Mainboard
Short Description
Mainboard D3003
Congratulations, you have
decided to buy an
innovative Fujitsu product.
The latest information about our products, useful tips, updates etc. is available
from our website: "
http://ts.fujitsu.com"
For automatic driver updates, go to: "http://ts.fujitsu.com/support/index.html"
Should you have any technical questions, please contact:
• our Hotline/Service Desk (see the Service Desk list or visit:
"
http://ts.fujitsu.com/support/servicedesk.html" )
• Your sales partner
• Your sales office
We hope you really enjoy using your new Fujitsu system.
Copyright
Fujitsu Tec
hnology Solutions 09/11
Published by
Fujitsu Technology Solutions GmbH
Mies-van-
der-Rohe-Straße 8
80807 Munich, Germany
Contact
h
ttp://t
s.fujitsu.com/support
All rights reserved, including intellectual property rights. Subject to technical alterations. Delivery subject to availability. No warranty is
offered or liability accepted in regard of the co m pleteness, correctness, or current applicability of any data or illustrations. Bra nd
names m
ay be protected trademarks of the respective manufacturer and/or protected by copyright. Use of these by the third parties
may constitute an infringement of the holders’ rights. Further information can be found at "
http://ts.fujitsu.com/terms_of_use.html"
Order N
o. Fujitsu Technology Solutions GmbH: A26361-D3003-Z330-1-8N19, edition 2
Internal connectors and slots
External connectors rear
A26361-D3003-Z330-1-8N19
External connectors front
D3003-A/B
RECOVERY BIOS
MULTIBOOT
SILENT DRIVES
FAN LESS
USB - dual channel
1
2
1 = VCC C
2 = VCC D
3 = Dat a negativ
e
C
4 = Dat a negative D
5=
6 = Dat a positive D
Data positive C
7 = GND
8 = GND
9= Key
10 = Not connected
Processor
mSATA
FCH Hudon E1
(A55E)
Intrusion
Drive
Power
Buzzer
Battery
Speaker
PoE
PCI
PCIe X1
USB
USB
RCV
SATA
Power
Button
LED HDD
LED Power
Memory Socket
DC Plug
COM 1
DVI-I
COM 2
Display Port
LAN
2x USB
2x USB
Mouse
Keyboard
Line IN
Line OUT
2x USB
Head OUT
Mic IN
Fujitsu Technology Solutions
Internal connectors and slots
List of onboard Features D3003-A D3003-B
CPU AMD
T44R T44R
Chipset
A55E A55E
Board size Mini-ITX Mini-ITX
DVI-D / DVI-I / VGA / DisplayPort / HDMI - / /-/ /- -/ /-/ /LVDS
--
Stereo Audio / 5.1 Multichannel Audio / S/PDIF /-/- /-/Buzzer / int. Speaker Support / /
LAN 1: Gbit / 100 Mbit / 1
0Mbit
/ / / /
LAN 1: ASF / WoL / Remote Boot - / / -/ /
LAN 1: iAMT (Version) / DASH - / - - / LAN 2: Gbit / 100 Mbit
/10Mbit
-/-/- -/-/LAN 2: ASF / WoL / Remote Boot - / - / - - / - / LAN 2: iAMT (Version) / DASH - / - - / SATA1):6Gb/s(P
orts) / 3 Gb/s (Ports)
(1) / - - / eSATA1)-support: 3 Gb/s (Ports) / 1,5 Gb/s (Ports) - / - - / RAID on Motherboard
--
Supported RAID Levels: 0 / 1 / 5 / 10 - / - / - / - - / - / - / FireWire
TM
/USB2.0/USB3.0
-/
/- -/ /FAN monitored: PSU2)/FAN1/FAN2/FAN3 -/-/-/-/- -/-/-/-/FAN controlled: PSU2)/FAN1/FAN2/FAN3 -/-/-/- -/-/-/Temperat
ure monitored: CPU / Onboard 1 / Onboard 2 /
Onboard
3 / Chipset / Super IO
/-/-/-
/-/
/-/-/-
/-/
Special Features
Green Edition (Halogen-free product)
--
Desk U
pdate (Simple driver update with DU DVD)
-
Recovery BIOS (Restores a corrupted BIOS)
HDD Password (Access protection for disk drives)
Mul
ti Boot (Comfortable boot from any boot device)
Silent Fan (OS independent, temperature related full
featured silent fan control)
--
Silent F an LT (OS independent, temperature related silent
fan control)
--
Silent Drives (Noise reduction for optical and hard disk
drives)
-
System Guard (View and adjust Silent Fan / Silent Fan LT)
--
SmartCard SystemLock (USB / serial) /- -/Keyboard Power Button (Fujitsu Technology Solutions
Keyboard Power Button Support)
0-Watt
--
Low Power Soft OFF
Fujitsu Technology Solutions
Internal connectors and slots
List of onboard Features D3003-A D3003-B
Internal Connectors
DIMM Sockests (DDR3 1066/1333, SO-DIMM)
21
PCI Express x16 Slot
--
PCI Express x1 Slot
proprietary x2
-
PCI Slot (32 bit, 33 MHz, Rev. 2.3)
1
-
Speaker
Specific socket for inte
rnal USB Stick
--
Serial (FIFO, 16550 compatible)
--
Intrusion (Case Open) onboard switch
-
Feature Connector (G
eneral Purpose I/O)
--
USB (2.0, ~480 Mbit/s, 2 channe ls p er connector)
21
Frontpanel (Power Switch, LEDs, Intel 10 pin header)
--
Dual channel LVD
S / Backlight Control
-/- -/-
Onboard Power O utpu t (+5 V / 2 A, +12 V / 2 A) for drives
-
Onboard (internal input) DC-IN 19-24 V / 3 A
--
Power over Eth
ernet module (PoE) DC-IN 15 V (optional)
External Connectors
Audio In / Line Out (or driver configuration) / Microphone In 1 / 2 / 1 1 / 2 / 1
PS/2 Mouse
/ Keyboard
/ /
USB (2.0, ~480 Mbit/s)
66
Serial (RS232, F IFO, 16550 compatible) 2 1
DC-IN (e
xternal input) 19 V / 2 A (depe ndent on system
compone
nts 20 V / 3.25 power supply necessary)
DC-IN (external input) 19-24 V / 3.25 A
--
1) Maximum supported Transfer Rate per Port
2) Not supported by standard Power Supplies
Power
Supply Requirements - for onboard components (worst case)
Source Volt
age
Maxi
mal variation
Main
board current
typ
ical
D3003-A/B
Main Power Supply 19
V
+/-10 % 1 A
Fujitsu Technology Solutions
Internal connectors and slots
External connectors rear
A26361-D3003-Z330-1-8N19
D3003-Sxx
USB - dual channel
1
2
1 = VCC C
2 = VCC D
3 = Dat a negative C
4 = Dat a negative D
5=
6 = Dat a positive D
Data positive C
7 = GND
8 = GND
9= Key
10 = Not connected
Processor
mSATA/USB
FCH Hudon E1
(A55E)
Intrusion
Drive Power
Buzzer
Battery
Audio
Frontpanel
PCI
PCIe X2
USB
USB
RCV
SATA 0
Memory Socket
DC Plug
COM 1
DVI-I
COM 2
Display Port
(-S2 only)
LAN
2x USB
LAN
2x USB
Mouse
Keyboard
Line IN
Line OUT
USB A
Connector
Power
LVDS (-S1/S3)
COM 2
LVDS Power (-S1/S3)
GPIO
Auto-On
Frontpanel
Backlight
Power
(-S1/S3)
SATA 1
FAN 1
FAN 2
SPDIF
Frontpanel Connector
1
2
1 = HDD LED+
2 = Power LED+
3 = HDD LED4 = Power LED GND
5=
6 = PowerSwitch P
ResetSwitch GND
7 = ResetSwitch P
8 = PowerSwitch GND
9 = Reserved (NC)
10 = (KEY)
WATCH DOGDESK UPDATERECOVERY BIOSHDD PA SSW OR D
MULTI BOOT
SILEN T DRIVES
FAN LESS
SYSTEM GUARDSILEN T FA NEXTEN DED TEMPERATU RE
24/7
O perating Mode
TPM
Backlight Control
(-S1/S3)
(proprietary)
Fujitsu Technology Solutions
Internal connectors and slots
List of onboard Features D3003-S1x D3003-S2x D3003-S3x
CPU AMD
T44R T56N T56N
Chipset
A55E A55E A55E
Board size Mini-ITX Mini-ITX Mini-ITX
DVI-D/DVI-I/VGA/DisplayPort/HDMI -/ /-/-/- -/ /-/ /- -/ /-/-/LVDS
-
Stereo Audio / 5.1 Multichannel Audio / S/PDIF /-/ /-/ /-/
Buzzer / int. Speaker Support /- /- /LAN 1: Gbit / 100 Mbit / 1
0Mbit
/ / / / / /
LAN 1: ASF / WoL / Remote Boot - / / -/ / -/ /
LAN 1: iAMT (Version) / DASH - / - - / - - / LAN 2: Gbit / 100 Mbit
/10Mbit
/ / / / / /
LAN 2: ASF / WoL / Remote Boot - / / -/ / -/ /
LAN 2: iAMT (Version) / DASH - / - - / - - / SATA1):6Gb/s(P
orts) / 3 Gb/s (Ports)
(2) / - (2) / - (2) / -
eSATA1)-support: 3 Gb/s (Ports) / 1,5 Gb/s
(Ports)
-/- -/- -/-
RAID on Motherboard
Supported RAID Levels: 0 / 1 / 5 / 1 0 / /-/- / /-/- / /-/FireWire
TM
/USB2.0/USB3.0
-/
/- -/ /- -/ /-
FAN monitored: PSU / FAN1 / FAN2 / FAN3
-/
4pin
PWM /
4pin PWM or
3pin/-
-/
4pin
PWM /
4pin PWM o r
3pin/-
-/
4pin
PWM /
4pin PWM or
3pin/FAN controlled: PSU / FAN1 / FAN2 / FAN3 - / / /- -/ / /- -/ / /Tem pe r
ature monitored: CPU / Onboard 1 /
Onboar
d2
/ / / / / /
Special Features
Green Edition (Halogen-free product)
---
Desk
Update (Simple driver update with DU
DVD
)
Recovery BIOS (Restores a corrupted BIOS)
HDD Password (Access protection for disk
drives)
M
ulti Boot (Comfortable boot from any boot
device)
Silent Fan (OS independent, temperature
related fan control and supervision)
Silent Fan LT (OS independent, temperature
related fan control)
---
Silent Drives (Noise reduction for optica l and
hard disk drives)
System Guard (View Silent Fan)
Fujitsu Technology Solutions
Internal connectors and slots
List of onboard Features D3003-S1x D3003-S2x D3003-S3x
Internal Conn ectors
DIMM Sockests (DDR3 1066/1333, SO-DIMM)
222
PCI Express x16 Slot
---
PCI Express x1 Slot
proprietary x2 proprietary x2 proprietary x2
PCISlot(32bit,33MHz,Rev.2.3)
111
Frontpanel Audio (9-pin, Intel standard header)
Specific socket for inte
rnal USB Stick
Serial (FIFO, 16550 compatible)
shared with
external, so
only one
device on
COM2 allowed
shared w ith
external, so
only one
device on
COM2 allowed
shared with
external, so
only one
device on
COM2 allowed
Intrusion (Ca se Open)
Feature Connector (General Purpose I/O)
USB (2.0, ~480 Mb
it/s, 2 channels per
connector)
222
Frontpanel (Power Switch, LEDs, Intel 10 pin
header)
Dual channel LVDS / Backlight Control / -/- /
Onboard Powe
r Output (+5 V / 2 A, +12 V / 2 A)
for drives
Onboard (internal input) DC-IN 19-24 V / 3 A
External Conn ecto rs
AudioIn/
Line Out (or driver configuration) /
Micropho
ne In
1/1/- 1/1/- 1/1/-
PS/2 Mouse / Keyboard / / /
USB (2.0, ~480 Mbit/s) 4 4 4
Seria
l (RS232, FIFO, 16550 compatible)
2(COM
2
share
dwith
inter
nal)
2(COM
2
share
dwith
inter
nal)
2(COM
2
share
d with
inter
nal)
DC-IN (external input) 19-24 V / 3.25 A
1) Maximum supported Transfer Rate per Port
Pow
er Supply Requirements - f or onboard components (worst case)
Source Vo
ltage
Ma
ximal variation
Ma
inboard current
ty
pical
D3003–Sxx
Main Power Supply
19 V - 24 V
+10 % / -15 %
1A
Fujitsu Technology Solutions
Mainboard D3003
First-time setup
Deutsch 9
English 17
Inhalt Deutsch - 1
DeutschInhalt
Kurzbeschreibung des Mainboards .................................................... 3
Anschlüsse und Steckverbinder . ....................................................... 4
Technische Daten Prozessor ........................................................... 5
Hauptspeicher ein-/ausbauen .......................................................... 6
BIOSUpdate ........................................................................... 7
BIOS-Update unter Windows mit dem Programm DeskFlash . . ............................. 7
BIOS-Update mit einem USB-Stick ....................................................... 7
Fujitsu Technology Solutions 9
AMD Copyright the AMD Arrow logo and combinations thereof are trademarks
of Advanced Micro Devices, Inc.
Windows 7, Windows Vista und Windows X P sind eingetragene Warenzeichen der Microsoft
Corporation.
PS/2 und OS/2 Warp sind eingetragene Warenzeichen von International Business Machines, Inc.
Alle weiteren genannten Warenzeichen sind Warenzeichen oder eingetragene Warenzeichen
der jeweiligen Inhaber und werden als geschützt anerkannt.
Copyright © Fujitsu Technology Solutions GmbH 2011
Alle Rechte vorbehalten, insbesondere (auch auszugsweise) die der Übersetzung, des
Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.
Zuwiderhandlungen verpflichten zu Schadenersatz.
Alle Rechte vorbehalten, insbesondere für den Fall der Patenterteilung oder GM-Eintragung.
Liefermöglichkeiten und technische Änderungen vorbehalten.
Kurzbeschreibung des Mainboards De
utsch - 3
Kurzbeschreibung des Mainboa
rds
Hinweise zu den Baugruppen
Beachten Sie bei Baugruppen mit EGB unbedingt Folgendes:
• Sie müssen sich statisch entladen (z. B. durch Berühren eines geerdeten
Gegenstands), bevor Sie mit Baugruppen arbeiten.
• Verwendete Geräte und Werkzeuge müssen frei von statischer Aufladung sein.
• Ziehen Sie den Netzstecker, b evor Sie Baugruppen stecken oder ziehen.
• Fassen Sie die Baugruppen nur am Rand an.
• Berühren Sie keine Anschluss-Stifte oder Leiterbahnen auf der Baugruppe.
Eine Übersicht der Leistungsmerkmale finden Sie im Datenblatt.
Besondere Merkmale
Ihr Mainboard ist in verschiedenen Ausbaustufen erhältlich. Abhängig von der Konfiguration
Ihres Mainboards besitzt oder unterstützt das Mainboard bestimmte Merkmale.
In diesem Handbuch finden Sie die wichtigsten Eigenschaften dieses Mainboards beschrieben.
Weitere Informationen zu Mainboards finden Sie im Handbuch "Basisinformationen Mainboard"
auf der CD "User Documentation" oder "OEM Mainboard" bzw. im Internet.
Fujitsu Technology Solutions 11
4 - Deutsch Anschlüsse und Steckverb
inder
Anschlüsse und Steckverbinde
r
Die Position der Anschlüsse und Steckverbinder Ihres M ainboards finden
Sie am Anfang des Handbuches.
Die markierten Komponenten und Steckverbinder müssen nicht auf
dem Mainboard vorhanden sein.
Externe Anschlüsse
Die Position der externen Anschlüsse Ihres Mainboards finden S ie am Anfang des Handbuches.
PS/2-Tastaturanschluss, violett PS/2-Mausanschluss, grün
LAN-Anschluss (RJ-45) Mikrofonanschluss, rosa
Audioeingang (Line in), hellblau oder
schwarz
USB – Universal Serial Bus, schwarz
Audioausgang (Line out), hellgrün oder
schwarz
DVI – I
Serielle Schnittstelle, türkis
+
+
DisplayPort
Die externen USB-Anschlüsse dürfen laut USB 2.0 Spezifikation maximal
mit 500 mA pro USB-Anschluss belastet werden.
Durch den Einsatz einer neuen Chipsatz-Technology kann sich ein verändertes
Verhalten beim Anschluss älterer USB-Geräte (Fullspeed, USB 1.1) ergeben.
Das betrifft zum Beispiel ältere Digitalkameras, von denen immer nur eine
(nicht zwei oder mehr gleichzeitig) betrieben werden kann. Neuere Geräte
der Spezifikation USB 2.0 sind davon nicht betroffen.
12 Fujitsu Technology Solutions
Technische Daten Prozessor Deutsch
-5
Technische Daten Prozessor
• D3003-A/B:
AMD FT1 eOntario T44R 1,2 GHz s
ingle core
• D3003-S1:
AMD FT1 eOntario T44R 1,2 GH
z single c ore
• D3003-S2:
AMD FT1 eOntario T56N 1,6
GHz / 1,65 GHz
1)
dual core
• D3003-S3:
AMD FT1 eOntario T56N 1,
6GHz/1,65GHz
1)
dual core
1) Abhängig vom Prozessor Stepping
Fujitsu Technology Solutions 13
6 - Deutsch Hauptspeicher ein-/ausb
auen
Hauptspeicher ein-/ausbauen
Technische Daten
Technologie
DDR3–1066 (CL7) / DDR3–1333 (CL9) SDRAM (SO-D IMM)
Gesamtgröße 1, 2, 4 und 8 GByte (D3003-A)
1, 2, und 4 GByte (D3003-B)
1, 2, 4 und 8 GByte (D3003-S)
Modulgröße 1, 2 oder 4 GByte pro Modul
Es dürfen nur ungepufferte 1,5 V-Speichermodule ohne ECC verwendet w erden.
DDR3-Speichermodule müssen der PC3-8500- oder PC3-10600-Spezifikation
entsprechen.
Die Mainboards verfügen über bis zu zwei Modul-Steckplätze.
Abhängig von der Syst emko nfiguration kann sich der sich tbare H auptspeicher red u ziere n.
Der Ein-/Ausbau ist im Handbuch "Ba sisinformationen Mainboard" beschrieben.
14 Fujitsu Technology Solutions
BIOS Update Deutsch - 7
BIOS Update
Wann sollte ein BIOS-Update durchgeführt werden?
Fujitsu Technology Solutions stellt neue BIOS-Versionen zur Verfügung, um die Kompatibilität
zu neuen Betriebssystemen, zu neuer Software oder zu neuer H ardw are zu gewährleisten.
Außerdem können neue BIOS-Funktionen integriert werden.
Ein BIO S-U pdate sollte auch immer dann durchgeführt werden, wenn ein Problem besteht,
das sich durch neue Treiber oder neue Software nicht beheben lässt.
Wo gibt es BIOS -Up dates?
Im Internet unter "
http://ts.fujitsu.com/mainboards" finden Sie die BI OS-Updates.
BIOS-Update unter
Windows mit dem
Programm DeskFlash
Ein BIOS-Update
kann unter Windows auch mit dem Programm DeskFlash durchgeführt werden.
Das Programm Des
kFlash finden Sie auf dem Datenträger "D rivers & Utilities" (unter Flash BIOS).
oder
► Laden Sie die Up
date-Datei für "Flash BIOS Update — Desk Flash Instant"
von unserer In
ternet-Seite auf Ihren PC.
► Führen Sie die Update-Datei aus.
► Folgen Sie de
n Bildschirmanweisungen.
BIOS-Update mit einem USB-Stick
► Halten Sie einen bootfähigen USB-Stick bereit.
► Laden Sie
die "Admin package — Compressed Flash Files" für bootfähige
USB-Stic
ks von unserer Internet-Seite auf Ihren PC.
► Entpacken Sie die ZIP-Datei und kopieren Sie die Dateie n auf Ihren bootfähigen USB-Stick.
► Starten
Sie den PC neu.
► Wählen Sie den USB-Stick als Boot Device.
► Booten
Sie von dem USB-Stick und starten sie DosFlash.BAT.
► Folgen Sie den Bildschirmanweisungen.
Fujitsu Technology Solutions 15
8 - Deutsch BIOS Update
16 Fujitsu Technology Solutions
Contents English - 1
EnglishContents
Brief description of mainboard . . ....................................................... 3
Interfaces and connectors . . ........................................................... 4
Processor technical data . . . . ........................................................... 5
Installing/removing main memory . . . ................................................... 6
BIOSUpdate ........................................................................... 7
BIOS update under Windows with DeskFlash program . .................................... 7
BIOSupdateusinga USBstick .......................................................... 7
Fujitsu Technology Solutions 17
AMD Copyright, the AMD Arrow logo and combinations thereof are trademarks
of Advanced Micro Devices, Inc.
Windows 7, Windows Vista and Windows XP are registered trademarks of Microsoft Corporation.
PS/2 and OS/2 Warp are registered trademarks of International Business Machines, Inc.
All other trademarks used in this document are trademarks or registered trad emarks of
their respective owners and are recognised as being protected.
Copyright © Fujitsu Technology Solutions GmbH 2011
All rights, including rights of translation, reproduction by printing, copying or similar
methods, of the whole document or parts thereof, are reserved.
In the event of violations, perpetrators will be liable to prosecution for damages.
All rights reserved, including rights crea ted by patent grant or registration of a utility model or design.
Subject to availability and tech nical modifications.
Brief description of mainboard Engl
ish - 3
Brief description of m ainboar
d
Information about boards
Be sure to observe the following for boards with ESD:
• You must always discharge static build up (e.g. by touching a grounded object)
before working with the board.
• The equipment and tools you use must be free of static charge.
• Remove the power plug from the mains supply before inserting or removing
boards.
• Always hold boards by their edges.
• Never touch connector pins or conductors on the board.
An overview of the features is provided in the data sheet.
Special features
Your mainboard is available in different configuration levels. Depending on the configuration,
your mainboard will be equipped with or provide support for certain features.
This manual describes the most important properties of this mainboard.
Additional information on mainboards is provided in the manual "Basic information on mainboard"
on the "User Documentation" or "OEM Mainboard" CD, or on the Internet.
Fujitsu Technology Solutions 19
4 - English Interfaces and connector
s
Interfaces and connectors
The location of the interfaces and connectors of your mainboard is specified
at the beginning of the manual.
The components and connectors marked are not necessarily present on the mainboard.
External ports
The location of the externa l connections of your mainboard is specified at the beginning of the manual.
PS/2 keyboard port, purple PS/2 mouse port, green
LAN port (RJ-45) Microphone jack (mono), pink
Audio input (line in), light blue or black USB – Universal Serial Bus, black
Audio output (line out), light green or
black
DVI – I
Serial interface, turquoise
+
+
DisplayPort
According to the USB 2.0 specifications, no more than 500 mA must
be connected to the external USB ports.
The use of a new chip set technology can m ean that the procedure is different when
connecting older USB devices (Fullspeed, USB 1.1). This relates, for example, to older
digital cameras of which only one (not two or more at the same time) can be operated at
any one time. Newer devices with specification USB 2.0 are not affected by this.
20 Fujitsu Technology Solutions
Processor technical data English - 5
Processor technical data
• D3003-A/B:
AMD FT1 eOntario T44R 1.2 GHz s
ingle core
• D3003-S1:
AMD FT1 eOntario T44R 1.2 GH
z single c ore
• D3003-S2:
AMD FT1 eOntario T56N 1.6
GHz / 1.65 GHz
1)
dual core
• D3003-S3:
AMD FT1 eOntario T56N 1.
6GHz/1.65GHz
1)
dual core
1) Depends on processor stepping
Fujitsu Technology Solutions 21
6 - English Installing/removing mai
nmemory
Installing/removing main mem
ory
Technical data
Technology
DDR3–1066 (CL7) / DDR3–1333 (CL9) SDRAM (SO-D IMM)
Tot al si ze
1, 2, 4 and 8 Gbyte (D3003-A)
1, 2 and 4 Gbyte (D3003-B)
1, 2, 4 and 8 Gbyte (D3003-S)
Module size
1, 2 or 4 Gbyte for one module
Only unbuffered 1.5 V memory modules without ECC may be used.
DDR3 memory modules must comply with the PC3-8500 or PC3-10600 specification.
The mainboards have up to two module slots.
Depending on how the system is configured, the visible main memory may be reduced.
The installation/removal is described in the "Basic information on mainboard" manual.
22 Fujitsu Technology Solutions
BIOS Update English - 7
BIOS Update
When should a BIOS update be performed?
Fujitsu Technology Solutions makes new BIOS versions available to ensure compatibility with new
operating systems, new softw are or new hardware. In addition, new BIOS functions can be integrated.
A BIOS update should also always be performed if there is a problem that cannot
be solved using new drivers or new software.
Where can I obtain BIOS updates?
Go to "
http://ts.fujitsu.com/mainboards" to find the BIOS upd ates.
BIOS update under Wi
ndows with DeskFlash program
A BIOS update can also be carried out under Windows with the DeskFlash program. The DeskFlash
program is located on the "Drivers & Utilities" data carrier (under Flash BIOS).
or
► Download the update file for "Flash BIOS Update — Desk Flash Instant"
onto your PC from our website.
► Run the update file.
► Follow the o n-screen instructions.
BIOS update using a USB stick
► Make sure you have a bootable USB stick available.
► Download the "Admin package — Compressed Flash Files" for bootable
USB sticks onto your PC from our website.
► Unzip the ZIP file and copy the files onto your bootable USB stick.
► Reboot the P C .
► Select the USB stick as the boot device.
► Boot from the USB stick and start DosFlash.BAT.
► Follow the o n-screen instructions.
Fujitsu Technology Solutions 23
