User’s Guide

Learn how to use your Fujitsu STYLISTIC Q552 Tablet PC



Guide

d’utilisation

Découvrez comment utiliser votre ordinateur portable Fujitsu STYLISTIC Q552

User’s

Guide

Learn how to use your

Fujitsu STYLISTIC® Q552 Tablet PC

Fujitsu America, Inc.has made every effort to ensure the accuracy and completeness of this document. Because ongoing development efforts are made to continually improve the capabilities of our products, however, the data contained herein represents Fuj itsu design objectives and is provided for comparative purposes; actual results may vary based on a variety of factors. This product data does not constitute a warranty. Specifications are subject to change without knowledge.

Fujitsu and the Fujitsu logo are registered trademarks of Fujitsu Limited; STYLISTIC is a registered trademark of Fujitsu America, Incorporated.

Microsoft and Windows are registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. The SD Logo is registered with the U.S. Patent and Trademark Office and with other trademark offices around the world by SD-3C, LLC. Intel, Intel Core, and Intel Atom are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. OmniPass is a trademark of Softex, Inc. Broadcom is a registered trademark of Broadcom Corporation. Norton Internet Security is a trademark of Symantec Corporation in the United States and other countries.

AirPrime is a trademark of Sierra Wireless Inc.

Gobi3000 is a trademark of Qualcomm Inc.

N-act and N-trig are either registered trademarks or trademarks of N-trig Ltd.

Adobe and Adobe Reader are registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.

Ralink is a registered trademark of Ralink Technology Corporation.

Bluetooth and the Bluetooth logo are registered trademarks of Bluetooth SIG, Inc.

Realtek is a trademark of Realtek Semiconductor Corp.

Wi-Fi is a trademark of the Wireless Ethernet Compatibility Alliance (WECA).

All other products are trademarks or registered trademarks of their respective companies. All other trademarks mentioned herein are the property of their respective owners.

Copyright 2012 Fujitsu America, Incorporated. All rights reserved. No part of this publication may be copied, reproduced, or translated, without the prior written consent of Fujitsu America, Incorporated. No part of this publication may be stored or transmitted in any electronic form without the prior consent of Fujitsu America, Incorporated. B6FJ-8821-01ENZ0-00

USER GUIDE FOR WIRELESS BROADBAND CONNECTION

IF YOU HAVE THE OPTIONAL WIRELESS WAN (WWAN) DEVICE INSTALLED IN YOUR TABLET PC, THE WWAN USER’S GUIDE IS LOCATED AT:

http://solutions.us.fujitsu.com/www/content/support/mobile/support_notices

LEASE CLICK “3G MINI-CARD GOBI3000 REGULATORY AND SAFETY INFORMATION” TO OPEN THE FULL USER GUIDE CONTAINING WARNINGS AND

PRECAUTIONS ASSOCIATED WITH RF SAFETY WHEN USING THE WWAN DEVICE.

DECLARATION OF CONFORMITY

according to FCC Part 15

Responsible Party Name: Fujitsu America, Inc.

Address: 1250 E. Arques Avenue

Sunnyvale, CA 94085

Telephone: (408) 746-6000

Declares that product: Base Model Configuration: STYLISTIC Q552 Tablet PC

Complies with Part 15 of the FCC Rules.

This device complies with Part 15 of the FCC rules. Operations are subject to the following two conditions:

(1) This device may not cause harmful interference, (2) This device must accept any interference received, including interference that may cause undesired operation.

IMPORTANT SAFETY INSTRUCTIONS

AC adapter output polarity:

This unit requires an AC adapter to operate. Use only UL Listed I.T.E. Class II Adapters with an output rating of 19 VDC, with a current of 2.1A (40 W).

When using your tablet PC, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following:

CAUTION: HOT SURFACE: THE BOTTOM OF THIS COMPUTER CAN BECOME HOT WHEN USED FOR LONG PERIODS OF TIME. WHEN USING THIS

DEVICE, TAKE CAUTION TO LIMIT LONG TERM OR CONTINUOUS USE WHILE RESTING IT ON EXPOSED SKIN, SUCH AS THE LAP.

• Do not use this product near water for example, near a bathtub, washbowl, kitchen sink or laundry tub, in a wet basement or near a

swimming pool.

• Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with local

codes for possible special disposal instructions.

SAVE THESE INSTRUCTIONS

For Authorized Repair Technicians Only

ANGER OF EXPLOSION IF LITHIUM (CLOCK) BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE

RECOMMENDED BY THE MANUFACTURER. DISPOSE OF USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTION.

OR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY WITH THE SAME TYPE AND RATING FUSE.

Recycling your battery

Over time, the batteries that run your mobile computer will begin to hold a charge for a shorter amount of time; this is a natural occurrence for all batteries. When this occurs, you may want to replace the battery with a fresh one*. If you replace it, it is important that you dispose of the old battery properly because batteries contain materials that could cause environmental damage if disposed of improperly.

Fujitsu is very concerned with environmental protection, and has enlisted the services of the Rechargeable Battery Recycling Corporation (RBRC)**, a non-profit public service organization dedicated to protecting our environment by recycling old batteries at no cost to you.

RBRC has drop-off points at tens of thousands of locations throughout the United States and Canada. To find the location nearest you, go to www.RBRC.org

or call 1-800-822-8837.

If there are no convenient RBRC locations near you, you can also go to the EIA Consumer Education Initiative website (http://EIAE.org/ search for a convenient disposal location.

Remember – protecting the environment is a cooperative effort, and you should make every effort to protect it for current and future generations.

* To order a new battery for your Fujitsu mobile computer, go to the Fujitsu shopping site at www.shopfujitsu.com

www.fujitsu.ca/products/notebooks

** RBRC is an independent third party to which Fujitsu provides funding for battery recycling; RBRC is in no way affiliated with Fujitsu.

in Canada.

in the US or

) and

Contents

About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Conventions Used in the Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Fujitsu Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Chapter 1 Getting to Know Your Tablet PC

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Locating the Connectors and Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Front Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Back Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Status Indicator Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Display Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Adjusting Display Panel Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Active Digitizer/Touchscreen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Active Digitizer Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Using the Capacitive Touchscreen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Using N-act™. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Accessing the OnScreen TouchPad. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Caring for the Pen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Tablet PC Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Chapter 2 Getting Started with Your Tablet PC

Power Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Connecting the Power Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Starting Your STYLISTIC Tablet PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Power On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Boot Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Hard Disk Drive Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

BIOS Setup Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Booting the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Starting Windows the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Power/Suspend/Resume Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Sleep Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Hibernation Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Windows Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Restarting the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Powering Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Chapter 3 User-Installable Features

Lithium Polymer Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Recharging the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Replacing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Secure Digital Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Installing SD Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Removing an SD Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Chapter 4 Troubleshooting Your Tablet PC

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Identifying the Problem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Specific Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Power On Self Test Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Restoring Your Pre-installed Software . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Chapter 5 Care and Maintenance

Caring for your Tablet PC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Cleaning your Tablet PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Storing your Tablet PC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Traveling with your Tablet PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Media Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Secure Digital Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Chapter 6 System Specifications

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Configuration Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Microprocessor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Chipset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Mass Storage Device Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Security Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Device Ports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Dimensions and Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Environmental Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Popular Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Included Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Learning About Your Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Glossary/Regulatory

Glossary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Appendix A: WLAN User’s Guide

Before Using the Optional Wireless LAN. . . . . . . . . . . . . . . . . . . . . . . . . . 93

Wireless LAN Device Covered by this Document . . . . . . . . . . . . . . . . . . . 93

Characteristics of the WLAN Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Wireless LAN Modes Using this Device. . . . . . . . . . . . . . . . . . . . . . . . . . . 94

Deactivating/Disconnecting the WLAN Device. . . . . . . . . . . . . . . . . . . . . 96

Deactivation Using the Wireless On/Off Switch . . . . . . . . . . . . . . . . . . . . 97

Disconnection Using the Icon in the Taskbar. . . . . . . . . . . . . . . . . . . . . . 97

Activating the WLAN Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Configuring the Wireless LAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Configuring the WLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Connection to the network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Troubleshooting the WLAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

WLAN Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Using the Bluetooth Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

What is Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Where to Find Information About Bluetooth . . . . . . . . . . . . . . . . . . . . . . 103

Appendix B: Fingerprint Sensor Device

Introducing the Fingerprint Sensor Device . . . . . . . . . . . . . . . . . . . . . . . . 104

Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Installing OmniPass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

User Enrollment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

Using OmniPass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

Configuring OmniPass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

OmniPass Control Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Appendix C: FujitsuHL User Guide

FujitsuHL Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Starting FujitsuHL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Closing FujitsuHL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

About FujitsuHL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Home Launcher. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

Gadget Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

Launcher Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

Photo Launcher. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

Documents Launcher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Camera Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Photo Viewer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

Preface

About This Guide

The STYLISTIC® Q552 Tablet PC is a high-performance pen-based computer that has been designed to support Microsoft®Windows® 7 Professional edition.

This manual explains how to operate your Tablet PC hardware and built-in system software. The STYLISTIC Q552 Tablet PC is a completely self-contained unit with a 10.1” WXGA LED backlit IPS display with 160

degree vertical and horizontal viewing angles. It has a powerful interface that enables it to support a variety of optional features.

Conventions Used in the Guide

Pages with additional information about a specific topic are cross-referenced within the text. On screen buttons or menu items appear in bold. Example: Click OK to restart your Tablet PC.

THE INFORMATION ICON HIGHLIGHTS INFORMATION THAT WILL ENHANCE YOUR UNDERSTANDING OF THE SUBJECT MATERIAL.

HE CAUTION ICON HIGHLIGHTS INFORMATION THAT IS IMPORTANT TO THE SAFE OPERATION OF YOUR COMPUTER, OR TO THE INTEGRITY OF YOUR

FILES. PLEASE READ ALL CAUTION INFORMATION CAREFULLY.

THE WARNING ICON HIGHLIGHTS INFORMATION THAT CAN BE HAZARDOUS TO EITHER YOU, YOUR TABLET PC, OR YOUR FILES. PLEASE READ ALL

WARNING INFORMATION CAREFULLY.

Fujitsu Contact Information

Service and Support

You can contact Fujitsu Service and Support in the following ways:

• Toll free: 1-800-8FUJITSU (1-800-838-5487)

• Website:

U.S.A. - us.fujitsu.com/solutions Canada - www.fujitsu.ca

Before you place the call, you should have the following information ready so that the customer support representative can provide you with the fastest possible solution:

• Product name

• Product configuration and serial numbers

• Purchase date

• Conditions under which the problem occurred

• Any error messages that have occurred

• Type of device connected, if any

- About This Guide

Fujitsu Shopping Online

You can go directly to the online by going to the website at: www.shopfujitsu.com.

Maintaining Latest Configuration

To ensure that you always have the most current driver updates related to your system, you should occasionally access the Fujitsu Software Download Manager (FSDM) utility. The FSDM utility is available from the Fujitsu Support site. FSDM will allow you to view a list of the most current drivers, utilities, and applications to determine whether you have the latest versions. If you have a Windows 7 operating system, you will need to go to the Support Site to download the FSDM Utility: http://support.fujitsupc.com/CS/Portal/support.do?srch=DOWNLOADS.

Limited Warranty

Your STYLISTIC Q552 Tablet PC is backed by a Fujitsu International Limited Warranty. Check the service kit that came with your tablet PC for the Limited Warranty period and terms and conditions.

- About This Guide

Chapter 1

Getting to Know Your Tablet PC

Overview

The STYLISTIC® Q552 Tablet PC is a highperformance pen-based computer that has been designed to support Microsoft® Windows® 7 Professional edition.

This chapter provides an overview of the STYLISTIC Q552 Tablet PC and its many features.

Figure 1. STYLISTIC Q552 Tablet PC

Locating the Connectors and Controls

Front Web Camera

Display

Pen Tether Attachment Point

Wireless Device Switch

Application Buttons

Status Indicators

Power/Suspend/ Resume Switch

DC Input Connector

Speaker

Docking Cradle Connector

Features and controls that you use to operate your Tablet PC are outlined below and illustrated in Figures 2 and 3. Details on using these features and controls are provided later in this manual.

Front Features

Front Web Camera The front-facing VGA web camera allows you to take pictures of yourself to send over the internet. For information

on using the microphone and web cam, see the documentation associated with the FujitsuHL application. See “Appendix C: FujitsuHL User Guide” on page 120.

Figure 2. STYLISTIC Q552 Tablet PC Features (Bottom, Right View)

- Locating the Connectors and Controls

Display

The 10.1” Wide XGA display offers 160 degree vertical and horizontal viewing angles.

Pen Tether Attachment Point

The pen tether attachment point is used to connect your pen -- or stylus -- to the system to prevent its loss.

Wireless Device On/Off switch

The wireless device on/off switch is used to turn the optional WLAN, WWAN, and Bluetooth devices on and off. Switching the device off when not in use will help to extend battery life.

Application Buttons

Allow you to quickly launch pre-defined applications and utilities, rotate your screen, and perform Ctl-Alt-Del by pressing a button. See “Tablet PC Buttons” on page 33.

System Status Indicators

Indicate the operational status of the Tablet PC power and battery charge level. See “Status Indicator Panel” on page 19.

Power/Suspend/Resume Switch

Allows you to turn on, off, sleep, resume, hibernate or wake the Tablet PC in order to optimize battery life. See “Starting Your STYLISTIC Tablet PC” on page 37.

DC input connector:

Allows you to connect the AC adapter or auto adapter.

Speaker

The speaker allows you to hear sound from the system.

Docking Cradle Connector

Allows you to connect the optional STYLISTIC Docking Cradle.

- Locating the Connectors and Controls

Battery Release Latches

Rear Web Camera

SD Card Slot

Fingerprint Sensor

Built-in Microphone

USB 2.0 Port

Smart Card Slot

Line Out/ Headphone Jack

HDMI Port

Built-in Microphone

Removable Battery

Figure 3. STYLISTIC Q552 Tablet PC Features (Back View)

Back Features

Battery Release Latches

Used to release the removable battery.

Rear Web Camera The 3.0 megapixel rear web camera allows you to take pictures of objects in front of you for sharing over the internet.

For information on using the camera, see the documentation associated with the FujitsuHL application. See “Appendix C: FujitsuHL User Guide” on page 120.

- Locating the Connectors and Controls

SD Card Slot

The Secure Digital (SD) card slot allows you to insert a flash memory card for data storage. Flash memory cards allow you to transfer data to and from a variety of different digital devices. See “Secure Digital Cards” on page 50.

Fingerprint Sensor

The fingerprint sensor allows you to start your system by swiping your finger over the sensor. See “Introducing the Fingerprint Sensor Device” on page 104.

Built-in Microphones

The built-in microphones allow you to input analog audio.

USB 2.0 port

Allows you to connect Universal Serial Bus-compliant devices (compliant with USB Standard Revision 2.0) to the Tablet PC. Four additional USB ports are located on the optional STYLISTIC Docking Cradle.

Smart Card Slot

The dedicated Smart Card slot allows you to insert a Smart Card on which you can store such data as medical information or electronic “cash”.

Line Out/Headphone Jack

Allows you to connect a set of stereo headphones.

HDMI Port

The HDMI port is used to connect compatible digital devices with your computer (such as a high-definition television or AV receiver).

Removable Lithium Polymer Battery

Can be removed and replaced with a charged battery. See “Lithium Polymer Battery” on page 45.

- Locating the Connectors and Controls

Status Indicator Panel

Power Charge/DC In

Icons appear under each of the system status LEDs in the status display indicating the status of system power and battery charge status. The location of icons in the Status display is shown in Figure 4.

Table 1 explains how the LEDs associated with the individual icons are displayed, and describes what the variations of that display indicate. (If an icon is not displayed, it indicates that the related system function is off or inactive.

Figure 4. Status Display Icons

- Status Indicator Panel

Table 1. Status Display Conditions

In the following table, a “blinking” LED flashes at the rate of once per second; an LED that is “blinking, slow” flashes at the rate of one second on, five seconds off.

Icon Mode/State LED State Remarks

Power

Charge/DC In

•On State

Blue,

The system is powered on and ready for use.

continuous

• Idle Mode

• Sleep Blue, blinking The system has suspended and saved active settings to RAM.

• Off State

Off The system has suspended and saved settings and data to the

hard disk drive.

•Hibernate

•On State

Green AC adapter and battery are available and charged battery level

is 50-100%.

• Idle Mode Orange AC adapter and battery are available and charged battery level

• Sleep

•Hibernate

Green, blinking Tablet PC is in Suspend mode, AC adapter and battery are

is less than 50%.

available and charged battery level is 50-100%.

• Off State Orange,

blinking

Tablet PC is in Suspend mode, AC adapter and battery are available and charged battery level is less than 50%.

Off The AC Adapter is not available.

- Status Indicator Panel

Figure 5. Tablet PC Display Panel

Display Panel

Your STYLISTIC Q552 Tablet PC contains an LCD display panel that is backlit for easier viewing in bright environments. The slate design of your Tablet PC allows you to easily hold the unit and rotate it 90o, 180o, or 270o in either direction. This display is used as a tablet, much as you would a pad of paper.

Adjusting Display Panel Brightness

To adjust brightness with the power management utility: Click Start -> Control Panel. In View by:, select one of the icon views. Select Display, then click Adjust brightness in

the left pane. Under Select a power plan, select the plan settings you want to use. Drag Screen brightness: bar (at the bottom of the window) to the left or right, depending on your preference.

- Display Panel

Holding the Tablet PC

The STYLISTIC Q552 can be held in any of four orientations, depending upon how you would like to use it. There are primary and secondary landscape orientations and primary and secondary portrait orientations. (The orientation nomenclatures reflect those used in the button utility). When you rotate the system using the Rotation button, the order in which it rotates is illustrated below. Note that when the system is undocked with WWAN, the secondary

landscape orientation is non-functional.

Primary Landscape Orientation

Secondary Portrait

Orientation

*Functional when docked only. When undocked with WWAN, this is nonfunctional

- Display Panel

Secondary Landscape Orientation*

Primary Portrait

Orientation

Active Digitizer/Touchscreen

Active Digitizer Display

The integrated active digitizer allows you to use the included stylus (also called a “pen”) as a pointing device.

(For detailed information about caring for your stylus, go to “Caring for the Pen” on page 30.)

You can use the stylus to click, double-click, drag items and icons, write text, or to draw like a pen or pencil in applications that support this behavior, such as drawing or painting programs. See the documentation that came with your application for details.

Clicking on Active Digitizer Display

To left-click, touch the object you wish to select and then lift the stylus tip immediately.

Figure 6. Using the Active Digitizer Display

- Active Digitizer/Touchscreen

Figure 7. Clicking on the Active Digitizer Display

Right-Clicking on Active Digitizer

Right-click can be accomplished by holding the front of the toggle button down while tapping on the screen. To change the settings for the right-click feature, go to Start

-> Control Panel -> Pen and Touch. In the Pen Options tab, select “Press and Hold” then click the [Settings] button.

• DO NOT USE EXCESSIVE FORCE WHEN TAPPING OR WRITING ON THE SCREEN WITH THE STYLUS. EXCESSIVE FORCE COULD RESULT IN DAMAGE TO

THE LED AND/OR ACTIVE DIGITIZER.

• TO PURCHASE ADDITIONAL OR REPLACEMENT STYLUSES, VISIT THE FUJITSU ACCESSORIES WEBSITE AT: WWW.SHOPFUJITSU.COM.

Double-Clicking

To double-click, touch the item twice, and then immediately remove the stylus tip.

Figure 8. Right-clicking Active Digitizer

- Active Digitizer/Touchscreen

Figure 9. Double-clicking the Display

Dragging

Dragging means moving an item with the stylus by touching the screen, moving and then lifting the stylus. To drag, touch the Active Digitizer Display with your stylus on the item you wish to move. While continuing to touch the screen with the stylus, drag the item to its new location by moving the stylus across the screen, and then lifting the stylus to release it.

Figure 10. Dragging on the Display

Calibrating the Display

In order to ensure accurate tracking between the stylus and cursor, you must run the Calibration Utility before you use the system for the first time, or after you change the display resolution.

To run the calibration utility:

1 Go to Start -> Control Panel. 2 Double-click the Tablet PC Settings icon and select the Display tab 3 Click the [Calibrate] button, then select whether you want to calibrate pen input or touch input. 4 Adjust the display of your Tablet PC to a comfortable angle and find the (+) symbol in the upper-left corner of the

display.

O NOT USE EXCESSIVE FORCE WHEN TAPPING ON THE SCREEN DURING CALIBRATION. USE OF EXCESSIVE FORCE COULD RESULT IN DAMAGE TO THE

LED

AND/OR TOUCH PANEL.

- Active Digitizer/Touchscreen

5 Using the stylus or your finger (depending upon which type of input you are calibrating), firmly touch the screen

directly on the (+) symbol. Lift the stylus from the screen and the target will move to a different screen location.

6 Repeat step 5 until you have selected all of the (+) symbols. 7 Once you have selected all the symbols, press the [OK] button. 8 Touch the stylus to various points on the screen to verify that the screen is correctly calibrated. If you are not

satisfied with the screen’s calibration, press the [Calibrate]) button to begin again.

Using the Capacitive Touchscreen

This Tablet PC has an optional dual digitizer that allows you to use either the stylus or your finger(s) as a pointing device. This type of display also allows you to use “gestures” to perform such actions as scroll, zoom, and rotate.

• GESTURE SUPPORT IS DETERMINED BY THE APPLICATION IN USE.

• THE STYLUS TAKES PRECEDENCE OVER FINGER TOUCH. IF THE STYLUS IS WITHIN ACTIVE RANGE OF THE SCREEN, FINGER TOUCH WILL BE DISABLED.

• WHEN ONE FINGER IS USED ON THE TOUCHSCREEN, IT BEHAVES IN THE SAME MANNER AS A STYLUS.

Right-clicking the touchscreen

To perform a right-click action using two fingers, press the first finger at the location you want to perform a right-click, then quickly tap and release the second finger on the screen.

Generic Gesture Mode

Your tablet has a few gestures to which it responds, as detailed below. (Note: In order to enjoy a much more robust set of gesture actions, you should install N-act™ using the Bonus Apps utility. See “Using N-act™” on page 28). To initiate gesture mode, two fingers must touch the screen within 200 ms of each other. If the second finger touches the screen after 200 ms has elapsed, the second finger is ignored. If more than two fingers touch the screen in that time, Advanced Gesture Mode is activated instead. When Gesture Mode is activated, no cursor movement is sent to the system.

When both fingers are removed, Gesture mode ends. When a third finger is added, gesture mode ends and Advanced gesture mode is activated. Note that if a gesture can’t be recognized, no action is taken. In that case, remove both fingers from the screen and try again.

- Active Digitizer/Touchscreen

Scrolling Gesture

To scroll through long documents or on a web page, place both fingers on the screen (one finger quickly followed by the second). If at least one finger has moved at least 3 mm, a scroll is considered. If both fingers are moving in the same direction and parallel (given a tolerance of 5 mm), Scroll Mode is activated. If one finger is stationary, it is not considered a scroll. If either finger is lifted, Scroll Mode is canceled.

Zoom Gesture

The zoom gesture is especially helpful when viewing pictures. To zoom in, place two fingers on the item you want to enlarge (one finger quickly followed by the second), then spread them away from each other.

If at least one finger has moved at least 10 mm, a zoom event is considered. If the distance between the fingers has changed by at least 10 mm, and both fingers have stayed on approximately the same line, Zoom Mode is entered. If either finger strays more than 10 mm from the “zoom line” created when the fingers first made contact, the zoom is canceled.

To zoom out, place two fingers on the item you want to reduce (one finger quickly followed by the second), then move them towards each other.

Rotate Gesture

To change the orientation of an object on the screen, place two fingers on the image you want to rotate (one finger quickly followed by the second), then move them in opposite directions (as if you were turning a knob). The direction the item turns is dependant upon the direction you move your fingers.

If at least one finger moves at least 12 mm, a rotate is considered. If one finger is stationary (moving less than 5 mm in any direction), and the other is moving, a rotate is considered. If the fingers begin moving in the same direction, the rotation is canceled. If the distance between the fingers changes by more than 10 mm, the rotation is canceled.

- Active Digitizer/Touchscreen

Using N-act™

N-act™ multi-touch application allows you to interact directly with the screen. N-act lets you use 1-, 2-, 3-, or 4-finger gestures to perform a number of actions that make using your tablet all the more enjoyable. To start N-act, you must first install it using the Bonus Apps utility (see “Installing Bonus Apps” on page 41). The following table explains briefly what each of the gestures does.

Gesture Name Action Required Result of Action One-Finger Gestures

N-actClick Tap screen with one finger. Clicks on an item on the screen. N-actDoubleClick Tap the screen twice quickly. Performs a double-click action N-actDrag andDrop Touch an item on the screen and move it

Drags on-screen items from one location to another.

without lifting your finger

Two-Finger Gestures

N-act2Scroll Place two fingers on the screen and move

Scrolls up and down a page.

them up or down.

N-act2Zoom Place two fingers on the screen and pinch

Pinching together zooms in; sliding apart zooms out.

them together or slide them.

N-act2Rotate Place two fingers on an item and holding

the thumb in place as an anchor, move

Rotates the selected object in the direction of the index finger arc.

the index finger in a wide arc.

N-act2Tap Tap two fingers twice in quick succession. Locks context-sensitive menus.

Three-Finger Gestures

N-act3SweepUp Place three fingers on the screen and

Maximizes the current window.

sweep them upwards.

N-act3SweepDown Place three fingers on the screen and

Minimizes the current window.

sweep them downwards.

- Active Digitizer/Touchscreen

N-act3Tap Tap three fingers on the screen. Displays all currently open windows in a 3D carousel

formation. N-act3Hold Place and hold three fingers on the screen. Rotates the carousel of files (see above). N-act3DoubleTap Tap three fingers twice on the screen. Minimizes all windows and displays the desktop. N-act3Side Sweep Sweep three fingers to the side of the

screen.

N-act2+1 Hold two fingers on the screen, then select

with third.

Four-Finger Gestures

N-act4Tap Select a word, sentence, paragraph, or

item. Tap four fingers on the screen, then lift them.

N-act4SweepUp Hold four fingers in a square to select a

specific area of the screen.

N-act4SweepDown Place four fingers on the screen to create a

zoom in square for a specific area. Then use one finger to navigate.

Browses through all open files within a specific

application. The initial direction you sweep determines

the direction and order the files are displayed.

When the two fingers are held, a context-sensitive

menu is displayed. Use the third finger to select from

the menu.

When the fingers are lifted, a menu of context-sensitive

web locations is displayed.

A context-sensitive menu of applications is displayed.

Once the zoom-in square is selected, one finger can be

used to move the square around the screen to magnify

the areas it moves over.

Accessing the OnScreen TouchPad

Your tablet has a handy on-screen touchpad that offers a variety of helpful functions. Features of the OnScreen TouchPad include:

• Virtual Mouse Emulator: The Virtual Mouse Emulator works in much the same manner as a hardware mouse.

With the virtual mouse, you can scroll, drag, and click, as well as perform [Ctl]+[Click] and [Shift]+[Click] actions.

• Application Launch/Key Macro: This window provides access to five pages, each of which can contain up to

twenty buttons. Each button can be programmed to open an application, a folder, document, or key (such as [Esc], [ Alt+X] and [Page Up]).

- Active Digitizer/Touchscreen

• Digital Keyboard: This window provides a soft keyboard for use in mathematical procedures. It works in much

the same way as the Windows standard calculator.

To access the OnScreen TouchPad, you must first install it using the Bonus Apps utility (see “Installing Bonus Apps” on page 41 for more information). Once it has been installed, go to the Start Menu > All Programs > Fujitsu OnScreen TouchPad. To learn more about the utility, click on Usage and Help.

Caring for the Pen

• ONLY USE THE PEN PROVIDED WITH YOUR TABLET PC. DO NOT USE SUBSTITUTE PEN TIPS THAT WERE NOT SPECIALLY DESIGNED FOR YOUR TABLET

PC. R

EPLACE THE STYLUS TIP IF IT IS WORN. THE WARRANTY DOES NOT COVER A SCRATCHED SCREEN.

• WHILE WRITING, DO NOT TO SCRATCH THE SURFACE OF THE DISPLAY (E.G., WITH A WRISTWATCH OR BRACELET).

HE PEN OF YOUR TABLET PC IS AN ELECTRONIC INSTRUMENT WHICH CAN BE DAMAGED IF USED INCORRECTLY. HANDLE THE PEN WITH CARE. THE

FOLLOWING LIST CONTAINS GUIDELINES FOR PROPER PEN HANDLING:

• DO NOT GESTURE WITH THE PEN OR USE IT AS A POINTER.

• NEVER USE THE PEN ON ANY OTHER SURFACE THAN THE SCREEN OF YOUR TABLET PC.

• DO NOT TRY TO TURN THE THUMB GRIP ON THE PEN.

• NEVER STORE THE PEN WITH THE TIP BEARING THE WEIGHT OF THE PEN. IF THE PEN IS STORED WITH THE TIP POINTING DOWN, THIS MAY HAVE AN

ADVERSE EFFECT ON THE PEN MECHANISM (PARTICULARLY UNDER HIGH TEMPERATURES). IN THIS CASE THE PEN TIP MAY REACT AS THOUGH IT IS CONSTANTLY BEING PRESSED DOWN.

• THE PEN CAN BE INFLUENCED BY ELECTROMAGNETIC FIELDS (CURSOR QUIVERS OR JUMPS). THERE MAY BE A FEW AREAS ON THE SCREEN WHERE

THE CURSOR QUIVERS SLIGHTLY IN SPITE OF PRESSING THE PEN DOWN FIRMLY.

- Active Digitizer/Touchscreen

Changing the Pen Settings

Pen Cap

AAAA-battery

Pen Barrel

There are a few changes you can make to your pen settings in order to make it more suitable to your needs (such as changing the pressure sensitivity). To do so, go to Start > Control Panel and select one of the icon views from the “View by:” dropdown. Click on the Pen and Touch icon to open the window from which you can change a variety of pen settings.

Changing the Pen Battery

• DO NOT REMOVE THE TIP OF THE PEN TO REPLACE THE BATTERY; REMOVE

ONLY THE CAP ON THE TOP OF THE PEN.

• THERE IS A RISK OF EXPLOSION IF THE BATTERY IS REPLACED BY AN

INCORRECT TYPE. DISPOSE OF USED BATTERIES IN ACCORDANCE WITH LOCAL INSTRUCTIONS.

The pen contains a AAAA-battery. Before proceeding, be sure to have a new battery available.

1 Remove the rear Pen Cap (Figure ). 2 Remove the battery from the pen barrel. 3 Insert the new battery into the pen barrel in the same

orientation as the one that was removed.

4 Close the rear Pen Cap.

Figure 11. Replacing the Battery

- Active Digitizer/Touchscreen

Replacing the Pen Tip

Pen Tip

With use, the pen tip may become worn or may pick up foreign particles that can scratch the screen. A damaged or worn tip may not move freely, causing unpredictable results when using the pen. If a problem like this should occur, you should replace the pen tip.

1 Pull the tip from the barrel. 2 Using one of the new tips that were supplied with your pen,

insert the pointed end of the tip into the barrel and push it in firmly until it is in place

Installing a Pen Tether

To prevent dropping or losing your pen, you should attach it to your system using the pen tether that is included with the system.

To attach the pen tether to your Tablet PC, perform the following steps:

1 Attach the end of the pen tether with the smaller loop to your

pen. To do so, push the end of the tether under the slot on the top of the pen, then thread the opposite end of the tether through the loop.

Figure 12. Replacing the Pen Tip

2 Attach the end of the pen tether with the larger loop to the

att achmen t point on the right side of your t ablet . To do so, insert the end of the pen tether through the attachment point, then feed the pen through the large loop in the tether.

- Active Digitizer/Touchscreen

Figure 13. Installing a Pen Tether

Tablet PC Buttons

Keyboard Button

Rotation Button

Ctl-Alt-Del

The three Tablet PC buttons are located on the right-hand side of a horizontally-oriented system. Two of the buttons have secondary functions. The secondary functions are activated by pressing and holding the button.

Figure 14. Application buttons

TL-ALT-DEL IS THE ONLY APPLICATION BUTTON THAT CAN BE USED WHILE THE SYSTEM IS LOGGING ON OR WHEN THE SYSTEM IS LOCKED (I.E.,

WHEN YOU HAVE THE LOGON OR COMPUTER LOCKED WINDOW SHOWING ON YOUR DESKTOP).

- Tablet PC Buttons

Button Icon

and Name

Keyboard

Button

Rotation

Button

Primary

Function

(Press)

Launch Tablet PC

Input Panel

Screen Rotate

Secondary

Function

(Press and

Press at Splash

Screen*

In BIOS Setup

Utility

Hold)

Launch FujitsuHL Boot Menu Enter

Enable/

Disable Auto

Rotate

BIOS Setup Utility Down

Description

Pressing the Keyboard button launches the Tablet PC Input Panel. Pressing and holding the button launches the FujitsuHL utility that provides shortcuts to a variety of commonly accessed tools and tasks, including the web camera application. If you press the Keyboard button while the Fujitsu logo appears during system boot, the Boot Menu will open. While you are in the BIOS Setup utility, this button can be used as an [Enter] key.

When you press the Rotate button, the system screen orientation changes from landscape (horizontal) to portrait (vertical) or from portrait to landscape. When you would like to use the Tablet PC as an eBook, for example, you would use the portrait orientation; when accessing spreadsheets, you would more typically use a landscape orientation. Press and hold the button to enable and disable the Auto Rotate function. If you press the Rotation button while the Fujitsu logo appears during system boot, the BIOS Setup Utility will open. While you are in the BIOS Setup utility, this button can be used as a Down key

Pressing the Ctl-Alt-Del button for approximately one second causes it to act as if Ctl-Alt-Del had actually been entered from a keyboard. If you press the Ctrl+Alt+Del button while the Fujitsu logo appears during system boot, the Application Menu will appear. While you are in the BIOS Setup utility, this button can be used as an Up key.

Ctl-Alt-Del Button

Ctrl + Alt + Del None

Application

* “Press at Splash Screen” refers to the action that occurs when you press the button when the Fujitsu logo appears when you first start up the system.

- Tablet PC Buttons

Chapter 2

Getting Started with Your Tablet PC

Power Sources

Your Fujitsu STYLISTIC Tablet PC has three possible power sources: a primary Lithium Polymer battery, an AC adapter or an optional Auto/Airline adapter.

Connecting the Power Adapters

The AC adapter or optional Auto/Airline adapter provides power for operating your Tablet PC and charging the batteries.

Connecting the AC Adapter

1 Plug the DC output cable into the DC power jack of your STYLISTIC Tablet PC. 2 Plug the AC adapter into an AC electrical outlet.

Connecting the Optional Auto/Airline Adapter

1 Plug the DC output cable into the DC power jack on your Tablet PC. 2 Plug the Auto/Airline adapter into the cigarette lighter of an automobile, or, 3 Plug the Auto/Airline adapter into the DC power jack on an airplane seat.

Figure 15. Connecting the AC Adapter

DC Power Jack

AC Adapter

Switching from AC Adapter Power or the Auto/Airline Adapter to Battery Power

1 Be sure that you have at least one charged battery installed. 2 Remove the AC adapter or the Auto/Airline adapter.

THE LITHIUM POLYMER BATTERY IS NOT CHARGED UPON PURCHASE. INITIALLY, YOU WILL NEED TO CONNECT EITHER THE AC ADAPTER OR THE A

UTO/AIRLINE ADAPTER TO USE YOUR TABLET PC.

- Power Sources

Starting Your STYLISTIC Tablet PC

Power On

Power/Suspend/Resume Switch

The Power/Suspend/Resume switch is used to turn on your STYLISTIC Tablet PC from its off state. Once you have connected your AC adapter or charged the internal Lithium Polymer battery, you can power on your Tablet PC.

HEN YOU TURN ON YOUR STYLISTIC TABLET PC BE SURE YOU HAVE A POWER SOURCE. THIS MEANS THAT AT LEAST ONE BATTERY IS INSTALLED

AND CHARGED, OR THAT THE AC OR AUTO/AIRLINE ADAPTER IS CONNECTED AND HAS POWER.

To turn on your STYLISTIC Tablet PC from its off state, slide the Power/Suspend/Resume switch, located on the bottom edge of the right side (when the system is held horizontally). When you are done working you can either leave your Tablet PC in Suspend mode or you can turn it off. See “Sleep Mode” on page 42 and “Powering Off” on page 44

Figure 16. Power/Suspend/Resume Switch

- Starting Your STYLISTIC Tablet PC

When you power on your STYLISTIC, it will perform a Power On Self Test (POST) to check the internal parts and configuration for correct functionality. If a fault is found, your STYLISTIC Tablet PC will emit an audio warning and/or an error message will be displayed. See “Power On Self Test Messages” on page 60. Depending on the nature of the problem, you may be able to continue by starting the operating system or by entering the BIOS setup utility and revising the settings.

After satisfactory completion of the POST, your Tablet PC will load your operating system.

NEVER TURN OFF YOUR STYLISTIC TABLET PC DURING THE POWER ON SELF TEST (POST) OR IT WILL CAUSE AN ERROR MESSAGE TO BE DISPLAYED

WHEN YOU TURN YOUR STYLISTIC TABLET PC ON THE NEXT TIME.

See “Power On Self Test Messages” on page 60.

Boot Sequence

The procedure for starting-up your Tablet PC is termed the Bootup sequence and involves your Tablet PC’s BIOS. When your STYLISTIC Tablet PC is first turned on, the main system memory is empty, and it needs to find instructions to start up your Tablet PC. This information is in the BIOS program. Each time you power up or restart your Tablet PC, it goes through a boot sequence which displays a Fujitsu logo until your operating system is loaded. During booting, your Tablet PC is performing a standard boot sequence including a Power On Self Test (POST). When the boot sequence is completed without a failure and without a request for the BIOS Setup Utility, the system displays the operating system’s opening screen.

The boot sequence is executed when:

• You turn on the power to your STYLISTIC Tablet PC.

• You restart your Tablet PC from the Windows Shut Down dialog box.

• The software initiates a system restart. Example: When you install a new application.

- Starting Your STYLISTIC Tablet PC

Hard Disk Drive Passwords

To provide additional security for your data, you can assign passwords to your hard disk drive(s). This feature is managed in the system BIOS Setup Utility. See

REMEMBER YOUR PASSWORDS. IF YOU SET AND FORGET YOUR USER AND MASTER HARD DISK PASSWORDS, FUJITSU WILL NOT BE ABLE TO RESET

IT. YOU MAY LOSE DATA AND HAVE TO REPLACE YOUR SYSTEM BOARD OR HARD DISK DRIVE.

BIOS Setup Utility

below for information about accessing the utility.

BIOS Setup Utility

The BIOS Setup Utility is a program that sets up the operating environment for your STYLISTIC Tablet PC. Your BIOS is set at the factory for normal operating conditions, therefore there is no need to set or change the BIOS’ environment to operate your Tablet PC.

The BIOS Setup Utility configures:

• Device control feature parameters, such as changing I/O addresses and boot devices.

• System Data Security feature parameters, such as passwords.

Entering the BIOS Setup Utility

To enter the setup utility, do the following:

1 Turn on or restart your STYLISTIC Tablet PC. 2 To enter the BIOS Setup Utility, either press the Rotation button (or press the [F2] key if you have an external

keyboard) when the Fujitsu logo appears on the screen. This will open the main menu of the BIOS Setup Utility with the current settings displayed.

3 Press the [RIGHT ARROW] or [LEFT ARROW] key to scroll through the other setup menus to review or alter the

current settings.

BIOS Guide

A guide to your Tablet PC’s BIOS is available online. Please visit our service and support website at

http://support.fujitsupc.com/CS/Portal/supporthome.do, then select User’s Guides under Product Information. Select

your Product, Series, and Model, then click [Go]. Under the Manuals tab, select the BIOS Guide.

- Starting Your STYLISTIC Tablet PC

Booting the System

We strongly recommend that you not attach any external devices until you have gone through the initial power on sequence.

When you turn on your Tablet PC for the first time, it will display a Fujitsu logo on the screen. If you do nothing the system will load the operating system, and then the Windows Welcome will begin.

Starting Windows the first time

IMPORTANT: DURING THE SETUP PROCEDURE, DO NOT DISCONNECT THE POWER SUPPLY, PRESS ANY BUTTONS, OR USE ANY PERIPHERAL DEVICES

SUCH AS A MOUSE OR KEYBOARD.

In order to ensure that you receive the most benefits from the Windows operating system, it should be registered the first time you use it.

1 First of all, you will need to read and accept the End User License Agreements (EULAs).

• IF YOU REJECT THE TERMS OF THE LICENSE AGREEMENTS YOU WILL BE ASKED TO REVIEW THE LICENSE AGREEMENTS FOR INFORMATION ON

RETURNING WINDOWS OR TO SHUT DOWN YOUR STYLISTIC TABLET PC.

• YOU CANNOT USE YOUR TABLET PC UNTIL YOU HAVE ACCEPTED THE LICENSE AGREEMENTS. IF YOU STOP THE PROCESS YOUR TABLET PC WILL

RETURN TO THE BEGINNING OF THE WINDOWS WELCOME PROCESS, EVEN IF YOU SHUT YOUR TABLET PC DOWN AND START IT UP AGAIN.

2 You will be prompted to enter your User Name and Password and you will be given a chance to select an icon for

your account.

3 The next screen asks for a Computer Name. 4 You will next see a “Help protect Windows automatically” screen in which the default choice is “Use recommended

settings”. The other two choices are “Install important updates only” and “Ask me later”. Select from the three choices.

5 On the next screen set your time and date settings.

- Starting Your STYLISTIC Tablet PC

6 You will next see the “Select your computer's current location” screen. Make your selection from Home, Work

(Default), and Public location.

7 The “Thank you” screen follows along with several other screens while Windows checks the system performance. 8 Windows will then boot up for the first time. As noted above, the first time you initialize your system, the screen

will be blank for approximately two minutes. This is normal. During this period, do not disconnect the power supply, press any buttons, or use any peripheral devices such as mouse or keyboard.

Registering Windows with Microsoft

To register your copy of Windows, be sure to go to the Microsoft's website at: http://windows.microsoft.com/enUS/windows7/help/register.

Registering your LIFEBOOK with Fujitsu

You can register your notebook by going to our website at: https://store.shopfujitsu.com/fpc/Ecommerce/Service.jsp. You will need to be set up with an Internet Service Provider (ISP) to register online.

Installing Bonus Apps

After you have started your system the first time, you will see a Bonus Apps icon on your desktop. Click on the icon to see which additional applications are available for you to install. Applications that are already installed appear in grey; those that are available for installation appear in blue.

Select the applications you wish to install by selecting the checkbox adjacent to your selection, or click [Select All] if you would like to install all available applications. Once you have made your selections, click [Install].

Note that in some cases (depending upon which application was selected for installation) after installation completes, the system will prompt you to reboot. There are also cases in which if multiple applications are selected to install but one of them needs a reboot, the system will reboot and continue installing the rest of the selected applications.

- Starting Your STYLISTIC Tablet PC

Power Management

Your Fujitsu STYLISTIC Tablet PC has many options and features for conserving battery power. Some of these features are automatic and need no user intervention. However, others depend on the parameters you set to best suit your operating conditions, such as those for the display brightness. Internal power management for your Tablet PC may be controlled from settings made in your operating system, pre-bundled power management application, or from settings made in BIOS setup utility.

Besides the options available for conserving battery power, there are also some things that you can do to prevent your battery from running down as quickly. For example, you can create an appropriate power saving profile, put your Tablet PC into Sleep mode when it is not performing an operation, and you can limit the use of high power devices. As with all mobile, battery powered computers, there is a trade-off between performance and power savings.

Power/Suspend/Resume Switch

When your Tablet PC is active, the Power/Suspend/Resume switch can be used to manually put the Tablet PC into Sleep mode. Push the Power/Suspend/Resume switch when the Tablet PC is active, but not actively accessing anything, and immediately release the button.

If your Tablet PC is suspended, pushing the Power/Suspend/Resume switch returns it to active operation. You can tell whether the system is Suspended by looking at the Power indicator. If the indicator is visible and not flashing, your Tablet PC is fully operational. If the indicator is visible not visible, the power is off or your Tablet PC is in Hibernation mode.

Sleep Mode

Sleep mode in Windows saves the contents of your system memory during periods of inactivity by maintaining power to critical parts. This mode turns off the CPU, display, hard drive, and all other internal components except those necessary to maintain system memory and for restarting.

and

flashing, the Tablet PC is in Sleep mode. If the indicator is

Your Tablet PC can be put in sleep mode by:

• Pressing the Power/Suspend/Resume switch when your system is turned on.

• Selecting “Sleep” after clicking [Start] then clicking the small arrow at the bottom right of the window.

• Timing out from lack of activity.

• Allowing the battery to reach the Dead Battery Warning condition.

- Power Management

Your Tablet PC’s system memory typically stores the file on which you are working, open application information, and any other data required to support operations in progress. When you resume operation from Sleep mode, your Tablet PC will return to the point where it left off. You must use the Power/Suspend/Resume switch to resume operation, and there must be an adequate power source available, or your Tablet PC will not resume.

• IF RUNNING YOUR TABLET PC ON BATTERY POWER, BE AWARE THAT THE BATTERY CONTINUES TO DISCHARGE WHILE YOUR TABLET PC IS IN SLEEP

MODE, THOUGH NOT AS QUICKLY AS WHEN FULLY OPERATIONAL.

• DISABLING THE POWER/SUSPEND/RESUME SWITCH PREVENTS IT FROM BEING USED TO PUT THE TABLET PC INTO SLEEP OR HIBERNATION MODE.

HE BUTTON RESUME FUNCTION CANNOT BE DISABLED.

• IF YOUR TABLET PC IS ACTIVELY ACCESSING INFORMATION WHEN YOU ENTER THE SLEEP OR HIBERNATION MODE, CHANGES TO OPEN FILES ARE NOT

LOST. THE FILES ARE LEFT OPEN AND MEMORY IS KEPT ACTIVE DURING SLEEP MODE OR THE MEMORY IS TRANSFERRED TO THE INTERNAL HARD DRIVE DURING HIBERNATION MODE.

• THE MAIN ADVANTAGE OF USING HIBERNATION IS THAT POWER IS NOT REQUIRED TO MAINTAIN YOUR DATA. THIS IS PARTICULARLY IMPORTANT IF

YOU WILL BE LEAVING YOUR TABLET PC IN A SUSPENDED STATE FOR A PROLONGED PERIOD OF TIME. THE DRAWBACK OF USING HIBERNATION MODE IS THAT IT LENGTHENS THE POWER DOWN AND POWER UP SEQUENCES AND RESETS PERIPHERAL DEVICES.

Hibernation Feature

The Hibernation feature saves the contents of your Tablet PC’s system memory to the hard drive as a part of the Suspend/Resume mode. Hibernation is enabled by default.

Defining Power Button Action

To determine what occurs when the power button is pressed, follow these steps:

1 From the Start menu, select Control Panel, then select the Power Options icon. 2 Select “Choose what the power button does”, then make your selections (Do Nothing, Sleep, Hibernate, or Shut

Down).

Windows Power Management

The Power Options icon located in the Windows Control Panel allows you to configure some of the power management settings. For example, you can use the Power Options to set the timeout values for turning off the display and hard disks whether you are running the Tablet PC on battery power or one of the adapters.

- Power Management

Restarting the System

If your system is on and you need to restart it, be sure that you use the following procedure.

1 Click the [Start] button, and then move the mouse over the small arrow at the bottom right of the right-hand

pane.

2 Select Restart from the list.

TURNING OFF YOUR STYLISTIC TABLET PC WITHOUT EXITING WINDOWS OR TURNING ON YOUR TABLET PC WITHIN 10 SECONDS OF THE SYSTEM

BEING SHUT OFF MAY CAUSE AN ERROR WHEN YOU START THE NEXT TIME.

Powering Off

If you turn off the power while accessing a disk there is a risk of data loss. To ensure that your Tablet PC shuts down without error, use the Windows shut down procedure.

E SURE TO CLOSE ALL FILES, EXIT ALL APPLICATIONS, AND SHUT DOWN YOUR OPERATING SYSTEM PRIOR TO TURNING OFF THE POWER. IF FILES ARE

OPEN WHEN YOU TURN THE POWER OFF, YOU WILL LOSE ANY CHANGES THAT HAVE NOT BEEN SAVED, AND MAY CAUSE DISK ERRORS.

Using the correct procedure to shut down from Windows allows your Tablet PC to complete its operations and turn off power in the proper sequence to avoid errors. The proper sequence is:

1 Click the [Start] button, and then move the mouse over the small arrow at the bottom right of the right-hand

pane.

2 Select Shut Down from the list.

If you are going to store your Tablet PC for a month or more, see “Caring for your Tablet PC” on page 63.

- Power Management

Chapter 3

User-Installable Features

Lithium Polymer Battery

Your STYLISTIC Tablet PC has a Lithium Polymer battery that provides power for operating your Tablet PC when no external power source is available. The battery is durable and long lasting, but should not be exposed to extreme temperatures, high voltages, chemicals or other hazards.

The Lithium Polymer battery operating time may become shorter if it is used under the following conditions:

• When used at temperatures that exceed a low of 5°C or a high of 35°C (41° to 95° F). Extreme temperatures not

only reduce charging efficiency, but can also cause battery deterioration. The Charging icon on the Status Indicator panel will flash when you try to charge a battery that is outside its operating temperature range.

• When using a high current device such as an external optical drive or the hard drive, using the AC adapter will

conserve your battery life.

DO NOT LEAVE A FAULTY BATTERY IN YOUR TABLET PC. IT MAY DAMAGE YOUR AC ADAPTER, OPTIONAL AUTO/AIRLINE ADAPTER, OR YOUR TABLET PC

ITSELF. IT MAY ALSO PREVENT OPERATION OF YOUR TABLET PC BY DRAINING ALL AVAILABLE CURRENT INTO THE BAD BATTERY.

• ACTUAL BATTERY LIFE WILL VARY BASED ON SCREEN BRIGHTNESS, APPLICATIONS, FEATURES, POWER MANAGEMENT SETTINGS, BATTERY CONDITION

AND OTHER CUSTOMER PREFERENCES. HARD DRIVE USAGE MAY ALSO HAVE A SIGNIFICANT IMPACT ON BATTERY LIFE. THE BATTERY CHARGING CAPACITY IS REDUCED AS THE BATTERY AGES. IF YOUR BATTERY IS RUNNING LOW QUICKLY, YOU SHOULD REPLACE IT WITH A NEW ONE.

• UNDER FEDERAL, STATE, OR LOCAL LAW IT MAY BE ILLEGAL TO DISPOSE OF BATTERIES BY PUTTING THEM IN THE TRASH. PLEASE TAKE CARE OF OUR

ENVIRONMENT AND DISPOSE OF BATTERIES PROPERLY. CHECK WITH YOUR LOCAL GOVERNMENT AUTHORITY FOR DETAILS REGARDING RECYCLING OR DISPOSING OF OLD BATTERIES. IF YOU CANNOT FIND THIS INFORMATION ELSEWHERE, CONTACT YOUR SUPPORT REPRESENTATIVE AT 1-800-

8FUJITSU (1-800-838-5487)

Recharging the Batteries

If you want to know the condition of the primary Lithium Polymer battery, check the Battery Level indicator located on the Status Indicator panel. The indicator changes as the battery level changes.

The Lithium Polymer battery is recharged internally using the AC adapter or Auto/Airline adapter. To recharge the battery make sure the battery that needs to be charged is installed in your STYLISTIC Tablet PC and connect the AC or Auto/Airline adapter.

AKE SURE THAT THE PERCENTAGE CHARGE IS INDICATED BY THE BATTERY CHARGING INDICATOR ON THE STATUS INDICATOR PANEL.

There is no memory effect on the Lithium Polymer battery therefore you do not need to discharge the battery completely before recharging. The charge times will be significantly longer if your Tablet PC is in use while the battery is charging. If you want to charge the battery more quickly, put your Tablet PC into Sleep mode, or turn it off while the adapter is charging the battery. (See Power Management on page 42 for mor e information on Sleep mode and shutdown

procedure)

SING HEAVY CURRENT DEVICES OR FREQUENT EXTERNAL OPTICAL DRIVE ACCESSES MAY PREVENT CHARGING COMPLETELY.

- Lithium Polymer Battery

Low Battery State

When the battery is running low, a low battery notification message will appear. If you do not respond to the low message, the batteries will continue to discharge until they are too low to operate. When this happens, your Tablet PC will go into Sleep mode. There is no guarantee that your data will be saved once the Tablet PC reaches this point.

• ONCE THE LOW BATTERY NOTIFICATION MESSAGE APPEARS, YOU NEED TO SAVE ALL YOUR ACTIVE DATA AND PUT YOUR TABLET PC INTO SLEEP MODE

UNTIL YOU CAN PROVIDE A NEW POWER SOURCE. YOU SHOULD PROVIDE A CHARGED BATTERY, AN AC POWER ADAPTER, OR AUTO/AIRLINE ADAPTER AS SOON AS POSSIBLE.

• WHEN YOU ARE IN SLEEP MODE THERE MUST ALWAYS BE AT LEAST ONE POWER SOURCE ACTIVE. IF YOU REMOVE ALL POWER SOURCES WHILE YOUR

STYLISTIC T

ABLET PC IS IN SLEEP MODE, ANY DATA THAT HAS NOT BEEN SAVED TO THE HARD DRIVE WILL BE LOST.

Dead Battery Suspend mode shows on the Status indicator just like the normal Sleep mode. Once your Tablet PC goes into Dead Battery Suspend mode you will be unable to resume operation until you provide a source of power either from an adapter, or a charged battery. Once you have provided power, you will need to press the Power/Suspend/Resume switch to resume operation.

In the Dead Battery Suspend mode, your data can be maintained for some time, but if a power source is not provided promptly, the Power indicator will stop flashing and go out, meaning that you have lost the data that was not stored. Once you provide power, you can continue to use your Tablet PC while an adapter is charging the battery.

Shorted Batteries

The Status Indicator panel indicator associated with the Battery Level indicator displays the operating level available in that battery. If this display shows a flashing red LED, it means the battery is damaged and must be replaced so it does not damage other parts of your STYLISTIC Tablet PC.

Replacing the Battery

With the purchase of an additional battery, you can have a fully charged spare to swap with one that is not charged. There are two ways to swap batteries, cold-swapping and hot-swapping:

Cold-swapping Batteries

To cold-swap batteries in your battery bay, follow these easy steps:

- Lithium Polymer Battery

1 Have a charged battery ready to install.

Lift Point

2 Perform one of the following two steps:

• Click the Fujitsu Battery Swap Utility icon on the desktop. Follow the instructions that appear to put the system

into Hibernate mode. (Please note that the system has not yet entered Hibernation until the Power indicator is no longer lit.) Using this procedure saves your data and the system powers down. It is then safe to swap the batteries.

• Save your data, then power down the system. It is then safe to swap the batteries.

3 Note that the battery latch on the left is spring loaded, while the latch on the right is not. Unlock the battery by

first pushing the right latch backwards, then pushing and holding the left latch (Figure 17). While holding the left latch, lift the battery out at the lift point (Figure 18).

4 To install a battery, first verify that the right latch is pushed back. While pushing the left latch back and holding

it, insert a new battery into the bay (Figures 19 and 20). Lock the battery in place by sliding the right latch forward.

5 Plug in the AC adapter and turn the power on.

Figure 17. Unlocking the Battery Figure 18. Removing the Battery

- Lithium Polymer Battery

Figure 19. Replacing the Battery Figure 20. Locking the Battery

Hot-swapping Batteries

To hot-swap batteries in your battery bay follow these easy steps:

E SURE TO PLUG IN AN AC ADAPTER PRIOR TO REMOVING THE BATTERY. THERE IS NO BRIDGE BATTERY PRESENT TO SUPPORT THE SYSTEM

WHILE THE BATTERY IS BEING REPLACED. IF YOU DO NOT USE AN AC ADAPTER YOU WILL LOSE ANY UNSAVED FILES.

1 Plug an AC Adapter into the system and connect it to a power outlet. 2 Follow steps 3 through 5 in “Cold Swapping Batteries”.

F THE LITHIUM POLYMER BATTERY CONNECTOR IS NOT FULLY SEATED, YOU MAY NOT BE ABLE TO USE YOUR TABLET PC OR CHARGE YOUR BATTERY.

- Lithium Polymer Battery

Secure Digital Cards

SD Card

SD Card Slot (relative location on rear)

SD Card

SD Card Slot

Your STYLISTIC Tablet PC supports Secure Digital (SD) cards, on which you can store and transfer data to and from a variety of digital devices. These cards use flash memory architecture, which means they don’t need a power source to retain data. Note that SD and SDHC Cards are supported, but SDXC Cards are not.

SD Cards allow portable storage among a variety of devices, such as cell phones, GPS systems, digital cameras, and PDAs. SD Cards transfer data quickly, with low battery consumption.

Figure 21. SD Card Slot - Front Access Figure 22. SD Card Slot - Rear Access

Installing SD Cards

When holding the Tablet PC in horizontal position with the front facing you and the web camera on the left, the SD Card slot is located at the top left edge of the system, in the rear (Figures 21 and 22). To install an SD Card, follow these steps:

- Secure Digital Cards

INSTALLING OR REMOVING AN SD CARD DURING YOUR STYLISTIC TABLET PC’S SHUTDOWN OR BOOTUP PROCESS MAY DAMAGE THE CARD AND/OR

YOUR STYLISTIC TABLET PC.

O NOT INSERT A CARD INTO A SLOT IF THERE IS WATER OR ANY OTHER SUBSTANCE ON THE CARD AS YOU MAY PERMANENTLY DAMAGE THE CARD,

YOUR STYLISTIC TABLET PC, OR BOTH.

1 See your specific card manual for instructions on the installation of your card. Some cards may require that your

Tablet PC is off while installing them.

2 Make sure there is no card currently in the slot. If there is, see Removing an SD Card. 3 With the product label facing in the same direction as the display screen, insert your card into the slot. 4 Push the card firmly into the slot until it is seated in the connector.

Removing an SD Card

To remove an SD Card, follow these easy steps:

EE YOUR CARD MANUAL FOR SPECIFIC INSTRUCTIONS ON THE REMOVAL OF YOUR CARD. SOME CARDS MAY REQUIRE YOUR STYLISTIC TABLET PC TO

BE IN SLEEP MODE OR OFF WHILE REMOVING THEM.

1 Select Safely Remove Hardware from the System Tray. Highlight the card in the list, then click [Stop]. 2 Push the SD Card in until it unlatches. It will then eject from the slot for removal.

- Secure Digital Cards

Chapter 4

Troubleshooting Your Tablet PC

Troubleshooting

There may be occasions when you encounter simple setup or operating problems that you can solve on the spot, or problems with peripheral devices that can be solved by replacing the device. The information in this section helps you isolate and resolve some of these straightforward issues and identify failures that require service.

Identifying the Problem

If you encounter a problem, go through the following procedure before pursuing complex troubleshooting:

1 Turn off your STYLISTIC Tablet PC. 2 Make sure the AC adapter is plugged into your Tablet PC and to an active AC power source. 3 Make sure that any cards installed are seated properly. If it appears that there is a problem with a card, remove

the card from the slot, thus eliminating it as a possible cause of failure.

4 Make sure that any devices connected to the external connectors are plugged in properly. You can also disconnect

such devices, thus eliminating them as possible causes of failure.

5 Turn on your Tablet PC. Make sure it has been off at least 10 seconds before you turn it back on. 6 Go through the boot sequence. 7 If the problem has not been resolved, refer to the Troubleshooting Table that follows for more detailed

troubleshooting information.

IF YOU KEEP NOTES ABOUT WHAT YOU HAVE TRIED, YOUR SUPPORT REPRESENTATIVE MAY BE ABLE TO HELP YOU MORE QUICKLY BY GIVING

ADDITIONAL SUGGESTIONS OVER THE PHONE.

8 If you have tried the solutions suggested in the Troubleshooting Table without success, contact your support

representative:

Toll free: 1-800-8FUJITSU (1-800-838-5487) Web site: http://solutions.us.fujitsu.com/www/content/support/contact/index.php

Before you place the call, you should have the following information ready so that the customer support representative can provide you with the fastest possible solution:

• Product name

• Product configuration number

• Product serial number

• Purchase date

• Conditions under which the problem occurred

• Any error messages that have occurred

• Type of device connected, if any

See the Configuration Label on the bottom of your Tablet PC for configuration and serial numbers.

Specific Problems

Using the Troubleshooting Table

When you have problems with your Tablet PC, try to find the symptoms under the Problem column of the troubleshooting table for the feature giving you difficulty. You will find a description of common causes for that symptom under the column Possible Cause and what, if anything, you can do to correct the condition under Possible Solutions. All possible causes or solutions may not apply to your Tablet PC.

- Troubleshooting

Troubleshooting Table

Audio Problems. . . . . . . . . . . . . . . . . . page 54

Hard Drive Problems. . . . . . . . . . . . . . page 54

Keyboard or Mouse Problems. . . . . . .page 54

Pen Input Problems . . . . . . . . . . . . . .page 55

Power Failures . . . . . . . . . . . . . . . . . . . page 56

Shutdown and Startup Problems . . . . page 58

Video Problems . . . . . . . . . . . . . . . . . . page 58

Miscellaneous Problems . . . . . . . . . . . page 59

USB Device Problems . . . . . . . . . . . . .page 55

Problem Possible Cause Possible Solutions

Audio Problems

There is no sound coming from the built-in speaker.

The volume is turned too low. Adjust the volume control on your Tablet PC and operating system. Click

the Volume icon in the system tray on the bottom right of the screen. (It looks like a speaker). If the Mute box has a red circle on it, click on it to deselect it.

Headphones are plugged into your Tablet PC.

Plugging in headphones disables the built-in speaker. Remove the headphones.

Hard Drive Problems

You cannot access your hard drive.

The wrong drive designator was used by an application when a bootable disc was used to start the Tablet PC.

Verify drive designator used by application is in use by the operating system. When the operating system is booted from a disc using an external drive, drive designations are automatically adjusted.

Keyboard or Mouse Problems

You have installed an optional external keyboard or mouse, and it does not seem to work.

Security is set so the OS cannot be started without a password.

Your external device is not properly installed.

- Troubleshooting

Verify your password and security settings.

Re-install your device.

Problem Possible Cause Possible Solutions

You have installed an optional external keyboard or mouse, and it does not seem to work. (continued)

You connected an external keyboard or a mouse and it seems to be locking up the system.

Your operating system is not set up with correct software driver for that device.

Your operating system is not setup with correct driver.

Your system has crashed. Try to restart your Tablet PC.

Check your device and operating system documentation and activate the proper driver.

Pen Input Problems

Cursor is not tracking the pen. Display needs to be calibrated See “Calibrating the Display” on page 25. for more information.

Tablet is not responding to the pen

System may have crashed. If the Tablet PC does not respond to the pen, connect an external keyboard

to the system to see if it responds to keyboard commands. If the system doesn’t respond to a keyboard, the application or system may have crashed, and it may be necessary to reboot the system. If the system responds to a keyboard but not to a pen, contact your local help desk or reseller, or call Fujitsu Service and Support at 1-800-8FUJITSU (1-800-838-

5487) for further assistance.

Memory Problems

Your System screen in the Control Panel does not show the correct amount of installed memory.

You have a memory failure. Check for Power On Self Test (POST) messages. See “Power On Self Test

Messages” on page 60.

USB Device Problems

Your system doesn’t recognize a USB device you installed, or the device doesn’t work properly.

The device is not properly installed. Remove and re-install the device.

Your device may not have the correct software driver active.

- Troubleshooting

See your software documentation and activate the correct driver.

Problem Possible Cause Possible Solutions

Your system doesn’t recognize a USB device you installed, or the device doesn’t work properly. (continued)

Power Failures

You turn on your Tablet PC and nothing seems to happen.

The device may have been installed as an application was running, so your system is not aware of its installation.

The installed battery is completely discharged or there is no power adapter installed.

The battery is installed but is faulty or very low.

System is at a critical thermal limit. To avoid damage to heat-sensitive components, the system enters sleep

AC power adapter is not plugged in properly.

The power adapter has no power from the AC or airline outlet.

Close the application and restart your Tablet PC.

Check the Status Indicator Panel to determine the presence and condition of the battery. See “Status Indicator Panel” on page 19. Install a charged battery or a Power adapter.

When the battery reaches a critically low level, the system is forced into Sleep mode to avoid a total system power failure. To correct this problem, either connect an external power supply (such as the AC adapter), or install a charged battery in the Tablet PC.

mode when it gets too hot. System operation cannot be resumed until the Tablet PC cools off to a tolerable temperature. Move the Tablet PC to a cooler location.

Verify that your adapter is connected correctly. See “Power Sources” on page 35.

Move the AC cord to a different outlet, or check for a line switch or tripped circuit breaker. If you are using an auto/airline adapter in a car be sure the ignition switch is in the On or Accessories position.

Your STYLISTIC Tablet PC turns off all by itself.

The power adapter is faulty. Try a different power adapter.

The power management parameters are set for auto timeouts which are too short for your operating needs.

Your power adapter has failed or lost its power source.

Move the mouse to restore operation. If that fails, push Power/Suspend/Resume switch. Check your power management settings, or close your applications and go to Power Options located in the Control Panel to adjust timeouts to better suit your needs.

Make sure the adapter is plugged in and the outlet has power.

- Troubleshooting

Problem Possible Cause Possible Solutions

Your STYLISTIC Tablet PC turns off all by itself.

(continued)

Your Tablet PC will not work on battery alone.

The battery seems to discharge too quickly.

You ignored a low battery alarm until the battery entered Dead Bat-

Install a power adapter, then push the Power/Suspend/Resume switch. See “Power Sources” on page 35.

tery Suspend mode.

You have a battery failure. Verify the condition of the battery using the Status Indicator panel. If the

battery is shorted, replace or remove it. See “Status Indicator Panel” on page 19.

The installed battery is dead. Replace the battery with a charged one or use an adapter.

No battery is installed. Install a charged battery.

Battery is improperly installed. Verify that the battery is properly connected by re-installing it.

Your installed battery is faulty. Verify the condition of the battery using the Status Indicator panel and

replace or remove any batteries that are shorted. See “Status Indicator Panel” on page 19.

The power savings features may be disabled.

The brightness is turned all the way up.

You’re running an application that

Check the Power Options menu settings and adjust according to your operating needs.

Turn down the brightness adjustment. The higher the brightness the more power your display uses.

Use a power adapter for this application when at all possible. uses a lot of power due to frequent drive access, or use of wireless devices.

The battery is very old. Replace the battery.

The battery was exposed to high

Replace the battery. temperatures.

The battery is too hot or too cold. Restore the Tablet PC to normal operating temperature. Charging icon on

the Status Indicator panel will flash when battery is outside of operating

range.

- Troubleshooting

Problem Possible Cause Possible Solutions

Shutdown and Startup Problems

The Suspend/Resume switch does not work.

The system powers up and displays power on information, but fails to load the operating system.

An error message is displayed on the screen during the boot sequence.

Your system seem to change setup parameters when you start it.

Video Problems

Suspend/Resume switch is disabled. To enable the button, go to Control Panel -> Power Options and click on

the Advanced tab. In the Power buttons area, select the “Choose what the

power button does” option.

There may be application software. conflict

You have a secured system requiring a password to load your operating system.

The boot sequence settings of the setup utility are not compatible with your configuration.

Hard drive was not detected. Use BIOS setup utility to auto detect the internal hard drive.

Power On Self Test (POST) has detected a problem.

BIOS setup changes were not saved when made and you exited the setup utility.

Close all applications and try the button again.

Make sure you have the right password. Enter the setup utility and verify

the Security settings and modify them as accordingly. See “BIOS Setup Util-

ity” on page 39.

Set the operating source by pressing the keyboard button while the Fujitsu

logo is on screen or use the [rotate button and enter the setup utility and

adjust the source settings from the Boot menu. See “BIOS Setup Utility” on

page 39.

See the Power On Self Test (POST) messages to determine the meaning

and severity of the problem. Not all messages are errors; some are simply

status indicators. See “Power On Self Test Messages” on page 60.

Make sure you select Save Changes And Exit when exiting the BIOS setup

utility.

The display is blank when you turn on your Tablet PC.

Power management timeouts are set for short intervals and you didn’t see the display go on and off again.

- Troubleshooting

Move the mouse to restore operation. If that fails, push the Power/Sus-

pend/Resume switch. (The display may be shut off by Sleep mode, Auto

Suspend or Video Timeout)

Problem Possible Cause Possible Solutions

The Tablet PC turned on with a series of beeps and the display is blank.

The display goes blank by itself after you have been using it.

The display has bright or dark spots.

Miscellaneous Problems

Error message displayed on the screen during operation of an application.

Power On Self Test detected a failure which does not allow the display to operate.

Power management timeouts are set for short intervals and you failed to notice the display come on and go off again.

The Tablet PC has gone into Sleep or Hibernate mode because you have not used it for a period of time.

If the spots are very tiny and few in number, this is normal for a large LCD display.

If the spots are numerous or large enough to interfere with your operation needs.

Application software often has its own set of error message displays.

Contact your support representative.

Push the Power/Suspend/Resume switch. (The display may be shut off by

Sleep Mode, Auto Suspend or Video Timeout)

Push Power/Suspend/Resume switch. Check power management settings

to adjust timeout values to suit your needs.

This is normal; do nothing.

Display is faulty; contact your support representative.

See your application manual and help displays screens for more informa-

tion. Not all messages are errors some may simply be status.

- Troubleshooting

Power On Self Test Messages

The following is a list of error-and-status messages that the Phoenix BIOS and/or your operating system can generate and an explanation of each message. Error messages are marked with an *. If an error message is displayed that is not in this list, write it down and check the operating system documentation on screen and in the manual. If you can find no reference to the message, contact a support representative.

*Invalid NVRAM Data

Problem with NVRAM access. In the unlikely case that you see this message you may have a display problem. You can continue operating but should contact your support representative for more information.

*Operating system not found

Operating system cannot be located on either drive A: or drive C: Enter the setup utility and see if both the fixed disk, and drive A: are properly identified and that the boot sequence is set correctly. Unless you have changed your installation greatly, the operating system should be on drive C:. If the setup utility is correctly set, your hard drive may be corrupted.

*Real time clock error - Check date and time settings

Real-time clock fails BIOS test. May require board repair. Contact your support representative.

- Troubleshooting

Restoring Your Pre-installed Software

Packed with your system you will find a Recovery and Utility disc for recovering your pre-installed software.

• IF YOU HAVE ACCESS TO THE INTERNET, VISIT THE FUJITSU SUPPORT WEBSITE AT HTTP://WWW.COMPUTERS.US.FUJITSU.COM/SUPPORT TO CHECK FOR

THE MOST CURRENT INFORMATION, DRIVERS AND HINTS ON HOW TO PERFORM RECOVERY AND SYSTEM UPDATES.

• THERE MAY BE CERTAIN FREE THIRD-PARTY APPLICATIONS PRE-INSTALLED ON YOUR SYSTEM THAT ARE NOT ON THE SUPPORT SITE. THE LATEST

VERSIONS OF THE APPLICATIONS CAN BE DOWNLOADED FROM THE THIRD-PARTY’S WEBSITE.

Recovery and Utility disc

The Recovery and Utility disc contains six utilities:

Recovery and Utility tabs

• Diagnostics tab: The Diagnostics tool is designed for use by IT professionals. It is not likely you will need to use

this tool. When you select devices from the Diagnosis window then click [Execute], several tests are performed on the selected components.

• Recovery tab: The Recovery tab contains two tools:

Restoring the Factory Image (only C: drive) and Restoring the Factory Image (full hard drive recovery). You can use these tools to perform a full hard drive recovery.

• Utility tab: The Utility tab contains three tools: Hard Disk Data Delete, Restore Recovery and Utility, and

Windows Complete PC Restore.

• The Hard Disk Data Delete utility is used to delete all data on the hard disk and prevent the data from

being reused. NOTE: Do not use the Hard Disk Data Delete utility unless you are absolutely certain that you want to erase your entire hard disk, including all partitions.

• Restore Recovery and Utility allows you to restore the first hidden partition.

• Windows Complete PC Restore utility allows you to restore an image created with Windows Backup and

Restore Center. Windows Complete PC Restore will overwrite the data on your hard disk drive.

To use the disc, follow the instructions in the “Using the Recovery and Utility Disc” booklet that is packaged with the disc.

- Restoring Your Pre-installed Software

Maintaining Latest Configuration

- Restoring Your Pre-installed Software

Chapter 5

Care and Maintenance

Caring for your Tablet PC

If you use your STYLISTIC Tablet PC carefully, you will increase its life and reliability. This section provides some tips for looking after the Tablet PC and its devices.

THE SYSTEM CONTAINS COMPONENTS THAT CAN BE SEVERELY DAMAGED BY ELECTROSTATIC DISCHARGE (ESD). TO MINIMIZE RISK TO THE

COMPONENTS, OBSERVE THE FOLLOWING PRECAUTIONS:

• IF YOU DROP YOUR TABLET PC OR DAMAGE THE HOUSING IN ANY WAY, IMMEDIATELY TURN OFF POWER AND DISCONNECT THE POWER PLUG. FAILURE

TO DO SO COULD RESULT IN A SHORT CIRCUIT, SMOKE, AND/OR FIRE. CONTACT FUJITSU SERVICE AND SUPPORT BY PHONE AT 1-800-8FUJITSU (1-

800-838-5487),

HTTP://SOLUTIONS.US.FUJITSU.COM/WWW/CONTENT/SUPPORT/CONTACT/INDEX.PHP TO LEARN HOW TO GET THE SYSTEM REPAIRED.

• BEFORE DOCKING OR UNDOCKING YOUR TABLET PC (WHEN USING A DOCKING CRADLE), IT IS GOOD PRACTICE TO TOUCH A GROUNDED METAL OBJECT

TO DISCHARGE STATIC ELECTRICITY IN YOUR BODY.

• ELECTRICAL EQUIPMENT MAY BE HAZARDOUS IF MISUSED. OPERATIONS OF THIS PRODUCT OR SIMILAR PRODUCTS, MUST ALWAYS BE SUPERVISED BY AN

ADULT. DO NOT ALLOW CHILDREN ACCESS TO THE INTERIOR OF ANY ELECTRICAL PRODUCTS AND DO NOT PERMIT THEM TO HANDLE ANY CABLES.

BY EMAIL AT 8FUJITSU@US.FUJITSU.COM, OR THROUGH THE WEBSITE AT

• Your STYLISTIC is a durable but sensitive electronic device. Treat it with respect and care.

• Make a habit of transporting it in a suitable carrying case.

• Do not attempt to service the computer yourself. Always follow installation instructions closely.

• Keep it away from food and beverages.

• If you accidentally spill liquid on your STYLISTIC Tablet PC:

1 Turn it off. 2 Position it so that the liquid can run out and let it dry out for 24 hours, or longer if needed. 3 If your Tablet PC will not boot after it has dried out, call your support representative.

• Do not use your Tablet PC in a wet environment (near a bathtub, swimming pool).

• Always use the AC adapter and batteries that are approved for your Tablet PC.

• Avoid exposure to sand, dust and other environmental hazards.

• Do not expose your Tablet PC to direct sunlight for long periods of time as temperatures above 140° F (60° C)

may damage your Tablet PC.

• Do not put heavy or sharp objects on the computer.

Cleaning your Tablet PC

• Always disconnect the power plug. (Pull the plug, not the cord.)

• Clean your STYLISTIC Tablet PC with a damp, lint-free cloth. Do not use abrasives or solvents.

• Use a soft cloth to remove dust from the screen. Never use glass cleaners.

• Always shut down the computer, unplug the power adapter, and remove the battery when cleaning or

disinfecting the computer exterior or LCD display.

Cleaning guidelines using recommended off-the-shelf cleaners Computer exterior. To clean the exterior, use one of the following off-the-shelf products:

• Office Depot® #154-616 Notebook Cleaning Kit

• Meridrew Enterprises Klear Screen® Wipes

• 3M CL563 Cleaner Wipes

Note: After cleaning with one of these products, gently polish with a dry, soft, lint-free cloth until the solution is no longer visible.

Disinfecting STYLISTIC computers

Wipe the surface with a soft cloth wipe and a 50% ethanol solution or use another ethanol-based germicide which has been registered as a hospital disinfectant by the EPA.

- Caring for your Tablet PC

• USE OF INCORRECT CLEANERS CAN RESULT IN OPTICAL IMPAIRMENT OF THE LCD AND/OR DAMAGE TO THE COMPUTER. ALWAYS REFER TO THE

CLEANER MANUFACTURER'S GUIDELINES AND MATERIAL SAFETY DATA SHEETS FOR PROPER HANDLING AND USE OF THE PRODUCTS.

• NEVER USE AMMONIA, ACIDIC, OR ALKALINE CLEANERS OR ORGANIC CHEMICALS SUCH AS PAINT THINNER, ACETONE, PROPYL OR ISOPROPYL

ALCOHOL, OR KEROSENE. IT MAY DAMAGE SURFACE FINISHES AND THE COATING OF THE LCD SCREEN.

• NEVER USE COMPRESSED AIR FOR CLEANING YOUR COMPUTER.

Storing your Tablet PC

• If storing your Tablet PC for a month or longer, turn it off, fully charge the battery, then remove and store all

Lithium Polymer batteries.

• Store your Fujitsu STYLISTIC in a cool, dry location. Temperatures should remain between 13ºF (-25ºC) and

140ºF (60ºC).

• Store your tablet and batteries separately. If you store your system with a battery installed, the battery will

discharge, and battery life will be reduced. In addition, a faulty battery might damage your system.

• ALWAYS POWER OFF THE COMPUTER BEFORE TRANSPORTING AND/OR PACKAGING IT. AFTER SHUTTING DOWN THE SYSTEM, WAIT UNTIL THE STATUS

LED

PANEL INDICATES POWER OFF CONDITION (I.E., NO LIGHTS ARE ILLUMINATED).

• IT IS POSSIBLE THAT THE UNIT MAY NOT AUTOMATICALLY GO TO POWER OFF OR HIBERNATE MODE WHEN YOU CLOSE THE LID. THIS SITUATION MAY

OCCUR DUE TO PRE-OS BOOT PASSWORD SECURITY SETTINGS OR SOME OTHER APPLICATION RUNNING ON THE COMPUTER.

• ATTEMPTING TO TRANSPORT THE COMPUTER WHILE POWER IS ON MAY DAMAGE THE TABLET PC DUE TO SHOCK OR OVERHEATING.

Traveling with your Tablet PC

• Do not transport your Tablet PC while it is turned on.

• You should carry your Tablet PC with you while traveling, rather than checking it in as baggage.

• Never put your Tablet PC through a metal detector; have it hand-inspected by security personnel. You can

however, put your Tablet PC through a properly tuned X-ray machine. To avoid problems, place it close to the entrance of the machine and remove it as soon as possible or have it hand-inspected by security personnel. Security officials may require you to turn your system on, so make sure you have a charged battery on hand.

- Caring for your Tablet PC

• Take the necessary plug adapters if you're traveling overseas. Check the following diagram to determine which

plug adapter you'll need or ask your travel agent.

Outlet Type Location Outlet Type Location

United States, Canada, parts of Latin America, Mexico, Japan, Korea, the Philippines, Taiwan

Russia and the Commonwealth of Independent

States (CIS), most of Europe, parts of Latin

America, the Middle East, parts of Africa,

Hong Kong, India, most of South Asia

United Kingdom, Ireland, Malaysia,

Singapore, parts of Africa

China, Australia, New Zealand

Batteries

Caring for your Battery

• Always handle batteries carefully.

• Do not short-circuit the battery terminals (that is, do not touch both terminals with a metal object). Do not

carry lose batteries in a pocket or purse where they may mix with coins, keys, or other metal objects. Doing so may cause an explosion or fire.

• Do not drop, puncture, disassemble, mutilate or incinerate the battery.

• Recharge batteries only as described in this manual and only in ventilated areas.

• Do not leave batteries in hot locations for more than a day or two. Intense heat can shorten the battery life.

• Do not leave a battery in storage for longer than 6 months without recharging it.

Increasing Battery Life

• Power your Tablet PC through the AC or optional auto/airline adapter whenever possible.

• If your tablet runs on battery power all day, connect it to an AC adapter overnight to recharge it.

• Keep brightness to the lowest level comfortable.

- Caring for your Tablet PC

• Set the power management for maximum battery life.

• Put your Tablet PC in Sleep mode when it is turned on and you are not actually using it.

• Limit your media drive access.

• Disable the Media Player auto insert notification function.

Media Care

Caring for your Media (when optional external optical drive is installed)

Media discs are precision devices and will function reliably if given reasonable care.

• Always store your media disc in its case when it is not in use.

• Always handle discs by the edges and avoid touching the surface.

• Avoid storing any media discs in extreme temperatures.

• Do not bend or scratch media discs or set heavy objects on them.

• Do not spill liquids or get dust on media discs.

• Never write on the label surface with a ballpoint pen or pencil. Always use a felt pen.

• If a disc is dirty, use only a DVD/CD cleaner or wipe it with a clean, soft, lint free cloth starting from the inner

edge and wiping to the outer edge.

• If a disc is subjected to a sudden temperature change, condensation may form on the surface. Wipe moisture

off with a soft, lint free cloth and let it dry at room temperature. DO NOT use a hair dryer or heater to dry discs.

Caring for an Optional Optical Drive

An optional optical drive is durable but you must treat it with care. Please pay attention to the following points:

• The drive rotates the compact disc at a very high speed. Do not carry it around or subject it to shock or vibration

with the power on.

• Avoid using or storing the drive where it will be exposed to extreme temperatures.

• Avoid using or storing the drive where it is damp or dusty.

• Avoid using or storing the drive near magnets or devices that generate strong magnetic fields.

• Avoid using or storing the drive where it will be subjected to shock or vibration.

• Do not disassemble or dismantle the optical drive.

• Use of a commercially available lens cleaner is recommended for maintenance of your drive.

- Caring for your Tablet PC

Secure Digital Cards

Caring for your Cards

Secure Digital Cards are durable, but you must treat them with care. The documentation supplied with your card will provide specific information, but you should pay attention to the following points:

• To keep out dust and dirt, store cards in their protective sleeves when they are not installed.

• Avoid prolonged exposure to direct sunlight or excessive heat.

• Keep the cards dry.

• Do not flex or bend the cards, and do not place heavy objects on top of them.

• Do not force cards into the slot.

• Avoid dropping cards, or subjecting them to excessive vibration.

- Caring for your Tablet PC

Chapter 6

AOUXXXXXXXXXXXXX

STQ552, AtomN2600, W7Pro, 64GB, 2G, WLAN, 10.1WXGA

FPC P/N: Q552-64GB-01

Configuration P/N:

Hard Drive

Part Number

Processor

Model #

MemoryOperating System Screen Size/Type

Configuration ID

Communications

System Specifications

Specifications

This section provides the hardware and environmental specifications for your Fujitsu STYLISTIC Tablet PC. Specifications of particular configurations will vary.

Configuration Label

The configuration label located on the bottom of your Tablet PC contains specific information regarding the options you’ve chosen for your Tablet PC. Following is an example configuration label.

Microprocessor

Intel® Atom™ N2600 processor (1.6 GHz)

Chipset

• Intel NM10

Memory

System Memory

• DDR3-800 MHz SDRAM memory module.

• Fixed 2GB of total memory (onboard).

Cache Memory

1 MB L2 cache on-die

Video

Video Color and Resolution Anti-glare 10.1" Wide XGA LED backlit IPS display

• Internal: 1280 x 800 pixel resolution, 16M colors

• External: 1280x720 pixel resolution, 16M colors

• Simultaneous: 1280 x 800, 16M colors

• 160° vertical and horizontal viewing angles

Digitizer

N-trig® DuoSense® technology. Dual Digitizer, consisting of active digitizer and capacitive touch panel (uses active stylus input and up to four finger touch input).

Video RAM

Intel® GMA3650 video graphics controller with 3D Accelerator. Maximum 760 MB UMA VRAM

- Specifications

Audio

• Realtek codec ALC269

• Headphones: Stereo headphone jack, 3.5 mm, 1 V

or less, minimum impedance 32 Ohms

rms

• One built-in speaker, 18 mm diameter

• Two built-in noise-cancelling dual analog microphones

Mass Storage Device Options

Hard Drive

• FDE Solid State Drive, mSATA/300 (3.0 Gbps), 64 GB, with TRIM command support

Communications

• WLAN: Ralink RT3572 802.11a/b/g/n Wireless LAN USB Device

• Bluetooth: Broadcom BCM20702 A1 Bluetooth V 3.0 USB device for wireless personal area network

communication

• WWAN: Optional integrated 3G Wireless Wide Area Network, Gobi3000 (Sierra Wireless AirPrime™ MC8355)

Security Features

Trusted Platform Module

Trusted Platform Module (TPM) installed for added system security.

Fingerprint Recognition Sensor

Swipe sensor for biometric security.

Smart Card Slot

Integrated Smart Card slot (requires third-party application)

- Specifications

Device Ports

On the STYLISTIC Tablet PC:

• SD Card slot

• One USB 2.0 (Universal Serial Bus) connectors for input/output devices

• One DC In connector

• One HDMI connector

• Docking port (100-pin), to dock with optional STYLISTIC Docking Cradle)

• One stereo headphone jack

• 3.0 megapixel rear-facing web camera with auto-focus

• VGA front-facing web camera

On the Optional STYLISTIC Docking Cradle

• Four USB 2.0 connectors for input/output devices

• One DC-in connector

• One docking connector (100-pin, to dock with Tablet PC)

Power

Battery Options

• Lithium Polymer Battery, 2 cells, 7.2V, 19Wh, 2620 mAh

• Lithium Polymer Battery, 4 cells, 7.2V, 38Wh, 5240 mAh

AC Adapter

Autosensing 100-240V AC, supplying 19V DC, 2.1A, 40W to the Tablet PC; includes an AC cable

Power Management

Conforms to ACPI (Advanced Configuration and Power Interface).

- Specifications

Dimensions and Weight

Overall Dimensions

Approximately 10.8" (w) x 7.56" (d) x 0.64" (h) (275 x 192 x 16.2 mm)

Environmental Requirements

Temperature

Operating: 41° to 95° F (5° to 35° C). Non-operating: 5° to 140° F (–15° to 60° C)

Humidity

Operating: 20% to 85%, relative, non-condensing. Non-operating: 8% to 85%, relative, non-condensing

Altitude

Operating: 10,000 feet (3,048 m) maximum

Popular Accessories

For ordering or additional information on Fujitsu accessories please visit our Web site at www.shopfujitsu.com or call 1-800-FUJITSU.

Included Software

Your tablet comes with software for playing audio and video files of various formats. Also included is virus protection software and Power Management software. The following list indicates the software included with your system. Some of these applications will be installed when you run Bonus Apps (See “Installing Bonus Apps” on page 41).

• Adobe® Reader

• FujitsuHL

• OmniPass

Fingerprint application

• CyberLink YouCam

• N-act™ multi-touch gesture

- Specifications

• Norton Internet Security™ (60-day free trial)

• Microsoft Office Starter 2010

• Microsoft Windows Live Essentials

Learning About Your Software

Tutorials

All operating systems and most application software have tutorials built into them upon installation. We highly recommend that you step through the tutorial before you use an application.

Manuals

Included with your Tablet PC you will find manuals for your installed operating system and other pre-installed software. Any manuals that are not included, are available online through the help system of the software. We recommend that you review these manuals for general information on the use of these applications.

Adobe Reader

The Adobe Reader allows you to view, navigate, and print PDF files from across all of the major computing platforms.

FujitsuHL

FujitsuHL provides a variety of tools and shortcuts to commonly-used applications and utilities. Among the features offered by FujitsuHL are the camera application for use with the built-in web camera, a calculator, and links to applications such as Explorer.

OmniPass® Fingerprint application

The fingerprint sensor uses Softex OmniPass which provides password management capabilities to Microsoft Windows operating systems. OmniPass lets you use a “master password” for all Windows, applications, and on-line passwords, and presents a convenient user interface through which you can securely manage passwords, users, and multiple identities for each user.

CyberLink YouCam

CyberLink YouCam allows you to capture photos or movies on the embedded webcam, add special effects to them, and share them in a variety of formats or via social networks.

- Specifications

N-act™ Multi-Touch Gesture Support

N-act™ multi-touch gesture support allows you to perform general gesture actions as well as a variety of advanced gesture actions. N-act employs 1-, 2-, 3-, and 4-finger gesture support.

Norton Internet Security

Your system is preinstalled with a free 60-day trial version of Symantec’s Norton Internet Security™. Norton Internet Security is a suite of tools designed to protect your LIFEBOOK notebook from computer viruses, hackers, spyware, and spam. It assists in the protection of data currently on your hard disk from destruction or contamination. The trial version is activated upon your acceptance of software license agreement. After 60 days, you will need to purchase a subscription from Symantec to download latest virus, spyware, and spam definitions.

Microsoft Windows Live Essentials

Windows Live Essentials is a suite of programs that make it easier and more enjoyable to use your LIFEBOOK. Live Essentials consists of 6 applications: Messenger, Photo Gallery, Writer, Mail, Movie Maker, and Silverlight. Messenger lets you quickly communicate and interact with individuals and groups. Photo Gallery is a flexible application that lets you organize, edit, and share your photos. Writer can be used to generate blog entries, upload videos and photos to your blogs, and publish your entries online. Mail makes it easy for you to manage your email accounts. Movie Maker makes great-looking movies and slideshows from your videos and photos. It’s simple to import standard or high definition video and photos, and then have AutoMovie add animations, music, and a title in minutes. Silverlight powers rich application experiences and delivers high quality, interactive video across the Web and mobile devices.

Microsoft Office Starter 2010 (32-bit)

Microsoft Office Starter 2010 includes reduced-functionality versions of Microsoft Word and Microsoft Excel that include advertising. Microsoft PowerPoint, Microsoft Outlook, and Microsoft Publisher are not included. Customers must purchase an Office 2010 Disc, PKC (Product Key Card), or select one of the full Microsoft Office 2010 suites to activate full-featured Office software on the PC.

Fujitsu offers a PKC (Product Key Card) for Microsoft Office Home and Student 2010 and Microsoft Office Home and Business 2010 (32-bit). Simply enter your product key and you’re ready to go!

Another option is to purchase a full Microsoft Office 2010 suite from either your computer reseller or online from Microsoft.

- Specifications

Operating System

The following operating system configuration is installed on your system:

Microsoft Windows 7 Professional Edition

- Specifications

Glossary

AC Adapter

A device which converts the AC voltage from a wall outlet to the DC voltage needed to power your STYLISTIC Tablet PC.

Access point

Wireless network device used to bridge wireless and wired network traffic.

ACPI

Advanced Configuration and Power Interface

Active-Matrix Display

A type of technology for making flat-panel displays which has a transistor or similar device for every pixel on the screen.

Ad Hoc Mode

Ad Hoc Mode refers to a wireless network architecture where wireless network connectivity between multiple computers is established without a central wireless network device, typically known as Access Points. Connectivity is accomplished using only client devices in a peer-to-peer fashion.

ADSL

Asymmetric Digital Subscriber Line. Technology for transporting high bit-rate services over ordinary phone lines.

Auto/Airline Adapter

A device which converts the DC voltage from an automobile cigarette lighter or aircraft DC power outlet to the DC voltage needed to power your STYLISTIC Tablet PC.

BIOS

Basic Input-Output System. A program and set of default parameters stored in ROM which tests and operates your STYLISTIC Tablet PC when you turn it on until it loads your installed operating system from disk. Information from the BIOS is transferred to the installed operating system to provide it with information on the configuration and status of the hardware.

Bit

An abbreviation for binary digit. A single piece of information which is either a one (1) or a zero (0).

bps

An abbreviation for bits per second. Used to describe data transfer rates.

Boot

To start-up a computer and load its operating system from disk, ROM or other storage media into RAM.

Bus

An electrical circuit which passes data between the CPU and the sub-assemblies inside your STYLISTIC Tablet PC.

Byte

8 bits of parallel binary information.

Cache Memory

A block of memory built into the micro-processor which is much faster to access than your system RAM and used in specially structured ways to make your overall data handling time faster.

Channel

Range of narrow-band frequencies used by the WLAN device to transmit data. IEEE802.11b/g - 11 channels, 22 MHz wide channels.

Command

An instruction which you give your operating system.

Configuration

The combination of hardware and software that makes up your system and how it is allocated for use.

CRT

Cathode Ray Tube. A display device which uses a beam of electronic particles striking a luminescent screen. It produces a visual image by varying the position and intensity of the beam.

Data

The information a system stores and processes.

Direct current. A voltage or current that does not fluctuate periodically with time.

Default Value

A pre-programmed value to be used if you fail to set your own.

DHCP

Dynamic Host Configuration Protocol. Used to automatically acquire parameters for communication, such as IP address. The sender of IP address is called a DHCP server; the receiver is called a DHCP client.

DIMM

Dual-in-line memory module.

Disk

A spinning platter of magnetic data storage media.

Disk Drive

The hardware which spins the disk and has the heads and control circuitry for reading and writing the data on the disk.

DMA

Direct Memory Access. Special circuitry for memory to memory transfers of data which do not require CPU action.

DMI

Desktop Management Interface. A standard that provides PC management applications with a common method of locally or remotely querying and configuring PC computer systems, hardware and software components, and peripherals.

DNS

Domain Name System. A function to control the association between the IP address and the name assigned to the computer. If you do not know the IP address but if you know the computer name, you can still communicate to that computer.

Driver

A computer program which converts application and operating system commands to external devices into the exact form required by a specific brand and model of device in order to produce the desired results from that particular equipment.

ECP

Extended Capability Port. A set of standards for high speed data communication and interconnection between electronic devices.

Encryption Key (Network Key)

Data encryption key used to encrypt message text and for computing message integrity checks. Data encryption protects data from unauthorized viewing.

This device uses the same encryption key to encode and decode the data, and the identical encryption key is required between the sender and receiver.

ESD

Electro-Static Discharge. The sudden discharge of electricity from a static charge which has built-up slowly. Example: the shock you get from a doorknob on a dry day or the sparks you get from brushing hair on a dry day.

FCC

Federal Communications Commission.

Gigabyte. One billion bytes.

Hard drive

A spinning platter of magnetic data storage media where the platter is very stiff.

I/O

Input/Output. Data entering and leaving your Tablet PC in electronic form.

I/O Port

The connector and associated control circuits for data entering and leaving your system in electronic form.

IEEE802.11a

Wireless LAN standard that supports a maximum data rate of 54 Mbps. 802.11a devices operate in the 5 GHz lower and middle UNII bands.

IEEE802.11b

Wireless LAN standard that supports a maximum data rate of 11 Mbps. 802.11b devices operate in the 2.4 GHz ISM band.

IEEE802.11g

Wireless LAN standard that supports a maximum data rate of 54 Mbps. 802.11g devices operate in the 2.4 GHz ISM band.

IEEE802.11n

Wireless LAN standard that supports a maximum data rate of up to 150 Mbps. 802.11n devices operate in the 2.4 and 5 GHz ISM bands.

Infrastructure

A name of a wireless LAN configuration. This type of communication uses an access point. Another type of communication is called Ad Hoc.

IP Address

An identifier for a computer or device on a TCP/IP network. Networks using the TCP/IP protocol route messages based on the IP address of the destination. The format of an IP address is a 32-bit numeric address written as four numbers separated by periods. Each number can be zero to 255. For example, 1.160.10.240 could be an IP address.

Within an isolated network, you can assign IP addresses at random as long as each one is unique. However, connecting a private network to the Internet requires using registered IP addresses (called Internet addresses) to avoid duplicates.

The four numbers in an IP address are used in different ways to identify a particular network and a host on that network. Three regional Internet registries -- ARIN, RIPE NCC and APNIC -- assign Internet addresses from the following three classes.

Class A - supports 16 million hosts on each of 126 networks Class B - supports 65,000 hosts on each of 16,000 networks Class C - supports 254 hosts on each of 2 million networks The number of unassigned Internet addresses is running out, so a new classless scheme called CIDR is gradually

replacing the system based on classes A, B, and C and is tied to adoption of IPv6.

Kilobyte. One thousand bytes.

LAN

Local Area Network. An interconnection of computers and peripherals within a single limited geographic location which can pass programs and data amongst themselves.

LCD

Liquid Crystal Display. A display type that makes images by controlling the orientation of crystals in a crystalline liquid.

Lithium Polymer Battery

Lithium Polymer (LiPoly) batteries are a type of rechargeable battery that has a high power-time life for its size and is not subject to the memory effect as Nickel Cadmium batteries. LiPoly batteries evolved from Lithium-ion battery technology, with the difference being how the electrolyte is stored. In Lithium-ion batteries, the electrolyte is stored in an organic solvent; in LiPoly batteries, it is stored in a solid polymer composite. The advantages of LiPoly over Lithium-ion include lower cost, better adaptability, reliability, and ruggedness.

MAC Address

Media Access Control Address. A unique physical address of a network card. For Ethernet, the first three bytes are used as the vendor code, controlled and assigned by IEEE. The remaining three bytes are controlled by each vendor (preventing overlap), therefore, every Ethernet card is given a unique physical address in the world, being assigned with a different address from other cards. For Ethernet, frames are sent and received based on this address.

Megabyte. One million bytes.

Memory

A repository for data and applications which is readily accessible to your STYLISTIC Tablet PC’s CPU.

MHz / Megahertz

1,000,000 cycles per second.

Monaural

A system using one channel to process sound from all sources.

MTU

Maximum Transmission Unit The maximum data size that can be transferred at a time through the Internet or other networks. You can set a

smaller MTU size to obtain successful communication, if you have difficulty transferring data due to the fact that the maximum size is too large.

Network key

Data that is used for encrypting data in data communication. The personal computer uses the same network key both for data encryption and decryption, therefore, it is necessary to set the same network key as the other side of communication.

Network name (SSID: Service Set Identifier ) When a wireless LAN network is configured, grouping is performed to avoid interference or data theft. This grouping

is performed with “Network name (SSID)”. In order to improve security, the network key is set allowing no communication unless “Network name (SSID)” coincides with the network key.

NTSC

National TV Standards Commission. The standard for TV broadcast and reception for the USA.

Operating System (OS)

A group of control programs that convert application commands, including driver programs, into the form required by a specific brand and model of CPU in order to produce the desired results from that equipment.

Partition

A block of space on a hard drive which is set aside and made to appear to the operating system as if it were a separate disk, and addressed by the operating system accordingly.

Peripheral Device

A piece of equipment which performs a specific function associated with but not integral to a computer. Examples: a printer, a modem, a CD-ROM.

Pitch (keyboard)

The distance between the centers of the letter keys of a keyboard.

Pixel

The smallest element of a display, a dot of color on your display screen. The more pixels per area the clearer your image will appear.

POST

Power On Self Test. A program which is part of the BIOS which checks the configuration and operating condition of your hardware whenever power is applied to your Tablet PC. Status and error messages may be displayed before the operating system is loaded. If the self test detects failures that are so serious that operation cannot continue, the operating system will not be loaded.

PPPoE

Point to Point Protocol over Ethernet. A protocol for Ethernet, using a Point-to-Point Protocol (PPP), which is used for connection on the phone line.

Program

An integrated set of coded commands to your computers telling your hardware what to do and how and when to do it.

Protocol

Procedures and rules use to send and receive data between computers.

- Method of sending and receiving data

- Process used to handle communication errors Conditions required for communication are organized in procedures for correct transfer of information.

RAM

Random Access Memory. A hardware component of your Tablet PC that holds binary information (both program and data) as long as it has the proper power applied to it.

RAM Module

A printed circuit card with memory and associated circuitry which allows the user to add additional memory to the computer without special tools.

Reset / Restart

The act of reloading the operating system. A reset erases all information stored in RAM.

Resume

To proceed after interruption. In your Tablet PC this refers to returning to active operation after having been in one of the suspension states.

ROM

Read Only Memory. A form of memory in which information is stored by physically altering the material. Data stored in this way cannot be changed by your Tablet PC and does not require power to maintain it.

SDRAM

Synchronous Dynamic Random Access Memory.

Serial Port

A connection to another device through which data is transferred one bit at a time on a single wire with any other wires only for control of the device not for transfer of data.

Shared key authentication

802.11 network authentication method in which the AP sends the client device a challenge text packet that the client must then encrypt with the correct WEP key and return to the AP. If the client has the wrong key or no key, authentication will fail and the client will not be allowed to associate with the AP. Shared key authentication is not considered secure, because a hacker who detects both the clear-text challenge and the same challenge encrypted with a WEP key can decipher the key.

SSID

Service Set Identifier, a 32-character unique identifier attached to the header of packets sent over a WLAN that acts as a password when a mobile device tries to connect to the BSS. The SSID differentiates one WLAN from another, so all access points and all devices attempting to connect to a specific WLAN must use the same SSID. A device will not be permitted to join the BSS unless it can provide the unique SSID. Because the SSID is broadcast in plain text, it does not supply any security to the network.

Status Indicator

A display which reports the condition of some portion of your hardware. On your STYLISTIC Tablet PC this is an LCD screen just above the keyboard.

Stereo (audio)

A system using two channels to process sound from two different sources.

Subnet mask

TCP-IP network is controlled by being divided into multiple smaller networks (subnets). IP address consists of the subnet address and that of each computer. Subnet mask defines how many bits of IP address comprise the subnet address; the same value will be set among computers communicating with each other.

System Clock

An oscillator of fixed precise frequency which synchronizes the operation of the system and is counted to provide time of day and date.

TCP/IP

Transmission Control Protocol/Internet Protocol. A standard Internet protocol that is most widely used.

TFT

Thin Film Transistor – A technology for flat display panels which uses a thin film matrix of transistors to control each pixel of the display screen individually.

Underwriters Laboratories – Independent organization that tests and certifies electrical safety of devices.

USB

Universal Serial Bus. Standard that allows you to simultaneously connect up to 127 USB devices such as game pads, pointing devices, printers, and keyboards to your computer.

VRAM

Video Random Access Memory. A memory dedicated to video display data and control.

WFM

Wired for Management is Intel’s broad-based initiative to reduce the total cost of ownership (TCO) of business computing without sacrificing power and flexibility.

Wi-Fi Compatible

Wi-Fi (Wireless Fidelity) Identifies that the product has passed the interoperability test, supplied by the WECA (Wireless Ethernet Compatibility Alliance), which guarantees the interoperability of wireless IEEE 802.11 LAN products.

WLAN

Wireless Local Area Network. A wireless interconnection of computers and peripherals within a single limited geographic location which can pass programs and data amongst themselves.

Regulatory Information

Notice

Changes or modifications not expressly approved by Fujitsu could void this user’s authority to operate the equipment.

FCC NOTICES

Notice to Users of Radios and Television

This equipment has been tested and found to comply with the limit for class B digital devices, pursuant to parts 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet that is on a different circuit than the receiver.

• Consult the dealer or an experienced radio/TV technician for help.

Shielded interconnect cables must be employed with this equipment to ensure compliance with the pertinent RF emission limits governing this device.

DOC (INDUSTRY CANADA) NOTICES

Notice to Users of Radios and Television

This class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de classe B respecte la norme canadienne ICES-003.

- Regulatory Information

Appendix A: WLAN User’s Guide

FCC Regulatory Information

Please note the following regulatory information related to the optional wireless LAN device.

Regulatory Notes and Statements

Wireless LAN, Health and Authorization for use

Radio frequency electromagnetic energy is emitted from Wireless LAN devices. The energy levels of these emissions, however, are far much less than the electromagnetic energy emissions from wireless devices such as mobile phones. Wireless LAN devices are safe for use by consumers because they operate within the guidelines found in radio frequency safety standards and recommendations. The use of Wireless LAN devices may be restricted in some situations or environments, such as:

• On board an airplane, or

• In an explosive environment, or

• In situations where the interference risk to other devices or services is perceived or identified as harmful.

In cases in which the policy regarding use of Wireless LAN devices in specific environments is not clear (e.g., airports, hospitals, chemical/oil/gas industrial plants, private buildings), obtain authorization to use these devices prior to operating the equipment.

Regulatory Information/Disclaimers

Installation and use of this Wireless LAN device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications made to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment. The manufacturer is not responsible for any radio or television interference caused by unauthorized modification of this device, or the substitution or attachment of connecting cables and equipment other than those specified by the manufacturer. It is the responsibility of the user to correct any interference caused by such unauthorized modification, substitution or attachment. The manufacturer and its authorized resellers or distributors will assume no liability for any damage or violation of government regulations arising from failure to comply with these guidelines.

This device must not be co-located or operated in conjunction with any other antenna or transmitter.

For IEEE 802.11a Wireless LAN: For operation within 5.15~5.25 GHz frequency range, it is restricted to indoor environments, and the antenna of this device must be integral.

Federal Communications Commission statement

This device complies with Part 15 of FCC Rules.

Operation is subject to the following two conditions: (1) This device may not cause interference, and, (2) This device must accept any interference, including interference that may cause undesired operation of this device.

FCC Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures:

1 Reorient or relocate the receiving antenna. 2 Increase the distance between the equipment and the receiver. 3 Connect the equipment to an outlet on a circuit different from the one the receiver is connected to. 4 Consult the dealer or an experienced radio/TV technician for help.

FCC Radio Frequency Exposure statement

The available scientific evidence does not show that any health problems are associated with using low power wireless devices. There is no proof, however, that these low power wireless devices are absolutely safe. Low power wireless devices emit low levels of radio frequency energy (RF) in the microwave range while being used. Whereas high levels of RF can produce health effects (by heating tissue), exposure to low-level RF that does not produce heating effects causes no known adverse health effects. Many studies of low-level RF exposure have not found any biological effects. Some studies have suggested that some biological effects might occur, but such findings have not been confirmed by additional research.

The wireless LAN radio device has been tested and found to comply with FCC radiation exposure limits set forth for an uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65.

Export restrictions

This product or software contains encryption code which may not be exported or transferred from the US or Canada without an approved US Department of Commerce export license. This device complies with Part 15 of FCC Rules., as well as ICES 003 B / NMB 003 B. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesirable operation. Modifications not expressly authorized by Fujitsu America, Inc. may invalidate the user's right to operate this equipment.

Canadian Notice

The device for the 5150 - 5250 MHz band is only for indoor usage to reduce the potential for harmful interference to co-channel mobile satellite systems.

The maximum antenna gain of 6 dBi permitted (for devices in the 5250 - 5350 MHz, 5470 - 5725 MHz and 5725 - 5825 MHz bands) to comply with the e.i.r.p. limit as stated in A9.2 of RSS210.

In addition, users are cautioned to take note that high power radars are allocated as primary users (meaning they have priority) of 5250 5350 MHz and 5650 - 5850 MHz and these radars could cause interference and/or damage to LE-LAN devices.

Before Using the Optional Wireless LAN

This manual describes the procedures required to properly set up and configure the optional integrated Wireless LAN USB device (referred to as “WLAN device” in the rest of the manual). Before using the WLAN device, read this manual carefully to ensure its correct operation. Keep this manual in a safe place for future reference.

Wireless LAN Device Covered by this Document

This document is applicable to systems containing the following device:

• Integrated Ralink RT3572 802.11a/b/g/n Wireless LAN USB Device

Characteristics of the WLAN Device

• The WLAN device is a USB module attached to the main board of the mobile computer.

• The WLAN device operates in license-free RF bands, eliminating the need to procure an FCC operating license.

The WLAN operates in the 2.4GHz Industrial, Scientific, and Medical (ISM) RF band and the lower, middle, and upper bands of the 5GHz Unlicensed National Information Infrastructure (UNII) bands.

• The WLAN devices are capable of four operating modes, IEEE802.11a, IEEE802.11b, IEEE802.11g, and

IEEE802.11n

• The WLAN devices are Wi-Fi certified and operate (as applicable) at a the maximum data rate of 150 Mbps

(theoretical) in IEEE802.11n mode; 54 Mbps in IEEE802.11a or IEEE802.11g mode; and 11 Mbps in IEEE802.11b mode.

• The WLAN devices support the following encryption methods - WEP, TKIP, CKIP, and AES encryption.

• The Wireless LAN devices are compliant with the following standards: WPA, WPA2, CCX1.0, CCX2.0, CCX3.0,

CCX4.0, and CCX5.0.

- Before Using the Optional Wireless LAN

Wireless LAN Modes Using this Device

Ad Hoc Mode

“Ad Hoc Mode” refers to a wireless network architecture where wireless network connectivity between multiple computers is established without a central wireless network device, typically known as Access Point(s). Connectivity is accomplished using only client devices in a peer-to-peer fashion. That is why Ad Hoc networks are also known as peer-to-peer networks. Ad Hoc networks are an easy and inexpensive method for establishing network connectivity between multiple computers. Ad Hoc mode requires that the SSID, network authentication, and encryption key settings are identically configured on all computers in the Ad Hoc network.

Figure 23. Ad Hoc Mode Network

- Before Using the Optional Wireless LAN

Access Point (Infrastructure) Mode

ADSL modem, cable modem, or similar

Internet

Wired LAN

Access Point*

Wireless LAN

*An optional hub for a wired LAN may be required depending upon the type of access point used.

Infrastructure mode refers to a wireless network architecture in which devices communicate with wireless or wired network devices by communicating through an Access Point. In infrastructure mode, wireless devices can communicate with each other or with a wired network. Corporate wireless networks operate in infrastructure mode because they require access to the WLAN in order to access services, devices, and computers (e.g., file servers, printers, databases).

Figure 24. Access Point (Infrastructure) Mode Network

- Before Using the Optional Wireless LAN

How to Handle This Device

The WLAN device is an optional device that may come pre-installed in your mobile computer. Under normal circumstances, it should not be necessary for you to remove or re-install it. The operating system that your mobile computer comes with has been pre-configured to support the WLAN device.

• The Wireless LAN devices support IEEE802.11a, IEEE802.11b, IEEE802.11g, and IEEE802.11n.

• The WLAN devices operate in the 2.4 GHz ISM band and the 5 GHz lower, middle, and upper UNII bands.

• Microwave ovens may interfere with the operation of WLAN devices since they operate in the same 2.4 GHz

frequency range as IEEE802.11b/g/n devices. Interference by microwaves does not occur with IEEE802.11a radio which operates in the 5 GHz RF band.

• Wireless devices that transmit in the 2.4 GHz range may interfere with operation of WLAN devices in

IEEE802.11b/g/n modes. Symptoms of interference include reduced throughput, intermittent disconnects, and many frame errors. It is HIGHLY recommended that these interfering devices be powered off to ensure proper operation of the WLAN device.

Deactivating/Disconnecting the WLAN Device

Disconnecting the WLAN device may be desired in certain circumstances (to extend battery life) or where certain environments require it (i.e. hospitals, clinics, airplanes, etc.). The WLAN device can be deactivated by using the Wireless On/Off Switch, and it can be disconnected in Windows using the WLAN icon in the system tray (Note that disconnecting via the icon in the system tray does not turn off the radio; it continues to transmit and receive even though it’s not connected.)

- Before Using the Optional Wireless LAN

Deactivation Using the Wireless On/Off Switch

Wireless Device Switch

The WLAN device can be deactivated quickly and efficiently by toggling the Wireless Device On/Off Switch to the Off position. The switch has no effect on non-Wireless LAN models.

Figure 25. Wireless LAN/Bluetooth On/Off Switch Location

Disconnection Using the Icon in the Taskbar

Note that disconnecting via the icon in the system tray does not turn off the radio; it continues to transmit and receive even though it’s not connected.

1 Right-click the WLAN icon in the taskbar at the bottom right of your screen. 2 Choose Disconnect from a network.

Activating the WLAN Device

Activation of the WLAN device can be accomplished using the same methods as the deactivation process

• Using the Wireless On/Off Switch

• In Windows, by right-clicking the WLAN icon then clicking “Connect to a network”

- Before Using the Optional Wireless LAN

Configuring the Wireless LAN

The WLAN device can be configured to establish wireless network connectivity using the software that is built into Windows. Support for most industry standard security solutions is contained in this software.

Pre-defined parameters are required for this procedure; consult with your network administrator for the parameters.

Configuring the WLAN

1 Click the Start button, then select Control Panel. 2 If the Control Panel is not in Classic View, select Classic View from the left panel. Double-click the Network

Connections icon.

3 Double-click on the Wireless Network Connection icon. 4 Click on [View Wireless Networks]. 5 Choose a wireless network. 6 Click [Connect]. 7 Enter the Network Key, if required. 8 Enter any required information. It may be necessary to consult with your network administrator for some of the

information.

9 If you require assistance, go to [Start] -> Help and Support -> Networking and the Web. Select the main topic in

which you are interested, then type in relevant keywords in the Search box.

Connection to the network

After you have configured your computer, you can connect to an active network by performing the following steps:

1 Click on the WLAN icon in the system tray. 2 Select “Connect to a network”. 3 Select a network from the list that appears, and click the [Connect] button.

After you have configured your computer, you can connect to an active network by clicking on the Wireless Network icon in the system tray.

- Configuring the Wireless LAN

Troubleshooting the WLAN

Troubleshooting

Causes and countermeasures for troubles you may encounter while using your wireless LAN are described in the following table. If you are unfamiliar with the steps required, consult your System Administrator or go to [Start] -> Help and Support -> Networking and the Web

Problem Possible Cause Possible Solution

Unavailable network connection

Incorrect network name (SSID) or network key

Weak received signal strength and/or link quality

The WLAN device has been deactivated or disabled

The computer to be connected is turned off

Ad hoc connection: verify that the network names (SSID’s) and network keys (WEP) of all computers to be connected have been configured correctly. SSID’s and WEP key values must be identical on each machine.

Access Point (Infrastructure) connection: set network name (SSID) and network key to the same values as those of the access point.

Set the Network Authentication value identically to that of the Access Point. Please consult your network administrator for this value, if necessary.
