24V DRIVE, ULTRA HIGH SPEED LINE THERMAL PRINTER
4” MECHANISM
FTP-641MCL101/102
■ OVERVIEW
This thermal printer (driven by 24 VDC) provides ultra-high speed
printing for 4-inch wide paper (114 mm). This printer is small in size,
light weight, and has low power consumption. The print head is
designed with open construction for easy maintenance.
This printer is suitable for a variety of applications, such as POS
terminals, ticket machines, label printers, measuring devices and
medical equipment.
In addition to the interface board, a driving LSI (MCU + Gate Array) is
also available.
FTP-641MCL101, 102
■ HIGHLIGHTS
• Ultra high speed printing
It can print at 100 mm/s (800 dotlines/s) by using Fujitsu
Components' unique head drive control system.
• Compact and lightweight
The printer has a low profile of only 28 mm, and a light weight of
approximately 290 g.
• Low power consumption
The peak current for head driving is approximately 6.0 A (at 50
mm/s printing speed, 50% printing ratio).
• Easy head access
Head-open construction makes head maintenance easy,
especially for head cleaning.
• Paper auto loading function
The thermal paper can be loaded without head-up lever operation.
• High resolution
8 dots/mm head provides clear print output.
• Selectable paper paths
Front or rear insertion types are available.
FTP-641MCL102 can print on paper thicknesses of up to 150 µm.
FTP-621CU102, FTP-633GA101
FTP-621DCL002
1
■ DESIGNATION
FTP-641MCL101/102
Item
Front paper insertion type
Printer mechanism
Rear paper insertion type (supports thick paper)
Interface board
Micro Controller Unit
LSI
Gate Array
■ GENERAL SPECIFICATIONS
SpecificationsItem
Printing method Thermal-sensitive line dot method
Dot structure 832 dots/line
Dot pitch (Horizontal) 0.125 mm (8 dots/mm)—Dot density
Dot pitch (Vertical) 0.125 mm (8 dots/mm)—Line feed pitch
Effective printing area 104 mm
Part number
FTP-641MCL101
FTP-641MCL102
FTP-621DCL002
FTP-621CU102
FTP-633GA101
Number of columns 69 columns/line (maximum)—Alphanumeric KANA
Maximum printing speed 800 dotlines/s (100 mm/s) maximum
JIS ANK : 128 International characters : 130
Character types Semi-graphic : 63 ASCII small characters : 31
Character composition, dimensions (H×W),
Number of columns (standard)
Interface 1) Centronics standard 2) Bus interface*
For head 0.64 (3.01) A (at 50 mm/s printing speed, 25% printing ratio)
Power supply
For motor 24 VDC ± 5%, 1.0 A maximum
For logic 5 VDC ± 5%, 0.5 A maximum
Weight Mechanism: approximately 290 g. Interface board: approximately 100 g
Dimensions
Mechanism 159 (W) × 48 (D) × 28.0 (H) mm (excluding connector)
Interface board 140 (W) × 89 (D) × 24.0 (H) mm
Download : 384
24 × 12 dots, (3.0 × 1.5 mm), 69 columns
32 × 16 dots, (4.0 × 2.0 mm), 52 columns
24 × 24 dots, (3.0 × 3.0 mm), 34 columns
32 × 32 dots, (4.0 × 4.0 mm), 26 columns
1
24 VDC ± 5%, average:*
0.33 (1.72) A (at 25 mm/s printing speed, 25% printing ratio)
3.09 (5.58) A (at 100 mm/s printing speed, 25% printing ratio)
( ): Peak
2
(Continued)
2
