Operating manual

System

STYLISTIC Q550

Congratulations, you have

innovative Fujitsu product.

decided to buy an

The latest information about our products, useful tips, updates etc. is available from our website: "

For automatic driver updates, go to: "http://support.ts.fujitsu.com/com/support/index.html"

Should you have any technical questions, please contact:

• our Hotline/Service Desk (see Service Desk list or visit:

http://ts.fujitsu.com/support/servicedesk.html")

• Your sales partner

• Your sales ofﬁce

We hope you really enjoy using your new Fujitsu system.

http://ts.fujitsu.com"

Fujitsu Tec

Published by

Fujitsu Technology Solutions Mies-van80807 Munich, Germany

Contact

All rights reserved, including intellectual property rights. Subject to technical alterations. Delivery subject to availability. No warra nty is offered or liability accepted in regard of the completeness, correctness, or cu rr ent app licability of any data or by copyright. Use of these by third parties for their own purposes may constitute an infringement of the holders’ rights. Further information can be found at "

hnology Solutions 2011 04/11

der-Rohe-Straße 8 (Mies-van-der-Rohe Street No. 8)

s.fujitsu.com/support

ttp://t

illustrations. Brand names may be protecte d trademarks of the respective manufacturer and/or protected

http://ts.fujitsu.com/terms_of_use.html"

Order No. Fujitsu Technology Solutions GmbH: A26391-K330-Z320-1-7619, edition 1

STYLISTIC Q550

Operating manual

Innovative technology 7 Ports and controls 9 Important notes 11 First-time setup of your device 17 WorkingwiththeTabletPC 20 Security functions 53 Connecting external devices 60 Settings in BIOS Setup Utility 64 Troubleshooting and tips 67 Technical data 75 Manufacturer’s notes 77 Index 84

Microsoft, MS and Windows are registered tr ademarks of the Microsoft Corporation.

Adobe Reader is a trademark of Adobe Systems Incorporated.

MultiMediaCard is a registered tradem ark of Inﬁneon Technologies AG

Sony and Memory Stick are registered trademarks of Sony Electronics, Inc.

All other trademarks referenced are trademarks or registered trademarks of their respective owners, whose protected rights are acknowledged.

In the event of violations, perpetrators will be liable to prosecution for damages.

Subject to availability and technical modiﬁcations.

Contents

Innovativetechnology ................................................................. 7

Furtherinformation ...................................................................... 7

Notational conventions .................................................................. 8

Portsand controls ..................................................................... 9

Importantnotes ........................................................................ 11

Safetynotes ............................................................................ 11

Additional safety notes for devices with radio components . . . . . ............................. 11

Protecting the display screen ............................................................ 12

Energy saving .......................................................................... 15

Energy saving under Windows ....................................................... 15

TravellingwithyourTablet PC ............................................................ 15

Before you travel ................................................................... 15

TransportingtheTablet PC ........................................................... 16

Cleaning the TabletPC .................................................................. 16

First-time setup

Unpacking and che Selectingalocat Mains adapter co Switchingonthe

Working with theTablet PC ............................................................ 20

Status indicators ........................................................................ 20

Switching on the TabletPC .............................................................. 21

Programming the ON/OFFswitch ..................................................... 21

Switching offthe TabletPC .............................................................. 21

Handwriting recognition under Windows 7 . . . . . ............................................ 22

Touchscreen ............................................................................ 22

Select display orientation (portraitorlandscape orientation) ................................. 23

Using ﬁngers . .......................................................................... 23

Calibrate the Dual Digitizer for ﬁnger-based operation of the device. ..................... 23

Actions with one ﬁnger . . . . ........................................................... 24

Actions with two ﬁngers . . . ........................................................... 24

Actions with three ﬁngers ............................................................ 26

Actions with four ﬁngers ............................................................. 29

Using the styluspen .................................................................... 33

Setting the pen ...................................................................... 34

Calibrating thepen .................................................................. 35

Changing th e pen tip . . .............................................................. 35

Removing the pen battery ............................................................ 36

Installing apen battery ............................................................... 36

Installing apen cord ................................................................. 36

Tablet buttons .......................................................................... 37

Programming the tablet buttons ...................................................... 38

Webcam ............................................................................... 39

Rechargeable battery ................................................................... 39

Charging, caringforand maintaining the battery ....................................... 40

Removing and installing the battery ................................................... 40

Using the power-management features ................................................... 43

Memory cards .......................................................................... 44

ofyourdevice .........................................................

cking the device ......................................................

ion .....................................................................

nnecting . . . . ...........................................................

device for the ﬁrsttime ..................................................

17 18 18 19

Fujitsu Technology Solutions 3

Contents

Supported format .................................................................... 44

Inserting the memorycard ........................................................... 44

Removing the memorycard .......................................................... 45

SIMcard ............................................................................... 45

Inserting the SIMcard ............................................................... 46

Removing aSIM card ............................................................... 46

Wireless LAN /Bluetooth/UMTS ........................................................ 46

Switching the wireless components on and off ......................................... 47

Setting up WLAN access ............................................................ 48

Access via UMTS ................................................................... 48

GPS ................................................................................... 48

Your Crad le (optional) . . . ................................................................ 48

Cradle c omponen ts . . ................................................................ 49

Setting up the Cradle ................................................................ 50

Connecting the Tablet PC to the Cradle . . ............................................. 50

Disconnecting the Tablet PC from the Cradle . ......................................... 52

Security functions ..................................................................... 53

Conﬁguring the ﬁngerprint sensor ........................................................ 53

Conﬁguring password protection in BIOS SetupUtility ...................................... 54

Protecting BIOS Setup Utility (supervisor and user password) . .......................... 54

Password prote ction for booting of the operating system . .............................. 55

Password protectionfortheharddisk ................................................. 56

SmartCard reader ....................................................................... 58

Inserting the SmartCard ............................................................. 58

Trusted Platform Module (TPM) (device-dependent) . . . . . .................................. 59

Enabling TPM ....................................................................... 59

Disabling TPM ...................................................................... 59

Connecting externaldevices ........................................................... 60

HDMIport .............................................................................. 61

Connecting USB devices ................................................................ 62

HowtoremoveUSBdevicescorrectly ................................................ 62

Headphone port . ....................................................................... 63

Settings in BIOS Setup Utility . . ........................................................ 64

Starting the BIOSSetupUtility ........................................................... 64

Operating BIOS SetupUtility ............................................................. 65

Exiting BIOS SetupUtility ................................................................ 66

Exit Saving Changes - save changes and exit BIOS Setup Utility . . . . ................... 66

Exit Discarding Changes – Discard changes and exit BIOS Se tup Utility . . ............... 66

Load Setup Defaults – Copy Standard Entries ......................................... 66

Discard Ch anges – Discard changes without exiting the BIOS Setup Utility ............... 66

Save Ch anges - save changes without exiting the BIOS Setup Utility . ................... 66

Save Changes and Power Off ........................................................ 66

Troubleshooting and tips .............................................................. 67

Help if problemsoccur ................................................................... 67

TheTablet PC’s date or timeisincorrect .................................................. 68

Battery indicatordoesnotilluminate ...................................................... 68

TheTablet PC’s touchscreen remains dark ................................................ 68

The display on the Tablet PC’s touchscreen is difﬁcult to read. .............................. 68

Theexternal monitor remains blank ...................................................... 69

Theexternal monitor isblankortheimageis unstable ..................................... 69

4 Fujitsu Technology Solutions

Contents

The c ursor does not correctly follow the pen movements . . . . . . ............................. 70

Peninputnotworking ................................................................... 70

TheTablet PC does notstartafterswitch on ............................................... 70

TheTablet PC stops working ............................................................. 71

The printer does not print . . . . . ........................................................... 71

The r adio connection to a network does not work . . ........................................ 71

Thebattery dischargestoo quickly ........................................................ 72

SmartCard reader is not recognised. . . . ................................................... 72

SmartCard PIN forgotten ................................................................ 72

SmartCard lost ......................................................................... 72

User and/or supervisor SmartCard lost ................................................... 73

Acoustic warnings ....................................................................... 73

Error messages on thescreen ........................................................... 73

Technicaldata ......................................................................... 75

Tablet PC .............................................................................. 75

Rechargeable battery ................................................................... 76

Mains adapter (40 W) . .................................................................. 76

Cradle (optional) ........................................................................ 76

Manufacturer’s notes .................................................................. 77

Disposal and recycling .................................................................. 77

Declarations of Conformity ............................................................... 77

Tested safety (TS, depending on the device) . . ............................................ 77

CEmarking ............................................................................ 78

Regulatory notices ...................................................................... 78

Regulatory information for Tablet PCs without radio device . ............................. 78

DOC(Industry CANADA) notices ..................................................... 80

FCC Regulatory information for Tablet PCs with radio device . . . ......................... 81

Index .................................................................................. 84

Fujitsu Technology Solutions 5

Contents

6 Fujitsu Technology Solutions

Innovative technology

... a nd ergonomic design make your device a reliable and convenient companion.

The device boots very quickly, is ready for immediate use and offers a particularly long operating time because of its high capacity battery.

The user-friendly "BIOS Setup Utility" offers powerful password prot ection functions which can be used to control your Tablet PC’s hardware and protect your system better against unauthorised use.

Information on the connections and controls for your Tablet PC can be found in chapter "

Ports and controls", Page 9.

Further information

The Windows drivers for your device can be found on our Internet site. The factory installation of your device does not support any other operating system. Fujitsu Technology Solutions accepts no liability whatsoever if any other operating system is use d.

Software oriented components of these instructions refer to Microso ft products, if they come within the scope of the delivery.

If you install other software products, pay attention to the operating instructions of the manufacturer.

Fujitsu Technology Solutions 7

Innovative technology

Notational conventions

Pay particular attention to text marked with this symbol. Failure to observe these warnings could pose a risk to health, damage the device or lead to loss of data. The warra nty will be invalidated if the device becomes defective through failure to observe these warnings.

Indicates important informa

tion for the proper use of the device.

►



This font

"This font"

Key

This font

Indicates an activity that must be performed

Indicates a result

indicates data entered the command line, e .g. start a program (star

indicates information that is displayed on the screen by a program, e.g.:

Installation is complete.

Indicates

• terms and texts used in a software interface, e.g.: Click on Save

• names of programs or ﬁles, e.g. Windows or setup.exe.

Indicates

• cross-references to anot her section, e.g. "Safety information"

• cross-references to an external source, e.g. a web address: For more information, go to "

• Names of CDs, DVDs and titles or designations for other materials, e.g.: "CD/DVD Drivers & Utilities" or "Safety/Regulations" manual

indicates a key on the keyboard, e.g: indicates terms and texts that are emphasised or highlighted, e.g.: Do

not switch off the device

using the keyboard in a program dialogue or at

your password (Name123) or a command used to

t.exe)

http://ts.fujitsu.com"

F10

8 Fujitsu Technology Solutions

Ports and controls

This chapter presents the individual hardware components of your device. It gives you an overview of the device’s indicators and connections. Please familiarise yourse lf with these components before you start to work with the device.

Front

1 = WebCam 2 = Eyelet for pen cord 3 = ON/OFF switch for wireless components 4 = Tablet button "Alt"

(function

5 = Tablet button "Change the screen

orientation"

Ctrl+Alt+Del)

function

6 = Tablet button "Keyboard" 7 = ON/OFF switch 8 = Status indicators 9 = DC input connector (DC IN) 10 = Port for Cradle

Fujitsu Technology Solutions 9

Ports and controls

Rear

1 = Battery co mpartment 2 = WebCam 3 = Memory card slot 4 = Fingerprint sensor

5 = USB port 6 = Headphone port 7 = HDMI port 8 = Microphones

10 Fujitsu Technology Solutions

Important notes

ImportantnotesNotes

Safety notes

SafetynotesNotes

This chapter contains essential safety information which must be followed when working with your Tablet PC. The other notes provide useful information on your Tablet PC.

Please follow the safety notes provided in the "Safety/Regulations" manual as well as the safety notes given below.

Please pay special attention to the sections in the manual marked with the symbol on the left.

When connecting and disconnecting cables, observe the relevant notes in this operating ma nual.

Read the information on the ambient conditions in the " and the " Tablet PC for use and switching it on for the ﬁrst time.

When cleaning the device, please observe the relevant notes in the section "

Pay attention to the additional safety notes for devices with radio components provided in the "Safety/Regulations" manual.

First-time setup of your devic e", Page 17chapter before preparing your

Cleaning th e Tablet PC", Page 16.

Important notes

Technical data", Page 75chapter

This Tablet PC c If you have que environment,

omplies with the relevant safety regulations for data processing equipm ent.

stions as to whe ther you can set up the Tablet PC in the intended

please contact your sales point or our hotline/help desk.

Additional safety notes for devices with radio components

Radiocomponent:WirelessLAN:Bluetooth,safetynotes

If a radio component (Wireless LAN/ Bluetooth) is integrated in your Tablet PC, you must be sure to observe the f ollowing safety precautions when using your Tablet PC:

• Switch off the radio components when you are in an aircraft or driving in a car.

• Switch off the radio c omponent s when you are in a hospital, an operating room or near a medical electronics system. The transmitted radio waves can impair the opera tion of medical devices.

• Switch off the radio components when you let the device get near ﬂammable gases or into hazardous environments (e.g. petrol station, paintshops), as the transmitted radio waves can cause an explosion or a ﬁre.

For information on how to switch radio components on and off, see chapter

Switching the wireless components on and off", Page 47.

Fujitsu Technology Solutions 11

Important notes

Protecting the display screen

The device is not waterproof. Do not pour liquids on the system or wash it with a heavily soaked cloth. Do not place items on the top of the display, or damage may occur.

During normal use of the device, small particles from the environment can become embedded in the pen tip and scratch the screen. To prevent scratching the screen, ensure that a screen protector is installed before using your device. The warranty does not cover a scratched screen.

You device is designed for a long period of use. Using a screen protector will help ensure that the screen remains as clear as possible. When installed, the screen protector becomes a durable, replaceable writing surface that protects the display screen from abrasion.

The screen protector is held onto the display screen surface by a thin strip of adhesive around the edges. There is a angled corner in one corner of the screen protector. It allows youtoslideyourﬁngernail under the screen protector for easy removal.

Please contact your dealer for additional screen protectors.

Proceed as follow s to attach a screen protector:

► If a screen protector is alread y installed on the display screen, remove it

before installing the new screen protector.

► Remove the protective coating from the adhesive side of the screen protecto r.

12 Fujitsu Technology Solutions

► Align the screen protector on the edges of the screen as illustrated and lay it

on the screen with the adhesive side downward.

► Make stroking m

ovements towards the outside edges in order to remove any air bubbles.

► Press the edges ﬁrmly.

Important notes

Fujitsu Technology Solutions 13

Important notes

To ensure a good seal between the screen protector and the display, do not lift the screen protector from the display once it has been applied.

► Carefully lift the plastic protective coating at the angled corner and pull it from the screen.

You can now touch the screen with the pen.



► To remove all adhesive residue and prevent the tip of the pen from squeaking,

wipe the screen protector with a s oft, dry cloth.

The adhesive sets completely within 48 hours.

14 Fujitsu Technology Solutions

Important notes

Energy saving

NotesEnergyEnergysaving

If you will not be using your Tablet PC, switch it off. Switch off any connected external devices when they are not in use. If you use the energy saving functions, the Tablet PC uses less power. You will then be able to work for longer before having to recharge the battery.

Energy efﬁciency is increased and the environmental impact is reduced. You save money while protecting the environment.

Energy saving under Windows

► Make use of the power management features (see ""Using the power-management features",

Page 43").

Travelling with you

MobileoperationNotesTransportationTabletPC

Please observe the points listed below when travelling with your Tablet PC.

rTabletPC

Before you travel

► Back up important data stored on your hard disk.

Tablet PCTravel,TabletPC

► Switch off the radio component for data security reasons. With data trafﬁc via a wireless

connection, it is also possible for unauthorised third parties to receive data.

Information on activating data encryption is provided in the documentation for your radio component.

► If you want to use your Tablet PC during a ﬂight, ﬁrst check with the ﬂight

attendants whether this is permissible.

When travelling in other countries

► If you are travelling abroad, check that the mains adapter can be operated with the

local mains voltage. If this is not the case, obtain the appropriate mains adapter for your Tablet PC. Do not use any other voltage converter!

► Check whether the local mains voltage and the power cable are compatible. If this is

not the case, buy a power cable that matches the local conditions.

► Enquire with the corresponding government ofﬁce of the country you will be

travelling in as to whether you may operate the radio component integrated in your Tablet PC there (also see "

CE marking", Page 78).

Fujitsu Technology Solutions 15

Important notes

Transporting the Tablet PC

Protect the Tablet PC from severe shocks and extreme temperatures (e.g., direct sunlight in a car).

► If your device has an optical drive, remove all data media (e.g. CD, DVD) from the drives.

TransportationTabletPC

► Switch off the Tablet PC. ► Unplug the mains adapter and all external devices from the power socket. ► Disconnect the mains adapter cable and the data cables for all external devices. ► To protect against damaging jolts and bumps, use a Tablet PC carrying

case to transport your Tablet PC.

Cleaning the Tablet PC

Do not clean any interior parts yourse lf; leave this job to a service technician.

Only use cleaning products designed for computers. Normal household cleaners and polishes can damage the markings on the keyboard and the Tablet, the paintwork or the Tablet PC itself.

Please ensure that no liquid enters the Tablet PC.

The touchscreen is very sensitive to scratches! Only clean the display surface with a very soft, slightly damp cloth.

► Switch the Tablet PC off.

display

CleaningNotesTabletPCKeyboardTouchpadTouchscreenCrystalView

► In order to prevent accidentially switching the device on, remove the power cable from the mains

adaptor and remove the battery (see " The casing surfaces may be cleaned with a dry cloth. If particularly dirty, use a damp cloth that



has been dipped in water mixed with mild domestic detergent and then carefully wrung out.

Removing and installing the battery", Page 40).

16 Fujitsu Technology Solutions

First-time setup of your device

First-time setup of your devic

First-timesetu pGettingstarted

On delivery, the battery can be found in the battery compartment or in the accessories kit. The battery must be charged if you want to operate your device using the battery.

When used on the move, the built-in battery provides the device with the necessary power. You can increase the operating time by using the available energy-saving functions.

For instructions on how to connect external devices (e.g. mouse, printer) to your device, please refer to the operating manual for your device.

Unpacking and

► Unpack all the individual parts. ► Check your

Please read the chapter "Important notes", Page 11.

If your device is equipped with a Windows operating system, the necessary hardware drivers and sup plied software are already pre-installed.

Beforeyouswitchonthedevicefortheﬁrst time, connect it to the mains voltage using the mains adapter, see " adapter must be con nected during the entire installation process.

A system test is performed when your device is ﬁrst switched on. Various messages can appear. The display may remain dark for a short time or may ﬂicker.

Please follow the i nstructions on the screen.

NEVER switch off your device during the ﬁrst-time setup pro cess.

Mains adapter conn ecting", Page 18.Themains

checking the device

Should you discover any dama ge that occurred during transportation, notify your local sales outlet immediately!

PackagingTransport

device for any visible damage which may have occurred during transportation.

You may ne

Fujitsu Technology Solutions 17

ed the packaging in the future, if you need to transpo rt your device.

First-time setup of your device

Selecting a location

SelectingalocationDeviceMainsadapter

Select a suitable location for the device before setting it up. Follow the instructions below when doing so:

• Never place the device or the mains adapter on a heat-sensitive surface. The surface could be damaged as a result.

• Never place the device on a soft surface (e.g. carpeting, upholstered furniture, bed). This can block the air vents and cause overheating and damage.

• The underside of the device heats up during normal operation. Prolonged contact with the skin may become unpleasant or even result in burns.

• Place the device on a stable, ﬂat, non-slippery surface. Please note that the rubber feet of the device may mark certain types of delicate surfaces.

• Keep other objects at least 100 mm away from the device and its mains adapter to ensure adequate v entilation.

• Never cover the ventilation slots of the device.

• Do not expose the device to extreme environmental conditions. Protect the device from dust, humidity, and heat.

Mains adapter connecting

PreparingforoperationMainsadapter

Observe the safety notes in the enclosed "Safety/Regulations" manual.

The supplied power cable conforms to the requirements of the country in which you purchased your device. Make sure that the power cable is approved for use in the country in which you intend to use it.

► Connect the power cable (1) to the

mains ada pter.

► Plug the mains cable (2) into a mains outlet. ► Connect the mains adapter cable (3) to

the DC jack (DC IN) of the device.

18 Fujitsu Technology Solutions

First-time setup of your device

Switching on the device for the ﬁrst time

Switchingonfortheﬁrsttime

On devices with ON/OFF switch for wireless components: Slide the ON/O F F switch for wireless components to the ON position before switching on the device.

When you switch on the device for the ﬁrst time, the supplied software is installed and conﬁgured. Because this procedure must not be interrupted, you should set aside enough time for it to be fully comp leted and connect the device to the mains using the mains adapter.

During the installation process, DO NOT restart the device unless you are requested to do so!

To make it easier to use y is pre-installed on th

our device for the ﬁrst time, the operating system

e hard disk.

► Slide the ON/OFF switch (1) to the right to switch on the Tablet PC.

The O N/O FF switch returns automatically to its original position.



The power-on indicator (2) lights up whenever the system is switched on.

► During installation, follow the instructions on screen.

If a Windows o perating system is installed on your device, you will ﬁnd more information on the system and drivers, help programmes, updates, m anuals etc. on the device or on the Internet at "

http://ts.fujitsu.com/support".

Fujitsu Technology Solutions 19

Working with the Tablet PC

TabletPC,operationTabletPC

This chapter describes the basics for operating your Tablet PC. You can ﬁnd instructions on how to connect external devices (e.g. mouse, printer) to the Tablet PC in the chapter "

Status indicators

StatusindicatorsSymbols

The status indicators provide information about the status of the power supply, the drives and the keyboard functions etc.

Connecting external devices", Page 60.

Please refer to the notes in "Important notes", Page 11.

Status d

20 Fujitsu Technology Solutions

isplays

tion

Descrip

on indicator

Power-

•Theind

• The indicator is ﬂashing: The Tablet PC is in sleep mode (Save-to-RAM).

•Thein

Batt

The b cha

icator is illuminated: The Tab let PC is switched on.

dicator is not illuminated: The Tablet PC is switched off or in

to-Disk mode.

Save-

ery charging indicator

attery charging indicator shows whether a battery is installed and being

rged.

Working with the Tablet PC

Switching on the Tablet PC

TabletPC:switchingonPower-onindicatorSuspend/Resumebutton

► Slide the ON/OFF switch (1) to the right to switch on the Tablet PC.

The O N/O FF switch returns automatically to its original position.



The power-on indicator (2) lights up whenever the system is switched on.

Programming the ON/OFF switch

You can pro

Operating system Menu

Windows 7

gram the ON/OFF switch:

If you ha do so, in found i

ve assigned a password, you must enter this when requested to

order to start the operating system. Detailed information can be

n the chapter "

Security functions" , Page 53.

Start - (Settings) - Control Panel - System and Security - Power Options

Switching off the Tablet PC

tPC

Table

► Close all applications and then shut down the operating system (please

see the "Operating System Manual").

► Slide the ON/OFF switch towards the right.

The O N/O FF switch returns automatically to its original position.



Fujitsu Technology Solutions 21

Working with the Tablet PC

Handwriting recognition under

Handwriting recognition under Windows 7 currently supports the following languages:

English, German, French, Italian, Japanese, Korean, Chinese (traditional and simpliﬁed), Dutch, Portuguese, Spanish, Brazilian, Norwegian (Bokmål and Nynorsk), Swedish, Finnish, Danish, Polish, Rumanian, Serbian (Cyrillic and Latin script), Catalan, Russian, Czech and Croatian.

Windows 7

Touchscreen

Touchsc reenNotes

High-quality T FT displays are installed in Tablet PCs from Fujitsu Technology Solutions GmbH. For technical reasons, TFT monitors are manufactured for a speciﬁc resolution. An optimal, clear picture can only be ensured with the correct resolution intended for the relevant TFT monitor. A monitor resolution which differs from the speciﬁcation can result in an unclear picture.

The screen resolution of your Tablet PC’s touchscreen is optimally set at the factory.

The standard of production techniques today cannot guarantee an absolutely fault-free screen display. A few isolated constant lit or unlit pixels (picture elements) may be presen t. The maximum permitted number of pixels faults is stipulated in the international standard ISO 9241-3 (Class II).

Example:

A monitor w ith a resolution of 1280 x 800 has 1280 x 800 = 1024000 pixels. Each pixel consists of three subpixels (red, green and blue), so there are almost 3 million subpixels in total. According to ISO 9241-3 (class II), a maxim um of 2 light and 2 dark pixels and an additional 5 light or 10 dark subpixels or a corresponding mix may be defective (1 light subpixel counts as 2 dark subpixels).

Pixel

Subpixel

Cluster A cluste r contains two or more defective pixels or

A pixel consists of 3 subpixels, normally red, green and blue. A pixel is the smallest element that can be generated by complete functionality of the display.

A subpixel is a separately addressable internal structure within a pixel t hat enhances the pixel function.

subpixels in a 5 x 5 pixel block.

Background lighting

TFT monitors are operated with background lighting. The luminosity of the background lighting can decrease while the Tablet PC is in use. However, you can set the brightness of your monitor individually.

Synchronising the display on the touchscreen and an external monitor

In Windows 7, you can switch between touchscreen and external monitor, if you open Control Panel - Windows Mobility Center,sectionExternal Display .

22 Fujitsu Technology Solutions

Working with the Tablet PC

Select display orientation (portrait or landscape orientation)

LandscapeorientationPortraitorientationDisplayorientation

You can choose to use either portrait or landscape orientation for the display. Press the

Tablet button

to switch between portrait and landscape orientation.

Windows 7

You can change these settings in the Fujitsu menu or under Start -(Settings -) Control Panel - Hardware and Sound - Display - Settings.

Proﬁles for operating with various different screen modes can be selected via the Fujitsu Tablet Control option in the Fujitsu menu. These proﬁles have preset standard conﬁgurations that can be modiﬁed as desired.

These settings do not just affect the monitor settings on the Tablet PC, but also any external monitors that may be connected.

Using ﬁngers

You can execute c

ertain commands by using your ﬁnger tip on the touchscreen of your device.

Everything whic be selected or

Calibrate th

e Dual Digitizer for ﬁnger-based

h you can select or activate using your ﬁ nger tip can also activated using the stylus pen.

operation of the device.

Before operating the device for the ﬁrst time using the ﬁngers, you must calibrate it so that your ﬁnger tips are recognized as accurately as possible.

You must calibrate the device again as soon as you notice that the variations are becoming greater.

Operating system Menu

Windows 7

To calibrate, call up the Hardware and Sound / Tablet PC Settings function in the Control Panel. You need to calibrate both portrait and landscape formats.

Fujitsu Technology Solutions 23

Working with the Tablet PC

Actions with one ﬁnger

Action Description

Selecting objects (click with the left mouse button)

Starting programs (double-click with the left mouse button)

Moving objects/windows (drag with left mouse button pressed, Drag & Drop)

Opening a context menu (click with the right mouse button)

Moving the cursor

► With your ﬁnger, tap once brieﬂyonthe

object.

► With your ﬁnger, tap twice brieﬂy in quick

succssion on the program icon.

► Place a ﬁnger directly on the object/window,

hold the ﬁnger pressed against the touchscreen and move the desired object/window.

► Touch the desired item once with your ﬁnger

tip. Keep the ﬁnger tip pressed against the

touchscreen. The context menu appears.

► Position one ﬁnger on the touchscreen and

move the ﬁnger in the desired direction.

24 Fujitsu Technology Solutions

Actions with two ﬁngers

Action Description

Scrolling

► Position two ﬁngers on the touchscreen. ► Move your ﬁngers upwards to scroll up.

► Move your ﬁngers downwards to scroll

down.

Rotating

Working with the Tablet PC

► Position the thumb on the touchscreen,

then turn the picture clockw ise or counter-clockwise using your index ﬁnger.

Fujitsu Technology Solutions 25

Working with the Tablet PC

Action Description

Increasing or decreasing the view

► Position two ﬁngers on the touchscreen and

move them apart to increase the view. or

► Position two ﬁngers on the touchscreen and

move them together to decrease the view.

Blocking context-sensitive menus

► With two ﬁngers, tap twice brieﬂy in quick

succession on the touchscreen.

26 Fujitsu Technology Solutions

Actions with three ﬁngers

Action Description

Maximising or minimising current window

► Position three ﬁ ngers on the touchscreen

and move them upwards to maximise the window.

► Position three ﬁ ngers on the touchscreen

and move them downwards to minimise the window.

Working with the Tablet PC

Fujitsu Technology Solutions 27

Working with the Tablet PC

Action Description

Displaying and rotating current w indow in 3D carousel layout

► Tap the touch scree n with your three ﬁngers

to display the 3D carousel. ► Hold your ﬁngertips pressed to change the

3D carousel layout.

Minimising all windows and displaying the desktop

► With three ﬁngers, tap the touchscreen twice

brieﬂy in quick succession.

28 Fujitsu Technology Solutions

Action Description

Scrolling through all open ﬁles in a program

Working with the Tablet PC

ngers on the touchscreen

he side (left or right) over

Displaying con

► Position three ﬁ

and move them to t the touchscreen

text menu and selecting entry

► Position two ﬁngers on the touchscreen. A context menu is displayed on the screen.

► With one ﬁnger on the other hand, tap on an

entry in the context menu.

The entry is selecte d.

Fujitsu Technology Solutions 29

Working with the Tablet PC

Actions with four ﬁngers

Action Description

Displaying a menu with context-sensitive web applications with one hand

You can select a word, sentence , paragrap h or an item

Displaying menu with context-sensitive web applications with two hands

► Ta p br ie ﬂy on the touchscreen with four

ﬁngers on one hand then lift your ﬁngers

from the screen. A menu with context-sensitive web applications

is displayed.

► To select an area, position two ﬁngers of

each hand in a rectangle on the touchscreen

as shown. A menu with context-sensitive web applications

is displayed.

30 Fujitsu Technology Solutions

Action Description

Enlarging the area

► To magnify an area of a document, position

two ﬁngers of each hand in a rectangle on the touchscreen as shown.

The selected area will be magniﬁed.

► Place one ﬁnger on the touchscreen to

move the rectangle around the touchscreen to magnify several areas.

Working with the Tablet PC

Fujitsu Technology Solutions 31

Working with the Tablet PC

Action Description

Paging through (fast scrolling)

► Position four ﬁngers on the touchscreen and

move them upwards to scroll up. or

► Position four ﬁngers on the touchscreen and

move them downwards to scroll down. The distance you sweep your ﬁngers indicates

how far you move up or down.

32 Fujitsu Technology Solutions

Working with the Tablet PC

Using the stylus pen

1 = pen tip

You can use the pen on your Tablet PC as an electronic writing implement to select items, and to navigate through programs on it. Programs that support handwriting recognition also allow you to write characters directly on the screen with the pen. You can also use the pen as a drawing tool.

The pen is retained securely in the pen slot. This ensures that the pen cannot be lost, regardless of whether you use the Tablet PC or transport it while travelling. Always replace the pen in its slot when you are not using it.

The Tablet PC is supplied with a pen cord which you can attach to the eyelets on the pen and on the Tablet PC.

2 = pen button

3 = eyelet for pen cord

Use only the pen provided with your Tablet PC. Do not use substitutes that were not designed for your Tablet PC. Replace th e stylus tip if it is wo rn. The warranty does not cover a scratched screen.

While writing, you should take care not to scratch the surface of the display (e.g. with a wristwatch or bracelet).

Fujitsu Technology Solutions 33

Working with the Tablet PC

The Tablet PC’s pen is an electronic instrument that can be damaged if used improperly. Handle the pen with care.

The following list contains guidelines for proper pen handling:

• Do not gesture with the pen.

• Do not use the pen as a pointer.

• Do not use the pen on surfaces other than the screen of the Tablet PC.

• Donottrytoturnthethumbgriponthepen. Thethumbgripisusedto place the pen in its slot and to take it out of the slot.

• Never store the pen with the tip bearing the weight of the pen (e.g. with the tip down in a pen holder). If the pen is stored with the tip pointing down, this may have an adverse effect on the pen mechanism (particularly under high tempe ratures). In this case the pen tip may react as though it is constantly being pressed down. To avoid damage, the pen should be stored in the pen slot when not in use.

Thepencanbeinﬂuenced by electromagn etic ﬁelds (cursor quive rs or jumps). There may be a few areas on the screen where the cursor quivers slightly in spite of pressing the pen d own ﬁrmly.

The screen responds to entries made with the tip of the ﬁnger or the pen when the tip of the ﬁnger or the pen is in direct contact with the screen.

You can use the pen to run all functions for which you would otherwise use a mouse.

The pen does not support erasing functions.

Handling Mouse Pen

Selecting menu items

Starting pro grams Double click with the left-hand mouse

Moving an object/window

Opening a context menu

Moving the cursor

Click with the left-hand mouse button.

button.

Drag with the left-hand mouse button held pressed.

Click with the right-hand mouse button.

To uch the menu entry with the pen tip.

Brieﬂy touch the program icon twice with the pen tip.

Place the pen tip directly on the object/window. Hold the pen tip pressed against the screen. Move the desired object/window.

Place the pen directly on the required element and hold the pen pressed against the screen.

Place the pen tip directly on the screen.

Setting the pen

Operating system Menu

Windows 7

34 Fujitsu Technology Solutions

Under Hardware and Sound – Pen and Input Devices in the Control Panel you can change various settings for the pen (assignment and function of the pen button).

Working with the Tablet PC

Calibrating the pen

Before using the pen for the ﬁrst time, you should calibrate it so that the cursor follows the movements of the pen as accurately as possible. You should also always repeat the calibration if the co-ordination bet ween the pen and cursor movement deteriorates.

Operating system Menu

Windows 7

To calibrate, call up the Hardware and Sound / Tablet PC Settings function in the Control Panel. You need to calibrate both portrait and landscape formats.

Changing the pen tip

With use, the pen tip may become worn or may pick up foreign particles that can scratch the screen. A damaged or worn tip may n ot move freely, causing unpredictable results when using the pen.

If these problems appear with your pen, you should change the pen tip.

► Pull t he pen tip from t he pen. ► Replace the pen tip with one of the

replacement tips that were supplied your pen. Insert the pointed end of the pen tip i nto the barrel and push it in gently until it is in place.

Do not continue to use a tip which is worn or damaged.

Fujitsu Technology Solutions 35

Working with the Tablet PC

Removing the pen battery

Do not take off the pen tip to change the battery.

The pen contains one AAAA battery.

Installing a pen battery

► Unscrew and remove the cap from

the pen (1).

► Pull the battery out of the pe n (2).

► Insert the new battery in the pen (1). ► Closethepencap(2).

Installing a pen cord

ould attach the pen with a pen cord to prevent accidentally dropping or losing it.

You sh

► Fast

36 Fujitsu Technology Solutions

en the pen cord to the pen eyelet and to the eyelet on the Tablet PC.

Working with the Tablet PC

Tablet buttons

Your Tablet PC is ﬁtted with three multi-functional tablet keys. You can navigate on the screen with a simple press of a button, call preset applications or ones that you have set yourself.

Basic functions before the device has booted

You c a n conﬁgure the functions in the table below yourself. The TPM PPI (Physical Presence Interface) menu is available only

if your system has a TPM module. The TPM PPI menu is displayed after the security condition for the TPM

running under Windows has been changed.

Function, if the key is

Key

Fujitsu Technology Solutions 37

pressed while booting the system

F1 (application menu)

F2 (BIOS setup)

F12 (Boot menu)

Function in application menu/boot menu/BIOS setup

High

Low Yes

Input No

Function in TPM PPI menu

—

Working with the Tablet PC

Basic functions when the device has booted

Button Basic function

Log on to the system or open the Windows Task Manager

If you keep this tablet button pressed for two seconds, you can log back onto the system again:

• after system startup

• after a system lock

• when returning from power manageme nt After log-on, pressing the tablet button for two seconds launches the Windows

Ta sk Ma nager or - in the network - opens the security window.

Change screen o rientation

When you p ress this tablet button, the o rientation of the screen display changes from portrait (vertical) to landscape (horizontal) or vice versa.

If you wish to use the Tablet PC as an eBook, you should use the portrait orientation.

When accessing spreadsheets, you would more typically use a landscape orientation.

Tap: Monitor keybo a rd

If you tap this tablet key, the monitor keyboard is displayed.

Hold down: Calls up the Fujitsu menu

If you hold this tablet key down, the TouchLauncher appe ars on y our screen. Use the TouchLauncher to run the installed programs.

When you press this tablet button and keep it held, the Fujitsu menu appears on your screen. The Fujitsu Menu is used to change certain system settings.

Programming the tablet buttons

You can program the tablet buttons to open a speciﬁc application or execute a s peciﬁc function when pressed.

Proceed as follows:

► In Control Panel, select the option to manage the settings for the tablet buttons and pen. ► Follow the instructions on the screen and program the tablet buttons as you require.

38 Fujitsu Technology Solutions

Webcam

Your device has two WebCams: one on the front side of the device and o ne on the rear.

Working with the Tablet PC

Depending on the s oftware u record video c lips or take p

• The picture quality depen

sed, you ca n use your Webcam to take pictures,

art in web chats.

ds on the lighting conditions and the software being used.

• You can only operate the webcam with a particular application (e.g. an Internet telephony program or a video conferencing p rogram which supports a webcam).

• When using the webcam the

Tablet PC support must not wobble.

• The webcam automatically adjusts itself to the cu rren t light level. For this reason the touchscreen may ﬂicker w hile the light level is adjusted.

Further information on using the webcam and on the additional settings which are possible for your webcam can be found in the help function of the program which uses the webcam.

If you wish to carry out a function test with your webcam, you can use the corresponding test software available at "

http://ts.fujitsu.com/support/".

Rechargeable battery

RechargeablebatteryBatteryLife,batteryRechargeablebatteryRechargeablebattery

For m obile use, the built-in battery provides the Tablet PC with the necessary power. You can increase the life of the battery by caring for the battery properly. The average battery life is around 500 charge/discharge cycles.

You can extend the battery life by taking advantage of the available energy saving functions.

Fujitsu Technology Solutions 39

Working with the Tablet PC

Charging, caring for and maintaining the battery

BatteryBattery

The Tablet PC battery can only be charged when the ambient temperature is between 5°C and max. 35°C.

You can charge the battery by connecting the Tablet PC to the mains adapter

Mains adapter connecting", Page 18).

(see "

If the battery is running low you will hear a warning alarm. If you do not connect the mains adapter within ﬁve minutes of the warning alarm described above, your Tablet PC will switch off automatically.

monitoring the battery charging level

BatteryBatterystatusmeter

Windows also has a "Battery status meter" in the taskbar for monitoring the battery capacity. When you place the mouse pointer on the battery symbol, the system d isplays the battery status.

Battery storage

tery

attery BatteryBatterySelf-discharge,bat

Chargingcapacity,b

Keep th e battery pack between 0°C and +30°C. The lower the temperature at which the batteries are stored, the lower the rate of self-discharge.

If you will be storing batteries for a longer period (longer than two months), the battery charge level should be approx. 30 %. To prevent exhaustive discharge which would permanently damage the battery, check the level of charge of the battery at regular intervals.

To be able to make use of the optimal charging capacity of the batteries, the battery should be completely discharged and then fully recharged.

If you do not use the batteries for long periods, remove them from the Tablet PC. Never store the batteries in the device.

Removing and installing the battery

Only use bat

Never use fo

Make sure t

Never stor can make it

40 Fujitsu Technology Solutions

teries approved by Fujitsu Siemens Computers for your Tablet PC.

rce when ﬁtting or removing a battery.

hat no foreign bodies get into the battery connections.

e a battery for longer periods in the discharged state. T his

impossible to recharge.

Working with the Tablet PC

Removing the battery

Please observe the safety information in chapter "Important n otes", Page 11.

Remove the power plug fro m the mains outlet!

► Switch the device off.

The device must not be in energy-saving mode.

► Remove all the cables from the device. ► Turn the device over and place it on a stable, ﬂat and clean surface. If necessary, lay an

anti-slip cloth on this surface to prevent the device from being scratched.

► Slide the release button in the direction of the arrow (1). ► Slide the release button in the direction of the arrow (2) and hold it in place. ► Remove the battery from th e battery compartment (3).

Fujitsu Technology Solutions 41

Working with the Tablet PC

Installing battery

► Slide the release button in the direction of the arrow (1). ► Slide the release button in the direction of the arrow (2) and hold it in place. ► Push the battery into the battery compartment until you feel it engage (3).

42 Fujitsu Technology Solutions

Working with the Tablet PC

Using the power-management features

PowerPowerBattery

The Tablet PC uses less power w hen the power management features are enabled. You will then be able to work longer when using the battery before having to recharge it.

Power efﬁciency is increased and environmental pollution reduced. By choosing the best power options, you can make signiﬁcant savings a nd at the same time help protect the environment.

We recommend the following settings:

Function On external power On battery power

Turn off monitor After 10 minutes After 5 minutes

Turn off hard disk(s) After 15 minutes After 10 minutes

Energy saving (S3) After 20 minutes After 15 minutes

Hibernate mode (S4

)

After 1 hour After 30 minutes

► Select the power man

agement functions in your Control Panel.

► Select the Screen Saver in your Control Panel.

► Keep a ﬁnger pressed on the desktop. Conﬁgure the screensaver under Personalization -

Change screensaver.

If you need further information about an option, you can get help with most settings by

pressing the

symbol in the upper right of the screen to open the Microsoft Help.

When the Tablet PC is in power saving mode, you mu st remember the following:

During power saving mode, open ﬁles are held in the main memory orinaswapﬁle on the hard disk.

Never switch off the Tablet PC while it is in a power saving mode. If the built-in battery is nearly ﬂat, c lo se the open ﬁles and do not go into power saving mode.

If you do not intend to use your Tablet PC for a long period of time:

► Exit the power saving mode if necessary via touching the screen or by switching on the

Ta blet PC.

► Close all opened programs and completely shut down the Tablet PC.

Fujitsu Technology Solutions 43

Working with the Tablet PC

Memory cards

Slot

Your Tablet PC is equipped with an integrated memory card reader.

Observe the manufacturer ’s instructions when handling the memory cards.

Memorycard

Supported format

The memory card reader supports the following format:

• Secure Digital (SD

Inserting the memory card

card)

► Carefully slide the memory card into the

slot. The label should be facing upward. Do not apply excessive force, as otherwise the delicate contact surfaces could be damaged.

Memorycard

Depending on the particular type



used, the memory card may protrude slightly from the slot.

44 Fujitsu Technology Solutions

Working with the Tablet PC

Removing the memory card

Memorycard

In order to protect your data, always follow th e correct procedure for removing the card outlined below.

You can stop the memory card via the corresponding icon in the task bar:

► Tap on the symbol. ► Select the c ard you want to stop and remove. ► Ta p OK.

Wait for the dialogue box which tells you that it is now safe to remove the memory card.



► On devices with card locking: Press

on the storage card (1).

Memorycard

The storage card is released and



can now be removed.

► Pull the storage card out of the slot (2).

Fujitsu Technology Solutions 45

Working with the Tablet PC

SIM card

A SIM Card (Subscriber Identity Module) is a chip card which is inserted in a mobile telephone or Tablet PC and, together with an integrated UMTS module, enables access to a mobile radio network.

When handling SIM cards, follow the instructions supplied by the provider.

Inserting the SIM card

► Remove the battery, see Chapter "Removing the battery", Page 41.

► Slide the SIM card into the slot (1) until

it engages, as shown in the battery compartment. The notch shows to the left, the chip to the bottom.

► Install the battery again, see Chapter "

Installing battery", Page 42.

Removing a SIM card

► Remove the battery, see Chapter "Removing the battery", Page 41.

► Press on the edge of the SIM card so that

it jumps up slightly out of the slot.

► Pull the SIM card out of the slot in the

direction of the arrow (1).

► Install the battery again, see Chapter "

Wirel

46 Fujitsu Technology Solutions

essLAN/Bluetooth/UMTS

The installation of radio components not approved by Fujitsu Technology Solutions will invalidate the certiﬁcations issued for this device.

Installing battery", Page 42.

Working with the Tablet PC

Switching the wireless components on and off

Before switching on your device for the ﬁrst time, the on/off switch for radio components must be in the "ON" position.

► Slide the ON/OFF switch into the "ON" position to activate the radio components.

WirelessLANWirelessLANBluetoothBluetooth

► Slide the ON/OFF switch to the "OFF" positio n to deactivate the radio components.

If you switch off the radio components, the wireless LAN transmission unit (antenna) and, if present, the Bluetooth and UMTS module will also be switch ed off.

You can enable and disable the installed radio components individually using the WirelessSelector programme

You can a lso deactivate the wireless components individually in the BIOS Setup. For this to occur, you must either not have assigned a supervisor password or if a supervisor password has been assigned, you must know this password.

Pay attention to the additional safety notes for devices with radio components provided in the "Safety/Regulations" manual.

Details on using Wireless LAN can be found in the online help system included in the Wireless LAN software.

You ca n ﬁnd more information on how to use Bluetooth on the CD you received with your Bluetooth software.

You can obtain more information on UMTS from your service provider.

Fujitsu Technology Solutions 47

Working with the Tablet PC

Setting up WLAN access

• Requirement: A WLAN must be available and you must have the

corresponding access information.

Information on conﬁguring the WLAN access can be found in the documentation for your operating system.

Access via UMTS

If you ordered an integrated UMTS module with your system, you can enjoy optimum reception and maximum energy efﬁciency without awkward c ables or antennas. The optional UMTS module is ready fo r use straight away.

If you did not order a UMTS module, you can purchase the acce ssories for UMTS reception from your retailer or your Fujitsu Technology Solutions de aler.

You will ﬁnd information on establishing the connection with the UMTS network in the documentation for the hardware used.

You can connect your device with the Internet via UMTS. To do this, use one of the following types of connection:

• a USB dongle (a USB stick with your mobile phone provider’s SIM card)

• mobile end-device (e.g. mobile phone with Bluetooth or cable connection)

GPS

If your device is e quip ped with an integrated GPS module, you can use your device as a navigation system with the help of a corresponding software programme.

48 Fujitsu Technology Solutions

Whether or not your device has this function depends on the selected device expansion stage.

Working with the Tablet PC

Your Cradle (optional)

Your Cradle is a device that helps you to quickly connect your Tablet PC to your peripheral devices, such as a printer, mouse, etc.

You only need to dock the Tablet PC in order to work with your peripheral devices.

Cradle components

CradlePorts

1 = Connect

2=USBports

Fujitsu Technology Solutions 49

or on the Cradle for the docking he Tablet PC

port of t

3 = DC input 4 = Unlocking lever

connector (DC IN)

Working with the Tablet PC

SettinguptheCradle

Select a suitable location for the Cradle before setting it up. Follow the instructions below when doing so:

• PlacetheCradleonaﬂat, stable, nonslippery surface.

• Never place the Cradle and the mains adapter on a heat-sensitive surf ace.

• Do not expose the Cradle to extreme environmental co nditions.

Protect the Cradle from dust, humidity and heat.

► Press the release lever and unfold the Cradle’s stand from (1), until it engages in its ﬁnal position

Connecting the Tablet PC to the Cradle

If you connect the Tablet PC to the Cradle during operation, problems can occu r. We recommend that you switch off the Tablet PC beforehand.

If the Tablet PC is connected to the Cradle, you must connect the mains adapter to the Cradle.

Cradle

► Switch off the Tablet PC.

50 Fujitsu Technology Solutions

Working with the Tablet PC

► Remove the power plug of the m ains adapter from the mains socket. ► Pull the mains adapter cable out of the DC jack (DC IN) of the Tablet PC.

► Position the Tablet PC so that it is in line with the storage space of the Cradle. ► Push the Tablet PC on to the Cradle in the direction of the arrow (1) until

you notice it engage with the plug.

► Plug the DC output connector on the mains adapter into the DC input

connector (DC IN) on the Cradle (2).

► Connect the power cable to the mains adapter (3). ► Plug the power cable into the mains socket (4). ► Close the clip on the rear side of the Cradle.

Fujitsu Technology Solutions 51

Working with the Tablet PC

Disconnecting the Tablet PC from the C radle

If you connect the Tablet PC to the Cradle during operation, problems can occur. We recommend that the Tablet PC is switched off or that the appropriate undocking function provided by the operating system is executed.

► Switch off the Tablet PC. ► Open the clip on the rear side of the Cradle.

► Lift the Tablet PC from the Cradle in the direction of the arrow (1), while

supporting the underneath of the Cradle.

52 Fujitsu Technology Solutions

Security functions

Securityfunctions

Your Tablet PC has several security features that you can use to secure your system from unauthorised access.

This chapter explains how to use each function, and what the beneﬁts are.

Please remember that in some cases, for example, forgetting your password, you may be locked out and unable to access your d ata. Therefore, please note the following information:

• Make regular backups to external data carriers such as external hard drives, CDs, DVDs or Blu-ray Discs.

• Some security functio of the passwords and ke

If you forget your passwords you will need to contact the our Service Desk. Deletion or resetting of passwords is not covered by your warranty and a charge will be made for assistance.

Conﬁguring the ﬁngerprint sensor

FingerprintsensorFingerprintsensor

The ﬁngerprint sensor can reco rd an image of a ﬁngerprint. With additional ﬁngerprint software, this image can be processed and used instead of a password.

ns need yo u to choose passwords. Make a note

eptheminasafeplace.

► You must install the ﬁngerprint software

in order to be able to use the

ﬁngerprint sensor (1).

Fujitsu Technology Solutions 53

Security functions

Conﬁguring password protection in BIOS Setup Utility

To navigate mo re easily in the BIOS Setup Utility, you can use an external USB keyboard.

Before using the various options for password protection in the BIOS Setup utility to increase data security, please observe the following:

Make a note of the passwords and keep them in a safe place. If you forget your supervisor password you will not be able to access your Tablet PC. Passwords are not covered by your warranty and a charge w ill be made for assistance.

Passwordprotection

Your password can be up to eight characters long and contain letters and numbers. No d istinction is made between uppercase and lowercase.

Protecting BIOS Se

If you have opened these operating instructions on the screen, we recommend that you print o ut the following instructions. Because you cannot call the instructions onto the screen while you are setting up the password.

BIOSSetupUtility

You prevent unauthorised use of the BIOS Setup Utility with both the supervisor and the user password. The supervisor password gives you access to all functions of the BIOS Setup Utility, wh ile the user password only provides some of the functions. You can only set a user password if a s uperviso r password has already been assigned.

Please refe r to the ""Settings in BIOS Setup Utility", Page 64 section for a description of how to call up and operate the BIOS Setup Utility.

tup Utility (supervisor and user password)

54 Fujitsu Technology Solutions

Security functions

Setting supervisor and user password

► Start the BIOS Setup Utility and go to the Security menu. ► Select the Set Supervisor Password ﬁeld and press the Enter key.

With Enter new Password: you are asked to enter a password.



► Enter the password and press the Enter key.

Conﬁrm new Password requires you to conﬁrm the password.



► Enter the password again and press the Enter key.

Changes have been saved is a conﬁrmation that the new password has been saved.



► To set the user password, select Set User Password and proceed exactly as

when conﬁguring the supervisor password. If you do not want to change any other settings, y ou can exit BIOS Setup Utility.



► In the Exit menu, select the option Save Changes & Exit. ► Select Yes and press the Enter key.

PasswordSupervisorpasswordUserpassword

The Tablet PC is rebooted and the new passw ord is effective. It will now be necessary to



ﬁrst enter your supervisor or user password in order to open the BIOS Setup Utility. Please note that the user password only provides access to a few of the BIOS settings.

Changing the supervisor or user password

You can only change the supervisor password when you have logged into the BIOS Setup Utility with the supervisor password.

PasswordSupervisorpasswordUserpassword

► Call the BIOS Setup Utility and go to the Security menu. ► When changing the password, proceed exactly as for password assignment.

Removing passwords

To remove a password (without setting a new password) perf orm the following steps:

password

rd PasswordSupervisor

Userpasswo

► Start the BIOS Setup Utility and go to the Security menu. ► Highlight the Set Supervisor Password or Set User P assword ﬁeld and press the Enter key.

You will be requ ested to enter the current password by the Enter Current Password prompt.



You will be requested to enter a new password by the Enter New Password prompt.

► Press the Enter key twice. ► In the Exit menu, select the option Save Changes & Exit. ► Select Yes and press the Enter key.

The Tablet PC is rebooted and the password is cancelled.



Removing the supervisor password simultane ously deactivates the user password.

Passw

Fujitsu Technology Solutions 55

ord protection for booting of the operating system

With the supervisor password you have set in the BIOS Setup Utility (see section " prevent booting of the operating s ystem.

Operatingsystem

Setting supervisor and u ser password", Page 55), you can also

Security functions

Activating system protection

► Start the BIOS Setup Utility and go to the Security menu.

Operatingsystem

► Select the Password on Boot option and press the Enter key. ► Select the desired option (Disabled, First Boot or Every Boot) and press the Ente r key ► Select the Save Changes & Exit option under Exit.

The Tablet PC reboots. You will be prompted to enter your password (the supervisor passwo rd).



Deactivating system protection

► Start the BIOS Setup Utility and go to the Security menu.

Operatingsystem

► Select the Password on Boot option and press the Enter key. ► Select the Disabled option and press the Enter key.

If you do n o t want to change any other settings, you can exit BIOS Setup Utility.



► Select the Save Changes & Exit option under Exit.

The Tablet PC reboo ts. The system is no longer password-protected.



Password protecti

ion:

Passwordprotect

The had disk password prevents unauthorised access to the hard disk drives and is c hecked internally each time the system is booted. The condition for this is that you have assigned at least the supervisor password.

on for the hard disk

Activating hard disk protection

► Call up the BIO

If you have not assigned BIOS passwords yet, deﬁne the supervisor and the user



password now, if desired (see "

► Mark the Hard ► In the Drive0 area mark the Set Master Password ﬁeld and press the Enter key.

Enter new Pa



► Enter the password and press the Enter key.

Conﬁrm new



► Enter the password again and press the Enter key.

Setup Not



new passw

► To assign the password for the second hard disk (Drive1), go to the Drive1 area and

select the ﬁeld Set Master Password, then proceed in exactly the same way as for setting up the password for the ﬁrst hard disk (Drive0).

d Password Entry on Boot is set to Enabled by default. You can exit the BIOS

The ﬁel



► From the Exit menu, choose the option Exit Saving Changes. ► Press



once you have ﬁnished changing the settings.

Setup

the Enter key and select Yes.

The Table PC reboots and your hard disk is now protected with a password. The password prompt is enabled as soon as the Tablet PC has rebooted.

SSetupand select the Security menu.

Security functions", Page 53).

Disk Security ﬁeld and press the Enter key.

ssword then appears and you are asked to enter a password.

Password requires you to conﬁrm the password.

ice: Changes have been saved is displayed to conﬁrm that the

ord has been saved.

56 Fujitsu Technology Solutions

Security functions

Deactivating hard disk protection

To cancel a password without setting a new one, proceed as follows:

► Call up the BIOS Setup and select the Security menu. ► Mark the Hard Disk Security ﬁeld and press the Enter key. ► In the Drive0 area mark the Set Master P assword ﬁeld and press the Enter key.

You will be initially requested to enter the old password by the Enter current Password prompt.



You will then be requested to enter a new password by the Enter new P assword prompt.

► After entering the password, press the Enter key three times. ► From the Exit menu, choose the option Exit Saving Changes. ► Press the Enter key and select Yes.

The Tablet PC reboots and there is no longer any password protection for this hard disk.



► To cancel the password for the second hard disk (Drive1), go to the Drive1 area

and select the ﬁeld Set Master Password, then proceed in exactly the same way as for cancelling the password for the ﬁrst hard disk (Drive0).

Fujitsu Technology Solutions 57

Security functions

SmartCard reader

Securityfunctions,Securityfunctions

SmartCards are not supplied as standard equipment. You can use all S martCards that comply with the ISO stand ard 7816-1, -2 or -3. These SmartCards are available from various ma nufacturers.

With the appropriate software yo u can use your SmartCard as an alternative to password protection, but also as a digital signature, for encrypting your e-mails or for home b anking.

We recommend that you always use two SmartCards. Always keep one of the SmartCards in a safe place if you are carrying the other SmartCard with you.

In order to be able to take advantage of all the security features of your Tablet PC, you will need a CardOS SmartCard from Fujitsu Technology Solutions.

The SmartCard can only be used with a PIN, offering maximum protection even if you lose the SmartCard. In order to maximise your security, the Ca rdO S SmartCard is disabled if three incorrect attempts are made to enter the PIN.

When you use the CardOS SmartCard for the ﬁrst time, you will either need to enter the preset PIN "12345678" or the PIN given to you by your systems administrator.

Inserting the SmartCard

Do not use force when inserting and removing the SmartCard.

Make sure that foreign objects do not fall into the SmartCard reader.

► Slide the SmartCard into the SmartCard reader with the chip facing upwa rds

(on some variants it faces down) and to the front.

58 Fujitsu Technology Solutions

Security functions

Trusted Platform Module (TPM) (device-dependent)

TPMTrustedPlatformModule

To use the TPM, you must activate the TPM in the BIOS Setup before the software is installed. The condition for this is that you have assigned at least the supervisor password (see "

Enabling TPM

• Requirement: You have assigned a supervisor password, see "Security functions", Page 53.

► Call up the BIOS Setup an ► Mark the TPM Security Chip Setting ﬁeld and press the Enter key. ► Select Enabled to ac ti

Once you have activated the TPM the Clear Security Chip option appears.



Select Clear Securit all secret keys (e.g etc.) generated by

Please note that yo encrypted with th

► Select the Exit Sa ► Press the Enter key and select Yes.

The Tablet PC re s



Disabling TPM

• Requirement: You have assigned a supervisor password, see "Security functions", Page 53.

► Call up the BIOS Setup and select the Security menu. ► Mark the TPM Security Chip Setting ﬁeld and press the Enter key. ► Select Disabled to deactivate the TPM. ► From the Exit menu, choose the option Exit Saving Changes. ► Press the Enter key and select Yes.

The Tablet PC is rebooted and the TPM is disabled.



Security functions", Page 53).

d select the Security menu.

vate the TPM.

yChipto delete the holder in the TPM. By clicking on Enabled,

. SRK - Storage Root Keys, AIK - Attestation Identity Keys

applications are deleted.

u will then no longer be able to access the data you have

e keys based on that holder.

ving Changes option in the Exit menu.

tarts and the TPM is switched on after the reboot.

Fujitsu Technology Solutions 59

Connecting external devices

Under all circumsta nces, please observe the s afety notes provided in the

Important notes", Page 11 chapter before connecting or disconnecting

any devices to or from your Tablet PC.

Always read the documentation supplied with the device you wish to connect.

Never connect or disconnect cables during a thunderstorm.

Never pull at a cable when disconnecting it. Always grasp the plug.

Adhere to the order described below when you connect external devices to the Tablet PC or separate them from it:

With some device s, such as USB devices, it is not necessary to switch off the Tablet PC and the device before connecting/disconnecting. For more information about whether or not devices need to be switched off, please refer to the documen tatio n supplied with the external device.

Some of the external devices require special drivers (see the operating system and external device documentation).

Connecting devices to the Tablet PC

1. Switch off the Tablet PC and all external devices.

2. Remove the mai

3. Connect the cables for your external devices following the instructions.

4. Plug all powe

vices

DevicesP eripheralde

ns plug for the Tablet PC and all relevant devices from the sockets.

r cables into the mains sockets.

Disconnecting devices from the Tablet PC

1. Switch off the Tablet PC and all external devices.

2. Remove the

3. Disconnect the cables for your external devices following the instructions.

DevicesP eripheraldevices

mains plug for the Tablet PC and all relevant devices from the sockets.

60 Fujitsu Technology Solutions

Connecting external devices

HDMI port

HDMIport

The HDMI port of your Tablet PC can be used to connect an external ampliﬁer, LCD TV or a plasma TV with an HD M I connection.

► Connect the data cable to the

external device .

► Connect the data cable to the H DMI

port of the Tablet PC.

Some LCD televisions have only two loudspeaker connections and therefore cannot reproduce Dolby digital or DTS. In order to reproduce the sound, you must go into Windows and adjust the sound settings.

Proceed as follows:

► Select Startsymbo

l – (Settings) – Control Panel – Hardware and Sound – Sound.

► Mark Realtek HDMI Output. ► Select Properti

es – Supported formats.

► Deactivate the setting s DTS audio and Dolby digital. ► Conﬁrm the sett

ings with OK.

Fujitsu Technology Solutions 61

Connecting external devices

Connecting USB devices

USBports

On the USB ports, you can connect external devices that a lso have a US B port (e.g. a DVD drive, a printer, a scanner or a modem).

USB devices are hot-pluggable. This means you can connect and disconnect devices while your operating system is r unning.

USB 2.0 has a data transfer rate of up to 480 Mbit/s.

Additional information can be found in the documentation for the USB devices.

► Connect the data cable to the

external device.

► Connect the data cable to the USB

port on the Tablet PC.

Device drivers

USB devices will be automatically recognised and installed by your operating system.

How to remove U

Always correctly remove the device according to the rules described below, to ensure that none of your data is lost.

► Ta p t h e s ym b ► Select the device which you want to shut down and remove. ► Ta p OK.

Wait for the dialogue box which tells you that it is now safe to remove the device .



62 Fujitsu Technology Solutions

ol for safe removal of the hardware.

SB devices correctly

Connecting external devices

Headphone port

ConnectingaudiodevicesAudioportsC onne ctingheadphones

Via the headphone port, you can connect either a headphone or an external speaker to your Tablet PC.

► Connect the audio cable to the

external device .

► Connect the audio cable to the headphone

port of the Tablet PC. The internal loudspeakers are disabled.



If you purchase a cable from a retailer, please note the following information:

The headphone port on your Tablet PC is a "3.5 mm jack socket".

If you wa nt to connect headphones or a speaker you will need a "3.5 mm jack plug".

Fujitsu Technology Solutions 63

Settings in BIO S Setup Utility

Settings in BIOS Setup Utility

BIOSSetupUtilitySystemsettings,BIOSSetup UtilityConﬁguration,BIOSSetupUtilitySetupSystemconﬁgurationHardwareconﬁguration

The BIOS Setup Utility allows you to set the system functions and the h ardwa re conﬁguration for the Tablet PC.

When it is delivered, the Tablet PC is set to factory default settings. You can change these settings in BIOS Setup Utility. Any changes you make take effect as soon as you save and exit the BIOS Setup Utility.

The BIOS Setup Utility program contains the following m enus:

About System Advanced

Security Boot Exit

Starting the BIOS Setup Utility

► Keep the "Change screen orientation" tablet button pressed and switch the Tablet PC on. ► If a password has been assigned, enter the password and press the Enter key.

To navigate mo re easily in the BIOS Setup Utility, you can use an external USB keyboard.

Displays information relating to the BIOS, processor and Tablet PC

Advanced system settings

Conﬁguration of various hardware components, such as mouse, keyboard, processor

Password settings and security functions

Conﬁguration of the start-up sequence Exits the BIOS Setup Utility

BIOSSetupUtility

If you have forgotten the password, contact your system administrator or contact our customer service centre.

The BIOS Setup Utility starts.

64 Fujitsu Technology Solutions

Settings in BIOS Setup Utility

Operating BIOS Setup Utility

BIOSSetupUtility

► Use the cursor keys



► Select the option you w ► Press the Enter key. ► Press the ► For future referen ce, make a note of the changes you have made (for example, in this manual).

Use the touchscreen to operate the function keys in the BIOS Setup Utility.

Tap on any element in the BIOS Setup menus or tap on the function or cursor keys indicated on the bottom of the screen.

Press theF1key to display help on the operation of the BIOS Setup Utility. The description of the individual settings is shown in the right-hand window of the BIOS Setup Utility.

With the

key you can load the default settings of the BIOS Setup Utility.

←

→

select the m enu you wish to access to make changes.

The menu is displayed on the screen.

↑

or↓.

ESC

ant to change with the cursor keys

key to exit

the selected menu.

Fujitsu Technology Solutions 65

Settings in BIO S Setup Utility

Exiting BIOS Setup Utility

BIOSSetupUtility

You need to select the desired option in the Exit menu and activate it by pressing the Enter key:

Exit Saving Changes - save ch

► To save the current menu settings and exit the BIOS Setup Utility, select ExitSavingChanges and Yes.

The Tablet PC is rebooted



and the new settings come into effect.

anges and exit BIOS Setup Utility

Exit Discarding Changes – Discard changes and exit BIOS Setup Utility

► To discard the changes, select Exit Discarding Changes and Yes.

The settings in place when BIOS Setup Utility was called remain effective. The BIOS



Setup Utility is terminated and the Tablet PC is rebooted.

Load Setup Defaul

► To copy the standard entries for all menus of the BIOS Setup Utility,

choose Load Setup Defaults and Yes.

ts – Copy Standard Entries

Discard C hanges – Discard changes without exiting the BIOS Setup Utility

► To discard the changes you have made, select Discard Changes and Yes.

The settings in place when BIOS Setup Utility was called remain effective.



You can now make additional settings in the BIOS Setup Utility.

► IfyouwanttoexitBIOS Setup Utilitywith these settings, select Exit Saving Changes and Yes.

Save Chan

ges - save changes without exiting

the BIOS Setup Utility

► To save the changes, select Save Changes and Yes.

The changes are saved. You can now make additional settings in the BIOS Setup Utility.



► If you want to exit BIOS Setup Utility with these settings, choose Exit Saving Changes and Yes.

Save Changes and Power Off

► To save the changes and switch off your device, select Save Changes and Power Off and Yes.

The changes are saved. Your device is shut down.



66 Fujitsu Technology Solutions

Troubleshooting and tips

TroubleshootingTipsFaultTroubleshooting

If a fault occurs, try to correct it as described. If you fail to correct the problem, proceed as follows:

► Make a note of the steps and the circumstances that led to the fault. Also

► Switch the Tablet PC off. ► Please contact the Hotline/Service Desk.

Follow the safety notes in the "Safety/Regulations" manual when connecting or disconnecting cables.

make a note of any error messages displayed.

You c a n ﬁnd the telephone numbers in the service desk list. Please have the following information ready when you call:

• The model name and serial number of the Tablet PC. The serial number is located on a sticker on the underside of the Tab let PC.

• Notes of any messages that appear on the screen and information on acoustic signals.

• Any changes you have made to the hardware or software after receiving the Tablet PC.

• Any changes you have made to the BIOS Setup settings after receiving the Tablet PC.

• Your system conﬁguration and all peripheral devices connected to your system.

• Your sales contract.

Our Tablet PCs means that co n in terms of we conﬁguratio compared to a games with i been appro losses or m versions c

Help if pr

Should you encounter a problem with your computer that you cannot resolve yourself:

► Note the ID number of your device. The ID number is found on the type rating

plate on the back or underside of the casing.

► For further clariﬁcation of the problem, contact the Help Desk for your country (see the Help

Desk list or visit the Internet at " do this, please have ready the ID num ber and serial numb er of your system.

Fujitsu Technology Solutions 67

oblems occur

have been designed primarily with mobile applications in mind. This

siderable effort has been made to optimise c ompon ents and equipment

ight, space and energy requirements. Depending on the pa rticu lar

n you have purchased, it is possible that functionality may be slightly reduced

desktop PC if you are running processor-intensive gaming software, e.g.

ntensive 3D graphics. Updating your hardware with drivers which have not

ved by Fujitsu Technology Solutions may result in performance losses, data

alfunction of the equipment. A list of approved drivers and current BIOS

an be downloaded from: "

http://ts.fujitsu.com/support/servicedesk.html"). When you

http://ts.fujitsu.com/support/downloads.html"

Troubleshooting and tips

TheTabletPC’sdateortimeisincorrect

SummertimeTime,day lightsavingsTimenotcorrectTimenotcorrectIncorrectdat e/timeDateisincorrectBufferbattery,load

Cause Troubleshooting

Time and date are incorrect. ► With the BIOS-Setup-Utility, you can set the

Date and time are still set incorrectly after switching on the Tablet PC.

date and time in the main menu.

► Please contact your sales outlet or our

Hotline/Service Desk.

Battery indicator does not illuminate

Cause

The battery is not installed correctly.

The battery is fully discharged. ► Charge the battery.

Fault elimination

► Switch the Tablet PC off. ► Check whether the battery is installed

correctly in its compartment.

► Switch the Tablet PC on.

► Install a charged battery.

► Connect the Tablet PC to a mains outlet

using the mains adapter.

The Tablet PC’s touchscreen remains dark

Touchsc reentouchscreenis toodark

Cause Troubleshooting

Touchscreen is switched off. ► Pre ss a key (external keyboard) or tap on

External monitor or television set connected.

the touchscreen.

► Check whet

are correc has been de Accelera

torDriverformobile".

her the graphics driver settings

t or whether an external monitor

tected in "Intel Graphics Media

The display on the Tablet PC’s touchscreen is difﬁcult to read.

Touchsc reenTouc hscre en

Cause Troubleshooting

Reﬂected glare ► Move the Tablet PC into a different position.

► Increase the brightness of the screen.

68 Fujitsu Technology Solutions

Troubleshooting and tips

The external monitor remains bl

Monitor

Cause Troubleshooting

Monitor is switched off. ► Switch the external monitor on.

Power saving has been activated (monitor is blank).

Brightness is set to dark.

Screen output is set on the Tablet PC’s touchscreen.

The external monitor’s powe r cable or data cable is not connected properly.

The external mo

ScreenMonitor

Cause Troubleshooti

The wrong exte or the w rong sc the applicat

rnal monitor has been selected

reen resolution has been set for

ion program.

nitor is blank or the image is unstable

► Press a key (external keyboard) or tap on

► Adjust the brightness of the

► Check whether the graphics driver settings

► Switch off the Tablet PC and the external

► Check whether the power cable is plugged

► Check whether the data cable is properly

► Switch on the Tablet PC and the external

► Terminate the

► Set the screen resolution: Set th e screen

► Select mo

ank

the touchscreen.

are correct or whether an external monitor has been detected in "Intel Graphics Media Accelerator Driver for mobile".

monitor.

properly into the external monitor and into the power socket.

connected to the Tablet PC and the external monitor (if it is plugged in with a connector).

monitor.

application program in Windows. If th terminating combination in order to s Tab l e t P C . C

resolution as described in the documentation for your operating system.

describe operatin

e error persists after

the program, use the key

for switching the screen output

witch to the touchscreen of the

hange the following setting:

nitor: Select monitor 1 or 2 as

d in the documentation for your

g system.

monitor.

Fujitsu Technology Solutions 69

Troubleshooting and tips

The cursor does not correctly follow the pen movements

Cause

Pen incorrectly calibrated

Fault elimination

► Calibrate the pen as shown under Hardware

and Sound / Tablet PC Settings in the Control

Panel, see "

Calibrating the pen", Page 35.

Setting the pen", Page 34 and

Pen input not working

Cause

Incorrect driver installed.

Troubleshooting

► If your device is one which can only be

operated using the pen, install the driver for the standard model.

► If your device is one which can be

operated using the p en and by ﬁnger, install the driver for the "Dual Digitizer" model.

The Tablet PC do

TheTabletPC

Cause Troubleshooti

The battery is

The battery is de ad.

The power adapter is not connected correctly.

70 Fujitsu Technology Solutions

not installed correctly.

es not start after switch on

► Check whether the battery is installed

correctly in its compartment.

► Switch on the Tablet PC.

► Charge the battery.

► Insert a charged battery.

► Connect the mains adapter to the Tablet

PC.

► Check whether the mains adapter is

connected correctly to the Tablet PC.

► Switch on the Tablet PC.

Troubleshooting and tips

The Tablet PC stops working

TheTabletPCEnergy savingmode

Cause Troubleshooting

The Tablet PC is in energy saving mode.

An application programme has caused the malfunction.

► Leave energy saving mode.

► Close the application progr

the Tablet PC (by restarting system or sw itching the devi

am or restart

the operating

ce off and back

on again).

The battery is dead.

► Charge the battery.

► Insert a charged batter

► Connect the mains adapter to the Tablet

PC.

The printer does not print

rint

Printerdoesnotp

Cause Troubleshooting

The printer is not switched on. ► Make sure that the printer is switch ed

The printer is not connected correctly.

The printer driver is fa ulty or not c orrectly installed, or it is the wrong printer driver.

on and ready for operation (refer to the documentation supplied with the printer).

► Check that the data cable connecting

the Table PC to the printer is properly connected.

► Check that the data cable connecting

the Tablet PC to the printer is properly connected.

► Check whether the correct printer driver is

loaded (refer to the printer documentation).

The radio connection to a network does not work

oconnectiontoanetworkdoes notwork

Theradi

Cause Troubleshooting

The wireless component is disabled.

The wireless component is enabled. Despite this, the wireless connection to a netwo rk does not work.

Fujitsu Technology Solutions 71

► Switch the radio component on (see

Switching the wireless components on and

" off", Page 47).

► Check whether the radio connection is

switched on via the software.

► Further information on using the radio

component can be found in the help ﬁles.

Troubleshooting and tips

The battery discharges too quic

Battery:

Cause

The battery is either too hot or case the battery indicator ﬂas

You may have an application running that consumes a great deal of power due to frequent accessing of the hard disk or optical drive.

The maximum brightness may have been set for the screen.

SmartCard reader is

Cause

Chip card inserted incorrectly.

too cold. In this

hes.

not recognised.

Troubleshooting

► Bring the Tablet PC up/down to a normal

► If the operating time of the battery life is

► Use the mains adapter as frequently as

► Reduce the brightness of the screen to

Troubleshooting

► Make sure you have i

► Check whether the SmartCard you are using

kly

temperature again.

extremely short, the battery is probably too old. Replace battery if necessary.

possible.

lower energy consumption: You will ﬁnd the setting under Control Panel – Hardware and Sounds – Windows Mobility Center.

nserted your SmartCard into th thechipfacingup

is supported. Your SmartCard must comply with th e ISO standard 7816-1, -2, -3 and -4.

e SmartCard reader with wards.

SmartCard PIN forgotten

Cause

PIN forgotten ► If you work in a network, contact your

Troubleshoo

system administrator, who can unlock your Tablet PC with a supervisor PIN.

ting

SmartCard lost

Cause

SmartCard lost ► If you work in a network, contact y our

72 Fujitsu Technology Solutions

Troubleshooting

system administrator, who can boot your Tablet PC with a Supervisor SmartCard.

Troubleshooting and tips

User and/or supervisor SmartCard lost

Cause

User and/or supervisor SmartCard lost ► If you have lost your User SmartCard, you

Troubleshooting

can continue working with the Supervisor SmartCard and initialise a new User SmartCard or deactivate the SystemLock function.

► If you have lost the Supervisor SmartCard,

you can continue working, but you no longer have all your rights and can no longer initialise a S u pervisor SmartCard.

► IfyouhavelostbothSmartCards,youcan

no longer boot your system. Please contact our Service Desk. You must provide proof of ownership for the device. Then the Service Desk will refer you to our service partner, who will unlock your device (for a charge).

Acoustic warnings

essages Acousticerrorm

Errors

Cause

A beep sounds every few seconds.

The battery is almost ﬂat.

Troubleshooting

► Charge the battery.

Error messages on the screen

ErrormessagesonthescreenErrormessage:

This section by the opera

Fujitsu Technology Solutions 73

describes the error messages generated by the BIOS Setup. Error messages displayed

ting system or programmes are described in the relevant d ocu m entation.

If the error contact th

message appears repeatedly, despite troubleshooting measures, please

e place of purchase or our customer service centre.

Troubleshooting and tips

Error message/cause Resolution

CMOS battery b ad

If the error message occurs repeatedly, the

► Contact your sales outlet or our

service centre.

buffer battery in the Tablet PC is ﬂat.

System CMOS checksum bad - default conﬁguration used

The system conﬁguration infor m ation is incorrect.

► Switch off the Tablet PC. ► Switch on the Tablet PC. ► Keep the "C hange screen or

button p ressed and switc

► In the BIOS Setup, select the Exit menu. ► Select the entry Load Se ► Select OK and press the Enter key.

Extended memory failed at offset: xxxx Failing Bits: zzzz zzzz

► Contact your sales outlet or our customer

service centre.

When testing the extende d memory an error has resulted at the address xxxx.

Failure Fixed Disk n

The s ettings of the hard disk drive are incorrect.

Keyboard controller error

► Start the BIOS Setup (Pri m ary Master

submenu) and select the correct settings.

► Switch off your Tablet PC with the ON/OFF

switch.

► Wait 3 - 5 seconds and switch on the Tablet

PC again.

Keyboard error

If you are using an external keybo ard:

► Check the connection and reboot the Tablet

PC.

nn Stuck key Operating system not found

► Make sure that no key is pressed.

► Check in th

disk has b

► Make sure that the operating system is

installed on the corresponding drive.

Press <F1> to resume, <F2> to SETU P

This error message appears if an error occurs during the self-test before starting the operating system.

Real time clock error

► Press the " Alt "key on the Tablet PC to boot

the operating system

► Keep the "Change screen orientation"tablet

button pressed an d switch on the Tablet PC to access the BIOS setup.

► Contact your sales outlet or our customer

service centre.

nnnnK Shadow RAM failed at offset: xxxx Failing Bits: zzzz

stem battery is dead - Replace and run SETUP

► Con

vice centre.

ser

► Contact your sales outlet or our customer

service centre.

System cache error - Cache disabled

► Contact your sales outlet or our customer

service centre.

System timer error

► Contact your sales outlet or our customer

service centre.

customer

ientation" ta blet

h on the Tablet PC .

tup Defaults.

e BIOS Setup whether your hard

een set correctly.

tact your sales outlet or our customer

74 Fujitsu Technology Solutions

Technical data

Tablet PC

General

Processor Intel Atom Z 670

Main memory (SO DIMM) 2 GByte DDR2 onboard

Electrical data

Safety regulations complied with C E

Protection class II

Maximum power consumption: (Tablet PC on with battery charging)

Touchscreen

Size 25.65 cm 16:10 TFT WXGA

Resolution

Pixel class II

Brightness control 6 levels

Technology

Digitizer and glass panel Dual digitizer with matt touch screen

Cameras • Front: VG A camera

Graphics card

Chip Intel GMA 600

Maximum resolution on external display: 1280 x 720 pixels

Dimensions

Width x depth x height 275 mm x 192 mm x 16.2 mm

ht depending on conﬁguration

Weig

Input devices

Tablet buttons 3 keys

Pen

Slots

Memory card slot

SmartCard slot

SIM card slot

Ports

HDMI port 1 x

Headphones port/Line Out

Docking port 1 x

USB (Universal Serial Bus) 1 x USB 2.0

40 W

1280 x 800 pixels/16 million colours

Wide-View High-Bright WXGA Display with LED Background Lighting

•Back:1.3m

•from

• from 0.87 kg with a 4-cell battery

1 freely programmable rocker button / eraser

1 x SD or MS card

3.5mmstereominijack

egapixels

0.76 kg with a 2-cell battery

Technical data

Fujitsu Technology Solutions 75

Technical data

Ambient condition s

Environment class DIN IEC 721

Mechanism class DIN IEC 721

Operating temperature 5℃ .... 35℃

Transport temperature (2K2) –15°C .... 60°C

7K1

7M2

Rechargeable battery

You c a n ﬁnd information on the batteries used in your device at

http://ts.fujitsu.com/support".

4-cell lithium polymer battery 5240 mAh

Rated voltage 7.2 V 7.2 V

Rated capacity 38 Wh 19 Wh

2-cell lithium polymer battery 2620 mAh

Mains adapter (40 W)

Technicaldata

Rated voltage 19 V

Max. rated current 2.1 A

An additional mains adapter or power cable can be ordered at any time.

Cradle (optional)

Electrical data

Safety regulations complied with CE

Protection class II

Ports

USB (Universal Serial Bus) 4 x USB 2.0

Docking port 30-pin

Ambient condition s

Environment class DIN IEC 721

Mechanism class DIN IEC 721

Operating temperature 5 °C .... 35℃

Transport temperature

7K1

7M2

–15 °C .... 60 ℃

76 Fujitsu Technology Solutions

Manufacturer’s notes

Disposal and recycling

Notes

Information about this subject can be found on your Tablet PC or on our Internet pages.

Declarations of Conformity

Declarationofconformity

The "Declarations of Co address under: "

Fujitsu Technology So essential requiremen

Tested safety (TS, depending on the device)

nformity" for the device can be found at our Internet

/ts.fujitsu.com/ce".

http:/

lutions hereby declares that your device is in compliance with th e

ts and other relevant provisions of Directive 1999/5/EC.

With the AntiGlare dis p lay, the device meets the requirements of the following directives:

• EN60950-1:2001

• DIN EN ISO 13406-2:2003

• EK1-ITB 2000:2008

• DIN EN ISO 9241-4:1999

Fujitsu Technology Solutions 77

Manufacturer’s notes

CE marking

CEmarking

CE marking for devices with radio component

This equipment complies with the requirements of Directive 1999/5/EC of the European Parliament and Commission from 9 March, 1999 governing Radio and Telecommunications Equipment and mutual recognition of conformity.

This equipment can be used in the following countries:

Belgium Bulgaria Denmark

Estonia Finland France

UK Ireland Iceland Italy

Latvia Liechtenstein Lithuania Luxembourg

Malta The

Poland Portugal Rumania

Switzerland Slovakia Slovenia Spain

Czech Republic

Contact the corresponding government ofﬁce in the respective country for current information on possible operating restrictions. If your country is not included in the list, then please contact the corresponding supervisory authority as to whether the use of this product is permitted in your country.

Regulatory notices

If there is no FCC logo and also no FCC ID on the device then this device is not approved by the Federal Communications Commission (FCC) of the USA. Although it is not explicitly forbidden to travel in the US trading area carrying this device, to avoid trouble at customs clearance, Fujitsu Technology Solutions G mbH recommends not to bring this device into the US trading area.

Netherlands

Hungary

Germany

Greece

Norway Austria

Sweden

Cyprus

Regulatory information for Tablet PCs without radio device

Regulatoryinformation

NOTICE:

Changes or modiﬁcations not expressly approved by Fujitsu Technology Solutions could void this user’s authority to operate the equipment.

Notice to Users of Radios and Television

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference w ill not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

78 Fujitsu Technology Solutions

Manufacturer’s notes

• Connect the equipment into an outlet that is on a different circuit than the receiver.

• Consult the dealer or an experienced radio/TV technician for help.

Notice to Users of the US Telephone Network

Your Tablet PC may be supplied with an internal modem which complies with Part 68 of the FCC rules. On this Tablet PC is a label that contains the FCC Registration Number and the Ringer Equivalence Number (REN) for this equipment among other information. If requested, the user must provide their telephone company with the following information:

1. The telephone number to which the Tablet PC is connected.

2. The Ringer Equivalence Number (REN) for this equipment.

3. The equipment requires a standard modular jack type USOC RJ-11C

which is FCC Part 6 8 compliant.

4. The FCC Registration Number. This equipment is designed to be connected to th e telephone network or premises wiring using

a standard modular jack type USOC RJ-11C which is FCC Part 68 compliant and a line cord between the modem and the telephone network with a minimum of 26AWG.

The REN is used to determine the number of devices that you may connect to your telephone line and still have all of those devices ring when your number is called. Too many de vices on one line may result in failure to ring in response to an incoming call. In most, but not all, areas the sum of the RENs of all of the devices should not exceed ﬁve (5). To be certain of the number of devices you may connect to your line, as determined by the RENs, contact your local telephone company. If this equipment causes harm to the telephone network, your telephone company may discontinue your service temporarily. If possible, they will notify you in advance. If advance notice is not practical they will notify you as soon as possible. You will also be advised of your right to ﬁle a complaint with the FCC.

This fax mode m also complies with fax branding requirements per FCC Part 68.

Your telephone company will probably ask you to disconnect this equipment from the telephone network until the problem is corrected and you are sure that the equipment is not malfunctioning. This equipment may not be used on coin-operated telephones provided by your telephone company. Connection to party lines is subject to state tariffs. Contact your state’s public utility commission, public service commission or corporation commission fo r more information.

This equipment includes automatic dialing capability. When programming and/or making test calls to emergency numbers:

• Remain on the line and brieﬂy explain to the dispatcher the reason for the call.

• Perform such activities in off-peak hours, such as early morning or late evening. FCC rules prohibit the use of non-hearing aid compatible telephones in the

following locations or applications:

• All public or semi-public coin-operated or credit card telephones.

• Elevators, highways, tunnels (automobile, subway, railroad or pedestrian) where a

person with impaired hearing might be isolated in an emergency.

• Places where telephones are speciﬁcally installed to alert emergency authorities

such as ﬁre, police or medical assistance personnel.

• Hospital rooms, residential health c are facilities, convalescent homes and prisons.

• Hotel, motel or apartment lobbies.

• Stores where telephones are used by patrons to order merchandise.

Fujitsu Technology Solutions 79

Manufacturer’s notes

• Public transportation terminals where telephone s are used to call taxis or to reserve lodging or rental cars.

• In hotel and m ote l rooms as at least ten percent of the rooms must contain he aring aid-compatible telephones or jacks for plug-in hearing aid compatible telephones which will be provided to hearing impaired customers on request.

DOC (Industry CANADA) notices

DOC(INDUSTRYCANADA)NOTICES

Notice to Users of Radios a

This Class B digital appa

nd Television

ratus meets all requirements of Canadian Interference-Causing Equipment

Regulations.

CET appareil numérique sur le matérial brouill

Notice to Users of the

de la class B respecte toutes les exigence du Réglement

eur du Canada.

Canadian Telephone Network

NOTICE:

This equipmen t meet Speciﬁcations. Th the registration n Conformity indica imply that Indust a telephone line t the local teleco certiﬁcation s

Repairs to tele maintenance fa any equipment user to discon

s the applicable Industry Canada Terminal Equipment Technical

is is conﬁrmed by the registration number. The abbreviation, IC, before

umber signiﬁes th at registration was performed based o n a Declaration of

ting that Industry Canada technical speciﬁcations were met. It does not

ry Canada approved the equipment. Before connecting this equipment to

he user should ensure that it is permissible to connect this equipment to

mmunication facilities. The user should be aware that compliance with the

tandards does not prevent service degradation in some situations.

communication equ ipment should be made by a Canadian authorised

cility. Any repairs or alterations not expressly approved by Fujitsu or

failures may give the telecommunication company cause to request the

nect the equipment from the telephone line.

NOTICE:

The Ringer E to each term allowedtob consist of Ringer Equ

quivalence Number (REN) for this terminal equipment is 0.0. The REN assigned

inal equipment provides an indication of the maximum number of terminals

e connected to a telephone interface. The termination on an interface may

any combination of devices subject only to the requirement that the sum of the

ivalence Numbers of all the devices does not exceed ﬁve.

CAUTION:

For safet telepho attempt inspec

y, users should ensure that the electrical ground of the power utility, the

ne lines and the metallic water pipes are connected together. Users should NOT

to make such connections themselves but should contact the appropriate electric

tion authority or electrician. This may be particularly important in rural areas.

Avis Aux Utilisateurs Du Réseau Télé phonique Canadien

AVIS : Le présent matériel est conforme aux spéciﬁcations techniques d’Industrie Canada applicables au matériel terminal. Cette conformité est conﬁrmée par le numéro d’enregistrement. Le sigle IC, placé devant le numéro d’enregistrement, signiﬁe que l’enregistrement s’est effectué conformément à une déclaration de conformité et indique que les spéciﬁcations techniques d’Industrie Canada ont été respectées. Il n’implique pas qu’Industrie Canada a approuvé le matériel.

80 Fujitsu Technology Solutions

Manufacturer’s notes

Avant de connecter cet équipement à une ligne téléphonique, l’utilisateur doit vériﬁer s’il est permis de connecter cet équipement au x installations de télécommunications locales. L’utilisateur est averti que même la conformité aux normes de certiﬁcation ne peut dans certains cas empêcher la dégradation du service.

Les réparations de l’équipement de télécommunications doivent être effectuées par un service de maintenance agréé au Canada. Toute réparation ou modiﬁcation, qui n’est pas expressément approuvée par F ujitsu, ou toute défaillance de l’équipement p eut entraîner la compagnie de télécommunications à exiger que l’utilisateur déconnecte l’équipement de la ligne téléphonique.

AVIS : L’indice d’équivalence de la sonnerie (IES) du présent matériel est de 0.0. L’IES assigné à chaque dispositif terminal indique le nombre maximal de terminaux qui peuvent être raccordés à une interface téléphonique. La terminaison d’une interface peut consister en une combinaison quelconque de dispositifs, à la seule condition que la somme d’indices d’équivalence de la sonnerie de tous les dispositifs n’excède pas 5.

AVERTISSEMENT:

Pour assurer la sécurité, les utilisateurs doivent vériﬁer que la prise de terre du service d’électricité, les lignes télphoniques et les conduites d’eau métalliques sont connectées ensemble. Les utilisateurs NE doivent PAS tenter d’établir ces connexions eux-mêmes, mais doivent contacter les services d’inspection d’installations électriques appropriés ou un électricien. Ceci peut ê tre particulièrement important en régions rurales.

UL Notice

This unit requir The correct out below for the co

es an AC adapter to operate. Only use a UL Listed Class 2 adapter. put rating is indicated on the AC adapter label. Refer to the illustration

rrect AC Adapter output polarity:

CAUTION:

To reduce the risk of ﬁre, use only 26AWG or larger telecommunications line cord.

For Authorized Repair Technicians Only

CAUTION:

For continued protection against risk of ﬁre, replace only with the same type and rating fuse.

WARNING:

Danger of explosion if Lithium (CMOS) battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer.

Dispose of u sed batteries according to the manufacturer’s instructions.

FCC Regulatory information for Tablet PCs with radio device

Regulatoryinformation

Federal Communications Commission statement

Fujitsu Technology Solutions 81

Manufacturer’s notes

This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause interference, and

(2) this device must accept any interference, including interference that may cause undesired operation of this device.

FCC Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communicatio ns.

However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the distance between the equipment and the receiver.

3. Connect the equipment to an outlet on a circuit different from the one the receiver is connected to.

4. Consult the dealer or an experienced radio/TV technician for help.

Please note the following regulatory information related to the optional radio device.

FCC Radio Frequency Exposure statement

This radio device has been evaluated under FCC Bulletin O ET 65C and found compliant with the requirements as set forth in CFR 47 Sections 2.1091, 2.1093, and 15.247 (b) (4) addressing RF Exposure from radio frequency devices. The radiated output power of this radio device is far below the FCC radio frequency exposure limits. Nevertheless, this device shall be used in such a manner that the potential for human contact during normal operation is minimized. When using this device, a certain sepa ration distance between antenna and nearby persons must be maintained to ensure RF exposure compliance. In order to comply with RF exposure limits established in the ANSI C95.1 standards, the distance between the antennas and the user should not be less than 20 cm (8 inches).

Regulatory Notes and Statements Radio device, health and authorisatio n for use

Radio-frequency electromagnetic energy is emitted from the wireless devices. The energy levels of these emissions, however, are far much less than the electromagn etic energy emissions from wireless devices such as mobile phones. Radio devices are safe for use by consumers because they o perate within the guidelines found in radio frequency safety standards and recommendations.

The use of the radio devices may be restricted in some situations or environments, such as:

• on board an airplane, or

• in an explosive environment, or

• in situations where the interference risk to other devices or services is perceived or identiﬁed as harmful.

In cases in which the policy regarding use of radio devices in speciﬁc environments is not clear (e.g., airports, hospitals, chemical/oil/gas industrial plants, private buildings), obtain authorization to use these devices prior to operating the equipment.

Regulatory Information/Disclaimers

82 Fujitsu Technology Solutions

Manufacturer’s notes

Installation and use o f this radio device must be in strict accordance w ith the instructions included in the user documentation provided with the product. A ny changes or modiﬁcations made to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment. The manufacturer is no t responsible for any radio or television interference caused by unauthorized modiﬁcation of this device, or the substitution or attachment of connecting cables and equipment other than those speciﬁed by the manufacturer. It is the responsibility of the user to correct any interference caused by such unauthorized modiﬁcation, substitution or attachment. The manufacturer and its authorized resellers or distributors will assume no liability for any damage or violation of government regulations arising from failure to comply with these guidelines.

Export restrictions

This product or software contains encryption code which may not be exporte d or transferred from the US or Canada without an approved US Department of Commerce export license. This device complies with Part 15 of FCC Rules, as well as ICES 003 B / NMB 003 B. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesirable operation.

Modiﬁcations not expressly authorised by Fujitsu Technology Solutions may invalidate the user’s right to operate this equipment.

Fujitsu Technology Solutions 83

Index

Acoustic error messages 73 Audio ports 63

Battery

battery life 39 caring for and maintaining 40 charge level 40, 43 charging 40 self-discharge 40 storage 40

Battery status m eter 40 Battery:

discharges too quickly 72

BIOS Setup Utility

calling 64 exiting 66 operating 65 protecting w ith password 54 settings 64

Bluetooth

Switching off module 47 Switching on module 47

Bluetooth, safety notes 11 Buffer battery, load 68

CE marking 78 Charging capacity, battery 40 Cleaning 16 Conﬁguration, BIO S Setup Utility 64 Connecting audio devices 63 Connecting headphones 63 Cradle

Connecting a Tablet PC 50 Ports 49

Crystal View display

cleaning 16

selecting 23

DOC (INDUSTRY CANADA) NOTICES 80

Energy

energy saving 15 Energy saving 15 Energy saving mode

leaving 71 Error message:

on the screen 73 Error messages on the screen 73 Errors

Acoustic warnings 73

Fault

correction 67 Fingerprint sensor 53

conﬁgure 53 First-time setup 17

Getting started 17 GPS 48

Hardware conﬁguration 64 HDMI port 61

Important notes 11 Incorrect date/time 68

Keyboard

cleaning 16

Date is incorrect 68 Declaration of conformity 77 Device

setting up 18

Devices

connecting 60 disconnecting 60

Display orientation

84 Fujitsu Technology Solutions

Landscape orientation

screen 23 Life, battery 39

Mains adapter

connecting 18

setting up 18

Index

Memory card

handling 44 inserting 44

removing 45 Mobile operation 15 Monitor

drifting display 69

remains blank 69

Notes 11

cleaning 16

disposal / recycling 77

energy saving 15

Safety 11

touchscreen 22

transport 15

Operating system

activating system protection 56

cancel system prote ction 56

protecting with passw ord 55

Packaging 17 Password

changing 55

entering 55

removing 55 Password protection 54 Password protection:

hard disk 56 Peripheral devices

connecting 60

disconnecting 60 Portrait orientation

screen 23 Ports

Cradle 49 Power

power consumption 43

power-management features 43 Power-on indicator 21 Preparing for operation 18 Printer does not print 71

Radio component :

safety notes 11 Rechargeable battery 39

see Battery 39

Regulatory information

Tablet PCs with radio device 81 Tablet PCs without ra dio device 78

Safety notes 11 Screen

no screen display 69

Security functions 53

SystemLock 58

Security func tions,

SmartCard 58 Selecting a location 18 Self-discharge, battery 40 Setup

see BIOS Setup Utility 64 Slot

Memory cards 44 Status indicators 20 Summer time 68 Supervisor password

changing 55

entering 55

removing 55 Suspend/Resume button 21 Switchingonfortheﬁrst time 19 Symbols

indicators 20 System conﬁguration 64 System settings, BIOS Setup Utility 64

Tablet PC

before you travel 15

cleaning 16

switching o ff 21

transporting 15–16

using 20 Tablet PC, operation 20 Tablet PC: switching on 21 Technical data

Mains adapter 76 The radio connection to a network does

not work 71 The Tablet PC

cannot be started 70

doesn’t work. 71 Time not correct 68 Time, daylight savings 68 Tips 67

Fujitsu Technology Solutions 85

Index

Touchpad

cleaning 16

Touchscreen

cleaning 16 difﬁcult to read 68 notes 22 reﬂected glare 68

remains blank 68 touchscreen is too dark 68 TPM 59 Transport

Transport damage 17 Transportation 15–16 Travel, Tablet PC 15 Troubleshooting 67 Trusted Platform Module 59

USB ports 62 User password

changing 55 entering 55 removing 55

Webcam 39 Wireless LAN

Switching off module 47 Switchingonmodule 47

Wireless LAN:

safety notes 11

86 Fujitsu Technology Solutions

Fujitsu Q550-30GB-01 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

STYLISTIC Q550

Contents

Innovative technology

Further information

Notational conventions

Ports and controls

Important notes

Safety notes

Additional safety notes for devices with radio components

Protecting the display screen

Energy saving

Energy saving under Windows

Before you travel

Transporting the Tablet PC

Cleaning the Tablet PC

First-time setup of your device

Selecting a location

Mains adapter connecting

Working with the Tablet PC

Status indicators

Switching on the Tablet PC

Programming the ON/OFF switch

Switching off the Tablet PC

Touchscreen

Background lighting

Select display orientation (portrait or landscape orientation)

Using the stylus pen

Setting the pen

Calibrating the pen

Changing the pen tip

Removing the pen battery

Installing a pen battery

Installing a pen cord

Tablet buttons

Programming the tablet buttons

Webcam

Rechargeable battery

Charging, caring for and maintaining the battery

Removing and installing the battery

Using the power-management features

Memory cards

Supported format

Inserting the memory card

Removing the memory card

SIM card

Inserting the SIM card

Removing a SIM card

Switching the wireless components on and off

Setting up WLAN access

Access via UMTS

Your Cradle (optional)

Cradle components

SettinguptheCradle

Connecting the Tablet PC to the Cradle

Disconnecting the Tablet PC from the C radle

Security functions

SmartCard reader

Inserting the SmartCard

Trusted Platform Module (TPM) (device-dependent)

Enabling TPM

Disabling TPM

Connecting external devices

Connecting devices to the Tablet PC

Disconnecting devices from the Tablet PC

HDMI port

Connecting USB devices

Headphone port

Settings in BIO S Setup Utility

Starting the BIOS Setup Utility

Operating BIOS Setup Utility

Exiting BIOS Setup Utility

Save Changes and Power Off

Troubleshooting and tips

TheTabletPC’sdateortimeisincorrect

Battery indicator does not illuminate

The Tablet PC’s touchscreen remains dark
