24V DRIVE, ULTRA HIGH SPEED LINE THERMAL PRINTER
4” MECHANISM, WITH AVAILABLE CUTTER
FTP-641MCL301/302
■ OVERVIEW
This thermal printer (driven by 24 VDC) and cutter provide high
speed printing for 4-inch wide paper (114 mm). This printer is small
in size, light weight, and has low power consumption. The print head
features open construction for easy maintenance.
This printer is suitable for a variety of applications, such as POS
terminals, ticket machines, label printers, measuring devices and
medical equipment.
In addition to the interface board, a driving LSI (MCU + Gate Array) is
also available.
■ HIGHLIGHTS
FTP-641MCL301/302 shown after
assembly with FTP-641CT001cutter
• Ultra high speed printing
It can print at 100 mm/s (800 dotlines/s) by using Fujitsu
Components' unique head drive control system.
• Auto cutter
Full or partial cutting are available by normal or reverse rotation of
the motor (command set).
• Low power consumption
The peak current for head driving is approximately 6.0 A (at 50
mm/s printing speed, 50% printing ratio).
• Easy head access
Head-open construction makes head maintenance easy,
especially for head cleaning.
• Paper auto loading function
The thermal paper can be loaded without head-up lever
operation.
• High resolution
8 dots/mm head provides clear print output.
• Selectable paper paths
Front or rear insertion types are available.
FTP-641MCL302 can print on paper thicknesses of up to 150 µm.
FTP-621CU102, FTP-633GA101
FTP-621DCL012
1
■ DESIGNATION
FTP-641MCL301/302
Item
Front paper insertion type
Printer mechanism
Rear paper insertion type (supports thick paper)
Cutter
Interface board
Micro Controller Unit
LSI
Gate Array
■ GENERAL SPECIFICATIONS
SpecificationsItem
Printing method Thermal-sensitive line dot method
Dot structure 832 dots/line
Dot pitch (Horizontal) 0.125 mm (8 dots/mm)—Dot density
Part number
FTP-641MCL301
FTP-641MCL302
FTP-641CT001
FTP-621DCL012
FTP-621CU102
FTP-633GA101
Dot pitch (Vertical) 0.125 mm (8 dots/mm)—Line feed pitch
Effective printing area 104 mm
Number of columns 69 columns/line (maximum)—Alphanumeric KANA
Maximum printing speed 800 dot lines/s (100 mm/s) maximum
JIS ANK : 128 International characters : 130
Character types Semi-graphic : 63 ASCII small characters : 31
Character composition, dimensions (H×W),
Number of columns (standard)
Interface 1) Centronics standard 2) Bus interface*
Cutting method Guillotine method
Cutting type Full-cut or partial cut (command set)
Cutter
Minimum cut length 20 mm
Paper thickness 65 to 150 µm
Download : 384
24 × 12 dots, (3.0 × 1.5 mm), 69 columns
32 × 16 dots, (4.0 × 2.0 mm), 52 columns
24 × 24 dots, (3.0 × 3.0 mm), 34 columns
32 × 32 dots, (4.0 × 4.0 mm), 26 columns
1
(Continued)
2
(Continued)
Power supply
FTP-641MCL301/302
SpecificationsItem
24 VDC ± 5%, average:*
0.33 (1.72) A (at 25 mm/s printing speed, 25% printing ratio)
For head 0.75 (3.01) A (at 50 mm/s printing speed, 25% printing ratio)
3.09 (5.58) A (at 100 mm/s printing speed, 25% printing ratio)
( ): Peak
For motor 24 VDC± 5%, 1.0 A maximum
For logic 5 VDC ± 5%, 0.5 A maximum
2
Weight Mechanism with cutter: approximately 640 g
Interface board: approximately 100g
Dimensions
Mechanism + cutter 161 (W) × 60 (D) × 71.0 (H) mm (excluding connector)
Interface board 140 (W) × 89 (D) × 24.0 (H) mm
Pulse durability : 1 × 108 pulse/dot (using Fujitsu Takamisawa's standard
Thermal head driving method)
Life Wear resistance : 50 km (at 25% printing ratio)
Cutter Cutting life: 3 × 105 times
3
Environmental
conditions
Operating temperature +5 to +40°C*
Operating humidity 20 to 85% RH (no condensation)
Storage temperature –20 to +60°C (excluding paper)
Storage humidity 5 to 95% RH (no condensation)
Head temperature By thermistor (applied energy control, abnormal temperature detection)
Detection Paper out/Mark detect By photointerrupter (command set)
Head-up By microswitch
Paper width 114 mm
Recommended thermal sensitive
5
paper*
+0
–1
1 ply paper in roll : FTP-040P0020
Thicker paper in roll : FTP-040PJ102*
4
*1: The data to be printed is automatically read out by the printer driver equipment memory (host system frame
memory). The communication is parameter transfer.
*2: At 25°C, maximum applied voltage, minimum head resistance, specified paper, stable printing ratio.
*3: Temperature range for guaranteed printing density. It can operate at 0 to +40°C.
*4: Printer mechanism FTP-641MCL302 is to be used.
*5: Please contact us for other thermal papers.
3
■ DIMENSIONS
Printer mechanism with cutter
FTP-641MCL301/302
135.2 (Mounting hole)
161
66.6 (Center of paper & connector)
14.2
21.9
35.5 (Mounting hole)
68 (At cutter open)
2.5 (Mounting hole)
JAPAN
40.5
12
Mounting screw
7.5 (300)
300
2-M3 Burring
11.8
Note:
All dimensions are nominal value.
Y
25.4
Y
123.8
71
(76)
Y-Y SECTION
60
<FTP-641MCL301>
Paper insertion
<FTP-641MCL302>
Paper insertion
Unit: mm
4
Interface board
FTP-641MCL301/302
139.7
129.6
113.1
73.7
88.9
(5.1)
(5.1)
78.8
(5.1)
22.9
CN5 CN6 CN1
14.0
14.0
CN3 CN4
31.8 15.3
4—ø3.6
CN9
CN2
CN7
28.0
CN11
25.4
CN10
(5.1)
(5.1)
88.9
17
1.6
5
Height of devices side
Height of solder side
■ INTERFACE, COMMAND, OPTIONS
Please refer to the FTP-621DCL002/012 DATA SHEET for Interface, Command, and Options.
23.6
Unit: mm
5
