Fujitsu M3096EX, M3096GX User Manual 2
M3096EX AND M3096GX
IMAGE SCANNER
OPERATOR’S GUIDE
C150-E009-07EN
REVISION RECORD
Edition
01
02
03
04
05
06
07
Date published
June, 1994
August, 1994
Janualy, 1995
April, 1995
September, 1995
January, 1996
August, 1996
Revised contents
First edition
Contents revised
Contents revised
Pick Roller replacement procedure added
Pad replacement procedure added
Appendix C, Declaration of Conformity added
Declaration of Conformity revised
Specification No.: C150-E009-07EN
This digital apparatus does not exceed the Class A limit for radio noise emissions from digital apparatus set out in the Radio
interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n’ément pas de bruits radioélectriques dépassant les limites applicables aux appareils
numériques de la classe A prescridtes dans le Réglesment sur le brouillage radioélectrique édicté par le ministere des
Communications du Canada.
Maschinenlärmlnformationsverordnung 3. GSGV, 18.01.1991:Der arbeisplatzbezogene Schalldruckpegel beträgt 70
dB(A)oder weniger gemäß ISO 7779.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
The contents of this manual is subject to change
without prior notice.
All Rights Reserved,
Copyright 1994, 1995, 1996 FUJITSU LIMITED
i
Conventions Special information, such as warnings, cautions are indicated as
follows:
WARNING
A WARNING indicates that personal injury may result if you do not
follow a procedure correctly.
CAUTION
A CAUTION indicates that damage to the scanner may result if you
do not follow a procedure correctly.
NOTICE
A NOTICE provides “how-to” tips or suggestions to help you perform
a procedure correctly. NOTEs are particularly useful for first-time
users.
ii
CONTENTS
page
CHAPTER 1 PREFACE .....................................................................................................1-1
CHAPTER 2 COMPONENTS ............................................................................................2-1
2.1 Checking the Components ..........................................................................................2-1
2.2 Part Names and Functions............................................................................................2-2
2.2.1 Exterior view of image scanner ...........................................................................2-2
2.2.2 Functions of each part ..........................................................................................2-3
2.3 Indication Panel Functions (standard model)...............................................................2-4
2.3.1 Indicators .............................................................................................................2-4
2.4 Operator Panel Functions (LCD model) ......................................................................2-4
2.4.1 Indicators .............................................................................................................2-5
2.4.2 Buttons and liquid crystal display screen ............................................................2-5
2.4.3 Liquid crystal display screen ...............................................................................2-6
2.4.4 Messages ............................................................................................................2-11
CHAPTER 3 INSTALLATION AND CONNECTIONS .................................................3-1
3.1 Precautions ...................................................................................................................3-1
3.2 Removing the Carrier Fixing Bracket ..........................................................................3-2
3.3 Connections..................................................................................................................3-3
3.4 Mounting the Stacker ...................................................................................................3-5
3.5 SCSI -ID Setting ..........................................................................................................3-6
CHAPTER 4 OPERATIONS ..............................................................................................4-1
4.1 Turning on the Power...................................................................................................4-1
4.2 Reading a Document in Flatbed Mode ........................................................................4-2
4.2.1 Reading a standard-size document ......................................................................4-2
4.2.2 Reading a page from a thick book .......................................................................4-3
4.2.3 Reading a document larger than the document board..........................................4-4
4.3 Reading Documents in ADF Mode..............................................................................4-5
iii
CHAPTER 5 MAINTENANCE ..........................................................................................5-1
5.1 Removing Jammed Documents ...................................................................................5-1
5.2 Notes on Daily Use ......................................................................................................5-2
5.3 Cleaning .......................................................................................................................5-2
5.3.1 Cleaning the document cover, document holding pad, and document bed .........5-2
5.3.2 Cleaning the ADF ................................................................................................5-3
5.4 Consumables/Periodical replacement parts .................................................................5-4
5.4.1 Parts number and replacement cycle ...................................................................5-4
5.4.2 Replacing pad ASY .............................................................................................5-4
5.4.3 Replacing pick roller............................................................................................5-5
CHAPTER 6 TROUBLESHOOTING ...............................................................................6-1
APPENDIX A ..........................................................................................................................A-1
A.1 Installation Specifications ...........................................................................................A-1
A.2 External Dimensions ...................................................................................................A-2
APPENDIX B ..........................................................................................................................B-1
B.1 Test mode for maintenance .........................................................................................B-1
APPENDIX C ..........................................................................................................................C-1
C.1 Option ..........................................................................................................................C-1
C.2 IPC-2/CMP-2 option board installation ......................................................................C-1
iv
FIGURES
page
2.1 Received components ..................................................................................................2-1
2.2 M3096EX/GX parts names ..........................................................................................2-2
2.3 M3096EX/GX Indication panel ...................................................................................2-4
2.4 M3096EX (LCD model) operator panel ......................................................................2-4
3.1 SCSI-ID setting ............................................................................................................3-6
4.1 Flatbed reading.............................................................................................................4-3
4.2 Removing the document cover.....................................................................................4-4
4.3 ADF paper chute setting ..............................................................................................4-7
4.4 Loading the document..................................................................................................4-9
5.1 Removing jammed documents.....................................................................................5-1
5.2 Cleaning the document cover, document holding pad, and document bed..................5-2
5.3 Cleaning the ADF ........................................................................................................5-3
5.4 Pick Roller replacement ...............................................................................................5-5
5.5 Move the Retaining spring ...........................................................................................5-6
5.6 Slide the Pick Roller ....................................................................................................5-6
5.7 Remove the Pick Roller ...............................................................................................5-6
A.1 External dimensions ....................................................................................................A-2
v
TABLES
page
1.1 The differences between the M3096EX and the M3096GX........................................1-1
3.1 SCSI-ID setting ............................................................................................................3-6
6.1 Check items..................................................................................................................6-1
A.1 Installation specifications............................................................................................A-1
B.1 LED at an error ............................................................................................................B-2
vi
CHAPTER 1 PREFACE
This manual describes how to operate the M3096EX and M3096GX image scanners. An image
scanner optically reads image information from a document and outputs the information to the
host system. The differences between the M3096EX and the M3096GX image scanners are
listed in table 1.1.
Table 1.1 The differences between the M3096EX and the M3096GX
Model number
M3096EX
LCD model
Standerd model
M3096GX
(Standerd
*Standerd model is the model which does not have LCD on operator panel.
This manual should be read before operating the image scanner to ensure correct operation.
Note on Copyright Act
This document cannot be reproduced or copied for any use other than private without the
author’s permission.
*
model)
Interface
RS232C
+
VIDEO
SCSI2
Shipping
models
North America
Europe
North America
Europe
Image size
A3 size or
double-letter
size
Automatic
document feeder
Yes
Max. 50 pages
(A4)
1 – 1
This page is intentionally left blank.
1 – 2
CHAPTER 2 COMPONENTS
2.1 Checking the Components
2.2 Part Names and Functions
2.3 Indication Panel Functions
2.4 Operator Panel Functions
After unpacking image scanner, confirm that all the components have been received. This
section describes the components of the image scanner and their functions.
2.1 Checking the Components
These high precision components must be handled with care. Confirm
that all the components shown in figure 2.1 have been received. If
any component is missing, please contact your local Fujitsu sales
person.
Image scanner
Operator’s Guide
(this manual)
Power cable
for Europe
Power cable for
North America
Terminator
(for M3096GX)
Pads
Inspection
report
One stacker and
two extensions
Figure 2.1 Received components
2 – 1
2.2 Part Names and Functions
This section shows the exterior view of image scanner. This section
also provides names of each part and describes their functions.
2.2.1 Exterior view of image scanner
The image scanner can read a document of A3 or double-letter size at
maximum.
Document cover
Automatic document
feeder (ADF)
Document
holding pad
Document
bed
Extension
Extension
Power switch
Stacker
Power inlet
ADF paper chute
Indication panel (Standerd model)
Operator panel (LCD model)
ADF lever
Third party slot opening
(M3096EX)
Interface connectors
2 – 2
Figure 2.2 M3096EX/GX parts names
2.2.2 Functions of each part
Document cover: Closed over and holds a document to be
Document bed: A document to be read is placed on the
Document holding pad: Presses a document to the document bed.
Automatic document feeder (ADF):
Stacker: Stacks the read documents.
Extension: Keeps the stacked documents from
Power switch: Turns the power on or off.
Indication panel: The indication panel indicates the status
ADF paper chute: Holds the documents to be fed by the
read.
bed also called Flatbed (FB).
Automatically feeds documents to the
reading position.
overhanging.
of the scanner.
automatic document feeder.
ADF lever: Opens or closes the automatic document
feeder to remove documents jammed in
the feeder.
Power inlet: To be connected to an AC power outlet
with the power cable.
Interface connectors: To be connected to the host system with
interface cables.
Third party slot opening: Reserved. (M3096EX)
2 – 3
2.3 Indication Panel Functions (standard model)
Figure 2.3 M3096EX/GX Indication panel
2.3.1 Indicators
The meaning of each indicator is as follows:
Power indicator (Green):
Lights to indicate the power is on.
Read (reading in progress) indicator (Green) :
Lights to indicate reading is in progress.
Power
Read
Check
Indicators
Check (device check) indicator (Yellow):
Lights if a device error occurs which may result in a service
call. This indicator blinks if a document is jammed in the
automatic document feeder. This indicator turns off when the
jammed documents are re-moved from the feeder and the
feeder is closed.
This indicator blinks in four seconds period if the ADF cleaning is necessary. (See 5.3.2)
2.4 Operator Panel Functions (LCD model)
The operator panel has indicators and a liquid crystal display screen
for displaying image scanner status. The operator panel also has
operation buttons.
Liquid crystal display screen
Mode 1
Mode 2
ADF
Buttons
Size
Landscape
Density
Halftone
Resolution
Document
Stop
Start
Power
Ready
Check
Indicators
2 – 4
Figure 2.4 M3096EX (LCD model) operator panel
2.4.1 Indicators
The meaning of each indicator is as follows:
Power indicator (Green):
Lights to indicate the power is on.
Read indicator (Green) :
In manual mode, when this lamp is lit, it indicates that the start
switch is enabled.
Check (device check) indicator (Yellow):
Lights if a device error occurs which may result in a service
call. This indicator blinks if a document is jammed in the
automatic document feeder. This indicator turns off when the
jammed documents are removed from the feeder and the feeder
is closed.
2.4.2 Buttons and liquid crystal display screen
The function of each button is as follows:
Start button:
Read operation can be started in either manual or automatic
mode. To start reading in manual mode, press this button while
the ready indicator is lit.
• Manual mode: Reading is started by the start button.
• Automatic mode: Reading is started by a command from
the host system.
Stop button:
This button is effective regardless of whether the scanner is in
manual or automatic mode. Press this button to stop the read
operation. When this button is pressed, the image scanner
operates as follows:
• Reading in flatbed mode: Reading is immediately stopped.
• Reading in ADF mode: Reading is immediately stopped
and documents being fed are ejected to the stacker.
After cleaning a jam, press the stop button to clear the
“Paper Jam” message displayed on the screen. The
ready screen will then be displayed to indicate that the
scanner is ready to read.
2 – 5
2.4.3 Liquid crystal display screen
The screen has two message lines. The current read mode status is
displayed in the upper line, and messages and the modes set by the
buttons are displayed in the lower line.
Upper line
Lower line
AFDA004>.L4
Reading mode Display
Flatbed
Automatic document feeder
: FB
: ADF
Doument orientation Display
Portrait:
Landscape:
:
:
Density
Very dark
Dark
Dynamic threshold
Simplified dynamic threshold
Normal
Light
Very light
Display
:
:
:
AT
:
AT2
:
:
:
Size
Double-letter size
Letter size
Legal size
A3 size
A4 size
If the optional PC board
1
}
is installed
Display
: DL
: LT
: LG
: A3
: A4
Resolution
400 dpi
300 dpi
240 dpi
200 dpi
Halftone processing
No halftone processing
Dither processing
Error diffusion processing
Automatic separation (by dither processing)
Automatic separation (by error diffusion processing)
Display
: 400
: 300
: 240
: 200
Display
:
: HT1
: HT2
: LP1
: LP2
If the optional PC
board is installed
If the optional PC board is not installed, automatic separation cannot be done.
Line or photo selection Display
To read a photo document
To read a line document
: P.
: L.
Image processing board (optional) installed
No
Yes
:
: >
2 – 6
The ADF, size, density, resolution, landscape, half-tone, document,
and mode 1 and 2 buttons described below are effective unless otherwise specified by the host system.
Automatic document feeder (ADF) button:
Selects whether to feed documents automatically by ADF or
manually on the flatbed. When this button is pressed, the lower
line is displayed as shown in Screen 1. Each time this button is
pressed, “FB” or “ADF” starts blinking in turn, and the read
operation status displayed in the upper line changes accordingly.
Screen 1 — The upper line shows a typical example.
Upper line
Lower line
AFDA
eRBF:da
004
FDA
Blinking
Size button:
Selects a document size. When this button is pressed, the lower
line is displayed as shown in Screen 2. Each time this button is
pressed, “DLT”, “LT”, “LG”, “A3”, or “A4” starts blinking in
turn, and the size displayed on the upper line changes accordingly.
Screen 2 — The upper line shows a typical example.
Upper line
Lower line
LFDA
:eziSLLG
TD
TL 4A3A
004
Blinking
If the direction indicated on the upper line is “ ”, only “LT”
or “A4” can be selected.
>.L4
>.LG
2 – 7
Loading...
