FujiFilm XP20, 16124937 User Manual

BL01299-201

DIGITAL CAMERA

FINEPIX XP20 Series

Owner’s Manual

Thank you for your purchase of this product. This manual describes how to use your FUJIFILM digital camera and the supplied software. Be sure that you have read and understood its contents and the warnings in “For Your Safety” (P ii) before using the camera.

For information on related products, visit our website at

http://www.fujifilm.com/products/digital_cameras/index.html

Before You Begin

First Steps

Basic Photography and Playback

More on Playback

Movies

Connections

Menus

Technical Notes

Troubleshooting

Appendix

For Your Safety

Installation

For Your Safety

IMPORTANT SAFETY INSTRUCTIONS

• Read Instructions: All the safety and operating instructions should be read before the appliance is operated.

• Retain Instructions: The safety and operating instructions should be retained for future reference.

• Heed Warnings: All warnings on the appliance and in the operating instructions should be adhered to.

• Follow Instructions: All operating and use instructions should be followed.

Installation

Power Sources: This video product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For video products intended to operate from battery power, or other sources, refer to the operating instructions.

Grounding or Polarization: This video product is equipped with a polarized alternatingcurrent line plug (a plug having one blade wider than the other). This plug will ﬁ t into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to ﬁ t, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

Alternate Warnings: This video product is equipped with a three-wire grounding-type plug, a plug having a third (grounding) pin. This plug will only ﬁ t into a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding type plug.

Overloading: Do not overload wall outlets and extension cords as this can result in a risk of ﬁ re or electric shock.

Ventilation: Slots and openings in the cabinet are provided for ventilation, to ensure reliable operation of the video product and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the video product on a bed, sofa, rug, or other similar surface.

This video product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to. This video product should never be placed near or over a radiator or heat register.

Attachments: Do not use attachments not recommended by the video product manufacturer as they may cause hazards.

Water and Moisture: product near water—for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like (excluding waterproof products).

Do not use this video

Power-Cord Protection: Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

Accessories: Do not place this video product on an unstable cart, stand, tripod, bracket, or table. The video product may fall, causing serious injury to a child or adult, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the video product. Any mounting of the appliance should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

Antennas

Use

Service

Antennas

Outdoor Antenna Grounding: If an outside antenna or cable system is connected to the video product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and builtup static charges. Section 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECTRICAL CODE

Ground Clamp

Electric Service

Equipment

Ground Clamps

Power Service Grounding Electrode System (NEC ART

250. PART H)

Power Lines: An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

Antenna Lead in Wire

Antenna Discharge Unit (NEC SECTION 810-20)

Grounding

Conductors

(NEC SECTION

810-21)

Use

Cleaning: Unplug this video product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

Object and Liquid Entry: Never push objects of any kind into this video product through openings as they may touch dangerous voltage points or short out parts that could result in a ﬁ re or electric shock. Never spill liquid of any kind on the video product (excluding waterproof products).

For added protection for this video

Lightning: product receiver during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the video product due to lightning and power-line surges.

Service

Servicing: Do not attempt to service this video product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualiﬁ ed service personnel.

Damage Requiring Service: Unplug this video product from the wall outlet and refer servicing to qualiﬁ ed service personnel under the following conditions:

• When the power-supply cord or plug is damaged.

• If liquid has been spilled, or objects have fallen into the video product.

• If the video product has been exposed to rain or water (excluding waterproof products).

• If the video product has been dropped or the cabinet has been damaged.

For Your Safety

If the video product does not operate normally follow the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualiﬁ ed technician to restore the video product to its normal operation.

When the video product exhibits a distinct change in performance—this indicates a need for service.

Replacement Parts: When replacement parts are required, be sure the service technician has used replacement parts speciﬁ ed by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in ﬁ re, electric shock or other hazards.

Safety Check: Upon completion of any service or repairs to this video product, ask the service technician to perform safety checks to determine that the video product is in proper operating condition.

iii

For Your Safety

WARNING

Be sure to read these notes before use

Safety Notes

• Make sure that you use your camera correctly. Read these safety

notes and your Owner’s Manual carefully before use.

• After reading these safety notes, store them in a safe place.

About the Icons

The icons shown below are used in this document to indicate the severity of the injury or damage that can result if the information indicated by the icon is ignored and the product is used incorrectly as a result.

This icon indicates that death or serious injury can result if the information is ignored.

WARNING

This icon indicates that personal injury or material damage can result if the information is ignored.

CAUTION

The icons shown below are used to indicate the nature of the instructions which are to be observed.

Triangular icons tell you that this information requires attention (“Important”).

Circular icons with a diagonal bar tell you that the action indicated is prohibited (“Prohibited”).

Filled circles with an exclamation mark indicate an action that must be performed (“Required”).

If a problem arises, turn the camera o , remove the battery, and disconnect and unplug the AC power adapter. Continued use of

the camera when it is emitting smoke, is emitting any unusual

Unplug from

odor, or is in any other abnormal state can cause a ﬁ re or elec-

power socket

tric shock. Contact your FUJIFILM dealer. Do not allow water or foreign objects to enter the camera. If water

or foreign objects get inside the camera, turn the camera oﬀ , remove the battery, and disconnect and unplug the AC power adapter. Continued use of the camera can cause a ﬁ re or electric shock. Contact your FUJIFILM dealer.

WARNING

Do not use the camera in the bathroom or shower (excluding water-

Do not use in

proof products). This can cause a ﬁ re or electric shock.

the bathroom or

shower

Never attempt to change or take apart the camera (never open the case). Failure to observe this precaution can cause ﬁ re or

Do not

electric shock.

disassemble

Should the case break open as the result of a fall or other accident, do not touch the exposed parts. Failure to observe this precau-

tion could result in electric shock or in injury from touching the damaged parts. Remove the battery immediately, taking care

Do not touch

to avoid injury or electric shock, and take the product to the

internal parts

point of purchase for consultation.

Do not change, heat or unduly twist or pull the connection cord and do not place heavy objects on the connection cord. These actions

could damage the cord and cause a ﬁ re or electric shock . If the cord is damaged, contact your FUJIFILM dealer.

Do not place the camera on an unstable surface. This can cause the camera to fall or tip over and cause injury.

Never attempt to take pictures while in motion. Do not use the camera while you are walking or driving a vehicle. This can result in you falling down or being involved in a traﬃ c accident.

Do not touch any metal parts of the camera during a thunderstorm. This can cause an electric shock due to induced current from the lightning discharge.

Do not use the battery except as speci ed. Load the battery as shown by the indicator.

Do not heat, change or take apart the battery. Do not drop or subject the battery to impacts. Do not store the battery with metallic products. Any of these actions can cause the battery to burst or leak

and cause ﬁ re or injury as a result.

Use only the battery or AC power adapters speci ed for use with this camera. Do not use voltages other than the power supply voltage shown. The use of other power sources can cause a ﬁ re.

If the battery leaks and  uid gets in contact with your eyes, skin or clothing,  ush the a ected area with clean water and seek medical attention or call an emergency number right away.

WARNING

CAUTION

Do not use the charger to charge batteries other than those speci ed here. The supplied battery charger is for use only with the

type of battery supplied with the camera. Using the charger to charge conventional batteries or other types of rechargeable batteries can cause the battery to leak ﬂ uid, overheat or burst.

When carrying the battery, install it in a digital camera or keep it in the hard case. When storing the battery, keep it in the hard case. When discarding, cover the battery terminals with insulation tape.

Contact with other metallic objects or batteries could cause the battery to ignite or burst.

Keep memory cards out of the reach of small children. Because memory cards are small, they can be swallowed by children. Be sure to store memory cards out of the reach of small children. If a child swallows a memory card, seek medical attention or call an emergency number.

Do not use this camera in locations a ected by oil fumes or steams. This can cause a ﬁ re or electric shock.

Do not use this camera in locations a ected by humidity or dust (excluding waterproof products). This can cause a ﬁ re or elec-

tric shock.

Do not leave this camera in places subject to extremely high temperatures. Do not leave the camera in locations such as a sealed

vehicle or in direct sunlight. This can cause a ﬁ re.

Keep out of the reach of small children. This product could cause injury in the hands of a child.

Do not place heavy objects on the camera. This can cause the heavy object to tip over or fall and cause injury.

Do not move the camera while the AC power adapter is still connected. Do not pull on the connection cord to disconnect the AC power adapter. This can damage the power cord or cables and cause

a ﬁ re or electric shock.

Do not use the AC power adapter when the plug is damaged or the plug socket connection is loose. This could cause a ﬁ re or electric

shock.

WARNING

CAUTION

For Your Safety

Do not cover or wrap the camera or the AC power adapter in a cloth or blanket. This can cause heat to build up and distort the cas-

ing or cause a ﬁ re.

When you are cleaning the camera or you do not plan to use the camera for an extended period, remove the battery and disconnect and unplug the AC power adapter. Failure to do so can cause a

ﬁ re or electric shock.

When charging ends, unplug the charger from the power socket. Leaving the charger plugged into the power socket can cause

Unplug from

a ﬁ re.

power socket

Using a  ash too close to a person’s eyes may temporarily a ect the eyesight. Take particular care when photographing infants and

young children.

When a memory card is removed, the card could come out of the slot too quickly. Use your  nger to hold it and gently release the card.

Injury could result to those struck by the ejected card. Request regular internal testing and cleaning for your camera.

Build-up of dust in your camera can cause a ﬁ re or electric shock. Contact your FUJIFILM dealer to request internal cleaning every two years. Please note that this service is not free of charge.

CAUTION

For Your Safety

Li-ion Batteries

AA Alkaline/Rechargeable NiMH Batteries

The Battery and Power Supply

Note: Check the type of battery used in your camera and read the appropriate sections.

The following describes the proper use of batteries and how to prolong their life. Incorrect use can shorten battery life or cause leakage, overheating, ﬁ re, or explosion.

Li-ion Batteries

Read this section if your camera uses a rechargeable Li-ion battery.

The battery is not charged at shipment. Charge the battery before use. Keep the battery in its case when not in use.

■ Notes on the Battery

The battery gradually loses its charge when not in use. Charge the battery one or two days before use.

Battery life can be extended by turning the camera oﬀ when not in use.

Battery capacity decreases at low temperatures; a depleted battery may not function at when cold. Keep a fully charged spare battery in a warm place and exchange as necessary, or keep the battery in your pocket or other warm place and insert it in the camera only when shooting. Do not place the battery in direct contact with hand warmers or other heating devices.

■ Charging the Battery

Charge the battery in the supplied battery charger. Charging times will increase at ambient temperatures below +10 °C (+50 °F) or above +35 °C (+95 °F). Do not attempt to charge the battery at temperatures above 40 °C (+104 °F); at temperatures below 0 °C (+32 °F), the battery will not charge.

Do not attempt to recharge a fully charged battery. The battery does not however need to be fully discharged before charging.

The battery may be warm to the touch immediately after charging or use. This is normal.

■ Battery Life

At normal temperatures, the battery can be recharged about 300 times. A noticeable decrease in the length of time the battery will hold a charge indicates that it has reached the end of its service life and should be replaced.

■ Storage

Performance may be impaired if the battery is left unused for extended periods when fully charged. Run the battery ﬂ at before storing it.

If the camera will not be used for an extended period, remove the battery and store it in a dry place with an ambient temperature of from +15 °C to +25 °C (+59 °F to +77 °F). Do not store in locations exposed to extremes of temperature.

■ Cautions: Handling the Battery

• Do not transport or store with metal objects such as necklaces or hairpins.

• Do not expose to ﬂ ame or heat.

• Do not disassemble or modify.

• Use with designated chargers only.

• Do not drop or subject to strong physical shocks.

• Do not expose to water.

• Keep the terminals clean.

• The battery and camera body may become warm to the touch after extended use. This is normal.

AA Alkaline/Rechargeable NiMH Batteries

Read this section if your camera uses AA alkaline or rechargeable AA NiMH batteries. Information on compatible battery

types may be found elsewhere in the camera manual.

■ Cautions: Handling the Batteries

• Do not expose to water, ﬂ ame, or heat, or store in warm or humid conditions.

• Do not transport or store with metal objects such as necklaces or hairpins.

• Do not disassemble or modify the batteries or battery casing.

• Do not subject to strong physical shocks.

• Do not use batteries that are leaking, deformed, or discolored.

• Keep out of reach of infants and small children.

• Insert in the correct orientation.

• Do not mix old and new batteries, batteries

AC Power Adapters (Available Separately)

with diﬀ erent charge levels, or batteries of diﬀ erent types.

• If the camera will not be used for an extended period, remove the batteries. Note that the camera clock will be reset.

• The batteries may be warm to the touch immediately after use. Turn the camera oﬀ and allow the batteries to cool before handling.

• Battery capacity tends to decrease at low temperatures. Keep spare batteries in a pocket or other warm place and exchange as necessary. Cold batteries may recover some of their charge when warmed.

• Fingerprints and other stains on the battery terminals can impair battery performance. Thoroughly clean the terminals with a soft, dry cloth before inserting them in the camera.

If the batteries leak, clean the battery compartment thoroughly before inserting new batteries.

If ﬂ uid from the battery comes into contact with skin or clothing, ﬂ ush the aﬀ ected area with water. If  uid

enters your eyes, immediately  ush the a ected area with water and seek medical attention. Do not rub your eyes. Failure to observe this precaution could result in permanent visual impairment.

■ NiMH Batteries

The capacity of Ni-MH batteries may be temporarily reduced when new, after long periods of disuse, or if they are repeatedly recharged before being fully discharged. This is normal and does not indicate a malfunction. Capacity can be increased by repeatedly discharging the batteries using the discharge option in the camera setup menu and recharging them using a battery charger.

Q C AUTION: Do not use the discharge option

with alkaline batteries.

The camera draws a small amount of current even when oﬀ . Ni-MH batteries that have been left in the camera for an extended period may be drawn down to the point that they no longer hold a charge. Battery performance may also drop if the batteries are run down in a device such as a ﬂ ashlight. Use the discharge option in the camera setup menu to discharge Ni-MH batteries. Batteries that no longer hold a charge even after repeatedly being discharged and recharged have reached the end of their service life and must be replaced.

Ni-MH batteries can be recharged in a battery charger (sold separately). Batteries may become warm to the touch after charging. Refer to the instructions provided with the charger for more information. Use the charger with compatible batteries only.

Ni-MH batteries gradually lose their charge when not in use.

■ Disposal

Dispose of used batteries in accord with local regulations.

For Your Safety

AC Power Adapters (Available Separately)

This section applies to all camera models. Use only FUJIFILM AC power adapters designated for use with this camera. Other adapters could damage the camera.

• The AC power adapter is for indoor use only.

• Be sure the DC plug is securely connected to the camera.

• Turn the camera oﬀ before disconnecting the adapter. Disconnect the adapter by the plug, not the cable.

• Do not use with other devices.

• Do not disassemble.

• Do not expose to high heat and humidity.

• Do not subject to strong physical shocks.

• The adapter may hum or become hot to the touch during use. This is normal.

• If the adapter causes radio interference, reorient or relocate the receiving antenna.

vii

For Your Safety

Take Test Shots

Notes on Copyright

Handling

Liquid Crystal

Trademark Information

Electrical Interference

Color Television Systems

Exif Print (Exif Version 2.3)

Take Test Shots

Notes on Copyright

Handling

Using the Camera

Do not aim the camera at extremely bright light sources, such as the sun in a cloudless sky. Failure to observe this precaution could damage the camera image sensor.

Before taking photographs on important occasions (such as at weddings or before taking the camera on a trip), take a test shot and view the result in the LCD monitor to ensure that the camera is functioning normally. FUJIFILM Corporation can not accept liability for damages or lost proﬁ ts incurred as a result of product malfunction.

Unless intended solely for personal use, images recorded using your digital camera system cannot be used in ways that infringe copyright laws without the consent of the owner. Note that some restrictions apply to the photographing of stage performances, entertainments, and exhibits, even when intended purely for personal use. Users are also asked to note that the transfer of memory cards containing images or data protected under copyright laws is only permissible within the restrictions imposed by those copyright laws.

To ensure that images are recorded correctly, do not subject the camera to impact or physical shocks while images are being recorded.

viii

Liquid Crystal

In the event that the LCD monitor is damaged, care should be taken to avoid contact with liquid crystal. Take the urgent action indicated should any of the following situations arise:

• If liquid crystal comes in contact with your skin, clean the area with a cloth and then wash thoroughly with soap and running water.

• If liquid crystal enters your eyes, ﬂ ush the affected eye with clean water for at least 15 minutes and then seek medical assistance.

• If liquid crystal is swallowed, rinse your mouth thoroughly with water. Drink large quantities of water and induce vomiting, then seek medical assistance.

Although the display is manufactured using extremely high-precision technology, it may contain pixels that are always lit or that do not light. This is not a malfunction, and images recorded with the product are unaﬀ ected.

Trademark Information

xD-Picture Card and E are trademarks of FUJIFILM Corporation. The typefaces included herein are solely developed by DynaComware Taiwan Inc. Macintosh, QuickTime, and Mac OS are trademarks of Apple Inc. in the U.S.A. and other countries. Windows7, Windows Vista, and the Windows logo are trademarks of the Microsoft group of companies. Adobe and Adobe Reader are either trademarks or registered trademarks of Adobe Systems Incorporated in the U.S.A. and/ or other countries. The SDHC and SDXC logos are trademarks of SD-3C, LLC. The HDMI logo is a trademark. YouTube is a trademark of Google Inc. All other trade names mentioned in this manual are the trademarks or registered trademarks of their respective owners.

Electrical Interference

This camera may interfere with hospital or aviation equipment. Consult with hospital or airline staﬀ before using the camera in a hospital or on an aircraft.

Color Television Systems

NTSC (National Television System Committee) is a color television telecasting speciﬁ cation adopted mainly in the U.S.A., Canada, and Japan. PAL (Phases Alternation by Line) is a color television system adopted mainly in European countries and China.

Exif Print (Exif Version 2.3)

Exif Print is a newly revised digital camera ﬁ le format in which information stored with photographs is used for optimal color reproduction during printing.

IMPORTANT NOTICE:

Read Before Using the Software

Direct or indirect export, in whole or in part, of licensed software without the permission of the applicable governing bodies is prohibited.

About This Manual

Table of Contents

...........................

xiii

Troubleshooting

............................

Warning Messages and Displays

.....

Memory Cards

About This Manual

Before using the camera, read this manual and the warnings in “For Your Safety” (P ii). For information on speci c topics, consult the sources below.

Table of Contents

The “Table of Contents” gives an overview of the entire manual. The

...........................PP

xiii

Troubleshooting

............................PP

Having a speci c problem with the camera? Find the answer here.

principal camera operations are listed here.

Warning Messages and Displays

.....PP

Find out what’s behind that  ashing icon or error message in the display.

Memory Cards

Pictures can be stored in the camera’s internal memory or on optional SD, SDHC, and SDXC memory cards (P 14), referred to in this manual as “memory cards.”

Frequently-Used Buttons

■■ Deleting Pictures

■■Taking Pictures During Playback

■■ Silent Mode

■■Turning the Camera on in Playback Mode

Frequently-Used Buttons

Deleting Pictures

y Press the selector up (b) to display

deletion options.

Taking Pictures During Playback

y To return instantly to shooting mode,

press the shutter button halfway.

Turning the Camera on in Playback Mode

y When the camera is

o , playback can be started by pressing the a button for about a second.

View

Silent Mode y Press and hold the DISP/

BACK button to disable

camera lights and sounds.

Shoot

Product Features and Precautions for Use

■■Water, Dust, and Shock Resistance

QQThe camera complies with JIS Class 8 water resistance and JIS Class 6 (IP68) dust resistance

standards, and has passed FUJIFILM drop tests (drop height: 1.5m/4.9ft.; impact surface: plywood, thickness 5cm/2.0in.) compliant with MIL-STD 810F Method 516.5: Shock. These results were obtained through in-house testing and are not a blanket guarantee of water resistance or invulnerability to damage or destruction. The accessories supplied with the camera are not water resistant.

■■Before Use

QQThe front surface of the camera lens is protected by a sheet of glass. Foreign matter on the

glass will appear in photographs; keep the glass clean at all times.

QQBe sure that the battery-chamber and connector covers are fully latched. The presence of wa-

ter, mud, or sand in the camera could cause malfunction.

QQDo not open or close the battery-chamber or connector cover with wet hands or near water,

for example while on or by a body of water.

QQBe sure the camera is completely dry before inserting or removing batteries or memory cards

or connecting the USB or A/V cable.

QQThe camera does not  oat. Be sure to attach the strap and keep it around your wrist when

using the camera.

■■During Use

QQRestrict underwater use to depths of 5 m (16ft.) or less and periods shorter than 120 minutes. QQDo not open or close the battery-chamber cover while under water. QQDo not use in hot springs or heated pools. QQDo not dive into water with the camera or otherwise subject it to excessive force. QQIf the camera is left on the sand, its temperature may exceed operating limits and sand may

get into the speaker or microphone.

QQSunscreen, suntan lotion, or other oily substances may discolor the camera body and should

be removed with a damp cloth.

QQThe camera may lose water resistance if subjected to excessive force or vibration. Consult your

retailer or a FUJIFILM-authorized repair technician.

Product Features and Precautions for Use

Water, Dust, and Shock Resistance

The camera complies with JIS Class 8 water resistance and JIS Class 6 (IP68) dust resistance standards, and has passed FUJIFILM drop tests (drop height: 1.5m/4.9ft.; impact surface: plywood, thickness 5cm/2.0in.) compliant with MIL-STD 810F Method 516.5: Shock. These results were obtained through in-house testing and are not a blanket guarantee of water resistance or invulnerability to damage or destruction. The accessories supplied with the camera are not water resistant.

Before Use

The front surface of the camera lens is protected by a sheet of glass. Foreign matter on the glass will appear in photographs; keep the glass clean at all times. Be sure that the battery-chamber and connector covers are fully latched. The presence of water, mud, or sand in the camera could cause malfunction. Do not open or close the battery-chamber or connector cover with wet hands or near water, for example while on or by a body of water. Be sure the camera is completely dry before inserting or removing batteries or memory cards or connecting the USB or A/V cable. The camera does not  oat. Be sure to attach the strap and keep it around your wrist when using the camera.

During Use

Restrict underwater use to depths of 5 m (16ft.) or less and periods shorter than 120 minutes. Do not open or close the battery-chamber cover while under water. Do not use in hot springs or heated pools. Do not dive into water with the camera or otherwise subject it to excessive force. If the camera is left on the sand, its temperature may exceed operating limits and sand may get into the speaker or microphone. Sunscreen, suntan lotion, or other oily substances may discolor the camera body and should be removed with a damp cloth. The camera may lose water resistance if subjected to excessive force or vibration. Consult your retailer or a FUJIFILM-authorized repair technician.

Product Features and Precautions for Use

■■After Use

QQRemove any foreign matter from the water-resistant seal and adjacent surfaces. Foreign mat-

ter could damage the seal, lowering water resistance.

QQAfter using the camera underwater or in locations where foreign matter might adhere to the

camera body, rinse the camera under the tap or leave it in a basin of fresh water for two to three minutes.

QQLiquid soaps, detergents, alcohol, and other cleansers may a ect water resistance and should

never be used.

QQAfter use, remove water droplets and foreign matter with a dry cloth,  rmly latch the battery-

chamber cover, and soak the camera in fresh water for about ten minutes. Dry the camera thoroughly after removing it from the water.

■■Storage and Maintenance

QQDo not store at temperatures below 0°C (32°F) or above 40°C (104°F). QQTo ensure continued water resistance, it is recommended that you have the water-resistant

seal replaced about once a year (a fee is charged for this service). Contact your retailer or a FUJIFILM-authorized repair technician for more information.

■■Cold Climates

QQBattery performance drops at low temperatures, reducing the number of pictures that can be

taken. Insulate the camera to keep it warm or place it in your clothing. QQUse an NP-45A battery. QQDisplay response may slow at low temperatures. This is not a malfunction.

After Use

Remove any foreign matter from the water-resistant seal and adjacent surfaces. Foreign mat-

ter could damage the seal, lowering water resistance.

After using the camera underwater or in locations where foreign matter might adhere to the

camera body, rinse the camera under the tap or leave it in a basin of fresh water for two to

three minutes.

Liquid soaps, detergents, alcohol, and other cleansers may a ect water resistance and should

never be used.

After use, remove water droplets and foreign matter with a dry cloth,  rmly latch the battery-

chamber cover, and soak the camera in fresh water for about ten minutes. Dry the camera

thoroughly after removing it from the water.

Storage and Maintenance

Do not store at temperatures below 0°C (32°F) or above 40°C (104°F).

To ensure continued water resistance, it is recommended that you have the water-resistant

seal replaced about once a year (a fee is charged for this service). Contact your retailer or a

FUJIFILM-authorized repair technician for more information.

Cold Climates

Battery performance drops at low temperatures, reducing the number of pictures that can be

taken. Insulate the camera to keep it warm or place it in your clothing.

Use an NP-45A battery.

Display response may slow at low temperatures. This is not a malfunction.

xii

Table of Contents

Before You Begin

First Steps

Basic Photography and Playback

More on Playback

Playback Options .............................................................37

I Favorites: Rating Pictures .........................................37

Playback Zoom ...............................................................38

Multi-Frame Playback ....................................................39

A Deleting Pictures ......................................................40

b Image Search ............................................................41

k PhotoBook Assist......................................................42

Creating a PhotoBook.....................................................42

Viewing Photobooks ......................................................43

Editing and Deleting Photobooks ...................................43

Viewing Panoramas ........................................................44

Movies

Recording Movies ............................................................45

Viewing Movies ...............................................................47

Connections

Viewing Pictures on TV ...................................................48

Printing Pictures via USB ................................................49

Printing the DPOF Print Order.........................................51

Viewing Pictures on a Computer ....................................53

Windows: Installing MyFinePix Studio ...........................53

Macintosh: Installing FinePixViewer...............................55

Connecting the Camera ..................................................57

Menus

Using the Menus: Shooting Mode ..................................60

Using the Shooting Menu...............................................60

Shooting Menu Options .................................................60

A SHOOTING MODE ....................................................60

N ISO ........................................................................61

O IMAGE SIZE ............................................................62

T IMAGE QUALITY .....................................................63

P FINEPIX COLOR .......................................................63

D WHITE BALANCE ....................................................64

R CONTINUOUS .........................................................65

b FACE DETECTION .....................................................65

F AF MODE ...............................................................66

V MOVIE QUALITY .....................................................66

q LED ILLUMINATOR...................................................66

xiv

Using the Menus: Playback Mode ..................................67

Using the Pla

Playback Menu Options ..................................................67

yback Menu ...............................................67

k PHOTOBOOK ASSIST ................................................67

b IMAGE SEARCH ......................................................67

A ERASE ...................................................................67

N EDIT ......................................................................68

j MARK FOR UPLOAD TO ............................................69

I SLIDE SHOW ..........................................................70

B RED EYE REMOVAL .................................................71

D PROTECT ................................................................71

G CROP .....................................................................72

O RESIZE ...................................................................72

C IMAGE ROTATE .......................................................73

E COPY .....................................................................73

S TRANSITION ...........................................................74

L MOVIE TRIMMING ...................................................74

MOVIE JOIN ..................................................................75

K PRINT ORDER (DPOF) ..............................................75

Table of Contents

The Setup Menu ..............................................................76

Using the Setup Menu ....................................................76

Setup Menu Options ......................................................77

F DATE/TIME .............................................................77

N TIME DIFFERENCE ...................................................77

L a ......................................................77

o SILENT MODE .........................................................77

R RESET ....................................................................78

K FORMAT ................................................................78

A IMAGE DISP. ...........................................................78

B FRAME NO. ............................................................79

G OPERATION VOL. .....................................................80

H SHUTTER VOLUME ..................................................80

e SOUND ..................................................................80

I PLAYBACK VOLUME ................................................80

J LCD BRIGHTNESS ....................................................80

E LCD MODE .............................................................81

M AUTO POWER OFF ...................................................81

L DUAL IS MODE .......................................................81

B RED E

YE REMOVAL .................................................81

D DIGITAL ZOOM .......................................................82

n SAVE ORG IMAGE ....................................................82

c GUIDANCE DISPLAY ................................................82

Q VIDEO SYSTEM .......................................................83

Table of Contents

Technical Notes

Troubleshooting

Appendix

Technical Notes

Optional Accessories .......................................................84

Accessories from FUJIFILM..............................................85

Caring for the Camera .....................................................86

Storage and Use .............................................................86

Cleaning .........................................................................87

Traveling ........................................................................87

Troubleshooting

Problems and Solutions ..................................................88

Warning Messages and Displays ....................................94

Appendix

Tips and Tricks..................................................................98

Internal Memory/Memory Card Capacity ....................101

Speci cations ................................................................102

xvi

Before You Begin

Symbols and Conventions

Supplied Accessories

Attaching the Strap

Before You Begin

Symbols and Conventions

The following symbols are used in this manual: Q : This information should be read before use to ensure correct operation. R : Additional information that may be helpful when using the camera. P : Other pages in this manual on which related information may be found.

Menus and other text in the LCD monitor are shown in bold. In the illustra- tions in this manual, displays may be simpli ed for explanatory purposes.

Supplied Accessories

The following items are included with the camera:

NP-45A rechargeable

battery

• Strap

• User Guide

BC-45B battery charger USB cable CD-ROM (contains

Attaching the Strap

Attach the strap as shown.

this manual)

Parts of the Camera

For more information, refer to the page listed to the right of each item.

Selector button

Move cursor up

d (exposure compensation) button (P 32)

b (delete) button (P x)

MENU/OK button

Move cursor left

F (macro) button (P 33)

Move cursor down

h (self-timer) button (P 36)

2 Before You Begin

Move cursor right

N ( ash) button (P 34)

Parts of the Camera

The Indicator Lamp

Indicator lamp

Camera status

Glows green

Blinks green

Blinks green and orange

Glows orange

Blinks orange

Blinks red

1 Zoom control ...........................................................20, 38

2 Shutter button .............................................................. 21

3 ON/OFF button ............................................................. 16

4 Flash ............................................................................. 34

5 Self-timer lamp ............................................................ 36

LED illuminator ............................................................. 66

6 Lens/protective glass

7 Speaker ......................................................................... 47

8 Microphone .................................................................. 45

9 LCD monitor .................................................................... 4

10 t (movie recording) button ........................................ 45

11 Indicator lamp (see below)

* Press and hold the DISP/BACK button until o is displayed.

The Indicator Lamp

12 Strap eyelet ....................................................................1

13 Battery-chamber cover latch .....................................9, 12

14 Connector cover latch ........................................ 48, 49, 57

15 DISP (display)/BACK button .....................................6, 18

o (silent mode) button* ................................................x

16 a (playback) button................................................... 23

17 Tripod mount

18 USB multi-connector ...............................................49, 57

19 Memory card slot .......................................................... 11

20 Battery latch ............................................................10, 13

21 Battery chamber .............................................................9

The indicator lamp shows camera status as follows:

Indicator lamp

Glows green Focus locked.

Blinks green Blur, focus, or exposure warning. Picture can be taken.

Blinks green and orange Recording pictures. Additional pictures can be taken.

Glows orange Recording pictures. No additional pictures can be taken at this time.

Blinks orange Flash charging;  ash will not  re when picture is taken.

Blinks red Lens or memory error.

Camera status

3Before You Begin

Parts of the Camera

Camera Displays

10:00

250

4.5

12 / 31/ 2050

Camera Displays

The following types of indicator may be displayed during shooting and playback. Indicators vary with camera settings.

■ Shooting

7 Movie quality ................................................................ 45

12/31/2050

250

10:00

4.5

800

1 Shooting mode ............................................................. 24

2 Intelligent Face Detection indicator .............................. 29

3 Continuous shooting mode ........................................... 65

4 Silent mode indicator ................................................3, 77

5 Focus frame .................................................................. 30

6 Internal memory indicator

* a: indicates that no memory card is inserted and that pictures will be stored in the camera’s internal memory (P 11).

8 Number of available frames ........................................ 101

9 Sensitivity ..................................................................... 61

10 Image size and quality .............................................62, 63

11 FINEPIX color ................................................................ 63

12 White balance ............................................................... 64

13 Battery level ................................................................... 5

14 Dual IS mode ................................................................ 81

15 Exposure compensation ................................................ 32

16 Date and time ............................................................... 18

17 Blur warning ............................................................35, 94

18 Focus warning .........................................................21, 94

19 Self-timer indicator ...................................................... 36

20 Macro (close-up) mode ................................................. 33

21 Flash mode ................................................................... 34

4 Before You Begin

■ Playback

100-0001

400

10:00 AM

1 / 250

4.5

4:3

12 / 31/ 2050

Battery Level

Indicator

Description

100-0001

YouTube

12/31/2050 1/250

Battery Level

Battery level is shown as follows:

Indicator

D (white) C (white) B (red) A (blinks red)

10:00 AM

4.5

Battery partially discharged. Battery more than half discharged. Low battery. Charge as soon as possible. Battery exhausted. Turn camera o and charge battery.

4:3

400

Parts of the Camera

1 Playback mode indicator..........................................23, 37

2 Intelligent Face Detection indicator .........................29, 71

3 Red-eye removal indicator ............................................ 71

4 Portrait enhancer .......................................................... 25

5 Silent mode indicator ................................................3, 77

6 Gift image ..................................................................... 37

7 Frame number .............................................................. 79

8 Mark for upload to ........................................................ 69

9 Photobook assist........................................................... 42

10 Favorites ....................................................................... 37

11 DPOF print indicator ..................................................... 51

12 Protected image ........................................................... 71

Description

5Before You Begin

Parts of the Camera

Hiding and Viewing Indicators

Press DISP/BACK to cycle through shooting and playback indicators as follows:

• Shooting: Indicators displayed/indicators hidden/best framing

• Playback: Indicators displayed/indicators hidden/I favorites

6 Before You Begin

First Steps

Charging the Battery

The Charging Indicator

Charging indicator

Battery status

Action

O

Battery not inserted.

Insert the battery.

On (green)

Battery fully charged.

Remove the battery.

On (yellow)

Battery charging.

—

Blinks (yellow)

Battery fault.

Unplug the charger and remove the battery.

First Steps

Charging the Battery

The battery is not charged at shipment. Charge the battery before use.

Place the battery in the supplied battery charger.

Insert the battery in the orientation indicated by the CBD labels.

The camera uses an NP-45A rechargeable battery.

Plug the charger in.

Battery

CBD

label

Battery charger

CBD label

Plug the charger into a power outlet. The charging indicator will light.

The Charging Indicator

The charging indicator shows battery charge status as follows:

Charging indicator

O

On (green)

On (yellow)

Blinks (yellow)

Battery status

Battery not inserted.

Battery fully charged.

Battery charging.

Battery fault.

Action

Insert the battery.

Remove the battery.

—

Unplug the charger and remove the battery.

Arrow

Charging the Battery

Charge the battery.

Remove the battery when charging is complete. See the speci cations (P 106) for charging times (note that charging times increase at low temperatures).

Q Unplug the charger when it is not in use.

8 First Steps

Inserting the Battery and a Memory Card

Although the camera can store pictures in internal memory, optional SD, SDHC, and SDXC memory cards (sold separately) can be used to store additional pictures. After charging the battery, insert the battery and memory card as described below.

Open the battery-chamber cover.

Press the latch as shown.

R Be sure the camera is o before opening the

battery-chamber cover.

Q Do not open the battery-chamber cover

when the camera is on. Failure to observe this precaution could result in damage to image  les or memory cards.

Q Do not use excessive force when handling the battery-chamber cover. Q Remove water droplets and other foreign matter with a dry cloth before open-

ing the battery-chamber cover.

9 First Steps

Inserting the Battery and a Memory Card

Insert the battery.

Insert the battery with the terminal  rst and in the orientation shown by the label inside the battery chamber, keeping the battery latch pressed to one side. Con rm that the battery is securely latched.

Q Insert the battery in the correct orientation.

Do NOT use force or attempt to insert the battery upside down or backwards. The battery

will slide in easily in the correct orientation.

Battery latch

Label

10 First Steps

Insert the memory card.

Holding the memory card in the orientation shown at right, slide it in until it clicks into place at the back of the slot.

Q Be sure card is in the correct orientation; do

not insert at an angle or use force. If the memory card is not correctly inserted or no memory card is inserted, a will appear in the LCD monitor and internal memory will be used for recording and playback.

Q SD/SDHC/SDXC memory cards can be locked,

making it impossible to format the card or to record or delete images. Before inserting an SD/SDHC/SDXC memory card, slide the writeprotect switch to the unlocked position.

Inserting the Battery and a Memory Card

Click

Write-protect switch

11 First Steps

Inserting the Battery and a Memory Card

Con rming That the Cover Is Latched

Close the battery-chamber cover.

Before closing the cover, check to con rm that there is no dust, sand, or other foreign matter on the water-resistant seal or adjacent surfaces.

Con rming That the Cover Is Latched

• Con rm that the battery-chamber or connector cover does not protrude from the camera body.

• The covers are latched when the latches are in the positions shown below at left.

Latch indicator

Con rm that there

are no gaps.

Unlatched

Latched

12 First Steps

Inserting the Battery and a Memory Card

Removing the Battery and Memory Card

Before removing the battery or memory card, turn the camera o and press the latch to open the battery-chamber cover.

To remove the battery, press the battery latch to the side, and

Battery latch

slide the battery out of the camera as shown.

To remove the memory card, press it in and release it slowly. The card can then be removed by hand. When a memory card is removed, the card could come out of the slot too quickly. Use your  nger to hold it and gently release the card.

13 First Steps

Inserting the Battery and a Memory Card

QQMemory Cards

■ Compatible Memory Cards

FUJIFILM and SanDisk SD, SDHC, and SDXC memory cards have been approved for use in the camera. A complete list of approved memory cards is available at http://www.fujifilm.com/support/digital_cameras/compatibility/. Operation is not guaranteed with other cards. The camera can not be used with xD-Picture Cards or MultiMediaCard (MMC) devices.

Memory Cards

• Do not turn the camera o or remove the memory card while the memory card is being formatted or data are being recorded to or deleted from the card. Failure to observe this precaution

could damage the card.

• Format SD/SDHC/SDXC memory cards before  rst use, and be sure to reformat all memory cards after using them in a computer or other device. For more information on formatting memory cards, see “K FORMAT” (P 78).

• Memory cards are small and can be swallowed; keep out of reach of children. If a child swallows a memory card, seek medical assistance immediately.

• miniSD or microSD adapters that are larger or smaller than the standard dimensions of an SD/SDHC/SDXC card may not eject normally; if the card does not eject, take the camera to an authorized service representative. Do not forcibly remove the card.

• Do not a x labels to memory cards. Peeling labels can cause camera malfunction.

• Movie recording may be interrupted with some types of SD/SDHC/SDXC memory card. Use a G card or better when shooting HD movies.

14 First Steps

+ 96 hidden pages

FujiFilm XP20, 16124937 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
