, you must either enter the preset P IN
"12345678" or the PIN which has been notified to you by your system administrator.

Inserting the SmartCard

Do not use force when inserting and removing the SmartCard.

Make sure that foreign objects do not fall into the SmartCard reader.

► Turn the Tablet PC over.
► Push

Fujitsu 61

the SmartCard into the SmartCard reader with the chip facing downwards.

Security functions

Trusted Platform Module - TPM (device dependent)

TPMTrustedPlatformModule

To use the TPM, you must enable the TPM in the BIOS Setup before the software is
installed. The requiremen t for this is that you have assigned at least the supervisor
HDD password (see "

Enabling TPM

• Requirement : You have assigned a supervisor HDD password (see "Security functions", Page 56).

► Call BIOS Setup and sele
► Mark the TPM Security Chip Setting field and press the Enter key.
► Select the entry Enabl

Once you have enabled the TPM the Clear Security Chip menu item appears.



You can clear the hold
all secret keys ( e.g
etc.) generated by

Take note that you c
encrypted on the h

► Select the Exit Sa
► Press the Enter key a nd select Yes.

The Tablet PC res



Disabling TPM

• Requirement : You have assigned a supervisor HDD password (see "Security functions", Page 56).

► Call BIOS Setup and select the Security menu.
► Mark the TPM Security Chip Setting field and press the Enter key.
► Select the entry Disabled to disable the TPM.
► From the Exit menu, choose t he option Exit Saving Changes.
► Press the Enter key a nd select Yes.

The Tablet PC is rebooted and the TPM is disabled.



Security functions", Page 56).

ct the Security menu.

ed to enable the TPM

er in the TPM using Clear Security Chip .WithEnabled,

. SRK - Storage Root Keys, AIK - Attestation Identity Keys

applications are deleted.

an then no longer access the data you have

older-based keys!

ving Changes option in the Exit menu.

tarts and the TPM is enabled after the reboot.

62 Fujitsu

Connecting external devices

Connecting external devices

Under all circumstances, please observe the safety notes provided in the

Important notes", Page 12 chapter before connecting or disconnecting

"

any devices to or from your Tablet PC.

Always read the documentation supplied with the device you wish to connect.

Never connect or disconnect cables during a thunderstorm.

Never pull at a cable when disconnecting it. Always grasp the plug.

Follow the order described below when you co nnect external devices to
the Tablet PC or separate them from it:

With some devices, such as USB devices, it is not necessary to sw itch off
the Tablet PC and the device before connecting/disconnecting. For more
information about whether or not devices need to be switched off, please refer
to the documentation supplied with your external device.

Some of the external devices require special drivers (see the operating
system and external device documentation).

Connecting devices to the Tablet PC (or to the do ckin g cradle)

1. Switch off the Tablet PC and all the external devices.

2. Disconnect th

3. Connect the cables for all the external devices according to the instructions.

4. Plug all the A

Devices,Peripherals,

e AC plugs for the Tablet PC and all the affected devices from the power outlets.

C plugs into the power outlets.

Disconnecting devices from the Tablet PC (or from the docking cradle)

1. Switch off the Tablet PC and all the external devices.

2. Disconnec

3. Disconnect the cables for all the external devices following the instructions.

Devices,Peripherals,

t the AC plugs for the Tablet PC and all the affected devices from the power outlets.

Fujitsu 63

Connecting external devices

Connecting an external monitor

HDMI port (via optional docki

HDMIport

The HDMI port of the docking cradle can b e used to co nnect an external amplifier,
LCD TV or a plasma TV with an HDMI connection.

Some LCD televisions have only two speakers/speaker ports and therefore
cannot reproduce Dolby Digital or DTS. To play back HDMI sound, you
must change the HDMI sound settings accordingly.

You c a n find the settings under Control Panel - Hardware and Sound. Deactivate the
settings for DTS Audio and D olby Digital to enab le playback of HDM I sound.

ng cradle)

► Connect the data cable to the

external device.

► Connect the data cable to

the HDMI port.

VGA monitor port (via optional docking cradle)

An analog moni
limited to a m

MonitorVGA portScreenconnectionMonitorconnection

tor is connected to the analog VG A monitor port. Screen output is

aximum of two screens at the same time.

► Switch off th

external mon

► Plug the data cable of the external

monitor into the monitor port.

► First swit

then switc

e Tablet PC and the

itor.

ch on the external monitor and

hontheTabletPC.

You c a n
scree

You ca
scre

64 Fujitsu

also switch back and forth betwee n the external monitor and the LCD

n of the Tablet PC, see "

n display the same image on the external monitor and on the LCD

en of the Tablet PC at the same time.

Touchscreen", Page 24.

Connecting external devices

Connecting USB devices

USBports

With the USB ports you can conne ct external devices that also have a USB port
(e.g. a DVD drive, a printer, a scanner or a modem).

USB devices are hot-swappable. This means you can connect and disconnect the
cables of USB devices while the operating system is running.

USB 1.x has a maximum data transfer rate of 12 Mbps.

USB 2.0 has a data transfer rate of up to 480 Mbps.

USB 3.0 has a data transfer rate of up to 5 Gbps.

Additional information can be found in the d ocumentation for the USB devices.

+

► Connect the dat
► Connect the data cable to a USB port (Tablet PC or docking cradle) or

micro USB port (only on Tablet PC).

Device drivers

USB devices will be automatically recognized and installed by your operating system.

For optional micro USB accessories (cables), see chapter "

a cable to the external device.

Micro USB adapters", Page 54.

How t o remove USB devices correctly

Always correctly remove the device according to the rules described below,
to ensure that none of your data is lost.

► Tap the symbol for safe removal of the hardware.
► Select the device you wish to shut down and remove.
► Ta p OK.

Wait for the dialog box which tells you that it is now safe to remove the device.



Fujitsu 65

Connecting external devices

Headphones port

ConnectingaudiodevicesAudioconnectionsConnectingheadphones

You can connect either headphones or external speakers to your Tablet PC via the headphone port.

► Connect the audio cable to the

external device.

► Connect the audio cable to the headphone

port of the Tablet PC.
The internal speakers are disabled.



If you buy a cable from a retailer, please note the following information:

The headphone port on your Tablet PC is a "3.5 mm jack socket".

If you want to connect headphones or speakers you will need a "3.5 mm jack plug".

66 Fujitsu

Settings in BIOS Setup Utility

Settings in BIOS Setup Utility

BIOSSetupUtilitySystemsettings,BIOSSetupUtilityConfiguration,BIOSSetupUtilitySetupConfiguringsystemConfiguringhardware

The BIOS S etup Utility allows you to set the system functions and the hard ware
configuration for the Tablet PC.

When the Tablet PC is delivered, the default settings are effective. You can change
these settings in the menus of the BIOS Setup Utility. Any changes you make take
effect as soon as you save and exit the BIOS Setu p Utility.

The BIOS Setup Utility program contains the following menus:

About
System
Advanced

Security
Boot
Exit

Starting the BIOS Setup Utility

► Keep the "Lock screen orientation" tablet button pressed and switch the Tablet PC on.

► If a password has been assigned, enter the password and press the Enter key.

To navigate more easily in the BIOS Setup Utility, you can use an external USB
keyboard, o r keep the volume button pressed during the boot process.

Displays information relating to the BIOS, processor and Tablet PC

Advanced system settings

Configuration of various hardware components, such as mouse , keyboard,
processor

Password settings and security functions

Configuration of the start-up sequence
Exits the BIOS Setup Utility

BIOSSetupUtility

If you have forgotten the password, contact your system administrator
or contact our customer service centre.

The BIOS Setup Utility starts.

Fujitsu 67

Settings in BIOS Setup Utility

BIOS Setup Utility operation

BIOSSetupUtility

Press the
of the individual settings is shown in the right-hand window of the BIOS Setup Utility.

With the

F1

key to display help about operation of the BIOS Setup Utility. The description

F9

key you ca n load the default settings of the BIOS Setup Utility.

► Use the cursor keys

The menu is displayed on the screen.



► Select the option you want to chan ge with the cursor keys

←

or→to select the menu you wish to access to make changes.

↑

or↓.

► Press the "Enter" key.
► Press the

ESC

key to exit the selected menu.

► For future reference, make a note of the changes you have m ade (for example, in this manual).

68 Fujitsu

Settings in BIOS Setup Utility

Exiting BIOS Setup Utility

BIOSSetupUtility

You need to select the desired option in the Exit menu and activate it by pressing the Enter key:

Exit Saving Changes - save ch

► To save th e current menu settings and exit the BIOS Setup Utility,selectExit Saving Changes and Yes.

The Tablet PC is rebooted



and the new settings come into effect.

anges and exit BIOS Setup Utility

Exit Discarding Changes - Reject changes and exit BIOS Setup Utility

► To d iscard the changes, select Exit Discarding Changes and Yes.

The settings which were valid when BIOS Setup Utility was called remain effective.



The BIOS Setup U tility ends and the Tablet PC is rebooted.

Load Setup Defaul

► To copy the standard entries for all menus of the BIOS Setup Utility,

choose Load Setup Defaults and Yes.

ts – load default values

Discard Changes - Discard Changes without exiting BIOS Setup Utility

► To discard the changes you have made, select Discard Changes and Yes.

ThesettingsinplacewhenBIOS Setup Utility was called remain effective.



You can now make additional settings in the BIOS Setup Utility.

► If you want to exit the BIOS Setup Utility withthesesettings,selectExit Saving Changes and Yes.

Save Chan

ges - save changes without exiting

the BIOS Setup Utility

► To save the changes, select Save Changes and Yes.

The changes are saved. You can now make additional settings in the B IO S Setup Utility.



► If you want to exit BIOS Setup Utility with these settings, choose Exit Saving Changes and Yes.

Save changes and power off

► To save the changes and switch off your device, select Save Changes and Power Off and Yes.

The changes are sa ved. Your device is shut down.



Fujitsu 69

Troubleshooting and tips

Troubleshooting and tips

TroubleshootingTipsFaultTroubleshooting

If a fault occurs, try to correct it as described. If you are unable to correct
the problem, proceed as follows:

► Make a note of the steps and the circumstances that led to the fault. Also

make a note of any error messages displayed.

► Switch the notebook off.
► Please contact the Hotline/Service Desk.

You can contact Fujitsu Se rvice and Support in the following ways:

• Toll free number: 1-800-Fujitsu (1-800-838-5487)

• Website: "
Please have the following information ready when you call:

• The model name and serial number of the notebook. The serial number is
located on a sticker on the underside of the notebook.

• N otes of any messag

• Any changes you have made to the hardware or software since
receiving the notebook.

• Any changes you ha

• Your system configuration and all peripheral devices connected to your system.

• Your sales cont

Our noteboo ks have been designed primarily with mobile applications in mind.
This means that considerable effort has been made to optimize components and
equipment in terms of weight, space and energy requirements. Depending on the
particular configuration you have purchased, it is possible that functionality may be
slightly reduced compared to a desktop PC if you are running processor-intensive
gaming software, e.g. games with intensive 3D graphics. Updating your hardware with
drivers which have not been approved by Fujitsu may result in performance losses,
data losses or malfunction of the equipment. A list of approved drivers and current
BIOS versions can be downloaded from: "

utions.us.fujitsu.com/www/content/support/contact/index.php"

http://sol

es that appear on the screen and information on a cou stic signals.

ve made to the BIOS Setup settings since receiving the notebook.

ract.

http://solutions.us.fujitsu.com"

Help if problems occur

Should you encou nter a problem with your computer that you cannot resolve yourself:

► Note the ID number of your device. The ID number is found on the type rating

plate on the back or underside of the casing.

► For further clarification of the problem, contact the Fujitsu Service Desk. W hen you do

this, please have ready the ID number and serial number of yo ur system.

Recov

disk:

atingsystem,recovering

oryImage
Hard

Oper

Fact

In the event you need to restore your original Factory Image refer to the steps
in "Appendix: Miscellaneous Information".

70 Fujitsu

ering your Factory Image

Troubleshooting and tips

The Tablet PC’s date or time is incorrect

SummertimeWinterti meIncorre cttimeTime notcorrectWrongdate/timeDatenotcorrectChargingback-upbattery

Cause Troubleshooting

Time and date are wrongly set. ► With the BIOS-Setup-Utility, you can set the

Date and time are still set incorrectly after
switchingontheTabletPC.

date and time in the Main menu.

► Please contact your sales outlet or our

hotline/service desk.

Battery indicator does not illuminate

Cause

The battery is discharged.

Troubleshooting

► Charge the battery.

or

► Connect the Tablet PC to a power outlet

using the AC adapter.

The Tablet PC’s touchscreen remains dark

n

Touchsc reendarktouchscree

Cause Troubleshooting

Tou chscreen is switched off. ► Press a key (external keyboard) or tap on

External monitor or television set connected.

the touchscreen.

► Check whether t

are correct or
has been detec
Accelerator D

river for mobile".

he graphics driver settings

whether an external monitor

ted in "Intel Graphics Media

The display on the Tablet PC’s touchscreen
is difficult to read.

Touchsc reenTouch scree n

Cause Troubleshooting

Reflected glare ► Move the Tablet PC into a different position.

► Increase the brightness of the screen.

Fujitsu 71

Troubleshooting and tips

The external monitor remains bl

Monitor

Cause Troubleshooting

Monitor is switched off. ► Switch the external monitor on.

Power saving has been activated (monitor is
blank).

Brightness is set to dark.

Screen output is set to the Tablet PC
touchscreen.

The external monitor’s AC cable or data cable is
not connected properly.

The external m o

MonitorMonitor

Cause Troubleshooti

The wrong exte
or the wrong sc
the applicat

rnal monitor has been selected

reen resolution has been set for

ion program.

nitor is blank or the image is unstable

► Press a key (external keyboard) or tap on

► Adjust the brightness of the

► Check whether the graphics driver settings

► Switch off the Tablet PC and the external

► Check whether the AC cab le is plugged

► Check that the data cable is properly

► Switch on the external monitor and the

► Ter m inate the

► Set the screen resolution: Set the screen

► Select mo

ank

the touchscreen.

are correct or w hether an external monitor
has been detected in "Intel Graphics Media
Accelerator Driver for mobile".

monitor.

properly into the external monitor and into
the power outlet.

connected to the Tablet PC and the external
monitor (if it is plugged in with a connector).

Tablet PC.

ng

application program in
Windows. If th
terminating
combination
in order to s
Tablet PC. C

resolution as described in the documentation
foryouroperatingsystem.

describe
operatin

e error persists after

the program, use the key

for switching the screen output

witch to the touchscreen of the

hange the following setting:

nitor: Select monitor 1 or 2 as

d in the documentation for your

gsystem.

monitor.

The cursor does not correctly follow the stylus movements

Cause

Stylus incorrectly calibrated. ► Calibrate the stylus as described in chapters

72 Fujitsu

Troubleshooting

Adjusting the stylus", Page 32 and

"

Calibrating the stylus", Page 32.

"

Troubleshooting and tips

Stylus input not working

Cause

Incorrect driver inst alled.

Troubleshooting

► If your device is one which can o nly be

operated using the stylus, install the driver
for the stan dard model.

or

► If your device is one which can be

operated using the stylus and by finger,
install the driver for the "Dual Digitizer"
model.

The Tablet PC does not start after switch on

TabletPC

Cause Troubleshooting

The battery is discharged.

The AC adapter is not properly connected. ► Check whether the AC adapter is properly

► Charge the battery.

or

► Connect the AC adapter to the Tablet

PC.

connected to the Tablet PC.

► Switch the Tabl

et PC on.

The Tablet PC stops working

TabletPCEnding

Cause Troubleshooting

The Tablet PC is in energy saving mode.

An application program has caused the
malfunction.

The battery is discharged.

Fujitsu 73

► End energy saving mo de.

► Close the application program or restart

the Tablet PC (by restarting the operating
system or switching the device off and back
on again).

► Charge the battery.

or

► Connect the AC adapter to the Tablet

PC.

Troubleshooting and tips

The printer does not print

Printerdoesnotprint

Cause Troubleshooting

The printer is not switched on. ► Make sure that the printer is sw

The printer is not connecte d c

The printer driver is faulty or not correctly
installed, or it is the wrong printer driver.

orrectly.

on and ready for operation (ref
documentation supplied with t

► Check that the data cable between the Tablet

PC and the printer is properly connected.

► Check that the data cable between the Tablet

PC and the printer is properly connected.

► Check whether the correct printer driver is

loaded (refer to the printer documentation).

itched

er to the

he printer).

The wireless connect

ctiontoanetworkdoesnotw or k

Thewirelessconne

Cause Troubleshooting

The wireless component is switched off. ► Switch the wireless c omponen t on (see

The wireless component is switched on. Desp ite
this, the wireless connection to a network does
not work.

The battery di

Battery

Cause

The battery i
case the batt

You may have an application running that
consumes a great deal of power due to frequent
accessing of the hard disk or optical drive.

The maximum brightness may have been set
for the screen.

s either too hot or too cold. In this

ery indicator flashes.

scharges too quickly

ion to a network does not work

Switching the wireless components on and

"
off", Page 40).

► Check whether the wireless connection is

enabled by the software.

► Further information on using the wireless

component can be found in the help files.

Troubleshooting

► Bring the Tablet PC up/down to a normal

operating temperature again.

► If the operating tim e of the battery life is

extremely short, the battery is probably too
old. Replace the battery if necessary.

► Use the AC adapter whenever possible.

► Reduce the brightness of the screen to

lower energy consumption: You will find the
setting under Control Panel – Hardware and
Sounds – Windows Mobility Center.

74 Fujitsu

Troubleshooting and tips

SmartCard reader is not recognized

Cause

Chip card inserted incorrectly.

Troubleshooting

► Make sure you have inserted your

SmartCard into the SmartCard reader with
the chip facing upwards.

► Check whether the SmartCard you are using

is supported. Your SmartCard must comply
with the ISO standard 7816-1, -2, -3 and - 4.

SmartCard PIN forgotten

Cause

PIN forgotten ► Ifyouworkinanetwork

Troubleshooting

system administrat
Tablet PC using a sup

, contact your

or, who can unlock your

ervisor PIN.

User and/or supervisor SmartCard lost

Cause

User and/or supervisor SmartCard lost ► If you have lost your user SmartCard, you

Troubleshooting

can continue working with the supervisor
SmartCard and initialize a new user
SmartCard or d eactivate the SystemLock
function.

► If you have lost the supervisor SmartCard,

you can also continue working, but you no
longer have all rights and ca nnot initialize
another supervisor SmartCard.

► If you have lost both SmartCards, you

cannot boot your system. Please contact our
customer service center. You must provide
proof of ownership for the device. The
customer service center will then refer you
to our service partner, who will unlock your
device (for a charge).

SmartC

Cause

SmartCard lost. ► If you work in a network, contact your

Fujitsu 75

ard lost

Troubleshooting

system administrator, who can boot your
Tab let PC with a supervisor SmartCard.

Troubleshooting and tips

Acoustic warning

Acousticwarn ingsErrors

Cause

A beep sounds every few seconds.

The battery is almost flat.

Troubleshooting

► Charge the battery.

Error messages on the screen

reen
Errormessagesonthesc

Errors

This section describes the error messages generated by the BIOS Setup. Error messages displayed
by the operating system or programs are described in the documentation for these programs.

If the error message appears repeatedly despite troubleshooting measures,
contact the place o f purchase or our customer service center.

Error message/cause Troubleshooting

CMOS Battery Bad

If the error message occurs repeatedly, the
buffer battery in the Tablet PC is flat.

System CMOS checksum bad - Default configuration
used

The system configuration information is
incorrect.

Extended memory failed at offset: xxxx Failing Bits:
zzzz zzzz

When testing the extended memory. an error
has resulted at the address xxxx.

Failure Fixed Disk n

The settings of the hard disk drive are incorrect.

Keyboard controller error

Keyboard error

nn Stuck key

► Contact your sales outlet or our customer

service center.

► Switch the Tablet PC off.
► Switch the Tablet PC on.
► Keep the v olume button and the shortcut

button pressed and switch the Tablet PC
on. If you keep the volume button pressed
during the boot process, you can switch into
the BIOS Setup-

► In the BIOS Setup, select the Exit menu.
► Select the entry Load Setup Defaults.
► Select OK and press the Enter key.

► Contact you

service cen

► Start the

submenu

► Switch

butto

r sales outlet or our customer

ter.

BIOS Setup (Primary Maste r

) and select the correct settings.

your Tablet PC off with the ON/OFF

n.

► Wait 3 - 5 seconds and switch the Tablet PC

on again.

If you use an external keyboard:

► Check the connection and reboot the Tablet

PC.

► Make sure that no key is pressed.

76 Fujitsu

Error message/cause Troubleshooting

Operating system not found

► Check in the BIOS Setup whether y

disk has been set correctly.

► Make sure that the operating system is

installed on the corresponding drive.

Press <F1> to resume, <F2> to SETUP

This error message appears if an error occurs
during the self-test before starting the operating
system.

► Press the

operating system

► Keep the

and switch on the Tablet P

Setup.

Real time clock error

► Contact your sales outlet or our customer

service center.

nnnnK Shadow RAM failed at offset: xxxx Failing
Bits: zzzz

System battery is dead - Replace and run SETUP

► Contact your sales outlet or our customer

service center.

► Contact your sales

service center.

System cache erro

r - Cache disabled

► Contact your sales outlet or our customer

service center.

System timer err

or

► Contact your sales outlet or our customer

service center.

Troubleshooting and tips

Alt

tablet button to boot the

tablet button pr

C to access BIOS

outlet or our customer

our hard

essed

Fujitsu 77

Technical data

Technical data

Tablet PC

General

Processor

Main memory (SO DIMM) 4GB DiMM onboard

Electrical data

Safety regulations complied with CE

Protection class II

Maximum power consumption (when the Tablet
PC is switched o n, connected to the keyboard
cover and the battery is charged):

Touchscreen

Size 10.1" WQXGA Wide View TFT

Screen resolution 2560 x 1600 pixels/16 million colors

Pixel cla ss II

Brightness control 12 levels

Technology Wide-View High-Bright Display with LED

Digitizer and glass panel

Cameras

Graphics card

Chip Intel® HD graphics

m resolution of external display:

Maximu

sions

Dimen

h x Depth x Height

Widt

Weight depending on configuration from 640 g / 1.31 lbs.

Input d evices

Tablet buttons 3 keys

tylus

S

Slots

Storage card slot 1 x micro SD Card

SIM card slot 1 x micro SIM card

Ports

Headphones port 3.5 mm stereo mini jack

Docking port 1 x

USB (Universal Serial Bu s) 1 x USB 3.0, 1 x micro USB 2.0

Ambient c onditions

Intel® BayTrail-T™ SoC, Quad Core Intel®
Atom™ Processor Z3770 (2.4 GHz)

36 W

background lighting

Dual digitizer with Glare touchscreen

• F ront: HD camera

• Back: 8 me

1920 x 1

10.51 in. x 7.12 in. x .51 in. (267.0 x 180.8 x 9.9
mm / 16.0 mm) (depending on the back shell)

Active stylus with a pressure button

gapixels, autofocus, mobile light

080 (1080p)

78 Fujitsu

Technical data

Environment class DIN IEC 721

Mechanism class DIN IEC 721

Operating temperature 5 °C .... 35 °C / 41 °F .... 95 °F

Transport temperature (2K2) –15 °C .... 60 °C / 5 °F .... 140 °F

7K1

7M2

WLAN specifications

Type of network

Transfer rate (Automatic switching) IEEE802.11 a an d g: 54

Active frequency • 8 02.11n: 2.4 GHz or 5 GHz

Typical operating distances

Number of ch

Secur

Maximum recommended number of c omputers
to be connected over wireless LAN (during ad
hoc connection)

annels

ity

Broadcom module DWM-W095A

2.4/5GHz Band Wire less LAN
(IEEE802.11a/b/g/n) + Bluetooth (Version

4.0+LE)

Mbps max. data r ate; IEEE802.11n: 300 Mbps
max. data rate

• 802.11b/g: 2400~2473 MHz

• 802.11a: 4900 ~ 5850 MHz

• 8 02.11a: 40 ft. (12 m) @ 54 Mbps; 300 ft.
(91m)@6Mbps

• 8 02.11b: 100 ft. (30 m) @ 11 Mbps; 300 ft.
(91m)@1Mbps

• 8 02.11g: 100 ft. (30 m) @ 54 Mbps; 300 ft.
(91m)@1Mbps

• 8 02.11n: Estimated doub le the operating
distance of 802.11g and 802.11a in their
respective frequencies

• 802.11a: 8 independent chann els

• 802.11b/g: 11 channels, 3 non-overlapping
channels

• 802.11n: Channel bonding takes two of
the non-overlapping 20MHz channels and
combines it into one 40MHz channe l. It is
actually 12 non-overlapping channels with
channel bonding and 24 without. Also, it is
1 non-overlapping channel in 2.4GHz when
channel bonding is used

ption types: WEP, TKIP, AES, WPA 1.0

Encry

A2.0compliant

and WP

yption key, lengths supported: 64 bits and

Encr

its

128 b

nits or less

10 u

Fujitsu 79

Technical data

Rechargeable battery

You can find information on the batteries used in your device on the
Internet at "

Rated voltage 7.2 V

Rated capacity 38 Wh

http://fujitsu.com/fts/support".

3-cell lithium polymer battery 9900 mAh

AC adapter (36 W)

Technicaldata

Rated voltage 12 V

Max. rated current 3 A

An additional AC adapter or AC cable can be ordered at any time.

Docking cradle (optional)

Electrical data

Safety regulations complied with CE

Protection class II

Ports

HDMI 1 x

USB (Universal Serial Bu s) 3 x USB 2.0

Docking port 18-pin

VGA monito

LAN port 1 x

Ambient

Environment class DIN IEC 721

Mechanism class DIN IEC 721

Opera

Tran

rport

conditions

ting temperature

sport temperature

1x

7K1

7M2

.. 35 °C / 41 °F .... 95 °F

5°C..

–15 °C .... 60 °C / 5 °F .... 140 °F

80 Fujitsu

Keyboard cover (optional)

Electrical data

Safety regulations complied with CE

Protection class II

Ports

Docking port 18-pin

Tou chpad Yes

Ambient conditions

Environment class DIN IEC 721

Mechanism class DIN

Operating temperature 5 °C .... 35 °C / 41 °F .... 95 °F

Transport temperature

IEC 721

7K1

7M2

–15 °C .... 60 °C / 5 °F .... 140 °F

VESA mount (optional)

Dimensions

Width x Depth x Height

Weight

230 mm x 138 m m x 14.1 mm / 9.06 in. x 5.43
in. x 0.56 in.

90 g / .198 bs.

Technical data

Shoulder strap (optional)

Dimensions

Width x Depth x Height

Weight

49.80 in. x .98 in. x 0.189 in. (1265 mm x 25

mm x 4.8 mm)

Approx.

.074 lbs. (33.4 g)

Folio case (optional)

Dimensions

Width x Depth x Height

Weight

Fujitsu 81

18.11 in. x 10.75 in. x 0.63 in. (460 mm x 273

mm x 16 mm)

Approx. .86 lbs. (390 g)

Technical data

USB adapters

Adapter Length Max. res olution

Micro USB to USB adapter

Micro USB to HDMI adapter

Micro USB to VGA adapter

Micro USB to D isp l a y Port
adapter

Micro USB to LAN adapter

6 inches

6 inches 1920 x 1080

6 inches 1920 x 1080

6 inches 1920 x 1080

6 inches

N/A

N/A

82 Fujitsu

Manufacturer’s notes

Manufacturer’s notes

Disposal and recycling

Notes

You can find information on this subject on your notebook or on our website

http://solutions.us.fujitsu.com/www/content/products/trade-in_program/").

("

Recycling your battery

Over time, the batteries that run your mobile computer will begin to hold a charge for a
shorter amo unt of time; this is a natural occurrence for all batteries. When this occurs,
you may want to replace the battery with a fresh one*. If y ou re place it, it is important
that you dispose of the old battery properly because batteries contain materials that
could cause environmental dam age if disposed of improperly.

Fujitsu is very concerned with environmental protection, and has enlisted the services of the
Rechargeable Battery Recycling Corporation (RBRC)**, a nonprofit public service organization
dedicated to protecting our environment by recycling old batteries at no cost to you.

RBRC has drop-off points at tens of thousands of locations throughout the United States and
Canada. To find the location nearest you, go to "

If there are no convenient RBRC locations near you, you can also go to the EIA Consumer
Education Initiative website "

Remember – protecting the environment is a cooperative effort, and we must
make every effort to protect it for current and future generations.

* To order a new battery for your Fujitsu mobile computer, go to the Fujitsu shopping site

www.shopfujitsu.com" in the US or "www.fujitsu.ca/products/notebooks" in Canada.

at "

** RBRC is an independent third party to which Fujitsu provides funding for
battery recycling; RBRC is in no way affiliated with Fujitsu.

http://EIAE.org/ " and search for a convenient disposal location.

www.RBRC.org" or call 1-800-822-8837.

Declarations of Conformity

ionofconform ity

Declarat

This device complies with Part 15 of the FCC rules. Operations are subject to the following two
conditions: (1) This device may not cause harmfu l interference, (2) This device must accept any
interference received, including interferen ce that may cause undesired operation.

Fujitsu 83

Manufacturer’s notes

Regulatory notices

FCC Notices

Regulatoryinformation

NOTICE:

Changes o r modifications not expressly ap proved by F ujitsu could void this
user’s authority to operate the equipment.

Notice to Users of Radios and Television

These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:

• R eorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• C onnect the equipment into an outlet that is on a different circuit than the receiver.

• C onsult the dealer or an experienced radio/TV technician for help.

DOC (Industry CAN

ANADA)NOTICES

DOC(INDUSTRYC

ADA) notice

Radios and Television

This Class B digital apparatus meets all requirements of Canadian Interference-Causing Equipment
Regulations.

CET appareil numérique de la class B respecte toutes les exigence du Réglement
sur le matérial brouilleur du Canada.

UL Notice

This unit r equires an AC adapter to operate. Only use UL Listed I.T.E. adapters with an output rating
of 19 VDC, with a minimum current of 3.42 (65W). The correct outpu t rating is indicated on the
AC adapter label. Refer to the illustration below for the correct AC Adapter output polarity:

When using your notebook equipmen t, basic safety precautions should always be followed to
reduce the risk of fire, electric s hock and injury to persons, including the following:

• D o not use this product near water for example, near a bathtub, washbowl, kitchen
sink or laundry tub, in a wet basement or near a swimming pool.

• U se only the power cord and batteries indicated in this manual. Do not dispose of batteries in a
fire. They may explode. Check with local codes for possible special disposal instructions.

84 Fujitsu

Manufacturer’s notes

For Authorized Repair Technicians Only

CAUTION:

For continued protection against risk of fire, replace only with the
same type and rating fuse.

WARNING:

Danger of explosion if Lit
with the same or equivalen

Dispose of used batterie

FCC Regulatory information

Regulatoryinformation

hium (CMOS) battery is incorrectly replaced. Replace only

t type recommended by the manufacturer.

s according to the manufacturer ’s instructions.

Federal Communications Commission statement

This device complies with Part 15 of FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause interference, and

(2) this device must accept any interference, including interference that may
cause undesired operation of this device.

FCC Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate rad io frequency energy. If not installed and used in accordance with
the instructions, it may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the distance between the equipment and the receiver.

3. Connect the equipment to an ou tlet on a circuit different from the one the receiver is connected to.

4. Consult the dealer or an experienced radio/TV technician for help.
Please note the following regulatory information related to the optional radio device.

FCC Radio Frequency Exposure statement

This radio device has been evaluated under FCC Bulletin OET 65C and found compliant with the
requirements as set forth in CFR 47 Sect ions 2.1091, 2.1093, and 15.247 (b) (4) addressing RF
Exposure from radio frequency devices. The radiated output power of this radio device is far below
the FCC radio frequency exposure limits. Nevertheless, this device shall be used in such a manner
that the pot ential for human contact during normal operation is minimized. When using this device, a
certain separation distance between antenna and nearby persons must be maintained to ensure RF
exposure compliance. In order to comply with RF exposure limits established in the ANSI C95.1
standards, the distance between the antennas and the user should not be less than 20 cm (8 inches).

Regulatory Notes and Statements
Radio device, health and authorization for use

Fujitsu 85

Manufacturer’s notes

Radio-frequency electromagnetic energy is emitte d from the wireless devices. The energy levels
of these emissions, however, are far much less than the electromagnetic energy emissions from
wireless devices such as mobile pho nes. Radio devices are s afe for use by consumers because
they operate within the guidelines found in radio frequen cy safety standards and recommendations.

The use of the radio devices may be restricted in some situations or environments, such as:

• on board an airplane, or

• in an explosive environment, or

• in situations where the interference risk to othe r devices or services is
perceived or identified as harmful.

In cases in which the policy regarding use of radio devices in specific environments is not
clear (e.g., airports, hospitals, chemical/oil/gas industrial plants, private buildings), obtain
authorization to use these devices prior to operating the equipment.

Regulatory Information/Disclaimers
Export restrictions

This product or software contains encryption code which may not be exported or
transferred from t he US or Canada without an approved US Department of Commerce
export license. This device complies with Part 15 of FCC Rules, as well as ICES 003 B /
NMB 003 B. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference
that may cause undesirable operation.

Modifications not expressly authorized by Fujitsu may invalidate the user’s
right to operate this equipment.

86 Fujitsu

Manufacturer’s notes

ENERGY STAR Compliance

Your Fujitsu system is an ENERGY STAR qualified mobile PC. By choosing a computer with the
latest energy-saving technology, you’re helping to preserve our environment for future generations.
ENERGY STAR is a joint program of the U.S. Environmental Protection Agency, U.S. Department
of Energy, Na tural Resources Canada, and other governments around the world helping us save
money while protecting the environment through energy efficient products and practices. With
energy costs and global warming top-of-mind for consumers, Fujitsu is committed to offering
solutions that help consumers conserve energy and improve the quality of our environment.

Sleep Mode:

You will notice that your computer is initially set so that the display turns off after 15 minutes of
user inactivity, and the computer goes into Sleep mode after 20 minutes of user inactivity. When
going into Sleep mode, the computer also reduces the speed of any active Ethernet network
links. To “wake” the computer from Sleep mode, press the Suspend/Resume Button.

Energy saving benefits:

Fujitsu ENERGY STAR qualified mobile PCs use about half as much electricity as standard
equipment – saving half in utility costs. But more than that, ENERGY STAR also makes a difference
for the environment. Did you know that the average house can be responsible for twice the
greenhouse gas emissions as the average car? That’s because every time you flip on a light
switch, run your dishwasher, or turn on your PC, you use energy, which means more greenhouse
gas emissions from power plants. So the more energy we can save through energy efficiency,
the more we help to reduce greenhouse gases and the risks of global warming.

To learn more abou t the important ENERGY STAR program, visit:"

To read about how Fujitsu is supporting Sustainable Management along with
several other environmental activities, visit the Fujitsu Corporate Citizenship page at:

http://www.computers.us.fujitsu.com/www/content/aboutus/environmental/environment.php".

"

www.energystar.gov".

Fujitsu 87

Appendix

Appendix

Image Backup and Recovery Procedures

Thank you for pu rchasing a Fujitsu computer. Fujitsu is committed to bringing you
the best computing experience with your new system.

It is very important that you create DVD copies of yo ur Recovery Image and Bootable Disk
before beginning to use your system. To do so, follow the instructions in the “Creating a
Backup of Bootable Disk and Recovery Image” section of this document.

It is also important that you create a copy of the software that is essential for your system to access the
internet (hereafter c alled “essential access software”) to external writable media or an external drive.
To do so, follow the instructions in the “Creating a Backup of the System-Specific Software Drivers”.

Creating a Backup of Bootable Disk and Recovery Image

When you purchased your new system, a copy of the recovery image was loade d into a
hidden partition on your hard disk drive. Having a copy of the recovery image available to
you means that in the event of system failure, you will be able to restore it and re-install
the essential access software using Fujitsu Software Auto Installer.

To make a copy of the recovery image to DVD d isks, you will need three or four blank
disks to create the copy. After creating the copy, be sure to label the disks and keep
them in a safe place to ensure they do not get damaged.

Note: If your system does not have an internal writable DVD drive, conne ct your
system to an external drive* before beginning the following steps.

1. Launch Syste
the Bootabl

2. On “Step 1: Select the Bootable Disk from the list”:
a. Select a
b. Notice the number of disks that are needed for the set.
c. Click N

3. On “Step 2: Confirm your Recovery Disk”, click Next .

4. On “Step
Start.I

5. On “Step 4”, when the disk creation is completed, a message appears.
Click Finish to exit the program.

6. Repea
steps

* DEPENDING UPON YOUR OPTICAL DRIVE AND MEDIA FORMAT USED, S OM E MEDIA
TYPES M AY BE INCOMPATIBLE FOR CREATING IMAGE BACKUPS.

88 Fujitsu

m Restore and Recovery from the desktop icon. It will allow you to create

e Disk and the Recovery Image Disk Set.

media type.

ext to proceed.

3:” follow the on-screen instructions to make the disk or disk set, then click

t takes approximately 20 minutes to make one disk.

t Step 1: Select Recovery Disk from the list and repeat the above

2(a), 2(b), 2(c), 3, 4 and 5 .

Appendix

Creating a Backup of Essential Access Software

When you purchased your new system, a “Fujitsu Software Extractor” shortcut was loaded to
“C:\Fujitsu\Drivers\AutoInstaller\”. This shortcut allows you to save the software driver packages
along with the extracted Auto Installer software package to a selected location. It is recommended
that you sa ve these packages to writable media or an external drive. This ensures that in the
event of system failure you will be able to re-install the essential access software.

1. Open the C:\Fujitsu\Drivers\AutoInstaller\ folder

2. Run “Fujitsu S o ftware Extractor” as an Administrator
a. Right-click on Fujitsu Software Extractor.
b. Select the “Run as Administrator” option from the menu that is displayed.

3. The default save location is C:\Fujitsu\ AutoInstaller\ Drivers\. You can change the location
by clicking on the Browse button and selecting your preferred location.

Note: It is recommended that you change the default location and save the
software packages to the external writable media or drive.

4. Click on the Save Packages button.

5. Fujitsu Software Extractor copies the zipped software packages and Readme files,
and extracts the Auto Installer folder to the selected location.

Note: The extracted Auto Installer will later be used to install the software
automatically on the system in the event of generic image restoration when
the software is not pre-installed in the image.

RECOVERYOURSY

STEM WHEN THE HARD

DRIVE IS STILL ACCESSIBLE

Using the Recovery and Utility Tools

The Recovery and Utility tools consist of a variety of tools that will help you recover your
recovery image and system images, and delete the data from your hard disk.

Methods for accessing the utilities

Recovery and Utility Tools are preinstalled in a hidden partition by the factory, or
they can be accessed by using the bootable disk.

Note: The Recovery and Utility tools may be deleted from y our hard disk
drive if you modify the partitions. If that occurs, you will not be able to
use the hidden partition for booting to Recovery and U tility Tools, but you
will still be able to boot from the Bootable Disk.

Fujitsu 89

Appendix

Determining whether Recovery and Utility is pre-loaded

1. Turn on or reboot your system. When the Fujitsu logo appears, press the

Tab

2. Use the

key to get to the Application Menu.

3. Check whether the Recovery and Utility option is present. If it is not present, it means
that the utility must be used from the Bootable Disk. Proceed to “Running Recovery and
Utility from the Bootable Disk” if Recovery and Utility is unavailable.

F12

key.

Running Recovery and Utility from hard disk

1. Turn on or reboot your system. When the Fujitsu logo appears, press the

Tab

2. Use the

3. Cursor down to Recovery and Utility and press the

key to get to the Application Menu.

Enter

key.

4. Choose your language, if necessary. Select Recovery and Utility to proceed.

5. Three tool options appear: Diagnostics, Recovery,andUtility (refer to the Recovery and
Utility tools section below for instructions on how to use these tools).

6. If this was successful please skip the next step and go to “Recovery and Utility tools.”

7. If this was NOT successful, please go to the next step.

F12

key.

Running Recovery and Utility from the Bootable disk

To verify/change the boot-up priority (rather than booting-up from the hard drive or
an external media drive), perform the following steps:

Enter

F12

.

1. Power on your syst em. When the Fujitsu logo appears on the screen, press the

2. Insert the bootable disk into the drive tray.

3. Highlight the CD/DVD option from the Boot menu , then press

Enter

.

4. Click OK.

5. Select CD/DVD boot mode: UEFI Mode, if applicable, and then press
While the files are being loaded from the disk, the Fujitsu logo screen will appear
followed by a progress bar at the bottom of the screen.

key.

90 Fujitsu

Appendix

Recovery and Utility tools

Note: Recovery and Utility tools may not be available on your system depending
on the region from which the system was shipped.

Diagnostics tool: The Diagnostics tool is designed for use by IT professionals. It is not likely you
will need to use this tool. If you should need to use this tool, perform the following steps:

1. Press the Diagnostics Tool button to start the Diagnostics tool.

2. Read the note, and then click OK.

3. Choose one or more of the following options for diagnostics on the Fujitsu Hardware Diagnostics
Tool window: CPU, Memory, D isplay, Hard Disk, CD/DVD/BD, Floppy Disk, Keyboard, and Mouse.

4. Click the Option button in the Tool menu to specify how many times the tool
should run diagnostics on each selected component.

5. Press Execute to start the Diagnostics tool.

6. After the execution is completed, the selected components are circled in red to indicate that they
have been diagnosed and the result dialog window opens. Click Close to close the w indow.

7. Click End to close the Diagnostics tool, and then click Yes to confirm the end of diagnostics session.

Recovery tool: The Recovery tool contains two options:

• Restore C Drive: Restore recovery image (only C: drive)

• Restore Full Hard Drive: Restore recovery image (full hard drive).

You can use these tools to restore the Recovery Image from the hidden partition, and perform a full
hard drive recovery. Please refer to instructions above for details on how to create a Recovery Image.

Restore the Re

1. Click [Restore C: drive] from Recovery and Utility tools

2. The progress
confirming t

3. Read the instruction screen and select Agree,thenclickNext.

4. Click OK to

5. When the progress bar appears, wait for the process to complete.

6. Click Fin

7. Follow the steps listed in the “Auto Installation support for software packages
from hidden partition” section.

8. Downloa
all the

9. Follow the steps listed in “Auto Installation support for software packages
downloaded from support website” section.

Fujitsu 91

hat the Image will be restored to the C: drive. Click Next.

ish when the process completes; the computer will restart to Windows.

d FSDM (Fujitsu Software Download Manager) from the support site and download

software applicable to the model and OS using FSDM.

covery Image from Hidden Partition

bar is followed by “Restore Recovery image (only C: driv e)” screen

acknowledge the warning message to restore recovery image to the C: drive.

Appendix

RECOVER YOUR SYSTEM WHEN THE HARD DRIVE IS NOT BOOTABLE

Restore the Recovery Image for Full Hard Drive

Follow the steps in the “Recovering your Recovery Image using Recovery and
Utility (for new hard drive or non-bootable hard drive)” section. You will need the
Bootable Disk and the Recovery Disk Set for this task.

Utility tool: If applicable for your region, the Utility tool contains two options:
Hard D isk Data Delete and Partition Creation.

The Hard Disk Data Delete utility is used to delete all data on the hard disk
and prevent the data from being reused.

NOTE: Do not use the Hard Disk Data Delete utility unless you are absolutely certain
that you want to erase your entire hard disk, including all partitions.

To delete hard disk data:

1. Click the Hard Disk Data Delete button. The progress bar appears, followed by the EULA screen.

2. Agree to the EULA and click Next.

3. Choose the hard disk from which the data should be deleted in the list of hard disks and click Next.
The Partition Creation utility is used to change the C: and D: drive partition sizes.

To run this utility: (This is not an option when using Windows 7.)

1. Click the Partition Creation button.

2. A progress bar appears, followed by the EULA screen. Agree to the EULA.

3. On the Recovery Tool - Partition Creation screen, move the slider to set disk size, and then click OK.

4. Click Yes in the Partition Creation confirmation dialog.

WARNING: It is highly recommended that you send your product to Fujitsu
Service to replace a hard drive. A mistake could possibly destroy your
computer, your new hard drive or both.

92 Fujitsu

Appendix

Recovering Your Recovery Image Using Recovery and Utility
(for new hard drive or non-boot

If you have installed a new hard drive or your hard drive is not boo table, perform the following steps.

Note: You will need the Bootable disk and Recovery Image disk set for this recovery.

able hard drive)

Enter

Enter

.

1. Power on your system. When the Fujitsu logo appears on the screen, press the

2. Insert the bootable disk in your DVD drive, then click OK.

3. Highlight the CD/DVD option from the Boot Menu and press

4. Select CD/DVD boot mode: Select UEFI Mode, if applicable and press
While the files are being loaded from the disk, the Fujitsu logo screen appears
followed by a progress bar at the bottom of the screen.

5. Choose your language, if necessary.

6. Three tool options appear: Diagnostics, Recovery and Utility. Select Recovery.

• For Windows 8.1: Select Restore full hard drive

• For Windows 7: Select Restoring the Factory Image (full hard drive recovery)

7. Click Next to confi rm full hard drive restoration. All data on HDD will be deleted.

8. Agree to EULA by selecting Agree option and clicking Next.

9. Click Next on the Recovery Disk Check screen to verify that the bootable
disk has been inserted into the optical drive.

10. The Checking for Recovery Disk screen appears followed by the prompt to insert the
first disk. Click OK to continue. Repeat this step for all disks. After all recovery disks
have been checked an d the check has been completed, click Next.

11. Follow the prompt to reinsert the first recovery disk and click Next.

12. Click OK when you receive the final warning inform ing you that all data on drive
C will be lost. T his starts the recovery process.

13. Follow the prompts to insert the next recovery disks and click OK.

14. After the copying of the image to the H DD completes the restore process is
complete, clic k Finish to restart the system. The computer will restart automatically
and then go through the firstbootprocess.

15. Follow the steps listed in “Auto Installation support for essential access
software from backup location” section.

16. Download FSDM (Fujitsu Softw are Download Manager) from support s ite and download
all the software applicable to the model and OS using FSDM.

17. Follow the steps listed in “Auto Installation support for essential access
software downloaded from support w ebsite.

Enter

.

key.

Fujitsu 93

Appendix

Installing the Software after the Recovery Image is Restored

Auto-installation support for essential access software
from hidden partition

The below listed steps are applicable only in cases in which the recovery image restore
and hidden partition contents have not been wiped out.

1. After the recovery image is restored, launch the desktop icon “Fujitsu Software Auto Installer”.

2. Double-click on “Fujitsu Software Auto Installer” d esktop icon.

3. Click Yes on User Account Control Dialog box. This will take some time to

process the software packages. A message will be displayed during this time,
“Please wait while the content is being processed”.

4. If EULA is displayed for Fujitsu Software A uto Installer, accept the EULA, otherwise continue.

5. Then Fujitsu Software Auto Installer user interface will be l aunched providing ability
to auto-install the essential access software o n the system.

6. It is recommended tha t you install all the software in the listed order. You can
Select All, to install the software in the order listed.

7. Click Install to start the installation.

8. After installing all the selected drivers, Installation Results window w ill be displayed. Click OK .

9. “You must restart the system for the settings to take effect. Do you wish to
reboot now?” message appears. Select Yes.

10. T he system will now reboot.

11. You can now connect to the internet and download FSDM (Fujitsu Software Download
Manager) from the support site and download all the software applicable to the
model and OS using FSDM if they are not downloaded yet.

94 Fujitsu

Appendix

Auto-installation support for essential access software
from backup location

The below listed steps are applicable in cases in which a backup copy was created as
mentioned in the section “Creating a Backup of essential access software”.

1. It is important to have the extracted Auto installer software package folder
and Readme file in the same location as other software folders. Otherwise
auto-installation of the software will not be supported.

2. Inside the Auto Installer software package, launch FjAutoinstall.exe as an Administrator.

3. Click Yes on the User A cco unt Control dialog box. This will take some time to
process the software packages. A message will be displayed during this time stating,
“Please wait while the content is being processed”.

4. If EULA is displayed for Fujitsu Software Auto In staller, accept the EULA, otherwise continue.

5. The Fujitsu Software Auto Installer user interface will be launched providing ability
to auto install the essential access software on the system.

6. It is recommended that you install all the software in the listed order. You can
“Select All”, to install the software in the order listed.

7. Click the Install button to start the installation.

8. After installing all the selected drivers, Installation Results window is be displayed. Click OK.

9. “You must restart the system for the settings to take effect. Do you wish to
reboot now?” message appears. Select Yes.

10. The system will now reboot.

Auto Installation support for the software downloaded from support website

1. Download FSDM (F ujitsu Software Download Manager) from the support site and download all
the drivers applicable to the model and OS using FSDM if they are not downloaded yet.

2. When the software packages are downloaded from web, it is important to download
the Auto Installer Software package and the model/language- specific Readme
file if you prefer to auto install the software.

3. It is important to ha ve the extracted Auto Installer software package folder
and Readme file in the same location as other software folders. Otherwise
auto-installation of the software will not be supported.

4. Inside the Auto Installer software package, launch FjAutoinstall.exe as administrator.

5. Click Yes on the User A cco unt Control dialog box. This will take some time to
process the software packages. A message will be displayed during this time stating
“Please wait while the content is being processed”.

6. If EULA is displayed for Fujitsu Software Auto In staller, accept the EULA, otherwise continue.

7. The Fujitsu Software Auto Installer user interface will be launched providing the a bility
to auto install the software downloaded from support site.

8. It is recommended that you install all the software in the listed order. You can
Select All, to install the softw are in the order listed.

9. Click the Install button to start the installation.

10. After installing all the selected drivers, the Installation Results window is displayed. Click OK.

11. “You must restart the system for the settings to tak e effect. Do you wish to
reboot now?” message appears. Select Yes.

12. The system will now reboot.

Fujitsu 95

Appendix

Downloading Driver Updates

To ensure that you always have the most current driver updates related to your system,
occasionally access the Fujitsu Software Download Manager (FSDM) utility. The FSDM
utility is available from the Fujitsu Support site. FSD M will allow you to view and
download a list of the most current drivers, utilities, and applications to determine whether
you have the latest versions. To download the FSDM Utility, go to the Support Site:

http://support.fujitsupc.com/CS/Portal/support.do?srch=DOWNLOADS".

"

If you are planning on downgrading, upgrading or changing versions of your operating system during
this process please see the User’s Guide for more information at "

http://solutions.us.fujitsu.com".

96 Fujitsu

Index

Index

A

AC adapter

connecting 18
Set up 18

Acoustic w arnings 76
Audio c onnections 66

B

Battery 35

battery charge 36
Caring for and maintaining 35
charge level 35
Charging 35
Discharges too quickly 74
see Rechargeable battery 35
Service life 35

battery charge meter 35
BIOS Setup Utility

, protecting with password 58
calling 67
exiting 69
operation 68
Settings 67

Bluetooth, S afety notes 12

C

Charging back-up b attery 71
Choose a location 18
Configuration, BIOS Setup Utility 67
Configuring hardware 67
Configuring system 67
Connecting audio devices 66
Connecting headphones 66
Cradle 43

Connecting a Tablet PC 44

D

dark touchscreen 71
Date not correct 71
Declaration of conformity 83
Devices,

connecting 63
disconnecting 63

Display orientation

select 25

DOC (INDUSTRY CANADA) NOTICES 84

E

Ending

energy saving mode 73

Energy

Energy consumption 36
Energy saving 13

Energy saving functions 36
