Fujitsu Q552 Getting Started Guide
Getting Started
Get Started with Your
STYLISTIC® Q552 Tablet PC
This guide will lead you through the start-up process for your new STYLISTIC Tablet PC and will also provide
some valuable tips. To learn about all the exciting features that your new STYLISTIC Tablet PC has to offer,
Ce guide pratique vous explique comment mettre en marche votre nouveau PC Tablette STYLISTIC et vous propose quelques
conseils utiles. Pour savoir comment proter des fonctionnalités inédites dont dispose votre nouveau PC Tablette, veuillez
consulter le guide d’utilisation. Vous pourrez y accéder après avoir effectué la procédure de démarrage initial.
please see the User’s Guide that can be accessed after completing the start-up procedure.
ENGLISH * FRANÇAIS
This convenient guide will lead you through the start-up
process and will also offer some valuable tips.
What’s in the Box
Check to see that all of the following items are in the box:
■ STYLISTIC Tablet PC
■ Getting Started Guide
■ Warranty
■ Removable Battery
■ AC Adapter
■ AC Cable
■ Pen Kit
■ Pen-tether
■ Cleaning Cloth
Depending upon your conguration, the following items may also
be shipped with your notebook:
■ Recovery/ Bootable disc
■ Microsoft Product Identier (bi-fold paper contains Microsoft
Controls, Connectors, and
Access Points
Front Web Camera
Docking Cradle Connector
Ofce product key for activation.
Display
Speaker
DC Input Connector
Power/Suspend/Resume Switch
Pen Tether
Attachment Point
Wireless Device Switch
Application Buttons
Status Indicators
BACK PANEL
Battery Release Latches
Removable Battery
Rear Web Camera
Built-in Microphone
SD Card Slot
Fingerprint Sensor
Built-in Microphone
USB 2.0 Port
SmartCard Slot
Line Out/Headphone Jack
HDMI Port
2
Initial Start Up
Installing a Pen Tether
Pen Cap
AAAA Battery
Pen Barrel
AC Adaptor
DC Power Jack
Wireless Device Switch
1. Install the AAAA-battery into the pen
(see diagram on blister pack) and install
the Pen Tether
■ Push one end of the tether under the slot on the top of
the pen, and then thread the opposite end of the tether
through the loop.
■ Insert the other end of the pen tether through the attach-
ment point on the STYLISTIC® Tablet PC, and feed the pen
through the large loop in the tether.
The lithium polymer battery is not charged upon purchase.
You will need to connect the ac adapter to charge your battery or use your stylistic Tablet pc. It will take approximately
5 hours to initially charge the battery.
There is an indicator on the battery. The indicator color
means: Green: 50% - 100% charge, Orange: 49% - 10%
charge, Red: under 10% charge.
2. Connect AC Power
■ Be sure that you have the battery installed.
■ Plug the AC cord into the AC Adapter.
■ Plug the DC output cable into the DC power jack of your
Tablet PC.
■ Plug the AC adapter into an AC electrical outlet.
3. Turn on Power
■ Slide and release the Power/Suspend/Resume switch.
■ The STYLISTIC Q552 Tablet is now on and the battery is
being charged.
■ The Tablet will begin a power-on self test. Once success-
fully completed, the operating system will begin the
initialization process.
4. Starting Windows® for the First Time
■ Accept the Microsoft® Windows® Licensing Agreement and
the Fujitsu End User License Agreement to proceed. Select
your User ID and Password during the “Welcome Screen.”
Keep a record of your User ID and password stored in a
secure place. THE SCREEN WILL GO DARK FOR SEVERAL
MINUTES. Do not attempt to turn power on or off during
this stage.
5. Connect to the Internet or Network
■ Ensure the Wireless Device Switch is “On.”
■ Register your Tablet with Fujitsu Service and Support
via our website (http://solutions.us.fujitsu.com/www/
content/support/).
This helps us to better serve you.
Power Suspend/Resume
Switch
Before starting next step, check to be sure that your Tablet is
NOT connected to a network or the Internet.
6. Activate Additional Utilities,
Applications, & Drivers
■ You can launch desktop icon “Fujitsu Bonus Apps” to see
if there are any additional application available for the
system. Bonus Apps contains optional applications. You
can select individual or all software that is available.
BonusApps will automatically install for you.
3
7. User’s Guide
■ Your electronic User’s Guide contains important detailed information
about your new computer. You can access your User’s Guide by selecting
its icon from the screen desktop.
■ The User’s Guide will be copied to your hard drive in the C:\Fujitsu\Manual
directory. Shortcuts to the User’s Guide will be placed on your desktop
and in the Start menu.
8. Calibrating the Display
In order to ensure accurate tracking between the stylus and cursor, run the
Calibration Utility before you use the system for the rst time, or after you
change the display resolution. To run the calibration utility:
■ Go to Start -> Control Panel.
■ Double-click the [Tablet PC Settings] icon and select the Display tab.
■ Click the [Calibrate] button, then select whether you want to calibrate
pen input or touch input.
■ Adjust the display of your Tablet PC to a comfortable angle and nd the
(+) symbol in the upper-left corner of the display.
■ Using the stylus or your nger (depending upon which type of input you
are calibrating), touch the screen directly on the (+) symbol. Lift your
stylus/nger from the screen and the target will move to a different loca-
tion on the screen.
■ Repeat until you have selected all of the (+) symbols.
■ Once you have selected all the symbols, press the [Yes] button.
■ Touch your stylus/nger to various points on the screen to verify that the
screen is correctly calibrated. If you are not satised with the screen’s
calibration, press the [Calibrate]) button to begin again.
Do not use e xcessive force when tapping on the screen dur ing calibration. Use of
excessive force could result in damage to the led and/or touch panel.
9. Using the Web Camera(s) (If your model is congured with
one)
The Q552 Tablet PC has a front and a rear facing Web Camera. This allows you
to take pictures of yourself or objects in front of you to send over the internet.
To use the Web Camera(s), rst launch FujitsuHL (Home
Launcher). There are two ways of doing this:
■ Pressing the [Keyboard] button on the PC for two seconds and more, or,
■ Tapping Start > All Programs > FujitsuHL, then selecting FujitsuHL.
To close FujitsuHL, tap the at the right top of the screen.
Application Buttons
The three Tablet PC buttons are located
on the right-hand side of a horizontally-
oriented system. Two of the buttons
have secondary functions. The secondary
functions are activated by pressing and
holding the button.
Ctl-Alt-Del is the only application button
that can be used while the system is logging
on or when the system is locked (i.e., when
you have the logon or computer locked
windows showing on your desktop).
Power Management
Your Fujitsu STYLISTIC Tablet PC has many
options and features for conserving
battery power. Some of these features are
automatic and need no user intervention.
However, others depend on the parameters
you set to best suit your operating
conditions, such as those for the display
brightness. Internal power management
for your Tablet PC may be controlled
from settings made in your operating
system, pre-bundled power management
application, or from settings made in BIOS
setup utility. See your User’s Guide to take
full advantage of these features.
As with all mobile, battery powered
computers, there is a trade-off between
performance and power savings.
Drivers
To check for the latest drivers go to
us.fujitsu.com/computers.
Photo Viewer Button
Home Button Shutter Button Setting Button
Camera Switch Button
4
Once FujitsuHL is launched you can access the Camera Tool by tapping the icon in the lower left corner of your display. The Camera
tool allows you to take and view pictures and modify the settings of the Web Camera(s).
■ Preview Area: This area shows the preview of the scene being viewed by the Web Camera.
■ Home Button: By tapping this button, you can return to the most recently used Launcher screen
■ Photo Viewer Button: By tapping this button, you execute the Photo Viewer to look at your pictures. If some photos have
already been saved, this button icon will be changed to the latest photo image.
■ Shutter Button: By tapping this button, you can take a picture. The pictures will be saved in the Camera folder under Pictures.
The lename contains the date on which the picture was taken.
■ Camera Switch Button: By tapping this button, you can switch between the rear-facing Web Camera and the front-facing Web
Camera.
■ Setting Button: By tapping this button, you can change the brightness, contrast, and color tone of the Web Camera.
Be sure and reference your User’s Guide for complete instructions on how to use FujitsuHL and the Web Camera(s).
To use fujitsuhl, you should set the display resolution to 1280 x 800 dots.
10. Access your User’s Guide
To take advantage of all the features of your new Fujitsu STYLISTIC Tablet PC, it is highly recommended that you review your electronic User’s Guide. It contains important detailed information about your new computer. You can access your User’s Guide by selecting its icon from the screen desktop.
Get Started with your
®
AH532 Notebook
LIFEBOOK
Indicators
Status Display Icons
Shows status of system power and battery.
Icon Mode / State LED state Remarks
Power On state
Idle mode
Sleep
Off State
Hibernate
Charge/DC In
On State
Idle Mode
Sleep
Hibernate
Off State
Blue
Continuousz
Blue,
blinking
Off The system is suspended and settings and data are saved to the hard disk drive
Green AC adapter and battery are available and charged battery level is 50-100%
Orange AC adapter and battery are available and charged battery level is less than 50%
Green,
blinking
Orange,
blinking
Off The AC Adapter is not available
The system is powered on and ready to use.
The system is suspended and saved active settings to RAM
Unit is in suspend mode, AC adapter and battery are available and charged battery
level is 50-100%
Unit is in suspend mode, AC adapter and battery are available and charged battery
level is less than 50%
5
