FUTRO A2xx-Series power than you expect!

Issue

May 2009

Pages

The smart solution with more

Take a look at the A2xx-series and find out how smart today`s thin client computing can be – and it is more powerful than you would think it is!

The FUTRO A is ideally suited for Windows Terminal Server computing. The server executes the applications, the screen is displayed on the client. Your data is saved secure on the server and is therefore protected against loss. Also the operating system is stored secure on a flash memory and safe from unauthorized changes due to a write protected file system.

Scout Enterprise is the perfect administration tool and helps you to manage and update the client easily. Space saving desing, no fan and rotating drives turn the FUTRO A2xx into the ideal thin client for your project and into

a minimizer of Total Cost of Ownership .

Accessibility

 eLux® NG or Windows® CE 5.0 operating system with

ICA / RDP protocol and terminal emulations

 TCP/IP network integration with DNS and DHCP support  10/100/1000 Mbit/s Ethernet LAN controller with PXE

bootcode on board

 Explorer for direct internet connection  Support of extended memory with MEMORYBIRD,

external USB CD-ROM drive and a wide range of Fujitsu keyboards

Reliability

 Cost-optimized and trusted solution for displaying and

running Windows applications

 Approved by Microsoft Terminal Server and Citrix

MetaFrame XP 1.8 / Presentation Server 3.0 / 4.0

 Highest quality design and function stability

Manageability

 Scout Enterprise remote administration is available as

option for Windows® CE 5.0 and in combination with eLux® NG

 Simple network administration: programs and data are on

the server

 Easy configuration, administra tion and sy ste m monit orin g

via optional tools

 Cost-effective remote administration via SNMP and

DHCP standard protocols

 Manageability tool Scout Enterprise for embedded Linux

solution

Security

 Optional external SmartCard reader  SmartCard support by Certification Server (RDP & ICA)  Access protection through Fujitsu SmartCard solution

with Sicrypt and CardOS/Gemplus SmartCards

 Secure operating system embedded on flash memory  Comfortable security support for SmartCard integration in

connection with Citrix MetaFrame

 Secure data transaction via VPN available

Ergonomics

 Stress-free working and silent operation without any

rotating fan and drives

 Very low power consumption, low heat dissipation

Page 2

elux® Lite can only be updated as a

composition with ELIAS

Control Default Reset

cards

VPN client Free S/WAN

SmartCard Reader Solo 2

Windows® CE 5.0 eLux® Lite eLux® NG

Microsoft Windows® CE 5.0 operating system

Target group

From Small Enterprises to Large Accounts with focus to Thin Client computing via ICA/RDP protocol and reduced use of local applications like emulation suite from Ericom

Local functions

 ICA-Client  RDP-Client  Internet Explorer  Media Player  VNC Viewer  VPN Client  ThinPrint Client  Terminal emulation PowerTerm

(ANSI, VT320/420, IBM 3270/5250) optional, additional license requested, optional orderable

complete SW image. No modular SW package (ELIAS) update is possible.

Target group

From Small Enterprises to channel Accounts with use of Thin Client access via ICA/RDP and Browser. Wide range of additional local functions possible.

Local functions

 ICA-Client V 10  RDP-Client 5.2 functionality  Browser Firefox  Acrobat Reader  NX-Client  Shockwave Flash  Real Player

eLux® NG is a Linux based embedded operating system, modular SW package (ELIAS) update is possible.

Target group

From Small Enterprises to Large Accounts with use of Thin Client access via ICA/RDP and Browser. Wide range of additional local functions possible.

Local functions

 ICA-Client V 10  RDP-Client V 5.2 functionality  Browser Mozilla, Opera or Firefox

available

 Acrobat Reader  Sun JVM 1.5  Tarantella-Client  ThinPrint Client  Terminal emulations for ANSI,

97801, VT320

 X.11 terminal application

Local functions requiring further licenses

Terminal Emulation PowerTerm (ANSI, VT320/420, IBM 3270 / 5250), additional license requested, optional orderable

Manageability with Scout Enterprise

 FUTRO utility tool for CE 5.0

- Flash memory management

- Embedded operating system

update and system monitoring

- Managing devices by location, group or user

Security

 Control Panel Password  Control Connection Configuration



VPN

 Only via customizing

Smartcard Support

 Driver Support for Fujitsu USB

Manageability with Scout Enterprise

- Flash memory management

- Embedded operating system

update and system monitoring

- Managing devices by location, group or user

Security

 SmartCard support within/without

certificate for CardOS or GemPlus

VPN

 Only via customizing

Smartcard Support

 Driver Support for Fujitsu USB

Manageability with Scout Enterprise

- Flash memory management

- Embedded operating system

update and system monitoring

- Managing devices by location, group or user

- Individual operating system

Security

 SmartCard support within/without

certificate for CardOS or GemPlus

VPN

 VPN client from Cisco (optional,

provided by UniCon Software Development, license required)



Smartcard Support

 Driver Support for Fujitsu USB

Page 3

Model

FUTRO A220

FUTRO A255

FUTRO A250

Operating System

Microsoft® Windows® CE 5.0

eLux® Lite (incl. license)

eLux® NG (w/o license)

Managing Software

Scout Enterprise (license incl.)

Scout Enterprise

Type

Thin client terminal

Software

Software Flash memory includes:

Flash memory includes: Operating

Flash memory system (MByte)

128

256

Mainboard

OEM

Cabinet

Picotower

Processor

AMD LX800, 500 MHz

System Bus

Memory (MByte)

128

256

Floppy disk drive

optional via USB

Optical drive

Hard disk drive (GByte)

optional via USB

Slots

Graphics (MByte)

VESA display support with DDC

32 MB discrete VideoRAM

VESA display support with DDC for

32 MB discrete VideoRAM

VESA display support with DDC for

32 MB discrete VideoRAM

Audio

on board

LAN (on board)

10/100 /1000 MBit/s Fast Ethernet

Weight (kg)

approx. 0.6

Dimensions mm

195 x 152 x 43

Options

Special features

Fanless, silent operation, very low

space requirement

Fanless, silent operation, very low

space requirement

Fanless, silent operation, very low

requirement

Data Sheet  Issue: 5/25/2009 FUTRO A Series Page 3 / 4

for operating

Operating system Microsoft® Windows® CE 5.0

- ICA-Client

- RDP-Client

- Internet Explorer

- Media Player

- VNC Viewer

- VPN Client

- ThinPrint Client

- Terminal Emulation PowerTerm (ANSI, VT320/420, IBM 3270/5250), optional additonal license requested

optional via USB optional via USB optional via USB

for automatic adjustment of resolution and refresh rate

system eLux®Lite (w/o ELIAS)

- ICA client, V10.35-2

- RDP client, V1.6.0.1-1

- Firefox, V2.0.0.7-3

- Acrobat Reader 5, V5.0.10-1

- Desktop themes, V1.6-1

- Desktop tools, V1.5-1

- eLux mirroring, V1.1-7

- GTK 2 Library Package, V2.10.12-1

- Real Player 10, V10.0.8-1

- Shockwave Flash, V9.0.124-1

- SSH-tools, V2.9.9p2-3

- NxClient, V3.2.0.9-1

- Open Motif, V2.2.3-1

- Security Libraries, V1.2-4

automatic adjustment of resolution and refresh rate

system eLux®NG

- ICA-Client

- RDP-Client functionality

- Browser

- Acrobat Reader

- Tarantella-Client

- ThinPrint Client

- Terminal-Emulations for

ANSI, 97801, VT320

- X.11 Terminal-Application

- Terminal Emulation

PowerTerm (ANSI, VT320/420, IBM 3270/5250), optional additonal license requested

automatic adjustment of resolution and refresh rate

(H x W x D) in

power consumption (average 7 W, max. 8.5 W), high reliability, long service life, no maintenance, small

power consumption (average 7 W, max.

8.5 W), high reliability, long service life,

no maintenance, small space

Page 4

Data Sheet  Issue: 5/25/2009 FUTRO A Series Page 4 / 4

Interfaces

1 x Mic in / headphone out (rear) 1 x Line out (rear) 1 x keyboard (PS/2) (rear) 1 x mouse (PS/2) (rear) 1 x monitor (15-pin, VGA) 1 x LAN RJ-45 1 x serial 1 x Universal Serial Bus (USB 2.0) (rear) 2 x Universal Serial Bus (USB 2.0) (front)

Display modes

VESA monitor support with DDC for automatic setting of resolution and refresh rate Video RAM 32 MB shared memory Resolution selectable 32/24/16/8 bit colors 1600 x 1200 / max 100 Hz 32/24/16/8 bit colors 1280 x 1024 / max 100 Hz 32/24/16/8 bit colors 1024 x 768 / max 100 Hz 32/24/16/8 bit colors 800 x 600 / max 100 Hz 32/24/16/8 bit colors 640 x 480 / max 100 Hz

Connectivity TP (Twisted Pair), RJ-45

TCP/IP with DNS and DHCP Point-to-Point over Ethernet Point-to Point tunneling protocol Layer-2 tunneling protocol Supported Citrix Load Balancing on ICA SNMP support allows configuration of terminal settings, reporting of terminal configuration and attached devic es, traps DHCP support for automatic firmware upgrades and unit configuration Multiple master browser support on ICA Wake on LAN

Electrical values (external AC/DC power supply)

Rated voltage (AC input) 100 - 240 V Rated frequency 50/60 Hz DC output 12V, tbd A,

Power consumption for standard configuration (AC input)

Peak (running application) 8.5 W Average (running OS, Idle mode) 7 W Minimum (ACPI status S5, soft-off) 2.3 W

Temperature / dimensions / weight

Ambient temperature 15°C – 35°C (IEC721) Dimensions (H x W x D) 195 x 152 x 43 Weight 0.75 kg

Compliance with standards

Product safety IEC60950, EN60950, UL60950, CAN/CSA-C22.2 No.60950-00 Electromagnetic Compatibility EN55022 class B, EN55024 EN61000-3-2/-3, FCC class B, ICES-003 tbd CE-Certification according to EC Directive 89/336/EEC 73/23/EEC

Security functions

Security functions implemented in the cabinet:

- Access protection via external SmartC ard reader (optio nal)

- Write-protect facility for Flash EPROM

- Kensington Lock at rear side

Available languages

English for CE. 27 selectable languages for eLuxNG

PXE

Backpacksolution* for FUTRO A2xx Please see the possible combinations in the backpack solution overview https://partners.ts.fujitsu.com/sites/dmsp/docs/other/inf-thin-clients-200209.doc

Order code: S26361-F2601-L518

* only usable with FUTRO A120 or FUTRO A2xx and
