Fujifilm Z1010 EXR Owner’s Manual

BL01660-200

DIGITAL CAMERA

FINEPIX Z1000EXR

Owner’s Manual

Thank you for your purchase of this product. This manual describes how to use your FUJIFILM digital camera and the supplied software. Be sure that you have read and understood its contents and the warnings in “For Your Safety” (P ii) before using the camera.

For information on related products, visit our website at

http://www.fujifilm.com/products/digital_cameras/index.html

Before You Begin

First Steps

Basic Photography and Playback

More on Photography

More on Playback

Movies

Connections

Menus

Technical Notes

Troubleshooting

Appendix

For Your Safety

Installation

For Your Safety

IMPORTANT SAFETY INSTRUCTIONS

• Read Instructions: All the safety and operating instructions should be read before the appliance is operated.

• Retain Instructions: The safety and operating instructions should be retained for future reference.

• Heed Warnings: All warnings on the appliance and in the operating instructions should be adhered to.

• Follow Instructions: All operating and use instructions should be followed.

Installation

Power Sources: This video product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For video products intended to operate from battery power, or other sources, refer to the operating instructions.

Grounding or Polarization: This video product is equipped with a polarized alternatingcurrent line plug (a plug having one blade wider than the other). This plug will ﬁ t into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to ﬁ t, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

Alternate Warnings: This video product is equipped with a three-wire grounding-type plug, a plug having a third (grounding) pin. This plug will only ﬁ t into a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding type plug.

Overloading: Do not overload wall outlets and extension cords as this can result in a risk of ﬁ re or electric shock.

Ventilation: Slots and openings in the cabinet are provided for ventilation, to ensure reliable operation of the video product and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the video product on a bed, sofa, rug, or other similar surface.

This video product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to. This video product should never be placed near or over a radiator or heat register.

Attachments: Do not use attachments not recommended by the video product manufacturer as they may cause hazards.

Water and Moisture: Do not use this video product near water—for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

Power-Cord Protection: Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

Accessories: Do not place this video product on an unstable cart, stand, tripod, bracket, or table. The video product may fall, causing serious injury to a child or adult, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the video product. Any mounting of the appliance should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

Antennas

Use

Service

Antennas

Outdoor Antenna Grounding: If an outside antenna or cable system is connected to the video product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and builtup static charges. Section 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECTRICAL CODE

Ground Clamp

Electric Service

Equipment

Ground Clamps

Power Service Grounding Electrode System (NEC ART

250. PART H)

Power Lines: An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

Antenna Lead in Wire

Antenna Discharge Unit (NEC SECTION 810-20)

Grounding

Conductors

(NEC SECTION

810-21)

Use

Cleaning: Unplug this video product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

Object and Liquid Entry: Never push objects of any kind into this video product through openings as they may touch dangerous voltage points or short out parts that could result in a ﬁ re or electric shock. Never spill liquid of any kind on the video product.

Lightning: For added protection for this video product receiver during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the video product due to lightning and powerline surges.

Service

Servicing: Do not attempt to service this video product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualiﬁ ed service personnel.

Damage Requiring Service: Unplug this video product from the wall outlet and refer servicing to qualiﬁ ed service personnel under the following conditions:

• When the power-supply cord or plug is damaged.

• If liquid has been spilled, or objects have fallen into the video product.

• If the video product has been exposed to rain or water.

• If the video product has been dropped or the cabinet has been damaged.

If the video product does not operate nor-

For Your Safety

mally follow the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualiﬁ ed technician to restore the video product to its normal operation.

When the video product exhibits a distinct change in performance—this indicates a need for service.

Replacement Parts: When replacement parts are required, be sure the service technician has used replacement parts speciﬁ ed by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in ﬁ re, electric shock or other hazards.

Safety Check: Upon completion of any service or repairs to this video product, ask the service technician to perform safety checks to determine that the video product is in proper operating condition.

iii

For Your Safety

WARNING

Be sure to read these notes before use

Safety Notes

• Make sure that you use your camera correctly. Read these safety

notes and your Owner’s Manual carefully before use.

• After reading these safety notes, store them in a safe place.

The icons shown below are used in this document to indicate the severity of the injury or damage that can result if the information indicated by the icon is ignored and the product is used incorrectly as a result.

This icon indicates that death or serious injury can result if the information is ignored.

WARNING

This icon indicates that personal injury or material damage can result if the information is ignored.

CAUTION

The icons shown below are used to indicate the nature of the instructions which are to be observed.

Triangular icons tell you that this information requires attention (“Important”).

Circular icons with a diagonal bar tell you that the action indicated is prohibited (“Prohibited”).

Filled circles with an exclamation mark indicate an action that must be performed (“Required”).

If a problem arises, turn the camera o , remove the battery, and disconnect and unplug the AC power adapter. Continued use of

the camera when it is emitting smoke, is emitting any unusual

Unplug from

odor, or is in any other abnormal state can cause a ﬁ re or elec-

power socket

tric shock. Contact your FUJIFILM dealer. Do not allow water or foreign objects to enter the camera. If water

or foreign objects get inside the camera, turn the camera oﬀ , remove the battery, and disconnect and unplug the AC power

Avoid exposure

adapter. Continued use of the camera can cause a ﬁ re or elec-

to water

tric shock. Contact your FUJIFILM dealer.

About the Icons

WARNING

Do not use the camera in the bathroom or shower. This can cause

Do not use in

a ﬁ re or electric shock.

the bathroom or

shower

Never attempt to change or take apart the camera (never open the case). Failure to observe this precaution can cause ﬁ re or

Do not

electric shock.

disassemble

Should the case break open as the result of a fall or other accident, do not touch the exposed parts. Failure to observe this precau-

tion could result in electric shock or in injury from touching the damaged parts. Remove the battery immediately, taking care

Do not touch

to avoid injury or electric shock, and take the product to the

internal parts

point of purchase for consultation.

Do not change, heat or unduly twist or pull the connection cord and do not place heavy objects on the connection cord. These actions

could damage the cord and cause a ﬁ re or electric shock . If the cord is damaged, contact your FUJIFILM dealer.

Do not place the camera on an unstable surface. This can cause the camera to fall or tip over and cause injury.

Never attempt to take pictures while in motion. Do not use the camera while you are walking or driving a vehicle. This can result in you falling down or being involved in a traﬃ c accident.

Do not touch any metal parts of the camera during a thunderstorm. This can cause an electric shock due to induced current from the lightning discharge.

Do not use the battery except as speci ed. Load the battery as shown by the indicator.

Do not heat, change or take apart the battery. Do not drop or subject the battery to impacts. Do not store the battery with metallic products. Any of these actions can cause the battery to burst or

leak and cause ﬁ re or injury as a result.

Use only the battery or AC power adapters speci ed for use with this camera. Do not use voltages other than the power supply voltage shown. The use of other power sources can cause a ﬁ re.

If the battery leaks and  uid gets in contact with your eyes, skin or clothing,  ush the a ected area with clean water and seek medical attention or call an emergency number right away.

WARNING

CAUTION

Do not use the charger to charge batteries other than those speci ed here. The supplied battery charger is for use only with the

type of battery supplied with the camera. Using the charger to charge conventional batteries or other types of rechargeable batteries can cause the battery to leak ﬂ uid, overheat or burst.

Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.

Do not use in the presence of  ammable objects, explosive gases, or dust.

When carrying the battery, install it in a digital camera or keep it in the hard case. When storing the battery, keep it in the hard case. When discarding, cover the battery terminals with insulation tape.

Contact with other metallic objects or batteries could cause the battery to ignite or burst.

Keep memory cards out of the reach of small children. Because memory cards are small, they can be swallowed by children. Be sure to store memory cards out of the reach of small children. If a child swallows a memory card, seek medical attention or call an emergency number.

Turn the camera o in crowds. The camera emits radio-frequency radiation that may interfere with pacemakers.

Turn the camera o in the vicinity of automatic doors, public address systems, and other automatically controlled devices. The camera

emits radio-frequency radiation that may cause these devices to malfunction.

Keep the camera at least 22cm away from people wearing pacemakers. The camera emits radio-frequency radiation that may

interfere with pacemakers.

Do not use this camera in locations a ected by oil fumes, steam, humidity or dust. This can cause a ﬁ re or electric shock.

Do not leave this camera in places subject to extremely high temperatures. Do not leave the camera in locations such as a sealed

vehicle or in direct sunlight. This can cause a ﬁ re.

Keep out of the reach of small children. This product could cause injury in the hands of a child.

WARNING

CAUTION

For Your Safety

Do not place heavy objects on the camera. This can cause the heavy object to tip over or fall and cause injury.

Do not move the camera while the AC power adapter is still connected. Do not pull on the connection cord to disconnect the AC power adapter. This can damage the power cord or cables and cause

a ﬁ re or electric shock.

Do not use the AC power adapter when the plug is damaged or the plug socket connection is loose. This could cause a ﬁ re or electric

shock.

Do not cover or wrap the camera or the AC power adapter in a cloth or blanket. This can cause heat to build up and distort the cas-

ing or cause a ﬁ re.

When you are cleaning the camera or you do not plan to use the camera for an extended period, remove the battery and disconnect and unplug the AC power adapter. Failure to do so can cause a

ﬁ re or electric shock.

When charging ends, unplug the charger from the power socket. Leaving the charger plugged into the power socket can cause

Unplug from

a ﬁ re.

power socket

Using a  ash too close to a person’s eyes may temporarily a ect the eyesight. Take particular care when photographing infants and

young children.

When a memory card is removed, the card could come out of the slot too quickly. Use your  nger to hold it and gently release the card.

Injury could result to those struck by the ejected card. Request regular internal testing and cleaning for your camera.

Build-up of dust in your camera can cause a ﬁ re or electric shock. Contact your FUJIFILM dealer to request internal cleaning every two years. Please note that this service is not free of charge.

Remove your  ngers from the  ash window before the  ash  res. Failure to observe this precaution could result in burns.

Keep the  ash window clean and do not use the  ash if the window is obstructed. Failure to observe these precautions could cause

smoke or discoloration.

CAUTION

For Your Safety

Li-ion Batteries

AA Alkaline/Rechargeable Ni-MH Batteries

The Battery and Power Supply

Note: Check the type of battery used in your camera and read the appropriate sections.

The following describes the proper use of batteries and how to prolong their life. Incorrect use can shorten battery life or cause leakage, overheating, ﬁ re, or explosion.

Li-ion Batteries

Read this section if your camera uses a rechargeable Li-ion battery.

The battery is not charged at shipment. Charge the battery before use. Keep the battery in its case when not in use.

■ Notes on the Battery

The battery gradually loses its charge when not in use. Charge the battery one or two days before use.

Battery life can be extended by turning the camera oﬀ when not in use.

Battery capacity decreases at low temperatures; a depleted battery may not function at when cold. Keep a fully charged spare battery in a warm place and exchange as necessary, or keep the battery in your pocket or other warm place and insert it in the camera only when shooting. Do not place the battery in direct contact with hand warmers or other heating devices.

■ Charging the Battery

Charge the battery in the supplied battery charger. Charging times will increase at ambient temperatures below +10 °C (+50 °F) or above +35 °C (+95 °F). Do not attempt to charge the battery at temperatures above 40 °C (+104 °F); at temperatures below 0 °C (+32 °F), the battery will not charge.

Do not attempt to recharge a fully charged battery. The battery does not however need to be fully discharged before charging.

The battery may be warm to the touch immediately after charging or use. This is normal.

■ Battery Life

At normal temperatures, the battery can be recharged about 300 times. A noticeable decrease in the length of time the battery will hold a charge indicates that it has reached the end of its service life and should be replaced.

■ Storage

Performance may be impaired if the battery is left unused for extended periods when fully charged. Run the battery ﬂ at before storing it.

If the camera will not be used for an extended period, remove the battery and store it in a dry place with an ambient temperature of from +15 °C to +25 °C (+59 °F to +77 °F). Do not store in locations exposed to extremes of temperature.

■ Cautions: Handling the Battery

• Do not transport or store with metal objects such as necklaces or hairpins.

• Do not expose to ﬂ ame or heat.

• Do not disassemble or modify.

• Use with designated chargers only.

• Do not drop or subject to strong physical shocks.

• Do not expose to water.

• Keep the terminals clean.

• The battery and camera body may become warm to the touch after extended use. This is normal.

AA Alkaline/Rechargeable Ni-MH Batteries

Read this section if your camera uses AA alkaline or rechargeable AA Ni-MH batteries. Information on compatible battery

types may be found elsewhere in the camera manual.

■ Cautions: Handling the Batteries

• Do not expose to water, ﬂ ame, or heat, or store in warm or humid conditions.

• Do not transport or store with metal objects such as necklaces or hairpins.

• Do not disassemble or modify the batteries or battery casing.

• Do not subject to strong physical shocks.

• Do not use batteries that are leaking, deformed, or discolored.

• Keep out of reach of infants and small children.

• Insert in the correct orientation.

• Do not mix old and new batteries, batteries

AC Power Adapters (Available Separately)

with diﬀ erent charge levels, or batteries of diﬀ erent types.

• If the camera will not be used for an extended period, remove the batteries. Note that the camera clock will be reset.

• The batteries may be warm to the touch immediately after use. Turn the camera oﬀ and allow the batteries to cool before handling.

• Battery capacity tends to decrease at low temperatures. Keep spare batteries in a pocket or other warm place and exchange as necessary. Cold batteries may recover some of their charge when warmed.

• Fingerprints and other stains on the battery terminals can impair battery performance. Thoroughly clean the terminals with a soft, dry cloth before inserting them in the camera.

If the batteries leak, clean the battery compartment thoroughly before inserting new batteries.

If ﬂ uid from the battery comes into contact with skin or clothing, ﬂ ush the aﬀ ected area with water. If  uid

enters your eyes, immediately  ush the a ected area with water and seek medical attention. Do not rub your eyes. Failure to observe this precaution could result in permanent visual impairment.

■ Ni-MH Batteries

The capacity of Ni-MH batteries may be temporarily reduced when new, after long periods of disuse, or if they are repeatedly recharged before being fully discharged. This is normal and does not indicate a malfunction. Capacity can be increased by repeatedly discharging the batteries using the discharge option in the camera setup menu and recharging them using a battery charger.

Q C AUTION: Do not use the discharge option

with alkaline batteries.

The camera draws a small amount of current even when oﬀ . Ni-MH batteries that have been left in the camera for an extended period may be drawn down to the point that they no longer hold a charge. Battery performance may also drop if the batteries are run down in a device such as a ﬂ ashlight. Use the discharge option in the camera setup menu to discharge Ni-MH batteries. Batteries that no longer hold a charge even after repeatedly being discharged and recharged have reached the end of their service life and must be replaced.

Ni-MH batteries can be recharged in a battery charger (sold separately). Batteries may become warm to the touch after charging. Refer to the instructions provided with the charger for more information. Use the charger with compatible batteries only.

Ni-MH batteries gradually lose their charge when not in use.

■ Disposal

Dispose of used batteries in accord with local regulations.

For Your Safety

AC Power Adapters (Available Separately)

This section applies to all camera models. Use only FUJIFILM AC power adapters designated for use with this camera. Other adapters could damage the camera.

• The AC power adapter is for indoor use only.

• Be sure the DC plug is securely connected to the camera.

• Turn the camera oﬀ before disconnecting the adapter. Disconnect the adapter by the plug, not the cable.

• Do not use with other devices.

• Do not disassemble.

• Do not expose to high heat and humidity.

• Do not subject to strong physical shocks.

• The adapter may hum or become hot to the touch during use. This is normal.

• If the adapter causes radio interference, reorient or relocate the receiving antenna.

vii

For Your Safety

Take Test Shots

Notes on Copyright

Handling

Liquid Crystal

Trademark Information

Electrical Interference

Color Television Systems

Exif Print (Exif Version 2.3)

Take Test Shots

Notes on Copyright

Handling

Using the Camera

Do not aim the camera at extremely bright light sources, such as the sun in a cloudless sky. Failure to observe this precaution could damage the camera image sensor.

Before taking photographs on important occasions (such as at weddings or before taking the camera on a trip), take a test shot and view the result in the LCD monitor to ensure that the camera is functioning normally. FUJIFILM Corporation can not accept liability for damages or lost proﬁ ts incurred as a result of product malfunction.

Unless intended solely for personal use, images recorded using your digital camera system cannot be used in ways that infringe copyright laws without the consent of the owner. Note that some restrictions apply to the photographing of stage performances, entertainments, and exhibits, even when intended purely for personal use. Users are also asked to note that the transfer of memory cards containing images or data protected under copyright laws is only permissible within the restrictions imposed by those copyright laws.

To ensure that images are recorded correctly, do not subject the camera to impact or physical shocks while images are being recorded.

viii

Liquid Crystal

In the event that the LCD monitor is damaged, care should be taken to avoid contact with liquid crystal. Take the urgent action indicated should any of the following situations arise:

• If liquid crystal comes in contact with your skin, clean the area with a cloth and then wash thoroughly with soap and running water.

• If liquid crystal enters your eyes, ﬂ ush the affected eye with clean water for at least 15 minutes and then seek medical assistance.

• If liquid crystal is swallowed, rinse your mouth thoroughly with water. Drink large quantities of water and induce vomiting, then seek medical assistance.

Although the display is manufactured using extremely high-precision technology, it may contain pixels that are always lit or that do not light. This is not a malfunction, and images recorded with the product are unaﬀ ected.

Trademark Information

xD-Picture Card and E are trademarks of FUJIFILM Corporation. The typefaces included herein are solely developed by DynaComware Taiwan Inc. Macintosh, QuickTime, and Mac OS are trademarks of Apple Inc. in the U.S.A. and other countries. Windows7, Windows Vista, and the Windows logo are trademarks of the Microsoft group of companies. Adobe and Adobe Reader are either trademarks or registered trademarks of Adobe Systems Incorporated in the U.S.A. and/or other countries. The SDHC and SDXC logos are trademarks of SD-3C, LLC. The HDMI logo is a trademark. YouTube is a trademark of Google Inc. All other trade names mentioned in this manual are the trademarks or registered trademarks of their respective owners.

Electrical Interference

This camera may interfere with hospital or aviation equipment. Consult with hospital or airline staﬀ before using the camera in a hospital or on an aircraft.

Color Television Systems

NTSC (National Television System Committee) is a color television telecasting speciﬁ cation adopted mainly in the U.S.A., Canada, and Japan. PAL (Phases Alternation by Line) is a color television system adopted mainly in European countries and China.

Exif Print (Exif Version 2.3)

Exif Print is a newly revised digital camera ﬁ le format in which information stored with photographs is used for optimal color reproduction during printing.

IMPORTANT NOTICE:

Read Before Using the Software

Direct or indirect export, in whole or in part, of licensed software without the permission of the applicable governing bodies is prohibited.

IMPORTANT: Read the following notices before using the camera’s built-in wireless transmitter.

Q This product, which contains encr yption function developed in

the United States, is controlled by the United States Export Administration Regulations and may not be exported or re-exported to any country to which the United States embargoes goods.

• Use only as part of a wireless network. FUJIFILM does not accept liability for damages resulting from unauthorized use. Do not use in applications requiring a high degree of reliability, for example in medical devices or other systems that may directly or indirectly impact human life. When using the device in computer and other systems that demand a greater degree of reliability than wireless networks, be sure to take all necessary precautions to ensure safety and prevent malfunction.

• Use only in the country in which the device was purchased. This device conforms to regulations governing wireless network devices in the country in which it was purchased. Observe all location regulations when using the device. FUJIFILM does not accept liability for problems arising from use in other jurisdictions.

• Wireless data (images) may be intercepted by third parties. The security of data transmitted over wireless networks is not guaranteed.

• Do not use the device in locations subject to magnetic  elds, static electric- ity, or radio interference. Do not use the transmitter in the vicinit y of microwave ovens or in other locations subject to magnetic ﬁ elds, static electricity, or radio interference that may prevent reception of wireless signals. Mutual inter ference may occur when the transmitter is used in the vicinity of other wireless devices operating in the

2.4GHz band.

• The wireless transmitter operates in the 2.4GHz band using DSSS and

OFDM modulation.

For Your Safety

• This device operates on the same frequency as commercial, educational, and medical devices and wireless transmitters. I t also operates on the

same frequency as licensed transmitters and special unlicensed lowvoltage transmitters used in RFID tracking systems for assembly lines and in other similar applications.

• To prevent interference with the above devices, observe the following precautions. Conﬁ rm that the RFID transmitter is not in operation before using this device. Should you obser ve that the device causes interference in licensed transmitters used for RFID tracking, immediately choose a new operating frequency for this device to prevent additional interference. I f you notice that this device causes interference in low-voltage RFID tracing systems, contact a FUJIFILM representative.

2.4DS/OF4

Wireless Network Devices: Cautions

This sticker indicates that this device operates in the 2.4GHz band using DSSS and OFDM modulation and may cause interference at distances of up to 40m.

About This Manual

Table of Contents

.............................

Troubleshooting

..........................

110

Warning Messages and Displays

...

118

Memory Cards

About This Manual

Before using the camera, read this manual and the warnings in “For Your Safety” (P ii). For information on speci c topics, consult the sources below.

Table of Contents

The “Table of Contents” gives an overview of the entire manual. The

.............................PP

Troubleshooting

..........................PP

Having a speci c problem with the camera? Find the answer here.

110

principal camera operations are listed here.

Warning Messages and Displays

...PP

118

Find out what’s behind that  ashing icon or error message in the display.

Memory Cards

Pictures can be stored in the camera’s internal memory or on optional SD, SDHC, and SDXC memory cards (P 17), referred to in this manual as “memory cards.”

Table of Contents

Before You Begin

First Steps

Basic Photography and Playback

More on Photography

Table of Contents

For Your Safety ..................................................................ii

IMPORTANT SAFETY INSTRUCTIONS ..................................ii

Safety Notes ....................................................................iv

About This Manual ............................................................x

Before You Begin

Symbols and Conventions .................................................1

Supplied Accessories .........................................................1

Parts of the Camera ..........................................................2

Camera Displays (Touch Panel) .........................................4

Shooting ........................................................................4

Playback .........................................................................5

The Touch Panel Display....................................................6

Tap .................................................................................6

Scroll ..............................................................................6

Playback Zoom ................................................................6

Rotating the Camera ........................................................8

Shooting ........................................................................8

Playback .........................................................................9

Touch Panel Icons ...........................................................10

Shooting ......................................................................10

Playback .......................................................................11

First Steps

Charging the Battery ......................................................12

Inserting the Battery and a Memory Card .....................14

Compatible Memory Cards .............................................17

Turning the Camera on and O ......................................19

Shooting Mode ..............................................................19

Playback Mode ...............................................................19

Basic Setup ......................................................................21

Basic Photography and Playback

Taking Pictures in R (E AUTO) Mode.............23

Viewing Pictures .............................................................28

More on Photography

Shooting Mode ................................................................29

E (E AUTO/E Priority) .................30

R (E AUTO) .................................................30

E Priority ..........................................................31

BAUTO .......................................................................32

R TOUCH E AUTO/JTOUCH & SHOOT .........32

SPSCENE POSITION.......................................................33

MOTION PANORAMA 360 .......................................35

DNATURAL LIGHT ......................................................37

CNATURAL & N.........................................................37

PPROGRAM AE ..............................................................37

Table of Contents

More on Playback

Movies

Connections

Focus Lock ........................................................................38

dExposure Compensation ..........................................40

NUsing the Flash (Super-Intelligent Flash) .................41

hUsing the Self-Timer .................................................43

gUsing the Self-Portrait Timer ...................................44

FMacro Mode (Close-ups) ...........................................45

bIntelligent Face Detection .......................................46

R Continuous Shooting ...............................................47

n Face Recognition.....................................................48

Adding New Faces ..........................................................48

Editing Existing Data ......................................................50

Adding Faces Automatically ...........................................51

More on Playback

Playback Options .............................................................53

Playback Zoom ...............................................................54

GMulti-Frame Playback .............................................56

e Deleting Pictures ........................................................58

q Uploading Pictures to a Smartphone (Tablet) ........59

H Image Search ...........................................................61

L PhotoBook Assist .....................................................63

Creating a PhotoBook.....................................................63

Viewing Photobooks ......................................................64

Editing and Deleting Photobooks ...................................64

p Face Retouch .............................................................65

j Edit ............................................................................66

fCOLLAGE .................................................................67

CIMAGE ROTATE .........................................................68

GCROP .......................................................................68

ORESIZE .....................................................................69

BRED EYE REMOVAL ...................................................69

Viewing Panoramas ........................................................70

Movies

Recording Movies ............................................................71

Movie Frame Size ...........................................................72

Viewing Movies ...............................................................73

Connections

Connecting the Camera to High De nition (HD) TVs ....74

Printing Pictures via USB ................................................76

Viewing Pictures on a Computer ....................................78

Windows: Installing MyFinePix Studio ...........................78

Macintosh: Installing FinePixViewer...............................80

Connecting the Camera ..................................................82

xii

Menus

Using the Menus: Shooting Mode ..................................85

Using the Shooting Menu...............................................85

Shooting Menu Options .................................................86

dEXP. COMPENSATION ...............................................86

NISO........................................................................86

OIMAGE SIZE ............................................................87

TIMAGE QUALITY .....................................................87

WMOVIE MODE .........................................................88

UDYNAMIC RANGE ...................................................88

PFILM SIMULATION ..................................................88

DWHITE BALANCE ....................................................89

RCONTINUOUS SHOOTING SETUP ...............................89

bFACE DETECTION ....................................................89

FAF MODE ...............................................................90

FMOVIE AF MODE ....................................................90

ZADVANCED ANTI BLUR ............................................91

yINTELLIGENT SHARPNESS ........................................91

MSET-UP ..................................................................91

Table of Contents

Using the Menus: Playback Mode ..................................92

Using the Playback Menu ...............................................92

Playback Menu Options ..................................................92

mPHOTOBOOK ASSIST ................................................92

lFAVORITES .............................................................92

hPICTURE COMPARE .................................................92

bIMAGE SEARCH ......................................................93

cEDIT ......................................................................93

pFACE RETOUCH .......................................................93

ISLIDE SHOW ..........................................................93

DPROTECT ................................................................94

ECOPY .....................................................................94

iERASE FACE RECOG. ................................................95

AERASE ...................................................................95

jMARK FOR UPLOAD TO ............................................96

qCONNECT TO SMARTPHONE .....................................97

MSET-UP ..................................................................97

xiii

Table of Contents

Technical Notes

Troubleshooting

Appendix

The Setup Menu ..............................................................98

Using the Setup Menu ....................................................98

Setup Menu Options ......................................................98

FDATE/TIME ............................................................98

NTIME DIFFERENCE ...................................................98

Qa ......................................................99

oSILENT MODE .........................................................99

RRESET ....................................................................99

KFORMAT ................................................................99

AIMAGE DISP. ...........................................................99

BFRAME NO. ..........................................................100

IVOLUME ..............................................................100

bSOUND ................................................................100

JLCD BRIGHTNESS ..................................................101

NAUTO POWER OFF ................................................101

L DUAL IS MODE .....................................................101

BRED EYE REMOVAL ...............................................101

R INTELLIGENT DIGITAL ZOOM ..................................102

cBEST FRAMING ....................................................102

t SAVE ORG IMAGE .................................................103

a STILL SHOOTING IN MOVIE ....................................103

mAUTOROTATE PB ...................................................103

OBACKGROUND COLOR ............................................103

aILLUMINATION .....................................................103

xPOWER MANAGEMENT .........................................104

qWIRELESS SETTING ...............................................104

U DATE STAMP ........................................................105

hCALIBRATION .......................................................105

iVERSION INFO ......................................................105

W START-UP SCREEN ................................................105

Technical Notes

Optional Accessories .....................................................106

Accessories from FUJIFILM............................................107

Caring for the Camera ...................................................108

Storage and Use ...........................................................108

Cleaning .......................................................................109

Traveling ......................................................................109

Troubleshooting

Problems and Solutions ................................................110

Warning Messages and Displays ..................................118

Appendix

Tips and Tricks................................................................123

Battery Performance ....................................................123

Silent Mode ..................................................................123

The Self-timer ..............................................................123

Intelligent Face Detection ............................................124

Pro Tips ........................................................................125

Internal Memory/Memory Card Capacity ....................126

Speci cations ................................................................127

xiv

Before You Begin

Symbols and Conventions

Supplied Accessories

Attaching the Strap

Before You Begin

Symbols and Conventions

The following symbols are used in this manual: Q : This information should be read before use to ensure correct operation. R : Additional information that may be helpful when using the camera. P : Other pages in this manual on which related information may be found.

Menus and other text in the LCD monitor are shown in bold. In the illustra- tions in this manual, displays may be simpli ed for explanatory purposes.

Supplied Accessories

The following items are included with the camera:

NP-45A recharge-

able battery

• Strap

• Basic Manual

* Shape of adapter varies with region of sale.

BC-45C battery

charger

Plug adapter

Attach the strap as shown.

Attaching the Strap

USB cable CD-ROM

(contains this

manual)

Parts of the Camera

For more information, refer to the page listed to the right of each item.

1 Shutter button .............................................................. 26

2 F (movie recording) button ....................................... 71

3 Indicator lamp ................................................................ 3

4 a (playback) button .................................................. 19

5 Speaker ......................................................................... 73

6 Microphone .................................................................. 71

7 Lens ............................................................................ 127

8 Self-portrait mirror ....................................................... 44

9 On/o switch and lens cover ......................................... 19

10 Flash ............................................................................. 41

11 Illuminator.................................................................. 103

Self-timer lamp ............................................................ 43

2 Before You Begin

12 Zoom control ................................................................25

13 LCD monitor ................................................................ 129

Touch panel display .................................................4, 6, 8

14 Strap eyelet ....................................................................1

15 Battery-chamber cover ................................................. 14

16 Tripod mount

17 HDMI mini connector .................................................... 74

18 Connector for USB cable ...........................................76, 82

19 Memory card slot .......................................................... 15

20 Battery chamber ...........................................................14

21 Battery latch ............................................................14, 16

Parts of the Camera

The Indicator Lamp

Indicator lamp

Camera status

Glows green

Blinks green

Blinks green and orange

Glows orange

Blinks orange

Blinks red

The Indicator Lamp

The indicator lamp shows camera status as follows:

Indicator lamp

Glows green Focus locked.

Blinks green Blur, focus, or exposure warning. Picture can be taken.

Blinks green and orange Recording pictures. Additional pictures can be taken.

Glows orange Recording pictures. No additional pictures can be taken at this time.

Blinks orange Flash charging;  ash will not  re when picture is taken.

Blinks red Lens or memory error.

Camera status

3Before You Begin

Parts of the Camera

Camera Displays (Touch Panel)

10: 00

127

12 / 31/ 2050

Camera Displays (Touch Panel)

The following types of indicator may be displayed during shooting and playback. Indicators vary with camera settings.

■ Shooting

7 Advanced anti blur ........................................................ 31

12/31/2050 10: 00

MENU DISP

1 Battery level ................................................................... 5

2 Dual IS mode .............................................................. 101

3 Intelligent Face Detection indicator .............................. 46

4 Silent mode indicator ................................................... 99

5 White balance ............................................................... 89

6 Continuous shooting mode ........................................... 47

* a: indicates that no memory card is inserted and that pictures will be stored in the camera’s internal memory (P 15).

127

1600

8 Intelligent sharpness .................................................... 91

9 Date stamp ................................................................. 105

10 Focus warning ............................................................118

11 Focus frame .................................................................. 38

12 Internal memory indicator

13 Image size/quality ........................................................ 87

14 Film simulation ............................................................. 88

15 Movie mode .................................................................. 72

16 Number of available frames ........................................ 126

17 Sensitivity ..................................................................... 86

18 Temperature warning ................................................. 113

19 Date and time ............................................................... 21

20 Dynamic range ............................................................. 88

21 Exposure compensation ................................................ 40

22 Blur warning ..........................................................42, 118

4 Before You Begin

Parts of the Camera

Battery Level

Indicator

Description

Hiding and Viewing Indicators

■ Playback

1 Playback mode indicator..........................................28, 53

100-0001

YouTube

MENU DISP

Battery Level

Battery level is shown as follows:

Indicator

D (white) C (white) B (red) A (blinks red)

Hiding and Viewing Indicators

Battery partially discharged. Battery more than half discharged. Low battery. Charge as soon as possible. Battery exhausted. Turn camera o and charge battery.

Tap DISP to cycle through shooting and playback indicators as follows: all icons and indicators displayed/all icons and indicators hidden/only button icons displayed.

2 Intelligent Face Detection indicator .............................. 46

3 Silent mode indicator ................................................... 99

4 Protected image ........................................................... 94

5 Photobook assist........................................................... 63

6 Gift image ..................................................................... 53

7 Frame number ............................................................ 100

8 Advanced anti blur ........................................................ 31

9 Motion panorama z ............................................35, 70

10 Face retouch/edit .....................................................65, 66

11 Red-eye removal indicator .....................................69, 101

12 Mark for upload to ........................................................ 96

13 Favorites ....................................................................... 92

Description

5Before You Begin

The Touch Panel Display

The touch panel display can be operated by tapping the display or gliding a  nger over the panel. The panel responds to pressure; use a  rm touch, but do NOT use excessive force.

■ Tap

Lightly tap the display to adjust settings or select pictures or menu op-

■ Playback Zoom

Place two  ngers on the display and slide them apart to zoom in.

tions.

BACK DISP

MENU DISP

■ Scroll

Slide them together to zoom out. Glide lightly over the display to scroll through pictures during playback.

BACK DISP

MENU DISP

6 Before You Begin

The Touch Panel Display

Q Note that some LCD monitor covers may a ect the visibility of the image in the

monitor or make the monitor less responsive. To avoid damaging the monitor and touch panel display, observe the following precautions:

• Use only your  ngers to operate the panel. Do not use excessive force.

• Do not sit on the camera (by, for example, leaving it in a back pocket when sitting down), place it under heavy objects, or attempt to force it into a small space (such as a suitcase that is already full).

• Do not attach objects to the camera strap that might place pressure on the monitor.

7Before You Begin

The Touch Panel Display

Rotating the Camera

With some exceptions, the display in the LCD monitor rotates 90 ° when the camera is in “tall” orientation.

■ Shooting

Camera held in “wide”

(landscape) orientation

MENU DISP

Camera held in “wide” (landscape) orientation

Camera held in “tall” (portrait) orientation

DISP

Camera held in “tall” (portrait) orientation

8 Before You Begin

■ Playback

The Touch Panel Display

Camera held in “wide”

(landscape) orientation

Camera held in “tall”

(portrait) orientation

DISP

Camera held in “wide” (landscape) orientation

MENU DISP

Camera held in “tall” (portrait) orientation

DISP

9Before You Begin

The Touch Panel Display

Touch Panel Icons

■ Shooting

Tap the icons in the shooting display to perform the operations listed below. The icons displayed vary with the options currently selected.

Shooting mode: Choose a shoot-

Flash mode: Choose a  ash

mode (P 41).

Self-timer: Use the selftimer (P 43).

ing mode (P 29).

Self-portrait timer: Use the self-portrait timer (P 44).

Face recognition: View face recognition options (P 48).

Macro mode: Shoot in macro mode (P 45).

10 Before You Begin

MENU DISP

Shooting menu: View the shooting menu (P 85).

Playback: View pictures (P 53).

Display: Turn indicators on or o (P 5).

The Touch Panel Display

■ Playback

Tap the icons in the playback display to perform the operations listed below. The icons displayed vary with the type of picture and the current playback mode.

Delete: Delete all or selected pictures (P 58).

Multi-frame: View multiple pictures (P 56).

Face retouch: Retouch faces (P 65).

Connect to smartphone: Upload pictures to a smartphone (P 59).

Image search: Find pictures (P 61).

Photobook assist: Create photobooks (P 63).

MENU DISP

Playback menu: View the playback menu (P 92).

Next: View the next picture (P 28).

Previous: View the previous picture (P 28).

Display: Turn indicators on or o (P 5).

11Before You Begin

First Steps

Charging the Battery

First Steps

Charging the Battery

The battery is not charged at shipment. Charge the battery before use.

Attach the plug adapter.

Attach the plug adapter as shown at right, making sure that it is fully inserted and clicks into place on the charger terminals.

Q The plug adapter is exclusively for use with the

supplied battery charger. Do not use it with other devices.

Place the battery in the supplied battery charger.

Insert the battery in the orientation indicated by the CFD

Battery

Arrow

labels.

The camera uses an NP-45A rechargeable battery.

CFD label

Battery charger

Plug adapter

Charge lamp

Charging the Battery

The Charging Indicator

Charging indicator

Battery status

Action

O

Battery not inserted.

Insert the battery.

On (green)

Battery fully charged.

Remove the battery.

On (orange)

Battery charging.

—

Blinks (orange)

Battery fault.

Unplug the charger and remove the battery.

Plug the charger in.

Plug the charger into an indoor power outlet. The charging indicator will light.

The Charging Indicator

The charging indicator shows battery charge status as follows:

Charging indicator

O

On (green)

On (orange)

Blinks (orange)

Charge the battery.

Battery status

Battery not inserted.

Battery fully charged.

Battery charging.

Battery fault.

Action

Insert the battery.

Remove the battery.

—

Unplug the charger and remove the battery.

Remove the battery when charging is complete. See the speci cations (P 131) for charging times (note that charging times increase at low temperatures).

Q Unplug the charger when it is not in use.

13First Steps

Inserting the Battery and a Memory Card

Although the camera can store pictures in internal memory, optional SD, SDHC, and SDXC memory cards (sold separately) can be used to store additional pictures. After charging the battery, insert the battery and memory card as described below.

Open the battery-chamber cover.

R Be sure the camera is o before opening

the battery-chamber cover.

Q Do not open the battery-chamber cover

when the camera is on. Failure to observe this precaution could result in damage to image  les or memory cards.

Q Do not use excessive force when handling the battery-chamber cover.

Insert the battery.

Insert the battery with the terminal  rst and in

Label

the orientation shown by the label inside the battery chamber, keeping the battery latch pressed to one side. Con rm that the battery is securely latched.

Q Insert the battery in the correct orientation. Do

NOT use force or attempt to insert the battery upside down or backwards. The

battery will slide in easily in the correct orientation.

Battery latch

14 First Steps

Inserting the Battery and a Memory Card

Insert the memory card.

Holding the memory card in the orientation shown at right, slide it in until it clicks into place at the back of the slot.

Q Be sure card is in the correct orientation;

do not insert at an angle or use force. If the memory card is not correctly inserted or no memory card is inserted, a will appear in the LCD monitor and internal memory will be used for recording and playback.

Q SD/SDHC/SDXC memory cards can be locked, making

it impossible to format the card or to record or delete images. Before inserting an SD/SDHC/SDXC memory card, slide the write-protect switch to the unlocked position.

Close the battery-chamber cover.

Click

Battery

Write-protect switch

15First Steps

Inserting the Battery and a Memory Card

RRUsing an AC Power Adapter

Removing the Battery and Memory Card

Using an AC Power Adapter

• The camera can be powered by an optional AC power adapter and DC coupler (sold separately). See the manuals provided with the AC power adapter and DC coupler for details.

• Depending on the country or region of sale, a demo mode slide show may start if the camera is turned on while powered by an AC power adapter. Press the shutter button to end the show.

Removing the Battery and Memory Card

Before removing the battery or memory card, turn the camera o and open the battery-chamber cover.

To remove the battery, press the battery latch to the side, and slide the battery out of the camera as shown.

Battery latch

To remove the memory card, press it in and release it slowly. The card can then be removed by hand. When a memory card is removed, the card could come out of the slot too quickly. Use your  nger to hold it and gently release the card.

16 First Steps

Inserting the Battery and a Memory Card

QQMemory Cards

■ Compatible Memory Cards

FUJIFILM and SanDisk SD, SDHC, and SDXC memory cards have been approved for use in the camera. A complete list of approved memory cards is available at http://www.fujifilm.com/support/digital_cameras/compatibility/. Operation is not guaranteed with other cards. The camera can not be used with xD-Picture Cards or MultiMediaCard (MMC) devices.

Memory Cards

• Do not turn the camera o or remove the memory card while the memory card is

being formatted or data are being recorded to or deleted from the card. Failure to

observe this precaution could damage the card.

• Format SD/SDHC/SDXC memory cards before  rst use, and be sure to reformat all

memory cards after using them in a computer or other device. For more information on formatting memory cards, see “K FORMAT” (P 99).

• Memory cards are small and can be swallowed; keep out of reach of children. If a

child swallows a memory card, seek medical assistance immediately.

• miniSD or microSD adapters that are larger or smaller than the standard dimensions

of an SD/SDHC/SDXC card may not eject normally; if the card does not eject, take the camera to an authorized service representative. Do not forcibly remove the card.

• Do not a x labels to memory cards. Peeling labels can cause camera malfunction.

• Movie recording may be interrupted with some types of SD/SDHC/SDXC memory

card. Use a G card or better when shooting HD or high-speed movies.

17First Steps

Inserting the Battery and a Memory Card

QQBatteries

• The data in internal memory may be erased or corrupted when the camera is repaired. Please note that the repairer will be able to view pictures in internal memory.

• Formatting a memory card or internal memory in the camera creates a folder in which pictures are stored. Do not rename or delete this folder or use a computer or other device to edit, delete, or rename image  les. Always use the camera to delete pictures from memory cards and internal memory; before editing or renaming  les, copy them to a computer and edit or rename the copies, not the originals.

Batteries

• Remove dirt from the battery terminals with a clean, dry cloth. Failure to observe this precaution could prevent the battery from charging.

• Do not a x stickers or other objects to the battery. Failure to observe this precaution could make it impossible to remove the battery from the camera.

• Do not short the battery terminals. The battery could overheat.

• Read the cautions in “The Battery and Power Supply” (P vi).

• Use only battery chargers designated for use with the battery. Failure to observe this precaution could result in product malfunction.

• Do not remove the labels from the battery or attempt to split or peel the outer casing.

• The battery gradually loses its charge when not in use. Charge the battery one or two days before use.

18 First Steps

Turning the Camera on and O

Shooting Mode

Playback Mode

RRSwitching to Shooting Mode

Turning the Camera on and O

Shooting Mode

To turn the camera on, open the lens cover fully. The camera turns o when the lens cover is closed.

Camera on Camera o

Playback Mode

If the lens cover is closed, the camera can be turned on in playback mode by pressing the a button for about a second.

To turn the camera o , press and hold the a button.

Switching to Shooting Mode

To exit to shooting mode, press the shutter button halfway.

19First Steps

Turning the Camera on and O

RRAuto Power O

Q Fingerprints and other marks on the lens can a ect pictures. Keep the lens clean. Q Turning the camera o does not completely end the supply of power to the camera. Q The indicator lamp lights when the camera is turned o . Do not remove the bat-

tery while the lamp is lit. The camera can not be turned on again until the lamp turns o .

Auto Power O

The camera will turn o automatically if no operations are performed for the length of time selected for N AUTO POWER OFF (P 101).

20 First Steps

Basic Setup

RR“NO” and “BACK”

Basic Setup

A language-selection dialog is displayed the  rst time the camera is turned on. Set up the camera as described below (you can reset the clock or change languages at any time using the F DATE/TIME or Q a options in the setup menu; for information on displaying the setup menu, see page 98).

Tap to select a language. Tap m or n to view ad-

ditional languages.

“NO” and “BACK”

Tap BACK to return to the previous step, NO to skip the current step. Any steps you skip will be displayed the next time the camera is turned on.

The date will be displayed. Tap the m or n arrows

to set the date and then tap OK. To change the order in which the year, month, and day are displayed, tap YY.MM.DD.

The time will be displayed. Select AM or PM, tap the

m or n arrows to set the time, and tap OK.

Tap a shooting mode.

START MENU

ENGLISH

FRANCAIS

1 / 4

ESPAÑOL

NEDERLANDS

START MENU

2012

YY MM DD

BACK OK

START MENU

BACK OK

DEUTSCH

PORTUGUÊS

ITALIANO

РУССКИЙ ﻲﺑﺮﻋ

DATE/TIME

01 01

DATE/TIME

12 00

hh mm

YY.MM.DD

21First Steps

Basic Setup

RRThe Camera Clock

Power management options will be displayed. Tap one of the following

options:

• n POWER SAVE: Save battery power.

• o CLEAR DISPLAY: Choose for a brighter, higher quality display.

Tap OK to enter shooting mode when setup is complete.

MENU DISP

The Camera Clock

If the battery is removed for an extended period, the camera clock will be reset and the language-selection dialog will be displayed when the camera is turned on.

22 First Steps

Basic Photography and Playback

Taking Pictures in

AUTO

) Mode

Basic Photography and Playback

Taking Pictures in RR ( (

AUTO

) Mode

This section describes how to take pictures in R (E AUTO) mode.

Turn the camera on.

Fully open the lens cover.

Select R mode.

Tap the shooting mode icon to view shooting modes and tap R.

MENU DISP

Display E options.

A description will be displayed. Tap the description to continue, or wait for it to clear from the display automatically.

BACK

SHOOTING MODE

AUTO

Motion Panorama

Natural Light

Touch EXR AUTO

Natural&Flash Program

Scene Position

Taking Pictures in R (E AUTO) Mode

The

Icon

Scene Icons (

30)

Select R.

Tap R to select R mode and then tap OK to exit to shooting mode.

The

Icon

In R mode, the camera continuously adjusts focus and searches for faces, in- creasing the drain on the battery. o is displayed in the LCD monitor.

MENU DISP

Scene Icons (PP

The camera automatically selects the appropriate scene.

R The camera analyses the scene and selects the preferred E mode when

the shutter button is pressed halfway (P 31).

30)

24 Basic Photography and Playback

Taking Pictures in R (E AUTO) Mode

Holding the Camera

Frame the picture.

Use the zoom control to frame the picture in the display.

MENU DISP

Zoom indicator

Zoom out Zoom in

Holding the Camera

MENU DISP

Hold the camera steady with both hands and brace your elbows against your sides. Shaking or unsteady hands can blur your shots.

To prevent pictures that are out of focus or too dark (underexposed), keep your  ngers and other objects away from the lens and  ash.

25Basic Photography and Playback

Taking Pictures in R (E AUTO) Mode

Focus.

Press the shutter button halfway to focus.

R The lens may make a noise when the camera focuses; this

is normal.

If the camera is able to focus, it will beep twice and the indicator lamp will glow green.

If the camera is unable to focus, the focus frame will turn red, s will be displayed, and the indicator lamp will blink green. Change the composition or use focus lock (P 38).

Double

beep

26 Basic Photography and Playback

Taking Pictures in R (E AUTO) Mode

The Shutter Button

Shoot.

Smoothly press the shutter button the rest of the way down to take the picture.

R If the subject is poorly lit, the  ash may  re when the pic-

ture is taken. For information on using the  ash when lighting is poor, see “N Using the Flash (Super-Intelligent Flash)” (P 41).

The Shutter Button

The shutter button has two positions. Pressing the shutter button halfway sets focus and exposure; to shoot, press the shutter button the rest of the way down.

Click

27Basic Photography and Playback

Viewing Pictures

Pictures can be viewed in the LCD monitor. When taking important photographs, take a test shot and check the results.

Tap the a icon.

The most recent picture will be displayed.

MENU DISP

View additional pictures.

Scroll left or right or tap o or p.

MENU DISP

Press the shutter button to exit to shooting mode.

28 Basic Photography and Playback

More on Photography

Shooting Mode

Mode

See

Mode

See

MOTION PANORAMA 360

AUTO

NATURAL LIGHT

TOUCH

AUTO/

NATURAL &

TOUCH & SHOOT

PROGRAM AE

SCENE POSITION

More on Photography

Shooting Mode

Choose a shooting mode according to the scene or type of subject. Tap the shooting mode icon in the LCD monitor and tap the icon for the desired mode.

MENU DISP

See

AUTO

TOUCH

Touch EXR AUTO

TOUCH & SHOOT

Touch&Shoot

SCENE POSITION

Scene Position

Mode

AUTO/

See

Mode

MOTION PANORAMA 360

Motion Panorama

NATURAL LIGHT

Natural Light

NATURAL & NN

Natural&Flash

PROGRAM AE

Program

A description of the selected mode will be displayed; tap the description to continue, or wait for it to clear from the display automatically.

Shooting Mode

AUTO/

Priority)

Scene

Main subject

AUTO

LANDSCAPE

NIGHT

(TRIPOD)

MACRO

BEACH

SUNSET

SNOW

SKY

GREEN-

ERY

SKY &

GREENERY

Non-portrait

aaccd

eeuuvvwwxxyyz

Portrait

Normal

ddddccddd

—

dduuddvvddwwddxxddyyddz

Backlit

gggc

—————

gugugvgvgwgwgxgxgygygz

Moving object

ccccccccd

cceeccuuccvvccwwccxxccyyccz

Portrait and motion

Normal

aaaaccaad

—

aauuaavvaawwaaxxaayyaaz

Backlit

bbbbc

—————

bbuubbvvbbwwbbxxbbyybbz

E ( (

Optimize settings for your current subject or improve clarity, reduce noise, or enhance dynamic range. Choose one of the following E modes in the shooting menu.

AUTO/

Priority)

BACK

SHOOTING MODE

Motion Panorama

AUTO

Natural Light

Touch EXR AUTO

Natural&Flash Program

■ R (E AUTO)

The camera automatically selects the scene and E mode according to shooting conditions (P 23).

R If S is selected for O IMAGE SIZE in R mode, the cam-

era will automatically select the optimal image size.

R R INTELLIGENT DIGITAL ZOOM is restricted to 2× (P 102).

MENU DISP

Scene icon

The Scene Icon

The camera selects from the following scenes:

Scene Main subject Non-portrait

Portrait

Moving object

Portrait and motion

Normal Backlit

* If n is displayed, the camera will take a series of shots (advanced anti-blur; P 31).

Q The mode selected may vary with shooting conditions. If the mode and subject do not match,

select B mode (P 32) or choose SP (P 33) and select a scene manually.

LAND-

AUTO

SCAPE

NIGHT

(TRIPOD)

MACRO

GREEN-

BEACH

SUNSET

SNOW

SKY

— —

ERY

SKY &

GREENERY

Scene Position

30 More on Photography

Shooting Mode

Advanced Anti Blur

When n is displayed, the camera will take a series of exposures and combine them to form a single image, reducing “noise” (mottling) and blur. Pictures taken using this process are indicated by a T icon during playback.

R n is available when ON is selected in the shooting menu (P 91) and the  ash

(P 41) is o or set to auto.

Q Some time may be required to combine the exposures into a single image. A

single combined image may not be created if the subject or camera moves during shooting. Keep the camera steady during shooting and do not move the camera until shooting is complete.

Q Frame coverage is reduced.

The E Icon

When the shutter button is pressed halfway, the camera chooses the preferred E mode:

• S (RESOLUTION PRIORITY): Produces crisp, clear shots.

• T (HIGH ISO & LOW NOISE): Reduces noise in pictures taken at high sensitivities.

• U (D-RANGE PRIORITY): Increases the amount of detail visible in highlights.

■ E Priority

Select this mode to manually choose from the following E modes:

• S (RESOLUTION PRIORITY): Choose for crisp, clear shots.

• T (HIGH ISO & LOW NOISE): Reduce noise in pictures taken at high sensitivities.

• U (D-RANGE PRIORITY): Increase the amount of detail visible in highlights.

U DYNAMIC RANGE (P 88) can be set to Z (1600%) and Y (800%).

31More on Photography

Shooting Mode

BBAUTO

RR TOUCH

AUTO/

TOUCH & SHOOT

AUTO

Choose for crisp, clear snapshots. This mode is recommended in most situations.

TOUCH

AUTO/JJ

TOUCH & SHOOT

Choose this mode to take pictures by touching the display instead of pressing the shutter button. Choose R TOUCH E AUTO (the camera automatically se- lects the appropriate scene and E modes when a

BACK

SHOOTING MODE

Motion Panorama

SHOOTING MODE

Motion Panorama

AUTO

Natural Light

AUTO

Natural Light

Scene Position

Touch EXR AUTO

Natural&Flash Program

Scene Position

Touch EXR AUTO

Natural&Flash Program

picture is taken) or J TOUCH & SHOOT, then touch anywhere inside the “touch and shoot” area to focus on the selected subject and take a picture.

MENU DISP

R If a face is detected in R mode, the camera will focus on the face rather than on

the selected subjected.

32 More on Photography

SCENE POSITION

Scene

Description hh PORTRAIT ZZ PORTRAIT ENHANCER MM LANDSCAPE NN SPORT OO NIGHT HH NIGHT (TRIPOD)

pp FIREWORKS

QQ SUNSET

RR SNOW

ss BEACH

UU PARTY VV FLOWER WW TEXT ll DOG mm CAT

SCENE POSITION

The camera o ers a choice of “scenes,” each adapted to particular shooting conditions or a speci c type of subject. Choose from the following options:

Scene

PORTRAIT

PORTRAIT ENHANCER LANDSCAPE SPORT NIGHT

NIGHT (TRIPOD)

FIREWORKS

SUNSET

SNOW

BEACH

PART Y FLOWER

TEXT DOG CAT

Choose for portraits. Choose for a smooth skin e ect when shooting portraits. Choose for daylight shots of buildings and landscapes. Choose when photographing moving subjects. Choose this mode for poorly lit twilight or night scenes. Choose this mode for slow shutter speeds when shooting at night. Slow shutter speeds are used to capture the expanding burst of light

from a  rework. Choose this mode to record the vivid colors in sunrises and sunsets. Choose for crisp, clear shots that capture the brightness of scenes domi-

nated by shining white snow. Choose for crisp, clear shots that capture the brightness of sunlit beach-

es. Capture indoor background lighting under low-light conditions. Choose for vivid close-ups of  owers. Take clear pictures of text or drawings in print. Choose when photographing dogs. Choose when photographing cats.

Description

BACK

SHOOTING MODE

Motion Panorama

Shooting Mode

AUTO

Natural Light

Scene Position

Touch EXR AUTO

Natural&Flash Program

33More on Photography

Shooting Mode

DOG/

CAT

DOG/

CAT

The camera focuses on the faces of dogs or cats that are facing the camera, and the self-timer menu o ers a n AUTO RELEASE option that releases the shutter auto- matically when a pet is detected (P 43). During playback, image search (P 61) can be used to search for pictures taken in either mode.

R Although camera can detect many di erent breeds of dogs and cats, results may vary with

the breed and shooting conditions. The camera may fail to detect pets with dark-colored faces or long hair covering their entire face. If a dog or cat is not detected, the camera focuses on the subject at the center of the frame.

34 More on Photography

Shooting Mode

MOTION PANORAMA 360

SHOOTING MODE

Follow an on-screen guide to take photos that will au-

AUTO

Natural Light

Touch EXR AUTO

Natural&Flash Program

tomatically be joined to form a panorama. The camera zooms all the way out and zoom remains  xed at the

BACK

Motion Panorama

widest angle until shooting is complete.

Tap y and select the pan direction.

MENU DISP

Tap u and select the angle through which you will

pan the camera while shooting.

MENU DISP

Press the shutter button all the way down to start recording. There is no

need to keep the shutter button pressed during recording.

Pan the camera in the direction shown by the arrow.

Shooting ends automatically when the progress bar is full and the panorama is complete.

R Shooting ends if the shutter button is pressed all the

way down during shooting. No panorama will be recorded if the shutter button is pressed before the camera has been panned through 120 °.

Progress bar

Scene Position

35More on Photography

Shooting Mode

SAVE ORG IMAGE

For Best Results

Q Panoramas are created from multiple frames. The camera may in some cases record

an greater or lesser angle than selected or be unable to stitch the frames together perfectly. The last part of the panorama may not be recorded if shooting ends before the panorama is complete.

Q Shooting may be interrupted if the camera is panned too quickly or too slowly. Pan-

ning the camera in a direction other than that shown cancels shooting.

Q The desired results may not be achieved with moving subjects, subjects close to

the camera, unvarying subjects such as the sky or a  eld of grass, subjects that are in constant motion, such as waves and waterfalls, or subjects that undergo marked changes in brightness. Panoramas may be blurred if the subject is poorly lit.

Choose u for seamless 360 ° panoramas that can be played back in a loop (P70).

R The

SAVE ORG IMAGE option in the setup menu can be used to record a t

panorama in addition to a seamless t panorama (P 103).

Q Depending on the subject and shooting conditions, the camera may produce

distorted results or a t panorama. The top and bottom of the area visible in the shooting display are cropped out and white strips may appear at the top and bottom of the display.

For Best Results

For best results, move the camera in a small circle at a steady speed, keeping the camera horizontal and being careful only to pan in the direction shown by the guides. If the desired results are not achieved, try panning at a di erent speed.

36 More on Photography

DDNATURAL LIGHT

CCNATURAL &

P PPROGRAM AE

NATURAL LIGHT

Capture natural light indoors, under low light, or where the  ash can not be used. The  ash turns o and sensitivity is raised to reduce blur.

NATURAL & NN

This mode helps ensure good results with backlit subjects and in other situations with di cult lighting. Each time the shutter button is pressed, the camera takes two shots: one shot without the  ash to preserve natural lighting, followed immediately by a second shot with the  ash. Do not move the camera until shooting is complete.

PROGRAM AE

The camera sets exposure automatically.

BACK

SHOOTING MODE

Motion Panorama

SHOOTING MODE

Motion Panorama

SHOOTING MODE

Motion Panorama

Shooting Mode

AUTO

Natural Light

AUTO

Natural Light

AUTO

Natural Light

Scene Position

Touch EXR AUTO

Natural&Flash Program

Scene Position

Touch EXR AUTO

Natural&Flash Program

Scene Position

Touch EXR AUTO

Natural&Flash Program

37More on Photography

Focus Lock

To compose photographs with o -center subjects:

Fo cus:

Position the subject in the focus frame ( ) and press the shutter button halfway to lock focus and exposure. Focus and exposure will remain locked while the shutter button is pressed halfway (AF/AE lock).

Recompose: Keep the button pressed halfway.

Shoot: Press the button all the way down.

MENU DISP

38 More on Photography

Focus Lock

Autofocus

Although the camera boasts a high-precision autofocus system, it may be unable to focus on the subjects listed below. If the camera is unable to focus, focus on another subject at the same distance and use focus lock to recompose the photograph.

• Very shiny subjects such as mirrors or car bodies.

• Fast-moving subjects.

• Subjects photographed through a window or other re-

 ective object.

• Dark subjects and subjects that absorb rather than re ect

light, such as hair or fur.

• Insubstantial subjects, such as smoke or  ame.

• Subjects that show little contrast with the background

(for example, subjects in clothing that is the same color as the background).

• Subjects positioned in front of or behind a high-contrast

object that is also in the focus frame (for example, a subject photographed against a backdrop of highly contrasting elements).

39More on Photography

d dExposure Compensation

Exposure Compensation

To adjust exposure compensation when photograph-

ing very bright, very dark, or high-contrast subjects, tap

MENU to display the shooting menu and select dEXP. COMPENSATION (P 86). Tap m or n to choose an ex-

MENU DISP

posure compensation value and then tap OK.

Choose positive values (m) to increase exposure

Choose negative values (n) to reduce exposure

R A d icon and exposure indicator are displayed at settings other than ±0. Exposure

compensation is not reset when the camera is turned o ; to restore normal exposure control, choose a value of ±0.

R Turn the  ash o when using exposure compensation.

40 More on Photography

N NUsing the Flash (Super-Intelligent Flash)

Option

Description

((AUTO FLASH

((FORCED FLASH

((SUPPRESSED FLASH

((SLOW SYNCHRO

Using the Flash (Super-Intelligent Flash)

When the  ash is used, the camera’s Super-Intelligent Flash system instantly analyzes the scene based on such factors as the brightness of the subject, its position in the frame, and its distance from the camera. Flash output and sensitivity are adjusted to ensure that the main subject is correctly exposed while preserving the e ects of ambient background lighting, even in dimly-lit indoor scenes. Use the  ash when lighting is poor, for example when shooting at night or indoors under low light.

Tap the  ash icon and choose from the following  ash modes:

MENU DISPPMENU DISP

Option

AUTO FLASH))

FORCED FLASH))

SUPPRESSED FLASH))

SLOW SYNCHRO))

The  ash  res when required. Recommended in most situations.

The  ash  res whenever a picture is taken. Use for backlit subjects or for natural coloration when shooting in bright light.

The  ash does not  re even when the subject is poorly lit. Use of a tripod is recommended.

Capture both the main subject and the background under low light (note that brightly lit scenes may be overexposed).

Description

41More on Photography

N Using the Flash (Super-Intelligent Flash)

Red-Eye Removal

R If the  ash will  re, p will be displayed when the shutter button is pressed halfway.

At slow shutter speeds, k will appear in the display to warn that pictures may be blurred; use of a tripod is recommended.

R The  ash may  re several times with each shot. Do not move the camera until

shooting is complete.

R The  ash may cause vignetting.

Red-Eye Removal

When Intelligent Face Detection (P 46) and red-eye removal (P 101) are on, redeye removal is available in auto (K; RED EYE REDUCTION),  ash on (L; FORCED FLASH), and slow sync (M; RED EYE & SLOW) modes. Red-eye removal minimizes “red-eye” caused when light from the  ash is re ected from the subject’s retinas.

42 More on Photography

h hUsing the Self-Timer

Option

Description

Using the Self-Timer

To use the self-timer, tap the self-timer icon and choose from the following options:

MENU DISP MENU DISP

Option

The shutter is released automatically when the camera detects the face of a cat

n ( AUTO RELEASE)

(AUTO RELEASE)

S (10 SEC)

R (2 SEC)

T (OFF) Self-timer o .

or dog (P 34).

R Tap STOP to end the auto-release timer.

The shutter is released automatically when the camera detects a human portrait subject facing the camera. Use for portraits of babies.

R Tap STOP to end the auto-release timer.

The shutter is released ten seconds after the shutter button is pressed. Use for self-portraits. The self-timer lamp on the front of the camera lights when the timer starts and begins to blink shortly before the photo is taken.

The shutter is released two seconds after the shutter button is pressed. Use to reduce blur caused by the camera moving when the shutter button is pressed. The self-timer lamp will blink as the timer counts down.

Description

43More on Photography

g gUsing the Self-Portrait Timer

Option

Description

Self-Portrait Mirror

Using the Self-Portrait Timer

To use the self-portrait timer, tap the self-portrait timer icon and choose from the following options:

SELF PORTRAIT

COUPLE

SELF PORTRAIT

TIMER

OFF

TIMER

Option

d ( SELF PORTRAIT

TIMER)

MENU DISP

BACK

Description

The camera will start the timer when it detects the selected number of portrait subjects. Tap

o or p to choose the number of subjects.

The camera starts the timer when it detects two portrait subjects close together.

c ( COUPLE TIMER)

Tap o or p to choose how close the subjects must be together before the timer starts (the more hearts, the closer the subjects must be together).

e (OFF) Self-portrait timer o .

Self-Portrait Mirror

To take a self-portrait, hold the camera in one hand and frame the shot in the selfportrait mirror (P 2).

44 More on Photography

F FMacro Mode (Close-ups)

Macro Mode (Close-ups)

For close-ups, tap the macro mode icon and select F. When macro mode is in e ect, the camera focuses on subjects near the center of the frame. Use the zoom control to compose pictures (P 25).

MENU DISP MENU DISP

To exit macro mode, tap the macro mode icon and select H.

R Use of a tripod is recommended to prevent blur caused by camera shake.

45More on Photography

b bIntelligent Face Detection

Intelligent Face Detection

Intelligent Face Detection sets focus and exposure for human faces anywhere in the frame, preventing the camera from focusing on the background in group portraits. Choose for shots that emphasize portrait subjects.

To use Intelligent Face Detection, tap MENU to display the shooting menu and select ON for b FACE DETEC-

P 89). Faces can be detected with the camera in

TION ( vertical or horizontal orientation; if a face is detected, it

MENU DISP

will be indicated by a green border. If there is more than one face in the frame, the camera will select the face closest to the center; other faces are indicated by white borders.

Q In some modes, the camera may set exposure for the frame

as a whole rather than the portrait subject.

Q If the subject moves as the shutter button is pressed, their

face may not be in the area indicated by the green border when the picture is taken.

MENU DISP

Green border

46 More on Photography

RR Continuous Shooting

Continuous Shooting

Capture motion in a series of pictures.

Tap MENU to display the shooting menu and select

R CONTINUOUS SHOOTING SETUP (P 89).

Choose a frame rate and number of frames.

R The  ash turns o automatically. The previously selected  ash mode is restored

when OFF is selected for R CONTINUOUS SHOOTING SETUP.

R Frame rate varies with shutter speed. R Focus and exposure are determined by the  rst frame in each series. R The number of pictures that can be recorded depends on the memory available. R Options for R CONTINUOUS SHOOTING SETUP are restricted to 3frames/s

(3frames) and OFF when h or Z is selected for SP, or in R, D, or E mode.

MENU DISP

47More on Photography

n n Face Recognition

Adding New Faces

Face Recognition

The camera can store information on the face and personal details (name, relationship, and birth date) of portrait subjects and assign these subjects priority for Intelligent Face Detection or display their names and other

Happy Birthday!

information during playback.

Adding New Faces

Follow the steps below to add faces to the face recognition database.

Select REGISTER.

Tap n to display face recognition options and tap REGISTER.

R To disable face recognition, select OFF.

Take a photograph.

After checking that the subject is facing the camera,

MENU DISP

frame the subject using the guides and take the photograph. A con rmation dialog will be displayed; tap REGISTER to add the face to the database, RETRY

CAPTURE THE FACE ALONG WITH THE GUIDLINE

BACK

to try again (if an error is displayed, tap BACK and try again).

48 More on Photography

n Face Recognition

Text Entry

Enter a name, relationship, and birth date.

The following options will be displayed:

• NAME: Enter a name as described in “Text Entry”, below.

• CATEGORY: Tap the option that describes your relationship to the subject.

• BIRTHDAY: Tap the m and n arrows to enter the subject’s date of birth,

then tap OK.

R If you zoom in on the face of a person in the face recognition database on their

birthday, the camera will display their name and the message “Happy Birthday!”

Tap OK.

After con rming that the information you have entered is correct, tap OK to return to the face recognition menu.

Text Entry

Tap the text entry mode button until the desired text

entry mode (uppercase letters, symbols, or numbers) is displayed.

To enter a character, tap the desired button one or more times (for example, tap

the PQRS button once to enter “P”, three times to enter “R”).

To proceed to the next character, tap p. To delete an existing character, tap o

or p to highlight the character and tap DEL. Names may be up to 14 characters long.

Tap OK when text entry is complete.

NAME

BACK OK

Mode button

&space

DEL

JKL GHI DEF ABC

WXYZTUV PQRSMNO

.,!-‘”()@/;

49More on Photography

n Face Recognition

Editing Existing Data

Follow the steps below to view, edit, or delete face recognition data.

Select VIEW & EDIT.

Tap n to display face recognition options and tap VIEW & EDIT.

Select a face.

The faces in the database will be displayed. Tap a face to display face recognition data for the selected subject.

View or edit face recognition data.

The name, category, or birth date can be edited as described in Step 3 of “Adding New Faces” (P 48). To retake the photo, tap REPLACING IMAGE and shoot a new portrait as described above.

Tap BACK to exit when you have  nished viewing or editing the face recognition data. To delete face recognition data for the selected subject, tap e.

50 More on Photography

n Face Recognition

Adding Faces Automatically

To automatically add frequently-photographed subjects to the face recognition database, select ON for AUTO REGISTRATION in the face recognition menu. If the camera detects a face that has been photographed many times without being added to the database, it will display a message prompting you to create a new face recognition entry. Tap OK and enter face recogni- tion data.

R The camera may sometimes fail to recognize new faces automatically. If necessary,

faces can be added manually using the REGISTER option.

51More on Photography

n Face Recognition

Face Recognition

The camera can store up to eight faces. If you attempt to add a ninth face, a con rmation dialog will be displayed; use VIEW & EDIT to make room for new faces by deleting existing data. AUTO REGISTRATION is disabled if there are already data for eight faces.

When Intelligent Face Detection (P 46) is on and the frame contains multiple subjects from the face recognition database, the camera displays the name of the subject that will be used to set focus and exposure (the subject shown by the green frame). If no name is entered, the camera will show “---”. Subjects identi ed using face recognition but not used to set focus and exposure are shown by orange frames, other subjects by white frames.

R The camera may fail to identify subjects in the face recognition database if they are not

facing the camera or are only partly in the frame, or if details of the subjects’ faces or expressions di er markedly from those in the database.

52 More on Photography

More on Playback

Playback Options

More on Playback

Playback Options

To view the most recent picture, tap a or press the a button.

MENU DISP

Scroll left or right or tap o or p to view additional pictures.

MENU DISP

R Pictures taken using other cameras are indicated by a m (“gift image”) icon during

playback.

Playback Options

Playback Zoom

To zoom a picture in or out:

Display the picture full screen and touch the picture

with two or more  ngers to activate zoom.

MENU DISP

Tap the display to zoom in on the selected area, or place two  ngers on the

screen and spread them apart to zoom in or pinch them together to zoom out. When the picture is zoomed in, you can scroll the display by gliding a  nger over the image.

BACK DISP BACK DISP BACK DISP

Zoom in Zoom out Scroll

Tap BACK to exit zoom.

R The maximum zoom ratio varies with image size. Playback zoom is not available

with cropped or resized copies saved at a size of a or smaller.

54 More on Playback

Zoom Controls

During playback zoom (P 54), you can also zoom in or out by tapping k or n and scroll the display by tapping m, n, o, or p (you can also select i with the camera zoom control to display the zoom slider and use the zoom control to zoom in and out; P 25).

Playback Options

BACK DISP

Navigation window shows portion of image currently visible in the display

55More on Playback

Playback Options

G GMulti-Frame Playback

Multi-Frame Playback

To view pictures nine at a time, tap G in single-frame view. The number of pictures displayed changes each time you tap G (you can also select j with the camera zoom control to increase the number of pictures displayed or i to decrease the number of pictures).

MENU DISP BACK

1 frame 9 frames

BACK

25 frames

In 9- and 25-frame views, scroll left or right or tap m, n, o, or p to view more pictures.

BACK

Tap a picture to view it full screen.

56 More on Playback

Rotating the Camera

When the camera is held in “tall” (portrait) orientation, the highlighted picture appears at the top of the display. Tap m, n, o, or p to high- light pictures and tap the picture at the top of the display to view it full screen.

Playback Options

57More on Playback

ee Deleting Pictures

Option

Description

FRAME

SELECTED

FRAMES

ALL

FRAMES

Deleting Pictures

To delete individual pictures, multiple selected pictures, or all pictures, tap MENU during playback to display the playback menu, select A ERASE (P 95), and choose from the options below. Note that deleted pictures can

MENU DISP

not be recovered. Copy important pictures to a computer or other storage device before proceeding.

Option

o or p to scroll through pictures and tap e. A con rmation dialog will be dis-

Tap

FRAME

played; tap OK to delete the current picture. Tap BACK to return to playback when all the desired pictures have been deleted.

SELECTED

Tap pictures to select or deselect (pictures that are currently selected for photobooks and other playback menu operations may be shown by u). When the operation is

FRAMES

complete, tap OK to display a con rmation dialog and tap OK to delete the selected pictures.

A con rmation dialog will be displayed; tap OK to delete all unprotected pictures (if a memory card is inserted, the pictures will be deleted from the memory card; the

ALL

pictures in internal memory are only deleted if no memory card is inserted). Tapping

FRAMES

BACK cancels deletion; note that any pictures deleted before you tapped BACK can not be recovered.

R Protected pictures can not be deleted. Remove protection from any pictures you

wish to delete (P 94).

Description

58 More on Playback

qq Uploading Pictures to a Smartphone (Tablet)

Uploading Pictures to a Smartphone (Tablet)

To upload pictures to a smartphone over a wireless network:

Start the FUJIFILM Photo Receiver app on your smartphone. For informa-

tion on downloading the free FUJIFILM Photo Receiver app, visit:

http://app.fujifilm-dsc.com/

Display a still picture on the camera and tap the

q icons on both the camera and the smartphone (movies can not be selected for upload).

MENU DISP

When the smartphone is detected, the camera will

display a message. Verify the destination on both the camera and smartphone and tap START SENDING.

When upload is complete, the camera will display

CONNECT TO SMARTPHONE

SMARTPHONESEND OK?

FUJIFILM-Z

START SENDING

BACK

CONNECT TO SMARTPHONE

123456

1000-1234

the message “TRANSMISSION COMPLETED”. Tap o or p to view more images and tap the q icons to

SMARTPHONE-

upload additional still pictures, or tap BACK to termi-

BACK

123456

nate the connection.

59More on Playback

q Uploading Pictures to a Smartphone (Tablet)

R Be sure that the battery is charged before beginning upload. Do not remove the

battery, turn the camera o , or remove the memory card until upload is complete.

R If you are unable to upload still pictures, check the smartphone’s settings. R Personal information may be revealed by the titles, dates, GPS data (where appli-

cable), and other information included with pictures. Verify the destination before beginning upload.

R The time needed for upload varies with  le size and the distance to the destination.

At default settings (recommended), ON is selected for qWIRELESS SETTING>

RESIZE IMAGE ON SENDING H (P104) and images are resized to H for upload. R The camera may be unable to upload images created or modi ed on other devices. R The camera can connect to only one smartphone at a time. R Upload may not succeed depending on signal quality. R The camera will end the connection to the smartphone automatically if no opera-

tions are performed for a set period.

60 More on Playback

HH Image Search

Option

Description BY DATE BY FACE BY

FAVORITES BY SCENE BY TYPE OF DATA BY UPLOAD MARK

Image Search

Search for pictures.

Tap the H icon in single-frame view.

Choose from the following options:

Option

BY DATE Search by date. BY FACE Search for faces from the face recognition database. BY II

FAVORITES Search by rating (P 92).

BY SCENE Search by scene. BY TYPE OF DATA Find all still pictures, all movies, or edited pictures. BY UPLOAD MARK

Find all pictures selected for upload to a speci ed destination (P 96).

Description

R Searches can also be performed from the playback menu (P 93).

Select a search condition. Only pictures that match

the search condition will be displayed (tap j or k to view additional search conditions).

MENU DISP

05/ 31/2050

BACK OK

06/ 03/2050

08/ 22/2050

06/ 11/2050

08/ 28/2050

05/ 31/2050

08/ 20/2050

61More on Playback

H Image Search

The large preview to the left of the thumbnails is the current picture. To

view the current picture full frame, tap the preview or tap OK.

05/ 31/2050

BACK OK

06/ 03/2050

08/ 22/2050

06/ 11/2050

08/ 28/2050

05/ 31/2050

08/ 20/2050

DISP

BACK

Tap o or p to scroll through the pictures that match the search conditions or tap I to view them in a slide show (P 93). To delete (P 58) or protect (P 94) the pictures, tap e or D respectively.

To exit, tap OK when the current picture is shown full frame. Tap OK to end

the search.

05/ 31/2050

DISP

BACK

62 More on Playback

EXIT SEARCH

BACK OK

LL PhotoBook Assist

Creating a PhotoBook

PhotoBook Assist

Create books from your favorite photos.

Creating a PhotoBook

Tap the L icon in single-frame view.

R Photobook assist can also be accessed from the

playback menu (P 92).

Tap NEW BOOK.

Tap one of the following to choose pictures for the new book.

• SELECT FROM ALL: Choose from all available pictures.

• SELECT BY IMAGE SEARCH: Choose from pictures matching selected search

conditions (P 61).

R Neither photographs a or smaller nor movies can be selected for photobooks.

Scroll through the images and tap L to select or deselect the current im-

age for inclusion in the book. To display the current image on the cover, tap J.

R The  rst picture selected becomes the cover image. Tap J to select a di erent

picture for the cover.

Tap MENU to exit when the book is complete.

MENU DISP

63More on Playback

L PhotoBook Assist

Viewing Photobooks

Editing and Deleting Photobooks

Photobooks

Tap COMPLETE PHOTOBOOK (to select all photos

or all photos matching the speci ed search conditions for the book, choose SELECT ALL). The new book will be added to the list in the photobook assist

SELECT IMAGES FOR PHOTOBOOK

SELECT ALL

COMPLETE PHOTOBOOK

BACK

menu.

Q Books can contain up to 300 pictures. Q Books that contain no photos are automatically deleted.

Viewing Photobooks

To view a book, tap it in the photobook assist menu and then tap o and p to scroll through the pictures.

Editing and Deleting Photobooks

Display the photobook and tap MENU. The following options will be displayed; select the desired option and follow the on-screen instructions.

• EDIT: Edit the book as described in “Creating a PhotoBook” (P 63).

• ERASE: Delete the book.

Photobooks

Photobooks can be copied to a computer using the supplied MyFinePix Studio software.

64 More on Playback

pp Face Retouch

Option

Description

SMOOTHING

BRIGHTEN

ENLARGE EYES

Face Retouch

To retouch faces in pictures taken with Intelligent Face Detection (pictures marked with g; P 46), tap the p icon in full-frame playback. The options shown at right will be displayed.

If the picture contains multiple faces, tap gTO SELECT FACE and tap the

MENU DISP

desired face.

Tap any of the following options and then tap to choose an amount. Re-

peat this step until you have adjusted all the desired options.

Option

SMOOTHING Soften details.

BRIGHTEN Brighten skin tones.

ENLARGE EYES Make eyes appear larger.

Description

To return to Step 1 and select another face, tap gTO SELECT FACE.

Tap OK.

A con rmation dialog will be displayed; tap OK to save the retouched

copy. To exit without creating a retouched copy, tap BACK.

R Face retouch may not be available with all faces depending on their orientation

and size.

R Unexpected results may occur with faces that are too close together.

65More on Playback

j j Edit

Option

Description ff COLLAGE CC IMAGE ROTATE GG CROP OO RESIZE BB RED EYE REMOVAL

Edit

To rotate pictures, make collages, or create cropped or resized copies of pictures, tap MENU and select cEDIT in the playback menu. Tap m or n to scroll through the menu and tap an option to select it.

Option

COLLAGE Create collages (P 67). IMAGE ROTATE Rotate pictures (P 68). CROP Create cropped copies of pictures (P 68).

RESIZE Create small copies of pictures (P 69).

RED EYE REMOVAL Create copies with reduced red eye (P 69).

R Edit options can also be accessed from the playback menu (P 93).

Description

MENU DISP

66 More on Playback

f fCOLLAGE

COLLAGE

Selecting f COLLAGE displays a selection of collage templates.

Tap the desired template for the collage.

Tap a frame in the template and then tap a picture at

COLLAGE

the right side of the display to place it in the selected frame (you can also select a picture  rst and then tap the target frame). Repeat until the template is  lled.

BACK

If the desired picture is not visible at the right side of the display, tap j or k to view more pictures.

R To rotate or crop an image for display in a collage, tap its

frame in the collage template. Rotation and crop tools will appear at the edges of the display. To rotate the picture, tap n. The picture is rotated 90 ° clockwise each time you tap the icon. Tap k or n to zoom the selected picture in or out and tap m, n, o, or p to position it in the frame. Tap OK when the operation is complete. Note that depending on the template, you may not be able to rotate or crop the image.

Tap OK to complete the collage.

Image size options will be displayed. Tap an option to create a collage at

COLLAGE

BACK OK

the selected size and save it as a new  le.

j Edit

67More on Playback

j Edit

C CIMAGE ROTATE

G GCROP

IMAGE ROTATE

This option rotates pictures for display on the camera. It has no e ect on pictures displayed on a computer or other device.

Tap the left and right arrows (o and p) to select the picture you wish to

rotate.

Tap W to rotate the picture 90 ° clockwise, X to rotate it 90 ° counterclockwise.

Tap OK.

The next time the picture is played back, the rotated one will be displayed.

R The camera may not be able to rotate pictures created with other devices.

CROP

Create cropped copies of pictures.

Tap the left and right arrows (o and p) to select the picture you wish to crop.

Tap k or n to zoom in and out (tap the picture to re-display the zoom

icons as needed) and tap m, n, o, or p to scroll the picture until the desired portion is displayed. Higher zoom ratios produce smaller copies.

Tap OK to save the cropped copy to a separate  le.

68 More on Playback

j Edit

O ORESIZE

B BRED EYE REMOVAL

RESIZE

Create small copies of pictures.

Tap the left and right arrows (o and p) to select the picture you wish to resize.

Tap an icon to copy the picture at the selected size. The sizes available vary

with the size of the original image.

RED EYE REMOVAL

This option is used with pictures taken using Intelligent Face Detection to create copies that have been processed to remove red eye.

Tap the left and right arrows (o and p) to select a picture.

Tap OK to create a copy with reduced red-eye.

R Red eye may not be removed if the camera is unable to detect a face or the face is

in pro le. Results may di er depending on the scene. Red eye can not be removed from pictures that have already been processed using red-eye removal.

R The amount of time needed to process the image varies with the number of faces

detected.

R Copies created with B RED EYE REMOVAL are indicated by a e icon during playback.

69More on Playback

Viewing Panoramas

100-0001

Operation

Description

End playback

Pause playback

Viewing Panoramas

To view a panorama, display in single-frame view and tap .

100-0001

MENU DISP

Horizontal panoramas are displayed from left to right, vertical panoramas from bottom to top. The following operations can be performed during playback:

Operation

End playback

Pause playback

Tap z to end playback. Tap y to pause playback. Tap x to resume.

R Panoramas can be zoomed in and out using gestures in single-frame playback

(P 54).

R z panoramas play back in an endless loop (P36); the playback direction can be

controlled by tapping o or p (or m or n in the case of vertical panoramas). The camera will not turn o automatically while playback is in progress (P101).

Description

70 More on Playback

Movies

Recording Movies

Taking Photographs During Recording

Movies

Recording Movies

Press F to shoot a movie. During recording, y REC and the time remaining will be displayed and sound will be recorded via the built-in microphone (be careful not to cover the microphone during recording).

y REC icon

Time remaining

999m59s

REC

Number of photos that can

be taken during recording

To end recording, press the F button again. Recording ends automatically when the movie reaches maximum length or memory is full.

R Zoom can be adjusted while recording is in progress. R Focus, exposure, and white balance are adjusted automatically throughout record-

ing. The color and brightness of the image may vary from that displayed before recording begins.

R Sounds made by the camera may be recorded.

Taking Photographs During Recording

Press the shutter button to take a photograph during recording.

R See page 103 for information on choosing how photographs are recorded. R The photo is saved separately from the movie and does not appear as part of the movie. Q Photos can not be taken while a high-speed movie is being recorded. Q The number of photos that can be taken is limited.

Recording Movies

Movie Frame Size

Option

Description

Q The indicator lamp lights while movies are being recorded. Do not open the bat-

tery chamber during shooting or while the indicator lamp is lit. Failure to observe this precaution could prevent the movie from being played back.

Q Vertical or horizontal streaks may appear in movies containing very bright subjects.

This is normal and does not indicate a malfunction.

Q The temperature of the camera may rise if it is used to record movies for an ex-

tended period or if the ambient temperature is high. This is normal and does not indicate a malfunction.

Movie Frame Size

Before recording, select a frame size using the WMOVIE MODE option in the shooting menu (P 88).

Option

i 1920 (1920 × 1080) Full HD (High De nition). h 1280

(1280 × 720)

f ( 640 × 480) Standard de nition. k 640 × 480 (80 fps)

k 320 × 240 (160 fps)

k 320 × 112 (320 fps)

High De nition.

High speed movie. Sound is not recorded, and focus, exposure, and white balance are not adjusted automatically. Black bands appear at the top and bottom of movies recorded at

Description

k 320 × 112.

72 Movies

Viewing Movies

Operation

Description

End playback

Pause playback

Adjust speed

100-0011

Playback Speed

Viewing Movies

During playback, movies are displayed as shown at right. Tap to begin playback. The following operations can be performed:

Operation

End playback

Pause playback

Adjust speed

Playback Speed

Tap z to end playback. Tap y to pause playback. Tap x to resume. Tap Q or R to adjust playback speed.

Tap Q or R to adjust playback speed. Speed is shown by the number of arrows (M or N).

Q Do not cover the speaker during playback.

Description

W mode icon

100-0011

MENU DISP

Arrow

346m42s

73Movies

Connections

Connecting the Camera to High De nition (HD) TVs

Connections

Connecting the Camera to High De nition (HD) TVs

An HDMI cable (available from third-party suppliers) can be used to connect the camera to High De nition (HD) devices (playback only). The USB cable can not be used while an HDMI cable is connected.

Turn the camera o and connect the HDMI cable as shown below.

HDMI mini connector

Insert into HDMI

Insert into HDMI connector

R Image quality may drop during movie playback.

Tune the television to the HDMI input channel. See the documentation

supplied with the television for details.

connector

Connecting the Camera to High De nition (HD) TVs

Press the a button for about a second to turn the camera on. Only the

button icons appear in the camera display; pictures and movies are played back on the TV. Note that the camera volume controls have no e ect on sounds played on the TV; use the television volume controls to adjust the volume.

While the camera is connected, pictures can be deleted (P 58) and rotated (P 68). You can also view pictures in playback zoom (P 54), muti-frame playback (P 56), slide show (P 93) and photobook (P 63).

75Connections

Printing Pictures via USB

If the printer supports PictBridge, the camera can be connected directly to the printer as shown below and pictures can be printed without  rst being copied to a computer. Note that depending on the printer, not all the functions described below may be supported.

Connect the supplied USB cable as shown and turn the printer on.

Turn the camera on.

Tap o or p to select a picture you wish to print.

Tap + or – to choose the number of copies (up to 99).

Repeat steps 3–4 to select additional pictures. Tap PRINT to display a con-

 rmation dialog when settings are complete.

76 Connections

Printing Pictures via USB

Printing the Date of Recording

Tap OK to start printing. Printing can be interrupted by tapping CANCEL,

but note that some printers may not respond immediately. If the printer stops before printing is complete, turn the camera o and then on again.

After con rming that PRINTING has cleared from the camera display, turn

the camera o and disconnect the USB csable.

R Pictures can be printed from internal memory or a memory card that has been

formatted in the camera.

R If no pictures are selected, the camera will print one copy of the current picture. R Page size, print quality, and border selections are made using the printer.

Printing the Date of Recording

To print the date of recording on pictures, tap MENU in the PictBridge display and select PRINT WITH DATE s (to print pictures without the date of recording, select PRINT WITHOUT DATE). Some printers do not support date printing. See the printer manual for details.

77Connections

Viewing Pictures on a Computer

Windows: Installing MyFinePix Studio

Windows 7 (SP 1)/Windows Vista (SP 2)

Windows XP (SP 3)

CPU

3 GHz Pentium 4 or better

(2.4

GHz Core 2 Duo or better)

2 GHz Pentium 4 or better

(2.4

GHz Core 2 Duo or better)

RAM

1 GB or more

512 MB or more

GB or more)

Free disk space

2 GB or more

GPU

Supports DirectX 9 or later

((recommended

Supports DirectX 7 or later

((required; performance not guaranteed with other GPUs

Video

Other

Viewing Pictures on a Computer

The supplied software can be used to copy pictures to a computer, where they can be stored, viewed, organized, and printed. Before proceeding, install the software as described below. Do NOT connect the camera to the computer until installation is complete.

Windows: Installing MyFinePix Studio

Con rm that the computer meets the following system requirements:

Windows 7 (SP 1)/Windows Vista (SP 2)

CPU

RAM

Free disk space

GPU

Video 1,024 × 768 pixels or more with 24-bit color or better

Other

1 Other versions of Windows are not supported. Only pre-installed operating systems are

supported; operation is not guaranteed on home-built computers or computers that have been upgraded from earlier versions of Windows.

2 Recommended when displaying HD movies.

3 GHz Pentium 4 or better

(2.4

GHz Core 2 Duo or better)

1 GB or more

Supports DirectX 9 or later

recommended))

• Built-in USB port recommended. Operation is not guaranteed with other USB ports.

• .NET Framework 3.5 Service Pack 1 required when uploading images or using Map Viewer.

• Internet connection (broadband recommended) required to install .NETFramework (if necessary), to use auto update feature, and when performing such tasks as sharing pictures on-line or via e-mail.

2 GB or more

required; performance not guaranteed with other GPUs))

Windows XP (SP 3)

2 GHz Pentium 4 or better

(2.4

GHz Core 2 Duo or better)

512 MB or more

GB or more)

Supports DirectX 7 or later

78 Connections

Viewing Pictures on a Computer

Windows 7/Windows Vista

If the Installer Does Not Start Automatically

Start the computer. Log in to an account with administrator privileges

before proceeding.

Exit any applications that may be running and insert the installer CD in a

CD-ROM drive.

Windows 7/Windows Vista

If an AutoPlay dialog is displayed, click SETUP.EXE. A “User Account Control” dialog will then be displayed; click Ye s ( Windows7) or Allow (Windows Vista).

The installer will start automatically; click Install MyFinePix Studio and follow the on-screen instructions to install MyFinePix Studio.

If the Installer Does Not Start Automatically

If the installer does not start automatically, select Computer or My Computer from the Start menu, then double-click the FINEPIX CD icon to open the FINEPIX CD window and double-click setup or SETUP.EXE.

If prompted to install Windows Media Player or DirectX, follow the on-

screen instructions to complete installation.

Remove the installer CD from the CD-ROM drive when installation is com-

plete. Store the installer CD in a dry location out of direct sunlight in case you need to re-install the software.

Installation is now complete. Proceed to “Connecting the Camera” (P 82).

79Connections

Viewing Pictures on a Computer

Macintosh: Installing FinePixViewer

CPU

RAM

Free disk space

Video

Other

Macintosh: Installing FinePixViewer

Con rm that the computer meets the following system requirements:

CPU PowerPC or Intel (Core 2 Duo or better)

Pre-installed copies of Mac OS X version 10.3.9–10.6 (visit http://www.fujifilm.

com/support/digital_cameras/compatibility/ for more information). Mac OS X version 10.7 and later not supported.

RAM 256 MB or more (1 GB or more)

Free disk space

Video 800 × 600 pixels or more with thousands of colors or better

Other

* Recommended when displaying HD movies.

After starting the computer and quitting any applications that may be run-

A minimum of 200 MB required for installation with 400 MB available when FinePixViewer is running

Built-in USB port recommended. Operation is not guaranteed with other USB ports.

ning, insert the installer CD in a CD-ROM drive and double-click Installer for Mac OS X.

An installer dialog will be displayed; click Installing FinePixViewer to start

installation. Enter an administrator name and password when prompted and click OK, then follow the on-screen instructions to install FinePixViewer. Click Exit to quit the installer when installation is complete.

80 Connections

Viewing Pictures on a Computer

Remove the installer CD from the CD-ROM drive. Note that you may be

unable to remove the CD if Safari is running; if necessary, quit Safari before removing the CD. Store the installer CD in a dry location out of direct sunlight in case you need to re-install the software.

Mac OS X 10.5 or earlier:

and select Preferences… from the Image Capture application menu. The Image Capture preferences dialog will be displayed; choose Other… in the When a camera is connected, open menu, then select FPVBridge in the “Applications/FinePixViewer” folder and click Open. Quit Image Capture.

Mac OS X 10.6: Connect the camera and turn it on. Open the “Applications” folder and start Image Capture. The camera will be listed under DEVICES; select the camera and choose FPVBridge from the Connecting this cam- era opens menu and click Choose. Quit Image Capture.

Installation is now complete. Proceed to “Connecting the Camera” (P 82).

Open the “Applications” folder, start Image Capture,

81Connections

Viewing Pictures on a Computer

Connecting the Camera

If the pictures you wish to copy are stored on a memory card, insert the

card into the camera.

R Windows users may require the Windows CD when starting the software for

the  rst time.

Q Loss of power during transfer could result in loss of data or damage to internal

memory or the memory card. Charge the battery before connecting the camera.

Turn the camera o and connect the

supplied USB cable as shown, making sure the connectors are fully inserted. Connect the camera directly to the computer; do not use a USB hub or keyboard.

Press the a button for about a second to turn the camera on. MyFinePix

Studio or FinePixViewer will start automatically; follow the on-screen instructions to copy pictures to the computer. To exit without copying pictures, click Cancel.

82 Connections

Viewing Pictures on a Computer

For more information on using the supplied software, start the application and select the appropriate option from the Help menu.

Q If a memory card containing a large number of images is inserted, there may be a

delay before the software starts and you may be unable to import or save images. Use a memory card reader to transfer pictures.

Q Make sure that the computer does not display a message stating that copying is in

progress and that the indicator lamp is out before turning the camera o or disconnecting the USB cable (if the number of images copied is very large, the indicator lamp may remain lit after the message has cleared from the computer display). Failure to observe this precaution could result in loss of data or damage to internal memory or the memory card.

Q Disconnect the camera before inserting or removing memory cards. Q In some cases, it may not be possible to access pictures saved to a network server

using the supplied software in the same way as on a standalone computer.

Q The user bears all applicable fees charged by the phone company or Internet ser-

vice provider when using services that require an Internet connection.

83Connections

Viewing Pictures on a Computer

Disconnecting the Camera

Uninstalling the Supplied Software

Disconnecting the Camera

After con rming that the indicator lamp is out, turn the camera o and disconnect the USB cable.

Uninstalling the Supplied Software

Only uninstall the supplied software when it is no longer required or before beginning reinstallation. After quitting the software and disconnecting the camera, drag the “FinePixViewer” folder from “Applications” into the Trash and select Empty Trash in the Finder menu (Macintosh), or open the control panel and use “Programs and Features” (Windows7/Windows Vista) or “Add or Remove Programs” (WindowsXP) to uninstall MyFinePix Studio. Under Windows, one or more con rmation dialogs may be displayed; read the contents carefully before clicking OK.

84 Connections

Menus

Using the Menus: Shooting Mode

Using the Shooting Menu

Menus

Using the Menus: Shooting Mode

Use the shooting menu to adjust shooting settings. The options available vary with the shooting mode selected.

Using the Shooting Menu

To view the shooting menu, tap the MENU icon

when the camera is in shooting mode.

Tap the icon for the desired menu item.

Tap the desired option.

MENU DISP

Using the Menus: Shooting Mode

Shooting Menu Options

d dEXP. COMPENSATION

((defaults to

N NISO

((defaults to

AUTO)

100

ISO

6400

Bright

Scene

Dark

Less noticeable

Noise (mottling)

More noticeable

Option

Description

AUTO

AUTO (3200) / AUTO (1600) / AUTO(800) / AUTO(400)

6400 / 3200 / 1600 / 800 / 400 / 200 / 100

Shooting Menu Options

defaults to

6400

Dark

defaults to 0)0)

AUTO)

EXP. COMPENSATION

100

Bright

Option

P 40).

ISO

Scene

Noise (mottling)

Description

As above, except that sensitivity will not be raised above the value in parentheses.

Sensitivity is set to the speci ed value, which is shown in the display.

More noticeable

Adjust exposure (

ISO

Control the camera’s sensitivity to light. Higher values can reduce blur; note, however, that mottling may appear in pictures taken at high sensitivities.

Less noticeable

AUTO Sensitivity is adjusted automatically in response to shooting conditions.

AUTO (3200) / AUTO (1600) / AUTO(800) / AUTO(400)

6400 / 3200 / 1600 / 800 / 400 / 200 / 100

86 Menus
